4-574-160-11(1)

DSC-RX100M4

Digital Still Camera

Instruction Manual

“Help Guide” (Web manual)

Refer to “Help Guide” for in-depth

instructions on the many functions of

the camera.

http://rd1.sony.net/help/dsc/1530/h_zz/

This camera is equipped with a built-in instruction guide.

In-Camera Guide

The camera displays explanations for MENU/Fn (Function) items and the

setting values.

1Press the MENU button or the Fn (Function) button.

2Select the desired item, then press the C/ (Delete) button.

English

Learning more about the camera (“Help Guide”)

“Help Guide” is an on-line manual. You can read the “Help

Guide” on your computer or smartphone.

Refer to it for in-depth instructions on the many functions of

the camera.

URL:

http://rd1.sony.net/help/dsc/1530/h_zz/

Viewing the Guide

C/ (Delete)

Fn (Function)

Owner’s Record

The model and serial numbers are located on the bottom. Record the serial number in the

space provided below. Refer to these numbers whenever you call your Sony dealer

regarding this product.

Model No. WW481040 (DSC-RX100M4)

Serial No. _____________________________

Model No. AC-UB10C/AC-UB10D

Serial No. _____________________________

To reduce fire or shock hazard, do not expose the unit to rain or

moisture.

IMPORTANT SAFETY INSTRUCTIONS

-SAVE THESE INSTRUCTIONS

DANGER

TO REDUCE THE RISK OF FIRE OR ELECTRIC

SHOCK, CAREFULLY FOLLOW THESE

INSTRUCTIONS

If the shape of the plug does not fit the power outlet, use an attachment plug adaptor of the

proper configuration for the power outlet.

[Battery pack

If the battery pack is mishandled, the battery pack can burst, cause a fire or even chemical

burns. Observe the following cautions.

• Do not disassemble.

• Do not crush and do not expose the battery pack to any shock or force such as

hammering, dropping or stepping on it.

• Do not short circuit and do not allow metal objects to come into contact with the battery

terminals.

• Do not expose to high temperature above 60°C (140°F) such as in direct sunlight or in a

car parked in the sun.

• Do not incinerate or dispose of in fire.

• Do not handle damaged or leaking lithium ion batteries.

WARNING

CAUTION

• Be sure to charge the battery pack using a genuine Sony battery charger or a device that

can charge the battery pack.

• Keep the battery pack out of the reach of small children.

• Keep the battery pack dry.

• Replace only with the same or equivalent type recommended by Sony.

• Dispose of used battery packs promptly as described in the instructions.

[AC Adaptor

Use the nearby wall outlet (wall socket) when using the AC Adaptor. Disconnect the AC

Adaptor from the wall outlet (wall socket) immediately if any malfunction occurs while

using the apparatus.

[RECYCLING LITHIUM-ION BATTERIES

Lithium-Ion batteries are recyclable.

You can help preserve our environment by returning your used

rechargeable batteries to the collection and recycling location nearest

you.

For more information regarding recycling of rechargeable batteries,

call toll free

1-800-822-8837, or visit http://www.call2recycle.org/

Caution: Do not handle damaged or leaking Lithium-Ion batteries.

[Battery pack

This device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

CAN ICES-3 B/NMB-3 B

This equipment complies with FCC/IC radiation exposure limits set forth for an

uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines

and RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment has very low

levels of RF energy that are deemed to comply without testing of specific absorption ratio

(SAR).

For Customers in the U.S.A. and Canada

If you have any questions about this product, you may call:

Sony Customer Information Center

1-800-222-SONY (7669)

The number below is for the FCC related matters only.

[Regulatory Information

This equipment must not be co-located or operated in conjunction with any other antenna

or transmitter.

[CAUTION

You are cautioned that any changes or modifications not expressly approved in this manual

could void your authority to operate this equipment.

[Note:

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference in

a residential installation. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the interference by one or

more of the following measures:

– Reorient or relocate the receiving antenna.

– Increase the separation between the equipment and receiver.

– Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

– Consult the dealer or an experienced radio/TV technician for help.

The supplied interface cable must be used with the equipment in order to comply with the

limits for a digital device pursuant to Subpart B of Part 15 of FCC Rules.

For Customers in the U.S.A.

Declaration of Conformity

Trade Name: SONY

Model No.: WW481040

Responsible Party: Sony Electronics Inc.

Address: 16535 Via Esprillo,

San Diego, CA 92127 U.S.A.

Telephone No.: 858-942-2230

This device complies with Part15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference, and (2)

this device must accept any interference received, including interference that may cause

undesired operation.

This device complies with Industry Canada licence-exempt RSS standard(s).

Operation is subject to the following two conditions: (1) this device may not cause

interference, and (2) this device must accept any interference, including interference that

may cause undesired operation of the device.

[Notice for the customers in the countries applying EU Directives

Manufacturer: Sony Corporation, 1-7-1 Konan Minato-ku Tokyo, 108-0075 Japan

For EU product compliance: Sony Deutschland GmbH, Hedelfinger Strasse 61, 70327

Stuttgart, Germany

Hereby, Sony Corporation, declares that this equipment is in compliance with the essential

requirements and other relevant provisions of Directive 1999/5/EC. For details, please

access the following URL:

http://www.compliance.sony.de/

[Notice

If static electricity or electromagnetism causes data transfer to discontinue midway (fail),

restart the application or disconnect and connect the communication cable (USB, etc.)

again.

This product has been tested and found compliant with the limits set out in the EMC

regulation for using connection cables shorter than 3 meters (9.8 feet).

The electromagnetic fields at the specific frequencies may influence the picture and sound

of this unit.

For Customers in Canada

For Customers in Europe

[Disposal of waste batteries and electrical and electronic

equipment (applicable in the European Union and other

European countries with separate collection systems)

This symbol on the product, the battery or on the packaging indicates

that the product and the battery shall not be treated as household waste.

On certain batteries this symbol might be used in combination with a

chemical symbol. The chemical symbols for mercury (Hg) or lead (Pb)

are added if the battery contains more than 0.0005% mercury or

0.004% lead. By ensuring these products and batteries are disposed of

correctly, you will help prevent potentially negative consequences for

the environment and human health which could otherwise be caused by inappropriate

waste handling. The recycling of the materials will help to conserve natural resources.

