MP5
Self loading rifle
Cal. .22L.R. HV Front Sight
Muzzle
Rear Receiver Pin
Compensator
Trigger
Safety
Upper Receiver
Lower Receiver
Rear Sight
MADE BY CARL WALTHER
Ejection Port Handguard
Magazine
Buttstock
Charging Handle
Magazine
ReleaseTrigger Guard Buttpad
READ THE INSTRUCTIONS AND
WARNINGS IN THIS MANUAL CAREFULLY BEFORE USING THIS
FIREARM.
WARNING:
USA
Grip
Buttstock Latch
Compensator
2
CONTENTS
No. Contents Page
Identification 1
Safety Rules 3 - 11
1 Safety Operating Instructions 12
2 Inspection 13
3 Loading the Firearm 14
4 Insertion of the First Cartridge 14 - 15
5 Firing 15
6 Decocking the Hammer 15-16
7 Firearm with Empty Magazine 16
8 Unloading 16
9 Clearing Misfires 17
10 Settings - Sights, Stock, Bolt Speed, Optical Sight 18 - 19
11 Field Stripping the Firearm 20
12 Cleaning 21 -22
13 Storage 22
14 Repair 23
15 Warranty 23 - 24
16 Technical Data 25
17 Exploded View / Parts 26 - 27
18 Variants / Accessories 28 - 29
19 Contact back
3
YOUR SAFETY RESPONSIBILITIY
SAFETY IS YOUR NUMBER ONE RESPONSIBILITY!
AT HOME, IN THE FIELD, AT THE RANGE, OR ANYWHERE, THE FIRST CONCERN OF EVERY FIREARM OWNER SHOULD BE SAFETY. APPLY THE
FOLLOWING SAFETY RULES IN EVERY SITUATION, WITH ANY KIND OF FIREARM.
YOU MUST FOLLOW ALL OF THESE SAFETY RULES TO ENSURE THE SAFE USE OF YOUR FIREARM
SAFE GUN HANDLING IS YOUR PERSONAL RESPONSIBILITY!
SAFE USE OF A FIREARM IS YOUR PERSONAL RESPONSIBILITY AND THE FAILURE TO FOLLOW ALL OF THESE
BASIC SAFETY RULES MAY RESULT IN SEVERE PERSONAL INJURY OR DEATH TO YOU OR OTHERS. YOU ARE THE MOST IMPORTANT SAFETY
DEVICE WHEN IT COMES TO THE USE OF YOUR FIREARM. CARL WALTHER GMBH AND UMAREX USA WILL NOT BE RESPONSIBLE FOR ANY
PERSONAL INJURY, DEATH OR PROPERTY DAMAGE THAT RESULTS FROM:
(1) THE CRIMINAL OR NEGLIGENT USE OF THIS FIREARM;
(2) A DISREGARD OF THESE SAFETY INSTRUCTIONS AND WARNINGS;
(3) IMPROPER OR CARELESS HANDLING OF THIS FIREARM;
(4) THE USE OF NON-STANDARD, DEFECTIVE, IMPROPER OR RELOADED AMMUNITION; OR
(5) IMPROPER OR NEGLIGENT MODIFICATIONS OR REPAIR TO THE FIREARM.
YOUR SAFETY RESPONSIBILITY
WARNING:
WARNING:
WARNING:
4
- SAFE GUN HANDLING IS YOUR PERSONAL RESPONSIBILITY AT ALL TIMES.
Firearms are dangerous and can cause serious injury or death if they are misused or used inappropriately. Safety must be the first
consideration of anyone who owns or handles firearms.
- YOU ARE RESPONSIBLE FOR FIREARM SAFETY AT ALL TIMES.
You must undertake full-time responsibility for your firearm´s safety and security. You must protect yourself and all others against injury or
death from misuse of the firearm.
- SAFE FIREARM STORAGE IS YOUR RESPONSIBILITY.
You must secure firearms safely from children and unauthorized users. A lock has been provided for use with this firearm.
Never assume that the use of this lock is sufficient to safely secure your firearm. You must always evaluate your personal situation and
employ the security system(s) that meet your needs and prevent children and unauthorized users from gaining access to your firearm.
- Accidents are the result of violating the rules of safe gun handling and common sense.
- For your safety and the safety of others, NEVER RELY ON MECHANICAL FEATURES ALONE.
Only your safe gun handling habits will ensure the safe use of the firearm.
This is your responsibility.
- NEVER KEEP AMMUNITION IN THE SAME LOCATION AS THE FIREARM.
Store in a separate and secure place.
- DO NOT ALTER, MODIFY OR REPLACE ANY OF THE PARTS OF THE INTERNAL COMPONENTS OF YOUR
FIREARM
All work must be performed by an Umarex USA authorized gunsmith. If you do otherwise, improper functioning may occur and serious
injury may result.
- NEVER MANIPULATE, ADJUST OR CHANGE ANY OF THE INTERNAL COMPONENTS OF
YOUR FIREARM
including the firing pin, or sear. Improper manipulation of any internal component may affect the safety and reliability of your
firearm and may cause serious injury.
YOUR SAFETY RESPONSIBILITIY
5
YOUR SAFETY RESPONSIBILITY
- READ AND UNDERSTAND THESE INSTRUCTIONS BEFORE USING YOUR FIREARM
THE FAILURE TO FOLLOW THESE BASIC FIREARM SAFETY RULES MAY RESULT IN AN UNINTENDED DISCHARGE
WHICH COULD CAUSE SERIOUS PERSONAL INJURY OR DEATH TO YOU AND OTHERS.
- BEFORE HANDLING ANY FIREARM, UNDERSTAND ITS OPERATION.
