INNERSHIELD®WIRES

Self-Shielded, Flux-Cored Wires

2

About The Lincoln

Electric Company

Innershield wire by Lincoln Electric is one of the most user-friendly,

convenient, versatile wires on earth. This exceptionally feedable

and consistent wire includes shielding, slagging and deoxidizing

materials built right in to its inner core. That means no external gas

bottles or flux on the job! It’s a superb choice for bridges, offshore

drilling rigs, and other outside welding applications where winds are

a factor.

• Shielding, slagging and deoxidizing materials are built right in to

the inner core.

• No need for external gas or flux.

• Many Innershield wires to choose from – a perfect wire for every

application.

• One of the most user-friendly welding processes on the market

today.

• A great choice for use in moderately windy conditions.

• As with all of our wires, Innershield’s arc characteristics are out-

standing! That’s because we pay more attention to chemistry,

quality of raw materials, and manufacturing processes than any

wire manufacturer in the world!

• Best of all, Innershield is designed and built by Lincoln Electric.

Our company is all about innovative thinking – about listening

and responding to the needs of welding professionals – about

finding ways to make welding quicker, stronger, and more

efficient.

Advantage Lincoln

More precise control. Innershield’s open arc process allows the

operator to control the placement of the weld metal and the pud-

dle with exceptional accuracy.

More consistent weld deposits. Innershield performs better

because Innershield is built better. The best raw materials, The

best manufacturing processes. The best quality control systems.

Lincoln Electric is the world’s premier

manufacturer of welding equipment and

consumables. No company on earth is

more focused on the ever-changing

needs of the welding

professional. Our business is all about

helping companies make their welding

operations more effective, more

efficient, more profitable.

Lincoln is truly your “One Source” when

it comes to welding. We’re a company

that continually rededicates itself to the

equally important goals of exceptional

quality, and exceptional service. Our

field support team –– with hundreds of

field sales engineers and thousands of

knowledgeable and responsive Lincoln

distributors in countries all over the

world –– is the

largest in the industry.

Innovative thinking. A quality and

service-first attitude. Fresh

approaches to design, manufacturing,

and packaging. Worldwide strength.

That’s Lincoln Electric.

Lincoln’s Innershield®Wire

3

www.lincolnelectric.com

Contents Page

Product Introduction . . . 2-3

Electrode Selection

Guide . . . . . . . . . . . . . . . 4-5

High Speed Single

Pass Welding . . . . . . . .6-11

General Purpose

Welding . . . . . . . . . . . .12-17

Structural Fabrication

Welding . . . . . . . . . . . .18-37

Pipe Fabrication . . . . .38-41

Agency Approvals . . . . . .42

Storing Innershield

Electrodes . . . . . . . . . . . .43

Versatility. No matter what welding positions your job requires, there’s

an Innershield wire specifically designed to handle it. We’ve provided

individual wire descriptions in this brochure that will make it easy for

you to choose the right Innershield product for your needs.

Better portability. Because Innershield is completely self-contained –

with shielding, slagging and deoxidizing materials built right in to the

wire’s core – there’s no need for flux feeding systems or gas bottles.

That means increased portability of your rigs, and more efficient weld-

ing operations.

Better feedability. We’ve coated Innershield wire with specially

designed lubricants that keep the wire feeding beautifully – inch after

inch, coil after coil.

Typical Applications

Innersheld wire is a great choice for a wide range of applications,

including:

• Automotive

• Truck & Trailers

• Construction, Farm & Mining Equipment

• Bridges

• Buildings

• Storage Tanks

• Ships & Barges

• Offshore Oil Drilling Platforms

• Pipelines

• Structural Fabrication

• Maintenance & Repair

Electrode AWS General Page

Name Classification Description No.

Innershield NR-1 & NR-5 E70T-3 Good for high speed flat and horizontal single pass automatic 6-7

welding applications, especially circumferential welds with

overlapping. Recommended for materials with a thickness

not greater than 3/16” (4.8mm).

Innershield NR-131 E70T-10 For automatic and semiautomatic high speed, single pass 8-9

welding on sheet metal with a thickness of .11” (2.8mm) or

more. A solid performer for twin arc welding applications,

especially in flat, horizontal, and automatic roundabout

positions. Good deposition rates and travel speeds.

Innershield NR-152 E71T-14 Designed for high speed, single pass automatic and 10-11

semiautomatic welding on materials from .030 - 3/16”

(0.8 - 4.8mm). A good choice for bare, galvanized, specialty

zinc-coated, Galvanneal, aluminized, or carbon steels.

Innershield NR-202 E71T-7 Excellent for all position welding. Can make very small welds 12-13

at high travel speeds. Cost-effective tacking wire than can

join carbon steel with other higher strength steels.

Innershield NR-211-MP E71T-11 Versatile wire suitable for all position welding of light gauge 14-15

steel or thin plate up to 1/2” (12.7mm). Low spatter

and excellent weld appearance make it a favorite with

operators.

Innershield NR-212 E71TG-G A good choice for general purpose, all position welding. 16-17

Produces smooth welds with excellent appearance. Designed

for single and multiple pass semiautomatic and automatic

welding of mild steel, sheet metal, plate and coated steel.

Low spatter level. Handles poor fit-up well.

Innershield NR-203M(1) E71T-8J Use in flat, horizontal, vertical up and overhead positions on 18-19

mild and low alloy steels. Good arc action and low spatter.

Meets minimum Charpy V-Notch properties for seismic

applications.

Innershield NR-203MP(1) E71T-8J Great for all position, single and multiple pass welding with 20-21

mild steel and some low alloy steels. Handles poor fit-up on

heavy wall tubes and gaps up to 3/8” (9.5mm) with 1/4”

(6.4mm) offset. Meets minimum Charpy V-Notch properties

for seismic applications.

Innershield NR-203 E71T8-Ni1 Use for all position, single and multiple pass welding on mild 22-23

Nickel (1%)(1) steel and some low alloy steels. Performs well in automatic

and semiautomatic applications. Produces a nickel bearing

weld deposit with Charpy V-Notch properties at low

temperatures. Can weld gaps up to 3/8” (9.5mm). Meets

minimum Charpy V-Notch properties for seismic applications.

4

INNERSHIELD®ELECTRODE SELECTION GUIDE

High Speed Single Pass Welding

General Purpose Welding

Structural Fabrication Welding

(1) Meets minimum Charpy V-Notch properties recommended in the “Seismic Provisions for Structural Steel Buildings” by

AISC, dated April 15, 1997.

5

Electrode AWS General Page

Name Classification Description No.

Innershield NR-203 E61T8-K6 Designed for single and multiple pass welding in automatic 24-25

Nickel C and semiautomatic applications. Good for low temperature

alloys. Produces a nickel bearing weld deposit with good

Charpy V-Notch properties at low temperatures.

Innershield NR-203 E71T8-K2 Similar to NR-203 Nickel C, but with increased capability 26-27

Ni C Plus(1) to join higher strength steels. Handles poor fit-up in the

vertical up position and welds gaps up to 1/4” (6.4mm)

with offsets up to 1/4” (6.4mm).

Innershield NR-232(1) E71T-8 A popular choice because of its high deposition rates with 28-29

out-of-position welding. Designed for single and multiple

pass welding of 3/16” (4.8mm) and heavier mild steel,

as well as some low alloy steels. Self-peeling slag.

Excellent Charpy V-Notch properties.

Innershield NR-305(1) E70T-6 Great for downhand welding applications where high 30-31

deposition rates and good penetration are desired. Designed

for use with mild steel and some low alloy steels on single

and multiple pass, automatic and semiautomatic welding.

Excellent operator appeal.

Innershield NR-311 E70T-7 Very high deposition rates and fast travel speeds. Welds 32-33

thicker mild steels and some low alloy steels. Good bead

shape and easy slag removal. Resists weld cracking.

Innershield NR-311 Ni(1) E70T7-K2 Similar to NR-311, but with Charpy V-Notch properties. 34-35

Designed for downhand, flat and horizontal welding on

1/8” (3.2mm) and thicker mild steel and some low alloy

steels. High deposition rates and fast travel speeds.

Produces a 1.5% nickel deposit for good low temperature

notch toughness. Good Charpy V-Notch properties.

Innershield NS-3M E70T-4 Extremely high deposition rate wire designed for automatic 36-37

and semiautomatic welding on mild steel and some low

alloy steels. Resistant to cracking on high sulfur steel

and porosity on mildly rusty, oily or dirty plates.

Soft, low penetrating arc.

Innershield NR-207 & E71T8-K6 Optimum performance on vertical down, hot, fill and cap 38-39

NR-207-H passes on standard cross-country pipelines and arctic

grade pipe. Excellent crack resistance and CTOD and

Charpy V-Notch properties. Meets API Pipe Grade X42

and X70 requirements.

Innershield NR-208-H E91T8-G Similar to NR-207-H, but with lower hydrogen and higher 40-41

strength. Produces weld deposits exceeding 80,000 psi

yield strength with excellent low temperature impacts.

Meets API Pipe Grade X80 requirements.

INNERSHIELD®ELECTRODE SELECTION GUIDE

Structural Fabrication Welding - Cont’d

Pipe Fabrication

(1) Meets minimum Charpy V-Notch properties recommended in the “Seismic Provisions for Structural Steel Buildings” by

AISC, dated April 15, 1997.

www.lincolnelectric.com

600 Lb. 600 Lb.

Diameter Speed Feed®Speed Feed

Inches (mm) Drum Reel

NR-1

.120 (3.0) EDS12150

5/32 (4.0) EDS12153

NR-5

3/32 (2.4) ED012699 ED012701

.120 (3.0) ED012696 ED012698

Transverse

Tensile Strength Longitudinal Hardness

psi (MPa) Bend Test Rockwell B

Requirements 70,000 (480) 180º over 3/4” Radius --

AWS E70T-3 min. No openings exceeding 1/8”

Test Results 72,000 - 79,000 Passed 95

Typical NR-1 (496 - 545)

Test Results 73,000 - 81,000 Passed 99

Typical NR-5 (503 - 558)

6

1G

2F

2G

Great choices for flat and horizontal

single pass automatic welds on sheet

metal with a thickness of 3/16”

(4.8mm) or less.

Both electrodes are built to perform in

high speed automatic welding applica-

tions. NR-1 is especially designed for

circumferential welds where the

weld’s finish overlaps its start.

A constant voltage power source is

recommended.

ADVANTAGE LINCOLN

• Self-shielded, flux-cored. No need

for external gas or flux.

• Produces quality welds in moderate

wind conditions with no tenting.

• Designed for high travel speeds –

up to 170 inches (4.3m) per minute.

• Our quality driven manufacturing

system – certified to ISO 9002 – and

our exceptionally high grade raw

materials mean every coil of

Innershield delivers great arc char-

acteristics and superior feedability.

TYPICAL APPLICATIONS

NR-1

• Straight welds.

• Roundabouts that overlap the start.

• Through welds on material up to 12

gauge.

• Joints susceptible to slag trapping.

NR-5

• 3-o’clock position welds.

• Can also be used for welds that

require 100% penetration with

copper back-up.

• NR-5 (3/32”) diameter can slso be

used in semiautomatic applications.

WELDING POSITIONS

INNERSHIELD NR®-1 & NR-5 AWS A5.20-95: E70T-3

CONFORMANCE

AWS A5.20-95: E70T-3

ASME SFA-5.20: E70T-3

DIAMETERS / PACKAGING

MECHANICAL PROPERTIES - As Welded per AWS A5.20

NOTES:

• NR-1 and NR-5 are not recom-

mended for welding steel that is

more than 3/16” (4.8mm) thick.

• NR-1 and NR-5 are also not recom-

mended for welding that requires

multiple passes.

%C %Mn %P %S %Si %Al %Ti

Requirements

AWS E70T-3 Not Required

per A5.20

Test Results(1)

.21 1.30 .007 .014 .59 .03 .15

NR-1

Test Results(1)

.19 .88 .006 .017 .33 .08 .33

NR-5

Wire, Polarity Wire Feed Arc Approx. Melt-Off Deposition

Electrical Stickout Speed Voltage Current Rate Rate Efficiency

Wire Weight in/min (m/min) (volts) (amps) lbs/hr (kg/hr) lbs/hr (kg/hr) (%)

.120” NR-1 160 (4.1) 21 - 22 500 25.2 (11.4) 22.0 (10.0) 87

DC+ 200 (5.1) 22 - 23 610 31.6 (14.3) 28.0 (12.7) 89

1-1/4” (32mm) 240 (6.1) 23 - 24 700 37.9 (17.2) 33.0 (15.0) 87

2.63 lbs/1000” 295 (7.5) 24 - 25 810 46.5 (21.1) 40.0 (18.1) 86

320 (8.1) 25 - 26 850 50.5 (23.0) 43.0 (19.5) 85

5/32” NR-1 100 (2.5) 21 - 22 630 24.0 (10.9) 19.2 (8.7) 80

DC+ 110 (2.8) 22 - 23 680 26.4 (12.1) 21.2 (9.6) 80

1-1/8 – 1-3/8” 130 (3.3) 23 - 24 780 31.2 (14.2) 25.4 (11.5) 81

(28-35mm) 150 (3.8) 24 - 25 860 36.0 (16.3) 29.5 (13.4) 82

4.07 lbs/1000” 180 (4.6) 25 - 26 960 43.2 (20.1) 35.7 (16.2) 83

3/32” NR-5 100 (2.5) 22 - 23 500 9.9 (4.5) 7.8 (3.5) 77

DC+ 150 (3.8) 23 - 24 435 14.8 (6.7) 12.3 (5.6) 83

1” (25mm) 200 (5.1) 24 - 25 510 19.8 (9.0) 16.9 (7.7) 85

1.60 lbs/1000” 250 (6.4) 25 - 26 575 24.7 (11.2) 21.4 (9.7) 87

.120” NR-5 130 (3.3) 22 - 23 500 18.0 (8.2) 16.7 (7.6) 93

DC+ 165 (4.2) 23 - 24 600 23.0 (10.4) 20.9 (9.5) 91

1” (25mm) 205 (6.5) 24 - 25 700 28.5 (12.9) 25.6 (11.6) 90

2.46 lbs/1000” 255 (6.5) 25 - 26 800 35.5 (16.1) 31.5 (14.3) 90

7

www.lincolnelectric.com

NOTE: Because of the exceptionally high arc speeds, welding parameters, joint positioning, and electrode wire placement critically affect the weld

results, publication C3.2410 should be consulted for important variables that must be controlled for depositing consistently acceptable welds of NR-1.

These are typical operating procedures and are not intended to serve as specific procedures for any applications.

INNERSHIELD NR-1 & NR-5

TYPICAL OPERATING PROCEDURES

DEPOSIT COMPOSITION

(1) Chemistry of single pass welds is highly dependent upon base metal chemistry and dilution.

Analysis shown are for information purposes only.

600 Lb. 600 Lb.

Diameter 50 Lb. Speed Feed®Speed Feed

Inches (mm) Coil Reel Drum

NR-131

3/32 (2.4) EDS12162 ED012163

8

1G

2F

2G

Use NR-131 Innershield wire for auto-

matic and semiautomatic high speed,

single pass welds on sheet metal with

a thickness of .11” (2.7mm) or more.