In case of products that for safety, performance or data integrity reasons require a

permanent connection with an incorporated battery, this battery should be replaced by

qualified service staff only. To ensure that the battery and the electrical and electronic

equipment will be treated properly, hand over these products at end-of-life to the

applicable collection point for the recycling of electrical and electronic equipment. For all

other batteries, please view the section on how to remove the battery from the product

safely. Hand the battery over to the applicable collection point for the recycling of waste

batteries. For more detailed information about recycling of this product or battery, please

contact your local Civic Office, your household waste disposal service or the shop where

you purchased the product or battery.

For Customers in Singapore

For Customers in U.A.E.

The number in parentheses indicates the number of pieces.

• Camera (1)

• Rechargeable Battery Pack NP-BX1 (1)

• Micro USB Cable (1)

•AC Adaptor (1)

• Power Cord (mains lead) (not supplied in the USA and Canada) (1)

• Wrist Strap (1)

• Strap adapter (2)

(Strap adapters are used to attach the shoulder strap (sold separately), as

illustrated.)

• Instruction Manual (this manual) (1)

• Wi-Fi Connection/One-touch (NFC) Guide (1)

This guide explains the functions that require a Wi-Fi connection.

About language setting

Change the screen language before using the camera if necessary (page 18).

Checking the supplied items

For further details on Wi-Fi functions/One-touch (NFC) functions, refer to

the “Wi-Fi Connection/One-touch (NFC) Guide” (supplied) or the “Help

Guide” (page 2).

AON/OFF (Power) button

BPower/Charge lamp

CShutter button

DMode dial

(Auto Mode)/

(Program Auto)/

(Aperture Priority)/

(Shutter Priority)/

(Manual Exposure)/

(Memory recall)/

(Movie)/ (High Frame

Rate)/ (Sweep Panorama)/

(Scene Selection)

EFor shooting: W/T (zoom) lever

For viewing: (Index) lever/

Playback zoom lever

FSelf-timer lamp/AF illuminator

GFlash

• Do not cover the flash with your

finger.

• When using the flash, slide the

(Flash pop-up) switch. If not

using the flash, press it down

manually.

HDiopter-adjustment lever

Identifying parts

IViewfinder

• When using the viewfinder, slide

down the viewfinder pop-up

switch (1), then pull the

eyepiece out from the viewfinder

until it clicks (2).

• When you look into the

viewfinder, the viewfinder mode

is activated, and when you take

your face away from the

viewfinder, the viewing mode

returns to the monitor mode.

JMicrophone

KViewfinder pop-up switch

LHook for strap

M (N Mark)

• Touch the mark when you

connect the camera to a

smartphone equipped with the

NFC function.

• NFC (Near Field

Communication) is an

international standard of the

short-range wireless

communication technology.

NControl ring

OLens

PEye sensor

Q(Flash pop-up) switch

RMonitor

• You can adjust the monitor to an

easily viewable angle and shoot

from any position.

SFor shooting: Fn (Function)

button

For viewing: (Send to

Smartphone) button

TMOVIE (Movie) button

UMulti/Micro USB Terminal

• Supports Micro USB compatible

device.

VHDMI micro jack

WMENU button

XWi-Fi antenna (built-in)

YControl wheel

wh (Playback) button

wj C/ (Custom/Delete) button

wk Battery insertion slot

wl Battery lock lever

e; Tripod socket hole

• Use a tripod with a screw less

than 5.5 mm (7/32 inches) long.

Otherwise, you cannot firmly

secure the camera, and damage to

the camera may occur.

ea Access lamp

es Memory card slot

ed Battery/Memory card cover

ef Speaker

Inserting the battery pack

1Open the cover.

2Insert the battery pack.

• While pressing the battery lock lever, insert the battery pack as

illustrated. Make sure that the battery lock lever locks after insertion.

• Closing the cover with the battery inserted incorrectly may damage the

camera.

Battery lock lever

Charging the battery pack

1Connect the camera to the AC Adaptor (supplied),

using the micro USB cable (supplied).

2Connect the AC Adaptor to the wall outlet (wall socket).

The power/charge lamp lights orange, and charging starts.

• Turn off the camera while charging the battery.

• You can charge the battery pack even when it is partially charged.

• When the power/charge lamp flashes and charging is not finished,

remove and re-insert the battery pack.

Power cord

(Mains lead)

For customers in the USA

and Canada

For customers in countries/regions

other than the USA and Canada

Power/Charge lamp

Lit: Charging

Off: Charging finished

Flashing:

Charging error or

charging paused

temporarily because the

camera is not within the

proper temperature range

• If the power/charge lamp on the camera flashes when the AC Adaptor is connected

to the wall outlet (wall socket), this indicates that charging is temporarily stopped

because the temperature is outside the recommended range. When the temperature

gets back within the appropriate range, the charging resumes. We recommend

charging the battery pack in an ambient temperature of between 10°C to 30°C

(50ºF to 86ºF).

• The battery pack may not be effectively charged if the terminal section of the

battery is dirty. In this case, wipe any dust off lightly using a soft cloth or a cotton

swab to clean the terminal section of the battery.

• Connect the AC Adaptor (supplied) to the nearest wall outlet (wall socket). If

malfunctions occur while using the AC Adaptor, disconnect the plug from the wall

outlet (wall socket) immediately to disconnect from the power source.

• When charging is finished, disconnect the AC Adaptor from the wall outlet (wall

socket).

• Be sure to use only genuine Sony brand battery packs, micro USB cable (supplied)

and AC Adaptor (supplied).

• The AC Adaptor AC-UD11 (sold separately) may not be available in some

countries/regions.

Charging time (Full charge)

The charging time is approximately 230 min. using the AC Adaptor

(supplied). The power/charge lamp lights up and then turns off immediately

when the battery pack is fully charged.

• The above charging time applies when charging a fully depleted battery pack at a

temperature of 25°C (77°F). Charging may take longer depending on conditions of

use and circumstances.

Notes

Charging by connecting to a computer

The battery pack can be charged by connecting the camera to a computer using

a micro USB cable. Connect the camera to the computer with the camera

turned off.

