IBM Security QRadar

WinCollect User Guide V7.2

򔻐򗗠򙳰

Note: Before using this information and the product that it supports, read the information in “Notices and

Trademarks” on page 61.

© Copyright IBM Corp. 2011 All Rights Reserved US Government Restricted Rights - Use, duplication or

disclosure restricted by GSA ADP Schedule Contract with IBM Corp.

ABOUT THIS GUIDE

Intended audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Technical documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Contacting customer support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Statement of good security practices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

1WHAT’S NEW IN WINCOLLECT V7.2

Distributed WinCollect deployment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

64-bit installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Communication management port change . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Automatic log source creation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Updated installation process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Performance improvements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Agent installations on Windows XP systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Heart beats are no longer updated in the QRadar user interface . . . . . . . . . . . . . . . . 4

Stand-alone installations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

2WINCOLLECT OVERVIEW

Distributed WinCollect agent installation process . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

3INSTALLATION PREREQUISITES FOR WINCOLLECT

Distribution options for WinCollect agents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Local collection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Remote Collection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Deployment considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Communication between WinCollect agents and QRadar Event Collectors . . . . . . . . 7

Hardware and software requirements for the WinCollect host. . . . . . . . . . . . . . . . . . . 8

Event per second rates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Prerequisites for upgrading WinCollect agents . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

4WINCOLLECT INSTALLATION

Installing the WinCollect agent RPM on QRadar . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Creating an authentication token for WinCollect agents . . . . . . . . . . . . . . . . . . . . . . 12

Installing the WinCollect agent on a WinCollect host. . . . . . . . . . . . . . . . . . . . . . . . . 13

Installing a WinCollect agent from the command-line interface . . . . . . . . . . . . . . . . . 15

Manually installing a WinCollect agent update . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

5POST INSTALLATION INSTRUCTIONS FOR WINCOLLECT AGENTS

WinCollect agent management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Manually adding a WinCollect Agent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Enabling or Disabling a WinCollect Agent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Deleting a WinCollect Agent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Destination management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Adding a destination to WinCollect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Deleting a destination from WinCollect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Schedule management. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Configuration options for systems with restricted policies for domain controller

credentials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Local installations with no remote polling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Configuring access to the registry for remote polling . . . . . . . . . . . . . . . . . . . . . 26

Configuring Windows event subscriptions for WinCollect agents . . . . . . . . . . . . 27

6LOG SOURCES FOR WINCOLLECT AGENTS

Adding a log source to a WinCollect agent. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Configuration options for log sources that use WinCollect plug-ins . . . . . . . . . . . . . 33

Microsoft DHCP log source configuration options. . . . . . . . . . . . . . . . . . . . . . . . 33

Microsoft IAS log source configuration options . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Microsoft ISA log source configuration options . . . . . . . . . . . . . . . . . . . . . . . . . . 34

File Forwarder log source configuration parameters. . . . . . . . . . . . . . . . . . . . . . 35

Microsoft IIS log source configuration options. . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Microsoft SQL log source configuration options . . . . . . . . . . . . . . . . . . . . . . . . . 37

Adding multiple log sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

7WINCOLLECT PLUG-IN REQUIREMENTS

Microsoft DHCP plug-in requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Enabling DHCP event logs on your Microsoft Windows Server . . . . . . . . . . . . . 42

Microsoft IAS and NPS plug-in requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Configuring the Microsoft IAS plug-in for WinCollect . . . . . . . . . . . . . . . . . . . . . 43

Microsoft IAS or NPS server log formats. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Microsoft IAS directory structure for event collection . . . . . . . . . . . . . . . . . . . . . 43

Microsoft ISA plug-in requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Configuring the Microsoft ISA plug-in . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Supported Microsoft ISA or TMG server log formats . . . . . . . . . . . . . . . . . . . . . 45

Microsoft ISA directory structure for event collection . . . . . . . . . . . . . . . . . . . . . 46

File Forwarder plug-in requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Microsoft IIS plug-in requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Microsoft IIS directory structure for event collection . . . . . . . . . . . . . . . . . . . . . . 47

Microsoft SQL Server plug-in . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

8XPATH QUERIES

Enabling remote log management on a Windows operating system . . . . . . . . . . . . 49

Windows 2008. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Windows 2008R2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Windows 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Creating a custom view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Adding an XPath log source. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

XPath query examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Example: Monitor events for a specific user . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Credential logon for Windows 2008 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

ATROUBLESHOOTING A WINCOLLECT AGENT

Installation log examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Example: Missing authorization or Console IP address . . . . . . . . . . . . . . . . . . . . 58

Example: Installation stopped by user . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Example: Installation file in use error . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58

Troubleshooting device configuration issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Device Polling Overdue . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

BNOTICES AND TRADEMARKS

Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Trademarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

INDEX

IBM Security QRadar WinCollect User Guide

ABOUT THIS GUIDE

The IBM Security QRadar WinCollect User Guide provides you with information for

how to install and configure WinCollect agents, and retrieve events from

Windows-based event sources.

The following IBM Security QRadar products support WinCollect:

•IBM Security QRadar SIEM

•IBM Security QRadar Log Manager

Intended audience This guide is intended for the system administrator who is responsible for Windows

event sources or WinCollect agent installation and configuration in your QRadar

deployment or in your network. This guide assumes that you have QRadar

administrative access and a knowledge of your corporate network and networking

technologies.

Technical

documentation

For information about how to access more technical documentation in the QRadar

products library, see Accessing IBM Security QRadar Documentation Technical

Note. (http://www.ibm.com/support/docview.wss?rs=0&uid=swg21614644)

To find IBM Security QRadar product documentation on the web, including all

translated documentation, access the IBM Knowledge Center

(http://www.ibm.com/support/knowledgecenter/SS42VS/welcome).

Contacting

customer support

For information on contacting customer support, see the Support and Download

Technical Note.

(http://www.ibm.com/support/docview.wss?rs=0&uid=swg21612861)

Statement of good

security practices

IT system security involves protecting systems and information through

prevention, detection and response to improper access from within and outside

your enterprise. Improper access can result in information being altered,

destroyed, misappropriated or misused or can result in damage to or misuse of

your systems, including for use in attacks on others. No IT system or product

should be considered completely secure and no single product, service or security

IBM Security QRadar WinCollect User Guide

2ABOUT THIS GUIDE

measure can be completely effective in preventing improper use or access. IBM

systems, products and services are designed to be part of a comprehensive

security approach, which will necessarily involve additional operational

procedures, and may require other systems, products or services to be most

effective. IBM DOES NOT WARRANT THAT ANY SYSTEMS, PRODUCTS OR

SERVICES ARE IMMUNE FROM, OR WILL MAKE YOUR ENTERPRISE

IMMUNE FROM, THE MALICIOUS OR ILLEGAL CONDUCT OF ANY PARTY.

IBM Security QRadar WinCollect User Guide

1WHAT’S NEW IN WINCOLLECT V7.2

WinCollect v7.2 includes updates.

Distributed

WinCollect

deployment

Using a distributed deployment, you can configure WinCollect agents to

communicate with an Event Collector. The Event Collector then sends the data to

your QRadar Console. You can manage your distributed deployment by using the

QRadar user interface. To use this feature, your QRadar system must be updated

to v7.2.1 Patch 3 or later.

Learn more

64-bit installation For new installations, depending on your Windows operating system bit version,

you can download 32-bit or 64-bit WinCollect agent installer. If you are upgrading,

when you install the WinCollect agent RPM, the installer automatically detects the

operating system bit version.

Communication

management port

change

WinCollect now uses port 8413 for management communication.

Learn more

Automatic log

source creation

When you install the WinCollect agent on a WinCollect host you can now configure

the agent to automatically create a log source in QRadar. This log source is

created when the agent first registers with QRadar. This log source will collect the

configured windows event log types from the Windows Server where the agent

was installed. This feature eliminates the need to set up a local log source for each

agent that is installed. Your QRadar system must be updated to v7.2.1 Patch 1 or

later.

Learn more

Updated

installation process

When you install the WinCollect RPM, it now includes all of the WinCollect plugins.

You can configure the WinCollect agent installation to automatically create and

tune a QRadar log souce.

You can also set the syslog status server, which is useful if you set up a

stand-alone installation.

IBM Security QRadar WinCollect User Guide

4WHAT’S NEW IN WINCOLLECT V7.2

Performance

improvements

There are many performance improvements, including significant increases to

EPS rates for tuned agents, both for local and remote collection. There are also

improvements to the agent logging and statistical information. See Table 3-2.

Agent installations

on Windows XP

systems

Installing the WinCollect agent is supported on Windows XP. See Table 3-2.

Heart beats are no

longer updated in

the QRadar user

interface

Heartbeats are supported as a syslog message and the QRadar user interface for

WinCollect agents is not updated. You will see new syslog messages for

heartbeats that you did not see in previous releases.

Stand-alone

installations

WinCollect agents can be installed in stand-alone mode. You can use an endpoint

management or software distribution product to manage the installation of your

stand-alone WinCollect agents

For more information about how to install stand-alone WinCollect agents, consult

Professional Services.

IBM Security QRadar WinCollect User Guide

2WINCOLLECT OVERVIEW

WinCollect is an agent that collects Microsoft Windows-based events from local or

remote Windows-based systems and sends them to IBM Security QRadar.

WinCollect is an application that collects events by running as a service on a

Windows system. The WinCollect agent can also collect events from other

Windows servers where the agent is not installed. WinCollect is centrally managed

from the QRadar user interface. Each WinCollect agent deployed in your network

can collect and forward events to QRadar Console or Event Collector by using

syslog.

Distributed

WinCollect agent

installation process

You can configure multiple WinCollect agents to communicate with an Event

Collector that then sends the data to your QRadar Console. To install a distributed

WinCollect agent deployment, you must perform the following procedures:

1 Install the WinCollect agent RPM on your QRadar Console.

2 Create an authorization token for your WinCollect agents.

3 Create destinations for WinCollect events in your deployment.

4 Install the WinCollect agent on your WinCollect hosts and set the Configuration

Console as the IP of your Event Collector.

5 Wait for QRadar to automatically discover your WinCollect agents.

IBM Security QRadar WinCollect User Guide

3INSTALLATION PREREQUISITES FOR

WINCOLLECT

Before you can install WinCollect agents, you must verify your deployment meets

the installation requirements.

Distribution

options for

WinCollect agents

WinCollect agents can be distributed in a remote collection configuration or

installed on the local host. The following WinCollect collection methods are

available: local and remote.

Local collection The WinCollect agent collects events only for the host on which it is installed. You

can use this collection method on a Windows host that is busy or has limited

resources, for example, domain controllers.

Remote Collection The WinCollect agent is installed on a single host and collects events from multiple

Windows systems. Remote collection allows you to easily scale the number of

Windows log sources that you can monitor.

Deployment

considerations

Use the following strategies to reduce the impact to system performance:

•To reduce the total number of agents, use remote collection where one agent

monitors many endpoints.

•If you update a group of WinCollect agents, do it during off-peak operating

hours.

•Deploy and manage the WinCollect agents in groups of 100 and monitor

system performance for issues.

Communication

between

WinCollect agents

and QRadar Event

Collectors

Open ports are required for data communication between WinCollect agents and

the QRadar host, and between WinCollect agents and the hosts that they remotely

poll.

WinCollect agent communication to QRadar Console and Event Collectors

All WinCollect agents communicate with the QRadar Console and Event Collectors

to forward events to QRadar and request updated information.

You must ensure firewalls that are between the QRadar Event Collectors and your

WinCollect agents allow traffic on the following ports:

•Port 8413 (management communication) is required for managing the

WinCollect agents. Port 8413 is used for features such as the heartbeat and

IBM Security QRadar WinCollect User Guide

8INSTALLATION PREREQUISITES FOR WINCOLLECT

configuration updates. Traffic is always initiated from the WinCollect agent. This

traffic is sent over TCP and communication is encrypted.