Not all firearms are the same. Familiarize yourself with the mechanical features of any firearm you intend to use. If you feel uncertain
about any operational aspects of your firearm, please contact Umarex USA before proceeding with its operation.
- ALWAYS SAFELY STORE AND SECURE YOUR FIREARM.
Safe and secure storage of your firearm is one of the most important responsibilities of firearm ownership. It is a full-time responsibility.
You must always secure your firearm and ammunition separately so that they are not accessible to children or other unauthorized
persons. (See Safe Storage Instructions in this manual).
- ALWAYS KEEP YOUR FIREARM POINTED IN A SAFE DIRECTION.
NEVER point this firearm at any person. Never point at anything you do not intend to shoot whether or not the firearm is loaded.
This is particulary important when loading, unloading, or field stripping the gun. ALWAYS control the direction of the muzzle.
- NEVER PLACE YOUR FINGER ON THE TRIGGER OR INSIDE THE TRIGGER GUARD UNLESS YOU INTEND TO
FIRE. Ensure that other objects do not touch the trigger.
- ALWAYS BE SURE OF YOUR TARGET AND WHAT IS BEYOND IT.
Always be sure of where the bullet will strike and shoot only where there is a safe backstop free of obstructions, water or other surfaces
which can cause ricochets. Think of what the bullet may hit if it misses the target or ricochets. Do not fire into the sky.
- NEVER DISASSEMBLE YOUR FIREARM OR MANIPULATE THE INTERNAL COMPONENTS OF YOUR FIREARM
beyond the field stripping procedure outlined in this manual. Improper disassembly or manipulation of your firearm may be dangerous and
can lead to serious injury or death.
- NEVER CARRY OR STORE A FIREARM with the hammer or striker in the cocked position.
WARNING:
6
- NEVER ALLOW YOUR FIREARM TO BE USED BY INDIVIDUALS WHO HAVE NOT READ OR DO NOT UNDERSTAND THESE FIREARM
SAFETY RULES
- BE SURE ALL ACCESSORIES, SUCH AS HOLSTERS AND GRIPS, ARE COMPATIBLE
with the firearm and that the accessories do not interfere with the safe operation.
- ALWAYS USE THE CORRECT AMMUNITION FOR YOUR PARTICULAR FIREARM
as indicated by the marking on the barrel or receiver. Never use non-standard, reloaded, or “handloaded” ammunition which has not been
subjected to internal ballistic pressure testing.
- ALWAYS HAVE ADEQUATE VENTILATION.
Discharging firearms in poorly ventilated areas, cleaning firearms, or handling ammunition may result in exposure to lead and other
substances known to cause birth defects, reproductive harm, and other serious physical injury. Review the warning and labels for all
ammunition and cleaning products carefully.
- NEVER USE ALCOHOL OR DRUGS BEFORE OR WHILE SHOOTING.
Do not use your firearm if you are on any medication which impairs, even slightly, your mental and/or physical ability.
- ALWAYS WEAR EYE AND HEARING PROTECTION SPECIFIED FOR FIREARM USE
every time you discharge your firearm. Make sure others in the vicinity of where you will be shooting wear protection as well.
- NEVER ALLOW ANY ALTERATION OR REPLACEMENT OF PARTS IN YOUR FIREARM UNLESS
PERFORMED BY AN UMAREX USA AUTHORIZED GUNSMITH.
If you do otherwise, improper functioning of your firearm may occur and serious injury or death may result.
- NEVER CROSS OBSTACLES SUCH AS FENCES OR STREAMS WITH A LOADED FIREARM.
- Firearm safety training is available. Contact your dealer, law enforcement agency, local sportman´s club, or the NRA for availability.
- APPROPRIATE USE FOR YOUR FIREARM MEANS USING YOUR FIREARM FOR LEGAL PURPOSES.
YOUR SAFETY RESPONSIBILITIY
7
YOUR SAFETY RESPONSIBILITY
SAFE STORAGE & TRANSPORTATION
SAFE AND SECURE STORAGE OF YOUR FIREARM IS ONE OF THE
MOST IMPORTANT RULES OF FIREARM SAFETY. YOUR FAILURE TO FOLLOW THESE RULES
MAY RESULT IN SERIOUS INJURY OR DEATH TO YOU OR OTHERS.
- You must always secure your firearm and ammunition separately so that they are not accessible to children or other unauthorized
persons.
- Safe and secure storage and transportation of your firearm is your responsibility. It is a full-time responsibility.
- YOU SHOULD ALWAYS SECURE YOUR FIREARM IN A MANNER THAT WILL PREVENT UNAUTHORIZED ACCESS. ALWAYS STORE YOUR
FIREARM UNLOADED.
Your firearm and ammunition should be stored separately and in a manner inaccessible to children and unauthorized persons.
- ALWAYS MAKE CERTAIN THAT YOUR FIREARM IS SAFELY SECURED IN A MANNER SO AS TO PREVENT
UNAUTHORIZED ACCESS TO THE FIREARM. CARL WALTHER HAS PROVIDED A LOCK FOR THIS PURPOSE.
Please read and follow the instructions for the use of this lock. There are other alternative locks and safe storage containers available in
the marketplace which may be appropriate for your particular needs. Consult your local gunshop, hardware store or local police
department for guidance on the variety of other safe storage devices or practices which may be appropriate for your particular needs.
By purchasing this firearm you have taken on the responsibility of safely securing the firearm at all times and preventing its unauthorized
use. Never assume that the use of only a lock is sufficient to safely secure your firearm. It is your personal responsibility to select and use
whatever measure or practices that will best enable you to be absolutely certain that your firearm is secure at all times.
You are responsible to determine which devices or practices are appropriate
for the safe storage of your firearm and your ammunition.
