Datasheet

802.11ac Wave 2 Enterprise Wi-Fi Access Point

Model: UAP-AC-HD

Simultaneous Dual-Band 4x4 Multi-User MIMO

Four-Stream 802.11ac Wave 2 Technology

802.3at PoE+ Compatibility

Datasheet

Scalable Enterprise Wi-Fi Management

UniFi® is the revolutionary Wi-Fi system that combines

enterprise performance, unlimited scalability, and a

central management controller. The UniFi AC HD AP has a

rened industrial design and can be easily installed using

the included mounting hardware.

Easily accessible through any standard web browser, the

UniFi Controller software is a powerful software engine

ideal for high-density client deployments requiring low

latency and high uptime performance.

Use the UniFi Controller software to quickly congure

and administer an enterprise Wi-Fi network – no special

training required. RF map and performance features,

real-time status, automatic UAP device detection, and

advanced security options are all seamlessly integrated.

Features

Save Money and Save Time UniFi comes bundled with a

non-dedicated software controller that can be deployed

on an on-site PC, Mac, or Linux machine; in a private

cloud; or using a public cloudservice. You also have the

option of deploying the compact UniFi Cloud Key with

built-in software.

Powerful Hardware The UniFi AC HD AP features the

latest in Wi-Fi 802.11ac Wave 2 MU-MIMO technology.

Intuitive UniFi Controller Software Congure and

manage your APs with the easy-to-learn user interface.

Expandable Unlimited scalability: build wireless

networks as big or small as needed. Start with one (or

upgrade to a ve‑pack) and expand to thousands while

maintaining a single unied management system.

Extend Your Coverage

With the UniFi Controller software running in a NOC or in the cloud, administrators can manage multiple sites: multiple,

distributed deployments and multi-tenancy for managed service providers. Below are some deployment examples.

University/Industrial Campus

Corporate Buildings

Internet Cafe

Dorm or Residence

Hotel

Datasheet

UniFi Controller

Packed with Features

Use the UniFi Controller to provision thousands

of UniFi APs, map out networks, quickly manage

system trafc, and provision additional UniFi APs.

View Your RF Environment

Use the RF environment functionality of the UniFi

AC HD AP to detect and troubleshoot nearby

interference, analyze radio frequencies, choose

optimal AP placement, and congure settings.

Powerful RF Performance Features

Advanced RF performance and conguration

features include spectral analysis, airtime fairness,

and band steering.

Detailed Analytics

Use the congurable reporting and analytics to

manage large user populations and expedite

troubleshooting.

Wireless Uplink

Wireless Uplink functionality enables wireless

connectivity between APs for extended range. One

wired UniFi AP uplink supports up to four wireless

downlinks on a single operating band, allowing

wireless adoption of devices in their default state

and real-time changes to network topology.

Guest Portal/Hotspot Support

Easy customization and options for Guest Portals

include authentication, Hotspot setup, and the

ability to use your own external portal server. Use

UniFi’s rate limiting for your Guest Portal/Hotspot

package offerings. Apply different bandwidth rates

(download/upload), limit total data usage, and

limit duration of use.

All UniFi APs include Hotspot functionality:

• Built-in support for billing integration using

major credit cards.

• Built-in support for voucher-based

authentication.

• Built-in Hotspot Manager for voucher creation,

guest management, and payment refund.

• Full customization and branding of Hotspot

portal pages.

Multi-Site Management

A single UniFi Controller running in the cloud

can manage multiple sites: multiple, distributed

deployments and multi-tenancy for managed

service providers. Each site is logically separated

and has its own conguration, maps, statistics,

guest portal, and administrator read/write and

read-only accounts.

WLAN Groups

The UniFi Controller can manage exible

congurations of large deployments. Create

multiple WLAN groups and assign them to an

AP’sradio. Each WLAN can be VLAN tagged.

Dynamic VLAN tagging per Wi‑Fi station (or

RADIUS VLAN) is also supported.

Dashboard

UniFi provides a visual representation of your network’s status

and delivers basic information about each network segment.

RF Map

Monitor UniFi APs and analyze the surrounding RF environment.

Statistics

UniFi organizes and visualizes network trafc in clear and

easy-to-read graphs.

Datasheet

802.11ac Technology

Initial 802.11ac Wave 1 SU-MIMO (Single-User,

Multiple Input, Multiple Output) technology allows an

earlier-generation AP, such as the UniFi AC Pro AP, to

communicate with only one client at a time.

802.11ac Wave 2 MU-MIMO (Multi-User, Multiple Input,

Multiple Output) technology allows a Wave 2 AP, such as

the UniFi AC HD AP, to communicate with multiple clients

at the same time – signicantly increasing multi‑user

throughput and overall user experience.

The following describes a 5-client scenario:

MU-MIMO Assuming the same conditions, a Wave 2 AP

provides up to 75% improvement1 overall over a Wave1

AP. This improvement increases wireless performance

and/or serves more clients at the same performance level.

