Getting the Most from Your Camera
- Accessories
Table of Contents
For Your Safety
Notices
Introduction
Auto Mode
Creative Mode
Best Moment Capture Mode
Motion Snapshot Mode
- Shooting in Motion Snapshot Mode
- Viewing Motion Snapshots
  - Deleting Motion Snapshots
Recording and Viewing Movies
More on Photography
More on Playback
Connections
The Playback Menu
The Shooting Menu
The Movie Menu
The Image Processing Menu
The Setup Menu
Technical Notes

DIGITAL CAMERA

Reference Manual

Thank you for your purchase of a Nikon digital camera. To get

the most from your camera, please be sure to read all instruc-

tions thoroughly and keep them where they will be read by all

who use the product.

Camera Settings

The explanations in this manual assume that default settings are used.

Symbols and Conventions

To make it easier to find the information you need, the following sym-

bols and conventions are used:

The 1, 3, 4, and 2 symbols represent up, down, left, and right on the

multi selector.

Digitutor

“Digitutor”, a series of “watch and learn” manuals in movie form, is avail-

able from the following website:

http://www.nikondigitutor.com/index_eng.html

DThis icon marks cautions; information that should be read before

use to prevent damage to the camera.

AThis icon marks notes; information that should be read before

using the camera.

0This icon marks references to other pages in this manual.

AFor Your Safety

Before using the camera for the first time, read the safety instructions in

“For Your Safety” (0x–xii).

Getting the Most from Your Camera 0ii

Table of Contents 0iv

sIntroduction 01

zAuto Mode 021

6Creative Mode 031

bBest Moment Capture Mode 045

9Motion Snapshot Mode 053

yRecording and Viewing Movies 057

tMore on Photography 067

IMore on Playback 079

QConnections 091

oThe Playback Menu 0107

iThe Shooting Menu 0117

(The Movie Menu 0139

)The Image Processing Menu 0143

gThe Setup Menu 0157

nTechnical Notes 0165

Getting the Most from Your Camera

Take photos with the shutter-release button.

Photos can be taken in any

mode by pressing the shutter-

release button. See page 6 for

more information.

Shutter-release button

Shoot movies with the movie-record button.

Movies can be recorded by

pressing the movie-record but-

ton in auto (029), creative

(044), and advanced movie

(057) modes.

Movie-record button

Create short movies with music.

Install the supplied software (091), copy photos and movies

to your computer using ViewNX 2 (095), and use Short Movie

Creator to create short movies (098).

View short movies in high definition.

Transfer short movies to the camera (099) and use an HDMI

cable to connect the camera to an HDTV (0100).

iii

Accessories

Expand your photographic horizons with a wide variety of inter-

changeable lenses and other accessories (0165).

Lenses

Wireless

mobile

adapters

Software for

Nikon digital

cameras

(available on

CD)

Mount

adapters

Waterproof

cases

Getting the Most from Your Camera ......................................... ii

Accessories .............................................................................................. iii

For Your Safety............................................................................... x

Notices..........................................................................................xiii

Introduction 1

Before You Begin ...........................................................................1

Parts of the Camera.......................................................................2

The Camera Body ................................................................................... 2

The Monitor.............................................................................................. 4

The Mode Dial ......................................................................................... 6

The Multi Selector .................................................................................. 7

The G Button.................................................................................... 8

& (Feature) .............................................................................................10

First Steps......................................................................................11

Auto Mode 21

Taking Photos in Auto Mode.....................................................21

Viewing Photographs .................................................................27

Deleting Pictures ..................................................................................28

Recording Movies in Auto Mode ..............................................29

Creative Mode 31

Choosing a Creative Mode.........................................................31

Choosing a Scene ........................................................................32

Taking Photos in P, S, A, and M Modes ......................................34

PProgrammed Auto............................................................................34

SShutter-Priority Auto........................................................................35

AAperture-Priority Auto ....................................................................36

MManual .................................................................................................37

Backlighting .................................................................................40

Easy Panorama.............................................................................41

Recording Movies in Creative Mode........................................44

Table of Contents

Best Moment Capture Mode 45

Slow View......................................................................................45

Smart Photo Selector..................................................................47

Viewing Photos Taken with the Smart Photo Selector ........50

Choosing the Best Shot ..................................................................... 50

Deleting Pictures.................................................................................. 51

Motion Snapshot Mode 53

Shooting in Motion Snapshot Mode .......................................53

Viewing Motion Snapshots .......................................................56

Deleting Motion Snapshots............................................................. 56

Recording and Viewing Movies 57

Recording HD Movies................................................................. 58

Recording Slow-Motion Movies ............................................... 62

Viewing Movies ...........................................................................65

Deleting Movies ................................................................................... 66

More on Playback 79

Photo Information ...................................................................... 79

Thumbnail Playback ................................................................... 82

Calendar Playback ......................................................................83

Playback Zoom ............................................................................ 84

Deleting Pictures .........................................................................85

Deleting the Current Picture............................................................85

The Playback Menu .............................................................................85

Rating Pictures .............................................................................86

Slide Shows...................................................................................87

Connections 91

Installing the Supplied Software..............................................91

System Requirements.........................................................................93

Viewing and Editing Pictures on a Computer........................95

Transferring Pictures...........................................................................95

Viewing Pictures ...................................................................................96

Creating Short Movies........................................................................98

Viewing Pictures on TV............................................................ 100

High-Definition Devices.................................................................. 100

Printing Photographs .............................................................. 102

Connecting the Printer.................................................................... 102

Printing Pictures One at a Time.................................................... 103

Printing Multiple Pictures............................................................... 104

Creating a DPOF Print Order: Print Set ...................................... 106

The Playback Menu 107

Selecting Multiple Images.............................................................. 109

Image Review ............................................................................ 110

Rotate Tall .................................................................................. 110

Protect ........................................................................................ 110

Rating.......................................................................................... 110

D-Lighting.................................................................................. 111

Resize .......................................................................................... 112

Crop............................................................................................. 113

Face-Priority Zoom................................................................... 114

Edit Movie .................................................................................. 114

Change Theme .......................................................................... 115

vii

The Shooting Menu 117

Reset Shooting Options ...........................................................119

Exposure Mode..........................................................................119

Image Quality.............................................................................120

Image Size...................................................................................120

Number of Shots Saved ...........................................................123

Movie Before/After ...................................................................123

File Format..................................................................................124

Metering .....................................................................................124

Auto Distortion Control ...........................................................125

Color Space.................................................................................126

Active D-Lighting ......................................................................127

Long Exposure NR.....................................................................128

Optical VR ...................................................................................128

Electronic VR ..............................................................................129

Focus Mode ................................................................................129

Manual Focus ......................................................................................132

AF-Area Mode ............................................................................134

Focus Lock............................................................................................135

Face-Priority ...............................................................................136

Built-in AF Assist........................................................................136

Flash Compensation.................................................................137

The Movie Menu 139

Reset Movie Options.................................................................140

Frame Rate..................................................................................140

Movie Settings ...........................................................................141

Movie Sound Options...............................................................142

viii

The Image Processing Menu 143

Reset Processing Options ....................................................... 144

White Balance............................................................................ 144

Fine-Tuning White Balance ........................................................... 145

Preset Manual..................................................................................... 146

ISO Sensitivity ........................................................................... 149

Picture Control .......................................................................... 150

Modifying Picture Controls............................................................ 150

Custom Picture Control ........................................................... 154

Edit/Save............................................................................................... 154

Load from/Save to Card.................................................................. 155

High ISO Noise Reduction....................................................... 156

The Setup Menu 157

Reset Setup Options ................................................................ 158

Format Memory Card............................................................... 158

Slot Empty Release Lock ......................................................... 159

Display ........................................................................................ 159

Display Brightness ............................................................................ 159

Grid Display ......................................................................................... 159

Shooting............................................................................................... 159

Playback................................................................................................ 160

Sound Settings.......................................................................... 160

Auto Power Off.......................................................................... 160

Shutter Button AE Lock ........................................................... 161

Flicker Reduction...................................................................... 161

Reset File Numbering .............................................................. 161

Time Zone and Date................................................................. 162

Language ................................................................................... 162

Auto Image Rotation................................................................ 163

Pixel Mapping ........................................................................... 164

Firmware Version ..................................................................... 164

Technical Notes 165

Optional Accessories ................................................................165

Approved Memory Cards................................................................167

Approved Eye-Fi Cards ....................................................................168

Attaching a Power Connector and AC Adapter......................169

Storage and Cleaning...............................................................171

Storage ..................................................................................................171

Cleaning................................................................................................171

Caring for the Camera and Battery: Cautions......................172

Available Settings .....................................................................176

Defaults.......................................................................................180

Memory Card Capacity.............................................................181

Troubleshooting........................................................................184

Battery/Display ...................................................................................184

Shooting (All Modes)........................................................................185

Shooting (P, S, A, and M Modes).....................................................186

Movies....................................................................................................186

Playback ................................................................................................187

Miscellaneous .....................................................................................187

Error Messages...........................................................................188

Specifications.............................................................................191

Nikon 1 J3 Digital Camera ..............................................................191

Battery Life ...........................................................................................208

Index ............................................................................................209

To prevent damage to your Nikon product or injury to yourself or to others,

read the following safety precautions in their entirety before using this equip-

ment. Keep these safety instructions where all those who use the product will

read them.

The consequences that could result from failure to observe the precautions

listed in this section are indicated by the following symbol:

❚❚WARNINGS

For Your Safety

AThis icon marks warnings. To prevent possible injury, read all warn-

ings before using this Nikon product.

AKeep the sun out of the frame. Keep the

sun well out of the frame when

shooting backlit subjects. Sunlight

focused into the camera when the

sun is in or close to the frame could

cause a fire.

ATurn off immediately in the event of mal-

function. Should you notice smoke or

an unusual smell coming from the

equipment or AC adapter (available

separately), unplug the AC adapter

and remove the battery immediately,

taking care to avoid burns. Continued

operation could result in injury. After

removing the battery, take the equip-

ment to a Nikon-authorized service

center for inspection.

ADo not use in the presence of flammable

gas. Do not use electronic equipment

in the presence of flammable gas, as

this could result in explosion or fire.

ADo not disassemble. Touching the prod-

uct’s internal parts could result in

injury. In the event of malfunction,

the product should be repaired only

by a qualified technician. Should the

product break open as the result of a

fall or other accident, remove the bat-

tery and/or AC adapter and then take

the product to a Nikon-authorized

service center for inspection.

AKeep out of reach of children. Failure to

observe this precaution could result

in injury. In addition, note that small

parts constitute a choking hazard.

Should a child swallow any part of

this equipment, consult a physician

immediately.

ADo not place the strap around the neck of

an infant or child. Placing the camera

strap around the neck of an infant or

child could result in strangulation.

ADo not remain in contact with the camera,

battery, or charger for extended periods

while the devices are on or in use. Parts of

the device become hot. Leaving the

device in direct contact with the skin

for extended periods may result in

low-temperature burns.

ADo not aim the flash at the operator of a

motor vehicle. Failure to observe this

precaution could result in accidents.

AObserve caution when using a flash.

•Using the camera with the flash in

close contact with the skin or other

objects could cause burns.

•Using a flash close to the subject’s

eyes could cause temporary visual

impairment. Particular care should

be observed when photographing

infants, when the flash should be no

less than one meter (39 in.) from the

subject.

AAvoid contact with liquid crystal. Should

the display break, care should be

taken to avoid injury due to broken

glass and to prevent the liquid crystal

from the display touching the skin or

entering the eyes or mouth.

AObserve proper precautions when handling

batteries. Batteries may leak or

explode if improperly handled.

Observe the following precautions

when handling batteries for use in

this product:

•Use only batteries approved for use

in this equipment.

•Do not short or disassemble the

battery.

•Be sure the product is off before

replacing the battery. If you are

using an AC adapter, be sure it is

unplugged.

•Do not attempt to insert the battery

upside down or backwards.

•Do not expose the battery to flame

or to excessive heat.

•Do not immerse in or expose to

water.

•Replace the terminal cover when

transporting the battery. Do not

transport or store the battery with

metal objects such as necklaces or

hairpins.

•Batteries are prone to leakage when

fully discharged. To avoid damage

to the product, be sure to remove

the battery when no charge

remains.

•When the battery is not in use,

attach the terminal cover and store

in a cool, dry place.

•The battery may be hot immedi-

ately after use or when the product

has been used on battery power for

an extended period. Before remov-

ing the battery turn the camera off

and allow the battery to cool.

•Discontinue use immediately

should you notice any changes in

the battery, such as discoloration or

deformation.

xii

AObserve proper precautions when handling

the charger:

•Keep dry. Failure to observe this

precaution could result in fire or

electric shock.

•Do not short the charger terminals.

Failure to observe this precaution

could result in overheating and

damage to the charger.

•Dust on or near the metal parts of

the plug should be removed with a

dry cloth. Continued use could

result in fire.

•Do not go near the charger during

thunderstorms. Failure to observe

this precaution could result in elec-

tric shock.

•Do not handle the plug or charger

with wet hands. Failure to observe

this precaution could result in elec-

tric shock.

•Do not use with travel converters or

adapters designed to convert from

one voltage to another or with DC-

to-AC inverters. Failure to observe

this precaution could damage the

product or cause overheating or fire.

AUse appropriate cables. When connect-

ing cables to the input and output

jacks, use only the cables provided or

sold by Nikon for the purpose to

maintain compliance with product

regulations.

ACD-ROMs: CD-ROMs containing soft-

ware or manuals should not be

played back on audio CD equipment.

Playing CD-ROMs on an audio CD

player could cause hearing loss or

damage the equipment.

xiii

•No part of the manuals included

with this product may be repro-

duced, transmitted, transcribed,

stored in a retrieval system, or trans-

lated into any language in any form,

by any means, without Nikon’s prior

written permission.

•Nikon reserves the right to change

the specifications of the hardware

and software described in these

manuals at any time and without

prior notice.

•Nikon will not be held liable for any

damages resulting from the use of

this product.

•While every effort has been made to

ensure that the information in these

manuals is accurate and complete,

we would appreciate it were you to

bring any errors or omissions to the

attention of the Nikon representa-

tive in your area (address provided

separately).

Notice for Customers in Canada

CAUTION

This Class B digital apparatus com-

plies with Canadian ICES-003.

ATTENTION

Cet appareil numérique de la classe B

est conforme à la norme NMB-003 du

Canada.

Notice for Customers in Europe

This symbol indicates that

electrical and electronic

equipment is to be col-

lected separately.

The following apply only to

users in European countries:

•This product is designated for sepa-

rate collection at an appropriate col-

lection point. Do not dispose of as

household waste.

•Separate collection and recycling

helps conserve natural resources

and prevent negative consequences

for human health and the environ-

ment that might result from incor-

rect disposal.

•For more information, contact the

retailer or the local authorities in

charge of waste management.

This symbol on the battery

indicates that the battery is

to be collected separately.

The following apply only to

users in European countries:

•All batteries, whether marked with

this symbol or not, are designated

for separate collection at an appro-

priate collection point. Do not dis-

pose of as household waste.

•For more information, contact the

retailer or the local authorities in

charge of waste management.

Notices

CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT

TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.

xiv

Notice for Customers in the U.S.A.

Federal Communications Commission (FCC) Radio Frequency Interference Statement

This equipment has been tested and

found to comply with the limits for a

Class B digital device, pursuant to Part

15 of the FCC rules. These limits are

designed to provide reasonable pro-

tection against harmful interference in

a residential installation. This equip-

ment generates, uses, and can radiate

radio frequency energy and, if not

installed and used in accordance with

the instructions, may cause harmful

interference to radio communications.

However, there is no guarantee that

interference will not occur in a particu-

lar installation. If this equipment does

cause harmful interference to radio or

television reception, which can be

determined by turning the equipment

off and on, the user is encouraged to

try to correct the interference by one

or more of the following measures:

•Reorient or relocate the receiving

antenna.

•Increase the separation between the

equipment and receiver.

•Connect the equipment into an out-

let on a circuit different from that to

which the receiver is connected.

•Consult the dealer or an experienced

radio/television technician for help.

CAUTIONS

Modifications

The FCC requires the user be notified

that any changes or modifications

made to this device that are not

expressly approved by Nikon Corpo-

ration may void the user’s authority to

operate the equipment.

Interface Cables

Use the interface cables sold or pro-

vided by Nikon for your equipment.

Using other interface cables may

exceed the limits of Class B Part 15 of

the FCC rules.

Notice for Customers in the State of California

WARNING: Handling the cord on this

product may expose you to lead, a

chemical known to the State of Cali-

fornia to cause birth defects or other

reproductive harm. Wash hands after

handling.

Nikon Inc., 1300 Walt Whitman Road,

Melville, New York 11747-3064, U.S.A.

Tel.: 631-547-4200

The Battery Charger

IMPORTANT SAFETY INSTRUCTIONS—SAVE THESE

INSTRUCTIONS

DANGER—TO REDUCE THE RISK OF FIRE OR ELECTRIC

SHOCK, CAREFULLY FOLLOW THESE INSTRUCTIONS

For connection to a supply not in the U.S.A., use an attachment plug adapter

of the proper configuration for the power outlet if needed. This power unit

is intended to be correctly oriented in a vertical or floor mount position.

Notice Concerning Prohibition of Copying or Reproduction

Note that simply being in possession of material that has been digitally cop-

ied or reproduced by means of a scanner, digital camera, or other device may

be punishable by law.

•Items prohibited by law from being copied

or reproduced

Do not copy or reproduce paper

money, coins, securities, govern-

ment bonds, or local government

bonds, even if such copies or repro-

ductions are stamped “Sample.”

The copying or reproduction of

paper money, coins, or securities

which are circulated in a foreign

country is prohibited.

Unless the prior permission of the

government has been obtained, the

copying or reproduction of unused

postage stamps or post cards issued

by the government is prohibited.

The copying or reproduction of

stamps issued by the government

and of certified documents stipu-

lated by law is prohibited.

•Cautions on certain copies and reproduc-

tions

The government has issued cautions

on copies or reproductions of securities

issued by private companies (shares,

bills, checks, gift certificates, etc.), com-

muter passes, or coupon tickets, except

when a minimum of necessary copies

are to be provided for business use by a

company. Also, do not copy or repro-

duce passports issued by the govern-

ment, licenses issued by public

agencies and private groups, ID cards,

and tickets, such as passes and meal

coupons.

•Comply with copyright notices

The copying or reproduction of

copyrighted creative works such as

books, music, paintings, woodcuts,

prints, maps, drawings, movies, and

photographs is governed by

national and international copyright

laws. Do not use this product for the

purpose of making illegal copies or

to infringe copyright laws.

Disposing of Data Storage Devices

Please note that deleting images or formatting memory cards or other data

storage devices does not completely erase the original image data. Deleted

files can sometimes be recovered from discarded storage devices using com-

mercially available software, potentially resulting in the malicious use of per-

sonal image data. Ensuring the privacy of such data is the user’s

responsibility.

Before discarding a data storage device or transferring ownership to another

person, erase all data using commercial deletion software, or format the

device and then completely refill it with images containing no private infor-

mation (for example, pictures of empty sky). Care should be taken to avoid

injury when physically destroying data storage devices.

xvi

AVC Patent Portfolio License

THIS PRODUCT IS LICENSED UNDER THE AVC PATENT PORTFOLIO LICENSE FOR THE PERSONAL

AND NON-COMMERCIAL USE OF A CONSUMER TO (I) ENCODE VIDEO IN COMPLIANCE WITH

THE AVC STANDARD (“AVC VIDEO”) AND/OR (II) DECODE AVC VIDEO THAT WAS ENCODED

BY A CONSUMER ENGAGED IN A PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR WAS

OBTAINED FROM A VIDEO PROVIDER LICENSED TO PROVIDE AVC VIDEO. NO LICENSE IS

GRANTED OR SHALL BE IMPLIED FOR ANY OTHER USE. ADDITIONAL INFORMATION MAY BE

OBTAINED FROM MPEG LA, L.L.C. SEE http://www.mpegla.com

Temperature Warnings

The camera may become warm to the touch during use; this is normal and

does not indicate a malfunction. At high ambient temperatures, after

extended periods of continuous use, or after several photographs have been

taken in quick succession, a temperature warning may be displayed, follow-

ing which the camera will turn off automatically to minimize damage to its

internal circuits. Wait for the camera to cool before resuming use.

Use Only Nikon Brand Electronic Accessories

Nikon cameras are designed to the highest standards and include complex

electronic circuitry. Only Nikon brand electronic accessories (including charg-

ers, batteries, AC adapters, and lens accessories) certified by Nikon specifically

for use with this Nikon digital camera are engineered and proven to operate

within the operational and safety requirements of this electronic circuitry.

The use of non-Nikon electronic accessories could damage the

camera and may void your Nikon warranty. The use of third-

party rechargeable Li-ion batteries not bearing the Nikon holo-

graphic seal shown at right could interfere with normal operation of the cam-

era or result in the batteries overheating, igniting, rupturing, or leaking.

For more information about Nikon brand accessories, contact a local autho-

rized Nikon dealer.

xvii

DUse Only Nikon Brand Accessories

Only Nikon brand accessories certified by Nikon specifically for use

with your Nikon digital camera are engineered and proven to operate

within its operational and safety requirements. THE USE OF NON-NIKON

ACCESSORIES COULD DAMAGE YOUR CAMERA AND MAY VOID YOUR NIKON WAR-

RANTY.

AServicing the Camera and Accessories

The camera is a precision device and requires regular servicing. Nikon

recommends that the camera be inspected by the original retailer or a

Nikon-authorized service representative once every one to two years,

and that it be serviced once every three to five years (note that fees

apply to these services). Frequent inspection and servicing are particu-

larly recommended if the camera is used professionally. Any accesso-

ries regularly used with the camera, such as lenses, should be included

when the camera is inspected or serviced.

ABefore Taking Important Pictures

Before taking pictures on important occasions (such as at weddings or

before taking the camera on a trip), take a test shot to ensure that the

camera is functioning normally. Nikon will not be held liable for dam-

ages or lost profits that may result from product malfunction.

ALife-Long Learning

As part of Nikon’s “Life-Long Learning” commitment to ongoing prod-

uct support and education, continually-updated information is avail-

able on-line at the following sites:

•For users in the U.S.A.: http://www.nikonusa.com/

•For users in Europe and Africa: http://www.europe-nikon.com/support/

•For users in Asia, Oceania, and the Middle East: http://www.nikon-asia.com/

Visit these sites to keep up-to-date with the latest product information,

tips, answers to frequently-asked questions (FAQs), and general advice

on digital imaging and photography. Additional information may be

available from the Nikon representative in your area. For contact infor-

mation, visit http://imaging.nikon.com/

xviii

Introduction

Before using your camera for the first time, confirm that the

package contains the items listed in the User’s Manual.

Before You Begin

Take a few moments to familiarize yourself with camera controls

and displays. You may find it helpful to bookmark this section

and refer to it as you read through the rest of the manual.

The Camera Body

Parts of the Camera

31 2 54

14 1213

1Movie-record button

.................................... 29, 44, 57, 59, 63

2Shutter-release

button ....................... 23, 46, 48, 54, 61

3Power switch........................................17

4Mode dial................................................ 6

5Microphone........................................142

6Focal plane mark (E) ......................133

7AF-assist illuminator ........................136

Self-timer lamp ...................................69

Red-eye reduction lamp ...................74

8Eyelet for camera strap......................11

9Flash pop-up button.......................... 72

10 HDMI connector cover ....................100

11 USB connector cover ......... 76, 95, 102

12 Lens release button..........................200

13 Dust shield ................................171, 172

14 Lens mount ................................. 16, 133

15 Mounting mark ................................... 16

16 Power lamp .......................................... 17

17 Body cap .............................................166

18 Built-in flash......................................... 72

19 HDMI mini-pin connector...............100

20 USB connector..................... 76, 95, 102

The Camera Body (Continued)

*Camera does not support TA-N100 tripod mounting spacer.

1011

12 13

1Monitor ....................................4, 79, 159

2K (playback) button ............27, 50, 56

3G (menu) button .......................... 8

4Multi selector......................................... 7

J (OK) button....................................... 7

& (feature) ...........................................10

E (exposure compensation)............71

M (flash mode).....................................73

C (continuous shooting/

self-timer)..................................... 67, 69

5Memory card access lamp......... 15, 22

6O (delete) button......................... 28, 85

7Power connector cover

for optional power connector......169

8Battery-chamber/memory card slot

cover latch........................... 13, 15, 169

9Battery-chamber/

memory card slot cover... 13, 15, 169

10 Tripod socket *

11 Speaker

12 Memory card slot................................ 13

13 Battery latch......................... 13, 15, 169

AHolding the Camera

When framing photographs, hold the camera as shown below.

Hold the camera in

your right hand.

Keep your elbows

propped lightly

against your torso.

Cradle the lens with

your left hand.

The Monitor

*Available only when Detailed is selected for Display > Shooting in the

setup menu (0159).

