The Power Tool For Contact & Control
GP329 Select V
GP339 Select V
ACCESSORISE AND ENHANCE YOUR RADIO’S CAPABILITIES
A comprehensive range of accessories is available so that Motorola’s
GP Professional Radio series for Select V can be customised to suit
your unique applications. Boost your productivity today by adding the
proper headsets, microphones, batteries, chargers or carry cases.
Motorola accessories are built with the highest quality standards and
are specially engineered to ensure maximum performance for your
radio, no matter what profession you’re in.
KEY ACCESSORIES
Multi-unit Charger
PMTN4028
Rapid-rate Desktop
Charger
PMTN4025
Remote Speaker
Microphone
PMMN4002
Light Weight Head Set
AZRMN4018
NiMH Battery &
Belt Clip
PMNN4008
Carry Case
HLN9701
Portable Military Standards 810 C, D, & E
810 C 810 D 810 E
Applicable MIL-STD Methods Procedures Methods Procedures Methods Procedures
Low Pressure 500.1 1 500.2 2 500.3 2
High Temp 501.1 1, 2 501.2 1, 2 501.3 1, 2
Low Temp 502.1 1 502.2 1, 2 502.3 1, 2
Temp. Shock 503.1 1 503.2 1 503.3 1
Solar Radiation 505.1 1 505.2 1 505.3 1
Rain 506.1 1, 2 506.2 1, 2 506.3 1, 2
Humidity 507.1 2 507.2 2, 3 507.3 2, 3
Salt Fog 509.1 1 509.2 1 509.3 1
Dust 510.1 1 510.2 1 510.3 1
Vibration 514.2 8, 10 514.3 1 514.4 1
Shock 516.2 1, 2, 5 516.3 1, 4 516.4 1, 4
MOTOROLA and the stylized M logo are trademarks of Motorola, Inc.
© Motorola, lnc. 2003
Visit us at www.motorola.com/cgiss/AP
AC3-04-009Rev1
GP329 & GP339 Specifications
GENERAL -VHF, UHF
*Frequency: 136-174 / 403-470 / 450-527
Channel Capacity: GP329 is 16 Channels GP339 is 255 Channels
Power Supply: Provided through rechargeable battery - 7.5V
DIMENSIONS: H x W x D (Radio footprint height excluding knobs)
With Standard High Capacity NiMH Battery: 137mm x 57.5mm x 37.5mm
With Ultra High Capacity NiMH Battery: 137mm x 57.5mm x 40.0mm
With NiCD Battery: 137mm x 57.5mm x 40.0mm
With LiIon Battery: 137mm x 57.5mm x 33.0mm
WEIGHT: GP329 GP339
With Standard High Capacity NiMH Battery: 420 gm 428 gm
With Ultra High Capacity NiMH Battery: 500 gm 508 gm
With NiCD Battery: 450 gm 458 gm
With LiIon Battery: 350 gm 358 gm
AVERAGE BATTERY LIFE @ 5/5/90 CYCLE Low Power High Power
With Standard High Capacity NiMH Battery: 11 hours 8 hours
With Ultra High Capacity NiMH Battery: 14 hours 11 hours
With NiCD Battery: 12 hours 9 hours
With LiIon Battery: 11 hours 8 hours
Sealing: Withstands rain testing per MIL-STD 810 C / D / E and IP54
Shock and Vibration: Protection provided via impact resistant housing exceeding MIL-STD 810 C / D / E and TIA/EIA 603
Dust and Humidity: Protection provided via environment resistant housing exceeding MIL-STD 810 C / D / E and TIA/EIA 603
TRANSMITTER RECEIVER
SPECIFICATION VHF/UHF SPECIFICATION VHF/ UHF
*Frequency 136-174 / 403-470 / 450-527 *Frequency 136-174 / 403-470 / 450-527
Frequency separation Full bandsplit Frequency separation Full bandsplit
Channel spacing 12.5/20/25kHz Sensitivity (12 dB SINAD) EIA .25µV
Freq Stability: (-30oC to 60oC,+25oCRef.) +/- 0.00025% Intermodulation(EIA) 70 dB
Power 136-174 - 5W Adjacent Channel Selectivity 70 dB @ 25kHz
403-470 - 4W 60 dB @ 12.5kHz
Modulation limiting ±2.5 @ 12.5 kHz/±4.0 @ 20 kHhz/±5.0 @ 25 kHz Spurious Rejection 70 dB
FM Hum & Noise -40 dB Rated Audio 500 mW
Conducted/Radiated Emission -66 dBw Audio Distortion 3%
Modulation FCC Type 12.5 kHz 11K0F3E 25 kHz 16K0F3E Hum and Noise -45 dB @ 12.5kHz, -50 dB @ 25kHz
Audio Response ( from 6 dB/octave +1 to -3 dB Audio Response (300-3000Hz) +1 to - 3 dB
pre-emphasis 300-3000Hz) Conducted Spurious Emission -57 dBm < 1Ghz/-47 dBm > 1 Ghz/FCC Part 15
Audio Distortion 3%
* Availability subject to country law and regulations.