• If the camera is connected to a laptop computer that is not connected to a power

source, the laptop battery level decreases. Do not charge for an extended period of

time.

• Do not turn on/off or restart the computer, or wake the computer to resume from

sleep mode when a USB connection has been established between the computer

and the camera. That may cause the camera to malfunction. Before turning on/off,

or restarting the computer or waking the computer from sleep mode, disconnect

the camera and the computer.

• No guarantees are made for charging using a custom-built computer or a modified

computer.

Notes

To a USB jack

Battery life and number of images that can be

recorded and played back

• The above number of images applies when the battery pack is fully charged. The

number of images may decrease depending on the conditions of use.

• The number of images that can be recorded is for shooting under the following

conditions:

– Using Sony Memory Stick PRO Duo™ (Mark2) media (sold separately)

– The battery pack is used at an ambient temperature of 25°C (77°F).

– [Display Quality] is set to [Standard]

• The number for “Shooting (still images)” is based on the CIPA standard, and is for

shooting under the following conditions:

(CIPA: Camera & Imaging Products Association)

– DISP is set to [Display All Info.].

– Shooting once every 30 seconds.

– The zoom is switched alternately between the W and T ends.

– The flash strobes once every two times.

– The power turns on and off once every ten times.

• The numbers of minutes for movie shooting are based on the CIPA standard, and

are for shooting under the following conditions:

– [ Record Setting]: 60i 17M(FH)/50i 17M(FH)

– Typical movie shooting: Battery life based on repeatedly starting/stopping

shooting, zooming, turning on/off, etc.

– Continuous movie shooting: Battery life based on non-stop shooting until the

limit (29 minutes) has been reached, and then continued by pressing the MOVIE

button again. Other functions, such as zooming, are not operated.

Battery life Number of images

Shooting (still

images)

Monitor — Approx. 280 images

Viewfinder — Approx. 230 images

Typical movie

shooting

Monitor Approx. 45 min. —

Viewfinder Approx. 45 min. —

Continuous

movie shooting

Monitor Approx. 80 min. —

Viewfinder Approx. 85 min. —

Viewing (still images) Approx. 200 min. Approx. 4000 images

Notes

Supplying power

You can use the AC Adaptor (supplied) to supply power during shooting or

playing back images, reducing battery pack consumption.

• The camera will not activate if there is no remaining battery. Insert a sufficiently

charged battery pack into the camera.

• If you use the camera while power is being supplied from a wall outlet (wall

socket), make sure that the icon ( ) displays on the monitor.

• Do not remove the battery pack while power is being supplied from a wall outlet

(wall socket). If you remove the battery pack, the camera will turn off.

• Do not remove the battery pack while the access lamp (page 10) is lit. The data on

the memory card may be damaged.

• As long as the power is on, the battery pack will not be charged even if the camera

is connected to the AC Adaptor.

• Under certain conditions, power may be supplied from the battery supplementarily

even if you are using the AC Adaptor.

• While power is being supplied via USB connection, the temperature inside the

camera will rise and the continuous recording time may be shortened.

Notes

Inserting a memory card (sold separately)

1Open the cover.

2Insert the memory card.

• With the notched corner facing as illustrated, insert the memory card

until it clicks into place.

3Close the cover.

Ensure the notched corner

faces correctly.

Memory cards that can be used

*1 SD Speed Class 4: or faster, or UHS Speed Class 1: or faster

*2 Memory cards that fulfill all of the following conditions:

– Capacity of 64 GB or more

– SD Speed Class 10: , or UHS Speed Class 1: or faster

When recording in 100 Mbps or more, UHS Speed Class 3: is required.

• For details on the number of recordable still images and recordable duration of

movies, refer to pages 32 to 33. Check the tables to select a memory card with the

desired capacity.

• Not all memory cards are guaranteed to operate correctly. For memory cards

produced by manufacturers other than Sony, consult the manufacturers of the

products.

• When using Memory Stick Micro media or microSD memory cards with this

camera, make sure to use with the appropriate adaptor.

To remove the memory card/battery pack

Memory card: Push the memory card in once to eject the memory card.

Battery pack: Slide the battery lock lever. Be sure not to drop the battery pack.

• Never remove the memory card/battery pack when the access lamp (page 10) is lit.

This may cause damage to data in the memory card.

Memory card For still

images

For movies

MP4 AVCHD XAVC S

Memory Stick PRO Duo

(Mark2 only) (Mark2 only) —

Memory Stick PRO-HG Duo™ —

Memory Stick Micro™ (M2)

(Mark2 only) (Mark2 only) —

SD memory card *1 *1 —

SDHC memory card

SDXC memory card *1 *1 *2

microSD memory card *1 *1 —

microSDHC memory card

microSDXC memory card *1 *1 *2

Notes

Setting the language and the clock

1Press the ON/OFF (Power) button.

Language setting screen is displayed when you turn on the camera for the

first time.

• It may take time for the power to turn on and allow operation.

2Select a desired language, then press z on the control

wheel.

Date & Time setting screen is displayed.

3Check that [Enter] is selected on the screen, then press

4Select a desired geographic location by following the

on-screen instructions, then press z.

5Set [Daylight Savings], [Date/Time] and [Date Format],

then press z.

• When setting [Date/Time], midnight is 12:00 AM, and noon is

12:00 PM.

6Check that [Enter] is selected, then press z.

Control wheel

ON/OFF (Power)

Select items: v/V/b/B

Set the numeric value of date and

time: v/V//

Set: z

Power/Charge lamp (green)

Shooting still images

Shooting movies

• When using the zoom function while shooting a movie, the sound of the camera

operating will be recorded. Sound from the camera tends to be recorded

particularly when [Zoom Speed] is set to [Fast] and when [Zoom Func. on Ring] is

set to [Quick]. The sound of the MOVIE button operating may also be recorded

when movie recording is finished.

• Continuous movie shooting is possible for a maximum of approximately

29 minutes at one time with the camera’s default settings and when the ambient

temperature is approximately 25°C (77°F). When movie recording is finished, you

can restart recording by pressing the MOVIE button again. Recording may stop to

protect the camera depending on the ambient temperature.