421 3 5 6 7 8 9 10 11

27 222325 2426 20

1Shooting mode ..................................... 6

2Live image control..............................25

Creative mode ............................. 31, 32

Best moment capture

selection ....................................... 45, 47

Advanced movie selection ........ 57, 62

Exposure mode ................................ 119

3Flexible program indicator...............34

4Flash mode...........................................72

5Self-timer ....................................... 67, 69

Continuous mode *.............................67

6Active D-Lighting *.......................... 127

7Picture Control *............................... 150

8White balance *................................ 144

9Movie settings (HD movies) *........ 141

Frame rate

(slow-motion movies) *................. 140

10 Image size *....................................... 120

11 Image quality *................................. 120

12 Focus mode *..................................... 129

13 AF-area mode *................................. 134

14 Face-priority *..............................24, 136

15 Focus area....................................22, 134

16 AF-area brackets *............................ 129

17 Flash compensation........................ 137

18 Exposure compensation ...................71

19 Flash-ready indicator.........................72

20 “K” (appears when memory remains

for over 1000 exposures).................20

21 Number of exposures remaining....20

Number of shots remaining

before memory buffer fills ..............68

White balance

recording indicator .........................147

Card warning indicator...........159, 188

22 Time available............................... 59, 63

23 ISO sensitivity ....................................149

24 ISO sensitivity indicator...................149

Auto ISO sensitivity indicator ........149

25 Aperture......................................... 36, 37

26 Shutter speed ............................... 35, 37

27 Metering .............................................124

28 Battery indicator *...............................20

29 Sound settings *................................160

30 HDR ........................................................40

31 Eye-Fi connection indicator *.........168

32 Autoexposure (AE) lock

indicator ........................................... 161

33 Microphone sensitivity *.................142

34 Time elapsed................................. 59, 63

35 Recording indicator..................... 59, 63

AThe Framing Grid

A framing grid can be displayed by selecting

On for Display > Grid display in the setup

menu (0159).

ASee also

For information on adjusting monitor brightness, see page 159.

The Mode Dial

The camera offers a choice of the follow-

ing shooting modes:

Mode dial

z Motion Snapshot mode (053): Each time the shutter is released, the

camera records a still image and about 1.6 s of movie footage. When the

resulting “Motion Snapshot” is viewed on the camera, the movie will

play back in slow motion over approximately 4 s, followed by the still

image.

uBest moment capture mode (045):

Choose the moment to release the shut-

ter as the scene plays back in slow motion

(slow view), or let the camera choose the

best shot based on composition and

motion (Smart Photo Selector).

C Auto mode (021): Let the camera pick

the settings for photographs and movies.

w Creative mode (031): For photographs

in which you want to use special effects,

match settings to the scene, or control

shutter speed and aperture.

v Advanced movie mode (057): Choose the shutter speed and aperture

for HD movies or shoot slow-motion movies.

The Multi Selector

The multi selector and J button are used

to adjust settings and navigate the cam-

era menus.

Multi selector

Settings: &

See page 10.

Menu navigation: 1

Move cursor up.

Settings: C

View continuous

shooting/self-timer

menu (067).

Menu navigation: 4

Return to previous

menu.

Select highlighted

item.

Settings: E

View exposure com-

pensation menu

(071).

Menu navigation: 2

Select highlighted item

or display sub-menu.

Settings: M

View flash mode menu (072).

Menu navigation: 3

Move cursor down.

AThe Multi Selector

Items can be highlighted by rotating the multi selector

as shown at right.

The G Button

Most shooting, playback, and setup

options can be accessed from the camera

menus. Press the G button to display

the menu selection dialog shown below,

then use the multi selector to highlight

the icon for the desired menu and press

J.G button

Shooting menu (0117):

Adjust settings for still photography.

Playback menu (0107): Movie menu (0139):

Adjust playback settings. Adjust movie-recording

options.

Image processing menu (0143): History menu:

Adjust white balance, ISO sensitivity,

Picture Controls, and other image

processing settings for photographs

and movies.

Display recently used settings,

or select Reset history > Yes to

remove all items from the

history menu.

Setup menu (0157):

Adjust basic camera settings.

❚❚ Using the Menus

1Select an item.

2Select an option.

Use the multi selector (07) to navigate

the playback, shooting, movie, image

processing, setup, and history menus.

Multi selector

Press 1 or 3 to highlight menu items

and press 2 to view options for the

highlighted item.

Press 1 or 3 to highlight the desired

option and press J to select.

AUsing the Menus

The items listed may vary with camera settings. Items displayed in gray

are not currently available (0176). To exit the menus and return to

shooting mode, press the shutter-release button halfway (023).

AChoosing a Menu

To display another menu, press 4 in Step 1

and then press 1 or 3 to highlight the

desired icon. Press 2 to position the cursor in

the highlighted menu.

& (Feature)

•Live image control (Cauto mode; 025): Adjust exposure (Bright-

ness control), contrast (Active D-Lighting), or depth of field

(Background softening), or freeze or blur motion (Motion

control). The effects can be previewed in the monitor.

•Creative (wcreative mode; 031): Choose from Programmed

auto (P), Shutter-priority auto (S), Aperture-priority auto (A),

Manual (M), Night landscape (j), Night portrait (o), Back-

lighting (m), Easy panorama (p), Soft (q), Miniature effect

(r), and Selective color (s).

•Best moment capture (ubest moment capture mode; 045): Choose

from Slow view and Smart Photo Selector (047) options.

•Advanced movie (vadvanced movie mode; 057): Choose Slow

motion (y) for slow-motion recording (062) or select Pro-

grammed auto (P), Shutter-priority auto (S), Aperture-prior-

ity auto (A), or Manual (M) for high-definition (HD) movie

recording.

•Theme (zMotion Snapshot mode; 055): Choose from Beauty,

Waves, Relaxation, and Tenderness.

Pressing 1(&) gives access to the fea-

tures listed below. Press 1(&) to display

options for the current mode, then rotate

the multi selector or press 1 or 3 to

highlight the desired option and press J

to select.

•Rating (playback mode; 086): Rate pic-

tures.

1Attach the camera strap.

Attach the strap securely to the two camera eyelets.

2Charge the battery.

Insert the battery into the charger q and plug the charger in

w. An exhausted battery fully charges in about two hours.

Unplug the charger and remove the battery when charging is

complete.

First Steps

AThe Plug Adapter

Depending on the country or region of

purchase, a plug adapter may be sup-

plied with the charger.

The shape of the

adapter varies with the country or region

of purchase. If a plug adapter is supplied,

raise the wall plug and connect the plug

adapter as shown at right, making sure

the plug is fully inserted.

Attempting to forcibly remove the plug

adapter could damage the product.

Battery

charging

Charging

complete

DThe Battery and Charger

Read and follow the warnings and cautions on pages x–xii and 172–

175 of this manual. Do not use the battery at ambient temperatures

below 0°C (32°F) or above 40°C (104°F); failure to observe this pre-

caution could damage the battery or impair its performance.

Capacity may be reduced and charging times may increase at bat-

tery temperatures from 0°C (32°F) to 10°C (50°F) and from 45°C

(113°F) to 60°C (140°F); the battery will not charge if its tempera-

ture is below 0°C (32°F) or above 60°C (140°F).

Charge the battery at ambient temperatures between 5°C (41°F)

and 35°C (95°F). If the CHARGE lamp flashes quickly during charging,

cease use immediately and take battery and charger to your retailer

or a Nikon-authorized service representative.

Do not move the charger or touch the battery during charging. Fail-

ure to observe this precaution could in very rare instances result in

the charger showing that charging is complete when the battery is

only partially charged. Remove and reinsert the battery to begin

charging again.

Use the charger with compatible batteries only. Unplug when not

in use.

3Insert the battery and a memory card.

Check to be sure the battery and card are in the correct orien-

tation. Using the battery to keep the orange battery latch

pressed to one side, slide the battery in until it latches, and

then slide in the memory card until it clicks into place.

Rear

DInserting and Removing Batteries and Memory Cards

Always turn the camera off before inserting or removing batteries

or memory cards. Note that the battery and memory cards may be

hot after use; observe due caution when removing the battery and

memory cards.

AFormatting Memory Cards

If this is the first time the memory card

will be used in the camera or if the card

has been formatted in another device,

select Format memory card in the setup

menu and follow the on-screen instruc-

tions to format the card (0158). Note

that this permanently deletes any data the

card may contain. Be sure to copy any

photographs and other data you wish to

keep to a computer before proceeding.

AThe Write Protect Switch

Memory cards are equipped

with a write protect switch to

prevent accidental loss of data.

When this switch is in the “lock”

position, the memory card can

not be formatted and photos can not be deleted or recorded. To

unlock the memory card, slide the switch to the “write” position.

Write-protect switch

ARemoving Batteries and Memory Cards

After turning the camera off, confirm that

the memory card access lamp (

3) is off

and open the battery-chamber/memory

card slot cover. To remove the battery, first

release it by pressing the orange battery

latch in the direction shown by the arrow

and then remove the battery by hand.

To remove a memory card, first press the

card in to eject it (q); the card can then

be removed by hand (w).

DMemory Cards

•The camera stores pictures on SD, SDHC, and SDXC memory cards

(available separately; 0167).

•Do not remove memory cards from the camera, turn the camera

off, or remove or disconnect the power source during formatting

or while data are being recorded, deleted, or copied to a com-

puter. Failure to observe these precautions could result in loss of

data or in damage to the camera or card.

•Do not touch the card terminals with your fingers or metal objects.

•Do not bend, drop, or subject to strong physical shocks.

•Do not apply force to the card casing. Failure to observe this pre-

caution could damage the card.

•Do not expose to water, heat, high levels of humidity, or direct

sunlight.

•Do not format memory cards in a computer.

4Attach a lens.

Be careful to prevent dust from entering the camera when the

lens or body cap is removed. The lens generally used in this

manual for illustrative purposes is a 1 NIKKOR VR 10–30mm

f/3.5–5.6. See page 128 for information on vibration reduc-

tion (VR) and page 200 for information on removing lenses.

ALenses with Retractable Lens Barrel Buttons

Lenses with retractable lens barrel but-

tons can not be used when retracted. To

unlock and extend the lens, keep the

retractable lens barrel button pressed (q)

while rotating the zoom ring (w). The

lens can be retracted and the zoom ring

locked by pressing the retractable lens

barrel button and rotating the ring in the opposite direction. Be

careful not to press the retractable lens barrel button while attach-

ing or removing the lens.

Keeping marks aligned, position lens on

camera, then rotate until it clicks into place.

Mounting mark

(camera)

Mounting mark (lens)

5Turn the camera on.

Press the power switch to turn the

camera on. The power lamp will

briefly light green and the monitor will

turn on. Be sure to remove the lens

cap before shooting.

ATurning the Camera Off

To turn the camera off, press the power switch again. The monitor

will turn off.

AAuto Power Off

If no operations are performed for about a minute, the display will

turn off and the power lamp start to flash (if desired, the delay

before the display turns off automatically can be changed using the

Auto power off option in the setup menu; 0160). The camera can

be reactivated by operating the shutter-release button. If no opera-

tions are performed for about three minutes after the display has

turned off, the camera will turn off automatically.

AAttaching and Removing Lenses

Turn the camera off before attaching or removing lenses. Note that

when the camera is turned off, the sensor protection barrier in the

lens will close, protecting the camera image sensor.

ALenses with Retractable Lens Barrel Buttons

If you are using a lens with a retractable lens barrel button (016),

the camera will turn on automatically when the retractable lens bar-

rel lock is released; in addition, if the view through the lens is dis-

played or the monitor is off, the camera will turn off when the lens

barrel is locked (in the case of 1 NIKKOR VR 10–30mm f/3.5–5.6 and

1 NIKKOR VR 30–110mm f/3.8–5.6 lenses, firmware version 1.10 or

later is required if locking the lens barrel is to turn the camera off

when the monitor is off; for information on updating lens firmware,

visit the Nikon website for your area).

6Choose a language and set the clock.

A language-selection dialog will be displayed the first time

the camera is turned on. Use the multi selector and J button

(07) to choose a language and set the camera clock. Photos

can not be taken until you have set the time and date.

Press 1 or 3 to highlight

language and press J.

Press 4 or 2 to highlight time

zone and press J.

Press 1 or 3 to highlight date

format and press J.

Press 1 or 3 to highlight daylight

saving time option and press J.

Note: The camera uses a 24-hour

clock. Language and clock can be

changed at any time using

Language (0162) and Time

zone and date (0162) options in

setup menu.

Press 4 or 2 to select items and

press 1 or 3 to change. Press J

when finished.

AThe Camera Clock

The camera clock is less accurate than most watches and household

clocks. Check the clock regularly against more accurate time pieces

and reset as necessary.

The camera clock is powered by an independent, rechargeable

power source, which is charged as necessary when the main battery

is installed or the camera is powered by an optional EP-5C power

connector and EH-5b AC adapter (0169). Three days of charging

will power the clock for about a month. If a message warning that

the clock is not set is displayed when the camera is turned on, the

clock battery is exhausted and the clock has been reset. Set the

clock to the correct time and date.

7Check the battery level and memory card capacity.

Check the battery level and number

of exposures remaining in the moni-

tor.

❚❚ Battery Level

❚❚ Number of Exposures Remaining

The monitor shows the number of pictures that can be stored

on the memory card at current settings (values over 1000 are

rounded down to the nearest hundred; e.g., values between

1200 and 1299 are shown as 1.2 k). If a warning is displayed

stating that there is not enough memory for additional

images, insert another memory card (013) or delete some

photos (085).

Display Description

NO ICON

Battery fully charged or

partially discharged;

level shown by L or

K icon in detailed

display (0159).

Low battery. Ready

fully-charged battery or

prepare to charge

battery.

Cannot take pictures.

Insert fully-charged

battery.

Battery exhausted;

shutter-release

disabled. Insert charged

battery.

Battery level

Exposures remaining

Auto Mode

Shoot photographs and movies. The camera automatically

adjusts settings to suit the subject.

1Select auto mode.

2Ready the camera.

3Frame the photograph.

Taking Photos in Auto Mode

Rotate the mode dial to C.

Hold the camera securely with both

hands, being careful not to obstruct

the lens, AF-assist illuminator, or

microphone. Rotate the camera as

shown at lower right when taking pic-

tures in “tall” (portrait) orientation.

Position your subject in the center of

the frame.

4Focus.

Press the shutter-release button half-

way to focus. If the subject is poorly lit,

the flash may pop up (072) and the

AF-assist illuminator (0136) may

light to assist the focus operation.

If the camera is able to focus, the selected

focus area will be highlighted in green

and a beep will sound (a beep may not

sound if the subject is moving).

If the camera is unable to focus, the focus

area will be displayed in red. See page

131.

5Shoot.

Smoothly press the shutter-release

button the rest of the way down to

release the shutter and record the

photograph. The memory card access

lamp will light and the photograph

will be displayed in the monitor for a

few seconds (the photo will automati-

cally clear from the display when the

shutter-release button is pressed half-

way). Do not eject the memory card or

remove or disconnect the power source

until the lamp has gone out and record-

ing is complete.

Memory card access

lamp

Focus area

AThe Shutter-Release Button

The camera has a two-stage shutter-release button. The camera

focuses when the shutter-release button is pressed halfway. To take the

photograph, press the shutter-release button the rest of the way down.

Focus: Press halfway Shoot: Press the rest

of the way down

ATaking Several Photographs in Succession

If Off is selected for Image review in the playback menu (0110), you

can take additional photographs without refocusing by keeping the

shutter-release button pressed halfway between shots.

AAutomatic Scene Selection

In auto mode, the camera automatically ana-

lyzes the subject and selects the appropriate

scene. The selected scene is shown in the

monitor.

Scene icon

cPortrait: Human portrait subjects.

dLandscape: Landscapes and cityscapes.

fNight portrait: Portrait subjects framed against dark backgrounds.

eClose up: Subjects close to the camera.

gNight landscape: Poorly-lit landscapes and cityscapes.

ZAuto: Subjects that do not fall into the categories listed above.

AUsing a Zoom Lens

Use the zoom ring to zoom in on the subject so that it fills a larger area

of the frame, or zoom out to increase the area visible in the final photo-

graph (select longer focal lengths on the lens focal length scale to

zoom in, shorter focal lengths to zoom out).

Zoom in Zoom out

Zoom ring

If you are using an optional lens with a power

drive zoom switch, select T to zoom in and W

to zoom out. The speed with which the cam-

era zooms in and out varies with how far you

slide the switch. The zoom position is shown

by the zoom guide in the display. Zoom guide

AFace Priority

The camera detects and focuses on portrait

subjects (face priority). A double yellow bor-

der will be displayed if a portrait subject is

detected facing the camera (if multiple faces,

up to a maximum of five, are detected, the

camera will select the closest subject). Press

the shutter-release button halfway to focus

on the subject in the double yellow border. The border will clear from

the display if the camera can no longer detect the subject (because, for

example, the subject has looked away).

AAvailable Settings

For information on the options available in auto mode, see page 176.

ASee Also

See page 160 for information on silencing the beep that sounds when

the camera focuses or the shutter is released.

❚❚ Live Image Control

Live image controls let you preview how

changes to each control will affect the

final photograph. To choose a live image

control for auto mode, press 1 (&), use

the multi selector to highlight a control,

and press J to view the effect.

Rotate the multi selector to choose a set-

ting and press J to select. To cancel live

image controls, press 1 (&) again.

Active D-Lighting: Preserve details in high-

lights and shadows for natural contrast.

Increase effect

Reduce effectActive D-Lighting: High Active D-Lighting: Low

Background softening: Soften background

details to make your subject stand out, or

bring both background and foreground

into focus.

Sharpen background

Soften background

Background sharp Background softened

Motion control: Suggest motion by blurring

moving objects, or “freeze” motion to

capture moving objects clearly.

Freeze motion

Blur motion

Freeze motion Blur motion

Brightness control: Make pictures brighter

or darker.

Brighter

DarkerBrighter Darker

DLive Image Control

Continuous shooting is not available (067) and the built-in flash can

not be used when live image control is in effect. Pressing the movie-

record button cancels live image control.

To end playback and return to shooting mode, press the shutter-

release button halfway.

Viewing Photographs

Press K to display your most recent pho-

tograph full frame in the monitor (full-

frame playback).

K button

Press 4 or 2 or rotate the multi selector

to view additional pictures.

ASee Also

For information on toggling photo info on or off, see page 160. See

page 82 for information on viewing multiple images. For information

on zooming in on the center of the current image, see page 84. See

page 87 for information on slide shows.

Deleting Pictures

To delete the current picture, press O. Note that once deleted, pic-

tures can not be recovered.

1Display the photograph.

Display the photograph you wish to delete as described on

the preceding page.

2Press O.

3Delete the photograph.

A confirmation dialog will be dis-

played.

O button

Press O again to delete the picture and

return to playback, or press K to exit

without deleting the picture.

ADeleting Multiple Pictures

The Delete option in the playback menu (085) can be used to delete

all or selected pictures.

In auto mode, the movie-record button

can be used to shoot HD movies with

sound at an aspect ratio of 16 : 9 (the

movie crop is shown in the display).

Press the movie-record button to start

and stop recording.

Recording Movies in Auto Mode

ATaking Photographs During Recording

Photographs can be taken at any time dur-

ing recording by pressing the shutter-

release button all the way down. Movie

recording is not interrupted.

ASee Also

See page 65 for information on viewing

movies.

Movie-record button

Creative Mode

Choose creative mode when to take photos using special effects,

match settings to the scene, or control shutter speed and aper-

ture.

1Select creative mode.

2Choose a scene.

Choosing a Creative Mode

Rotate the mode dial to w.

Press 1 (&) and highlight a scene

using the multi selector (032).

Press J to select the

highlighted scene. Your

selection is indicated by

an icon in the display.

Creative mode offers a choice of the following scenes:

Choosing a Scene

Option Description

Programmed auto (P)

The camera sets shutter speed and aperture for opti-

mal exposure (034). Recommended for snapshots

and in other situations in which there is little time to

adjust camera settings.

Shutter-priority auto

(S)

You choose the shutter speed; the camera selects an

aperture for best results (035). Use to freeze or blur

motion.

Aperture-priority

auto (A)

You choose the aperture; the camera selects a shut-

ter speed for best results (036). Use to blur the

background or bring both foreground and back-

ground into focus.

Manual (M)

You control both shutter speed and aperture (037).

Choose a shutter speed of “Bulb” for long time-expo-

sures (038).

Night landscape (j)

Each time the shutter-release button is fully pressed,

the camera takes a series of shots and combines

them to capture low lighting in night scenes; during

processing, a message is displayed and no pictures

can be taken. The flash does not fire and the edges of

photos are cropped out. Note that the desired results

may not be obtained if the camera or subject moves

during shooting; if the camera is unable to combine

the images, a warning will be displayed and only

one picture will be taken.

Night portrait (o)

Each time the shutter-release button is fully pressed,

the camera takes a series of shots, some with the

flash and some without, and combines them to cap-

ture background lighting in portraits taken at night

or under low light; during processing, a message is

displayed and no pictures can be taken. Note

that

the edges of photos are cropped out and that

the

desired results may not be obtained if the camera or

subject moves during shooting; if the camera is

unable to combine the images, a warning will be dis-

played and the camera will take a single picture

using the flash.

Backlighting (m)Photograph backlit subjects (040).

Easy panorama (p)Shoot panoramas for later viewing on the camera

(041).

Soft (q)

Shoot photographs with a

soft filter effect. To choose

the amount of softening,

press

when the view

through the lens is dis-

played, highlight an option

using the multi selector,

and press

to select.

Miniature effect (r)

The top and bottom of each photo is blurred so that

the subject appears to have been a diorama photo-

graphed at short range. Works best when shooting

from a high vantage point.

Selective color (s)

Take photos in which only

a selected hue appears in

color. To choose the hue,

press

when the view

through the lens is dis-

played and use the multi

selector and

button.

AAvailable Settings

For information on the options available in creative mode, see page

178.

Option Description

P, S, A, and M modes offer varying degrees of control over shutter

speed and aperture. Choose a mode and adjust settings accord-

ing to your creative intent.

PProgrammed Auto

In this mode, the camera automatically adjusts shutter speed

and aperture for optimal exposure in most situations. This mode

is recommended for snapshots and other situations in which

you want to leave the camera in charge of shutter speed and

aperture.

❚❚ Choosing a Combination of Shutter Speed and Aperture

Although the shutter speed and aperture

chosen by the camera will produce opti-

mal results, you can also choose from

other combinations that will produce the

same exposure (“flexible program”).

Rotate the multi selector clockwise for

large apertures (low f-numbers) that blur

background details or fast shutter speeds

that “freeze” motion. Rotate the multi

selector counterclockwise for small aper-

tures (high f-numbers) that increase

depth of field or slow shutter speeds that blur motion. U is dis-

played while flexible program is in effect.

Taking Photos in P, S, A, and M Modes

ARestoring Default Shutter Speed and Aperture Settings

To restore default shutter speed and aperture settings, rotate the multi

selector until U is no longer displayed or turn the camera off. The

default shutter speed and aperture is automatically restored when the

camera enters standby mode.

SShutter-Priority Auto

In shutter-priority auto, you choose the shutter speed while the

camera automatically selects the aperture that will produce the

optimal exposure. Use slow shutter speeds to suggest motion

by blurring moving subjects, fast shutter speeds to “freeze”

motion.

❚❚ Choosing a Shutter Speed

Rotate the multi selector to choose from

shutter speeds between 30 s and 1

16,000 s.

Rotate the selector clockwise for faster

shutter speeds, counterclockwise for

slower shutter speeds.

Fast shutter speed (1

1600 s) Slow shutter speed (1 s)

AContinuous Shooting

The selected shutter speed may change

when continuous shooting (067) is in effect.

AAperture-Priority Auto

In aperture-priority auto, you choose the aperture while the

camera automatically selects the shutter speed that will produce

the optimal exposure. Large apertures (low f-numbers) reduce

depth of field, blurring objects behind and in front of the main

subject. Small apertures (high f-numbers) increase depth of

field, bringing out details in the background and foreground.

Short field depths are generally used in portraits to blur back-

ground details, long field depths in landscape photographs to

bring the foreground and background into focus.

❚❚ Choosing an Aperture

Rotate the multi selector counterclock-

wise for larger apertures (lower f-num-

bers), clockwise for smaller apertures

(higher f-numbers). The minimum and

maximum values depend on the lens cur-

rently in use.

Large aperture (f/5.6) Small aperture (f/16)

MManual

In manual mode, you control both shutter speed and aperture.

❚❚ Choosing Shutter Speed and Aperture

Adjust shutter speed and aperture with

reference to the exposure indicator (see

below). Press 2 to highlight shutter

speed or aperture and rotate the multi

selector to choose a value, then repeat

for the remaining item. Rotate the selec-

tor clockwise for faster shutter speeds or

smaller apertures (higher f-numbers),

counterclockwise for slower shutter

speeds and larger apertures (lower f-

numbers). Shutter speeds can be set to

values as fast as 1

16,000 s or as slow as 30 s,

or to “Bulb” to hold the shutter open

indefinitely for a long time-exposure

(038). Aperture can be set to values

between the minimum and maximum for

the lens.

AContinuous Shooting

The selected shutter speed may change when continuous shooting

(067) is in effect.

Shutter speed

Press 2 to highlight

aperture.

perture

Press 2 to highlight

shutter speed.

6❚❚ Long Time-Exposures (M Mode Only)

Select a shutter speed of “Bulb” for long

time-exposures of moving lights, the

stars, night scenery, or fireworks. The

shutter remains open while the shutter-

release button is held down. To prevent

blur, use a tripod.

1Ready the camera.

Mount the camera on a tripod or place it on a stable, level sur-

face. To prevent loss of power before the exposure is com-

plete, use a fully charged EN-EL20 battery or an optional

EH-5b AC adapter and EP-5C power connector. Note that

noise (bright spots, randomly-spaced bright pixels, or fog)

may be present in long exposures; before shooting, choose

On for Long exposure NR in the shooting menu (0128).

