Scope of Accreditation
For
Tra-Cal, LLC
7901 Beechcraft Avenue, Suite M & N
Gaithersburg, MD 20879
Todd Chaikin
301-527-9200
In recognition of a successful assessment to ISO/IEC 17025:2005, ANSI/NCSL Z540-1:1994(R2002), and
ANSI/NCSL Z540.3:2006(R2014) sub-clause 5.3 to the following Calibration and Measurement
Capabilities, accreditation has been granted to Tra-Cal, LLC for the following:
Accreditation granted through: May 31, 2019
Calibration
Electrical – Capacitance1
Calibration
Parameter/Equipment
Range
Expanded Uncertainty of
Measurement (+/-)
Remarks
Capacitance – Source
1 kHz
1 nF
0.2 pF
GR 1404-A Capacitor
GR 1409-T Capacitor
Fluke 5520A Calibrator
1 kHz
0.1 µF
0.0000 29 µF
10 Hz to 10 kHz
190 pF to 1.0999 nF
0.028 nF
10 Hz to 3 kHz
1.1 nF to 3.2999 nF
0.031 nF
10 Hz to 1 kHz
3.3 nF to 10.9999 nF
0.044 nF
10 Hz to 1 kHz
(11 to 32.99) nF
0.21 nF
10 Hz to 1 kHz
(33 to 109.99) nF
0.44 nF
10 Hz to 1 kHz
(110 to 329.99) nF
1.3 nF
(10 to 600) Hz
(0.33 to 1.09) µF
0.007 2 µF
(10 to 300) Hz
(1.1 to 3.29) µF
0.014 µF
(10 to 150) Hz
(3.3 to 10.99) µF
0.045 µF
(10 to 120) Hz
(11 to 32.99) µF
0.19 µF
(10 to 80) Hz
(33 to 109.99) µF
0.69 µF
DC to 50 Hz
(110 to 329.99) µF
2.1 µF
DC to 20 Hz
(0.33 to 1.09) mF
0.009 mF
DC to 6 Hz
(1.1 to 3.29) mF
0.021 mF
DC to 2 Hz
(3.3 to 10.99) mF
0.069 mF
DC to 0.6 Hz
(11 to 32.99) mF
0.32 mF
DC to 0.2 Hz
(33 to 99.99) mF
1.4 mF
Certificate # L2151
Form 28.8—Rev 11 – 3/1/14 Page 2 of 12
Calibration
Parameter/Equipment
Range
Expanded Uncertainty of
Measurement (+/-)
Remarks
Capacitance - Measure
1 kHz
(200 pF to 20 µF)
0.045 µF
GenRad 1689
Precision RLC
Digibridge
Electrical – Current1
Calibration
Parameter/Equipment
Range
Expanded Uncertainty of
Measurement (+/-)
Remarks
DC Current – Source
(0 to 2.2) mA
(2.2 to 22) mA
(22 to 220) mA
(0.22 to 2.2) A
0.000 15 mA
0.001 5 mA
0.018 mA
0.24 mA
Fluke 5700A Calibrator
(2.2 to 11) A
0.007 4 A
Fluke 5520A Calibrator
(11 to 20) A
0.023A
(20 to 100) A
2.7 A
HP 6260B power
supply
DC Current – Measure
(0 to 100) nA
(0.1 to 1) µA
(1 to 10) µA
(10 to 100) µA
(0.1 to 1) mA
(1 to 10) mA
(10 to 100) mA
(0.1 to 1) A
0.3 nA
0.000 97 µA
0.000 45µA
0.003 2 µA
0.005 mA
0.007 mA
0.011 mA
0.15 mA
Agilent 3458A 8 ½
Digit Multimeter
(1 to 10) A
0.025 A
Fluke 45 Multimeter
DC Current - Measure
(0 to 25) A
(25 to 50) A
(50 to 100) A
(100 to 750) A
