Care and Handling of Surgical Instruments
The methods discussed have been validated for cleaning and sterilizing medical devices
distributed by Invotec International and other fine surgical instrument suppliers. They have
been developed using standard equipment and practices common to most health care
facilities. Manual cleaning methods, steam and ETO sterilization were used as much as
possible.
The Sterilization Guidelines presented are based on type of product, placed into specific
categories.
Category Type of Product
Instruments with rough surfaces Applicators, burs, rasps, brushes, curettes
Instruments with sliding hinges
Adenotomes, forceps, punches, rongeur
Instruments with screw pivot hinges Scissors, specula, retractors, calipers
Instruments whose surfaces that can be
marred, scored, or scratched.
Mallet heads, cutting blocks, Instruments
made of or having Delrin® (DupontTM)
surfaces, specula, mixing bowls.
Instruments with lumens and channels Suction tips, cannulas, needles.
Recommended Cleaning Supplies:
•Enzyme solution (i.e. Klenzyme®), detergent (Manu-Klenz®) lukewarm water, soft
bristle brush, and a clean soft towel.
•Detergents: Proteolytic enzymatic detergents with a pH range between 6.0 and 8.0
should be used. These detergents have nonionic surfactants. Detergents should be
used in a concentration level recommended by the manufacturer. NOTE: Undiluted
detergents and those with pH's greater than 8.0 can strip the coloration from metal
instruments.
•Ultrasonic Cleaners designed for fine cleaning of medical devices.
Cleaning Procedure:
1. Soak for a minimum of two (2) minutes in enzyme solution
2. Rinse thoroughly under lukewarm water
3. Manually clean with a soft bristle brush while immersed in a detergent solution,
paying close attention to crevices and hard-to-clean areas.
a. If using a power washer, close adherence to washer manufacturers’
procedures should be followed.
4. Rinse thoroughly under lukewarm water
5. Dry with a clean soft cloth
6. Visibly examine for damage, rust deposits, and cleanliness.
III
Sterilization Recommendations
Device
Type
Prevacuum
Wrapped
Prevacuum
Unwrapped
Gravity
Unwrapped
Gravity
wrapped EO Chemical
Disinfectant
Chemical
Sterilant
Peracetic
Acid
Gas
Plasma
Rough
Surfaces YES YES YES YES YES YES YES YES YES
Sliding
Hinges YES YES YES YES YES YES YES YES YES
Lever
Hinges YES YES YES YES YES YES YES YES YES
Screw Pivot YES YES YES YES YES YES YES YES YES
Lumens YES YES YES YES YES YES YES NO YES
Sterilization
Trays YES YES YES YES YES YES YES NO NO
Steam
Sterilizable
Endoscopes
YES YES YES YES YES YES YES YES YES
A “NO” indicates Invotec International does not have the data to support the recommendation
of the specific method of sterilization for a given category.
Cycle Parameters
Prevacuum Cycle (wrapped and unwrapped): Three (3) preconditioning pulses with a minimum
exposure time of 4 minutes at 270˚F (132˚C).
Gravity Cycle (wrapped): 270˚F (132˚C) with a minimum exposure time of 15 minutes.
Gravity Cycle (Unwrapped): 270˚F (132˚C) with a minimum exposure time of 10 minutes.
Ethylene Oxide Cycle
Sterilant
Temperature
Humidity
Preconditioning
Concentration
Exposure
100% EO 131˚F (55˚C) 65-75% 1 hour 725 mg/l 120-360 minutes
Aerate a minimum of 12 hours at 131 ˚F (55˚C)
Liquid Chemical Cycle
Concentration of
Glutaraldehyde
Temperature Exposure for
Disinfection
Exposure for
Sterilization
2.4% 77˚F (25˚C) 45 minutes 10 hours
•Implants are sold as one-time use items and not intended for re-sterilization.
•Most reusable instruments are sold nonsterile. These devices should be placed into
suitable packaging for the sterilization process (i.e., central supply wrap (CSR),
autoclave bags, paper/Tyvek® pouches, dedicated sterilization trays and sterilized prior
to use. All instruments should be examined and cleaned prior to sterilization.