AThe Exposure Indicator

When shutter speeds other than “Bulb” are selected, the exposure indi-

cator shows whether the photograph would be under- or over-

exposed at current settings.

Optimal exposure Underexposed by 1

3EV Overexposed by over 2 EV

2Choose a shutter speed of “Bulb”.

Press 2 to highlight shutter speed and

rotate the multi selector counterclock-

wise to select “Bulb”.

3Open the shutter.

After focusing, press the shutter-release button all the way

down. Keep the shutter-release button pressed until the

exposure is complete.

4Close the shutter.

Take your finger off the shutter-release button.

Shooting ends automatically after about two minutes. Note that

some time may be required to record long exposures.

The method used to capture details in shaded areas of back-lit

subjects depends on the option selected for HDR in the shoot-

ing menu (0117).

Backlighting

Details in highlights and shadows are preserved using HDR (high

dynamic range); Z appears in the display. Each time the shutter-

release button is fully pressed, the camera takes two shots in quick

succession and combines them to preserve details in highlights

and shadows in high-contrast scenes; the built-in flash does not

fire. While the shots are combined, a message will be displayed and

the shutter release will be disabled. The final photograph will be

displayed when processing is complete.

First exposure

(darker)

Second exposure

(brighter)

Combined HDR


Off

The flash fires to “fill in” (illuminate) shadows in back-lit subjects.

Only one shot is taken when the shutter-release button is fully

pressed, and the flash fires with each shot.

DFraming HDR Photographs

The edges of the image will be cropped out. The desired results may

not be achieved if the camera or subject moves during shooting.

Depending on the scene, shading may be uneven and shadows may

appear around bright objects or halos around dark objects. If the cam-

era is unable to successfully combine the two images, a single image

will be recorded at normal exposure and Active D-Lighting (0127) will

be applied.

Follow the steps below to shoot panoramas. During shooting,

the camera focuses using auto-area AF (0134); face detection

(024) is not available. Exposure compensation (071) can be

used, but the built-in flash will not fire.

1Set focus and exposure.

Frame the start of the pan-

orama and press the shut-

ter-release button halfway.

Guides will appear in the

display.

2Start shooting.

Press the shutter-release

button the rest of the way

down and then lift your fin-

ger from the button. a, c,

d, and b icons will appear in

the display to indicate the

possible pan directions.

3Pan the camera.

Easy Panorama

Slowly pan the camera up, down, left,

or right as shown below. Shooting will

start when the camera detects the pan

direction and a progress indicator will

appear in the display. Shooting ends

automatically when the end of the

panorama is reached.

Progress indicator

An example of how to pan the camera is shown below. With-

out changing your position, pan the camera in a steady curve

either horizontally or vertically. Time the pan according to

the option selected for Image size in the shooting menu:

about 15 seconds are needed to complete the pan when

ANormal panorama is selected, about 30 seconds when

BWide panorama is selected.

APanoramas

High-distortion wide-angle lenses may fail to produce the desired

results. An error message will be displayed if the camera is panned too

quickly or unsteadily.

The completed panorama will be slightly smaller than the area visible

in the display during shooting. No panorama will be recorded if shoot-

ing ends before the halfway point; if shooting ends after the halfway

point but before the panorama is complete, the unrecorded portion

will be shown in gray.

❚❚ Viewing Panoramas

Panoramas can be viewed by pressing 3 when a panorama is

displayed full frame (027). The start of the panorama will be

displayed with the smallest dimension filling the display and the

camera will then scroll through the picture in the original pan

direction.

The following operations can be performed:

Navigation

window

Guide

To Use Description

Pause Pause playback.

Play JResume playback when the panorama is

paused or during rewind/advance.

Advance/

rewind

Press 4 to rewind, 2 to advance. If playback is

paused, the panorama rewinds or advances a

segment at a time; keep the button pressed

for continuous rewind or advance.

Return to

full-frame

playback

/KPress 1 or K to exit to full-frame playback.

Recording Movies in Creative Mode

In creative mode, the movie-record but-

ton can be used to shoot HD movies

with sound at an aspect ratio of 16 : 9

(the corners of the movie crop are shown

in the display). Press the movie-record

button to start and stop recording. Note

that regardless of the mode selected,

movies are recorded using programmed

auto exposure; to adjust exposure when

shooting movies, select advanced movie

mode (057).

Movie-record button

Movie crop

ATaking Photographs During Recording

Photographs can be taken at any time during recording by pressing the

shutter-release button all the way down. Movie recording is not inter-

rupted.

ASee Also

See page 65 for information on viewing movies.

Best Moment Capture Mode

This mode is ideal for fast-changing, hard-to-capture subjects.

Choose when to release the shutter as the scene plays back in

slow motion (slow view), or let the camera choose the best shot

based on composition and motion (Smart Photo Selector; 047).

In this mode, the camera captures a short sequence of still

images and plays them back in slow motion so that you can

choose the precise moment for a photograph. While the shutter-

release button is pressed halfway, the camera records up to 20

frames over about 1.3 s and plays them back in a continuous

slow-motion loop. When the frame you want to keep is dis-

played, press the shutter-release button the rest of the way

down to record the current frame and discard the remaining

images. To use slow view, select Slow view from the 1 (&) but-

ton menu in best moment capture mode.

1Select best moment capture mode.

Slow View

Rotate the mode dial to u. If Smart

Photo Selector is selected, choose

Slow view.

2Frame the photograph.

3Press the shutter-release button halfway.

4View the buffer contents.

5Record the desired frame.

Compose the photograph with your

subject in the center of the frame.

The camera will focus (022) and then,

over a span of about 1.3 s, record 20

frames to a temporary memory buffer.

Keep the shutter-release button

pressed halfway to play the frames in

the buffer back in a continuous loop

about 6.5 s long. The position of the

current frame is shown by a progress

indicator.

Progress indicator

Press the shutter-release button all

the way down to record the current

frame and discard the remaining

images; the selected frame will be dis-

played for a few seconds when record-

ing is complete. To exit without

recording a photograph, release the

button without pressing it all the way

down.

AViewing and Deleting Photos Taken in Slow View

Photos taken in slow view can be viewed as described on page 27 or

deleted as described on page 28.

Choose Smart Photo Selector mode to let the camera help you

take photos that capture a fleeting expression on the face of a

portrait subject or other hard-to-time shots such as group pho-

tos in party scenes. Each time the shutter is released, the camera

automatically selects the best shot and a number of best shot

candidates based on composition and motion. To use the Smart

Photo Selector, select Smart Photo Selector from the 1 (&)

button menu in best moment capture mode.

1Select best moment capture mode.

Smart Photo Selector

Rotate the mode dial to u. If Slow

view is selected, choose Smart Photo

Selector.

2Frame the photograph.

3Begin buffering photographs.

4Shoot.

Smoothly press the shutter-release

button the rest of the way down. The

camera will compare shots recorded

to the buffer both before and after the

shutter-release button was pressed all

the way down, and select five to copy

to the memory card. Note that some

time may be required. The best pic-

ture is displayed in the monitor when

recording is complete.

Compose the photograph with your

subject in the center of the frame.

Press the shutter-release button half-

way to focus (022). An icon will be

displayed as the camera begins

recording images to the memory

buffer. The camera continuously

adjusts focus to account for changes

in the distance to the subject while

the shutter-release button is pressed

halfway.

ABuffering

Buffering begins when the shutter-release button is pressed halfway

and ends after about 90 seconds or when the shutter-release button is

pressed all the way down.

DSmart Photo Selector Files

Do not delete the “NCSPSLST.LST” file from the “NCFL” folder on the

memory card or change the file names of images taken with the Smart

Photo Selector. The camera will no longer recognize the affected files

as Smart Photo Selector images and will instead handle them as inde-

pendent photographs.

AAvailable Settings

For information on the options available in best moment capture

mode, see page 176.

ABest Moment Capture Mode

The camera automatically chooses a scene mode appropriate to the

subject. Movies can not be recorded, and pressing the movie-record

button has no effect. The flash can not be used.

ASee Also

Use the Number of shots saved option in the shooting menu to

choose the number of shots selected by the Smart Photo Selector

(0123).

Shutter-release

button pressed

halfway to focus

Shutter-release button

pressed all the way

down Shooting ends

Buffering

Choosing the Best Shot

Viewing Photos Taken with the Smart Photo Selector

Press K and use the multi selector to

display photographs taken with the

Smart Photo Selector (027; pictures

taken with the Smart Photo Selector are

indicated by a y icon). Of the photo-

graphs recorded by the Smart Photo

Selector, only the best shot will be dis-

played (when you press the multi selec-

tor right to view the next picture, the

camera will skip over the best shot can-

didates, with the result that the next pic-

ture displayed will not have a file

number that immediately follows that of

the current picture). To end playback

and return to shooting mode, press the

shutter-release button halfway.

K button

When a photograph taken with the

Smart Photo Selector is displayed, you

can choose the best shot by pressing 3.

Press 4 or 2 to view the other pictures

in the sequence and press J to select

the current picture as the best shot. To

return to normal playback, press D.

Deleting Pictures

Pressing O when a picture taken with the

Smart Photo Selector is selected displays

a confirmation dialog; press O again to

delete the best shot and the best shot

candidates, or press K to exit without

deleting the pictures. Note that once

deleted, pictures can not be recovered.

ADeleting Individual Photographs

Pressing the O button in the best shot selec-

tion dialog displays the following options;

highlight an option using the multi selector

and press J to select.

•This image: Delete the current photo (note

that the picture currently selected as the

best shot can not be deleted).

•All except best shot: Delete the best shot candidates, but not picture cur-

rently selected as the best shot.

A confirmation dialog will be displayed; to delete the selected image or

images, highlight Yes and press J.

O button

Motion Snapshot Mode

Record brief movie vignettes with your photographs. Each time

the shutter is released, the camera records a still image and

about 1.6 s of movie footage. When the resulting “Motion Snap-

shot” is viewed on the camera, the movie will play back in slow

motion over approximately 4 s, followed by the still image; play-

back is accompanied by a background track about 10 s long.

1Select Motion Snapshot mode.

2Frame the picture.

Shooting in Motion Snapshot Mode

Rotate the mode dial to z.

Compose the photograph with your

subject in the center of the frame.

AAvailable Settings

For information on the options available in Motion Snapshot mode, see

page 176.

3Begin buffering.

4Shoot.

Smoothly press the shutter-release

button the rest of the way down. The

camera will record a photograph,

together with about 1.6 s of movie

footage beginning before and ending

after the time the shutter-release but-

ton was pressed all the way down.

Note that some time may be required.

When recording is complete, the pho-

tograph will be displayed for a few

seconds.

Press the shutter-release button half-

way to focus (022). An icon will be

displayed as the camera begins

recording footage to the memory

buffer.

ABuffering

Buffering begins when the shutter-release button is pressed halfway

and ends after about 90 seconds or when the shutter-release button is

pressed all the way down.

Shutter-release

button pressed

halfway to focus

Shutter-release button

pressed all the way

down Shooting ends

Buffering

❚❚ Choosing a Theme

To choose the background music for the

movie, press 1(&) and use the multi

selector and J button to select from

Beauty, Waves, Relaxation, and Tender-

ness.

To play the background music for the

highlighted theme, press 2 and rotate

the multi selector to adjust volume.

AMotion Snapshot Mode

Live audio is not recorded. Movies can not be recorded using the

movie-record button and the flash can not be used.

ASee Also

See page 123 for information on choosing what portions of the buffer

are included in the movie footage. For information on saving Motion

Snapshots in a format that can be viewed in most movie playback soft-

ware, see page 124.

9Deleting Motion Snapshots

To delete the current Motion Snapshot,

press O. A confirmation dialog will be dis-

played; press O again to delete the photo

and movie and return to playback, or

press K to exit without deleting the file.

Note that once deleted, Motion Snapshots

can not be recovered.

Viewing Motion Snapshots

Press K and use the multi selector to dis-

play a Motion Snapshot (027; Motion

Snapshots are indicated by a z icon).

Pressing 3 when a Motion Snapshot is

displayed plays back the movie portion in

slow motion over a period of about 4 s,

followed by the photo; the background

track plays for about 10 s (to choose a

new background track, use the Change

theme option in the playback menu;

0115). To end playback and return to

shooting mode, press the shutter-release

button halfway.

K button

O button

Recording and Viewing Movies

The camera can record high-definition

(HD) movies with an aspect ratio of 16 : 9

and slow-motion movies with an aspect

ratio of 8 : 3. Movies can be recorded by

pressing the movie-record button in the

following shooting modes: Movie-record button

Mode Movie type Description

CAuto mode (029)

HD (16 : 9)

The camera automatically

optimizes settings for the

current subject or scene.

wCreative mode (044)

Shoot movies. Regardless of

the scene selected with the

camera, movies are recorded

in mode P; shutter speed and

aperture are controlled by

the camera.

Advanced

movie

mode ( 058,

62)

Programmed

auto (P)

Shutter speed and aperture

are controlled by the camera.

Shutter-

priority auto

(S)

You choose the shutter

speed; the camera automati-

cally adjusts aperture for

optimal exposure (035).

Aperture-

priority auto

(A)

You choose the aperture; the

camera automatically adjusts

shutter speed for optimal

exposure (036).

Manual (M)You choose the shutter speed

and aperture (037).

Slow motion

(y)

Slow

motion

(8 : 3)

Record silent slow-motion

movies. Movies are recorded

at 400 fps and play back at

about 30 fps (062).

AAvailable Settings

For information on the options available in advanced movie mode, see

page 176.

Record movies with sound at an aspect ratio of 16 : 9.

1Choose a shooting mode.

2Frame the opening shot.

Recording HD Movies

Rotate the mode dial to choose a

shooting mode. Note that best

moment capture and Motion Snap-

shot modes do not support HD movie

recording.

For greater control of exposure, select v (advanced movie

mode), press 1(&), and choose from P Programmed auto, S

Shutter-priority auto, A Aperture-priority auto, and M

Manual (057).

Frame the opening shot with your

subject in the center of the display.

AThe 0 Icon

A 0 icon indicates that movies can not be recorded.

3Start recording.

4End recording.

Press the movie-record button to

begin recording. A recording indica-

tor, the time elapsed, and the time

available are displayed while record-

ing is in progress.

AAudio Recording

Be careful not to cover the microphone

and note that the built-in microphone

may record sounds made by the camera

or lens. By default, the camera focuses

continuously; to avoid recording focus

noise, select Single AF for Focus mode in

the movie menu (0129). The Movie

sound options item in the movie menu

offers microphone sensitivity and wind

noise options (0142).

Movie-record button

Recording indicator/

Time elapsed

Time available

Press the movie-record button again

to end recording. Recording will end

automatically when the maximum

length is reached (0141), the mem-

ory card is full, another mode is

selected, the lens is removed, or the

camera becomes hot (0xvi). Movie-record button

AMaximum Length

At default settings, HD movies can be up to 4 GB in size and 20 min-

utes in length (for more information, see page 141); note that

depending on memory card write speed, shooting may end before

this length is reached (0167).

AThe Movie Crop

The movie crop is shown in the monitor.

AFocus Lock

If Single AF is selected for Focus mode in the movie menu for

advanced movie mode, focus will lock while the shutter-release button

is pressed halfway (0135).

HD crop (16 : 9) Slow-motion movie crop

(8 : 3)

❚❚ Taking Photographs During HD Movie Recording

Press the shutter-release button all the

way down to take a photograph without

interrupting HD movie recording. Photo-

graphs taken during movie recording

have an aspect ratio of 3 : 2.

ATaking Photographs During Movie Recording

Up to 20 photographs can be taken with each movie shot. Please note

that photographs can not be taken with slow-motion movies.

DRecording Movies

Flicker, banding, or distortion may be visible in the display and in the

final movie under fluorescent, mercury vapor, or sodium lamps or if the

camera is panned horizontally or an object moves at high speed

through frame (flicker and banding can be reduced in HD movies by

choosing a Flicker reduction option that matches the frequency of the

local AC power supply as described on page 161, but note that the

slowest shutter speed available is 1

100 s at 50 Hz, 1

60 s at 60 Hz; flicker

reduction is not available with slow-motion movies). Bright light

sources may leave after-images when the camera is panned. Jagged

edges, color fringing, moiré, and bright spots may also appear. When

recording movies, avoid pointing the camera at the sun or other strong

light sources. Failure to observe this precaution could result in damage

to the camera’s internal circuitry.

ASee Also

Frame size and frame rate options are described on page 141.

Silent slow-motion movies with an aspect ratio of 8 : 3 can be

recorded by selecting y Slow motion from the 1 (&) button

menu in advanced movie mode. Slow-motion movies are

recorded at 400 fps and play back at about 30 fps.

1Select advanced movie mode.

2Frame the opening shot.

Recording Slow-Motion Movies

Rotate the mode dial to v. If an

option other than y Slow motion is

selected, choose y Slow motion.

Frame the opening shot with your

subject in the center of the display.

3Focus.

4Start recording.

Press the movie-record button to

begin recording. A recording indica-

tor, the time elapsed, and the time

available are displayed while record-

ing is in progress. The camera focuses

on the subject at the center of the dis-

play; face detection (024) is not

available and focus and exposure can

not be adjusted.

Movie-record button

Recording indicator/

Time elapsed

Time available

Focus area

5End recording.

Press the movie-record button again

to end recording. Recording will end

automatically when the maximum

length is reached, the memory card is

full, another mode is selected, the lens

is removed, or the camera becomes

hot (0xvi).

AMaximum Length

Up to 3 seconds of footage can be recorded; note that depending

on memory card write speed, shooting may end before this length

is reached (0167).

ASee Also

Frame rate options are described on page 140.

Movie-record button

Movies are indicated by a 1 icon in full-frame playback (027).

Press 3 to start playback.

The following operations can be performed:

Viewing Movies

1 icon/Length

Movie playback indicator/

Current position/total length

Guide Volume

To Use Description

Pause Pause playback.

Play JResume playback when the movie is paused

or during rewind/advance.

Advance/

rewind

Press 4 to rewind, 2 to advance. Speed

increases with each press, from 2× to 4× to 8×

to 16×. If playback is paused, the movie

rewinds or advances one frame at a time; keep

the button pressed for continuous rewind or

advance.

Adjust

volume Rotate the multi selector to adjust volume.

Return to

full-frame

playback

/KPress 1 or K to exit to full-frame playback.

Deleting Movies

To delete the current movie, press O. A

confirmation dialog will be displayed;

press O again to delete the movie and

return to playback, or press K to exit

without deleting the movie. Note that

once deleted, movies can not be recovered.

ASee Also

See page 114 for information on trimming

unwanted footage from movies.

O button

More on Playback

Photo information is superimposed on images displayed in full-

frame playback (027). The information displayed can be

selected using the Display > Playback option in the setup

menu (0160).

❚❚ Basic Info

Photo Information

Still images Movies

1 2 3

875

212

1Shooting mode

2Protect status.....................................110

3Frame number/total number of

images

4Image quality.....................................120

Frame rate..................................140, 141

5Image size...........................................120

Frame size..................................140, 141

6File name ............................................122

7Time of recording ...................... 18, 162

8Date of recording....................... 18, 162

9Battery indicator ................................. 20

10 Rating ....................................................86

11 Movie length........................................65

12 Audio recording indicator...............142

13 On-screen guide (for movies) .......... 65

❚❚ Detailed Photo Information

Still images

Movies

1234

22 2023 19

1 2 4

1Shooting mode

2Frame number/total number of

images

3Protect status.....................................110

4Camera name

5Retouch indicator ...........111, 112, 113

Movie edit indicator.........................114

6Histogram showing distribution of

tones in image ...................................81

7ISO sensitivity ....................................149

8Focal length .......................................197

9Flash mode........................................... 73

10 Flash compensation.........................137

11 Exposure compensation ................... 71

12 Metering .............................................124

13 Creative mode .............................. 31, 32

Best moment capture selection

.... 45, 47

Advanced movie selection........ 57, 62

Exposure mode .................................119

14 Shutter speed ............................... 35, 37

15 Aperture......................................... 36, 37

16 Picture Control ..................................150

17 Active D-Lighting indicator............127

18 HDR indicator ...................................... 40

19 Image quality.....................................120

Frame rate .................................140, 141

20 Image size...........................................120

Frame size..................................140, 141

21 File name ............................................122

22 Time of recording ...................... 18, 162

23 Date of recording....................... 18, 162

24 Battery indicator ................................. 20

25 White balance....................................144

White balance fine-tuning .............145

26 Color space.........................................126

27 Rating .................................................... 86

28 Auto distortion control....................125

29 Audio recording indicator ..............142

AHistograms (080)

Camera histograms are intended only as a guide and may differ from

those in imaging applications. Sample histograms are shown below:

•If brightness varies evenly across the

image, the distribution of tones

will be relatively even.

•If the image is dark, tone distribu-

tion will be shifted to the left.

•If the image is bright, tone distribu-

tion will be shifted to the right.

Exposure compensation shifts the distribution of tones to the right

when raised, to the left when lowered. Histograms can give you a

rough idea of overall exposure when bright ambient lighting makes it

difficult to see the display in the monitor.

To view pictures in “contact sheets” of 4, 9, or 72 images, press J

when a picture is displayed full frame and rotate the multi selec-

tor counterclockwise.

The following operations can be performed:

Thumbnail Playback

To Use Description

Display more

images

Rotate the multi selector counterclockwise

to increase the number of images displayed

from 1 to 4, from 4 to 9, or from 9 to 72. To

view images taken on selected dates (083),

rotate the selector counterclockwise when

72 images are displayed.

Display fewer

images

Rotate the multi selector clockwise to

reduce the number of images displayed

from 72 to 9 or 9 to 4. To view the high-

lighted image full frame, rotate the selector

clockwise when 4 images are displayed.

Highlight

images

Use the multi selector to highlight images.

You can delete (085) the highlighted

image or zoom in for a closer look (084).

View

highlighted


JPress J to view the highlighted image full

frame.

Delete

highlighted


OSee page 85.

To view pictures taken on a selected date, rotate the multi selec-

tor counterclockwise when 72 pictures are displayed (082).

The following operations can be performed:

Calendar Playback

To Use Description

Display

calendar

To view the calendar, rotate the multi selec-

tor counterclockwise when 72 images are

displayed (082).

Exit to

thumbnail

playback

To return to the 72-image display, rotate the

multi selector clockwise when the calendar

is displayed.

Highlight date Use multi selector to highlight date in calen-

dar display.

View pictures

taken on

highlighted

date

JPress J to view the first picture taken on

the highlighted date.

Delete pictures

taken on

highlighted

date

OPress O to delete all pictures taken on the

highlighted date.

To zoom in on a photograph, display it full frame and press J

and rotate the multi selector clockwise. Playback zoom is not

available with movies or Motion Snapshots.

The following operations can be performed:

Playback Zoom

To Use Description

Zoom in Rotate the multi selec-

tor clockwise to zoom

in, counterclockwise to

zoom out. Whenever

you zoom in or out, a

navigation window will

appear with the area

currently visible in the display indicated by a yel-

low border. Press 1, 3, 4, or 2 to scroll the

image.

Zoom out

View other

areas of


View faces

Faces (up to five)

detected during

face

priority

are indicated by

white borders in the

navigation window.

Press 4 or 2 to view

other faces.

Exit zoom JReturn to full-frame playback.

ASee Also

The Face-priority zoom option in the playback menu (0114) is used

to choose whether the multi selector to be used to scroll from face to

face during face-priority zoom.

Pictures can be deleted from the memory card as described

below. Note that once deleted, pictures can not be recovered; pro-

tected images, however, will not be deleted.

Deleting the Current Picture

The Playback Menu

To delete multiple images, press the G button, select Delete

in the playback menu, and choose from the options below. A

confirmation dialog will be displayed; select Yes to delete the

images (note that some time may be required if a large number

of images is selected).

Deleting Pictures

To delete the picture currently displayed

in full-frame playback or selected in the

thumbnail list, press O. A confirmation

dialog will be displayed; press O again to

delete the picture and return to playback,

or press K to exit without deleting the

picture. O button

Delete selected images

Highlight images and press 3 to select or dese-

lect (0109). Press J to exit when the selection is

complete.

Delete all images Delete all pictures on the memory card.

Rate pictures or mark them as candidates for later deletion. Rat-

ing is not available with protected images.

1Select a picture.

Display a picture in full-frame playback.

2Press 1(&).

Rating Pictures

Press 1(&) and rotate the multi

selector to choose from ratings of

zero to five stars, or select ) to mark

the picture as a candidate for later

deletion.

1Select the type of image used in the show.

Highlight the desired option and press J.

Slide Shows

To view a slide show of the pictures on

the memory card, press the G button,

select Slide show in the playback menu,

and follow the steps below.

G button

All images Display all the images on the memory card.

Still images

Display still images only. Images taken using Easy

panorama will be displayed in panorama mode

(041).

Movies Display movies only.

Motion Snapshot Display only the movie portion of Motion Snapshots.

The associated photographs are not displayed.

Select images by

date

Display only images

recorded on a selected

date. A calendar will be

displayed; use the multi

selector to highlight a

date.

Selected scene

Display only photos belonging to a specific scene.

Choose from

Auto

Portrait

Landscape

Night landscape

Night portrait

Backlighting

Close-up

Easy panorama

Soft

Miniature

effect

, and

Selective color

Face priority Display only images in which the camera has

detected a face (024).

2Adjust display times and choose a background track.

Adjust the following options:

Frame interval Choose how long each still image is displayed.