Designed to perform well in twin-arc

welding applications, especially in flat,

horizontal, and automatic roundabout

positions.

A constant voltage power source is

recommneded.

ADVANTAGE LINCOLN

• Self-shielded, flux-cored. No need

for external gas or flux.

• Produces quality welds in moderate

wind conditions with no tenting.

• Excellent deposition rates.

• High travel speeds.

• A great choice for welds that join

light steel to heavier members.

Transverse

Tensile Strength Longitudinal Hardness

psi (MPa) Bend Test Rockwell B

Requirements 70,000 (480) 180º over 3/4” Radius

AWS E70T-10 min. No opening exceeding 1/8” --

Test Results 73,000 - 82,000 Passed 90

(503 - 565)

TYPICAL APPLICATIONS

Single Arc:

• 1/8” (3.2mm) and 3/16” (4.8mm)

fillet welds with travel speeds up to

75 in/min (1.9 m/min).

Twin Arc:

• 1/4” (6.4mm) and 5/16” (8.0mm) fil-

let welds with travel speeds up to 75

in/min (1.9 m/min).

• An excellent performer on fillets and

laps. NR-131 is also a good choice

for corner, edge and butt joints.

NOTES:

• NR-131 should not be used for

applications requiring Charpy V-

Notch properties.

WELDING POSITIONS

INNERSHIELD NR-131 AWS A5.20-95: E70T-10

CONFORMANCE

AWS A5.20-95: E70T-10

ABS: E70T-10

DIAMETERS / PACKAGING

MECHANICAL PROPERTIES - As Welded per AWS A5.20

• Our quality driven manufacturing

system – certified to ISO 9002 – and

our exceptionally high grade raw

materials mean every coil of

Innershield delivers great arc char-

acteristics and superior feedability.

%C %Mn %P %S %Si %Al

Requirements

AWS E70T-10 .23 .45 /006 .004 .25 1.17

per A5.20

Test Results(1) .252 .53 .008 .009 .21 1.55

Wire, Polarity Wire Feed Arc Approx. Melt-Off Deposition

Electrical Stickout Speed Voltage Current Rate Rate Efficiency

Wire Weight in/min (m/min) (volts) (amps) lbs/hr (kg/hr) lbs/hr (kg/hr) (%)

3/32” 150 (3.8) 25 - 26 390 14.3 (6.5) 11.6 (5.3) 81

Single Arc DC- 200 (5.1) 25 - 27 490 19.0 (8.6) 15.6 (7.1) 82

1-1/4” (32mm) 250 (6.4) 26 - 27 570 23.7 (10.8) 19.6 (8.9) 82

1.580 lbs/1000” 350 (8.9) 26 - 28 720 33.1 (15.0) 27.6 (12.5) 83

425 (10.8) 27 - 28 810 40.1 (18.2) 33.6 (15.2) 83

3/32” 130 (3.3) 25 - 26 550 24.5 (11.1) 17.9 (8.1) 72

Twinarc DC- 175 (4.4) 26 - 27 740 33.0 (15.0) 26.4 (12.0) 79

1-1/2” (38mm) 225 (5.7) 26 - 28 910 42.5 (19.3) 34.8 (15.8) 81

3.160 lbs/1000” 275 (7.0) 27 - 29 1030 51.9 (23.5) 42.0 (19.1) 80

325 (8.3) 28 - 30 1090 61.4 (27.9) 48.2 (21.9) 78

9

(1) Chemistry of single pass welds is highly dependent upon base metal chemistry and dilution.

Analysis shown are for information purposes only.

NOTE: NR-131 will not produce weld deposits meeting the minimum Charpy V-Notch properties

recommended in the “Seismic Provisions for Structural Steel Buildings” by AISC, dated April 15,

1997. For these and other applications specifying notch toughness, the following Innershield elec-

trodes should be considered: NR-203MP, NR-203 Nickel C Plus, NR-203 Nickel (1%), NR-232,

NR-305, NR-311 Ni.

INNERSHIELD NR-131

TYPICAL OPERATING PROCEDURES

DEPOSIT COMPOSITION

www.lincolnelectric.com

NOTE: These are typical operating procedures and are not intended to serve as specific procedures for any applications.

10

1G

2F

2G

NR-152 is an excellent wire for auto-

matic and semiautomatic welding on

steels including bare, galvanized,

specialty zinc-coated, Galvanneal®(1),

aluminized, or carbon.

Designed for high speed, single pass

welding on materials from .030” to

3/16” (1.2mm - 4.8mm).

A constant voltage power source is

recommended.

Transverse

Tensile Strength Longitudinal Hardness

psi (MPa) Bend Test Rockwell B

Requirements 72,000 (497) 180º over 3/4” Radius

AWS E71T-14 min. No opening exceeding 1/8” --

Test Results 72,000 - 82,000 Passed 93

(496 - 565)

WELDING POSITIONS

ADVANTAGE LINCOLN

• Self-shielded, flux-cored. No need

for external gas or flux.

• Produces quality welds in moderate

wind conditions with no tenting.

• A great choice for coated steels.

• NR-152’s exceptionally soft arc

means less burnthrough on thin

gauge materials.

• An operator favorite!

NOTES:

• NR-152 should not be used for

applications requiring Charpy V-

Notch properties.

• The preferred drag angle is 15º.

However, NR-152 is capable of

welding at zero drag angle, facilitat-

ing easy fixturing in automatic

applications.

500 Lb 600 Lb. 600 Lb.

Diameter 25 Lb. 50 Lb. Speed Feed®Speed Feed Speed Feed

Inches (mm) Spool Coil Drum Drum Reel

.045 (1.1) EDS01702

.052 (1.3) EDS01703

.062 (1.6) EDS01021 ED012185 ED024301

.068 (1.7) ED012186 ED019580 ED019579

5/64 (2.0) EDS12187 ED024265

INNERSHIELD NR-152 AWS A5.20-95: E71T-14

DIAMETERS / PACKAGING

MECHANICAL PROPERTIES - As Welded per AWS A5.20

CONFORMANCE

AWS A5.20-95: E71T-14

• Excellent overlapping capabilities.

Use NR-152 for roundabouts, or to

repair itself.

• Fast, sure restarts with no end

clipping necessary.

• Our quality driven manufacturing

system – certified to ISO 9002 – and

our exceptionally high grade raw

materials mean every coil of

Innershield delivers great arc char-

acteristics and superior feedability.

TYPICAL APPLICATIONS

• Spot or stitch welds up to .030”

(0.8mm) thick sheet metal.

• Continuous welds on .048” (1.2mm)

in a travel speed range of 40-60

in/min (1.0-1.5m/min).

• Continuous welds on coated steels

in a travel range of 30-40 in/min

(0.7-1.0 m/min).

(1) Galvanneal is a registered trademark of Keystone Consolidated Industries, Inc., Peoria, IL.

%C %Mn %P %S %Si %Al

Requirements

AWS E71T-14 Not Required

per A5.20

Test Results(1)

.062 .30 .99 .013 .007 .24 1.63

.068 .30 .91 .009 .011 .25 1.55

5/64 .26 .82 .008 .015 .21 1.07

Wire, Polarity Wire Feed Arc Approx. Melt-Off Deposition

Electrical Stickout Speed Voltage Current Rate Rate Efficiency

Wire Weight in/min (m/min) (volts) (amps) lbs/hr (kg/hr) lbs/hr (kg/hr) (%)

.045” 60 (1.5) 15 - 16 95 1.3 (0.5) 1.1 (0.5) 84

DC- 90 (2.3) 16 - 17 135 2.1 (0.9) 1.8 (0.8) 85

3/8” (10mm) 120 (3.0) 17 - 18 160 2.8 (1.2) 2.5 (1.1) 89

.392 lbs/1000” 150 (3.8) 18 - 19 180 3.4 (1.5) 3.1 (1.4) 91

.052” 55 (1.4) 16 - 17 100 1.7 (0.7) 1.6 (0.7) 94

DC- 90 (2.3) 17 - 18 150 2.6 (1.1) 2.4 (1.1) 92

3/8” (10mm) 110 (2.8) 18 - 19 170 3.5 (1.5) 2.9 (1.3) 82

.500 lbs/1000” 130 (3.3) 19 - 20 190 3.8 (1.7) 3.5 (1.6) 92

.062” 30 (0.8) 13 - 14 90 1.3 (0.5) 1.2 (0.5) 92

DC- 40 (1.0) 14 - 15 115 1.8 (0.8) 1.6 (0.7) 88

3/8” (10mm) 50 (1.3) 15 - 16 140 2.2 (0.9) 2.0 (0.9) 90

.736 lbs/1000” 70 (1.8) 16.5 - 17.5 185 3.1 (1.4) 2.8 (1.3) 90

110 (2.8) 19 - 20 265 4.8 (2.1) 4.4 (2.0) 91

.068” 30 (0.8) 13 - 14 68 1.6 (0.7) 1.4 (0.6) 87

DC- 40 (1.0) 13.5 - 14.5 95 2.2 (0.9) 1.9 (0.9) 86

1/2” (13mm) 50 (1.3) 14.5 - 15.5 120 2.7 (1.2) 2.4 (1.1) 88

.910 lbs/1000” 60 (1.5) 15.5 - 16.5 145 3.3 (1.4) 2.9 (1.3) 87

80 (2.0) 16.5 - 17.5 190 4.4 (1.9) 3.9 (1.8) 88

110 (2.8) 20 - 21 240 6.0 (2.7) 5.4 (2.4) 90

5/64” 40 (1.0) 16 - 17 125 2.8 (1.2) 2.5 (1.1) 89

DC- 70 (1.8) 18 - 19 230 4.8 (2.1) 4.3 (1.9) 89

3/4” (19mm) 80 (2.0) 19 - 20 260 5.5 (2.4) 4.9 (2.2) 89

1.15 lbs/1000” 100 (2.5) 21 - 22 310 6.9 (3.1) 6.1 (2.7) 88

125 (3.2) 24 - 25 355 8.6 (3.9) 7.6 (3.4) 88

11

(1) Chemistry of single pass welds is highly dependent upon base metal chemistry and dilution.

Analysis shown are for information purposes only.

INNERSHIELD NR-152

TYPICAL OPERATING PROCEDURES

DEPOSIT COMPOSITION

www.lincolnelectric.com

NOTE: These are typical operating procedures and are not intended to serve as specific procedures for any applications.

Diameter 14 Lb. 50 Lb.

Inches (mm) Coil Coil

5/64 (2.0) ED012287 ED012288

12

1G

2F

2G

3G

➔

4G

5G

➔

Innershield NR-202 is a cost-effective

wire that produces consistently good

looking weld beads.

Designed for semiautomatic welding.

An excellent tacking wire.

A constant voltage power source is

recommended.

Yield Strength Tensile Strength Elongation Hardness

psi (MPa) psi (MPa) (%) Rockwell B

Requirements 58,000 (400) 70,000 (480) 22 --

AWS E71T-7 min. min. min.

Test Results 60,000 - 75,000 72,000 - 95,000 22 - 27 87 - 93

(414 - 517) (497 - 655)

WELDING POSITIONS

• Smaller diameter wires are generally

used for out-of-position.

• Larger diameter wires are generally

used for flat and horizontal welding.

TYPICAL APPLICATIONS

• Structural fabrication where no seis-

mic requirements are present.

• Vertical and overhead plate welding.

• Fabrication of machinery parts and

hoppers.

• Short assembly welds on brackets

and clips.

• Roundabout groove welds.

NOTES:

• NR-202 should not be used for

applications requiring Charpy V-

Notch properties.

ADVANTAGE LINCOLN

• Self-shielded, flux-cored. No need

for external gas or flux.

• Produces quality welds in moderate

wind conditions with no tenting.

• A great wire to use when cost is a

primary issue, and no impact prop-

erties are required.

(1) The strength and elongation properties reported were obtained from a .505” tensile specimen artificially aged at

220°F (104°C) for 48 hours, as permitted by AWS A5.20-95. A naturally aged tensile specimen may take

months to achieve the specified properties. See AWS A5.20-95, paragraph A8.3. The time required for the

natural aging of weld deposits is dependent upon ambient conditions, weldment geometry, the metallurgical

structure of the weld deposit and other factors.

INNERSHIELD NR-202 AWS A5.20-95: E71T-7

DIAMETERS / PACKAGING

MECHANICAL PROPERTIES(1) - As Welded per AWS A5.20

CONFORMANCE

AWS A5.20-95: E71T-7

ABS: E71T-7

• Our quality driven manufacturing

system – certified to ISO 9002 – and

our exceptionally high grade raw

materials mean every coil of

Innershield delivers great arc char-

acteristics and superior feedability.

Wire, Polarity Wire Feed Arc Approx. Melt-Off Deposition

Electrical Stickout Speed Voltage Current Rate Rate Efficiency

Wire Weight in/min (m/min) (volts) (amps) lbs/hr (kg/hr) lbs/hr (kg/hr) (%)

.068” 55 (1.4) 19 - 20 130 2.8 (1.3) 1.7 (0.8) 61

DC- 100 (2.5) 20 - 21 190 5.0 (2.3) 3.7 (1.7) 74

1” (25mm) 150 (3.8) 21 - 22 245 7.6 (3.4) 6.0 (2.7) 79

.842 lbs/1000” 175 (4.4) 22 - 23 270 8.8 (4.0) 7.1 (3.2) 81

210 (5.3) 23 - 24 300 10.6 (4.8) 8.7 (3.9) 82

50 (1.3) 19 - 20 150 3.4 (1.5) 2.0 (0.9) 59

5/64” 100 (2.5) 20 - 21 235 6.8 (3.1) 5.1 (2.3) 75

DC- 150 (3.8) 21 - 22 305 10.2 (4.6) 8.3 (3.8) 81

1” (25mm) 175 (4.4) 22 - 23 335 11.9 (5.4) 9.9 (4.5) 83

1.09 lbs/1000” 200 (5.1) 22 - 23 365 13.6 (6.2) 11.4 (5.2) 84

230 (5.8) 23 - 24 400 15.7 (7.1) 13.3 (6.0) 85

13

%C %Mn %P %S %Si %Al

Requirements

AWS E71T-7 Report 1.75 .03 .03 .60 1.80

per A5.20-95 Only max. max. max. max. max.

Test Results .19 .72 .007 .003 .20 1.34

NOTE: NR-202 will not produce weld deposits meeting the minimum Charpy V-Notch properties

recommended in the “Seismic Provisions for Structural Steel Buildings” by AISC, dated April 15,

1997.For these and other applications specifying notch toughness, the following Innershield elec-

trodes should be considered: NR-203MP, NR-203 Nickel C Plus, NR-203 Nickel (1%), NR-232,

NR-305, NR-311 Ni.

INNERSHIELD NR-202

TYPICAL OPERATING PROCEDURES

DEPOSIT COMPOSITION

www.lincolnelectric.com

NOTE: These are typical operating procedures and are not intended to serve as specific procedures for any applications.