Shooting still images/movies

1Press the shutter button halfway down to focus.

When the image is in focus, a beep sounds and the z indicator lights.

2Press the shutter button fully down to shoot an image.

1Press the MOVIE (Movie) button to start recording.

• Use the W/T (zoom) lever to change the zoom scale.

2Press the MOVIE button again to stop recording.

Notes

Mode dial

Shutter button

: Auto Mode

: Movie

MOVIE

W/T (zoom)

lever

W: zoom out

T: zoom in

Selecting next/previous image

Select an image by pressing B (next)/b (previous) on the control wheel or by

turning the control wheel. Press z in the center of the control wheel to view

movies.

Deleting an image

1Press the C/ (Delete) button.

2Select [Delete] with v on the control wheel, then press z.

Returning to shooting images

Press the shutter button halfway down.

Viewing images

1Press the (Playback) button.

C/ (Delete)

Control wheel

(Playback)

W: zoom out

T: zoom in

Select images: B (next)/b (previous) or

turn the control wheel

Set: z

Control wheel

DISP (Display Contents): Allows you to change the screen display.

(Drive Mode): Allows you to switch between shooting methods, such

as single shooting, continuous shooting or bracket shooting.

/ (Exposure Comp./Photo Creativity): Allows you to adjust image

brightness./Allows you to operate the camera intuitively and shoot creative

images easily.

(Flash Mode): Allows you to select a flash mode for still images.

Fn (Function) button

Allows you to register 12 functions and recall those functions when shooting.

1Press the Fn (Function) button.

2Select the desired function by pressing v/V/b/B on the control wheel.

3Select the setting value by turning the control wheel or the control ring.

Control ring

Your favorite functions can be assigned to the control ring. When shooting,

established settings can be changed just by turning the control ring.

Introduction of other functions

Control ring

Control wheel

Fn (Function)

Menu Items

(Camera Settings)

Image Size Selects the size of still images.

Aspect Ratio Selects the aspect ratio for still images.

Quality Sets the image quality for still images.

Img. Size(Dual Rec) Sets the size of still images shot when recording a

movie.

Quality(Dual Rec) Sets the image quality for still images shot when

recording a movie.

File Format Selects the movie file format.

Record Setting Selects the size of the recorded movie frame.

Dual Video REC

Sets whether to simultaneously record an XAVC S

movie and MP4 movie or an AVCHD movie and

MP4 movie.

HFR Settings Sets the High Frame Rate shooting settings.

Panorama: Size Selects the size of panoramic images.

Panorama: Direction Sets the shooting direction for panoramic images.

Drive Mode Sets the drive mode, such as for continuous shooting.

Bracket Settings

Sets self-timer shooting in bracket mode, shooting

order for exposure bracketing, and white balance

bracketing.

Flash Mode Sets the flash settings.

Flash Comp. Adjusts the intensity of flash output.

Red Eye Reduction Reduces the red-eye phenomenon when using flash.

Focus Mode Selects the focus method.

Focus Area Selects the area of focus.

AF Illuminator Sets the AF illuminator, which provides light for a

dark scene to aid focusing.

Exposure Comp. Compensates for the brightness of the entire image.

ISO Adjusts the luminous sensitivity.

ISO AUTO Min. SS Sets the slowest shutter speed at which ISO

sensitivity will start to change in [ISO AUTO] mode.

ND Filter

Sets the function that reduces the amount of light.

You can set to a slower shutter speed, reduce the

aperture value, etc.

Metering Mode Selects the method for measuring brightness.

White Balance Adjusts color tones of an image.

DRO/Auto HDR Compensates automatically for brightness and

contrast.

Creative Style Selects the desired image processing. You can also

adjust contrast, saturation and sharpness.

Picture Effect Selects the desired effect filter to achieve a more

impressive and artistic expression.

Picture Profile Changes settings such as color and tone when

recording movies.

Focus Magnifier Enlarges the image before shooting so that you can

check the focus.

Long Exposure

Sets noise reduction processing for shots with a

shutter speed of 1/3 second or longer.

High ISO NR Sets noise reduction processing for high-sensitivity

shooting.

Center Lock-on AF

Sets the function to track a subject and continue

focusing when pressing the center button in the

shooting screen.

Smile/Face Detect.

Selects to detect faces and adjust various settings

automatically. Sets to automatically release the

shutter when a smile is detected.

Auto Dual Rec

Sets the shutter to release automatically when an

impressive composition including a person is detected

during movie shooting.

Soft Skin Effect Sets the Soft Skin Effect and the effect level.

Auto Obj.

Framing

Analyzes the scene when capturing faces, close-ups,

or subjects tracked by Lock-on AF function, and

automatically trims and saves another copy of the

image with a more impressive composition.

Auto Mode You can shoot selecting either Intelligent Auto or

Superior Auto.

(Custom Settings)

Scene Selection Selects pre-set settings to match various scene

conditions.

High Frame Rate Selects the exposure mode during High Frame Rate

shooting to suit your subject or effect.

Movie Selects the exposure mode to suit your subject or

effect.

SteadyShot

Sets SteadyShot for shooting still images. Reduces

blur from camera shake when shooting while holding

the camera.

SteadyShot Sets SteadyShot for shooting movies.

Color Space Changes the range of reproducible colors.

Auto Slow Shut.

Sets the function that automatically adjusts the shutter

speed following the brightness of the environment in

movie mode.

Audio Recording Sets whether to record audio when shooting a movie.

Micref Level Selects the microphone level during movie recording.

Wind Noise Reduct. Reduces wind noise during movie recording.

Memory recall

Selects a setting registered in advance when the mode

dial is set to MR (Memory recall). Optical zoom scale,

etc. can be registered.

Memory Registers the desired modes or camera settings.

Zebra Displays stripes to adjust brightness.

MF Assist Displays an enlarged image when focusing manually.

Focus Magnif. Time Sets the length of time the image will be shown in an

enlarged form.

Grid Line Sets a grid line display to enable alignment to a

structural outline.

Marker Display Sets whether to display the marker on the monitor

when recording movies.

Marker Settings Sets the marker displayed on the monitor when

recording movies.

