HP90 H9S2GLR128 OR 228 08/13 page 1 of 3
© 2013 Koninklijke Philips N.V. All rights reserved.
Specifications are subject to change without notice.
www.philips.com/luminaires
Project:
Location:
Catalog No:
Fixture Type:
Mfg: Lamps: Qty:
Notes:
H9S2GLR128 OR 228
HP90
Ordering Guide
2' X 4' DIRECT/INDIRECT RECESSED FLUORESCENT
ACRYLIC LINEAR PRISMATIC LENS
STATIC, 1 OR 2 LAMP T5
HP90 combines a recessed contoured body with an enclosed linear
prismatic translucent lens to create an exciting highly efficient
direct/indirect luminaire.
Explanation of Catalog Number Example: H9S2GLR128UNVHI
HP90 Body
Style
Fixture
Width
Ceiling
Type
Lens
Type Reector Lamp
Qty
Lamp/
Fixture
Length
Voltage Ballast Type Options
H9 S 2 G L R 28
Direct/
Indirect
Recessed
S =
Static
2 = 2'Fits Both
Standard
Grid and
Slot Grid
L =
Acrylic
Lens
R =
Specular
Aluminum
1 =
1 Lamp
2 =
2 Lamp
(By Others)
28 = T5 28W
(Nominal 48")
UNV = 120/277V
120 = 120V
277 = 277V
347 = 347V
<10THD
PG 1 or 2 Lamp Elec. T5
Program Start
VY 1 or 2 Lamp Elec. T5
Program Start Step-Dim
WA 1 or 2 Lamp Elec. T5
Instant Start (120V or
277V Only)
PF 1 or 2 Lamp Elec. T5
LOL Dimming
NOTE: 347V. Emergency in T5/T5HO
Not Available. Please Consult Your
Philips Lighting Representative for
120V and 277V.
Add
Appropriate
Suffix to
Catalog No.
Highly efcient with
balanced
illumination
and versatility.
HP90 H9S2GLR128 OR 228 08/13 page 2 of 3
© 2013 Koninklijke Philips Electronics N.V. All rights reserved.
Specifications are subject to change without notice.
www.philips.com/luminaires
H9S2GLR128 OR 228
HP90
Features
• Can provide 54.6 maintained footcandles of
balanced brightness illumination at only .68 watts
per square foot.
• 87.2% efficient (1 lamp, 28W T5).
• 90.4% efficient (2 lamp, 28W T5).
• Direct/indirect appearance with soft
contoured interior.
• Lens encloses lamp compartment.
• Translucent DR acrylic linear prismatic lens.
• Tension screws secure ends to body.
• Same fixture fits both G and T ceiling types.
• Fits flush to face of slot grid (T) ceiling types.
• Lamp shield opens from either side.
• 95% reflective specular aluminum reflector.
• Ballast accessible from room side.
• Can be continuous row mounted.
• Wiring access plate standard.
• Optional DALI ballast iGEN TECHNOLOGY
accepts digital dimming controllers, scene
controllers and automatic control devices.
Specications
Performance: In an installation of 2 lamp 28W
luminaires in a room cavity ratio of 1, reflectance
80% ceiling, 50% wall, 20% floor, the C.U. shall not be
less than .94. To reduce glare the average brightness at
65° shall not exceed 2574 candelas per square meter.
To control veiling reflections, luminaire output in the
30°–90° zone shall not be less than 73.8%
Materials: Chassis parts are die-formed code
gauge steel.
Lamp Shield: Linear prismatic translucent DR
acrylic lens.
Finish: Chassis Exterior—Baked white acrylic enamel.
Cavity—baked flat white acrylic enamel. Phosphate
undercoating. Reflector—low iridescence specular
aluminum 95% reflectance.
Electrical: Thermally protected class “P” ballast
C.B.M. approved, non PCB. If K.O. is within 3" of
ballast, use wire suitable for at least 90°. UL Listed for
damp locations.
Labels: I.B.E.W./UL and ULc Listed.
This product may have a mercury containing lamp.
Manage in accord with Disposal Laws.
See: www.lamprecycle.org
Options/Accessories
Electrical/Wiring Options: Consult your Philips
Lighting representative.
Fusing: Internal fast-blow fusing. Suffix: F.
Drywall Kit: Order catalog number: FK92X4.
Dimensions Mounting Methods
Fully Enclosed
Lamp Compartment
Built-in Earthquake Clips
2½"
(64mm)
2" x 2½" Access Plate
with (2) ⅞" dia. K.O.
48" (1219mm)
Exposed Slot T-grid Ceiling
Exposed T-bar
by Others
1⅞"
Max. Acoustical
material
by Others
9/16"
24"
1½"
Max.
15/16"
24"
Acoustical
Material
by Others
Exposed T-bar
by Others
Exposed T-grid Ceiling
* For ush mounting when using 9/16"
Exposed T-Grid ceiling system consult
your Philips Lighting representative
5" (127mm)
24" (610mm)
5"
(127mm)
HP90 H9S2GLR128 OR 228 08/13 page 3 of 3
© 2013 Koninklijke Philips N.V. All rights reserved.