(750 to 1 000) A
0.29 % of reading
0.34 % of reading
0.34 % of reading
0.36 % of reading
0.31 % of reading
Current Shunt
Monitored with DMM
AC Current - Source
(0 to 220) µA
(10 to 20) Hz
(20 to 40) Hz
40 Hz to 1 kHz
(1 to 5) kHz
(5 to 10) kHz
0.2 µA
0.11 µA
0.042 µA
0.18 µA
0.46 µA
Fluke 5700A Calibrator
(0.22 to 2.2) mA
(10 to 20) Hz
(20 to 40) Hz
40 Hz to 1 kHz
(1 to 5) kHz
(5 to 10) kHz
0.002 mA
0.001 1mA
0.000 42 mA
0.001 8 mA
0.004 6 mA
Certificate # L2151
Form 28.8—Rev 11 – 3/1/14 Page 3 of 12
Calibration
Parameter/Equipment
Range
Expanded Uncertainty of
Measurement (+/-)
Remarks
AC Current - Source
(2.2 to 22) mA
(10 to 20) Hz
(20 to 40) Hz
40 Hz to 1 kHz
(1 to 5) kHz
(5 to 10) kHz
0.021 mA
0.011 mA
0.004 2 mA
0.018 mA
0.046 mA
Fluke 5700A Calibrator
AC Current - Source
(22 to 220) mA
(10 to 20) Hz
(20 to 40) Hz
40 Hz to 1 kHz
(1 to 5) kHz
(5 to 10) kHz
0.2 mA
0.11 mA
0.047 mA
0.18 mA
0.46 mA
(0.22 to 2.2) A
40 Hz to 1 kHz
(1 to 5) kHz
(5 to 10) kHz
0.001 9 A
0.002 2 A
0.025 A
(2.2 to 11) A
40 Hz to 1 kHz
(1 to 5) kHz
(5 to 10) kHz
0.007 9 A
0.012 A
0.042 A
Fluke 5700A/5725
Calibrator
AC Current - Measure
(0 to 100) µA
(10 to 20) Hz
(20 to 45) Hz
45 Hz to 1 kHz
0.5 uA
0.22 uA
0.13 uA
Agilent 3458A 8 ½
Digit DMM
(0.1 to 1.0) mA
(10 to 20) Hz
(20 to 45) Hz
(45 to 100) Hz
100 Hz to 5 kHz
(5 to 20) kHz
(20 to 50) kHz
(50 to 100) kHz
0.004 6 mA
0.002 mA
0.001 mA
0.000 77mA
0.000 92 mA
0.005 1 mA
0.008 1 mA
(1 to 10) mA
(10 to 20) Hz
(20 to 45) Hz
(45 to 100) Hz
100 Hz to 5 kHz
(5 to 20) kHz
(20 to 50) kHz
(50 to 100) kHz
0.049 mA
0.02 mA
0.011 mA
0.007 7 mA
0.011 mA
0.051 mA
0.081 mA
(10 to 100) mA
(10 to 20) Hz
(20 to 45) Hz
(45 to 100) Hz
100 Hz to 5 kHz
(5 to 20) kHz
(20 to 50) kHz
(50 to 100) kHz
0.49 mA
0.2 mA
0.11 mA
0.077 mA
0.11 mA
0.51 mA
0.81 mA
Certificate # L2151
Form 28.8—Rev 11 – 3/1/14 Page 4 of 12
Calibration
Parameter/Equipment
Range
Expanded Uncertainty of
Measurement (+/-)
Remarks
AC Current - Measure
(0.1 to 1.0) A
(10 to 20) Hz
(20 to 45) Hz
(45 to 100) Hz
100 Hz to 5 kHz
(5 to 20) kHz
(20 to 50) kHz
0.005 A
0.002 4 A
0.001 7 A
0.001 8 A
0.003 9 A
0.012 A
Agilent 3458A 8 ½
Digit DMM
AC Current - Measure
(1 to 10) A
45 Hz to 1 kHz
0.34 A
Fluke 45 DMM
Electrical – Inductance
Calibration
Parameter/Equipment
Range
Expanded Uncertainty of
Measurement (+/-)
Remarks
Inductance – Source
1 kHz