300 Lb. 600 Lb

Diameter 1 Lb 10 Lb 14 Lb 25 Lb 50 Lb 50 Lb. Speed-Feed Speed-Feed®

Inches (mm) Spool Spool Coil Readi-Reel®Coil Readi-Reel Reel Reel

.035 (0.9) ED027641 ED016354 ED016364

.045 (1.1) ED016363 ED016365 EDS01040 EDS01522

.068 (1.7) ED012506 ED017827 ED012507

5/64 (2.0) ED012508 ED017828 ED012509

3/32 (2.4) ED013869 EDS14358

14

1G

2F

2G

3G

➔

4G

One of our most popular all-purpose

Innershield wires.

A terrific choice for light gauge steel

or thin plate. Performs well on coated

steels.

Restricted to 1/2” (12.7mm) maxi-

mum plate thickness for .068, 5/64”

and 3/32” diameters, and 5/16”

(7.9mm) maximum plate thickness for

.035 and .045 diameters.

A constant voltage power source is

recommended.

Yield Strength Tensile Strength Elongation Hardness

psi (MPa) psi (MPa) (%) Rockwell B

Requirements 58,000 (400) 70,000 (480) 20 --

E71T-11 min. min. min.

Test Results 58,000 - 69,000 72,000 - 95,000 22 - 25 85 - 95

Typical NR-211MP (400- 476) (497 - 655)

TYPICAL APPLICATIONS

• Single or multiple pass welding.

• Structural fabrication where no seis-

mic requirements are present.

• Robotic welding applications.

• Fabrication and repair of machinery

parts, trucks, auto bodies, saddles,

tanks and hoppers.

• Welding on racks, scaffolding, light

angle structurals, joists, and small

roundabout applications.

NOTES:

• NR-211-MP should not be used for

applications requiring Charpy V-

Notch properties.

RECOMMENDED

MAXIMUM PLATE THICKNESS

Diameter Max. Plate

Inches (mm) Thickness

.035 & .045 5/16”

(0.9 & 1.1) (7.9mm)

.068, 5/64, & 3/32 1/2”

(1.7, 2.0 & 2.4) (12.7mm)

ADVANTAGE LINCOLN

• Self-shielded, flux-cored. No need

for external gas or flux.

• Produces quality welds in moderate

wind conditions with no tenting.

• An extremely popular wire with

excellent operator appeal, low spat-

ter, and good weld appearance.

• NR-211-MP is an extremely versa-

tile wire – suitable for all position

welding.

(1) The strength and elongation properties reported were obtained from a .505” tensile specimen artificially

aged at 220°F (104°C) for 48 hours, as permitted by AWS A5.20-95. A naturally aged tensile specimen

may take months to achieve the specified properties. See AWS A5.20-95, paragraph A8.3. The time

required for the natural aging of weld deposits is dependent upon ambient conditions, weldment

geometry, the metallurgical structure of the weld deposit and other factors.

INNERSHIELD NR-211-MP AWS A5.20-95: E71T-11

DIAMETERS / PACKAGING

MECHANICAL PROPERTIES(1) - As Welded per AWS A5.20

CONFORMANCE

AWS A5.20-95: E71T-11

ASME SFA-5.20: E71T-11

ABS: E71T-11 (.068 - 3/32” only)

CWB: E4801T-11-CH

WELDING POSITIONS

• A good choice when poor fitup is an

issue.

• Our quality driven manufacturing

system – certified to ISO 9002 – and

our exceptionally high grade raw

materials mean every coil of

Innershield delivers great arc char-

acteristics and superior feedability.

15

www.lincolnelectric.com

Wire, Polarity Wire Feed Arc Approx. Melt-Off Deposition

Electrical Stickout Speed Voltage Current Rate Rate Efficiency

Wire Weight in/min (m/min) (volts) (amps) lbs/hr (kg/hr) lbs/hr (kg/hr) (%)

.035” 50 (1.3) 14 - 15 30 0.8 (0.4) 0.7 (0.3) 81

DC- 70 (1.8) 15 - 16 60 1.2 (0.5) 1.0 (0.5) 83

3/8” (10mm) 90 (2.3) 16 - 17 90 1.7 (0.8) 1.4 (0.6) 82

.250 lbs/1000” 110 (2.8) 16.5 - 17.5 120 2.1 (1.0) 1.7 (0.8) 81

.045” 70 (1.8) 15 - 16 120 1.6 (0.7) 1.1 (0.5) 69

DC- 90 (2.3) 16 - 17 140 2.2 (1.0) 1.7 (0.8) 77

3/8” (10mm) 110 (2.8) 17 - 18 160 2.7 (1.2) 2.3 (1.0) 85

.393 lbs/1000” 130 (3.3) 18 - 19 170 3.2 (1.5) 2.7 (1.2) 84

.068” 40 (1.0) 15 - 16 125 2.1 (1.0) 1.7 (0.8) 81

DC- 75 (1.9) 18 - 19 190 4.0 (1.8) 3.4 (1.5) 85

1/2 - 1” (13 - 25mm) 130 (3.3) 20 - 21 270 7.0 (3.2) 6.1 (2.8) 88

.889 lbs/1000” 175 (4.4) 23 - 24 300 9.4 (4.3) 8.4 (3.8) 89

5/64” 50 (1.3) 16 - 17 180 3.5 (1.6) 2.9 (1.3) 83

DC- 75 (1.9) 18 - 19 235 5.3 (2.4) 4.5 (2.0) 85

1/2 - 1” (13 - 25mm) 120 (3.0) 20 - 21 290 8.4 (3.8) 7.4 (3.4) 88

1.17 lbs/1000” 160 (4.1) 22 - 23 325 11.2 (5.1) 10.0 (4.5) 89

3/32” 50 (1.3) 16 - 17 245 5.0 (2.3) 4.2 (1.9) 84

DC- 75 (1.9) 19 - 20 305 7.5 (3.4) 6.4 (2.9) 85

1/2 - 1” (13 - 25mm) 100 (2.5) 20 - 21 365 10.0 (4.5) 8.7 (3.9) 87

1.66 lbs/1000” 130 (3.3) 22 - 23 400 12.9 (5.9) 11.3 (5.1) 88

%C %Mn %P %S %Si %Al

Requirements

AWS E71T-11 Report 1.75 .03 .03 .60 1.8

per A5.20 Only max. max. max. max. max.

Test Results .21 - .30 .45 - .65 .005 - .012 .003 - .010 .10 - .25 1.20 - 1.80

(.068, 5/64, 3/32)

(.035 & .045) .21 .50 - .75 .003 - .010 .001 - .008 .10 - .25 1.20 - 1.80

INNERSHIELD NR-211-MP

TYPICAL OPERATING PROCEDURES

DEPOSIT COMPOSITION

NOTE: NR-211MP will not produce weld deposits meeting the minimum Charpy V-Notch impact properties

recommended in the “Seismic Provisions for Structural Steel Buildings” by AISC, dated April 15, 1997. For

these and other applications specifying notch toughness, the following Innershield electrodes should be

considered: NR-203MP, NR-203Nickel C Plus, NR-203 Nickel (1%), NR-232, NR-305, NR-311 Ni.

NOTE: These are typical operating procedures and are not intended to serve as specific procedures for any applications.

16

1G

2F

2G

3G

➔

4G

An excellent general purpose, all posi-

tion wire for automatic and semiauto-

matic applications.

Designed for single and multiple pass

welding on mild steel, sheet metal and

plate. Also performs well on coated

steel.

A constant voltage power source is

recommended.

ADVANTAGE LINCOLN

• Self-shielded, flux-cored. No need

for external gas or flux.

• Produces quality welds in moderate

wind conditions with no tenting.

• A good choice when poor fitup is an

issue.

• NR-212 is an extremely versatile

wire. Weld in any position, on a

wide range of materials including

coated steel. Not recommended for

vertical up.

• Alternative to NR-211-MP when

thicker applications are involved.

Yield Strength Tensile Strength Elongation

psi (MPa) psi (MPa) (%)

Requirements 58,000 (400) 70,000 - 90,000 20

AWS E71TG-G min. (480 - 620) min. min.

Test Results 67,500 (465) 86,200 (594) 27

Typical NR-212

TYPICAL APPLICATIONS

• Single or multiple pass, all position

welding on materials 1.1mm and

thicker.

• Can be used on weathering steels

where a color match is important.

• Structural fabrication where no seis-

mic requirements are present.

• Short assembly welds.

• Coated steel welds.

• Fabrication and repair of truck bod-

ies, tanks, hoppers, racks, scaffold-

ing and light angle structurals.

• Robotic applications.

• Our quality driven manufacturing

system – certified to ISO 9002 –

and our exceptionally high grade

raw materials mean every coil of

Innershield delivers great arc char-

acteristics and superior feedability.

(1) The strength and elongation properties reported were obtained from a .505” tensile

specimen artificially aged at 220°F (104°C) for 48 hours, as permitted by AWS A5.29-80.

A naturally aged tensile specimen may take months to achieve the specified properties.

See AWS A5.20-95, paragraph A8.3. The time required for the natural aging of weld

deposits is dependent upon ambient conditions, weldment geometry, the metallurgical

structure of the weld deposit and other factors.

Diameter 10 Lb. 14 Lb. 25 Lb. 50 Lb.

Inches (mm) Spool Coil Readi-Reel®Coil

.045 (1.1) ED026090 ED026091

.068 (1.7) ED027803 ED026859 ED026861

5/64 (2.0) ED027794 ED026860 ED026858

3/32 (2.4) (See your local Lincoln Representative for packaging information for 3/32” .)

INNERSHIELD NR-212 AWS A5.29-98: E71TG-G

DIAMETERS / PACKAGING

MECHANICAL PROPERTIES(1) - As Welded per AWS A5.29

CONFORMANCE

AWS A5.29-98: E71TG-G

ASME SFA-5.29: E71TG-G

WELDING POSITIONS

NOTES:

• NR-212 should not be used for

applications requiring Charpy V-

Notch properties.

Wire, Polarity Wire Feed Arc Approx. Melt-Off Deposition

Electrical Stickout Speed Voltage Current Rate Rate Efficiency

Wire Weight in/min (m/min) (volts) (amps) lbs/hr (kg/hr) lbs/hr (kg/hr) (%)

55 (1.4) 14 - 15 75 1.3 (0.6) 1.1 (0.5) 84

.045” 70 (1.8) 15 - 16 90 1.6 (0.7) 1.4 (0.6) 87

DC- 90 (2.3) 16 - 17 115 2.1 (0.9) 1.8 (0.8) 85

3/8” (10mm) 110 (2.8) 17 - 18 135 2.6 (1.2) 2.2 (1.0) 84

.393 lbs/1000” 130 (3.3) 18 - 19 155 3.1 (1.4) 2.6 (1.2) 83

150 (3.8) 19 - 20 170 3.5 (1.6) 3.0 (1.4) 85

60 (1.5) 16 - 17 145 3.1 (1.4) 2.4 (1.1) 77

.068” 75 (1.9) 18 - 19 180 3.8 (1.7) 3.2 (1.4) 84

DC- 90 (2.3) 19 - 20 200 4.5 (2.0) 3.8 (1.7) 84

3/4” (19mm) 120 (3.0) 20 - 21 230 6.0 (2.7) 5.2 (2.3) 86 .

820 lbs/1000” 150 (3.8) 21 - 22 255 7.4 (3.3) 6.4 (2.9) 86

175 (4.4) 22 - 23 275 8.7 (3.9) 7.5 (3.4) 86

60 (1.5) 16 - 17 200 3.8 (1.7) 3.3 (1.5) 86

5/64” 75 (1.9) 18 - 19 225 4.7 (2.1) 4.1 (1.8) 87

DC- 90 (2.3) 19 - 20 245 5.7 (2.6) 5.0 (2.3) 87

3/4” (19mm) 110 (2.8) 20 - 21 275 7.1 (3.2) 6.2 (2.8) 87

1.064 lbs/1000” 130 (3.3) 21 - 22 300 8.3 (3.7) 7.3 (3.3) 87

150 (3.8) 22 - 23 325 9.6 (4.3) 8.4 (3.8) 87

3/32” 75 (1.9) 19 - 20 270 7.3 (3.3) 6.2 (2.8) 84

DC- 100 (2.5) 21 - 22 330 9.8 (4.4) 8.5 (3.8) 86

1” (25mm) 125 (3.2) 23 - 24 375 12.3 (5.5) 10.7 (4.8) 86

1.583 lbs/1000” 150 (3.8) 25 - 26 420 14.9 (6.7) 12.6 (5.7) 84

17

www.lincolnelectric.com

NOTE: NR-212 will not produce weld deposits meeting the minimum Charpy V-Notch impact properties

recommended in the “Seismic Provisions for Structural Steel Buildings” by AISC, dated April 15, 1997.

For these and other applications specifying notch toughness, the following Innershield electrodes should

be considered: NR-203MP, NR-203 Nickel C Plus, NR-203 Nickel (1%), NR-232, NR-305, NR-311 Ni.

INNERSHIELD NR-212

TYPICAL OPERATING PROCEDURES

NOTE: These are typical operating procedures and are not intended to serve as specific procedures for any applications.

NOTE: In order to meet the alloy requirements of the G group, the weld deposit needs to have

the minimum, as specified in the table, of only one of the elements marked with an asterisk.

%C %Mn* %P %S %Si* %Al %Ni*

Requirements

AWS E71TG-G Report 1.75 .04 .03 .80 1.8 .50

per A5.29 Only min. max. max. max. max. max.

Test Results .10 .97 .007 .003 .31 1.52 1.10

DEPOSIT COMPOSITION

Diameter 14 Lb 50 Lb

Inches (mm) Coil Coil

5/64 (2.0) ED012295 ED012296

3/32 (2.4) ED012294

Charpy V-Notch

Yield Strength Tensile Strength Elongation ft-lbs (Joules) Hardness

psi (MPa) psi (MPa) (%) @ -20°F (-29°C) @ -40°F (-40°C) Rockwell B

Requirements 58,000 (400) 70,000 (480) 22 20 (27) --

AWS E71T-8 min. min. min. min. --

58,000 (400) 70,000 (480) 22 20 (27) --AWS E71T-8J min. min. min. -- min.

Test Results 60,000 - 69,000 72,000 - 83,000 22 - 30 120 - 160 130 -150 86

(414 - 476) (496 - 572 ) (161 - 215) (175 - 201)

Stress Relieved(3) 53,000 - 55,000 68,000 - 70,000 28 - 31 75 - 120 -- --

(365 - 379) (469 - 480) (102 - 163) --

18

ADVANTAGE LINCOLN

• Self-shielded, flux-cored. No need

for external gas or flux.

• Produces quality welds in moderate

wind conditions with no tenting.

• Easy slag removal.

• Our quality driven manufacturing

system – certified to ISO 9002 – and

our exceptionally high grade raw

materials mean every coil of

Innershield delivers great arc char-

acteristics and superior feedability.

Designed for flat, horizontal, vertical

up and overhead position welding.

A good choice for automatic and

semiautomatic applications. Performs

well on mild steel and some low alloy

steels.

Meets Charpy V-Notch properties.(1)

A constant voltage power source is

recommended.