•Port 514 (syslog events) is used by the WinCollect agent to forward syslog

events to QRadar. You can configure WinCollect log sources to provide events

by using TCP or UDP. You can decide which transmission protocol is required

for each WinCollect log source. Port 514 traffic is always initiated from the

WinCollect agent.

WinCollect agents remotely polling Windows event sources

WinCollect agents that remotely poll other Windows operating systems for events

include have extra port requirements.

The following ports are used when WinCollect agents remotely poll for

Windows-based events:

Collecting events by polling remote Windows systems uses dynamic RPC. To use

dynamic RPC, you must allow inbound traffic to the Windows system that

WinCollect attempts to poll for events on port 135. Port 135 is used for Endpoint

Mapping by Windows.

If you remotely poll any Windows operating system other than the Windows Vista

operating system, you might need to allow ports in the range between 1024 and

port 5000. You can configure Windows to restrict the communication to specific

ports for the older versions of Windows Firewall, for example Windows XP. For

more information, see your Windows documentation.

Hardware and

software

requirements for

the WinCollect host

The Windows system that hosts the WinCollect agent must meet the following

minimum requirements:

Table 3-1 Port usage for WinCollect remote polling

Protocol and port Usage

TCP port 135 Microsoft Endpoint Mapper

UDP port 137 NetBIOS name service

UDP port 138 NetBIOS datagram service

TCP port 139 NetBIOS session service

TCP port 445 Microsoft Directory Services for file transfers that

use Windows share

Table 3-2 WinCollect host hardware and software requirements

Requirement Description

Memory 8GB (2GB reserved for the WinCollect agent)

Processing Intel Core 2 Duo processor 2.0 GHz

IBM Security QRadar WinCollect User Guide

Event per second rates 9

To tune your installation to improve the performance of a single WinCollect agent,

contact IBM Professional Services.

Event per second

rates

Before you install your WinCollect agents, it is important to understand the number

of events that can be collected by a WinCollect agent.

The event per second (EPS) rates in Table 3-3 represent a test network. This

information can help you determine the number of WinCollect agents that you

need to install on your network. WinCollect supports default EPS rates and also

supports tuning, which allows you to improve the performance of a single

WinCollect agent. You can tune local collection as part of the agent installation.

Improving the performance of existing installations and remote collection must be

done with the help of IBM Professional Services or IBM Customer Support.

Exceeding these EPS rates without tuning can cause you to experience

performance issues or event loss, especially on busy systems.

The following table describes the default EPS rate in our test environment:

Disk space 3 GB of available disk space for software and log

files

6 GB might be required if events are stored on a

schedule

Available

processor

resources

20%

Supported

operating systems

•Windows Server 2003

•Windows Server 2008

•Windows Server 2008R2

•Windows Server 2012

•Windows 7

•Windows Vista

•Windows XP

Required user role

permissions

Administrator

Distribution One WinCollect agent for each host.

Table 3-2 WinCollect host hardware and software requirements

Requirement Description

Table 3-3 WinCollect test environment

Installation Type Tuning EPS Log Sources Total EPS

Local Collection Default 250 1 250

Remote Collection Default 5 - 10 500 2500

IBM Security QRadar WinCollect User Guide

10 INSTALLATION PREREQUISITES FOR WINCOLLECT

Tuning an agent to increase the EPS rates for remote event collection is highly

dependent on your network, the number of log sources you assign to the agent,

and the number of events generated by each log source.

Prerequisites for

upgrading

WinCollect agents

Before you upgrade WinCollect agents, ensure that the following conditions are

met:

1 If you are running QRadar V7.1 (MR2), ensure that WinCollect agent

7.1.0-QRADAR-AGENT-WINCOLLECT-7.1-613263 is installed.

2 If you are running QRadar V7.2.0 or later, ensure that WinCollect agent

7.2.0-QRADAR-AGENT-WINCOLLECT-7.2-613265 is installed.

You can confirm the version of the installed WinCollect agent by using one of the

following methods:

•In QRadar, select Help > About, then select the link “Additional Release

Information”.

•Use ssh to log in to the QRadar console, and run the following command:

rpm -qa | grep -i AGENT-WINCOLLECT

Note: Before you install the new WinCollect agent, open the WinCollect panel in

the Admin tab, and ensure that all WinCollect agents are listed as version 7.1.2.

If you installed AGENT-WINCOLLECT-7.1-613263 or

AGENT-WINCOLLECT-7.2-613265, but one or more agents are still listed as

version 7.1.1, ensure that you wait for the V7.1.2 update to be replicated to the

agents.

Before you installed the WinCollect agent, the replication time setting was

specified by the Configuration Poll Interval in the WinCollect Agent Configuration

panel.

Local Collection Tuned 5000 1 5000

Remote Collect Tuned varies varies 2500+

Table 3-3 WinCollect test environment

Installation Type Tuning EPS Log Sources Total EPS

IBM Security QRadar WinCollect User Guide

4WINCOLLECT INSTALLATION

To install WinCollect on a Windows-based host, you must download and install a

WinCollect agent RPM on QRadar, create an authentication token, and then install

a WinCollect agent on a Windows-based host. Install the WinCollect agent on each

Windows-based host from which you want to collect events or on the host that you

want to use for remote collection.

First time installations require that you install both the WinCollect agent RPM and

the WinCollect agent executable (.exe)

Upgrades require that you install only the WinCollect agent RPM. If automatic

updates are enabled, the WinCollect agent RPM sends updates to all of the

WinCollect agents.

Installing the

WinCollect agent

RPM on QRadar

To use the QRadar user interface to manage a distributed deployment of

WinCollect agents, you must install the WinCollect agent RPM on your QRadar

Console. This agent includes the required protocol to enable communication

between QRadar system and the managed WinCollect hosts.

Procedure

Step 1 Download the WinCollect agent RPM file from the following website:

http://www.ibm.com/support

Step 2 Copy the RPM to your QRadar system.

Log in to QRadar as the root user.

Step 3 Type the following command:

rpm -Uvh

AGENT-WINCOLLECT-<Qradar_version>-<build_number>.noarch.rpm

Step 4 To install the protocol files, type the following command:

yum groupinstall wincollect

Step 5 If you are prompted for configuration, type y.

Step 6 Log in to QRadar.

Step 7 On the Admin tab toolbar, select Advanced > Deploy Full Configuration.

Step 8 As the root user, run the following command: service tomcat restart

IBM Security QRadar WinCollect User Guide

12 WINCOLLECT INSTALLATION

Creating an

authentication

token for

WinCollect agents

Third-party or external applications that interact with QRadar require an

authentication token. Before you install WinCollect agents in your network, you

must create an authentication token. This authentication token is required for every

WinCollect agent you install.

About this task

In the Manage Authorized Services window, you must select a user role that you

want to use this authentication token. For most configurations, the All user role

can be selected. The Admin user role provides more privileges, which can create

a security concern.

The authentication token allows WinCollect agents to exchange data with QRadar

appliances. Create one authentication token for all of your WinCollect agents that

communicate events with your QRadar host. If the authentication token expires,

the WinCollect agent cannot receive log source configuration changes.

Procedure

Step 1 Click the Admin tab.

Step 2 On the navigation menu, click System Configuration.

Step 3 Click the Authorized Services icon.

Step 4 Click Add Authorized Service.

In the Manage Authorized Services window, configure the parameters.

Table 4-4 Add Authorized Services parameters

Perameter Description

Service Name Type a name for this authorized service. The name

can be up

to 255 characters in length. For example, WinCollect

Agent.

User Role From the list box, select a user role.

Administrators can create a user role or assign a

default user role to the authorization token. For most

configurations, the All user role can be selected.

Note: The admin user role provides additional

privileges, which can create a security concern and

should not be used.

IBM Security QRadar WinCollect User Guide

Installing the WinCollect agent on a WinCollect host 13

Step 5 Click Create Service.

Step 6 Record the generated authentication token value.

Installing the

WinCollect agent

on a WinCollect

host

You can install the WinCollect agents on Windows-based hosts in your network.

The WinCollect agent collects Windows-based events and sends them to your

QRadar Console or QRadar Event Collector.

When you install WinCollect, you can now choose to have QRadar automatically

create a log source for the WinCollect agent host that is based on the agent

registration with QRadar. You can also specify a forwarding destination host for the

log source data. To use this feature, your QRadar system must be updated to

v7.2.1 Patch 1 or later.

Before you begin

Ensure that the following conditions are met:

•You created an authentication token for the WinCollect agent.

•You must add a WinCollect destination before you configure automatic log

source creation. The WinCollect agent sends the Windows event logs to the

configured destination. The destination can be the console or an Event

Collector. See Adding a destination to WinCollect.

•If you want to automatically create a log source for this agent, you must know

the name of the destination that you want to send your Windows log source to.

See Adding a destination to WinCollect. If you do not remember the

destination name, click Admin > Data Sources > WinCollect > Destinations.

•Hardware and software requirements for the WinCollect host

•Communication between WinCollect agents and QRadar Event Collectors.

Procedure

Step 1 Download the WinCollect agent setup file from the following website:

http://www.ibm.com/support

Expiry Date Type or select an expiry date using the calendar

provided. Alternately, select the No Expiry check

box to indicate you do not want the service token to

expire. The Expiry Date field allows you to define a

date when you want this service to expire. If the date

defined expires, the service is no longer authorized

and a new authorization token needs to be

generated by an administrator. By default, the

authorized service is valid for 30 days.

Table 4-4 Add Authorized Services parameters

Perameter Description

IBM Security QRadar WinCollect User Guide

14 WINCOLLECT INSTALLATION

Note: If the Services window is open on the Windows host, the WinCollect agent

installation fails.

Step 2 Right-click the WinCollect agent installation file and select Run as administrator.

Step 3 Follow the prompts in the installation wizard. The following table describes some of

the parameters.

Table 4-5 WinCollect installation wizard parameters

Parameter Description

Host Identifier Type a name to identify the WinCollect agent to the

QRadar Console. You must use a unique identifier

for each WinCollect agent you install. The name you

type in this field is displayed in the WinCollect agent

list of the QRadar Console.

Authentication

Token Type the authentication token you created in QRadar

for the WinCollect agent.

For example,

af111ff6-4f30-11eb-11fb-1fc117711111

For more information on creating an authorization

token for WinCollect, see Creating an

authentication token for WinCollect agents.

Configuration

console

Required for all installations, except stand-alone

mode. Leave blank for stand-alone mode

installations. Type the IP address or host name of

your QRadar console. For example, 100.10.10.1 or

hostname.

Note: This parameter is intended for the QRadar

console only. Do not specify an Event Collector or

non-console appliance in this field. To use an event

collector as your configuration console, your QRadar

system must be updated to V7.2.1 Patch 3 or later.

Log Source Name Required. The name can be up to 255 characters in

length.

Log Source

Identifier

Required if the Enable Automatic Log Source

Creation checkbox is selected. Identifies the remote

device that the WinCollect agent polls.

Event Logs Select the Window event logs that you want the log

source to collect and send to QRadar.

Target Destination The WinCollect Destination must be configured in

QRadar before proceeding.

IBM Security QRadar WinCollect User Guide

Installing a WinCollect agent from the command-line interface 15

If you want to enable automatic log source creation, your QRadar Console or

Event Collector must be installed with QRadar 7.2.1 Maintenance Release 1 Patch

1 or later.

Installing a

WinCollect agent

from the

command-line

interface

Use the command-line interface (CLI) to install a WinCollect agent on a host

without the installation wizard.