100 µH
0.29 µH
GR 1482-B
1 kHz
10 mH
0.012 mH
GR 1482-H
1 kHz
100 mH
0.13 mH
GR 1482-L
(0.1 to 1) kHz
500 mH
0.76 mH
GR 1482-N
100 Hz
1 H
0.001 3 H
GR 1482-P
1 kHz
1 H
0.001 3 H
GR 1482-P
(0.1 to 1) kHz
10 H
0.015 H
GR 1482-T
(0.1 to 1) kHz
10 H
0.015 H
GR 1482-T
Inductance - Measure
1 kHz
100 µH to 10 H
0.23 % of reading 0.29 µH
GenRad 1689
Electrical – Resistance1
Calibration
Parameter/Equipment
Range
Expanded Uncertainty of
Measurement (+/-)
Remarks
Resistance Source
1 Ω
85 µΩ
L&N 4020B resistor
10 Ω
0.99 mΩ
L&N 4025B resistor
100 Ω
3.8 mΩ
L&N 4030B resistor
1 kΩ
28 mΩ
L&N 4035B resistor
10 kΩ
0.13 Ω
Fluke 742A-10k resistor
100 kΩ
3.4 Ω
L&N 4045B resistor
1 MΩ
38 Ω
L&N 4050B resistor
Certificate # L2151
Form 28.8—Rev 11 – 3/1/14 Page 5 of 12
Calibration
Parameter/Equipment
Range
Expanded Uncertainty of
Measurement (+/-)
Remarks
Resistance Source
1
1.9
10
19
100
190
1 k
1.9 k
10 k
19 k
100 k
190 k
1 M
1.9 M
10 M
19 M
100 M
0.000 13
0.000 013
0.000 094
0.000 15
0.000 25
0.000 41
0.002
0.003 3
0.018
0.039
0.22
0.55
4.1
62 kΩ
35 kΩ
53 kΩ
62 kΩ
Fluke 5700A Calibrator
Resistance Source
(0 to 11)
(11 to 33)
(33 to 110)
(110 to 330)
(0.33 to 1.1) k
(1.1 to 3.29) k
(3.3 to 11) k
(11 to 32.99) k
(33 to 110) k
(110 to 330) k
330 k to 1.1 M
(1.1 to 3.3) M
(3.3 to 11) M
(11 to 33) M
(33 to 110) M
(110 to 330) M
(330 to 1 100) M
0.001 2
0.001 7
0.001 7
0.002 9
0.006 1
0.034
0.083
0.34
0.84
3.2
6.9
50
210
3.5 k
9.7 k
140 kΩ
1.4 MΩ
Fluke 5520A Calibrator
Resistance Measure
(0 to 1) Ω
81 µΩ
Agilent 3458A 8 ½
Digit Multimeter
(1 to 10) Ω
0.39 mΩ
(10 to 100) Ω
2.5 mΩ
(0.1 to 1) kΩ
17 mΩ
Resistance Measure
(1 to 10) kΩ
17 mΩ
Agilent 3458A 8 ½
Digit Multimeter
(10 to 100) kΩ
1.7 Ω
(0.1 to 1) MΩ
27 Ω
(1 to 10) MΩ
0.61 MΩ
(10 to 100) MΩ
4.2 MΩ
(0.1 to 1) GΩ
8.2 MΩ
Certificate # L2151
Form 28.8—Rev 11 – 3/1/14 Page 6 of 12
Calibration
Parameter/Equipment
Range
Expanded Uncertainty of
Measurement (+/-)
Remarks
RTD Resistance
Simulation
Pt 395, 100 Ω
(-200 to 800) °C
0.27 ºC
Fluke 5520A Calibrator
Pt 385, 200 Ω
(-200 to 630) °C
0.2 ºC
Pt 385, 500 Ω
(-200 to 630) °C
0.22 ºC
Pt 385, 1 k Ω
(-200 to 630) °C
0.46 ºC
Pt 3916, 100 Ω
(-200 to 630) °C
0.29 ºC
Pt 3926, 100 Ω
(-200 to 630) °C
0.14 ºC
Cu 427, 10 Ω
(-100 to 260) °C
0.35 ºC
Electrical – RF Power
Calibration
Parameter/Equipment
Range
Expanded Uncertainty of
Measurement (+/-)