TYPICAL APPLICATIONS

• General plate fabrication, including

bridge construction, hull plate and

stiffener welding on ships and

barges.

• Fabrication of storage tanks.

• A good fast freeze electrode for verti-

cal up and overhead welding. (We

recommend the use of NR-203MP

where vertical down is necesary.)

• Performs well on out-of-position

groove welds – especially on large

diameter, heavy wall tubular con-

struction.

(1)Will meet minimum Charpy V-Notch

properties recommended in the

“Seismic Provisions for Structural

Steel Buildings” by AISC, dated April

15, 1997.

1G

2F

4G

2G

5G

➔

3G

➔

(2) The strength and elongation properties reported were obtained from a .505” tensile specimen artificially aged at 220°F (104°C) for 48 hours, as

permitted by AWS A5.20-95. A naturally aged tensile specimen may take months to achieve the specified properties. See AWS A5.20-95, para-

graph A8.3. The time required for the natural aging of weld deposits is dependent upon ambient conditions, weldment geometry, the metallurgical

structure of the weld deposit and other factors.

(3) Stress relieved 1 hour at 1150°F (621°C).

INNERSHIELD NR-203M AWS A5.20-95: E71T-8J

DIAMETERS / PACKAGING

MECHANICAL PROPERTIES(2) - As Welded per AWS A5.20

CONFORMANCE

AWS A5.20-95: E71T-8 & E71T-8J

ASME SFA-5.20: E71T-8 & E71T-8J

ABS: 3SA-3YSA

Lloyd’s: 3S-3YS

CWB: E4801T-8-CH

WELDING POSITIONS

The opacity of NR-203M slag to x-ray is such that slag inclusions will normally appear lighter than the weld.

Voids will normally appear darker than the weld. When using gamma-radiography, slag inclusions and voids will

normally appear darker than the weld. Improved x-ray film readability usually can be obtained by slight over-

exposure at an excitation potential consistent with good x-ray practice, but not over 240 KV. For detailed

information on welding techniques, procedure adjustments, and their effects on weld appearance and quality,

request publication C3.2400 “Innershield Electrode - Semiautomatic Production Welding Guide”.

19

www.lincolnelectric.com

Wire, Polarity Wire Feed Arc Approx. Melt-Off Deposition

Electrical Stickout Speed Voltage Current Rate Rate Efficiency

Wire Weight in/min (m/min) (volts) (amps) lbs/hr (kg/hr) lbs/hr (kg/hr) (%)

5/64” 50 (1.3) 16 - 17 145 3.2 (1.5) 2.5 (1.1) 78

DC- 70 (1.8) 17 - 18 180 4.5 (2.0) 3.4 (1.5) 76

3/4” (19mm) 90 (2.3) 18 - 19 220 5.8 (2.6) 4.4 (2.0) 76

1.07 lbs/1000” 140 (3.6) 21 - 22 300 9.0 (4.1) 6.7 (3.0) 74

3/32” 50 (1.3) 16 - 17 200 4.7 (2.1) 3.5 (1.6) 74

DC- 95 (2.4) 20 - 21 310 8.9 (4.0) 6.7 (3.0) 75

3/4” (19mm) 110 (2.8) 21 - 22 330 10.3 (4.7) 7.8 (3.5) 76

1.56 lbs/1000” 120 (3.0) 22 - 23 350 11.2 (5.1) 8.8 (3.9) 79

%C %Mn %P %S %Si %Al

Requirements

AWS E71T-8 Report 1.75 .03 .03 .60 1.8

per A5.20 only max. max. max. max. max.

Test Results .08 1.50 .010 .005 .25 .80

RADIOGRAPHIC GUIDELINES

INNERSHIELD NR-203M

TYPICAL OPERATING PROCEDURES

DEPOSIT COMPOSITION

NOTE: These are typical operating procedures and are not intended to serve as specific procedures for any applications.

Charpy V-Notch

Yield Strength Tensile Strength Elongation ft-lbs (Joules) Hardness

psi (MPa) psi (MPa) (%) @ -20°F (-29°C) @-40°F (-40°C) Rockwell B

Requirements 58,000 (400) 70,000 (480) 22 20 (27) Not

AWS E71T-8J min. min. min. min. Specified --

Test Results 60,000 - 65,000 72,000 - 80,000 28 - 31 50 - 200 66 82 - 92

Typical NR-203MP (414 - 448) (496 - 552) (68 - 271) (90)

Diameter 10 Lb 14 Lb 22 Lb 50 Lb

Inches (mm) Spool Coil Readi-Reel®Coil

.040 (1.0)(1) EDS25039

.068 (1.7) ED025041 ED025040 ED025042

5/64 (2.0) ED021604 ED021601

3/32 (2.4)

20

Designed for all position, single and

multiple pass welding including vertical

down.

Performs well in automatic and semi-

automatic applications. Appropriate

for use on mild steel and some low

alloy steels.

A constant voltage power source is

recommended.

Meets Charpy V-Notch properties(1).

• Makes root beads in groove welds

without backup bars.

• Our quality driven manufacturing

system – certified to ISO 9002 – and

our exceptionally high grade raw

materials mean every coil of

Innershield delivers great arc char-

acteristics and superior feedability.

TYPICAL APPLICATIONS

• General plate fabrication, including

bridge construction, hull plate and

stiffener welding on ships and

barges.

• Fabrication of storage tanks.

• Structural fabrication, including appli-

cations involving seismic require-

ments(1).

(1)Will meet minimum Charpy V-Notch

properties recommended in the

“Seismic Provisions for Structural

Steel Buildings” by AISC, dated April

15, 1997.

ADVANTAGE LINCOLN

• Self-shielded, flux-cored. No need

for external gas or flux.

• Produces quality welds in moderate

wind conditions with no tenting.

• Fast freezing slag system facilitates

all position welding, including verti-

cal down.

• Handles poor fit-up on heavy wall

tubes. Gaps up to 3/8” (9.5mm)

with 1/4” (6.35mm) offset are weld-

able with NR-203MP.

1G

2F

4G

2G

3G

➔

5G

➔

3G

➔

(1) The strength and elongation properties reported were obtained from a .505” tensile specimen artificially aged at 220°F (104°C)

for 48 hours, as permitted by AWS A5.20-95. A naturally aged tensile specimen may take months to achieve the specified

properties. See AWS A5.20-95, paragraph A8.3. The time required for the natural aging of weld deposits is dependent upon

ambient conditions, weldment geometry, the metallurgical structure of the weld deposit and other factors.

(1) Manufactured in metric diameter, U.S. customary size approximate.

INNERSHIELD NR-203MP AWS A5:20-95: E71T-8J

DIAMETERS / PACKAGING

MECHANICAL PROPERTIES(1) - As Welded per AWS A5.20

CONFORMANCE

AWS A5.20-95: E71T-8J

ASME SFA-5.20: E71T-8J

ABS: 3SA-3YSAH15

Lloyd’s: 3S-3YH15

DNV: III YMSH15

GL: 3YSH15

BV: SA3YMH

NK: KSW53NH10

WELDING POSITIONS

Wire, Polarity Wire Feed Arc Approx. Melt-Off Deposition

Electrical Stickout Speed Voltage Current Rate Rate Efficiency

Wire Weight in/min (m/min) (volts) (amps) lbs/hr (kg/hr) lbs/hr (kg/hr) (%)

.068” 70 (1.8) 16 - 17 145 3.3 (1.5) 2.3 (1.0) 69

DC- 90 (2.3) 18 - 19 180 4.2 (1.9) 3.2 (1.5) 76

3/4” (19mm) 120 (3.0) 20 - 21 225 5.6 (2.5) 4.3 (2.0) 76

.782 lbs/1000” 140 (3.5) 21 - 22 255 6.4 (2.9) 4.8 (2.2) 75

150 (3.8) 23 - 24 265 6.8 (3.1) 5.1 (2.3) 75

50 (1.3) 16 - 17 130 3.1 (1.4) 1.9 (0.9) 61

5/64” 70 (1.8) 18 - 19 180 4.3 (2.0) 2.9 (1.3) 67

DC- 90 (2.3) 19 - 20 220 5.6 (2.5) 4.2 (1.9) 75

3/4” (19mm) 110 (2.8) 20 - 21 260 6.8 (3.1) 5.3 (2.4) 77

1.032 lbs/1000” 120 (3.0) 21 - 22 280 7.4 (3.4) 5.9 (2.7) 79

140 (3.6) 22 - 23 310 8.7 (3.9) 6.8 (3.1) 78

3/32” 50 (1.3) 18 - 19 210 4.4 (2.0) 3.3 (1.5) 75

DC- 70 (1.8) 19 - 20 260 6.2 (2.8) 4.8 (2.2) 77

3/4” (19mm) 95 (2.4) 21 - 22 320 8.4 (3.8) 6.6 (3.0) 78

1.46 lbs/1000” 110 (2.8) 22 - 23 350 9.7 (4.4) 7.7 (3.5) 79

130 (3.3) 23 - 24 390 11.4 (5.2) 9.1 (4.1) 79

21

www.lincolnelectric.com

%C %Mn %P %S %Si %Al

Requirements

AWS E71T-8J Report 1.75 .03 .03 .60 1.8

per A5.20 only max. max. max. max. max.

Test Results .075 1.45 <.010 <.003 .33 .80

INNERSHIELD NR-203MP

TYPICAL OPERATING PROCEDURES

DEPOSIT COMPOSITION

The opacity of NR-203MP slag to x-ray is such that slag inclusions will normally appear lighter than the weld.

Voids will normally appear darker than the weld. When using gamma-radiography, slag inclusions and voids will

normally appear darker than the weld. Improved x-ray film readability usually can be obtained by slight over-

exposure at an excitation potential consistent with good x-ray practice, but not over 240 KV. For detailed

information on welding techniques, procedure adjustments, and their effects on weld appearance and quality,

request publication C3.2400 “Innershield Electrode - Semiautomatic Production Welding Guide”.

RADIOGRAPHIC GUIDELINES

NOTE: These are typical operating procedures and are not intended to serve as specific procedures for any applications.

Diameter 14 Lb Coil 50 Lb

Inches (mm) (56 Lb. Carton) Coil

5/64 (2.0) ED012385 ED012386

3/32 (2.4) ED012383 ED012384

22

Designed for all position, single and

multiple pass welding including vertical

down on mild steel and some low

alloy steels. Performs well in automatic

and semiautomatic applications.

Produces a nickel bearing weld

deposit with good Charpy V-Notch

properties at low temperatures(1).

A constant voltage power source is

recommended.

ADVANTAGE LINCOLN

• Self-shielded, flux-cored. No need

for external gas or flux.

• Produces quality welds in moderate

wind conditions with no tenting.

• Produces a nickel weld deposit (.80

- 1.1% Ni).

• Handles poor fit-up in the vertical up

position. Welds gaps up to 3/8”

(9.5mm).

1G

2F

4G

2G

5G

➔

3G

➔

3G

➔

Charpy V-Notch

Yield Strength Tensile Strength Elongation ft-lbs (Joules)

psi (MPa) psi (MPa) (%) @ -20°F (-29°C) @ -40ºF (-40ºC)

Requirements 58,000 min. 70,000 - 90,000 20 20 (27) Not

AWS E71T8-Ni1 (400) (483 - 620) min. min. Specified

Test Results 66,000 - 75,000 72,000 - 85,000 20 - 30 24 - 111 42 - 87

(455 - 517) (496 - 585) (33 - 151) (57 - 118)

Stress-Relieved(2) 61,000 - 70,000 67,000 - 74,000 27 - 30 70 - 99

(421 - 483) (462 - 510) (95 - 134)

(1) The strength and elongation properties reported were obtained from a .505” tensile specimen artificially aged at 220°F (104°C)

for 48 hours, as permitted by AWS A5.29-80. A naturally aged tensile specimen may take months to achieve the specified

properties. See AWS A5.20-95, paragraph A8.3. The time required for the natural aging of weld deposits is dependent upon

ambient conditions, weldment geometry, the metallurgical structure of the weld deposit and other factors.

(2) Stress relieved 1 hour at 1150°F (621°C).

• Makes root beads in groove welds

without backup bars.

• Our quality driven manufacturing

system – certified to ISO 9002 – and

our exceptionally high grade raw

materials mean every coil of

Innershield delivers great arc char-

acteristics and superior feedability.

TYPICAL APPLICATIONS

• Roundabout groove welds on heavy

wall tubular construction

• Offshore welding applications.

• A good choice for use on weathering

steels where color match is impor-

tant.

• Bridges and other outdoor structural

components with weathering steel.

(1)Will meet minimum Charpy V-Notch

properties recommended in the

“Seismic Provisions for Structural

Steel Buildings” by AISC, dated April

15, 1997.

INNERSHIELD NR-203 NICKEL (1%) AWS A5.29-98: E71T8-Ni1

DIAMETERS / PACKAGING

MECHANICAL PROPERTIES(1) - As Welded per AWS A5.29

WELDING POSITIONS

CONFORMANCE

AWS A5.29-98: E71T8-Ni1

ASME SFA-5.29: E71T8-Ni1

ABS: 3SA-3YSA

Lloyd’s: 3S-3YSH15

DNV: III YMSH15

Wire, Polarity Wire Feed Arc Approx. Melt-Off Deposition

Electrical Stickout Speed Voltage Current Rate Rate Efficiency

Wire Weight in/min (m/min) (volts) (amps) lbs/hr (kg/hr) lbs/hr (kg/hr) (%)

50 (1.3) 16 - 17 145 3.0 (1.4) 2.3 (1.0) 76

5/64” 70 (1.8) 18 - 19 195 4.3 (2.0) 3.3 (1.5) 76

DC- 90 (2.3) 19 - 20 240 5.5 (2.5) 4.3 (2.0) 78

3/4” (19mm) 110 (2.8) 20 - 21 275 6.7 (3.0) 5.3 (2.4) 79

1.015 lbs/1000” 120 (3.1) 21 - 22 290 7.3 (3.3) 5.8 (2.6) 79

140 (3.6) 22 - 23 310 8.5 (3.9) 6.9 (3.1) 81

3/32” 50 (1.3) 18 - 19 215 4.6 (2.1) 3.6 (1.6) 78

DC- 70 (1.8) 19 - 20 260 6.4 (2.9) 5.1 (2.3) 79

3/4” (19mm) 95 (2.4) 21 - 22 315 8.7 (3.9) 7.0 (3.2) 80

1.518 lbs/1000” 110 (2.8) 22 - 23 345 10.0 (4.5) 8.1 (3.7) 81

130 (3.3) 23 - 24 385 11.8 (5.4) 9.6 (4.4) 81

The opacity of NR-203 Nickel (1%) slag to x-ray is such that slag inclusions will normally appear lighter than the weld. Voids will normally

appear darker than the weld. When using gamma-radiography, slag inclusions and voids will normally appear darker than the weld.

Improved x-ray film readability usually can be obtained by slight over-exposure at an excitation potential consistent with good x-ray

practice, but not over 240 KV. For detailed information on welding techniques, procedure adjustments, and their effects on weld appear-

ance and quality, request publication C3.2400 “Innershield Electrode - Semiautomatic Production Welding Guide”.