WARNING:
8
NEVER LOCK A LOADED FIREARM AND NEVER LOAD A LOCKED FIREARM
- NEVER ASSUME THAT A ``HIDING`` PLACE IS A SECURE STORAGE METHOD.
Others may be aware of your storage location or come upon it by chance. It is your personal responsibility to use common sense when
storing and securing your firearm and ammunition and to always make sure that it is not accessible to children or other unauthorized
persons. Always make sure your firearm is unloaded before storing.
- ALWAYS FOLLOW THE LAW!!
You must be familiar with all local, state, and federal laws regarding the safe discharge, storage and transportation of your firearm.
Failure to know and follow the law may result in unauthorized access or use of your firearm by another. Obey all laws relating to the
storage and transportation of firearms. Your local police department or gunshop will furnish you with available information on storing
and/or transporting a firearm legally.
- NEVER TRANSPORT A LOADED FIREARM.
When transporting your firearm, be sure it is unloaded and the bolt or action is open.
- YOUR FIREARM IS YOUR RESPONSIBILITY.
Protect your firearm from theft or misuse by untrained or unqualified individuals.
PREPARATION FOR FIRING
THE FAILURE TO FOLLOW THESE FIREARM SAFETY
REQUIREMENTS WILL CAUSE SERIOUS INJURY OR DEATH TO YOU OR OTHERS.
- ALWAYS WEAR ADEQUATE AND PROPER EAR PROTECTION SPECIFIED
FOR FIREARM USE to prevent permanent damage to your hearing. Make sure others who are nearby are wearing ear protection as well.
- ALWAYS WEAR SAFETY GLASSES SPECIFIED FOR FIREARM USE, whether indoors or out. Safety glasses should protect your eyes from
the firing flash and particles associated with the discharge of ammunition. Failure to do so creates a risk of personal injury from particle or
debris ejection or ricochets.
YOUR SAFETY RESPONSIBILITIY
WARNING:
WARNING:
9
YOUR SAFETY RESPONSIBILITY
- NEVER SHOOT AT HARD SURFACES, WATER OR UP INTO THE SKY.
Always select a place to shoot that has a safe backstop and is free from obstruction and water surfaces which cause ricochets.
- ALWAYS BE AWARE OF PEOPLE AROUND YOU so that persons cannot accidentally walk into the line of fire.
- ALWAYS POSITION THE SHOOTER SO THAT ALL OTHERS ARE OUT OF THE LINE OF FIRE
and are not within an area where they may be struck by ricochets, or by ejected cases from other types of firearms.
- ALWAYS KEEP FINGERS AND OTHER PARTS OF YOUR BODY AWAY FROM THE MUZZLE AND AWAY FROM THE FIREARM BOLT AND
EJECTION PORT.
- ALWAYS BE ALERT AND ALWAYS FOLLOW THE SAFETY INSTRUCTIONS OF FIRING RANGE OFFICER.
- ALWAYS BE SURE THAT ALL ACTIONS OF FIREARMS ARE OPEN, THAT CHAMBERS ARE CLEAR OF AMMUNITION, MAGAZINES ARE
REMOVED, AND THE FIREARM IS POINTING IN A SAFE DIRECTION.
- ALWAYS BE ALERT.
Never shoot if you are tired, cold or impaired in any way.
- ALWAYS TREAT YOUR FIREARM AS IF IT WERE LOADED.
- NEVER USE ALCOHOL OR DRUGS BEFORE OR WHILE SHOOTING.
10
AMMUNITION
A GENERAL PRINCIPLES
- There are different types of ammunition for different types of firearms. Your firearm has been designed for ammunition of a specific type
and a specific caliber. It is important to select the proper ammunition for your firearm.
NEVER USE AMMUNITION NOT SPECIFICALLY DESIGNATED FOR USE IN YOUR FIREARM. FAILURE TO USE
THE CORRECT TYPE OR CALIBER OF AMMUNITION MAY CAUSE THE FIREARM TO JAM, FAIL TO FIRE OR EVEN GENERATE EXCESSIVE
PRESSURE WHICH CAN DAMAGE OR EVEN RUPTURE YOUR FIREARM, CAUSING PERSONAL INJURY, DEATH OR PROPERTY DAMAGE.
- You are responsible for selecting ammunition that meets industry standards and is appropriate in type and caliber for this firearm.
- Locate the caliber designation marked on the left side of the lower receiver. This information indicates the ammunition caliber that should
be used in this firearm.
B HANDLOADED OR RELOADED AMMUNITION
NEVER USE NON-STANDARD, RELOADED OR ``HANDLOADED`` AMMUNITION WHICH HAS NOT BEEN
SUBJECTED TO INTERNAL BALLISTIC PRESSURE TESTING. RELOADED OR HANDLOADED AMMUNITION MAY HAVE MANY
MANUFACTURING AND QUALITY VARIABLES (SUCH AS THE TYPE AND AMOUNT OF GUN POWDER). ANY AMMUNITION THAT IS
IMPROPERLY MANUFACTURED, EVEN IN THE SLIGHTEST DEGREE, MAY FAIL TO FIRE OR MAY GENERATE EXCESSIVE INTERNAL
PRESSURES WHICH CAN DAMAGE OR EVEN RUPTURE THE FIREARM, CAUSING PERSONAL INJURY OR DEATH TO THE SHOOTER OR
THOSE IN THE IMMEDIATE VICINITY.
YOUR SAFETY RESPONSIBILITIY
WARNING:
WARNING:
11
YOUR SAFETY RESPONSIBILITY
- Use only commercially manufactured ammunition with internal ballistic pressure which are in strict accordance with the specifications of
the Sporting Arms and Ammunition Manufacturers´ Institute (SAAMI). If you are uncertain, contact your ammunition supplier for verification.