Remarks
RF Power - Source
10 MHz to 2.3 GHz
(2.3 to 18.6) GHz
(18.6 to 26.5) GHz
(26.5 to 40) GHz
(40 to 50) GHz
200 Hz to 10.0 MHz
10MHz to 80.0MHz
(-20 to 18) dBm
(-20 to 18) dBm
(-20 to 18) dBm
(-25 to 3) dBm
(-25 to 0) dBm
(-86.98 to 13.01) dBm
(-86.98 to 13.01) dBm
1.1 dB
1.7 dB
2.3 dB
1.2 dB
2.2 dB
0.42 dB
0.13 dB
HP 8340B/83554A
Signal Generator
HP 83650B Signal
Generator
HP 3335A Signal
Generator
RF Power Flatness -
Source
200 Hz to 10 MHz
10 MHz to 25 MHz
25 MHz to 80 MHz
10 MHz to 2.3 GHz
(2.3 to 18.6) GHz
(18.6 to 26.5) GHz
(26.5 to 40) GHz
(40 to 50) GHz
(-86.98 to 13.01) dBm
(-86.98 to 13.01) dBm
(-86.98 to 13.01) dBm
(-20 to 18) dBm
(-20 to 18) dBm
(-20 to 18) dBm
(-25 to 3) dBm
(-25 to 0) dBm
0.42 dBm
0.14 dBm
0.21 dBm
1.1 dB
1.7 dB
2.3 dB
1.2 dB
2.2 dB
HP 3335A Signal
Generator
HP8340B Signal
Generator
HP 83650B Signal
Generator
Certificate # L2151
Form 28.8—Rev 11 – 3/1/14 Page 7 of 12
Calibration
Parameter/Equipment
Range
Expanded Uncertainty of
Measurement (+/-)
Remarks
RF Relative Attenuation
2.5 MHz to 26.5 GHz
(-12 to 0) dB
(-12 to -22) dB
(-22 to -31) dB
(-31 to -40) dB
(-40 to -50) dB
(-50 to -61) dB
(-61 to -71) dB
(-71 to -80) dB
(-80 to -90) dB
(-90 to -100) dB
(-100 to -110) dB
(-110 to -120) dB
0.18 dB
0.21 dB
0.23 dB
0.27 dB
0.29 dB
0.32 dB
0.34 dB
0.51 dB
0.60 dB
0.62 dB
0.65 dB
0.69 dB
HP 8902A Measuring
Receiver w/11793A
RF Power - Measure
(-127 to -30) dBm
150 kHz to 2.6 GHz
0.33 dB + 0.1 dB/dB
HP 8902A Measuring
Receiver w/11722A
Sensor
(-25 to +20) dBm
100 kHz to 4.2 GHz
10 MHz to 18 GHz
50 MHz to 26.5 GHz
50 MHz to 50 GHz
0.29 dB
0.13 dB
0.23 dB
0.4 dB
HP 438A Power Meter
w/ 8482A Sensor
w/ 8481A Sensor
w/ 8485A Sensor
w/ 8487A Sensor
Distortion
20 Hz to 20 kHz
(20 to 100) kHz
1.5 dB
3.1 dB
HP 8903B
Electrical – Voltage1
Calibration
Parameter/Equipment
Range
Expanded Uncertainty of
Measurement (+/-)
Remarks
DC Voltage - Source
(0 to 220) mV
6.6 µV
Fluke 5700A/5725A
Calibrator
(0.22 to 2.2) V
22 µV
(2.2 to 11) V
0.1 mV
(11 to 22) V
0.23 mV
(22 to 220) V
2.4 mV
(220 to 1 000) V
15 mV
DC Voltage – Measure
1 µV to 100 mV
3.3 µV
Agilent 3458A 8 ½
Digit Multimeter
(0.1 to 1) V
14 µV
(1 to 10) V
59 µV
(10 to 100) V
0.8 mV
(100 to 1 000) V
16 mV
(1 to 10) kV
360 V
Fluke 80K-40 w/8 ½
Digit Multimeter
(10 to 25) kV
400 V
(25 to 40) kV
1.9 kV
Certificate # L2151
