May 13, 2011
To Our Valued Customers:
At the close of business Monday, June 13, 2011 we will implement a group of list price changes. We apolo-
gize for having to increase prices again so close to the May 9, 2011 price change. Unfortunately we have
been left with little choice.
We have received urgent price increase notices from major U.S. manufacturers implementing their increases
without notice. What is common to these manufacturers is that they all use chemical components that are
petroleum based. The affected products are silicones, sealants, lubricants, solvent cements and primers.
Also note that other manufacturers are increasing prices due to fuel, overhead and continued raw material
cost increases.
The following page is an initial tab listing of the product groups that are changing at the close of business
Monday, June 13, 2011. The new list prices will be available on our website at www.americangranby.com on
or about June 6, 2011. Changes will be indicated in bold type. Catalog pages with list pricing can be viewed
and downloaded for printing to update your AGI catalog. Excel files are also available for download on the
site. We will not be mailing a hard-copy price change mailing.
If you do not have access to our website, please contact your sales representative or Customer Service and
we will forward you a copy of the Excel spreadsheet or the new catalog pages.
Sincerely,
Gary Palley
V.P. Sales & Marketing
7652 Morgan Road
Liverpool, New York 13090
(315) 451-1100
Fax: (315) 451-6928
www.americangranby.com
The Original Source of Vendor Consolidation
Product Page Numbers
Pool Rope & Rope Accy P.03
Relief Valves P.05
Float Valves P.24
Butterfly Valves P.25
Clear Braided Hose P.31
Boss Silicones P.41 - P.42
Tank Crosses 1.07
Tank Crosses 1.10a - 1.10b
Tank Crosses 1.11
Relief Valves / Tank Accy 1.23 - 1.24
Clear Braided Hose 1.25
Air Volume Controls/Releases 1.27 - 1.28
Installation Accy 1.29 - 1.30
Insert Fittings 1.31 - 1.32
Flow Control Valves 1.35 - 1.36
Pitless Adapters 1.55
Well Point Supplies 1.68
Pitcher Pump 1.71
Cylinder parts 1.78
Rod Couplings 1.80
Jet Lube 1.90 - 1.94
Check Valves 2.01 - 2.04
Foot Valves 2.05
Hydrants 2.17
Hydrants 2.19
Ball Valves - NEW 3.02
Ball Valves / Float Valves 3.03 - 3.04
Swing Check Valves 3.06
Plumbing Valves 3.07 - 3.08
Butterfly Valves 3.23
RO Systems - NEW 4.08a
UV Systems 4.46 - 4.48
INSTRUCTIONS FOR OBTAINING LIST PRICE CHANGE DATA - JUNE 14, 2011
To obtain copies of our list price changes go to www.americangranby.com. Click the DOWNLOAD tab.
There are multiple options for you to download.
• For an Excel file of the latest list price changes in alpha numeric order: On the left under PRICE CHANGE UPDATES click on the
6/14/11 Price Change Excel File. This Excel file can be re-sorted or filtered as you need and includes both old and new list
prices plus the % change. This file can be used as a reference or update to your operating system.
• For a .PDF version of only the updated catalog pages: On the left under PRICE CHANGE UPDATES click on the 6/14/11
Catalog Page Changes PDF file. Print out only the catalog pages with changes and insert into your current product catalog.
• Click on FULL CATALOG and SECTION DOWNLOADS for .PDF files of the Full Granby Catalog or for specific sections.
Product Page Numbers
Galv Compression Ftgs 6.02
Pipe Repair Clamps 6.03
Clear Braided Hose 6.13
Wax Gaskets 6.18
Hanger Strapping 6.27
Pipe Straps 6.29 - 6.30
Pipe Hooks 6.31 - 6.32
Pipe Hangers 6.33 - 6.34
Pipe Hangers 6.35 - 6.36
Stud Protectors 6.39
Tapes 7.02
Boss Silicones 7.09 - 7.12
Dow Silicones 7.14
Cements, Primers Cleaners 7.17 - 7.26
Super Lube 8.05 - 8.09
Plumbing Tools 11.09 - 11.10
Insert Fittings - Red Brass 12.03 - 12.04
Insert Fittings - Steel 12.05 - 12.06
Insert Fittings - Steel / YB 12.07 - 12.08
Galv Compression Couplings 12.16
Pipe Repair Clamps 12.17
Merchant Couplings 12.25
Threaded Bronze 12.27 - 12.32
Import Malleables 12.33 - 12.40
Domestic Malleables 12.41 - 12.48
Nipples - RB 12.50
Nipples - Steel 12.51 - 12.52
6/14/11
P.3
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Pool Rope - Twisted/Braided
Pool Rope Features:
• Polypropylene.
• Floatable.
• Waterproof.
• Rot Resistant.
• Easy to Handle.
• Resists Oil and Gasoline.
• Resists Most Chemicals.
• Resistant to Abrasion.
• Resistant to Color Fading.
Part Number Color Diameter Length List Price
Twisted Pool Rope
PR25-6 Blue/White 1/4” 600’ $ 69.53
PR38-4 Blue/White 3/8” 400’ 111.43
PR38-6 Blue/White 3/8” 600’ 166.10
PR50-3 Blue/White 1/2” 300’ 131.10
PR50-6 Blue/White 1/2” 600’ 262.22
PR58-6 Blue/White 5/8” 600’ 448.38
PR75-3 Blue/White 3/4” 300’ 294.77
PR75-6 Blue/White 3/4” 600’ 589.57
PR38-3R Red/White 3/8” 300’ 83.05
PR38-6R Red/White 3/8” 600’ 166.10
PR50-3R Red/White 1/2” 300’ 131.10
PR50-6R Red/White 1/2” 600’ 262.22
PR75-3R Red/White 3/4” 300’ 294.77
PR75-6R Red/White 3/4” 600’ 589.57
PR38-3O Orange/White 3/8” 300’ 83.05
PR38-6O Orange/White 3/8” 600’ 166.10
PR50-3O Orange/White 1/2” 300’ 131.10
PR50-6O Orange/White 1/2” 600’ 262.22
PR75-3O Orange/White 3/4” 300’ 294.77
PR75-6O Orange/White 3/4” 600’ 589.57
PR38-3W Solid White 3/8” 300’ 83.05
PR38-6W Solid White 3/8” 600’ 166.10
PR50-3W Solid White 1/2” 300’ 131.10
PR50-6W Solid White 1/2” 600’ 262.22
PR75-3W Solid White 3/4” 300’ 294.77
PR75-6W Solid White 3/4” 600’ 589.57
YR25-500 Solid Yellow 1/4” 500’ 50.89
YR25-1 Solid Yellow 1/4” 1000’ 98.93
Braided Pool Rope
BPR38-5 Blue/White 3/8” 500’ 96.24
Splicing Fid
FID Splicing Fid, For 3/8” braided rope 2.18
FID
BPR Series
PR Series
5/3/11
P.4
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Pool Rope Anchors & Hooks
Part Number Description Ctn Qty List Price
HOE2 Chrome Plated Brass CURVED COPING MOUNT 72 $ 11.45
Oval Rope Anchor (Set of 2 w/ ss self tap screws)
HOE2F Chrome Plated Brass FLAT WALL MOUNT 6/72 12.87
Oval Rope Anchor (Set of 2 w/ ss self tap screws, EPDM gasket)
HOE2FB Chrome Plated Brass FLAT WALL MOUNT 6/72 20.76
Oval Rope Anchor w/ brass mounting bracket and hardware
(Set of 2 w/ ss screws, EPDM gasket, brass mounting brackets)
HCA Chrome Plated Brass Cup Anchor for 12/120 9.81
concrete pools.
HEBA Chrome Plated Brass wall mount eye with washer 20/200 12.32
gasket and nut for vinyl liners. 1-3/8” long bolt
HPRS Chrome Plated Strap Type Rope Anchor 12/252 12.47
used under coping for vinyl pools. 14” long
HRH Chrome Plated Brass “S” Rope Hook 500 5.04
for 1/4”-1/2” rope
AGHP52 CLEAT Style Chrome Plated Brass Hook 125 15.39
for 3/8” & 1/2” rope w/ ss screws
AGHP53 CLEAT Style Chrome Plated Brass Hook 125 20.04
for 3/4” rope w/ ss screws
HCA HEBA
HRH
HPRS
AGHP
Chrome Plated Brass Rope Accessory Features:
• Bright chrome finished brass rope accessories.
• Precision cast from corrosion resistant brass.
• Stainless steel fasteners.
• Black or White EPDM gaskets.
• Fully assembled.
HOE2FB
HOE2F
HOE2
HOE2
6/14/11
P.5
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Pool Heater Accessories
LR SERIES Features:
• For use with Laars-Raypak pool and spa heaters.
• Available in copper or stainless steel, with plastic quick connect union or
bronze male adapter.
Part Number Size Ctn Qty List Price
Copper Tube with 1 Bronze Male Adapter
LR617 1-1/2” x 6” x 17” 12 $ 119.95
LR619 1-1/2” x 6” x 19” 12 125.82
LR623 1-1/2” x 6” x 23” 12 136.81
LR626 1-1/2” x 6” x 26” 12 139.01
LR623-2 2” x 6” x 23” 6 186.43
Copper Tube with Plastic Quick Connect Union
LR617UN 1-1/2” x 6” x 17” 8 108.79
LR623UN 1-1/2” x 6” x 23” 8 119.78
Stainless Steel Tube with Plastic Quick Connect Union
LR617SSUN 1-1/2” x 6” x 17” 8 104.40
LR619SSUN 1-1/2” x 6” x 19” 8 111.92
LR621SSUN 1-1/2” x 6” x 21” 8 123.24
LR623SSUN 1-1/2” x 6” x 23” 8 128.08
LR626SSUN 1-1/2” x 6” x 26” 8 146.98
LR617-2SSUN 2” X 6” X 17” 6 147.20
LR619-2SSUN 2” X 6” X 19” 6 151.37
LR623-2SSUN 2” X 6” X 23” 6 165.44
Replacement Union Assembly
PHU150 LR/PL Series-1-1/2” 1 23.41
PHU200 LR/PR Series-2” 1 26.54
Union O-Ring
PHU150 O-RING 1 1/2” o-ring 1 2.64
PHU200 O-RING 2” o-ring 1 2.64
Heater Union Repair Split Nut
HSNR150 1 1/2” FBT Heater Split Nut Set w/ screws 125 4.42
HSNR200 2” FBT Heater Split Nut Set w/ screws 100 4.98
LR Series LRUN Series
Hot Water Swimming Pool Heater
Safety Relief Valve Features:
• Bronze safety relief valve protects ASME Section IV hot water
heating boilers and hydronic heating systems.
• High capacity design features corrosion resistant construction.
• Ideal for use in swimming pool heater applications, hot water boilers and
hydronic heating systems.
• ASME Section IV.
• Set pressure 75 psi. 20-80 psig certified pressure range.
• Maximum temperature service 250ºF
• Stainless steel springs.
• Registered in all Canadian provinces and territories, CRN #0G8547.5C
• Made in USA.
Part Number Description Height Ctn Qty List Price
10-417-15 3/4” M/F Safety relief valve 3” 100 $ 42.13
10-417-15
5/3/11
P.6
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Equipment Pads
HEF-T-PADTM Features:
• Injection molded from high impact polyolefin for strength and durability.
• Resistant to impact, UV degradation and weathering.
• Will not crack, flake or warp.
• Virtually impervious to climate changes.
• Drillable, permits installation of refrigerant
and electrical lines under and through pad.
Also permits equipment to be easily secured
to pad.
• Unique, non-creep surface absorbs vibration
and noise and keeps equipment in it’s original
position.
• Gray
Part Number Size Pallet Qty List Price
2” HEF-T-PADS
X2424211 24” x 24” x 2” one piece 24 $ 52.18
X2430211 24” x 30” x 2” one piece 24 66.41
X2436211 24” x 36” x 2” one piece 24 80.24
X3232211 32” x 32” x 2” one piece 24 85.33
X3244211 32” x 44” x 2” one piece 24 107.51
X3636211 36” x 36” x 2” one piece 24 106.67
X3830211 38” x 30” x 2” one piece 24 86.92
X3836211 38” x 36” x 2” one piece 24 110.69
X3842211 38” x 42” x 2” one piece 24 139.77
3” HEF-T-PADS
X2424311 24” x 24” x 3” one piece 16 63.99
X2436311 24” x 36” x 3” one piece 16 98.62
X3030311 30” x 30” x 3” one piece 16 81.75
X3232311 32” x 32” x 3” one piece 16 98.94
X3244311 32” x 44” x 3” one piece 16 131.40
X3636311 36” x 36” x 3” one piece 16 133.90
X3848311 38” x 48” x 3” one piece 16 172.56
X5055301 50” x 55” x 3” modular 16 308.71
X2600311 26” diameter round x 3” one piece 16 61.03
2/15/11
P.23
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Check Valves - PVC Spa, By-Pass
Part Number IPS Size Body Length Ctn Qty List Price
PVC Spa Air Valve - 1-1/2” ips socket / 2” ips o.d. spigot
1050-20 2” 5-1/8” 12 $ 26.38
PVC In Line By-Pass Check Valve
1095-20 2” w/ 5# spring 5” 12 33.27
CPVC 90° Spring Check Valve, w/ stainless steel poppet
1901-15 1 1/2” check valve, 1 lb. tension 12 82.32
1903-15 1 1/2” check valve, 3 lb. tension 12 82.32
1901-20 2” socket x 2 1/2” spigot valve, 1 lb. tension 12 82.32
1903-20 1” socket x 2 1/2” spigot valve, 3 lb. tension 12 82.32
1050 Series
1901/1903 Series
1095 Series
PVC Spa Air Valve Features:
• Drip proof seal at low pressure.
• 1 1/2” IPS deep socket connection with 2” IPS OD spig-
ot
• Excess solvent cement trap at base of socket to help
prevent solvents from entering sealing area.
• Minimum restriction of air flow, using 1/4 lb. spring
resulting in less burden on blower motor.
• Domed shaped seat for even air flow.
• EPDM seal.
• Stainless steel spring.
PVC In-Line By-Pass Check Valve Features:
• In-line shape takes less space.
• Raised valve seat prevents excess cement of solvent
from affecting the seal area.
• Poppet is equipped with EPDM seal.
• Body is made of Type 1 PVC.
• All metal parts are stainless steel.
• Valve stem is reinforced w/ full length stainless steel shaft.
• Static pressure tested: 150 psi @ 72°F. Back pressure tested at 150 psi.
• Quick burst test proves in excess of 500 psi
• 2” iron pipe size
• Valve can be used on 1-1 1/2” pipe by use of a PVC Sch 40 bushing.
• Begins to open at 1/2 lb. or 5 lb.
• NSF approved.
CPVC 90° Spring Check Valve Features:
• Use in pool, spa applications.
• CPVC body with corrosion proof poppet.
• Spring made of 302 stainless.
• Available with 1 lb. or 3 lb. spring tension.
• NSF approved.
See “FLO/NDS” tab for
a complete line of Flo
Control PVC check
valves.
6/14/11
P.24
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Bronze Float Valves
Bronze Float Valve Features:
• Cast bronze body
• Buna-N Disc
• Heavy Duty
• Tapped for 1/4-20SAE rod
• Threaded outlet
• Rated at 125 psi.
BFV Series
Part Number Size Inlet Outlet Tapped Ctn/Case Qty List Price
BFV1/2 1/2” 1/2” mpt 1/2” mpt 1/4”-20SAE 10/100 $ 29.70
BFV3/4 3/4” 3/4” mpt 3/4” mpt 1/4”-20SAE 10/80 35.83
BFV1 1” 1” mpt 1” mpt 1/4”-20SAE 10/40 47.34
Brass Rods Features:
• Brass SAE
• Male thread both ends
BFVR Series
Part Number Length Thread Fits Valve Size Ctn/Case Qty List Price
BFVR8 8” 1/4”-20SAE 1/2” - 1” 50/400 $ 6.62
BFVR10 10” 1/4”-20SAE 1/2” - 1” 50/300 7.67
BFVR12 12” 1/4”-20SAE 1/2” - 1” 50/300 8.59
Plastic Float Features:
• Lightweight, Corrosion resistant PVC
• Up to 175°F
• For open tank service only
BFVFP Series
Part Number Float Diam. Buoyancy Female Connection Ctn Qty List Price
BFVFP5 5” 2.17 lbs. 1/4”-20SAE 100 $ 21.23
BFVFP6 6” 3.8 lbs. 1/4”-20SAE 100 25.00
BFVFP8 8” 9.87 lbs. 1/4”-20SAE 20 31.08
6/14/11
P.25
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Butterfly Valves - Cast Iron
Flanges & Bolt kits available,
see page P.28
ISO 9002
HBFV Series
Part No. Size Weight(lbs) Ctn Qty List Price
Ductile Iron ENP Plated Disc*
HBFV2 2” 7 1 $ 107.09
HBFV21/2 2-1/2” 8 1 126.65
HBFV3 3” 10 1 162.95
HBFV4 4” 12 1 209.38
HBFV5 5” 15.5 1 229.78
HBFV6 6” 17.5 1 273.75
HBFV8 8” 33 1 461.73
HBFV10 10” 50 1 577.31
HBFV12 12” 74 1 917.27
Ductile Iron ENP Plated Disc - GEAR DRIVE *
HBFV6-GEAR 6” 28.5 1 351.89
HBFV8 GEAR 8” 54 1 573.50
Replacement Handles for HBFV Series
BFH2 2" 1 17.46
BFH3 3" 1 17.46
BFH4 4" 1 17.46
BFH5 5" 1 20.87
BFH6 6" 1 20.87
BFH8 8" 1 42.94
BFH10 10" 1 42.94
BFH12 12" 1 48.88
HFBV GEAR Series
Cast Iron Butterfly Valve Features:
• Designed for swimming pool, irrigation and water systems.
• Wafer body features 4 alignment holes.
• Lever lock handle (spring loaded) provides excellent manual control
for balancing or shut off services.
• Notched throttling plate allows balancing in 10º increments in any
position desired within 90º arc rotation of the disc.
• Positive bubble-tight shutoff with minimum torque.
• Seat face eliminates need for flange gaskets.
• Phenolic backed seats prevent collapse, are stretch resistant,
blowout proof and field replacable.
•EPDM seats temperature rated at -30°F to 275°F.
• 416 stainless steel shaft
• Bidirectional dead-end capability for 250 psi (2” - 12”).
• Compatible with ANSI 125/150 flanges.
• Valves meet AWWA C-504-87 section 5 proof of design tests.
• Designed to comply with MSS SP-67 and API 609.
•Ductile iron, ENP plated disc.
• Manufactured for AGI in an ISO 9002 facility.
• Imported
*
4/2009
P.26
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Butterfly Valves - Cast Iron
MATERIAL SPECIFICATIONS
No. Part Material
1 Body Cast Iron
2 Disc Ductile Iron
3 Seat EPDM
4 Shaft 416 Stainless Steel
5 Taper Pin 316 Stainless Steel
6 Key Carbon Steel
7 O-rings EPDM
8-10 Bushing PTFE
SIZE \ DIMENSION (in) for HBFV Series
A B C D E F G H J K L2 M2 N O
2” 6 3/8 3 1/4 1 3/4 1 1/4 1/2 3/8 2.76 .39 2 3/4 4 3/4 11/16 4 4 1.26
2 1/2” 6 7/8 3 3/4 1 7/8 1 1/4 1/2 3/8 2.76 .39 2 3/4 5 1/2 11/16 4 4 3/4 1.83
3” 7 1/8 4 1 7/8 1 1/4 1/2 3/8 2.76 .39 2 3/4 6 11/16 4 5 1/8 2.54
4” 7 7/8 4 7/8 2 1/8 1 1/4 5/8 3/8 2.76 .47 2 3/4 7 1/2 11/16 4 6 3/4 3.54
5” 8 3/8 5 3/8 2 1/4 13/16 3/4 3/8 2.76 .55 2 3/4 8 1/2 13/16 4 7 3/4 4.36
6” 8 7/8 5 7/8 2 1/4 1 1/4 3/4 3/8 2.76 .55 2 3/4 9 1/2 13/16 4 8 5/8 5.72
8” 10 1/4 7 1/8 2 1/2 1 3/4 7/8 7/16 4.02 .67 3 3/4 11 3/4 13/16 4 10 9/16 7.6
10” 11 1/2 8 1/4 2 3/4 1 3/4 1 1/8 7/16 4.02 .87 3 3/4 14.14 15/16 4 13 1/16 9.5
12” 13 1/4 9 3/4 3 1/8 1 3/4 1 1/4 7/16 4.02 .95 3 3/4 17 15/16 4 16 1/8 11.45
6/14/11
P.31
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Clear Braided PVC Hose
Part Nominal (inches) Max Working Pressure Reel Approx Wt List Price
Number ID OD PSI@68ºF PSI@122ºF Length per CFT. Per Reel
CBH316-1 3/16 0.375 250 105 100’ 4.5 lbs $ 117.06
CBH25-1 1/4 0.438 250 105 100’ 5.7 lbs 102.32
CBH516-1 5/16 0.525 250 105 100’ 7.5 lbs 150.56
CBH38-1 3/8 0.594 225 97 100’ 9.0 lbs 145.37
CBH50-1 1/2 0.750 200 86 100’ 13.8 lbs 195.91
CBH50-3 1/2 0.750 200 86 300’ 13.8 lbs 587.73
CBH58-1 5/8 0.875 200 86 100’ 16.5 lbs 231.09
CBH75-1 3/4 1.030 150 65 100’ 21.9 lbs 293.71
CBH75-3 3/4 1.030 150 65 300’ 21.9 lbs 881.15
CBH100-1 1 1.300 125 54 100’ 31.5 lbs 378.42
CBH100-2 1 1.300 125 54 200’ 31.5 lbs 707.34
CBH125-50 1 1/4 1.625 100 43 50’ 45.0 lbs 359.08
CBH125-1 1 1/4 1.625 100 43 100’ 45.0 lbs 718.17
CBH150-50 1 1/2 1.937 100 43 50’ 64.0 lbs 432.96
CBH150-1 1 1/2 1.937 100 43 100’ 64.0 lbs 865.91
CBH200-50 2 2.490 75 33 50’ 95.0 lbs 739.93
CBH200-1 2 2.490 75 33 100’ 95.0 lbs 1479.89
Clear Braided PVC Hose
Standard Wall, Class 125 Features:
• Flexible, see through clear hose with braid pattern
reinforcement of two polyester spirals.
• Flexible clear PVC NSF 51 certified to 100ºF (38ºC),
USP CLASS V1 rated.
• All hose compound ingredients used are listed in
US FDA CFR, Title 21.
• Temperature range + 25º to 150º F / -5º to +65ºC.
• Silicone free.
• Food and beverage grade, standard wall.
• Use for air, water lines.
** Temperatures higher than 68ºF reduce available working pressure. See next
page for temperature, working pressure calculation chart and cautionary note.
4/2009
P.32
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Clear Braided PVC Hose
Effects of Elevated Temperatures on Thermoplastic Hose.
The compounds used in clear braided PVC hose are generally referred to as thermoplastics. These materials
achieve their optimum physical properties at room temperature, 68ºF (20ºC). As these materials are exposed
to increased ambient temperatures, they will soften and their physical properties will change. This will have
the effect of sharply reducing the available working pressure. Coupling retention will also be reduced. The
charts below illustrate this effect. In all cases, the product should be tested in a controlled, secure and safe
environment, and all operating conditions should be considered prior to use.
All published working pressures of AGI Series CBH hose are based on a room temperature of 68ºF (20ºC).
CAUTIONARY NOTE
The charts are to used as a guideline only. The information and recommendations contained here are, to the
best of our manufacturer’s knowledge, accurate and reliable, but no guarantee of their accuracy is made. All
products are sold upon the condition that purchasers shall make their own tests to determine the suitability of
such products for their particular purposes and uses, and purchasers assume all risks and liability for the
results of use of the products, including use in accordance with seller’s recommendations. Variability in length
of exposure, temperature, pressure, velocity of fluid, and chemical concentration all contribute to reduced
working pressure and hose reliability.
Example from the Fahrenheit Chart
If working pressure at 68ºF is 200 psi,
then the WP at 110ºF is 200 x 50%, or
100 psi
Example from the Celsius Chart
If working pressure at 20º is 14 bar, then
the WP at 50ºC is 14 x 50%, or 5.6 bar
6/14/11
P.41
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
BOSS® Pool & Spa Adhesives, Lubricants & Sealants
BOSS® line of adhesives, grouts and lubricants
are specifically formulated for use with pools and
whirlpool baths.
BOSS® 801 Neutral Cure Silicone Adhesive Features:
• A one part, low odor, non-corrosive, oxime cure adhesive and sealant.
• Provides excellant adhesion to ceramic tile, spa jets, skimmers, lighting fixtures,
plumbing and fiber optic lighting.
• Adheres well to fiberglass, ABS, acrylic, PVC, wood and masonry.
BOSS® 802 Acetoxy Cure Silicone General Purpose Adhesive Features:
• A one part, acetoxy cure, adhesive/sealant.
• Performs well in jet sealing applications.
• Designed for many other pool and spa maintenance and repair needs.
BOSS® 803 Neutral Cure Silicone Adhesive/Grout Features:
• A one part, low odor, non-corrosive, oxime cure silicone grout.
• Formulated for use in repairing tile installations.
• Adheres well to fiberglass, ABS, acrylic, PVC, wood and masonry.
BOSS® 804 Neutral Cure Silicone Ceramic Tile Grout Features:
• A one part, low odor, non-corrosive, oxime cure silicone grout.
• Spreads easily and provides ample tooling time.
• Excellent ahdesion to all ceramic tiles
BOSS® 820 Pool & Spa Silicone Lubricant Features:
• Water washout resistant and non-solidifying compound.
• Provides superb lubricant for rubber o-rings.
• Non-corrosive, silicone lubricant compound.
Part Number Description Ctn Qty List Price
80100B Silicone Adhesive Clear, 10.3 oz cart 12 $ 15.31
80101B Silicone Adhesive White, 10.3 oz cart 12 15.31
80200B Silicone Adhesive Gen Purpose, Clear 10.3 oz. cart 12 9.37
80201B Silicone Adhesive Gen Purpose, White 10.3 oz cart 12 9.37
80331B Silicone Adhesive Grout, Clear 3 oz. tube 12 7.65
80401B Silicone Ceramic Tile Grout, White 10.3 oz cart 12 15.31
82001B Pool & Spa Lubricant Clear, 1 oz tube bulk 288 5.18
82002B Pool & Spa Lubricant Clear, 1 oz tube 36 pc tub 36 249.90
82030B Pool & Spa Lubricant Clear, 3 oz tube 12 7.88
82000B Pool & Spa Lubricant Clear, 5.3 oz tube 12 13.21
6/14/11
P.42
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
BOSS® Expanding Foam Sealant
BOSS® 333 Expanding Foam Sealant Features:
• Easy to use, multi-purpose urethane foam.
• Unlike ordinary sealants, it expands three times it’s original volume.
• Adheres to all building materials except Teflon®, silicone and polyethelene.
• Seals by expanding into gaps, cracks and crevices.
• Uses including insulating, sealing and filling gaps around pipes, plumbing
fixtures,ductwork and foundations.
• UL classified.
Part Number Description Ctn Qty List Price
33316B * Expanding Foam Sealant, 12 oz can w/ application tip 12 $ 14.55
33324B * Expanding Foam Sealant, 24 oz can w/ application tip 12 28.47
* SHIPPING NOTE: Ground shipping only. Can NOT be shipped via air.
R19028
CAULKING AND SEALANTS
SURFACE BURNING CHARACTERISTICS
APPLIED TO INORGANIC REINFORCED
CEMENT BOARD*
FLAME SPREAD: 5 SMOKE DEVELOPED: 20
38FN
* Tested as applied in three 3/4” beads 5” on center covering
12.5% of the exposed test sample area.
DIRECTIONS FOR USE:
1. Shake can before and during use.
2. Surface must be clean and free of grease and oil.
3. Can must be held UPSIDE DOWN during application.
4. Insert straw into void and depress the trigger. The use of protec-
tive gloves is highly recommended.
5. Fill void 50% full to allow for expansion.
6. Uncured foam can be cleaned with acetone or paint thinner.
7. Cured foam can be trimmed, sanded, painted r stained. Foam
MUST be painted or coverred if application is exposed to UV light.
4/30/11
P.43
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Installation & Repair
Part Number Size Ctn Qty List Price
82093 7” stick 12 $ 21.22
PERMAPOXY
Underwater Repair
Epoxy
• Ideal for pool & spa
repairs.
• Resin and hardener in
same stick
• Hand kneadable.
• Unaffected by chlorinated
or salt water.
• Sets in 5 minutes, cures in
1 hour.
• Dries White.
• Can be sanded and drilled.
3M Spray Adhesives
BLUE 72
• Repositionable BLUE pressure sensitive
spray adhesive.
• One side bonds in 8 hours, aggressive
tack, low soak in.
• Covers 100 sq ft.
• Ideal for pool liner installation.
ORANGE FOAM FAST 74
• Permanent, light orange, fast tack.
• Two sides bond in 15 minutes.
• Covers 260 sq. ft.
Both manufactured for AGI in an ISO 900
facility.
Pallet pricing available. Call your sales rep.
Part Ctn/Pallet
Number Size Qty List Price
BLUE 72 Blue Spray Adhesive 12/768 $ 35.70
24 fl oz can, 17.3 oz net wt.
ORANGE 74 Orange spray adhesive 12/768 43.33
24 fl oz can, 17.3 oz net wt
ISO 9001 ISO 9001
Fix A Leak Features:
Fix A Leak is a blended material, designed to
seal leaks in just about anything. It works in
any kind of pool, spa or hot tub, regardless of
constructed material, concrete, fiberglass,
acrylic, wood, etc. It works equally well in all
plumbing materials including PVC, ABS, poly
plastics, vulcathen, copper, steel, etc.
• Seals leaks up to 1/8” in diameter.
• Forms a permanent seal.
• One quart is designed to seal leaks in up to
20,000 gallons. Do not use in excess of 1
quart per 5,000 gallons of water.
• Cures in 24-48 hours.
• Patented by Marlig Industries, Inc.
Part
Number Description Ctn Qty List Price
FAL32 Fix A Leak Sealant, 32 oz. 12 $ 49.25
FAL8 Fix A Leak Sealant, 8 oz. 20 20.11
FAL32
Part
Number Width x Length Ctn Qty List Price
HDT260 2” x 60 yards 24 $ 20.70
Contractor/Industrial Grade
Cloth Reinforced Duct Tape
• Multi-purpose duct tape.
• Polyethylene coated cloth backing.
• Natural rubber based adhesive.
• Temperature range: 40ºF to 200°F.
• Superior tensile strength, adhesion
& tack.
• Recommended for pool liner instal-
lations.
• Conformable and will not curl or
twist during application.
• 10 mil thickness
• Silver
• Manufactured for AGI in an
ISO 9002 facility.
HDT Series
ISO 9002
See the “Tapes, Sealants, Cements” and “Permatex Industrial” tabs for more installation & repair materials.
2/15/11
P.44
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Installation & Repair
HARVARD CONTRACTOR’S
Anchor Kit Features:
• Anchor kits complete with 100 plastic anchors, 100 screws and 1/4”
masonry drill bit in a plastic case.
• Plastic gray ribbed anchors with lip design for electronic timer, pump start
relay installations. Use with concrete block, brick and wallboard.
• Anchors have internal ribs for better centering of screws, locking lugs
against pull and twist. Exterior design prevents fall out in overhead holes.
• Kit available with combination slotted/phillips head or tri-combination,
slotted/phillips/hex head #10 x 1” screws.
• Kits complete with 1/4” x 4” masonry drill bit.
• Clear, unbreakable plastic case with molded-in hanging tab.
Combo Tri Combo
Head Head
Part Number Description Ctn Qty List Price
AK10CSPR Ribbed Combo Head 36 $14.11
AK10TCR Ribbed Tri Combo Head 36 15.00
HARVARD CONTRACTOR’S
Power Cord Features:
• Three prong straight (115V) or right angle (115V, 220V) molded plugs.
• 16 gauge, 3 conductor, 13 amp, 125 Volt rating.
• 14 gauge, 3 conductor, 15 amp, 250 Volt rating.
• Six foot cord length.
• Free end is split, stripped 3/8”.
• UL and CSA listed in US and Canada.
PTC163-6ST PTC163-6RA
PTC143-6RA220
Part Number Description Wire Gauge Volt Rating Ctn Qty List Price
PTC163-6ST Straight plug cord 16 125 V 50 $ 6.61
PTC163-6RA Right angle plug cord 16 125 V 50 9.47
PTC143-6RA220 Right angle plug cord 14 250 V 50 14.11
4/30/11
P.47
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Concrete Repair
DP600
Part Number Description Ctn Qty List Price
DP600 Concrete Repair, 8.4 fl oz cartridge 6 $ 111.72
supplied with 2 nozzles
Horizontal Concrete Repair Features:
Hardens in as little at 5 minutes,
Cracks and spalls in concrete floors are an eyesore as well as a potential
safety risk. Fixing them has meant either hiring and waiting for an outside
contractor or doing it youself with a repair method that takes the floor out of
service for up to 24 hours. Now with 3M Concrete Repair, you save money
and time.
• Self-leveling urethane flows
smoothly into cleaned cracks and
gaps and hardens in as little as 5
minutes. A fork lift can pass over a
repair in as few as 15 minutes.
• Hardens to any depth without
cracking or shrinking.
• Flexible urethane expands and
contracts for durability that outlasts
repairs made with concrete.
• Do it yourself with a common
caulking gun and eliminate the cost
and wait for an outside contractor.
• Easy to use - Just clean damaged
area and fill. With every squeeze of
the caulking gun trigger, cartridge
nozzle meters and mixes precise
proportions for optimum
performance.
Part Number Size Color Ctn Qty List Price
CG9 9” Ratchet Blue 20 4.39
9” Ratchet Style Caulking Gun
4/2009
P.48
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Concrete Repair
Horizontal Concrete Repair Specifications:
• Gray, self-leveling urethane concrete repair.
• 8.4 fl oz. cartridge of concrete repair and 2 nozzles.
• Work life of 70 sec.
• Handling time of 5 minutes
• Cure time of 60 minutes
Applications:
• Repairing cracks and spalls on concrete floors or horizontal surfaces.
• Setting anchors in concrete floors or horizontal surfaces.
• Light-duty custom threading and anchoring.
• Use outdoors or in highly ventilated area.
Clean
Remove all loose
material from area
to be filled.
Concrete should be
dry and grease-free.
Fill
Dispense product
into deepest part of
repair areas, slightly
overfilling. Product
self-levels and is
tack-free in as little
as one minute.
Finish
In as little as 15 min-
utes, product can be
sanded to remove
rough edges. It can
be painted within
one hour.
Bead Size Linear Feet per
dimension 8.4 fl oz.
1/16” 815.0
1/8” 205.0
1/4” 51.9
3/8” 22.2
1/2” 12.4
Approximate coverage:
Crack Crack Lineat Feet per
Width Depth 8.4 fl. oz.
1/4” 1/4” 19.3
1/2” 1/4” 9.9
3/4” 1/4” 6.4
1” 1/4” 4.9
1/4” 1/2” 9.9
1/2” 1/2” 4.9
3/4” 1/2” 3.0
1” 1/2” 2.0
Quick and Easy Spall Repair
6/14/11
1.7
TM www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Tank Crosses - Short Cast
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
CHT100FB 2 1/2” 1” fpt 1” X 3/4” 3/4” (1) 1/4” (2) Bronze Import 5/40 $ 34.29
CCAT100B 4 1/4” 1” x 3/4” 1” x 3/4” 1/2” (1) 1/4” (2), 1/2” (1) Bronze Import 4/40 52.54
CHC125B 4 1/4” 1 1/4” x 1” 1” x 3/4” 1/2” (1) 1/4” (3) Bronze USA 12 51.43
CHC12550BS 4 1/2" 1 1/4" x 1" 1" x 3/4" 3/4" (1) 1/4" (2) Brass Import 5/40 41.00
CIC701B 3 3/4” 1 1/4” x 1” 1 1/4” x 1” 3/4” (1) 1/4” (3) Bronze USA 12 56.61
CHT125B 3 3/4” 1 1/4” x 1” 1 1/4” x 1” 3/4” (1) 1/4” (2) Bronze Import 5/30 34.29
CIC701BS 4 1/2" 1 1/4" x 1" 1 1/4" x 1" 3/4" (1) 1/4" (2) Brass Import 4/32 39.82
CIC125B 4 1/4” 1 1/4” x 1” 1” x 3/4” 3/4” (1) 1/4” (2), 1/2” (1) Bronze Import 4/40 51.66
CIC125 4 1/4” 1 1/4” x 1” 1” x 3/4” 3/4” (1) 1/4” (2), 1/2” (1) PVC* USA 100 12.32
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
CICS100B 4 3/4” 1” 1” x 3/4” 1/2” (2) 1/4” (2) Bronze USA 12 $ 46.71
CICS100BS 4 1/2” 1” x 3/4” 1” x 3/4” 1/2” (2) 1/4” (2) Brass Import 5/40 27.31
CIC3125B 5” 1 1/4” x 1” 1 1/4” x 1” 3/4” (2) 1/4” (2) Bronze USA 12 62.87
CIC3125BS 4 1/2” 1 1/4” x 1” 1 1/4” x 1” 3/4” (2) 1/4” (2) Brass Import 4/32 41.00
CIC71250BS 4 1/2" 1 1/4" x 1" 1" x 3/4" 1/2" (2) 1/4" (2) Brass Import 5/40 39.71
CIC712B 4” 1 1/4” x 1” 1” x 3/4” 3/4” (2) 1/4” (2) Bronze USA 12 53.45
General Tank Cross Features:
• Internal and external threads reduce fittings needed and installation time.
• Reduces turbulence and waterlogging in tanks without separate air chambers.
• Cast bronze, brass, injected molded PVC, galvanized ductile iron.
• Prices are for bulk packaged tank crosses.
• For individually boxed crosses, remove “C” prefix and add $2.25 to list price.
Short Cast Crosses with 1 drain and 2 or 3 top
ports.
* Do not use teflon tape with
PVC tank cross applications.
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
CICS100BSUE** 5 1/2” 1” 1”x3/4” 1/2” (2) 1/4” (2) Brass Import 4/24 $ 31.05
CICS100BSU* 5 1/2” 1” 1”x3/4” 1/2” (2) 1/4” (2) Brass Import 4/24 46.21
☺CICS100BU** 5 1/2” 1” 1” x 3/4” 1/2” (2) 1/4” (2) Bronze Import 4/24 29.00
CICS125BSUE** 5 1/2” 1 1/4”x 1” 1 1/4” x 1” 3/4” (2) 1/4” (2) Brass Import 4/24 43.48
CICS125BSU* 5 1/2” 1 1/4”x 1” 1 1/4” x 1” 3/4” (2) 1/4” (2) Brass Import 4/24 62.78
☺CICS125BU** 5 1/2” 1 1/4” x 1” 1 1/4” x 1” 3/4” (2) 1/4” (2) Bronze Import 4/24 41.00
Short Cast Crosses with Union Disconnect
* with Teflon gasket seal
** with metal to metal ball joint seal
“E” Series light pattern brass tank crosses compete with Merrill & Boshart equiva-
lents.
Short Cast Crosses with 2 drain and 2 top ports.
CHT100FB CHT125B
5/3/11
1.8
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Tank Crosses - Short Cast, Specialty
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
CWM100BS 4 1/2” 1” (FIP) 1”x3/4” 1/2” (2) 1/4” (2) Brass Import 5/40 $ 34.07
CWM125BS 4 3/4” 1 1/4” (FIP) 1 1/4”x1” 3/4” (2) 1/4” (2) Brass Import 4/32 42.04
CICS736BS 2 1/2” 1 1/4” MIP x 1” FIP 1”x3/4” 1/2” (2) 1/4” (2) Brass Import 5/40 29.12
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
CFC100BS 4 1/2” 1” Union Th. 1” x 3/4” 1/2” (2) 1/4” (2) Brass Import 5/40 $ 27.14
CFC125BS 4 1/2” 1 1/4” Union Th. 1 1/4” x 1” 3/4” (2) 1/4” (2) Brass Import 5/30 36.20
Short cast crosses for use with Flexcon Well-Rite, Online Series
Short cast crosses for use with Flexcon Flex-Lite Series, WellMate Tanks
General Tank Cross Features:
• Internal and external threads reduce fittings needed and installation time.
• Reduces turbulence and waterlogging in tanks without separate air chambers.
•Cast bronze, brass, injected molded PVC, galvanized ductile iron.
• Prices are for bulk packaged tank crosses.
• For individually boxed crosses, remove “C” prefix and add $2.25 to list price.
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
CICS100BSFTU 4” 1” fpt union 1” x 3/4” 1/2” (2) 1/4” (2) Brass Import 4/32 $ 46.82
CICS100BSFTU65 6 1/2” 1” fpt union 1” x 3/4” 1/2” (2) 1/4” (2) Brass Import 4/32 38.89
CICS1251BSFTU 4” 11/4” fpt union 1” x 3/4” 1/2” (2) 1/4” (2) Brass Import 4/32 43.57
CICS125BSFTU 4” 11/4” fpt union 11/4” x 1” 3/4” (2) 1/4” (2) Brass Import 4/24 60.43
Short cast female union tank crosses for use with Flexcon “Flex-Lite” Series,
WellMate Tanks. FPT brass union w/ American Standard Buna-N o-ring.
•1” uses AS 568-212 o-ring
•1 1/4” uses AS 568-320 o-ring.
• CICS100BSFTU65 for use with WellMate Low Profile Series or other 1” mpt
connection tanks that need extra length.
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
CWM100BSQC 4 1/2" Quick Connect 1” x 3/4” 1/2" (2) 1/4" (2) Brass Import 4/32 $ 35.96
CWM125BSQC 4 1/2" Quick Connect 11/4" x 1” 3/4" (2 1/4" (2) Brass Import 3/24 37.04
Short cast quick connect (w/ Buna-N oring) tank crosses
for use with WellMate “Quick Connect” Series tanks.
• 1” and 1 1/4” uses AS 568-220 o-ring.
6/14/11
1.10a
TM
Tank Crosses - Short Cast NO LEAD Brass, Stainless Steel
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
NO LEAD Brass
CICS100BSENL 4 1/2” 1” x 3/4” 1” x 3/4” 1/2” (2) 1/4” (2) No Lead Brass Import 4/24 28.70
CIC3125BSENL 4 1/2” 1 1/4” x 1” 1 1/4” x 1” 3/4” (2) 1/4” (2) No Lead Brass Import 4/24 40.75
Tank Cross Features:
• Internal and external threads reduce fittings needed and
installation time.
• Reduces turbulence and waterlogging in tanks without separate air
chambers.
• Cast NO LEAD brass or 304 Stainless Steel.
•NO LEAD brass tank crosses are CA AB1953 certified.
• 304 Stainless Steel crosses contain no lead.
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
NO LEAD Brass
CICS100BSUENL 5 1/2” 1” 1”x3/4” 1/2” (2) 1/4” (2) No Lead Brass Import 4/24 $ 42.45
CICS125BSUENL 5 1/2” 1 1/4”x 1” 1 1/4” x 1” 3/4” (2) 1/4” (2) No Lead Brass Import 4/24 58.93
304 Stainless Steel
CICS100SSU 5 1/2” 1” 1”x3/4” 1/2” (2) 1/4” (2) Stainless Import 4/24 65.72
CICS125SSU 5 3/4” 1 1/4”x 1” 1 1/4” x 1” 3/4” (2) 1/4” (2) Stainless Import 4/24 85.54
Short Cast Crosses with Union Disconnect
• Metal to metal ball joint seal on NO LEAD brass crosses.
• Teflon gasket seal on 304SS crosses.
“E” Series light pattern brass tank crosses compete with Merrill &
Boshart equivalents.
Short Cast Crosses with 2 drain and 2 top ports.
“E” Series light pattern No Lead brass tank crosses compete with Merrill &
Boshart equivalents.
6/14/11
1.10b
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Tank Crosses - Long Cast NO LEAD Brass, Stainless Steel
General Tank Cross Features:
• Internal and external threads reduce fittings needed and installation
time.
• Reduces turbulence and waterlogging in tanks without separate air
chambers.
• Cast NO LEAD brass or 304 Stainless Steel.
•NO LEAD brass tank crosses are CA AB1953 certified.
• 304 Stainless Steel crosses contain no lead.
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
NO LEAD Brass
CIC100BSENL 11” 1” 1” x 3/4” 1/2” (2) 1/4” (2) No Lead Brass Import 2/24 $ 40.89
CIC100BS14ENL 14” 1” 1” x 3/4” 1/2” (2) 1/4” (2) No Lead Brass Import 2/12 55.51
CIC125BS14ENL 14” 1 1/4” 1 1/4” x 1” 3/4” (2) 1/4” (2) No Lead Brass Import 2/12 76.53
NO LEAD Brass Long Cast Tank Crosses with 2 drain and 2 top ports.
“E” Series light pattern brass tank crosses compete with Merrill & Boshart
equivalents.
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
NO LEAD Brass
CIC100BSUENL 11” 1” 1” x 3/4” 1/2” (2) 1/4 “(2) No Lead Brass Import 2/20 $ 53.95
CIC100BSU14ENL 14” 1” 1” x 3/4” 1/2” (2) 1/4 “(2) No Lead Brass Import 2/12 64.11
CIC125BSU14ENL 14” 1 1/4” 1 1/4” x 1” 3/4” (2) 1/4 “(2) No Lead Brass Import 2/12 78.75
304 Stainless Steel
CIC100SSU 11” 1” 1” x 3/4” 1/2” (2) 1/4 “(2) 304 Stainless Import 2/20 77.68
CIC100SSU14 14” 1” 1” x 3/4” 1/2” (2) 1/4 “(2) 304 Stainless Import 2/20 88.75
CIC125SSU14 14” 1 1/4” 1 1/4” x 1” 3/4” (2) 1/4 “(2) 304 Stainless Import 2/12 111.79
Long Cast Tank Crosses with union disconnect, 2 drain & 2 top ports.
“E” Series light pattern brass tank crosses compete with Merrill & Boshart
equivalents.
• Metal to metal ball joint seal on NO LEAD brass crosses.
• Teflon gasket seal on 304SS crosses.
6/14/11
1.11
TM www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Tank Crosses - Long Cast
General Tank Cross Features:
• Internal and external threads reduce fittings needed and installation time.
• Reduces turbulence and waterlogging in tanks without separate air chambers.
• Cast bronze, brass, injected molded PVC, galvanized ductile iron.
• For individually boxed crosses, remove “C” prefix and add $2.25 to list price.
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
CHC100BSE 11” 1” 1” x 3/4” 1/2” (1) 1/4” (2) Brass Import 2/24 $ 44.29
CHC100BS 11” 1” 1” x 3/4” 1/2” (1) 1/4” (2) Brass Import 2/24 50.64
CHC100B 11” 1” 1” x 3/4” 1/2” (1) 1/4” (2) Bronze USA 12 62.32
Long Cast Tank Crosses with 1 drain and 2 top ports.
“E” Series light pattern brass tank crosses compete with Merrill & Boshart equiva-
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
CIC100BSE 11” 1” 1” x 3/4” 1/2” (2) 1/4” (2) Brass Import 2/24 $ 39.11
CIC100BS 11” 1” 1” x 3/4” 1/2” (2) 1/4” (2) Brass Import 2/24 50.64
CIC100B 11” 1” 1” x 3/4” 1/2” (2) 1/4” (2) Bronze USA 12 62.89
CIC100BS14 14” 1” 1” x 3/4” 1/2” (2) 1/4” (2) Brass Import 2/20 56.39
CIC125BS14E 14” 1 1/4” 1 1/4” x 1” 3/4” (2) 1/4” (2) Brass Import 2/12 86.81
CIC125BS14 14” 1 1/4” 1 1/4” x 1” 3/4” (2) 1/4” (2) Brass Import 15 101.96
Long Cast Tank Crosses with 2 drain and 2 top ports.
“E” Series light pattern brass tank crosses compete with Merrill & Boshart
equivalents.
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
CIC100BU85 8 1/2” 1” 1” x 3/4” 1/2” (2) 1/4” (2) Bronze Import 2/20 $ 67.61
CIC100BSUE 11” 1” 1” x 3/4” 1/2” (2) 1/4 “(2) Brass Import 2/20 59.64
CIC100BU 11” 1” 1” x 3/4” 1/2” (2) 1/4 “(2) Bronze Import 2/20 69.77
CIC100BU14 14” 1” 1” x 3/4” 1/2” (2) 1/4 “(2) Bronze Import 2/20 74.14
CIC125BSU14E 14” 1 1/4” 1 1/4” x 1” 3/4” (2) 1/4 “(2) Brass Import 2/12 90.04
CIC125BU14 14” 1 1/4” 1 1/4” x 1” 3/4” (2) 1/4 “(2) Bronze Import 2/12 103.85
Long Cast Tank Crosses with union disconnect, 2 drain and 2 top ports.
“E” Series light pattern brass tank crosses compete with Merrill & Boshart
equivalents.
• Metal to metal ball joint seal.
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
CHC100BU 11” 1” 1” x 3/4” 1/2” (1) 1/4” (2) Bronze Import 2/20 $ 69.77
CHC125BU14 14” 1 1/4” 1 1/4” x 1” 3/4” (1) 1/4’ (2) Bronze Import 2/12 108.95
Long Cast Tank Crosses with union disconnect, 1 drain and 2 top ports.
• Metal to metal ball joint seal.
2/15/11
1.12
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Tank Crosses - Long, Fabricated
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
CHC100BF 11” 1” 1” x 3/4” 1/2” (1) 1/4” (2) Bronze/Copper USA 12 $ 65.82
CHC100BF13 13” 1” 1” x 3/4” 1/2” (1) 1/4” (2) Bronze/Copper USA 12 71.54
CHC125BF 14” 1 1/4” 1 1/4” x 1” 3/4” (1) 1/4” (2) Bronze/Copper USA 12 81.94
CHC125BF16 16” 1 1/4” 1 1/4” x 1” 3/4” (1) 1/4” (2) Bronze/Copper USA 6 87.04
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
CIC740BF 18” 1” 1” x 3/4” 1/2” (2) 1/4” (2) Bronze/Copper USA 9 $ 151.46
CIC741BF 18” 1 1/4” 1 1/4” x 1” 3/4” (2) 1/4“(2) Bronze/Copper USA 6 243.05
Part Overall Tank Leg Drain Ports Top Ports USA or Ctn List
Number Length Conn. Conn. Size (Qty) Size (Qty) Material Import Qty Price
CIC100BF 11” 1” 1” x 3/4” 1/2” (2) 1/4” (2) Bronze/Copper USA 12 $ 65.00
CIC100BF13 13” 1” 1” x 3/4” 1/2” (2) 1/4” (2) Bronze/Copper USA 12 71.54
CIC125BF 14” 1 1/4” 1 1/4” x 1” 3/4” (2) 1/4” (2) Bronze/Copper USA 12 80.36
CIC125BF16 16” 1 1/4” 1 1/4” x 1” 3/4” (2) 1/4” (2) Bronze/Copper USA 6 83.46
Long Fabricated Tank Crosses with 2 drain and 2 top taps.