Specifications are subject to change without notice.
www.philips.com/luminaires
Philips Lighting Company
200 Franklin Square Drive
Somerset, NJ 08873
Phone: 855-486-2216
Philips Lighting Company
281 Hillmount Road
Markham ON, Canada L6C 2S3
Phone: 800-668-9008
H9S2GLR128 OR 228
HP90
Performance
Model No. H9S2GLR128UNVPG
Model No. H9S2GLR228120WA
Coefficients of Utilization
Ceiling 80% 50% 30%
Wall 70 50 30 50 30 10 50 30 10
RCR Zonal Cavity Method—
Effective Floor Cavity Reflectance = 0.20
Room Cavity Ratio
1
2
3
4
5
6
7
8
9
10
95
86
79
72
66
61
57
53
50
47
91
79
70
62
55
50
45
41
38
35
87
73
62
54
47
42
38
34
31
28
85
74
66
58
52
47
43
40
36
34
82
70
60
52
46
41
37
33
30
28
80
66
55
47
41
36
32
29
26
24
82
71
63
56
51
46
42
39
36
33
79
68
58
51
45
40
36
33
30
27
77
64
54
47
41
36
32
28
26
23
Coefficients of Utilization
Ceiling 80% 50% 30%
Wall 70 50 30 50 30 10 50 30 10
RCR Zonal Cavity Method—
Effective Floor Cavity Reflectance = 0.20
Room Cavity Ratio
1
2
3
4
5
6
7
8
9
10
98
89
81
74
68
63
58
54
50
47
94
81
71
63
56
50
46
42
38
35
90
75
63
55
48
42
38
34
31
28
88
76
67
59
53
48
43
40
37
34
85
71
61
53
46
41
37
33
30
27
82
67
56
47
41
36
32
28
25
23
84
73
64
57
51
46
42
39
36
33
82
69
59
51
45
40
36
32
30
27
79
66
55
47
40
35
31
28
25
23
Zonal Lumen Summary
Zone Lumens % Lamp % Fixt
0–30
0–40
0–60
0–90
90–180
0–180
690
1115
1892
2398
0
2398
25.1
40.5
68.8
87.2
0.0
87.2
28.8
46.5
78.9
100.0
0.0
100.0
Zonal Lumen Summary
Zone Lumens % Lamp % Fixt
0–30
0–40
0–60
0–90
90–180
0–180
1520
2445
3423
3496
0
3496
26.3
42.9
60.1
61.3
0.0
61.3
43.0
69.9
97.9
100.0
0.0
100.0
Luminance Data in Candela/Sq. Meter
Average
in Deg.
Average
0 Deg.
Average
45 Deg.
Average
90 Deg.
45
55
65
75
85
1143.
1000.
772.
538.
313.
1020.
919.
859.
965.
486.
1035.
1009.
1137.
1340.
439.
Luminance Data in Candela/Sq. Meter
Average
in Deg.
Average
0 Deg.
Average
45 Deg.
Average
90 Deg.
45
55
65
75
85
2152.
1970.
1739.
1403.
850.
2401.
2256.
2206.
2396.
1200.
2468.
2382.
2574.
2682.
1000.
LER = FP–75.8IW–31.55BF–1.0
Comparative yearly lighting energy cost per
1000 lumens = $3.16
Report Number: G2006156
Catalog Number: H9S2GLR128UNVPG
Lamp: (1) F28 T5
Luminaire: HP90 2' x 4' with linear
prismatic lens.
Ballast: QTP 2X28 T5/UNV-PSN
Report is based on 2610 lumens per lamp.
Efficiency: 87.2%
CIE Type: Direct-Indirect
Plane: 0 Deg. 90 Deg.
Spacing Criteria: 1.3 1.2
Shielding Angles: 90 90
Plane: 0 Deg. 90 Deg.
Luminous Length: 47.760 23.760
LER = FP–84.3IW–54.6BF–0.93
Comparative yearly lighting energy cost per
1000 lumens = $2.85
Report Number: G2006010
Catalog Number: H9S2GLR228120WA
Lamp: (1) F28 T5
Luminaire: HP90 2' x 4' with linear
prismatic lens.
Ballast: WA
Report is based on 2610 lumens per lamp.
Efficiency: 90.4%
CIE Type: Direct-Indirect
Plane: 0 Deg. 90 Deg.
Spacing Criteria: 1.2 1.4
Shielding Angles: 90 90
Plane: 0 Deg. 90 Deg.
Luminous Length: 46.800 22.800
Candela Distribution
Candela Distribution
Angle 0.0 45.0 90.0 FLUX
0
5
15
25
35
45
55
65
75
85
90
833
825
801
752
677
562
399
227
97
19
2
833
832
817
754
638
502
367
253
174
29
2
833
840
825
746
625
509
403
334
241
27
2
80
230
346
403
397
341
266
179
36
Angle 0.0 45.0 90.0 FLUX
0
5
15
25
35
45
55
65
75
85
90
1481
1471
1421
1298
1131
921
673
412
191
40
3
1481
1474
1429
1344
1219
1061
872
659
424
63
3
1481
1478
1446
1398
1301
1175
1006
803
490
41
3
140
404
620
763
814
767
629
394
77