C AMMUNITION SPECIFICS
- Use only ammunition specifically recommended for your firearm.
- Never mix ammunition.
- Never use a cartridge not specifically designated for use in your firearm.
- Pressure from the wrong type of ammunition may exceed the capability of your firearm and may damage or even rupture your firearm.
- In some cases, a round of ammunition not specified on your firearm may fit into the chamber. Firing ammunition not specified on your
firearm may cause it to rupture and cause serious injury or death to you or others.
- Always inspect your ammunition before using it. Never use dirty, corroded or damaged ammunition which can lead to a burst cartridge
which may cause damage to the firearm and personal injury or death.
.22 L.R. CALIBER CARTRIDGES HAVE A WIDE RANGE OF LOADS, FROM LOW VELOCITY FOR SPORT
SHOOTING AND MAXIMUM PRECISION TO VERY POWERFUL FOR A HIGH PROJECTILE VELOCITY. TO ENSURE RELIABLE OPERATION, A
SEMI-AUTOMATIC FIREARM MUST BE MATCHED TO A CERTAIN CARTRIDGE LOAD. FOR THIS REASON THE CAL. .22 L.R. HK MP5 HAS
BEEN DESIGNED FOR HIGH-QUALITY STANDARD AMMUNITION AND HV (HIGH VELOCITY) AMMUNITION, AND ONE CAN BE SURE OF
TROUBLE-FREE OPERATION ONLY WITH THESE TYPES. PLEASE NOTE THAT THESE RIFLES ARE NOT DESIGNED FOR THE USE OF CAL. .22
EXTRA LONG AMMUNITION.
WARNING:
12
OPERATING INSTRUCTIONS
1 Manual Safety
SAFE POSITION - turn the safety lever so it is pointing
to the word “SAFE” (fig. 1).
FIRE POSITION - turn the safety lever so it is pointing
to the word “FIRE” (fig. 2).
The safety can be operated from both sides of the firearm.
Left side = fig. 1 and 2
Right side = fig. 3 and 4
fi g. 4 Manual safety in
“FIRE” position
fi g. 3 Manual safety in
“SAFE” position
fi g. 1 Manual safety in
“SAFE” position
fi g. 2 Manual safety in
“FIRE” position
ALWAYS LEAVE THE MANUAL
SAFETY ENGAGED (ON “SAFE”) UNTIL YOU INTEND TO FIRE.
WARNING:
NEVER RELY SOLELY ON
MECHANICAL FEATURES ALONE - ALWAYS BE EXTREMELY
CAREFUL, USE SAFE GUN HANDLING PRACTICES, AND AVOID
SITUATIONS WHICH COULD LEAD TO AN ACCIDENT.
WARNING:
ALWAYS INSPECT THE CHAMBER OF YOUR FIREARM AFTER THE MAGAZINE HAS BEEN REMOVED FROM THE
GUN. MAKE SURE THAT NO CARTRIDGE IS LEFT IN THE CHAMBER.
WARNING:
13
INSPECTION
2 Inspection
Functional Inspection:
1. Bolt movement: Make sure the firearm is ON SAFE, then remove the magazine and retract the bolt by pulling back the charging handle.
Release the charging handle to return the bolt fully forward into battery.
2. Bolt catch: Insert the empty magazine, retract the bolt by pulling back the charging handle. The bolt locks back in rearmost position.
3. Decocking: Make sure that the firearm is ON SAFE and unloaded (magazine removed, chamber cleared, empty chamber indicator
(blue tab) is installed, and barrel clear of any obstructions)!
Pull charging handle rearward and then release allowing it to freely move forward. Place safety in the “FIRE” position, make sure the
muzzle is pointed is a safe direction. Pull the trigger. The hammer drops to a de-cocked position. Put back on “SAFE”.
BEFORE LOADING, MAKE SURE THAT THE FIREARM IS ALWAYS POINTED IN A SAFE DIRECTION, IS ON SAFE,
AND IS UNLOADED (MAGAZINE REMOVED, CHAMBER CLEARED, EMPTY CHAMBER INDICATOR (BLUE TAB) IS INSTALLED, AND BARREL
CLEAR OF ANY OBSTRUCTIONS).
WARNING:
NEVER PUT YOUR HAND IN FRONT OF THE MUZZLE.
WARNING:
14
fi g. 7
LOADING THE FIREARM
3 Loading the Firearm
fi g. 5
fi g. 6
4 Loading the chamber with the first cartridge
Pick up the firearm with your shooting hand and point the muzzle in a safe direction. Use your other hand to
retract and release the bolt with the help of the charging handle (fig. 8). Never put your hand in front of the
muzzle. As the bolt travels forward it inserts the first round into the chamber. The hammer is now cocked.
Leave the safety in the safe position until you are ready to fire.
Press magazine release and remove empty magazine (fig. 5). Use the side-mounted button to push the
follower down. Insert the cartridge under the magazine lips, at the same time pushing down the follower
(fig. 6). Do not use excessive force. Remove empty chamber indicator (blue tab). Insert the loaded
magazine until the magazine catch locks it in position (fig. 7). After inserting a magazine, always test to
make sure it is locked in place by giving it a firm tap on the bottom of the magazine.
BEFORE LOADING, MAKE SURE THAT THE FIREARM IS ALWAYS POINTED
IN A SAFE DIRECTION, IS ON SAFE, AND IS UNLOADED (MAGAZINE REMOVED, CHAMBER CLEARED,
EMPTY CHAMBER INDICATOR (BLUE TAB) IS INSTALLED, AND BARREL CLEAR OF ANY OBSTRUCTIONS).
WARNING:
NEVER PUT YOUR HAND IN FRONT OF THE MUZZLE.
