Datasheet

MVME5500 Series

VME Single-Board

Computer

■MPC7455 PowerPC® processor at 1 GHz

■256KB of on-chip L2 cache and 2MB of L3 cache

■AltiVec™ coprocessor for high-performance

computational applications

■512MB of on-board 133 MHz SDRAM ECC memory

and 512MB additional memory via a memory

mezzanine card for a total of 1GB of memory

■Two banks of soldered Flash memory, 32MB and 8MB

■Dual independent 64-bit PCI buses and PMC sites

with a bus speed of up to 66 MHz

■Gigabit Ethernet interface plus an additional

10/100BaseTX Ethernet interface

■64-bit PCI expansion mezzanine connector allowing

up to four more PMCs

■I/O compatibility with MVME51xx family

■Single VME slot even when fully configured with two

PMC modules or one PMC module and an add-on

memory mezzanine

■Support for processor PMCs (PrPMCs)

Motorola's highest performance VMEbus single-board computer

The MVME5500 is the latest flagship of the Motorola VME product line, enabling

higher levels of performance in a single VMEbus slot. The MVME5500 utilizes the

latest MPC7455 processor running at 1 GHz, which is ideal for data intensive

applications.

The MVME5500 provides more than just better processor performance; it also provides

balanced performance from the processor, memory, dual independent local buses and

I/O subsystems. The powerful Marvell system controller, with support for a 133 MHz

host bus and a 133 MHz SDRAM memory bus, is well matched to the high speed

processor. To match the system I/O to the outstanding processor performance, the

MVME5500 provides dual 64-bit, 33/66 MHz PCI buses. Each PCI bus has a PMC site

supporting cards running at 33 or 66 MHz. The Universe II VME interface and PMCspan

connector are isolated from the PMC sites on a dedicated 33 MHz PCI bus segment so

that both PMC sites are capable of 66 MHz operation. The MVME5500 also offers a

Gigabit Ethernet interface, a 10/100BaseTX Ethernet interface and two serial ports. All

of this adds up to a set of well-balanced, high-performance subsystems for

unparalleled performance.

The MVME5500 series is designed to meet the needs of OEMs including those in

defense and aerospace, industrial automation and medical imaging market segments.

Customers looking for a "technology refresh" for their application while maintaining

backward compatibility with their existing VMEbus infrastructure can upgrade to the

MVME5500 series and take advantage of the enhanced performance features.

PMC

Slot 2

PMC

FP I/O

COM2

Planar

UART

EIA232

L3 Cache

2MB

MPC7455

1 GHz

COM1

FP I/O

NVRAM

RTC

Battery Flash

32MB

(soldered)

8MB

(soldered)

A32/D64-bit, 133MHz

SDRRAM

Mezzanine

512MB

SDRRAM

133 MHz

512MB

Port 2

10/100BaseTX

FP I/O

Gigabit

Ethernet

Contoller

UART

EIA232

PCI Bridge &

Memory Controller

Discovery

PCI

Bridge

PMCspan

Connector

Universe II

IPMC

Slot 1

Port 1

10/100/1000

BaseTX

FP I/O PMC

FP I/O

66 MHz PCI Local Bus

- A32/D64-bit

Ethernet

10/100BaseTX

PHY

66 MHz PCI Local Bus

- A32/D64-bit

33 MHz PCI Local Bus

- A32/D64-bit

2MVME5500 Series

MVME5500 Series Details

Backward Compatibility The MVME5500 continues the direction that Motorola started with the MVME5100 series of providing a migration

path from Motorola's embedded controllers and single-board computers (SBCs) to a single platform. This migration

path enables OEMs to support varying I/O requirements with the same base platform, simplifying part number

maintenance, technical expertise requirements and sparing.

The MVME5500 series offers customers a migration path from the MVME2300, MVME2400, MVME2600,

MVME2700 and MVME5100 boards to allow them to take advantage of features such as the MPC7455 processor,

Gigabit Ethernet and dual independent 33/66 MHz PMC sites.