• Crosses fabricated with 96.5% tin, 3.5% lead free solder.
Long Fabricated Tank Crosses with 1 drain and 2 top taps.
• Crosses fabricated with 96.5% tin, 3.5% lead free solder.
General Tank Cross Features:
• Internal and external threads reduce fittings needed and installation time.
• Reduces turbulence and waterlogging in tanks without separate air chambers.
•Cast bronze, brass, injected molded PVC, galvanized ductile iron.
• Prices are for bulk packaged tank crosses.
• For individually boxed crosses, remove “C” prefix and add $2.25 to list price.
Long Fabricated Elevated Tank Crosses with union disconnect.
• Crosses fabricated with 96.5% tin, 3.5% lead free solder.
6/14/11
1.23
TM www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Pressure Relief Valves
Part Number Size Pressure Setting Ctn/Case List Price
Bronze Relief Valves - Made in USA
RV50 1/2”x 1/2” Set at 75 psi 50/150 $ 18.52
RV75 3/4”x 1/2” Set at 75 psi 50/150 19.16
RV50-100 1/2” x 1/2” Set at 100 psi 50/150 18.52
RV75-100 3/4” x 1/2” Set at 100 psi 50/150 19.16
Brass Relief Valves - Imported
IRV50 1/2”x 1/2” Set at 75 psi 10/100 9.66
IRV75 3/4”x 1/2” Set at 75 psi 10/100 9.99
IRV7575 3/4”x 3/4” Set at 75 psi 10/100 11.25
IRV50-100 1/2” x 1/2” Set at 100 psi 10/100 9.66
IRV75-100 3/4” x 1/2” Set at 100 psi 10/100 9.99
IRV7575-100 3/4” x 3/4” Set at 100 psi 10/100 11.25
NO LEAD Brass Relief Valves - Imported
IRV50NL 1/2”x 1/2” Set at 75 psi 10/100 10.76
IRV75NL 3/4”x 1/2” Set at 75 psi 10/100 11.30
IRV50-100NL 1/2” x 1/2” Set at 100 psi 10/100 10.54
IRV75-100NL 3/4” x 1/2” Set at 100 psi 10/100 10.54
304 Stainless Steel Relief Valves - Imported
IRV50SS 1/2”x 1/2” Set at 75 psi 10/100 21.79
IRV75SS 3/4” x 3/4” Set at 75 psi 10/100 23.04
IRV50-100SS 1/2” x 1/2” Set at 100 psi 10/100 21.79
IRV75-100SS 3/4” x 1/2” Set at 100 psi 10/100 23.04
Hamilton Brass Adjustable Safety Relief Valves Set at Adjustable to Sold at Preset Only
HRV50 1/2” mipt x 1/2” fipt 75 psi 150 psi 25 47.72
HRV75 3/4” mipt x 3/4” fipt 75 psi 100 psi 25 70.26
HRV175 1” mipt x 3/4” fipt 75 psi 200 psi 25 115.72
HRV125 1 1/4” mipt x 1 1/4” fipt 75 psi 200 psi 10 218.37
HRV Series
RV and IRV Series Relief Valve Features:
• Heavy duty brass, no lead brass (CA AB1953 certified) or 304 stainless steel for
shallow, deep well and submersible pumps.
• Spring loaded and pre-set under pressure, NOT ADJUSTABLE.
• 1/2” or 3/4” (IRV7575) discharge.
• RV Series are manufactured for AGI in an ISO 9001 facility.
• IRV series imported.
Hamilton Adjustable Safety Relief Valve Features:
• Preset at 75 P.S.I. with concealed adjusting screw to prevent tampering.
• Brass-heavy duty.
• Full-flow design with Buna-N seats.
RV Series
IRV IRV-NL Series
NOTE: Relief valves on this page are not for use
with hot water heaters. Recommended for cold
water system installations only.
Preset relief valves are NOT intended to be
adjusted. Any adjustment to preset relief valves
voids warranty.
ISO 9001
FLOW RATES
PSI 85 90 95 100 105 110 115
RV Series gpm .30 7.3 7.7 9.8 17.9 18.9 20.6
IRV Series gpm 2.0 2.7 3.8 4.7 7.0 12.0 12.7
PSI 10 20 30 40 60 80 100
HRV50 .6 1.5 2.5 3.6 6.1 8.8 11.8
HRV75 2.8 5.5 11.0 13.8 17.9
HRV175 6.0 12.6 19.0 24.6 35.6 44.8 52.3
HRV125 12.0 35.0 48.4 69.2 106.5 132.5 150.0
IRV SS Series
6/14/11
1.24
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Installation Accessories - Tank
Tank Legs Features:
• Elevates tank above floor and out of condensation pools.
• Leveled on uneven floors without the use of tools.
• Custom molded from high strength ABS.
Pump Mounting Bracket Features:
• Elevates pump out of corrosive atmosphere.
• Heavy duty 12 gauge cold rolled steel with gray enamel coating. Heaviest
steel gauge bracket available in the market.
• Plastic protectors on the pump stand legs prevent scratching of the tank.
• Supplied with 1", 1 1/4" zinc plated steel screws and steel adapter for larger
tanks.
• Fits all pumps and comes individually cartoned.
Air Valve Features:
• Used for reciprocating and submersible pumps to admit air to system.
• Used for charging applications and many other uses.
• Available in long and short patterns.
Pressure Test Gauge Features:
• 0-100 psi, 2" plastic lens.
• Brass test fitting with pressure release button.
• Heavy rubber boot to protect gauge from damage.
Part Number Size Pressure Setting/Description Ctn Qty List Price
Tank Legs
TL3 (3/Package), ABS 48 $ 3.45
Pump Mounting Brackets
PMB1 12 gauge steel plate, Gray 20 24.47
Air Valves
SN18 1/8” Short, Light Spring (Snifter) 25/250 2.43
SN18L 1/8” Long, Light Spring (Snifter) 25/250 3.02
SN25 1/4” Short, Heavy Spring (Air) 25/250 3.25
SN25L 1/4” Long, Light Spring (Snifter) 25/250 3.11
LVC18 Replacement Core for light spring models 0.94
Pressure Test Gauge
PTG1002 Pressure test gauge 50 11.96
TL3
PMB1
SN18L, SN18. SN25L, SN25
PTG1002
6/14/11
1.25
TM www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Clear Braided PVC Hose
Part Nominal (inches) Max Working Pressure Reel Approx Wt List Price
Number ID OD PSI@68ºF PSI@122ºF Length per CFT. Per Reel
CBH316-1 3/16 0.375 250 105 100’ 4.5 lbs $ 117.06
CBH25-1 1/4 0.438 250 105 100’ 5.7 lbs 102.32
CBH516-1 5/16 0.525 250 105 100’ 7.5 lbs 150.56
CBH38-1 3/8 0.594 225 97 100’ 9.0 lbs 145.37
CBH50-1 1/2 0.750 200 86 100’ 13.8 lbs 195.91
CBH50-3 1/2 0.750 200 86 300’ 13.8 lbs 587.73
CBH58-1 5/8 0.875 200 86 100’ 16.5 lbs 231.09
CBH75-1 3/4 1.030 150 65 100’ 21.9 lbs 293.71
CBH75-3 3/4 1.030 150 65 300’ 21.9 lbs 881.15
CBH100-1 1 1.300 125 54 100’ 31.5 lbs 378.42
CBH100-2 1 1.300 125 54 200’ 31.5 lbs 707.34
CBH125-50 1 1/4 1.625 100 43 50’ 45.0 lbs 359.08
CBH125-1 1 1/4 1.625 100 43 100’ 45.0 lbs 718.17
CBH150-50 1 1/2 1.937 100 43 50’ 64.0 lbs 432.96
CBH150-1 1 1/2 1.937 100 43 100’ 64.0 lbs 865.91
CBH200-50 2 2.490 75 33 50’ 95.0 lbs 739.93
CBH200-1 2 2.490 75 33 100’ 95.0 lbs 1479.89
Clear Braided PVC Hose
Standard Wall, Class 125 Features:
• Flexible, see through clear hose with braid pattern
reinforcement of two polyester spirals.
• Flexible clear PVC NSF 51 certified to 100ºF (38ºC),
USP CLASS V1 rated.
• All hose compound ingredients used are listed in
US FDA CFR, Title 21.
• Temperature range + 25º to 150º F / -5º to +65ºC.
• Silicone free.
• Food and beverage grade, standard wall.
• Use for air, water lines.
** Temperatures higher than 68ºF reduce available working pressure. See next
page for temperature, working pressure calculation chart and cautionary note.
4/2009
1.26
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Clear Braided PVC Hose
Effects of Elevated Temperatures on Thermoplastic Hose.
The compounds used in clear braided PVC hose are generally referred to as thermoplastics. These materials
achieve their optimum physical properties at room temperature, 68ºF (20ºC). As these materials are exposed
to increased ambient temperatures, they will soften and their physical properties will change. This will have
the effect of sharply reducing the available working pressure. Coupling retention will also be reduced. The
charts below illustrate this effect. In all cases, the product should be tested in a controlled, secure and safe
environment, and all operating conditions should be considered prior to use.
All published working pressures of AGI Series CBH hose are based on a room temperature of 68ºF (20ºC).
CAUTIONARY NOTE
The charts are to used as a guideline only. The information and recommendations contained here are, to the
best of our manufacturer’s knowledge, accurate and reliable, but no guarantee of their accuracy is made. All
products are sold upon the condition that purchasers shall make their own tests to determine the suitability of
such products for their particular purposes and uses, and purchasers assume all risks and liability for the
results of use of the products, including use in accordance with seller’s recommendations. Variability in length
of exposure, temperature, pressure, velocity of fluid, and chemical concentration all contribute to reduced
working pressure and hose reliability.
Example from the Fahrenheit Chart
If working pressure at 68ºF is 200 psi,
then the WP at 110ºF is 200 x 50%, or
100 psi
Example from the Celsius Chart
If working pressure at 20º is 14 bar, then
the WP at 50ºC is 14 x 50%, or 5.6 bar
Part Number Tank Tank Suction Ctn Qty Tapped Standard
(Tapped) Capacity Port Port List Price List Price
Non-repairable *
AV45E 80 1/4” pipe 7/16”-24 pipe 50 $ 12.32
AV45 80 1/4” pipe 7/16”-24 pipe 50 30.14
AV45F 80 1/4” pipe 1/8” pipe tap 50 31.54
AV100E 120 3/8” pipe 7/16”-24 pipe 50 12.32
AV100 120 3/8” PIPE 7/16”-24 PIPE 50 34.13
AV100F 120 3/8” PIPE 1/8” PIPE TAP 50 36.18
Repairable *
AV30 42 1/4” PIPE 7/16”-24 PIPE 100 33.20
AV42 AV42T 80 1/4” pipe tap 1/4” pipe tap 50 45.36 43.36
AV80 AV80T 120 1/4” pipe tap 1/4” pipe tap 50 53.11 50.28
AV120 AV120T 220 3/8” pipe tap 1/4” pipe tap 25 69.68 66.79
Repair Kits• Fits all makes of repairable diaphragm type controls
AV30-3A For Brady AV30 controls 42 26.33
AV42-3A For Brady AV42 controls 42 30.94
AV80-3A For Brady AV80 controls 42 36.17
AV120-3A For Brady AV120 controls 42 47.38
Plastic Air Charger *
AC100 30 21.13
CAC100 Bulk Packed 17.88
Air Charger with Tubing and Fittings **
AC100TF 20 27.27
AC100TFBT Black Tubing 20 27.27
Air Charger Installation Kit with Tubing and Fittings **
UTF1 24 12.44
UTF1BT Black Tubing 24 12.93
6/14/11
1.27
TM www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Air Volume Controls
AC100
AV Non-Repairable
Brady Air Volume Control Features:
• Maintains water flow-stretches pump life.
• Repairable and non-repairable offering.
• Diaphragm-type air volume control maintains correct proportions of air & water in jet systems.
• Die Cast, 96% Zinc.
• Individually cartoned.
• Available with or without Tapped Gauge Port.
• “E” Series compares to Boshart “AVC” and Merrill “AV” series non-repairable controls.
Air Charger Features:
• For jet systems.
• Positive action control.
• No flexing diaphragm or metal springs to malfunction.
• Will not corrode in a moist environment.
• Fits all tanks up to and including 82 gallon.
• Available with tube & fittings as an optional extra, specify AC100TF. Includes 60” tubing &
assortment of special brass fittings & adapters, eliminates duplication of inventories with a
single kit for all applications.
Universal Air Charger Installation Kit Features:
• Fits all air volume controls.
• Includes 60” polyethylene tubing and assortment of special brass fittings and adapters,
eliminating duplication of inventories with a single kit for all applications.
** See page 6.7 for additional lengths of MV4040 1/2” OD x 0.17” ID translucent and black tubing.
*
AV Repairable
6/14/11
1.28
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Air Releases & Controls
HARVARD
All Plastic Deep Well Air Release Features:
• Formerly Robert Shaw* AE10
(*used with permission of Invensys Controls)
• Maintains proper ratio of air to water in submersible water
systems.
• All polyethylene construction eliminates corrosion.
• Includes gauge port and 0-40 psi limited bleed adjustment.
• Made in USA.
Brady Plastic Deep Well Air Release Features:
• Maintains the proper ratio of air to water.
• Constructed of ABS resin grade plastic.
• Non-corrosive, non-conductive and completely serviceable.
• Release mechanism consists of a Buna-N procession ball & 316 stainless steel
spring.
• Factory set at 20 P.S.I., adjustable from 0 to 40 P.S.I.
Deep Well Air Release Features:
• Maintains proper ratio of air to water in
submersible water systems.
• Deluxe deep well air release features ABS float and cast body
which prevents galvanic action at pump tank tapping.
• WJ1 Imported.
Shallow Well Control Features:
• Preserves correct proportion of water and air in shallow well
reciprocating pump systems.
• Imported.
Part Number Tapping Manufacturer Ctn Qty List Price
All Plastic Deep Well Air Release
HAE1 1 1/4” Harvard (formerly Robert Shaw) 49 $ 45.71
BAR125N 1 1/4” Brady 50 37.75
Deep Well Air Release
WJ1 1 1/4” Ametek 20 58.86
HF93B-1 1 1/4” Johnson 50 38.62
Shallow Well Control
SWCL 1 1/4” Ametek 20 66.35
HAE1
WJ1
SWCL
HF93B1
BAR125N
Formerly Robert
Shaw/Invensys
6/14/11
1.29
TM www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Installation Accessories - Submersible
Deluxe Torque Arrestor Features:
• Two piece design, molded from PVC or rubber.
• PVC torque arrestor is 40% heavier than competitors
to resist long-term casing abrasion.
• Field adjustable to hold pump centered in well.
• Fits all well casings from 4” to 8” I.D.
• Torque Arrestor is securely fastened to 1” or 1 1/4” drop pipe
w/ 2 Ideal all stainless steel clamps included.
• Available bagged, boxed or bulk without clamps.
Submersible Torque Arrestor Features:
• "Spider" style molded from rubber.
• Installs at discharge cap of submersible pump.
• Tabs are easily cut for field alteration.
• 4”-6” casing, 1” center hole.
Natural Rubber Pump Guide Features:
• Installed at the top of the submersible discharge cap.
• Permits the pump to be lowered without damage from abrading
against the well casing & ledge while centering the pump in the well.
Cable Guard Features:
• Snap-in and self clamping styles.
• Keeps power cable from abrading against well casing.
• A minimum of three to five should be used; one at the pump,
one no further than 15’ above the pump, and one between 25’
and 30’ above the pump.
• Adjustable - use in 4”, 5” and 6” wells. Available for 1” or 1 1/4”
drop pipe.
• Made of polyethylene and will float.
Part Number Description Color Ctn Qty List Price
Deluxe PVC Torque Arrestor
TA48 Bagged, with 2 Ideal all stainless steel clamps Black 16 $ 12.32
TA48B Boxed, with 2 Ideal all stainless steel clamps Black 12 15.00
CTA48 Bulk, no clamps Black Bulk 9.36
Deluxe Rubber Torque Arrestor
TA48R Bagged with 2 Ideal all stainless steel clamps Black 16 15.68
TA48RB Boxed, with 2 Ideal all stainless steel clamps Black 12 18.36
CTA48R Bulk, No clamps Black Bulk 13.93
Standard Rubber Torque Arrestor
TA6100 6x1, (spider type) Black 50 26.19
Natural Rubber Pump Guides Fits Casing ID Guide OD Drop Pipe
SG400-3X1 4” 3” 1” Bulk 4.89
SG400-3X11/4 4” 3” 1 1/4” Bulk 4.89
SG500-4X1 5” 4” 1” Bulk 5.30
SG558-5X1 5-5/8” 5” 1” Bulk 8.10
SG600-55/8X1 6” 5 5/8” 1” Bulk 9.00
SG600-55/8X11/4 6” 5 5/8” 1 1/4” Bulk 9.00
SG625-6X1 6 1/4” 6” 1” Bulk 10.28
SG625-6X2 6 1/4” 6” 2” Bulk 9.73
Cable Guard
MG6 With two cable holes, fits 4”-6” casing, Polyethylene 100 0.96
WG100 1” Self-clamping style, fits 4”-6” casing 48 2.93
WG125 1 1/4” Self-clamping style, fits 4”-6” casing 48 4.86
TA48
TA6100
MG6 WG Series
SG Series
6/14/11
1.30
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Installation Accessories - Submersible
PO100
ES
Part Number Description Ctn Qty List Price
Braided Safety Rope
MR25-500 Blue/White, 1/4” x 500’ Plastic Reel, 1000# 1 $ 34.93
MR25-1 Blue/White, 1/4” x 1000’ Plastic Reel, 1000# 1 62.57
MR25-3 Blue/White, 1/4” x 3000’ Plastic Reel, 1000# 1 197.32
Twisted Safety Rope
SR25-500 Black, 1/4” x 500’ Plastic Reel, 1200# 1 50.89
SR25-1 Black, 1/4” x 1000’ Plastic Reel, 1200# 1 98.93
SR25-3 Black, 1/4” x 3000’ Plastic Reel, 1200# 1 305.54
Bleeder Orifices
PO75B 3/4”, Brass 25/250 11.61
PO100 1”, Rubber, 25 per bag 100 2.04
BOT100 Yellow Brass Insert Tee 1”, w/rubber bleeder orifice 6 45.18
Ejector Screen
ES1 Brass Screen 1 9.40
ES1S Stainless Steel Screen 1 9.02
Cable Ties
CT150 Bag of 100 Nylon, 1” to 1 1/4” diameter pipe, 8” long 1 6.18 /100
CT300 Bag of 100 Nylon, 1 1/2” to 4” diameter pipe, 15 ” long 1 14.42 /100
Submersible Safety Rope Features:
• Custom extruded from tough polypropylene fiber.
• Highly resistant to chafing, abrasion &corrosion.
• Recommended wherever minimum stretch and maximum strength are required.
• Twisted SR25 Series tested in excess of 1,200 lbs.. Braided MR25 Series tested in
excess of 1,000 lbs.
• Plastic or wood reels.
Bleeder Orifices Features:
• Provides a fast bleed through its large opening.
• Complete closure prevents loss of pumping volume.
• Full 1” size molded of virgin rubber increases bleed capacity & reduces cost of pipe fitting.
• 3/4” available in brass.
• Bleeder orifice tee available. Includes yellow brass insert tee w/ 1” rubber bleeder orifice.
Ejector Screen Features:
• Protects heat pumps against plugged nozzles and clogged venturis.
• Non-corrosive brass or stainless steel screen.
• Installs easily in discharge side of ejector.
Cable Tie Features:
• UL approved, self-clinching nylon fastener.
• Ideal for holding cable to drop pipe, positioning cable guards, etc.
• Withstands -65º to 225ºF.
• Packaged in bags of 100.
• Manufactured for AGI in an ISO 9002 facility.
CT Series ISO 9002
MR Series
6/14/11
1.31
TM www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Pump Installation Adapters & Fittings
Features:
• Heavy pattern, contractor grade cast bronze or stainless steel material.
• Rope adapters have integral pad eye for easy use with submersible rope.
SEE PAGE 12.3 and 12.4 for a complete line of imported cast bronze insert fittings.
Part Number Size Style # Barbs Ctn/CaseQty List Price
Cast Bronze Male Insert Adapters (INS x MIP)
RBMA1/2 1/2” x 1/2” Hex 5 10/200 $ 7.04
RBMA3/4 3/4” x 3/4” Hex 5 10/200 9.00
RBMA1 1” x 1” Hex 7 10/100 13.41
RRBMA1 1” x 1” Round 6 10/100 13.79
RBMA1X3/4 1” x 3/4” Hex 5 10/100 10.79
RBMA1X11/4 1” x 11/4” Hex 6 10/100 16.75
RBMA11/4 1 1/4” x 1 1/4” Hex 6 10/100 17.96
RBMA11/4X1 1 1/4” x 1” Hex 7 10/100 17.32
RBMA11/2 1 1/2” x 1 1/2” Hex 6 5/50 20.79
RBMA11/2X11/4 11/2” x 1 1/4” Hex 6 10/100 18.89
RBMA2 2” x 2” Hex 7 5/50 33.71
Cast Bronze Extra Long Male Adapters (INS x MIP)
XLRBMA1 1” x 1” Hex 12 10/100 20.18
XLRBMA1x11/4 1” x 1 1/4” Hex 12 10/100 20.32
XLRBMA11/4 1 1/4” x 1 1/4” Hex 12 10/100 23.93
XLRBMA2 2” x 2” Hex 12 5/50 41.64
Cast Bronze Male Union Adapters (INS x MIP)
RBMUA1 1” x 1” Hex 6 10/80 22.78
RBMUA11/4 1 1/4” x 1 1/4” Hex 6 10/40 20.33
Cast Bronze Rope Adapters (INS x MIP) ☺
RBRA1 1” x 1” Round w/ rope eye 11 10/100 15.61
RBRA1X11/4 1” x 1 1/4” Round w/ rope eye 6 10/100 17.51
RBRA11/4 1 1/4” x 1 1/4” Round w/ rope eye 6 10/100 19.64
Cast Bronze Rope Adapters (INS x MIP)
BDR125 1”x1 1/4” Heavy duty ☺9 10/50 31.55
BW100 1” HD long pattern ☺9 10/50 36.23
Cast Bronze Female Adapters (INS x FIP) ☺
RBFA1/2 1/2” x 1/2” Round 5 10/200 9.11
RBFA3/4 3/4” x 3/4” Round 5 10/100 11.57
RBFA1 1” x 1” Round 5 10/100 16.93
RBFA11/4 1 1/4” x 1 1/4” Round 7 10/100 19.54
RBFA11/2 1 1/2” x 1 1/2” Round 6 5/50 23.68
RBFA2 2” x 2” Round 7 5/50 36.96
Cast Stainless Steel Male Insert Adapters (MIP xINS) ☺ Grade 304 *
SSMA1/2 1/2" Hex 6 10/100 8.18
SSMA3/4 3/4" Hex 6 10/200 10.26
SSMA1 1” Hex 6 10/100 17.00
SSMA11/4 1 1/4” Hex 6 5/100 20.71
SSMA11/4X1 1 1/4” x 1” Hex 6 5/100 18.00
XLSSMA11/4X1 1 1/4” x 1” Hex (Heavy pattern xlong) 13 5/60 46.86
SSMA11/2 1 1/2" Hex 6 5/80 26.89
SSMA2 2" Hex 6 5/40 37.49
RBMA
XLRBMA
RBFA
RBRA
RBMUA
RRBMA
☺Imported
SSMA
*
6/14/11
1.32
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Pump Installation Adapters & Fittings
Part Number Size Style # Barbs Ctn/CaseQty List Price
Cast Stainless Steel Male Insert Adapters (MIPxINS) Made in USA Grade 316 *
SS12-1/2 1/2” Round 6 25/300 21.17
SS12-3/4 3/4” Round 7 25/200 19.49
SS12-1 1” Round 7 20/160 22.08
SS12-11/4 1 1/4” Round 6 20/120 36.20
SS12-11/2 1 1/2” Round 6 10/60 49.01
SS12-2 2” Round 7 10/40 64.41
SS38-11/4 X1 1 1/4” x 1” Round 7 25 52.13
Cast Stainless Steel Hex Bushing (MIPxFIP) ☺Grade 304 *
SSHB1X1/4 1” x 1/4” Hex - 10/200 7.54
SSHB1X1/2 1” x 1/2” Hex - 10/200 7.54
SSHB1X3/4 1” x 3/4" Hex - 10/200 8.61
SSHB11/4x1 1 1/4" x 1" Hex - 10/160 11.82
Steel Well Seal Elbows (INS x INS) **
S99-1 1” 10 26.66
S99-11/4 1 1/4” 10 36.03
Steel Well Seal Elbows (INS x INS) - IMPORTED ☺ *
ISWSE100 1” 25 13.11
ISWSE125 1 1/4” 15 21.54
Brass Well Seal Elbow, ins x ins**
B99-1 1” 5 96.50
B99-11/4 1-1/4” 5 181.67
Steel Venturi Adapter, mipt x ins **
S86-3/4X6 3/4" x 6” 25 18.05
S86-3/4X10 3/4" x 10" 25 21.49
S86-3/4X12 3/4 x 12” 25 21.76
S86-1X6 1" x 6" 25 13.71
S86-1X8 1" x 8" 25 16.56
S86-1x10 1" x 10" 25 18.60
S86-1X12 1" x 12" 25 21.24
S86-11/4X6 1-1/4" x 6" 25 18.66
S86-11/4X8 1-1/4" x 8" 25 21.01
S86-11/4X10 1-1/4" x 10" 20 25.34
S86-11/4X12 1-1/4" x 12” 25 32.46
Steel Venturi Adapter, mipt x ins IMPORTED ☺ *
ISVMA1X6 1" x 6" 60 5.43
ISVMA1X8 1" x 8" 50 7.95
ISVMA1X10 1" x 10" 40 9.44
ISVMA11/4X6 1-1/4" x 6" 50 7.46
ISVMA11/4X8 1-1/4" x 8" 40 9.27
ISVMA11/4X10 1-1/4" x 10" 30 11.05
Red Brass Venturi Adapter, ins x mipt **
B86-1X6 1" x 6" 25/100 44.84
B86-1X8 1" x 8" 25/100 59.07
B86-11/4X6 1-1/4" x 6" 25/100 66.40
B86-11/4X8 1-1/4" x 8" 25/100 87.43
SS12
☺Imported
S86, ISVMA, B86
S99, ISWSE, B99
SSHB
*
**
6/14/11
1.35
TM www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Flow Control Valves - Dole
NEW OLD Flow Inlet/
Part Number (GPM) Outlet List Price
Brass Housing/Nickel Plated
GA.06 0.06 3/8” FIPT $53.50
GA.13 DV.13 0.13 3/8” fipt 53.50
GA.19 DV.19 0.19 3/8” fipt 53.50
GA.25 DV2.5 0.25 3/8” fipt 53.50
GA.35 0.35 3/8” fipt 53.50
GA.50 DV5 0.50 3/8” fipt 53.50
GA.75 DV75 0.75 3/8” fipt 53.50
GA1.0 DV10 1.0 3/8” fipt 53.50
GB1.0 DV10-1/2 1.0 1/2” fipt 55.48
GB1.5 DV15 1.5 1/2” fipt 55.48
GB2.0 DV20 2.0 1/2” fipt 55.48
GB2.5 DV25 2.5 1/2” fipt 55.48
GB3.0 DV30 3.0 1/2” fipt 55.48
GB3.5 DV35 3.5 1/2” fipt 55.48
GB4.0 DV40 4.0 1/2” fipt 55.48
GB5.0 DV50-1/2 5.0 1/2” fipt 55.48
GB6.0 DV60-1/2 6.0 1/2” fipt 55.48
GC1 DV1.0 1.0 3/4” fipt 69.09
GC1.5 1.5 3/4” fipt 69.09
GC2.0 DV2.0 2.0 3/4” fipt 69.09
GC2.5 DV2.5-3/4 2.5 3/4” fipt 69.09
GC3.0 DV30-3/4 3.0 3/4” fipt 69.09
GC3.5 DV3.5-3/4 3.5 3/4” fipt 69.09
GC4.0 DV40-3/4 4.0 3/4” fipt 69.09
GC5.0 DV50 5.0 3/4” fipt 69.09
GC6.0 DV60 6.0 3/4” fipt 69.09
GC7.0 DV70 7.0 3/4” fipt 69.09
GC8.0 DV80 8.0 3/4” fipt 69.09
GC9.0 DV90 9.0 3/4” fipt 69.09
GC10 DV100 10.0 3/4” fipt 69.09
GC11.5 DV115 11.5 3/4” fipt 69.09
GY1.0 DV1-3/4MXF 1.0 3/4”mipt x fipt 65.91
GY1.5 DV1.5-3/4MXF 1.5 3/4”mipt x fipt 65.91
GY2.0 DV2-3/4MXF 2.0 3/4”mipt x fipt 65.91
GY2.5 DV2.5-3/4MXF 2.5 3/4”mipt x fipt 65.91
GY3.0 DV3-3/4MXF 3.0 3/4”mipt x fipt 65.91
GY3.5 DV3.5-3/4MXF 3.5 3/4”mipt x fipt 65.91
GY4.0 DV4-3/4MXF 4.0 3/4”mipt x fipt 65.91
GY5.0 DV5-3/4MXF 5.0 3/4”mipt x fipt 65.91
GY6.0 DV6-3/4MXF 6.0 3/4”mipt x fipt 65.91
GY7.0 DV7-3/4MXF 7.0 3/4”mipt x fipt 65.91
Dole Flow Control Valve Features:
• Prevents over-pumping of low yield wells.
• Installs in the discharge line between check valve and pressure tank.
• Do not use to suspend pipe.
• Self cleaning, designed to deliver constant volume of water over wide pressure drop
range.
• Flow rated maintained within +/- 15% up to a pressure drop of 125 psi.
• Maximum system pressure 200 psi.
• Carton Quantity is 1 for all items.
GA, GB, GC, GX Series
3/8” - 1”fipt
Brass Housing/
Nickle Plated
GY Series
3/4 mipt” x 3/4”fipt
Brass Housing/
Nickle Plated
GP GT, GF, GH, GK
Series
1 1/4” - 3” mipt
Steel Housing/
Zinc Plated
6/14/11
1.36
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Flow Control Valves - Dole
NEW OLD Flow Inlet/
Part Number (GPM) Outlet List Price
GY8.0 DV8-3/4MXF 8.0 3/4”mipt x fipt $ 65.91
GY9.0 DV9-3/4MXF 9.0 3/4”mipt x fipt 65.91
GY10 DV10-3/4MXF 10.0 3/4”mipt x fipt 65.91
GY11.5 11.5 3/4”mipt x fipt 65.91
GX1.0 DV10-1 1.0 1” fipt 133.12
GX1.5 DV15-1 1.5 1” fipt 133.12
GX2.0 DV20-1 2.0 1” fipt 133.12
GX2.5 DV25-1 2.5 1” fipt 133.12
GX3.0 DV30-1 3.0 1” fipt 133.12
GX3.5 DV35-1 3.5 1” fipt 133.12
GX4.0 DV40-1 4.0 1” fipt 133.12
GX5.0 DV50-1 5.0 1” fipt 133.12
GX6.0 DV60-1 6.0 1” fipt 133.12
GX7.0 DV70-1 7.0 1” fpt 133.12
GX8.0 DV80-1 8.0 1” fpt 133.12
GX9.0 DV90-1 9.0 1” fpt 133.12
GX10 DV100-1 10.0 1” fipt 133.12
GX12 DV120 12.0 1” fipt 133.12
GX13.5 DV135-1 13.5 1” fipt 133.12
GX15 DV150 15.0 1” fipt 133.12
GX20 DV200 20.0 1” fipt 133.12
GX25 DV250 25.0 1” fipt 133.12
GX30 DV300 30.0 1” fipt 133.12
Steel Housing/Zinc Plated
GP1.0 DV1.0-11/4 1.0 1 1/4” mipt 140.51
GP1.5 1.5 1 1/4” mipt 140.51
GP2.0 2.0 1 1/4” mipt 140.51
GP2.5 2.5 1 1/4” mipt 140.51
GP3.0 3.0 1 1/4” mipt 140.51
GP3.5 3.5 1 1/4” mipt 140.51
GP4.0 4.0 1 1/4” mipt 140.51
GP5.0 5.0 1 1/4” mipt 140.51
GP6.0 6.0 1 1/4” mipt 140.51
GP7.0 DV75-11/4 7.0 1 1/4” mipt 140.51
GP8.0 8.0 1 1/4” mipt 140.51
GP9.0 9.0 1 1/4” mipt 140.51
GP10 DV10-11/4 10.0 1 1/4” mipt 140.51
GP12 DV12-11/4 12.0 1 1/4” mipt 140.51
GP13.5 13.5 1 1/4” mipt 140.51
GP15 DV15-11/4 15.0 1 1/4” mipt 140.51
GP20 DV20-11/4 20.0 1 1/4” mipt 140.51
GP25 DV25-11/4 25.0 1 1/4” mipt 140.51
GP30 DV30-11/4 30.0 1 1/4” mipt 140.51
GT1.0 1.0 1 1/2” mipt 155.58
GT1.5 1.5 1 1/2” mipt 155.58
GT2.0 DV2-11/2 2.0 1 1/2” mipt 155.58
GT2.5 2.5 1 1/2” mipt 155.58
GT3.0 3.0 1 1/2” mipt 155.58
GT3.5 3.5 1 1/2” mipt 155.58
GT4.0 4.0 1 1/2” mipt 155.58
GT5.0 DV5-11/2 5.0 1 1/2” mipt 155.58
NEW OLD Flow Inlet/
Part Number (GPM) Outlet List Price
Steel Housing/Zinc Plated
GT6.0 6.0 1 1/2” mipt $ 155.58
GT7.0 DV7-11/2 7.0 1 1/2” mipt 155.58
GT8.0 8.0 1 1/2” mipt 155.58
GT9.0 DV9-11/2 9.0 1 1/2” mipt 155.58
GT10 DV10-11/2 10.0 1 1/2” mipt 155.58
GT12 12.0 1 1/2” mipt 155.58
GT13.5 13.5 1 1/2” mipt 155.58
GT15 DV15-11/2 15.0 1 1/2” mipt 155.58
GT20 DV20-11/2 20.0 1 1/2” mipt 155.58
GT25 DV25-11/2 25.0 1 1/2” mipt 155.58
GT30 DV30-11/2 30.0 1 1/2” mipt 155.58
GF10 DV10-2 10.0 2” mipt 265.38
GF11.5 11.5 2” mipt 265.38
GF12 DV12-2 12.0 2” mipt 265.38
GF13.5 DV135-2 13.5 2” mipt 265.38
GF15 15.0 2” mipt 265.38
GF20 DV20-2 20.0 2” mipt 265.38
GF25 25.0 2” mipt 265.38
GF30 DV30-2 30.0 2” mipt 265.38
GH30 30.0 2-1/2” mipt 587.75
GH35 DV350 35.0 2-1/2” mipt 587.75
GH40 DV400 40.0 2-1/2” mipt 587.75
GH45 DV450 45.0 2-1/2” mipt 587.75
GH50 DV500 50.0 2-1/2” mipt 587.75
GH55 DV550 55.0 2 1/2” mipt 587.75
GH60 DV600 60.0 2-1/2” mipt 587.75
GH65 DV650 65.0 2-1/2” mipt 587.75
GH70 DV700 70.0 2-1/2” mipt 587.75
GH75 DV750 75.0 2-1/2” mipt 587.75
GH80 DV800 80.0 2-1/2” mipt 587.75
GH85 85.0 2-1/2” mipt 587.75
GH90 DV900 90.0 2 1/2” mipt 587.75
GK30 30.0 3” mipt 611.45
GK35 DV3500 35.0 3” mipt 611.45
GK40 DV4000 40.0 3” mipt 611.45
GK45 DV4500 45.0 3” mipt 611.45
GK50 50.0 3” mipt 611.45
GK55 DV5500 55.0 3” mipt 611.45
GK60 60.0 3” mipt 611.45
GK65 DV6500 65.0 3” mipt 611.45
GK70 70.0 3” mipt 611.45
GK75 75.0 3” mipt 611.45
GK80 80.0 3” mipt 611.45
GK85 DV8500 85.0 3” mipt 611.45
GK90 90.0 3” mipt 611.45
GK95 95.0 3” mipt 611.45
GK100 DV1000 100.0 3” mipt 611.45
GK105 105.0 3” mipt 611.45
GK110 110.0 3” mipt 611.45
GK115 115.0 3” mipt 611.45
GK120 DV1200 120.0 3” mipt 611.45
6/14/11
1.55
TM www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Pitless Adapters - Bronze
Pitless Adapter Features:
• Cast from 81% COPPER content alloy bronze to insure long life
and durability in the most aggressive well conditions.
• Extended casing nipple makes installation easy.
• Rubber inner and outer casing gaskets for certified &
approved water tight seal from ground water conta-
mination.
• Built-in lowering eyelet for easier installation (except PT300).
• All PT Series pitless adapters are individually boxed.
• PT300T, PT800T tapped with 1/4” FPT tap-
ping for
underground well tank installations.
• PT700, PT725, PT2000 made in US.
Part Drop Pipe Nominal Well Casing Hole Max Load
Number Size Casing Opening Capacity (lbs.) Ctn Qty List Price
PT300 1” 5” through 8” 1 3/4” 800 10 $ 45.54
PT800 1” 5” through 8” 1 3/4” 900 10 74.82
PT700 1” 5” through 12” 1 3/4” 5,000 10 144.80
PT825 1-1/4” 5” through 8” 2 1/4” 2,000 10 151.29
PT725 1-1/4” 5” through 12” 2 1/8” 5,000 10 222.87
PT3000 2” 5 5/8” through 12” 3 1/8” 5,000 4 461.99
PT2000 2” 5 5/8” through 12” 3 1/8” 5,000 4 552.44
PT900 1” & 1-1/4” (2 Hole) 5” through 8” 1 3/4” & 2 1/4” 2,000 1 427.11
PT300 O-Ring Fits PT300 1 3.33
PT800 O-Ring Fits PT800, 825 and 900 1 3.39
TAPPED Pitless Adapters for underground tanks
PT300T 1” 5” through 8” 1 3/4” 800 1 49.09
PT800T 1” 5” through 8” 1 3/4” 900 1 78.37
BWS75-100 3/4” FPT x 1” MPT 5” through 8” 1 3/8” _ 10/60 27.50
PT700 & PT725
PT800
PT900
PT825
Bronze Drain and Wire Fitting Features:
• Cast from bronze to insure long life and durability in the most
aggressive well conditions.
• Fastens to well casing to provide tapping for well drain,
electrical conduit, bulkhead fittings & other related uses.
• Rubber gasket seals out ground water contamination.
BWS75-100
PT3000
PT300
PT800T
2/15/11
1.56
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Pitless Adapters - Clear hole, Snap-on
Features:
• CLEAR CASING DESIGN - no internal obstructions.
• Self -supporting (750 lbs / 300’ of 1” iron pipe).
• 300 series stainless steel spring, pivot pin, pull cable, U-
bolt, washers, nuts and extra wide backing strap.
• Built-in safety features should spring or cable fall.
• Available in combination with conduit or watertight caps.
• Quality American made bronze.
• Easy to install.
• All BA Series pitless adapters and BA-SC combination units are certified
and approved watertight to PAS-97 Standards. ☺
Part Number Description Nominal Casing Drop Ctn List
Well Size” O.D.” Pipe” Qty Price
BA4-100 ☺Pitless Adapter Only 4 4 1/2 1 1 $ 282.28
BA4-100C With C4 Alum Conduit Cap 4 4 1/2 1 1 323.17
BA4-100SC ☺With SC4 ABS/Alum Cap 4 4 1/2 1 1 327.90
BA4-100WT With AWTC4 Alum Cap 4 4 1/2 1 1 264.16
BA4-125 ☺Pitless Adapter Only 4 4 1/2 1 1/4 1 291.98
BA4-125C With C4 Alum Conduit Cap 4 4 1/2 1 1/4 1 331.32
BA4-125SC ☺With SC4 ABS/Alum Cap 4 4 1/2 1 1/4 1 336.85
BA4-125WT With AWTC4 Alum Cap 4 4 1/2 1 1/4 1 358.12
BA45-100 ☺Pitless Adapter Only 4 1/2 SDR17 4.95 1 1 285.92
BA45-100SC ☺With SC45 ABS/Alum Cap 4 1/2 SDR17 4.95 1 1 342.71
BA45-125 ☺Pitless Adapter Only 4 1/2 SDR17 4.95 1 1/4 1 296.18
BA45-125SC ☺With SC45 ABS/Alum Cap 4 1/2 SDR17 4.95 1 1/4 1 256.25
BA5-100 ☺Pitless Adapter Only 5 5 9/16 1 1 288.68
BA5-100SC ☺With SC5 ABS/Alum Cap 5 5 9/16 1 1 348.11
BA5-125 ☺Pitless Adapter Only 5 5 9/16 1 1/4 1 298.97
BA5-125SC ☺With SC5 ABS/Alum Cap 5 5 9/16 1 1/4 1 361.46
BA6-100P Pitless Adapter Only for Plastic Pipe 6 6 5/8 1 1 302.63
BA6-100PSC With SC6 ABS/Alum Cap for Plastic Pipe 6 6 5/8 1 1 354.62
BA6-100S Pitless Adapter Only for Steel Pipe 6 6 5/8 1 1 302.63
BA6-100SSC With SC6 ABS/Alum Cap for Steel Pipe 6 6 5/8 1 1 354.62
BA Series
Installation Instructions
Note: Apply lubricant to o-ring on male member of body & female portion of saddle.
1. Cut 2 1/4” diameter discharge hole in casing with a 2 1/4” hole saw. Attach saddle and U-bolt.
2. File notch in top of casing above discharge hole for alignment and for easy reinstallation if pump
must be pulled later.
3. Assemble pump and drop pipe to body and lower into casing with 1” support pipe longer than
dim A. Note: Make sure male member snaps completely into female portion of saddle.
4. Remove 1” support pipe and attach cap.
10/12/10
1.67
TM www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Drive Well Points
Imperial Series Features:
• Designed to be driven into all types of soil.
• Imperial series are wrapped outside with a stainless steel screen
• Stainless steel jacket over gauze construction is permanently fixed to
perforated steel pipe.
• Design allows the passage of all the sand free water the pipe can carry.
• Cast iron drive point head can be removed for easy field extension by coupling
together with the second well point for added capacity.
Part No. Simmons Pipe Size Length Gauze Ctn Qty List Price
Standard Series with Inner Stainless Steel Gauze
S94-60 1721 1 1/4 30” 60 1 $ 132.01
S98-60 1722 1 1/4 36” 60 1 142.23
S102-60 1724 1 1/4 48” 60 1 173.75
S168-60 1752 2 36” 60 1 216.51
S172-60 1753 2 48” 60 1 279.67
S176-60 1754 2 60” 60 1 342.83
S94-80 1727 1 1/4 30” 80 1 132.01
S98-80 1728 1 1/4 36” 80 1 142.23
Part No. Simmons Pipe Size Length Gauze Ctn Qty List Price
Imperial with Outer Stainless Steel Gauze
I90-60 1720-1 1 1/4 24” 60 1 $ 121.81
I94-60 1721-1 1 1/4 30” 60 1 131.88
I98-60 1722-1 1 1/4 36” 60 1 142.11
I100-60 1723-1 1 1/4 42” 60 1 153.44
I102-60 1724-1 1 1/4 48” 60 1 173.75
I136-60 1740-1 1 1/2 24” 60 1 143.98
I138-60 1741-1 1 1/2 30” 60 1 162.35
I144-60 1742-1 1 1/2 36” 60 1 179.33
I168-60 1752-1 2 36” 60 1 216.43
I172-60 1753-1 2 48” 60 1 279.67
I176-60 1754-1 2 60” 60 1 342.83
I90-80 1726-1 1 1/4 24” 80 1 121.81
I94-80 1727-1 1 1/4 30” 80 1 131.88
I98-80 1728-1 1 1/4 36” 80 1 142.11
I102-80 1730-1 1 1/4 48” 80 1 173.75
I138-80 1746-1 1 1/2 30” 80 1 162.35
I144-80 1747-1 1 1/2 36” 80 1 179.33
Standard Series Features:
• For use in rocky or sandy soil.
• Standard series are wrapped inside with a stainless steel screen.
• Unique corrosion resistant construction features protect stainless steel
gauze held in place between galvanized pipe and a stainless steel liner.
• Self flushing chamfered holes in galvanized pipe eliminate clay or sand
build-up, giving maximum water yield with minimum development time.
S-Series
I-Series
6/14/11
1.68
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Drive Well Point Supplies
Part Number Valve Size Pressure Pipe Tap Ctn Qty List Price
80002C 2" NPT Male 1” NPS Left Hand Female Bulk $ 75.29
Part Number Pipe Size Description Ctn Qty List Price
8660B 2” No. 19B S/Steel Ball 12 $ 72.04
“Sand Shark”, Backwash Valves Features:
• Used in soft soil to jet open-end screen to desired depth.
• Thickwalled, cast iron construction with saw teeth to rip through roots and debris.
• Solid ABS ball check keeps sand from entering well when jetting operations are complete.
• Not spring loaded.
80002C
Sand Shark
Valve
8660B
Backwash
Valve
Part Number Rt. Hand Thread Well Strainer Coupling Coupling Ctn List Price
Pipe Size Size Size O.D. Length Qty
Turned Couplings
434J11/4X11/4 1-1/4 x 1-1/4” 2 1” 1 13/16” 2-1/4” 48 $ 5.89
434-11/4X11/4 1 1/4 X 1 1/4” 2 1 1/4 1 15/16” 2 1/4 48 6.47
Part Number Description Pipe Size Length (in.) Ctn Qty List Price
Galvanized Drive Couplings
DC125C 1-1/4” 1-1/4” 2.75 40 $ 8.03
DC150 1-1/2” 1-1/2” 2.75 40 9.93
DC200 2” 2” 2.90 30 13.39
DC200L 2” Long Pattern 2” 3.40 30 17.68
Drive Caps
C125 Heavy Duty Forged Steel 1-1/4” 32 13.39
C200 Heavy Duty Forged Steel 2” 16 23.21
Turned Coupling Features:
• Used for suspending flush well points or strainers from drive shoes or
tubular cylinders.
• Galvanized with standard pipe thread.
• Furnished with right hand pipe threads.
• Thin wall 434J.
434 Series
C125
DC
Galvanized Drive Coupling Features:
• Heavy pattern with deep recess for shouldering on imperfect threads of well points.
• Assures proper driving of well points and standard pipe.
• Taper tapped, reamed and drifted.
Drive Cap Features:
• Heavy duty forged steel.
• Standard pipe threads.
• Vented on top.
6/14/11
1.71
TM www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Pitcher Pump
Part
Number Description List Price
118P1 Complete Plunger Assembly (includes *) 36.98
118P2 * Cup Leather for Plunger only 13.16
118P3 Plunger Rod and Cage (no cup leather) 14.26
118P4 * Plunger Rod 7.34
118P5 * Plunger Cage 9.15
118P6 * Plunger Weight 5.03
118P7 Flat Leather for Base Valve 9.49
118P8 Weight and Screw for Flat Valve 6.54
118P9 Flat Valve Leather and Weight 15.99
118P10 * Threaded Nut for Plunger Cage 10.60
118P11 Pump Base with Bolts (118P15) 34.10
118P12 Pump Cylinder 38.79
118P13 Pump Top with Set Screw (118P17) 17.48
118P14 Pump Handle with Two Bolts (118P16) 29.34
118P15 3/8 x1-1/4 Bolts for Pump Base 12.62
118P16 3/8 x 2 bolts for Pump Handle 4.46
118P17 Set Screw for Pump Top 3.81
PITCHER PUMP REPLACEMENT PARTS
Pitcher Pump Features:
• Recommended for shallow pump applications – depth rating up to 30'.
• Easily installed.
• Made of heavy cast iron.
• Dark green hard enamel paint finish.
• Has open spout.
• 15-3/4” high.
• Tapped for 1-1/4” drop pipe.
• 15 lbs.
• Pumps are individually packaged 4 per master carton.
• Parts are carton qty 1.