Command-line installations deploy WinCollect agents simultaneously to multiple

remote systems that use third-party products remote or batch installations.

About this task

The WinCollect installer uses the following parameters:

Advanced Tuning Machine Poll Interval (msec) is the polling interval

that determines the number of milliseconds (msec)

between queries to the Windows host

•Use a polling interval of 3500 when the

WinCollect agent collects events from computers

that have a low event per second rate, for

example, collecting from 50 remote computers

that provide 20 events per second or less.

•Use a polling interval of 1000 when the

WinCollect agent collects events from a small

number of remote computers that have a high

event per second rate, for example collecting from

10 remote computers that provide 100 events per

second or less.

The minimum polling interval is 100 milliseconds

(.1 seconds). The default is 3000 milliseconds or

3 seconds.

Minimum number

of logs to process

per pass

Consult IBM Customer Support prior to changing

these values.

Maximum number

of logs to process

per pass

Consult IBM Customer Support prior to changing

these values.

Table 4-5 WinCollect installation wizard parameters

Parameter Description

Table 4-6 WinCollect installer parameters

Parameters Description

/qn Runs the WinCollect agent installation without

a user interface.

IBM Security QRadar WinCollect User Guide

16 WINCOLLECT INSTALLATION

INSTALLDIR The installation directory for the WinCollect

agent. Your directory name cannot include

spaces and quotation marks enclose the

directory path, for example,

INSTALLDIR=“C:\IBM\WinCollect\”

AUTHTOKEN=token Authorizes the WinCollect service, for

example,

AUTH_TOKEN=af111ff6-4f30-11eb-11fb-1fc1

17711111

HOSTNAME=host name The identifiable name, IP address or host

name for the WinCollect agent host. The at

(@) symbol is not allowed in the host identifier

field.

FULLCONSOLEADRESS=host_addr

ess

The IP address or host name of your QRadar

Console or Event Collector, for example,

FULLCONSOLEADRESS=100.10.10.1.

Your QRadarsystem must be updated to

v7.2.1 Patch 3 or later if you want to configure

the agent to use an Event Collector as its

FULLCONSOLEADRESS

LOG_SOURCE_AUTO_CREATION Enables automatic log source creation. If you

enable this parameter, you must configure the

log source parameters.

This feature requires that your QRadar

system be updated to v7.2.1 Patch 1or later.

LOG_SOURCE_AUTO_CREATION_

PARAMETERS

Defines the parameters that you want the log

source creation process to use. Ensure that

each parameter uses the format:

Parameter_Name=value.The parameters

are separated with ampersands (&).

This feature requires that your QRadar

system be updated to v7.2.1 Patch 1 or later.

Log source creation uses the following

parameters:

Component1.AgentDevice Required. Must be 'DeviceWindowsLog'

Component1.Action Required. Must be ‘create’

Component1.LogSourceName Not required. The name of the log source that

is created. The default is

WindowsAuthServer @

<LogSourceIdentifier>

Component1.LogSourceIdentifier Required. Must be the IP or hostname of the

system that the agent is installed on

Component1.Destination.Name Required if Component1.Destination.Id is not

set

Table 4-6 WinCollect installer parameters (continued)

Parameters Description

IBM Security QRadar WinCollect User Guide

Installing a WinCollect agent from the command-line interface 17

Procedure

Step 1 Download the WinCollect agent setup file from the following website:

http://www.ibm.com/support

Step 2 From the desktop, select Start > Run.

Step 3 Type the following command:

cmd

Step 4 Click OK.

Step 5 Navigate to the download directory that contains the WinCollect agent setup file.

Note: The Services window cannot be open on the Windows host or the

WinCollect agent installation fails.

Step 6 Type the following command:

AGENT-WinCollect-7.2.0.<build>-setup.exe /s /v"/qn

INSTALLDIR=”C:\IBM\WinCollect" AUTHTOKEN=token

FULLCONSOLEADRESS=host_address HOSTNAME=hostname

LOG_SOURCE_AUTO_CREATION=true|false

LOG_SOURCE_AUTO_CREATION_PARAMETERS=”parameters”””

The following example shows an installation where the log source is automatically

created.

AGENT-WinCollect-<version>-setup.exe /s /v"/qn

INSTALLDIR="C:\IBM\WinCollect"

AUTHTOKEN=eb59386c-e098-49b8-ba40-d6fb46bfe7d1

FULLCONSOLEADDRESS=<IP_address>:8413 HOSTNAME=<my_host>

LOG_SOURCE_AUTO_CREATION_ENABLED=True

LOG_SOURCE_AUTO_CREATION_PARAMETERS=""Component1.AgentDevice=De

Component1.CoalesceEvents Not required. True or False. For more

information see the Log Sources User Guide.

Component1.StoreEventPayload Not required. True or False. For more

information see the Log Sources User Guide.

Component1.Encoding Not required. The default character encoding

is UTF-8.

Component1.Log.Application Required

Component1.Log.Security Required

Component1.Log.System Required

Component1.Log.DNS+Server Required

Component1.Log.Directory+Service Required

Component1.Log.File+Replication+S

ervice

Required

Table 4-6 WinCollect installer parameters (continued)

Parameters Description

IBM Security QRadar WinCollect User Guide

18 WINCOLLECT INSTALLATION

viceWindowsLog&Component1.Action=create&Component1.LogSourceNam

e=LSN2&Component1.LogSourceIdentifier=<IP_address>&Component1.D

estination.Na:me=Dest1&Component1.CoalesceEvents=True&Component

1.StoreEventPayload=True&Component1.Encoding=UTF-8&Component1.L

og.Application=True&Component1.Log.Security=True&Component1.Log

.System=True&Component1.Log.DNS+Server=False&Component1.Log.Dir

ectory+Service=False&Component1.Log.File+Replication+Service=Fa

lse"""

The following example shows an installation where automatic log creation is not

used:

AGENT-WinCollect-<version>-setup.exe /s /v"/qn

INSTALLDIR="C:\IBM\WinCollect"

AUTHTOKEN=eb59386c-e098-49b8-ba40-d6fb46bfe7d1

FULLCONSOLEADDRESS=<IP_address>HOSTNAME=<my_host"

Step 7 Press Enter.

Manually installing

a WinCollect agent

update

When you install an agent update RPM file, the QRadar host can automatically

update all WinCollect agents that are enabled to receive automatic updates.

About this task

When enabled, WinCollect agents request updated configurations from the

QRadar host based on the configuration polling interval. If new WinCollect agent

files are available for download, the agent downloads and installs updates and

restarts required services. No events are lost when you update your WinCollect

agent because events are buffered to disk. Event collection forwarding continues

when the WinCollect service starts.

After you update an agent to WinCollect V7.2.x, the agent remains configured to

communicate with the QRadar host until you manually update the agent

configuration to communicate with the target Event Collector.

Procedure

Step 1 Download the WinCollect agent update RPM file from the following website to your

QRadar host.

http://www.ibm.com/support

Step 2 Log in to QRadar as the root user.

Step 3 Navigate to the directory with the downloaded WinCollect agent RPM file.

Step 4 Type the following command:

rpm -Uvh filename

For example, type the following command: rpm -Uvh

AGENT-WinCollect-version.noarch.rpm

Step 5 To install the protocol files, type the following command:

yum groupinstall wincollect

IBM Security QRadar WinCollect User Guide

Manually installing a WinCollect agent update 19

Step 6 If you are prompted for configuration, type y.

Step 7 Log in to QRadar.

Step 8 On the Admin tab toolbar, select Deploy Full Configuration.

Step 9 As root user, run the following command: service tomcat restart

Step 10 On the navigation menu, click Data Sources.

Step 11 Click the WinCollect icon.

Step 12 Click Agents.

Step 13 Select the WinCollect agent that you want to update in your deployment.

Step 14 If the agent is disabled, click Enable/Disable Automatic Updates.

WinCollect agents that are enabled for automatic updates are updated and

restarted. The amount of time it takes an agent to update depends on the

configuration polling interval for the WinCollect agent

IBM Security QRadar WinCollect User Guide

5POST INSTALLATION INSTRUCTIONS

FOR WINCOLLECT AGENTS

After you install a WinCollect deployment, you manage your deployment by using

the IBM Security QRadar user interface. You can manage your WinCollect agents,

destinations, and schedules. You can also managed configuration options for

systems with restricted policies.

WinCollect agent

management

The WinCollect agent is responsible for communicating with the individual log

sources, parsing events, and forwarding the event information to QRadar by using

syslog.

After you install the WinCollect agent on your Windows host, wait for QRadar to

automatically discover the WinCollect agent.

The automatic discovery process typically takes a few minutes to complete. The

registration request to the QRadar host might be blocked by firewalls in your

network.

Manually adding a

WinCollect Agent

If you delete your Agent and need to add it back, you can manually add your

WinCollect agent.

Procedure

Step 1 Click the Admin tab.

Step 2 On the navigation menu, click Data Sources.

Step 3 Click the WinCollect icon.

Step 4 Click Agents.

Step 5 Click Add.

Step 6 Configure the parameters.

IBM Security QRadar WinCollect User Guide

22 POST INSTALLATION INSTRUCTIONS FOR WINCOLLECT AGENTS

The following table describes some of the parameters:

Step 7 Click Save.

Step 8 On the Admin tab, click Deploy Changes.

The WinCollect agent is added to the agent list.

Enabling or Disabling

a WinCollect Agent

You can disable a WinCollect agent from the QRadar Console. If you disable a

WinCollect agent, the event forwarder for the WinCollect agent is disabled. This

prevents the agent from forwarding events. Individual log sources in the log source

list show that the log sources are enabled, but no events are collected because the

agent is disabled from forwarding events.

Procedure

Step 1 Click the Admin tab.

Step 2 On the navigation menu, click Data Sources.

Step 3 Click the WinCollect icon.

Step 4 Select the WinCollect agent that you want to enable or disable.

Step 5 Click Enable/Disable.

Table B-1 WinCollect agent parameters

Parameter Description

Description Optional. If you specified an IP address as the name of

the WinCollect agent, add descriptive text to identify the

WinCollect agent or the log sources the WinCollect

agent is managing.

Enabled If selected, events are forwarded from the WinCollect

agent to the QRadar Console for the log sources that

the WinCollect agent manages.

Automatic Updates Enabled Select this check box to allow the QRadar Console to

update the WinCollect agent with software and

configuration updates.

Heart Beat Interval Defines how often the WinCollect agent communicates

its status to the QRadar Console. The interval ranges

from 0 minutes (Off) to 20 minutes.

Configuration Poll Interval Defines how often the WinCollect agent polls the

QRadar Console for updated log source configuration

information or agent software updates. The interval

ranges from 0 minutes (Off) to 20 minutes.

Disk Cache Capacity (MB) Used to buffer events to disk when your event rate

exceeds the event throttle or when the WinCollect

agent is disconnected from the Console.

6 GB might be required if events are stored on a

schedule.

Disk Cache Root Directory The directory where the WinCollect agent stores

cached WinCollect events.

IBM Security QRadar WinCollect User Guide

Destination management 23

Note: If you enable a WinCollect agent, the log sources that are managed by the

WinCollect agent are also enabled. These log sources count toward your log

source license limit. If you exceed your log source license limit, the system

generates a notification.

Deleting a WinCollect

Agent

If you delete a WinCollect agent, the QRadar Console removes the agent from the

agent list and disables all of the log sources that are managed by the deleted

WinCollect agent.

WinCollect agents that were previously automatically discovered are not

rediscovered in WinCollect. To add a deleted WinCollect agent back to the agent

list in the QRadar, you must manually add the deleted agent. For example, if you

delete a WinCollect agent with a host identifier name VMRack1 and reinstall the

agent with the same host identifier name (VMRack1), the WinCollect agent does

not automatically discover the WinCollect agent.