Radios meet applicable regulatory requirements.
All specifications shown are subject to change without notice. Specifications are not representative of all radios and may vary in different radios.
GP Professional Radio Series for Select V
Effective communication is the cornerstone for
success in any organisation.
With Motorola’s GP Professional Radio series
for Select V - the GP329 and GP339 portable
radios, in your communication solution,
enhanced productivity and operational success
are only a push of a button away.
You can now enjoy instantaneous contact with
your work teams, ensuring always that
productivity and efficiency levels of your
operations are kept high.
The GP Professional Radio series for Select V
is compatible with Private-Line and 5-tone
Selective signalling protocols.
KEY FEATURES
Clear Crisp Audio Quality
Sound quality is critical for effective communications.
The GP Professional Radio series for Select V is
specially equipped with Motorola’s voice compression
and expansion technology called X-PAND™. The X-
PAND™ feature enables crisper, clearer and stronger
audio quality, allowing users to continue
communicating even in noisy conditions. In addition,
low-level expansion enables further improvements
in audio quality by reducing unwanted background
noise usually heard during pauses in conversation.
Programmable Channel Spacing
(12.5/20/25 kHz)
The series allows programmable channel spacing of
12.5/20/25 kHz; offering flexibility and easy migration
of channel spacing requirements when the need arises.
Option Board Expandability
Existing capabilities offered by the GP Professional
Radio series can be expanded by including one of
the following option boards:
•Encryption for message security.
•Voice Storage board that allows users to store,
retrieve and delete voice messages easily.
Lithium Ion Battery Option
Accompanied with the latest technology in battery
chemistry, Motorola’s GP series offers a Lithium Ion
battery option which provides the same talk time at
a lighter weight.
Lone Worker
Customised to meet your specific needs, this feature
provides added security and safety for individuals
who work remotely from their team as well as for
those who work in hazardous conditions. The radio
provides continued normal operations when the
buttons are pressed regularly but will sound a warning
signal if there’s no response after a pre-determined
time lapse. Should there be no further response, the
radio automatically makes an emergency call.
Whisper
The radio microphone’s sensitivity is increased,
allowing users to speak quietly into a radio while
still being heard clearly over the air.
Stun/Unstun
Provides an added security to prevent the abuse of
the radio system and can only be activated by the
system manager or administrator. In the event a
radio is stolen or used illegally, the system
administrator can send a signal to stun the radio,
making it incapable for use. Conversely, the radio
can be returned to operational use by sending an
unstun signal or by returning the radio for
reprogramming.
The communication solution for all your needs
ACCELERATED LIFE
TESTING
Stringent Motorola’s
Accelerated Life Testing
simulating five years of
hard use in real life, EIA
RS-316B in Shock,
Vibration, Dust, Humidity,
IP54 for Sealing.
ISO 9001 STANDARD
Compliance with ISO 9001 Standard - an
international quality system assurance on
design, development, production,
installation and servicing of a product.
•
M
e
e
t
s
I
S
O
M
a
n
u
f
a
c
t
u
r
i
n
g
&
D
e
s
i
g
n
Q
u
a
l
i
t
y
S
y
s
t
e
m
MIL-STD 810C, D AND E
Stamp of approval from the U.S. Military
for use in rough environments.