4x4 Spatial Streams At any single time, a Wave 2 AP can

communicate with the following MU-MIMO clients:

• four 1x1 clients

• two 2x2 clients

• one 2x2 client and two 1x1 clients

• one 3x3 client and one 1x1 client

A 4x4 Wave 2 AP delivers up to 33% greater performance1

than a Wave 1 AP that is 3x3 in both radio bands.

Real-World Performance The UniFi AC HD AP is the rst

UniFi 802.11ac Wave 2 AP. Combining the performance

increases from MU-MIMO technology and the use of 4x4

spatial streams, the UniFi AC HD AP delivers up to 125%

greater performance1 than a typical Wave 1 AP.

Client Compatibility For optimal performance, use

MU‑MIMO clients. SU‑MIMO clients will also benet and

gain up to 10-20% greater performance when used with

the UniFi AC HD AP.

¹ Actual performance values may vary depending on environmental and

installation conditions.

Single-Client Aggregate Throughput

56%

Improvement

UniFi AC Pro AP

UniFi AC HD AP

050 100 150 200 250 300 350 400 450 500 550 600 650 700 750 800

850 900 950

Mbps

600 Mbps

940 Mbps

10-Client Aggregate Throughput

238%

Improvement

130 Mbps

UniFi AC Pro AP

UniFi AC HD AP

440 Mbps

050 100 150 200 250 300 350 400 450 Mbps

100-Client Aggregate Throughput

900%

Improvement

UniFi AC Pro AP

UniFi AC HD AP

300 Mbps

050 100 150 200 250 300 350 400 450 Mbps

30*

* Mbps

High-Density Scenarios

For high-density environments, such as a concert venue

or outdoor fair where there are numerous clients in a

relatively small space, we recommend the UniFi AC HD AP.

Both Wave 1 and Wave 2 APs offer 28 independent

(non‑overlapping) channels: three for the 2.4 GHz band

and twenty‑ve for the 5 GHz band, including DFS

channels.

When you use the 2.4 GHz band in a high-density

location, you encounter self-interference and channel

saturation. When you use the 5 GHz band, you can deploy

smaller cells (coverage areas), so you can support more

clients in any cell that deploys more than one AP.

With the advantages of MU-MIMO technology and 4x4

spatial streams, the UniFi AC HD AP can support more

than triple the number of users2 than a typical Wave1 AP.

Recommended Maximum Number

ofUsers

70 Users

UniFi AC Pro AP

UniFi AC HD AP

050 100 150 200 250 300 350 400 450 500 Users

250 Users

Theoretical Maximum Number of Users

125 Users

UniFi AC Pro AP

UniFi AC HD AP

500 Users

050 100 150 200 250 300 350 400 450 500 Users

For more information, go to:

ubnt.link/UniFi-UAPs-High-Density

² Actual numbers may vary depending on environmental and installation

conditions.

Datasheet

802.11ac Wave 1 SU-MIMO

SU-MIMO: A Wave 1 AP communicates with one client at

atime.

802.11ac Wave 2 MU-MIMO

MU-MIMO with 1x1 clients: The UniFi AC HD AP

communicates with four 1x1 clients at a time.

MU-MIMO with 2x2 and 1x1 clients: The UniFi AC HD AP

communicates with one 2x2 client and two 1x1 clients at

a time.

MU-MIMO with 3x3 and 1x1 clients: The UniFi AC HD AP

communicates with one 3x3 client and one 1x1 client at

atime.

Model Summary

UAP-AC-HD

Environment Indoor or Outdoor (Covered)

Simultaneous Dual-Band ✓

2.4 GHz Radio Rate 800 Mbps

2.4 GHz MIMO 4x4

5 GHz Radio Rate 1733 Mbps

5 GHz MIMO 4x4

Secondary Ethernet Port ✓

PoE Mode 802.3at PoE+

Ceiling Mount ✓

Wall Mount ✓

Wireless Uplink ✓

DFS Certication ✓

Datasheet

Hardware Overview

Deploy the UniFi AC HD AP in high-density environments

requiring maximum wireless performance. The UniFi AC

HD AP features simultaneous, dual-band, 4x4 MU-MIMO

technology and convenient 802.3at PoE+ compatibility.

Available in single‑ and ve‑packs*.

Easy Mounting Its sleek design seamlessly integrates

into any environment (allaccessories included) and is

compatible with existing UAP-AC-PRO mounts.

LED Unique LED provisioning ring provides administrator

location tracking and alerts for each device.

Dual Gigabit Ethernet The UniFi AC HD AP offers a

secondary port available for bridging.

* Five-packs do not ship with PoE adapters; we recommend powering the

UniFi APs with the UniFi PoE Switch instead.

Superior Processing Power The UniFi AC HD AP is

capable of complex operations (guest control, ltering,

and other resource‑intensive tasks) that may slow down a

lesser-equipped AP.

Power over Ethernet (PoE) Includes PoE functionality.

Each single-pack includes a PoE adapter.