Procedure

Step 1 Click the Admin tab.

Step 2 On the navigation menu, click Data Sources.

Step 3 Click the WinCollect icon.

Step 4 Select the agents that you want to delete.

Step 5 Click Delete.

Step 6 Click OK.

To delete multiple WinCollect agents, press the Ctrl key to select multiple agents,

and then click Delete.

Destination

management

WinCollect destinations define the parameters for how the WinCollect agent

forwards events to the Event Collector or QRadar Console.

A destination allows you to manage how log sources for your WinCollect agents

forward events in your deployment. Destination parameters assigned to a log

source define where events are forwarded. Log sources can use multiple

destinations for forwarding events internally or externally to your deployment.

Internal destinations can include other QRadar Consoles or Event Collectors.

External destinations can include non-aQRadar systems, such as syslog servers

or log management solutions.

Adding a destination

to WinCollect

To assign where WinCollect agents in your deployment forward their events, you

can create destinations for your WinCollect deployment.

Procedure

Step 1 Click the Admin tab.

Step 2 On the navigation menu, click Data Sources.

IBM Security QRadar WinCollect User Guide

24 POST INSTALLATION INSTRUCTIONS FOR WINCOLLECT AGENTS

Step 3 Click the WinCollect icon.

Step 4 Click Destinations.

Step 5 Click Add.

Step 6 Configure the parameters.

The following table describes some of the parameters:

Step 7 Click Save.

Deleting a

destination from

WinCollect

If you delete a destination, the event forwarding parameters are removed from the

WinCollect agent.

Destinations are a global parameter. If you delete a destination when log sources

are assigned to the destination, the WinCollect agent cannot forward events. Event

collection is stopped for a log source when an existing destination is deleted.

Events on disk that were not processed are discarded when the destination is

deleted.

Table B-1 Destination parameters

Parameter Description

Port QRadar can receive events from WinCollect agents on

either UDP or TCP port 514.

Throttle (events per

second)

Defines a limit to the number of events that the

WinCollect agent can send each second.

Queue High Water Mark

(bytes)

Defines an upper limit to the size of the event queue.

If the high water mark limit is reached, the WinCollect

agent attempts to prioritize events to reduce the

number of queued events.

Queue Low Water Mark

(bytes)

Defines a lower limit to the size of the event queue.

If the queue changes from a high water mark to a level

that is at or below the low water mark limit, the event

prioritization returns to normal.

Storage Interval (seconds) Defines an interval before the WinCollect agent writes

events to disk or memory.

Processing Period

(microseconds)

Defines the frequency with which the WinCollect agent

evaluates the events in the forward queue and the

events in the on disk queue. Used to optimize event

processing.

Schedule Mode •If you assign a schedule with the Forward Events

option selected, the WinCollect agent forwards

events within a user-defined schedule. When the

events are not being forwarded, they are stored until

the schedule runs again.

•If the Store Events option is selected, the

WinCollect agent only stores events to disk within a

user-defined schedule and then forwards events to

the destination as specified.

IBM Security QRadar WinCollect User Guide

Schedule management 25

Procedure

Step 1 Click the Admin tab.

Step 2 On the navigation menu, click Data Sources.

Step 3 Click the WinCollect icon.

Step 4 Click Destinations.

Step 5 Select the destination that you want to delete.

Step 6 Click Delete.

Step 7 Click OK.

Schedule

management

WinCollect schedules define when the WinCollect agent forwards events to the

QRadar Event Collector or QRadar Console.

Use a schedule to manage when WinCollect agents forward or store events to disk

in your deployment. Schedules are not required. If a schedule does not exist, the

WinCollect agent automatically forwards events and stores them only if network

limitations causes delay.

You can create schedules for your WinCollect deployment to assign when the

WinCollect agents in your deployment forward their events.

Events that are unable to be sent during the schedule are automatically queued for

the next available interval.

Procedure

Step 1 Click the Admin tab.

Step 2 On the navigation menu, click Data Sources.

Step 3 Click the WinCollect icon.

Step 4 Click Schedules.

Step 5 Click Add.

Step 6 Click Next.

Step 7 Configure the parameters.

Step 8 Select a check box for each day of the week that you want included in the

schedule.

Step 9 Click Next.

Step 10 Optional. From the Available Destinations list, select a destination and click the

selection (>) symbol to add a destination to the schedule.

Step 11 Click Next.

Step 12 Click Finish.

IBM Security QRadar WinCollect User Guide

26 POST INSTALLATION INSTRUCTIONS FOR WINCOLLECT AGENTS

Configuration

options for

systems with

restricted policies

for domain

controller

credentials

To collect events from remote systems without using domain administrator

credentials, alternative configuration options are available.

WinCollect requires credentials based on the type of collection that you are

attempting to use for your WinCollect log sources.

When WinCollect agents collect events from the local host, the event collection

service uses the Local System account credentials to collect and forward events.

Local collection requires that you install a WinCollect agent on a host where local

collection occurs.

Remote collection inside or across a Windows domain might require domain

administrator credentials to ensure that events can be collected. If your corporate

policies restrict the use of domain administrator credentials, you might be required

to complete more configuration steps for your WinCollect deployment.

Local installations

with no remote

polling

You can install WinCollect locally on each host that you cannot remotely poll.

After you install WinCollect, QRadar automatically discovers the agent and you

can create a WinCollect log source. You can specify to use the local system by

selecting the Local System check box in the log source configuration.

Local installations are suitable for domain controllers where the large event per

second (EPS) rates can limit the ability to remotely poll for events from these

systems. A local installation of a WinCollect agent provides scalability for busy

systems that send bursts of events when user activity is at peak levels.

Configuring access

to the registry for

remote polling

You can configure a local policy for your Windows systems to allow a WinCollect

log source to remotely poll for events.

Configure a user account or group with the Manage auditing and security logs

option in their Local Security Policy editor.

When a local policy is configured on each system that you want to remotely poll, a

single WinCollect agent uses the Windows Event Log API to read the remote

registry and retrieve event logs. The Windows Event Log API does not require

domain administrator credentials; however, the Event API method does require an

account that has access to the remote registry and to the security event log.

With this collection method, the log source can remotely read the full event log, but

requires WinCollect to parse the retrieved event log information from the remote

host against cached message content. WinCollect uses version information from

the remote operating system to ensure that the message content is correctly

parsed before it forwards the event to QRadar.

IBM Security QRadar WinCollect User Guide

Configuration options for systems with restricted policies for domain controller credentials 27

Procedure

Step 1 Log on to the Windows computer that you want to remotely poll for events.

Step 2 Select Start > Programs > Administrative Tools, and then click Local Security

Policy.

Step 3 From the navigation menu, select Local Policies > User Rights Assignment.

Step 4 Right-click on Manage auditing and security log and select Properties.

Step 5 From the Local Security Setting tab, click Add User or Group to add your

WinCollect user to the local security policy.

Step 6 Log off of the Windows host and try to poll the remote host for Windows-based

events that belong to your WinCollect log source.

If you cannot collect events for the WinCollect log source, verify that your group

policy does not override your local policy. You can also verify that the local firewall

settings on the Windows host allow remote event log management.

Configuring

Windows event

subscriptions for

WinCollect agents

To provide events to a single WinCollect agent, you can use Microsoft event

subscriptions to forward events on each Windows system to provide events. With

event subscriptions configured, numerous Windows hosts can forward their events

to QRadar without administrator credentials.

To use event subscriptions, you must do these tasks:

1 Configure event subscriptions on your Windows hosts.

2 Configure a log source on the WinCollect agent that receives the events. The

WinCollect log source must have the Local System check box and Forwarded

Events check box selected.

The events collected are defined by the configuration of the event subscription on

the remote host that sends the events. WinCollect forwards all of the events sent

by the subscription configuration, regardless of what event log check boxes are

selected for the log source.

Event subscriptions only apply to WinCollect agents and hosts that are configured

on the following Windows operating systems:

•Windows 8

•Windows 7

•Windows Server 2008 R2

•Windows Server 2012

•Windows Vista

For more information about event subscriptions, see your Microsoft documentation

or the following website: http://technet.microsoft.com/en-us/library/cc749183.aspx.

IBM Security QRadar WinCollect User Guide

6LOG SOURCES FOR WINCOLLECT

AGENTS

A single WinCollect agent can manage and forward events from the local system

or remotely poll a number of Windows-based log sources and operating systems

for their events.

Log sources that communicate through a WinCollect agent can be added

individually. If the log sources contain similar configurations, you can

simultaneously add multiple log sources. A change to an individually added log

source updates only the individual log source. A change made to a group of log

sources updates all of the log sources in the log source group.

Adding a log

source to a

WinCollect agent

You can add a log source to a specific WinCollect agent in your deployment. When

you add a new log source to a WinCollect agent or edit the parameters of a log

source, the WinCollect service is restarted. The events are cached while the

WinCollect service restarts on the agent.

Before you begin

If you want to configure a log source that uses a WinCollect plug-in, you must read

the requirements and perform the necessary steps to prepare the third-party

device. For more information, see WinCollect plug-in requirements.

About this task

Use the Log Filter Type parameter to configure the log source to ignore events

that are filtered by log type. You can also configure WinCollect agents to ignore

events globally by ID code or log source. Exclusion filters for events are available

for the following log types:

•Security

•System

•Application

•DNS Server

•File Replication Service

•Directory Service

Global exclusions use the EventIDCode field from the event payload. To

determine the values that are excluded, source and ID exclusions use the

IBM Security QRadar WinCollect User Guide

30 LOG SOURCES FOR WINCOLLECT AGENTS

Source= field and the EventIDCode= field of the Windows event payload.

Separate multiple sources by using a semi-colon.

Procedure

Step 1 Click the Admin tab.

Step 2 On the navigation menu, click Data Sources.

Step 3 Click the WinCollect icon.

Step 4 Click Agents.

Step 5 Select the WinCollect agent, and click Log Sources.

Step 6 Click Add.

Step 7 Choose one of the following options:

•For a WinCollect log source, select Microsoft Windows Security Event Log

from the Log Source Type list and then select WinCollect from the Protocol

Configuration list.

•If this log source uses a WinCollect plug-in, configure the plug-in specific

parameters. For more information about these parameters, see Configuration

options for log sources that use WinCollect plug-ins.

Step 8 Configure the common parameters.

The following table describes the common parameters:

Table C-1 WinCollect log source parameters

Parameter Description

Log Source Identifier The IP address or host name of a remote Windows

operating system from which you want to collect

Windows-based events. The log source identifier must

be unique for the log source type.

The Log Source Identifier field in a WinCollect log

source is used to poll events from remote sources.

Local System Disables remote collection of events for the log source.

The log source uses local system credentials to collect

and forward events to the QRadar.

Domain The Windows domain that includes the Windows log

source. This parameter is optional.

The following examples use the correct syntax: LAB1,

server1.mydomain.com

The following example uses incorrect

syntax:\\mydomain.com

Application or Service Log

Type

Optional. Used for XPath queries. Provides a

specialized XPath query for products that write their

events as part of the Windows application log. This

allows you to separate Windows events from events

that is classified to a log source for another product.

IBM Security QRadar WinCollect User Guide

Adding a log source to a WinCollect agent 31

Log Filter Type Configures the WinCollect agent to ignore specific

events from the Windows event log.

Forwarded Events Enables QRadar to collect events that are forwarded

from remote Windows event sources that use

subscriptions.

Forward events that use event subscriptions are

automatically discovered by the WinCollect agent and

forwarded as if they are a syslog event source. When

you configure event forwarding from your Windows

system, enable event pre-rendering.

Event Types At least one event type must be selected.