IPMC Modules

The IPMC761 and IPMC712 are optional add-on PMC modules that provide backward compatibility with previous

generation Motorola products (such as MVME2600, MVME2700 and MVME5100 in IPMC mode) using the MVME761

or MVME712M transition module. IPMC modules provide rear I/O support for the following:

• One single-ended Ultra Wide SCSI port

• One parallel port

• Four serial ports (two or three async and one or two sync/async, depending on module)

With an IPMC installed, one PMC slot is still available, providing support for OEM product customization.

P2 I/O Modes

Like the MVME5100 series, the MVME5500 series supports two, jumper-configurable P2 I/O modes: PMC mode and

IPMC mode. PMC mode is backward compatible with the MVME2300/MVME2400 and MVME5100 in PMC mode. In

PMC mode, 64 pins from PMC slot 1 and 46 pins from PMC slot 2 are available on P2 for PMC rear I/O. In IPMC mode,

the MVME5500 series supports legacy MVME761 or MVME712M I/O modules (with limited PMC I/O) when an

IPMC761 or IPMC712 PMC card is populated in PMC slot 1. In this configuration, PMC slot 2 contains some signals

that are reserved for extended SCSI.

Transition Modules

MVME761

The MVME761 transition module provides industry-standard connector access to the IEEE 1284 parallel port, a

10BaseT or 100BaseT port via an RJ-45 connector, two DB-9 connectors providing access to the asynchronous serial

ports configured as EIA-574 DTE and two HD-26 connectors providing access to the sync/async serial ports. These

serial ports, labeled as Serial 3 and Serial 4 on the faceplate of the MVME761, are individually user-configurable as

EIA-232, EIA-530, V.35, or X.21 DCE or DTE via the installation of Motorola Serial Interface Modules (SIMs).

A P2 adapter board provides interface signals to the MVME761 transition module. Two separate P2 adapter boards

are available: one for 3-row backplanes and one for 5-row backplanes. The 3-row P2 adapter board provides

connection for 8-bit SCSI. A 5-row P2 adapter board supports 16-bit SCSI and PMC I/O.

MVME712M

The MVME712M transition module provides industry-standard connector access to the Centronics parallel port, a

narrow SCSI port, and four DB-25 connectors providing access to the asynchronous/synchronous serial ports jumper

configurable as EIA-232 DCE or DTE. A P2 adapter board provides interface signals to the MVME712M transition

module. The 3-row P2 adapter board also provides connection for 8-bit SCSI.

To gain access to the additional user-definable I/O pins provided via the 5-row VME64 extension connector, a special

P2 adapter board is available. This adapter panel replaces the traditional 3-row P2 adapter board and extends its

capability by providing access to the PMC I/O pins.

MVME5500 SERIES DETAILS

MVME5500 Series 3

Software Support Firmware Monitor

Firmware must fulfill the traditional functions of power-on self-test (POST), initialization, low-level setup and debug,

and operating system booting. Motorola's innovative firmware (known as MOTLoad) that is resident on the

MVME5500 exceeds these requirements with expanded features such as interrupt driven I/O, more comprehensive

power-up tests and extensive diagnostics with new scripting capability. And of course, MOTLoad provides a

debugger interface similar to the time proven "BUG" interface on previous VMEbus boards from Motorola.

Operating Systems and Kernels

WindRiver Systems VxWorks, TimeSys Linux, Green Hills Software INTEGRITY and LynuxWorks LynxOS are available

for the MVME5500.

Libraries

VSI/Pro VSIPL libraries from MPI Software Technology are available on the MVME5500.

Specifications

Processor

System Controller

Marvell GT-64260B

Main Memory

Flash Memory

NVRAM

Counters/Timers

VMEbus Interface: ANSI/VITA 1-1994 VME64 (IEEE STD

1014)

Ethernet Interfaces

Asynchronous Serial Ports

SPECIFICATIONS

Microprocessor: MPC7455

Clock Frequency: 1 GHz

On-chip L1 Cache (I/D): 32KB/32KB

On-chip L2 Cache (I/D): 256KB

L3 Cache: 2MB

Type: PC133 ECC SDRAM

Speed: 133 MHz

Capacity: 512MB on-board, expandable to 1GB with

add-on memory mezzanine card. Note: If a

PMC module is plugged into PMC slot 1,

the memory mezzanine card cannot be

used because the PMC module covers the

memory mezzanine connector.