Movie playback

time

Choose how much of each movie is played back

before the next slide is displayed. Choose Same as

frame interval to display the next slide after the

time selected for Frame interval, No limit to play

back the entire movie before displaying the next

slide.

Audio

Mute audio playback or

choose a slide show back-

ground track (to play the

highlighted background

track prior to selection,

press 2 and rotate the

multi selector to adjust

volume; to end playback,

press 2 again). Select

Movie sound tracks to play only audio recorded

with movies; in this case, no sound is played for still

images or Motion Snapshots.

3Select Start.

The following operations can be performed while a slide

show is in progress:

The options shown at right are dis-

played when the show ends. Select

Resume to restart or Exit to exit to the

playback menu.

Highlight Start and press J to start

the slide show.

To Use Description

Skip back/skip

ahead

Press 4 to return to the previous frame,

2 to skip to the next frame.

Pause/resume JPause the show. Press again to resume.

Adjust volume Rotate the multi selector to adjust vol-

ume.

Exit to playback

mode KEnd the show and return to playback

mode.

Connections

Install the supplied software to copy pictures to your computer

for viewing and editing pictures and creating short movies.

Before installing the software, confirm that your system meets

the requirements on page 93.

1Launch the installer.

Start the computer, insert

the ViewNX 2/Short Movie

Creator installer CD, and

launch the installer.

2Select a language.

If the desired language is

not available, click Region

Selection to choose a dif-

ferent region and then

choose the desired lan-

guage (region selection is

not available in the Euro-

pean release).

3Start the installer.

Click Install and follow the

on-screen instructions.

Installing the Supplied Software

q Select region (if required)

w Select language e Click Nex

Click Instal

4Exit the installer.

Click Yes (Windows) or OK (Mac OS) when installation is com-

plete.

The following software is installed:

•ViewNX 2

•Short Movie Creator

•Apple QuickTime (Windows only)

5Remove the installer CD from the CD-ROM drive.

Windows Mac OS

Click Yes Click OK

ASupplied Software

Be sure to update to the latest versions of the supplied software.

Nikon Message Center 2 will periodically check for updates while the

computer is connected to the Internet.

System Requirements

The system requirements for ViewNX 2 are:

Windows

CPU

•Photos/JPEG movies: Intel Celeron, Pentium 4, or Core series,

1.6 GHz or better

•H.264 movies (playback): 3.0 GHz Pentium D or better

•H.264 movies (editing): 2.6 GHz Core 2 Duo or better

OS Pre-installed versions of Windows XP, Windows Vista, Win-

dows 7, and Windows 8

RAM

•Windows 8/Windows 7/Windows Vista: 1 GB or more (2 GB or more rec-

ommended)

•Windows XP: 512 MB or more (2 GB or more recommended)

Hard-disk

space

A minimum of 500 MB available on the startup disk (1 GB or more rec-

ommended)

Monitor

•Resolution: 1024 × 768 pixels (XGA) or more (1280 × 1024 pixels/SXGA

or more recommended)

•Color: 24-bit color (True Color) or more

Mac OS

CPU

•Photos/JPEG movies: Intel Core or Xeon series

•H.264 movies (playback): 2 GHz Core Duo or better

•H.264 movies (editing): 2.6 GHz Core 2 Duo or better

OS Mac OS X version 10.6, 10.7, or 10.8

RAM 512 MB or more (2 GB or more recommended)

Hard-disk

space

A minimum of 500 MB available on the startup disk (1 GB or more rec-

ommended)

Monitor

•Resolution: 1024 × 768 pixels (XGA) or more (1280 × 1024 pixels/SXGA

or more recommended)

•Color: 24-bit color (millions of colors) or more

AMotion Snapshots

ViewNX 2 is required to view Motion Snapshots saved using the File

format > NMS files option in the shooting menu (0124).

The system requirements for Short Movie Creator are:

If your system does not meet the above requirements, only

ViewNX 2 will be installed (093).

Windows

CPU 2 GHz intel Core 2 Duo or better

OS Pre-installed versions of Windows XP, Windows Vista, Win-

dows 7, and Windows 8

RAM 1.5 GB or more with at least 128 MB of video RAM (2 GB or more

with at least 256 MB of video RAM recommended for creating HD movies)

Hard-disk

space

A minimum of 500 MB available on the startup disk (1 GB or more rec-

ommended)

Monitor •Resolution: 1024 × 768 pixels (XGA) or more

•Color: 32-bit color (True Color) or more

Other DirectX 9 or later and OpenGL 1.4 or later

Mac OS

CPU 2 GHz intel Core 2 Duo or better

OS Mac OS X version 10.6, 10.7, or 10.8

RAM 1GB or more

Hard-disk

space

A minimum of 500 MB available on the startup disk (1 GB or more rec-

ommended)

Monitor •Resolution: 1024 × 768 pixels (XGA) or more

•Color: 24-bit color (millions of colors) or more

ASupported Operating Systems

See the websites listed on page xvii for the latest information on sup-

ported operating systems.

Transferring Pictures

1Choose how pictures will be copied to the computer.

Choose one of the following methods:

•Direct USB connection: Turn the camera off and ensure that the

memory card is inserted in the camera. Connect the camera

to the computer using the supplied USB cable (do not use

force or insert the connectors at an angle) and then turn the

camera on.

•SD card slot: If your computer is equipped with an SD card slot,

the card can be inserted directly in the slot.

•SD card reader: Connect a card reader (available separately

from third-party suppliers) to the computer and insert the

memory card.

2Start the Nikon Transfer 2 component of ViewNX 2.

If a message is displayed prompting you to choose a pro-

gram, select Nikon Transfer 2.

Viewing and Editing Pictures on a Computer

AWindows 7

If the following dialog is displayed, select Nikon Transfer 2 as

described below.

1Under Import pictures and

videos, click Change pro-

gram. A program selection

dialog will be displayed; select

Import File using Nikon

Transfer 2 and click OK.

2Double-click Import file.

3Click Start Transfer.

At default settings, all the

pictures on the memory

card will be copied to the

computer.

4Terminate the connection.

If the camera is connected to the computer, turn the camera

off and disconnect the USB cable. If you are using a card

reader or card slot, choose the appropriate option in the com-

puter operating system to eject the removable disk corre-

sponding to the memory card and then remove the card from

the card reader or card slot.

Viewing Pictures

Pictures are displayed in

ViewNX 2 when transfer is com-

plete.

AStarting ViewNX 2 Manually

•Windows: Double-click the

ViewNX 2 shortcut on the desk-

top.

•Mac OS: Click the ViewNX 2 icon in

the Dock.

Click Start Transfe

❚❚ Retouching Photographs

To crop pictures and perform

such tasks as adjusting sharp-

ness and tone levels, click the

Edit button in the toolbar.

❚❚ Creating Short Movies

Use the Short Movie Creator to

create short movies combining

photos, music, Motion Snap-

shots, and movie footage

(098).

❚❚ Printing Pictures

Click the Print button in the

toolbar. A dialog will be dis-

played, allowing you to print

pictures on a printer connected

to the computer.

AFor More Information

Consult online help for more infor-

mation on using ViewNX 2.

Creating Short Movies

Use the supplied Short Movie Creator software to create movies

combining photographs with Motion Snapshots, movies, and

music.

1Transfer pictures.

Transfer pictures as described on page 95.

2Select components.

Select pictures in ViewNX 2.

3Start Short Movie Creator.

The images selected in Step

2 will be displayed in the

Short Movie Creator “Com-

ponents” panel; if desired,

additional pictures can be

dragged into the “Compo-

nents” panel from ViewNX 2

and re-ordered using drag

and drop. In the case of

photos taken with the

Smart Photo Selector, only the best shot will be displayed.

The photo and movie components of Motion Snapshots

appear as separate files.

4Select a style and background track.

Select a style in the “Styles” panel and a background track in

the “Music” panel. To preview the movie, click .

Click the Short Movie

Creator button in ViewNX 2.

“Components” panel

5Save the movie.

Click Create Movie. The dia-

log shown at right will be

displayed; select one of the

following options and click

Create.

•Save file: Save the movie to a

folder on the computer.

•Save to Camera (memory card):

Save the movie to a mem-

ory card so that it can later

be played back on the cam-

era. To use this option, you

will first need to insert a memory card that has been format-

ted in the camera (0158) into a card reader or card slot.

AStarting Short Movie Creator

If ViewNX 2 is not running, you can start

Short Movie Creator by double-clicking

the Short Movie Creator icon on the

desktop (Windows) or clicking the Short

Movie Creator icon in the Dock (Mac OS). Windows Mac OS

AViewing Short Movies on Other Devices

Movies saved to a memory card using the Save to Camera (memory

card) option in Short Movie Creator can be viewed on the camera, or

displayed on a television monitor when the camera is connected to a

TV (0100). Movies created in other applications or using the Save file

option in Short Movie Creator can not be viewed on the camera.

AFor More Information

Consult online help for more infor-

mation on using Short Movie Cre-

ator.

100

Connect the camera to a television for playback.

High-Definition Devices

A type C mini-pin High-Definition Multimedia Interface (HDMI)

cable (available separately from third-party suppliers) can be

used to connect the camera to high-definition video devices.

1Connect the HDMI cable.

Turn the camera off and connect the HDMI cable.

2Tune the device to the HDMI channel.

3Turn the camera on.

Turn the camera on; the camera monitor will remain off and

the camera shooting mode display will appear on the HD

device. Pictures can be played back using camera controls as

described elsewhere in this manual; note that the edges of

images may not be visible in the display.

Viewing Pictures on TV

AConnecting an HDMI Cable

Always turn the camera off before connecting or disconnecting HDMI

cables. When connecting cables, do not use force or attempt to insert

the connectors at an angle.

Connect to HD device

(choose cable with

appropriate connector)

Connect to camera

101

❚❚ HDMI Device Control

To control the camera remotely from a device that supports

HDMI-CEC (High-Definition Multimedia Interface–Consumer

Electronics Control), select On for HDMI device control in the

camera setup menu. The HDMI-CEC device will display a remote

control guide and the remote control can be used in place of the

following camera controls:

The remote control guide can be hidden or displayed at any time

by pressing the yellow button on the remote control. See the

television manual for details.

DClose the Connector Cover

Close the connector cover when the connectors are not in use. Foreign

matter in the connectors can interfere with data transfer.

ATelevision Playback

Volume can be adjusted using the controls on the television; adjusting

volume on the camera has no effect. Use of an EH-5b AC adapter and

EP-5C power connector (available separately) is recommended for

extended playback.

Camera Remote control

1, 3, 4, 2Up, down, left, and right buttons

JCenter button

KBlue button

GRed button

Slide show menu Green button

102

Selected JPEG images can be printed on a PictBridge printer

connected directly to the camera.

Connecting the Printer

Connect the camera using the supplied USB cable.

1Turn the camera off.

2Connect the USB cable.

Turn the printer on and connect the USB cable as shown. Do

not use force or attempt to insert the connectors at an angle.

3Turn the camera on.

Printing Photographs

AUSB Hubs

Connect the camera directly to the printer; do not connect the

cable via a USB hub.

A welcome screen will be displayed in

the monitor, followed by a PictBridge

playback display.

APrinting Via Direct USB Connection

Be sure the EN-EL20 battery is fully charged or use an optional EH-5b

AC adapter and EP-5C power connector.

103

Printing Pictures One at a Time

1Select a picture.

Press 4 or 2 to view additional pictures. Rotate the multi

selector clockwise to zoom in on the current frame (084;

rotate the multi selector counterclockwise to exit zoom). To

view nine pictures at a time, rotate the selector counterclock-

wise when a picture is displayed full frame. Press 1, 3, 4, or

2 to highlight pictures, or rotate the multi selector clockwise

to display the highlighted picture full frame.

2Adjust print options.

Press J to display PictBridge print options (0105). Press 1

or 3 to highlight options and press 2 to select.

3Start printing.

Highlight Start printing and press J

to start printing. To cancel before all

copies have been printed, press J

again.

DSelecting Photographs for Printing

Movies and NEF (RAW) photographs (0120) can not be selected for

printing. If Motion Snapshots are selected, only the photographs will

be printed; the movie portion will not be printed. If photographs taken

with the Smart Photo Selector are selected, only the best shot will be

printed.

DPanoramas

Some printers may not print panoramas, while at some settings others

may not print entire panoramas. See the printer manual for details.

104

Printing Multiple Pictures

1Display the PictBridge menu.

Press the G button in the PictBridge playback display (see

Step 3 on page 102).

2Choose an option.

Highlight one of the following options and press 2.

•Select images for printing: Select pictures for printing.

•Print DPOF print order: Print an existing print order created with

the DPOF print order option in the playback menu

(0106). The current print order will be displayed in Step 3.

•Index print: To create an index print of all JPEG pictures on the

memory card, proceed to Step 4. Note that if the memory

card contains more than 256 pictures, a warning will be dis-

played and only the first 256 images will be printed.

3Select pictures.

Press 4 or 2 to highlight pictures. To select the current pic-

ture for printing, press 1. The number of prints will be set to

1; press 1 or 3 to specify the number of prints (up to 99; to

deselect the picture, press 3 when the number of prints is 1).

Continue until all the desired pictures have been selected.

4Adjust print options.

Press J to display PictBridge print options. Press 1 or 3 to

highlight page size, border, or time stamp items and press 2

to display the options described on page 105; note that a

warning will be displayed if the selected page size is too small

for an index print.

105

5Start printing.

Highlight Start printing and press J

to start printing. To cancel before all

copies have been printed, press J

again.

AErrors

See page 188 for information on what to do if an error occurs during

printing.

APictBridge Print Options

Page

size

Highlight a page size (only sizes supported by the current

printer are listed) and press J to select and exit to the previous

menu (to print at the default page size for the current printer,

select Use printer settings).

Number

copies

This option is listed only when pictures are printed one at a

time. Press 1 or 3 to choose number of copies (maximum 99),

then press J to select and return to the previous menu.

border

This option is listed only if supported by the printer. Highlight

Use printer settings (use current printer settings), Yes (print

white borders), or No (no borders) and press J to select and

exit to the previous menu.

time

stamp

Highlight Use printer settings (use current printer settings),

Yes (print times and dates of recording on photos), or No (no

time stamp) and press J to select and exit to the previous

menu.

Crop

This option is listed only when pictures are printed one at a

time on a printer that supports cropping. To exit without crop-

ping, highlight No and press J. To crop the current picture,

highlight Yes and press 2. A crop selection dialog will be dis-

played; rotate the multi selector clockwise to increase the size

of the crop, counterclockwise to decrease. Press 1, 3, 4, or 2

to position the crop and press J. Note that print quality may

drop if small crops are printed at large sizes.

106

Creating a DPOF Print Order: Print Set

The DPOF print order option is used to

create digital “print orders” for Pict-

Bridge-compatible printers and devices

that support DPOF. Press the G but-

ton, select DPOF print order in the play-

back menu, and choose from the

following options:

Select/

set

Press 4 or 2 to highlight pictures

(0109). To select the current picture

for printing, press 1. The picture will

be marked with a Z icon and the

number of prints will be set to 1; press

1 or 3 to specify the number of

prints (up to 99; to deselect the pic-

ture, press 3 when the number of prints is 1). When the selec-

tion is complete, press J to display printing options. Highlight

Print shooting info (print the shutter speed and aperture on all

pictures in the print order) or Print date (print the date of

recording on all pictures in the print order) and press 2 to select

or deselect, and then press J to complete the print order.

Reset Remove all pictures from the print order.

DDPOF Print Order

DPOF date and shooting info options are not supported when printing

via direct USB connection; to print the date of recording on photo-

graphs in the current print order, use the PictBridge Print time stamp

option (0105).

The DPOF print order option can not be used if there is not enough

space on the memory card to store the print order. For restrictions on

the types of images that can be selected for printing, see page 103.

Print orders may not print correctly if images are deleted using a com-

puter or other device after the print order is created.

107

The Playback Menu

To display the playback menu, press G and select Playback.

The playback menu contains the following options:

G button

Option Description Default 0

Delete Delete multiple images. — 85

Slide show View movies and photos in a slide

show.

Image type: All images

Selected scene: Auto

Frame interval: 5 s

Movie playback time:

Same as frame interval

Audio: Background track 1


review

Choose whether pictures are

displayed after shooting. On 110

Rotate tall

Rotate “tall” (portrait-orientation)

pictures for display during

playback.

On 110

DPOF print

order Create digital “print orders”. — 106

Protect Protect pictures from accidental

deletion. — 110

Rating Rate pictures. — 110

D-Lighting

Brighten shadows in dark or back-lit

photos, creating a retouched copy

that is saved separately from the

unmodified original.

— 111

Resize Create small copies of selected

pictures.

Choose size:

1280×856; 1.1 M 112

108

Crop Create cropped copies of selected

pictures. Aspect ratio: 3 : 2 113

Face-

priority

zoom

Choose whether 4 and 2 can be

used during playback zoom (084)

to select faces detected with face

priority.

On 114

Edit movie

Create copies of movies from which

unwanted footage has been

trimmed.

—114

Change

theme

Change the themes for existing

Motion Snapshots. —115

APlayback

The camera may be unable to display or retouch images that were cre-

ated or have been edited with other devices.

AImage Quality

Copies created from JPEG photos are the same quality as the original,

while copies created from NEF (RAW) photos are saved as fine-quality

JPEG images (0120).

Option Description Default 0

109

Selecting Multiple Images

Choosing the options listed below dis-

plays an image selection dialog. Press 4

or 2 to highlight pictures (only pictures

to which the operation applies are avail-

able for selection).

•Delete > Delete selected images (085)

•DPOF print order > Select/set (0106)

•Protect > Select/set (0110) •Rating (0110)

•D-Lighting (0111) •Resize > Select images (0112)

•Crop > Select images (0113) •Edit movie (0114)

•Change theme (0115)

AInspecting Pictures

The picture currently highlighted in the

thumbnail display can be inspected by press-

ing 1; except in the cases of DPOF print

order, Rating, and Change theme, the pic-

ture will be displayed full screen while the

button is pressed.

110

If On is selected, pictures will be displayed immediately after

shooting. To view pictures when Off is selected, press the K

button.

Choose whether to rotate “tall” (portrait-orientation) pictures for

display during playback. Note that because the camera itself is

already in the appropriate orientation during shooting, images

are not rotated automatically during image review.

Protect selected images from accidental deletion. Note that this

option does NOT protect files from deletion when the memory

card is formatted (0158).

Press 4 or 2 to highlight pictures (0109) and press 1 or 3 to

choose a rating (086). Press J to exit when the operation is

complete.

Image Review

Rotate Tall

“Tall” (portrait-orientation) pictures are automatically rotated

for display in the camera monitor. Pictures taken with Off

selected for Auto image rotation (0163) will be displayed in

“wide” (landscape) orientation.

Off “Tall” (portrait-orientation) pictures are displayed in “wide”

(landscape) orientation.

Protect

Select/set

Press 4 or 2 to highlight pictures (0109) and press 3 to

select or deselect. Press J to exit when the operation is com-

plete.

Reset Remove protection from all pictures.

Rating

111

Applied to selected images, D-Lighting creates copies that have

been processed to brighten shadows. Use to retouch dark or

backlit photographs.

Press 4 or 2 to highlight an image

(0109) and press J to display the

options shown at right. Press 1 or 3 to

choose the amount of correction per-

formed (the effect can be previewed in

the display) and press J to create a

retouched copy.

D-Lighting

Before After

DD-Lighting

Noise (randomly-spaced bright pixels, fog, or lines) may appear in cop-

ies created with D-Lighting. Uneven shading may be visible with some

subjects.

AImage Size

Copies created from JPEG photos are the same size as the original,

while copies created from NEF (RAW) photos are saved as JPEG images

with a size of 4608 × 3072.

112

Create small copies of selected photo-

graphs. Select

Choose size

and choose a

size from

1280×856; 1.1M

(1280 × 856 pix-

els),

960×640; 0.6 M

(960 × 640 pixels), and

640×424; 0.3M

(640 × 424 pixels), and then

choose

Select images

. Press

highlight pictures (

109

) and press

to select or deselect. When

the selection is complete, press

to display a confirmation dialog

and select

Yes

to save the resized copies.

Resize

DResized Copies

Playback zoom may not be available with resized copies.

113

Create a cropped copy of selected photographs.

The selected image will be displayed with

a default crop of the selected aspect ratio

shown in yellow. Use the controls below

to size and position the crop and save the

copy.

Crop

Select

images

To select an image for trimming, choose Select images, high-

light a picture (0109), and press J.

Aspect

ratio Choose from aspect ratios of 3 : 2, 4 : 3, 1 : 1, and 16 : 9.

To Use Description

Decrease crop

size

Rotate the multi selector counterclockwise

to decrease the size of the crop.

Increase crop

size

Rotate the multi selector clockwise to

increase the size of the crop.

Position crop Press 1, 3, 4, or 2 to position the crop.

Create copy JSave the current crop as a separate file.

DCropped Copies

Playback zoom may not be available with

cropped copies. The size of the copy varies

with crop size and aspect ratio and appears

at upper left in the crop display.

114

If On is selected, 4 and 2 can be used during playback zoom to

select faces detected with face priority. If Off is selected, 4 and

2 can be used with 1 and 3 to scroll the display.

Trim footage from movies to create edited copies.

1Select Choose start point or Choose end point.

Choose from the following options:

•Choose start point: Trim the opening

footage.

•Choose end point: Trim the closing foot-

age.

2Select a movie.

Press 4 or 2 to highlight a movie (0109) and press J to

select.

3Pause the movie on opening or closing frame.

Play the movie back, pressing J to

begin and resume playback and 3 to

pause (065; the first frame is indi-

cated by a h icon in the display, the

last frame by i). Pause playback

when you reach the frame that will

become the new opening or closing frame.

4Delete the unwanted frames.

Press 1 to delete all frames before (Choose start point) or

after (Choose end point) the current frame.

Face-Priority Zoom

Edit Movie

115

5Save the copy.

Highlight Yes and press J to save the

edited copy. If necessary, the copy can

be trimmed as described above to

remove additional footage.

Assign existing Motion Snapshots new themes (NMS-format files

only; Motion Snapshots created with MOV file selected for File

format in the shooting menu can not be assigned new themes).

Choose from Beauty, Waves, Relaxation, Tenderness, and

None. Highlight a Motion Snapshot and press J to display a list

of themes (to play a theme, highlight it and press 2; volume can

be adjusted by rotating the multi selector). Highlight the new

theme and press J. A confirmation dialog will be displayed;

select Ye s to save the selected Motion Snapshot with the new

theme.

DTrimming Movies

Movies must be at least two seconds long. If a copy can not be created

at the current playback position, the current position will be displayed

in red in Step 4 and no copy will be created. The copy will not be saved

if there is insufficient space available on the memory card.

To prevent the camera from turning off unexpectedly, use a fully-

charged battery when editing movies.

Change Theme

ASee Also

See page 124 for information on Motion Snapshot file formats.

116

117

The Shooting Menu

To display the shooting menu, press G and select Shooting.

The shooting menu contains the following options:

G button

Option Description Default 0

Reset shooting

options

Reset shooting options to

default values. —119

Exposure

mode

Choose how the camera sets

shutter speed and aperture in

Motion Snapshot mode

(053).

Scene auto selector 119

Image quality Choose a file format and

compression ratio. JPEG normal 120

Image size Choose a size for new photos.

4608 × 3072; 14.2 M

(standard photos)/ Normal

panorama (panoramas)

120

Number of

shots saved

Choose the number of shots

selected by the Smart Photo

Selector (047).

5123

Movie before/

after

Choose when the movie

portion of Motion Snapshots is

recorded (053).

1.0 s : 0.6 s 123

File format Choose a file format for new

Motion Snapshots (053). NMS files 124

Metering Choose how the camera

meters exposure. Matrix 124

118

*Varies with lens (0128).

Auto distortion

control

Choose whether the camera

corrects barrel and pincushion

distortion.

Off 125

Color space Choose a color space for new

pictures. sRGB 126

Active

D-Lighting

Avoid loss of detail in

highlights and shadows. On 127

HDR

Enhance detail in highlights

and shadows when

photographing high-contrast

scenes with Backlighting

selected in creative mode.

On 40

Long exposure

Reduce noise in long time-

exposures. Off 128

Optical VR

Adjust settings for 1 NIKKOR

lenses with vibration

reduction.

Active/On*128

Electronic VR

Choose whether to use

vibration reduction in Motion

Snapshot mode (053). This

feature is available even if

vibration reduction is not

offered by the attached 1

NIKKOR lens.

On 129

Focus mode Choose how the camera

focuses. See page 130 129

AF-area mode Choose how the focus area is

selected. Auto-area 134

Face-priority Turn face priority on or off. On 136

Built-in AF

assist

Control the built-in AF-assist

illuminator. On 136

Flash

compensation Control flash output. 0.0 137

Option Description Default 0

119

Select Yes to reset the options in the shooting menu and other

shooting settings to default values (0117, 180).

The options in the exposure mode menu offer varying degrees

of control over shutter speed and aperture in Motion Snapshot

mode (053).

Reset Shooting Options

Exposure Mode

hScene auto

selector

An automatic, “point-and-shoot” mode in which the

camera not only chooses shutter speed and aperture

but adjusts other settings to suit the subject (

automatic

scene selection;

023).

PProgrammed

auto

The camera sets shutter speed and aperture for optimal

exposure (034). Recommended for snapshots and in

other situations in which there is little time to adjust

camera settings.