23

www.lincolnelectric.com

%C %Mn %Ni %P %S %Si %Al %V %Cr %Mo

Requirements

AWS E71T8-Ni1 0.12 1.50 .80 - 0.03 0.03 0.80 1.8 0.05 0.15 0.35

per A5.29 max. max. 1.10 max. max. max. max. max. max. max.

Test Results .081 1.17 .96 .006 .003 .27 .88 <.01 .03 .02

RADIOGRAPHIC GUIDELINES

INNERSHIELD NR-203 NICKEL (1%)

TYPICAL OPERATING PROCEDURES

DEPOSIT COMPOSITION

NOTE: These are typical operating procedures and are not intended to serve as specific procedures for any applications.

Diameter 14 Lb

Inches (mm) Coil

5/64 (2.0) ED012310

24

An all position wire designed for weld-

ing low temperature alloys.

Single and multiple pass welding.

Automatic and semiautomatic applica-

tions.

Produces a nickel-bearing weld deposit

with good Charpy V-Notch properties

at low temperatures(1).

A constant voltage power source is

recommended.

ADVANTAGE LINCOLN

• Self-shielded, flux-cored. No need

for external gas or flux.

• Produces quality welds in moderate

wind conditions with no tenting.

• Produces a nickel weld deposit (.80-

1.1% Ni).

• Our quality driven manufacturing

system – certified to ISO 9002 – and

our exceptionally high grade raw

materials mean every coil of

Innershield delivers great arc char-

acteristics and superior feedability.

TYPICAL APPLICATIONS

• Applications requiring good CTOD

properties and Charpy V-Notch

properties.

• Offshore welding applications.

• Storage, pipe, transportation and

other applications involving low tem-

perature alloys.

• Roundabout groove welds on heavy

wall tubular construction.

• General plate fabrication including

bridges.

• Hull plate and stiffener welding on

ships and barges.

(1)Will meet minimum Charpy V-Notch

properties recommended in the

“Seismic Provisions for Structural

Steel Buildings” by AISC, dated April

15, 1997.

1G

2F

4G

2G

5G

➔

3G

➔

3G

➔

Charpy V-Notch

Yield Strength Tensile Strength Elongation ft-lbs (Joules) Hardness

psi (MPa) psi (MPa) (%) @ -20°F (-29°C) @ -40ºF (-40ºC) Rockwell B

Requirements 50,000 min. 60,000 - 80,000 22 20 (27) Not --

AWS E61T8-K6 (345) (414 - 551) min. min. Required

Test Results 58,000 71,000 29 80 - 264 50 - 175 80

Typical NR-203 Nickel C (400) (489) (108 - 358) (68 - 237)

(1) The strength and elongation properties reported were obtained from a .505” tensile specimen artificially aged at 220°F (104°C) for 48 hours,

as permitted by AWS A5.29-80. A naturally aged tensile specimen may take months to achieve the specified properties. See AWS A5.20-95,

paragraph A8.3. The time required for the natural aging of weld deposits is dependent upon ambient conditions, weldment geometry, the

metallurgical structure of the weld deposit and other factors.

INNERSHIELD NR-203 NICKEL C AWS A5.29-98: E61T8-K6

DIAMETERS / PACKAGING

MECHANICAL PROPERTIES(1) - As Welded per AWS A5.29

WELDING POSITIONS

CONFORMANCE

AWS A5.29-98: E61T8-K6

ABS: 3SA

Lloyd’s: 3SH15

DNV: III MS(H15)

The opacity of NR-203 Nickel C slag to x-ray is such that slag inclusions will normally appear lighter than the weld.

Voids will normally appear darker than the weld. When using gamma-radiography, slag inclusions and voids will nor-

mally appear darker than the weld. Improved x-ray film readability usually can be obtained by slight over-exposure

at an excitation potential consistent with good x-ray practice, but not over 240 KV. For detailed information on

welding techniques, procedure adjustments, and their effects on weld appearance and quality, request publication

C3.2400 “Innershield Electrode - Semiautomatic Production Welding Guide”.

25

www.lincolnelectric.com

Wire, Polarity Wire Feed Arc Approx. Melt-Off Deposition

Electrical Stickout Speed Voltage Current Rate Rate Efficiency

Wire Weight in/min (m/min) (volts) (amps) lbs/hr (kg/hr) lbs/hr (kg/hr) (%)

5/64” 50 (1.3) 16 - 17 120 3.2 (1.5) 2.1 (1.0) 66

DC- 70 (1.8) 17 - 18 170 4.5 (2.0) 3.2 (1.5) 71

3/4” (19mm) 90 (2.3) 19 - 20 210 5.8 (2.6) 4.3 (2.0) 74

1.062 lbs/1000” 110 (2.8) 20 - 21 240 7.0 (3.2) 5.4 (2.4) 77

%C %Mn %P %S %Si %Al %V %Ni %Cr %Mo

Requirements

AWS E61T8-K6 0.15 .50 - .03 .03 .80 1.8 .05 .40 - .20 .15

per A5.29 max. 1.50 max. max. max. max. max. 1.00 max. max.

Test Results .058 .83 .004 <.003 .05 .73 <.01 .57 .08 <.01

RADIOGRAPHIC GUIDELINES

INNERSHIELD NR-203 NICKEL C

TYPICAL OPERATING PROCEDURES

DEPOSIT COMPOSITION

NOTE: These are typical operating procedures and are not intended to serve as specific procedures for any applications.

26

Similar to NR-203 Nickel C, but with

increased capability to join high-

strength steels.

Designed for all position welding. Single

and multiple pass. Automatic and

semiautomatic applications.

Produces a nickel bearing weld deposit

with excellent Charpy V-Notch proper-

ties(1).

A constant voltage power source is

recommended.

WELDING POSITIONS

TYPICAL APPLICATIONS

• Applications requiring good Charpy

V-Notch properties.

• Roundabout groove welds on heavy

wall tubular construction.

• Offshore welding applications.

• Structural fabrication, including

those with seismic requirements(1).

• General plate fabrication including

bridges.

• Hull plate and stiffener welding on

ships and barges.

1G

2F

4G

2G

5G

➔

3G

➔

Charpy V-Notch

Yield Strength Tensile Strength Elongation ft-lbs (Joules)

psi (MPa) psi (MPa) (%) @ -20°F (-29°C)

Requirements 58,000 min. 70,000 - 90,000 20 20 min.

AWS E71T8-K2 (400) (490 - 620) min. (27)

Test Results 61,000 - 72,000 72,000 - 84,000 22 - 30 102 - 212

(421 - 496) (496 - 579) (137 - 285)

Diameter 14 Lb.

Inches (mm) Coil

5/64 (2.0) ED020227

(1) The strength and elongation properties reported were obtained from a .505” tensile specimen artificially

aged at 220°F (104°C) for 48 hours, as permitted by AWS A5.29-80. A naturally aged tensile specimen may

take months to achieve the specified properties. See AWS A5.20-95, paragraph A8.3. The time required for

the natural aging of weld deposits is dependent upon ambient conditions, weldment geometry, the

metallurgical structure of the weld deposit and other factors.

ADVANTAGE LINCOLN

• Self-shielded, flux-cored. No need

for external gas or flux.

• Produces quality welds in moderate

wind conditions with no tenting.

• Produces a nickel weld deposit

(.80-1.1% Ni).

• A good choice for welding weather-

ing steels.

3G

➔

INNERSHIELD NR-203 Ni C Plus AWS A5.29-98: E71T8-K2

MECHANICAL PROPERTIES(1) - As Welded per AWS A5.29

DIAMETERS/PACKAGING

CONFORMANCE

AWS A5.29-98: E71T8-K2

• Handles poor fit-up in the vertical up

position. Successfully welds gaps

up to 1/4” with offsets up to 1/4”.

• Our quality driven manufacturing

system – certified to ISO 9002 – and

our exceptionally high grade raw

materials mean every coil of

Innershield delivers great arc char-

acteristics and superior feedability.

(1)Will meet minimum Charpy V-Notch

properties recommended in the

“Seismic Provisions for Structural

Steel Buildings” by AISC, dated April

15, 1997.

The opacity of NR-203 Ni C Plus slag to x-ray is such that slag inclusions will normally appear lighter than the

weld. Voids will normally appear darker than the weld. When using gamma-radiography, slag inclusions and

voids will normally appear darker than the weld. Improved x-ray film readability usually can be obtained by

slight over-exposure at an excitation potential consistent with good x-ray practice, but not over 240 KV. For

detailed information on welding techniques, procedure adjustments, and their effects on weld appearance

and quality, request publication C3.2400 “Innershield Electrode - Semiautomatic Production Welding Guide”.

27

www.lincolnelectric.com

Wire, Polarity Wire Feed Arc Approx. Melt-Off Deposition

Electrical Stickout Speed Voltage Current Rate Rate Efficiency

Wire Weight in/min (m/min) (volts) (amps) lbs/hr (kg/hr) lbs/hr (kg/hr) (%)

5/64” 50 (1.3) 16 - 17 115 3.2 (1.5) 2.3 (1.0) 72

DC- 70 (1.8) 17 - 18 170 4.5 (2.0) 3.3 (1.5) 73

3/4” (19mm) 90 (2.3) 19 - 20 210 5.8 (2.6) 4.4 (2.0) 76

1.091 lbs/1000” 110 (2.8) 20 - 21 245 7.0 (3.2) 5.5 (2.5) 79

%C %Mn %P %S %Si %Al %V %Ni %Cr %Mo

Requirements

AWS E71T8-K2 0.15 0.5 - 0.03 0.03 0.80 1.8 0.05 1.00 - 0.15 0.35

per A5.29 max. 1.75 max. max. max. max. max. 2.00 max. max.

Test Results .05 .85 .009 <.003 .07 1.08 <.01 1.27 .14 .02

RADIOGRAPHIC GUIDELINES

INNERSHIELD NR-203 Ni C Plus

TYPICAL OPERATING PROCEDURES

DEPOSIT COMPOSITION

NOTE: These are typical operating procedures and are not intended to serve as specific procedures for any applications.

28

The highest deposition rates of any

Innershield wire for out-of-position

welding.

An extremely popular wire designed

for single and multiple pass welding of

3/16” (4.8mm) and heavier mild steel,

as well as some low alloy steels.

NR-232’s weld deposits meet

Charpy V-Notch requirements(1).

A constant voltage power source is

recommended.

WELDING POSITIONS

Charpy V-Notch

Yield Strength Tensile Strength Elongation ft-lbs (Joules) Hardness

psi (MPa) psi (MPa) (%) @ -20°F (-29°C) Rockwell B

Requirements 58,000 (400) 70,000 (480) 22 20 --

AWS E71T-8 min. min. min. (27)

Test Results (1) 60,000 - 74,000 72,000 - 87,000 22 - 30 20 - 69 88-90

(414 - 510) (496 - 600) (27 - 94)

1G

2F

4G

2G

5G

➔

3G

➔

TYPICAL APPLICATIONS

• Structural fabrication, including

those subject to seismic require-

ments(1).

• General plate fabrication including

bridges.

• Hull plate and stiffener welding on

ships and barges.

• Machinery parts, tanks, hoppers,

racks and scaffolding.

(1)Will meet minimum Charpy V-Notch

properties recommended in the

“Seismic Provisions for Structural

Steel Buildings” by AISC, dated April

15, 1997.

ADVANTAGE LINCOLN

• Self-shielded, flux-cored. No need

for external gas or flux.

• Produces quality welds in moderate

wind conditions with no tenting.

• Fast freezing slag system supports

high deposition rates on out-of-

position welding.

• Self peeling slag.

Diameter 13.5 Lb. 22 Lb. 50 Lb.

Inches (mm) Coil Readi-Reel®Coil

.068 (1.7) ED012518 ED012519

.072 (1.8) ED012522 ED012521 ED012523

5/64 (2.0) ED012525 ED012524 ED012526

(1) The strength and elongation properties reported were obtained from a .505” tensile specimen artificially aged at 220°F

(104°C) for 48 hours, as permitted by AWS A5.20-95. A naturally aged tensile specimen may take months to achieve the

specified properties. See AWS A5.20-95, paragraph A8.3. The time required for the natural aging of weld deposits is

dependent upon ambient conditions, weldment geometry, the metallurgical structure of the weld deposit and other factors.

INNERSHIELD NR-232 AWS A5.20-95: E71T-8

DIAMETERS / PACKAGING

MECHANICAL PROPERTIES(1) - As Welded per AWS A5.20

CONFORMANCE

AWS A5.20-95: E71T-8

ABS: 3SA-3YSAH

Lloyd’s: 3S-3YSH15

DNV: III YMSH15

G.L.: 3YSH10

N.K.: KSW 53NH10

MIL Spec: MIL-71T-8AS

B.V.: SA3YMH

• Our quality driven manufacturing

system – certified to ISO 9002 – and

our exceptionally high grade raw

materials mean every coil of

Innershield delivers great arc char-

acteristics and superior feedability.

29

www.lincolnelectric.com

Wire, Polarity Wire Feed Arc Approx. Melt-Off Deposition

Electrical Stickout Speed Voltage Current Rate Rate Efficiency

Wire Weight in/min (m/min) (volts) (amps) lbs/hr (kg/hr) lbs/hr (kg/hr) (%)

110 (2.7) 18 - 20 195 5.0 (2.3) 3.9 (1.8) 78

.068” 130 (3.3) 19 - 21 225 6.2 (2.8) 4.6 (2.0) 74

DC- 150 (3.8) 19 - 21 250 7.1 (3.2) 5.3 (2.4) 75

1/2-1” (12-25mm) 170 (4.3) 20 - 22 270 7.8 (3.5) 6.1 (2.8) 78

.755 lbs/1000” 195 (5.0) 23 - 24 300 9.4 (4.3) 7.0 (3.2) 74

250 (6.4) 23 - 24 350 11.8 (5.4) 9.0 (4.0) 76

320 (7.4) 25 - 27 400 15.2 (6.9) 11.4 (5.2) 75

80 (2.0) 16 - 18 130 4.0 (1.8) 3.3 (1.5) 83

.072” 140 (3.6) 18 - 21 225 6.8 (3.1) 5.5 (2.5) 81

DC- 155 (3.9) 19 - 22 240 7.2 (3.3) 6.0 (2.7) 83

1/2-1” (12-25mm) 170 (4.3) 20 - 23 255 8.0 (3.6) 6.5 (2.9) 81

.778 lbs/1000” 250 (6.4) 22 - 24 315 11.7 (5.3) 9.6 (4.3) 82

290 (7.4) 23 - 25 350 13.6 (6.2) 11.0 (5.0) 81

60 (1.5) 16 - 17 145 3.7 (1.7) 2.7 (1.2) 73

5/64” 115 (2.9) 19 - 20 260 7.0 (3.2) 5.5 (2.5) 78

DC- 120 (3.0) 19 - 20 270 7.3 (3.3) 5.7 (2.6) 78

1/2-1” (12-25mm) 130 (3.3) 20 - 21 285 7.8 (3.5) 6.2 (2.8) 79

1.000 lbs/1000” 180 (4.6) 22 - 23 365 10.9 (5.0) 8.7 (3.9) 80

%C %Mn %P %S %Si %Al

Requirements

AWS E71T-8 Report 1.75 .03 .03 .60 1.8

per A5.20 only max. max. max. max. max.

