General information, technical data
HERZ-Thermostatic valves
Thermostatic heads and valves marked with the CENCER mark
of conformity in the HERZ-Product Range have been tested ac-
cording to EN 215.
The maximum permissible differential pressure for all HERZ-
Thermostatic valves is 0.6 bar, with the exception of dimensions
3/4 and 1 with 0.4 bar and HERZ-TS-90-E and HERZ-TS-E with
0.2 bar.
In order to reduce noise during operation the differential pressure
should be determined in accordance with the “VDMA Instruction
Sheet for Planning and Hydraulic Balancing of Heating Systems
with Thermostatic Radiator Valves” (max. 0.2 bar).
Universal models
HERZ-Radiator valves and threaded radiator connections of
sizes 3/8 – 3/4 are universal models with special sockets, except
HERZ-TS-E and HERZ-RL-1-E. They are suitable for connecting
threaded pipes with a pipe thread and copper, soft steel or plas-
tic pipes, the latter three by means of a compression union.
The same applies to STRÖMAX, STRÖMAX-D, STRÖMAX-M,
STRÖMAX-R 1/2. A special adapter is available for dimension
3/4.
The corresponding tables show the wide variety of compression
unions.
Standard models
HERZ-AS and radiator connections 1 and 1, HERZ-TS-valves
1, as well as HERZ-TS-E-valves are standard models with
threaded sockets for threaded pipes.
Nickel-plated and Brass Versions
Unless otherwise stated, HERZ-Fittings and HERZ-Distributor
connection systems are supplied with a nickel-plated surface.
Pipe ttings are mainly installed in boiler houses or in riser mains.
Unless otherwise stated, these valves are supplied in brass ver-
sion.
Technical Data
for all HERZ-Fittings
Maximum operating temperature TS 120 °C
Maximum operating pressure PS 10 bar
These values are valid unless otherwise stated in the article
description.
Hot water quality according Austrian Standard ÖNORM H 5195
and/or VDI-Regulation 2035.
Storage temperature (not installed) – 40 °C until 60 °C.
for compression unions for metal pipes.
When using compression unions for copper and steel pipes,
take into account the permissible temperature and pressure rat-
ings according to EN 1254-2:1998, Table 5.
for plastic pipe connections
Plastic pipe connections are suitable for application classes
4 and 5 according ISO 10508 (panel heating and radiator
connection) as well as for pipes made of PE-RT (DIN 4721),
PE-MDX (DIN 4724), PB and PE-X (DIN 4726) as well as lastic
composite tubes (ÖNORM B 5157).
Operating temperature, resulting thereof: maximum 95 °C with
10 bar. It is the operators task, to regulate the operating pres-
sure Poper and the operating temperature Toper in such a way
that they are conforming to standards and that operational data
of the pipe producer are respected.
Any deviations from this data are specially mentioned in the
technical documentation.
Hand Wheel Colours
Hand wheels and plastic components are white, in case of pipe
ttings they are red. When colours are different, this is specially
mentioned. Special colours are available upon enquiry.
Documentation
Brochures, standard sheets and tender data sheets are avail-
able for all HERZ-Products and product groups. Your HERZ-
Representatives will be glad to supply these materials upon
request.
Order number
The seven-digit numbers include the former four-digit article
number in bold print. The order number denes the valve to
be ordered in terms of series, dimension, colour and model
and is suitable for electronic data processing. You are kindly
requested to use this number in your orders in order to rule out
any confusion.
ean, VKE
The European Article Number (ean) is a thirteen-digit number
featuring the country and manufacturer code – ean 90 04174, as
well as the product code and check digit.
The ean is valid for one unit or one invoicing unit and not for the
sales units (VKE = Verkaufseinheiten) specied. We will be glad
to send you the ean list for sales units (VKE) upon request.
ARA
HERZ Armaturen is a licensee of the Austrian waste-recycling
corporation (“Altstoff Recycling Austria Aktiengesellschaft“)
registered under licence number 2102. The waste disposal
charge is paid on the basis of the licensing agreement.
Modications
HERZ Armaturen reserves the right to make modications
necessitated by technological progress and/or market
requirements, and to supply modied products without prior
notice.
Tentative standard DIN V3838 “Euro cone”,
threaded connection G 3/4 A with inner cone
As the currently valid provisional standard, DIN V3838, can still
be altered up to the time when the denitive standard comes
into force, and the period up to when all products on offer
correspond to the standard is not known, a mix of products
from different manufacturers for the connection of ttings and
compression adapters should be avoided for reasons of safety
if any doubts should arise about their compatibility HERZ offers
a comprehensive pipe connection programme and guarantees
that current as well as future developments of HERZ compression
connections are always an exact t with HERZ ttings, so that
combination with other brands of product is not necessary.
As HERZ cannot assume any guarantee for other brands of
products, combinations with other manufacturers’ products are
outside the HERZ guarantee.
Images
It is understood that images in the HERZ product ranges are
symbolic representations and may therefore differ visually from
the actual products.
ISO 9001
Certication
HERZ Armaturen Ges.m.b.H., A–1230V Vienna, has an effective
quality management system in all divisions of the business,
suitable for upholding all-important trust from customers. Proof
has been furnished that the requirements according to ÖNORM
EN ISO 9001:2000 are fullled.