HPP10
Master
Part Number Description Ctn Qty List Price
HPP10 Pitcher Pump, Cast Iron, Size #2 4 $ 118.75
4/2009
1.72
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
10/12/10
1.77
TM www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Cylinder Replacement Parts
Product Number Description List Price Page
70039E A40 2-1/2” x 12” Barrel Only $ 264.88 76
70039F A40 2-1/2” x 16” Barrel Only 285.71 76
70039G A40 3” x 12” Barrel Only 404.76 76
70039H A40 3” x 16” Barrel Only 485.12 76
70043C A40 2-1/2” Cap 54.64 76
70043D A40 3” Cap 69.82 76
8015C Top Cap 449B 1-7/8” 46.11 73
8015D Top Cap 449B 2-1/4” 116.70 73
8015E Top Cap 449B 2-3/4” 113.04 73
8034D Cylinder Packer Rubber 450/7039 13.46 75
8036A Check Packer Rubber 450/7039 8.36 75
8041A Seating Tool for 450 Cylinders 6.07 75
8042C Bottom Cap 449B 1-7/8” 53.55 73
8042D Bottom Cap 449B 2-1/4” 131.32 73
8042E Bottom Cap 449B 2-3/4” 118.56 73
80723A Plunger Assembly A40 2” 250.00 76
80723B Plunger Assembly A40 2 1/4” 276.79 76
80723C Plunger Assembly A40 2 1/2” 276.79 76
80723D Plunger Assembly A40 3” 297.62 76
80724A A40 2” Check Valve 104.17 76
80724B A40 2-1/4” Check Valve 112.00 76
80724C A40 2 1/2” Check Valve 130.95 76
80724D A40 3” Check Valve 142.86 76
8099B Plunger Poppet 442 1 11/16 & 1 13/16 12.98 74
8099C Plunger Poppet 442 2” 33.42 74
8099D Plunger Poppet 442 2-1/4” 34.43 74
8099E Plunger Poppet 442 2-1/2” 34.53 74
8099G Plunger Poppet 442 3” 35.56 74
8248B Top Cap 1” Tap 442 1-11/16” 49.59 74
8248D Top Cap 1” Tap 442 1-13/16” 36.67 74
8248E Top Cap 1 1/4” Tap 442 2” 41.37 74
8248G Top Cap 1 1/4” Tap 442 2-1/4” 26.71 74
8248H Top Cap 1 1/2” Tap 442 2-1/4” 39.00 74
8248J Top Cap 1 1/4” Tap 442 2-1/2” 34.78 74
8248R Top Cap 1 1/4” Tap 442 3” 35.78 74
8248T Top Cap 2” Tap 442 3” 91.57 74
8281N Brass Base Ring 450/7039 15.86 75
8333BC Barrel Only 442 2-1/4” x 18” 127.31 74
8333D Barrel Only 442 1 11/16” x 18” 108.47 74
8333DB Barrel Only 442 2” x 16” 82.36 74
8333DC Barrel Only 442 1 1/4” x 20” 118.28 74
8333FB Barrel Only 442 2 x 18” 92.04 74
®
6/14/11
1.78
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Cylinder Replacement Parts
Product Number Description List Price Page
8333H Barrel Only 442 1 11/16” x 16” 105.42 74
8333HB Barrel Only 442 2 x 20” 94.56 74
8333JA Barrel Only 442 1 13/16” x 16” 67.66 74
8333LA Barrel Only 442 1 13/16 x 18” 76.70 74
8333NA Barrel Only 442 1 13/16 x 20” 85.42 74
8333NC Barrel Only 442 2 1/2 x 18” 109.31 74
8333ND Barrel Only 442 3 x 20” 284.39 74
8333PC Barrel Only 442 2 1/2 x 20” 242.25 74
8333PD Barrel Only 442 3” x 22” 146.14 74
8333R Barrel Only 442 1 11/16” x 22” 124.55 74
8333RC Barrel Only 442 2 1/2” x 22” 112.94 74
8333ZB Barrel Only 442 2 1/4 x 16” 115.36 74
8334AB Barrel Only 449 2 1/4 x 30” 279.02 73
8334BB Barrel Only 449 2 1/4 x 36” 263.24 73
8334N Barrel Only 449 1 7/8 x 24” 130.49 73
8334P Barrel Only 449 1 7/8 x 30” 186.76 73
8334R Barrel Only 449 1 7/8 x 36” 230.86 73
8334XC Barrel Only 449 2 3/4 x 24” 195.44 73
8334YC Barrel Only 449 2 3/4 x 30” 241.47 73
8334ZA Barrel Only 449 2 1/4 x 24” 199.19 73
8334ZC Barrel Only 449 2 3/4 x 36” 283.03 73
8509B Cylinder End Base 450 2” 37.47 75
8513C Spring Dog 4500 for 450 Cylinder 62.61 75
8514B Plunger Assembly 450/7039 1 13/16 82.75 75
8515AP Check Assembly 450/7039 2” 58.37 75
8520B Cylinder Barrel & Base 7039 10ST 93.19 75
8520F Cylinder Barrel & Base 7039 14ST 104.71 75
8522A Plunger Assembly w/ leathers 442 1 11/16” 104.58 74
8522B Plunger Assembly w/ leathers 442 1 13/16” 86.27 74
8522C Plunger Assembly w/ leathers 442 2” 86.22 74
8522D Plunger Assembly w/ leathers 442 2 1/4” 107.80 74
8522F Plunger Assembly w/ leathers 442 2 1/2” 115.77 74
8522J Plunger Assembly w/ leathers 442 3” 154.51 74
8525C Check Poppet 450 Cylinder 14.29 75
8525D Plunger Poppet 450 Cylinder 14.29 75
8533C Check Assembly w/ leathers 449B 1 7/8” 99.79 73
8533D1 Check Assembly w/ leathers 449B 2 1/4” 135.84 73
8533E1 Check Assembly w/ leathers 449B 2 3/4” 229.76 73
8546B Bronze Ball 449B 1 1/16” 57.70 73
8546D Bronze Ball 449B 1 5/16” 71.60 73
8546E Bronze Ball 449B 1 11/16” 112.87 73
8599A Plunger Assembly w/ leathers 449B 1 7/8” 138.75 73
8599C Plunger Assembly w/ leathers 449B 2 1/4” 184.56 73
®
4/2009
1.79
TM www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Cylinder Operating Data
Dia. of Area of
pump Length of stroke in inches with capacity per stroke in gallons circle
cylinder cylinder
in inches 1 2 3 4 5 6 7 8 10 12 18 24 sq in
1 3/8 .0064 .0128 .0192 .0256 .0320 .0384 .0448 .0512 .0640 .0768 .1152 .1536 1.4849
1 1/2 .0076 .0153 .0229 .0306 .0382 .0459 .0535 .0612 .0765 .0918 .1375 .1832 1.7671
1 5/8 .0090 .0180 .0270 .0360 .0450 .0540 .0630 .0720 .0900 .1080 .1620 .2140 2.0739
1 3/4 .0104 .0208 .0312 .0416 .0512 .0625 .0729 .0833 .1041 .1249 .1872 .2497 2.4053
1 13/16 .0112 .0224 .0336 .0448 .0560 .0672 .0784 .0896 .1120 .1344 .2016 .2688 2.5802
1 7/8 .0120 .0240 .0360 .0480 .0600 .0720 .0840 .0960 .1200 .1440 .2160 .2280 2.7612
1 31/32 .0132 .0263 .0395 .0527 .0659 .0790 .0922 .1054 .1317 .1580 .2371 .3161 3.0440
2 .0136 .0272 .0408 .0544 .0680 .0816 .0952 .1088 .1360 .1632 .2448 .3264 3.1416
2 3/16 .0163 .0325 .0488 .0650 .0812 .0976 .1137 .1300 .1625 .1952 .2928 .3904 3.7584
2 1/4 .0172 .0344 .0516 .0688 .0860 .1033 .1205 .1377 .1721 .2071 .3104 .4137 3.9760
2 1/2 .0212 .0425 .0637 .0850 .1062 .1275 .1487 .1700 .2125 .2550 .3825 .5100 4.9070
2 3/4 .0257 .0514 .0771 .1028 .1285 .1543 .1800 .2057 .2571 .3085 .4628 .6171 5.9395
3 .0306 .0612 .0918 .1224 .1530 .1836 .2142 .2448 .3060 .3672 .5508 .7344 7.0686
Table showing amount of water discharged per stroke by single acting cylinder.
The diameter of cylinder and length of stroke being known.
To obtain the capacity of a pump with a diameter of cylinder given in the table, but with a longer stroke than 24 inches (the longest
stroke given in teh table), add or multiply the capacity to represent the required length of stroke.
For instance: The capacity of a cylinder with a 30 inche stroke would be the same as that (having the same diameter) of an 18 inch
stroke cylinder, added to the capacity of a 12 inch stroke cylinder. The same result may be obtained by multiplying the capacity of
a cylinder with a 10 instroke by 3.
To obtain the amount of water discharged per minute, multiply the capacity per stoke by the number of strokes per minute. To
obtain the amount of water discharged per hour, multiply this figure by 60.
Capacities are given in American Gallons. To find English gallons, deduct 1/6; to find liters, multiply by 3.75.
®
Product Number Description List Price Page
8599E Plunger Assembly w/ leathers 449B 2 3/4” 259.07 73
8853DA Bottom Cap Check Assembly 442 3” 173.98 74
8853U Bottom Cap Check Assembly 442 1 11/16” 95.36 74
8853V Bottom Cap Check Assembly 442 1 13/16” 65.75 74
8853W Bottom Cap Check Assembly 442 2” 85.03 74
8853X Bottom Cap Check Assembly 442 2 1/4” 83.79 74
8853Z Bottom Cap Check Assembly 442 2 1/2” 117.32 74
8854A Check Poppet w/ facing 442 1 11/16” 9.69 74
8854B Check Poppet w/ facing 442 1 13/16” 14.29 74
8854C Check Poppet w/ facing 442 2” 14.56 74
8854D Check Poppet w/ facing 442 2 1/4” & 2 1/2” 25.86 74
8854G Check Poppet w/ facing 442 3” 59.60 74
6/14/11
1.80
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Rod Couplings
720 Rod Couplings
Part Number Size Size of Hexagon Overall Length Ctn Qty List Price
8075B1 3/8”x3/8” 5/8” 1-3/4” 25 $ 1.81
8075C1 7/16”x3/8” 5/8” 1-3/4” 25 1.81
8075D1 7/16”x7/16” 5/8” 1-3/4” 25 1.83
8075E1 1/2”x3/8” 11/16” 1-3/4” 25 3.23
8075F1 1/2”x7/16” 11/16” 1-3/4” 25 3.39
8075G1 1/2”x1/2” 11/16” 1-3/4” 25 2.28
8075J1 5/8”x7/16” 13/16” 2-1/8” BULK 4.71
8075K1 5/8” x 1/2” 13/16” 2 1/8” BULK 8.83
8075L1 5/8”x5/8” 13/16” 2-1/8” BULK 4.65
720
720 Series Rod Coupling Features:
• Hexagon shaped, galvanized couplings.
• Made from solid bars of cold-rolled steel.
• Use to connect steel pump rods.
4/2009
1.89
TM www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Jet-Lube®
Add extra years to the life of any drill rig with the
products used for years.
Use Jet-Lube specialty lubricants, thread compounds and sealants on drill rods, pipe, collars,
stabs, subs, wire and cable for lower down-time and longer rig life.
Water well drillers use Jet-Lube products on pumps, compressors and potable water connections. You name it,
there's a Jet-Lube product for it. There's even environmental safe cleaners and degreasers.
Jet-Lube products are tested tough every day. Every product is the result of more than 50 years of testing and
research. Jet-Lube is the only thread compound manufactured with its own downhole simulation,
testing and certification equipment. Products are tested on rigs all over the world. Whether
drilling in soft rock or harder formations, Jet-Lube delivers ultimate protection.
On tool joints, drill rods and pipe, on threaded connections, flanges and
exposed threads. For water wells and monitor wells.
For swivels, crown bearings, travel blocks and open gears; for anti-friction
bearings; for all lube points on rigs.
On cables, ropes, sheave grooves; on cable spool guides and running gears;
roller chain.
For potable water line connections; lines for fuel and gases.
For truck machinery; floors, tanks and trucks.
Jobsite protection.
5
6
4
3
2
1
Where to apply Jet-Lube products:
ISO 9001
6/14/11
1.90
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Jet-Lube®
Kopr-Kote® Heavy Duty Drill Pipe Compound (Lead Free)
A high performance, lead free, copper based thread com-
pound for heavy duty drilling. Protects against seizure, galling
and downhole makeup.
ARCTIC grade also available. Temp. rating -65°F to 300°F.
Part Net Contents & Shipping Case Case List
Number Container Type Weight/Case Equivalents Qty Price
JL10050 14 oz. cartridge 36 lbs. 1 30 $ 35.89
JL10023 1 gal pail 11 lbs. 1 1 164.04
JL10012 2 gal pail 21 lbs. 1 1 309.57
JL10015 5 gal pail 52 lbs. 2 1 614.89
JL10512 ARCTIC GRADE 2 gal pail 21 lbs. 1 1 340.50
JL10515 ARCTIC GRADE 5 gal pail 52 lbs. 2 1 676.36
JL100 Series
Jet-Lube 21® Intermediate Grade Drill Pipe Compound (Lead Free)
The lead free professional choice for intermediate drilling applications in softer
formations. Environmentally safe.
Part Net Contents & Shipping Case Case List
Number Container Type Weight/Case Equivalents Qty Price
JL10923 1 gal pail 10 lbs. 1 1 $ 106.18
JL10912 2 gal pail 20 lbs. 1 1 206.57
JL10915 5 gal pail 49 lbs. 2 1 423.61
JL109 Series
Jet-Lube Dope Brushes
Thread compound dope brushes, taper or bevel style. 1 1/8" x 16". Can be used
in 1, 2 or 5 gallon pails.
Part Net Contents & Shipping Case Case List
Number Container Type Weight/Case Equivalents Qty Price
JL03000 1 1/8" x 16" Taper 9 lbs. 1 12 $ 35.29
JL03500 1 1/8" x 16" Bevel 9 lbs. 1 12 33.79
JL03 Series
1
1
1
ISO 9001
Eco-Safe™ Nonmetallic Thread Compound
Premium quality, nonmetallic thread compound containing carbon based
fibers and additives and other extreme pressure and anti-wear additives.
Part Net Contents & Shipping Case Case List
Number Container Type Weight/Case Equivalents Qty Price
JL14523 1 gal pail 12 lbs. 1 1 $ 152.79
JL14512 2 gal pail 22 lbs. 1 1 308.39
JL14515 5 gal pail 48 lbs. 1 1 504.07
JL145 Series
1
Bullseye™ Water Well and Environmental Compound
High purity thread compound designed for sensitive water well and other envi-
ronmental drilling applications requiring a petroleum hydrocarbon-free product.
Part Net Contents & Shipping Case Case List
Number Container Type Weight/Case Equivalents Qty Price
JL66823 1 gal pail 12 lbs. 1 1 $ 250.68
JL66812 2 gal pail 20 lbs. 1 1 476.75
JL668 Series
1
6/14/11
1.91
TM www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Jet-Lube®
Run-N-Seal® Tubing and Casing Sealant
An environmentally safe nonmetallic sealant for threaded tubing and casing. Passes
California COR Title 22
Part Net Contents & Shipping Case Case List
Number Container Type Weight/Case Equivalents Qty Price
JL17023 1 gal pail 11 lbs. 1 1 $ 114.21
JL17012 2 gal pail 22 lbs. 1 1 204.32
JL17015 5 gal pail 54 lbs. 2 1 447.46
JL170 Series
Well-Guard® Monitor Well Drill Thread Compound
A thread compound which provides state-of-the-art protection against galling, seizure
and thread damage while being in full compliance with all EPA guidelines. Petroleum
hydrocarbon-free and brushable to -10°F. Test results available.
Part Net Contents & Shipping Case Case List
Number Container Type Weight/Case Equivalents Qty Price
JL18572 1 pint plastic jar 14 lbs. 1 12 $ 72.96
JL18523 1 gal pail 11 lbs. 1 1 478.96
JL18515 5 gal pail 54 lbs. 2 1 2002.29
JL185 Series
RD-N™ Synthetic Rock Drilling Oil for Environmental Drilling
Provides superior lubrication for all makes of pneumatic percussion tools and prevents
premature wear of hammer bits. An ISO 100/SAE 30 oil which exceeds all current EPA
guidelines. Certified test results available. Can be used as a wire rope lubricant or
hydraulic oil on restricted sites where petroleum based products are banned.
Part Net Contents & Shipping Case Case List
Number Container Type Weight/Case Equivalents Qty Price
JL18033 1 gal jug 36 lbs. 1 4 $ 187.43
JL18035 5 gal jug 42 lbs. 2 1 844.25
JL180 Series
1
1
1
ISO 9001
JLS® Economy Grade Drill Pipe Compound (Lead Free)
Economical choice for use only where drilling conditions are
least demanding. For use in light to medium drilling in sandy
formations. Environmentally safe.
Part Net Contents & Shipping Case Case List
Number Container Type Weight/Case Equivalents Qty Price
JL11923 1 gal pail 10 lbs. 1 1 $ 84.79
JL11912 2 gal pail 20 lbs. 1 1 157.07
JL11915 5 gal pail 50 lbs. 2 1 330.18
JL119 Series
1
Enviro-Guard™ Drop Pipe Lubricant and Sealant.
Specially formulated to aid in the assembly/disassembly of downhole casing
for water wells.
Part Net Contents & Shipping Case Case List
Number Container Type Weight/Case Equivalents Qty Price
JL18423 1 gal pail 12 lbs. 1 1 $ 188.54
JL18412 2 gal pail 24 lbs. 1 1 355.32
JL18415 5 gal pail 48 lbs. 1 1 859.82
JL184 Series
1
6/14/11
1.92
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Jet-Lube®
769 Lubricant® and Penetrant
Heavy duty penetrating lubricant for all environments. When
drilling in marshland or near coastlines, protects operating parts
against salt corrosion. Frees rusted and frozen parts, displaces
moisture, cleans and prevents rust. Non-flammable.
MIL-C-23411A. Federal spec V V-P-216B. USDA-H2
Part Net Contents & Shipping Case Case List
Number Container Type Weight/Case Equivalents Qty Price
JL37341 12 oz. aerosol 12 lbs. 1 12 $ 18.96
JL37341
WLD™ Wire Rope, Cable and Roller Chain Dressing and Lubricant
Extend the life of wirelines, ropes, cables, grooves. Specially formulated with molyb-
denum disulfide and graphite to reduce friction and wear on cable strands. Tacky and
adhesive for lasting protection. Penetrates wire strands to lubricate the core, then keeps
on working to prevent moisture from corroding the cable. Black
Part Net Contents & Shipping Case Case List
Number Container Type Weight/Case Equivalents Qty Price
JL28541 12 oz. aerosol 12 lbs. 1 12 $ 21.75
JL28541
WRL™ Wire Rope and Chain Lubricant/Oil
USDA authorized non-drying film penetrates to the rope core for long-term protection.
May be applied by spraying, pouring or with automatic lube system. Pumpable to -25F.
Amber
Part Net Contents & Shipping Case Case List
Number Container Type Weight/Case Equivalents Qty Price
JL34041 12 oz. aerosol 12 lbs. 1 12 $ 22.64
JL34041
2
3
3
ISO 9001
ALCO-EP™ Premium Grease with Moly-Aluminum Complex (Black)
Water restant aluminum complex based grease contains graphite, molybdenum disul-
fide and premium EP additive package for maximum metal protection, water resistance
and high temperature (450F) capability in an all-weather formulation. NLGI Grade 2
Part Net Contents & Shipping Case Case List
Number Container Type Weight/Case Equivalents Qty Price
JL37050 14 oz. cartridge 36 lbs. 1 30 $ 15.00
JL37050
2
ALCO-EP™ EFC™ WW Extreme Service Multipurpose Grease.
Premium multipurpose calcium sulfonate complex grease thick-
ening a blend of synthetic oils selected to provide the level of
biodegradation required to meet the most safe enviromental rat-
ings.
Part Net Contents & Shipping Case Case List
Number Container Type Weight/Case Equivalents Qty Price
JL36950 14 oz. cartridge 36 lbs. 1 30 $ 23.00
JL36916 35 lb. pail 39 lbs. 1 1 753.79
JL369 Series
2
6/14/11
1.93
TM www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Jet-Lube®
TFW™ Anti-Sieze Thread Sealant with PTFE
Low friction and non-toxic, TFW is used to prevent thread leaks of almost all fluids,
gases or steam, even at temperatures up to 500 F. Can be used on metal, PVC, ABS and
CPVC fittings and piping. IAPMO approved.
Part Net Contents & Shipping Case Case List
Number Container Type Weight/Case Equivalents Qty Price
JL24002 1/2 pint brush top can 9 lbs. 1 12 $ 26.82
JL24004 1 pint brush top can 17 lbs. 1 12 38.79
JL240 Series
Pitless Adapter Lube™ Assembly Lubricant
Preservative designed to aid in installation of pitless adapters. USDA H-1 authorized.
Corrosion preventative contains anti-bacterial/anti-fungal additive.
Part Net Contents & Shipping Case Case List
Number Container Type Weight/Case Equivalents Qty Price
JL71741 12 oz. aerosol 13 lbs. 1 12 $ 22.68
JL71741
TF-15® Thread Sealant with PTFE for fiberglass pipe
High pressure thread sealant containing PTFE and EP additives that allow for easy
breakout without seizing, stripping or galling. Highly recommended for use as a sealant
on fiberglass tubing and casing threads. Passes California COR Title 22
Part Net Contents & Shipping Case Case List
Number Container Type Weight/Case Equivalents Qty Price
JL23023 1 gal pail 11 lbs. 1 1 $ 157.14
JL23023
Easy-Clean® Concentrated Rig Wash
A biodegradable detergent to clean oil and grime from equipment or pumping station
machinery. Industrial strength concentrated powdered detergent.
Part Net Contents & Shipping Case Case List
Number Container Type Weight/Case Equivalents Qty Price
JL30519 40 lb. 6 gal pail 43 lbs. 2 1 $ 345.18
JL30519
4
4
4
5
ISO 9001
V-2® Multi Purpose PTFE Thread Sealant
A soft setting, non-petroleum based thread sealant for use
where immediate pressurization is desired. Non-staining, low
odor, off white in color. Use on all types of metals, reinforced
fiberglass and PVC. MIL-TT-S-1732. USDA H-2 Authorized.
IAPMO Approved.
Part Net Contents & Shipping Case Case List
Number Container Type Weight/Case Equivalents Qty Price
JL35502 1/2 pint brush top can 11 lbs. 1 12 $ 29.32
JL35504 1 pint brush top can 19 lbs. 1 12 43.46
JL355 Series
4
6/14/11
1.94
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Jet-Lube®
Jet-Lube 5000™ Water Based Cleaner and Degreaser
Emulsifies (lifts and suspends) dirt, carbon, grease, etc., for
removal by rinsing or wiping. May be used on surfaces compati-
ble with water. Use full strength or dilute with fresh or salt water.
Environmentally safe and compliant with EPA 624 & 625.
Part Net Contents & Shipping Case Case List
Number Container Type Weight/Case Equivalents Qty Price
JL71043 16 oz. trigger spray 14 lbs. 1 12 $ 18.75
JL71033 1 gal jug 35 lbs. 1 4 73.68
JL71035 5 gal jug 45 lbs. 2 1 299.89
JL710 Series
Clean-Up Plus™ Organic Solvent Cleaner
Environmentally safe cleaner and degreaser. Blend of organic solvents, safe non-flam-
mable CO2 propellant. Citrus scent. Residue free product is safe on all metals. 29KV
dielectric strength. No Tri 1-1-1. USDA authorized.
Part Net Contents & Shipping Case Case List
Number Container Type Weight/Case Equivalents Qty Price
JL72542 15 oz. aerosol 16 lbs. 1 12 $ 21.82
JL72542
Clean-Up™ Industrial Cleaner and Safety Solvent
Heavy duty low foaming cleaner/degreaser. Fast working, non-flammable residue free
product formulated with an ozone friendly chlorinated solvent. 29 KV dielectric strength.
No Tri 1-1-1.
Part Net Contents & Shipping Case Case List
Number Container Type Weight/Case Equivalents Qty Price
JL61542 18 oz. aerosol 15 lbs. 1 12 $ 21.93
JL61542
Moly Mist™ Dry Film Lubricant
Use to break in equipment and assemble moving parts. Micro-fine molybdenum disul-
fide suspended in a quick-drying carrier. Bonds to any surface in seconds to provide low
coefficient of friction, extended lubrication and improved operation.
Part Net Contents & Shipping Case Case List
Number Container Type Weight/Case Equivalents Qty Price
JL16041 12 oz. aerosol 13 1 12 $ 28.29
JL16041
TOP-GUN™ Wasp and Hornet Killer
EPA registered formula kills wasps, hornets, yellow jackets and bees on contact from
15-20 feet. Instant knockdown. Non conductive - 35KV formula for total protection.
Part Net Contents & Shipping Case Case List
Number Container Type Weight/Case Equivalents Qty Price
JL51541 14 oz. aerosol 15 1 12 $ 20.96
JL51541
5
5
5
5
6
ISO 9001
6/14/11
2.1
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Check Valves - Brass, Bronze
Part Number Size Ctn Qty List Price
CV50BS 1/2” 100 $ 10.07
CV75BS 3/4” 80 13.71
CV100BS 1” 60 20.00
CV125BS 1 1/4” 40 33.27
CV150BS 1 1/2” 30 37.38
CV200BS 2” 20 66.72
CV-BS Series BRASS Check Valves
• Rough body finish.
CHECK VALVE Features:
• Cast Brass, bronze, lead free brass or
stainless steel body & poppet.
• Buna-N o-ring (Viton on stainless steel).
• Stainless steel springs, washers, locknuts.
• Delrin poppet stem guide.
• 200 psi WOG working presure.
• 300 lb. max hang weight (down pull) tension.
• Individually cartoned.
• Imported.
CV-BS Series
Part Number Size Ctn Qty List Price
CV50B 1/2” 100 $ 13.25
CV75B 3/4” 80 19.36
CV100B 1” 60 27.32
CV125B 1 1/4” 40 38.39
CV150B 1 1/2” 30 51.96
CV200B 2” 20 89.11
CV300B 3” 6 308.04
CV400B 4" 3 653.04
CV-B Series BRONZE Check Valves
• Machined body finish.
CV-B Series
Part Number Size Ctn Qty List Price
CVNL50BS 1/2” 100 $ 11.96
CVNL75BS 3/4” 80 17.75
CVNL100BS 1” 60 26.17
CVNL125BS 1 1/4” 40 41.31
CVNL150BS 1 1/2” 30 47.63
CVNL200BS 2” 20 77.48
CVNL300BS 3” 6 273.21
CVNL400BS 4” 3 668.98
CVNL-BS Series LEAD FREE BRASS Check Valves
• Rough body finish.
CVNL-BS Series
Part Number Size Ctn Qty List Price
CVXLD100BS 1” x 1" 60 $ 38.75
CVXLD125BS 1 1/4" x 1 1/4" 40 45.54
CVXLD Series BRASS Check Valves
• Rough body finish.
• Extra long at discharge end.
CVXLD Series
6/14/11
2.2
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Check Valves - Brass, Bronze, Stainless Steel
Part Number Size Ctn Qty List Price
SSCV50 1/2” 100 $ 24.65
SSCV75 3/4” 80 33.55
SSCV100 1” 60 44.23
SSCV125 1 1/4” 40 59.14
SSCV150 1 1/2” 30 77.53
SSCV200 2” 20 128.71
SSCV300 3” 6 545.16
SSCV400 4” 3 1048.57
SSCV1025 1” fpt x 1 1/4” mpt 60 62.50
SSCV Series STAINLESS STEEL Check Valves
• 304 cast stainless steel casting, springs, washers, lock nut.
• Viton o-ring
Part Number Size (FPT X MPT) Ctn Qty List Price
CVMR100BS 1” x 1" 60 $ 30.89
CVMR-BS Series BRASS Submersible Check Valves
• Rough body finish.
• FPT x MPT
IMPORTED CHECK VALVE Features:
• Cast Brass, bronze, lead free brass or
stainless steel body & poppet.
• Buna-N o-ring (Viton on stainless steel).
• Stainless steel springs, washers, locknuts.
• Delrin poppet stem guide.
• 200 psi WOG working presure.
• 300 lb. maximum hang weight (down pull)
tension.
• Individually cartoned.
• Imported.
SSCV Series
CVMR-BS Series
Part Number Size (FPT X MPT) Ctn Qty List Price
CVM100B 1” x 1" 60 $ 35.89
CVM125B 1" x 1 1/4" 60 34.29
CVM1252B 1 1/4" x 1 1/4" 40 51.25
CVM-B Series BRONZE Submersible Check Valves
• Machined body finish.
• FPT x MPT
CVM-B Series
Part Number Size (MXF) Ctn Qty List Price
CVMXL100BS 1” x 1" 60 $ 26.61
CVMXL125BS 11/4" x 1 1/4" 40 34.82
CVMXL Series BRASS Submersible Check Valves
• Rough body finish.
• Extra long body.
CVMXL Series
6/14/11
2.3
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Check Valves - Brass, Bronze
CHECK VALVE Features:
• Cast Brass, bronze, lead free brass or
stainless steel body & poppet.
• Buna-N o-ring (Viton on stainless steel).
• Stainless steel springs, washers, locknuts.
• Delrin poppet stem guide.
• 200 psi WOG working presure.
• 300 lb. maximum hang weight (down pull)
tension.
• Individually cartoned.
• Imported
Part Number Size (FPT X MPT) Ctn Qty List Price
CVMNL1252BS 1 1/4" x 1 1/4" 40 $ 51.61
CVMNL-BS Series LEAD FREE BRASS Submersible Check Valves
• Rough body finish.
• FPT x MPT
CVMNL-BS Series
Part Number Size Ctn Qty List Price
CVT1001B 1" 60 $ 35.64
CVT1251B 1 1/4" 40 39.91
CVT-1B Series BRONZE Single Tap Check Valves
• Machined body finish.
• 1/8" inlet tap.
CVT-1B Series
Part Number Size Ctn Qty List Price
CVRT1002BS 1" 60 $ 31.25
CVRT1252BS 1 1/4" 40 43.96
CVRT-2BS Series BRASS Double Tap Check Valves
• Rough body finish.
• One 1/8" inlet tap.
• One 1/4" outlet tap.
CVRT-2BS Series
6/14/11
2.4
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Check Valves - Brass, Bronze
CHECK VALVE Features:
• Cast Brass, bronze, lead free brass or
stainless steel body & poppet.
• Buna-N o-ring (Viton on stainless steel).
• Stainless steel springs, washers, locknuts.
• Delrin poppet stem guide.
• 200 psi WOG working presure.
• 300 lb. maximum hang weight (down pull)
tension.
• Individually cartoned.
• Imported.
Part Number Size Ctn Qty List Price
CVT1002B 1" 60 $ 33.57
CVT1252B 1 1/4" 40 45.00
CVT1502B 1 1/2" 30 56.96
CVT2002B 2" 20 112.50
CVT-2B Series BRONZE Double Tap Check Valves
• Machined body finish.
• One 1/8" inlet tap.
• One 1/4" outlet tap.
CVT-2B Series
Part Number Size Ctn Qty List Price
CVT1003B 1" 60 32.68
CVT1253B 1 1/4" 40 38.04
CVT-3B Series BRONZE Control Center Check Valves
• Machined body finish.
• One 1/8" inlet tap.
• One 1/8" and one 1/4" outlet taps.
CVT-3B Series
Part Number Size Ctn Qty List Price
CVC100B 1" 60 34.46
CVC125B 1 1/4" 40 40.38
CVC-B Series BRONZE Control Center Check Valves
• Machined body finish.
• One 1/8" inlet tap.
• One 1/8" and two 1/4" outlet taps.
CVC-B Series
6/14/11
2.5
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Foot Valves - Brass, Bronze
FOOT VALVE Features:
• Cast Brass, bronze, lead free brass or
stainless steel body & poppet.
• Buna-N o-ring (Viton on stainless steel).
• Stainless steel springs, washers, locknuts and strainers.
• 200 psi WOG working presure.
• Individually cartoned.
• Imported.
Part Number Size Enters Pipe Ctn Qty List Price
FVR50BS 1/2" 1 1/4" 100 $ 10.60
FVR75BS 3/4" 1 1/2" 80 14.11
FVR100BS 1" 2" 60 19.92
FVR125BS 1 1/4" 2 1/2" 40 26.22
FVR150BS 1 1/2" 3" 30 31.25
FVR200BS 2" 3 1/2" 20 52.68
FVR-BS Series BRASS Foot Valves
• Rough body finish.
FVR-BS Series
Part Number Size Enters Pipe Ctn Qty List Price
FV50B 1/2" 1 1/4" 100 $ 13.25
FV75B 3/4" 1 1/2" 80 15.38
FV100B 1" 2" 60 23.39
FV125B 1 1/4" 2 1/2" 40 30.89
FV1251B 1 1/4" 2" 50 31.84
FV150B 1 1/2" 3" 30 40.89
FV200B 2" 3 1/2" 20 69.82
FV300B 3" 5" 8 261.61
FV400B 4" - 4 455.36
FV-B Series BRONZE Foot Valves
• Machined body finish.
FV-B Series
Part Number Size Enters Pipe Ctn Qty List Price
FV100125B 1" FPT x 1 1/4"MPT 2" 60 $ 28.21
FV-B Series BRONZE Dual Purpose Foot Valves
• Machined body finish.
FV-BS Series
2/15/11
2.6
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Foot Valves - Brass, Bronze, Stainless Steel
Part Number Size Enters Pipe Ctn Qty List Price
SSFV50 1/2” 1 1/4" 100 $ 16.79
SSFV75 3/4” 1 1/2" 80 21.71
SSFV100 1” 2" 60 41.79
SSFV125 1 1/4” 2 1/2" 40 55.34
SSFV150 1 1/2” 3" 30 58.07
SSFV200 2” 3 1/2" 20 124.89
SSFV300 3” 5" 8 464.41
SSFV400 4” - 4 735.21
SSFV Series STAINLESS STEEL Foot Valve Features:
• 304 Stainless steel casting, spring, washer, locknut, strainer
• Viton o-ring
FOOT VALVE Features:
• Cast Brass, bronze, lead free brass or
stainless steel body & poppet.
• Buna-N o-ring (Viton on stainless steel).
• Stainless steel springs, washers, locknuts and strainers.
• 200 psi WOG working presure.
• Individually cartoned.
• Imported.
SSFV Series
Part Number Size Enters Pipe Ctn Qty List Price
FVNL50BS 1/2" 1 1/4" 100 $ 10.47
FVNL75BS 3/4" 1 1/2" 80 16.96
FVNL100BS 1" 2" 60 24.61
FVNL125BS 1 1/4" 2 1/2" 40 33.13
FVNL150BS 1 1/2" 3" 30 39.21
FVNL200BS 2" 3 1/2" 20 72.14
FVNL300BS 3” 5” 8 232.50
FVNL400BS 4” - 4 427.86
FVNL Series LEAD FREE BRASS Foot Valves
• Rough body finish.
FVNL-BS Series
Screen/Cap/Screw Spring FVSC CVSP
Part Number Part Number Size List Price List Price
FVSC50 CVSP50 1/2” $ 6.36 $ 2.68
FVSC75 CVSP75 3/4” 6.71 2.68
FVSC100 CVSP100 1” 7.36 2.68
FVSC125 CVSP125 1 1/4” 8.86 3.36
FVSC150 CVSP150 1 1/2” 9.11 3.36
FVSC200 CVSP200 2” 9.50 3.75
FVSC300 CVSP300 3” 43.75 4.43
FVSC400 CVSP400 4” 62.50 4.79
FVSC, CVSP Series Stainless Screen, Endcap, Screw, Spring
• Spring replacement for all imported check and foot valves
FVSC & CVSP Series
6/14/11
2.17
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Yard Hydrants - Frost Proof
5451 Series Frost Proof Yard Hydrant
Features:
• Fully frost proof, shut-off valve below frost line.
• Heavy cast iron head with 3/4” brass discharge connection
and bucket hook.
• Heavy, galvanized steel, corrosion resistant, 1” stand-pipe.
• Galvanized carbon steel connecting rod. Brass operating rod.
• Long lasting Buna-N rubber plunger with solid brass core.
• Integral valve seat cast into BRONZE valve body. 3/4” FPT connection with
double bypass bottom valve for superior flow, less risk of debris blockage.
• 1/8” FPT drain hole.
• Rated to 80 PSI, adjustable. See page 2.18 for adjustment procedure.
• Packed securely in individual heavy weight carton.
• Independent lab tested.
• CE certified.
Part Number Bury Overall Weight List Price
Depth Length (Pounds)
54511 1 42” 12.4 $ 117.59
54512 2 54” 15.2 123.98
54513 3 66” 17.8 134.62
54514 4 78” 21.0 143.67
54515 5 90” 22.3 154.31
54516 6 102” 26.2 162.82
54518 8 126” 30.7 184.10
5451 Series
Part Number Size # Barbs Ctn/Case Qty List Price
Vacuum Breaker
HVB75 3/4” Meets ASSE 1011 specifications 20/200 $ 7.54
Cast Bronze Hydrant Elbow (INSxMIP)
RBHE3/4 3/4”x 3/4” 5 10/100 11.80
RBHE1X3/4 1” x 3/4” 5 10/100 16.39
RBHE1 1” x 1” 5 10/100 16.75
RBHE11/4 1 1/4” x 1 1/4” 5 5/50 30.86
Cast Bronze Extra Long Hydrant Elbow (INS x MIP)
XLRBHE1 1”x 1” 8 10/100 21.61
XLRBHE1X3/4 1” x 3/4” 10 10/100 18.75
Cast Bronze Hydrant Tee (INS x MIP)
RBHT3/4 3/4” x 3/4” 4 10/100 16.00
RBHT1x3/4 1” x 3/4” 6 10/100 21.25
RBHT1 1” x 1” 4 10/100 21.61
RBHE
RBHT
HVB75
# Item Material
9 Handle Cast iron
10 Clevis Rod 360 brass
11 Head Cast Iron
13 Hose Adpt 3/4" 360 brass
14 Bottom valve Bronze 81-3-7-9
Stand Pipe Steel - galvanized 1”
Materials of Construction
# Item Material
1 Plunger Buna-N/360 brass
2 Fulcrum Bolt Steel - Zinc plated
3 Fulcrum Nut Steel - Zinc plated
4 Links Steel - Zinc plated
5 Set Screw Steel - Zinc plated
6 Packing Nut 360 brass
7 Packing Teflon filled graphite
8 Connector Brass
®
NEW, Improved
flow rates*
45 gpm @ 50 psi
4/2009
2.18
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Yard Hydrants - Replacement Parts
5451 Series Hydrant Replacement Parts
Part Number Item Number Description List Price
YRK1 Repair Kit (Items 1-8) $ 17.33
9175B 1 Plunger - rubber 6.37
9023B 2 Fulcrum Bolt - steel 0.36
9023C 3 Nut - steel 0.27
9023D 4 Links (set of 2) - steel 2.38
9023E 5 Set Screw square head - steel 0.47
9023A 6 Packing Nut - brass 2.78
29609G 7 Packing - graphite (2 - 1 old, 1 new style) 3.56
9023G 8 Connector - brass 5.31
2506K 9 Handle - painted cast iron 10.14
2222AHNS 10 Clevis Rod - brass NEW STYLE (double bypass) 11.77
2500K 11 Head only - painted cast iron 34.19
382914 13 Hose Adapter - brass 7.31
381504 14 Valve Body - bronze 45.00
2575K Complete Head Assembly (Items 2-13) 53.59
STEEL ROD (use with double bypass valve 5451 Series)
TA7100099NS 54511 Rod (32 5/8” old or 32.4” new) 7.49
TA7100100NS 54512 Rod (44 5/8” old or 44.4” new) 10.62
TA7100101NS 54513 Rod (56 5/8” old or 56.4” new) 13.67
TA7100102NS 54514 Rod (68 5/8” old or 68.4” new) 16.51
TA7100103NS 54515 Rod (80 5/8” old or 80.4” new) 19.39
TA7100104NS 54516 Rod (92 5/8” old or 92.4” new) 22.28
TA7100105NS 54518 Rod (116 5/8” old or 116.4” new) 24.45
®
5451 HYDRANT ADJUSTMENT PROCEDURE
1. Turn water supply OFF.
2. Open hydrant to relieve pressure.
3. Loosen set screw. (Item 1)
4. Push brass rod down as far as it will go by hand to be sure the plunger is touching the
seat.
5. Open handle (Item 2) approximately 30° from closed position.
6. Tighten set screw snugly.
7. Turn water supply ON.
8. Operate hydrant and make sure the hydrant is shutting off properly and flowing properly.
9. If hydrant still does not shut off, repeat steps 1 through 8.
10. Flow water through hydrant and then close completely to check for proper drainage by:
a) listening for water draining down pipe or
b) putting your hand over the hose connection to feel for a vacuum.
If hydrant does not drain, see step 11.
11. To clear drain hole blockage, close off hydrant spout by using hose cap or by attaching and kinking a hose. Open and close
hydrant to allow water pressure to clear blockage. Repeat step 10 to verify proper drainage. If hydrant still does not drain, repeat
steps 1 through 10 to fully uncover drain hole.
CAUTION: Do not try to make the shutoff adjustment in one attempt or you may overadjust and cause damage to the plunger and
3/4” 5451 Hydrant Flow Rates
PSI
10
15
20
25
30
35
40
45
50
GPM 15 20 25 30 35 40 45
45 GPM @ 50 PSI
42.5 GPM @ 45 PSI
37.5 GPM @ 35 PSI
40 GPM @ 40 PSI
35 GPM @ 30 PSI
32.5 GPM @ 25 PSI
29.3 GPM @ 20 PSI
25.7 GPM @ 15 PSI
20 GPM @ 10 PSI
NOTE: All 5451 Series Hydrants are preset at factory. There should be no need for any adjustment on initial installation. Adjust
only if water does not shut off or hydrant does not operate properly.
6/14/11
2.19
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Part Bury Pipe Overall
Number Depth Length Length Ctn Qty List Price
H800 1 ft 33” 39 1/2” 1 $ 146.02
H801 1 1/2 ft 41” 47 1/2” 1 150.10
H802 2 ft 47” 53 1/2” 1 154.49
H803 3 ft 59” 65 1/2” 1 163.16
H804 4 ft 71” 77 1/2” 1 174.85
H805 5 ft 83” 89 1/2” 1 186.58
H806 6 ft 95” 101 1/2” 1 201.33
H807 7 ft 107” 113 1/2” 1 213.01
H808 8 ft 119” 125 1/2” 1 228.21
Part Number Size # Barbs Ctn/Case Qty List Price
Vacuum Breaker
HVB75 3/4” Meets ASSE 1011 specifications 20/200 $ 7.54
Cast Bronze Hydrant Elbow (INSxMIP)
RBHE3/4 3/4”x 3/4” 5 10/100 11.80
RBHE1X3/4 1” x 3/4” 5 10/100 16.39
RBHE1 1” x 1” 5 10/100 16.75
RBHE11/4 1 1/4” x 1 1/4” 5 5/50 30.86
Cast Bronze Extra Long Hydrant Elbow (INS x MIP)
XLRBHE1 1”x 1” 8 10/100 21.61
XLRBHE1X3/4 1” x 3/4” 10 10/100 18.75
Cast Bronze Hydrant Tee (INS x MIP)
RBHT3/4 3/4” x 3/4” 4 10/100 16.00
RBHT1x3/4 1” x 3/4” 6 10/100 21.25
RBHT1 1” x 1” 4 10/100 21.61
Deluxe Frost Proof Yard Hydrant Features:
• FROST-PROOF - Shut-off valve operates below the
frost line.
• Pistol type handle eliminates pinching.
• Can be padlocked.
• Wheel handle controls water flow at rate desired.
• Solid brass rod will not rust or cut into packing.
• Water in standpipe drains out when hydrant is off.
• Brass nozzle threaded for standard 3/4” hose coupling.
• Inner parts removable without digging.
• 80 PSI maximum pressure.
• Individually boxed.
RBHE
RBHT
HVB75
CONTAINS LEAD - Not for
sale in California. Call for
lead free hydrant quote.
2/15/11
2.20
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Yard Hydrants - Replacement Parts
Part Reference
Number Number Name of Part List Price
8820 A Head $ 52.74
8821 B Handle 17.14
8822 C Valve Body 60.34
8823 D Brass Extension 11.66
8824 E Hand Wheel 2.98
8825 * F Connector - brass 28.95
8826 * G Links(pair) - brass 15.35
8827 * H Packing Nut - brass 10.17
8828 I Brass Hose Adapter 10.94
8829 J Hydrant Stem 4.16
8839 * K O-Ring Packing 2.87
8814-0 L 7/16” Pump Rod for H800 25.07
8814-1 7/16” Pump Rod for H801 31.45
8814-2 7/16” Pump Rod for H802 37.50
8814-3 7/16” Pump Rod for H803 47.89
8814-4 7/16” Pump Rod for H804 58.02
8814-5 7/16” Pump Rod for H805 68.20
8814-6 7/16” Pump Rod for H806 78.21
8814-7 7/16” Pump Rod for H807 88.39
8814-8 7/16” Pump Rod for H808 98.41
8815-0 M Pipe Casing for H800 28.77
8815-1 Pipe Casing for H801 37.93
8815-2 Pipe Casing for H802 45.16
8815-3 Pipe Casing for H803 57.21
8815-4 Pipe Casing for H804 69.22
8815-5 Pipe Casing for H805 81.22
8833 * N Plunger - Buna-N 12.44
8834 P Rod Coupling 4.70
8301 * Q Lock Nut - stainless steel 0.91
8836 * R Fulcrum Bolt - stainelss steel 3.72
8837 * S Set Screw - stainless steel 1.81
8610 T Screw for Wheel 1.47
840 Head, Complete 85.86
850 *Included in Parts Kit 41.77
Replacement Parts For H800 Series Hydrants
5/3/11
3.1
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Ball Valves - Brass
Forged Brass Full Port Ball Valve Features:
• Heavy pattern forged brass construction.
• Full port allows maximum flow & minimum pressure drop or turbulence.
• Teflon® seats, chrome plated brass ball.
• Teflon® stem packing with adjustable gland follower.
• Blow out proof stem design.
• 600 PSI W.O.G. non-shock; 150 PSI S.W.P. (400 PSI 21/2”, 3” 4”)
• CSA Certified, UL Listed.
• Imported, Manufactured for American Granby in an ISO 9001 facility.
Part Number Ctn/Case List Price Part Number List Price
Threaded Size Qty Threaded Sweat Sweat
HFBV6-25T 1/4” 50/100 $ 8.46
HFBV6-38T 3/8” 50/100 8.25
HFBV6-50T 1/2” 50/100 11.49 HFBV6-50S $ 10.16
HFBV6-75T 3/4” 30/60 17.18 HFBV6-75S 16.12
HFBV6-100T 1” 20/40 27.18 HFBV6-100S 25.48
HFBV6-125T 1- 1/4” 12/24 41.23 HFBV6-125S 42.29
HFBV6-150T 1-1/2” 9/18 63.83 HFBF6-150S 60.64
HFBV6-200T 2” 6/12 92.56 HFBV6-200S 82.19
HFBV6-250T 2-1/2” 2/4 214.45
HFBV6-300T 3” 2/4 279.27
HFBV6-400T 4” 2 526.62
HFBV6 Series
MATERIAL SPECIFICATIONS
Handle nut Zinc Coated Steel
Handle Zinc Coated Steel
Gland Follower Forged Brass
Stem Packing Teflon®
Ball Chrome Plated Brass
Seats Teflon®
Body Forged Brass
End Adapter Forged Brass
DIMENSIONS (IN.) SIZE A (S/T) B (S/T) C D (S/T)
1/4” 1.79/1.76 1.73/1.73 3.54 .32/.39
3/8” 1.91/1.76 1.73/1.73 3.54 .39/.39
1/2” 2.05/2.05 1.84/1.92 3.54 .58/.58
3/4” 2.75/2.36 2.00/2.09 3.78 .75/.75
1” 3.23/2.76 2.44/2.56 4.53 .95/.95
1 1/4” 3.82/3.31 2.85/2.95 4.53 1.26/1.26
1 1/2” 4.43/3.66 3.17/3.35 5.51 1.58/1.58
2” 5.32/4.18 3.45/3.68 5.51 1.94/1.94
2 1/2” 6.28/5.36 4.76/4.76 8.66 2.52/2.52
3” 7.15/6.04 5.08/5.08 8.66 2.95/2.95
4” 9.28/7.39 5.87/5.87 9.61 3.90/3.90
Forged Brass Full Port Drainable Ball Valve Features:
• Heavy pattern forged brass construction.
• Full port allows maximum flow & minimum pressure drop or turbulence.
• Drain feature allows water line to be drained to prevent freeze-up.
• Teflon® seats, chrome plated brass ball.
• Teflon® stem packing with adjustable gland follower.
• Blow out proof stem design.
• 600 PSI W.O.G. non-shock.
• Imported, Manufactured for American Granby in an ISO 9001 facility.
Part Number Ctn/Case List Price Part Number List Price
Threaded Size Qty Threaded Sweat Sweat
- 1/2” 10/100 HDB50S $ 15.57
HDBV75T 3/4” 5/60 22.55 HDBV75S 22.55
HDBV100T 1” 6/36 31.43 HDBV100S 33.20
HDBV Series
MATERIAL SPECIFICATIONS and
DIMENSIONS
Same as HFBV6 Series above
Teflon® is a Dupont registered trademark
ISO 9001
ISO 9001
5/23/11
3.2
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Ball Valves - Brass
Forged Brass Conventional Port Ball Valve Features:
• Regular pattern forged brass constuction.
• Conventional port with excellant flow characteristics compared with other
valves in its class.
• Teflon® seats, chrome plated brass ball.
• Double o-ring stem seal.
• Blow-out proof stem design.
•400 PSI W.O.G non-shock, 125 PSI S.W.P.
• Imported. Manufactured for American Granby in an ISO 9001 facility.
Threaded Sweat Ctn/Case
Part Number Part Number Size Qty List Price
IBV50T IBV50S 1/2” 16/128 $ 8.64
IBV75T IBV75S 3/4” 10/100 14.60
IBV100T IBV100S 1” 12/48 23.61
IBV125T IBV125S 1-1/4” 8/32 36.39
IBV150T IBV150S 1-1/2” 6/24 53.71
IBV200T IBV200S 2” 4/16 81.79
IBV Series
MATERIAL SPECIFICATIONS
Handle Nut Zinc Coated Steel
Handle Zinc Coated Steel
Stem O-Rings NBR
Stem Forged Brass
Ball Chrome Plated Brass
Seats Teflon®
Body Forged Brass
End Adapter Forged Brass
DIMENSIONS (IN.) SIZE A (TxT) A (SxS) B C D
1/2” 1.83 1.97 1.54 .39 3.19
3/4” 2.09 2.44 2.09 .59 3.64
1” 2.40 2.95 2.20 .79 3.64
1 1/4” 2.76 3.35 2.36 .98 3.64
1 1/2” 3.27 4.00 2.64 1.26 4.41
2” 3.82 4.82 3.15 1.57 5.63
Teflon® is a Dupont registered trademark
ISO 9001
Forged Brass FULL Port Ball Valve with Hose Barbs
Features:
• Heavy pattern forged brass constuction.
• Full port allows maximum flow and minimum pressure
drop or turbulence.
• Teflon® seats, chrome plated brass ball.
• Teflon® stem packing with adjustable gland follower.
• Blow-out proof stem design.
•600 psi W.O.G. non-shock; 150 psi S.W.P.
• Insert hose barb ends for use with polyethylene pipe connections.
• Imported. Manufacturered for American Granby in an ISO 9001 facility.