Enable Active Directory

Lookups

If the WinCollect agent is in the same domain as the

domain controller that is responsible for the Active

Directory lookup, you can select this check and leave

the override domain and DNS parameters blank.

Override Domain Controller

Name

The IP address or host name of the domain controller

that is responsible for the Active Directory lookup.

Required when the domain controller that is responsible

for Active Directory lookup is outside of the domain of

the WinCollect agent.

Override DNS Domain

Name

The fully qualified domain name of the DNS server that

is responsible for the Active Directory lookup.

This example shows a fully qualified domain name:

wincollect.com.

Remote Machine Poll

Interval (ms)

The number of milliseconds between queries that poll

remote Windows hosts for new events. The higher the

expected event rate, the more frequently the WinCollect

agent needs to poll remote hosts for events.

•Use 7500 when the WinCollect agent collects events

from a large number of remote computers that have

a low event per second rate, for example, 100

remote computers that provide 10 events per second

or less.

•Use 3500 when the WinCollect agent collects events

from a large number of remote computers that have

a low event per second rate, for example, 50 remote

computers that provide 20 events per second or

less.

•Use 1000 when the WinCollect agent collects events

from a small number of remote computers that have

a high event per second rate, for example, 10

remote computers that provide 100 events per

second or less.

Table C-1 WinCollect log source parameters (continued)

Parameter Description

IBM Security QRadar WinCollect User Guide

32 LOG SOURCES FOR WINCOLLECT AGENTS

Step 9 Click Save.

Step 10 On the Admin tab, click Deploy Changes.

XPath Query Structured XML expressions that you can use to

retrieve customized events from the Windows security

event log.

If you specify an XPath Query to filter events, the check

boxes that you selected from the Standard Log Type

or Event Type are ignored and the events that are

QRadar collects use the contents of the XPath Query.

To collect information by using an XPath Query, you

might be required to enable Remote Event Log

Management on Windows 2008. For more information,

see XPath queries.

Microsoft Server 2003 does not support XPath Queries

for events.

Credibility The credibility indicates the integrity of an event or

offense as determined by the credibility value from the

source devices. Credibility increases if multiple sources

report the same event.

Target Internal Destination Managed hosts with an event processor component in

the Deployment Editor can be the target of an internal

destination.

Target External Destination Forwards your events to one or more external

destinations that you have configured in your

destination list.

Coalescing Events Enables the log source to coalesce (bundle) events.

By default, automatically discovered log sources inherit

the value of the Coalescing Events list from the

System Settings properties in QRadar. However,

when you create or edit a log source, you can select the

Coalescing Events check box to coalesce events for

an individual log source.

Store Event Payload Enables the log source to store event payload

information.

By default, automatically discovered log sources inherit

the value of the Store Event Payload list from the the

System Settings properties in QRadar. However,

when you create or edit a log source, you can select the

Store Event Payload check box to retain the event

payload for an individual log source.

Table C-1 WinCollect log source parameters (continued)

Parameter Description

IBM Security QRadar WinCollect User Guide

Configuration options for log sources that use WinCollect plug-ins 33

Configuration

options for log

sources that use

WinCollect plug-ins

Each WinCollect plug-in has a unique set of configuration options. Use this

reference to configure the plug-in specific log source parameters.

Microsoft DHCP log

source configuration

options

The following table describes the log source configuration options for the Microsoft

DHCP plug-in:

Microsoft IAS log

source configuration

options

The following table describes the log source configuration options for the Microsoft

IAS plug-in:

Table C-2 Protocol parameters for WinCollect Microsoft DHCP

Parameter Description

Log Source Type Microsoft DHCP

Protocol Configuration WinCollect Microsoft DHCP

Local System To collect local events, the WinCollect agent must be

installed on the same host as your Microsoft DHCP

Server. The log source uses local system credentials to

collect and forward events to the QRadar.

Folder Path The directory path to your DHCP event logs.

•For a local directory path, use

c:\WINDOWS\system32\dhcp

•For a remote directory path, use \\DHCP IP

address\c$\Windows\System32\dhcp

File Pattern Type the regular expression (regex) required to filter

the filenames. All files that match the pattern are

included in the processing. The default file pattern is .*

and matches all files in the Folder Path field.

Table C-3 Protocol parameters for WinCollect Microsoft IAS

Parameter Description

Log Source Type Microsoft IAS Server

Protocol Configuration WinCollect Microsoft IAS / NPS

Local System To collect local events, the WinCollect agent must be

installed on the same host as your Microsoft IAS server.

The log source uses local system credentials to collect

and forward events to the QRadar.

Root Directory The directory path to your IAS event logs.

•For a local directory path, use

%WINDIR%\System32\Logfiles

•For a remote directory path, use \\<IAS

IP>\c$\Windows\System32\Logfiles

IBM Security QRadar WinCollect User Guide

34 LOG SOURCES FOR WINCOLLECT AGENTS

Microsoft ISA log

source configuration

options

The following table describes the log source configuration options for the Microsoft

ISA plug-in:

File Monitor Policy •Notification-based (local) uses the Windows file

system notifications to detect changes to your event

log.

•Polling-based (remote) monitors changes to

remote files and directories. The agent polls the

remote event log and compares the file to the last

polling interval. If the event log contains new events,

the event log is retrieved.

Polling Interval The polling interval, which is the amount of time

between queries to the root log directory for new

events.

Table C-3 Protocol parameters for WinCollect Microsoft IAS (continued)

Parameter Description

Table C-4 Protocol parameters for WinCollect Microsoft ISA

Parameter Description

Log Source Type Microsoft ISA

Protocol Configuration WinCollect Microsoft ISA / Forefront TMG

Local System To collect local events, the WinCollect agent must be

installed on the same host as your Microsoft ISA or

Forefront TMG server. The log source uses local

system credentials to collect and forward events to the

QRadar.

IBM Security QRadar WinCollect User Guide

Configuration options for log sources that use WinCollect plug-ins 35

File Forwarder log

source configuration

parameters

The following table describes the log source configuration options for the File

Forwarder plug-in:

Root Directory The directory path to your ISA event logs.

When you specify a remote file path, use a dollar

sign ($) instead of a colon (:) to represent your drive

name.

Microsoft ISA 2004

•For a local directory path, use <Program

Files>\MicrosoftISAServer\ISALogs\

•For a remote directory path, use \<ISA server

IP>\<Program

Files>\MicrosoftISAServer\ISALogs\

Microsoft ISA 2006

•For a local directory path, use

%systemroot%\LogFiles\ISA\

•For a remote directory path, use \<ISA server

IP>\%systemroot%\LogFiles\ISA\

Microsoft Threat Management Gateway

•For a local directory path, use <Program

Files>\<Forefront Directory>\ISALogs\

•For a remote directory path, use \\<ISA server

IP>\<Program Files>\<Forefront

Directory>\ISALogs\

File Monitor Policy •Notification-based (local) uses the Windows file

system notifications to detect changes to your event

log.

•Polling-based (remote) monitors changes to

remote files and directories. The agent polls the

remote event log and compares the file to the last

polling interval. If the event log contains new events,

the event log is retrieved.

Polling Interval The amount of time between queries to the root log

directory for new events.

Table C-4 Protocol parameters for WinCollect Microsoft ISA (continued)

Parameter Description

Table C-5 File Forwarder protocol parameters

Parameter Description

Log Source Type Universal DSM

Protocol Configuration WinCollect File Forwarder

Local System Disables remote collection of events for the log source.

The log source uses local system credentials to collect

and forward events to the QRadar.

IBM Security QRadar WinCollect User Guide

36 LOG SOURCES FOR WINCOLLECT AGENTS

Microsoft IIS log

source configuration

options

The following table describes the log source configuration options for the Microsoft

IIS plug-in:

Root Directory The location of the log files to forward to QRadar.

If the WinCollect agent remotely polls for the file, the

root log directory must specify both the server and the

folder location for the log files. For example,

\\server\sharedfolder\remotelogs\.

File Pattern The regular expression (regex) required to filter the file

names. All matched files are included in the processing.

The default file pattern is .* and matches all files in the

Root Directory field.

Monitoring Algorithm •Continuous Monitoring is intended for files

systems that append data to log files.

•File Drop is used for the log files in the root log

directory that are read one time, and then ignored in

the future.

File Monitor Type •Notification-based (local) uses the Windows file

system notifications to detect changes to your event

log.

•Polling-based (remote) monitors changes to

remote files and directories. The agent polls the

remote event log and compares the file to the last

polling interval. If the event log contains new events,

the event log is retrieved.

File Reader Type •Text (file held open) - The system that generates

your event log continually leaves the file open to

append events to the end of the file.

•Text (file open when reading) - The system that

generates your event log opens the event log from

the last known position, and then writes events and

closes the event log.

•Memory Mapped Text (local only) - Select this

option only when advised by Professional Services.

This option is used when the system that generates

your event log polls the end of the event log for

changes. This option requires the Local System

check box to be selected.

Table C-5 File Forwarder protocol parameters (continued)

Parameter Description

Table C-6 Protocol parameters for WinCollect Microsoft IIS

Parameter Description

Log Source Type Microsoft IIS

Protocol Configuration WinCollect Microsoft IIS

IBM Security QRadar WinCollect User Guide

Configuration options for log sources that use WinCollect plug-ins 37

Microsoft SQL log

source configuration

options

The following table describes the log source configuration options for the Microsoft

SQL plug-in:

Root Directory The directory path to your Microsoft IIS log files.

•For Microsoft IIS 6.0 (full site), use

%SystemRoot%\LogFiles

•For Microsoft IIS 6.0 (individual site), use

%SystemRoot%\LogFiles\site name

•For Microsoft 7.0-8.0 (full site), use

%SystemDrive%\inetpub\logs\LogFiles

•For Microsoft IIS 7.0-8.0 (individual site), use

%SystemDrive%\inetpub\logs\LogFiles\site name

Polling Interval The amount of time between queries to the root log

directory for new events.

Protocol Logs Specifies what items to collect from Microsoft IIS.

Select one or more of the following options:

•FTP

•NNTP/News

•SMTP/Mail

•W3C

Table C-6 Protocol parameters for WinCollect Microsoft IIS (continued)

Parameter Description

Table C-7 Protocol parameters for WinCollect Microsoft SQL

Parameter Description

Log Source Type Microsoft SQL

Protocol

Configuration

WinCollect Microsoft SQL

IBM Security QRadar WinCollect User Guide

38 LOG SOURCES FOR WINCOLLECT AGENTS

Adding multiple log

sources

You can add multiple log sources at one time to QRadar. The log sources must

share a common configuration protocol and be associated with the same

WinCollect agent.

You can upload a text file that contains a list of IP addresses or host names, run a

query against a domain controller to get a list of hosts, or manually input a list of IP

Root Directory The directory path to your SQL event logs.

Microsoft SQL 2000

•For a local directory path, use C:\Program

Files\Microsoft SQL Server\Mssql\Log

•For a remote directory path, use \\SQL IP

address\c$\Program Files\Microsoft SQL

Server\Mssql\Log

Microsoft SQL 2005

•For a local directory path, use c:\Program

Files\Microsoft SQL

Server\MSSQL.1\MSSQL\LOG\

•For a remote directory path, use \\SQL IP

address\c$\Program Files\Microsoft SQL

Server\MSSQL.1\MSSQL\LOG\

Microsoft SQL 2008

•For a local directory path, use C:\Program

Files\Microsoft SQL

Server\MSSQL10.MSSQLSERVER\MSSQL\Log\

•For a remote directory path, use \\SQL IP

address\c$\Program Files\Microsoft SQL

Server\MSSQL10.MSSQLSERVER\MSSQL\Log\

Microsoft SQL 2008R2

•For a local directory path, use C:\Program

Files\Microsoft SQL

Server\MSSQL10_50.MSSQLSERVER\MSSQL\Log

•For a remote directory path, use \\SQL IP

address\c$\Program Files\Microsoft SQL

Server\MSSQL10_50.MSSQLSERVER\MSSQL\Log

Log File Name The name of the file that contains the SQL error log.