SShutter-

priority auto

You choose the shutter speed; the camera selects an

aperture for best results (035). Use to freeze or blur

motion.

AAperture-

priority auto

You choose the aperture; the camera selects a shutter

speed for best results (036). Use to blur the back-

ground or bring both foreground and background into

focus.

MManual You control both shutter speed and aperture (037). Set

shutter speed to “Bulb” for long time-exposures.

AISO Sensitivity (P, S, A, and M Modes)

When an “auto” option is selected for ISO sensitivity (0149), the cam-

era will automatically adjust sensitivity within the selected range if

optimal exposure can not be achieved at the selected shutter speed or

aperture.

120

Choose a file format and compression ratio for photographs.

Choose the size of photographs.

❚❚ Standard Photographs

The following options are available in still image and Smart

Photo Selector modes and when an option other than Easy pan-

orama is selected in creative mode.

Image Quality

Option File type Description

NEF (RAW) NEF

Compressed 12-bit raw data from the image sensor

are saved directly to the memory card. White bal-

ance, contrast, and other settings can be adjusted

on a computer after shooting.

JPEG fine

JPEG

Record JPEG images at a compression ratio of

roughly 1 : 4 (fine quality).

JPEG normal Record JPEG images at a compression ratio of

roughly 1 : 8 (normal quality).

JPEG basic Record JPEG images at a compression ratio of

roughly 1 : 16 (basic quality).

NEF (RAW) +

JPEG fine

NEF/

JPEG

Two images are recorded: one NEF (RAW) image

and one fine-quality JPEG image.

Image Size

Option Size (pixels) Approximate print size at 300 dpi (cm/in.) 1

#4608×3072; 14.2 M 4608 × 3072 39.0 × 26.0/15.4 × 10.2

$3456×2304; 8.0 M 3456 × 2304 29.3 × 19.5/11.5 × 7.7

%2304×1536; 3.5 M 2304 × 1536 19.5 × 13.0/ 7.7 × 5.1

121

❚❚ Panoramas

The following options are available when Easy panorama is

selected in creative mode.

1Figures for horizontal and vertical panorama are reversed if camera is

rotated 90 degrees.

2Print size in inches equals image size in pixels divided by printer resolution

in dots per inch (dpi; 1 inch=approximately 2.54 cm).

Option Size (pixels)1Approximate print size at 300 dpi

(cm/in.) 2

ANormal

panorama

Camera panned

horizontally: 4800 × 920 40.6 × 7.8/16.0 × 3.0

Camera panned

vertically: 1536 × 4800 13.0 × 40.6/5.1 × 16.0

BWide

panorama

Camera panned

horizontally: 9600 × 920 81.3 × 7.8/32.0 × 3.1

Camera panned

vertically: 1536 × 9600 13.0 × 81.3/5.1 × 32.0

122

ANEF (RAW)/NEF (RAW) + JPEG

The option selected for image size does not affect the size of NEF (RAW)

images. NEF (RAW) images can be viewed on the camera or using soft-

ware such as Capture NX 2 (available separately; 0166) or ViewNX 2

(supplied).

When photographs taken at NEF (RAW) + JPEG are viewed on the cam-

era, only the JPEG image will be displayed. When photographs taken at

these settings are deleted, both NEF and JPEG images will be deleted.

AFile Names

Photos and movies are stored as image files with names of the form

“xxx_nnnn.yyy,” where:

•xxx is either NMS (Motion Snapshots recorded with NMS files

selected for File format; 0124) or DSC (photos, MOV-format Motion

Snapshots, and movies, including copies created with Edit movie;

0114),

•nnnn a four-digit number between 0001 and 9999 assigned automat-

ically in ascending order by the camera, and

•yyy one of the following three letter extensions: “NEF” for NEF (RAW)

images, “JPG” for JPEG images, or “MOV” for movies.

The NEF and JPEG files recorded at settings of NEF (RAW)+JPEG have

the same file names but different extensions. Trimmed copies created

with Edit movie (0114) have file names beginning with “DSC”; copies

created with the other retouch options in the playback menu have file

names beginning with “CSC” (e.g., “CSC_0001.JPG”). Images recorded

with Adobe RGB selected for Color space (0126) have names that

begin with an underscore (e.g., “_DSC0001.JPG”).

AImage Quality and Size

Together, image quality and size determine how much space each pho-

tograph occupies on the memory card. Larger, higher quality images

can be printed at larger sizes but also require more memory, meaning

that fewer such images can be stored on the memory card (0181).

123

Choose the number of shots selected by the Smart Photo Selec-

tor. If 5 is selected, the camera will save the best shot and 4 best

shot candidates. If 1 is selected, the camera will save only the

best shot.

Choose whether the movie portions of Motion Snapshots end

when the shutter-release button is pressed all the way or about

0.6 s after (053). If 1.6 s : 0 s is selected, the photograph used

for the Motion Snapshot will feature the last frame of the movie.

Number of Shots Saved

Movie Before/After

1.0 s : 0.6 s

Movie footage starts about a second before the shutter-

release button is pressed all the way down and ends about

0.6 s after.

1.6 s : 0 s

The camera records about 1.6 s of movie footage, ending

when the shutter-release button is pressed all the way down.

Shutter-release button

pressed halfway

Shutter-release button

pressed all the way down

1.0 s 0.6 s

Movie footage

Shutter-release button

pressed halfway

Shutter-release button

pressed all the way down

1.6 s

Movie footage

124

Choose the file format for Motion Snapshots (053).

Choose how the camera sets exposure.

File Format

NMS files

Motion Snapshots are recorded as a 4 s MOV file and a JPEG

image. Motion Snapshots can only be viewed on the camera or

using ViewNX 2 (093).

MOV file

Motion Snapshots are recorded as a 10 s MOV file that can be

viewed in a variety of computer applications. The Motion Snap-

shot is not displayed automatically when shooting ends (054);

for information on viewing Motion Snapshot movies, see page

65.

Metering

LMatrix

The camera meters a wide area of the frame and adjusts for

contrast (tone distribution), color, composition, and subject

distance, producing natural results in most situations.

MCenter-

weighted

The camera meters the entire frame but assigns the greatest

weight to the center area. This is the classic meter for por-

traits and is recommended if you are using filters with an

exposure factor (filter factor) over 1×.

NSpot

The camera meters the current focus area; use to meter off-

center subjects (if Auto-area is selected for AF-area mode

as described on page 134, the camera will meter the center

focus area, while during face priority the camera will meter

the focus area closest to the center of the selected face;

024). Spot metering ensures that the subject will be cor-

rectly exposed, even when framed against a background

that is much brighter or darker.

AMetering and Shooting Mode

In auto and best moment capture modes and in creative modes other

than P, S, A, and M, and when hScene auto selector (0119) is chosen

in Motion Snapshot mode, metering is adjusted automatically accord-

ing to the scene.

125

Select On to reduce barrel distortion in photos taken with wide-

angle lenses and to reduce pin-cushion distortion in photos

taken with long lenses (note that the edges of photographs may

be cropped out, and that there may be an increase in the time

needed to process images before they are saved). This option is

available only with 1 NIKKOR lenses and not with other NIKKOR

lenses attached using the FT1 mount adapter (0202). Results

are not guaranteed with third-party lenses.

Auto Distortion Control

126

The color space determines the gamut of colors available for

color reproduction. Choose sRGB for photos that will be used

“as is,” with no further modification, Adobe RGB for photos that

will be extensively processed or retouched after leaving the

camera. Note that regardless of the option selected, sRGB is

used for movies and Motion Snapshots and for photos taken

during movie recording.

Color Space

AColor Space

Color spaces define the correspondence between colors and the

numeric values by which they are represented in a digital image file.

The sRGB color space is widely used, while Adobe RGB is typically used

in publishing and commercial printing. sRGB is recommended when

taking photographs that will be printed without modification or

viewed in applications that do not support color management, or

when taking photographs that will be printed with ExifPrint, the direct

printing option on some household printers, or kiosk printing or other

commercial print services. Adobe RGB photographs can also be

printed using these options, but colors will not be as vivid.

JPEG photographs taken in the Adobe RGB color space are DCF compli-

ant; applications and printers that support DCF will select the correct

color space automatically. If the application or device does not support

DCF, select the appropriate color space manually. For more informa-

tion, see the documentation provided with the application or device.

ANikon Software

ViewNX 2 (supplied) and Capture NX 2 (available separately) automati-

cally select the correct color space when opening photographs created

with this camera.

127

Active D-Lighting preserves details in highlights and shadows

for natural contrast. Use with high contrast scenes such as a

brightly lit outdoor view framed in a door or window or a sub-

jects in the shade on a sunny day. It is most effective when used

with Matrix metering (0124).

Active D-Lighting

Active D-Lighting: Off Active D-Lighting: Y On

DActive D-Lighting

Noise (randomly-spaced bright pixels, fog, or lines) may appear in pho-

tographs taken with Active D-Lighting. Uneven shading may be visible

with some subjects.

A“Active D-Lighting” Versus “D-Lighting”

The Active D-Lighting option in the shooting menu adjusts exposure

before shooting to optimize the dynamic range, while the D-Lighting

option in the playback menu (0111) brightens shadows in images

after shooting.

128

Photographs taken at slow shutter speeds are automatically pro-

cessed to reduce “noise” (bright spots, randomly-spaced bright

pixels, or fog), slightly increasing recording times. Selecting On

increases the amount of noise reduction performed at shutter

speeds slower than 1 s and increases the time required to record

images by roughly 1.5 to 2 times. During processing, a warning

will be displayed and pictures can not be taken (if the camera is

turned off before processing is complete, the picture will be

saved but noise reduction will not be performed). In continuous

release mode, frame rates will slow and while photographs are

being processed, the capacity of the memory buffer will drop.

This option is available with 1 NIKKOR lenses that support vibra-

tion reduction (VR). The options available vary with the type of

lens: Normal/Active/Off for lenses that support active vibration

reduction and On/Off for other VR lenses. Choose Active, Nor-

mal, or On to reduce the effects of vibration; choose Active

when shooting from a moving vehicle or while walking or for

other forms of strong camera shake, Normal for the relatively

mild camera shake that occurs while standing still.

Long Exposure NR

Optical VR

AVibration Reduction

When the camera is panned, vibration reduction applies only to motion

that is not part of the pan (if the camera is panned horizontally, for

example, vibration reduction will be applied only to vertical shake),

making it much easier to pan the camera smoothly in a wide arc. The

composition may appear to change after the shutter is released, but

this does not indicate a malfunction.

129

Select On to enable electronic vibration reduction while record-

ing Motion Snapshots. This feature is available even if the

attached 1 NIKKOR lens does not support vibration reduction.

Note that there will be a slight delay before recording begins

and that the edges of the image will be cropped out when On is

selected.

Choose how the camera focuses.

*Shutter can only be released if camera is able to focus.

Electronic VR

Focus Mode

AF-A Auto-select AF: The camera automatically selects AF-S if the subject is

stationary, AF-C if it is moving.

AF-S Single AF: For stationary subjects. Focus locks when the shutter-

release button is pressed halfway. *

AF-C

Continuous AF: For subjects in motion. The

camera focuses continuously on the sub-

ject in the AF-area brackets while the

shutter-release button is pressed half-

way (note that the AF-area brackets

appear only in the detailed display;

0159). Photos can be taken whether or

not the camera is in focus. AF-area brackets

AF-F Full-time AF: For subjects in motion. The camera focuses continu-

ously; photos can be taken whether or not the camera is in focus.

MF Manual focus: Focus manually (0132). Photos can be taken whether

or not the camera is in focus.

130

AFocus Mode

The options available vary as shown below.

Menu Focus mode

Shooting AF-A (default), AF-S, AF-C, MF

Movies

P Programmed auto, S Shutter-

priority auto, A Aperture-priority

auto, M Manual

AF-F (default), AF-S, MF

y Slow motion AF-S (default), MF

131

AGetting Good Results with Autofocus

Autofocus does not perform well under the conditions listed below.

The shutter release may be disabled if the camera is unable to focus

under these conditions, or the focus area may be displayed in green

and the camera may sound a beep, allowing the shutter to be released

even when the subject is not in focus. In these cases, focus manually

(0132) or use focus lock (0135) to focus on another subject at the

same distance, and then recompose the photograph.

There is little or no contrast between

the subject and the background.

The subject contains areas of sharply

contrasting brightness.

Example: The

subject is the

same color as

the back-

ground.

Examples: The

subject is half

in the shade; a

night scene

with point illu-

mination.

The subject contains objects at differ-

ent distances from the camera.

Background objects appear larger

than the subject.

Example: The

subject is

inside a cage.

Example: A

building is in

the frame

behind the

subject.

The subject is dominated by regular

geometric patterns.

The subject contains many fine details

or is made up of objects that are small

or lack variation in brightness.

Example: Blinds

or a row of

windows in a

skyscraper.

Example: A field

of flowers.

ASee Also

See page 160 for information on controlling the beep that sounds

when the camera focuses.

132

Manual Focus

Manual focus can be used when autofocus does not produce the

desired results.

1Select manual focus.

2Choose a magnification.

3Display the manual focus guides.

Highlight Manual focus in the focus

mode menu (0129) and press 2.

To choose the magnification for the

manual focus display, highlight 10×

zoom, 5× zoom, or 2× zoom and

press J.

In the shooting display, press J to

magnify the view at the center of the

frame by the amount selected in

Step 2 (this feature is not available

during movie recording or in slow-

motion movie mode). Manual focus

guides are also displayed.

133

4Focus.

Rotate the multi selector until the sub-

ject is in focus. Rotate the multi selec-

tor clockwise to increase the focus

distance, counterclockwise to

decrease; the faster you rotate the

multi selector, the quicker the focus

distance changes. The focus indicator

shows the approximate focus dis-

tance. Press J when the subject is in

focus.

Press 1, 3, 4, or 2 to view areas of

the frame not currently visible in the

display; the visible portion is shown

by the navigation window.

Focus indicator

Navigation window

AMovies

The multi selector can also be used to choose the focus distance if man-

ual focus is selected prior to movie recording. Rotate the multi selector

clockwise to increase the focus distance, counterclockwise to decrease;

the faster you rotate the multi selector, the quicker the focus distance

changes.

AFocal Plane Position

To determine the distance between your

subject and the camera, measure from the

focal plane mark on the camera body. The

distance between the lens mounting flange

and the focal plane is approximately 17 mm

(0.7 in.). Focal plane mark

Approx.

17 mm

134

Choose how the focus area for autofocus is selected.

AF-Area Mode

eAuto-

area

The camera automatically detects the subject and selects

the focus area.

cSingle-

point

Press J to view the focus area

selection display, then use the

multi selector to position the

focus area over your subject

and press J; the camera

focuses on the subject in the

selected focus area only.

Use

with stationary subjects.

Focus area

9Subject

tracking

Press J to view the focus area

selection display, then use the

multi selector to position the

focus area over your subject

and press J. The focus area

will track the subject as it

moves through the area shown

at right. The camera will focus

on the selected subject when

the shutter-release button is

pressed halfway. To end focus

tracking when shooting is

complete, press J.

Focus area

Subject tracking area

ASubject Tracking

The camera may be unable to track subjects if they move quickly, leave

the frame or are obscured by other objects, change visibly in size, color,

or brightness, or are too small, too large, too bright, too dark, or similar

in color or brightness to the background.

135

Focus Lock

When Single AF is selected for Focus mode (0129), focus lock

can be used to change the composition after focusing on the

subject in the center of the frame, allowing you to focus on a

subject that will not be in the center of the final composition. If

the camera is unable to focus using autofocus (0131), you can

also focus on another subject at the same distance and then use

focus lock to recompose the photograph. Focus lock is most

effective when an option other than Auto-area is selected for

AF-area mode (0134).

1Lock focus.

Position the subject in the center of

the frame and press the shutter-

release button halfway to initiate

focus. Check that the focus area is dis-

played in green. Focus will remain

locked while the shutter-release but-

ton is pressed halfway.

2Recompose the photograph and shoot.

Focus will remain locked between

shots.

Do not change the distance between the camera and the sub-

ject while focus lock is in effect. If the subject moves, lift your fin-

ger from the shutter-release button to end focus lock and then

focus again at the new distance.

136

Choose On to enable face priority (024).

When On is selected, the built-in AF-

assist illuminator will light to illuminate

poorly-lit subjects if:

•AF-S is selected for focus mode (0129)

or single AF is selected in AF-A, and

•Auto-area or Single-point is selected

for AF-area mode (0134).

The AF-assist illuminator will not light to assist the focus opera-

tion in advanced movie mode, during movie recording, or when

Off is selected. If the AF-assist illuminator does not light, autofo-

cus may not produce the desired results when lighting is poor.

Face-Priority

Built-in AF Assist

AThe AF-Assist Illuminator

Larger lenses may prevent the illuminator lighting all or part of the sub-

ject. Remove lens hoods when using the illuminator. Information on

the modes in which AF-assist is available may be found on page 176.

AF-assist illuminator

137

Flash compensation alters flash output

from the level suggested by the camera,

changing the brightness of the main sub-

ject relative to the background. Choose

from values between –3 EV (darker) and

+1 EV (brighter) in increments of 1

3EV; in

general, positive values make the subject brighter while nega-

tive values make it darker.

A Y icon is displayed when flash com-

pensation is in effect. Normal flash out-

put can be restored by setting flash

compensation to ±0. Flash compensa-

tion is not reset when the camera is

turned off.

Flash Compensation

138

139

(

The Movie Menu

To display the movie menu, press G and select Movies.

The movie menu contains the following options:

1Varies with lens (0128).

2The camera focuses on the subject in the center of the frame when

ySlow motion is selected in advanced movie mode.

3Face detection is not available when y Slow motion is selected in

advanced movie mode.

G button

Option Description Default 0

Reset movie

options

Reset movie menu options to

their default values. —140

Frame rate Choose a frame rate for slow-

motion movies (062). 400 fps 140

Movie settings Choose HD movie frame size

and frame rate (058). 1080/60i 141

Metering Choose how the camera

meters exposure. Matrix 124

Movie sound

options

Choose sound recording

options.

Microphone:

Auto sensitivity (A)

Wind noise reduction: On

142

Optical VR

Adjust settings for 1 NIKKOR

lenses with vibration

reduction.

Active/On1128

Focus mode Choose how the camera

focuses. See page 130 129

AF-area mode Choose how the focus area is

selected. Auto-area2134

Face-priority Turn face priority on or off. On3136

140

(

Select Yes to reset the options in the movie menu to default val-

ues (0139).

Choose a frame rate for slow-motion movies (062). The faster

the frame rate, the smaller the frame size.

*All figures are approximate. Slow-motion movies will play back over a

period of about 13.2 (400 fps) or 40 (1200 fps) times the recording time.

Reset Movie Options

Frame Rate

Option Frame size (pixels)

Bit rate

(approx.)

Maximum length

(shooting)

Maximum length

(playback)*

400 fps 640 × 240 2 Mbps 3 seconds 40 seconds

1200 fps 320 × 120 1 Mbps 3 seconds 2 minutes

ASee Also

For information on the total length of movies that can be stored on the

memory card, see page 183.

141

(

Choose a frame size and frame rate for HD movies (058).

*Sensor output is about 60 fps.

Movie Settings

Option Frame size (pixels) Recording rate

Bit rate

(approx.) Maximum length

t1080/60i 1920 × 1080 59.94 fields/s *24 Mbps 20 minutes

r1080/30p 29.97 fps 24 Mbps

u720/60p 1280 × 720 59.94 fps 16 Mbps 29 minutes

s720/30p 29.97 fps 12 Mbps

APhoto Frame Size

Photographs recorded by pressing the shutter-release button all the

way down during movie recording have an aspect ratio of 3 : 2. The

frame size varies with the option selected for Movie settings:

•1080/60i and 1080/30p: 4608 × 3072 pixels

•720/60p and 720/30p: 1280 × 856 pixels

ASee Also

For information on the total length of movies that can be stored on the

memory card, see page 183.

142

(

Adjust movie sound recording settings for the built-in micro-

phone.

❚❚ Microphone

Select Microphone off to disable sound recording. Selecting

any other option enables recording and sets the microphone to

the selected sensitivity.

❚❚ Wind Noise Reduction

Select On to enable the low-cut filter, reducing noise produced

by wind blowing over the microphone (note that other sounds

may also be affected).

Movie Sound Options

AThe 2 Icon

Movies recorded with the microphone off are indicated by a 2 icon in

full-frame and movie playback.

143

)

The Image Processing Menu

To display the image processing menu, press G and select

Image processing.

The image processing menu contains the following options:

G button

Option Description Default 0

Reset

processing

options

Reset image processing

options to their default values. —144

White balance Adjust settings for different

types of lighting. Auto 144

ISO sensitivity Control the camera’s sensitivity

to light. Auto (160–3200) 149

Picture Control Choose how the camera

processes pictures. Standard 150

Custom Picture

Control

Create custom Picture

Controls. —154

High ISO noise

reduction

Reduce noise at high ISO

sensitivities. On 156

144

)

Select Yes to reset the options in the image processing menu to

default values (0143).

White balance ensures that colors are unaffected by the color of

the light source. Auto white balance is recommended for most

light sources, but other values can be selected if necessary

according to the type of source.

Reset Processing Options

White Balance

vAuto Automatic white balance adjustment. Recom-

mended in most situations.

JIncandescent Use under incandescent lighting.

IFluorescent Use with cool-white fluorescent lighting.

HDirect sunlight Use with subjects lit by direct sunlight.

NFlash Use with built-in flash.

GCloudy Use in daylight under overcast skies.

MShade Use in daylight with subjects in the shade.

YUnderwater Choose when taking pictures underwater using an

optional WP-N2 waterproof case (0165).

LPreset manual Measure white balance (0146).

AWhite Balance and Shooting Mode

In auto and best moment capture modes and creative modes other

than P, S, A, and M, and when hScene auto selector (0119) is chosen

in Motion Snapshot mode, white balance is adjusted automatically

according to the scene.

145

)

Fine-Tuning White Balance

Options other than Preset manual can be fine-tuned as follows:

1Display fine-tuning options.

Highlight an option other than Preset

manual and press 2 to display the

fine-tuning options shown at right.

2Fine-tune white balance.

Use the multi selector to fine-tune white balance.

3Save changes and exit.

Press J. An asterisk will appear next to the white balance

icon (04) in the detailed display (0159) to show that white

balance has been altered from default values.

Increase green

Increase blue Increase amber

Increase magenta

AWhite Balance Fine Tuning

The colors on the fine-tuning axes are relative, not absolute. For

example, moving the cursor to B (blue) when a “warm” setting such

as J (incandescent) is selected will make photographs slightly

“colder” but will not actually make them blue.

Coordinates

Adjustmen

146

)

Preset Manual

Preset manual is used to record and recall custom white balance

settings for shooting under mixed lighting or to compensate for

light sources with a strong color cast.

1Light a reference object.

Place a neutral gray or white object under the lighting that

will be used in the final photograph. A standard gray panel

can be used for increased precision.

2Select Preset manual.

Highlight Preset manual in the white

balance menu and press 2. The dialog

shown at right will be displayed; high-

light Yes and press J to overwrite the

existing value for preset manual white

balance.

The message shown at right will be

displayed.

147

)

3Measure white balance.

When the camera is ready to measure

white balance, a flashing L will be

displayed. Before the indicator stops

flashing, frame the reference object so

that it fills the display and press the

shutter-release button all the way

down. No photograph will be

recorded; white balance can be mea-

sured accurately even when the cam-

era is not in focus.

4Check the results.

If the camera was able to measure a

value for white balance, the message

shown at right will be displayed. To

return to shooting mode immediately,

press the shutter-release button half-

way.

If lighting is too dark or too bright, the

camera may be unable to measure

white balance.

The message at right

will be displayed.

Return to Step 3 and

measure white balance again.

148

)

DAuto Power Off

White balance measurement will end without a new value being

acquired if no operations are performed for the time selected for Auto

power off in the setup menu (0160; the default is 1 minute).

DPreset White Balance

The camera can store only one value for preset white balance at a time;

the existing value will be replaced when a new value is measured. Note

that exposure is automatically increased by 1EV when measuring

white balance; in mode M, adjust exposure so that the exposure indica-

tor shows ±0 (037).

AColor Temperature

The perceived color of a light source varies with the viewer and other

conditions. Color temperature is an objective measure of the color of a

light source, defined with reference to the temperature to which an

object would have to be heated to radiate light in the same wave-

lengths. While light sources with a color temperature in the neighbor-

hood of 5000–5500 K appear white, light sources with a lower color

temperature, such as incandescent light bulbs, appear slightly yellow

or red. Light sources with a higher color temperature appear tinged

with blue. The camera white balance options are adapted to the follow-

ing color temperatures (all figures are approximate):

•Sodium-vapor lamps: 2700 K

•J (incandescent)/

Warm-white fluorescent: 3000 K

•White fluorescent: 3700 K

•Cool-white fluorescent: 4200 K

•Day white fluorescent: 5000 K

•H (direct sunlight): 5200 K

•N (flash): 5400 K

•G (cloudy): 6000 K

•Daylight fluorescent: 6500 K

•Mercury-vapor lamps: 7200 K

•M (shade): 8000 K

149

)

The higher the ISO sensitivity, the less light needed to make an

exposure, allowing faster shutter speeds or smaller apertures,

but the more likely the image is to be affected by “noise” in the

form of randomly-spaced bright pixels, fog, or lines.