WARNING:
ALWAYS LOAD A ROUND INTO THE CHAMBER BY FEEDING IT FROM THE
MAGAZINE. FAILURE TO FOLLOW THIS WARNING CAN RESULT IN SEVERE INJURY OR DEATH TO YOU OR
OTHERS. NEVER ATTEMPT TO LOAD THE FIREARM BY INSERTING A ROUND INTO THE OPEN EJECTION
PORT.
WARNING:
15
fi g. 8
LOADING / FIRING / DECOCKING
5 Firing
Grasp firearm with one hand on forearm and other hand on grip with index finger resting along outside of
trigger guard. Raise firearm and pull buttstock firmly into shoulder.
Aim at a safe target. Move the manual safety to the fire position. Squeeze the trigger slowly and maintain
the pressure until the round is fired.
Your firearm loads another round immediately after firing.
- You may continue to fire by pulling and fully releasing the trigger until the magazine is empty. fi g. 9
6 Decocking
- If you decide not to fire after the hammer has been cocked or if you decide to suspend firing, keep the firearm pointed in a safe direction.
- Remove your finger from within the trigger guard.
- Place the manual safety in the “SAFE” position and remove the magazine.
- Pull charging handle rearward to eject any remaining cartridge(s).
MP5 CAL. .22L.R. ARE DESIGNED SO THAT THEY ARE ABLE TO FIRE
WHEN THE MAGAZINE IS REMOVED. THEREFORE, IF THE MAGAZINE IS REMOVED FROM THE FIREARM
AND THERE IS A LOADED ROUND IN THE CHAMBER, IT WILL FIRE IF THE TRIGGER IS PULLED. AFTER
INSERTING A MAGAZINE, ALWAYS TEST TO MAKE SURE IT IS LOCKED IN PLACE BY APPLYING SOME
REMOVAL PRESSURE TO THE MAGAZINE.
WARNING:
YOUR FIREARM IS NOW READY TO FIRE. KEEP YOUR FINGER OFF THE
TRIGGER AND OUT OF THE TRIGGER GUARD UNTIL YOU ARE READY TO FIRE.
WARNING:
- If you wish to stop, release trigger, remove finger from trigger guard, and set safety selector to “SAFE” position. If you have fired the last
round from the magazine, the bolt will be held in the rearmost position so that the firearm can quickly be reloaded by replacing the empty
magazine with a full magazine, or the chamber can be inspected to ensure it is empty (fig. 9).
16
EMPTY MAGAZINE / UNLOADING
fi g. 11
fi g. 10 Manual safety in
“FIRE” position
- Make sure that the firearm is unloaded (magazine removed, chamber cleared, empty chamber indicator
(blue tab) installed, and barrel clear of any obstructions)!
- You must be certain there is no cartridge in the chamber or obstructions in the barrel. Remember that
any time you release the bolt while a magazine containing cartridges is in the firearm, you will have
reloaded the firearm and it will be capable of firing.
- Place the manual safety in the “FIRE” position (fig. 10).
- Squeeze trigger to decock the firearm.
- Place the manual safety in the “SAFE“ position.
- The firearm may now be transported safely.
NOTE: The gun has an internal bolt catch. To put the bolt into its forward position, remove the magazine,
make sure the chamber is clear, insert the empty chamber indicator (blue tab), then retract the charging
handle and release it.
KEEP THE FIREARM POINTED IN A SAFE DIRECTION WHEN DECOCKING. FAILURE TO DO THIS CAN RESULT IN
SERIOUS INJURY OR DEATH.
WARNING:
7 Firearm with Empty Magazine
After the last round has been fired, the bolt catch holds the bolt in the open position (fig. 11).
Place the manual safety in the “SAFE” position.
Continue shooting - Replace the empty magazine with a full one. Pull bolt rearward and release with the
help of the charging handle (fig. 8), the bolt will travel forward and load the
chamber with the first round. Keep your firearm in your shooting hand, finger off
the trigger and the firearm pointed in a safe direction so that there is no danger to
other persons.
Discontinue shooting - Remove magazine and inspect the chamber to verify it does not contain any
ammunition (fig. 11). Close the bolt and decock hammer as described in section 6.
17
8 Unloading
Point the muzzle in a safe direction. Make sure the firearm is ON SAFE. Remove the magazine. Ensure that the chamber is empty by pulling back
the charging handle to visually inspect the chamber (fig. 11). Place empty chamber indicator (blue tab) into the empty chamber (fig. 23). Keep
firearm pointed in a safe direction. Retract and release the charging handle so that the bolt moves into battery. Push the manual safety to the
“FIRE” position (fig. 10) and squeeze trigger to decock the firearm. The firearm may now be carried safely.
9 Clearing Misfires
- If a cartridge fails to fire, place the manual safety in the “SAFE” position, wait 30 seconds while keeping the muzzle pointed in a safe
direction.
- Remove the magazine.
- Keep your finger off the trigger and out of the trigger guard.
- Grasp the bolt with the charging handle and briskly pull it fully rearward to eject the misfired round. Check the barrel chamber
and bore for any obstructions by passing a cleaning rod from muzzle to ejection port. Never look down the barrel from the muzzle end.
- You must be certain there are no cartridges in the chamber or obstructions in the barrel. Remember that any time you release the bolt while
a magazine containing cartridges is in the firearm, you will have reloaded the firearm and it will be capable of firing.
CLEARING MISFIRES / SETTINGS
IF YOUR FIREARM GIVES ANY INDICATION THAT IT IS NOT PERFORMING PROPERLY OR THE OPERATION OF
YOUR FIREARM HAS CHANGED “THE WAY IT FEELS OR SOUNDS”, STOP FIRING. MAKE SURE THE FIREARM IS POINTED IN A SAFE
DIRECTION, UNLOAD THE FIREARM AND HAVE IT INSPECTED AND TEST FIRED BY A GUNSMITH QUALIFIED TO PERFORM SERVICE ON HK
MP5 RIMFIRE RIFLES MADE BY CARL WALTHER.