Motorola: Reliability & Quality
GP329
GP339
GP329 - YOUR EASY-TO-USE &
COST EFFECTIVE SOLUTION
The GP329 radio offers a practical two-way radio
solution for professionals who need a rugged, reliable
radio to stay in contact. Equipped with user-friendly
features and intuitive programmable buttons for easy
navigation, the GP329 increases productivity by
streamlining your radio use and enabling you to
concentrate on the job at hand.
With X-PAND™, the GP329 assures you of crisp, clear
audio quality even in the noisiest conditions. It also
offers 16 channels in addition to a basic array of
signalling capabilities. With adjustable power levels,
you always have control over your radio usage.
Moreover, with an LED indicator and an alert to notify
you when your battery power is running low, you’ll
never be caught with dead air, especially during mission-
critical situations or emergencies.
The GP329 radio - it’s easy communication at your
finger tips.
GP339 - YOUR VERSATILE COMMUNICATION
COMPANION
The GP339 is vital for growing organisations due to its
wide range of versatile offerings and its ability to
accommodate 255 different communication channels.
No matter where it is used, in the rugged environment
of the construction site or in the posh elegance of a
hotel, the GP339 ensures world-class reliability and
efficiency that is very much associated with Motorola’s
series of professional radios.
Like the GP329, the GP339 offers superb audio clarity
through the X-PAND™ feature. The GP339 can store
commonly-used contact lists and up to 100 individual
caller-IDs and phone numbers for immediate access.
Time-conscious users can also rely on programmable
buttons for key features and the call timer feature for
efficient management of airtime.
The GP339 radio - adaptability at your command.
GP329 and GP339 - SERVING YOUR
COMMUNICATION NEEDS
Signalling
The radio software encompasses Private Line and
5-tone Selective signalling.
Channel Scan
Enables activity on different communications
channels to be monitored and answered - eliminating
the incidence of missed calls as well as simplifying
the radio’s operation for users of multiple
communication channels.
Battery Strength Indicator
For early warning on low battery strength, the GP329
is equipped with a tri-colour LED battery gauge; the
GP339 has an on-screen LCD display indicator.
Voice-Operated Transmit (VOX)
Hands-free operation with voice activated
transmission via headsets.
Adjustable Power Levels
Optimises coverage and conserves battery
consumption.
Talkaround
Freedom to communicate via a repeater for wide
area coverage; or bypass a repeater and talk directly
to another unit for easy local unit-to-unit
communications. Ideal for maintaining continued
communications in the event of system failure or
maintenance.
Call Forward
Incoming calls can be forwarded to another radio
user – enabling continued communication for the
operations.
Additional benefits for GP339 – enhancing
your communication versatility
User Information Display
Easy to read 14-character alpha-numeric dot matrix
text display.
Name Tagging
Capable of assigning visual caller-ID to 8 specific
users/talkgroups.
Contact List
Enables users to access up to 100 pre-programmed
numbers; displayed either in alphabetic or numeric
formats. A total of nine tones can be tagged to
the pre-programmed numbers providing caller -
identification.
Status Calls
Pre-defined text messages can be tagged to code
digits in the Status list enabling users to send
meaningful messages quickly without the need to
talk. The status list is for both incoming and
outgoing calls.
Call Timer
Enforces the efficient use of airtime by limiting the
duration of calls. Callers are given warning
indications (visual and audio), prior to the call ending.
Dual Tone Multi Frequency (DTMF)
Activated when the radio is required to operate
in a radio system as well as link up with a
telephone network.
Menu
Users can select functions through easy to navigate
menu keys.
Keypad Lock/Unlock
Keypad keys and menu keys can be locked to
eliminate accidental key presses and to deter non-
users from tampering with the radio.
Backlight
Enhanced ease of use in subdued light by
illuminating the radio display, keypad and menu
navigation keys - programmable to be permanently
switched on, off or switched on for a timed period.
Reliable Warranty
Each Motorola radio is backed by a reliable warranty
on radio parts and labour provided by experienced
Motorola engineers.