Configurations: 512MB in two banks

Type: EEPROM, on-board programmable

Capacity: 40MB total in two banks of 32MB and

8MB, both soldered

Write Protection: 32MB of surface-mount Flash is write-

protectable via jumper

Capacity: 32KB (4KB available for users)

Cell Storage Life: 50 years at 55° C

Cell Capacity Life: 5 years at 100% duty cycle, 25° C

Removable Battery: Yes

TOD Clock Device: M48T37V

Real-Time

Timers/Counters:

Eight, 32-bit programmable

Watchdog Timer: Time-out generates reset

Controller: Tundra Universe II

DTB Master: A16-A32; D08-D64, SCT, BLT

DTB Slave: A24-A32; D08-D64, BLT, UAT

Arbiter: RR/PRI

Interrupt

Handler/Generator:

IRQ 1-7/Any one of seven IRQs

System Controller: Yes, jumperable or auto detect

Location Monitor: Two, LMA32

Port 1

Controller: Intel 82544EI Gigabit Ethernet controller

Interface Speed: 10/100/1000Mb/s

Connector: Routed to front panel RJ-45

Port 2

Controller: Controller integrated into GT-64260B

system controller

Interface Speed: 10/100Mb/s

Connector: Routed to front panel RJ-45 or optionally

routed to P2, RJ-45 on MVME761

Controller: Two TL16C550C UARTs

Number of Ports: Two, 16550 compatible

Async Baud Rate, b/s

max.:

38.4K EIA-232, 115Kb/s raw

Connector: Routed to front panel RJ-45; one on planar

for development use

4MVME5500 Series

Dual IEEE P1386.1 PCI Mezzanine Card Slots

Note: If a PMC module is plugged in PMC slot 1, the memory

mezzanine card cannot be used because the PMC module covers the

memory mezzanine connector.

PCI Expansion Connector

Power Requirements

Note: In a 3-row chassis, PMC current should be limited to 19.8 watts

(total of both PMC slots). In a 5-row chassis, PMC current should be

limited to 46.2 watts (total of both PMC slots).

Board Size

IPMC Modules PMC Interface

SCSI Bus

Note: 16-bit SCSI operation precludes the use of some PMC slot 2

signals.

Synchronous Serial Ports

Asynchronous Serial Ports

Parallel Port

Power Requirements

(Additional power load placed on MVME5500 with IPMC installed)

Address/Data: A32/D32/D64, PMC PN1, PN2, PN3, PN4

connectors

PCI Bus Clock: 33/66 MHz

Signaling: 3.3V or 5V, configurable with keying pin

Power: +3.3V, +5V, ±12V

Module Types: Two single-wide or one double-wide, front

panel or P2 I/O, PMC and PrPMC support

Address/Data: A32/D32/D64

PCI Bus Clock: 33 MHz

Signaling: 5V

Power: +3.3V, +5V, ±12V

Connector: 114-pin connector located on MVME5500

planar, same location as on MVME5100

planar

+5V ± 5%

MVME5500-0163: 6.7 A typ., 8.0 A max.

MVME5500-0163 with

memory mezzanine:

7.5 A typ., 9.0 A max.

MVME5500-0163 with

IPMC712/761:

7.6 A typ., 9.2 A max.

Height: 233.4 mm (9.2 in.)

Depth: 160.0 mm (6.3 in.)

Front Panel Height: 261.8 mm (10.3 in.)

Width: 19.8 mm (0.8 in.)

Max. Component

Height:

14.8 mm (0.58 in.)