Form 28.8—Rev 11 – 3/1/14 Page 8 of 12
Calibration
Parameter/Equipment
Range
Expanded Uncertainty of
Measurement (+/-)
Remarks
AC Voltage Source
2.2 mV to 22 mV
(10 to 20) Hz
(20 to 40) Hz
40 Hz to 20 kHz
(20 to 50) kHz
(50 to 100) kHz
(100 to 300) kHz
(300 to 500) kHz
(0.5 to 1) MHz
0.002 7 mV
0.001 8 mV
0.001 7 mV
0.003 1 mV
0.004 6 mV
0.007 6 mV
0.011 mV
0.015 mV
Fluke 5700A/5725A
Calibrator
22 mV to 220 mV
(10 to 20) Hz
(20 to 40) Hz
40 Hz to 20 kHz
(20 to 50) kHz
(50 to 100) kHz
(100 to 300) kHz
(300 to 500) kHz
(0.5 to 1) MHz
0.015 mV
0.006 3 mV
0.003 4 mV
0.011 mV
0.024 mV
0.034 mV
0.047 mV
0.08 mV
220 mV to 2.2 V
(10 to 20) Hz
(20 to 40) Hz
40 Hz to 20 kHz
(20 to 50) kHz
(50 to 100) kHz
(100 to 300) kHz
(300 to 500) kHz
(0.5 to 1) MHz
0.15 mV
0.061 mV
0.028 mV
0.092 mV
0.2 mV
0.28 mV
0.46 mV
0.92 mV
2.2 V to 22 V
(10 to 20) Hz
(20 to 40) Hz
40 Hz to 20 kHz
(20 to 50) kHz
(50 to 100) kHz
(100 to 300) kHz
(300 to 500) kHz
(0.5 to 1) MHz
0.001 5 V
0.000 46 V
0.000 22 V
0.000 36 V
0.000 72 V
0.001 2 V
0.003 1 V
0.006 1 V
AC Voltage Source
22 V to 220 V
(10 to 20) Hz
(20 to 40) Hz
40 Hz to 20 kHz
(20 to 50) kHz
(50 to 100) kHz
(100 to 300) kHz
(300 to 500) kHz
(0.5 to 1) MHz
0.015 V
0.004 6 V
0.002 2 V
0.003 6 V
0.007 2 V
0.015 V
0.036 V
0.076 V
Fluke 5700A/5725A
Calibrator
Certificate # L2151
Form 28.8—Rev 11 – 3/1/14 Page 9 of 12
Calibration
Parameter/Equipment
Range
Expanded Uncertainty of
Measurement (+/-)
Remarks
AC Voltage Source
220 V to 750 V
(10 to 20) Hz
(20 to 40) Hz
40 Hz to 20 kHz
(20 to 50) kHz
(50 to 100) kHz
(100 to 300) kHz
(300 to 500) kHz
0.5 to 1) MHz
0.15 V
0.046 V
0.023 V
0.064 V
0.15 V
0.41 V
1.4 V
3.3 V
Fluke 5700A/5725A
Calibrator
750 V
(30 to 50) kHz
(50 to 100) kHz
0.52 V
2 V
Fluke 5725A Calibrator
1100 V
50 Hz to 1 kHz
0.12 V
Fluke 5700A Calibrator
1100 V
40 Hz to 1 kHz
(1 to 20) kHz
(20 to 30) kHz
0.11 V
0.21 V
0.76 V
Fluke 5725A Calibrator
AC Voltage –
Measurement
10 mV to 100 mV
(1 to 40) Hz
40Hz to 1kHz
(1 to 20) kHz
(20 to 50) kHz
(50 to 100) kHz
(100 to 300) kHz
0.003 6 mV
0.002 5 mV
0.003 6 mV
0.012 mV
0.058 mV
0.46 mV
Agilent 3458A 8 ½
Digit Multimeter
(0.1 to 10) V
(1 to 40) Hz
40Hz to 1kHz
(1 to 20) kHz
(20 to 50) kHz
(50 to 100) kHz
(100 to 300) kHz
300 kHz to 1MHz
(1 to 2) MHz
0.000 085 V
0.000 085 V
0.000 17 V
0.000 36 V
0.001 2 V
0.005 8 V
0.012 V
0.018 V
AC Voltage –