Test Results .17 .72 .007 .003 .31 .71

INNERSHIELD NR-232

TYPICAL OPERATING PROCEDURES

DEPOSIT COMPOSITION

NOTE: These are typical operating procedures and are not intended to serve as specific procedures for any applications.

Diameter 22 Lb 50 Lb

Inches (mm) Readi-Reel Coil

5/64 (2.0) ED028696

3/32 (2.4) ED012593

Charpy V-Notch

Yield Strength Tensile Strength Elongation ft-lbs (Joules)

psi (MPa) psi (MPa) (%) @ 0°F (-18°C) @ -20°F (-29°C)

Requirements 58,000 (400) 70,000 (480) 22 -- 20 (27)

AWS E70T-6 min. min. min. min.

Test Results 62,000 - 76,000 72,000 - 89,000 23 - 32 21 - 54 21 - 35

As Welded (427 - 524) (496 - 614) (28 - 73) (28 - 47)

Stress Relieved(2) 54,000 - 62,000 71,000 - 84,000 28 - 37 34 - 60 20 - 56

(372 - 427) (489 - 579) (46 - 81) (27 - 76)

30

1G

2F

An extremely high deposition rate

wire, designed for single and multiple

pass, automatic and semiautomatic

welding of mild steel and some low

alloy steels.

NR-305 has very good penetration.

ADVANTAGE LINCOLN

• Self-shielded, flux-cored. No need

for external gas or flux.

• Produces quality welds in moderate

wind conditions with no tenting.

• A great choice for downhand weld-

ing applications where high deposi-

tion rates and good penetration are

desired.

• Low spatter.

• Excellent operator appeal.

• Welds well on lightly rusted or

primed plate.

• A constant voltage power source is

recommended.

(1) The strength and elongation properties reported were obtained from a .505” tensile specimen artificially aged at 220°F

(104°C) for 48 hours, as permitted by AWS A5.20-95. A naturally aged tensile specimen may take months to achieve the

specified properties. See AWS A5.20-95, paragraph A8.3. The time required for the natural aging of weld deposits is

dependent upon ambient conditions, weldment geometry, the metallurgical structure of the weld deposit and other factors.

(2) Stress relieved 1 hour at 1150°F (621°C).

TYPICAL APPLICATIONS

• General plate fabrication including

bridges and offshore rigs.

• Shipyards.

• Stiffener welding on ships and

barges.

• Welding over tack welds made with

stick electrodes.

(1)Will meet minimum Charpy V-Notch

properties recommended in the

“Seismic Provisions for Structural

Steel Buildings” by AISC, dated April

15, 1997.

INNERSHIELD NR-305 AWS A5.20-95: E70T-6

DIAMETERS / PACKAGING

MECHANICAL PROPERTIES(1) - As Welded per AWS A5.20

WELDING POSITIONS

CONFORMANCE

AWS A5.20-95: E70T-6

ABS: 2SA, 2YSA

DNV: II YMS

GL: 2YS

BV: SA2YM

• Our quality driven manufacturing

system – certified to ISO 9002 – and

our exceptionally high grade raw

materials mean every coil of

Innershield delivers great arc char-

acteristics and superior feedability.

Wire, Polarity Wire Feed Arc Approx. Melt-Off Deposition

Electrical Stickout Speed Voltage Current Rate Rate Efficiency

Wire Weight in/min (m/min) (volts) (amps) lbs/hr (kg/hr) lbs/hr (kg/hr) (%)

5/64” 200 (5.1) 22 - 23 385 12.8 (5.8) 10.0 (4.5) 78

DC+ 250 (6.4) 24 - 26 430 16.0 (7.2) 13.0 (5.8) 81

7/8” (22mm) 350 (8.8) 28 - 33 450 22.5 (10.2) 18.8 (8.5) 83

1.07 lbs/1000” 450 (11.4) 30 - 35 545 28.9 (13.1) 24.5 (11.1) 84

3/32” 160 (4.1) 21 - 23 330 13.3 (6.0) 11.0 (5.0) 82

DC+ 240 (6.1) 24 - 26 425 20.0 (9.1) 16.7 (7.6) 83

1-1/2 – 2-1/2” (38 - 63mm) 300 (7.6) 27 - 29 475 25.0 (11.3) 21.0 (9.5) 84

1.39 lbs/1000” 400 (10.2) 33 - 35 525 33.4 (15.2) 28.0 (12.7) 83

31

www.lincolnelectric.com

%C %Mn %P %S %Si %Al

Requirements

AWS E70T-6 Report 1.75 .03 .03 .60 1.8

per A5.20 Only max. max. max. max. max.

Test Results .08 1.26 .012 .005 .23 1.19

INNERSHIELD NR-305

TYPICAL OPERATING PROCEDURES

DEPOSIT COMPOSITION

NOTE: These are typical operating procedures and are not intended to serve as specific procedures for any applications.

600 Lb. 600 Lb.

Diameter 14 Lb. 22 Lb. 50 Lb. Speed-Feed®Speed-Feed

Inches (mm) Coil Readi-Reel®Coil Reel Drum

5/64 (2.0) ED014464 ED014515 ED014459

3/32 (2.4) ED025740 ED012629 ED012630 ED012628

7/64 (2.8) ED012632 ED012633 ED012631

32

1G

2F

2G

1G

One of our most popular wires, with a

very high deposition rate and excellent

penetration..

Designed for single and multiple pass,

automatic and semiautomatic welding

of thicker mild steels and some low

alloy steels.

A constant voltage power source is

recommended.

Yield Strength Tensile Strength Elongation Hardness

Condition psi (MPa) psi (MPa) (%) Rockwell B

Requirements 58,000 (400) 70,000 (480) 22 --

AWS E70T-7 min. min. min.

Test Results 60,000 - 66,000 82,000 - 90,000 22 - 26 87 - 92

(414 - 455) (565 - 620)

TYPICAL APPLICATIONS

• Fillet, lap and butt welds on 1/8”

(3.2mm) and thicker steels.

• Horizontal butt welds such as

column-to-column structural con-

nections not subject to seismic

requirements.

• General fabrication and assembly

welding.

NOTES:

• NR-311 should not be used for

applications requiring Charpy V-

Notch properties.

(1) The strength and elongation properties reported were obtained from a .505” tensile specimen artificially

aged at 220°F (104°C) for 48 hours, as permitted by AWS A5.20-95. A naturally aged tensile specimen

may take months to achieve the specified properties. See AWS A5.20-95, paragraph A8.3. The time

required for the natural aging of weld deposits is dependent upon ambient conditions, weldment

geometry, the metallurgical structure of the weld deposit and other factors.

ADVANTAGE LINCOLN

• Self-shielded, flux-cored. No need

for external gas or flux.

• Produces quality welds in moderate

wind conditions with no tenting.

• Very high deposition rates and fast

travel speeds.

• Resists weld cracking on high sulfur

steels.

• Smooth operation. Good bead

shape.

INNERSHIELD NR-311 AWS A5.20-95: E70T-7

DIAMETERS / PACKAGING

MECHANICAL PROPERTIES(1) - As Welded per AWS A5.20

WELDING POSITIONS

CONFORMANCE

AWS A5.20-95: E70T-7

ASME SFA-5.20: E70T-7

ABS: E70T-7 per AWS A5.20-95

• Easy slag removal in deep grooves.

• Deep penetration.

• Excellent operator appeal.

• Our quality driven manufacturing

system – certified to ISO 9002 – and

our exceptionally high grade raw

materials mean every coil of

Innershield delivers great arc char-

acteristics and superior feedability.

33

www.lincolnelectric.com

Wire, Polarity Wire Feed Arc Approx. Melt-Off Deposition

Electrical Stickout Speed Voltage Current Rate Rate Efficiency

Wire Weight in/min (m/min) (volts) (amps) lbs/hr (kg/hr) lbs/hr (kg/hr) (%)

5/64” 100 (2.5) 21 190 6.4 (2.9) 5.0 (2.3) 78

DC- 160 (4.1) 25 275 10.3 (4.7) 8.0 (3.6) 78

1-1/4” (32mm) 240 (6.1) 26 355 15.4 (7.0) 12.4 (5.6) 80

1.07 lbs/1000” 300 (7.6) 28 410 19.3 (8.8) 15.8 (7.2) 82

3/32” 75 (1.9) 21 200 7.0 (3.2) 5.4 (2.5) 77

DC- 135 (3.4) 24 300 13.1 (5.9) 10.2 (4.6) 78

1-1/2” (38mm) 150 (3.8) 25 325 14.6 (6.6) 11.4 (5.2) 78

1.62 lbs/1000” 210 (5.3) 27 400 20.4 (9.3) 16.5 (7.5) 81

270 (6.9) 30 450 26.2 (11.9) 22.0 (10.0) 84

7/64” 100 (2.5) 23.5 325 12.0 (5.4) 10.0 (4.5) 83

DC- 145 (3.7) 25.5 400 17.8 (8.1) 14.5 (6.6) 82

1-1/2” (38mm) 175 (4.4) 27 450 21.5 (9.8) 18.0 (8.2) 83

2.05 lbs/1000” 240 (6.1) 30.5 550 29.5 (13.4) 25.5 (11.6) 86

300 (7.6) 33 625 36.9 (16.7) 33.0 (15.0) 89

%C %Mn %P %S %Si %Al

Requirements

AWS E70T-7 Report 1.75 .03 .03 .60 1.8

per A5.20-95 Only max. max. max. max. max.

Test Results .25 .50 .008 <.003 .10 1.46

NOTE: NR-311 will not produce weld deposits meeting the minimum Charpy V-Notch properties

recommended in the “Seismic Provisions for Structural Steel Buildings” by AISC, dated April 15, 1997.

For these and other applications specifying notch toughness, the following Innershield electrodes

should be considered: NR-203MP, NR-203Nickel C Plus, NR-203 Nickel (1%), NR-232, NR-305,

NR-311 Ni.

INNERSHIELD NR-311

TYPICAL OPERATING PROCEDURES

DEPOSIT COMPOSITION

NOTE: These are typical operating procedures and are not intended to serve as specific procedures for any applications.

Diameter 22 Lb. 50 Lb.

Inches (mm) Readi-Reel®Coil

5/64 (2.0) ED017819

3/32 (2.4) ED017822

7/64 (2.8) ED017824

34

1G

2F

2G

3G

➔

Similar to NR-311 wire, but with

Charpy V-Notch properties(1).

Designed for downhand, flat, and hor-

izontal welding on 1/8” (3.2mm) and

thicker mild steel and some low alloy

steels. Automatic and semiautomatic.

A constant voltage power source is

recommended.

Charpy V-Notch

Yield Strength Tensile Strength Elongation ft-lbs (Joules) Hardness

Condition psi (MPa) psi (MPa) (%) @ -20ºF (-29ºC) Rockwell B

Requirements 58,000 (400) 70,000 (482) 20 20 (27) --

min. min. min. min. min.

AWS E70T7-K2

Test Results 64,000 - 75,000 80,000 - 89,000 22 - 31 20 - 50 (27 - 68) 87 - 92

(441 - 517) (551 - 613)

TYPICAL APPLICATIONS

• General fabrication and assembly

welding.

• Structural fabrication, including appli-

cations involving seismic require-

ments(1).

• Single and multiple pass welds.

• Fillet and lap welds.

• Horizontal butt welds such as

column-to-column structural con-

nections.

• Deep groove welds.

• Square edge butt welds.

NOTES:

•(1)Meets minimum Charpy V-Notch

properties recommended in the

“Seismic Provision for Structural

Steel Buildings”, by AISC, dated

April 15, 1997.

ADVANTAGE LINCOLN

• Self-shielded, flux-cored. No need

for external gas or flux.

• Produces quality welds in moderate

wind conditions with no tenting.

• High deposition rates and fast travel

speeds.

• Produces a 1.5% Nickel deposit for

good low temperature notch tough-

ness.

• Our quality driven manufacturing

system – certified to ISO 9002 – and

our exceptionally high grade raw

materials mean every coil of

Innershield delivers great arc char-

acteristics and superior feedability.

(1) The strength and elongation properties reported were obtained from a .505” tensile specimen artificially aged at 220°F

(104°C) for 48 hours, as permitted by AWS A5.29-80. A naturally aged tensile specimen may take months to achieve the speci-

fied properties. See AWS A5.20-95, paragraph A8.3. The time required for the natural aging of weld deposits is dependent upon

ambient conditions, weldment geometry, the metallurgical structure of the weld deposit and other factors.

INNERSHIELD NR-311 Ni AWS A5.29-98: E70T7-K2

DIAMETERS / PACKAGING

MECHANICAL PROPERTIES(1) - As Welded per AWS A5.29

WELDING POSITIONS

• We recommend 5/64” (2.0mm) wire

for vertical-down welding.

• 7/64” (2.8mm) wire is limited to

approximately 20° downhill.

CONFORMANCE

AWS A5.29-98: E70T7-K2

Lloyd’s: 2S-2YS

DNV: IIYMS

GL: 2YS

BV: SA2YM

NKK: KSW 52 NH10

Wire, Polarity Wire Feed Arc Approx. Melt-Off Deposition

Electrical Stickout Speed Voltage Current Rate Rate Efficien cy

Wire Weight in/min (m/min) (volts) (amps) lbs/hr (kg/hr) lbs/hr (kg/hr) (%)

5/64” 100 (2.5) 21 - 23 170 5.5 (2.5) 3.9 (1.8) 70

DC- 130 (3.3) 24 - 26 205 7.2 (3.3) 5.2 (2.4) 72

1” (25mm) 160 (4.0) 25 - 27 235 8.8 (4.0) 6.5 (2.9) 73

0.930 lbs/1000” 200 (5.0) 26 - 28 270 11.0 (5.0) 8.3 (3.8) 75

240 (6.1) 27 - 29 295 13.3 (6.1) 10.0 (4.5) 75

75 (1.9) 20 - 22 200 6.2 (2.8) 4.2 (1.9) 67

3/32” 100 (2.5) 21 - 23 245 8.3 (3.8) 5.9 (2.7) 71

DC- 125 (3.1) 23 - 25 285 10.4 (4.7) 7.5 (3.4) 72

1-1/4” (32mm) 150 (3.8) 25 - 27 330 12.5 (5.7) 9.1 (4.1) 72

1.39 lbs/1000” 175 (4.4) 26 - 28 365 14.5 (6.6) 10.8 (4.9) 74

200 (5.0) 27 - 29 390 16.6 (7.6) 12.3 (5.6) 74

7/64” 100 (2.5) 22 - 24 310 11.4 (5.2) 8.4 (3.8) 73

DC- 140 (3.5) 24 - 26 370 15.8 (7.2) 11.8 (5.4) 74

1-1/2” (38mm) 170 (4.3) 26 - 28 430 19.5 (8.9) 14.5 (6.6) 74

1.89 lbs/1000” 200 (5.0) 28 - 30 470 22.8 (10.4) 17.0 (7.7) 74

240 (6.1) 29 - 31 520 27.2 (12.4) 20.4 (9.2) 75

35

www.lincolnelectric.com

%C %Mn %P %S %Si %Al %Ni %Mo %Cr %V

Requirements

AWS E70T7-K2 .15 max. .50 - 1.75 .03 max. .03 max. .80 max. 1.8 max. 1.00 - 2.00 .35 max. .15 max. .05 max.

per A5.29

Test Results .06 1.23 .005 <.003 .20 1.24 1.28 <.01 .03 <.01

INNERSHIELD NR-311 Ni

TYPICAL OPERATING PROCEDURES

DEPOSIT COMPOSITION

NOTE: These are typical operating procedures and are not intended to serve as specific procedures for any applications.