Address/Data: A32/D32/D64, PMC PN1, PN2, PN3, PN4

connectors

PCI Bus Clock: 33 MHz

Signaling: 5V

Module Type: Basic single-wide; P2 I/O

Controller: Symbios 53C895A

PCI Local Bus DMA: Yes, with PCI local bus burst

Asynchronous (8-bit

mode):

5.0MB/s

Ultra SCSI: 20.0MB/s (8-bit mode), 40.0MB/s (16-bit

mode)

Controller: 85230/8536

Number of Ports: Two (IPMC761); one (IPMC712)

Configuration: IPMC761: TTL to P2 (both ports), SIM

configurable on MVME761;

IPMC712: EIA-232 to P2

Baud Rate, bps max.: 2.5M sync, 38.4K async

Oscillator Clock Rate

(PCLK):

10 MHz/5 MHz

Controller: 16C550 UART; 85230/8536

Number of Ports: Two (IPMC761); three (IPMC712)

Configuration: EIA-574 DTE (IPMC761);

EIA-232 (IPMC712)

Async Baud Rate, b/s

max.:

38.4K EIA-232, 115Kb/s raw

Controller: PC97307

Configuration: 8-bit bi-directional, full IEEE 1284 support;

Centronics compatible (minus EPP and

ECP on MVME712M)

Modes: Master only

IPMC761 IPMC712

+5V: 0.5 A max. 0.5 A max.

+3.3V: 0.75 A max. 0.75 A max.

MVME5500 Series 5

Transition Modules I/O Connectors

Board Size

All Modules Environmental Safety

All printed wiring boards (PWBs) are manufactured with a flammability

rating of 94V-0 by UL recognized manufacturers.

Electromagnetic Compatibility (EMC)

Intended for use in systems meeting the following regulations:

Motorola Computer Group board products are tested in a

representative system to the following standards, results pending for

configurations with IPMC712:

MVME761 MVME712M

Asynchronous Serial Ports: Two, DB-9 labeled as COM1 and COM2 Three, DB-25 labeled as Serial 1, Serial 2, and Serial 3

Synchronous Serial Ports: Two HD-26 labeled as Serial 3 and Serial 4 (user-

configurable via installation of SIMs),

Two 60-pin connectors on MVME761 planar for

installation of two SIMs

One, DB-25 labeled as Serial 4

Parallel Port: HD-36, Centronics compatible D-36, Centronics compatible

Ethernet: 10BaseT or 100BaseT, RJ-45 NA

SCSI: 8- or 16-bit, 50- or 68-pin connector via P2 adapter 8-bit, standard SCSI D-50

Height: 233.4 mm (9.2 in.)

Depth: 80.0 mm (3.1 in.)

Front Panel Height: 261.8 mm (10.3 in.)

Front Panel Width: MVME761: 19.8 mm (0.8 in.)

MVME712M: 39.6 mm (1.6 in.)

Operating Non-operating

Temperature: 0° C to +55° C

(inlet air temp.

w/forced air cooling)

–40° C to +85° C

Vibration: 1 G sinusoidal,

5–100 Hz

2 axes U.S.: FCC Part 15, Subpart B, Class A (non-residential)

Canada: ICES-003, Class A (non-residential)

CE Mark per European EMC Directive 89/336/EEC with

Amendments; Emissions: EN55022 Class A; Immunity: EN55024

www.motorola.com/computer

Motorola Computer Group

Regional Offices

NORTH AMERICA: Tempe, AZ 1 800 759 1107 or +1 602 438 5720

EUROPE: Loughborough, UK +44 1509 634300

EAST MEDITERRANEAN: Tel Aviv, Israel +972 3 568 4388

ASIA: Shanghai, China +86 21 5292 5693

PACIFIC RIM: Tokyo, Japan +81 3 5424 3101

ASIA/PACIFIC: Hong Kong +852 2966 3210

Ordering Information

ORDERING INFORMATION

Part Number Description

MVME5500-0161 1 GHz MPC7455 PowerPC processor, 512MB SDRAM, Scanbe handles

MVME5500-0163 1 GHz MPC7455 PowerPC processor, 512MB SDRAM, IEEE handles

Memory

RAM5500-007 512MB memory mezzanine expansion card

MVME5500 Series VME Single Board Computer Data Sheet MVME5100 DS

Navigation menu

Versions of this User Manual:

Views

Navigation