Auto Review Sets auto review to display the captured image after

shooting.

DISP Button

Sets the type of information to be displayed on the

monitor or in the viewfinder by pressing DISP on the

control wheel.

Peaking Level Enhances the outline of in-focus ranges with a

specific color when focusing manually.

Peaking Color Sets the color used for the peaking function.

Exposure Set. Guide Sets the guide displayed when exposure settings are

changed in the shooting screen.

Live View Display Sets whether or not to reflect settings such as

exposure compensation in screen display.

Pre-AF Sets whether or not to perform auto focus before the

shutter button is half pressed.

Zoom Speed Sets the zooming speed when you operate the zoom

lever.

Zoom Setting Sets whether to use the Clear Image Zoom and Digital

Zoom when zooming.

FINDER/MONITOR Sets the method for switching between the viewfinder

and monitor.

Release w/o Card Sets whether to release the shutter when a memory

card is not inserted.

AEL w/ shutter

Sets whether to perform AEL when the shutter button

is half pressed. This is useful when you want to adjust

the focus and exposure separately.

Shutter Type Sets whether a mechanical shutter or an electronic

shutter is used when shooting still images.

Self-portrait/ -timer Sets whether to use a 3-second delay self-timer when

the screen is tilted upward about 180 degrees.

Face Registration Registers or changes the person to be given priority in

the focus.

Write Date Sets whether to record a shooting date on the still

image.

Function Menu Set. Customizes the functions displayed when the Fn

(Function) button is pressed.

(Wireless)

Custom Key Settings Assigns a desired function to the button and the

control ring.

Zoom Func. on Ring

Sets the zooming function of the control ring. When

you select [Quick], the zoom position moves in

accordance with the degree of rotation of the control

ring. When you select [Step], you can move the zoom

position to a fixed step of the focal length.

MOVIE Button Sets whether to always activate the MOVIE button.

Wheel Lock

Sets whether to disable the control wheel temporarily

by using the Fn button when shooting. You can

disable/enable the control wheel by pressing and

holding down the Fn button.

Send to Smartphone Transfers images to display on a smartphone.

Send to Computer Backs up images by transferring them to a computer

connected to a network.

View on TV You can view images on a network-enabled TV.

One-touch(NFC)

Assigns an application to One-touch (NFC). You can

call up the application when shooting by touching an

NFC-enabled smartphone to the camera.

Airplane Mode You can set this device to not perform wireless

communications.

WPS Push You can register the access point to the camera easily

by pushing the WPS button.

Access Point Set. You can register your access point manually.

Edit Device Name You can change the device name under Wi-Fi Direct,

etc.

Disp MAC Address Displays the MAC address of the camera.

SSID/PW Reset Resets the SSID and password of smartphone

connection.

Reset Network Set. Resets all network settings.

(Application)

(Playback)

(Setup)

Application List Displays the application list. You can select the

application you want to use.

Introduction Displays instructions on using the application.

Delete Deletes an image.

View Mode Sets the way in which images are grouped for

playback.

Image Index Displays multiple images at the same time.

Display Rotation Sets the playback direction of the recording image.

Slide Show Shows a slide show.

Rotate Rotates the image.

Enlarge Image Enlarges the playback images.

Protect Protects the images.

Motion Interval ADJ

Adjusts the interval for showing the tracking of

subjects in [Motion Shot Video], where the tracking

of the subject’s motion will be shown when playing

back movies.

Specify Printing Adds a print order mark to a still image.

Beauty Effect Retouches a person’s face on a still image and saves

the retouched image as a new image.

Monitor Brightness Sets the monitor brightness.

Viewfinder Bright. Sets the brightness of the electronic viewfinder.

Finder Color Temp. Sets the color temperature of the viewfinder.

Volume Settings Sets the volume for movie playback.

Audio signals Sets the operating sound of the camera.

Upload Settings Sets the upload function of the camera when using an

Eye-Fi card.

Tile Menu Sets whether to display the tile menu every time you

press the MENU button.

Mode Dial Guide Turns the mode dial guide (the explanation of each

shooting mode) on or off.

Delete confirm. Sets whether Delete or Cancel is preselected in the

Delete confirmation screen.

Display Quality Sets the display quality.

Pwr Save Start Time Sets the length of time until the camera turns off

automatically.

Function for VF close Sets whether to turn the power off when the

viewfinder is closed.

NTSC/PAL Selector By changing the TV format of the device, shooting in

a different movie format is possible.

Demo Mode Sets demonstration playback of a movie to on or off.

TC/UB Settings Sets the time code (TC) and user bit (UB).

HDMI Settings Sets the HDMI settings.

4K Output Sel.

Sets how to record and output 4K movies via HDMI

when the camera is connected to an external recorder/

player that supports 4K.

USB Connection Sets the USB connection method.

USB LUN Setting

Enhances compatibility by limiting the functions of

the USB connection. Set to [Multi] in normal

conditions and to [Single] only when the connection

between the camera and a computer or AV

component cannot be established.

USB Power Supply

Sets whether to supply power via USB connection

when the camera is connected to a computer or USB

device using a micro USB cable.

Language Selects the language.

Date/Time Setup Sets date and time, and daylight savings.

Area Setting Sets the location of use.

Format Formats the memory card.

File Number Sets the method used to assign file numbers to still

images and movies.

Select REC Folder Changes the selected folder for storing still images

and movies (MP4).

New Folder Creates a new folder for storing still images and

movies (MP4).

Folder Name Sets the folder format for still images.

Recover Image DB Recovers the image database file and enables

recording and playback.

Display Media Info.

Displays the remaining recording time of movies and

the recordable number of still images on the memory

card.

Version Displays the camera software version.

Setting Reset Restores settings to their defaults.

Installing the following software to your computer will make your camera

experience more convenient.

• PlayMemories Home™: Imports images to your computer and lets you use

them in different ways (page 31).

• Image Data Converter: Displays RAW images and processes them.

• Remote Camera Control: Controls a camera connected to your computer via

a USB cable.

You can download and install this software to your computer from the

following URLs.

• When using Remote Camera Control, select the MENU button t (Setup) t

[USB Connection] t [PC Remote] and then connect the camera to your

computer.