Ctn/Case
Part Number Size Qty List Price
HFBV6-50I 1/2” 50/100 $ 15.61
HFBV6-75I 3/4” 30/60 24.11
HFBV6-100I 1” 20/40 29.82
HFBV6-125I 1-1/4” 12/24 54.47
HFBV6-I Series
MATERIAL SPECIFICATIONS
Handle nut Zinc Coated Steel
Handle Zinc Coated Steel
Gland Follower Forged Brass
Stem Packing Teflon®
Ball Chrome Plated Brass
Seats Teflon®
Body Forged Brass
End Adapter Forged Brass
Teflon® is a Dupont registered trademark
ISO 9001
6/14/11
3.3
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Ball Valves - Gas, Stainless
Stainless Steel Full Port Ball Valve Features:
• 316 Stainless steel ball valves
• Full Port, 1000 psi WOG
• Locking Handle (padlock not included)
• Investment castings.
• PTFE seal and packing.
• Blow-out proof stem.
• Mounting pad tapping.
• FPT x FPT
Part Number Description Size T x T Case Qty List Price
SSBV25TLH Stainless 1000# 1/4” 2/80 $ 28.98
SSBV38TLH Stainless 1000# 3/8” 2/80 26.39
SSBV50TLH Stainless 1000# 1/2” 2/80 29.36
SSBV75TLH Stainless 1000# 3/4” 2/60 40.33
SSBV100TLH Stainless 1000# 1” 2/40 59.14
SSBV125TLH Stainless 1000# 1 1/4” 2/30 90.40
SSBV150TLH Stainless 1000# 1 1/2” 2/16 133.89
SSBV200TLH Stainless 1000# 2” 2/10 199.85
SSBV250TLH Stainless 1000# 2 1/2” 2/4 372.17
SSBV300TLH Stainless 1000# 3” 2/4 604.77
SSBV Series
MATERIAL SPECIFICATIONS
Body Stainless Steel
Cap Stainless Steel
Ball Stainless Steel
Seats PTFE
Stem Stainless Steel
Handle Stainless Steel
Packing PTFE
Seal Gasket PTFE
Nut Stainless Steel
Handle Cover Plastic
Thrust Washer Stainless Steel
DIMENSIONS (IN.) SIZE D L H W
1/4” 0.394 2.126 1.732 3.701
3/8” 0.472 2.126 1.732 3.701
1/2” 0.591 2.441 2.087 4.134
3/4” 0.787 2.913 2.283 4.528
1” 0.984 3.268 2.480 4.843
1 1/4” 1.260 3.858 2.835 5.354
1 1/2” 1.496 4.173 3.307 6.614
2” 1.969 4.724 3.701 6.772
2 1/2” 2.559 6.299 4.803 9.134
3” 3.150 7.402 5.197 9.370
Forged Brass Gas Ball Valve Features:
• Heavy duty two piece forged brass body.
• For use with natural, manufactured, mixed, liquified petroleum
and LP gas/air mixtures.
• Meets ANSI standard Z21.15 for use as a gas appliance
connector valve (1/2 lb. system). CSA, US/AGA B-16.44
• UL Listed 757X for fire protection.
• Pressure rated at 175 psi W.O.G. non-shock.
• Imported, Mfg for American Granby in an ISO 9001 facility.
Lever Style Tee Style Size
Part Number Part Number t x t Ctn/Case Qty List Price
HGBVL50T HGBVT50T 1/2” 12/144 $ 10.99
HGBVL75T HGBVT75T 3/4” 12/96 16.59
HGBVL100T HGBVT100T 1” 6/96 30.46
HGBVL Series HGBVT Series
MATERIAL SPECIFICATIONS
Handle Screw Steel
Handle Aluminum
Stem O-Rings NBR
Stem Forged Brass
Ball Chrome Plated Brass
Seats Teflon®
Body Forged Brass
End Adapter Forged Brass
DIMENSIONS (IN.) BTU
SIZE A B C Capacity/Hr.
1/2” 2.21 1.46 1.81 295,000
3/4” 2.38 1.75 1.81 795,000
1” 2.91 1.89 1.81 1,200,000
ISO 9001
6/14/11
3.4
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Valves - Bronze Float
Bronze Float Valve Features:
• Cast bronze body
• Buna-N Disc
• Heavy Duty
• Tapped for 1/4-20SAE rod
• Threaded outlet
• Rated at 125 psi
BFV Series
Part Number Size Inlet Outlet Tapped Ctn Qty List Price
BFV1/2 1/2” 1/2” mpt 1/2” mpt 1/4”-20SAE 10/100 $ 29.70
BFV3/4 3/4” 3/4” mpt 3/4” mpt 1/4”-20SAE 10/80 35.83
BFV1 1” 1” mpt 1” mpt 1/4”-20SAE 10/40 47.34
Brass Rods Features:
• Brass SAE
• Male thread both ends
BFVR Series Part Number Length Thread Fits Valve Size Ctn Qty List Price
BFVR8 8” 1/4”-20SAE 1/2” - 1” 50/400 $ 6.62
BFVR10 10” 1/4”-20SAE 1/2” - 1” 50/300 7.67
BFVR12 12” 1/4”-20SAE 1/2” - 1” 50/300 8.59
Plastic Float Features:
• PVC
• Corrosion resistant
• Lightweight
• Up to 175°F
• For open tank service only
BFVFP Series Part Number Float Diam. Buoyancy Female Connection Ctn Qty List Price
BFVFP5 5” 2.17 lbs. 1/4”-20SAE 100 $ 21.23
BFVFP6 6” 3.8 lbs. 1/4”-20SAE 100 25.00
BFVFP8 8” 9.87 lbs. 1/4”-20SAE 20 31.08
5/3/11
3.5
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Valves - Brass Gate
GV200 Series Forged Brass Gate Valve Features:
• Constructed of heavy duty forged brass.
• Die-cast body, forged bonnet are connected with a teflon body to bonnet
gasket for a leak proof seat.
• Screwed bonnet, non-rising stem, solid wedge disc and integral seats.
• Teflon® stem seal packing. Teflon® is a registered trademark of Dupont.
• Cast iron hand wheel
• Rated at 200 PSI WOG; 125 PSI SWP (working pressure, non shock)
• Threaded ends produced to ANSI/ASME B1.20.1 (NPT) standards.
• Sweat ends produced to ANSI B16.18-1984 standards
• Imported
Threaded Sweat Ctn/Case
Part Number Part Number Size Qty List Price
GV200-50T 1/2” 10 / 100 $ 12.01
GV200-50S 1/2” 10 / 100 13.21
GV200-75T 3/4” 10 / 100 14.91
GV200-75S 3/4” 10 / 100 14.83
GV200-100T 1” 5 / 50 21.64
GV200-100S 1” 5 / 50 20.32
GV200-125T 1 1/4” 5 / 50 31.40
GV200-125S 1 1/4” 5 / 50 42.87
GV200-150T 1 1/2” 2 / 30 37.50
GV200-150S 1 1/2” 2 / 30 45.57
GV200-200T 2” 2 / 20 62.31
GV200-200S 2” 2 / 20 75.36
GV200-250T 2 1/2” 1 / 10 138.58
GV200-300T 3” 1 / 10 176.96
GV200-400T 4” 1 / 4 319.02
MATERIAL SPECIFICATIONS
Wheel Nut Brass
Hand Wheel Cast Iron
Gland Follower Nut Brass
Gland Follower Brass
Stem Seal Packing Teflon
Bonnet Brass
Body-Bonnet Gasket Teflon
Lock Nut Brass
Stem Brass
Disc Brass
Body Brass
DIMENSIONS (IN.) SIZE A (IPS) A (CxC) B (IPS) B (CxC) C
1/2” 1.68 1.76 2.77 2.79 2.15
3/4” 1.76 2.34 2.97 3.10 2.15
1” 2.03 2.69 3.44 3.63 2.34
1 1/4” 2.30 3.01 4.02 4.37 2.93
1 1/2” 2.46 3.36 4.45 4.96 2.93
2” 2.69 3.98 5.23 6.13 3.12
2 1/2” 3.43 6.36 3.90
3” 3.71 7.41 4.29
4” 4.45 9.17 5.07
GV200 Series
6/14/11
3.6
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Valves - Brass Swing Check
Brass Swing Check Valve Features:
• Constructed of heavy duty cast brass.
• Screwed cap, swing type disc and integral seat.
• Prevents backflow while offering full flow performance with a minimum
of turbulence or pressure loss.
• Rated 200 PSI W.O.G. (working pressure non-shock)
• Imported.
• Manufactured for American Granby in an ISO 9001 factory.
Threaded Sweat Ctn/Case
Part Number Part Number Size Qty List Price
HSCV50T 1/2” 10/120 $ 17.66
HSCV50S 1/2” 10/120 18.26
HSCV75T 3/4” 10/80 21.73
HSCV75S 3/4” 10/80 22.31
HSCV100T 1” 5/60 28.21
HSCV100S 1” 5/60 28.75
HSCV125T 1-1/4” 5/40 44.03
HSCV125S 1-1/4” 5/40 46.33
HSCV150T 1-1/2” 5/30 50.89
HSCV150S 1-1/2” 5/30 53.26
HSCV200T 2” 2/24 86.26
HSCV200S 2” 2/24 89.64
HSCV250T 2-1/2” 1/15 162.41
HSCV300T 3” 1/10 228.95
HSCV400T 4” 1/6 364.73
MATERIAL SPECIFICATIONS
Cap Brass
Body Brass
Disc Brass
Hinge Pin Brass
Screw Brass
DIMENSIONS (IN.) SIZE A (IPS) A (CxC) B (IPS) B (CxC)
1/2” 2.05 2.05 1.47 1.49
3/4” 2.32 2.32 1.58 1.58
1” 2.56 2.56 1.68 1.68
1 1/4” 3.12 3.12 1.84 1.84
1 1/2” 3.45 3.45 2.15 2.15
2” 4.16 4.16 2.69 2.69
2 1/2” 5.11 2.93
3” 5.74 3.78
4” 6.79 3.90
HSCV Series
ISO 9001
6/14/11
3.7
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Plumbing Valves - Low Pressure
Part Number Size Description Ctn/Case Qty List Price
Brass Boiler Drains
HBD50 ☺1/2” mip x ght 12/144 $ 8.66
HBD75 3/4” mip x ght 12/144 9.91
HBD50SB ☺1/2 w/ stuffing box mip x ght 12/144 9.89
HBD75SB 3/4” w/ stuffing boxmip x ght 12/144 11.01
Brass Full Flow Boiler Drains
IBD50SB ☺1/2” w/ stuffing box mip x ght 12/144 12.16
IBD75SB 3/4” w/ stuffing box mip x ght 12/144 12.46
NO LEAD Brass Full Flow Boiler Drains (CA AB1953 certified)
IBD50SBNL ☺1/2” w/ stuffing box mip x ght 12/144 12.53
IBD75SBNL 3/4” w/ stuffing box mip x ght 12/144 12.86
Brass No-Kink Boiler Drains
HNKD50 ☺1/2” mip x ght 12/144 8.76
HNKD75 3/4” mip x ght 12/144 9.66
Brass Hose Bibbs
HHB50 ☺1/2” mip x ght 12/144 9.76
HHB75 3/4” mip x ght 12/144 11.11
Brass Hose Bibbs - No Garden Hose Thread, Sampling Valve
HHB50NHT ☺1/2” mip x spout 12/144 9.45
HHB75NHT 3/4” mip x spout 12/144 10.57
1/4 turn Ball Valve Brass Hose Bibbs w/ T Handle - 200 psi WOG non-shock
IHBB50 ☺1/2” mip x ght (blue handle) 12/144 10.13
IHBB75 3/4” mip x ght (blue handle) 12/144 11.86
THBB50 1/2” mip x ght ITALY (red handle) 10/100 16.60
THBB75 3/4” mip x ght ITALY (red handle) 10/100 19.84
1/4 turn Ball Valve 304 Stainless Steel Hose Bibbs w/ T Handle -
200 psi WOG non-shock
IHBB50SS 1/2” mip x ght 12/144 22.32
IHBB75SS 3/4” mip x ght 12/144 22.79
1/4 turn Ball Valve Brass Hose Bibbs w/ T Handle - 200 psi WOG non-shock
No garden hose thread - Sampling valve
IHBB50NHT ☺1/2” mip x spout (blue handle) 12/144 10.59
IHBB75NHT 3/4” mip x spout (blue handle) 12/144 11.47
1/4 turn Ball Valve 304 Stainless Steel Hose Bibbs w/ T Handle -
200 psi WOG non-shock - No garden hose thread - Sampling valve
IHBB50SSNHT 1/2” mip x spout 12/144 22.32
IHBB75SSNHT 3/4” mip x spout 12/144 25.75
BOILER DRAINS • HOSE BIBBS
• 125 PSI WOG (working pressure - non-shock), 200 PSI WOG (1/4 turn ball valves hose bibbs)
• All valves shown below are CSA rated except THBB/IHBB Series
• Imported
HBD Series HBD-SB Series
IBD-SB Series
IBD-SBNL Series
HNKD Series
HHB Series
THBB Series
IHBB Series
HHBNHT Series
IHBBNHT Series
☺Has combination 1/2” mip and 1/2” solder connection
IHBBSS Series
IHBBSSNHT Series
6/14/11
3.8
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Plumbing Valves - Brass, Low Pressure
Part Number Size Description Ctn/Case Qty List Price
Full Flow Bent Nose Garden Valves
HBNG50 1/2” fip x ght 12/72 $ 14.93
HBNG75 3/4” fip x ght 12/72 14.93
HBNG100 1” fip x ght 12/72 17.64
Brass Angle Sill Cocks
HSC50T 1/2” fip x ght 12/144 10.23
HSC75T 3/4” fip x ght 12/144 11.86
HSC50C 1/2” swt x ght 12/144 9.71
HSC75C 3/4” swt x ght 12/144 10.56
Chrome Plated Brass Frost Proof Sill Cocks, IPS x Sweat Fitting
H504 1/2 x 4” 2/40 31.04
H506 1/2 x 6” 2/40 32.68
H508 1/2 x 8” 2/40 33.45
H510 1/2 x 10” 2/40 34.98
H512 1/2 x 12” 2/40 35.98
H514 1/2 x 14” 2/40 36.98
Chrome Plated Brass Frost Proof Sill Cocks w/ 3/4” mpt x 1/2” fip connection
H504-3/4 3/4 x 1/2 x 4” 2/40 31.75
H506-3/4 3/4 x 1/2 x 6” 2/40 33.12
H508-3/4 3/4 x 1/2 x 8” 2/40 34.48
H510-3/4 3/4 x 1/2 x 10” 2/40 35.84
H512-3/4 3/4 x 1/2 x 12” 2/40 36.72
H514-3/4 3/4 x 1/2 x 14” 2/40 38.56
Chrome Plated Brass Anti-Siphon Sill Cocks* w/ 1/2” mip x 1/2” swt connection
H504AS 1/2 x 4” 2/30 38.32
H506AS 1/2 x 6” 2/30 39.95
H508AS 1/2 x 8” 2/30 41.38
H510AS 1/2 x 10” 2/30 42.77
H512AS 1/2 x 12” 2/30 44.15
H514AS 1/2 x 14” 2/30 45.72
* with integral vacuum breaker
Vacuum Breaker
HVB75 3/4” Meets ASSE 1011 specifications 20/200 $ 7.54
BENT NOSE GARDEN • ANGLE SILL COCKS • FROST PROOF SILL COCKS
• 125 PSI WOG (working pressure - non-shock)
• Imported
HBNG Series
HSC Series
H500 Series
H500AS Series
HVB75
6/14/11
3.23
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Butterfly Valves - Cast Iron
Flanges & Bolt kits available,
see page 3.26
ISO 9002
HBFV Series
Part No. Size Weight(lbs) Ctn Qty List Price
Ductile Iron ENP Plated Disc*
HBFV2 2” 7 1 $ 107.09
HBFV21/2 2-1/2” 8 1 126.65
HBFV3 3” 10 1 162.95
HBFV4 4” 12 1 209.38
HBFV5 5” 15.5 1 229.78
HBFV6 6” 17.5 1 273.75
HBFV8 8” 33 1 461.73
HBFV10 10” 50 1 577.31
HBFV12 12” 74 1 917.27
Ductile Iron ENP Plated Disc - GEAR DRIVE *
HBFV6-GEAR 6” 28.5 1 351.89
HBFV8 GEAR 8” 54 1 573.50
Replacement Handles for HBFV Series
BFH2 2" 1 17.46
BFH3 3" 1 17.46
BFH4 4" 1 17.46
BFH5 5" 1 20.87
BFH6 6" 1 20.87
BFH8 8" 1 42.94
BFH10 10" 1 42.94
BFH12 12" 1 48.88
HFBV GEAR Series
Cast Iron Butterfly Valve Features:
• Designed for swimming pool, irrigation and water systems.
• Wafer body features 4 alignment holes.
• Lever lock handle (spring loaded) provides excellent manual control
for balancing or shut off services.
• Notched throttling plate allows balancing in 10º increments in any
position desired within 90º arc rotation of the disc.
• Positive bubble-tight shutoff with minimum torque.
• Seat face eliminates need for flange gaskets.
• Phenolic backed seats prevent collapse, are stretch resistant,
blowout proof and field replacable.
•EPDM seats temperature rated at -30°F to 275°F.
• 416 stainless steel shaft
• Bidirectional dead-end capability for 250 psi (2” - 12”).
• Compatible with ANSI 125/150 flanges.
• Valves meet AWWA C-504-87 section 5 proof of design tests.
• Designed to comply with MSS SP-67 and API 609.
•Ductile iron, ENP plated disc.
• Manufactured for AGI in an ISO 9002 facility.
• Imported
*
4/2009
3.24
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Butterfly Valves - Cast Iron
MATERIAL SPECIFICATIONS
No. Part Material
1 Body Cast Iron
2 Disc Ductile Iron
3 Seat EPDM
4 Shaft 416 Stainless Steel
5 Taper Pin 316 Stainless Steel
6 Key Carbon Steel
7 O-ring EPDM
8-10 Bushing PTFE
SIZE \ DIMENSION (in) for HBFV Series
A B C D E F G H J K L2 M2 N O
2” 6 3/8 3 1/4 1 3/4 1 1/4 1/2 3/8 2.76 .39 2 3/4 4 3/4 11/16 4 4 1.26
2 1/2” 6 7/8 3 3/4 1 7/8 1 1/4 1/2 3/8 2.76 .39 2 3/4 5 1/2 11/16 4 4 3/4 1.83
3” 7 1/8 4 1 7/8 1 1/4 1/2 3/8 2.76 .39 2 3/4 6 11/16 4 5 1/8 2.54
4” 7 7/8 4 7/8 2 1/8 1 1/4 5/8 3/8 2.76 .47 2 3/4 7 1/2 11/16 4 6 3/4 3.54
5” 8 3/8 5 3/8 2 1/4 13/16 3/4 3/8 2.76 .55 2 3/4 8 1/2 13/16 4 7 3/4 4.36
6” 8 7/8 5 7/8 2 1/4 1 1/4 3/4 3/8 2.76 .55 2 3/4 9 1/2 13/16 4 8 5/8 5.72
8” 10 1/4 7 1/8 2 1/2 1 3/4 7/8 7/16 4.02 .67 3 3/4 11 3/4 13/16 4 10 9/16 7.6
10” 11 1/2 8 1/4 2 3/4 1 3/4 1 1/8 7/16 4.02 .87 3 3/4 14.14 15/16 4 13 1/16 9.5
12” 13 1/4 9 3/4 3 1/8 1 3/4 1 1/4 7/16 4.02 .95 3 3/4 17 15/16 4 16 1/8 11.45
4/2009
4.45
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Ultraviolet Disinfection Systems
SAFE LITE Economy Series UV Disinfection System
Features:
• Quick installation.
• Economical.
• 304 stainless steel chamber. Electropolished.
• Powered by wall mounted ballast with lamp on indicator.
• 8 gallon complete with flow control.
Standard Series UV Disinfection System Features:
UV Series:
• Constructed for wall mounting.
• 304 stainless steel chamber. Electropolished.
• Sight port to safely view operation.
• 7 & 15 gallon complete with flow control.
• CSA approved.
UV-W Series:
• Same as UV series with:
• Internal wiper unit for manual cleaning of quartz sleeve.
• 8 & 15 gallon complete with flow control.
UV-SE Series:
• Same as UV series with:
• 7 & 15 gallon complete with flow control. Remote flow
control adder for 24 gallon (not included)
• Electronic built-in “lamp-out” circuit/alarm.
• ON/OFF indicator light.
• Standard auxillary output terminal for optional solenoid
shut-off (UVS077 not included).
• CSA pending
• Completely automatic.
• Compact and easy to install.
• No chemicals required.
• Low operating costs.
• Low maintenance.
• No taste or odor.
UVSL Series
UV, UV-SE &
UV-W Series
Ultraviolet disinfection is an effective way to pro-
vide bacteria free water for home or industry.
TM
6/14/11
4.46
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Ultraviolet Disinfection Systems
Part Max # of KW @ AMPS @ Pipe Dimensions Flow Lamp Out List
Number GPM Lamps 120V 120V 220V Size LxWxD Weight Control Alarm Price
Safe Lite Economy Series
UVSL8 8 1 0.07 .60 .30 3/4” MIP 18”x4”x7” 28 Yes No $ 858.70
Standard Series
UV7 7 1 0.07 .60 .30 3/4” MIP 18”x4”x7” 19 Yes No 1270.91
UV15 15 1 0.07 .60 .30 3/4” MIP 36”x4”x7” 28 Yes No 1600.46
Standard Series w/ Lamp out alarm
UV7SE 7 1 0.07 .60 .30 3/4” MIP 18”x4”x7” 19 Yes Yes 1289.28
UV15SE 15 1 0.07 .60 .30 3/4” MIP 36”x4”x7” 28 Yes Yes 1621.50
Lamp out circuit board provides a visual and audible alarm when a lamp outage occurs.
Solenoid protection can be added via the on-board relay and the purchase of an UVS077 Solenoid.
220V 50Hz less power cord net adder $ 35.72. Not available on SE series.
Non standard porting net adder $ 75.00
Standard Series w/ Internal wiper*
UV8W 8 1 0.07 .60 .30 3/4” MIP 18”x4”x7” 25 Yes No 1681.10
Water entering the disinfection
unit flows in the space between
the quartz sleeve and the cham-
ber wall. Turbulent flow through
the unit insures exposure of
micro-organisms to lethal
dosages of ultraviolet rays.
Water exiting the chamber is
safe and ready to use.
Typical Installation
* Check with AGI for delivery lead time on UV-W series
TM 6/14/11
4.47
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Ultraviolet Disinfection Parts
Part For Use
Number Description With Series List Price
Accessories
UVM254 UV Dosage meter w/ alarm UV, UV-W $ 1169.19
UVS079 Shut-0ff Solenoid 1” FNPT, use w/ UVM254, UV, UV-W, 232.97
or UVM257 Specify when ordering UV-SE, UVC
Maintenance & Repair Parts
UVP4025 Brass end nut assembly - complete (new) All models 68.89
UVP5175 Monitor lens kit 62.77
UVP8544 O-ring - Standard for end nut 3.21
UVP8222 Ballast - (120V, 60 Hz) 7-8 gpm units 81.58
UVP8224 Ballast - (120V, 60Hz) 12-45 gpm units 88.68
UVP8225 Ballast - (120V, 60Hz) 24-120 gpm units 121.93
Service Kits - Include bulb, quartz sleeve, o-rings and small tube of silicone.
Recommended 1 per year.
UVK07 Includes (1) UVB1805 bulb, UV7, UV7SE 146.49
(1) UVQS6211 sleeve, (2) UVP8544 o-rings
UVK015 Includes (1) UVB8246 bulb, All 15 models 195.48
(1) UVQS6608 sleeve, (2) UVP8544 o-rings
UVK024 Includes (2) UVB8246 bulb, All 24 models 396.89
(2) UVQS6608 sleeve, (4) UVP8544 o-rings
UVM254
UVS077
TM
6/14/11
4.48
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Ultraviolet Disinfection Parts
Part For Use
Number Bulb Length Description With Series List Price
UV Bulbs
UVB1805 14” 1 pin each end UV7, UV7SE $ 112.79
UVB1814 27.3” 1 pin each end 130.82
UVB8246 33.2” 1 pin each end All 15 UVC80 24 28 60 120 130.82
UVB11149 45.88” 1 pin each end 130.82
UVB11550 61.2” 1 pin each end UVC130 bulb 191.03
UVB2436 17” 2 pins each end 130.82
UVB2457 18” 2 pins each end DWSW-8 130.82
UVB2793 31.34” 2 pins each end 130.82
UVB4287 11.3” 4 pins one end 130.82
UVB4330 13” 4 pins one end 130.82
UVB4357 14.5” 4 pins one end 130.82
UVB4409 16” 4 pins one end 130.82
UVB4436 17” 4 pins one end 130.82
UVB4450 17.71” 4 pins one end DWS-8V, SE8V, 130.82
SL5, SL8, SL8V
UVB4739 29” 4 pins one end DWS-12V, SE12V 130.82
UVB4793 31.34” 4 pins one end 130.82
UVB4810 32” 4 pins one end 130.82
UVB4854 33.2” 4 pins one end 130.82
Bulb length is from end to end excluding pin connection.
Quartz Sleeves - Open Ends (22 mm ID, 24.5mm OD)
UVQS6211 14.37” Quartz Sleeve UV7, UV7SE 39.67
UVQS1483 19” Quartz Sleeve DWSW-8 49.90
UVQS6608 32.62” Quartz Sleeve All 12 15 24 48 60 80 120 83.42
UVQS1575 62” Quartz Sleeve UVC130 168.40
Quartz Sleeves - Domed Ends (22 mm ID, 24.5mm OD)
UVQS1435D 17” Dome End Quartz Sleeve 84.67
UVQS476D 19” Dome End Quartz Sleeve SL5, SL8, DWS-8V 83.42
UVQS335D 34” Dome End Quartz Sleeve 83.42
UVB Series - 4 pins one end
UVQS Series
UVQS-D Series
UVB Series - 2 pins each end
UVB Series - 1 pin each end
4/2009
6.1
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Compression Couplings-Imported, PVC/CPVC
MATERIAL SPECIFICATIONS
# Part Material
1 Body UPVC, CPVC
2 Compression Nut UPVC, CPVC
3 Gasket - PVC NR
Gasket - CPVC EPDM
Part Number Material Size Case Qty List Price
PC10-1/2 PVC 1/2” IPS 100 $ 2.33
PC10-3/4 PVC 3/4” IPS 90 2.70
PC10-1 PVC 1” IPS 60 3.49
PC10-11/4 PVC 1 1/4” IPS 40 4.20
PC10-11/2 PVC 1 1/2” IPS 30 5.79
PC10-2 PVC 2” IPS 20 8.06
PC10-21/2 PVC 2 1/2” IPS 10 18.42
PC10-3 PVC 3” IPS 4 26.06
PC10-4 PVC 4” IPS 2 34.39
PC10-6 PVC 6” IPS 2 82.73
HW10CTS1/2 CPVC 1/2” CTS 20/360 4.07
HW10CTS3/4 CPVC 3/4” CTS 20/240 4.93
PVC Compressing Coupling Features:
• Iron Pipe Size (PVC), Copper Tube Size (CPVC)
• For use with cold water (PVC) or hot water (CPVC-CTS)
• Natural rubber gasket seals
• Rated at 200 psi at 70°F
• Imported
"PC" Series IPS DIMENSIONS (IN.)
SIZE D d d1 L
1/2” 1.85 .91 .83 5.24
3/4” 2.09 1.18 1.04 5.32
1” 2.40 1.42 1.31 5.75
1 1/4” 2.87 1.81 1.65 6.30
1 1/2” 3.15 2.05 1.89 6.89
2” 3.62 2.56 2.37 7.87
2 1/2” 4.53 2.52 2.87 9.92
3” 5.28 3.62 3.49 10.87
4” 6.34 4.65 4.49 11.93
6” 8.78 6.85 6.62 11.22
"HW" Series CTS DIMENSIONS (IN.)
1/2” 1.30 .71 .63 4.49
3/4” 1.85 .95 .88 5.00
For Use with
Part Number Coupling Sizes Ctn Qty List Price
Adjustable Strap Wrench
SW400 1/2” through 4” 10/60 $ 17.68
SW600 1/2” through 6” 10/60 20.18
SW Series
6/14/11
6.2
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Compression Fittings, Galvanized
Recommended Maximum Pressure
(PSI)
Size Torque Anchored
Ft. Lbs Piping
1/2” 150 150
3/4” 150 150
1” 225 100
1-1/4” 225 100
1-1/2” 225 100
2” 300 75
Coupling GC10 - Made in U.S.A. - Steel Tube
Part Number Size Pipe O.D. Ctn Qty List Price
GC10-1/2 1/2” .840 12 $ 25.66
GC10-3/4 3/4” 1.050 12 27.98
GC10-1 1” 1.315 12 33.04
GC10-11/4 1-1/4” 1.660 6 44.12
GC10-11/2 1-1/2” 1.900 6 48.73
GC10-2 2” 2.375 6 61.24
Coupling GC10C - Long Pattern - Imported - Malleable Iron, 125 PSI, 120° F
Part Number Size Pipe O.D. Ctn/Case Qty List Price
GC10C1/2 1/2” .840 30 / 60 $ 10.20
GC10C3/4 3/4” 1.050 25 / 50 11.44
GC10C1 1” 1.315 15 / 30 13.42
GC10C11/4 1-1/4” 1.660 12 / 24 17.04
GC10C11/2 1-1/2” 1.900 9 / 18 20.19
GC10C2 2” 2.375 14 30.19
Adapters GC12 - Made in U.S.A. - Steel Tube
Part Number Size Pipe O.D. Ctn Qty List Price
GC12-1/2 1/2” .840 12 $ 37.50
GC12-3/4 3/4” 1.050 12 36.18
GC12-1 1” 1.315 12 38.31
GC12-11/4 1-1/4” 1.660 6 45.54
GC12-11/2 1-1/2” 1.900 6 63.32
GC12-2 2” 2.375 6 63.44
Galvanized Long Pattern Compressing Fitting Features:
• Bodies made of steel tubing. (GC 10), malleable iron (GC10C)
• End nuts made of malleable iron.
• Galvanized finish
• Buna-N gaskets on domestic fittings.
• SBR gaskets on GC10C series.
• Maximum rated service temperature for gaskets: 212°F (100º C).
WARNING: Designer and/or contractor must provide suitable anchoring
of piping to prevent pull-out from fittings when applications subject pip-
ing to external forces such as ground shift and temperature variations
that cause linear pipe contraction.
GC10C Series
GC10 Series
GC12 Series
ISO 9002
6/14/11
6.3
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Pipe Repair Clamps
Repair Clamp Features:
• Pipe repair clamps eliminate the need for costly pipe replacement for
simple leaks.
• Non-corrosive clamp band is made of annealed stainless steel.
• Nuts and bolts are cadmium plated with a chromate finish; heavy duty hex
nut with washer.
• Lugs are made of annealed, malleable iron for maximum strength and
permanence; iron phosphate finish.
• Neoprene gasket with maximum rated service temperature of 212° F
(100ºC).
• Imported
Nominal IPS CTS Ctn
Part Number Pipe Size Pipe O.D. Tube O.D. Qty List Price
3” Wide, 1 Bolt
HRC3-3/8 3/8” .675 .625 6/72 $ 5.94
HRC3-1/2 1/2” .840 .875 6/72 6.98
HRC3-3/4 3/4” 1.050 1.125 6/72 7.13
HRC3-1 1” 1.315 1.375 6/72 7.97
HRC3-11/4 1 1/4” 1.660 1.625 6/72 8.79
HRC3-11/2 1 1/2” 1.900 6/72 8.90
HRC3-2 2” 2.375 6/72 10.67
HRC3-21/2 2 1/2” 2.875 6/48 11.37
HRC3-3 3” 3.50 6/48 12.05
HRC3-4 4” 4.50 6/24 12.35
6” Wide, 2 Bolts
HRC6-1/2 1/2” .840 .875 6/56 12.54
HRC6-3/4 3/4” 1.050 1.125 6/56 13.44
HRC6-1 1” 1.315 1.375 6/56 13.60
HRC6-11/4 1 1/4” 1.660 1.625 6/56 15.06
HRC6-11/2 1 1/2” 1.900 6/56 16.49
HRC6-2 2” 2.375 6/56 19.77
HRC6-21/2 2 1/2” 2.875 6/24 21.28
HRC6-3 3” 3.50 6/24 22.44
HRC6-4 4” 4.50 6/24 22.92
Straight through bolt
pull on lugs gives
more uniform pres-
sure on the band,
more pressure on
pipe with less torque
on nut.
Oval lug opening in
band won’t tear - no
corners to rip out as
with square hole.
Lugs above pipe level
don’t pull into pipe.
Gives more tension
on band - more seal-
ing power yet won’t
crush pipe.
Band covers lead
edge of lug. Equal
pressure across
entire band. No fric-
tion - no cutting into
pipe surface by raw
edge of band open-
ing.
7/20/10
6.4
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Couplings, Caps - Flexible & No-Hub
Part Number Size Connection Ctn Qty List Price
NO HUB COUPLINGS
C150C 1 1/2 X 1 1/2 CI X CI 100 $ 9.37
C200C 2 X 2 CI X CI 100 9.37
C215C 2 X 1 1/2 CI X CI 100 10.92
C300C 3 X 3 CI X CI 100 10.92
C400C 4 X 4 CI X CI 100 13.22
FLEXIBLE COUPLINGS
MR0244 4 X 4 CLAY X CI/PL 18 14.44
MR5615/125 11/4 x 1 1/2 CI/PL x TUBE 24 7.60
MR56125 1 1/2” Tubing, Copper or 1 1/4” PL to Same 24 6.89
MR5615 1 1/2 x 1 1/2 CI/PL X CI/PL 24 7.31
MR5622/125 2 x 1 1/4 CI/PL x CI/PL 24 7.66
MR56215 2 X 1 1/2 CI/PL X CI/PL 24 8.33
MR5622 2 X 2 CI/PL X CI/PL 24 7.88
MR56315 3 x 1 1/2 CI/PL x CI/PL 24 13.93
MR5632 3 X 2 CI/PL X CI/PL 24 9.84
MR5633 3 X 3 CI/PL X CI/PL 18 10.64
MR5642 4 x 2 CI/PL x CI/PL 18 17.19
MR5643 4 X 3 CI/PL X CI/PL 18 14.35
MR5644 4 X 4 CI/PL X CI/PL 24 13.33
MR5655 5 X 5 CI/PL X CI/PL 14 20.88
MR5664 6 x 4 CI/PL x CI/PL 10 31.02
MR5666 6 X 6 CI/PL X CI/PL 12 28.51
DRAIN PIPING TO TUBULAR TRAP *
MRTC150 1 1/4” x 1 1/2” 24 4.19
MRDTC150 1 1/4” or 1 1/2” x 1 1/4” or 1 1/2” 24 5.13
MRDTC215 2” x 1 1/4” or 1 1/2” 24 6.77
* Any combination of 1 1/4” or 1 1/2” tubular drain (plastic, tubular or copper)
END CAPS
0701-011 1 1/2” 24 4.08
0702-019 2” 24 4.80
0703-017 3” 24 6.07
0704-015 4” 24 7.76
0705-020 5” 20 15.51
0706-028 6” 12 15.97
Coupling, Cap Features:
• Flexible couplings for joining all types of sewer pipe,
including transitions from one type to another.
• NO-HUB couplings for joining cast iron pipe sections
• End Caps for capping cast iron, steel, PVC and ABS pipe.
• 300 Series stainless steel clamps
• Meets IAPMO File #0317, BOCA ESI RR#90-68, SBCCI PST&ESI Report #9483B
• CSA Approved
MRTC Series
MR Series
C Series
07 Series
6/14/11
6.13
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Clear Braided PVC Hose
Part Nominal (inches) Max Working Pressure Reel Approx Wt List Price
Number ID OD PSI@68ºF PSI@122ºF Length per CFT. Per Reel
CBH316-1 3/16 0.375 250 105 100’ 4.5 lbs $ 117.06
CBH25-1 1/4 0.438 250 105 100’ 5.7 lbs 102.32
CBH516-1 5/16 0.525 250 105 100’ 7.5 lbs 150.56
CBH38-1 3/8 0.594 225 97 100’ 9.0 lbs 145.37
CBH50-1 1/2 0.750 200 86 100’ 13.8 lbs 195.91
CBH50-3 1/2 0.750 200 86 300’ 13.8 lbs 587.73
CBH58-1 5/8 0.875 200 86 100’ 16.5 lbs 231.09
CBH75-1 3/4 1.030 150 65 100’ 21.9 lbs 293.71
CBH75-3 3/4 1.030 150 65 300’ 21.9 lbs 881.15
CBH100-1 1 1.300 125 54 100’ 31.5 lbs 378.42
CBH100-2 1 1.300 125 54 200’ 31.5 lbs 707.34
CBH125-50 1 1/4 1.625 100 43 50’ 45.0 lbs 359.08
CBH125-1 1 1/4 1.625 100 43 100’ 45.0 lbs 718.17
CBH150-50 1 1/2 1.937 100 43 50’ 64.0 lbs 432.96
CBH150-1 1 1/2 1.937 100 43 100’ 64.0 lbs 865.91
CBH200-50 2 2.490 75 33 50’ 95.0 lbs 739.93
CBH200-1 2 2.490 75 33 100’ 95.0 lbs 1479.89
Clear Braided PVC Hose
Standard Wall, Class 125 Features:
• Flexible, see through clear hose with braid pattern
reinforcement of two polyester spirals.
• Flexible clear PVC NSF 51 certified to 100ºF (38ºC),
USP CLASS V1 rated.
• All hose compound ingredients used are listed in
US FDA CFR, Title 21.
• Temperature range + 25º to 150º F / -5º to +65ºC.
• Silicone free.
• Food and beverage grade, standard wall.
• Use for air, water lines.
** Temperatures higher than 68ºF reduce available working pressure. See next
page for temperature, working pressure calculation chart and cautionary note.
4/2009
6.14
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Clear Braided PVC Hose
Effects of Elevated Temperatures on Thermoplastic Hose.
The compounds used in clear braided PVC hose are generally referred to as thermoplastics. These materials
achieve their optimum physical properties at room temperature, 68ºF (20ºC). As these materials are exposed
to increased ambient temperatures, they will soften and their physical properties will change. This will have
the effect of sharply reducing the available working pressure. Coupling retention will also be reduced. The
charts below illustrate this effect. In all cases, the product should be tested in a controlled, secure and safe
environment, and all operating conditions should be considered prior to use.
All published working pressures of AGI Series CBH hose are based on a room temperature of 68ºF (20ºC).
CAUTIONARY NOTE
The charts are to used as a guideline only. The information and recommendations contained here are, to the
best of our manufacturer’s knowledge, accurate and reliable, but no guarantee of their accuracy is made. All
products are sold upon the condition that purchasers shall make their own tests to determine the suitability of
such products for their particular purposes and uses, and purchasers assume all risks and liability for the
results of use of the products, including use in accordance with seller’s recommendations. Variability in length
of exposure, temperature, pressure, velocity of fluid, and chemical concentration all contribute to reduced
working pressure and hose reliability.
Example from the Fahrenheit Chart
If working pressure at 68ºF is 200 psi,
then the WP at 110ºF is 200 x 50%, or
100 psi
Example from the Celsius Chart
If working pressure at 20º is 14 bar, then
the WP at 50ºC is 14 x 50%, or 5.6 bar
5/3/11
6.17
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Washer & Ice Maker Boxes
Washer Box Features:
• Center drain or dual drain.
• High impact polystyrene.
• 4 support brackets.
• Easy drain knockout.
• Top mount knockouts
• Box dimensions: 8 3/4” w x 7 1/2” h x 3 5/8” d
• Faceplate dimensions: 11 3/4” w x 10 1/8” h
Ice Maker Box Features:
• 2 support brackets.
• High impact polystyrene.
• Valves comply with requirements of NSF 61, Section 9.
• Available in several box and valve configurations.
• Provides quick, safe water supply and shutoff for refrigerator ice maker
and water dispenser.
• Box dimensions: 6” w x 6” h x 3 3/8”D.
• Faceplate dimensions: 8 1/4” w x 8 1/4” H
Part Valve
Number Connection Valve Type Drain Ctn Qty List Price
Standard Washer Boxes
38934 1/2” Sweat 1/4 turn brass ball valves Center 12 $ 61.12
38937 1/2” CPVC 1/4 turn brass ball valves Center 12 63.31
38945 1/2” PEX 1/4 turn brass ball valves Center 12 71.27
Dual Drain Washer Boxes
38673 1/2” Sweat 1/4 turn brass ball valves Dual 12 74.76
38670 1/2” CPVC 1/4 turn brass ball valves Dual 12 74.76
38660 1/2” Sweat Single Lever ball valves Dual 12 117.68
Ice Maker Boxes
38681 1/2” Sweat 1/4 turn brass ball valve 6 46.07
38680 1/2” CPVC 1/4 turn brass ball valve 6 46.05
38684 1/2” PEX 1/4 turn brass ball valve 6 46.53
38805 Box Only None 6 14.64
Washer Box
Ice Maker Box
6/14/11
6.18
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Closet Flanges & Gaskets
Level Fit Closet Flange Features:
• 3” or 4” all plastic flange solvent welds inside of 4”
or over 3” Sch 40 DWV pipe.
• Four mounting slots.
• Four countersunk holes for secure attachment to the floor.
Level Fit Closet Flange with metal ring Features:
• The metal ring provides added strength and cracking resistance to the flange and can
be rotated to allow precise alignment of bolts and screws.
• 3” or 4” flange solvent welds inside of 4” or over 3” Sch 40 DWV pipe.
Level Fit Offset Closet Flange with metal ring Features:
• The metal ring provides added strength and cracking resistance to the flange and can
be rotated to allow precise alignment of bolts and screws.
• 3” or 4” flange solvent welds inside of 4” or over 3” Sch 40 DWV pipe.
• 2” offset allows a margin of error for drain pipe/flange alignment.
Part
Number Material Description Size Ctn Qty List Price
Closet Flanges
43505 PVC Plastic ring closet flange w/ KO 3” x 4” 12 $ 7.23
43503 PVC Plastic ring closet flange 3” x 4” 12 6.38
43502 ABS Plastic ring closet flange 3” x 4” 12 6.82
Closet Flanges with Metal Adjustable Ring
43513 PVC Metal ring closet flange 3” x 4” 12 10.56
43512 ABS Metal ring closet flange 3” x 4” 12 12.84
Offset Closet Flanges
43501 PVC Offset closet flange 3” x 4” 12 19.18
43500 ABS Offset closet flange 3” x 4” 12 27.36
Part
Number Material Description Size Ctn Qty List Price
43543 PVC Urinal flange kit 2” 10 $ 38.13
Adjustable Urinal Flange Kit Features:
• Horizontal mounting slots accommodate urinals with 3 1/2” to 7” mount centers.
• Kit includes all bolts, nuts, washers and gaskets.
• Flanges solvent weld into any 2” fitting. They do not weld “over”.
43503
43513
43500
Wax Closet Gasket Features:
• Amber-color.
• Meets Federal specifications HH-C-536A.
Part Number Description & Material Size Ctn Qty List Price
AGWAX Standard wax gasket 3”, 4” 48 $ 2.50
AGWAXH Wax gasket w/Horn 3”, 4” 24 3.16
AGWAXJ Jumbo wax gasket 1 1/2” 3”, 4” 24 6.09
6/14/11
6.27
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Perforated Hanger Strapping
101 Series Galvanized Duct Tape
• 24 and 28 gauge
• Alternate 1/4” and 5/16” bolt and nail holes
• 3/4” width
102 Series Plastic Polypropylene Hanger Strapping
• 1/8” dia. holes
• Max working load - 15# @ 85° F
• Breaking Strength - 100# @ 68° F
100G Series Galvanized or Zinc Plated
• Perforated hanger strapping
• 20 to 28 gauge
• 1/4” bolt holes
• 3/4” width
Part Number Size Ctn Qty List Price
101 Series - Galvanized Duct Tape
101-10 3/4” x 10’ x 24 gauge 50 $ 2.57
101-50 3/4” x 50’ x 24 gauge 10 14.78
101-100 3/4” x 100’ x 24 gauge 5 28.60
101-10-28 3/4” x 10’ x 28 gauge 50 2.28
101-50-28 3/4” x 50’ x 28 gauge 10 13.56
101-100-28 3/4” x 100’ x 28 gauge 5 24.64
102 Series - Plastic Polypropylene
102-10 3/4” x 10' x .05 gauge BULK/100 2.42
102-25 3/4” x 25' x .05 gauge 1/40 4.71
102-50 3/4” x 50' x .05 gauge 1/20 12.59
102-100 3/4” x 100' x .05 gauge 1/10 22.50
100G Series - Galvanized or Zinc Plated
100G-10-24 3/4” x 10’ x 24 gauge 50 2.56
100G-50-24 3/4” x 50’ x 24 gauge 10 14.78
100G-100-24 3/4” x 100’ x 24 gauge 5 28.60
100G-10-28 3/4” x 10’ x 28 gauge 50 2.12
100G-10-22 3/4” x 10’ x 22 gauge 50 3.21
100G-50-22 3/4” x 50’ x 22 gauge 10 18.48
100G-100-22 3/4” x 100’ x 22 gauge 5 34.56
100G-10-20 3/4” x 10’ x 20 gauge 50 3.75
100G-50-20 3/4” x 50’ x 20 gauge 10 20.19
100G-100-20 3/4” x 100’ x 20 gauge 5 23.42
100S Series - Steel Plain
100S-10-24 3/4” x 10’ x 24 gauge 50 2.28
101 Series
100G and 100S Series
102 Series
5/3/11
6.28
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Clip & Van Hangers
604 Series Insulated Glide Clip Features:
• Specially compounded material wrapped around copper clad steel
permits smooth, silent pipe movement.
• Prevents electrolysis and corrosion.
• Resists temperature up to 280º F(137º C). Ideal for hot water heating or supply lines ––
eliminates creaking noises made by pipe expanding and contracting against wood
surfaces.
606 Series Van Hanger Features:
• Unique design for applications that require space between pipe and mounting surface.
• Copper clad steel, heavy duty metal construction.
608 Series Copper Tube Strap Features:
• Copper clad steel; heavy duty metal construction.