Measurement
(10 to 100) V
(1 to 40) Hz
40Hz to 1kHz
(1 to 20) kHz
(20 to 50) kHz
(50 to 100) kHz
(100 to 300) kHz
0.024 V
0.024 V
0.024 V
0.041 V
0.14 V
0.46 V
Agilent 3458A 8 ½
Digit Multimeter
(100 to 1 000) V
(1 to 40) Hz
40 Hz to 1 kHz
(1 to 20) kHz
(20 to 50) kHz
(50 to 100) kHz
0.46 V
0.46 V
0.69 V
1.4 V
3.5 V
Certificate # L2151
Form 28.8—Rev 11 – 3/1/14 Page 10 of 12
Calibration
Parameter/Equipment
Range
Expanded Uncertainty of
Measurement (+/-)
Remarks
AC Voltage –
Measurement
(2 to 20) mV
200 kHz to 1 MHz
(1 to 10) MHz
(10 to 20) MHz
1.7 mV
2.0 mV
2.5 mV
Fluke 8920A True
RMS Voltmeter
(0.02 to 20) V
200kHz to 1MHz
(1 to 10) MHz
(10 to 20) MHz
0.25 V
0.29 V
0.36 V
Thermocouple Millivolt
Simulation
Type C
(0 to 2 316) °C
0.98 ºC
Fluke 5520A Calibrator
Type E
(-250 to 1 000) °C
0.44 ºC
Type J
(-210 to 1 200) °C
0.31 ºC
Type K
(-200 to 1 372) °C
0.47 ºC
Type N
(-200 to 1 300) °C
0.47 ºC
Type R
(0 to 1 767) °C
0.66 ºC
Type S
(0 to 1 767) °C
0.55 ºC
Type T
(-250 to 400) °C
0.73 ºC
Type U
(-200 to 600) °C
0.65 ºC
Thermodynamic – Humidity
Calibration
Parameter/Equipment
Range
Expanded Uncertainty of
Measurement (+/-)
Remarks
Relative Humidity
(23 ± 5) °C
(10 to 80) % RH
2.4 % RH
Veriteq SP-2000
Logger
Thermodynamic – Thermodynamic Sources1
Calibration
Parameter/Equipment
Range
Expanded Uncertainty of
Measurement (+/-)
Remarks
Temperature Measurement
(Ovens, Furnaces,
Freezers, Chambers, Ice
Baths – System Accuracy
Test)
(-45 to 200) ºC
2.2 ºC
Fluke 51 with Type J
TC probe
(200 to 500) ºC
2.5 ºC
Time and Frequency – Frequency / Period
Calibration
Parameter/Equipment
Range
Expanded Uncertainty of
Measurement (+/-)
Remarks
Frequency – Source2
10 MHz
7.6 · 10-11 · f
HP 58503A GPS
Receiver
DC to 20 MHz
7.6 · 10-11 · f + 0.58 Hz
HP 3325B Generator
10 MHz to 26.5 GHz
7.6 · 10-11 · f + 1.2 Hz
HP 8340B Generator
Certificate # L2151
Form 28.8—Rev 11 – 3/1/14 Page 11 of 12
Calibration
Parameter/Equipment
Range
Expanded Uncertainty of
Measurement (+/-)
Remarks
Frequency - Measure1,2
1 Hz to 225 MHz
7.6 · 10-11 · f + 0.6 mHz
HP 53131A Counter
10 Hz to 525 MHz
7.6 · 10-11 · f + 0.58 Hz
5351B 50 Ω Counter
(0.5 to 26.5) GHz
7.6 · 10-11 · f + 0.58 Hz
5351B 50 Ω Counter
Frequency Modulation –
Measure
Rate (20 Hz to 10 kHz)
40 kHz Peak Deviation
Rate (20 Hz to 200 kHz)
400 kHz Peak Deviation
CW (0.25 to 10) MHz