ISO Sensitivity

Auto (160–6400)

Auto (160–3200)

Auto (160–800)

The camera adjusts ISO sensitivity in response to

lighting conditions. ISO sensitivity is adjusted in

the range given in brackets; choose larger ranges

for increased sensitivity when lighting is poor,

smaller ranges to reduce noise.

160, 200, 400, 800,

1600, 3200, 6400 ISO sensitivity is fixed at the selected value.

A“Auto” ISO Sensitivity Options

When auto ISO sensitivity control is in effect,

the display shows an ISO AUTO icon and the

current ISO sensitivity.

150

)

Choose how the camera processes photographs.

Modifying Picture Controls

Existing preset and custom Picture Controls (0154) can be

modified to suit the scene or your creative intent.

1Display options.

Highlight an item in the Picture Con-

trol menu and press 2 to display Pic-

ture Control settings (0152; the

settings available with custom Picture

Controls are the same as the preset

controls on which they are based). To

use an unmodified Picture Control, highlight it and press J.

Picture Control

QStandard Standard processing for balanced results. Recom-

mended in most situations.

RNeutral

Minimal processing for natural results. Choose for

photographs that will later be extensively processed

or retouched.

SVivid

Pictures are enhanced for a vivid, photoprint effect.

Choose for photographs that emphasize primary col-

ors.

TMonochrome Take monochrome photographs.

ePortrait Process portraits for natural texture and a rounded

feel.

fLandscape Take vibrant photographs of landscapes and city-

scapes.

151

)

2Adjust settings.

Press 1 or 3 to highlight the desired

setting and press 4 or 2 to choose a

value. Repeat this step until all set-

tings have been adjusted, or select

Quick adjust to choose a preset combination of settings.

Default settings can be restored by pressing the O button.

3Save changes and exit.

Press J.

APreset Picture Controls Versus Custom Picture Controls

The Picture Controls supplied with the camera are referred to as preset

Picture Controls. Custom Picture Controls are created through modifica-

tions to existing Picture Controls using the Custom Picture Control

option in the image processing menu (0154). If desired, custom Pic-

ture Controls can be saved to a memory card and copied to other

Nikon 1 J3 cameras or loaded into compatible software (0155).

AModified Picture Controls

Picture Controls that have been modified

from default settings are indicated by aster-

isks (“*”) next to the Picture Control name and

icon in the Picture Control menu (0150) and

next to the Picture Control icon (04) in the

detailed display (0159).

APicture Control and Shooting Mode

In auto and best moment capture modes and creative modes other

than P, S, A, and M, and when hScene auto selector (0119) is chosen

in Motion Snapshot mode, the camera automatically chooses a Picture

Control according to the scene.

152

)

❚❚ Picture Control Settings

Quick adjust

Choose from options between –2 and +2 to reduce or

exaggerate the effect of the selected Picture Control

(note that this resets all manual adjustments). For

example, choosing positive values for Vivid makes pic-

tures more vivid. Not available with Neutral, Mono-

chrome, or custom Picture Controls.

Manual adjustments

(all Picture Controls)

Sharpening

Control the sharpness of outlines. Select A to adjust

sharpening automatically according to the type of

scene, or choose from values between 0 (no sharpen-

ing) and 9 (the higher the value, the greater the sharp-

ening).

Contrast

Select A to adjust contrast automatically according to

the type of scene, or choose from values between –3

and +3 (lower values prevent highlights in portrait sub-

jects from being “washed out” in direct sunlight, while

higher values preserve detail in misty landscapes and

other low-contrast subjects).

Brightness Choose –1 for reduced brightness, +1 for enhanced

brightness. Does not affect exposure.

Manual adjustments

(non-monochrome only)

Saturation

Control the vividness of colors. Select A to adjust satu-

ration automatically according to the type of scene, or

choose from values between –3 and +3 (lower values

reduce saturation and higher values increase it).

Hue

Choose negative values (to a minimum of –3) to make

reds more purple, blues more green, and greens more

yellow, positive values (up to +3) to make reds more

orange, greens more blue, and blues more purple.

Manual adjustments

(monochrome only)

Filter

effects

Simulate the effect of color filters on monochrome pho-

tographs. Choose from Off, yellow, orange, red, and

green (0153).

Toning

Choose the tint used in monochrome photographs

from B&W (black-and-white), Sepia, Cyanotype (blue-

tinted monochrome), Red, Yel low, Green, Blue Green,

Blue, Purple Blue, and Red Purple (0153).

153

)

D“A” (Auto)

Results for auto sharpening, contrast, and saturation vary with expo-

sure and the position of the subject in the frame.

APrevious Settings

The line under the value displayed in the Pic-

ture Control setting menu indicates the pre-

vious value for the setting. Use this as a

reference when adjusting settings.

AFilter Effects (Monochrome Only)

The options in this menu simulate the effect of color filters on mono-

chrome photographs. The following filter effects are available:

Y (yellow) Enhance contrast. Can be used to reduce the brightness

of the sky in landscape photographs. Orange produces

more contrast than yellow, red more contrast than orange.

O (orange)

R (red)

G (green) Softens skin tones. Can be used for portraits.

Note that the effects achieved with Filter effects are more pronounced

than those produced by physical glass filters.

AToning (Monochrome Only)

Pressing 3 when Toning is highlighted dis-

plays saturation options. Press 4 or 2 to

adjust saturation. Saturation control is not

available when B&W (black-and-white) is

selected.

154

)

The Picture Controls supplied with the camera can be modified

and saved as custom Picture Controls.

Edit/Save

To create a custom Picture Control, select Edit/save and follow

the steps below.

1Select a Picture Control.

Highlight an existing Picture Control

and press 2, or press J to proceed to

Step 3 to save a copy of the high-

lighted Picture Control without fur-

ther modification.

2Edit the selected Picture Control.

See page 152 for more information. To

abandon any changes and start over

from default settings, press the O but-

ton. Press J when settings are com-

plete.

3Save the Picture Control.

Highlight a destination (C-1 through

C-9) and press J to save the custom

Picture Control and return to the

image processing menu.

The new Picture Control will be listed

in the Picture Control menu.

Custom Picture Control

155

)

Load from/Save to Card

Custom Picture Controls created using the Picture Control Utility

available with ViewNX 2 or optional software such as

Capture NX 2 can be copied to a memory card and loaded into

the camera, or custom Picture Controls created with the camera

can be copied to the memory card to be used in other Nikon 1 J3

cameras and compatible software and then deleted when no

longer needed.

To copy custom Picture Controls to or from the memory card, or

to delete custom Picture Controls from the memory card, select

Load from/save to card in the Custom Picture Control menu.

The following options will be displayed:

Copy to camera Copy custom Picture Controls from the memory card to

custom Picture Controls C-1 through C-9.

Delete from card

Delete selected custom Picture

Controls from the memory

card. The confirmation dialog

shown at right will be dis-

played before a Picture Control

is deleted; to delete the

selected Picture Control, high-

light Yes and press J.

Copy to card Copy a custom Picture Control (C-1 through C-9) to a

selected destination (1 through 99) on the memory card.

ACopy to Card

Up to 99 custom Picture Controls can be stored on the memory card at

any one time. The memory card can only be used to store user-created

custom Picture Controls. The preset Picture Controls supplied with the

camera can not be copied to the memory card or deleted.

ACustom Picture Control > Delete

The Delete option in the Custom Picture Control menu can be used to

delete selected custom Picture Controls from the camera when they

are no longer needed.

156

)

Select On to reduce “noise” (randomly-spaced bright pixels,

lines, or fog). If Off is selected, noise reduction will only be per-

formed at high ISO sensitivities; the amount of noise reduction is

less than that performed when On is selected.

High ISO Noise Reduction

157

The Setup Menu

To display the setup menu, press G and select Setup.

The setup menu contains the following options:

G button

Option Description Default 0

Reset setup options

Reset setup menu options to

default values.

—158

Format memory card

Format the memory card.

—158

Slot empty release

lock

Allow the shutter to be

released when no memory

card is inserted in the cam-

era.

Release locked 159

Display

Adjust display brightness,

view or hide a framing grid,

and choose the information

displayed in the monitor.

Display brightness: 0

Grid display: Off

Shooting: Simple

Playback: Basic info

159

Sound settings

Choose the sounds made

during shooting.

Autofocus/self-timer: On

Shutter: On 160

Auto power off Choose the auto power off

delay. 1 min 160

Shutter button AE

lock

Choose whether exposure

locks when the shutter-

release button is pressed

halfway.

Off 161

HDMI device control

Choose whether remote

controls for HDMI-CEC

devices to which the cam-

era is connected can be

used to operate the cam-

era.

On 101

158

Select Ye s to reset all setup menu options other than Flicker

reduction, Time zone and date, and Language to default val-

ues.

Select Yes to format the memory card. Note that this permanently

deletes all data on the card, including protected images; before

proceeding, be sure to copy important pictures and other data

to a computer (095). To exit without formatting the memory

card, highlight No and press J.

Flicker reduction Reduce flicker or banding. —161

Reset file numbering Reset file numbering. —161

Time zone and date Set the camera clock. Daylight saving time: Off 162

Language Choose a language for the

camera displays. —162

Auto image rotation Record camera orientation

with pictures. On 163

Wireless mobile

adapter

Enable or disable the wire-

less mobile adapter. —76

Pixel mapping

Check and optimize the

camera image sensor and

image processors.

—164

Firmware version Display the current firm-

ware version. —164

Reset Setup Options

Format Memory Card

The message shown at right is displayed

while the card is formatted; do not remove

the memory card or remove or disconnect

the power source until formatting is com-

plete.

Option Description Default 0

159

If Enable release is selected, the shutter can be released when

no memory card is inserted. No pictures will be recorded,

although they will be displayed in demo mode. Select Release

locked to enable the shutter only when a card is inserted.

Adjust the following display options.

Display Brightness

Press 1 or 3 to choose a value for moni-

tor brightness. Choose higher values to

brighten the display and lower values to

make the display darker.

Grid Display

Select On to display a framing grid (05).

Shooting

Choose the information displayed during shooting (04).

Slot Empty Release Lock

Display

Simple Detailed

160

Playback

Choose the information displayed during playback (079).

Highlight items and press 2 to select or

deselect. If Autofocus/self-timer is

selected, a beep will sound when the

camera focuses and during self-timer

photography; to mute the beep, remove

the check from this item. Select Shutter

to play a sound when the shutter is released, or remove the

check from this item to mute the shutter. Press J to exit when

settings are complete.

Choose how long the display remains on

when no operations are performed

(017). Choose shorter delays to reduce

the drain on the battery. Once the display

has turned off, it can be reactivated by

pressing the shutter-release button.

Basic info Detailed info Image only

Sound Settings

Auto Power Off

161

If On is selected, exposure will lock while

the shutter-release button is pressed

halfway.

Reduce flicker and banding in the display and in movies while

shooting under fluorescent or mercury-vapor lighting. Choose a

frequency which matches that of the local AC power supply.

When a photograph is taken or a movie is

recorded, the camera names the file by

adding one to the number of the previ-

ous file (0122). If the current folder is

numbered 999 and contains either 999

photographs or a photograph numbered

9999, the shutter-release button will be disabled and no further

photographs can be taken. To reset file numbering to 0001,

select Yes for Reset file numbering and then either format the

current memory card or insert a new memory card.

Shutter Button AE Lock

Flicker Reduction

AFlicker Reduction

If you are unsure as to the frequency of the local power supply, test

both options and choose the one that produces the best results. Flicker

reduction may not produce the desired results if the subject is very

bright, in which case you should select mode A or M and choose a

smaller aperture (larger f-number).

Reset File Numbering

162

Change time zones, set the camera clock,

choose the date display order, or turn

daylight saving time on or off (018).

Choose a language for camera messages and displays.

Time Zone and Date

Time zone Choose a time zone. The camera clock is automatically set

to the time in the new time zone.

Date and time Set the camera clock.

Date format Choose the order in which the day, month, and year are

displayed.

Daylight

saving time

Turn daylight saving time on or off. The camera clock will

automatically be advanced or set back one hour. The

default setting is Off.

Language

163

Photographs taken while On is selected contain information on

camera orientation, allowing them to be rotated automatically

during playback or when viewed in ViewNX 2 (supplied) or

Capture NX 2 (available separately; 0166). The following orien-

tations are recorded:

Camera orientation is not recorded when Off is selected. Choose

this option when panning or taking photographs with the lens

pointing up or down.

Auto Image Rotation

Landscape (wide)

orientation

Camera rotated 90°

clockwise

Camera rotated 90°

counterclockwise

DAuto Image Rotation

Image orientation is not recorded for movies, Motion Snapshots, or

panoramas.

ARotate Tall

To automatically rotate “tall” (portrait-orientation) photographs for dis-

play during playback, select On for the Rotate tall option in the play-

back menu (0110).

164

Check and optimize the camera image sensor and image proces-

sors if you notice unexpected bright spots in your pictures (note

that the camera comes with the sensor and processors already

optimized). Before performing pixel mapping as described

below, check that the battery is fully charged.

1Attach a lens and lens cap.

Turn the camera off and attach a 1 NIKKOR lens. Do not

remove the lens cap.

2Select Pixel mapping.

Turn the camera on, press G, and select Pixel mapping in

the setup menu.

3Select Yes.

Pixel mapping begins immediately. Note that other opera-

tions can not be performed while pixel mapping is in

progress. Do not turn the camera off or remove or disconnect

the power source until pixel mapping is complete.

4Turn the camera off.

Turn the camera off when pixel mapping is complete.

View the current firmware version.

Pixel Mapping

Firmware Version

165

Technical Notes

Read this chapter for information on compatible accessories,

cleaning and storing the camera, and what to do if an error mes-

sage is displayed or you encounter problems using the camera.

At the time of writing, the following accessories were available

for your camera.

Optional Accessories

Lenses 1 mount lenses

Mount

adapters

Mount Adapter FT1: The FT1 allows NIKKOR F mount lenses to

be used with Nikon 1 interchangeable lens format digital

cameras. The angle of view of an F mount lens mounted on

the FT1 is equivalent to that of a 35 mm format lens with a

focal length about 2.7 × longer. See page 202 for informa-

tion on using the FT1. For information on attaching the FT1

and precautions for use, see the FT1 Mount Adapter User’s

Manual. For information on the lenses that can be used, see

Compatible NIKKOR F Mount Lenses. The FT1 Mount Adapter

User’s Manual and Compatible NIKKOR F Mount Lenses are

included with the FT1.

Power

sources

•Rechargeable Li-ion Battery EN-EL20 (011–13): Additional

EN-EL20 batteries are available from local retailers and

Nikon-authorized service representatives.

•Battery Charger MH-27 (011): Recharge EN-EL20 batteries.

•Power Connector EP-5C, AC Adapter EH-5b: These accessories can

be used to power the camera for extended periods (EH-5a

and EH-5 AC adapters can also be used). An EP-5C power

connector is required to connect the camera to the EH-5b,

EH-5a, or EH-5; see page 169 for details.

Waterproof

cases

Waterproof Case WP-N2: In addition to protecting the camera

from rain, snow, and spray, this waterproof case can be used

to take photographs underwater.

166

Software Capture NX 2: A complete photo editing package offering such

features as white balance adjustment and color control

points.

Note: Use the latest versions of Nikon software; see the web-

sites listed on page xvii for the latest information on supported

operating systems. At default settings, Nikon Message Center

2 will periodically check for updates to Capture NX 2 and other

Nikon software and firmware while you are logged in to an

account on the computer and the computer is connected to

the Internet. A message is automatically displayed when an

update is found.

Body caps Body Cap BF-N1000: The body cap keeps the dust shield free of

dust when a lens is not in place.

Wireless

mobile

adapters

Wireless Mobile Adapter WU-1b (076): Create a wireless connec-

tion that can be used by smart devices running the Wireless

Mobile Utility to download pictures or control the camera

remotely.

167

Approved Memory Cards

The following cards have been tested and approved for use in

the camera. Cards with class 6 or faster write speeds are recom-

mended for movie recording. Recording may end unexpectedly

when cards with slower write speeds are used.

1Check that any card readers or other devices with which the card will be

used support 2 GB cards.

2Check that any card readers or other devices with which the card will be

used are SDHC-compliant. The camera supports UHS-1.

3Check that any card readers or other devices with

which the card will be used are SDXC-compliant.

The camera supports UHS-1.

Other cards have not been tested. For more details on the above

cards, please contact the manufacturer.

SD cards SDHC cards2SDXC cards 3

SanDisk

2GB14GB, 8GB, 16GB, 32GB 64 GB

Toshiba

Panasonic 48 GB, 64 GB

Lexar Media

—

4GB, 8GB, 16GB

—

Platinum II 4GB, 8GB, 16GB, 32GB

Professional

Full-HD Video 4GB, 8GB, 16GB

168

Approved Eye-Fi Cards

When inserted in the camera, Eye-Fi cards can be used to upload

photographs to a preselected destination. As of October 2012,

the camera supports 8 GB Pro X2 SDHC cards. Eye-Fi cards are for

use only in the country of purchase in accordance with local reg-

ulations. Eye-Fi cards may not be available in some countries or

regions; consult the manufacturer for more information. Be sure

the Eye-Fi card firmware has been updated to the latest version.

Card status is indicated by an icon in the

display:

•f (static): Eye-Fi upload enabled; wait-

ing to begin upload.

•f (animated): Eye-Fi upload enabled;

uploading data.

•e: Eye-Fi upload enabled but no pictures available for upload.

•g: Error.

DEye-Fi Cards

Note that pictures will not be uploaded if signal strength is insufficient,

and that Eye-Fi upload is disabled during movie recording. In locations

in which wireless devices are prohibited, turn the camera off and

remove the card. See the manual provided with the Eye-Fi card, and

direct any inquiries to the manufacturer.

169

Attaching a Power Connector and AC Adapter

Turn the camera off before attaching an optional power connec-

tor and AC adapter.

1Ready the camera.

Open the battery-chamber/mem-

ory card slot cover.

2Insert the EP-5C power connector.

Be sure to insert the connector in the

orientation shown, using the connec-

tor to keep the orange battery latch

pressed to one side. The latch locks

the connector in place when the con-

nector is fully inserted.

3Close the battery-chamber/memory card slot cover.

Position the power connector cable so

that it passes through the power con-

nector slot and close the battery-

chamber/memory card slot cover.

170

4Connect the AC adapter.

Connect the AC adapter power cable to the AC socket on AC

adapter (e) and the EP-5C power cable to the DC socket (r).

A P icon is displayed in the monitor when the camera is

171

Storage

If the camera will not be used for an extended period, remove

the battery and store it in a cool, dry area with the terminal cover

in place. To prevent mold or mildew, store the camera in a dry,

well-ventilated area. Do not store your camera with naphtha or

camphor moth balls or in locations that:

•are poorly ventilated or subject to humidities of over 60%

•are next to equipment that produces strong electromagnetic

fields, such as televisions or radios

•are exposed to temperatures above 50 °C (122 °F) or below –10 °C

(14 °F)

Cleaning

Do not use alcohol, thinner, or other volatile chemicals.

Storage and Cleaning

Camera body

Use a blower to remove dust and lint, then wipe gently with

a soft, dry cloth. After using the camera at the beach or sea-

side, wipe off sand or salt with a cloth lightly dampened in

distilled water and dry thoroughly. Important: Dust or other

foreign matter inside the camera may cause damage not cov-

ered under warranty.

Lens

Lenses are easily damaged. Remove dust and lint with a

blower. If using an aerosol blower, keep the can vertical to

prevent the discharge of liquid. To remove fingerprints and

other stains, apply a small amount of lens cleaner to a soft

cloth and clean with care.

Monitor

Remove dust and lint with a blower. When removing finger-

prints and other stains, wipe the surface lightly with a soft

cloth or chamois leather. Do not apply pressure, as this

could result in damage or malfunction.

Dust shield The dust shield is easily damaged. Remove dust and lint

with a blower.

172

Do not drop: The product may malfunction if subjected to strong shocks or

vibration.

Keep dry: This product is not waterproof, and may malfunction if

immersed in water or exposed to high levels of humidity. Rusting of the

internal mechanism can cause irreparable damage.

Avoid sudden changes in temperature: Sudden changes in temperature, such

as those that occur when entering or leaving a heated building on a cold

day, can cause condensation inside the device. To prevent condensation,

place the device in a carrying case or plastic bag before exposing it to

sudden changes in temperature.

Keep away from strong magnetic fields: Do not use or store this device in the

vicinity of equipment that generates strong electromagnetic radiation

or magnetic fields. Strong static charges or the magnetic fields produced

by equipment such as radio transmitters could interfere with the display,

damage data stored on the memory card, or affect the product’s internal

circuitry.

Keep the lens mount covered: Be sure to attach the body cap if the camera is

without a lens.

Do not touch the dust shield: The dust shield covering the image sensor is

easily damaged. Under no circumstances should you exert pressure on

the shield or poke it with cleaning tools. These actions could scratch or

otherwise damage the shield.

Turn the product off before removing or disconnecting the power source: Do not

unplug the product or remove the battery while the product is on or

while images are being recorded or deleted. Forcibly cutting power in

these circumstances could result in loss of data or in damage to product

memory or internal circuitry. To prevent an accidental interruption of

power, avoid carrying the product from one location to another while

the AC adapter is connected.

Caring for the Camera and Battery: Cautions

173

Cleaning: When cleaning the camera body, use a blower to gently remove

dust and lint, then wipe gently with a soft, dry cloth. After using the cam-

era at the beach or seaside, wipe off any sand or salt using a cloth lightly

dampened in pure water and then dry the camera thoroughly.

Lenses are easily damaged. Dust and lint should be gently removed with

a blower. When using an aerosol blower, keep the can vertical to prevent

discharge of liquid. To remove fingerprints and other stains from the

lens, apply a small amount of lens cleaner to a clean, soft cloth and wipe

the lens carefully.

Storage: To prevent mold or mildew, store the camera in a dry, well-venti-

lated area. If you are using an AC adapter, unplug the adapter to prevent

fire. If the product will not be used for an extended period, remove the

battery to prevent leakage and store the camera in a plastic bag contain-

ing a desiccant. Do not, however, store the camera case in a plastic bag,

as this may cause the material to deteriorate. Note that desiccant gradu-

ally loses its capacity to absorb moisture and should be replaced at reg-

ular intervals.

To prevent mold or mildew, take the camera out of storage at least once

a month. Turn the camera on and release the shutter a few times before

putting it away.

Store the battery in a cool, dry place. Replace the terminal cover before

putting the battery away.

Notes on the monitor: The monitor is constructed with extremely high pre-

cision; at least 99.99% of pixels are effective, with no more than 0.01%

being missing or defective. Hence while these displays may contain pix-

els that are always lit (white, red, blue, or green) or always off (black), this

is not a malfunction and has no effect on images recorded with the

device.

Images in the monitor may be difficult to see in a bright light.

Do not apply pressure to the display, as this could cause damage or mal-

function. Dust or lint on the display can be removed with a blower.

Stains can be removed by wiping lightly with a soft cloth or chamois

leather. Should the monitor break, care should be taken to avoid injury

from broken glass and to prevent liquid crystal from the display touch-

ing the skin or entering the eyes and mouth.

174

Do not leave the lens pointed at the sun: Do not leave the lens pointed at the

sun or other strong light source for an extended period. Intense light

may cause the image sensor to deteriorate or produce a white blur effect

in photographs.

Moiré: Moiré is an interference pattern created by the interaction of an

image containing a regular, repeating grid, such as the pattern of weave

in cloth or windows in a building, with the camera image sensor grid. In

some cases, it may appear in the form of lines. If you notice moiré in your

photographs, try changing the distance to the subject, zooming in and

out, or changing the angle between the subject and the camera.

Lines: Noise in the form of lines may in rare cases appear in pictures of

extremely bright or backlit subjects.

Batteries: Batteries may leak or explode if improperly handled. Observe

the following precautions when handling batteries:

•Use only batteries approved for use in this equipment.

•Do not expose the battery to flame or excessive heat.

•Keep the battery terminals clean.

•Turn the product off before replacing the battery.

•Remove the battery from the camera or charger when not in use and

replace the terminal cover. These devices draw minute amounts of

charge even when off and could draw the battery down to the point

that it will no longer function. If the battery will not be used for some

time, insert it in the camera and run it flat before removing it and stor-

ing it in a location with an ambient temperature of 15 °C to 25 °C (59 °F

to 77 °F; avoid hot or extremely cold locations). Repeat this process at

least once every six months.

•Turning the camera on and off repeatedly when the battery is fully dis-

charged will shorten battery life. Batteries that have been fully dis-

charged must be charged before use.

•The internal temperature of the battery may rise while the battery is in

use. Attempting to charge the battery while the internal temperature is

elevated will impair battery performance, and the battery may not

charge or charge only partially. Wait for the battery to cool before

charging.

•Continuing to charge the battery after it is fully charged can impair bat-

tery performance.

175

•A marked drop in the time a fully charged battery retains its charge

when used at room temperature indicates that it requires replacement.

Purchase a new EN-EL20 battery.

•Charge the battery before use. When taking photographs on impor-

tant occasions, ready a spare EN-EL20 battery and keep it fully charged.

Depending on your location, it may be difficult to purchase replace-

ment batteries on short notice. Note that on cold days, the capacity of

batteries tends to decrease. Be sure the battery is fully charged before

taking photographs outside in cold weather. Keep a spare battery in a

warm place and exchange the two as necessary. Once warmed, a cold

battery may recover some of its charge.

•Used batteries are a valuable resource; recycle in accord with local reg-

ulations.