Part Number Size Mounting Hardware (incl) Ctn Qty List Price
Insulated Glide Clips
604-1/2 1/2” Copper Clad Nails 10 $ 3.44
604-3/4 3/4” Copper Clad Nails 10 3.70
604-1 1” Copper Clad Nails 10 4.64
604-11/4 1-1/4” Copper Clad Nails 10 5.23
Copper Clad Van Hangers
606-1/2 1/2” Copper Clad Screw 20 2.64
606-3/4 3/4” Copper Clad Screw 20 2.86
606-1 1” Copper Clad Screw 20 3.12
Copper Tube Straps
608-1/2 1/2” Copper Clad Nails 100 0.36
608-3/4 3/4” Copper Clad Nails 50 0.46
608-1 1” Copper Clad Nails 50 0.57
608-11/4 1-1/4” Copper Clad Nails 50 0.67
604 Series
606 Series
608 Series
6/14/11
6.29
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Pipe Straps & Clamps
500 Series Copper Clad Tube Straps
• 2 ear and one ear styles
510 Series Copper Clad Tube Straps
• One ear styles
511 Series Plastic Tube Tallon
• Made of polyethylene
• 1/2, 3/4 and 1” sizes available
513 Series Single Shot Hanger
• Plastic with nail
515 Series Suspension Clamp
• Made of polyethylene
Part Number Size Ctn Qty List Price
Copper Clad Tube Straps, TWO HOLE
500-1/2 1/2” 100 $ 0.13
500-3/4 3/4” 100 0.16
500-1 1” 100 0.19
500-11/4 1 1/4” 100 0.47
Copper Clad Tube Straps, ONE HOLE
510-1/4 1/4” 100 0.43
510-3/8 3/8” 100 0.43
510-1/2 1/2” 100 0.45
510-3/4 3/4” 100 0.49
510-1 1” 100 0.96
510-11/2 1 1/2” 50 2.27
510-2 2” 50 2.65
Tube Tallon Clamp
511-1/2 1/2” 100 0.23
511-3/4 3/4” 100 0.32
511-1 1” 50 0.86
Suspension Clamp
513-1/2 1/2” 50 0.65
513-3/4 3/4” 50 0.81
Suspension Clamp
515-1/2 1/2” 100 0.47
515-3/4 3/4” 100 0.50
515-1 1” 50 1.45
511 Series
500 Series
515 Series
510 Series
513 Series
6/14/11
6.30
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Pipe Straps
600 Series
Part Number Size Ctn Qty List Price
Galvanized Pipe Straps
600-1/4 1/4” 100 $ 0.18
600-3/8 3/8” 100 0.18
600-1/2 1/2” 100 0.15
600-3/4 3/4” 100 0.21
600-1 1” 100 0.34
600-11/4 1 1/4” 50 0.44
600-11/2 1 1/2” 50 0.51
600-2 2” 50 0.79
600-21/2 2 1/2” 25 1.28
600-3 3” 25 1.64
600-4 4” 25 2.73
Plastic Coated Pipe Straps
603-1 1” 50 4.02
603-11/4 1 1/4” 50 4.28
603-11/2 1 1/2” 50 4.68
603-2 2” 50 4.96
603-3 3” 25 8.57
603-4 4” 25 10.71
603-6 6” 10 28.39
One Hole Pipe Straps
610-1/4 1/4” Pipe 100 0.25
610-3/8 3/8” Pipe 100 0.32
610-1/2 1/2” Pipe 100 0.37
610-3/4 3/4” Pipe 100 0.61
610-1 1” Pipe 100 0.70
610-11/4 1 1/4” Pipe 100 1.13
610-11/2 1 1/2” Pipe 50 1.94
610-2 2” Pipe 50 2.27
One Hole EMT Straps
620-1/2 1/2” EMT 100 0.37
620-3/4 3/4” EMT 100 0.38
620-1 1” EMT 100 0.48
620-11/4 1 1/4” EMT 100 0.83
620-11/2 1 1/2” EMT 50 1.19
620-2 2” EMT 50 2.27
600 Series Galvanized Pipe Straps
• 2 ear
• 1/2 - 2” sizes available
603 Series Plastic Coated Pipe Straps
• 2 ear
• 1” - 2” sizes available
610 and 620 Series Galvanized Pipe Straps
• 1 ear
• 1” - 2” sizes available
603 Series
610/620 Series
6/14/11
6.31
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Tube & Pipe Hooks
200 S Series Bright Steel
200 C Series Copper Clad
200S and 200C
Series
Part Number Size (pipe x length) Ctn Qty List Price
Bright Steel
200S-1/2X4 1/2” X 4” 50 $ 0.51
200S-1/2X6 1/2” X 6” 50 0.57
200S-1/2X8 1/2” X 8” 50 0.68
200S-1/2X10 1/2” X 10” 50 1.26
200S-1/2x12 1/2” x 12” 50 1.41
200S-3/4X4 3/4” X 4” 50 0.51
200S-3/4X6 3/4” X 6” 50 0.57
200S-3/4X12 3/4” X 12” 50 1.41
200S-1X4 1” X 4” 50 0.51
200S-1X6 1” X 6” 50 0.57
200S-1X8 1” X 8” 50 0.68
200S-1X10 1” X 10” 50 1.26
200S-11/4X6 1 1/4” X 6” 50 0.92
200S-11/4X8 1 1/4” X 8” 50 1.11
200S-11/4X10 1 1/4” X 10” 50 1.26
200S-11/4X12 1 1/4” X 12” 50 1.41
200S-11/2X6 1 1/2” X 6” 50 0.92
200S-11/2X8 1 1/2” X 8” 50 1.11
200S-11/2X10 1 1/2” X 10” 50 1.26
200S-11/2X12 1 1/2” X 12” 50 1.41
200S-2X6 2” X 6” 50 0.92
200S-2X8 2” X 8” 50 1.11
200S-2X10 2” X 10” 50 1.26
200S-2X12 2” X 12” 50 1.41
Copper Clad
200C-1/2X4 1/2” X 4” 50 0.59
200C-1/2X6 1/2” X 6” 50 0.66
200C-1/2X8 1/2” X 8” 50 0.82
200C-1/2X10 1/2” X 10” 50 1.54
200C-1/2X12 1/2” X 12” 50 1.74
200C-3/4X4 3/4” X 4” 50 0.59
200C-3/4X6 3/4”X 6” 50 0.66
200C-3/4X8 3/4” X 8” 50 0.82
200C-3/4X10 3/4” X 10” 50 1.54
200C-3/4X12 3/4” X 12” 50 1.74
200C-1X4 1” X 4” 50 0.59
200C-1X6 1” X 6” 50 0.66
200C-1X8 1” X 8” 50 0.82
200C-1X10 1” X 10” 50 1.54
200C-1X12 1” X 12” 50 1.74
6/14/11
6.32
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Tube & Pipe Hooks
200 C Series Copper Clad
200 P Series Plastic Coated
Part Number Size (pipe x length) Ctn Qty List Price
200C-11/4X6 1 1/4” X 6” 50 $ 0.66
200C-11/4X8 1 1/4” X 8” 50 0.82
200C-11/4X10 1 1/4” X 10” 50 1.54
200C-11/4X12 1 1/4” X 12” 50 1.74
200C-11/2X6 1 1/2” X 6” 50 1.08
200C-11/2X8 1 1/2” X 8” 50 1.17
200C-11/2X10 1 1/2” X 10” 50 1.54
200C-11/2X12 1 1/2” X 12” 50 1.74
200C-2X6 2” X 6” 50 1.08
200C-2X8 2” X 8” 50 1.17
200C-2X10 2” X 10” 50 1.54
200C-2X12 2” X 12” 50 1.74
Plastic Coated
200P-1/2X4 1/2” X 4” 50 1.77
200P-1/2X6 1/2” X 6” 50 1.88
200P-1/2X8 1/2” X 8” 50 2.72
200P-1/2X10 1/2” X 10” 50 4.87
200P-1/2x12 1/2” x 12” 50 6.27
200P-3/4X4 1/2” Pipe* x 4" 50 1.77
200P-3/4X6 1/2” Pipe* x 6" 50 1.88
200P-3/4X8 1/2” Pipe* x 8" 50 2.72
200P-3/4X10 1/2” Pipe* x 10" 50 4.87
200P-3/4X12 1/2” Pipe* x 12" 50 6.27
200P-1x4 3/4” Pipe* x 4" 50 1.77
200P-1X6 3/4” Pipe* x 6" 50 1.88
200P-1X8 3/4” Pipe* x 8" 50 2.72
200P-1X10 3/4” Pipe* x 10" 50 4.87
200P-1X12 3/4” Pipe* x 12" 50 6.27
200P-11/4X6 1” Pipe * x 6" 50 3.44
200P-11/4X8 1” Pipe * x 8" 50 4.53
200P-11/4X10 1” Pipe * x 10" 50 4.87
200P-11/4X12 1” Pipe * x 12" 50 6.27
200P-11/2X6 1 1/4” Pipe * x 6" 50 3.44
200P-11/2X8 1 1/4” Pipe * x 8" 50 4.53
200P-11/2X10 1 1/4” Pipe * x 10" 50 4.87
200P-11/2X12 1 1/4” Pipe * x 12" 50 6.27
200P-2X6 1 1/2” Pipe * x 6" 50 3.44
200P-2X8 1 1/2” Pipe * x 8" 50 4.53
200P-2X10 1 1/2” Pipe * x 10" 50 4.87
200P-2X12 1 1/2” Pipe * x 12" 50 6.27
* For plastic coated steel pipe hooks, order tube hook of next larger size.
Ex: For 3/4” x 6” pipe use 1” x 6” hook.
200P Series
200S and 200C
Series
6/14/11
6.33
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Pipe Hangers
DWV Hanger - Galvanized
• Not plastic coated
Part Number Size Ctn Qty List Price
Light Clevis
104-1/2 1/2” 100 $ 1.68
104-3/4 3/4” 100 1.72
104-1 1” 100 1.77
104-11/4 1 1/4” 100 1.88
104-11/2 1 1/2” 100 2.04
104-2 2” 50 2.17
104-21/2 2 1/2” 25 3.80
104-3 3” 25 4.19
104-4 4” 25 5.68
Copperclad Clevis
406-1/2 1/2” 100 1.93
406-3/4 3/4” 100 1.98
406-1 1” 100 2.31
406-11/4 1 1/4” 100 2.47
406-11/2 1 1/2” 100 2.73
406-2 2” 50 3.27
Standard Clevis, Black
204-1/2 1/2” 100 1.93
204-3/4 3/4” 100 1.93
204-1 1” 100 2.04
204-11/4 1 1/4” 100 2.33
204-11/2 1 1/2” 100 2.52
204-2 2” 50 2.76
204-21/2 2 1/2” 25 5.41
204-3 3” 25 5.84
204-4 4” 25 7.23
204-5 5” 15 13.82
204-6 6” 10 15.27
204-8 8” 8 23.90
204-10 10” BULK 64.28
204-12 12” BULK 61.69
DWV Hanger - Galvanized
120-11/2 1 1/2” 50 2.35
120-2 2” 50 2.47
120-3 3” 50 2.57
120-4 4” 50 2.95
Clevis
DWV Hanger
6/14/11
6.34
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Pipe Hangers
Part Number Size Ctn Qty List Price
Adjustable Swivel Ring, Galvanized
300-1/2 1/2” 100 $ 1.55
300-3/4 3/4” 100 1.55
300-1 1” 100 1.64
300-11/4 1 1/4” 100 1.64
300-11/2 1 1/2” 100 1.93
300-2 2” 100 2.09
300-21/2 2 1/2” 50 3.75
300-3 3” 50 4.44
300-4 4” 25 5.68
300-5 5” 20 7.88
300-6 6” 20 8.62
300-8 8” 10 10.61
Adjustable Swivel Ring, Copperclad
301-1/2 1/2” 100 2.67
301-3/4 3/4” 100 2.72
301-1 1” 100 2.82
301-11/4 1 1/4” 100 2.87
301-11/2 1 1/2” 100 2.92
301-2 2” 100 3.20
Riser Clamp, Black
108-1 1” 25 5.68
108-11/4 1 1/4” 25 5.89
108-11/2 1 1/2” 25 6.65
108-2 2” 25 7.39
108-21/2 2 1/2” 25 8.15
108-3 3” 25 9.86
108-4 4” 25 12.59
108-5 5” 15 18.48
108-6 6” 10 19.45
108-8 8” BULK 50.36
108-10 10” BULK 62.95
All Thread Rod
900-1/4 1/4” 50 5.20
900-3/8 3/8” 25 9.80
900-1/2 1/2” 15 18.52
900-5/8 5/8” 9 31.12
900-3/4 3/4” 6 47.96
900-1 1” 3 90.87
Adjustable Swivel Ring
• Galvanized, or copperclad
• 1/2” to 4” - 3/8” rod
• 5” to 8” - 1/2” rod
900 All Thread Rod
• 6’ length, plain
300 Swivel Ring
900 Rod
108 Riser Clamp
6/14/11
6.35
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Split Ring Pipe Hangers
Split Ring Hangers - Malleable Iron
• Galvanized, black or copper clad
• 3/8” to 2” - 3/8” rod
• 2 1/2” to 4” - 1/2” rod
Split Ring Hangers
Part Number Size Rod Size Ctn Qty List Price
Split Ring Pipe Hanger, Black malleable
202-3/8 3/8” 3/8" 50 $ 3.02
202-1/2 1/2” 3/8" 50 3.02
202-3/4 3/4” 3/8" 50 3.14
202-1 1” 3/8" 50 3.49
202-11/4 1 1/4” 3/8" 25 4.31
202-11/2 1 1/2” 3/8" 25 5.34
202-2 2’ 3/8" 25 5.59
Split Ring Pipe Hanger, Galvanized malleable
385-3/8 3/8” 3/8" 50 3.37
385-1/2 1/2” 3/8" 50 3.37
385-3/4 3/4” 3/8" 50 3.60
385-1 1” 3/8" 50 4.13
385-11/4 1 1/4” 3/8" 25 4.94
385-11/2 1 1/2” 3/8" 25 6.92
385-2 2” 3/8" 25 6.39
385-21/2 2 1/2” 1/2" 25 14.53
385-3 3” 1/2" 25 17.44
385-4 4” 1/2" 25 23.25
Split Ring Pipe Hanger, Copper Clad, Malleable
485-3/8 3/8” 3/8" 50 2.68
485-1/2 1/2” 3/8" 50 2.68
485-3/4 3/4” 3/8" 50 2.73
485-1 1” 3/8" 50 3.08
485-11/4 1 1/4” 3/8" 25 3.66
485-11/2 1 1/2” 3/8" 25 3.78
485-2 2” 3/8" 25 4.47
485-21/2 2 1/2” 1/2" 25 14.53
485-3 3” 1/2" 25 17.44
485-4 4” 1/2" 25 23.25
6/14/11
6.36
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Plastic Pipe Hangers & Accessories
Part Number Size Ctn Qty List Price
DWV Hanger Plastic Coated
220-11/2 1 1/2” 50 $ 5.63
220-2 2” 50 5.89
220-3 3” 50 6.56
220-4 4” 50 7.37
220-6 6” 25 19.49
DWV Extension Bar
221-3 16 gauge x 3’ 25 2.59
Stop Keys
413-6 6’ 6 101.79
413-8 8’ 6 138.48
413-10 10’ 6 158.62
Ceiling Flanges
208-3/8BT 3/8” bolt thread, malleable iron 100 1.66
389-1/4PT 1/4” pipe thread, galvanized 100 1.74
389-3/8BT 3/8” bolt thread, galvanized 100 1.76
389-1/2BT 1/2” bolt thread, galvanized 100 4.56
489-3/8BT 3/8” bolt thread, copper clad 100 2.04
C Clamps For Pipe Sizes Fits Rods Size
122-1/4 1/4” without locknut 50 4.03
122-3/8 1/2" - 2" 3/8” without locknut 100 3.35
122-1/2 2 1/2" - 3 1/2" 1/2” without locknut 100 4.91
123-3/8 1/2" - 2" 3/8” with locknut 100 3.37
123-1/2 2 1/2" - 3 1/2" 1/2” with locknut 100 4.02
123-5/8 4" - 5" 5/8” with locknut 50 14.73
123-3/4 6" 3/4” with locknut 50 18.86
Top Beam Clamp , 3/4” Standard Opening
125-3/8 3/8” rod 100 2.79
125-1/2 1/2”rod 100 3.49
DWV Extension Bar
Stop Keys
Flanges
C Clamps
Top Beam Clamp
DWV Hanger
6/14/11
6.39
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Stud Protectors
918, 919, 916 and 913 FHA Plates
• 1 1/2” width and 3” width in 18 gauge
• 18, 16 and 13 gauge
530 Stud Guards
• Triangle points
• 1 1/2” width
• 18 gauge
531 Stud Guards
• Triangle points
• 1 1/2” width
• 20 gauge
920 Stud Guards
• Twist points
• 1 1/2” width
• 19 gauge
922 Stud Guards
• Interlocking
• 1 1/2” width
• 20 gauge
Part Number Size and Gauge Ctn Qty List Price
FHA Plates
918-11/2X9 1 1/2” X 9”, 18 gauge 50 $ 0.90
918-11/2X12 1 1/2” X 12”, 18 gauge 50 1.13
918-11/2X18 1 1/2” X 18”, 18 gauge 50 1.71
916-11/2X9 1 1/2” X 9”, 16 gauge 50 1.11
916-11/2X12 1 1/2” X 12”, 16 gauge 50 1.56
916-11/2X18 1 1/2” X 18”, 16 gauge 50 2.32
913-11/2X9 1 1/2” X 9”, 13 gauge 50 1.47
913-11/2X12 1 1/2” X 12”, 13 gauge 25 2.19
913-11/2X18 1 1/2” X 18”, 13 gauge 25 3.28
919-3X9 3” X 9”, 18 gauge 50 1.59
919-3X12 3” X 12”, 18 gauge 50 2.12
919-3X18 3” X 18”, 18 gauge 50 3.21
Stud Guards
530-11/2X3 1 1/2” X 3”, 18 gauge 100 0.28
530-11/2x5 1 1/2” x 5”, 18 gauge 100 0.42
530-11/2X6 1 1/2” X 6”, 18 gauge 100 0.46
531-11/2X3 1 1/2” X 3”, 20 gauge 100 0.23
531-11/2x5 1 1/2” x 5”, 20 gauge 100 0.37
531-11/2X6 1 1/2” X 6”, 20 gauge 100 0.39
920-11/2X3 1 1/2” x 3”, 19 gauge 100 0.24
920-11/2X6 1 1/2” X 6”, 19 gauge 100 0.41
922-11/2X3 1 1/2” x 3”, 20 gauge 100 0.21
922-11/2X6 1 1/2” X 6”, 20 gauge 100 0.42
918/916/913 FHA Plates
530 & 531 Stud Guards
920 Stud Guards
922 Stud Guards
4/2009
6.40
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
5/3/11
7.5
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Hand Cleaner Towels
SCRUBS® WATERLESS HAND CLEANING TOWELS
So unique they needed a patent! Powerful yet safe cleaning
agents work together with an absorbent, non scratching abra-
sive hand cleaning towel. The result is hands that are clean
and protected, with a pleasant fragrance...and are residue
free. These shop size, durable towels quickly remove tough to clean
substances including: Dirt, Heavy Grease, Adhesives, Lubricants, Oils,
Ink, Tar, Wax, Caulk, Sealants, Paint and more.
Part
Number Description Ctn Qty List Price
SCRB72 Scrubs 72 Count Bucket 6 $ 35.62
42293 Scrubs Attachable Bracket 1 24.23
Scrubs® is registered
by Dymon Inc.
Features:
• Pre-moistened, heavy duty towel with pumice scrubbing power.
• Works fast to loosen, dissolve and absorb dirt & grease.
• Deep cleaning scrubbers remove embedded grime easily.
• Conditions and softens hands... No rinsing. No drying. No residue.
PERMATEX FAST ORANGE® HAND CLEANER WIPES
Fast Orange Hand Cleaner Wipes remove the toughest grease,
tar, grime, ink, paints, sealants, adhesives and other difficult
soils. Each pre-moistened wipe has a textured surface on one
side that is ideal for cleaning heavy-duty soils from hands, tools
and work areas. The wipes also have a smooth side for general
purpose cleaning.
Suggested applications: Fields service trucks, industrial work stations, construc-
tion, utility maintenance, transportation, printing, municipal maintenance, marine
and warehouse personnel.
Part
Number Description Ctn Qty List Price
25072 72 count bucket 6 $ 47.31
4/30/11
7.6
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
3M™Spray Adhesive
ISO 9002
3M™ BLUE 72 Spray Adhesives
• Pressure sensitive repositionable adhesive
• Aggressive tack and low soak-in.
• Use it for temporarily positioning and holding many fabrics.
• Precise spray control with a wide spray pattern.
• Ideal for pool liner installation
• Manufactured for AGI in an ISO 900 facility.
Part Ctn/Pallet
Number Can Size Qty List Price
BLUE 72 Blue Spray Adhesive 24 fl oz. can 12/768 $ 35.70
17.33 oz. net
ORANGE74 Orange spray adhesive 24 fl oz. can 12/768 43.33
17.33 oz. net
3M™ ORANGE FOAM FAST 74 Spray Adhesives
• 74 Foam Fast Adhesive gives fast tack with foam-tearing strength and a soft, non-
dimpling glue line.
• Bonds foam to foam, foam to metal.
• Non-misting, precise spray pattern.
• Not for sale in California. Does not meet Aerosol Consumer Products VOC limits.
• Manufactured for AGI in an ISO 900 facility.
Product Bond Bonding Spray Spray Color Temperature Coverage
Type Time Width Pattern Resistance
72 Temp or One side-8 hrs 3-3.5 in Controlled Blue 120°F 100 sq ft.
Permanent Two sides-7 days Lace 48°C 9.3 m2
74 Permanent One side -not recommended 1-3 in Lace Light Orange 120°F 260 sq ft.
Two sides-15 minutes variable 48°C 25 m2
Pallet pricing available. Call your Sales Representative.
4/30/11
7.7
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Concrete Repair
DP600
Part Number Description Ctn Qty List Price
DP600 Concrete Repair, 8.4 fl oz cartridge 6 $ 111.72
supplied with 2 nozzles
Horizontal Concrete Repair Features:
Hardens in as little at 5 minutes,
Cracks and spalls in concrete floors are an eyesore as well as a potential
safety risk. Fixing them has meant either hiring and waiting for an outside
contractor or doing it youself with a repair method that takes the floor out of
service for up to 24 hours. Now with 3M Concrete Repair, you save money
and time.
• Self-leveling urethane flows
smoothly into cleaned cracks and
gaps and hardens in as little as 5
minutes. A fork lift can pass over a
repair in as few as 15 minutes.
• Hardens to any depth without
cracking or shrinking.
• Flexible urethane expands and
contracts for durability that outlasts
repairs made with concrete.
• Do it yourself with a common
caulking gun and eliminate the cost
and wait for an outside contractor.
• Easy to use - Just clean damaged
area and fill. With every squeeze of
the caulking gun trigger, cartridge
nozzle meters and mixes precise
proportions for optimum
performance.
Part Number Size Color Ctn Qty List Price
CG9 9” Ratchet Blue 20 4.39
9” Ratchet Style Caulking Gun
4/2009
7.8
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Concrete Repair
Horizontal Concrete Repair Specifications:
• Gray, self-leveling urethane concrete repair.
• 8.4 fl oz. cartridge of concrete repair and 2 nozzles.
• Work life of 70 sec.
• Handling time of 5 minutes
• Cure time of 60 minutes
Applications:
• Repairing cracks and spalls on concrete floors or horizontal surfaces.
• Setting anchors in concrete floors or horizontal surfaces.
• Light-duty custom threading and anchoring.
• Use outdoors or in highly ventilated area.
Clean
Remove all loose
material from area
to be filled.
Concrete should be
dry and grease-free.
Fill
Dispense product
into deepest part of
repair areas, slightly
overfilling. Product
self-levels and is
tack-free in as little
as one minute.
Finish
In as little as 15 min-
utes, product can be
sanded to remove
rough edges. It can
be painted within
one hour.
Bead Size Linear Feet per
dimension 8.4 fl oz.
1/16” 815.0
1/8” 205.0
1/4” 51.9
3/8” 22.2
1/2” 12.4
Approximate coverage:
Crack Crack Lineat Feet per
Width Depth 8.4 fl. oz.
1/4” 1/4” 19.3
1/2” 1/4” 9.9
3/4” 1/4” 6.4
1” 1/4” 4.9
1/4” 1/2” 9.9
1/2” 1/2” 4.9
3/4” 1/2” 3.0
1” 1/2” 2.0
Quick and Easy Spall Repair
Tapes - Teflon® Thread Seal
5/3/11
7.1
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Imported Teflon® Thread Seal Tape Features:
• Medium density thread seal tape requires fewer wraps.
• Manufactured from 100% virgin PTFE.
• 3.5 mil thick.
• Mil. Spec. T-27730A.
• Meets ASTM D-3308.
Part Number Width Length Color Ctn/Case Qty List Price
HTST260-1/2 1/2” 260 inches White 144/576 $ 0.86
HTST260-3/4 3/4” 260 inches White 144/576 1.25
HTST260-1 1” 260 inches White 144/576 1.44
HTST520-1/2 1/2” 520 inches White 144/576 1.29
HTST520-3/4 3/4” 520 inches White 144/576 1.53
HTST520-1 1” 520 inches White 144/576 1.72
• Telfon® is a Dupont registered trademark
HTST Series
Part Number Width Length Color Case Qty List Price
HTT260 1/2” 260 in White 144 $ 1.80
HTT520 1/2” 520 in White 144 2.68
HTT520-3/4 3/4” 520 in White 144 4.22
HTT520-1 1” 520 in White 144 5.45
HTT260-1/2OXY 1/2” 260 in Green 144 4.50
HTT260-1/2PP 1/2” 260 in Pink 144 4.50
HTT260-1/2XHD 1/2” 260 in White 144 3.86
HTT260-1/2SS 1/2” 260 in Light Gray 144 4.50
HTT260-1/2GAS 1/2” 260 in Yellow 144 3.86
Made in USA Teflon® Thread Seal Tape Features:
• UL Listed.
• 100% virgin PTFE.
HTT260/HTT520 Medium Density Teflon® Tape
• White general purpose
• Medium density.
HTT260-1/2SS Gray Stainless Steel Teflon® Tape
• Nickel pigment added for use on all stainless steel threads.
• Prevents galling, seizing and corrosion.
• High density for course SS threads.
HTT260-1/2PP Pink Plumbers Teflon® Tape
• For plumbers and pipe fitters.
• Pink to signify heavier than standard or medium density.
HTT260-1/2GAS Yellow Gas Service Teflon® Tape
• For gas lines of all types- Natural gas, butane, propane.
HTT260-1/2OXY Green Oxygen Teflon® Tape
• Green for oxygen applications. Grease free.
• For all oxygen lines. Will not support combustion.
HTT260-1/2XHD White Extra High Density Teflon® Tape
• For all industrial applications.
• Can be used for water, oil, chemical, medical or food processing.
HTT Series
• Telfon® is a Dupont
registered trademark
Part Number Color Usage Thickness Density Temp Range Specs
HTT260 White General 3.5 mil .90 -450°F to +550°F Mil T-27730A
HTT520 White General 3.5 mil .90 -450°F to +550°F Mil T-27730A
HTT260-1/2OXY Green Oxygen lines 3.5 mil 1.55 -450°F to +550°F Mil T-27730A/AA58092
HTT260-1/2PP Pink Plumbing 3.5 mil 1.55 -450°F to +550°F Mil T-27730A/AA
HTT260-1/2XHD White Industrial 3.5 mil 1.20 -450°F to +550°F Mil T-27730A
HTT260-1/2SS Light Gray Stainless Steel 3.5 mil 1.55 -450°F to +550°F Mil T-27730A/AA58092
HTT260-1/2GAS Yellow Gas lines 3.5 mil 1.20 -450°F to +550°F Mil T-27730A
Tapes - Electrical, Vinyl
6/14/11
7.2
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Part Number Thickness WidthxLength Color Ctn Qty List Price
AWT60 7 mil 3/4” x 60 feet Black 64 $ 2.22
AWT60-2 7 mil 2” x 60 feet Black 48 5.64
Part Number Thickness WidthxLength Color Ctn Qty List Price
T60 7 mil 3/4” x 60 feet Black 64 $ 1.97
Premium All Weather Vinyl Electrical and Pipe Wrap Tape Features:
• For use in all weather applications.
• Use for insulation, protective jacketing and harnessing and pipe wrap.
• 7 mil thickness, 3/4” or 2” width.
• Temperature range 14°F and 176°F.
• Meets Mil. Spec. MIL-1-7798A.
• Tested to ASTM D-1000
• Imported
General Purpose Vinyl Electrical Tape Features:
• Economical, flexible, general purpose electrical tape.
• Use for insulation, protective jacketing and harnessing.
• 7 mil thickness.
• Temperature Range 32ºF and 176ºF.
• Meets mil spec. MIL-I-7798A.
• Imported
T Series
AWT Series
Part Number Thickness WidthxLength Color Ctn Qty List Price
TS33-20 7 mil 3/4” x 20 feet Black 10/100 $ 6.18
TS33-44 7 mil 3/4” x 44 feet Black 10/100 11.20
TS33-66 7 mil 3/4” x 66 feet Black 10/100 14.18
TS88-66 8.5 mil 3/4” x 66 feet Black 10/100 17.71
3M® Scotch® Professional Use Premium Vinyl Plastic Tape Features:
• Highly comformable, super stretchy in all weather applications.
• Resists UV rays, abrasion, corrosion, alkalies and acids.
• Flame Retardent.
• 7 mil tape thickness Super 33+. 8.5 mil thickness Super 88
• Temperature range 0°F to 220°F.
• Use as a primary insulation for wire cable splices up to 600V.
• Use as protective jacketing.
• Made in USA. Made for AGI in a ISO 900X facility.
TS Series
• Scotch® is a 3M regis-
tered trademark
ISO 900 X
Super 33+
ASTM D-3005 Type I
UL273 & CSA LR48769
Super 88
MIL-I-24391C
ASTM D-3005 Type I
UL 539H & CSA LR48769
Part Number Thickness WidthxLength Color Ctn Qty List Price
1700 7 mil 3/4” x 60 feet Black 100 $ 3.08
3M® 1700 Temflex™ Vinyl Electrical Tape Features:
• Economical, flexible, general purpose electrical tape.
• Use for protective jacketing and harnessing.
• 7 mil thickness.
• Temperature rating to 176°F, 80°C.
• Meets ASTM D-2301 Type 1.
• Imported
1700
LISTED
539H
Insulating Tape
LR48769
6/14/11
7.9
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Boss®136 Firestop/Draft Sealant
BOSS® 136 Firestop/Draft Sealant is a single component fire
rated sealant and is a noncombustible filler caulking used for
firestopping applications in the annular space around wires,
pipes, ducts, vents, cable lines and other penetrations to the
building envelope. It is a non-slumping sealant that sets to form
a hard surface. BOSS® 136 can be applied to any gap or penetration where the specification
is noncombustible and/or ASTM-E136 rated. BOSS® 136 is to be used for interior applications
only.
The noncombustible specification is common to one and two family construction and to non-
rated penetrations in multifamily and commercial construction. BOSS® 136 is colored red for
ease of inspection.
In the event of a fire BOSS® 136 will prevent the spread of fire, smoke and toxic gases
through penetration openings.
BOSS® 136 serves to form a “gasket or seal against air infiltration” as required by the
Model Energy Code in both performance and prescriptive versions.
FEATURES:
• Completely non-toxic and contains no asbestos or PCB’s.
• Noncombustible.
• Applied with a conventional caulking gun.
• Easily applied sealant with water cleanup capabilities.
• An accredited fire block/smoke seal caulk.
• Single component system, no mixing necessary and no additions
required.
• Meets residential construction code approvals including I.R.C.
• For interior applications only.
• Available in traditional cartridge and NEW aerosol can.
• Excellent adhesion to a wide variety of substrate material.
APPLICABLE STANDARDS
• UBC Page 1-378, 1997 edition.
• CABO Section 602.7, Item 4 of the 1995 edition.
• BOCA (NBC) regulation 704.4.1.1 1996.
• ASTM E-136.
Part
Number Description Ctn Qty List Price
BOSS136 10.1 oz cartridge 12 $ 11.28
REQUIRED AREAS OF USAGE FOR
FIRESTOPPING*
Seal ALL areas of penetration as shown
in the illustration below.
• ALL - Exterior wall studs
(including horizontal penetrations.)
• ALL - Floor penetrations.
• ALL - Ceiling penetrations.
• ALL - Framing around chimneys
(at ceiling and floor levels.)
* Always consult local buliding codes.
4/2009
7.10
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Boss®136 Firestop/Draft Sealant
HOW TO USE
• Cut nozzle to desired bead size. Insert cartridge into
standard caulking gun.
• For a smooth seal, hold at 45°angle and apply by push-
ing sealant ahead of nozzle.
• Apply at 40°F or above.
• To ensure good adhesion, all surfaces should be clean
and free of dust, oil, loose materials or any other sub-
stances.
• Make sure that BOSS® 136 makes complete contact
with the entire surface of the opening and also the sur-
face of the penetrating item.
Always follow cartridge directions. Clean the area to be treat-
ed so that it is free of all particles and debris. For large
openings, mineral wool fibers can be used as a backer to
help hold the product in place until cured. Steel screen wire
can be stapled in place over the material when a large open-
ing is overhead or configured such that the material will not
support it’s own weight during cure.
TEMPERATURE RANGE
BOSS® 136 freezes in the cartridge at temperatures below
32° F. The product can be warmed and applied at any tem-
perature but will not cure below 40° F. Freeze thaw cycles do
not alter the cured product. Cure time may exceed 72 hours
at non-freezing temperature.
CAUTION
• Keep from freezing
• Do not take internally
• Keep out of reach of children.
CONTAINS
• Sodium Silicate CAS# 1344-09-8.
COLOR
Boss® 136 Fire/Smoke and Draft Sealant is red in color
for ease of inspection.
PACKAGING
Boss® 136 Firestop/Draft Sealant is available in standard
10.1 fl. oz cartridges and 11.0 oz. net wt. aerosol cans.
STORAGE & SHELF LIFE
Boss® 136 should not be stored where the ambient tem-
peratures exceed 120°F or below 35°F. Should freezing
occur, insure that product is defrosted fully prior to use. Shelf
life is 12 months from the date of shipment. Ensure stock is
SPECIFICATIONS
Meets or exceeds ASTM E-136 for noncom-
bustible building materials. Conforms to BOCA
National Building Code (1996), CABO one and
two family dwelling code (1995), Uniform
Building Code (1997), Section 796, Fire Block
and Draft Stop. BOCA-SBCCI-ICBO-NFPA Building
Codes. Consult you local code official for the
proper use of product.
NONCOMBUSTIBLE BUILDING
MATERIALS IN ACCORDANCE WITH
ASTM E-136
<9NA6>
ALSO CLASSIFIED IN ACCORDANCE WITH ASTM E
136-96a, “Standard test method for the behavior of
materials in a vertical tube furnace at 750°C.”
CLASSIFIED
6/14/11
7.11
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
BOSS®Expanding Foam Sealant
BOSS® 333 Expanding Foam Sealant Features:
• Easy to use, multi-purpose urethane foam.
• Unlike ordinary sealants, it expands three times it’s original volume.
• Adheres to all building materials except Teflon®, silicone and polyethelene.
• Seals by expanding into gaps, cracks and crevices.
• Uses including insulating, sealing and filling gaps around pipes, plumbing
fixtures,ductwork and foundations.
• UL classified.
Part Number Description Ctn Qty List Price
33316B * Expanding Foam Sealant, 12 oz can w/ application tip 12 $ 14.55
33324B * Expanding Foam Sealant, 24 oz can w/ application tip 12 28.47
* SHIPPING NOTE: Ground shipping only. Can NOT be shipped via air.
R19028
CAULKING AND SEALANTS
SURFACE BURNING CHARACTERISTICS
APPLIED TO INORGANIC REINFORCED
CEMENT BOARD*
FLAME SPREAD: 5 SMOKE DEVELOPED: 20
38FN
* Tested as applied in three 3/4” beads 5” on center covering
12.5% of the exposed test sample area.
DIRECTIONS FOR USE:
1. Shake can before and during use.
2. Surface must be clean and free of grease and oil.
3. Can must be held UPSIDE DOWN during application.
4. Insert straw into void and depress the trigger. The use of protec-
tive gloves is highly recommended.
5. Fill void 50% full to allow for expansion.
6. Uncured foam can be cleaned with acetone or paint thinner.
7. Cured foam can be trimmed, sanded, painted r stained. Foam
MUST be painted or coverred if application is exposed to UV light.
6/14/11
7.12
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
BOSS®Adhesives, Lubricants & Sealants
BOSS® line of adhesives, grouts and lubricants
are specifically formulated for use with pools and
whirlpool baths.
BOSS® 801 Neutral Cure Silicone Adhesive Features:
• A one part, low odor, non-corrosive, oxime cure adhesive and sealant.
• Provides excellant adhesion to ceramic tile, spa jets, skimmers, lighting fixtures,
plumbing and fiber optic lighting.
• Adheres well to fiberglass, ABS, acrylic, PVC, wood and masonry.
BOSS® 802 Acetoxy Cure Silicone General Purpose Adhesive Features:
• A one part, acetoxy cure, adhesive/sealant.
• Performs well in jet sealing applications.
• Designed for many other pool and spa maintenance and repair needs.
BOSS® 803 Neutral Cure Silicone Adhesive/Grout Features:
• A one part, low odor, non-corrosive, oxime cure silicone grout.
• Formulated for use in repairing tile installations.
• Adheres well to fiberglass, ABS, acrylic, PVC, wood and masonry.
BOSS® 804 Neutral Cure Silicone Ceramic Tile Grout Features:
• A one part, low odor, non-corrosive, oxime cure silicone grout.
• Spreads easily and provides ample tooling time.
• Excellent ahdesion to all ceramic tiles
BOSS® 820 Pool & Spa Silicone Lubricant Features:
• Water washout resistant and non-solidifying compound.
• Provides superb lubricant for rubber o-rings.
• Non-corrosive, silicone lubricant compound.
Part Number Description Ctn Qty List Price
80100B Silicone Adhesive Clear, 10.3 oz cart 12 $ 15.31
80101B Silicone Adhesive White, 10.3 oz cart 12 15.31
80200B Silicone Adhesive Gen Purpose, Clear 10.3 oz. cart 12 9.37
80201B Silicone Adhesive Gen Purpose, White 10.3 oz cart 12 9.37
80331B Silicone Adhesive Grout, Clear 3 oz. tube 12 7.65
80401B Silicone Ceramic Tile Grout, White 10.3 oz cart 12 15.31
82001B Pool & Spa Lubricant Clear, 1 oz tube bulk 288 5.18
82002B Pool & Spa Lubricant Clear, 1 oz tube 36 pc tub 36 249.90
82030B Pool & Spa Lubricant Clear, 3 oz tube 12 7.88
82000B Pool & Spa Lubricant Clear, 5.3 oz tube 12 13.21
2/15/11
7.13
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Dow Corning®General Purpose Silicone Sealant
Dow Corning ® General Purpose Silicone Sealant Features:
• Cures to 100% silicone rubber.
• One part, ready to use. Fast cure, high strength.
• Resistant to sunlight & weather extremes.
• Remains flexible; will not become brittle, crack or tear.
• Removable, reusable, resealable nozzle.
• Meets the requirements of FDA Regulation No. 21CFR177.2600.
Dow Corning General Purpose Silicone Sealant is a one-part acetoxy cure silicone sealant for
general purpose applications. Provides a flexible bond and will not harden or crack. Trademate
General Purpose Silicone Sealant is a high performance sealant, with +/- 25% movement capa-
bility when properly applied.
It can be used as a bedding material, formed-in-place gaskets and bumpers. Adhere trim,
name plates, signs. Seal around sinks, faucets, showers, tubs, toilets and vents. It can be used
for most marine applications. Seal between hull and deck, most boat decks, windows, port
lights, windshields and hatches.
Part Number Size Color Ctn Qty List Price
PLB90C 10.3 oz. cartridge Clear 12 $ 9.90
PLB90W 10.3 oz. cartridge White 12 9.90
CG9 9” Ratchet Blue 20 4.39
PLB 90 Series
Product Properties:
Tooling Time * . . . . . . . . . . . . . . . . . . . . . . . . . .5-10 minutes
Tack Free Time * . . . . . . . . . . . . . . . . . . . . . . . .15-20 minutes
Complete Set-up time * . . . . . . . . . . . . . . . . . . .24 hours (1/8”)
Cure System . . . . . . . . . . . . . . . . . . . . . . . . . . . .Acetoxy
Application Temperture Range . . . . . . . . . . . . .-20°F to 122°F
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .-29°C to 50°C
As Cured (after 7 days)
Durometer hardness Shore A . . . . . . . . .27 points
Tensile Strength . . . . . . . . . . . . . . . . . . . .350 psi
Elongation . . . . . . . . . . . . . . . . . . . . . . . . .600 %
Temperture Range - continuous . . . . . . .-40°F to 350°F
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .-40°C to 176°C
Movement capability . . . . . . . . . . . . . . . . . . . . .+/- 25%
* At 77°F (25°C) and 50% relative humidity
Approval/Specifications:
• ASTM C920 Type S, Grade NS, Class 25, Use NT, G and A.
• Federal Specification TT-S-001543A, Type non-sag, Class A,
• Federal Specificaiton TT-S-00230C, Type II, Class A
9” Ratchet Style Caulking Gun
Storage:
• Store below 90° F (32°C) in a dry place.
• To store short term, replace cap.
• To store long term, unscrew nozzle, screw cap in
cartridge and store nozzle in cap.
Limitations:
• Not for structural glazing
• Not paintable
• Not suited for prolonged submersion in water or below-
grade applications.
• May not adhere to oily woods or be compatible with sub-
strates made of methylmethacrylate, polycarbonate,
polypropylene, polyethylene and polytetrafluroethylene.
• Not suitable for surfaces that might bleed oils, plasticiz-
ers or solvents or porous surfaces such as cement-like
materials, stone or surfaces prone to attack by weak
acids.
• May not cure properly if used in spaces confined from
atmospheric moisture.
• May cause corrosion on some brass, copper, zinc or
zinc-alloy containing fixtures (galvanized).
• This product is neither tested nor represented as suit-
able for medical or pharmaceutical uses.
• Not for use where abrasion and physical abuse are
encountered.
6/14/11
7.14
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Dow Corning®Tub, Tile & Ceramic Silicone Sealant
Dow Corning® Tub, Tile & Ceramic Silicone Sealant
Features:
• Cures to 100% silicone rubber.
• One part, ready to use. Fast cure, high strength.
• Cured silicone is mildew resistant
• Remains flexible; will not become brittle, crack or tear.
• Removable, reusable, resealable nozzle.
• Clear & almond colors meet the requirements of FDA Regulation No. 21CFR177.2600.
Dow Corning Tub, Tile & Ceramic Silicone Sealant is a one-part acetoxy cure silicone sealant
for non-porous surface applications requiring a mildew-resistant sealant. This versatile mate-
rial can be used as an adhesive, selant, or grout for repairing or replacing ceramic tiles as well
as in many other plumbing applications. It can be used for tub and shower enclosures.
It can be used to form watertight seals around bathtubs, shower enclosures, sink vanities,
countertops, lavatories, faucets, saunas, hot tubs, plumbing fixtures, drains, piping, shower
doors and floor seams.
PLB 100 Series
Product Properties:
Tooling Time * . . . . . . . . . . . . . . . . . . . . . . . . . .5-10 minutes
Tack Free Time * . . . . . . . . . . . . . . . . . . . . . . . .15-20 minutes
Complete Set-up time * . . . . . . . . . . . . . . . . . . .24 hours (1/8”)
Cure System . . . . . . . . . . . . . . . . . . . . . . . . . . . .Acetoxy
Application Temperture Range . . . . . . . . . . . . .-20°F to 122°F
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .-29°C to 50°C
As Cured (after 7 days)
Durometer hardness Shore A . . . . . . . . .27 points
Tensile Strength . . . . . . . . . . . . . . . . . . . .325 psi
Elongation . . . . . . . . . . . . . . . . . . . . . . . . .600 %
Temperture Range - continuous . . . . . . .-40°F to 350°F
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .-40°C to 176°C
Movement capability . . . . . . . . . . . . . . . . . . . . .+/- 25%
* At 77°F (25°C) and 50% relative humidity
Approval/Specifications:
• ASTM C920 Type S, Grade NS, Class 25, Use NT, G and A.
• Federal Specification TT-S-001543A, Type non-sag, Class A,
• Federal Specificaiton TT-S-00230C, Type II, Class A
Part Number Size Color Ctn Qty List Price
PLB103C 3 oz tube Clear 12 $ 7.17
PLB103W 3 oz tube White 12 7.17
PLB100C 10.3 oz cartridge Clear 12 11.00
PLB100W 10.3 oz cartridge White 12 11.00
CG9 9” Ratchet Blue 20 4.39
9” Ratchet Style Caulking Gun
Storage:
• Store below 90° F (32°C) in a dry place.
• To store short term, replace cap.
• To store long term, unscrew nozzle, screw cap in cartridge
and store nozzle in cap.
Limitations:
• Not for structural glazing
• Not paintable
• Not suited for prolonged submersion in water or below-
grade applications. Not for aquarium use as product con-
tains a fungicide.
• May not adhere to oily woods or be compatible with sub-
strates made of methylmethacrylate, polycarbonate,
polypropylene, polyethylene and polytetrafluroethylene.
• Not suitable for surfaces that might bleed oils, plasticizers
or solvents or porous surfaces such as cement-like materi-
als, stone or surfaces prone to attack by weak acids.
• May not cure properly if used in spaces confined from
atmospheric moisture.
• May cause corrosion on some brass, copper, zinc or zinc-
alloy, containing fixtures (galvanized).
• This product is neither tested nor represented as suitable
for medical or pharmaceutical uses.
• Not for use where abrasion and physical abuse are
encountered.
6/14/11
7.17
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
PVC Solvent Cements
PVC REGULAR CLEAR CEMENTS LO-VOC
Part List
Number Size Case Qty Price
2266S 4 oz. 24 $ 7.59
2256S 8 oz. 24 11.48
2246S 16 oz. 24 19.30
2236S 32 oz. 12 33.23
2224 1 gallon 6 118.41
• Regular bodied, clear cement for use
on PVC pipe and fittings. Up to 4” for
DWV Sch 40 and up to 2” for Sch 80.
• Recommended for ALL grades and
types of PVC pipe and fittings, potable
water and DWV.
• Sets up quickly.
• Recommended application temperature
40°F to 110°F.
• Meets ASTM D-2564.
• Meets California Air Quality
Management District and other environ-
mental disctict rules.
2200 Series
CLEAR
2800 Series
CLEAR
• Regular bodied, clear cement for use
on PVC pipe and fittings. Up to 4” for
DWV Sch 40 and up to 2” for Sch 80.
• Recommended for ALL grades and
types of PVC pipe and fittings, potable
water, pressure pipe, gas, conduit and
DWV.
• Sets up quickly.
• Recommended application tempera-
ture 40°F to 100°F.
• Meets ASTM D-2564.
• Meets California Air Quality
Management District and other envi-
ronmental disctict rules.
Part List
Number Size Case Qty Price
2866S 4 oz. 24 $ 6.54
2856S 8 oz. 24 10.98
2846S 16 oz. 24 19.15
2836S 32 oz. 12 33.80
2824 1 gallon 6 118.86
PVC REGULAR CLEAR ADVANCED CEMENTS LO-VOC
PVC MEDIUM CLEAR CEMENTS LO-VOC
Part List
Number Size Case Qty Price
1266S 4 oz. 24 $ 7.97
1256S 8 oz. 24 12.37
1246S 16 oz. 24 21.62
1236S 32 oz. 12 30.13
1224 1 gallon 6 128.18
1200 Series
CLEAR
• Medium bodied, clear cement for use
on PVC pipe and fittings. Up to 6” for
Sch 40 and Sch 80.
• Recommended for ALL grades and
types of PVC pipe and fittings, drain,
waste and vent pipe, and potable
water
• Recommended application tempera-
ture 40°F to 110°F.
• Meets ASTM D-2564.
• Meets California Air Quality
Management District and other envi-
ronmental disctict rules.
6/14/11
7.18
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
PVC Solvent Cements
PVC MEDIUM GRAY CEMENTS LO-VOC
Part List
Number Size Case Qty Price
1666S 4 oz. 24 $ 8.13
1656S 8 oz. 24 12.46
1646S 16 oz. 24 20.34
1636S 32 oz. 12 36.45
1624 1 gallon 6 131.11
1600 Series
GRAY
• Medium bodied, gray colored cement
for use on PVC pipe and fittings. Up to
6” for Sch 40 and Sch 80.
• Recommended for ALL grades and
types of PVC pipe and fittings, potable
water and DWV.
• Recommended application tempera-
ture 40°F to 110°F.
• Meets ASTM D-2564.
• Meets California Air
Quality Management District and other
environmental disctict rules.
PVC MEDIUM “HOT” BLUE CEMENTS LO-VOC PLUMB-TITE™
Part List
Number Size Case Qty Price
2066S 4 oz. 24 $ 8.89
2056S 8 oz. 24 13.88
2046S 16 oz. 24 24.53
2036S 32 oz. 12 13.88
2024 1 gallon 6 170.33
2000 Series
BLUE
• Medium bodied, blue colored cement
for PVC pipe and fittings. Up to 6” for
Sch 40 and Sch 80.
• Very fast setting cement formulated
for wet conditions and/or quick pres-
surization and fast installation.
• Recommended for ALL grades and
types of PVC pipe and fittings, potable
water, pressure pipe and DWV.
• Blue color fades to clear in direct sun-
light.
• No primer needed on non-pressure
DWV, where local codes permit.
• Recommended application tempera-
ture 40°F to 110°F.
• Meets ASTM D-2564.
• Meets California Air
Quality Management District and other
environmental disctict rules.
6/14/11
7.19
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
PVC Solvent Cements
PVC ALL WEATHER CEMENTS LO-VOC POLAR-WELD
Part List
Number Size Case Qty Price
2666S 4 oz. 24 $ 10.66
2656S 8 oz. 24 12.81
2646S 16 oz. 24 29.80
2636S 32 oz. 12 48.67
2624 1 gallon 6 174.97
2600 Series
CLEAR
• Medium bodied, clear cement for PVC
pipe and fittings. Up to 6” for Sch 40
and Sch 80.
• Recommended for ALL grades and
types of PVC pipe and fittings, potable
water, pressure pipe and DWV.
• Non-pressure DWV, up through 4”
diameter: No primer needed, where
local codes permit.
• Formulated for fast initial set-up at
temperatures down to -5°F to 110°F.
• Meets ASTM D-2564.
• Meets California Air
Quality Management District and other
environmental disctict rules.
PVC MEDIUM RAIN-R-SHINE® BLUE CEMENTS LO-VOC
Part List
Number Size Case Qty Price
30890 4 oz. 24 $ 7.77
30891 8 oz. 24 12.56
30893 16 oz. 24 18.03
30894 32 oz. 12 36.37
30895 1 gallon 6 120.19
308 Series
BLUE
• Medium bodied, blue colored cement
for PVC pipe and fittings. Up to 6” for
Sch 40 and Sch 80.
• Very fast setting cement formulated
for wet conditions and/or quick pres-
surization and fast installation.
• Recommended for ALL grades and
types of PVC pipe and fittings, potable
water and DWV.
• Pool/Irrigation installations.
• No primer needed on non-pressure
DWV, where local codes permit.
• Recommended application tempera-
ture 40°F to 110°F.
• Meets ASTM D-2564.
• Meets California Air
Quality Management District and other
environmental disctict rules.
6/14/11
7.20
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
PVC Solvent Cements
PVC MEDIUM “HOT” BLUE CEMENTS LO-VOC TURF-TITE
Part List
Number Size Case Qty Price
2466S 4 oz. 24 $ 8.61
2456S 8 oz. 24 13.82
2446S 16 oz. 24 24.07
2436S 32 oz. 12 42.28
2424 1 gallon 6 158.20
2400 Series BLUE
• Medium bodied, blue colored cement
for PVC pipe and fitting. Up to 6” for
Sch 40 and Sch 80.
• Very fast setting cement formulated
for wet conditions and/or quick pres-
surization and fast installation.
• Recommended for ALL grades and
types of PVC pipe and fittings, potable
water, pressure pipe and DWV.
• Irrigation installations.
• Fades to clear in sunlight.
• No primer needed on non-pressure
DWV, where local codes permit.
• Recommended application tempera-
ture 40°F to 110°F.
• Meets ASTM D-2564.
• Meets California Air Quality
Management District and other envi-
ronmental disctict rules.
PVC MEDIUM “HOT” BLUE CEMENTS LO-VOC POOL-TITE
Part List
Number Size Case Qty Price
2366S 4 oz. 24 $ 8.33
2356S 8 oz. 24 12.93
2346S 16 oz. 24 19.89
2336S 32 oz. 12 35.53
2324 1 gallon 6 111.77
2300 Series
BLUE
• Medium bodied, blue colored cement
for PVC pipe and fittings. Up to 6” for
Sch 40 and Sch 80.
• Very fast setting cement formulated for
wet conditions.
• Recommended for ALL grades and
types of PVC pipe and fittings, potable
water, pressure pipe, gas, conduit, PVC
flex pipe and DWV.
• Color fades to clear in sunlight.
• No primer needed on non-pressure
DWV, where local codes permit.
• Recommended application tempera-
ture 40°F to 100°F.
• Works on flex to rigid pipe applications.
• Meets ASTM D-2564.
• Meets California Air Quality
Management District and other envi-
ronmental disctict rules.
6/14/11
7.21
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
PVC, CPVC Solvent Cements
PVC MEDIUM CLEAR FAST SET CEMENTS LO-VOC POOL-CLEAR
Part List
Number Size Case Qty Price
30875 4 oz. 24 $ 7.82
2946S 16 oz. 24 28.53
2936S 32 oz. 12 47.79
2924 1 gallon 6 145.65
2900 Series
CLEAR
• Medium bodied, clear cement for PVC
pipe and fitting. Up to 6”
• Recommended for Sch 40 and Sch 80
pipe and fittings.
• Also recommended for PVC flex pipe.
• Meets ASTM D-2564.
• Meets California Air
Quality Management
District and other environmental disc-
tict rules.
CPVC MEDIUM ORANGE CEMENTS LO-VOC
Part List
Number Size Case Qty Price
3266S 4 oz. 24 $ 9.76
3256S 8 oz. 24 15.09
3246S 16 oz. 24 29.43
3236S 32 oz. 12 39.82
3200 Series
ORANGE
• Medium bodied, orange colored
cement for use on CPVC pipe and fit-
tings. Up to 6”.