ORO/NAS INS
ORO/NAS INS
R&CS ACC
OSS
OTO ACC
DIS
LAR INS
OTO INS
RHI INS
LAR ACC
SPE ACC
PSB
OTO ACC
R&CS ACC DIS OSS LAR ACC SPE ACC RHI INS PSB OTO INS LAR INS
CONTENTCONTENT
ACCESSORIES
RHINOLOGY AND COSMETIC SURGERY Swiss Therapy™ Cold Therapy 1
Scar Sheeting 2
Skin Markers 3
Micro Electro Dissection Needle 3
Chin Implants 4
Malar Implants 5
Implantable Silicone Blocks 5
Nasal Dorsal Implants 6-7
Silicone Sheeting, Tubing and Blocks 8
Septal Buttons 8
Internal Nasal Splints 9-10
External Nasal Splints 11
Dressing and Packing 12-13
Gelatin Packing 14
Hyaluronic Acid Gel 15
Silicone Epistaxis Balloon 16
Rhinology Knives and Blades 17
DISPOSABLE SUCTIONS Rhinologic and Otologic 21-23
OTOLOGY Dressing and Packing 27
Burs - Ultrabur Drill 28
Myringotomy Knives & ENT Blades 29-30
Phenol Applicator 31
Myringotomy Kits & Specula 31
Ventilation Tubes 32-34
Otovent® Middle Ear Auto Ination 35
OSSICULAR PROTHESIS Incus 39-40
Incus-Stapes 41
Partial 42-43
Total 44-45
Serenocem 46
Canal Wall 47
Caps and Shoes 47
Stapes 48-49
Bucket Handles 50
Nitinol Stapes 51-52
Instrumentation 53
Trials 54
Accessories 55
LARYNGEAL Tracheal T-tubes 59
Disposable Adenoid Curettes 59
Surface Electrodes 60
SPECIALTY PRODUCTS Lighting Systems 63-66
Ophthalmic Sponge Packing 67
Cotton Tipped Applicators 68
Anti-fog 68
Headrest 68
Sterilization Trays 69
RHINOLOGY INSTRUMENTS
Telescopes 73-74
Forceps 75-83
Antrum Punches, Back Biters and Kerrisons 84-89
Nasal Scissors 90-94
Knives and Blades 95
Osteotomes, Chisels and Saws 96-99
Elevators and Probes 100-101
Septum Instruments 102-103
Curettes 104-105
Speculas 106-108
Retractors, hooks 109-112
Rasps 113-115
Sinus Suction Tips 116-117
Mallets 118
Needle Holders, Wire Twisters 119-122
Tissue Thumb Forceps 123
Miscellaneous Nasal and Sinus 124-126
Measuring Instruments 127
PARANASAL, SKULL BASE, PITUITARY INSTRUMENTS
Retractors 131
Forceps 132-133
OTOLOGY INSTRUMENTS
TUNING FORKS Tuning Forks 137
EXTERNAL EAR CANAL INSTRUMENTS Ear Speculum 138-139
Ear Curettes 140
Loops & Hooks 141-143
Probes 143
Tympanum Perforators 144-145
Ear Catheters 146
Air Bags 147
Powder Blower 147
MIDDLE EAR INSTRUMENTS Instrument Set 148
Suctions 149-150
Elevators 151-152
Snares 153
Rongeurs 154
Ear Forceps 155-160
R&CS ACC
OSS
OTO ACC
DIS
LAR INS
OTO INS
RHI INS
LAR ACC
SPE ACC
PSB
Ear Scissors 161
Malleus Forceps 162
Needles/Picks 163
Hooks 164-165
Tympanoplasty Knives 166-169
Micro Elevators 170-171
Stapes Curettes 172
Footplate Drill 173
Mobilizers 174
Measuring & Cutting 175
LARYNGEAL INSTRUMENTS
MICRO LARYNGOSCOPY Operating Largyngoscopes 179-180
Scissors and Forceps 181-187
Micro Knives and Elevators 188-189
Suctions 190-191
Injection Needles 192
LASER MICRO SURGERY Suctions and Protectors 193-194
BRONCHOESOPHAGOSCOPY Forceps 195-198
Suctions 199
Accessories 200
ORONASOPHARYNGEAL INSTRUMENTS
Adenotomes 203
Adenoid Currettes 204-206
Laryngeal Mirrors 207-208
Mouth Gags - Tongue Depressors 209-215
Retractors 216-218
Tongue Spatulas 219-221
Nasopharynx Forceps 222-225
Tonsil Artery Forceps 226-227
Tonsil Seizing Forceps 228-229
Tonsil Knives 230-231
Tonsil Screws 232
Tonsil Dissectors 233-234
Tonsil Scissors 235-236
Tonsil Snares 237-239
Tonsiltome 240
Tonsilletomy Instruments 241-242
Tonsil Needles 243
Suctions 244-245
Tonsil Accessories 246
ORO/NAS INS
OTO ACC
R&CS ACC DIS OSS LAR ACC SPE ACC PSB OTO INS LAR INSRHI INS
1
Swiss Therapy™
SWISS THERAPY™ EYE AND FULL FACE MASKS
An easy to use, post-operative cold compress for a variety of plastic surgery or cosmetic