WARNING:
NEVER TRY TO RE-USE A MISFIRED CARTRIDGE.
WARNING:
18
SETTINGS
fi g. 13
10.2 Setting of the Rear Sight
The elevation is adjusted by turning the sight drum (fig 12). Turning the drum clockwise lowers point-of-
impact and turning drum counter-clockwise raises point-of-impact.
The windage is adjusted by turning the windage screw on the right side of the rear sight (fig. 13). Before
adjusting the sight for windage the locking screw on top of the sight must be loosened (fig.13). After the
windage adjustment is made, retighten the locking screw. Turning the windage screw clockwise moves
point-of-impact left and turning counter-clockwise moves point-of-impact right.
10.3 Setting of the Retractable Stock
The length of the buttstock can be adjusted. Pushing the buttstock latch allows the buttstock to be
positioned in either an extended or closed position (fig. 14).
fi g. 14
1.
2.
10 Settings
10.1 Setting the Rear Sight
The rotating rear sight drum provides four various diameter apertures. Adjusting the rear sight apertures is
done by rotating the rear sight drum (fig 12).
fi g. 12
19
FIELD STRIPPING
10.4 Setting of the Bolt Speed
The bolt speed can be adjusted for different ammunition requirements. To reach the screw for bolt speed
adjustment the gun has to be disassembled as described in Section 11 Field Stripping.
Only adjust the bolt speed if problems are encountered when firing a different type of ammunition.
For high velocity ammunition, use the correct size Allen wrench (hex key) to increase the bolt speed by
turning the screw clockwise (fig. 15). First, position the adjustment screw so that the screwhead is flush
with the surrounding surface. Then, incrementally turn the screw clockwise up to a maximum of 9
complete revolutions to achieve maximum performance. Do not turn more than nine (9) turns
clockwise.
For standard ammunition, use the correct size Allen wrench (hex key) to decrease the bolt speed by
turning the screw counter clockwise (fig. 15). The screwhead must never rise above “flush” with the
surrounding surface.
fi g. 15
To mount an optical sight you need a low profile mount (Section 18.2 Accessories). Place the low profile
mount on the lugs of the upper receiver and secure it by tightening the bolts on the four clamps (fig. 16).
Then place the optical sight on the mount and secure in the usual manner (fig. 17).
fi g. 16
10.5 Mounting an Optical sight
fi g. 17
20
FIELD STRIPPING
To disassemble insert an empty magazine, pull back the bolt to its rearmost position with the charging
handle. Remove the magazine for further disassembly. Visually inspect to verify that no ammo remains
anywhere in the rifle. Push the rear receiver pin out of the gun to the right (fig. 18-19) , buttstock must be
removed so that upper receiver pivots upward.
NOTE: Further disassembly is not necessary or recommended and will void your warranty.
If the compensator is removed, to reinstall: hand-tighten and then use the supplied wrench to further
tighten by only 1/4 turn (fig. 20).
fi g. 19
fi g. 18
fi g. 20
11 Field Stripping
ALWAYS FOLLOW THE DISASSEMBLY INSTRUCTIONS EXACTLY. NEVER DO
ANYTHING BEYOND WHAT YOU ARE SPECIFICALLY INSTRUCTED TO DO IN THIS MANUAL. NEVER ALTER
OR MODIFY THE PARTS IN YOUR FIREARM.
WARNING:
ALWAYS WEAR EYE PROTECTION THAT IS SPECIFIED FOR USE WITH
FIREARMS, EVERY TIME YOU HANDLE YOUR FIREARM FOR CLEANING AND MAINTENANCE.
WARNING:
PRIOR TO DISASSEMBLY, PLACE THE MANUAL SAFETY IN THE SAFE
POSITION, TAKE OUT THE MAGAZINE AND CHECK THAT THE FIREARM IS NOT LOADED.
WARNING:
21
- Verify gun is ON SAFE.
- Insert EMPTY magazine and retract charging handle so that bolt assembly remains in open position.
- Remove magazine.
- Visually inspect to verify that no ammo remains anywhere in the rifle.
- Remove the rear receiver pin and the buttstock so that the receiver pivots upward.
- Thoroughly clean the bolt assembly area with a brush and cloth (aerosol gun scrubber works great) to remove powder residue and debris.
- Clean the barrel with bore solvent utilizing a flexible cleaning rod inserted through breech end of barrel (where bullet seats).
NOTE: Cleaning the barrel from the muzzle end requires a bore brush that does NOT exceed 1-inch in the length. Using a brush
exceeding this length will result in the brush being lodged in the breech area.
Remove fouling from breech, magazine lips, follower, and receiver with a brush and a cloth. Clean the barrel with bore solvent and a brush and
then dry it with cleaning patches; always begin at the chamber. Repeat until barrel is clean. Apply a thin coat of oil to all metal parts.
Reassemble firearm and check for proper function.
12 Cleaning
In order to keep the firearm functional and to extend its service life, the firearm should be cleaned and
maintained at regular intervals.
CLEANING
BEFORE CLEANING, MAKE SURE THAT THE FIREARM IS ALWAYS POINTED IN A SAFE DIRECTION, IS ON SAFE ,
AND IS UNLOADED (MAGAZINE REMOVED, CHAMBER CLEARED, AND BARREL CLEAR OF ANY OBSTRUCTIONS).