• For copper tube size (CTS) and Sch
80, potable water pressure pipe.
• Recommended application tempera-
tures down to 40°F to 110°F.
• Meets ASTM F-493.
• Meets California Air
Quality Management District and other
environmental disctict rules.
CPVC FLOWGUARD® GOLD™ LO-VOC 1-STEP YELLOW CEMENTS
Part List
Number Size Case Qty Price
31910 4 oz. 24 $ 10.56
31911 8 oz. 24 16.88
31912 16 oz. 24 30.44
319 Series
• Exceeds new environmental require-
ments and meets various CA district
rules.
• For copper tube size (CTS) CPVC hot
and cold potable water pipe and fit-
tings up to 2” interference fit only.
• May be used without primer where
local codes permit.
• For cold water systems and hot water
systems up to 180°F.
• Faster cure time/reduced installation
time.
• Meets ASTM F-493.
• Meets California Air Quality
Management District and other envi-
ronmental disctict rules.
6/14/11
7.22
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
PVC and Multipurpose Solvent Cements
PVC HEAVY DUTY CLEAR CEMENTS LO-VOC
Part List
Number Size Case Qty Price
1566S 4 oz. 24 $ 6.39
1556S 8 oz. 24 10.04
1546S 16 oz. 24 21.97
1536S 32 oz. 12 35.87
1524 1 gallon 6 111.13
1500 Series
CLEAR
• Heavy bodied, clear cement for PVC
pipe and fittings. Up to 18” for Sch 40
and Sch 80.
• Recommended for ALL grades and
types of PVC pipe and fittings, potable
water and DWV.
• Thick formula fills gaps in large diame-
ter pipe and loose fitting joints.
• Recommended application tempera-
ture 40°F to 110°F.
• Meets ASTM D-2564.
• Meets California Air Quality
Management District and other envi-
ronmental disctict rules.
PVC HEAVY DUTY GRAY CEMENTS LO-VOC
Part List
Number Size Case Qty Price
1756S 8 oz. 24 $ 14.03
1746S 16 oz. 24 25.68
1736S 32 oz. 12 45.12
1724 1 gallon 6 160.50
1700 Series
GRAY
• Heavy bodied, gray colored cement
for use on PVC pipe and fittings. Up to
18” for Sch 40 and Sch 80.
• Recommended for ALL grades and
types of PVC pipe and fittings, potable
water and DWV.
• Thick formula fills gaps in large diame-
ter pipe and fitting.
• Recommended application tempera-
ture 40°F to 110°F.
• Meets ASTM D-2564.
• Meets California Air
Quality Management District and other
environmental disctict rules.
MULTI PURPOSE REGULAR CLEAR CEMENTS LO-VOC
Part List
Number Size Case Qty Price
6266S 4 oz. 24 $ 8.80
6256S 8 oz. 24 14.04
6246S 16 oz. 24 19.24
6236S 32 oz. 12 33.26
30848 1 gallon 6 122.63
• Regular bodied, clear cement for ABS,
PVC or CPVC up to 4”.
• Recommended for pipe and fittings Sch
40 and Sch 80, potable water, pressure
pipe and DWV.
• Recommended application temperature
40°F to 110°F.
• Meets performance requirements of
ASTM D-2564, D-2235, F-493.
• Meets California Air Quality
Management District and other environ-
mental disctict rules.
6200 Series
CLEAR
6/14/11
7.23
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
ABS Solvent Cements
ABS MEDIUM BLACK CEMENTS LO-VOC
Part List
Number Size Case Qty Price
4466S 4 oz. 24 $ 8.40
4456S 8 oz. 24 11.84
4446S 16 oz. 24 12.12
4436S 32 oz. 12 35.76
4424 1 gallon 6 102.52
4400 Series BLACK
• Medium bodied, black cement for
ABS pipe and fittings. Up to 6”.
• For ALL types and grades or ABS pipe
and fittings for DWV.
• For all non-pressure applications.
• Recommended application tempera-
tures 40°F to 110°F.
• Meets ASTM D-2235.
• Meets California Air
Quality Management District and other
environmental disctict rules.
ABS TO PVC TRANSITION GREEN CEMENTS LO-VOC
Part List
Number Size Case Qty Price
30900 4 oz. 24 $ 8.73
30925 16 oz. 24 22.40
30926 32 oz. 12 39.70
• Medium bodied, green colored cement
for use in joining ABS to PVC in non-
pressure transition joints.
• All schedules up to 6” pipe fittings.
• Recommended application temperature
40°F to 110°F.
• Meets ASTM D-3138.
• Meets California Air Quality
Management District and other environ-
mental disctict rules.
309 Series
GREEN
6/14/11
7.24
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Primers
CLEAR PRIMER - NSF LISTED LO-VOC
Part List
Number Size Case Qty Price
9366S 4 oz. 24 $ 7.94
9356S 8 oz. 24 11.07
9346S 16 oz. 24 22.75
9336S 32 oz. 12 32.37
9324 1 gallon 6 116.96
9300 Series
CLEAR
• A clear aggresive primer for use on
PVC and CPVC pipe and fittings.
• All schedules and diameters.
• Removes all surface dirt, grease and
grime as well as softens pipe to allow
a fast, secure solvent weld.
• Meets ASTM F-656.
• Meets California Air Quality
Management District and other envi-
ronmental disctict rules.
PURPLE PRIMER - NSF LISTED LO-VOC
Part List
Number Size Case Qty Price
8766S 4 oz. 24 $ 9.01
8756S 8 oz. 24 12.45
8746S 16 oz. 24 21.93
8736S 32 oz. 12 29.73
8724 1 gallon 6 116.46
8700 Series
PURPLE
• A purple tinted aggresive primer for
use on PVC and CPVC pipe and fit-
tings.
• Exceeds new environmental require-
ments and meets various CA district
rules.
• For use in areas where plumbing code
calls for verification that a primer has
been used.
• Removes all surface dirt, grease and
grime as well as softens pipe to allow
a fast, secure solvent
weld.
BLUE PRIMER - NSF LISTED LO-VOC PRIME-TITE™
Part List
Number Size Case Qty Price
8056S 8 oz. 24 $ 14.17
8046S 16 oz. 24 24.21
8036S 32 oz. 12 43.38
8000 Series
BLUE
• A blue-tinted aggresive primer for use
on PVC and CPVC pipe and fittings.
• Blue color fades to clear in direct sun-
light.
• Formulated to work with “TITE” prod-
ucts.
• Meets ASTM F-656.
• Meets California Air
Quality Management District and other
environmental disctict rules.
6/14/11
7.25
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Primers and Cleaners
PURPLE PRIMER/CLEANER LO-VOC
Part List
Number Size Case Qty Price
8866S 4 oz. 24 $ 7.79
8856S 8 oz. 24 11.63
8846S 16 oz. 24 22.75
8836S 32 oz. 12 31.70
8824S 1 gallon 6 108.44
8800 Series
PURPLE
• Purple tinted all purpose
primer/cleaner for PVC and CPVC pipe
and fittings.
• Removes surface dirt, grease and
grime as well as softens pipe to allow
a fast, secure solvent weld.
• Less aggressive than clear primer and
purple primer.
• Purple tint for verification for code.
• Exceeds new environmental require-
ments and meets various CA district
rules.
CLEANER LO-VOC
Part List
Number Size Case Qty Price
7366S 4 oz. 24 $ 6.80
7356S 8 oz. 24 8.99
7346S 16 oz. 24 15.97
7336S 32 oz. 12 21.26
7324 1 gallon 6 89.78
7300 Series
CLEAR
• Clear cleaner for ABS, PVC and CPVC
pipe and fittings.
• All schedules and diameters.
• Exceeds new environmental require-
ments and meets various CA district
rules.
• Fast-acting cleaner removes surface
dirt, grease and grime.
•Flows freely and evaporates quickly.
DAUBERS and EMPTY CANS
Part List
Number Size Case Qty Price
DAUBERS
31312 Fits 32 oz quart can 48 $ 3.52
31310 Fits 16 oz pint can 48 2.94
31309 Fits 8 oz 1/2 pint can 24 3.32
EMPTY CANS
30901 Gallon 2 7/8” mouth 6 27.73
• Replacement product daubers.
• Reusable cone top metal con-
tainers.
4/2009
7.26
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM 6/14/11
8.5
Super Lube®is a patented, multi-purpose synthetic lubricant,
containing SYNCOLON® (PTFE) particles held in suspension.
Super Lube lasts longer and outperforms convential petrole-
um-based greases and oils. Packaging includes tubes,
grease cartridges, aerosols, bottles, pails and drums.
How does the chemistry of SuperLube differ from conventional petroleum-based
greases and mineral oils? Super Lube grease and oils are exceptionally pure lubri-
cants because they are synthetic. This gives SuperLube very stable and predictable
chemical properties. Petroleum-based machine and gear oils are made from refined
crude oil and contain impurities which cannot be removed. These impurities inter-
fere with film strength and wear protection. They also form deposits at high tempera-
tures and solidify at low temperatures. Petroleum-based greases are formulated by adding lithium, calcium or sodium
thickeners to petroleum-based oil.
Lubricants - Super Lube®
Part Number (old) Description Case Qty List Price
31040 (23755) 6 oz. aerosol 12 $ 12.04
31110 (20029) 11 oz. aerosol 12 14.87
51600 (24575) 32 oz. non-aerosol trigger spray 12 35.65
31110
51600
Benefits:
• Synthetic with PTFE
• Provides more reliable lubrication and outlasts petroleum based
greases & oils
• Non-toxic, odorless
• USDA H--1 for use in federally inspected meat & poultry plants.
• Remains free flowing in freezing temperatures
• High dielectric strength
• Water and saltwater waterproof
• Will not stain or harm wood, rubber, leather, plastics, fabric & paint
• Won't drip, run or evaporate
• 1A copper corrosion
• Excellent salt spray performance
• Repels dirt, dust, grit and grime
• Prevents rust and corrosion while reducing friction
• Reduces maintenance for longer machinery life
Applications:
• Plain & anti-friction bearings
• Ball & roller bearings
• Wheel bearings
• Chassis points
• Fifth wheels
• Electric motor bearings
• Disc brake assemblies
• Pumps
• Blowers
• Cams
• Slides
• Conveyors
• Chains
• Water pumps
• Valves
• Open gears
Super Lube ® and
SYNCOLON ® are
trademarks of SYNCO
Chemical Corp.
Super Lube Aerosol
A multi-purpose PTFE based synthetic lubricant available in aerosol form. Super Lube aerosol dis-
perses and penetrates while lubricating & loosening rust and dirt. Super Lube aerosol offers con-
tinuous protection as it "sets up" and forms a grease film barrier that defends against oxidation.
This barrier helps extend the life of equipment and reduces maintenance.
Super Lube Non-Aerosol Pump
Because of environmental concerns, many industrial facilities do not allow the use of aerosol prod-
ucts. Super Lube Oil with PTFE is available in a one quart trigger spray container to address these
needs.
6/14/11
8.6
TM
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Lubricants - Super Lube®
11016
Benefits:
• Clean, non-staining
• For uses from -40°F to +500°F
• Non-conducting
• Easy to use
• Resists acid attacks
• Dries on contact
• Effective mold release agent
• Not affected by oil, water or solvents
• Long lasting lubrication
• Cleans while lubricating
• Stops squeaking, sticking
• Prevents corrosion
Applications:
• Industrial slides and glides
• High speed machinery
• Precision instruments
• Door and trunk hinges
• Pipe fittings
• Electronic & electrical equipment
• Chains
• Tools
• Zippers
• Lock cylinders
• Rusted nuts and bolts
• Cable pivots
Part Number Description Case Qty List Price
11016 11 oz. aerosol 12 $ 17.10
Benefits:
• Waterproof
• Non-toxic (USDA rating H1)
• Synthetic with PTFE
• Reduces friction and wear
• Extends machinery &
equipment life
• Reduces maintenance
• Viscosity stable
• Long-lasting
Applications:
• Plain, anti-friction & roller bearings
• Enclosed industrial gears
• Enclosed chains
• Gearhead motors
• Paper machines
• Conveyors
• Machine ways
• Reciprocating compressor
lubricant additive
• Machine tools
• Centralized systems
• Straight, helical, bevel & spiral gears
Part Number (old) Description Case Qty List Price
51010SL (82333) 7 ml precision oiler 12 $ 7.28
51040 (82334) 1 gallon 4 131.60
82337 (52040) Light Weight Oil 1 gallon 4 114.58
51010
Typical Properties:
Color: Translucent white
Viscosity tested to ASTM D445
cSt@ 100°F: 14-17
cSt @ 40°F: 118-122
ISO grade: 220
Replaces ISO grade: 150-320
Replaces SAE grade gear oils: 90
Viscosity index: 145
Shelf Life: 24 months
Super Lube Dri Lube (Dri-Film)
Super Lube Dri-Lube is a self-cleaning lubricant that actually cleans while lubri-
cating. Super Lube Dri-Lube leaves behind a protective shield lubricant that
will not attract dust. The dry coating provides a low coefficient of friction which
gives excellent lubrication and release properties. Dri-Lube can be used on
wood, metal and most plastics not under stress and has excellent thermal and
chemical stability, forming a natural insulating barrier when used on electronics.
Super Lube Oil with PTFE
Super Lube Oil with PTFE is a premium synthetic oil with suspended PTFE particles that bond to
surfaces to add lubricity to moving parts. Super Lube Oil with PTFE is used for applications which
allow parts to be confined (ie. gear box). Use it as a general purpose lubricant for industrial
machinery and equipment. Super Lube Oil with PTFE provides long life protection against friction,
wear, rust and corrosion. Machinery lasts longer, downtime is reduced, and productivity is
increased. Super Lube Oil with PTFE is safe on metal, rubber, plastic, wood, leather, fabric & paint-
ed surfaces.
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM 6/14/11
8.7
Lubricants - Super Lube®
41150 21030
Benefits:
• Clean
• Non-toxic
• Non-staining
• Dielectric
• USDA Rating H1
• Will not drip, run or evaporate
• Impervious to salt water, safe in potable water
• Long lasting
• Prevents rust & corrosion while reducing
friction
• Compatible with conventional lubricants
• Repels dirt, dust, grit & grime
• Extends machinery and equipment life
• Reduces maintenance while saving time & money
• Reduces friction and wear
• Will not stain or harm wood, rubber, leather,
plastic, fabrics and paint.
Applications:
• Plain and anti-friction bearings
• Ball and roller bearings
• Wheel bearings
• Chassis points
• Fifth wheels
• Electric motor bearings
• Disc brake assemblies
• Pumps
• Blowers
• Cams
• Slides
• Conveyors
• Chains
• Water pumps
• Valves
• Open gears
• Switch assemblies
• Cables
• Fans
• Electronic equipment
• Deep drawing application
Super Lube Grease Replaces
• Lithium, Bentone, Calcium or
Aluminim complex grease
• High & low temperature greases
• Electric motor grease
• Food grade grease
• Bearing, wheel bearing grease
• Multi-purpose grease
• Dielectric grease
• Valve sealant
• O-ring lubricant
Part Number (old) Description Case Qty List Price
21010 (82324) 1/2 oz. tube 12 $ 6.22
21030 (82325) 3 oz. tube 12 10.50
72350 (41150) 400 g cartridge 12 21.97
41160 (82329) 400 g jar 12 22.68
41050 (82330) 5 lb. pail 4 119.27
41030 (82331) 30 lb. pail 1 671.36
TYPICAL PROPERTIES
Color: Translucent white
Operating Temperature
Range: -45° to 450°F
NLGI Grade (ASTM D1092): 2
Dropping point (ASTM D566):
>500°F (260C)
Four ball test (ASTM D2783):
Load wear index: 81.73 kg
Weld point: 400 kg
Oxidation stability 100 hrs.
(ASTM D942): 0 psi
Wheel bearing leakage
(ASTM D1263): 0.2g
Copper corrosion 24 hrs @
100°C (ASTM D4048): 1B,
shiny
Shelf life: 24 months
Super Lube Grease
Super Lube is a patented synthetic NLGI grade 2 heavy-duty, multi-pur-
pose lubricant with PTFE. Synthetic base fluids and the addition of
PTFE micro powders combine to form a premium lubricant that pro-
vides long life protection against friction, wear, rust and corrosion.
Machinery lasts longer, downtime is reduced, and productivity is
increased.
Super Lube is a USDA listed Food Grade Lubricant, rated H1 for incidental food contact.
Super Lube will not run or drip, does not evaporate or form gummy deposits and will not
dry out, melt or separate.
Super Lube is a synthetic, heavy duty lubricant that is compatible with most other lubri-
cants. Super Lube Grease outlasts conventional greases 50-100% and has excellent
adhesion.
6/14/11
8.8
TM
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Lubricants - Super Lube®
Super Lube Product Display
• 36 pc. assortment with counter display
• Contains:
12 #21030 Super Lube Grease w/ PTFE, 3 oz. tubes
12 #31040 Super Lube w/ PTFE 6 oz. aerosol
12 #31110 Super Lube w/ PTFE 11 oz. aerosol
11362
Part Number Description Display Qty List Price
11362 Assorted Counter Display 36 $ 513.30
21013 Counter display w/ Grease 40 297.55
51013 Counter display w/ Oiler 48 327.70
Super Lube Grease w/ PTFE Counter display
• Packaged in a cardboard counter display
• Contains 40, 1/2 oz. tubes Super Lube w/ PTFE grease
Super Lube Precision Oiler w/ PTFE Counter display
• Packaged in a cardboard counter display
• Contains 48, 7 ml precision oiler pens of Super Lube w/ PTFE
21013 and 51013
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM 6/14/11
8.9
Lubricants - Super Lube®
Benefits:
• Wide temperture range
• Works on types of pneumatic equipment
• Prevents rust and corrosion
• Can be used as a light oil
• Gives worn tools new life
• Less friction and wear
• Protects against corrosives
• Less tendancy for bubbles
• Absorbs moisture
• Eliminates ice buildup and frost in air tools.
Applications:
• Air impact tools
• Drills
• Grinders
• Screwdrivers
• Sanders
• Percussion tools
• Household shop tools
• All air tool oil lubricated
Super Lube Air Tool Lubricant
Super Lube Air Tool Lubricant is formulated to meet the special require-
ments for industrial, household and agricultural tools. It absorbs water
and eliminates any ice buildup and frost in air tools. Blended rust and
corrosion inhibitors and a special base fluid oil minimizes wear and
allows operation of air tools at temperatures as low as -40°F.
Part Number Description Case Qty List Price
12004 4 oz. bottle 6 $ 8.87
12016 16 oz. bottle 12 19.25
12032 32 oz. bottle 12 35.41
12040 1 gallon 4 122.37
12050 5 gallon 1 568.31
Benefits:
• Cleans and Penetrates
• Loosens rusted parts
• Frees sticky mechanisms
• Stops squeaks
• Protects against rust &
corrosion
• Drives out moisture
• Leaves a protective
lubricating film
Typical Properties:
TEST METHOD SYNCOPEN
Color Translucent Brown
Specific Gravity ASTM D1298 .85
Pour Point ASTM D97 -40°F
Salt Spray Test ASTM B117 Pass
(500 hrs)
Copper Corrosion ASTM D130 1A
24 hrs @ 100°C
USDA Rating NSF H1
Shelf Life 24 months
Super Lube Syncopen
Super LubeSynthetic Penetrant is a super fast acting, penetrating, synthetic oil that
cuts through rust or corrosion. Syncopen penetrates hard to reach areas to allow
easy removal of rusted and corroded screws, nuts or bolts. Syncopen penetrates,
lubricates and leaves a protective film to help prevent future rusting or corrosion.
Part Number Description Case Qty List Price
85011 11 oz. aerosol 12 $ 14.08
85032 32 oz. trigger pump spray bottle 12 37.63
85010 1 gallon 4 122.18
85050 5 gallon 1 584.24
4/2009
8.10
TM
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
Part Number Description Ctn Qty List Price
SW500C Stub Wrench 25 6.43
SW500C
SW500 Nipple Extractor Features:
• For 1/2” or 3/4” plastic nipples.
• Easy to remove broken plastic riser from sprinkler pipe and fittings.
• Insert tip and turn.
For Use with
Part Number Coupling Sizes Ctn Qty List Price
SW400 1/2” through 4” 60 $ 17.68
SW600 1/2” through 6” 60 20.18
SW Series
Part Number Description Ctn Qty List Price
WCS1022 Wire Cutter/Stripper 100 $ 17.68
WCS1022MU Wire Cutter/Stripper/Crimper 72 17.68
WCS1022, WCS1022MU
Adjustable Strap Wrench:
HARVARD CONTRACTOR’S WCS1022 Wire
Cutter/Strippers Features:
• Combination wire cutter and stripper.
• Strips wire sizes 22-10 AWG.
• Heavy duty scissor opening spring.
• Cushioned plastic grips.
• Easy locking thumb lock.
HARVARD CONTRACTOR’S WCS1022MU Wire
Cutter/Stripper/Crimper Features:
• Compact, high quality multi-use tool designed for perform six most
common electrical wiring functions.
• Made of heat-treated carbon steel.
• Handles a variety of terminal and connector styles-insulated and non-
insulated.
• Wire range 22-10 AWG.
• Anvil-type wire cutter for clean cuts.
• Crimp dies for 22-10 AWG non-insulated terminals and connectors.
• Wire stripping stations for circumferencial cutless effort.
• Crimp die for 7 and 8 mm ignition parts.
• Cushioned plastic grips.
Miscellaneous Tools
5/3/11
11.9
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Garbage Disposal Wrench Features:
• Fits standard units.
4-Way Key Features:
• For use on square stem 1/4”, 9/32”, 5/16”, 11/32”.
Tub and Shower Valve Socket Wrench Set Features:
• Set includes sockets, handle and wire.
Radiator Spud Wrench Features:
• For use when spud wrench or key is required.
• Plated.
4 Way Countersunk Plug Wrench Features:
• Steel construction.
Internal Pipe Wrench Features:
• Available in sizes 3/8”, 1/2”, 3/4” and 1”.
Adjustable Strainer and Spud Wrench Features:
• Use for Basket Strainers and Closet Spud.
• Minimum 1” to Maximum 3”.
• Plated.
4-Way P.O. Plug Wrench Features:
• Plated.
• Use when installing or removing tub drains, P.O. plugs & basket strainers.
Strainer Wrench
• Plated steel.
• For use on basket strainers and tub drains with crossbars.
•Long handle for leverage.
Spanner and Strainer Wrench Features:
• Plated, malleable iron.
• For use on basket strainer jam nuts.
Part Number Description Ctn Qty List Price
HGD10 Garbage disposal wrench 1 $ 7.11
HK400 Four way key 6 5.23
HW500 Complete wrench set 1 16.36
HR Radiator spud wrench 5 22.37
HP400 4 way plug wrench 1 25.86
HI380 3/8” internal pipe wrench 5 4.40
HI500 1/2” internal pipe wrench 5 5.48
HI750 3/4” internal pipe wrench 5 5.72
HI100 1” internal pipe wrench 5 10.50
HK50 Utility knife w/extra blade 12 7.40
HAS300 Adjustable strainer wrench 10 15.54
HPO400 4-Way plug wrench 10 7.04
HS200 Strainer wrench 10 8.64
HS500 Spanner/strainer wrench 10 8.47
HK50
HGD10
HK400 HW500
HR
HP400
HI
HAS300
HPO400
HS200
HS500
TM www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
6/14/11
11.10
Plumbing Tools
6/14/11
12.3
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Insert Fittings - Cast Bronze
• For use with flexible plastic pipe
• Heavy Pattern, contractor grade cast bronze.
• Imported Number Ctn/Case List
Part Number Size Style of Barbs Qty Price
Cast Bronze Male Insert Adapters (INS x MIP)
RBMA1/2 1/2” x 1/2” Hex 5 10/200 $ 7.04
RBMA3/4 3/4” x 3/4” Hex 5 10/200 9.00
RBMA1 1” x 1” Hex 7 10/100 13.41
RRBMA1 1” x 1” Round 6 10/100 13.79
RBMA1X3/4 1” x 3/4” Hex 5 10/100 10.79
RBMA1X11/4 1” x 11/4” Hex 6 10/100 16.75
RBMA11/4 1 1/4” x 1 1/4” Hex 6 10/100 17.96
RBMA11/4X1 1 1/4” x 1” Hex 7 10/100 17.32
RBMA11/2 1 1/2” x 1 1/2” Hex 6 5/50 20.79
RBMA11/2X11/4 11/2” x 1 1/4” Hex 6 10/100 18.89
RBMA2 2” x 2” Hex 7 5/50 33.71
Cast Bronze Extra Long Male Adapters (INS x MIP)
XLRBMA1 1” x 1” Hex 12 10/100 20.18
XLRBMA1x11/4 1” x 1 1/4” Hex 12 10/100 20.32
XLRBMA11/4 1 1/4” x 1 1/4” Hex 12 10/100 23.93
XLRBMA2 2” x 2” Hex 12 5/50 41.64
Cast Bronze Male Union Adapters (INS x MIP)
RBMUA1 1” x 1” Hex 6 10/80 22.78
RBMUA11/4 1 1/4” x 1 1/4” Hex 6 10/40 20.33
Cast Bronze Rope Adapter (INS x MIP)
RBRA1 1” x 1” Round w/ rope eye 11 10/100 15.61
RBRA1X11/4 1” x 1 1/4” Round w/ rope eye 6 10/100 17.51
RBRA11/4 1 1/4” x 1 1/4” Round w/ rope eye 6 10/100 19.64
Cast Bronze Female Adapters (INS x FIP)
RBFA1/2 1/2” x 1/2” Round 5 10/200 9.11
RBFA3/4 3/4” x 3/4” Round 5 10/100 10.18
RBFA1 1” x 1” Round 5 10/100 16.61
RBFA11/4 1 1/4” x 1 1/4” Round 7 10/100 19.54
RBFA11/2 1 1/2” x 1 1/2” Round 6 5/50 23.68
RBFA2 2” x 2” Round 7 5/50 36.96
Cast Bronze Couplings (INS x INS)
RBC1/2 1/2” x 1/2” Hex 4 10/220 6.30
RBC3/4 3/4” x 3/4” Hex 4 10/200 9.50
RBC3/4X1 3/4” x 1” Hex 5 x 6 10/100 12.50
RBC1 1” x 1” Hex 5 10/100 13.04
RBC1X11/4 1” x 1 1/4” Hex 6 10/100 20.32
RBC11/4 1 1/4” x 1 1/4” Hex 6 10/100 19.00
RBC11/2 1 1/2” x 1 1/2” Hex 4 5/50 19.79
RBC2 2” x 2” Hex 4 5/50 28.00
Cast Bronze Extra Long Couplings (INS x INS)
XLRBC1 1” x 1” Hex 12 10/100 20.71
XLRBC11/4 1 1/4” x 1 1/4” Hex 12 5/50 29.93
XLRBC2 2” x 2” Hex 12 5/25 54.68
XLRBMA
RBFA
RBRA
RBC
XLRBC
RBMUA
RBMA
RRBMA
6/14/11
12.4
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Insert Fittings - Cast Bronze
Number Ctn/Case
Part Number Size of Barbs Qty List Price
Cast Bronze Hydrant Elbow (INS x MIP)
RBHE3/4 3/4” x 3/4” 5 10/100 $ 11.80
RBHE1x3/4 1” x 3/4” 5 10/100 21.25
RBHE1 1” x 1” 5 10/100 16.75
RBHE11/4 1 1/4” x 1 1/4” 6 5/50 30.86
Cast Bronze Extra Long Hydrant Elbows (INS x MIP)
XLRBHE1 1” x 1” 8 10/100 21.61
XLRBHE1X3/4 1” x 3/4” 10 10/100 18.75
Cast Bronze Combination Elbows (INS x FIP)
RBFE1 1” x 1” 8 5/50 21.86
RBFE1x11/4 1” x 1 1/4” 8 5/50 21.86
RBFE11/4 1 1/4” x 1 1/4” 6 5/50 25.79
Cast Bronze Elbows (INS x INS)
RBE3/4 3/4” x 3/4” 5 10/200 13.68
RBE1 1” x 1” 6 10/100 18.36
RBE11/4 1 1/4” x 1 1/4” 6 10/50 30.32
Cast Bronze Ground Source Elbows (INS x MIP w/ 1/4” tap)
RBGSE3/4 3/4” x 3/4” 10/100 13.96
RBGSE1X3/4 1” x 3/4” 10/100 13.96
RBGSE1 1” x 1” 10/80 18.04
RBGSE11/4 1 1/4” x 1 1/4” 5/50 28.71
Cast Bronze Hydrant Tees (INS x MIP)
RBHT3/4 3/4” x 3/4” 4 10/100 16.00
RBHT1X3/4 1” x 3/4” 6 10/100 22.14
RBHT1 1” x 1” 4 10/100 21.61
Cast Bronze Tees (INS x INS)
RBT3/4 3/4” x 3/4” 5 10/100 15.36
RBT1 1” x 1” 6 10/100 25.79
RBT11/4 1 1/4” x 1 1/4” 6 5/50 39.57
Cast Bronze Combination Tees (INS x FPT)
RBFT3/4 3/4" x 3/4" 6 10/100 20.83
RBFT1 1" x 1" 6 6/60 37.10
RBFT1X1X3/4 1” x 1” x 3/4” 6 8/80 31.50
RBFT11/4 1 1/4” x 1 1/4” 6 4/40 45.56
RBHE
RBE
RBHT
RBT
• For use with flexible plastic pipe
• Heavy Pattern, contractor grade cast bronze.
• Imported
RBFE
RBFT
RBGSE
6/14/11
12.5
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Insert Fittings - Steel, Zinc Plated
Part Number Size Ctn/Case Qty List Price
Male Adapter, mipt x ins *
S12-1/2 1/2" 25 $ 4.63
S12-3/4 3/4” 25 4.95
S12-1 1” 20 6.34
S12-11/4 1-1/4” 20 8.03
S12-11/2 1-1/2” 10 9.95
S12-2 2” 10 14.36
S12-21/2 2-1/2” BULK 37.66
S12-3 3” BULK 50.80
S12-4 4” BULK 82.29
Male Adapter, mipt x ins IMPORTED **
IMAS50 1/2" 50/300 1.39
IMAS75 3/4" 50/200 1.91
IMAS100 1" 25/200 2.51
IMAS125 1 1/4" 12/108 4.49
IMAS150 1 1/2" 6/90 5.83
IMAS200 2" 5/60 8.55
IMAS250 2 1/2” 2/10 21.95
IMAS300 3” 2/10 24.87
IMAS400 4” 2/10 39.86
Extra Long Male Adapter, mipt x ins *
XS12-1 1” 25 12.30
XS12-11/4 1-1/4” 25 16.25
XS12-11/2 1-1/2” 25 18.71
Extra Long Male Adapter, mipt x ins IMPORTED **
IMAS100XL 1” 10/120 4.04
IMAS125XL 1 1/4” 10/80 6.96
Reducing Male Adapter, mipt x ins *
S38-3/4X1/2 3/4" x 1/2" 25 20.10
S38-1X3/4 1" x 3/4” 25 22.16
S38-11/4X1 1-1/4" x 1” 25 25.29
S38-11/2X11/4 1-1/2" x 1-1/4” 25 31.42
S38-2X11/2 2" x 1-1/2” 25 42.17
Reducing Male Adapter, ins x mipt *
S74-1X3/4 1" x 3/4” 25 12.44
S74-11/4X1 1-1/4" x 1 25 17.80
S74-11/2X11/4 1-1/2" x 1-1/4” 25 21.20
Reducing Male Adapter, ins x mipt IMPORTED **
IMAS7550 3/4” x 1/2” 250 4.47
IMAS1075 1” x 3/4” 250 5.14
Venturi Adapter, mipt x ins *
S86-3/4X6 3/4" x 6” 25 18.05
S86-3/4X10 3/4" x 10" 25 21.48
S86-3/4X12 3/4 x 12” 25 21.76
S86-1X6 1" x 6" 25 13.71
S86-1X8 1" x 8" 25 16.56
S86-1x10 1" x 10" 25 18.60
S86-1X12 1" x 12" 25 21.24
S86-11/4X6 1-1/4" x 6" 25 18.66
S86-11/4X8 1-1/4" x 8" 25 21.01
S86-11/4X10 1-1/4" x 10" 25 25.34
S86-11/4X12 1-1/4" x 12” 25 32.46
• For use with flexible poly pipe
• Made in North America.
• IMAS Imported
• Made from Sch 40 C.W. steel pipe,
zinc plated.
S12, IMAS
S38
S74, IMAS
XS12, IMAS--XL
S86
***
6/14/11
12.6
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Insert Fittings - Steel, Zinc Plated
Part Number Size Ctn/Case Qty List Price
Venturi Adapter, mipt x ins IMPORTED **
ISVMA1X6 1" x 6" 60 $ 5.43
ISVMA1X8 1" x 8" 50 7.95
ISVMA1X10 1" x 10" 40 9.44
ISVMA11/4X6 1-1/4" x 6" 50 7.46
ISVMA11/4X8 1-1/4" x 8" 40 9.27
ISVMA11/4X10 1-1/4" x 10" 30 11.49
Well Seal Elbow, ins x ins *
S99-1 1” 10 26.66
S99-11/4 1-1/4” 10 36.03
Well Seal Elbow, ins x ins IMPORTED **
ISWSE100 1” BULK 13.11
ISWSE125 1-1/4” BULK 21.54
Coupling, ins x ins *
S10-1/2 1/2” 25 4.18
S10-3/4 3/4” 25 4.95
S10-1 1” 20 6.70
S10-11/4 1-1/4” 20 9.51
S10-11/2 1-1/2” 10 10.64
S10-2 2” 10 19.60
S10-3 3” BULK 65.36
S10-4 4” BULK 104.56
Coupling, ins x ins IMPORTED **
ICS50 1/2" 50/300 1.35
ICS75 3/4" 50/200 1.91
ICS100 1" 25/200 2.34
ICS125 1 1/4" 20/120 4.38
ICS150 1 1/2" 10/60 5.57
ICS200 2" 10/60 7.40
ICS250 2 1/2” 2/10 21.99
ICS300 3” 2/10 24.46
ICS400 4” 2/10 29.46
Extra Long Coupling, ins x ins *
XS10-1 1” 25 22.32
XS10-11/4 1-1/4” 25 32.08
Extra Long Coupling, ins x ins IMPORTED **
ICS100XL 1” 10/120 3.93
ICS125XL 1-1/4” 10/80 6.96
Female Adapter, fipt x ins *
S90-1/2 1/2” 25/300 12.82
S90-3/4 3/4” 25/200 16.76
S90-1 1” 20/160 21.61
S90-11/4 1-1/4” 20/120 26.93
S90-11/2 1-1/2” 10/60 31.99
S90-2 2” 10/40 38.79
Female Adapter, fipt x ins IMPORTED **
IFAS100 1” 125 4.82
IFAS125 1 1/4” 100 11.11
S90, IFAS
S10, ICS
XS10, ICS--XL
S99, ISWSE
• For use with flexible poly pipe
• Made in North America.
• ISVMA, ISWSE, IFAS, ICS - Imported
• Made from Sch 40 C.W. steel pipe,
zinc plated.
ISVMA
***
6/14/11
12.7
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Insert Fittings - Stainless Steel
SS12 Series SS38 Series
Part Number Size # Barbs Ctn/Case Qty List Price
Grade 316 SS, MADE IN U.S.A.
Male Adapter, MIPT X INS , ROUND PATTERN
SS12-1/2 1/2” 6 25/300 $ 21.17
SS12-3/4 3/4” 7 25/200 19.49
SS12-1 1” 7 20/160 22.08
SS12-11/4 1-1/4” 6 20/120 36.20
SS12-11/2 1-1/2” 6 10/60 49.01
SS12-2 2” 7 10/40 64.41
Male Reducing Adapter mipt x red. ins
SS38-11/4x1 1-1/4 x 1” 7 25/100 52.13
Grade 316 SS, EXTRA LONG, MADE IN U.S.A.
Male Adapter, MIPT X INS , ROUND PATTERN
XSS12-1 1 14 25 43.07
XSS12-11/4 11/4 14 25 56.11
Grade 316 SS, MADE IN U.S.A.
Coupling, INS X INS, ROUND PATTERN
SS10-1 1 7 20 31.50
SS10-11/4 11/4 7 20 41.64
Grade 316 SS, EXTRA LONG, MADE IN U.S.A.
Coupling, INS X INS, ROUND PATTERN
XSS10-1 1 14 25 56.98
Features:
• Imported cast from Grade 304 Stainless Steel.
• Made in U.S.A. from Grade 316 Stainless Steel.
• For use with flexible poly pipe.
Part Number Size # Barbs Ctn/Case Qty List Price
Grade 304 SS, IMPORTED
Male Adapters, MIPT X INS, HEX PATTERN
SSMA1/2 1/2" 6 10/200 $ 8.18
SSMA3/4 3/4" 6 10/200 10.26
SSMA1 1” 6 10/100 17.00
SSMA11/4 1 1/4” 6 5/100 20.71
SSMA11/4X1 1 1/4” x 1” 6 5/100 18.00
SSMA11/2 1 1/2" 6 5/80 26.89
SSMA2 2" 6 5/40 37.49
Grade 304 SS, HEAVY PATTERN EXTRA LONG, IMPORTED
Male Adapters, MIPT X INS, HEX PATTERN
XLSSMA11/4X1 1 1/4” x 1” 13 5/60 46.86
SSMA Series XLSSMA
SS10 Series
6/14/11
12.8
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Insert Fittings - Yellow Brass
Part Number Size Ctn/Case Qty List Price
Yellow Brass Adapters, ins x solder
YB00-1/2 1/2” 10/200 $ 4.11
YB00-3/4 3/4” 10/200 5.86
YB00-1 1” 10/200 7.93
YB00-11/4 1-1/4” 10/200 8.39
YB00-11/2 1-1/2” 5/80 29.46
Yellow Brass Couplings, ins x ins
YB10-1/2 1/2” 10/200 4.82
YB10-3/4 3/4 “ 10/200 5.54
YB10-1 1” 10/200 7.50
YB10-11/4 1-1/4” 10/200 9.82
Yellow Brass Adapters, ins x mipt
YB12-1 1” 10/200 9.25
YB00
YB10
YB12
• For use with flexible poly pipe
• Imported
4/2009
12.15
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Compression Couplings-Imported, PVC/CPVC
MATERIAL SPECIFICATIONS
# Part Material
1 Body UPVC, CPVC
2 Compression Nut UPVC, CPVC
3 Gasket - PVC NR
Gasket - CPVC EPDM
Part Number Material Size Case Qty List Price
PC10-1/2 PVC 1/2” IPS 100 $ 2.33
PC10-3/4 PVC 3/4” IPS 90 2.70
PC10-1 PVC 1” IPS 60 3.49
PC10-11/4 PVC 1 1/4” IPS 40 4.20
PC10-11/2 PVC 1 1/2” IPS 30 5.79
PC10-2 PVC 2” IPS 20 8.06
PC10-21/2 PVC 2 1/2” IPS 10 18.42
PC10-3 PVC 3” IPS 4 26.06
PC10-4 PVC 4” IPS 2 34.39
PC10-6 PVC 6” IPS 2 82.73
HW10CTS1/2 CPVC 1/2” CTS 20/360 4.07
HW10CTS3/4 CPVC 3/4” CTS 20/240 4.93
PVC Compressing Coupling Features:
• Iron Pipe Size (PVC), Copper Tube Size (CPVC)
• For use with cold water (PVC) or hot water (CPVC-CTS)
• Natural rubber gasket seals
• Rated at 200 psi at 70°F
• Imported
"PC" Series IPS DIMENSIONS (IN.)
SIZE D d d1 L
1/2” 1.85 .91 .83 5.24
3/4” 2.09 1.18 1.04 5.32
1” 2.40 1.42 1.31 5.75
1 1/4” 2.87 1.81 1.65 6.30
1 1/2” 3.15 2.05 1.89 6.89
2” 3.62 2.56 2.37 7.87
2 1/2” 4.53 2.52 2.87 9.92
3” 5.28 3.62 3.49 10.87
4” 6.34 4.65 4.49 11.93
6” 8.78 6.85 6.62 11.22
"HW" Series CTS DIMENSIONS (IN.)
1/2” 1.30 .71 .63 4.49
3/4” 1.85 .95 .88 5.00
For Use with
Part Number Coupling Sizes Ctn Qty List Price
Adjustable Strap Wrench
SW400 1/2” through 4” 10/60 $ 17.68
SW600 1/2” through 6” 10/60 20.18
SW Series
6/14/11
12.16
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Compression Fittings, Galvanized
Recommended Maximum Pressure(PSI)
Size Torque Anchored
Ft. Lbs Piping
1/2” 150 150
3/4” 150 150
1” 225 100
1-1/4” 225 100
1-1/2” 225 100
2” 300 75
Galvanized Long Pattern Compression Fitting Features:
• Bodies made of steel tubing (GC10), malleable iron (GC10C)
• End nuts made of malleable iron.
• Galvanized finish
• Buna-N gaskets on domestic fittings.
• SBR gaskets on GC10C series.
• Maximum rated service temperature for gaskets: 212°F (100º C).
• GC10C manufactured for AGI in an ISO9002 facility.
WARNING: Designer and/or contractor must provide suitable anchor-
ing of piping to prevent pull-out from fittings when applications sub-
ject piping to external forces such as ground shift and temperature
variations that cause linear pipe contraction.
GC10C Series
GC10 Series
GC12 Series
ISO 9002
Coupling GC10C - Long Pattern - Imported - Malleable Iron, 125 PSI, 120° F
Part Number Size Pipe O.D. Ctn/Case Qty List Price
GC10C1/2 1/2” .840 30 / 60 $ 10.20
GC10C3/4 3/4” 1.050 25 / 50 11.44
GC10C1 1” 1.315 15 / 30 13.42
GC10C11/4 1-1/4” 1.660 12 / 24 17.04
GC10C11/2 1-1/2” 1.900 9 / 18 20.19
GC10C2 2” 2.375 14 30.19
Coupling GC10 - Made in U.S.A. - Steel Tube
Part Number Size Pipe O.D. Ctn Qty List Price
GC10-1/2 1/2” .840 12 $ 25.66
GC10-3/4 3/4” 1.050 12 27.98
GC10-1 1” 1.315 12 33.04
GC10-11/4 1-1/4” 1.660 6 44.12
GC10-11/2 1-1/2” 1.900 6 48.73
GC10-2 2” 2.375 6 61.24
Adapters GC12 - Made in U.S.A. - Steel Tube
Part Number Size Pipe O.D. Ctn Qty List Price
GC12-1/2 1/2” .840 12 $ 37.50
GC12-3/4 3/4” 1.050 12 36.18
GC12-1 1” 1.315 12 38.31
GC12-11/4 1-1/4” 1.660 6 45.54
GC12-11/2 1-1/2” 1.900 6 63.32
GC12-2 2” 2.375 6 63.44
6/14/11
12.17
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Pipe Repair Clamps
Repair Clamp Features:
• Pipe repair clamps eliminate the need for costly pipe replacement for
simple leaks.
• Non-corrosive clamp band is made of annealed stainless steel.
• Nuts and bolts are cadmium plated with a chromate finish; heavy duty
hex nut with washer.
• Lugs are made of annealed, malleable iron for maximum strength and
permanence; iron phosphate finish.
• Neoprene gasket with maximum rated service temperature of 212° F
(100ºC).
• Imported
Nominal IPS CTS Ctn
Part Number Pipe Size Pipe O.D. Tube O.D. Qty List Price
3” Wide, 1 Bolt
HRC3-3/8 3/8” .675 .625 6/72 $ 5.94
HRC3-1/2 1/2” .840 .875 6/72 6.98
HRC3-3/4 3/4” 1.050 1.125 6/72 7.13
HRC3-1 1” 1.315 1.375 6/72 7.97
HRC3-11/4 1 1/4” 1.660 1.625 6/72 8.79
HRC3-11/2 1 1/2” 1.900 6/72 8.90
HRC3-2 2” 2.375 6/72 10.67
HRC3-21/2 2 1/2” 2.875 6/48 11.37
HRC3-3 3” 3.50 6/48 12.05
HRC3-4 4” 4.50 6/24 12.35
6” Wide, 2 Bolts
HRC6-1/2 1/2” .840 .875 6/56 12.54
HRC6-3/4 3/4” 1.050 1.125 6/56 13.44
HRC6-1 1” 1.315 1.375 6/56 13.60
HRC6-11/4 1 1/4” 1.660 1.625 6/56 15.06
HRC6-11/2 1 1/2” 1.900 6/56 16.49
HRC6-2 2” 2.375 6/56 19.77
HRC6-21/2 2 1/2” 2.875 6/24 21.28
HRC6-3 3” 3.50 6/24 22.44
HRC6-4 4” 4.50 6/24 22.92
Straight through bolt
pull on lugs gives
more uniform pres-
sure on the band,
more pressure on
pipe with less torque
on nut.
Oval lug opening in
band won’t tear - no
corners to rip out as
with square hole.
Lugs above pipe level
don’t pull into pipe.
Gives more tension
on band - more seal-
ing power yet won’t
crush pipe.
Band covers lead
edge of lug. Equal
pressure across
entire band. No fric-
tion - no cutting into
pipe surface by raw
edge of band open-
ing.
7/20/10
12.18
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Couplings, Caps - Flexible & No-Hub
Part Number Size Connection Ctn Qty List Price
NO HUB COUPLINGS
C150C 1 1/2 X 1 1/2 CI X CI 100 $ 9.37
C200C 2 X 2 CI X CI 100 9.37
C215C 2 X 1 1/2 CI X CI 100 10.92
C300C 3 X 3 CI X CI 100 10.92
C400C 4 X 4 CI X CI 100 13.22
FLEXIBLE COUPLINGS
MR0244 4 X 4 CLAY X CI/PL 18 14.44
MR5615/125 11/4 x 1 1/2 CI/PL x TUBE 24 7.60
MR56125 1 1/2” Tubing, Copper or 1 1/4” PL to Same 24 6.89
MR5615 1 1/2 x 1 1/2 CI/PL X CI/PL 24 7.31
MR5622/125 2 x 1 1/4 CI/PL x CI/PL 24 7.66
MR56215 2 X 1 1/2 CI/PL X CI/PL 24 8.33
MR5622 2 X 2 CI/PL X CI/PL 24 7.88
MR56315 3 x 1 1/2 CI/PL x CI/PL 24 13.93
MR5632 3 X 2 CI/PL X CI/PL 24 9.84
MR5633 3 X 3 CI/PL X CI/PL 18 10.64
MR5642 4 x 2 CI/PL x CI/PL 18 17.19
MR5643 4 X 3 CI/PL X CI/PL 18 14.35
MR5644 4 X 4 CI/PL X CI/PL 24 13.33
MR5655 5 X 5 CI/PL X CI/PL 14 20.88
MR5664 6 x 4 CI/PL x CI/PL 10 31.02
MR5666 6 X 6 CI/PL X CI/PL 12 28.51
DRAIN PIPING TO TUBULAR TRAP *
MRTC150 1 1/4” x 1 1/2” 24 4.19
MRDTC150 1 1/4” or 1 1/2” x 1 1/4” or 1 1/2” 24 5.13
MRDTC215 2” x 1 1/4” or 1 1/2” 24 6.77
* Any combination of 1 1/4” or 1 1/2” tubular drain (plastic, tubular or copper)
END CAPS
0701-011 1 1/2” 24 4.08
0702-019 2” 24 4.80
0703-017 3” 24 6.07
0704-015 4” 24 7.76
0705-020 5” 20 15.51
0706-028 6” 12 15.97
Coupling, Cap Features:
• Flexible couplings for joining all types of sewer pipe,
including transitions from one type to another.
• NO-HUB couplings for joining cast iron pipe sections
• End Caps for capping cast iron, steel, PVC and ABS pipe.
• 300 Series stainless steel clamps
• Meets IAPMO File #0317, BOCA ESI RR#90-68, SBCCI PST&ESI Report #9483B
• CSA Approved
MRTC Series
MR Series
C Series
07 Series
6/14/11
12.27
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Threaded Bronze Fittings
Part Number Size Ctn Qty List Price
90 º Elbow, fipt x fipt
B90L1/8 1/8” 25 $ 6.32
B90L1/4 1/4” 25 6.32
B90L3/8 3/8” 25 6.32
B90L1/2 1/2” 25 9.59
B90L3/4 3/4” 25 12.98
B90L1 1” 20 19.96
B90L11/4 1-1/4” 10 31.75
B90L11/2 1-1/2” 5 39.67
B90L2 2” 5 64.50
B90L21/2 2 1/2” 1 126.62
B90L3 3” 1 194.23
B90L4 4” 1 647.40
90 º Elbow, Reducer fipt x fipt
B90L1/2X3/8 1/2” x 3/8” 25 10.42
B90L3/4X1/2 3/4” x 1/2” 25 14.16
B90L1x1/2 1” x 1/2” 25 24.87
B90L1X3/4 1” x 3/4” 25 24.87
B90L11/4X1 1 1/4” x 1” 10 38.84
45º Elbows, fipt x fipt
B45L1/8 1/8” 25 6.92
B45L1/4 1/4” 25 6.92
B45L3/8 3/8” 25 6.92
B45L1/2 1/2” 25 8.78
B45L3/4 3/4” 25 12.98
B45L1 1” 25 21.85
B45L11/4 1-1/4” 10 34.95
B45L11/2 1-1/2” 10 43.77
B45L2 2” 5 71.03
B45L21/2 2 1/2” 1 192.26
B45L3 3” 1 309.00
B45L4 4” 1 706.36
90 º Street Elbow, fipt x mipt
B90SL1/8 1/8” 25 9.59
B90SL1/4 1/4“ 25 9.59
B90SL3/8 3/8” 25 9.59
B90SL1/2 1/2” 25 11.95
B90SL3/4 3/4” 25 16.89
B90SL1 1” 10 27.89
B90SL11/4 1-1/4” 10 42.75
B90SL11/2 1-1/2” 10 55.60
B90SL2 2” 5 94.34
B90SL21/2 2 1/2” 1 206.02
B90SL3 3” 1 309.00
B90SL4 4” 1 927.13
B45L Series
B90L Series
B90SL Series
Threaded Bronze 125 lb. SIAM
• Dimension: ANSI B16.15, ASME B16.14, A-A-59617, MSS-SP-106
• Threads: ANSI/ASME B1.20.1
• Material: ASTM B62-93 (C83600)
• Imported. Manufactured for AGI in an ISO 9001 facility.