CW (0.01 to 1.3) GHz
0.24 kHz
5.9 kHz
HP 8902A Measuring
Receiver
Amplitude Modulation –
Measure
Rate (20 Hz to 10 kHz)
Depth (10 to 99) %
Rate (50 Hz to 10 kHz)
Depth (10 to 99) %
Rate (20 Hz to 100 kHz)
Depth (10 to 99) %
Rate (50 Hz to 50 kHz)
Depth (10 to 99) %
CW (0.15 to 10) MHz
CW (0.15 to 10) MHz
CW (0.01 to 1.3) GHz
CW (0.01 to 1.3) GHz
3.6 % of reading
2.4 % of reading
3.6 % of reading
1.3 % of reading
HP 8902A Measuring
Receiver
Phase Modulation –
Measure
Rate (200 Hz to 10 kHz)
Rate (200 Hz to 20 kHz)
CW (0.15 to 10) MHz
CW (0.01 to 1.3) GHz
1.3 rad
8.8 rad
HP 8902A Measuring
Receiver
Time and Frequency – Oscilloscopes1
Calibration
Parameter/Equipment
Range
Expanded Uncertainty of
Measurement (+/-)
Remarks
Amplitude
Square Wave into 1 MΩ
(Peak-to-Peak)
(1 to 24.999) mV
0.075 mV
Fluke 5520A-SC600
Calibrator
(25 to 109.99) mV
0.17 mV
110 mV to 2.1999 V
0.049 V
(2.2 to 10.999) V
0.013 V
(11 to 130) V
0.15 V
Amplitude
Square Wave into 50 Ω
(Peak-to-Peak)
(1 to 24.999) mV
0.12 mV
Fluke 5520A-SC600
Calibrator
(25 to 109.99) mV
0.36 mV
10 mV to 2.1999 V
0.005 8 V
(2.2 to 6.6) V
0.014 V
Certificate # L2151
Form 28.8—Rev 11 – 3/1/14 Page 12 of 12
Calibration
Parameter/Equipment
Range
Expanded Uncertainty of
Measurement (+/-)
Remarks
Rise / Fall-time
50 Ω load
5 mV to 2.5 V
(Peak-to-Peak)
1 kHz to 2 MHz
350 pS
Fluke 5520A-SC600
Calibrator
2 MHz to 10 MHz
400 pS
Bandwidth
relative to 50 kHz
50 Ω load
(0.05 to 100) MHz
0.087 mV
Fluke 5520A-SC600
Calibrator
(100 to 300) MHz
0.23 mV
(300 to 600) MHz
0.23 mV
(0.05 to 100) MHz
0.058 V
(100 to 300) MHz
0.058 V
(300 to 600) MHz
0.059 V
Timebase
50 Ω Load
5 s to 50 mS
0.029 S
Fluke 5520A-SC600
Calibrator
20 mS to 2 nS
0.002 9 mS
Calibration and Measurement Capability (CMC) is expressed in terms of the measurement parameter, measurement range,
expanded uncertainty of measurement and remarks. The expanded uncertainty of measurement is expressed as the standard
uncertainty of the measurement multiplied by a coverage factor of 2 (k=2), corresponding to a confidence level of
approximately 95%.
Notes:
1) Laboratory offers calibration services at the laboratory's own facilities and at the client or other agreed upon facilities.
2) f is defined as the measured / generated frequency.
Approved by: Date: May 31, 2016
R. Douglas Leonard
Chief Technical Officer
Re-Issued: 5/31/16