Using software

1Using the Internet browser on your computer, go to one

of the following URLs, and then follow the instructions

on the screen to download the desired software.

Windows:

http://www.sony.co.jp/imsoft/Win/

Mac:

http://www.sony.co.jp/imsoft/Mac/

• An Internet connection is required.

• For details on operation, refer to the support page or Help page of the

software.

Notes

The software PlayMemories Home allows you to import still images and

movies to your computer and use them. PlayMemories Home is required for

importing XAVC S movies and AVCHD movies to your computer.

http://www.sony.net/pm/

• An Internet connection is required to use PlayMemories Online or other network

services. PlayMemories Online or other network services may not be available in

some countries or regions.

• If the software PMB (Picture Motion Browser), supplied with models released

before 2011, has already been installed on your computer, PlayMemories Home

will overwrite it during the installation. Use PlayMemories Home, the successor

software of PMB.

• New functions may be installed in PlayMemories Home. Connect the camera to

your computer even if PlayMemories Home is already installed on your computer.

• Do not disconnect the micro USB cable (supplied) from the camera while the

operating screen or the accessing screen is displayed. Doing so may damage the

data.

• To disconnect the camera from the computer, click on the tasktray, then click

[Eject DSC-RX100M4].

Importing images to your computer and using

them (PlayMemories Home)

Notes

Importing images from

your camera

Sharing images on

PlayMemories Online™

Uploading

images to

network services

Creating

movie

discs

Viewing images

on a calendar

For Windows, the following functions are also

available:

Playing back imported

images

You can add the desired functions to your camera by connecting to the

application download website (PlayMemories Camera Apps™) via the

Internet.

http://www.sony.net/pmca/

• After installing an application, you can call up the application by touching an

NFC-enabled Android smartphone to the N mark on the camera, using the

[One-touch(NFC)] function.

The number of still images and recordable time may vary depending on the

shooting conditions and the memory card.

Still images

[ Image Size]: L: 20M

When [ Aspect Ratio] is set to [3:2]*

* When the [ Aspect Ratio] is set to other than [3:2], you can record more

pictures than shown above. (Except when [ Quality] is set to [RAW].)

Movies

The table below shows the approximate total recording times using a memory

card formatted with this camera. The recording time for XAVC S and AVCHD

movies is the recording time when shooting with [Dual Video REC] set to

[Off].

Adding functions to the camera

Number of still images and recordable time of

movies

Capacity

Quality 8GB 64 GB

Standard 1150 images 9600 images

Fine 690 images 5500 images

Extra fine 510 images 4150 images

RAW & JPEG 235 images 1900 images

RAW 355 images 2850 images

(h (hour), m (minute))

* only when [NTSC/PAL Selector] is set to [NTSC].

• Continuous movie shooting is possible for a maximum of approximately

29 minutes at one time with the camera’s default settings and when the ambient

temperature is approximately 25°C (77°F). The maximum continuous recording

time of an MP4 (28M) format movie is about 20 minutes (limited by the 4 GB file

size restriction).

• The recordable time of movies varies because the camera is equipped with VBR

(Variable Bit-Rate), which automatically adjusts image quality depending on the

shooting scene. When you record a fast-moving subject, the image is clearer but

the recordable time is shorter because more memory is required for recording.

The recordable time also varies depending on the shooting conditions, the subject

or the image quality/size settings.

Capacity

Record Setting

8GB 64 GB

30p 100M/25p 100M — 1 h 15 m

30p 60M/25p 60M — 2 h 5 m

24p 100M* — 1 h 15 m

24p 60M* — 2 h 5 m

60p 50M/50p 50M — 2 h 35 m

30p 50M/25p 50M — 2 h 35 m

24p 50M* — 2 h 35 m

120p 100M/100p 100M — 1 h 15 m

120p 60M/100p 60M — 2 h 5 m

60i 24M(FX)/50i 24M(FX) 40 m 6 h

60i 17M(FH)/50i 17M(FH) 55 m 8 h 15 m

60p 28M(PS)/50p 28M(PS) 35 m 5 h 5 m

24p 24M(FX)/25p 24M(FX) 40 m 6 h

24p 17M(FH)/25p 17M(FH) 55 m 8 h 15 m

1920×1080 60p 28M/

1920×1080 50p 28M 35 m 5 h 20 m

1920×1080 30p 16M/

1920×1080 25p 16M 1 h 8 h 25 m

1280×720 30p 6M/

1280×720 25p 6M 2h 35m 22h

Functions built into this camera

• This camera is compatible with 1080 60p or 50p-format movies. Unlike standard

recording modes up to now, which record in an interlacing method, this camera

records using a progressive method. This increases the resolution, and provides a

smoother, more realistic image. Movies recorded in 1080 60p/1080 50p format

can be played back only on 1080 60p/1080 50p-supported devices.

• This camera is compatible with 4K 30p/4K 25p/4K 24p recording. Movies can be

recorded in a higher resolution than HD format.

• While aboard an airplane, set [Airplane Mode] to [On].

On use and care

Avoid rough handling, disassembling, modifying, physical shock, or impact such as

hammering, dropping, or stepping on the product. Be particularly careful of the lens.

Notes on recording/playback

• Before you start recording, make a trial recording to make sure that the camera is

working correctly.

• The camera is neither dust-proof, nor splash-proof, nor water-proof.

•Do not expose the camera to sunlight or shoot sunward for a long time. The internal

mechanism may be damaged.

• If moisture condensation occurs, remove it before using the camera.

• Do not shake or strike the camera. It may cause a malfunction and you may not be

able to record images. Furthermore, the recording media may become unusable or

image data may be damaged.

Do not use/store the camera in the following places

• In an extremely hot, cold or humid place

In places such as in a car parked in the sun, the camera body may become

deformed and this may cause a malfunction.

• Storing under direct sunlight or near a heater

The camera body may become discolored or deformed, and this may cause a

malfunction.

• In a location subject to rocking vibration

• Near a location that generates strong radio waves, emits radiation or is strongly

magnetic place. Otherwise, the camera may not properly record or play back

images.

• In sandy or dusty places

Be careful not to let sand or dust get into the camera. This may cause the camera to

malfunction, and in some cases this malfunction cannot be repaired.