DServicing the Camera and Accessories

The camera is a precision device and requires regular servicing. Nikon

recommends that the camera be inspected by the original retailer or

Nikon-authorized service representative once every one to two years,

and that it be serviced once every three to five years (note that fees

apply to these services). Frequent inspection and servicing are particu-

larly recommended if the camera is used professionally. Any accesso-

ries regularly used with the camera, such as lenses, should be included

when the camera is inspected or serviced.

176

The following table lists the settings that can be adjusted in each

mode.

❚❚ C Auto, u Best Moment Capture, v Advanced Movie, and z Motion

Snapshot Modes

Available Settings

v z

P S A M hP S A M

Shooting, movie, and image processing menus

Exposure mode — — — — — — ✔✔✔✔✔

Image quality ✔1✔——— ——————

Image size 2✔1✔—————————

Number of shots

saved —✔3——— ——————

Movie before/after — — — — — — ✔✔✔✔✔

File format — — — — — — ✔✔✔✔✔

Metering — — ✔4✔4✔4✔4—✔✔✔✔

Auto distortion

control ✔1✔——— ——————

Color space ✔1✔——— ——————

Active D-Lighting — — — — — — — — — — —

HDR — — — — — — — — — — —

Long exposure NR ✔—— — — ——————

Optical VR5✔✔ ✔ ✔ ✔ ✔ ✔✔✔✔✔

Electronic VR — — — — — — ✔✔✔✔✔

Focus mode — — ✔✔✔ ✔—————

AF-area mode — — ✔4✔4✔4✔4—✔✔✔✔

Face-priority — — ✔4✔4✔4✔4—✔✔✔✔

Built-in AF assist ✔✔ ——— —✔✔✔✔✔

Flash

compensation —— — — — — —————

Frame rate 6—— — — — — —————

177

1Has no effect on movies recorded with movie-record button.

2RAW images fixed at 4608 × 3072 pixels.

3Smart Photo Selector mode only.

4Not available when y Slow motion is selected in advanced movie mode

(062).

5VR lenses only.

6y Slow motion selected in advanced movie mode.

7Continuous and self-timer can not be used together.

Shooting, movie, and

image processing menus

Movie settings ✔—✔4✔4✔4✔4—————

Movie sound

options ✔—✔4✔4✔4✔4—————

White balance — — ✔✔✔ ✔—✔✔✔✔

ISO sensitivity — — ✔✔✔ ✔—✔✔✔✔

Picture Control — — ✔✔✔ ✔—✔✔✔✔

Custom Picture

Control —— ✔✔✔ ✔—✔✔✔✔

High ISO noise

reduction

✔✔ ✔ ✔ ✔ ✔ ✔✔✔✔✔

Other settings

Focus area

selection —— ✔4✔4✔4✔4—✔✔✔✔

Flexible program ——— — — ——————

Autoexposure lock — — ✔✔✔——✔✔✔—

Focus lock — — ✔✔✔ ✔—✔✔✔✔

Continuous 7✔—— — — ——————

Self-timer 7✔—✔✔✔ ✔—————

Exposure

compensation

✔—✔4✔4✔4——✔✔✔—

Flash mode ✔—— — — ——————

Advanced movie — — ✔✔✔ ✔—————

Theme — — — — — — ✔✔✔✔✔

v z

P S A M hP S A M

178

❚❚ w Creative Mode

In the table below, creative modes are represented by the

following icons: jnight landscape, onight portrait,

mbacklighting, peasy panorama, qsoft, rminiature effect,

and sselective color.

P S A M j o m p q r s

Shooting, movie, and image processing menus

Exposure mode ———————————

Image quality ✔1✔1✔1✔1✔1,2✔1,2 ✔1,2 ✔1,2✔1,2 ✔1,2 ✔1,2

Image size ✔1,3✔1,3 ✔1,3 ✔1,3 ✔1✔1✔1✔1✔1✔1✔1

Number of shots

saved ———————————

Movie before/after ———————————

File format ———————————

Metering ✔1,4✔1,4✔1,4 ✔1,4 ———————

Auto distortion

control ✔1✔1✔1✔1✔1✔1✔1—✔1✔1✔1

Color space ✔1✔1✔1✔1✔1✔1✔1✔✔

1✔1✔1

Active D-Lighting ✔1✔1✔1✔1———————

HDR ——————✔————

Long exposure NR ✔4✔4✔4✔4———————

Optical VR5✔✔✔✔✔✔✔✔✔✔✔

Electronic VR ———————————

Focus mode ✔1,4 ✔1,4✔1,4✔1,4 ———————

AF-area mode ✔1✔1✔1✔1———————

Face-priority ✔✔✔✔———————

Built-in AF assist ✔✔✔✔✔✔✔✔✔✔✔

Flash compensation ✔4✔4✔4✔4—✔✔

6—✔✔✔

Frame rate ———————————

Movie settings ✔✔✔✔✔✔✔✔✔✔✔

Movie sound options ✔✔✔✔✔✔✔✔✔✔✔

White balance ✔✔✔✔———————

ISO sensitivity ✔1,4✔1,4 ✔1,4✔1,4 ———————

Picture Control ✔✔✔✔———————

Custom Picture

Control ✔✔✔✔———————

High ISO noise

reduction ✔✔✔✔———————

179

1Has no effect on movies recorded with movie-record button.

2NEF (RAW) and NEF (RAW) + JPEG fine not available.

3RAW images fixed at 4608 × 3072 pixels.

4Not available when 15, 30, or 60 fps is selected for self-timer/continuous.

5VR lenses only.

6Not available when HDR is on.

7Continuous and self-timer can not be used together.

Other settings

Focus area selection ✔✔✔✔———————

Flexible program ✔1——————————

Autoexposure lock ✔✔✔—✔✔✔✔✔✔✔

Focus lock ✔✔✔✔✔✔✔✔✔✔✔

Continuous 7✔✔✔✔———————

Self-timer7✔4✔4✔4✔4✔✔✔—✔✔✔

Exposure

compensation ✔✔✔—✔✔✔✔✔✔✔

Flash mode ✔4✔4✔4✔4—✔✔

6—✔✔✔

Advanced movie ———————————

Theme ———————————

P S A M j o m p q r s

180

Defaults for the options in the playback, shooting, movie, image

processing, and setup menus may be found on pages 107, 117,

139, 143, and 157, respectively. Defaults for other settings are

listed below.

*Not displayed when Auto-area is selected for AF-area mode.

Defaults

Option Default

Focus area (0134) Center *

Flexible program (034) Off

Focus lock (0135) Off

Continuous/self-timer (067) 8 (single frame)

Exposure compensation (071) 0.0

Flash mode (073) Auto, Soft, Miniature effect,

Selective color: Auto

Night portrait: Red-eye reduction

P Programmed auto, S Shutter-priority

auto, A Aperture-priority auto, M Manual,

Backlighting: Fill flash

Best moment capture (045) Slow view

Advanced movie (057) P Programmed auto

Theme (055) Beauty

Picture Control settings (0150) Unmodified

181

The following table shows the number of pictures or amount of

movie footage that can be stored on a 16 GB Toshiba SD-

E016GUX UHS-I SDHC card at different image quality, size, or

movie settings. All figures are approximate; file size varies with

the scene recorded.

❚❚ Auto, Creative (Easy Panorama Excluded), Slow View, and Smart Photo

Selector1

1Number of shots saved set to 1.

2Maximum number of pictures that can be stored in memory buffer at

ISO 160. Drops if long exposure noise reduction is on (0128) and at frame

rates of 15, 30, and 60 fps (067).

3Available in P, S, A, M mode only.

4Image size applies to JPEG images only. Size of NEF (RAW) images can not

be changed. File size is the total for NEF (RAW) and JPEG images.

Memory Card Capacity

Image quality

(0120)

Image size

(0120) File size No. of images Buffer capacity 2

NEF (RAW) +

JPEG fine 3, 4

4608 × 3072 26.6 MB 591 25

3456 × 2304 23.1 MB 682 25

2304 × 1536 20.5 MB 766 26

NEF (RAW) 3— 17.4 MB 902 27

JPEG fine

4608 × 3072 9.2 MB 1700 31

3456 × 2304 5.6 MB 2700 37

2304 × 1536 3.1 MB 5000 50

JPEG normal

4608 × 3072 4.6 MB 3300 41

3456 × 2304 2.9 MB 5400 53

2304 × 1536 1.6 MB 9800 75

JPEG basic

4608 × 3072 2.4 MB 6600 61

3456 × 2304 1.5 MB 10700 85

2304 × 1536 0.8 MB 18600 100

182

❚❚ Easy Panorama

❚❚ Smart Photo Selector1

1Number of shots saved set to 5. File size is total for 5 images.

2Image size applies to JPEG images only. Size of NEF (RAW) images can not

be changed. File size is the total for NEF (RAW) and JPEG images.

Image quality

(0120)

Image size

(0120) File size No. of images

JPEG fine

Normal

panorama

4800 × 920 4.5 MB 3400

1536 × 4800 4.5 MB 3400

Wide

panorama

9600 × 920 8.6 MB 1800

1536 × 9600 8.6 MB 1800

JPEG normal

Normal

panorama

4800 × 920 2.3 MB 6800

1536 × 4800 2.3 MB 6800

Wide

panorama

9600 × 920 4.4 MB 3500

1536 × 9600 4.4 MB 3500

JPEG basic

Normal

panorama

4800 × 920 1.2 MB 13200

1536 × 4800 1.2 MB 13200

Wide

panorama

9600 × 920 2.2 MB 7000

1536 × 9600 2.2 MB 7000

Image quality (0120) Image size (0120) File size No. of shots

NEF (RAW) + JPEG fine2

4608 × 3072 133.1 MB 118

3456 × 2304 115.4 MB 136

2304 × 1536 102.7 MB 153

NEF (RAW) — 87.1 MB 180

JPEG fine

4608 × 3072 45.9 MB 342

3456 × 2304 28.2 MB 557

2304 × 1536 15.6 MB 1000

JPEG normal

4608 × 3072 23.2 MB 679

3456 × 2304 14.3 MB 1000

2304 × 1536 8.0 MB 1900

JPEG basic

4608 × 3072 11.8 MB 1300

3456 × 2304 7.4 MB 2100

2304 × 1536 4.2 MB 3700

183

❚❚ HD Movies

*For information on the maximum length that can be recorded in a single

clip, see page 141.

❚❚ Slow-Motion Movies

*Up to 3 s of slow-motion footage can be recorded in a single clip. Playback

length is about 13.2 (400 fps) or 40 (1200 fps) times the recorded length.

❚❚ Motion Snapshots

*File size is the total for a single photograph and movie.

Movie settings (0141) Maximum total length (approx.)*

1080/60i 1 hours 28 minutes

1080/30p 1 hours 28 minutes

720/60p 2 hours 12 minutes

720/30p 2 hours 56 minutes

Frame rate (0140) Maximum total recorded length (approx.)*

400 fps 1 hours 4 minutes

1200 fps 2 hours 8 minutes

Image quality Image size Format (0124) File size No. of shots

— — NMS 21.6 MB *729

— — MOV 30.8 MB 510

184

If the camera fails to function as expected, check this list of com-

mon problems before consulting your retailer or Nikon repre-

sentative.

Battery/Display

Troubleshooting

The camera is on but does not respond: Wait for recording or any other process-

ing to end. If the problem persists, turn the camera off. If the camera still

does not respond, remove and replace the battery or disconnect and

reconnect the AC adapter, but note that this will delete any data not yet

saved. Data already saved to the memory card are unaffected.

The display is off:

•The camera is off (017) or the battery is exhausted (011, 20).

•The display has turned off automatically to save power (0160). The

display can be reactivated by pressing the shutter-release button.

•The camera is connected to a computer (095) or television (0100).

The camera turns off without warning:

•The battery is low (011, 20).

•The display has turned off automatically to save power (0160). The

display can be reactivated by pressing the shutter-release button.

•The camera’s internal temperature is high (0xvi, 190). Wait for the

camera to cool before turning it on again.

Indicators are not displayed: Use the Display > Shooting and Display >

Playback options in the setup menu to choose the information dis-

played (0159).

185

Shooting (All Modes)

The camera takes time to turn on: Delete files or format the memory card.

The shutter-release is disabled:

•The battery is exhausted (011, 20).

•The memory card is locked (014) or full (020).

•The flash is charging (072).

•The camera is not in focus (022).

•You are currently filming a slow-motion movie (061).

Only one picture is taken each time the shutter-release button is pressed in continuous

release mode: 5 fps is selected for Continuous/self-timer and the built-in

flash is raised.

The camera does not focus automatically:

•The subject is not suited to autofocus (0131).

•The camera is in manual focus mode (0129, 132).

Focus does not lock when the shutter-release button is pressed halfway: Set the

focus mode to AF-S (0129, 135).

Focus area selection is unavailable: Focus area selection is not available in

auto-area AF (0134) or face priority (024). In other AF-area modes, the

focus area can be selected by pressing J.

AF-area mode selection is unavailable: The camera is in auto or best moment

capture mode (045), an option other than P, S, A, M is selected in creative

mode (031), manual focus mode is selected (0129), or the h Scene

auto selector is used (0119).

Image size selection is unavailable: NEF (RAW) is selected for image quality

(0120).

The camera is slow to record photos: Turn long exposure noise reduction off

(0128). In creative mode, additional time may be needed to record pho-

tos when Night landscape (032), Night portrait (033) or Easy pan-

orama (041) is selected or when Backlighting is selected and HDR is

on (040).

Noise (bright spots, randomly-spaced bright pixels, fog, or lines) appears in photos:

•Lower ISO sensitivity or enable high ISO noise reduction (0149).

•Use long exposure noise reduction at shutter speeds slower than 1 s

(0128).

Smudges appear in photographs: Clean the front and rear lens elements or the

dust shield (0171).

186

Shooting (P, S, A, and M Modes)

Movies

Flicker or banding appears in movies or in the display: Choose a Flicker reduc-

tion setting that matches the local AC power supply (0161).

No flash: See page 75. The flash will not fire when off (073); in P, S, A, and

M modes, the flash will not fire when lowered.

Menu items are unavailable: Some options are only available in particular

shooting or exposure modes (0176) or when the built-in flash is raised

(072) or wireless mobile adapter is attached (076).

The shutter release is disabled: You selected mode S after choosing a shutter

speed of “Bulb” in mode M (035).

Some shutter speeds are not available: You are using the flash.

Colors are unnatural:

•Adjust white balance to match the light source (0144).

•Adjust Picture Control settings (0150).

Cannot measure white balance: The subject is too dark or too bright (0147).

Picture Controls produce varying results: A (auto) is selected for sharpening,

contrast, or saturation. For consistent results over a series of photos,

choose another setting (0152, 153).

Noise (reddish areas and other artifacts) appears in long time-exposures: Enable

long exposure noise reduction (0128).

Cannot record movies: The movie-record button can not be used to record

movies in best moment capture or Motion Snapshot mode (049, 55).

No sound is recorded for movies:

• Microphone off is selected for Movie sound options > Microphone

(0142).

•Live audio is not recorded with slow-motion movies (062) or Motion

Snapshots (053).

187

Playback

Miscellaneous

NEF (RAW) images are not displayed: The camera displays only the JPEG copies

of NEF (RAW) + JPEG fine images (0122).

“Tall” (portrait) orientation photos are displayed in “wide” (landscape) orientation:

•Select On for Rotate tall (0110).

•The photos were taken with Auto image rotation off (0163).

•Camera was pointed up or down when the photo was taken (0163).

•Photo is displayed in image review (0110).

Cannot hear movie sound:

•Rotate the multi selector clockwise to raise the volume (065). If the

camera is connected to a television (0100), use the controls for the TV

to adjust the volume.

•Live audio is not recorded with slow-motion movies (062) or Motion

Snapshots (055).

Cannot delete images:

•Remove protection from the files before deletion (0110).

•The memory card is locked (014).

Cannot select photos for printing: The memory card is full (020) or locked

(014) or the photos are in NEF (RAW) format. To print NEF (RAW) pho-

tos, transfer the pictures to a computer and use the supplied software or

Capture NX 2 (095).

Pictures are not displayed on TV: The camera is not correctly connected

(0100).

Pictures cannot be transferred to a computer: If your system does not meet the

requirements on page 93, you may still be able to transfer pictures to the

computer using a card reader.

Photos are not displayed in Capture NX 2: Update to the latest version (0166).

The date of recording is not correct: Set the camera clock (018, 162).

Menu items are unavailable: Some options are only available at particular

settings (0176) or when a memory card is inserted (013).

188

This section lists the error messages that appear in the display.

Error Messages

Message Solution 0

(Shutter-speed or

aperture display

flashes)

If the subject is too bright, lower ISO

sensitivity or choose a faster shutter

speed or smaller aperture (higher

f-number).

35, 36,

37, 149

If the subject is too dark, raise ISO sen-

sitivity, use the flash, or choose a

slower shutter speed or larger aperture

(lower f-number).

35, 36,

37, 72,

149

Keeping the zoom ring

button pressed, rotate

the zoom ring to

extend the lens.

A lens with a retractable lens barrel

button is attached with the lens barrel

retracted. Press the retractable lens

barrel button and rotate the zoom ring

to extend the lens.

16, 199

Check lens. Pictures

can only be taken

when a lens is

attached.

Attach a lens. 16

Cannot take pictures.

Insert fully-charged

battery.

Turn the camera off and recharge the

battery or insert a fully charged spare

battery.

11, 13

Start-up error. Turn the

camera off and then

on again.

Turn the camera off, remove and

replace the battery, and then turn the

camera on.

13, 17

The clock has been

reset. Set the camera clock. 18, 162

No memory card. Turn the camera off and confirm that

the card is correctly inserted. 13

This memory card is

not formatted. Format

the memory card?

Select Yes to format the card, or turn

the camera off and insert another

memory card.

13, 158

189

Memory card is locked

(write protected). Turn the camera off and slide the card

write-protect switch to the “write”

position.

Eye-Fi cards cannot be

used with the write-

protect switch in the

"lock" position.

Memory card is full.

•You may be able to record additional

images if you reduce image quality or

size.

120

•Delete unwanted images. 85

•Insert another memory card. 13, 167

This memory card

cannot be used. Card

may be damaged;

insert a different card.

•Use an approved card. 167

•Format the card. If the problem per-

sists, the card may be damaged. Con-

tact a Nikon-authorized service

representative.

158

•Insert a new memory card. 13, 167

Cannot create

additional folders on

memory card.

If the current folder is numbered 999 and

contains either 999 photographs or a

photograph numbered 9999, the shut-

ter-release button will be disabled and

no further photographs can be taken.

Choose

Yes

for

Reset file numbering

and then either format the current mem-

ory card or insert a new memory card.

161

The movie-record

button cannot be used

in this mode.

The movie-record button can not be

used in best moment capture or

Motion Snapshot modes.

49, 55

Photographs cannot

be recorded in this

mode.

The shutter-release button can not be

used to take photographs while a

slow-motion movie is being recorded.

Photographs cannot be

taken in shutter- priority

auto mode at a shutter

speed of “Bulb”.

Choose a different shutter speed, or

select mode M.35, 37

Message Solution 0

190

*See the printer manual for more information.

Cannot shoot

panorama with lens of

this focal length.

Use a lens with a focal length of 6 to

30 mm to shoot panoramas. If you are

using a zoom lens, choose a focal

length between 6 and 30 mm.

Failed to update lens

firmware. Try again

after turning the

camera off and on.

Turn the camera off and then on again

and reattempt the update. If the prob-

lem persists or reoccurs frequently,

contact a Nikon-authorized service

representative.

—

An error has occurred.

Press the shutter-

release button again.

Press the shutter-release button. Con-

tact a Nikon-authorized service repre-

sentative if the problem persists or re-

occurs frequently.

—

An error has occurred

in the internal circuitry.

Try again after turning

the camera off and on.

Turn the camera off and then on again.

If the problem persists or reoccurs fre-

quently, contact a Nikon-authorized

service representative.

—

The camera’s internal

temperature is high.

The camera will now

turn off.

Wait for the camera to cool. xvi

Memory card contains

no images.

To view pictures, insert a memory card

containing images. 13

Cannot display this file.

The file has been created or modified

on a computer or different make of

camera, or is corrupt.

—

Check printer. Check the printer. — *

Check paper. Select Resume after loading paper of

the correct size. —*

Paper jam. Clear the jam and select Resume.—

Out of paper. Insert paper and select Resume.—

Check ink supply. Select Resume after checking the ink. — *

Out of ink. Replace the ink and select Resume.—

Message Solution 0

191

Nikon 1 J3 Digital Camera

Specifications

Type

Type Digital camera with support for interchangeable

lenses

Lens mount Nikon 1 mount

Effective angle of view Approx. 2.7× lens focal length (35 mm format

equivalent)

Effective pixels 14.2 million

Image sensor

Image sensor 13.2 mm × 8.8 mm CMOS sensor (Nikon CX for-

mat)

Storage

Image size (pixels) Still images (auto, best moment capture, and all creative

modes other than Easy panorama; aspect ratio 3 : 2)

•4608 × 3072 •3456 × 2304

•2304 × 1536

Still images (Normal panorama, camera panned

horizontally; aspect ratio 120 : 23)

•4800 × 920

Still images (Normal panorama, camera panned vertically;

aspect ratio 8 : 25)

•1536 × 4800

Still images (Wide panorama, camera panned horizontally;

aspect ratio 240 : 23)

•9600 × 920

Still images (Wide panorama, camera panned vertically;

aspect ratio 4 : 25)

•1536 × 9600

Still images (taken during movie recording, aspect ratio 3 : 2)

•4608 × 3072 (1080/60i, 1080/30p)

•1280 × 856 (720/60p, 720/30p)

Still images (Motion Snapshots; aspect ratio 16 : 9)

•4608 × 2592

192

File format •NEF (RAW): 12-bit, compressed

•JPEG: JPEG-Baseline compliant with fine (approx.

1:4), normal (approx. 1 : 8), or basic (approx. 1 : 16)

compression

•NEF (RAW) + JPEG: Single photograph recorded in

both NEF (RAW) and JPEG formats

Picture Control system Standard, Neutral, Vivid, Monochrome, Portrait,

Landscape; selected Picture Control can be mod-

ified; storage for custom Picture Controls

Media SD (Secure Digital), SDHC, and SDXC memory cards

File system DCF (Design Rule for Camera File System) 2.0, DPOF (Digi-

tal Print Order Format), Exif (Exchangeable Image File Format

for Digital Still Cameras) 2.3, PictBridge

Shooting modes Cauto; w creative, with a choice of the follow-

ing options: P, S, A, M, j night landscape, o night

portrait, m backlighting, peasy panorama, q

soft, r miniature effect, and s selective color;

ubest moment capture (t slow view and y

Smart Photo Selector), vadvanced movie

(HD—P, S, A, M only—and y slow motion),

zMotion Snapshot

Shutter

Type Electronic shutter

Speed 1

16,000 –30 s in steps of 1

3EV; Bulb

Note: Bulb ends automatically after approximately 2 minutes

Flash sync speed Synchronizes with shutter at X=1

60 s or slower

Release

Mode •Single frame, continuous

•Self-timer

Frame advance rate Approx. 5, 15, 30, or 60 fps

Self-timer 2 s, 5 s, 10 s

193

Exposure

Metering TTL metering using image sensor

Metering method •Matrix

•Center-weighted: Meters 4.5 mm circle in center of

frame

•Spot: Meters 2 mm circle centered on selected

focus area

Mode P programmed auto with flexible program;

Sshutter-priority auto; Aaperture-priority auto;

Mmanual; hscene auto selector

Exposure compensation –3–+3 EV in increments of 1

3EV

Exposure lock Luminosity locked at metered value when shut-

ter-release button is pressed halfway

ISO sensitivity

(Recommended Exposure

Index)

ISO 160–6400 in steps of 1 EV; auto ISO sensitiv-

ity control (ISO 160–6400, 160–3200, 160–800) available

(user controlled in P, S, A, and M modes)

Active D-Lighting On, off

Focus

Autofocus Hybrid autofocus (phase-detection/contrast-

detect AF); AF-assist illuminator

Lens servo •Autofocus (AF): Single AF (AF-S); continuous AF

(AF-C); auto AF-S/AF-C selection (AF-A); full-

time AF (AF-F)

•Manual focus (MF)

AF-area mode Single-point, auto-area, subject tracking

Focus area •Single-point AF: 135 focus areas; the center 73

areas support phase-detection AF

•Auto-area AF: 41 focus areas

Focus lock Focus can be locked by pressing shutter-release

button halfway (single AF)

Face priority On, off

194

Flash

Built-in flash •Auto; Soft, Miniature effect, Selective color (Creative

mode): Flash pops up automatically and fires as

required

•Night portrait, Backlighting (Creative mode): Flash

pops up automatically and fires with every shot

•P programmed auto, S shutter-priority auto, A aperture-

priority auto, M manual (Creative mode): Manual pop-

Guide Number (GN) Approx. 5/16 (m/ft, ISO 100, 20 °C/68 °F; at ISO

160, Guide Number is approx. 6.3/20.7)

Control i-TTL flash control using image sensor

Mode Auto, auto + red-eye reduction, fill flash, fill flash

+ slow sync, red-eye reduction, red-eye reduction

+ slow sync, rear-curtain sync, rear curtain + slow

sync, off

Flash compensation –3–+1 EV in increments of 1

3EV

Flash-ready indicator Lights when built-in flash unit is fully charged

White balance Auto, incandescent, fluorescent, direct sunlight,

flash, cloudy, shade, underwater, preset manual,

all except preset manual with fine tuning

195

Movie

Metering TTL metering using image sensor

Metering method •Matrix

•Center-weighted: Meters 4.5 mm circle in center of

frame

•Spot: Meters 2 mm circle centered on selected

focus area

Frame size (pixels)/

recording rate

HD movies (aspect ratio 16 : 9)

•1920 × 1080/60i (59.94 fields/s*)

•1920 × 1080/30p (29.97 fps)

•1280 × 720/60p (59.94 fps)

•1280 × 720/30p (29.97 fps)

Slow-motion movies (aspect ratio 8 : 3)

•640 × 240/400 fps (plays at 30p/29.97 fps)

•320 × 120/1200 fps (plays at 30p/29.97 fps)

Motion Snapshot (aspect ratio 16 : 9)

1920 × 1080/60p (59.94 fps) (plays at 24p/23.976 fps)

File format MOV

Video compression H.264/MPEG-4 Advanced Video Coding

Audio recording format AAC

Audio recording device Built-in stereo microphone; sensitivity adjustable

*Sensor output is about 60 fps.