600 Lb. 600 Lb.

Diameter 14 Lb. 22 Lb. 50 Lb. Speed-Feed®Speed-Feed

Inches (mm) Coil Readi-Reel®Coil Reel Drum

5/64 (2.0) ED012739 ED017905 ED012740

3/32 (2.4) ED012736 ED012735

.120 (3.0) ED012732 ED012734 ED012731

36

1G

2F

A very high deposition rate wire,

designed for automatic and semiauto-

matic welding on mild steel and some

low alloy steels.

Can also be used to join sulfur or high

carbon steels.

A constant voltage power source is

recommended.

Yield Strength Tensile Strength Elongation Hardness

psi (MPa) psi (MPa) (%) Rockwell B

Requirements 58,000 (400) 70,000 (480) 22 --

AWS E70T-4 min. min. min.

Test Results 60,000 - 70,000 72,000 - 93,000 22 - 30 85 - 95

Typical NS-3M (414 - 483) (497 - 641)

WELDING POSITIONS

TYPICAL APPLICATIONS

• General fabrication.

• Structural fabrication where no seis-

mic requirements exist.

• Machinery bases.

• Heavy equipment repair.

• Multiple pass fillet and lap welds.

• Corner welds and single pass butt

welds.

• Single pass 1/4 - 1/2” (6.4 -

12.7mm) fillet and lap welds.

NOTES:

• NS-3M should not be used for

applications requiring Charpy

V-Notch properties.

ADVANTAGE LINCOLN

• Self-shielded, flux-cored. No need

for external gas or flux.

• Produces quality welds in moderate

wind conditions with no tenting.

• High deposition rates for excellent

productivity.

• Resists cracking on high sulfur

steel.

• Resists porosity on mildly rusty, oil

or dirty plate.

• Easy slag removal – even in deep

grooves.

(1) The strength and elongation properties reported were obtained from a .505” tensile specimen artificially aged

at 220°F (104°C) for 48 hours, as permitted by AWS A5.20-95. A naturally aged tensile specimen may take

months to achieve the specified properties. See AWS A5.20-95, paragraph A8.3. The time required for the

natural aging of weld deposits is dependent upon ambient conditions, weldment geometry, the metallurgical

structure of the weld deposit and other factors.

INNERSHIELD NS-3M AWS A5.20-95: E70T-4

DIAMETERS / PACKAGING

MECHANICAL PROPERTIES(1) - As Welded per AWS A5.20

CONFORMANCE

AWS A5.20-95: E70T-4

ASME SFA-5.20: E70T-4

ABS: E70T-4 per AWS A5.20-95

• Soft, low penetration arc.

• Our quality driven manufacturing

system – certified to ISO 9002 – and

our exceptionally high grade raw

materials mean every coil of

Innershield delivers great arc char-

acteristics and superior feedability.

NOTE: NS-3M will not produce weld deposits meeting the minimum Charpy V-Notch properties

recommended in the “Seismic Provisions for Structural Steel Buildings” by AISC, dated April 15, 1997.

For these and other applications specifying notch toughness, the following Innershield electrodes

should be considered: NR-203MP, NR-203 Nickel C Plus, NR-203 Nickel (1%), NR-232, NR-305,

NR-311 Ni.

%C %Mn %P %S %Si %Al

Requirements

AWS E70T-4 Report 1.75 .03 .03 .60 1.8

per A5.20 Only max. max. max. max. max..

Test Results .25 .45 .006 <.003 .29 1.59

Typical NS-3M

Wire, Polarity Wire Feed Arc Approx. Melt-Off Deposition

Electrical Stickout) Speed Voltage Current Rate Rate Efficiency

Wire Weight in/min (m/min) (volts) (amps) lbs/hr (kg/hr) lbs/hr (kg/hr) (%)

5/64” 200 (5.1) 29 - 31 280 12.2 (5.5) 10.1 (4.6) 83

DC+ 240 (6.1) 30 - 32 315 14.8 (6.7) 12.1 (5.5) 82

2” (51mm) 260 (6.6) 30 - 32 330 16.0 (7.3) 13.2 (6.0) 83

1.03 lbs/1000” 300 (7.6) 31 - 33 350 18.6 (8.4) 15.2 (6.9) 82

3/32” 110 (2.8) 28 - 30 250 10.1 (4.6) 8.2 (3.7) 81

DC+ 150 (3.8) 29 - 31 300 14.0 (6.4) 11.7 (5.3) 84

2-3/4” (70mm) 185 (4.7) 30 - 32 350 17.4 (7.9) 14.6 (6.6) 84

1.53 lbs/1000” 230 (5.8) 31 - 33 400 21.6 (9.8) 18.3 (8.3) 85

275 (7.0) 32 - 34 450 26.0 (11.8) 22.0 (10.0) 85

.120 140 (3.6) 28 - 30 380 19.8 (9.0) 15.5 (7.0) 78

DC+ 175 (4.4) 29 - 31 450 24.6 (11.2) 20.0 (9.1) 81

2-3/4” (70mm) 200 (5.1) 30 - 32 500 28.0 (12.7) 23.2 (10.5) 83

2.34 lbs/1000” 225 (5.7) 31 - 33 550 31.4 (14.2) 26.2 (11.9) 83

.120 210 (5.3) 35 - 37 450 29.0 (13.2) 25.0 (11.3) 86

DC+ 250 (6.4) 36 - 38 500 34.5 (15.6) 29.0 (13.2) 84

3-3/4” (95mm) 300 (7.6) 37 - 39 550 41.5 (18.8) 34.0 (15.4) 82

2.34 lbs/1000” 355 (9.0) 38 - 40 600 49.0 (22.2) 39.5 (18.0) 81

37

www.lincolnelectric.com

INNERSHIELD NS-3M

TYPICAL OPERATING PROCEDURES

DEPOSIT COMPOSITION

NOTE: These are typical operating procedures and are not intended to serve as specific procedures for any applications.

Diameter 14 Lb. Coil 14 Lb. Coil 22 Lb.

Inches (mm) (56 Lb. Carton) (56 Lb. Pail) Readi-Reel

NR-207

.068 (1.7) ED016280 ED016312

5/64 (2.0) ED012437 ED012438

NR-207-H

.068 (1.7) EDS19565 ED019566

5/64 (2.0) EDS19568

38

Designed for optimum performance

on vertical down hot, fill and cap pass-

es on standard cross-country

pipelines and arctic grade pipe.

Excellent crack resistance, plus out-

standing CTOD and Charpy V-Notch

properties. Both wires also meet API

Pipe Grade X42 and X70 require-

ments.

NR-207-H is a baked wire with a

lower hydrogen level for higher

strength steels.

A constant voltage power source is

recommended.

WELDING POSITIONS

TYPICAL APPLICATIONS

• Standard cross country pipelines.

• Arctic grade pipe.

NOTES:

• NR-207-H will deposit weld material

with diffusible hydrogen levels of less

than 8.0 ml/100g.

ADVANTAGE LINCOLN

• Self-shielded, flux-cored. No need

for external gas or flux.

• Produces quality welds in moderate

wind conditions with no tenting.

INNERSHIELD NR-207 & NR-207-H AWS A5.29-98: E71T8-K6

DIAMETERS / PACKAGING

CONFORMANCE

AWS A5.29-98: E71T8-K6

ABS: E71T8-K6

DNV: IIIYMSH15

BV: SA3YMH

GL: 3YSH15

• Use these wires instead of stick for

improved productivity on pipeline

projects.

• Our quality driven manufacturing

system – certified to ISO 9002 – and

our exceptionally high grade raw

materials mean every coil of

Innershield delivers great arc char-

acteristics and superior feedability.

1G

2F

4G

2G

3G

➔

5G

➔

3G

➔

Charpy V-Notch

Yield Strength Tensile Strength Elongation ft-lbs (Joules) Hardness

psi (MPa) psi (MPa) (%) @ -20°F (-29°C) @-40°F (-40°C) Rockwell B

Requirements 58,000 (400) 70,000 - 90,000 20 20 (27) Not

AWS E71T-8J min. (483 - 620) min. min. Specified --

Test Results 58,000 - 64,000 75,000 - 80,000 20 - 33 130 - 170 109 84 - 90

Typical NR-203MP (400 - 441) (517 - 551) (176 - 230) (147)

(1) The strength and elongation properties reported were obtained from a .505” tensile specimen artificially aged at 220°F (104°C) for 48 hours,

as permitted by AWS A5.20-95. A naturally aged tensile specimen may take months to achieve the specified properties. See AWS A5.20-95,

paragraph A8.3. The time required for the natural aging of weld deposits is dependent upon ambient conditions, weldment geometry, the metal-

lurgical structure of the weld deposit and other factors.

MECHANICAL PROPERTIES(1) - As Welded per AWS A5.20

%C %Mn %P %S %Si %Al %Ni %Cr %Mo %V

Requirements

AWS E71T8-K6 .15 .50- .03 .03 .80 1.8 .40- .20 .15 .05

per A5.29 max. 1.50 max. max. max. max. 1.00 max. max. max.

Test Results .06 .94 .005 <.003 .26 .1.07 .76 .02 .02 <.01

Typical NR-207

Wire, Polarity Wire Feed Arc Approx. Melt-Off Deposition

Electrical Stickout Speed Voltage Current Rate Rate Efficiency

Wire Weight in/min (m/min) (volts) (amps) lbs/hr (kg/hr) lbs/hr (kg/hr) (%)

.068” 80 (2.0) 17 - 18 190 3.8 (1.7) 3.0 (1.3) 79

DC- 105 (2.6) 18 - 19 230 5.0 (2.2) 4.0 (1.8) 80

3/4” (19mm) 120 (3.0) 19 - 20 245 5.7 (2.5) 4.5 (2.0) 79

0.078 lbs/1000” 145 (3.6) 21 - 22 275 6.8 (3.0) 5.5 (2.4) 81

170 (4.3) 21 - 22 295 8.0 (3.6) 6.4 (2.9) 80

5/64” 70 (1.7) 17 - 18 205 4.5 (2.0) 3.4 (1.5) 76

DC- 80 (2.0) 18 - 19 225 5.1 (2.3) 3.9 (1.7) 76

3/4” (19mm) 90 (2.2) 18 - 19 240 5.8 (2.6) 4.5 (2.0) 78

1.04 lbs/1000” 110 (2.7) 20 - 21 275 7.0 (3.1) 5.5 (2.4) 79

130 (3.3) 20 - 21 300 8.3 (3.7) 6.5 (2.9) 78

39

www.lincolnelectric.com

INNERSHIELD NR-207 & NR-207-H

TYPICAL OPERATING PROCEDURES

DEPOSIT COMPOSITION

NOTE: These are typical operating procedures and are not intended to serve as specific procedures for any applications.

Diameter 14 Lb. Coil

Inches (mm) (56 Lb. Pail)

.068 (1.7) EDS22113

5/64 (2.0) ED023366

40

Similar to NR-207-H wire, with lower

hydrogen and higher strength.

Designed for optimum performance

on vertical down hot, fill and cap pass-

es on standard cross country pipelines

and arctic grade pipe.

Meets API Pipe Grade X80 require-

ments.

A constant voltage power source is

recommended

WELDING POSITIONS

TYPICAL APPLICATIONS

• Standard cross-country pipelines.

• Arctic-grade pipe.

NOTES:

• NR-208-H will deposit weld material

with diffusible hydrogen levels of

less than 8.0 ml/100g.

ADVANTAGE LINCOLN

• Self-shielded, flux-cored. No need

for external gas or flux.

• Produces quality welds in moderate

wind conditions with no tenting.

• Use instead of stick for improved

productivity on pipeline projects.

INNERSHIELD NR-208-H AWS A5.29-98: E91T8-G

DIAMETERS / PACKAGING

CONFORMANCE

AWS A5.29-98: E91T8-G

ASME: SFA-5.20: E91T8-G

1G

2F

4G

2G

3G

➔

5G

➔

3G

➔

• Produces weld deposits exceeding

80,000 psi yield strength.

• Our quality driven manufacturing

system – certified to ISO 9002 – and

our exceptionally high grade raw

materials mean every coil of

Innershield delivers great arc char-

acteristics and superior feedability.

Charpy V-Notch

Yield Strength Tensile Strength Elongation ft-lbs (Joules) Hardness

psi (MPa) psi (MPa) (%) @ -20°F (-29°C) @-40°F (-40°C) Rockwell B

Requirements 78,000 (538) 90,000 - 110,000 17 Not Not

AWS E71T-8J min. (620 - 758) min. Specified Specified --

Test Results 81,000 - 86,000 94,000 - 99,000 25 - 27 50 44 90 - 96

Typical NR-203MP (558 - 593) (648 - 682) (67) (59)

(1) The strength and elongation properties reported were obtained from a .505” tensile specimen artificially aged at 220°F (104°C) for 48 hours,

as permitted by AWS A5.20-95. A naturally aged tensile specimen may take months to achieve the specified properties. See AWS A5.20-95,

paragraph A8.3. The time required for the natural aging of weld deposits is dependent upon ambient conditions, weldment geometry, the metal-

lurgical structure of the weld deposit and other factors.

MECHANICAL PROPERTIES(1) - As Welded per AWS A5.29

41

www.lincolnelectric.com

%C %Mn* %P %S %Si* %Al %Ni* %Cr* %Mo* %V*

Requirements

AWS E91T8-G Report 1.75 .03 .03 .80 1.8 .50 .30 .20 .10

per A5.29 only min. max. max. min. min.. min.. min. min. min.