File Monitor Policy •Notification-based (local) uses the Windows file system

notifications to detect changes to your event log.

•Polling-based (remote) monitors changes to remote files

and directories. The agent polls the remote event log and

compares the file to the last polling interval. If the event log

contains new events, the event log is retrieved.

Table C-7 Protocol parameters for WinCollect Microsoft SQL (continued)

Parameter Description

IBM Security QRadar WinCollect User Guide

Adding multiple log sources 39

addresses or host names by typing them in one at a time.

Depending on the number of WinCollect log sources that you add at one time, it

can time for the WinCollect agent to access and collect all Windows events from

the log source list.

Procedure

Step 1 Click the Admin tab.

Step 2 On the navigation menu, click Data Sources.

Step 3 Click the WinCollect icon.

Step 4 Select the WinCollect agent, and click Log Sources.

Step 5 From the Bulk Actions menu, select Bulk Add.

Step 6 Configure values for your log sources.

Step 7 Select one of the following methods to bulk import log sources:

•Select the File Upload tab and then select a text file IP addresses or host

names of log sources that you want to add. The maximum number of log

sources you can add is 500.

The text file must contain one IP address or host name per line. Extra

characters after an IP address or host names longer than 255 characters result

in an error. As a result a log source from the host list might not be added.

•Select the Domain Controller tab and then type the IP address and full domain

name for the domain controller. To search a domain, you must add the domain,

user name, and password for the log source before you poll the domain for

hosts to add.

•Select the Manual tab and then type an IP address or host name to add to the

host list. Click Add Host.

Step 8 Click Save.

Step 9 Click Continue.

The log sources are added to your WinCollect agent.

IBM Security QRadar WinCollect User Guide

7WINCOLLECT PLUG-IN

REQUIREMENTS

Some log sources require a WinCollect plug-in to support communication between

your WinCollect agent and the Microsoft Windows servers. Each plug-in has a

unique set of requirements and instructions.

All plug-ins are available for download from the IBM support website

(https://www.ibm.com/support).

WinCollect plug-ins support the following server versions:

Table D-1 Supported server versions for WinCollect plug-ins

Plug-in Supported servers

Microsoft DHCP Microsoft DHCP Server 2003

Microsoft DHCP Server 2008

Microsoft DHCP Server 2012

Microsoft IAS Windows 2003 operating systems with Microsoft IAS

Server 2003 enabled

Windows 2008 operating systems with Microsoft

Network Policy Server 2008 enabled

Windows 2012 operating systems with Microsoft

Network Policy Server 2012 enabled

Microsoft ISA Microsoft ISA Server 2004

Microsoft ISA Server 2006

Microsoft Forefront Threat Management Gateway

2010

Microsoft IIS Microsoft IIS Server 6.0

Microsoft IIS Server 7.0

Microsoft IIS Server 7.5

Microsoft IIS Server 8.0

Microsoft SQL Microsoft SQL Server 2000

Microsoft SQL Server 2003

Microsoft SQL Server 2008

Microsoft SQL Server 2008R2

IBM Security QRadar WinCollect User Guide

42 WINCOLLECT PLUG-IN REQUIREMENTS

Microsoft DHCP

plug-in

requirements

WinCollect agents support local collection and remote polling for Microsoft DHCP

Server installations.

To remotely poll for Microsoft DHCP Server events, you must provide administrator

credentials or domain administrator credentials. If your network policy restricts the

use of administrator credentials, you can install a WinCollect agent on the same

host as your Microsoft DHCP Server. Local installations of WinCollect do not

require special credentials to forward DHCP events to QRadar.

The DHCP event logs that are monitored by WinCollect are defined by the

directory path you specify in your WinCollect DHCP log source.

WinCollect evaluates the root log directory folder to automatically collect new

DHCP events that are written to the event log. As described in the following table,

DHCP event logs start with DHCP, contain a three-character day of the week

abbreviation, and end with .log. DHCP log files in the root log directory that match

either an IPv4 or IPv6 DHCP log format is monitored for new events by the

WinCollect agent.

Log files that do not match the DHCP event log format are not parsed or forwarded

to QRadar.

Enabling DHCP event

logs on your

Microsoft Windows

Server

To write DHCP events to a file for WinCollect, you must enable DHCP event logs

on your Microsoft Windows Server.

Procedure

Step 1 Log in to your Microsoft Windows Server.

Step 2 Click Control Panel > Administrative Tools > DHCP.

Step 3 Choose one of the following options:

•Windows Server 2003 - Right-click on your DHCP server and select

Properties.

•Microsoft Server 2008R2 and above - Right-click on IPv4 or IPv6 and select

Properties.

Step 4 Click the General tab.

Step 5 Click Enable DHCP Audit Logging.

Step 6 Click Apply.

Step 7 Click OK.

Table D-2 Example log format for Microsoft DHCP events

Log type Example log file format

IPv4 DhcpSrvLog-Mon.log

IPv6 DhcpV6SrvLog-Wed.log

IBM Security QRadar WinCollect User Guide

Microsoft IAS and NPS plug-in requirements 43

Windows 2008R2 Servers use DHCP logs that are enabled independently. You

might be required to repeat this procedure to enable both IPv4 and IPv6 audit logs.

Microsoft IAS and

NPS plug-in

requirements

The Microsoft Internet Authentication Service (IAS) plug-in for WinCollect forwards

RADIUS and authentication, authorization, and accounting (AAA) events from

Microsoft IAS or Network Policy (NPS) Servers to IBM Security QRadar.

Configuring the

Microsoft IAS plug-in

for WinCollect

WinCollect agents support local event collection and remotely poll for Microsoft

IAS and NPS events that log to a file.

To configure a WinCollect plug-in for Microsoft IAS, do these steps:

1 On your Microsoft IAS or NPS server, configure the system to generate W3C event

logs.

2 On your QRadar Console, install the WinCollect plug-in for the Microsoft IAS

protocol.

3 On your QRadar Console, configure a WinCollect log source to collect event logs.

4 On your QRadar Console, verify that the events are forwarded from your

WinCollect agent.

5 If you do not receive events or status messages, verify that the WinCollect agent

can communicate by either TCP or UDP on port 514 to the QRadar Console or

QRadar Event Collector.

Microsoft IAS or NPS

server log formats

Microsoft IAS and NPS installations write RADIUS and authentication events to a

common log directory.

To collect these events with WinCollect, you must configure Microsoft IAS or

Microsoft NPS to write an event log file to a directory.

WinCollect supports the following event log formats:

•Data Transformation Service (DTS)

•Open Database Connectivity (ODBC)

•Internet Authentication Service (IAS)

Microsoft IAS

directory structure

for event collection

The event logs that are monitored by WinCollect are defined by the configuration

of the root directory in your log source.

When you specify a root log directory, you must point the WinCollect agent to the

folder that contains Microsoft ISA or NPS events. The root log directory does not

recursively search sub-directories for event files.

To increase performance you can create a sub folder for your IAS and NPS event

logs. For example, you can create a directory similar to the following:

\Windows\System32\Logfiles\NPS. When you create a specific event folder

IBM Security QRadar WinCollect User Guide

44 WINCOLLECT PLUG-IN REQUIREMENTS

the agent does not have to evaluate a large number of files to locate your event

logs.

If your system generates large amounts of IAS or NPS events, you can configure

your Windows system to create a new event log at daily intervals. Creating new

logs ensures that the agent does not have to search large logs for new events.

Microsoft ISA

plug-in

requirements

The WinCollect plug-in for Microsoft Internet Security and Acceleration (ISA)

forwards network proxy and firewall events from Microsoft ISA or Microsoft

Forefront Threat Management Gateway (TMG) servers to IBM Security QRadar.

Configuring the

Microsoft ISA plug-in

WinCollect agents support local event collection and remotely poll for Microsoft

ISA and TMG events that log to a file.

To configure a WinCollect plug-in for Microsoft ISA, do these steps:

1 On your Microsoft ISA or TMG server, configure the system to generate W3C

event logs.

2 On your QRadar Console, install the WinCollect plug-in for the Microsoft ISA

protocol.

3 On your QRadar Console, configure a WinCollect log source to collect event logs.

4 On your QRadar Console, verify that the events are forwarded from your

WinCollect agent.

5 If you do not receive events or status messages, verify that the WinCollect agent

can communicate by either TCP or UDP on port 514 to the QRadar Console or

QRadar Event Collector.

IBM Security QRadar WinCollect User Guide

Microsoft ISA plug-in requirements 45

Supported Microsoft

ISA or TMG server

log formats

Microsoft ISA and Forefront Threat Management Gateway installations create

individual firewall and web proxy event logs in a common log directory. To collect

these events with WinCollect, you must configure your Microsoft ISA or Microsoft

TMG to write event logs to a log directory.

WinCollect supports the following event log formats:

•Web proxy logs in WC3 format (w3c_web)

•Microsoft firewall service logs in WC3 format (w3c_fws)

•Web Proxy logs in ISA format (isa_web)

•Microsoft firewall service logs in ISA format (isa_fws)

The W3C event format is the preferred event log format. The W3C format contains

a standard header with the version information and all of the fields that are

expected in the event payload. You can customize the W3C event format for the

firewall service log and the web proxy log to include or exclude fields from the

event logs.

You can use the default W3C format fields. If the W3C format is customized, the

following fields are required to properly categorize events:

Table D-1 W3C format required fields

Required field Description

Client IP (c-ip) Source IP address

Action Action that is taken by the firewall

Destination IP (r-ip) Destination IP address

Protocol (cs-protocol) Application protocol name, for example,

HTTP or FTP

Client user name (cs-username) User account that made the data request of

the firewall service

Client user name (username) User account that made the data request of

the web proxy service

IBM Security QRadar WinCollect User Guide

46 WINCOLLECT PLUG-IN REQUIREMENTS

Microsoft ISA

directory structure

for event collection

The event logs that are monitored by WinCollect are defined by the configuration

of the root directory in your log source.

WinCollect evaluates the directory folder and recursively searches the subfolders

of the root log directory to determine when new events are written to the event log.

By default, the WinCollect plug-in polls the root log directory for updated event logs

every five seconds.

File Forwarder

plug-in

requirements

With the WinCollect plug-in for File Forwarder, WinCollect agents can collect and

forward event logs for Windows appliances or software.

Use the plug-in to configure a root directory that the WinCollect agent can monitor

for Windows-based event log files.

After you configure your device, you can map your File Forwarder to a syslog

destination. WinCollect evaluates the root log directory to determine when file

changes occur.

The log files that are read by the plug-in must be text-based, single-line events.

Multi-line events are not supported. The File Forwarder plug-in requires a

Universal DSM to parse and categorize events.

Microsoft IIS

plug-in

requirements

With the WinCollect plug-in for Microsoft Internet Information Server (IIS),

WinCollect agents can parse local event logs from your Microsoft IIS server and

forward IIS events to IBM Security QRadar.

To collect Microsoft IIS events, a WinCollect agent must be installed on your

Microsoft IIS server. Remote polling for Microsoft IIS events is not supported by the

WinCollect plug-in for Microsoft IIS.

Microsoft Internet Information Services (IIS) includes a range of administrative

features for website management. You can monitor attempts to access your

websites to determine whether attempts were made to read or write to your files.

You can create a single Microsoft IIS log source to record events from your entire

website directory or individual websites.