B90L Reducer Series
Part Number Ctn Qty List Price
90 º Elbow, fipt x fipt
TB90L1/8 50/600 $ 4.01
TB90L1/4 100/400 4.01
TB90L3/8 75/300 4.01
TB90L1/2 50/200 6.08
TB90L3/4 25/100 8.24
TB90L1 20/80 12.70
TB90L11/4 25/50 20.14
TB90L11/2 35 25.19
TB90L2 20 40.98
TB90L21/2 10 80.46
TB90L3 6 123.39
90 º Elbow, Reducer fipt x fipt
TB90L1/2X3/8 50/200 6.61
TB90L3/4X1/2 30/120 9.03
TB90L1x1/2 25/100 15.79
TB90L1X3/4 25/50 15.79
TB90L11/4X1 50 24.64
45º Elbows, fipt x fipt
TB45L1/8 50/600 4.39
TB45L1/4 120/480 4.39
TB45L3/8 50/300 4.39
TB45L1/2 50/200 5.58
TB45L3/4 25/100 8.24
TB45L1 90 13.90
TB45L11/4 50 22.19
TB45L11/2 40 27.81
TB45L2 25 45.10
90 º Street Elbow, fipt x mipt
TB90SL1/8 200/800 6.08
TB90SL1/4 100/400 6.08
TB90SL3/8 60/240 6.08
TB90SL1/2 50/200 7.60
TB90SL3/4 25/100 10.71
TB90SL1 20/60 17.69
TB90SL11/4 20/40 27.14
TB90SL11/2 35 35.32
TB90SL2 25 59.92
SIAM - THAILAND CHINA
Threaded Bronze 125 lb. CHINA
• Threads: ANSI B16.15 125S fittings
• Threads: ANSI B16.24 150S flanges
• Material: ASTM B584-C84400
ISO 9001
6/14/11
12.28
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Threaded Bronze Fittings
Part Number Size Ctn Qty List Price
45º Street Elbows, fipt x mipt
B45SL1/8 1/8” 25 $ 9.79
B45SL1/4 1/4” 25 9.79
B45SL3/8 3/8” 25 9.79
B45SL1/2 1/2” 25 11.95
B45SL3/4 3/4” 25 16.89
B45SL1 1” 10 27.89
B45SL11/4 1 1/4” 10 42.75
B45SL11/2 1 1/2” 5 57.28
B45SL2 2” 1 145.04
Tee, fipt x fipt x fipt
BT1/8 1/8” 25 8.78
BT1/4 1/4” 25 8.78
BT3/8 3/8” 25 8.78
BT1/2 1/2” 25 11.12
BT3/4 3/4” 25 15.91
BT1 1” 10 28.26
BT11/4 1-1/4” 5 39.67
BT11/2 1-1/2” 5 54.52
BT2 2” 5 89.42
BT21/2 2 1/2” 1 240.14
BT3 3’ 1 265.74
BT4 4” 1 882.76
Tee, Reducer fipt x fipt x fipt
BT3/4X1/2 3/4 x 3/4 x 1/2” 10 19.09
BT3/4X3/4X1/4 3/4 x 3/4 x 1/4” 25 20.97
BT3/4X1 3/4 x 3/4 x 1” 10 37.93
BT1X1/4 1 x 1 x 1/4” 10 37.92
BT1X1/2 1 x 1 x 1/2” 10 37.92
BT1X3/4 1 x 1 x 3/4” 10 34.70
BT1X3/4X3/4 1 x 3/4 x 3/4” 10 37.93
BT1X3/4X1 1 x 3/4 x 1” 10 37.91
BT11/4X3/4 1 1/4 x 1 1/4 x 3/4” 10 53.21
BT11/4X1 1 1/4 x 1 1/4 x 1” 5 49.04
BT11/2X3/4 1 1/2 x 1 1/2 x 3/4” 5 67.57
BT11/2X1 1 1/2 x 1 1/2 x 1” 5 67.57
BT11/2X11/4 1 1/2 x 1 1/2 x 11/4 5 67.57
BT2X3/4 2 x 2 x 3/4” 5 110.41
BT2X1 2 x 2 x 1” 5 110.41
BT2X11/2 2 x 2 x 1 1/2” 1 110.41
BT Series
BT Reducer Series
Part Number Ctn Qty List Price
45º Street Elbows, fipt x mipt
TB45SL1/8 50/600 $ 6.21
TB45SL1/4 35/420 6.21
TB45SL3/8 270 6.21
TB45SL1/2 100/20 7.60
TB45SL3/4 60/120 10.71
TB45SL1 30/60 17.69
TB45SL11/4 20/40 27.14
TB45SL11/2 15/30 36.41
TB45SL2 18 61.69
Tee, fipt x fipt x fipt
TBT1/8 75/450 5.58
TBT1/4 50/300 5.58
TBT3/8 45/180 5.58
TBT1/2 40/120 7.09
TBT3/4 35/70 10.08
TBT1 20/40 17.96
TBT11/4 14/28 25.19
TBT11/2 11/22 34.65
TBT2 6/12 56.77
TBT3 1/6 168.79
Tee, Reducer fipt x fipt x fipt
TBT3/4X1/2 45/90 12.12
TBT1X1/4 60 24.11
TBT1X1/2 35/70 24.11
TBT1X3/4 30/60 22.08
TBT1X3/4X3/4 65 24.11
TBT1X3/4X1 50 24.11
TBT11/4X3/4 18/36 33.80
TBT11/4X1 18/36 31.15
TBT11/2X3/4 15/30 42.90
TBT11/2X1 13/26 42.90
TBT11/2X11/4 13/26 42.90
TBT2X3/4 9/18 70.11
TBT2X1 9/18 70.11
TBT2X11/2 8/16 70.11
SIAM - THAILAND CHINA
B45SL Series
Threaded Bronze 125 lb. SIAM
• Dimension: ANSI B16.15, ASME B16.14, A-A-59617, MSS-SP-106
• Threads: ANSI/ASME B1.20.1
• Material: ASTM B62-93 (C83600)
• Imported. Manufactured for AGI in an ISO 9001 facility.
Threaded Bronze 125 lb. CHINA
• Threads: ANSI B16.15 125S fittings
• Threads: ANSI B16.24 150S flanges
• Material: ASTM B584-C84400
ISO 9001
6/14/11
12.29
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Threaded Bronze Fittings
Part Number Size Ctn Qty List Price
Cross, fipt
BCR1/8 1/8” 100 $ 21.93
BCR1/4 1/4” 275 21.93
BCR3/8 3/8” 125 21.93
BCR1/2 1/2” 25 26.64
BCR3/4 3/4” 10 25.81
BCR1 1” 5 40.89
BCR11/4 1 1/4” 1 64.04
BCR11/2 1 1/2” 8 84.96
BCR2 2” 1 170.40
Couplings, fipt x fipt
BC1/8 1/8“ 25 6.71
BC1/4 1/4” 25 6.71
BC3/8 3/8” 25 6.71
BC1/2 1/2” 25 8.41
BC3/4 3/4” 25 11.12
BC1 1” 25 16.86
BC11/4 1-1/4” 10 26.30
BC11/2 1-1/2” 10 35.72
BC2 2” 5 58.82
BC21/2 2 1/2” 1 127.30
BC3 3” 1 176.54
BC4 4” 1 338.50
Couplings, Reducing fipt x fipt
BC1/4X1/8 1/4 x1/8” 25 7.14
BC3/8X1/8 3/8 x 1/8” 25 6.59
BC3/8X1/4 3/8” x 1/4” 25 7.14
BC1/2X1/8 1/2” X 1/8” 100 10.77
BC1/2X1/4 1/2 x 1/4” 25 8.95
BC1/2X3/8 1/2 x 3/8” 25 8.95
BC3/4X1/4 3/4 x 1/4” 25 14.75
BC3/4X3/8 3/4” X 3/8” 50 14.43
BC3/4X1/2 3/4 x 1/2” 25 13.27
BC1X3/8 1” X 3/8” 25 22.11
BC1X1/2 1 x 1/2” 25 22.11
BC1X3/4 1 x 3/4” 25 22.11
BC11/4X1/2 1-1/4 x 1/2” 10 39.44
BC11/4X3/4 1-1/4 x 3/4” 10 35.72
BC11/4X1 1-1/4 x 1” 10 35.72
BC11/2X1/2 1 1/2” X 1/2” 35 64.49
BC11/2X3/4 11/2” x 3/4” 10 50.87
BC11/2X1 1-1/2 x 1” 10 45.17
BC11/2X11/4 1-1/2 x 1-1/4” 10 45.17
BC2X1/2 2” X 1/2” 25 96.71
BC2X3/4 2” X 3/4” 15 96.71
BC2X1 2 x 1” 10 75.62
BC2X11/4 2 x 1-1/4” 10 67.19
BC2X11/2 2 x 1-1/2” 5 67.19
Case quantities
required
please for fittings
through 2”
BC Reducer Series
BC Series
BCR Series
Part Number Ctn Qty List Price
Cross, fipt
TBCR1/8 180 $ 11.36
TBCR1/4 80 11.36
TBCR3/8 30/60 11.36
TBCR1/2 45 11.36
TBCR3/4 30/60 16.38
TBCR1 40 35.97
TBCR11/4 24 40.67
TBCR2 5/10 108.24
Couplings, fipt x fipt
TBC1/8 60/720 4.26
TBC1/4 150/600 4.26
TBC3/8 100/400 4.26
TBC1/2 50/200 5.37
TBC3/4 25/100 7.09
TBC1 100 10.68
TBC11/4 75 16.70
TBC11/2 50 22.69
TBC2 30 37.37
Couplings, Reducing fipt x fipt
TBC1/4X1/8 35/420 4.58
TBC3/8X1/8 30/360 4.58
TBC3/8X1/4 30/360 4.58
TBC1/2X1/8 70/280 5.67
TBC1/2X1/4 75/300 5.67
TBC1/2X3/8 40/240 5.67
TBC3/4X1/4 50/200 9.35
TBC3/4X3/8 30/180 8.44
TBC3/4X1/2 45/180 8.44
TBC1X1/2 30/120 14.05
TBC1X3/4 25/100 14.05
TBC11/4X1/2 25/75 25.07
TBC11/4X3/4 90 22.69
TBC11/4X1 80 22.69
TBC11/2X1/2 20/60 32.32
TBC11/2X3/4 30/90 32.32
TBC11/2X1 65 28.69
TBC11/2X11/4 60 28.69
TBC2X1/2 40 48.01
TBC2X3/4 40 48.01
TBC2X1 40 48.01
TBC2X11/4 40 42.65
TBC2X11/2 35 42.65
SIAM - THAILAND CHINA
Threaded Bronze 125 lb. SIAM
• Dimension: ANSI B16.15, ASME B16.14, A-A-59617, MSS-SP-106
• Threads: ANSI/ASME B1.20.1
• Material: ASTM B62-93 (C83600)
• Imported. Manufactured for AGI in an ISO 9001 facility.
Threaded Bronze 125 lb. CHINA
• Threads: ANSI B16.15 125S fittings
• Threads: ANSI B16.24 150S flanges
• Material: ASTM B584-C84400
ISO 9001
6/14/11
12.30
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Threaded Bronze Fittings
BCP Series
Part Number Size Ctn Qty List Price
Bushing, mipt x fipt
BB1/4X1/8 1/4 x 1/8” 25 5.72
BB3/8X1/8 3/8x 1/8” 25 6.61
BB3/8X1/4 3/8 x 1/4” 25 6.83
BB1/2x1/8 1/2” x 1/8” 25 6.34
BB1/2X1/4 1/2 x 1/4” 25 5.34
BB1/2X3/8 1/2 x 3/8” 25 5.34
BB3/4X1/8 3/4 x 1/8” 25 8.88
BB3/4X1/4 3/4 x 1/4” 25 8.88
BB3/4X3/8 3/4 x 3/8” 25 7.32
BB3/4X1/2 3/4 x 1/2” 25 7.32
BB1X1/4 1 x 1/4” 25 13.51
BB1X3/8 1” X 3/8” 125 13.51
BB1X1/2 1 x 1/2” 25 11.12
BB1X3/4 1 x 3/4” 25 11.12
BB11/4X1/4 1-1/4 x 1/4” 25 22.72
BB11/4X3/8 1 1/4” X 3/8” 25 29.43
BB11/4X1/2 1 1/4” x 1/2” 25 22.72
BB11/4X3/4 1-1/4 x 3/4” 25 18.93
BB11/4X1 1-1/4 x 1” 25 18.93
BB11/2X1/2 1-1/2 x 1/2” 25 29.52
BB11/2X3/4 1-1/2 x 3/4” 25 29.52
BB11/2X1 1-/2 x 1” 25 24.16
BB11/2X11/4 1-1/2 x 1-1/4” 25 24.16
BB2X1/2 2 X 1/2” 10 43.05
BB2X3/4 2 x 3/4” 10 43.05
BB2X1 2 x 1” 10 43.05
BB2X11/4 2 x 1-1/4” 10 35.72
BB2X11/2 2 x 1-1/2” 10 35.72
BB21/2X1 2 1/2” X 1 5 109.95
BB21/2X11/4 2 1/2” X 1 1/4” 5 109.95
BB21/2X11/2 2 1/2” X 1 1/2” 5 109.94
BB21/2X2 2-1/2 x 2” 5 71.48
BB3X1 3” X 1” 5 321.23
BB3X2 3 x 2” 5 108.10
Caps, fipt
BCP1/8 1/8” 25 5.02
BCP1/4 1/4” 25 5.02
BCP3/8 3/8” 25 5.02
BCP1/2 1/2” 25 6.71
BCP3/4 3/4” 25 8.88
BCP1 1” 25 13.77
BCP11/4 1-1/4” 25 21.07
BCP11/2 1-1/2” 10 28.43
BCP2 2” 10 48.26
BCP21/2 2 1/2” 5 120.02
BCP3 3” 1 191.41
BCP4 4” 1 281.71
Part Number Ctn Qty List Price
Bushing, mipt x fipt
TBB1/4X1/8 240/1440 $ 3.37
TBB3/8X1/8 100/600 3.37
TBB3/8X1/4 100/600 3.37
TBB1/2X1/8 150/600 4.05
TBB1/2X1/4 100/600 3.37
TBB1/2X3/8 100/600 3.37
TBB3/4X1/8 50/300 5.61
TBB3/4X1/4 50/300 5.61
TBB3/4X3/8 50/300 4.67
TBB3/4X1/2 50/300 4.67
TBB1X1/4 50/200 8.55
TBB1X3/8 200 8.55
TBB1X1/2 50/200 7.09
TBB1X3/4 50/200 7.09
TBB11/4X1/4 30/120 14.45
TBB11/4X1/2 30/120 14.45
TBB11/4X3/4 30/120 12.01
TBB11/4X1 30/120 12.01
TBB11/2X1/2 25/75 18.75
TBB11/2X3/4 25/75 18.75
TBB11/2X1 25/75 15.34
TBB11/2X11/4 25/75 15.34
TBB2X1/2 60 27.33
TBB2X3/4 20/60 27.33
TBB2X1 20/60 27.33
TBB2X11/4 20/60 22.69
TBB2X11/2 20/60 22.69
TBB21/2X2 1/32 45.39
TBB3X1 1/20 79.95
TBB3X2 1/20 68.67
Caps, fipt
TBCP1/8 100/1200 3.17
TBCP1/4 200/800 3.17
TBCP3/8 50/600 3.17
TBCP1/2 50/300 4.26
TBCP3/4 40/240 5.61
TBCP1 35/140 8.77
TBCP11/4 25/100 13.36
TBCP11/2 25/75 18.07
TBCP2 18/54 30.64
SIAM - THAILAND CHINA
BB Series
Threaded Bronze 125 lb. SIAM
• Dimension: ANSI B16.15, ASME B16.14, A-A-59617, MSS-SP-106
• Threads: ANSI/ASME B1.20.1
• Material: ASTM B62-93 (C83600)
• Imported. Manufactured for AGI in an ISO 9001 facility.
Threaded Bronze 125 lb. CHINA
• Threads: ANSI B16.15 125S fittings
• Threads: ANSI B16.24 150S flanges
• Material: ASTM B584-C84400
ISO 9001
6/14/11
12.31
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Threaded Bronze Fittings
BP Series
BU Series
BLN Series
Part Number Size Ctn Qty List Price
Lock Nut
BLN1/8 1/8” 25 $ 3.49
BLN1/4 1/4” 25 3.49
BLN3/8 3/8” 25 3.49
BLN1/2 1/2” 25 5.34
BLN3/4 3/4” 25 6.34
BLN1 1” 25 9.43
BLN11/4 1 1/4” 25 15.36
BLN11/2 1 1/2” 25 19.91
BLN2 2” 10 31.65
Square Head Plug, mipt
BP1/8 1/8” 25 6.23
BP1/4 1/4” 25 5.77
BP3/8 3/8” 25 7.06
BP1/2 1/2” 25 6.64
BP3/4 3/4” 25 7.56
BP1 1” 25 9.97
BP11/4 1-1/4” 25 14.88
BP11/2 1-1/2” 25 18.97
BP2 2” 10 29.83
BP21/2 2 1/2” 5 70.73
BP3 3” 5 81.82
BP4 4” 1 220.72
Threaded Union, fipt x fipt
BU1/8 1/8” 25 26.52
BU1/4 1/4” 25 22.42
BU3/8 3/8” 25 22.42
BU1/2 1/2” 25 24.43
BU3/4 3/4” 25 33.78
BU1 1” 10 44.73
BU11/4 1-1/4” 5 65.49
BU11/2 1-1/2” 5 77.41
BU2 2” 1 119.13
BU21/2 2 1/2” 1 323.78
BU3 3” 1 361.96
BU4 4” 1 1103.60
SIAM - THAILAND CHINA
Part Number Ctn Qty List Price
Lock Nut
TBLN1/8 100/600 $ 2.18
TBLN1/4 100/400 2.18
TBLN3/8 500/1000 2.18
TBLN1/2 100/600 3.37
TBLN3/4 50/300 4.05
TBLN1 60/240 5.98
TBLN11/4 30/120 9.73
TBLN11/2 25/100 12.65
TBLN2 30/90 20.11
Square Head Plug, mipt
TBP1/8 900/3600 3.68
TBP1/4 500/2000 3.68
TBP3/8 45/540 3.68
TBP1/2 150/600 4.24
TBP3/4 100/400 4.81
TBP1 50/200 6.32
TBP11/4 35/140 9.46
TBP11/2 30/120 12.01
TBP2 100 18.97
TBP3 30 50.19
Threaded Union, fipt x fipt
TBU1/8 30/180 14.27
TBU1/4 60/240 14.27
TBU3/8 35/140 14.27
TBU1/2 25/100 15.50
TBU3/4 20/80 21.46
TBU1 35/70 28.42
TBU11/4 35 41.61
TBU11/2 25 49.15
TBU2 18 75.68
TBU3 8 229.91
Threaded Bronze 125 lb. SIAM
• Dimension: ANSI B16.15, ASME B16.14, A-A-59617, MSS-SP-106
• Threads: ANSI/ASME B1.20.1
• Material: ASTM B62-93 (C83600)
• Imported. Manufactured for AGI in an ISO 9001 facility.
Threaded Bronze 125 lb. CHINA
• Threads: ANSI B16.15 125S fittings
• Threads: ANSI B16.24 150S flanges
• Material: ASTM B584-C84400
ISO 9001
6/14/11
12.32
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Threaded Bronze Fittings - Chrome Plated
CP45L Series
CP90L Series
CP90SL Series
Part Number Size Ctn Qty List Price
90 º Elbow, fipt x fipt
CP90L3/8 3/8” 25 $ 44.93
CP90L1/2 1/2” 25 44.93
CP90L3/4 3/4” 25 60.11
CP90L1 1” 25 97.77
45º Elbows, fipt x fipt
CP45L3/8 3/8” 25 55.24
CP45L1/2 1/2” 25 55.24
CP45L3/4 3/4” 25 78.43
CP45L1 1” 25 133.81
90 º Street Elbow, fipt x mipt
CP90SL3/8 3/8” 25 60.11
CP90SL1/2 1/2” 25 60.11
CP90SL3/4 3/4” 25 82.73
CP90SL1 1” 10 135.35
Tee, fipt x fipt x fipt
CPT3/8 3/8” 25 52.78
CPT1/2 1/2” 25 52.78
CPT3/4 3/4” 25 75.01
CPT1 1” 10 135.35
Couplings, fipt x fipt
CPC3/8 3/8” 25 37.59
CPC1/2 1/2” 25 37.59
CPC3/4 3/4” 25 52.78
CPC1 1” 25 90.02
CPT Series
CPC Series
ISO 9001
Threaded Bronze 125 lb. SIAM
• Dimension: ANSI B16.15, ASME B16.14, A-A-59617, MSS-SP-106
• Threads: ANSI/ASME B1.20.1
• Material: ASTM B62-93 (C83600)
• Imported. Manufactured for AGI in an ISO 9001 facility.
6/14/11
12.33
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Malleable Iron Fittings - Imported
Inner/Master List
Size Ctn Qty Price
90º ELBOW fiptxfipt
BIM90L1/8 50/600 $ 2.05
BIM90L1/4 35/420 1.94
BIM90L3/8 45/270 1.94
BIM90L1/2 UF 50/200 1.46
BIM90L3/4 UF 30/90 2.21
BIM90L1 UF 20/60 3.12
BIM90L11/4 UF 20/40 5.07
BIM90L11/2 UF 10/20 6.64
BIM90L2 UF 8/16 11.40
BIM90L21/2 UF 1/15 24.79
BIM90L3 UF 1/10 37.00
BIM90L4 UF 1/5 78.62
90º ELBOW REDUCER fiptxfipt
BIM90L3/8X1/8 60/360 4.06
BIM90L3/8X1/4 60/360 2.56
BIM90L1/4X1/8 60/360 3.50
BIM90L1/2X1/8 40/240 2.51
BIM90L1/2X1/4 UF 40/240 2.51
BIM90L1/2x3/8 UF 50/200 2.40
BIM90L3/4x1/2 40/120 2.52
BIM90L3/4X1/4 UF 50/150 3.34
BIM90L3/4X3/8 UF 50/150 3.34
BIM90L1X1/4 UF 30/90 5.27
BIM90L1X3/8 UF 30/90 5.27
BIM90L1X3/4 UF 30/90 3.23
BIM90L11/4X1/2 UF 30/60 6.97
BIM90L11/4x1 UF 20/40 5.27
BIM90L11/4X3/4 UF 30/60 5.96
BIM90L11/2x1 UF 20/40 8.62
BIM90L11/2x11/4 UF 15/30 8.62
BIM90L2x1 UF 14/28 12.43
BIM90L2x11/4 UF 10/20 12.43
BIM90L2x11/2 UF 10/20 10.92
BIM90L21/2X3/4 F9/18 30.51
BIM90L21/2X1 F1/16 30.51
BIM90L21/2X11/4 F1/15 30.51
BIM90L21/2X11/2 UF 1/15 30.51
BIM90L21/2X2 UF 1/15 30.00
BIM90L3X2 UF 1/10 48.46
Inner/Master List
Size Ctn Qty Price
90º ELBOW fiptxfipt
GIM90L1/8 50/600 $ 2.87
GIM90L1/4 35/420 2.73
GIM90L3/8 45/270 2.73
GIM90L1/2 UF 50/200 1.84
GIM90L3/4 UF 30/90 2.24
GIM90L1 UF 20/60 4.07
GIM90L11/4 UF 20/40 6.25
GIM90L11/2 UF 10/20 8.25
GIM90L2 UF 8/16 13.73
GIM90L21/2 UF 1/15 34.18
GIM90L3 UF 1/10 57.43
GIM90L4 UF 1/5 99.47
90º ELBOW REDUCER fiptxfipt
GIM90L3/8X1/8 60/360 5.24
GIM90L3/8X1/4 60/360 3.70
GIM90L1/4X1/8 60/360 4.15
GIM90L1/2X1/8 40/240 3.45
GIM90L1/2X1/4 UF 40/240 3.45
GIM90L1/2 x 3/8 UF 50/200 3.45
GIM90L3/4 x 1/2 UF 40/120 3.34
GIM90L3/4X1/4 UF 50/150 4.40
GIM90L3/4X3/8 UF 50/150 4.40
GIM90L1X1/4 UF 30/90 6.93
GIM90L1X3/8 UF 30/90 6.93
GIM90L1 x 3/4 UF 30/90 4.27
GIM90L11/4 x 1 UF 20/40 7.10
GIM90L11/2 x 1 UF 20/40 10.94
GIM90L11/2 x 11/4 UF 15/30 10.94
GIM90L2 x 1 UF 14/28 15.21
GIM90L2 x 11/4 UF 10/20 15.21
GIM90L2 x 11/2 UF 10/20 13.27
GIM90L21/2X3/4 F9/18 48.63
GIM90L21/2X1 F1/16 48.63
GIM90L21/2X11/4 F1/15 48.63
GIM90L21/2X11/2 UF 1/15 48.63
GIM90L21/2X2 UF 1/15 43.31
GIM90L3X2 UF 1/10 68.40
BLACK GALVANIZED
Specifications:
Material: ANSI/ASTM A197
Dimensions: ANSI B.16.3 fittings
ASME/ANSI B.16.39 unions
Threads: ASME/ANSI B.1.20.1
Imported Malleable Iron Fitting Features:
• Class 150 malleable iron pipe fittings
• Suitable for water, steam, air, gas and oil
• All fittings are air pressure tested
• Working pressure: Max: 300 psi @ -20°F to 150°F. , Min 150 psi @
350°F
• Made in China
• Tensile Strength:Min 48000 psi (330 MPa)
• Elongation: Min 8%
BIM90L/GIM90L Series
BIM90L/GIM90L
Reducer Series
ISO 9002
U- UL Approval
F- FM Approval
All class 150 imported malleable iron pipe fittings are manufactured under a
quality control program complying with CSA B-51 speccifications.
Canadian Registration Number OA5312.5C
Galvanized ONLY: NSF 61-4 Listed by IAPMO R&T. Meets CA AB1953
6/14/11
12.34
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Malleable Iron Fittings - Imported
BLACK
Inner/Master List
Size Ctn Qty Price
45º ELBOW fiptxfipt
BIM45L1/8 50/600 $ 2.96
BIM45L1/4 35/420 3.06
BIM45L3/8 50/300 2.79
BIM45L1/2 UF 50/200 2.40
BIM45L3/4 UF 40/120 2.93
BIM45L1 UF 20/60 3.74
BIM45L11/4 UF 20/40 6.52
BIM45L11/2 UF 15/30 8.07
BIM45L2 UF 9/18 12.12
BIM45L21/2 UF 1/15 34.20
BIM45L3 UF 1/10 44.44
BIM45L4 UF 1/6 86.27
90º STREET ELBOW fiptxmipt
BIM90SL1/8 50/600 2.96
BIM90SL1/4 35/420 2.96
BIM90SL3/8 40/240 2.96
BIM90SL1/2 UF 60/180 3.07
BIM90SL3/4 UF 30/90 2.96
BIM90SL1 UF 30/60 4.29
BIM90SL11/4 UF 20/40 6.52
BIM90SL11/2 UF 13/26 8.73
BIM90SL2 UF 7/14 14.09
BIM90SL21/2 UF 1/13 34.83
BIM90SL3 UF 1/8 53.14
45º STREET ELBOW fiptxmipt
BIM45SL1/8 50/600 4.62
BIM45SL1/4 35/420 3.45
BIM45SL3/8 45/270 3.91
BIM45SL1/2 UF 100/200 3.12
BIM45SL3/4 UF 60/120 4.85
BIM45SL1 UF 30/60 5.61
BIM45SL11/4 UF 20/40 9.67
BIM45SL11/2 UF 15/30 12.00
TEE fiptxfiptxfipt
BIMT1/8 75/450 3.12
BIMT1/4 50/300 2.95
BIMT3/8 UF 45/180 2.95
BIMT1/2 UF 40/120 1.93
BIMT3/4 UF 35/70 2.69
BIMT1 UF 20/40 4.80
BIMT11/4 UF 14/28 7.75
BIMT11/2 UF 11/22 9.67
BIMT2 UF 6/12 16.44
BIMT21/2 UF 1/10 33.79
BIMT3 UF 1/6 50.76
BIMT4 UF 1/4 119.12
Inner/Master List
Size Ctn Qty Price
45º ELBOW fiptxfipt
GIM45L1/8 50/600 $ 4.11
GIM45L1/4 35/420 3.65
GIM45L3/8 50/300 3.59
GIM45L1/2 UF 50/200 2.81
GIM45L3/4 UF 40/120 3.93
GIM45L1 UF 20/60 4.49
GIM45L11/4 UF 20/40 8.19
GIM45L11/2 UF 15/30 9.76
GIM45L2 UF 9/18 14.59
GIM45L21/2 UF 1/15 49.37
GIM45L3 UF 1/10 71.74
GIM45L4 UF 1/6 120.29
90º STREET ELBOW fiptxmipt
GIM90SL1/8 50/600 3.90
GIM90SL1/4 35/420 3.75
GIM90SL3/8 40/240 3.75
GIM90SL1/2 UF 60/180 3.84
GIM90SL3/4 UF 35/90 3.75
GIM90SL1 UF 30/60 5.11
GIM90SL11/4 UF 20/40 8.58
GIM90SL11/2 UF 13/26 10.53
GIM90SL2 UF 7/14 18.26
GIM90SL21/2 UF 1/13 49.53
GIM90SL3 UF 1/8 74.77
45º STREET ELBOW fiptxmipt
GIM45SL1/8 50/600 5.37
GIM45SL1/4 35/420 4.58
GIM45SL3/8 45/270 5.22
GIM45SL1/2 UF 100/200 4.00
GIM45SL3/4 UF 60/120 6.54
GIM45SL1 UF 30/60 8.07
GIM45SL11/4 UF 20/40 12.15
GIM45SL11/2 UF 15/30 14.67
TEE fiptxfiptxfipt
GIMT1/8 75/450 4.07
GIMT1/4 50/300 3.54
GIMT3/8 45/180 3.54
GIMT1/2 UF 40/120 2.17
GIMT3/4 UF 35/70 3.67
GIMT1 UF 20/40 5.98
GIMT11/4UF 14/28 9.48
GIMT11/2 UF 11/22 11.84
GIMT2 UF 6/12 19.76
GIMT21/2 UF 1/10 53.03
GIMT3 UF 1/6 62.20
GIMT4 UF 1/4 147.06
BIM45L/GIM45L
Series
BIM90SL/GIM90SL
Series
BIM45SL/GIM45SL
Series
BIMT/GIMT Series
Carton Quantities subject to change. Contact Customer Service
U- UL Approval
F- FM Approval
GALVANIZED
6/14/11
12.35
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Malleable Iron Fittings - Imported
BLACK
Inner/Master List
Size Ctn Qty Price
TEE REDUCER fiptxfiptxfipt
BIMT1/2X1/2X3/8 UF 45/180 $ 3.73
BIMT3/4x1/2x1/2 UF 45/90 3.94
BIMT3/4X1/2x3/4 UF 45/90 4.33
BIMT3/4X3/4X1/4 UF 50/100 4.18
BIMT3/4x3/4x1/2 UF 45/90 3.51
BIMT3/4X3/4X1 UF 25/50 3.79
BIMT1X1/2X1/2 UF 30/60 6.43
BIMT1X1/2X3/4 UF 25/50 6.43
BIMT1X1/2X1 UF 30/60 5.52
BIMT1X3/4X1/2 UF 25/50 5.48
BIMT1x3/4x3/4 UF 25/50 5.10
BIMT1x3/4x1 UF 25/50 5.52
BIMT1x1x1/2 UF 35/70 4.85
BIMT1x1x3/4 UF 30/60 4.85
BIMT1X1X11/4 UF 18/36 10.24
BIMT11/4X1/2X11/4 UF 10/40 10.02
BIMT11/4X3/4X3/4 UF 20/40 10.02
BIMT11/4X3/4X1 UF 18/36 9.39
BIMT11/4x3/4x11/4 UF 18/36 9.15
BIMT11/4X1X1/2 UF 18/36 9.74
BIMT11/4X1X3/4 UF 18/36 8.83
BIMT11/4X1X1 UF 20/40 8.83
BIMT11/4X11/4X1/2 UF 20/40 8.77
BIMT11/4x11/4x3/4 UF 18/36 7.69
BIMT11/4x11/4x1 UF 18/36 7.69
BIMT11/4x1x11/4 UF 18/36 10.24
BIMT11/2X1/2X11/2 UF 13/26 11.99
BIMT11/2X3/4X3/4 F13/26 19.12
BIMT11/2X3/4X11/4 F11/22 9.13
BIMT11/2X3/4X11/2 UF 13/26 11.99
BIMT11/2X1X3/4 F18/36 11.97
BIMT11/2X1X1 UF 15/30 11.97
BIMT11/2X1X11/2 UF 13/26 11.99
BIMT11/2X11/4X3/4 UF 11/22 11.99
BIMT11/2X11/4X1 UF 11/22 10.30
BIMT11/2X11/4X11/4 UF 11/22 16.20
BIMT11/2X11/2X1/2 UF 20/40 10.26
BIMT11/2x11/2x3/4 UF 15/30 9.74
BIMT11/2x11/2x1 UF 13/26 9.74
BIMT11/2X11/2X11/4 UF 13/26 11.78
BIMT2X1/2X2 UF 10/20 18.75
BIMT2X3/4X3/4 9/18 18.40
BIMT2X3/4X2 UF 9/18 18.40
BIMT2X1X2 UF 9/18 18.75
BIMT2X11/2X11/4 UF 8/16 18.75
BIMT2X11/2X11/2 UF 8/16 18.40
BIMT2X11/2X2 UF 8/16 18.75
BIMT2X2X1/2 UF 10/20 15.20
BIMT2X2X1 UF 9/18 15.20
BIMT2X2X11/4 UF 9/18 16.07
BIMT2X2X11/2 UF 9/18 16.07
Inner/Master List
Size Ctn Qty Price
TEE REDUCER fiptxfiptxfipt
GIMT1/2X1/2X3/8 45/180 $ 4.50
GIMT3/4x1/2x1/2 UF 45/90 5.24
GIMT3/4X3/4X1/4 UF 45/90 4.77
GIMT3/4x3/4x1/2 UF 50/100 4.62
GIMT3/4x1/2x3/4 UF 45/90 5.24
GIMT3/4X3/4X1 UF 25/50 7.99
GIMT1X1/2X3/4 UF 25/50 7.97
GIMT1X1/2X1 UF 30/60 5.54
GIMT1X3/4X1/2 UF 25/50 5.54
GIMT1x3/4x3/4 UF 25/50 7.78
GIMT1x3/4x1 UF 25/50 7.78
GIMT1x1x1/2 UF 35/70 6.46
GIMT1x1x3/4 UF 30/60 6.46
GIMT1X1X11/4 UF 18/36 12.41
GIMT11/4X1/2X11/4 UF 10/40 8.36
GIMT11/4X3/4X3/4 UF 20/40 8.36
GIMT11/4x3/4x1 UF 18/36 12.72
GIMT11/4x3/4x11/4 UF 18/36 11.48
GIMT11/4X1X1/2 UF 18/36 12.13
GIMT11/4X1X3/4 UF 18/36 12.16
GIMT11/4X1X1 UF 20/40 8.36
GIMT11/4x11/4x3/4 UF 18/36 10.02
GIMT11/4x11/4x1 UF 18/36 10.02
GIMT11/4x1x11/4 UF 18/36 12.41
GIMT11/2X1/2X11/2 UF 13/26 16.82
GIMT11/2X3/4X3/4 F13/26 22.18
GIMT11/2X3/4X11/4 F11/22 10.55
GIMT11/2X3/4X11/2 UF 13/26 15.31
GIMT11/2X1X3/4 F18/36 10.55
GIMT11/2X1X1 UF 15/30 10.55
GIMT11/2X1X11/2 UF 13/26 15.31
GIMT11/2X11/4X3/4 UF 11/22 15.31
GIMT11/2X11/4X1 UF 11/22 15.00
GIMT11/2X11/4X11/4 UF 11/22 21.37
GIMT11/2X11/2X1/2 UF 20/40 10.55
GIMT11/2x11/2x3/4 UF 15/30 12.41
GIMT11/2x11/2x1 UF 13/26 12.41
GIMT11/2X11/2X11/4 UF 13/26 10.55
GIMT2X1/2X2 UF 10/20 21.63
GIMT2X3/4X3/4 9/18 21.22
GIMT2X3/4X2 UF 9/18 21.22
GIMT2X1X2 UF 9/18 21.63
GIMT2X11/2X11/4 UF 8/16 21.63
GIMT2X11/2X11/2 UF 8/16 21.22
GIMT2X11/2X2 UF 8/16 21.63
GIMT2X2X1 UF 9/18 17.96
GIMT2X2X11/4 UF 9/18 21.10
GIMT2X2X11/2 UF 9/18 21.10
BIMT/GIMT
Reducer Series
U- UL Approval
F- FM Approval
GALVANIZED
6/14/11
12.36
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Malleable Iron Fittings - Imported
BLACK
Inner/Master List
Size Ctn Qty Price
BIMT21/2X21/2X1 UF 1/10 $39.90
BIMT21/2X21/2X11/2 UF 1/10 39.90
BIMT21/2X21/2X2 UF 1/10 39.97
BIMT3X3X3/4 UF 1/12 54.38
BIMT3X3X1 UF 1/12 53.40
BIMT3X3X11/4 UF 1/12 54.38
BIMT3X3X11/2 UF 1/12 53.40
BIMT3X3X2 UF 1/6 53.40
BIMT3X3X21/2 UF 1/6 61.03
street TEE fiptxfiptxmipt
BIMST1/2 UF 25/150 4.89
BIMST3/4 UF 25/100 6.52
BIMST1 UF 20/60 8.91
BIMST11/4 UF 20/40 18.25
CROSS fipt
BIMCR1/8 60/180 7.10
BIMCR1/4 80/240 6.03
BIMCR3/8 60/120 6.16
BIMCR1/2 UF 45/90 6.97
BIMCR3/4 UF 30/60 8.49
BIMCR1 UF 16/32 10.49
BIMCR11/4 UF 9/18 17.02
BIMCR11/2 UF 8/16 21.05
BIMCR2 UF 5/10 34.83
BIMCR21/2 UF 1/6 61.48
BIMCR3 UF 1/4 91.66
BIMCR4 UF 1/2 187.10
Right Hand Coupling fiptxfipt
BIMRHC1/4 40/480 2.49
BIMRHC3/8 50/300 2.49
BIMRHC1/2 UF 60/240 1.99
BIMRHC3/4 UF 50/150 2.31
BIMRHC1 UF 25/75 3.52
BIMRHC11/4 UF 32/64 4.55
BIMRHC11/2 UF 18/36 6.07
BIMRHC2 UF 12/24 8.86
BIMRHC21/2 UF 1/16 24.11
BIMRHC3 UF 1/12 32.59
BIMRHC4 UF 1/7 65.01
Inner/Master List
Size Ctn Qty Price
GIMT21/2X21/2X1 UF 1/10 $30.78
GIMT21/2X21/2X11/2 UF 1/10 30.78
GIMT21/2X21/2X2 UF 1/10 57.56
GIMT3X3X3/4 UF 1/12 81.60
GIMT3X3X1 UF 1/12 78.08
GIMT3X3X11/4 UF 1/12 79.61
GIMT3X3X11/2 UF 1/12 78.08
GIMT3X3X2 UF 1/6 78.08
GIMT3X3X21/2 UF 1/6 87.71
street TEE fiptxfiptxmipt
GIMST1/2 UF 25/150 6.97
GIMST3/4 UF 25/100 7.62
GIMST1 UF 20/60 12.10
GIMST11/4 UF 20/40 25.01
CROSS fipt
GIMCR1/8 60/180 9.05
GIMCR1/4 80/240 9.05
GIMCR3/8 60/120 9.05
GIMCR1/2 UF 45/90 9.07
GIMCR3/4 UF 30/60 11.07
GIMCR1 UF 16/32 15.25
GIMCR11/4 UF 9/18 22.10
GIMCR11/2 UF 8/16 26.84
GIMCR2 UF 5/10 51.15
GIMCR21/2 UF 1/6 97.60
GIMCR3 UF 1/4 131.48
GIMCR4 UF 1/2 265.63
Right Hand Coupling fiptxfipt
GIMRHC1/4 40/480 3.18
GIMRHC3/8 50/300 3.18
GIMRHC1/2 UF 60/240 2.56
GIMRHC3/4 UF 50/150 2.94
GIMRHC1 UF 25/75 4.85
GIMRHC11/4 UF 32/64 6.60
GIMRHC11/2 UF 18/36 7.55
GIMRHC2 UF 12/24 11.07
GIMRHC21/2 UF 1/16 33.74
GIMRHC3 UF 1/12 45.10
GIMRHC4 UF 1/7 95.79
BIMRHC/GIMRHC
Series
BIMCR/GIMCR Series
BIMST/GIMST
Reducer Series
U- UL Approval
F- FM Approval
BIMT/GIMT
Reducer Series
GALVANIZED
6/14/11
12.37
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Malleable Iron Fittings - Imported
BLACK
Inner/Master List
Size Ctn Qty Price
REDUCING COUPLING fiptxfipt
BIMRC1/4 x 1/8 35/420 $ 2.18
BIMRC3/8 x 1/4 30/360 2.18
BIMRC1/2 x 1/4 U50/300 1.94
BIMRC1/2 x 3/8 UF 40/240 1.87
BIMRC3/4X1/4 U30/180 2.47
BIMRC3/4 x 3/8 UF 30/180 2.47
BIMRC3/4 x 1/2 UF 60/180 2.10
BIMRC1X3/8 UF 40/120 3.88
BIMRC1 x 1/2 UF 25/100 3.30
BIMRC1 x 3/4 UF 25/100 3.30
BIMRC11/4 x 1/2 UF 25/75 4.78
BIMRC11/4 x 3/4 UF 25/75 4.15
BIMRC11/4 x 1 UF 20/60 4.15
BIMRC11/2 x 3/4 UF 30/60 6.85
BIMRC11/2 x 1 UF 25/50 6.07
BIMRC11/2 x 11/4 UF 24/48 5.22
BIMRC2 x 1/2 UF 21/42 9.88
BIMRC2 x 3/4 UF 21/42 8.69
BIMRC2 x 1 UF 21/42 8.22
BIMRC2 x 11/4 UF 18/36 8.69
BIMRC2 x 11/2 UF 18/36 7.58
BIMRC21/2X11/2 UF 1/16 22.62
BIMRC21/2X2 UF 1/20 19.38
BIMRC3X1 1/12 30.79
BIMRC3X11/4 1/12 30.79
BIMRC3X11/2 UF 1/12 30.22
BIMRC3X2 UF 1/12 25.09
BIMRC3X21/2 UF 1/12 30.22
BIMRC4X2 UF 1/9 60.57
BIMRC4X3 UF 1/8 60.57
HEX BUSHING miptxfipt
BIMHB1/4X1/8 100/1200 2.64
BIMHB3/8x1/4 100/600 2.64
BIMHB1/2x1/8 U150/600 2.64
BIMHB1/2x1/4 UF 100/600 2.64
BIMHB1/2x3/8 UF 100/600 2.64
BIMHB3/4X1/8 U50/300 2.57
BIMHB3/4x1/4 U50/300 2.54
BIMHB3/4x3/8 UF 50/300 2.57
BIMHB3/4x1/2 UF 50/300 2.40
BIMHB1X1/8 U50/200 2.96
BIMHB1X1/4 U50/200 3.21
BIMHB1X3/8 U50/200 3.26
BIMHB1x1/2 UF 50/200 2.49
BIMHB1x3/4 UF 50/200 2.49
BIMHB11/4X1/4 U30/120 4.13
BIMHB11/4X3/8 U30/120 3.66
BIMHB11/4x1/2 UF 30/120 3.51
BIMHB11/4x3/4 UF 30/120 3.19
BIMHB11/4x1 UF 30/120 3.19
Inner/Master List
Size Ctn Qty Price
REDUCING COUPLING fiptxfipt
GIMRC1/4 x 1/8 35/240 $ 2.71
GIMRC3/8 x 1/4 30/360 2.71
GIMRC1/2 x 1/4 U50/300 2.44
GIMRC1/2 x 3/8 UF 40/240 2.31
GIMRC3/4X1/4 U30/180 3.06
GIMRC3/4 x 3/8 UF 30/180 3.06
GIMRC3/4 x 1/2 UF 60/180 2.71
GIMRC1X3/8 UF 40/120 5.52
GIMRC1 x 1/2 UF 25/100 4.50
GIMRC1 x 3/4 UF 25/100 4.15
GIMRC11/4 x 1/2 UF 25/75 7.08
GIMRC11/4 x 3/4 UF 25/75 5.73
GIMRC11/4 x 1 UF 20/60 5.73
GIMRC11/2 x 3/4 UF 30/60 7.33
GIMRC11/2 x 1 UF 25/50 7.33
GIMRC11/2 x 11/4 UF 24/48 6.97
GIMRC2 x 1/2 UF 21/42 11.99
GIMRC2 x 3/4 UF 21/42 11.99
GIMRC2 x 1 UF 21/42 10.05
GIMRC2 x 11/4 UF 18/36 8.68
GIMRC2 x 11/2 UF 18/36 8.13
GIMRC21/2X11/2 UF 1/16 31.64
GIMRC21/2X2 UF 1/20 31.08
GIMRC3X1 1/12 42.08
GIMRC3X11/4 1/12 42.08
GIMRC3X11/2 UF 1/12 41.27
GIMRC3X2 UF 1/12 38.98
GIMRC3X21/2 UF 1/12 41.34
GIMRC4X2 UF 1/9 89.29
GIMRC4X3 UF 1/8 89.29
HEX BUSHING miptxfipt
GIMHB1/4X1/8 100/1200 3.83
GIMHB3/8X1/4 100/600 3.83
GIMHB1/2x1/8 U150/600 3.83
GIMHB1/2x1/4 UF 100/600 3.83
GIMHB1/2x3/8 UF 100/600 3.83
GIMHB3/4X1/8 U50/300 4.40
GIMHB3/4x1/4 U50/300 3.95
GIMHB3/4x3/8 UF 50/300 4.40
GIMHB3/4x1/2 UF 50/600 3.54
GIMHB1X1/8 U50/200 4.14
GIMHB1X1/4 U50/200 4.70
GIMHB1X3/8 U50/200 7.32
GIMHB1x1/2 UF 50/200 4.24
GIMHB1x3/4 UF 50/200 3.99
GIMHB11/4X1/4 U30/120 6.77
GIMHB11/4X3/8 U30/120 6.77
GIMHB11/4x1/2 30/120 5.93
GIMHB11/4x3/4 UF 30/120 5.40
GIMHB11/4x1 UF 30/120 5.40
BIMHB/GIMHB Series
BIMRC/GIMRC
Reducer Series
U- UL Approval
F- FM Approval
GALVANIZED
6/14/11
12.38
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Malleable Iron Fittings - Imported
Inner/Master List
Size Ctn Qty Price
HEX BUSHING Cont. miptxfipt
BIMHB11/2X1/4 U25/75 $ 4.86
BIMHB11/2x1/2 UF 25/75 4.00
BIMHB11/2x3/4 UF 25/75 4.00
BIMHB11/2x1 UF 25/75 3.51
BIMHB11/2x11/4 UF 25/75 4.00
BIMHB2X1/4 U20/60 6.85
BIMHB2x1/2 UF 20/60 6.07
BIMHB2x3/4 UF 20/60 4.86
BIMHB2x1 UF 20/60 4.55
BIMHB2x11/4 UF 20/60 4.55
BIMHB2x11/2 UF 20/60 5.07
BIMHB21/2X3/4 UF 1/30 8.25
BIMHB21/2X1 UF 1/24 8.25
BIMHB21/2X11/4 UF 1/24 8.25
BIMHB21/2X11/2 UF 1/28 7.68
BIMHB21/2X2 UF 1/32 7.65
BIMHB3X3/4 UF 1/20 11.40
BIMHB3X1 UF 1/20 11.40
BIMHB3X11/4 UF 1/20 11.40
BIMHB3X11/2 UF 1/20 11.63
BIMHB3X2 UF 1/20 13.61
BIMHB3X21/2 UF 1/20 13.61
BIMHB31/2X3 UF 1/10 25.53
BIMHB4X3/4 F1/10 23.12
BIMHB4X1 F1/10 23.12
BIMHB4X11/4 UF 1/10 23.12
BIMHB4X11/2 UF 1/10 23.12
BIMHB4X2 F1/10 20.16
BIMHB4X21/2 F1/10 22.71
BIMHB4X3 UF 1/10 20.16
CAP fipt
BIMCA3/8 50/600 1.62
BIMCA1/2 UF 50/300 1.47
BIMCA3/4 UF 40/240 1.99
BIMCA1 UF 35/140 2.40
BIMCA11/4 UF 25/100 3.12
BIMCA11/2 UF 25/75 4.27
BIMCA2 UF 18/54 5.57
BIMCA21/2 UF 1/30 13.86
BIMCA3 UF 1/20 20.60
BIMCA4 UF 1/14 32.16
BIMCA6 UF 1/2 128.50
BLACK
Inner/Master List
Size Ctn Qty Price
HEX BUSHING Cont. miptxfipt
GIMHB11/2X1/4 U25/75 $ 8.59
GIMHB11/2x1/2 UF 25/75 7.84
GIMHB11/2x3/4 UF 25/75 7.84
GIMHB11/2x1 UF 25/75 7.06
GIMHB11/2X11/4 UF 25/75 6.52
GIMHB2X1/4 U20/60 9.85
GIMHB2 x 1/2 UF 20/60 9.85
GIMHB2 x 3/4 UF 20/60 9.09
GIMHB2 x 1 F20/60 8.64
GIMHB2 x 11/4 UF 20/60 8.64
GIMHB2 x 11/2 UF 20/60 7.55
GIMHB21/2X3/4 UF 1/30 14.19
GIMHB21/2X1 UF 1/24 14.19
GIMHB21/2X11/4 UF 1/24 14.19
GIMHB21/2X11/2 UF 1/28 13.87
GIMHB21/2X2 UF 1/32 12.36
GIMHB3X3/4 UF 1/20 18.72
GIMHB3X1 UF 1/20 18.72
GIMHB3X11/4 UF 1/20 18.72
GIMHB3X11/2 UF 1/20 18.36
GIMHB3X2 UF 1/20 16.64
GIMHB3X21/2 UF 1/20 17.63
GIMHB31/2X3 UF 1/10 41.40
GIMHB4X3/4 F1/10 39.27
GIMHB4X1 F1/10 39.27
GIMHB4X11/4 UF 1/10 39.27
GIMHB4X11/2 UF 1/10 39.27
GIMHB4X2 F1/10 34.65
GIMHB4X21/2 F1/10 39.27
GIMHB4X3 UF 1/10 36.63
CAP fipt
GIMCA3/8 50/600 2.44
GIMCA1/2 UF 50/300 1.87
GIMCA3/4 UF 40/240 2.69
GIMCA1 UF 35/140 2.96
GIMCA11/4 UF 25/100 4.38
GIMCA11/2 UF 25/75 5.52
GIMCA2 UF 18/54 6.97
GIMCA21/2 UF 1/30 22.20
GIMCA3 UF 1/20 26.91
GIMCA4 UF 1/14 53.43
GIMCA6 UF 1/2 194.45
BIMHB/GIMHB Series
BIMCA/GIMCA Series
Carton Quantities subject to change. Contact Customer Service
☺ Steel, Made in USA
U- UL Approval
F- FM Approval
GALVANIZED
6/14/11
12.39
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Malleable Iron Fittings - Imported
BLACK
Inner/Master List
Size Ctn Qty Price
Square Head Plug mipt
BIMP1/8 ☺100 $ 0.66
BIMP1/4 ☺100 0.66
BIMP3/8 ☺45/540 0.99
BIMP1/2 UF ☺40/480 1.03
BIMP3/4 UF ☺25/300 1.11
BIMP1 UF 40/160 1.61
BIMP11/4 UF 25/100 2.39
BIMP11/2 UF 24/72 2.81
BIMP2 UF 15/45 3.97
BIMP21/2 UF 1/40 7.27
BIMP3 UF 1/30 9.96
BIMP4 F1/8 20.88
BIMP5 UF 1/4 44.95
BIMP6 UF 1/2 55.47
Unions, 150 lbs UL Listed fiptxfipt
BIMU150-1/8 30 /180 $ 9.66
BIMU150-1/4 30/180 9.18
BIMU150-3/8 35/140 6.21
BIMU150-1/2 UF 30/120 5.93
BIMU150-3/4 UF 25/75 8.91
BIMU150-1 UF 20/40 8.86
BIMU150-11/4 UF 18/36 11.75
BIMU150-11/2 UF 12/24 18.60
BIMU150-2 UF 8/16 27.87
BIMU150-21/2 UF 1/10 54.25
BIMU150-3 UF 1/5 65.88
FLOOR FLANGE fipt
BIMFF1/4 30/180 5.36
BIMFF3/8 50/200 5.36
BIMFF1/2 F25/100 5.36
BIMFF3/4 F20/80 5.73
BIMFF1 F20/60 7.43
BIMFF11/4 F15/45 10.22
BIMFF11/2 F12/36 11.92
BIMFF2 F8/24 14.46
EXTENSION PIECE
BIMEP1/2 F50/300 4.29
BIMEP3/4 F60/180 6.31
BIMEP1 F30/60 8.78
BIMEP11/4 F30/60 10.98
BIMEP11/2 F1/35 11.75
BIMEP2 F15/30 13.77
Inner/Master List
Size Ctn Qty Price
Square Head Plug mipt
GIMP1/8 ☺100 $ 1.00
GIMP1/4 ☺100 1.00
GIMP3/8 ☺45/540 1.31
GIMP1/2 UF ☺40/480 1.44
GIMP3/4 UF ☺25/300 1.48
GIMP1 UF 40/160 2.48
GIMP11/4 UF 25/100 4.15
GIMP11/2 UF 24/72 5.63
GIMP2 UF 15/45 7.08
GIMP21/2 UF 1/40 13.91
GIMP3 UF 1/30 19.73
GIMP4 F1/8 40.89
GIMP5 UF 1/4 78.38
GIMP6 UF 1/2 81.18
Unions, 150 lbs UL Listed fiptxfipt
GIMU150-1/8 30/180 $ 11.51
GIMU150-1/4 30/180 11.15
GIMU150-3/8 35/140 9.03
GIMU150-1/2 UF 30/120 7.08
GIMU150-3/4 UF 25/75 9.03
GIMU150-1 UF 20/40 10.65
GIMU150-11/4 UF 18/36 15.00
GIMU150-11/2 UF 12/24 18.50
GIMU150-2 UF 8/16 28.18
GIMU150-21/2 UF 1/10 47.80
GIMU150-3 UF 1/5 101.48
FLOOR FLANGE fipt
GIMFF1/4 30/180 11.44
GIMFF3/8 50/200 11.44
GIMFF1/2 F25/100 11.44
GIMFF3/4 F20/80 12.81
GIMFF1 F20/60 14.08
GIMFF11/4 F15/45 16.04
GIMFF11/2 F12/36 19.99
GIMFF2 F8/24 26.33
EXTENSION PIECE
GIMEP1/2 F50/300 6.07
GIMEP3/4 F60/180 9.07
GIMEP1 F30/60 11.35
GIMEP11/4 F30/60 13.82
GIMEP11/2 F1/35 16.16
GIMEP2 F15/30 20.88
BIMU/GIMU Series
BIMFF/GIMFF Series
Carton Quantities subject to change. Contact Customer Service
BIMEP/GIMEP Series
U- UL Approval
F- FM Approval
BIMP/GIMP Series
GALVANIZED
4/2009
12.40
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
6/14/11
12.41
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Malleable Iron Fittings - Domestic
Size Ctn Qty List Price
90º ELBOW fiptxfipt
BM90L1/8 35/210 $ 6.00
BM90L1/4 30/180 5.86
BM90L3/8 30/180 5.86
BM90L1/2 50/200 4.06
BM90L3/4 35/140 4.90
BM90L1 20/80 8.51
BM90L11/4 20/40 14.03
BM90L11/2 8/32 18.46
BM90L2 8/16 31.82
BM90L21/2 12 70.88
BM90L3 5 103.72
BM90L4 4 222.79
90º ELBOW REDUCER fiptxfipt
BM90L3/8 x 1/4 25/150 8.24
BM90L1/2 x 1/4 30/180 7.95
BM90L1/2 x 3/8 50/200 7.74
BM90L3/4 x 3/8 30/180 7.95
BM90L3/4 x 1/2 30/120 7.95
BM90L1 x 1/2 25/100 11.03
BM90L1 x 3/4 20/80 10.23
BM90L11/4 x 3/4 15/60 19.16
BM90L11/4 x 1 10/40 17.18
BM90L11/2 x 1/2 12/48 26.57
BM90L11/2 x 3/4 12/48 27.73
BM90L11/2 x 1 10/40 24.24
BM90L11/2 x 11/4 15/30 24.24
BM90L2 x 1/2 10/40 33.53
BM90L2 x 3/4 15/30 42.30
BM90L2 x 1 12/24 39.90
BM90L2 x 11/4 10/20 39.90
BM90L2 x 11/2 10/20 35.10
BM90L21/2 x 11/2 12 102.02
Case quantities required please for fittings through 2”
Size Ctn Qty List Price
90º ELBOW fiptxfipt
GM90L1/8 35/210 $ 9.29
GM90L1/4 30/180 8.48
GM90L3/8 30/180 8.48
GM90L1/2 50/200 5.46
GM90L3/4 35/140 6.71
GM90L1 20/80 12.42
GM90L11/4 20/40 19.63
GM90L11/2 8/32 25.62
GM90L2 8/16 41.98
GM90L21/2 12 109.85
GM90L3 5 181.11
GM90L4 4 319.43
90º ELBOW REDUCER fiptxfipt
GM90L3/8 x 1/4 25/150 13.58
GM90L1/2 x 1/4 30/180 11.71
GM90L1/2 x 3/8 50/200 10.05
GM90L3/4 x 3/8 30/180 16.09
GM90L3/4 x 1/2 30/120 11.66
GM90L1 x 1/2 25/100 15.89
GM90L1 x 3/4 20/80 14.97
GM90L11/4 x 3/4 15/60 30.16
GM90L11/4 x 1 10/40 25.10
GM90L11/2 x 1/2 12/48 34.66
GM90L11/2 x 3/4 12/48 40.12
GM90L11/2 x 1 10/40 40.12
GM90L11/2 x 11/4 15/30 40.12
GM90L2 x 1/2 10/40 44.87
GM90L2 x 3/4 15/30 56.88
GM90L2 x 1 12/24 55.75
GM90L2 x 11/4 10/20 53.74
GM90L2 x 11/2 10/20 46.88
GM90L21/2 x 11/2 12 177.02
GM90L3 x 2 8 250.82
BLACK GALVANIZED
BM90L/GM90L Series
Domestic Malleable Iron Fitting Features:
• Class 150 malleable iron pipe fittings
• Suitable for water, steam, air, gas and oil
• All fittings are air pressure tested
• Working pressure:
Max: 300 psi @ -20°F to 150°F.