WARNING:
22
MOUNTING ACCESORIES / CLEANING / STORAGE
Always keep and store your firearm in an unloaded condition with the safety in the “SAFE” position. Keep
the firearm and ammunition away from children and unauthorized persons. Firearms should be stored
separately from ammunition. Always store your firearm with the empty chamber indicator (blue tab) in
the chamber to make sure no cartridge is loaded (fig. 23).
fi g. 23
- Apply 4 drops of gun oil to the main spring (fig. 21).
- Apply 1 drop of gun oil to the extractor (fig. 22).
- Apply 1 drop of gun oil to each end of the firing pin assembly as
well as the moving parts of the buttstock. (fig. 21-22).
- Reassemble rifle by installing the rear pin.
- Wipe down exterior surface of rifle with gun oil.
- Insert the blue tab (empty chamber indicator), pull the charging
handle rearward, then release to close the bolt assembly.
NOTE: Do not apply more oil to the recoil spring, extractor or firing
pin assembly than is mentioned above. Doing so will result in an
13 Storage
NEVER LEAVE A LOADED FIREARM UNATTENDED!
WARNING:
fi g. 21 fi g. 22
increased accumulation of powder residue which can lead to misfires and jamming issues.
23
REPAIR / WARRANTY
14 Repair
Do not return defective or damaged product to the dealer. If your firearm needs repair, call Umarex USA (479) 646-4210 and ask for the Service
Department.
15 Warranty
LIMITED ONE YEAR WARRANTY
This product is warranted to the original owner for 1 year from date of purchase against defects in material and workmanship and is not
transferable.
WHAT IS COVERED
Replacement parts and labor.
WHAT IS NOT COVERED
Parts, labor, and shipping charges to Umarex USA for defective product and damages caused by abuse or failure to perform normal mainte-
nance as well as any other expense. Consequential damages, or incidental expenses, including damage to property. Umarex USA will not be
responsible for unauthorized adjustments or modifications, use of defective or improper ammunition, corrosion, criminal misuse, negligence,
resale, and/or use under the influence of drugs or alcohol. Some states do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitation or exclusion may not apply to you. Umarex USA reserves the right to determine what constitues ordinary wear
and tear.
WARRANTY CLAIMS
Warranty Claims and Repair for U.S. customers. Call Umarex USA (479)-646-4210 and ask for the Service Department. If it is determined a
return is necessary, you will be issued a Return Authorization Number. Write this number boldly on the box and return the product prepaid to
Umarex USA. Your name, address, phone number and a note with the model number, serial number, and explanation of the defect found must
be included in the package. Also include a copy of the original purchase receipt along with a check in the amount of $24.95, payable to Umarex
USA, to cover return shipping and handling charges.
ONLY AN UMAREX USA AUTHORIZED GUNSMITH SHOULD INSPECT AND REPAIR YOUR FIREARM!
WARNING:
24
WARRANTY
IMPLIED WARRANTIES
Any implied warranties, including the implied warranties of merchantability and fitness for a particular purpose, are limited in duration to 1 year
from date of retail purchase. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE
LIMITATIONS MAY NOT APPLY TO YOU. TO THE EXTENT ANY PROVISION OF THIS WARRANTY IS PROHIBITED BY FEDERAL STATE, OR MUNICIPAL
LAW WHICH CANNOT BE PREEMPTED, IT SHALL NOT BE APPLICABLE. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO
HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE AND COUNTRY TO COUNTRY.
UNDER NO CIRCUMSTANCES SHALL UMAREX USA AND CARL WALTHER GMBH BE RESPONSIBLE FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGES WITH RESPECT TO ECONOMIC LOSS, INJURY, DEATH OR PROPERTY DAMAGE, WHETHER AS A RESULT OF BREACH OF THIS
WARRANTY, NEGLIGENCE OR OTHERWISE.
NOTE: All liability is excluded in the event that the instructions and warnings in this manual are not observed.
SHIPPING GUIDELINES
• Ensure that the firearm is unloaded.
• Do not attempt to ship a firearm via US Postal Service; only federally licensed firearm dealers may ship a firearm by US Postal Service.
• DO NOT SHIP ANY AMMUNITION.
• Enclose a letter which includes your full name and address (no P.O. Boxes, please), daytime telephone number, e-mail address, the serial
number of the firearm, and details of the problem experienced (stating the brand and type of ammunition used when the problem occurred)
or work desired.
• Record the serial number before shipping, in case you wish to check on the repair status of your firearm.
• Please remove all custom parts and accessories, such as stocks, special sights and scopes, or slings from your firearm before returning.
• Place the firearm in its original box and then pack it securely within another container to avoid damage.
• The package must NOT bear any markings which indicate the identity of the contents.
• It is recommended that shipments be insured by the owner, since Umarex USA will accept no responsibility for loss or damage in transit.
• It is most important that you comply with federal, state, and local laws and regulations. The following guidelines are meant to help, but you
must seek assistance from the appropriate authorities if necessary.
• If your firearm must be replaced, it may be necessary to ship the replacement to a dealer rather than directly to you. You will be requested to
furnish a signed FFL (Federal Firearms License) from your dealer in such an instance.
