DMI Sports For Customer Service Call 1.800.399.4402

1.800.399.4402

FAX: 215.283.9573

Please have your model number when inquiring about parts.

Or write to:

DMI Sports

Customer Service

375 Commerce Drive

Fort Washington PA, 19034

Please visit our web site at:

www.dmisports.com

When contacting DMI Sports, please provide your model number

and item number (if applicable) if requesting a replacement part.

Item numbers can be found inside this owners manual.

Congratulations on the purchase of your new DMI Sports

Pool table. Our products are designed and manufactured

to give you years of game playing enjoyment.

KEEP BOX AND PACKING MATERIAL UNTIL TABLE

HAS BEEN COMPLETELY ASSEMBLED.

ALL DAMAGE MUST BE REPORTED TO DMI

WITHIN TEN DAYS OF RECEIPT.

If you have any problems with your new product,

PLEASE DO NOT RETURN IT TO THE STORE.

Please contact us:

Your Model Number _______________________

Your model number is also located on the original carton. These instructions

are also available online at: www.dmisports.com.

MFT200-CT

0101005

DMI Sports For Customer Service Call 1.800.399.4402

Please Keep Your Instructions! (You will need your Model number should you need to contact us.)

Before attempting assembly, please read through this instruction book to familiarize yourself with all

the parts and assembly steps. We recommend that two adults assemble this table. Please refer to the

Parts Identifier on the following page and be sure that all parts have been included. Although extreme-

ly rare, occasionally a part may be missing. If you are missing a part, or if you have any questions, please

call our customer service department at 1.800.399.4402 Mon-Fri between the hours of 9:00am and

5:00pm E.S.T; or you can reach us at: www.dmisports.com.

Do not return the game to the store. Please contact us first at: 1.800.399.4402 or on our website at:

www.dmisports.com.

IMPORTANT!

TWO ADULTS ARE REQUIRED TO ASSEMBLE

THIS POOL TABLE

-2-

DMI Sports For Customer Service Call 1.800.399.4402

PARTS IDENTIFIER

HARDWARE PARTS

H1 H2

A1 A2 A3

Leg Bolt

RPMFT200-BOLT

Leg Washer

RPMFT200-WASH

Triangle, Plastic

MFA40993

Chalk

MFA42405

Billiard Balls

MFA41655

Qty. 8 Qty. 8

Qty. 1 Qty. 2 Qty. 1

ACCESSORY PARTS

A4 Qty. 2

2 Piece Billiard Cues

MFR40432

ASSEMBLY PARTS

P1 P2 P3 P4

Main Frame

RPMFT200-TABLE Leg

RPMFT200-LEG

Qty. 1

Qty. 1 Qty. 2 Qty. 1

-3-

Table Tennis Net Set

MFCT-200NP

Conversion Top

MFCT-200

A5 Qty. 1

Wrench, Multi

RPMFT200-MWRENCH

P5 Qty. 4

Leg Levelers

RPMFT200-LEV

DMI Sports For Customer Service Call 1.800.399.4402

ASSEMBLY

STEP 1.

Carefully remove all parts from the box.

Attach Legs (P2) to the Main Frame (P1) using Bolts (H1) and Washers (H2) as shown in Fig. 1.1.

STEP 2.

Attach Leg Levelers (P5) to each Leg (P2) as shown below in FIG 2.1.

FIG 1.1

FIG 2.1

-4-

P2 H2 P1

H1

P5

DMI Sports For Customer Service Call 1.800.399.4402

ASSEMBLY

STEP 3.

With the assistance of at least one other adult, carefully turn your table over.

Please refer to page 6 for leg leveling instructions.

FIG 3.1

-5-

FIG 5.1

Conversion Top Assembly

The conversion top comes in two parts. Attach the two parts as shown in Fig. 4.1.

Once the two sides of the conversion top are combined, attach the net as shown in Figure 5.1.

FIG 4.1

DMI Sports For Customer Service Call 1.800.399.4402

INSTRUCTIONS FOR LEVELING A POOL TABLE

• Assemble pool table according to the instructions, making sure levelers are screwed in completely,

then turning one full turn out.

• Any type of level would be sufficient to perform this procedure. However, a two-foot level is

recommended.

• Before leveling, make sure level is placed on the playing surface, not the rails.

• Level the ends between the corner pockets. Place the level on the playing surface between the two

corner pockets and adjust the levelers in or out to position the bubble in the middle of the level.

• Repeat the step above to the opposite corner pockets.

• Next, level the length of the table. Place the level next to the side pocket and adjust the levelers in or

out to position the bubble in the middle of the level.

• Repeat the step above to the opposite length of the table.

• Recheck both short ends to ensure bubble is in the middle on the level.

• Depending on the surface the pool table sits, especially deep pile carpeting, the pool table needs to

settle for 24 hours. Recheck the level on each side of the table after 24 hours.

• These same instructions may be followed to level hockey and soccer table play surfaces as well.

-6-

DMI Sports For Customer Service Call 1.800.399.4402

REF

H1

H2

A1

A2

A3

A4

A5

P2

P3

P4

P5

PART#

RPMFT200-BOLT

RPMFT200-WASH

MFA40993

MFA42405

MFA41655

MFR40432

RPMFT200-MWRENCH

RPMFT200-LEG

MFCT-200

MFCT-200NP

RPMFT200-LEV

DESCRIPTION

Leg Bolt

Leg Washer

Triangle, Plastic

Chalk

Billiard balls

2 Piece Cues

Wrench, Multi

Leg

Conversion Top

Table Tennis Net Set

Leg levelers

UNIT

PRICE

TOTAL

AMOUNT

Subtotal:

PA Residents Add 6% State Sales Tax:

Shipping and Handling Charges:

TOTAL:

(ea.)

(ea.)

(ea.)

(ea.)

(ea.)

(ea.)

(ea.)

(ea.)

(ea.)

(ea.)

(ea.)

PARTS RE-ORDER FORM MFT200-CT Pool Table

DATE:

NAME:

ADDRESS:

CITY:

PHONE:

STATE: ZIP CODE:

Send this form along with your

check or money order payable to:

DMI SPORTS

375 Commerce Drive

Fort Washington, PA 19034

www.dmisports.com

.25

.25

8.00

N/A

30.00

12.00

8.00

30.00

85.00

15.00

5.00

SHIPPING AND HANDLNG:

Up to $15.00 add $2.00 for S&H

Over $15.00 add $8.00 for S&H