Test Results .05 2.13 .011 <.002 .25 1.13 .79 .02 <.01 <.01

Wire, Polarity Wire Feed Arc Approx. Melt-Off Deposition

Electrical Stickout Speed Voltage Current Rate Rate Efficiency

Wire Weight in/min (m/min) (volts) (amps) lbs/hr (kg/hr) lbs/hr (kg/hr) (%)

.068” 70 (1.7) 15 - 16 165 3.2 (1.5) 2.6 (1.1) 82

DC- 90 (2.2) 17 - 18 195 4.0 (1.8) 3.3 (1.5) 82

3/4” (19mm) 120 (3.0) 19 - 20 225 5.4 (2.5) 4.5 (2.0) 83

0.80 lbs/1000” 145 (3.6) 20 - 21 255 6.7 (3.0) 5.5 (2.5) 82

170 (4.3) 21 - 22 278 7.7 (3.5) 6.3 (2.8) 82

5/64” 70 (1.7) 16 - 17 195 4.0 (1.8) 3.2 (1.4) 81

DC- 80 (2.0) 17 - 18 220 4.6 (2.1) 3.9 (1.7) 84

3/4” (19mm) 90 (2.2) 18 - 19 235 5.4 (2.4) 4.5 (2.0) 84

1.04 lbs/1000” 110 (2.7) 19 - 20 270 6.5 (2.9) 5.5 (2.4) 85

130 (3.3) 19 - 20 295 7.6 (3.5) 6.5 (2.9) 85

INNERSHIELD NR-208-H

TYPICAL OPERATING PROCEDURES

DEPOSIT COMPOSITION

NOTE: These are typical operating procedures and are not intended to serve as specific procedures for any applications.

NOTE: In order to meet the alloy requirements of the G group, the weld deposit needs to have the minimum, as specified

in the table, of only one of the elements marked with an asterisk.

Innershield®AWS/ ABS Lloyd’s DNV BV CWB/CSA GL

Wire(1) ASME Grade Grade Grade Grade Grade Grade Military Other

NR-203 E61T8-K6 3SA 3SH15 IIIMSH15(3) JIS

Nickel C

NR-1 E70T-3

NR-5 E70T-3

NS-3M E70T-4 E4802T-4-CH JIS

NR-305 E70T-6 2SA-2YSA IIYMS(2) SA2YM(2) E4802T-6-CH 2YS(2) JIS

NR-311 E70T-7 E4802T-7-CH JIS

NR-131 E70T-10 JIS

NR-311 Ni E70TG-K2 2SA-2YSA 2S-2YS IIYMS SA2YM 2YS JIS

NR-202 E71T-7

NR-203MP E71T-8J 3SA-3YSAH15 3S-3YSH15 IIIYMSH15 SA3YMH E4801T-8-CH 3YSH15 JIS

NR-203M E71T-8J 3SA-3YSA 3S-3YS

NR-232 E71T-8 3SA-3YSAH15 3S-3YSH15 IIIYMSH15 SA3YMH E4801T-8-CH 3YSH10 MIL-71T-8AS JIS, TUV

NR-203 Ni E71T8-K2 JIS

C Plus

NR-207 E71T8-K6 IIIYMSH15 SA3YMH E71T8-K6-H16 3YSH15 JIS, TUV

NR-207-H E71T8-K6 JIS, TUV

NR-203 E71T8-Ni1 3SA-3YSA 3S-3YSH15 IIIYMSH15 E71T8-Ni1-H16 3YSH15 JIS, TUV

Nickel 1%

NR-211-MP E71T-11 E4801T-11-CH JIS

NR-212 E71TG-G E71TG-G-CH JIS

NR-152 E71T-14 JIS

NR-208-H E91T8-G JIS, TUV

42

ABS: American Bureau of Shipping

Lloyd’s: Lloyd’s Register of Shipping

DNV: Det Norske Veritas

GL: Germanischer Lloyd

BV: Bureau Veritas

(1) Approvals are updated periodically. Consult your local Lincoln district office for the latest Approval/Grade revision.

(2) 3/32” diameter only.

(3) Tested at -40°F.

AGENCY APPROVALS(1)

43

Customer Assistance Policy

The business of The Lincoln Electric Company is manufacturing and selling high quality welding equipment, consumables, and cut-

ting equipment. Our challenge is to meet the needs of our customers and to exceed their expectations. On occasion, purchasers

may ask Lincoln Electric for advice or information about their use of our products. We respond to our customers based on the best

information in our possession at that time. Lincoln Electric is not in a position to warrant or guarantee such advice, and assumes no

liability, with respect to such information or advice. We expressly disclaim any warranty of any kind, including any warranty of fitness

for any customer’s particular purpose, with respect to such information or advice. As a matter of practical consideration, we also

cannot assume any responsibility for updating or correcting any such information or advice once it has been given, nor does the

provision of information or advice create, expand or alter any warranty with respect to the sale of our products.

Lincoln Electric is a responsive manufacturer, but the selection and use of specific products sold by Lincoln Electric is solely within

the control of, and remains the sole responsibility of the customer. Many variables beyond the control of Lincoln Electric affect the

results obtained in applying this type of fabrication methods and service requirements.

STORING INNERSHIELD ELECTRODES

In general, Innershield electrodes will produce weld deposits

which achieve hydrogen levels below 16 ml per 100 grams

deposited metal. These products, like other products which

produce deposits low in hydrogen, must be protected from

exposure to the atmosphere in order to maintain hydrogen

levels as low as possible, preventing rusting of the product

and prevent porosity during welding. Accordingly, the follow-

ing storage conditions are recommended for Innershield

lectrodes in their original, unopened boxes and plastic bags.

The recommended storage conditions are such that they

maintain condition of 90 grains of moisture per pound of

dry air. Examples of storage conditions that will meet this

requirement are given below:

For best results, electrode should be consumed as soon as

practicable. However, it may be stored up to three years from

the date of manufacture. Consult your Lincoln distributor or

sales representative if there is a question as to when the

electrode was made.

Once the electrode packaging is opened, Innershield elec-

trodes can be subject to contamination from atmospheric

moisture. Care has been taken in the design of these prod-

ucts to select core ingredients that are essentially resistant to

moisture pick-up; however, condensation of the moisture

from the atmosphere onto the surface of the electrode can be

sufficient enough to degrade the product.

The following minimum precautions should be taken to safe-

guard product after opening the original package. Electrode

should be used within approximately 1 week after opening the

original package. Opened electrode should not be exposed to

damp, moist conditions or extremes in temperature and/or

humidity where surface condensation can occur. Electrodes

mounted on wire feeders should be protected against con-

densation. It is recommended that electrode removed from its

original packaging be placed in poly bags (4 mil minimum

thickness) when not in use.

Ambient Maximum

Temperature Relative

Fahrenheit Celsius Humidity

60° - 70° (16° - 21°) 80%

70° - 80° (21° - 27°) 60%

80° - 90° (27° - 32°) 45%

90° - 100° (32° - 38°) 30%

Innershield electrodes will evidence high moisture levels in the

form of gas tracks, higher spatter and porosity. Any rusty elec-

trode should be discarded.

Innershield Products Used for Applications Requiring

More Restrictive Hydrogen Control

The AWS specifications for flux-cored electrodes, ANSI/AWS

A5.20, states that “Flux-cored arc welding is generally

considered to be a low hydrogen welding process”. To further

clarify the issue, this specification makes available optional

supplemental designators for maximum diffusible hydrogen

levels of 4, 8 and 16 ml per 100 grams of deposited weld

metal.

Some Innershield products have been designed and manufac-

tured to produce weld deposits meeting more stringent dif-

fusible hydrogen requirements. These electrodes are usually

distinguished by an “H” added to the product name. These

electrodes will remain relatively dry under recommended

storage conditions in their original, unopened package or

container.

For critical applications in which the weld metal hydrogen

must be controlled (usually H8 or lower), or where shipping

and storage conditions are not controlled or known, only

hermetically sealed packaging is recommended. Innershield

electrodes are available in hermetically sealed packages on a

Special Order basis.

Once the package has been opened, the electrode should not

be exposed to conditions exceeding 80% relative humidity for

a period greater than 16 hours, or any less humid condition for

greater than 24 hours. Conditions that exceed 80% RH will

decrease the maximum 16 hour exposure period.

After exposure, hydrogen levels can be reduced by condition-

ing the electrode. Electrode may be conditioned at a tempera-

ture of 230ºF (110°C) ± 25ºF (-3.8°C) for a period of 6 to 12

hours, cooled and then stored in sealed poly bags (4 mil mini-

mum thickness) or equivalent. Electrode on plastic spools

should not be heated at temperatures in excess of 150ºF.

Electrode that is rusty should be discarded.

www.lincolnelectric.com

THE

LINCOLN ELECTRIC

COMPANY

Local Sales and Service through Global

Subsidiaries and Distributors

Cleveland, Ohio 44117-1199 U.S.A

TEL: 216.481.8100

FAX: 216.486.1751

WEB SITE: www.lincolnelectric.com

Cored Wire

C3.2000 3/00

LINCOLN NORTH AMERICA

DISTRICT SALES OFFICES

LATIN AMERICA

Miami, Florida U.S.A.

Phone: (305) 888-3203

EUROPE

The Netherlands

Phone: 31 24 3522 911

RUSSIA, AFRICA & MIDDLE EAST

Cleveland, Ohio U.S.A.

Phone: (216) 481-8100

ASIA PACIFIC

Singapore

Phone: 65 276 0878

LINCOLN INTERNATIONAL HEADQUARTERS

HARRIS CALORIFIC DIVISION

2345 Murphy Blvd., Gainesville, Georgia 30504 U.S.A.

Phone: 1-800-241-0804 • Fax: (770) 535-0544 • Web Site: www.harriscal.com

DISTRIBUTED BY:

USA

ALABAMA

BIRMINGHAM 35124-1156

(205) 988-8232

MOBILE 36693-4310

(334) 666-6524

ALASKA

Contact SEATTLE

District Office

(206) 575-2456

ARIZONA

PHOENIX 85260-1768

(602) 348-2004

ARKANSAS

LITTLE ROCK 72116-7034

(501) 771-4842

CALIFORNIA

FRESNO 93722-3949

(209) 276-0110

LOS ANGELES 90670-2936

(562) 906-7700

SACRAMENTO 95677-4729

(916) 630-1885

SAN DIEGO 92108-3911

(619) 208-9001

SAN FRANCISCO 94550-9657

(925) 443-9353

COLORADO

DENVER 80112-5115

(303) 792-2418

CONNECTICUT

NORTH HAVEN 06238

(860) 742-8887

WASHINGTON DC

HERNDON, VA 20170-5227

(703) 904-7735

FLORIDA

JACKSONVILLE 32259-4396

(904) 287-9595

MIAMI 33178

(305) 888-3203

ORLANDO 32714-1974

(407) 788-8557

TAMPA 33619-4480

(770) 475-0955

GEORGIA

ATLANTA 30076-4914

(770) 475-0955

SAVANNAH 31401-5140

(912) 231-9604

HAWAII

See SEATTLE

District Office

(206) 575-2456

ILLINOIS

CHICAGO 60521-5629

(630) 920-1500

PEORIA 61607-2046

(309) 697-8240

INDIANA

FT. WAYNE 46825-5547

(219) 484-4422

SOUTH BEND 46530-0577

(219) 277-8619

INDIANAPOLIS 46038-9459

(317) 845-8445

IOWA

CEDAR RAPIDS 52402-3160

(319) 362-6804

DAVENPORT 52806-1344

(319) 386-6522

DES MOINES 50265-6218

(515) 224-4121

KANSAS

KANSAS CITY 66214-1625

(913) 894-0888

WICHITA 67037

(316) 788-7367

KENTUCKY

LOUISVILLE 40203-2906

(502) 636-5125

LOUISIANA

BATON ROUGE 70809-2256

(504) 922-5151

SHREVEPORT 71108-2521

(318) 869-3531

MARYLAND

BALTIMORE 21050

(443) 831-0416

MASSACHUSETTS

BOSTON 02154-8414

(781) 899-2010

MICHIGAN

DETROIT 48034-4005

(248) 353-9680

FLUSHING 48433-1855

(810) 487-1310

GRAND RAPIDS 49512-3924

(616) 942-8780

MINNESOTA

MINNEAPOLIS 55447-5435

(612) 551-1990

MISSISSIPPI

JACKSON 39212-9635

(601) 372-7679

MISSOURI

KANSAS CITY (KS) 66214-1625

(913) 894-0888

ST. LOUIS 63146-3572

(314) 993-5465

MONTANA

Contact SEATTLE

District Office

(206) 575-2456

NEBRASKA

OMAHA 68046-2826

(402) 339-1809

NEW JERSEY

EDISON 08837-3939

(732) 225-2000

NEW MEXICO

ALBUQUERQUE 87111-2158

(505) 237-2433

NEW YORK

ALBANY 12065-1139

(518) 877-8278

BUFFALO 14225-5515

(716) 681-5554

NEW YORK CITY

(888) 269-6755

EAST SYRACUSE 13057-1040

(315) 432-0281

NORTH CAROLINA

CHARLOTTE 28273-6200

(704) 588-3251

RALEIGH 27604-8456

(919) 231-5855

OHIO

CINCINNATI 45242-3706

(513) 554-4440

CLEVELAND 44143-1433

(216) 289-4160

COLUMBUS 43221-4073

(614) 488-7913

DAYTON 45439-1254

(937) 299-9506

TOLEDO 43528-9483

(419) 867-7284

OKLAHOMA

OKLAHOMA CITY 73119-2416

(405) 686-1170

TULSA 74146-1622

(918) 622-9353

OREGON

PORTLAND 97230-1030

(503) 252-8835

PENNSYLVANIA

BETHLEHEM 18020-2062

(610) 866-8788

ERIE 16506-2979

(814) 835-3531

JOHNSTOWN 15905-2506

(814) 535-5895

PHILADELPHIA 19008-4310

(610) 543-9462

PITTSBURGH 15275-1002

(412) 787-7733

YORK 17404-1144

(717) 764-6565

SOUTH CAROLINA

GREENVILLE 29681-4724

(864) 967-4157

COLUMBIA 29209

(803) 783-2851

SOUTH DAKOTA

SIOUX FALLS 57108-2609

(605) 339-6522

TENNESSEE

KNOXVILLE 37923-4506

(423) 693-5513

MEMPHIS 38115-5946

(901) 363-1075

NASHVILLE 37210-3816

(615) 316-9777

TRI-CITIES 37604-3338

(423) 928-6047

TEXAS

DALLAS 76051-7602

(817) 329-9353

HOUSTON 77060-3143

(281) 847-9444

SAN ANTONIO 78133-3502

(830) 964-2421

UTAH

MIDVALE 84047-3759

(801) 233-9353

VIRGINIA

HERNDON 20170-5227

Washington, D.C.

(703) 904-7735

ROANOKE 24153-1447

(800) 916-0778

WILLIAMSBURG 23602-7048

(757) 870-5508

WASHINGTON

SEATTLE 98188-7615

(206) 575-2456

SPOKANE 99005-9637

(509) 468-2770

WEST VIRGINIA

CHARLESTON 25526-9796

(304) 757-9862

WISCONSIN

GREEN BAY 54302-1829

(920) 435-1012

MILWAUKEE 53186-0403

(262) 650-9364

CANADA

ALBERTA

CALGARY T2H 2M3

(403) 253-9600

EDMONTON T6H 2K1

(403) 436-7385

WINNIPEG R3N 0C7

(204) 488-6398

BRITISH COLUMBIA

VANCOUVER V3B 7A2

(604) 844-5209

MARITIMES

NOVA SCOTIA B2X 3N2

(902) 434-2725

MANITOBA

WINNIPEG R3N 0C7

(204) 488-6398

ONTARIO

TORONTO M4G 2B9

(416) 421-2600

QUEBEC

MONTREAL J5Y 2G3

(514) 654-3121