The Microsoft IIS device plug-in can read and forward events for the following logs:

•Website (W3C) logs

•File Transfer Protocol (FTP) logs

•Simple Mail Transfer Protocol (SMTP) logs

•Network News Transfer Protocol (NNTP) logs

The WinCollect plug-in can monitor W3C, IIS, and NCSA formatted event logs.

However, the IIS and NCSA event formats do not contain as much event

information in their event payloads as the W3C event format. To collect the

maximum information that is available, you can configure your Microsoft IIS server

IBM Security QRadar WinCollect User Guide

Microsoft SQL Server plug-in 47

to write events in W3C format. WinCollect can collect both ASCII and UTF-8

encoded event log files.

Microsoft IIS

directory structure

for event collection

WinCollect can monitor your entire IIS directory structure.

The sites and event logs that are monitored by WinCollect are defined by the

configuration of the root directory in your log source. When you specify a root log

directory, WinCollect evaluates the directory folder and all subfolders to determine

when new events are written to the event log. When you monitor the IIS root

website, WinCollect can use one log source to collect all of your IIS server events.

If you want to monitor individual websites, you must configure a log source for

each website in your directory. You can configure the log source for the individual

website to monitor the root log directory in your IIS directory structure.

By default, Microsoft IIS installations update event logs every 30 seconds.

Depending on the number of sites that you monitor, you might notice that your

WinCollect agent uses more resources during event log update intervals.

Microsoft SQL

Server plug-in

You can use the WinCollect plug-in for Microsoft SQL Server to parse event logs

from the Microsoft SQL Server and forward the event information to IBM Security

QRadar.

The error log is a standard text file that contains SQL Server information and error

messages.

WinCollect monitors the SQL error log for new events and forwards the event to

QRadar. The error log can provide meaningful information to help you to

troubleshoot issues or alert you to potential or existing problems. The error log

output includes the time and date that the message was logged, the source of the

message, and the description of the message. If an error occurs, the log contains

the error message number and a description. Microsoft SQL Server retains

backups of the last six error log files.

WinCollect can collect SQL error log events. To collect Microsoft SQL Server audit

and authentication events, you can configure the Microsoft SQL Server DSM. For

more information, see the IBM Security QRadar DSM Configuration Guide.

WinCollect agents support local collection and remote polling for Microsoft SQL

Server installations. To remotely poll for Microsoft SQL Server events, you must

provide administrator credentials or domain administrator credentials. If your

network policy restricts the use of administrator credentials, you can install a

WinCollect agent on the same host as your Microsoft SQL Server. Local

installations of WinCollect do not require special credentials to forward SQL events

to QRadar.

IBM Security QRadar WinCollect User Guide

8XPATH QUERIES

An XPath query is a log source parameter that filters specific events when the

query communicates with a Windows 2008-based event log.

XPath queries use XML notation and are available in QRadar when you retrieve

events by using the WinCollect protocol. The most common method of creating an

XPath query is to use Microsoft Event Viewer to create a custom view. The custom

view that you create for specific events in Event Viewer can generate XPath

notations. You can then copy this generated XPath notation in your XPath query to

filter your incoming log source events for specific event data.

Note: To manually create your own XPath queries, you must be proficient with

XPath 1.0 and XPath queries.

Enabling remote

log management on

a Windows

operating system

Enables remote log management only when your log source is configured to

remotely poll other Windows systems.

Local system log sources that use XPath queries do not require a remote log

management firewall exception for locally collected events.

Windows 2008 You can enable remote log management on Windows Server 2008 for XPath

queries.

Procedure

Step 1 On your desktop, select Start > Control Panel.

Step 2 Click the Security icon.

Step 3 Click Allow a program through Windows Firewall.

Step 4 If prompted by User Account Control, click Continue.

Step 5 From the Exceptions tab, select Remote Event Log Management.

Step 6 Click OK.

IBM Security QRadar WinCollect User Guide

50

Windows 2008R2 You can enable remote log management on Windows Server 2008R2 for XPath

queries.

Procedure

Step 1 On your desktop, select Start > Control Panel.

Step 2 Click the Windows Firewall icon.

Step 3 From the menu, click Allow a program or feature through Windows Firewall.

Step 4 If prompted by User Account Control, click Continue.

Step 5 Click Change Settings.

Step 6 From the Allowed programs and features pane, select the Remote Event Log

Management check box.

This also selects a check box for a network type. Depending on your network, you

might need to correct or select additional network types.

Step 7 Click OK.

Windows 7 You can enable remote log management on Windows 7 for XPath queries.

Procedure

Step 1 On your desktop, select Start > Control Panel.

Step 2 Click the System and Security icon.

Step 3 From the Windows Firewall pane, click Allow a program through Windows

Firewall.

Step 4 If prompted by User Account Control, click Continue.

Step 5 Click Change Settings.

Step 6 From the Allowed programs and features pane, select the Remote Event Log

Management check box.

Depending on your network, you might need to correct or select additional network

types.

Step 7 Click OK.

IBM Security QRadar WinCollect User Guide

Creating a custom view 51

Creating a custom

view

Use the Microsoft Event Viewer to create custom views, which can filter events for

severity, source, category, keywords, or specific users.

WinCollect supports up to 10 selected event logs in the XPath query. Event IDs

that are suppressed do not contribute towards the limit.

WinCollect log sources can use XPath filters to capture specific events from your

logs. To create the XML markup for your XPath Query parameter, you must create

a custom view. You must log in as an administrator to use Microsoft Event Viewer.

XPath queries that use the WinCollect protocol the TimeCreated notation do not

support filtering of events by a time range. Filtering events by a time range can

lead to errors in collecting events.

Procedure

Step 1 On your desktop, select Start > Run.

Step 2 Type the following command:

Eventvwr.msc

Step 3 Click OK.

Step 4 If you are prompted, type the administrator password and press Enter.

Step 5 On the Action menu, select Create Custom View.

When you create a custom view, do not select a time range from the Logged list.

The Logged list includes the TimeCreated element, which is not supported in

XPath queries for the WinCollect protocol.

Step 6 In Event Level, select the check boxes for the severity of events that you want to

include in your custom view.

Step 7 Select an event source:

Step 8 Type the event IDs to filter from the event or log source.

Use commas to separate IDs. for example, the following list contains an individual

ID and a range: 4133, 4511-4522.

Step 9 From the Task Category list, select the categories to filter from the event or log

source.

Step 10 From the Keywords list, select the keywords to filter from the event or log source.

Step 11 Type the user name to filter from the event or log source.

Step 12 Type the computer or computers to filter from the event or log source.

Step 13 Click the XML tab.

Step 14 Copy and paste the XML to the XPath Query field of your WinCollect log source

configuration.

Note: If you specify an XPath query for your log source, only the events that are

specified in the query are retrieved by the WinCollect protocol and forwarded to

IBM Security QRadar WinCollect User Guide

52

QRadar. Check boxes that you select from the Standard Log Type or Event Type

are ignored by the log source configuration.

What to do next

Configure a log source with the XPath query.

Adding an XPath

log source

You can create a log source that includes the XPath query from the Event Viewer.

Procedure

Step 1 Click the Admin tab.

Step 2 On the navigation menu, click Data Sources.

Step 3 Click the WinCollect icon.

Step 4 Click Agents.

Step 5 Select the WinCollect agent, and click Log Sources.

Step 6 Click Add.

Step 7 From the Log Source Type list, select Microsoft Windows Security Event Log.

Step 8 From the Protocol Configuration list, select WinCollect.

Step 9 Configure the parameters:

Table E-1 WinCollect log source parameters

Parameter Description

Log Source Identifier The IP address or host name of a remote Windows

operating system from which you want to collect

Windows-based events. The log source identifier must

be unique for the log source type.

The Log Source Identifier field in a WinCollect log

source is used for polling events from remote sources.

This field is used in the same manner as the

RemotMachine field in the Adaptive Log Exporter.

Local System Disables remote collection of events for the log source.

The log source uses local system credentials to collect

and forward events to the QRadar.

Domain The Windows domain that includes the Windows log

source. This parameter is optional.

The following examples use the correct syntax: LAB1,

server1.mydomain.com

The following example uses incorrect

syntax:\\mydomain.com

Standard Log Types Clear all of the log type check boxes.

The XPath query defines the log types for the log

source.

Forwarded Events Clear this check box.

IBM Security QRadar WinCollect User Guide

Adding an XPath log source 53

Step 10 Click Save.

Step 11 On the Admin tab, click Deploy Changes.

Event Types Clear this check box. The XPath query defines the log

types for the log source.

Enable Active Directory

Lookups

If the WinCollect agent is in the same domain as the

domain controller that is responsible for the Active

Directory lookup, you can select this check and leave

the override domain and DNS parameters blank.

Override Domain Controller

Name

The IP address or host name of the domain controller

that is responsible for the Active Directory lookup.

Required when the domain controller that is responsible

for Active Directory lookup is outside of the domain of

the WinCollect agent.

Override DNS Domain

Name

The fully qualified domain name of the DNS server that

is responsible for the Active Directory lookup.

For example, the following domain name uses the

correct syntax: wincollect.com.

WinCollect Agent The WinCollect agent to manage this log source.

Remote Machine Poll

Interval (ms)

The number of milliseconds between queries to the

remote Windows host to poll for new events. The higher

the expected event rate, the more frequently the

WinCollect agent needs to poll remote hosts for events.

•Use 7500 when the WinCollect agent collects events

from a large number of remote computers that have

a low event per second rate, for example, 100

remote computers that provide 10 events per second

or less.

•Use 3500 when the WinCollect agent collects events

from a large number of remote computers that have

a low event per second rate, for example, 50 remote

computers that provide 20 events per second or

less.

•Use 1000 when the WinCollect agent collects events

from a small number of remote computers that have

a high event per second rate, for example, 10

remote computers that provide 100 events per

second or less.

XPath Query The XPath query that you defined in Microsoft Event

Viewer.

To collect information by using an XPath query, you

might be required to enable Remote Event Log

Management on Windows 2008.

Note: Microsoft Server 2003 does not support XPath

Queries for events.

Table E-1 WinCollect log source parameters (continued)

Parameter Description

IBM Security QRadar WinCollect User Guide

54

XPath query

examples

Use these XPath examples as a reference when you create XPath queries. For

more information about XPath queries, see your Microsoft documentation.

Example: Monitor

events for a specific

user

In this example, the query retrieves events from all Windows event logs for the

guest user.

<QueryList>

<Query Id="0" Path="Application">

<Select Path="Application">*[System[(Level=4 or Level=0) and

Security[@UserID='S-1-5-21-3709697454-1862423022-1906558702-501

']]]</Select>

<Select Path="Security">*[System[(Level=4 or Level=0) and

Security[@UserID='S-1-5-21-3709697454-1862423022-1906558702-501

']]]</Select>

<Select Path="Setup">*[System[(Level=4 or Level=0) and

Security[@UserID='S-1-5-21-3709697454-1862423022-1906558702-501

']]]</Select>

<Select Path="System">*[System[(Level=4 or Level=0) and

Security[@UserID='S-1-5-21-3709697454-1862423022-1906558702-501

']]]</Select>

<Select Path="ForwardedEvents">*[System[(Level=4 or Level=0) and

Security[@UserID='S-1-5-21-3709697454-1862423022-1906558702-501

']]]</Select>

</Query>

</QueryList>

Credential logon for

Windows 2008

In this example, the query retrieves specific event IDs from the security log for

Information-level events that are associated with the account authentication in

Windows 2008.

<QueryList>

<Query Id="0" Path="Security">

<Select Path="Security">*[System[(Level=4 or Level=0) and

( (EventID &gt;= 4776 and EventID &lt;= 4777) )]]</Select>

</Query>

</QueryList>

In this example, the query examines event IDs to retrieve specific events for a user

account that is created on a fictional computer that contains a user password

database.