On carrying

• Do not sit down in a chair or other place with the camera in the back pocket of

your trousers or skirt, as this may cause malfunction or damage the camera.

Notes on using the camera

ZEISS lens

The camera is equipped with a ZEISS lens which is capable of reproducing sharp

images with excellent contrast. The lens for the camera has been produced under a

quality assurance system certified by ZEISS in accordance with the quality

standards of ZEISS in Germany.

Notes on the monitor, electronic viewfinder and lens

• The monitor and electronic viewfinder are manufactured using extremely high-

precision technology, and over 99.99% of the pixels are operational for effective

use. However, some tiny black and/or bright dots (white, red, blue or green) may

appear on the monitor and electronic viewfinder. These dots are a normal result of

the manufacturing process, and do not affect the recording.

• Do not hold the camera by the monitor or the viewfinder.

• Take care that your fingers or other objects are not caught in the lens when it is

operating.

• Take care that your finger is not in the way when pushing the viewfinder down.

• Do not forcibly push down the viewfinder when the eyepiece is pulled out.

• If water, dust or sand adheres to the viewfinder unit, it may cause a malfunction.

Notes on shooting with the viewfinder

This camera is equipped with an Organic Electro-Luminescence viewfinder with

high resolution and high contrast. The camera is designed to provide an easily

viewable viewfinder by appropriately balancing various elements.

• The image may be slightly distorted near the corners of the viewfinder. This is not

a malfunction. When you want to check every detail of the entire composition, you

can also use the monitor.

• If you pan the camera while looking into the viewfinder or move your eyes

around, the image in the viewfinder may be distorted or the color of the image may

change. This is a characteristic of the lens or display device and is not a

malfunction. When you shoot an image, we recommend that you look at the center

area of the viewfinder.

Notes on the flash

• Do not carry the camera by the flash unit, or use excessive strength on it.

• If water, dust or sand get into the open flash unit, it may cause a malfunction.

• Take care that your finger is not in the way when pushing the flash down.

Sony accessories

Use only genuine Sony brand accessories, otherwise it may cause a malfunction.

Sony brand accessories may not come to market for some countries or regions.

On camera’s temperature

Your camera and battery may get hot due to continuous use, but it is not a

malfunction.

On the overheat protection

Depending on the camera and battery temperature, you may be unable to record

movies or the power may turn off automatically to protect the camera.

A message will be displayed on the screen before the power turns off or you can no

longer record movies. In this case, leave the power off and wait until the camera and

battery temperature goes down. If you turn on the power without letting the camera

and battery cool down enough, the power may turn off again or you may be unable

to record movies.

On charging the battery

• If you charge a battery that has not been used for a long time, you may be unable

to charge it to the proper capacity.

This is due to the battery characteristics. Charge the battery again.

• Batteries which have not been used for more than a year may have become

deteriorated.

Warning on copyright

• Television programs, films, videotapes, and other materials may be copyrighted.

Unauthorized recording of such materials may be contrary to the provisions of the

• To prevent [Copyright Info] from being used illegally, leave [Set Photographer]

and [Set Copyright] blank when you lend or transfer the camera.

• Sony bears no responsibility for any trouble or damage caused by unauthorized

use of [Copyright Info].

No guarantee in the case of damaged content or recording failures

Sony can provide no guarantees in the event of failure to record or loss or damage of

recorded images or audio data due to a malfunction of the camera or recording

media, etc. We recommend backing up important data.

Cleaning the camera surface

Clean the camera surface with a soft cloth slightly moistened with water, then wipe

the surface with a dry cloth. To prevent damage to the finish or casing:

– Do not expose the camera to chemical products such as thinner, benzine, alcohol,

disposable cloths, insect repellent, sunscreen or insecticide.

Maintaining the monitor

• Hand cream or moisturizer left on the monitor may dissolve its coating. If you get

any on the monitor, wipe it off immediately.

• Wiping forcefully with tissue paper or other materials can damage the coating.

• If fingerprints or debris are stuck to the monitor, we recommend that you gently

remove any debris and then wipe the monitor clean with a soft cloth.

Notes on wireless LAN

We assume no responsibility whatsoever for any damage caused by unauthorized

access to, or unauthorized use of, destinations loaded on the camera, resulting from

loss or theft.

Notes on security when using wireless LAN products

• Always make sure that you are using a secure wireless LAN to avoid hacking,

access by malicious third parties, or other vulnerabilities.

• It is important that you set the security settings when using a wireless LAN.

• If a security problem arises because no security precautions are in place or due to

any inevitable circumstances when using a wireless LAN, Sony bears no

responsibility for the loss or damage.

Playback speed

The playback speed will vary as below depending on the assigned [ Frame Rate]

and [ Record Setting].

* only when [NTSC/PAL Selector] is set to [NTSC].

[ Priority Setting] and recordable duration

• Sound will not be recorded.

• The movie will be recorded in XAVC S HD format.

Notes on High Frame Rate shooting

Frame Rate

Record Setting

24p 50M*30p 50M/

25p 50M

60p 50M/

50p 50M

240fps/250fps 10 times slower 8 times slower/

10 times slower

4 times slower/

5 times slower

480fps/500fps 20 times slower 16 times slower/

20 times slower

8 times slower/

10 times slower

960fps/1000fps 40 times slower 32 times slower/

40 times slower

16 times slower/

20 times slower

Priority Setting Frame Rate

Effective pixel

number read out

from image

sensor

Recordable

duration

Quality Priority

240fps/250fps 1824 × 1026

Approx. 2 seconds480fps/500fps 1676 × 566

960fps/1000fps 1136 × 384

Shoot Time Priority

240fps/250fps 1676 × 566

Approx. 4 seconds480fps/500fps 1136 × 384

960fps/1000fps 800 × 270

Notes

Camera

[System]

Image device: 13.2 mm × 8.8 mm

(1.0 type) CMOS sensor

Effective pixel number of camera:

Approx. 20.1 Megapixels

Total pixel number of camera:

Approx. 21.0 Megapixels

Lens: ZEISS Vario-Sonnar T 2.9×

zoom lens

f = 8.8 mm – 25.7 mm (24 mm –

70 mm (35 mm film equivalent))

F1.8 (W) – F2.8 (T)

While shooting movies (HD 16:9):

25.5 mm – 74 mm*1

While shooting movies (4K 16:9):

28 mm – 80 mm

*1 When [ SteadyShot] is set to

[Standard]

SteadyShot: Optical

File format (Still images): JPEG (DCF,

Exif, MPF Baseline) compliant,

RAW (Sony ARW 2.3 Format),

DPOF compatible

File format (Movies):

XAVC S format (XAVC S format

compliant):

Video: MPEG-4 AVC/H.264

Audio: LPCM 2ch (48 kHz 16 bit)

AVCHD format (AVCHD format

Ver. 2.0 compatible):

Video: MPEG-4 AVC/H.264

Audio: Dolby Digital 2ch,

equipped with Dolby Digital Stereo

Creator

•Manufactured under license from

Dolby Laboratories.