Monitor 7.5 cm (3-in.), approx. 921k-dot, TFT LCD with

brightness adjustment

Playback Full-frame and thumbnail (4, 9, or 72 images or

calendar) playback with playback zoom, movie

and panorama playback, slide show, histogram

display, auto image rotation, and rating option

Interface

USB Hi-Speed USB

HDMI output Type C mini-pin HDMI connector

196

•Unless otherwise stated, all figures are for a camera with a fully-charged bat-

tery operating at the temperature specified by the Camera and Imaging

Products Association (CIPA): 23 ±3 °C (73.4 ±5.4 °F).

•Nikon reserves the right to change the specifications of the hardware and

software described in this manual at any time and without prior notice.

Nikon will not be held liable for damages that may result from any mistakes

that this manual may contain.

Supported languages Arabic, Bengali, Chinese (Simplified and Tradi-

tional), Czech, Danish, Dutch, English, Finnish,

French, German, Greek, Hindi, Hungarian, Indo-

nesian, Italian, Japanese, Korean, Norwegian, Per-

sian, Polish, Portuguese (European and Brazilian),

Romanian, Russian, Spanish, Swedish, Tamil, Thai,

Turkish, Ukrainian, Vietnamese

Power source

Battery One rechargeable Li-ion EN-EL20 battery

AC adapter EH-5b AC adapter; requires EP-5C power connec-

tor (available separately)

Tripod socket 1

4-in. (ISO 1222)

Dimensions/weight

Dimensions (W × H × D)

Approx. 101.0 × 60.5 × 28.8 mm (4.0 × 2.4 × 1.1 in.),

excluding projections

Weight Approx. 244 g (8.6 oz) with battery and memory

card but without body cap; approx. 201 g (7.1 oz),

camera body only

Operating environment

Temperature 0 °C–40 °C (+32 °F–104 °F)

Humidity 85% or less (no condensation)

197

MH-27 battery charger

Rated input AC 100–240 V, 50–60 Hz, 0.2 A

Rated output DC 8.4 V/0.6 A

Supported batteries Nikon EN-EL20 rechargeable Li-ion batteries

Charging time Approx. 2 hours at an ambient temperature of

25 °C (77 °F) when no charge remains

Operating temperature 0 °C–40 °C (+32 °F–104 °F)

Dimensions (W × H × D) Approx. 67.0 × 28.0 × 94.0 mm (2.6 × 1.1 × 3.7 in.),

excluding plug adapter

Weight Approx. 83 g (2.9 oz), excluding plug adapter

EN-EL20 rechargeable Li-ion battery

Type Rechargeable lithium-ion battery

Rated capacity 7.2 V, 1020 mAh

Operating temperature 0 °C–40 °C (+32 °F–104 °F)

Dimensions (W × H × D) Approx. 30.7 × 50.0 × 14.0 mm (1.2 × 2.0 × 0.6 in.)

Weight Approx. 41 g (1.4 oz), excluding terminal cover

1 NIKKOR VR 10–30mm f/3.5–5.6

Type 1 mount lens

Focal length 10–30 mm

Maximum aperture f/3.5–5.6

Construction 12 elements in 9 groups (including 3 aspherical elements)

Angle of view 77°–29° 40′

Vibration reduction Lens shift using voice coil motors (VCMs)

Minimum focus distance 0.2 m (0.7 ft) from focal plane at all zoom positions

Diaphragm blades 7 (rounded diaphragm opening)

Diaphragm Fully automatic

Aperture range •10 mm focal length: f/3.5–16

•30 mm focal length: f/5.6–16

Filter-attachment size 40.5 mm (P=0.5 mm)

Dimensions Approx. 57.5 mm diameter × 42 mm (distance from

camera lens mount flange when lens is retracted)

Weight Approx. 115 g (4.1 oz)

198

Specifications subject to change without notice. Nikon will not be held liable

for damages that may result from any mistakes that this manual may contain.

1 NIKKOR 11–27.5mm f/3.5–5.6

Type 1 mount lens

Focal length 11–27.5 mm

Maximum aperture f/3.5–5.6

Construction 8 elements in 6 groups (including 1 ED lens element and

1 aspherical lens element), 1 protective glass element

Angle of view 72°–32° 20′

Minimum focus distance 0.3 m (1.0 ft) from focal plane at all zoom positions

Diaphragm blades 7 (rounded diaphragm opening)

Diaphragm Fully automatic

Aperture range •11 mm focal length: f/3.5–16

•27.5 mm focal length: f/5.6–16

Filter-attachment size 40.5 mm (P=0.5 mm)

Dimensions Approx. 57.5 mm diameter × 31 mm (distance from

camera lens mount flange when lens is retracted)

Weight Approx. 83 g (3.0 oz)

199

❚❚ 1 NIKKOR Lenses

1 NIKKOR VR 10–30mm f/3.5–5.6

1 NIKKOR 11–27.5mm f/3.5–5.6

Lens hood mounting mark

Zoom ring

Lens mounting mark

CPU contacts

Focal length mark

Focal length scale

Retractable lens barrel button

Lens cap

Zoom ring

Lens mounting mark

CPU contacts

Focal length mark

Focal length scale

Retractable lens barrel button

Lens cap

200

1 NIKKOR lenses are exclusively for Nikon 1 interchangeable lens

format digital cameras. The angle of view is equivalent to a

35 mm format lens with a focal length about 2.7× longer. The

1 NIKKOR VR 10–30mm f/3.5–5.6 supports normal and active

vibration reduction and vibration reduction off (0128).

Use the zoom ring to zoom in and out.

ADetaching the Lens

Before removing or exchanging lenses,

retract the lens and turn the camera off

(016). To remove the lens, press and hold

the lens release button (q) while turning the

lens clockwise (w). After removing the lens,

replace the lens caps and camera body cap.

ALens Care

•When using an optional lens hood, do not pick up or hold the lens or

camera using only the hood.

•Keep the CPU contacts clean.

•Use a blower to remove dust and lint from the lens surfaces. To

remove smudges and fingerprints, apply a small amount of ethanol or

lens cleaner to a soft, clean cotton cloth or lens-cleaning tissue and

clean from the center outwards using a circular motion, taking care

not to leave smears or touch the glass with your fingers.

•Never use organic solvents such as paint thinner or benzene to clean

the lens.

•A lens hood or NC filter can be used to protect the front lens element.

•Attach the front and rear caps when the lens is not in use.

•If the lens will not be used for an extended period, store it in a cool,

dry location to prevent mold and rust. Do not store in direct sunlight

or with naphtha or camphor moth balls.

•Keep the lens dry. Rusting of the internal mechanism can cause irrep-

arable damage.

•Leaving the lens in extremely hot locations could damage or warp

parts made from reinforced plastic.

201

ASupplied Accessories

•40.5 mm snap-on Front Lens Cap LC-N40.5

•Rear Lens Cap LF-N1000

AOptional Accessories

•40.5 mm screw-on filters

•Bayonet Hood HB-N101 (for use with the 1 NIKKOR VR 10–30mm

f/3.5–5.6; attaches as shown below).

•40.5 mm screw-on Hood HN-N102 (for use with the 1 NIKKOR

11–27.5mm f/3.5–5.6; attaches as shown below)

202

❚❚ The Optional FT1 Mount Adapter

Read this section for information on using the optional FT1

mount adapter. Before proceeding, be sure that you have read

and understood this manual and the documentation for the FT1

and lenses.

Autofocus

Autofocus is available only with AF-S lenses; other lenses sup-

port manual focus only. Set the camera focus mode to AF-S (the

camera will not focus in other autofocus modes). The only AF-

area mode available is Single-point and the camera focuses on

the subject in the center focus area only. Face priority is not sup-

ported. In some cases, a beep may sound, the in-focus indicator

may be displayed, and pictures can be taken when the camera is

not in focus; if this occurs, focus manually.

Manual Focus

Follow the steps below to focus manually when using the FT1

with a NIKKOR F mount lens.

1Select manual focus mode.

In the shooting menu, select Focus mode, highlight Manual

focus, press 2, and choose the magnification for the manual

focus display from 10×, 5×, and 2× (0132).

2Focus.

Rotate the lens focus ring until the

subject is in focus.

203

If the lens supports autofocus with manual override, after

focusing using autofocus you can keep the shutter-release

button pressed halfway and rotate the lens focus ring to fine-

tune focus manually. To refocus using autofocus, press the

shutter-release button halfway again.

To zoom in on the display for more

precise focus, press J (note that this

feature is not available during movie

recording or in slow-motion movie

mode). The display will be zoomed in

to the magnification selected in Step 1

and a navigation window will appear

in a gray frame at the bottom right of

the display.

Navigation window

Use the multi selector to scroll to areas

of the frame not visible in the display.

Press J to exit zoom.

204

The Electronic Rangefinder

Note that with some subjects, the in-focus indicator (I) may be

displayed when the camera is not in focus. Check focus in the

display before shooting.

Error Messages and Displays

The following warnings appear in the camera aperture display.

Restrictions

•Auto and best moment capture modes are not supported.

•Motion Snapshots can be recorded only when an AF-S lens is

attached and AF-S (Single AF) is selected for focus mode and

then only when the camera is in focus. Do not attempt to

adjust focus using the focus ring.

•Shutter speeds of 1 s or slower are not available.

•The sound monitor switch and focus operation button (Focus

Lock/MEMORY RECALL/AF Start) have no effect.

If a CPU lens is attached in manual focus

mode, the focus indicator can be used to

check whether the camera is focused on

the subject in the center focus area.

Focus indicator Status

IIn focus.

2Camera focused in front of subject.

4Camera focused behind subject.

24 Unable to determine focus.

(flashes)

Display Problem Solution

FEE Lens aperture ring is not

locked at minimum aperture.

When using CPU lenses, lock

aperture ring at minimum aper-

ture (highest f-number).

F–– Non-CPU lens is attached, or

no lens is attached.

When using non-CPU lens, rotate

lens aperture ring to adjust aper-

ture.

205

Precautions for Use

•Lenses over 380 g (13.4 oz) should be supported at all times.

Do not hold the camera or carry the camera by the strap with-

out supporting the lens. Failure to observe this precaution

could damage the camera lens mount.

•Lines may appear in photographs taken with non-CPU lenses

stopped down to minimum aperture.

•Select mode A or M to prevent sounds made by the lens being

picked up by the microphone.

•During continuous shooting, focus is fixed at the position for

the first shot in each burst. Frame rates will slow when 5fps is

selected for Continuous/self-timer.

•Certain lenses will block the AF-assist illuminator and, at some

distances, the flash.

•The tops and bottoms may be missing from circular bokeh

shapes created at wide apertures using lenses with a maximum

aperture of f/1.4.

206

❚❚ Supported Standards

•DCF Version 2.0: The Design Rule for Camera File Systems (DCF) is

a standard widely used in the digital camera industry to ensure

compatibility among different makes of camera.

•DPOF: Digital Print Order Format (DPOF) is an industry-wide

standard that allows pictures to be printed from print orders

stored on the memory card.

•Exif version 2.3: The camera supports Exif (Exchangeable Image

File Format for Digital Still Cameras) version 2.3, a standard in

which information stored with photographs is used for optimal

color reproduction when the images are output on Exif-com-

pliant printers.

•PictBridge: A standard developed through cooperation with the

digital camera and printer industries, allowing photographs to

be output directly to a printer without first transferring them to

a computer.

•HDMI: High-Definition Multimedia Interface is a standard for

multimedia interfaces used in consumer electronics and AV

devices capable of transmitting audiovisual data and control

signals to HDMI-compliant devices via a single cable connec-

tion.

207

ATrademark Information

Macintosh, Mac OS, and QuickTime are registered trademarks of Apple

Inc. in the United States and/or other countries. Microsoft, Windows,

and Windows Vista are either registered trademarks, or trademarks of

Microsoft Corporation in the United States and/or other countries. The

PictBridge logo is a trademark. Google Play is a trademark of Google

Inc. The SD, SDHC, and SDXC logos are trademarks of SD-3C, LLC. HDMI,

the HDMI logo and High-Definition Multimedia Interface are trade-

marks or registered trademarks of HDMI Licensing LLC.

All other trade names mentioned in this manual or the other documen-

tation provided with your Nikon product are trademarks or registered

trademarks of their respective holders.

AFreeType License (FreeType2)

AMIT License (HarfBuzz)

(http://www.freedesktop.org/wiki/Software/HarfBuzz). All rights

reserved.

208

Battery Life

The number of shots or movie footage that can be recorded with

fully-charged batteries varies with the condition of the battery,

temperature, the interval between shots, and the length of time

menus are displayed. Sample figures for EN-EL20 (1020 mAh)

batteries are given below.

•Still images: Approximately 220 shots

•Movies: Approximately 45 minutes of HD footage at 1080/60i

Measured according to CIPA standards at 23 ±3 °C (73.4 ±5.4 °F)

with the camera at default settings, a fully-charged battery, a

1 NIKKOR VR 10–30mm f/3.5–5.6 lens, and a 16 GB Toshiba

SD-E016GUX UHS-I SDHC card. Value for still images obtained

under the following test conditions: photographs taken at

intervals of 30 s with the built-in flash fired with every other

shot and the camera turned off and then on after every ten

shots. Value for movies obtained under the following test con-

ditions: a series of 20 minute movies with a file size of up to

4 GB were recorded; recording was only interrupted when tem-

perature warning was displayed.

The following can reduce battery life:

•Keeping the shutter-release button pressed halfway

•Repeated autofocus operations

•Taking NEF (RAW) photographs

•Slow shutter speeds

•Using a wireless mobile adapter or Eye-Fi cards

•Using vibration reduction mode with VR lenses

•Using zoom with power zoom lenses

To ensure that you get the most from rechargeable Nikon

EN-EL20 batteries:

•Keep the battery contacts clean. Soiled contacts can reduce

battery performance.

•Use batteries immediately after charging. Batteries will lose

their charge if left unused.

209

Symbols

C (Auto mode) ............................. 6, 21

w (Creative mode) .................... 6, 31

u (Best moment capture mode) . 6,

v (Advanced movie mode) .... 6, 57

z (Motion Snapshot mode) ..... 6, 53

h (Scene auto selector) ............. 119

P (Programmed auto) 32, 34, 57, 119

S (Shutter-priority auto) ...32, 35, 57,

119

A (Aperture-priority auto) 32, 36, 57,

119

M (Manual) ................... 32, 37, 57, 119

j (Night landscape) .........................32

o (Night portrait) ..............................33

m (Backlighting) .........................33, 40

p (Easy panorama) ...................33, 41

q (Soft) ..................................................33

r (Miniature effect) ........................33

s (Selective color) ............................33

y (Slow motion) ...............................62

c (Portrait) .........................................23

d (Landscape) ...................................23

f (Night portrait) .............................23

e (Close up) .......................................23

g (Night landscape) .......................23

Z (Auto) ..............................................23

U (flexible program) .........................34

G (menu) button ...... 8, 107, 117,

139, 143, 157

K (playback) button ..........27, 50, 56

O (delete) button ...28, 51, 56, 66, 85

J (OK) button ...................................... 7

& (feature) 10, 25, 31, 47, 55, 58, 62,

C (continuous shooting/self-timer) .

67, 69

E (exposure compensation) .........71

N (flash mode) ....................................73

L (Preset manual) ........................146

L (matrix) ..........................................124

M (centerweighted) .......................124

N (spot) ..............................................124

e (auto-area) ..................................134

c (single-point) .............................134

9 (subject tracking) ....................134

8 (Single frame) ............................... 67

Y (red-eye reduction) .................... 74

p (slow sync) .................................... 74

q (rear-curtain sync) ...................... 74

N (flash-ready indicator) ................. 72

AC adapter ............................... 165, 169

Accessories ........................................165

Active D-Lighting ............................127

Adobe RGB ........................................126

Advanced movie mode .......6, 57, 58

AE lock ................................................161

AF ................................................ 129, 134

AF-A .....................................................129

AF-area mode ...................................134

AF-assist illuminator ......................136

AF-C .....................................................129

AF-F ......................................................129

AF-S ......................................................129

Aperture ........................................36, 37

Aperture-priority auto ..... 32, 36, 57,

119

Attaching the lens ............................ 16

Auto distortion control .................125

Auto image rotation ......................163

Auto mode ......................................6, 21

Auto power off ..........................17, 160

Auto-area (AF-area mode) ...........134

Autofocus ................................. 129, 134

Automatic scene selection ............ 23

Auto-select AF ..................................129

Available settings ............................176

Index

210

Background track ................56, 88, 98

Backlighting .................................33, 40

Basic info .....................................79, 160

Battery ............................11, 13, 20, 197

Beep .......................................22, 69, 160

Best moment capture mode .........45

Best shot ........................................47, 50

Body cap ........................................2, 166

Border ..................................................105

Brightness ..........................................152

Buffering ........................................48, 54

Built-in AF assist ...............................136

Built-in flash ........................................72

Bulb ........................................................38

Calendar ........................................83, 87

Calendar playback ............................83

Capture NX 2 ..................122, 155, 166

CEC .......................................................101

Center-weighted (Metering) .......124

Change theme .................................115

Charging a battery ............................11

Clock ......................................18, 19, 162

Clock battery .......................................19

Close up ................................................23

Color space ........................................126

Color temperature ..........................148

Compatible lens ..............................165

Computer .............................................91

Continuous AF ..................................129

Contrast .................................... 127, 152

Creating short movies .............. 97, 98

Creative mode ....................................31

Crop ...........................................105, 113

Custom Picture Control .......151, 154

Date and time ............................18, 162

Date format ................................18, 162

Daylight saving time ...............18, 162

DCF version 2.0 ...................... 126, 206

Defaults ..............................................180

Delete ........................ 28, 51, 56, 66, 85

Delete all images .............................. 85

Delete selected images .................. 85

Detailed display .......................... 4, 159

Detailed photo information .80, 160

Digital Print Order Format ...........206

Display ................................................159

Display brightness ..........................159

D-Lighting .........................................111

DPOF ................................104, 106, 206

DPOF print order ................... 104, 106

Dust shield .............................. 171, 172

Easy panorama ........................... 33, 41

Edit movie ..........................................114

Electronic VR .....................................129

Exif version 2.3 ....................... 126, 206

Exposure ........................... 71, 119, 124

Exposure compensation ................ 71

Exposure indicator ........................... 38

Exposure mode ...............................119

Eye-Fi ...................................................168

Face priority ...............................24, 136

Face-priority zoom .........................114

File format .........................................124

Fill flash ................................................. 74

Filter effects ............................ 152, 153

Fine-tuning white balance ..........145

Firmware version ............................164

Flash ..............................................72, 137

Flash compensation .......................137

Flash mode .......................................... 73

Flash range .......................................... 75

Flash-ready indicator ....................... 72

Flexible program ............................... 34

Flicker reduction .............................161

Focal length ................................. 24, 80

Focal length scale ....................24, 199

211

Focal plane mark ........................2, 133

Focus ..........................................129, 134

Focus area .................................. 22, 134

Focus lock .......................................... 135

Focus mode ...................................... 129

Format ......................................... 14, 158

Format memory card ............. 14, 158

Frame rate .........................79, 140, 141

FT1 ....................................................... 202

Full-frame playback ...................27, 79

Full-time AF ...................................... 129

Grid display ............................................ 5

H.264 ................................................... 195

HD movies ........................... 57, 58, 141

HDMI ..........................................100, 206

HDMI device control ..................... 101

HDMI-CEC ......................................... 101

HDR ........................................................40

High definition .......................100, 206

High ISO noise reduction ............ 156

Histogram ............................................81

Hue ...................................................... 152

Image processing menu .............. 143

Image quality ................................... 120

Image review ................................... 110

Image selection .............................. 109

Image size ......................................... 120

Index print ........................................ 104

ISO sensitivity .................................. 149

JPEG ..................................................... 120

Landscape .................................. 23, 150

Language ................................... 18, 162

Lens .................... 16, 24, 128, 165, 197

Lens cap ............................................. 200

Lens mount .......................................133

Live image control ............................ 25

Load from/save to card .................155

Long exposure NR ..........................128

Manual ...........................32, 37, 57, 119

Manual focus ....................................132

Matrix (Metering) ............................124

Maximum aperture .............. 197, 198

Memory card ...13, 15, 158, 167, 181

Memory card access lamp ............. 22

Memory card capacity ..................181

Metering .............................................124

Microphone ...............................59, 142

Miniature effect .................................33

Mode dial ................................................6

Monitor .......................................... 4, 159

Monochrome ....................................150

Motion Snapshot mode .................. 53

Mount adapter ....................... 165, 202

MOV ..................................122, 124, 183

Movie before/after .........................123

Movie menu ......................................139

Movie settings ..................................141

Movie sound options .....................142

Movie-record button . 29, 44, 57, 59,

Movies ............................29, 44, 57, 141

Multi selector .........................................7

NEF ............................................. 120, 122

NEF (RAW) ................................ 120, 122

Neutral ................................................150

Night landscape ......................... 23, 32

Night portrait .............................. 23, 33

Nikon Transfer 2 ................................. 95

NMS ...................................122, 124, 183

Normal panorama ................ 121, 182

Number of shots saved .................123

212

Optical VR ..........................................128

Photo information ............................79

PictBridge .................................102, 206

Picture Control ....................... 150, 154

Pixel mapping ..................................164

Playback ........................................27, 79

Playback menu .................................107

Playback zoom ...................................84

Portrait .........................................23, 150

Power connector ...................165, 169

Power drive zoom switch ...............24

Power switch .......................................17

Preset manual .........................144, 146

Press the shutter-release button all

the way down ............................22, 23

Press the shutter-release button

halfway .........................................22, 23

Print date ............................................106

Print DPOF print order ...................104

Printing ...............................................102

Programmed auto ......32, 34, 57, 119

Protect .................................................110

Quick adjust ......................................152

Rating ...........................................86, 110

Rear-curtain sync ..............................74

Red-eye reduction ............................74

Removing the lens from the camera

200

Reset file numbering .....................161

Reset movie options ......................140

Reset processing options .............144

Reset setup options .......................158

Reset shooting options .................119

Resize ...................................................112

Retractable lens barrel button ....16,

17, 199

Rotate tall ..........................................110

Saturation ..........................................152

Scene auto selector ........................119

Scene selection .................................. 32

SD card ...............................................167

Select images for printing ...........104

Selective color .................................... 33

Self-timer ...................................... 67, 69

Sensitivity ..........................................149

Setup menu ......................................157

Sharpening ........................................152

Shooting menu ................................117

Short Movie Creator ........... 91, 97, 98

Shutter button AE lock .................161

Shutter speed .............................. 35, 37

Shutter-priority auto 32, 35, 57, 119

Shutter-release button .... 22, 23, 46,

48, 54, 161

Single AF ............................................129

Single frame ........................................ 67

Single-point ......................................134

Size .................112, 120, 141, 191, 195

Slide show ........................................... 87

Slot empty release lock .................159

Slow motion ..............................62, 140

Slow sync ............................................. 74

Slow view ............................................. 45

Smart Photo Selector ...................... 47

Soft ......................................................... 33

Sound settings .................................160

Speaker ....................................................3

Spot (Metering) ...............................124

sRGB .....................................................126

Standard .............................................150

Strap ...................................................... 11

Subject tracking ..............................134

System requirements ...................... 93

Television ...........................................100

Temperature warnings ....................xvi

213

Theme ......................................... 55, 115

Thumbnail playback .........................82

Time ............................................. 18, 162

Time stamp ....................................... 105

Time zone .......................................... 162

Time zone and date ....................... 162

Timer ......................................................67

Toning .......................................152, 153

Trimming movies ........................... 114

USB ........................................ 76, 95, 102

USB cable ................................... 95, 102

ViewNX 2 ..............................................91

Vivid .................................................... 150

Volume ...........................................65, 89

VR ......................................................... 128

Waterproof case .....................144, 165

White balance .................................. 144

Wide panorama .....................121, 182

Wind noise reduction ................... 142

Wireless mobile adapter ....... 76, 166

Zoom guide .........................................24

Zoom ring .................................. 24, 199

No reproduction in any form of this manual, in whole or in

part (except for brief quotation in critical articles or reviews),

may be made without written authorization from NIKON

CORPORATION.

SB2L01(11)

6MVA4411-01

Nikon 1 J3 Manual User Guide And Product Specification

Navigation menu

Versions of this User Manual:

Views

Navigation