Min 150 psi @ 366°F
• Made in USA
Malleable Iron Fitting Specifications:
Material: ASTM A197
Dimensions: ANSI/ASME B16.3
ANSI/ASME B1.20.1
Pressure ratings: ANSI/ASME B16.3
Coatings: ASTM A153, A165
BM90L/GM90L
Reducer Series
6/14/11
12.42
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Malleable Iron Fittings - Domestic
Size Ctn Qty List Price
45º ELBOW fiptxfipt
BM45L1/4 35/210 $ 8.83
BM45L3/8 40/240 8.83
BM45L1/2 50/200 6.70
BM45L3/4 40/160 8.29
BM45L1 25/100 10.44
BM45L11/4 10/40 18.47
BM45L11/2 10/40 22.84
BM45L2 8/16 34.54
BM45L21/2 15 99.95
BM45L3 8 129.83
BM45L4 4 254.58
90º STREET ELBOW fiptxfipt
BM90SL1/8 40/240 8.65
BM90SL1/4 30/180 8.65
BM90SL3/8 30/180 8.65
BM90SL1/2 50/200 8.40
BM90SL3/4 35/140 8.40
BM90SL1 20/80 11.89
BM90SL11/4 15/30 18.47
BM90SL11/2 12/24 24.71
BM90SL11/2 x 11/4 16/32 44.87
BM90SL2 8/16 40.15
BM90SL21/2 8 101.77
BM90SL3 8 155.35
45º STREET ELBOW fiptxfipt
BM45SL1/8 30/180 13.60
BM45SL3/8 30/180 11.48
BM45SL1/2 50/200 9.37
BM45SL3/4 40/160 14.15
BM45SL1 25/100 16.48
BM45SL11/4 25/50 28.49
BM45SL11/2 15/30 36.74
BM45SL2 10/20 61.77
TEE fiptxfiptxfipt
BMT1/8 35/210 9.04
BMT1/4 35/210 8.51
BMT3/8 30/180 8.51
BMT1/2 30/120 5.42
BMT3/4 20/80 7.78
BMT1 12/48 13.33
BMT11/4 15/30 21.60
BMT11/2 10/20 26.85
BMT2 15 45.78
BMT21/2 8 98.70
BMT3 6 145.39
BMT4 3 351.40
Size Ctn Qty List Price
45º ELBOW fiptxfipt
GM45L1/4 35/210 $ 11.57
GM45L3/8 40/240 12.92
GM45L1/2 50/200 8.64
GM45L3/4 40/160 12.42
GM45L1 25/100 14.03
GM45L11/4 10/40 26.21
GM45L11/2 10/40 30.78
GM45L2 8/16 45.55
GM45L21/2 15 158.50
GM45L3 8 230.53
GM45L4 4 386.45
90º STREET ELBOW fiptxfipt
GM90SL1/8 40/240 12.14
GM90SL1/4 30/180 11.75
GM90SL3/8 30/180 11.75
GM90SL1/2 50/200 12.01
GM90SL3/4 35/140 12.01
GM90SL1 20/80 16.06
GM90SL11/4 15/30 26.96
GM90SL11/2 12/24 33.84
GM90SL11/2 x 11/4 16/32 55.08
GM90SL2 8/16 57.06
GM90SL21/2 8 165.05
GM90SL3 8 240.20
45º STREET ELBOW fiptxfipt
GM45SL1/8 30/180 17.68
GM45SL3/8 30/180 17.42
GM45SL1/2 50/200 13.20
GM45SL3/4 40/160 20.95
GM45SL1 25/100 26.84
GM45SL11/4 25/50 40.28
GM45SL11/2 15/30 48.78
GM45SL2 10/20 80.34
TEE fiptxfiptxfipt
GMT1/8 35/210 13.14
GMT1/4 35/210 11.08
GMT3/8 30/180 11.08
GMT1/2 30/120 7.08
GMT3/4 20/80 11.66
GMT1 12/48 18.86
GMT11/4 15/30 29.93
GMT11/2 10/20 37.21
GMT2 15 60.47
GMT21/2 8 170.27
GMT3 6 199.68
GMT4 3 472.35
BLACK GALVANIZED
BM45L/GM45L
Series
BM90SL/GM90SL
Series
BM45SL/GM45SL
Series
BMT/GMT Series
6/14/11
12.43
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Malleable Iron Fittings - Domestic
Size Ctn Qty List Price
TEE Reducing fiptxfiptxfipt
BMT1/2 x 1/2 x 1/4 25/100 $ 9.24
BMT1/2 x 1/2 x 3/4 30/120 13.91
BMT3/4 x 1/2 x 1/2 30/120 12.37
BMT3/4 x 3/4 x 1/4 30/120 13.39
BMT3/4 x 3/4 x 3/8 30/120 14.79
BMT3/4 x 3/4 x 1/2 25/100 12.05
BMT3/4 x 1/2 x 3/4 20/80 13.91
BMT3/4 x 3/4 x 1 15/60 18.34
BMT1 x 1/2 x 1/2 20/80 17.32
BMT1 x 1/2 x 3/4 20/80 20.66
BMT1 x 1/2 x 1 15/60 17.32
BMT1 x 3/4x 1/2 20/40 17.41
BMT1 x 3/4 x 3/4 20/40 16.09
BMT1 x 3/4 x 1 20/40 17.65
BMT1 x 1 x 1/4 20/80 19.25
BMT1 x 1 x 1/2 15/60 15.20
BMT1x1x3/4 25/50 15.20
BMT1x 1 x 11/4 15/30 33.66
BMT11/4 x 1/2 x 11/4 10/40 32.27
BMT11/4 x 3/4 x 3/4 10/40 32.27
BMT11/4 x 3/4 x 1 10/40 29.88
BMT11/4 x 3/4 x 11/4 15/30 29.24
BMT11/4 x 1 x 1 15/30 28.38
BMT11/4 x 11/4 x 1/2 15/30 27.71
BMT11/4 x 11/4 x 3/4 12/24 24.29
BMT11/4 x 11/4 x 1 14/28 26.33
BMT11/4 x 1 x 11/4 15/30 34.07
BMT11/2 x 1/2 x 11/2 10/20 38.56
BMT11/2 x 3/4 x 3/4 10/40 64.63
BMT11/2 x 3/4 x 11/2 10/20 38.56
BMT11/2 x 1 x 11/2 10/20 38.56
BMT11/2 x 11/4 x 3/4 10/20 38.56
BMT11/2 x 11/4 x 1 8/16 33.10
BMT11/2 x 11/4 x 11/4 10/20 51.73
BMT11/2 x 11/4 x 11/2 10/20 58.14
BMT11/2 x 11/2 x 1/2 8/32 32.46
BMT11/2 x 11/2 x 3/4 10/20 30.66
BMT11/2 x 11/2 x 1 10/20 30.66
BMT11/2 x 11/2 x 11/4 8/40 37.92
BMT2 x 1/2 x 2 8/16 60.12
BMT2 x 3/4 x 2 8/16 59.08
BMT2 x 1 x 2 8/16 60.12
BMT2 x 2 x 1/2 10/20 48.97
BMT2 x 2 x 3/4 10/20 48.05
BMT2 x 2 x 1 10/20 48.05
BMT2 x 2 x 11/4 8/16 51.73
BMT2 x 2 x 11/2 8/16 51.73
BMT2 x 11/4 x 11/4 8/16 60.12
BMT2 x 11/2x11/4 8/16 60.23
BMT2 x 11/2 x 11/2 8/16 59.08
BMT21/2 x 21/2 x 2 12 128.40
Size Ctn Qty List Price
TEE Reducing fiptxfiptxfipt
GMT1/2 x 1/2 x 3/8 35/140 $ 16.44
GMT3/4 x 1/2 x 1/2 30/120 19.40
GMT3/4 x 3/4 x 1/4 30/120 17.33
GMT3/4 x 3/4 x 1/2 25/100 16.23
GMT3/4 x 1/2 x 3/4 20/80 18.51
GMT3/4 x 3/4 x 1 15/60 27.92
GMT1x1/4x1 15/80 29.48
GMT1 x 1/2 x 1/2 20/80 28.45
GMT1 x 1/2 x 3/8 20/80 29.06
GMT1 x 1/2 x 1 15/60 28.45
GMT1 x 3/4x 1/2 20/40 28.45
GMT1 x 3/4 x 3/4 20/40 27.44
GMT1 x 3/4 x 1 20/40 28.45
GMT1 x 1 x 1/2 15/60 22.78
GMT1x1x3/4 25/50 22.78
GMT1x 1 x 11/4 15/30 46.04
GMT11/4 x 1/2 x 11/4 10/40 44.77
GMT11/4 x 3/4 x 3/4 10/40 48.72
GMT11/4 x 3/4 x 1 10/40 46.31
GMT11/4 x 3/4 x 11/4 15/30 42.00
GMT11/4 x 1 x 1 15/30 42.87
GMT11/4 x 11/4 x 1/2 15/30 37.34
GMT11/4 x 11/4 x 3/4 12/24 35.33
GMT11/4 x 11/4 x 1 14/28 35.33
GMT11/4 x 1 x 11/4 15/30 45.33
GMT11/2 x 1/2 x 11/2 10/20 61.56
GMT11/2 x 3/4 x 3/4 10/40 81.94
GMT11/2 x 3/4 x 11/2 10/20 56.14
GMT11/2 x 1 x 11/2 10/20 56.14
GMT11/2 x 11/4 x 3/4 10/20 56.14
GMT11/2 x 11/4 x 1 8/16 53.06
GMT11/2 x 11/4 x 11/4 10/20 77.82
GMT11/2 x 11/4 x 11/2 10/20 77.82
GMT11/2 x 11/2 x 1/2 8/32 46.12
GMT11/2 x 11/2 x 3/4 10/20 43.64
GMT11/2 x 11/2 x 1 10/20 43.64
GMT11/2 x 11/2 x 11/4 8/40 54.64
GMT2 x 1/2 x 2 8/16 79.37
GMT2 x 3/4 x 2 8/16 77.86
GMT2 x 1 x 2 8/16 79.37
GMT2 x 2 x 1/2 10/20 70.99
GMT2 x 2 x 3/4 10/20 63.72
GMT2 x 2 x 1 10/20 62.53
GMT2 x 2 x 11/4 8/16 75.02
GMT2 x 2 x 11/2 8/16 75.05
GMT2 x 11/4 x 11/4 8/16 79.37
GMT2 x 11/2x11/4 8/16 79.37
GMT2 x 11/2 x 11/2 8/16 77.86
GMT21/2 x 21/2 x 2 12 210.91
BLACK GALVANIZED
BMT/GMT
Reducer Series
6/14/11
12.44
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Malleable Iron Fittings - Domestic
Size Ctn Qty List Price
TEE Reducing, Cont. fiptxfiptxfipt
BMT3 x 3 x 3/4 8 $ 174.84
BMT3 x 3 x 1 8 172.32
BMT3 x 3 x 11/4 8 181.56
BMT3 x 3 x 11/2 8 178.28
BMT3 x 3 x 2 8 171.49
BMT3 x 3 x 21/2 8 203.72
STREET TEE fiptxmiptxfipt
BMST3/4 20/80 19.85
BMST1 12/24 26.23
BMST11/4 10/20 43.14
CROSS fipt
BMCR1/2 30/120 20.52
BMCR3/4 15/60 24.83
BMCR1 15/30 30.59
BMCR11/4 12/24 49.65
BMCR11/2 8/16 61.54
BMCR2 8 101.17
Right Hand Coupling fiptxfipt
BMRHC1/4 35/210 7.28
BMRHC3/8 40/240 7.28
BMRHC1/2 40/240 5.61
BMRHC3/4 40/160 6.58
BMRHC1 25/100 9.84
BMRHC11/4 15/60 15.10
BMRHC11/2 10/40 17.22
BMRHC2 8/32 25.52
BMRHC21/2 8 70.43
BMRHC3 8 95.21
BMRHC4 4 191.75
REDUCING COUPLING fiptxfipt
BMRC1/4 x 1/8 ☺25/150 7.67
BMRC3/8 x 1/4 25/150 7.67
BMRC1/2 x 1/4 25/150 6.97
BMRC1/2 x 3/8 30/180 6.59
BMRC3/4 x 1/4 35/210 8.80
BMRC3/4 x 3/8 35/210 8.80
BMRC3/4 x 1/2 50/200 7.37
BMRC1 x 3/8 30/120 14.45
BMRC1 x 1/2 30/120 11.75
BMRC1 x 3/4 25/100 11.48
BMRC11/4 x 1/2 15/60 17.32
BMRC11/4 x 3/4 15/60 14.76
BMRC11/4 x 1 15/60 14.76
BLACK GALVANIZED
Size Ctn Qty List Price
TEE Reducing, Cont. fiptxfiptxfipt
GMT3 x 3 x 3/4 8 $ 385.03
GMT3 x 3 x 1 8 275.98
GMT3 x 3 x 11/4 8 291.88
GMT3 x 3 x 11/2 8 286.30
GMT3 x 3 x 2 8 275.98
GMT3 x 3 x 21/2 8 321.44
STREET TEE fiptxmiptxfipt
GMST3/4 20/80 25.39
GMST1 12/24 40.14
GMST11/4 10/20 66.94
CROSS fipt
GMCR1/2 30/120 29.12
GMCR3/4 15/60 35.48
GMCR1 15/30 48.96
GMCR11/4 12/24 73.60
GMCR11/2 8/16 86.10
GMCR2 8 163.10
Right Hand Coupling fiptxfipt
GMRHC1/4 35/210 10.13
GMRHC3/8 40/240 10.47
GMRHC1/2 40/240 8.00
GMRHC3/4 40/160 9.22
GMRHC1 25/100 15.11
GMRHC11/4 15/60 12.31
GMRHC11/2 10/40 24.22
GMRHC2 8/32 35.41
GMRHC21/2 8 108.40
GMRHC3 8 144.87
GMRHC4 4 313.93
REDUCING COUPLING fiptxfipt
GMRC1/4 x 1/8 ☺25/150 10.39
GMRC3/8 x 1/4 25/150 10.39
GMRC1/2 x 1/4 25/150 9.33
GMRC1/2 x 3/8 30/180 9.70
GMRC3/4 x 1/4 35/210 11.78
GMRC3/4 x 3/8 35/210 11.78
GMRC3/4 x 1/2 50/200 10.38
GMRC1 x 3/8 30/120 22.46
GMRC1 x 1/2 30/120 17.29
GMRC1 x 3/4 25/100 16.06
GMRC11/4 x 1/2 15/60 28.70
GMRC11/4 x 3/4 15/60 22.37
GMRC11/4 x 1 15/60 21.93
BMT/GMT
Reducer Series
BMST/GSMT Series
BMCR/GMCR Series
BMRHC/GMRHC Series
BMRHC/GMRHC
Reducer Series
☺ Steel
6/14/11
12.45
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Malleable Iron Fittings - Domestic
Size Ctn Qty List Price
REDUCING COUPLING - con’t fiptxfipt
BMRC11/2 x 1/2 15/60 $ 22.03
BMRC11/2 x 3/4 10/40 24.83
BMRC11/2 x 1 10/40 21.64
BMRC11/2 x 11/4 10/40 18.66
BMRC2 x 1/2 8/32 35.87
BMRC2 x 3/4 8/32 30.97
BMRC2 x 1 15/30 29.26
BMRC2 x 11/4 10/20 30.97
BMRC2 x 11/2 10/20 27.04
BMRC21/2 x 11/2 10 73.75
BMRC21/2 x 2 10 62.16
BMRC3 x 1 8 98.96
BMRC3x 11/4 8 100.80
BMRC3 x 11/2 8 97.16
BMRC3 x 2 8 80.46
BMRC3 x 21/2 8 93.95
BMRC4 x 2 4 194.75
BMRC4 x 3 4 194.75
HEX BUSHING miptxfipt
BMHB1/4 x 1/8 ☺25/150 7.61
BMHB3/8 x 1/8 ☺25/150 7.61
BMHB3/8 x 1/4 ☺25/150 7.61
BMHB1/2 x 1/8 ☺25/150 7.61
BMHB1/2 x 1/4 ☺25/150 7.61
BMHB1/2 x 3/8 ☺25/150 7.61
BMHB3/4 x 1/8 25/150 7.52
BMHB3/4 x 1/4 25/150 7.14
BMHB3/4 x 3/8 25/150 7.32
BMHB3/4 x 1/2 25/150 6.59
BMHB1 x 1/8 25/150 10.70
BMHB1 x 1/4 25/150 9.24
BMHB1 x 3/8 25/150 9.50
BMHB1 x 1/2 25/150 7.03
BMHB1 x 3/4 25/150 6.92
BMHB11/4 x 1/8 25/150 12.88
BMHB11/4x1/4 25/150 13.28
BMHB11/4 x 1/2 25/150 10.28
BMHB11/4 x 3/4 25/150 9.04
BMHB11/4 x 1 25/150 9.04
BMHB11/2 x 1/4 15/150 15.47
BMHB11/2 x 1/2 30/120 11.76
BMHB11/2 x 3/4 30/120 11.76
BMHB11/2 x 1 30/120 10.32
BMHB11/2 x 11/4 30/120 11.48
BMHB2x 1/4 20/80 16.68
BMHB2 x 1/2 20/80 18.68
BMHB2 x 3/4 20/80 14.77
BMHB2 x 1 20/80 14.12
BMHB2 x 11/4 20/80 14.12
BMHB2 x 11/2 20/80 14.44
BLACK GALVANIZED
Size Ctn Qty List Price
REDUCING COUPLING - con’t fiptxfipt
GMRC11/2 x 1/2 15/60 $ 33.84
GMRC11/2 x 3/4 10/40 28.84
GMRC11/2 x 1 10/40 28.84
GMRC11/2 x 11/4 10/40 27.24
GMRC2 x 1/2 8/32 48.86
GMRC2 x 3/4 8/32 43.31
GMRC2 x 1 15/30 39.34
GMRC2 x 11/4 10/20 41.59
GMRC2 x 11/2 10/20 36.20
GMRC21/2 x 11/2 10 116.04
GMRC21/2 x 2 10 109.76
GMRC3 x 1 8 154.18
GMRC3 x 11/4 8 154.18
GMRC3 x 11/2 8 145.86
GMRC3 x 2 8 137.85
GMRC3 x 21/2 8 140.76
GMRC4 x 2 4 315.60
GMRC4 x 3 4 315.60
HEX BUSHING miptxfipt
GMHB1/4 x 1/8 ☺25/150 12.14
GMHB3/8 x 1/8 ☺25/150 12.14
GMHB3/8 x 1/4 ☺25/150 12.14
GMHB1/2 x 1/8 ☺25/150 12.14
GMHB1/2 x 1/4 ☺25/150 12.14
GMHB1/2 x 3/8 ☺25/150 12.14
GMHB3/4 x 1/8 25/150 13.20
GMHB3/4 x 1/4 25/150 12.84
GMHB3/4 x 3/8 25/150 14.36
GMHB3/4 x 1/2 25/150 10.99
GMHB1 x 1/8 25/150 17.66
GMHB1 x 1/4 25/150 15.00
GMHB1 x 3/8 25/150 15.08
GMHB1 x 1/2 25/150 13.58
GMHB1 x 3/4 25/150 12.63
GMHB11/4 x 1/8 25/150 22.09
GMHB11/4 X 1/4 25/150 22.63
GMHB11/4 X 3/8 25/150 22.63
GMHB11/4 x 1/2 25/150 19.28
GMHB11/4 x 3/4 25/150 17.02
GMHB11/4 x 1 25/150 17.02
GMHB11/2 x 1/4 15/120 30.48
GMHB11/2 x 1/2 30/120 23.70
GMHB11/2 x 3/4 30/120 23.70
GMHB11/2 x 1 30/120 21.41
GMHB11/2 x 11/4 30/120 20.52
GMHB2x 1/4 20/80 34.52
GMHB2 x 1/2 20/80 29.70
GMHB2 x 3/4 20/80 27.60
GMHB2 x 1 20/80 27.60
GMHB2 x 11/4 20/80 27.60
GMHB2 x 11/2 20/80 23.81
BMRHC/GMRHC
Reducer Series
BMHB/GMHB Series
☺ Steel
6/14/11
12.46
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Malleable Iron Fittings - Domestic
Size Ctn Qty List Price
HEX BUSHING CONT. miptxfipt
BMHB21/2 x 3/4 20 $ 25.98
BMHB21/2 x 1 20 25.98
BMHB21/2 x 11/4 20 25.98
BMHB21/2 x 11/2 20 22.60
BMHB21/2 x 2 20 22.25
BMHB3x1/2 10/20 39.10
BMHB3 x 3/4 10/20 38.16
BMHB3 x 1 10/20 35.12
BMHB3 x 11/4 10/20 35.12
BMHB3 x 11/2 10/20 35.12
BMHB3 x 2 10/20 26.23
BMHB3 x 21/2 10 30.41
BMHB4 x 3/4 10 79.59
BMHB4 x 1 10 79.59
BMHB4 x 11/4 10 79.59
BMHB4 x 11/2 10 73.29
BMHB4 x 2 10 59.16
BMHB4 x 21/2 10 71.59
BMHB4 x 3 10 59.16
FLUSH BUSHING
BMFB1 x 3/4 25/150 18.28
BMFB11/4 x 1 25/150 19.77
DOUBLE TAP BUSHING
BMDTB2X11/4 20 29.20
CAP fipt
BMCA1/4 ☺40 5.40
BMCA3/8 ☺40 4.53
BMCA1/2 50/300 4.10
BMCA3/4 40/240 5.56
BMCA1 25/150 6.72
BMCA11/4 25/100 8.86
BMCA11/2 20/80 12.18
BMCA2 10/40 17.76
BMCA21/2 6/12 40.46
BMCA3 6/12 60.12
BMCA4 5/10 103.08
BLACK GALVANIZED
Size Ctn Qty List Price
HEX BUSHING CONT. miptxfipt
GMHB21/2 x 3/4 20 $ 50.27
GMHB21/2 x 1 20 50.27
GMHB21/2 x 11/4 20 50.27
GMHB21/2 x 11/2 20 45.25
GMHB21/2 x 2 20 39.63
GMHB3x1/2 10/20 66.32
GMHB3 x 3/4 10/20 66.32
GMHB3 x 1 10/20 66.32
GMHB3 x 11/4 10/20 64.78
GMHB3 x 11/2 10/20 59.69
GMHB3 x 2 10/20 51.58
GMHB3 x 21/2 10 55.37
GMHB4 x 1 10 139.00
GMHB4 x 11/4 10 139.00
GMHB4 x 11/2 10 139.00
GMHB4 x 2 10 108.28
GMHB4 x 21/2 10 139.00
GMHB4 x 3 10 108.28
FLUSH BUSHING
GMFB1 x 3/4 25/150 30.81
GMFB11/4 x 1 25/150 38.13
DOUBLE TAP BUSHING
GMDTB2X1X1 20 48.66
GMDTB2X11/4X11/4 20 48.66
CAP fipt
GMCA1/4 ☺40 7.33
GMCA3/8 ☺40 7.33
GMCA1/2 50/300 6.06
GMCA3/4 40/240 8.38
GMCA1 25/150 10.39
GMCA11/4 25/100 13.67
GMCA11/2 20/80 17.52
GMCA2 10/40 24.54
GMCA21/2 6/12 71.27
GMCA3 6/12 86.38
GMCA4 5/10 190.81
BMHB/GMHB Series
BMFB/GMFB Series
BMCA/GMCA Series
☺ Steel
6/14/11
12.47
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Malleable Iron Fittings - Domestic
Size Ctn Qty List Price
LOCK NUT
BMLN1/8 ☺100/600 5.63
BMLN1/4 ☺100/600 5.18
BMLN3/8 50/300 6.76
BMLN1/2 50/300 5.80
BMLN3/4 50/300 6.33
BMLN1 40/160 12.13
BMLN11/4 40/160 9.97
BMLN11/2 40/160 14.01
BMLN2 25/100 23.23
Square Head Plug mipt
BMP1/8 ☺100 $ 1.02
BMP1/4 ☺100 1.02
BMP3/8 ☺100 1.02
BMP1/2 ☺100 1.11
BMP3/4 ☺100 1.23
BMP1 40/240 3.79
BMP11/4 40/160 6.05
BMP11/2 40/80 8.56
BMP2 25/50 9.98
BMP21/2 20/40 24.31
BMP3 10/20 28.16
BMP4 5/10 58.00
BMP5 109.03
Unions, 150 lbs UL Listed
BMU150-1/8 25/150 31.08
BMU150-1/4 35/210 28.75
BMU150-3/8 35/210 19.81
BMU150-1/2 40/160 17.94
BMU150-3/4 30/60 20.62
BMU150-1 25/50 26.87
BMU150-11/4 15/30 38.55
BMU150-11/2 12/24 48.07
BMU150-2 8/16 55.88
BMU150-21/2 8 166.49
BMU150-3 8 200.42
BMU150-4 1 522.70
FLOOR FLANGE (diameter)
BMFF1/4 2 3/8” 25/150 12.57
BMFF3/8 2 15/16” 25/150 12.57
BMFF1/2 3” 30/120 18.93
BMFF3/4 3 1/4” 30/120 19.93
BMFF1 3 7/8” 30/60 23.78
BMFF11/4 3 7/8” 30/60 23.78
BMFF11/2 4 1/2” 10/40 30.59
BMFF2 5 1/2” 15/30 36.80
BMFF21/2 5 13/16” 10 40.38
BMFF3 6 3/8” 10 50.99
BLACK GALVANIZED
Size Ctn Qty List Price
LOCK NUT
GMLN1/8 ☺100/600 6.40
GMLN1/4 ☺100/600 5.18
GMLN3/8 50/300 8.48
GMLN1/2 50/300 6.86
GMLN3/4 50/300 8.04
GMLN1 40/160 14.62
GMLN11/4 40/160 14.03
GMLN11/2 40/160 18.21
GMLN2 25/100 32.07
Square Head Plug mipt
GMP1/8 ☺100 $ 1.52
GMP1/4 ☺100 1.54
GMP3/8 ☺100 1.54
GMP1/2 ☺100 1.66
GMP3/4 ☺100 1.79
GMP1 40/240 8.10
GMP11/4 40/160 13.52
GMP11/2 40/80 18.26
GMP2 40/50 22.68
GMP21/2 20/40 47.92
GMP3 10/20 61.38
GMP4 5/10 119.03
GMP5 236.65
Unions, 150 lbs UL Listed
GMU150-1/8 25/150 44.29
GMU150-1/4 35/210 39.00
GMU150-3/8 35/210 26.10
GMU150-1/2 40/160 23.81
GMU150-3/4 30/60 27.37
GMU150-1 25/50 35.83
GMU150-11/4 15/30 51.81
GMU150-11/2 12/24 62.77
GMU150-2 8/16 72.17
GMU150-21/2 8 250.69
GMU150-3 8 350.87
GMU150-4 1 751.10
FLOOR FLANGE (diameter)
GMFF1/4 2 3/8” 25/150 24.43
GMFF3/8 2 15/16” 25/150 24.43
GMFF1/2 3” 30/120 47.30
GMFF3/4 3 1/4” 30/120 47.30
GMFF1 3 7/8” 30/60 43.17
GMFF11/4 3 7/8” 30/60 57.38
GMFF11/2 4 1/2” 10/40 73.52
GMFF2 5 1/2” 15/30 93.37
GMFF21/2 5 13/16” 10 113.51
GMFF3 6 3/8” 10 110.78
☺ Steel
BMP/GMP Series
BMU/GMU Series
BMFF/GMFF Series
BMLN/GMLN Series
4/2009
12.48
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
10/12/10
12.49
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Nipples - Schedule 80 PVC, CPVC
Schedule 80 PVC and CPVC Nipple Features:
• Sturdy, Sch 80 PVC, CPVC
• Chemical Resistant.
• Gray or white (1/2” thru 2”) in Sch 80 PVC.
• Threaded on both ends.
• Standard carton quantity of 50 (1/2” diam) or 25 (3/4”thru 2” diam).
• Threaded one end only (TOE) available upon request.
• Clear available upon request.
ORDER BY SIZE ONLY (DIAMETER X LENGTH)
EXAMPLES: 1/2X3 FOR GRAY PVC
1/2X3W FOR WHITE PVC
CPVC1XCLOSE FOR CPVC
SCHEDULE 80 PVC NIPPLE LIST PRICES
PRE-CUT PIPE THREADED BOTH ENDS
PIPE LENGTH
DIA. 18” 24” 30” 36” 48”
1/2” 2.30 2.78 3.50 4.21 5.27
3/4” 2.75 3.47 4.36 5.36 7.08
1” 4.36 5.17 7.73 9.87
1 1/4” 6.38 15.98
1 1/2” 10.29 13.83
2” 18.28
3” 32.37 41.66
SCHEDULE 80 PVC NIPPLE LIST PRICES-GRAY & WHITE
(SHADED AREA INDICATES SIZES AVAILABLE IN WHITE PVC)
PIPE LENGTH
DIA. CLOSE CLOSE 1 1/2” 2” 2 1/2” 3” 4” 5” 6” 8” 10” 12”
1/4” 7/8” 0.91 1.11 1.16 1.36 2.26
3/8” 1” 0.87 1.01 2.02
1/2” 1 1/8” 0.59 0.68 0.68 0.74 0.77 0.86 1.05 1.12 1.32 1.56 1.68
3/4” 1 3/8” 0.64 0.68 0.74 0.77 0.81 0.99 1.16 1.36 1.58 1.88 2.04
1” 1 1/2” 0.92 1.08 1.19 1.21 1.43 1.76 1.94 2.29 2.73 3.04
1 1/4” 1 5/8” 1.33 1.46 1.57 1.73 1.98 2.34 2.62 3.18 3.72 4.19
1 1/2” 1 3/4” 1.66 1.84 1.94 2.10 2.46 2.77 3.18 3.83 4.39 4.94
2” 2” 2.19 2.46 2.62 3.09 3.61 4.02 4.93 5.81 6.66
3” 7.95 9.57 11.21 15.04 16.97 21.08 25.06
4” 13.01 14.99 18.99 22.52 27.14 31.74
SCHEDULE 80 CPVC PIPE NIPPLES
PART NO. SIZE CTN QTY LIST PRICE
CPVC1XCLOSE 1 X CLOSE 25 $ 2.62
CPVC11/2xCLOSE 1 1/2 x CLOSE 25 3.83
CPVC11/2X6 1 1/2X 6 25 11.03
CPVC11/2x8 1 1/2 x 8 25 13.41
CPVC11/2X12 1 1/2 X 12 25 20.88
CPVC2XCLOSE 2 X CLOSE 25 6.38
CPVC2X6 2 X 6 25 15.73
CPVC2x8 2 x 8 25 18.62
CPVC2X12 2 X 12 BULK 28.70
CPVC2x24 2 x 24 BULK 57.74
6/14/11
12.50
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Nipples - Red Brass, Chrome Plated Red Brass
RED BRASS PIPE NIPPLE LIST PRICES
PIPE LENGTH
DIA. CLOSE CLOSE 1 1/2” 2” 2 1/2” 3” 3 1/2” 4” 4 1/2” 5” 5 1/2” 6”
1/8” 3/4” $3.30 3.76 4.01 4.62 4.89 5.29 5.92 6.70 7.26 7.91 8.43
1/4” 7/8” 3.76 4.30 4.82 5.33 4.83 6.99 7.89 8.91 9.72 10.54 11.37
3/8” 1” 4.00 4.78 5.33 6.22 7.16 8.25 9.22 10.45 11.42 12.44 13.42
1/2” 1 1/8” 4.92 5.67 6.73 7.99 9.36 10.71 12.26 13.59 14.99 16.46 17.79
3/4” 1 3/8” 7.15 7.54 9.04 10.50 12.09 13.86 15.71 17.50 19.32 21.07 21.85
1” 1 1/2” 10.51 12.90 15.04 17.18 19.86 22.27 24.82 27.46 30.10 32.69
1 1/4” 1 5/8” 16.01 17.95 19.24 24.82 27.07 31.25 36.35 38.17 40.60 45.46
1 1/2” 1 3/4” 20.05 21.49 24.75 29.49 32.61 38.48 41.27 47.93 49.95 54.20
2” 2” 30.80 33.49 38.04 45.12 47.33 52.85 58.47 64.22 69.74
Red Brass Nipple Features:
• Red Brass pipe conforms to ASTM B43-91
• 85% copper, 15% zinc, no lead
• Made in the U.S.A.
• Manufactured for AGI in an ISO 9002 facility.
• Standard carton quantity is 25 pieces through 1” diameter.
• Standard carton quantity is 10 pieces 1 1/4” - 2” diameter.
ISO 9002
Chrome Plated Red Brass Nipple Features:
• Red brass pipe conforms to ASTM B43-91
• 85% copper, 15% zinc, no lead.
• Made in the U.S.A.
• Manufactured for AGI in an ISO 9002 facility.
• Standard carton quantity is 25.
chrome plated RED BRASS PIPE NIPPLE LIST PRICES
PIPE LENGTH
DIA. CLOSE CLOSE 1 1/2” 2” 2 1/2” 3” 3 1/2” 4” 4 1/2” 5” 5 1/2” 6”
3/8” 1” $ 8.43 9.97 12.12 13.09 16.07 17.34 20.58 21.97 24.06 26.12 28.26
1/2” 1 1/8” 11.23 12.98 15.29 18.19 21.31 24.33 27.91 30.26 33.35 36.58 40.60
3/4” 1 3/8” 18.33 23.06 30.85 43.80
1” 1 1/2” 27.00 33.31 44.78 58.30 71.88 78.74 85.85
ISO 9002
ORDER BY PART NUMBER B80 WITH SIZE (DIAMETER X LENGTH)
EXAMPLE: B80-1/2 X3
ORDER BY PART NUMBER CP80 WITH SIZE (DIAMETER X LENGTH)
EXAMPLE: CP80-1/2 X3
6/14/11
12.51
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Nipples - Black Steel
Black Steel Nipple Features:
• Standard carton quantity is 25 pieces for all diameters up to 2”and all lengths up to 6”.
• Carton quantities required for nipples through 2” diameter.
• Imported.
BLACK STEEL PIPE NIPPLE LIST PRICES
STANDARD WELDED
PIPE LENGTH
DIA. CLOSE CLOSE 1 1/2” 2” 2 1/2” 3” 3 1/2” 4” 4 1/2” 5” 5 1/2” 6” 7” 8” 9” 10” 11” 12”
1/8” 3/4” 0.98 1.18 1.18 1.36 1.36 1.77 1.77 3.15 3.15 3.49 3.49 4.80 5.31 5.59
1/4” 7/8” 1.16 1.23 1.23 1.59 1.59 1.87 1.87 2.81 2.81 3.30 3.03 5.07 5.07 5.98 6.59
3/8” 1” 1.18 1.35 1.35 1.72 1.72 2.04 2.04 2.95 2.95 3.35 3.35 5.78 5.78 6.48 6.48 7.06 7.06
1/2” 1 1/8” 1.03 1.03 1.03 1.23 1.23 1.50 1.50 1.72 1.72 1.99 1.99 3.49 3.49 4.19 4.19 4.98 4.98
3/4” 1 3/8” 1.17 1.22 1.22 1.45 1.45 1.80 1.80 2.17 2.17 2.57 2.57 4.29 4.29 4.95 4.95 5.51 5.51
1” 1 1/2” 1.72 1.89 2.04 2.04 2.64 2.64 3.20 3.20 3.76 3.76 5.70 5.70 6.69 6.69 7.67 7.67
11/4” 1 5/8” 2.20 2.38 2.73 2.73 3.52 3.52 4.33 4.33 5.09 5.09 7.18 7.18 8.63 8.63 9.76 9.76
11/2” 1 3/4” 2.72 2.93 3.29 3.29 4.18 4.18 5.11 5.11 6.02 6.02 8.25 8.25 9.73 9.73 11.58 11.58
2” 2” 3.73 4.29 4.29 5.52 5.52 6.73 6.73 7.96 7.96 11.71 11.71 13.79 13.79 15.84 15.84
21/2” 2 1/2” 11.22 11.53 13.56 13.56 14.86 16.14 16.14 20.51 23.06 25.62
3” 2 5/8” 13.85 15.06 17.85 17.85 19.68 19.68 21.42 21.42 28.87 28.87 32.42 35.97 35.97
4” 2 7/8” 20.88 24.16 26.57 26.57 29.49 29.49 34.05 34.05 39.19 46.53
6” 3 1/8” 37.88 66.13 76.86 86.56 106.27 126.00
BLACK STEEL PIPE NIPPLE LIST PRICES
PRE-CUT PIPE THREADED BOTH ENDS
PIPE PACK
DIA. QTY 18” 24” 30” 36” 48” 60” 72”
3/8” 5 $ 9.90 12.34
1/2” 5 7.39 9.72 11.36 13.38 16.92 20.31 24.97
3/4” 5 9.17 11.73 13.71 16.24 21.62 26.47 30.46
1” 3 11.77 15.40 17.77 21.44 47.98 35.24 41.64
1 1/4” 3 14.99 20.21 23.85 28.10 37.53 46.79
1 1/2” 3 17.12 23.12 28.14 33.72 44.78 55.84 67.10
2” 3 23.85 31.60 37.74 45.24 60.09 74.96
2 1/2” 3 52.35
3” 3 51.89 68.50 101.48 134.51
4” 3 73.38 96.95
ORDER BY PART NUMBER BS80 WITH SIZE (DIAMETER X LENGTH)
EXAMPLE: BS80-1/2 X3
Black Steel Tank Leg Features:
• For use with standard steel tanks
• No cradle required
• Threaded one end x square cut
PART NO. CTN QTY LIST PRICE
BS80-11/4X10TOE 5/20 $ 8.63
BS80-11/4X11TOE 5/20 9.76
BS80-11/4X12TOE 5/20 9.76
BS80-11/4X14TOE 5/20 9.76
6/14/11
12.52
www.americangranby.com
In the United States: Phone (800) 776-2266 Fax (800) 729-3299
In Canada: Phone (866) 503-5523 Fax (888) 562-2095
TM
Nipples - Galvanized Steel
Galvanized Steel Nipple Features:
• Standard carton quantity is 25 pieces for all diameters up to 2”and all lengths up to 6”.
• Carton quantities required for nipples through 2” diameter.
• Imported.
GALVANIZED STEEL PIPE NIPPLE LIST PRICES
STANDARD WELDED
PIPE LENGTH
DIA. CLOSE CLOSE 1 1/2” 2” 2 1/2” 3” 3 1/2” 4” 4 1/2” 5” 5 1/2” 6” 7” 8” 9” 10” 11” 12”
1/8” 3/4” 1.22 1.70 1.70 2.24 2.22 2.62 2.62 4.46 4.46 4.98 4.98 6.59
1/4” 7/8” 1.31 1.54 1.54 1.99 1.99 2.38 2.38 3.29 3.29 3.65 3.65 6.27 6.27 7.04 7.04 7.79
3/8” 1” 1.41 1.61 1.61 2.18 2.18 2.58 2.58 3.59 3.59 3.97 3.97 6.35 7.53 8.39
1/2” 1 1/8” 1.17 1.30 1.30 1.50 1.50 1.84 1.84 2.20 2.20 2.49 2.49 4.36 4.36 5.21 5.21 5.95 5.95
3/4” 1 3/8” 1.45 1.58 1.58 1.73 1.73 2.16 2.16 2.71 2.71 3.22 3.22 5.61 5.61 6.24 6.24 6.97 6.97
1” 1 1/2” 2.00 2.35 2.53 2.53 3.07 3.07 3.74 3.74 4.27 4.27 7.10 7.10 8.15 8.15 9.47 9.47
11/4” 1 5/8” 2.68 2.91 3.15 3.15 3.90 3.90 4.64 4.64 5.61 5.61 8.76 8.76 10.43 10.43 12.09 12.09
11/2” 1 3/4” 3.12 3.36 3.74 3.74 4.76 4.76 5.75 5.75 6.47 6.47 10.00 10.00 11.67 11.67 13.33
2” 2” 4.40 4.95 4.95 6.04 6.04 7.72 7.72 8.94 8.94 14.60 14.60 17.10 17.10 19.60 19.60
21/2” 2 1/2” 13.13 13.65 15.85 15.85 17.67 17.67 19.40 19.40 25.01 25.01 28.49 31.90 31.90
3” 2 5/8” 15.77 17.95 21.04 21.04 24.53 24.53 25.94 25.94 34.94 34.94 39.84 39.83 44.81 44.81
4” 2 7/8” 23.63 37.89 28.22 31.67 31.67 35.02 35.02 41.81 48.42 55.11
6” 3 1/8” 46.06 56.87 80.40 105.22 129.20 153.15
GALVANIZED STEEL PIPE NIPPLE LIST PRICES
PRE-CUT PIPE THREADED BOTH ENDS
PIPE PACK
DIA. QTY 18” 24” 30” 36” 48” 60” 72”
3/8” 5 11.89
1/2” 5 9.13 11.73 13.87 16.01 20.54 25.32 29.91
3/4” 5 10.84 13.90 17.10 19.63 25.65 31.40 37.07
1” 3 13.96 18.60 21.70 24.80 32.89 41.39
1 1/4” 3 18.40 24.67 29.15 33.62 44.58 55.43
1 1/2” 3 20.91 27.97 33.79 39.60 52.64 66.69
2” 3 28.51 37.71 44.38 51.05 66.37 82.92
2 1/2” 3 43.84 57.83 74.51
3” 3 61.75 81.46 102.07 120.74 160.03
4” 3 87.31 107.11 171.31 227.21
ORDER BY PART NUMBER GS80 WITH SIZE (DIAMETER X LENGTH)
EXAMPLE: GS80-1/2 X3
GALVANIZED STEEL REDUCING PIPE NIPPLES
PART NO. SIZE CTN QTY LIST PRICE
GSR80-3/4X1/2X23/4 3/4 X 1/2 X 2 3/4 25 $ 11.96
GSR80-11/4x1x31/2 1 1/4 x 1 x 3 1/2 25 14.41
GSR80-1x3/4x3 1 x 3/4 x 3 25 13.45