Movies (MP4 format):

Video: MPEG-4 AVC/H.264

Audio: MPEG-4 AAC-LC 2ch

Recording media: Memory Stick PRO

Duo media, Memory Stick Micro

media, SD cards, microSD memory

cards

Flash: Flash range (ISO sensitivity

(Recommended Exposure Index)

set to Auto):

Approx. 0.4 m to 10.2 m

(1.31 ft. to 33.46 ft.) (W)/

Approx. 0.4 m to 6.5 m

(1.31 ft. to 21.33 ft.) (T)

[Input/Output connectors]

HDMI connector: HDMI micro jack

Multi/Micro USB Terminal*:

USB communication

USB communication: Hi-Speed USB

(USB 2.0)

* Supports Micro USB compatible

device.

[Viewfinder]

Type: Electronic viewfinder (Organic

Electro-Luminescence)

Total number of dots:

2 359 296 dots

Frame coverage: 100%

Magnification: Approx. 0.59 ×

(35 mm-format equivalent) with

50 mm lens at infinity, –1 m–1

Eye point: Approx. 20 mm from the

eyepiece, approx. 19.2 mm from

the eyepiece frame at –1 m–1

Diopter adjustment:

–4.0 m–1 to +3.0 m–1

Specifications

[Monitor]

LCD monitor:

7.5 cm (3.0 type) TFT drive

Total number of dots:

1 228 800 dots

[Power, general]

Power: Rechargeable battery pack

NP-BX1, 3.6 V

AC Adaptor AC-UB10C/UB10D,

Power consumption:

Approx. 1.9 W (during shooting

with the monitor)

Approx. 2.3 W (during shooting

with the viewfinder)

Operating temperature: 0 °C to 40 °C

(32 °F to 104 °F)

Storage temperature: –20 °C to +60 °C

(–4 °F to +140 °F)

Dimensions (CIPA compliant)

(Approx.):

101.6 mm × 58.1 mm × 41.0 mm

(4 inches × 2 3/8 inches ×

1 5/8 inches) (W/H/D)

Mass (CIPA compliant) (Approx.):

298 g (10.5 oz) (including NP-BX1

battery pack, Memory Stick PRO

Duo media)

Microphone: Stereo

Speaker: Monaural

Exif Print: Compatible

PRINT Image Matching III:

Compatible

[Wireless LAN]

Supported standard: IEEE 802.11 b/g/n

Frequency: 2.4 GHz

Supported security protocols: WEP/

WPA-PSK/WPA2-PSK

Configuration method: Wi-Fi Protected

Setup™ (WPS) / manual

Access method: Infrastructure Mode

NFC: NFC Forum Type 3 Tag

compliant

Model No. WW481040

AC Adaptor AC-UB10C/UB10D

Power requirements: AC 100 V to

240 V, 50 Hz/60 Hz, 70 mA

Output voltage: DC 5 V, 0.5 A

Rechargeable Battery Pack

NP-BX1

Battery type: Lithium-ion battery

Maximum voltage: DC 4.2 V

Nominal voltage: DC 3.6 V

Maximum charge voltage: DC 4.2 V

Maximum charge current: 1.89 A

Capacity: 4.5 Wh (1 240 mAh)

Design and specifications are subject to

change without notice.

Trademarks

• Memory Stick and are

trademarks or registered trademarks

of Sony Corporation.

• XAVC S and are

registered trademarks of Sony

Corporation.

• “AVCHD Progressive” and

“AVCHD Progressive” logotype are

trademarks of Panasonic Corporation

and Sony Corporation.

• Dolby and the double-D symbol are

trademarks of Dolby Laboratories.

• The terms HDMI and HDMI High-

Definition Multimedia Interface, and

the HDMI Logo are trademarks or

registered trademarks of HDMI

Licensing LLC in the United States

and other countries.

• Windows is a registered trademark of

Microsoft Corporation in the United

States and/or other countries.

• Mac is a registered trademark of

Apple Inc. in the United States and

other countries.

• iOS is a registered trademark or

trademark of Cisco Systems, Inc.

• iPhone and iPad are registered

trademarks of Apple Inc. in the

United States and other countries.

• SDXC logo is a trademark of SD-3C,

LLC.

• Android and Google Play are

trademarks of Google Inc.

• Wi-Fi, the Wi-Fi logo, Wi-Fi

Protected Setup are registered

trademarks of the Wi-Fi Alliance.

• The N Mark is a trademark or

registered trademark of NFC Forum,

Inc. in the United States and in other

countries.

• DLNA and DLNA CERTIFIED are

trademarks of Digital Living

Network Alliance.

• Facebook and the “f” logo are

trademarks or registered trademarks

of Facebook, Inc.

• YouTube and the YouTube logo are

trademarks or registered trademarks

of Google Inc.

• Eye-Fi is a trademark of Eye-Fi, Inc.

• In addition, system and product

names used in this manual are, in

general, trademarks or registered

trademarks of their respective

developers or manufacturers.

However, the ™ or ® marks may not

be used in all cases in this manual.

Additional information on this

product and answers to frequently

asked questions can be found at

our Customer Support Website.

DSC RX100M4 Sony RX100 IV Manual For Sonys Premium Compact Camera

Navigation menu

Versions of this User Manual:

Views

Navigation