PoE Standard The UniFi AC HD AP is compatible with

an 802.3at PoE+ compliant switch. We recommend

powering your UniFi devices with a UniFi PoE Switch (sold

separately).

UniFi PoE Switch Available in 8, 16, 24, and 48-port

versions with multiple power output options, the UniFi

PoE Switch conveniently offers auto-sensing IEEE 802.3af

PoE/802.3at PoE+.

Datasheet

UAP-AC-HD Specications

UAP-AC-HD

Dimensions 220 x 220 x 48.1 mm (8.66 x 8.66 x 1.89")

Weight

With Mounting Kits

700 g (1.54 lb)

830 g (1.83 lb)

Networking Interface (2) 10/100/1000 Ethernet Ports

Buttons Reset

Power Method Power over Ethernet (48V), 802.3at PoE+ Supported

Supported Voltage Range 44 to 57VDC

Power Supply 48V, 0.5A PoE Gigabit Adapter*

Power Save Supported

Maximum Power Consumption 17W

TX Power

2.4 GHz

5 GHz

6-25 dBm

Antennas

2.4 GHz

5 GHz

(2) Dual‑Port, Dual‑Polarity Antennas, 3 dBi each

(2) Dual‑Port, Dual‑Polarity Antennas, 4 dBi each

Wi-Fi Standards 802.11 a/b/g/n/ac/ac-wave2

Wireless Security WEP, WPA‑PSK, WPA‑Enterprise (WPA/WPA2, TKIP/AES)

802.11w/PMF

BSSID Up to Four per Radio

Mounting Wall/Ceiling (Kits Included)

Operating Temperature ‑10 to 70° C (14 to 158° F)

Operating Humidity 5 to 95% Noncondensing

Certications CE, FCC, IC

* Only the single-pack of the UAP-AC-HD includes a PoE adapter.

Advanced Trafc Management

VLAN 802.1Q

Advanced QoS Per-User Rate Limiting

Guest Trafc Isolation Supported

WMM Voice, Video, Best Effort, and Background

Concurrent Clients 500+

Supported Data Rates (Mbps)

Standard Data Rates

802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11n 6.5 Mbps to 450 Mbps (MCS0 ‑ MCS23, HT 20/40)

802.11ac 6.5 Mbps to 1.7 Gbps (MCS0 ‑ MCS9 NSS1/2/3/4, VHT 20/40/80)

802.11b 1, 2, 5.5, 11 Mbps

802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps

Datasheet

System Example

Internet

UniFi Switch

(LAN Devices)

UniFi Controller UniFi AC HD

UniFi VoIP Phones

Wireless Clients

Wired Clients

UniFi Switch

1:28

TUE, MAY 20

Calculator

Calendar

Gallery

Sound Recorder

Hangouts

Gmail

Settings

Drive

1:28

TUE, MAY 20

Calculator

Calendar

Gallery

Sound Recorder

Hangouts

Gmail

Settings

Drive

UniFi AC HD

Wireless Clients

UniFi Security

Gateway Pro

UniFi Server

Datasheet

AIJL070317

www.ubnt.com

Specications are subject to change. Ubiquiti products are sold with a limited warranty described at: www.ubnt.com/support/warranty

trademarks or registered trademarks of Ubiquiti Networks, Inc. in the United States and in other countries. All other trademarks are the property of their

respective owners.

UniFi Switch Compatibility

The UniFi switches are compatible with UniFi Access Points and UniFi G3 Video Cameras, as detailed below.

UniFi AP Model US-8 US-8-60W US-8-150W US-16-150W US-24-250W US-24-500W US-48-500W US-48-750W

UVC‑G3

UVC‑G3‑DOME ✓✓✓✓✓✓✓✓

UAP

UAP-LR

UAP-PRO ✓✓✓✓✓✓✓✓

UAP-AC-LITE 1✓✓✓✓✓✓✓✓

UAP-AC-LR 1✓✓✓✓✓✓✓✓

UAP-AC-PRO ✓✓✓✓✓✓✓✓

UAP-AC-M ✓✓✓✓✓✓✓✓

UAP-AC-M-PRO ✓✓✓✓✓✓✓✓

UAP-AC-IW 2✓✓✓✓✓✓✓✓

UAP-AC-IW-PRO 2✓✓✓✓✓✓✓✓

UAP-AC-HD ✓✓✓✓✓✓

✓Compatible with the UniFi switch

Requires Instant 802.3af Gigabit PoE Converter: INS-3AF-I-G or INS-3AF-O-G

Requires 802.3at power; switch provides 802.3af only

Notes:

1. UAP-AC-LITE and UAP-AC-LR models manufactured before September 2016 require the Instant 802.3af Gigabit PoE Converter.

2. For the UAP-AC-IW and UAP-AC-IW-PRO, PoE passthrough is supported by all of the switches listed above except for models US-8 and US-8-60W.

UniFi AC HD AP Datasheet Uni Fi_UAP HD_DS Fi UAP DS

Navigation menu

Versions of this User Manual:

Views

Navigation