Table E-1 Event IDs in this example

ID Description

4776 The domain controller attempted to validate

credentials for an account.

4777 The domain controller failed to validate credentials

for an account.

IBM Security QRadar WinCollect User Guide

XPath query examples 55

<QueryList>

<Query Id="0" Path="Security">

<Select Path="Security">*[System[(Computer='Password_DB') and

(Level=4 or Level=0) and (EventID=4720 or (EventID &gt;= 4722

and EventID &lt;= 4726) or (EventID &gt;= 4741 and EventID

&lt;= 4743) )]]</Select>

</Query>

</QueryList>

Table E-2 Event IDs in this example

ID Description

4720 A user account was created.

4722 A user account was enabled.

4723 An attempt was made to change the password of an

account.

4724 An attempt was made to reset password of an

account.

4725 A user account was disabled.

4726 A user account was deleted.

4741 A computer account was created.

4742 A computer account was changed.

4743 A computer account was deleted.

IBM Security QRadar WinCollect User Guide

ATROUBLESHOOTING A WINCOLLECT

AGENT

Log files created by the WinCollect agent during configuration or installation

contain error messages and other valuble information. To determine the root cause

of your error, review the error logs.

The WinCollect agent creates an installation log file during the installation process

for both standard and command-line installations.

The Status parameter might indicate that there is an issue with a WinCollect

agent. The Status parameter is located in the WinCollect window in IBM Security

QRadar SIEM. The WinCollect agent might report the following statuses:

•Running indicates that the WinCollect agent is active on the Windows host.

•Stopped indicates that the WinCollect agent is stopped. If the WinCollect

service is stopped, events from the log sources that are managed by the agent

are not forwarded to the QRadar Console.

•Unavailable indicates that the WinCollect service that reports on the status of

the WinCollect agent is stopped or restarted. The services can no longer report

the agent status.

•No Communication from Agent indicates that the WinCollect agent has not

established communication with the QRadar Console. If you manually added

the WinCollect agent, verify that the Host Name parameter is correct. Also

verify that firewalls in your deployment are not blocking communication

between the WinCollect agent and the Event Collector or QRadar Console.

You can also view the installation log for error information about your WinCollect

agent installation.

Procedure

Step 1 Log in to the host of your WinCollect agent.

Step 1 On the desktop, select Start > Run.

Step 2 Type the following:

%TEMP%

Step 3 Click OK.

The Windows Explorer displays the temporary directory.

Step 4 Open the WinCollect installation log from the temporary directory.

Setup Log <Date> <#00X>.txt

Step 5 Review the log file to determine the cause of the installation failure.

IBM Security QRadar WinCollect User Guide

58

Installation log

examples

The installation log captures the install process for WinCollect and includes

information about the installation failure. The information contained in the setup log

file is required to troubleshoot WinCollect installations with Customer Support.

Example: Missing

authorization or

Console IP address

The following text shows the error message generated when the AUTH_TOKEN or

CONFIG_CONSOLE_ADDRESS is missing from the command-line installation:

ERROR: Installation was aborted because only one of /AUTH_TOKEN

and /CONFIG_CONSOLE_ADDRESS were specified. Both must be

specified (for remote configuration management) or neither

specified (for stand-alone operation)

Example: Installation

stopped by user

The following text shows the message generated when a standard installation is

stopped by the user:

Message box (Yes/No):

Setup is not complete. If you exit now, the program will not be

installed.

You may run Setup again at another time to complete the

installation.

Exit Setup?

Example: Installation

file in use error

The WinCollect agent cannot be installed while the WinCollect service is running.

To avoid an installation issue, stop the WinCollect service before you attempt to

reinstall the WinCollect agent on your host. The following text displays the

message error message when an installation file is in use:

Defaulting to Abort for suppressed message box

(Abort/Retry/Ignore):

C:\Program Files (x86)\WinCollect\bin\WinCollect.exe

An error occurred while trying to replace the existing file:

DeleteFile failed; code 5.

Access is denied.

Click Retry to try again, Ignore to skip this file (not

recommended), or Abort to cancel installation.

IBM Security QRadar WinCollect User Guide

Troubleshooting device configuration issues 59

Troubleshooting

device

configuration

issues

The WinCollect agent creates a device log that stores configuration information

and warnings about log sources that are configured for each WinCollect agent.

Each time the WinCollect service is restarted or the date changes, a new log is

created on the Windows host for the WinCollect agent. All device logs contain time

stamps to help you find the most recent log file.

The device log captures log source configuration information for WinCollect and

includes information about log source issues.

Procedure

Step 1 Log in to the host of your WinCollect agent.

Step 2 Navigate to the following directory on the WinCollect host:

C:\Program Files\IBM\WinCollect\logs\

On 64-bit operating systems, this file is the following location:

C:\Program Files (x86)\WinCollect\IBM\logs\

Step 3 Open the following file:

WinCollect_Device.date identifier.txt

Device Polling

Overdue

A warning message that indicates that device polling is overdue occurs when the

WinCollect agent is waiting to remotely collect events from a log source that is

managed by the WinCollect agent, but the device polling is in the queue.

This warning message can occur when you add or edit a large number of remotely

collected log sources for a WinCollect agent with a large number of remotely

collected log sources. Each time that the log source is edited, the service is

restarted on the WinCollect agent and each log source is polled for updated

events. Log sources near the bottom of the list can be in queue waiting to be

polled. If log sources are waiting to be polled, the following message is displayed

in the device log:

WARN Device.WindowsLog.EventLogMonitor.OnTimerExpired : Event

log 10.100.100.10 [\\10.100.100.10:Application] is seriously

overdue to be polled (interval 500 millisec, overdue = 45005

millisec).

This message indicates that the WinCollect agent is waiting to poll the remote log

source for events.

IBM Security QRadar WinCollect User Guide

BNOTICES AND TRADEMARKS

What’s in this appendix:

•Notices

•Trademarks

This section describes some important notices, trademarks, and compliance

information.

Notices This information was developed for products and services offered in the U.S.A.

IBM may not offer the products, services, or features discussed in this document in

other countries. Consult your local IBM representative for information on the

products and services currently available in your area. Any reference to an IBM

product, program, or service is not intended to state or imply that only that IBM

product, program, or service may be used. Any functionally equivalent product,

program, or service that does not infringe any IBM intellectual property right may

be used instead. However, it is the user's responsibility to evaluate and verify the

operation of any non-IBM product, program, or service.

IBM may have patents or pending patent applications covering subject matter

described in this document. The furnishing of this document does not grant you

any license to these patents. You can send license inquiries, in writing, to:

IBM Director of Licensing

IBM Corporation

North Castle Drive

Armonk, NY 10504-1785 U.S.A.

For license inquiries regarding double-byte character set (DBCS) information,

contact the IBM Intellectual Property Department in your country or send inquiries,

in writing, to:

Intellectual Property Licensing

Legal and Intellectual Property Law

IBM Japan Ltd.

19-21, Nihonbashi-Hakozakicho, Chuo-ku

Tokyo 103-8510, Japan

The following paragraph does not apply to the United Kingdom or any other

country where such provisions are inconsistent with local law:

IBM Security QRadar WinCollect User Guide

62

INTERNATIONAL BUSINESS MACHINES CORPORATION PROVIDES THIS

PUBLICATION "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER

EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED

WARRANTIES OF NON-INFRINGEMENT, MERCHANTABILITY OR FITNESS

FOR A PARTICULAR PURPOSE. Some states do not allow disclaimer of express

or implied warranties in certain transactions, therefore, this statement may not

apply to you.

This information could include technical inaccuracies or typographical errors.

Changes are periodically made to the information herein; these changes will be

incorporated in new editions of the publication. IBM may make improvements

and/or changes in the product(s) and/or the program(s) described in this

publication at any time without notice.

Any references in this information to non-IBM Web sites are provided for

convenience only and do not in any manner serve as an endorsement of those

Web sites. The materials at those Web sites are not part of the materials for this

IBM product and use of those Web sites is at your own risk.

IBM may use or distribute any of the information you supply in any way it believes

appropriate without incurring any obligation to you.

Licensees of this program who wish to have information about it for the purpose of

enabling: (i) the exchange of information between independently created programs

and other programs (including this one) and (ii) the mutual use of the information

which has been exchanged, should contact:

IBM Corporation

170 Tracer Lane,

Waltham MA 02451, USA

Such information may be available, subject to appropriate terms and conditions,

including in some cases, payment of a fee.

The licensed program described in this document and all licensed material

available for it are provided by IBM under terms of the IBM Customer Agreement,

IBM International Program License Agreement or any equivalent agreement

between us.

Any performance data contained herein was determined in a controlled

environment. Therefore, the results obtained in other operating environments may

vary significantly. Some measurements may have been made on

development-level systems and there is no guarantee that these measurements

will be the same on generally available systems. Furthermore, some

measurements may have been estimated through extrapolation. Actual results

may vary. Users of this document should verify the applicable data for their specific

environment.

Information concerning non-IBM products was obtained from the suppliers of those

products, their published announcements or other publicly available sources. IBM

has not tested those products and cannot confirm the accuracy of performance,

compatibility or any other claims related to non-IBM products. Questions on the

IBM Security QRadar WinCollect User Guide

Trademarks 63

capabilities of non-IBM products should be addressed to the suppliers of those

products.

All statements regarding IBM's future direction or intent are subject to change or

withdrawal without notice, and represent goals and objectives only.

All IBM prices shown are IBM's suggested retail prices, are current and are subject

to change without notice. Dealer prices may vary.

This information contains examples of data and reports used in daily business

operations. To illustrate them as completely as possible, the examples include the

names of individuals, companies, brands, and products. All of these names are

fictitious and any similarity to the names and addresses used by an actual

business enterprise is entirely coincidental.

If you are viewing this information softcopy, the photographs and color illustrations

may not appear.

Trademarks IBM, the IBM logo, and ibm.com are trademarks or registered trademarks of

International Business Machines Corp., registered in many jurisdictions worldwide.

Other product and service names might be trademarks of IBM or other companies.

A current list of IBM trademarks is available on the Web at “Copyright and

trademark information” at www.ibm.com/legal/copytrade.shtml.

The following terms are trademarks or registered trademarks of other companies:

Java and all Java-based trademarks and logos are trademarks or registered

trademarks of Oracle and/or its affiliates.

Microsoft, Windows, Windows NT, and the Windows logo are trademarks of

Microsoft Corporation in the United States, other countries, or both.

IBM Security QRadar WinCollect User Guide

INDEX

A

agent

adding 21

deleting 23

disabling 22

enabling 22

agent installations 7

audience 1

authorized services 12

authorizing WinCollect 12

B

bulk actions

adding 38

C

collection type

local 7

remote 7

command line 11

credentials 26

D

deployment 7

destinations

adding 23

deleting 24

device log examples 59

E

EPS 8

F

file forwarder plug-in 46

H

host requirements 8

I

installation

log examples 58

installing

command-line installation 11

Internet Information Server (IIS) 43, 44, 46

L

log source

adding 21, 29

deleting 23

enabling/disabling 22

managing 25, 29

M

Microsoft IIS

overview 43, 44

Microsoft IIS plug-in 43, 44, 46

Microsoft SQL plug-in 47

P

plug-ins

file forwarder 46

Microsoft IIS 43, 44, 46

Microsoft SQL 47

R

remote polling credentials 26

remote polling interval 31, 53

S

schedules

deleting 25

security practices statement 1

T

tested events per second 8

troubleshooting 59

device polling overdue 59

W

WinCollect

adding multiple sources 38

WinCollect credentials 26

WinCollect log source

adding 29

X

XPath

creating custom views 51

remote event log management 49

66 INDEX

IBM Security QRadar WinCollect User Guide

XPath examples 54