25
TECHNICAL DATA
HECKLER & KOCH
MP5 A5
HECKLER & KOCH
MP5 SD6
caliber .22 L.R. HV .22 L.R. HV
action blowback blowback
trigger single stage trigger single stage trigger
trigger pull 6.5 - 8.4 lbs (2950 g - 3810 g) 6.5 - 8.4 lbs (2950 g - 3810 g)
magazine capacity 25 rounds 25 rounds
dimensions (L/H/W) 26.8-33.8 / 8.5 / 2.2 inch
(680 - 860 / 216 / 55 mm)
26.8-33.8 / 8.5 / 2.2 inch
(680 - 860 / 216 / 55 mm)
barrel length 16.1 inch (409 mm) 16.1 inch (409 mm)
sight radius 13.2 inch (335 mm) 13.2 inch (335 mm)
diameter of rear sight aperture 0.24/0.13/0.11/0.1 inch
(6 / 3.4 / 2.9 /2.5 mm)
0.24/0.13/0.11/0.1 inch
(6 / 3.4 / 2.9 /2.5 mm)
front sight width 0.07 inch (1.8 mm) 0.07 inch (1.8 mm)
weight w/out mag 7 lbs (3200g) 6.7 lbs (3060 g)
magazine weight (empty) 2.5 ounce (70 g) 2.5 ounce (70 g)
16 Technical Data
26
EXPLODE VIEW
17 Exploded view/ Parts
17.1 Exploded view
MP5
27
DESIGNATION
577.70.04
578.10.03.1
576.20.39.1
578.10.01.1
578.11.01
578.11.11
578.11.06
576.20.16.3
578.10.02.1
578.10.06.1
578.10.08.1
578.10.07.1
578.10.12.1
578.10.13.1
578.10.04.1
578.10.05.1
578.30.08.1
578.30.03.1
578.30.05.1
578.70.20
578.72.20
578.30.09
578.30.01.1
578.32.01.1
578.30.02.1
578.32.02.1
578.50.01.1
578.51.01.1
578.50.04.1
1
5
9
10
11
19
24
26
27
28
29
30
31
32
33
34
35
36
37
40
44
45
46
47
48
578.51.05
578.52.05
578.50.03.1
578.40.03.1
576.50.02
578.50.02
576.40.09.1
578.10.10.1
578.40.01.1
578.45.01.0
578.10.11.1
576.40.17.0
506.40.05.1
576.40.25.1
576.40.06.3
576.40.07.1
578.40.05.1
578.40.04
578.40.02.1
578.45.02.0
576.40.14.1
576.40.15.3
576.40.18.1
576.40.11.0
576.20.36.0
578.20.01.1
578.20.07.1
576.20.28.3
578.20.04
576.20.40.1
49
51
52
53
54
55
56
57
58
59
60
61
62
64
65
69
70
71
72
73
74
75
76
77
80
576.20.14.1
578.20.05.1
578.20.06.1
576.20.29.1
578.20.10.0
576.20.15.3
576.20.04
576.20.18.3
570.20.18.1
570.20.23.3
578.20.24.3
578.20.22.1
578.20.20.1
578.20.23.1
576.20.41.1
578.20.09.2
576.40.08.3
578.20.03.0
578.20.02.1
576.10.08.3
578.20.21.3
512.20.42.1
576.100.04.1
576.20.24.3
506.20.47.3
578.60
578.61
578.30.11.3
512.50.06.2
578.50.05.2
578.71.22.1
576.20.21.1
81
82
83
84
85
86
87
88
89
91
92
93
94
95
97
98
99
101
102
103
104
105
106
107
108
109
110
111
112
113
rear sight
receiver top
system screw
receiver right
Back plate
buttstock
push pin
screw nut
receiver left
magazine catch
magazine catch spring
magazine catch button
screw
screw
spring guiding rod
spring guiding rod bolt
cocking handle spring
cocking handle support
cocking handle
front sight
front sight SD
push pin
forearm
forearm SD
cocking handle tube
cocking handle tube SD
barrel sleeve Int.
barrel sleeve USA
muzzle nut
fake silencer
fake silencer SD
lug tube
bolt
barrel USA
barrel Int.
system screw
magazine release lever
slide housing right
slide housing right Russia
bushing magazine release lever
extractor
bolt for extractor
spring
spring adjustment screw
main spring bolt
main spring
slide
slide housing left
slide housing left Russla
spring for slide catch
pin for slide catch
adjustment pin
slide catch
ejector
trigger housing right
bumper
pin
hammer
hammer spring
hammer spring receptor
safety
safety detent pin
spring
disconnector
pin
trigger sear
pin
spring
screw nut
pin
safety lever right
pistol grip
safety lever left
pin
spring
slide cover pin
trigger
trigger housing left
lock washer
screw
simulating device
Wench SW13
allen wrench SW4
allen wrench SW2.5
SA magazine 25 rd
SA magazine 10 rd
Roll pin
O-Ring
O-Ring
Front sight post 2
disconnector spring
17.2 Parts
28
MP5 A5
• Metal Receiver
• Retractable Stock
• Adjustable Rear Sight (Windage, Elevation)
MP5 SD6
• Metal Receiver
• Adjustable Rear Sight (Windage, Elevation)
• Retractable Stock
18 Variants and accessories
18.1 Variants
VARIANTS
29
MP5 Magazine
10 Round 2245310
25 Round 2245311
Sling Swivel
2245331
Fixed Stock
2245332
Walther PS 55 Scope
2300580
RIS for MP5 A5
2245330
Walther PS 22 Point Sight
2300577
Low Profile Mount
2245334
HK .22 LR Forearm Grip
2245333
18.2 Accessories
ACCESSORIES
MP5
All technical changes and modifications reserved.
8.578.80.02 rev. D
July 2011
CONTACT
HK MP5 .22 Rimfire Rifles
made by Carl Walther - Germany
under license from Heckler & Koch
Distribution and repair service by:
UMAREX USA Inc. www.umarexusa.com www.hk22rimfire.com
Sales + Warranty Service
7700 Chad Colley Boulevard / Fort Smith, AR 72916 / USA Phone: 479-646-4210 / Fax: 479-646-4206
This INSTRUCTION MANUAL should always accompany the firearm and be
transferred with it upon change of ownership or when presented to another person.
A copy of the INSTRUCTION MANUAL is available FREE upon request from:
