Arm® Compiler

Errors and Warnings Reference Guide

Release Information

Document History

Issue Date Confidentiality Change

A 14 March 2014 Non-Confidential Arm Compiler v6.00 Release

B 15 December 2014 Non-Confidential Arm Compiler v6.01 Release

C 30 June 2015 Non-Confidential Arm Compiler v6.02 Release

D 18 November 2015 Non-Confidential Arm Compiler v6.3 Release

E 24 February 2016 Non-Confidential Arm Compiler v6.4 Release

F 29 June 2016 Non-Confidential Arm Compiler v6.5 Release

G 04 November 2016 Non-Confidential Arm Compiler v6.6 Release

0607-00 05 April 2017 Non-Confidential Arm Compiler v6.7 Release. Document numbering scheme has

changed.

0608-00 30 July 2017 Non-Confidential Arm Compiler v6.8 Release.

0609-00 25 October 2017 Non-Confidential Arm Compiler v6.9 Release.

0610-00 14 March 2018 Non-Confidential Arm Compiler v6.10 Release.

Non-Confidential Proprietary Notice

This document is protected by copyright and other related rights and the practice or implementation of the information contained in

this document may be protected by one or more patents or pending patent applications. No part of this document may be

reproduced in any form by any means without the express prior written permission of Arm. No license, express or implied, by

estoppel or otherwise to any intellectual property rights is granted by this document unless specifically stated.

Your access to the information in this document is conditional upon your acceptance that you will not use or permit others to use

the information for the purposes of determining whether implementations infringe any third party patents.

THIS DOCUMENT IS PROVIDED “AS IS”. ARM PROVIDES NO REPRESENTATIONS AND NO WARRANTIES,

EXPRESS, IMPLIED OR STATUTORY, INCLUDING, WITHOUT LIMITATION, THE IMPLIED WARRANTIES OF

MERCHANTABILITY, SATISFACTORY QUALITY, NON-INFRINGEMENT OR FITNESS FOR A PARTICULAR PURPOSE

WITH RESPECT TO THE DOCUMENT. For the avoidance of doubt, Arm makes no representation with respect to, and has

undertaken no analysis to identify or understand the scope and content of, third party patents, copyrights, trade secrets, or other

rights.

This document may include technical inaccuracies or typographical errors.

TO THE EXTENT NOT PROHIBITED BY LAW, IN NO EVENT WILL ARM BE LIABLE FOR ANY DAMAGES,

INCLUDING WITHOUT LIMITATION ANY DIRECT, INDIRECT, SPECIAL, INCIDENTAL, PUNITIVE, OR

CONSEQUENTIAL DAMAGES, HOWEVER CAUSED AND REGARDLESS OF THE THEORY OF LIABILITY, ARISING

OUT OF ANY USE OF THIS DOCUMENT, EVEN IF ARM HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH

DAMAGES.

This document consists solely of commercial items. You shall be responsible for ensuring that any use, duplication or disclosure of

this document complies fully with any relevant export laws and regulations to assure that this document or any portion thereof is

not exported, directly or indirectly, in violation of such export laws. Use of the word “partner” in reference to Arm’s customers is

not intended to create or refer to any partnership relationship with any other company. Arm may make changes to this document at

any time and without notice.

If any of the provisions contained in these terms conflict with any of the provisions of any click through or signed written

agreement covering this document with Arm, then the click through or signed written agreement prevails over and supersedes the

conflicting provisions of these terms. This document may be translated into other languages for convenience, and you agree that if

Arm® Compiler

reserved.

Non-Confidential

there is any conflict between the English version of this document and any translation, the terms of the English version of the

Agreement shall prevail.

The Arm corporate logo and words marked with ® or ™ are registered trademarks or trademarks of Arm Limited (or its

trademarks of their respective owners. Please follow Arm’s trademark usage guidelines at http://www.arm.com/company/policies/

trademarks.

Arm Limited. Company 02557590 registered in England.

110 Fulbourn Road, Cambridge, England CB1 9NJ.

LES-PRE-20349

Confidentiality Status

This document is Non-Confidential. The right to use, copy and disclose this document may be subject to license restrictions in

accordance with the terms of the agreement entered into by Arm and the party that Arm delivered this document to.

Unrestricted Access is an Arm internal classification.

Product Status

The information in this document is Final, that is for a developed product.

Web Address

http://www.arm.com

Arm® Compiler

reserved.

Non-Confidential

Contents

Arm® Compiler Errors and Warnings Reference

Guide

Preface

About this book ...................................................... ...................................................... 6

Chapter 1 Licensing Errors and Warnings

1.1 List of the licensing error and warning messages .......................... .......................... 1-9

Chapter 2 Assembler Errors and Warnings

2.1 List of the armasm error and warning messages .......................... .......................... 2-13

Chapter 3 Linker Errors and Warnings

3.1 Suppressing armlink error and warning messages ........................ ........................ 3-44

3.2 List of the armlink error and warning messages ...................................................... 3-45

Chapter 4 ELF Image Converter Errors and Warnings

4.1 List of the fromelf error and warning messages ........................... ........................... 4-89

Chapter 5 Librarian Errors and Warnings

5.1 List of the armar error and warning messages ........................................................ 5-92

Chapter 6 Other Errors and Warnings

6.1 Internal faults and other unexpected failures ............................. ............................. 6-94

6.2 List of other error and warning messages ............................... ............................... 6-95

reserved.

Non-Confidential

Preface

This preface introduces the Arm® Compiler Errors and Warnings Reference Guide.

It contains the following:

•About this book on page 6.

reserved.

Non-Confidential

About this book

The Arm® Compiler Errors and Warnings Reference Guide provides lists of the errors and warnings that

each of the compilation tools can generate. It does not include errors and warnings produced by

armclang.

Using this book

This book is organized into the following chapters:

Chapter 1 Licensing Errors and Warnings

Describes license-related error and warning messages that might be displayed by the assembler,

the linker, or the ELF image converter.

Chapter 2 Assembler Errors and Warnings

Describes the error and warning messages for the assembler, armasm.

Chapter 3 Linker Errors and Warnings

Describes the error and warning messages for the linker, armlink.

Chapter 4 ELF Image Converter Errors and Warnings

Describes the error and warning messages for the ELF image converter, fromelf.

Chapter 5 Librarian Errors and Warnings

Describes the error and warning messages for the Arm librarian, armar.

Chapter 6 Other Errors and Warnings

Describes error and warning messages that might be displayed by any of the tools.

Glossary

The Arm® Glossary is a list of terms used in Arm documentation, together with definitions for those

terms. The Arm Glossary does not contain terms that are industry standard unless the Arm meaning

differs from the generally accepted meaning.

See the Arm® Glossary for more information.

Typographic conventions

italic

Introduces special terminology, denotes cross-references, and citations.

bold

Highlights interface elements, such as menu names. Denotes signal names. Also used for terms

in descriptive lists, where appropriate.

monospace

Denotes text that you can enter at the keyboard, such as commands, file and program names,

and source code.

monospace

Denotes a permitted abbreviation for a command or option. You can enter the underlined text

instead of the full command or option name.

monospace italic

Denotes arguments to monospace text where the argument is to be replaced by a specific value.

monospace bold

Denotes language keywords when used outside example code.

Preface

About this book

reserved.

Non-Confidential

<and>

Encloses replaceable terms for assembler syntax where they appear in code or code fragments.

For example:

MRC p15, 0, <Rd>, <CRn>, <CRm>, <Opcode_2>

SMALL CAPITALS

Used in body text for a few terms that have specific technical meanings, that are defined in the

Arm® Glossary. For example, IMPLEMENTATION DEFINED, IMPLEMENTATION SPECIFIC, UNKNOWN, and

UNPREDICTABLE.

Feedback

Feedback on this product

If you have any comments or suggestions about this product, contact your supplier and give:

• The product name.

• The product revision or version.

• An explanation with as much information as you can provide. Include symptoms and diagnostic

procedures if appropriate.

Feedback on content

If you have comments on content then send an e-mail to errata@arm.com. Give:

• The title Arm Compiler Errors and Warnings Reference Guide.

• The number 100074_0610_00_en.

• If applicable, the page number(s) to which your comments refer.

• A concise explanation of your comments.

Arm also welcomes general suggestions for additions and improvements.

Note

Arm tests the PDF only in Adobe Acrobat and Acrobat Reader, and cannot guarantee the quality of the

represented document when used with any other PDF reader.

Other information

•Arm® Developer.

•Arm® Information Center.

•Arm® Technical Support Knowledge Articles.

•Technical Support.

•Arm® Glossary.

Preface

About this book

reserved.

Non-Confidential

Chapter 1

Licensing Errors and Warnings

Describes license-related error and warning messages that might be displayed by the assembler, the

linker, or the ELF image converter.

It contains the following section:

•1.1 List of the licensing error and warning messages on page 1-9.

reserved.

1-8

Non-Confidential

1.1 List of the licensing error and warning messages

A list of the error and warning messages that are caused by license-related issues.

The license error codes have three components; a prefix letter, an error number, and a suffix letter:

LNNNND

The prefix letter L indicates the tool that generated the error:

• For the assembler, armasm, the error code starts with A.

• For the linker, armlink, the error code starts with L.

• For the ELF image converter, fromelf, the error code starts with Q.

The error numbers, NNNN, are identical for each tool.

The suffix letter, D, indicates the severity of the error:

•W means warning.

•E means error.

•F means fatal.

Note

For the compiler, armclang, error messages are still generated, but with no error code.

[A9503E|L9503E|Q9503E]: Keys for <targetName> back-end could not be found in product

definition.

[A9506E|L9506E|Q9506E]: Message received by <targetName> back-end is not valid.

[A9507E|L9507E|Q9507E]: <targetName> back-end returned status=<status> with invalid

version number (<versionNumberReceived>).

[A9511E|L9511E|Q9511E]: Unable to determine the current toolkit. Ensure that

ARM_TOOL_VARIANT is set correctly.

[A9515E|L9515E|Q9515E]: There is at least one feature CheckedOut for module

<moduleName>. Unregister is not allowed until you CheckedIn all the features.

[A9517E|L9517E|Q9517E]: Parsing error: <errorMessage> (<fileName>:<lineNumber>).

[A9518W|L9518W|Q9518W]: Parsing warning: <warningMessage> (<fileName>:<lineNumber>).

[A9519E|L9519E|Q9519E]: Your installation appears to be corrupt.

This may be subsumed into a common code for these errors, where the problem is that there is

something wrong with one or more of the mapping files.

[A9520E|L9520E|Q9520E]: Product definition string is empty. Set command will be

ignored.

[A9521E|L9521E|Q9521E]: File I/O error when determining the current toolkit. Ensure

that ARM_TOOL_VARIANT is set correctly, and you have read permissions for the

complete toolchain installation.

[A9526W|L9526W|Q9526W]: Failed to write to license cache file <fileName>. Error

<errorNumber>: <errorString>.

[A9527W|L9527W|Q9527W]: Failed to calculate license cache file contents <fileName>.

[A9528W|L9528W|Q9528W]: Failed to close license cache file <fileName>. Error

<errorNumber>: <errorString>.

[A9529W|L9529W|Q9529W]: Failed to move or copy license cache file from

<source_fileName> to <destination_fileName>. Error <errorNumber>: <errorString>.

1 Licensing Errors and Warnings

1.1 List of the licensing error and warning messages

reserved.

1-9

Non-Confidential

[A9530W|L9530W|Q9530W]: Failed to remove license cache file <fileName>. Error

<errorNumber>: <errorString>.

[A9531W|L9531W|Q9531W]: Failed to read license cache file <fileName>. Error

<errorNumber>: <errorString>.

[A9533W|L9533W|Q9533W]: License cache file invalid <fileName>.

[A9534E|L9534E|Q9534E]: Failed to create hash of cache file.

[A9535F|L9535F|Q9535F]: Dynamic library: error <error> while finding address of

function <function> in library <dllPath>.

[A9536F|L9536F|Q9536F]: Dynamic library: error <error> while loading library <dllPath>.

[A9539F|L9539F|Q9539F]: Dynamic library: failed to create checking module in library

<dllPath>.

[A9540F|L9540F|Q9540F]: Could not call DoCommand of external library, as the pointer to

it is NULL.

[A9542F|L9542F|Q9542F]: Could not allocate memory for encryption key.

[A9544E|L9544E|Q9544E]: Cannot check in feature <featureName> with version

<featureVersion> because it has not been checked out.

[A9545E|L9545E|Q9545E]: Info key <keyName> could not be found in product definition

<mappingOrigin>.

[A9546E|L9546E|Q9546E]: Your license has expired (expiry date: <expiryDate>).

[A9547E|L9547E|Q9547E]: No license checking back-end registered with id <id> for

feature <featureName>.

[A9549E|L9549E|Q9549E]: The feature <featureName> is not available with your current

toolkit and license. Ensure that ARM_TOOL_VARIANT is set correctly for your toolkit.

[A9550E|L9550E|Q9550E]: The feature <featureName> is not available with your current

toolkit and license. Ensure that ARM_TOOL_VARIANT is set correctly for your toolkit.

[A9552E|L9552E|Q9552E]: The feature <featureName> is not available with your current

toolkit and license. Ensure that ARM_TOOL_VARIANT is set correctly for your toolkit.

[A9554E|L9554E|Q9554E]: Invalid data returned from <moduleId> back-end for feature

<featureName>.

1 Licensing Errors and Warnings

1.1 List of the licensing error and warning messages

reserved.

1-10

Non-Confidential

[A9555E|L9555E|Q9555E]: Unable to checkout a license.

See the following table for more specific replacements per Flex error code:

Flex error

number

Message

-1 Unable to check out a license. The license file could not be found. Check that

ARMLMD_LICENSE_FILE is set to the correct path.

-4 Maximum number of license seats reached.

-5 The provided license does not enable these tools.

-9 This host does not match the host ID in the license.

-10 The license has expired.

-14 Unable to resolve the license server’s IP address. Check that ARMLMD_LICENSE_FILE

is set correctly.

-15 Unable to connect to the license server. Check that ARMLMD_LICENSE_FILE is set

correctly and the license server is available.

-30 Cannot read license file.

-34 System date/time is not the same as the license server.

-88 The system clock has been set back.

-96 Unable to connect to the license server. Check that ARMLMD_LICENSE_FILE is set

correctly and the license server is available.

-97 Unable to connect to the license server. Check that ARMLMD_LICENSE_FILE is set

correctly and the license server is available.

[A9558E|L9558E|Q9558E]: System clock tampering detected. License checkout will fail.

[A9559E|L9559E|Q9559E]: License information retrieval for feature <featureName> with

version <version> was cancelled because no back-end is associated with it.

[A9561E|L9561E|Q9561E]: No generation date specified, but relative expiry dates

present.

[A9580E|L9580E|Q9580E]: <target> is not available with your current toolkit and

license. Ensure that ARM_TOOL_VARIANT is set correctly for your toolkit.

1 Licensing Errors and Warnings

1.1 List of the licensing error and warning messages

reserved.

1-11

Non-Confidential

Chapter 2

Assembler Errors and Warnings

Describes the error and warning messages for the assembler, armasm.

It contains the following section:

•2.1 List of the armasm error and warning messages on page 2-13.

reserved.

2-12

Non-Confidential

2.1 List of the armasm error and warning messages

A list of the error and warning messages that armasm produces.

Note

License-related error messages can be found in the 1.1 List of the licensing error and warning messages

on page 1-9 section.

A1017E: :INDEX: cannot be used on a pc-relative expression

The :INDEX: expression operator has been applied to a PC-relative expression, most likely a

program label. :INDEX: returns the offset from the base register in a register-relative expression.

If you require the offset of a label called <label> within an area called <areaname>, use

<label> - <areaname>.

See the following in the armasm User Guide:

Unary operators.

A1020E: Bad predefine: <directive>

The operand to the --predefine or --pd command-line option was not recognized. The

directive must be enclosed in quotes if it contains spaces, for example on Windows:

--predefine "versionnum SETA 5"

If the SETS directive is used, the argument to the directive must also be enclosed in quotes,

which might require escaping, depending on the operating system and shell. For example:

--predefine "versionstr SETS \"5A\""

A1021U: No input file

No input file was specified on the command line. This might be because there was no

terminating quote on a quoted argument.

A1023E: File "<filename>" could not be opened: <reason>

A1024E: File "<filename>" could not all be loaded: <reason>

A1042E: Unrecognized APCS qualifier '<qualifier>'

There is an error in the argument given to the --apcs command line option. Check the spelling

of <qualifier>.

A1051E: Cannot open --depend file '<filename>': <reason>

A1055E: Cannot open --errors file '<filename>': <reason>

A1056E: Target cpu '<cpu>' not recognized

The name given in the --cpu command line option is not a recognized processor name. Check

the spelling of the argument.

Use --cpu=list to list the supported processors and architectures.

A1067E: Output file specified as '<filename1>', but it has already been specified as

'<filename2>'

More than one output file, -o filename, has been specified on the command line. Misspelling a

command line option can cause this.

2 Assembler Errors and Warnings

2.1 List of the armasm error and warning messages

reserved.

2-13

Non-Confidential

A1071E: Cannot open listing file '<filename>': <reason>

The file given in the --list <filename> command-line option could not be opened. This could

be for any of the following reasons:

• The given name is not valid.

• There is no space.

• A read-only file with the same name already exists.

• The file is in use by another process.

Check you have specified the correct path for the file.

A1072E: The specified listing file '<filename>' must not be a .s or .o file

The filename argument to the --list command line option has an extension that indicates it is a

source or object file. This might be because the filename argument was accidentally omitted

from the command line. Check that the correct argument is given to the --list command line

option.

A1073E: The specified output file '<filename>' must not be a source file

The object file specified on the command line has a filename extension that indicates it is a

source file. This might be because the object filename was accidentally omitted from the

command line.

A1074E: The specified depend file '<filename>' must not be a source file

The filename argument to the --depend command line option has an extension that indicates it

is a source (.s) file. This might be because the filename argument was accidentally omitted

from the command line. Check that the correct arguments are given.

A1075E: The specified errors file '<filename>' must not be a source file

The filename argument to the --errors command line option has an extension that indicates it

is a source (.s) file. This might be because the filename argument was accidentally omitted

from the command line. Check that the correct arguments are given.

A1085W: Forced user-mode LDM/STM must not be followed by use of banked R8-R14

The Arm architecture does not permit you to access banked registers in the instruction

immediately following a User registers LDM or STM. Adding a NOP immediately after the LDM or

STM is one way to avoid this.

For example:

stmib sp, {r0-r14}^ ; Return a pointer to the frame in a1.

mov r0, sp

change to:

stmib sp, {r0-r14}^ ; Return a pointer to the frame in a1.

nop

mov r0, sp

A1088W: Faking declaration of area AREA |$$$$$$$|

This is reported when no AREA directive is specified. See also message number A1105E.

A1099E: Structure stack overflow max stack size <max>

A1100E: Structure stack underflow

A1105E: Area directive missing

This is reported when no AREA directive is specified. See also message number A1088W.

A1106E: Missing comma

A1107E: Bad symbol type, expect label

A1108E: Multiply defined symbol '<name>'

A1109E: Bad expression type

2 Assembler Errors and Warnings

2.1 List of the armasm error and warning messages

reserved.

2-14

Non-Confidential

A1110E: Expected constant expression

A constant expression was expected after, for example, SETA.

See the following in the armasm User Guide:

Numeric expressions.

A1111E: Expected constant or address expression

A1112E: Expected address expression

A1113E: Expected string expression

A string expression was expected after, for example, SETS.

See the following in the armasm User Guide:

String expressions.

A1114E: Expected register relative expression

A1116E: String operands can only be specified for DCB

A1117E: Register symbol '<name>' already defined

A1118E: No current macro expansion

A1119E: MEND not allowed within conditionals

MEND means END of Macro (not the English word mend).

See the following in the armasm User Guide:

About macros.

A1120E: Bad global name

A1121E: Global name '<name>' already exists

A1122E: Locals not allowed outside macros

A1123E: Bad local name

A1125E: Unknown or wrong type of global/local symbol '<name>'

A1126E: Bad alignment boundary, must be a multiple of 2

A1127E: Bad IMPORT/EXTERN name

A1128E: Common name '<sym>' already exists

A1129E: Imported name '<sym>' already exists

A1130E: Bad exported name

A1131E: Bad symbol type for exported symbol '<sym>'

A1132E: REQUIRE directive not supported for <entity> format output

A1133E: Bad required symbol name

A1134E: Bad required symbol type, expect (symbol is either external or label) and

(symbol is relocatable and absolute)

A1135E: Area name missing

AREA names starting with any non-alphabetic character must be enclosed in bars, for example

change:

AREA 1_DataArea, CODE, READONLY

to:

AREA |1_DataArea|, CODE, READONLY

A1136E: Entry address already set

2 Assembler Errors and Warnings

2.1 List of the armasm error and warning messages

reserved.

2-15

Non-Confidential

A1137E: Unexpected characters at end of line

This is given when extra characters that are not part of an instruction are found on an instruction

line.

For example:

ADD r0, r0, r1 comment

You could change this to:

ADD r0, r0, r1 ; comment

A1138E: String "<string>" too short for operation, length must be > <oplength>

A1139E: String overflow, string exceeds <max> characters

A1140E: Bad operand type

A1141E: Relocated expressions may only be added or subtracted

A1142E: Subtractive relocations not supported for <entity> format output

This can occur when subtracting symbols that are in different areas, for example:

IMPORT sym1

IMPORT sym2

DCD (sym2 - sym1)

A1143E: COMMON directive not supported for %s format output

A1144E: DCDO directive not supported for %s format output

A1145E: Undefined exported symbol '<sym>'

A1146E: Unable to open output file <filename>: <reason>

A1147E: Bad shift name

A1148E: Unknown shift name <name>, expected one of LSL, LSR, ASR, ROR, RRX

A1150E: Bad symbol, not defined or external

This typically occurs in the following cases:

• When the current file requires an INCLUDE of another file to define some symbols, for

example:

"init.s", line 2: Error: A1150E: Bad symbol

2 00000000 DCD EBI_CSR_0

In this case, the solution is to include the required definitions file. For example:

INCLUDE targets/eb40.inc

• When the current file requires IMPORT for some symbols, for example:

"init.s", line 4: Error: A1150E: Bad symbol

4 00000000 LDR r0, =||Image$$RAM$$ZI$$Limit||

In this case, the solution is to import the required symbol, for example:

IMPORT ||Image$$RAM$$ZI$$Limit||

A1151E: Bad register name symbol

Example:

MCR p14, 3, R0, Cr1, Cr2

The coprocessor registers CR must be labeled as a lowercase c for the code to build. The register

can be r or R:

MCR p14, 3, r0, c1, c2

MCR p14, 3, R0, c1, c2

A1152E: Unexpected operator

2 Assembler Errors and Warnings

2.1 List of the armasm error and warning messages

reserved.

2-16

Non-Confidential

A1153E: Undefined symbol

A1154E: Unexpected operand, operator expected

A1155E: Unexpected unary operator equal to or equivalent to <operator>

A1156E: Missing open bracket

A1157E: Syntax error following directive

A1158E: Illegal line start, should be blank

Some directives, for example, ENTRY, IMPORT, EXPORT, and GET must be on a line without a label

at the start of the line. This error is given if a label is present.

A1159E: Label missing from line start

Some directives, for example, FUNCTION or SETS, require a label at the start of the line, for

example:

my_func FUNCTION

label SETS

This error is given if the label is missing.

A1160E: Bad local label number

A numeric local label is a number in the range 0-99, optionally followed by a name.

See the following in the armasm User Guide:

Numeric local labels.

A1161E: Syntax error following local label definition

A1162E: Incorrect routine name '<name>'

A1163E: Unknown opcode <name> , expecting opcode or Macro

The most common reasons for this are:

• Forgetting to put white space in the left hand margin, before the instruction. For example,

change the following:

MOV PC,LR

to:

MOV PC,LR

• Use of a hardware floating point instruction without using the --fpu switch. For example:

FMXR FPEXC, r1 ;

must be assembled with armasm --fpu=vfp

• Mis-typing the opcode:

ADDD

instead of:

ADD

A1164E: Opcode not supported on selected processor

The processor selected on the armasm command line does not support this instruction.

See the following:

Arm® Architecture Reference Manual.

A1165E: Too many actual parameters, expecting <actual> parameters

A1166E: Syntax error following label

A1167E: Invalid line start

2 Assembler Errors and Warnings

2.1 List of the armasm error and warning messages

reserved.

2-17

Non-Confidential

A1168E: Translate not allowed in pre-indexed form

A1169E: Missing close square bracket

A1170E: Immediate 0x<adr> out of range for this operation, must be below (0x<adr>)

This error is given when a DCB, DCW or DCWU directive is used with an immediate that is too large.

See the following in the armasm User Guide:

•DCB.

•DCW and DCWU.

A1171E: Missing close bracket

A1172E: Bad rotator <rotator>, must be even and between 0 and 30

A1173E: ADR/L cannot be used on external symbols

The ADR and ADRL pseudo-instructions can only be used with labels within the same code

area. To load an out-of-area address into a register, use LDR instead.

A1174E: Data transfer offset 0x<val> out of range. Permitted values are 0x<min> to

0x<max>

A1175E: Bad register range

A1176E: Branch offset 0x<val> out of range. Permitted values are 0x<min> to 0x<max>

Branches are PC-relative, and have a limited range. If you are using numeric local labels, you

can use the ROUT directive to limit their scope. This helps to avoid referring to the wrong label

by accident.

See the following in the armasm User Guide:

Numeric local labels.

A1179E: Bad hexadecimal number

A1180E: Missing close quote

A1181E: Bad operator

A1182E: Bad based <base> number

A1183E: Numeric overflow

A1184E: Externals not valid in expressions

A1185E: Symbol missing

A1186E: Code generated in data area

An instruction has been assembled into a data area. This can happen if you have omitted the

CODE attribute on the AREA directive.

See the following in the armasm User Guide:

AREA.

A1187E: Error in macro parameters

A1188E: Register value <val> out of range. Permitted values are <min> to <max>

A1189E: Missing '#'

A1190E: Unexpected '<entity>'

A1191E: Floating point register number out of range 0 to <maxi>

A1192E: Coprocessor register number out of range 0 to 15

A1193E: Coprocessor number out of range 0 to 15

A1194E: Bad floating-point number

A1195W: Small floating point value converted to 0.0

A1196E: Too late to ban floating point

2 Assembler Errors and Warnings

2.1 List of the armasm error and warning messages

reserved.

2-18

Non-Confidential

A1198E: Unknown operand

This can occur when an operand is accidentally mistyped.

For example:

armasm --cpu=8-A.64 init.s -g -PD "ROM_RAM_REMAP SETL {FALS}"

must be:

armasm --cpu=8-A.64 init.s -g -PD "ROM_RAM_REMAP SETL {FALSE}"

See the following in the armasm User Guide:

Assembly time substitution of variables.

A1199E: Coprocessor operation out of range 0 to <maxi>

A1200E: Structure mismatch expect While/Wend

A1201E: Substituted line too long, maximum length <max>

A1202E: No pre-declaration of substituted symbol '<name>'

See the following in the armasm User Guide:

Assembly time substitution of variables.

A1203E: Illegal label parameter start in macro prototype

A1204E: Bad macro parameter default value

A1205E: Register <reg> occurs multiply in list

A1206E: Registers should be listed in increasing register number order

This warning is given if registers in, for example, LDM or STM instructions are not specified in

increasing order and the --checkreglist option is used.

A1207E: Bad or unknown attribute

This error is given when an invalid attribute is given in the AREA directive. For example:

AREA test,CODE,READONLY,HALFWORD

HALFWORD is invalid, so remove it.

See the following in the armasm User Guide:

AREA.

A1209E: ADRL cannot be used with PC as destination

A1210E: Non-zero data within uninitialized area '<name>'

A1211E: Missing open square bracket

A1212E: Division by zero

A1213E: Attribute <entity> cannot be used with attribute <entity>

A1214E: Too late to define symbol '<sym>' as register list

A1215E: Bad register list symbol

A1216E: Bad string escape sequence

A1217E: Error writing to code file <codeFileName>: <reason>

A1219E: Bad APSR, CPSR or SPSR designator

For example:

MRS r0, PSR

It is necessary to specify which status register to use (CPSR or SPSR), such as, for example:

MRS r0, CPSR

A1220E: BLX <address> must be unconditional

A1221E: Area attribute '<entity>' not supported for <entity> object file format

A1223E: Comdat Symbol '<name>' is not defined

2 Assembler Errors and Warnings

2.1 List of the armasm error and warning messages

reserved.

2-19

Non-Confidential

A1224E: <entity> format does not allow PC-relative data transfers between areas

A1225E: ASSOC attribute is not allowed in non-comdat areas

A1226E: SELECTION attribute is not allowed in non-comdat areas

A1227E: Comdat Associated area '<name>' undefined at this point in the file

A1228E: Comdat Associated area '<name>' is not an area name

A1229E: Missing COMDAT symbol

A1230E: Missing '}' after COMDAT symbol

A1234E: Undefined or Unexported Weak Alias for symbol '<sym>'

A1237E: Invalid register or register combination for this operation

A1238E: Immediate value must be word aligned when used in this operation

A1240E: Immediate value cannot be used with this operation

A1241E: Must have immediate value with this operation

A1242E: Offset must be word aligned when used with this operation

A1243E: Offset must be halfword aligned with this operation

A1244E: Missing '!'

A1245E: B or BL from Thumb code to ARM code

A1246E: B or BL from ARM code to Thumb code

A1247E: BLX from ARM code to ARM code, use BL

This occurs when there is a BLX label branch from A32 code to A32 code within this

assembler file. This is not permitted because BLX label always results in a change of

instruction set state. The usual solution is to use BL instead.

A1248E: BLX from Thumb code to Thumb code, use BL

This occurs when there is a BLX label branch from T32 code to T32 code within this assembler

file. This is not permitted because BLX label always results in a change of instruction set state.

The usual solution is to use BL instead.

A1249E: Post indexed addressing mode not available

A1250E: Pre indexed addressing mode not available for this instruction, use [Rn, Rm]

A1253E: Thumb branch to external symbol cannot be relocated: not representable in

<fmt>

A1254E: Halfword literal values not supported

In the following example, change the LDRH into LDR, which is the standard way of loading

constants into registers:

LDRH R3, =constant

A1256E: DATA directive can only be used in CODE areas

A1259E: Invalid PSR field specifier, syntax is <PSR>_ where <PSR> is either CPSR or

SPSR

A1260E: PSR field '<entity>' specified more than once

A1261E: MRS cannot select fields, use APSR, CPSR or SPSR directly

This is caused by an attempt to use fields for CPSR or SPSR with an MRS instruction. For

example:

MRS r0, CPSR_c

A1262U: Expression storage allocator failed

A1265U: Structure mismatch: IF or WHILE unmatched at end of INCLUDE file

A1267E: Bad GET or INCLUDE for file <filename>

A1268E: Unmatched conditional or macro

A1269U: unexpected GET on structure stack

A1270E: File "<entity>" not found

A1271E: Line too long, maximum line length is <MaxLineLength>

A1272E: End of input file

A1273E: '\\' should not be used to split strings

A1274W: '\\' at end of comment

2 Assembler Errors and Warnings

2.1 List of the armasm error and warning messages

reserved.

2-20

Non-Confidential

A1283E: Literal pool too distant, use LTORG to assemble it within 1KB

For T32 code, a literal pool must be within 1KB of an LDR instruction that is trying to access it.

See also warning A1563W.

A1753E: Unrecognized memory barrier option

A1754E: Cannot change the type of a scalar register

A1755E: Scalar index has already been specified on this register

A1756E: Data type must be specified on all registers

A1757W: Symbol attributes must be within square brackets; Any other syntax is

deprecated

A1758W: Exporting multiple symbols with this directive is deprecated

A1759E: Specified processor or architecture does not support Thumb-2EE instructions

A1760W: Build Attribute <from> is '<attr>'

A1761W: Difference in build attribute from '<diff>' in <from>

A1762E: Branch offset 0x<val> out of range of 16-bit Thumb branch, but offset

encodable in 32-bit Thumb branch

This is caused when assembling for T32 if an offset to a branch instruction is too large to fit in a

16-bit branch. The .W suffix can be added to the instruction to instruct the assembler to generate

a 32-bit branch.

2 Assembler Errors and Warnings

2.1 List of the armasm error and warning messages

reserved.

2-35

Non-Confidential

A1763W: Inserted an IT block for this instruction

This indicates that the assembler has inserted an IT block to permit a number of conditional

instructions in T32 code. For example:

MOVEQ r0,r1

This warning is off by default. It can be enabled using --diag_warning A1763.

A1764W: <name> instructions are deprecated in architecture <arch> and above

A1765E: Size of padding value on ALIGN must be 1, 2 or 4 bytes

This is caused when the optional padsize attribute is used with an ALIGN directive, but has an

incorrect size. It does not refer to the parameter to align to. The parameter can be any power of 2

from 2^0 to 2^31.

A1766W: Size of padding value for code must be a minimum of <size> bytes; treating as

data

A1767E: Unexpected characters following attribute

A1768E: Missing '='

A1769E: Bad NEON or VFP system register name symbol

A1771E: Bad floating-point bitpattern when expecting <exp>-bit bitpattern

A1772E: Destination type must be signed or unsigned integer, and source type must be

32-bit or 64-bit floating-point

A1773E: Floating-point conversion only possible between 32-bit single-precision and

64-bit double-precision types

A1774E: Fixed-point conversion only possible for 16-bit or 32-bit signed or unsigned

types

A1775E: Conversion between these types is not possible

A1776E: This operation is not available for 32-bit single-precision floating point

types

A1777E: <n> is out of range for symbol type; value must be between <min> and <max>

A1778E: <n> is out of range for symbol binding; value must be between <min> and <max>

A1779E: DCDO cannot be used on READONLY symbol '<key>'

A1780E: Unknown ATTR directive

A1781E: Tag #<id> cannot be set by using ATTR

A1782E: Tag #<id> should be set with ATTR <cmd>

A1783E: Attribute scope must be a label or section name

A1784W: Reference to weak definition '<sym>' not relocated

A1785E: Macro '<macuse>' not found, but '<macdef>' exists

2 Assembler Errors and Warnings

2.1 List of the armasm error and warning messages

reserved.

2-36

Non-Confidential

A1786W: This instruction using SP is deprecated and may not work in future

architecture revisions

This warning is generated when all of the following conditions are satisfied:

• You explicitly use the SP in a deprecated way, for example:

ADD sp, r0, #100

• You are assembling for a target architecture that supports 32-bit T32 instructions, in other

words Armv6T2 or later.

• You are assembling to A32 code.

Arm deprecates the explicit use of the SP in A32 instructions in any way that is not possible in

the corresponding T32 instruction. Such deprecated register uses are still possible in A32

instructions for backwards compatibility and you can suppress this warning by using the

assembler’s command line option --diag_suppress=1786. However, Arm recommends you

modify your code, because it might not work in future architecture revisions.

You can replace the deprecated use of the SP shown in the example with a sequence like:

ADD r1, r0, #100

MOV sp, r1

Note

• When assembling to T32, rather than A32 code, and the target architecture is Armv6T2 or

later, the assembler generates error A1477E instead.

• When assembling for an architecture or processor that does not support 32-bit T32

instructions, in other words Arm architectures before Armv6T2, by default no diagnostic is

emitted.

A1787W: Use of VFP Vector Mode is deprecated in ARMv7

A1788W: Explicit use of PC in this instruction is deprecated and may not work in

future architecture revisions

This warning is generated when all of the following conditions are satisfied:

• You explicitly use the PC in a deprecated way, for example:

CMP pc, #1

• You are assembling for a target architecture that supports 32-bit T32 instructions, in other

words Armv6T2 or later.

• You are assembling to A32 code.

Arm deprecates the explicit use of the SP in A32 instructions in any way that is not possible in

the corresponding T32 instruction. Such deprecated register uses are still possible in A32

instructions for backwards compatibility and you can suppress this warning by using the

assembler’s command line option --diag_suppress=1786. However, Arm recommends you

modify your code, because it might not work in future architecture revisions.

Note

• When assembling to T32, rather than A32 code, and the target architecture is Armv6T2 or

later, the assembler generates error A1477E instead.

• When assembling for an architecture or processor that does not support 32-bit T32

instructions, in other words Arm architectures before Armv6T2, by default no diagnostic is

emitted.

A1789W: Explicit use of PC in this instruction is deprecated and and may not work in

future architecture revisions, except as destination register

2 Assembler Errors and Warnings

2.1 List of the armasm error and warning messages

reserved.

2-37

Non-Confidential

A1790W: Writeback ignored in Thumb LDM loading the base register

This is caused by incorrectly adding an exclamation mark to indicate base register writeback.

For example:

LDM r0!, {r0-r4}

is not a legal instruction because r0 is the base register and is also in the destination register list.

In this case, the assembler ignores the writeback and generates:

LDM r0, {r0-r4}

A1791W: Previous value of tag #<id> will be overridden

A1792E: Undefined build attributes tag

A1793E: Conversion only possible between 16-bit and 32-bit floating point

A1794E: Conversion operations require two data types

A1795E: Source and destination vector must contain <n> elements

A1796E: Register type not consistent with data type

A1797E: Specified FPU is not compatible with CPU architecture

A1798W: Output is not WYSIWYG (<output>)

A1799W: Output has not been checked for WYSIWYG property

A1800W: No output for line

A1801E: Instruction is UNPREDICTABLE in current instruction set

A1803E: Bad system instruction name

A1804E: Bad CP14 or CP15 register name for instruction

A1805E: Register is Read-Only

A1806E: Register is Write-Only

A1807W: Instruction executes as NOP on target CPU

A1808E: Generated object file may be corrupt (<reason>)

A1809W: Instruction aligns PC before using it; section ought to be at least 4 byte

aligned

This warning is generated when all the following conditions apply:

• You are using a PC-relative offset in a T32 instruction that requires the PC to be word-

aligned.

• The code section containing this instruction has less than 4-byte alignment.

• The instruction is not relocated at link time (because of a relocation emitted by the

assembler).

If these conditions are all met, and the code section containing this instruction is not placed at a

4-byte aligned address when linking, the instruction might operate on or with the wrong address

at runtime. This is because the instruction aligns the PC to a 4-byte address before using it.

The following example shows an LDR instruction in T32 that is diagnosed by this warning

because the section has an alignment of 2 bytes:

AREA ||.text||, CODE, READONLY, ALIGN=1

THUMB

LDR r0, [pc, #8] ; gives warning A1809W

A1810E: Base register writeback value unclear; use '[rn,#n]!' or '[rn],#n' syntax

A1811E: Size of fill value must be 1, 2 or 4 bytes and a factor of fill size

A1812W: Instruction cannot be assembled in the opposite instruction set

A1813W: 32-bit instruction used where 16-bit could have been used

A1814E: No output file

A1815E: SHT_ARM_EXIDX sections require a link order dependency to be set

A1816E: Unknown opcode '<name>' in CODE16, but exists in THUMB

A1817W: ATTR tag #<id> setting ignored in <scope>

A1818W: ATTR COMPAT flag <flag> and vendor '<vendor>' setting ignored in <scope>

A1819W: ATTR compatible with tag #<id> setting ignored in <scope>

A1820E: Register and processor mode not valid for instruction

2 Assembler Errors and Warnings

2.1 List of the armasm error and warning messages

reserved.

2-38

Non-Confidential

A1821E: Expected constant or register expression

A1822E: Expected list of 32-bit extension registers

A1823E: Expected list of 64-bit extension registers

A1824E: Expected core register or 32-bit, 64-bit or 128-bit extension register

A1825E: Expected constant or 32-bit extension register

A1826E: Expected constant or 64-bit extension register

A1827E: Expected constant or 128-bit extension register

A1828E: Expected core register or 32-bit extension register

A1829E: Expected core register or 64-bit extension register

A1830E: Expected core register or 128-bit extension register

A1831E: Expected constant, floating-point constant, core register or 64-bit extension

A1832E: Expected floating-point constant, core register or 32-bit extension register

A1833E: Expected constant or '{option}', where option is a constant from 0 to 255

A1834E: Expected register or address expression

A1835E: Too few data types specified on instruction

A1836E: Expected '<dt>' data type for destination

A1837E: Expected '<dt>' data type for first source

A1838E: Unexpected characters when expecting '<word1>' or '<word2>'

A1839E: Destination register must be scalar

A1840E: First source register must be scalar

A1841E: Alignment specified on base register not valid for instruction

A1842E: Syntax not allowed for a pseudo-instruction

A1843E: Literal load not supported for instruction

A1844E: Literal type not supported

A1845E: Register type not available in current instruction set

A1846E: Invalid field specifiers for CPSR or SPSR: must be followed by at least one

of c, x, s or f

A1847E: Expression requiring more than one relocation not allowed

This can occur during the assembly of A32 instructions when trying to access data in another

area. For example, using:

LDR r0, [pc, #label - . - 8]

or its equivalent:

LDR r0, [pc, #label-{PC}-8]

where label is defined in a different AREA.

Change your code to use the simpler, equivalent syntax:

LDR r0, label

This works if label is either in the same area or in a different area.

A1848W: State change in IT block

A1849E: Scalar index on operand out of range for data type

A1850E: Width must be before any data type qualifiers

A1851E: Invalid line start - local label not supported on this directive

A1852E: Use of VFP Vector Mode is not supported on target FPU

A1853E: Alignment of instruction or target must be at least <n>-byte aligned

A1854E: Unknown opcode '<name>', maybe wrong target CPU?

A1856E: Shifted register operand not allowed

A1857E: Specified shift not allowed

A1858E: Flag setting form of this instruction not available

A1859E: Flag preserving form of this instruction not available

A1860E: Register operands must be from R0 to R7 in this instruction

A1861E: Option '<opt>' is obsolete.

2 Assembler Errors and Warnings

2.1 List of the armasm error and warning messages

reserved.

2-39

Non-Confidential

A1862E: Data type size for floating-point must be 16 or 32

A1863E: Data type size for floating-point must be 32

A1864E: Data type size for floating-point must be 16, 32 or 64

A1865W: '#' not seen before constant expression

A1866E: Wireless MMX Control register not defined on target CPU

A1867E: Immediate 0x<val> out of range for this operation. Permitted values are

multiples of <mult> from 0x<min> to 0x<max>

A1868E: Bitfield LSB out of range. Permitted values are 0 to <max>

A1869E: Register <field> must not be PC

A1870W: Area '<name>' has incorrect attributes, expect '<attrs>'

A1871E: Immediate 0x<imm> cannot be represented by 0-255 shifted left by 0-23 or

duplicated in all, odd or even bytes

This error occurs when armasm cannot encode the instruction with the specified immediate.

For example, in Arm Compiler 4.1 and above, the following instruction causes this error in T32

state:

ADDS r0, r1, #-20

A workaround is to use the equivalent SUBS instruction instead:

SUBS r0, r1, #20

A1872E: Shift by register not allowed

A1873E: Only the non-writeback form of this instruction exists

A1874E: Specified register list cannot be loaded or stored in target instruction set

A1875E: Register Rn must be from R0 to R7 in this instruction

Change the specified register to be in the range R0 to R7.

A1876W: Use of '|' as a synonym for the :OR: operator is deprecated.

A1877E: Specified register for <field> not allowed in current instruction set

A1878E: Offset must be <reqalign>-byte aligned when used with this operation

A1879E: Specified addressing mode not available

A1880E: Data transfer size not available

A1881E: <mode> load/store mode is not permitted

A1882E: Destination and first source register must be same

A1883E: Destination and second source register must be same

A1884E: Specified AIF bits not available on target CPU

A1885E: Cannot change processor mode in current instruction set

A1886E: Invalid operand size for add with carry-in: must be 16 or 32

A1887E: Specified source data type not allowed; must be one of: <str>

A1888E: Specified destination data type not allowed; must be one of: <str>

A1889E: Specified register type not available on target architecture

A1890E: Specified shift results in UNPREDICTABLE behaviour

A1891E: With this register combination, writeback results in UNPREDICTABLE behaviour

A1892W: Writeback with this register combination is deprecated and may not work in

future architecture revisions

A1893E: The specified flags result in UNPREDICTABLE behaviour

A1894E: The specified immediate results in UNPREDICTABLE behaviour

A1895E: The specified condition results in UNPREDICTABLE behaviour

A1896E: Specified alignment not supported on this instruction

A1897E: Bitfield width out of range. Permitted values are 1 to <max>

A1898E: Target cannot be relocated. No suitable relocation exists for this

instruction

A1899E: Specified operator is only allowed on the following instructions: <instrs>

A1900W: Deprecated system instruction name

A1901E: Specified system instruction not supported on target architecture

2 Assembler Errors and Warnings

2.1 List of the armasm error and warning messages

reserved.

2-40

Non-Confidential

A1902E: Specified special register not supported on target architecture

A1903E: Line not seen in first pass; cannot be assembled

This occurs if an instruction or directive does not appear in pass 1 but appears in pass 2 of the

assembler.

The following example shows when a line is not seen in pass 1:

AREA x,CODE

[ :DEF: foo

num EQU 42 ; Assembler does not see this line during pass 1 because

; foo is not defined at this point during pass 1

]

foo DCD num

END

A1905U: Pre-processor step failed for '<filename>'

A1906W: Unfinished IT block

A1907W: Test for this symbol has been seen and may cause failure in the second pass.

This diagnostic is suppressed by default. Enable it to identify situations that might result in

errors A1903E, A1908E, or A1909E.

A1908E: Label '<name>' value inconsistent: in pass 1 it was <val1>; in pass 2 it was

<val2>

The following example generates this error because in pass 1 the value of x is 0x0004+r9, and in

pass 2 the value of x is 0x0000+r0:

map 0, r0

if :lnot: :def: sym

map 0, r9

field 4

endif

x field 4

sym LDR r0, x

A1909E: Line not seen in second pass; cannot be assembled

This occurs if an instruction or directive appears in pass 1 but does not appear in pass 2 of the

assembler.

The following example shows when a line is not seen in pass 2:

AREA x,CODE

[ :LNOT: :DEF: foo

MOV r1, r2 ; Assembler does not see this line during pass 2 because

; foo is already defined

]

foo MOV r3, r4

END

A1911E: Immediate 0x<val> out of range for this operation. Immediate value must be 0

A1912E: In this instruction, register <field> must not be PC when flag-setting is

specified

A1913E: Specified operand type not allowed in this position

A1914E: Expected expression

A1915W: Relocation is not recommended on this instruction or directive

A1916E: Unknown built-in variable '<name>'

A1917E: Expected vector register expression

A1921E: Expected 8-bit byte register expression

A1922E: Expected 16-bit halfword register expression

A1923E: Expected list of vector registers

A1925E: Coprocessor number must be 14 or 15 on this architecture

A1927E: Expected core register, 64-bit extension register or vector register

A1931W: This instruction inside IT block is deprecated

A1932E: Register type not allowed on this architecture

A1933E: Option '<opt>' not supported on target architecture

2 Assembler Errors and Warnings

2.1 List of the armasm error and warning messages

reserved.

2-41

Non-Confidential

A1934E: Shift by <shift> not allowed. Permitted values are <allowed>

A1936E: Literal pool too distant, use LTORG to assemble it within <distance>

A1937E: Conversions to fixed point only support rounding mode Z

A1938E: Coprocessor number must be 14 on this architecture

A1939W: This mnemonic is deprecated

A1940E: Execute only is not compatible with <option>

A1941E: Unable to align to a non-multiple of <nopsize> using NOP instructions

A1942E: Data declarations are not permitted in execute-only sections

A1943E: INCBIN cannot be used in execute-only sections

A1944E: Literal pool entries cannot be generated in execute-only sections

A1992E: MOVT of external symbol must follow corresponding MOVW instruction

A1993E: This operator requires a relocation that is not supported in <objfmt>

A1994E: This directive is not supported in <objfmt>

A1995E: Weak definitions are not supported in <objfmt>

A1996E: TYPE must only be used after WEAK on IMPORT

A1997E: Expected alias for weak extern symbol

A1998E: Comdat Associated area must have Comdat Associative selection type

A1999E: Comdat Associated area cannot be another Comdat Associated area

2 Assembler Errors and Warnings

2.1 List of the armasm error and warning messages

reserved.

2-42

Non-Confidential

Chapter 3

Linker Errors and Warnings

Describes the error and warning messages for the linker, armlink.

It contains the following sections:

•3.1 Suppressing armlink error and warning messages on page 3-44.

•3.2 List of the armlink error and warning messages on page 3-45.

reserved.

3-43

Non-Confidential

3.1 Suppressing armlink error and warning messages

You can use command-line options to suppress or downgrade some of the diagnostic messages that the

linker produces.

All linker warnings are suppressible with --diag_suppress, in the same way as compiler warnings. For

example:

--diag_suppress 6306

Some errors such as L6220E, L6238E and L6784E can be downgraded to a warning by using:

--diag_warning

3 Linker Errors and Warnings

3.1 Suppressing armlink error and warning messages

reserved.

3-44

Non-Confidential

3.2 List of the armlink error and warning messages

A list of the error and warning messages that armlink produces.

Note

License-related error messages can be found in the 1.1 List of the licensing error and warning messages

on page 1-9 section.

L6000U: Out of memory.

This error is reported by RVCT v4.0 and earlier. For more details on why you might see this

error and possible solutions, see the description for error L6815U.

L6001U: Could not read from file <filename>.

L6002U: Could not open file <filename>: <reason>

This indicates that the linker was unable to open a file specified on the linker command line.

This can indicate a problem accessing the file or a fault with the command line. Some common

examples of this message are:

•L6002U: Could not open file /armlib/{libname}: No such file or directory

Specify the library path with --libpath.

•Error : armlink : L6002: Could not open file errors=ver.txt

This is caused by a missing double-dash (--) in front of errors=ver.txt. If you do not

prefix options with -- or -, the linker treats them as input files and fails the link step because

it is unable to load all the specified files.

See the following in the armlink User Guide:

--libpath=pathlist.

See the following in the Compiler User Guide:

Toolchain environment variables.

L6003U: Could not write to file <filename>.

An file I/O error occurred while reading, opening, or writing to the specified file.

L6004U: Incomplete library member list <list> for <library>.

This can occur if there is whitespace in the list of library objects.

The following example fails with Fatal error: L6004U: Missing library member in

member list for x.lib:

armlink x.lib(foo.o, bar.o)

The following example succeeds:

armlink x.lib(foo.o,bar.o)

Another less common cause is a corrupt library, or possibly a library in an unsupported format.

L6005U: Extra characters on end of member list for <library>.

L6006U: Overalignment value not specified with OVERALIGN attribute for execution

region <regionname>.

See the following in the armlink User Guide:

•Syntax of an input section description.

•Overalignment of execution regions and input sections.

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-45

Non-Confidential

L6007U: Could not recognize the format of file <filename>.

The linker can recognize object files in ELF format and library files in AR format. The specified

file is either corrupt, or is in a file format that the linker cannot recognize.

L6008U: Could not recognize the format of member <mem> from <lib>.

The linker can recognize library member objects in the ELF file format. The specified library

member is either corrupt, or is in a file format that the linker cannot recognize.

L6009U: File <filename> : Endianness mismatch.

The endianness of the specified file or object did not match the endianness of the other input

files. The linker can handle input of either big endian or little endian objects in a single link step,

but not a mixed input of some big and some little endian objects.

L6010U: Could not reopen stderr to file <filename>: <reason>

An file I/O error occurred while reading, opening, or writing to the specified file.

L6011U: Invalid integer constant : <number>.

Specifying an illegal integer constant causes this. An integer can be entered in hexadecimal

format by prefixing &, 0x, or 0X.

L6015U: Could not find any input files to link.

The linker must be provided with at least one object file to link.

For example, if you try to link with:

armlink lib.a -o foo.axf

the linker reports this error.

You must instead use, for example:

armlink foo_1.o foo_2.o lib.a -o foo.axf

L6016U: Symbol table missing/corrupt in object/library <object>.

This can occur when linking with libraries built with the GNU tools. This is because GNU ar

can generate incompatible information.

The workaround is to replace ar with armar and use the same command-line arguments.

Alternatively, the error is recoverable by using armar -s to rebuild the symbol table.

L6017U: Library <library> symbol table contains an invalid entry, no member at offset

0x<offset>.

The library might be corrupted. Try rebuilding it.

L6018U: <filename> is not a valid ELF file.

L6019U: <filename> is not a valid 64 bit ELF file.

L6020U: <filename> is not a valid 32 bit ELF file.

L6022U: Object <objname> has multiple <table>.

The object file is faulty or corrupted. This might indicate a compiler fault. Contact your supplier.

L6024U: Library <library> contains an invalid member name.

The file specified is not a valid library file, is faulty or corrupted. Try rebuilding it.

L6025U: Cannot extract members from a non-library file <library>.

The file specified is not a valid library file, is faulty or corrupted. Try rebuilding it.

L6026U: ELF file <filename> has neither little or big endian encoding

The ELF file is invalid. Try rebuilding it.

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-46

Non-Confidential

L6027U: Relocation #<rel_class>:<rel_number> in <objname>(<secname>) has invalid/

unknown type.

This might indicate a compiler fault. Contact your supplier.

L6028U: Relocation #<rel_class>:<rel_number> in <objname>(<secname>) has invalid

offset.

This might indicate a compiler fault. Contact your supplier.

L6029U: Relocation #<rel_class>:<rel_number> in <objname>(<secname>) is wrt invalid/

missing symbol.

The relocation is with respect to a symbol that is either:

• invalid or missing from the object symbol table

• a symbol that is not suited to be used by a relocation.

This might indicate a compiler fault. Contact your supplier.

L6030U: Overalignment <overalignment> for region <regname> must be at least 4 and a

power of 2

See the following in the armlink User Guide:

•Execution region attributes.

•Syntax of an input section description.

•Overalignment of execution regions and input sections.

L6031U: Could not open scatter description file <filename>: <reason>

An I/O error occurred while trying to open the specified file. This could be because of an invalid

filename.

L6032U: Invalid <text> <value> (maximum <max_value>) found in <object>

L6033U: Symbol <symbolname> in <objname> is defined relative to an invalid section.

L6034U: Symbol <symbolname> in <objname> has invalid value.

This is most often caused by a section-relative symbol having a value that exceeds the section

boundaries.

L6035U: Relocation #<rel_class>:<rel_number> in ZI Section <objname>(<secname>) has

invalid type.

ZI Sections cannot have relocations other than of type R_ARM_NONE.

L6036U: Could not close file <filename>: <reason>

An I/O error occurred while closing the specified file.

L6037U: '<arg>' is not a valid argument for option '<option>'.

The argument is not valid for this option. This could be because of a spelling error, or because of

the use of an unsupported abbreviation of an argument.

L6038U: Could not create a temporary file to write updated SYMDEFS.

An I/O error occurred while creating the temporary file required for storing the SYMDEFS

output.

L6039W: Relocation from #<rel_class>:<rel_number> in <objname>(<secname>) with

respect to <symname>. Skipping creation of R-type relocation. No corresponding R-type

relocation exists for type <rel_type>.

--reloc is used with objects containing relocations that do not have a corresponding R-type

relocation.

L6041U: An internal error has occurred (<clue>).

Contact your supplier.

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-47

Non-Confidential

L6042U: Relocation #<rel_class>:<rel_number> in <objname>(<secname>) is wrt a mapping

symbol(#<idx>, Last Map Symbol = #<last>).

Relocations with respect to mapping symbols are not permitted. This might indicate a compiler

fault. Contact your supplier.

L6043U: Relocation #<rel_class>:<rel_number> in <objname>(<secname>) is with respect

to an out of range symbol(#<val>, Range = 1-<max>).

Relocations can only be made with respect to symbols in the range (1-n), where n is the number

of symbols.

L6047U: The size of this image (<actual_size> bytes) exceeds the maximum allowed for

this version of the linker

L6048U: The linker is unable to continue the link step (<id>). This version of the

linker will not create this image.

L6049U: The linker is unable to continue the link step (<id>). This version of the

linker will not link with one or more given libraries.

L6050U: The code size of this image (<actual_size> bytes) exceeds the maximum allowed

for this version of the linker.

L6058E: Syntax error parsing linker script <script> at line <lineno> : <token>

The link ld script has a syntax error at the line number.

L6064E: ELF Executable file <filename> given as input on command line

This might be because you specified an object file as output from from the compiler without

specifying the -c compiler option. For example:

armclang --target aarch64-arm-none-eabi file.c -o file.o

armlink file.o -o file.axf

L6065E: Load region <name> (size <size>) is larger than maximum writable contiguous

block size of 0x80000000.

The linker attempted to write a segment larger than 2GB. The size of a segment is limited to

2GB.

L6175E: EMPTY region <regname> cannot have any section selectors.

L6176E: A negative max_size cannot be used for region <regname> without the EMPTY

attribute.

Only regions with the EMPTY attribute are permitted to have a negative max_size.

L6177E: A negative max_size cannot be used for region <regname> which uses the

+offset form of base address.

Regions using the +offset form of base address are not permitted to have a negative max-size.

L6188E: Special section <sec1> multiply defined by <obj1> and <obj2>.

A special section is one that can only be used once, such as "Veneer$$Code".

L6195E: Cannot specify both '<attr1>' and '<attr2>' for region <regname>

See the following in the armlink User Guide:

•Load region attributes.

•Execution region attributes.

•Inheritance rules for load region address attributes.

•Inheritance rules for execution region address attributes.

•Inheritance rules for the RELOC address attribute.

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-48

Non-Confidential

L6200E: Symbol <symbolname> multiply defined by <object1> and <object2>.

A common example of this:

Symbol __stdout multiply defined (by retarget.o and stdio.o).

This means that there are two conflicting definitions of __stdout present in retarget.o and

stdio.o. The one in retarget.o is your own definition. The one in stdio.o is the default

implementation, which was probably linked-in inadvertently.

stdio.o contains a number of symbol definitions and implementations of file functions like

fopen, fclose, and fflush.

stdio.o is being linked-in because it satisfies some unresolved references.

To identify why stdio.o is being linked-in, you must use the --verbose link option switch. For

example:

armlink [... your normal options...] --verbose --list err.txt

Then study err.txt to see exactly what the linker is linking in, from where, and why.

You might have to either:

• eliminate the calls like fopen, fclose, and fflush

• re-implement the _sys_xxxx family of functions.

See the following in the Arm® C and C++ Libraries and Floating-Point Support User Guide:

Tailoring input/output functions in the C and C++ libraries.

L6201E: Object <objname> contains multiple entry sections.

The input object specifies more than one entry point. Use the --entry command-line option to

select the entry point to use.

See the following in the armlink User Guide:

--entry=location.

L6202E: <objname>(<secname>) cannot be assigned to non-root region '<regionname>'

A root region is a region that has an execution address the same as its load address. The region

does not therefore require moving or copying by the scatter-load initialization code.

Certain sections must be placed in a root region in the image, including:

•__main.o.

• The linker-generated table (Region$$Table).

• Scatter-loading (__scatter*.o) objects from the library.

• Decompressor (__dc*.o) objects from the library.

If a required section is not placed in a root region, the linker reports, for example:

anon$$obj.o(Region$$Table) cannot be assigned to a non-root region 'RAM'.

You can use InRoot$$Sections to include all required sections in a root region:

ROM_LOAD 0x0000 0x4000

{

ROM_EXEC 0x0000 0x4000 ; root region

{

vectors.o (Vect, +FIRST) ; Vector table

* (InRoot$$Sections) ; All library sections

; that must be in a root region

; for example, __main.o, __scatter*.o,

; dc*.o and * Region$$Table

}

RAM 0x10000 0x8000

{

* (+RO, +RW, +ZI) ; all other sections

}

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-49

Non-Confidential

L6203E: Entry point (<address>) lies within non-root region <regionname>.

The image entry point must correspond to a valid instruction in a root-region of the image.

L6204E: Entry point (<address>) does not point to an instruction.

The image entry point you specified with the --entry command-line option must correspond to

a valid instruction in the root-region of the image.

See the following in the armlink User Guide:

--entry=location.

L6205E: Entry point (<address>) must be word aligned for ARM instructions.

This message is displayed because the image entry point you specified with the --entry

command-line option is not word-aligned. For example, you specified --entry=0x8001 instead

of --entry=0x8000.

See the following in the armlink User Guide:

--entry=location.

L6206E: Entry point (<address>) lies outside the image.

The image entry point you specified with the --entry command-line option is outside the

image. For example, you might have specified an entry address of 0x80000 instead of 0x8000,

as follows:

armlink --entry=0x80000 test.o -o test.axf

See the following in the armlink User Guide:

--entry=location.

L6208E: Invalid argument for --entry command: '<arg>'

See the following in the armlink User Guide:

--entry=location.

L6209E: Invalid offset constant specified for --entry (<arg>)

See the following in the armlink User Guide:

--entry=location.

L6210E: Image cannot have multiple entry points. (<address1>,<address2>)

One or more input objects specifies more than one entry point for the image. Use the --entry

command-line option to select the entry point to use.

See the following in the armlink User Guide:

--entry=location.

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-50

Non-Confidential

L6211E: Ambiguous section selection. Object <objname> contains more than one section.

This can occur when using the linker option --keep on an assembler object that contains more

than one AREA. The linker must know which AREA you want to keep.

To solve this, use more than one --keep option to specify the names of the AREAs to keep,

such as:

--keep boot.o(vectors) --keep boot.o(resethandler) …

Note

Using assembler files with more than one AREA might give other problems elsewhere, so this is

best avoided.

L6213E: Multiple First section <object2>(<section2>) not allowed.

<object1>(<section1>) already exists.

Only one FIRST section is permitted.

L6214E: Multiple Last section <object2>(<section2>) not allowed.

<object1>(<section1>) already exists.

Only one LAST section is permitted.

L6215E: Ambiguous symbol selection for --First/--Last. Symbol <symbol> has more than

one definition.

See the following in the armlink User Guide:

•--first=section_id.

•--last=section_id

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-51

Non-Confidential

L6216E: Cannot use base/limit symbols for non-contiguous section <secname>

The exception handling index tables that are generated by the compiler are placed in

SHT_ARM_EXIDX sections. For more information, see Exception Handling ABI for the Arm®

Architecture.

At link time these tables must be placed in the same execution region and be contiguous. If you

explicitly place these sections non-contiguously using specific selector patterns in your scatter

file, then this error message is likely to occur. For example:

LOAD_ROM 0x00000000

{

ER1 0x00000000

{

file1.o (+RO) ; from a C++ source

* (+RO)

}

ER2 0x01000000

{

file2.o (+RO) ; from a C++ source

}

ER3 +0

{

* (+RW, +ZI)

}

This might produce the following error if exception handling index tables are in both file1.o

and file2.o, because the linker cannot place them in separate regions:

Error: L6216E: Cannot use base/limit symbols for non-contiguous section .ARM.exidx

Also, the .init_array sections must be placed contiguously within the same region for their

base and limit symbols to be accessible.

The correct code is:

LOAD_ROM 0x00000000

{

ER1 0x00000000

{

file1.o (+RO) ; from a C++ source

*(0x70000001) ; The exception handling index tables must be placed

; explicitly in a single region. We use 0x70000001,

; the identifier of SHT_ARM_EXIDX, to collect all the

; exception tables into this execution region.

*(.init_array) ; Section .init_array must be placed

; explicitly, otherwise it is shared between

; two regions and the linker is unable to

; decide where to place it.

* (+RO)

}

ER2 0x01000000

{

file2.o (+RO) ; from a C++ source

}

ER3 +0

{

* (+RW, +ZI)

}

In this example, the base and limit symbols are contained in .init_array in a single region.

See the following in the Arm® C and C++ Libraries and Floating-Point Support User Guide:

C++ initialization, construction and destruction.

L6217E: Relocation #<rel_class>:<rel_number> in <objname>(<secname>) with respect to

<symbol>. R_ARM_SBREL32 relocation to imported symbol

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-52

Non-Confidential

L6218E: Undefined symbol <symbol> (referred from <objname>).

Some common examples of this are:

• User Error. There is a reference to an undefined or incorrectly defined symbol.

•Undefined symbol __ARM_switch8 or __ARM_ll_<xxxx> functions

The helper functions are automatically generated into the object file by the compiler.

Note

An undefined reference error can, however, still be generated if linking objects from legacy

projects where the helper functions are in the h_xxx libraries (h indicates that these are

compiler helper libraries, rather than standard C library code).

Re-compile the object or ensure that these libraries can be found by the linker.

• When attempting to refer to a function or entity in C from a function or entity in C++. This is

caused by C++ name mangling, and can be avoided by marking C functions extern "C".

•Undefined symbol thunk{v:0,-44} to Foo_i::~Foo_i() (referred from Bar_i.o)

The symbol thunk{v:0,-44} to Foo_i::~Foo_i() is a wrapper function round the regular

Foo_i::~Foo_i().

Foo_i is a derived class of some other base class, therefore:

— it has a base-class vtable for when it is referred to by a pointer to that base class

— the base-class vtable has an entry for the thunk

— the destructor thunk is output when the actual (derived class) destructor is output.

Therefore, to avoid the error, ensure this destructor is defined.

•Undefined symbol main (referred from kernel.o)

The linker is reporting that your application does not include a main() function.

L6219E: <type> section <object1>(<section1>) attributes {<attributes>} incompatible

with neighboring section <object2>(<section2>).

This error occurs when the default ordering rules used by the linker (RO followed by RW

followed by ZI) are violated. This typically happens when one uses +FIRST or +LAST, for

example in a scatter file, attempting to force RW before RO.

L6220E: <type> region <regionname> size (<size> bytes) exceeds limit (<limit> bytes).

Example:

Execution region ROM_EXEC size (4208184 bytes) exceeds limit (4194304 bytes).

This can occur where a region has been given an (optional) maximum length in the scatter file,

but the size of the code and data being placed in that region has exceeded the limit. This error is

suppressible with --diag_suppress 6220.

For example, this might occur when using .ANYnum selectors with the ALIGN directive in a

scatter file to force the linker to insert padding. You might be able to fix this using the

--any_contingency option.

See the following in the armlink User Guide:

•Placement of unassigned sections with the .ANY module selector.

•--any_contingency.

•--diag_suppress=tag[,tag,...].

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-53

Non-Confidential

L6221E: <type1> region <regionname1> with <addrtype1> range [<base1>,<limit1>)

overlaps with <type2> region <regionname2> with <addrtype2> range [<base2>,<limit2>).

This error can occur even though information in the scatter-loading description file and map

information generated by the linker indicate that the execution regions do not overlap.

In RVCT v4.0 and earlier, the linker did not provide as much information, making the message

harder to understand:

Warning L6221E: <type1> region <regionname1> overlaps with <type1> region

Example test.s file:

AREA area1, CODE

BX lr

AREA area2, READWRITE, NOINIT

SPACE 10

AREA area3, READWRITE

DCD 10

END

Example scatter.txt file:

LR1 0x8000

{

ER1 +0

{

*(+ro)

}

ER2 +0

{

*(+zi)

}

ER3 +0

{

*(+rw)

}

Built with:

armasm test.s

armlink -o test.axf --scatter scatter.txt test.o

Generates:

Warning: L6221E: Execution region ER2 with Execution range

[0x00008004,0x00008010) overlaps with Execution region ER3 with Load range

[0x00008004,0x00008008).

The linker might emit warning message L6221E when an execution region base address overlaps

with the load address of another region. This could be due to an incorrect scatter file. The

memory map of the image has a load view and an execution view, described by the scatter-

loading file. A non-ZI section must have a unique load address and in most cases must have a

unique execution address. From RVCT v3.1 onwards, the linker no longer assigns space to ZI

execution regions. Therefore this warning might be because a load region LR2 with a relative

base address immediately follows a ZI execution region in a load region LR1.

Because the overlapping part might not have real code or data inside, the warning might be

harmless.

From RVCT v4.0 build 821 onwards, you can use the following linker options to find out the

addresses of each region, and any regions that overlap with a load region:

--load_addr_map_info --map --list=map.txt

You can do one of the following:

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-54

Non-Confidential

• Ignore the warning, only if after analysis it is possible to determine that the execution region

is not going to corrupt the load region that has not yet been copied to its execution region

address. Also, debug the application to confirm that it initializes and executes correctly.

• Adjust the base addresses of the execution regions.

• Use the FIXED scatter-loading attribute to make the load regions and execution regions have

the same base addresses.

See the following in the armlink User Guide:

•Scatter files containing relative base address load regions and a ZI execution region.

•Execution region attributes.

•Root execution regions and the FIXED attribute.

L6222E: Partial object cannot have multiple ENTRY sections, <e_oname>(<e_sname>) and

<oname>(<sname>).

Where objects are being linked together into a partially-linked object, only one of the sections in

the objects can have an entry point.

Note

It is not possible in this case to use the linker option --entry to select one of the entry points.

L6223E: Ambiguous selectors found for <objname>(<secname>) from Exec regions

<region1> and <region2>.

This occurs if the scatter file specifies <objname>(<secname>) to be placed in more than one

execution region. This can occur accidentally when using wildcards (*). The solution is to make

the selections more specific in the scatter file.

L6224E: Could not place <objname>(<secname>) in any Execution region.

This occurs if the linker cannot match an input section to any of the selectors in your scatter file.

You must correct your scatter file by adding an appropriate selector.

See the following in the armlink User Guide:

Section placement with the linker.

L6225E: Number <str...> is too long.

L6226E: Missing base address for region <regname>.

L6227E: Using --reloc with --rw-base without --split is not allowed.

See the following in the armlink User Guide:

•--reloc.

•--rw_base=address.

•--split.

L6228E: Expected '<str1>', found '<str2>'.

L6229E: Scatter description <file> is empty.

L6230E: Multiple execution regions (<region1>,<region2>) cannot select <secname>.

L6231E: Missing module selector.

L6232E: Missing section selector.

L6233E: Unknown section selector '+<selector>'.

L6234E: <ss> must follow a single selector.

For example, in a scatter file:

* (+FIRST, +RO)

+FIRST means place this (single) section first. Selectors that can match multiple sections (for

example, +RO or +ENTRY) are not permitted to be used with +FIRST (or +LAST). If used together,

the error message is generated.

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-55

Non-Confidential

L6235E: More than one section matches selector - cannot all be FIRST/LAST.

See the following in the armlink User Guide:

•Section placement with the FIRST and LAST attributes.

•Syntax of an input section description.

L6236E: No section matches selector - no section to be FIRST/LAST.

The scatter file specifies a section to be +FIRST or +LAST, but that section does not exist, or has

been removed by the linker because it believes it to be unused. Use the linker option --info

unused to reveal which objects are removed from your project. Example:

ROM_LOAD 0x00000000 0x4000

{

ROM_EXEC 0x00000000

{

vectors.o (Vect, +First) << error here

* (+RO)

}

RAM_EXEC 0x40000000

{

* (+RW, +ZI)

}

Some possible solutions are:

• Ensure vectors.o is specified on the linker command line.

• Link with --keep vectors.o to force the linker not to remove this, or switch off this

optimization entirely, with --no_remove. Arm does not recommend this.

• Arm recommends that you add the ENTRY directive to vectors.s, to tell the linker that it is a

possible entry point for your application. For example:

AREA Vect, CODE

ENTRY ; define this as an entry point

Vector_table

...

Then link with --entry Vector_table to define the real start of your code.

See the following in the armlink User Guide:

•Section placement with the FIRST and LAST attributes.

•--entry=location.

•--info=topic[,topic,...].

•--keep=section_id.

•--remove, --no_remove.

•Syntax of an input section description.

See the following in the armasm User Guide:

ENTRY.

L6237E: <objname>(<secname>) contains relocation(s) to unaligned data.

L6238E: <objname>(<secname>) contains invalid call from '<attr1>' function to

'<attr2>' function <sym>.

This error is generated when Application Binary Interface (ABI) incompatibilities exist, such as:

• Attempting to link RWPI code with non-RWPI code.

• A function that does not preserve eight-byte alignment calls a function that requires eight-

byte alignment.

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-56

Non-Confidential

Example of a stack alignment conflict

This linker error is given when you specify the --strict_preserve8_require8 option

and a stack alignment conflict is detected in object code. The ABI for the Arm®

Architecture suggests that code maintains eight-byte stack alignment at its interfaces.

This alignment permits efficient use of LDRD and STRD instructions to access eight-byte

aligned double and long long data types.

Symbols such as ~PRES8 and REQ8 are used in place of Build Attributes of the objects:

•PRES8 means that the object preserves eight-byte alignment of the stack.

•~PRES8 means that the object does not preserve eight-byte alignment of the stack (~

meaning NOT).

•REQ8 means that the object requires eight-byte alignment of the stack.

This link error typically occurs in the following cases:

• You are assembling code that does not preserve eight-byte stack alignment and that

code calls compiled C/C++ code that requires eight-byte stack alignment.

• You are attempting to link legacy objects that have been compiled with older tools

with objects that are compiled with recent tools. Legacy objects that do not have

these attributes are treated as ~PRES8, even if they do preserve eight-byte alignment.

For example:

Error: L6238E: foo.o(.text) contains invalid call from '~PRES8 (The user

did not require code to preserve 8-byte aligment of 8-byte data objects)'

function to 'REQ8 (Code was permitted to depend on the 8-byte aligment of

8-byte data items)' function foobar.

This error means that a function (in the object foo.o, section .text) that does not

preserve eight-byte stack alignment, is trying to call function foobar that requires

eight-byte stack alignment.

A similar warning that might be encountered is:

Warning: L6306W: '~PRES8' section foo.o(.text) should not use the address of

'REQ8' function foobar

Where the address of an external symbol is being referred to.

There are two possible solutions to work around this issue:

• Rebuild all your objects and libraries.

If you have any assembler files, you must check that all instructions preserve eight-

byte stack alignment, and if necessary, correct them.

For example, change:

STMFD sp!, {r0-r3, lr} ; push an odd number of registers

STMFD sp!, {r0-r3, r12, lr} ; push even number of registers

If all instructions preserve eight-byte stack alignment, then armasm automatically

marks the object as preserving eight-byte alignment of the stack. Therefore, it is no

longer necessary to add the PRESERVE8 directive to the top of each armasm-style

assembler file.

The armclang integrated assembler does not automatically mark an object as

preserving eight-byte alignment of the stack. Therefore, you must check that your

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-57

Non-Confidential

GNU-style assembly code preserves eight-byte stack alignment. If it does, then add

the following directive to your assembly code:

.eabi_attribute Tag_ABI_align_preserved, 1

• You might have legacy objects and libraries that cannot be rebuilt for the following

reasons:

— You do not have the source code.

— The old objects must not be rebuilt (for example, for qualification and

certification reasons).

If you have objects and libraries that cannot be rebuilt, then you must inspect them

to check whether they preserve eight-byte alignment or not.

Use fromelf -c to disassemble the object code. C/C++ code that is compiled with

ADS 1.1 or later normally preserves eight-byte alignment, but assembled code does

not.

If your objects do preserve eight-byte alignment, then you can suppress the linker

error L6238E with the use of --diag_suppress 6238 on the linker command line.

By using the --diag_suppress 6238 option, you are guaranteeing that these

objects preserve eight-byte alignment.

The linker warning L6306W is suppressible with --diag_suppress 6306.

See also:

•8 Byte Stack Alignment FAQ.

•--strict_preserve8_require8 in the armlink User Guide.

L6239E: Cannot call non-interworking <t2> symbol '<sym>' in <obj2> from <t1> code in

<obj1>(<sec1>)

Example:

Cannot call non-interworking ARM symbol 'ArmFunc' in object foo.o from THUMB code in

bar.o(.text)

This problem can be caused by foo.c not being compiled with the option --apcs /interwork,

to enable A32 code to call T32 code (and T32 to A32) by linker-generated interworking veneers.

L6241E: <objname>(<secname>) cannot use the address of '<attr1>' function <sym> as

the image contains '<attr2>' functions.

When linking with --strict, the linker reports conditions that might fail as errors, for example:

Error: L6241E: foo.o(.text) cannot use the address of '~IW' function main as the

image contains 'IW' functions.

IW means interworking, and ~IW means non-interworking.

L6242E: Cannot link object <objname> as its attributes are incompatible with the

image attributes.

Each object file generated by the compilation tools includes a set of attributes that indicates the

options that it was built with. The linker checks the attributes of each object file it processes. If

it finds attributes that are incompatible with those of object files it has loaded previously, it

generates this error.

There are two common reasons for this error:

• Object files compiled with incompatible options. For example:

— attempting to link one file compiled for Cortex‑A processors, with another file compiled

for Cortex‑M processors.

— attempting to link files that have incompatible FPU options.

• Linking objects that have been compiled with an older toolchain that uses an incompatible

ABI. See Are legacy objects and libraries compatible with my project? for more information.

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-58

Non-Confidential

L6243E: Selector only matches removed unused sections - no section to be FIRST/LAST.

All sections matching this selector have been removed from the image because they were

unused. For more information, use --info unused.

L6244E: <type> region <regionname> address (<addr>) not aligned on a <align> byte

boundary.

L6245E: Failed to create requested ZI section '<name>'.

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-59

Non-Confidential

L6248E: <objname>(<secname>) in <attr1> region '<r1>' cannot have <rtype> relocation

to <symname> in <attr2> region '<r2>'.

This error can occur when you are trying to build position-independent (PI) code. Consider, for

example the following code:

#include <stdio.h>

char *str = "test";

int main(void)

{

printf ("%s",str);

}

When you compile and link this using:

armcc -c --apcs /ropi/rwpi pi.c

armlink --ropi --rwpi pi.o

the linker reports the following error message:

Error: L6248E: pi.o(.data) in PI region 'ER_RW' cannot have address type relocation

to .conststring in PI region 'ER_RO'.

This is because the compiler generates a global pointer str that must be initialized to the

address of the string in the .conststring section. However, absolute addresses cannot be used

in a PI system, so the link step fails.

To resolve this, you must re-write the code to avoid the explicit pointer. You can do this using

either of the following methods:

• Use a global array instead of a global pointer, for example:

#include <stdio.h>

const char str[] = "test";

int main(void)

{

printf ("%s",str);

}

• Use a local pointer instead of a global pointer, for example:

#include <stdio.h>

int main(void)

{

char *str = "test";

printf ("%s",str);

}

Note

If you are using an array of pointers, such as:

char * list[] = {"zero", "one", "two"};

the linker reports a separate error for each element in the array. In this case, Arm recommends

you declare a two dimensional array for the list, with the first dimension as the number of

elements in the array, and the second dimension as the maximum size of an element in the array,

for example:

char list[3][5] = {"zero", "one", "two"};

You must change the printf() statement to, for example:

printf("%s", list[1]);

See compiler error number 1359.

L6249E: Entry point (<address>) lies within multiple sections.

L6250E: Object <objname> contains illegal definition of special symbol <symbol>.

L6251E: Object <objname> contains illegal reference to special symbol <symbol>.

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-60

Non-Confidential

L6252E: Invalid argument for --xreffrom/--xrefto command: '<arg>'

L6253E: Invalid SYMDEF address: <number>.

L6254E: Invalid SYMDEF type : <type>.

The content of the symdefs file is invalid.

See the following in the armlink User Guide:

Symdefs file format.

L6255E: Could not delete file <filename>: <reason>

An I/O error occurred while trying to delete the specified file. The file was either read-only, or

was not found.

L6257E: <object>(<secname>) cannot be assigned to overlaid Execution region

'<ername>'.

This message indicates a problem with the scatter file.

See the following in the armlink User Guide:

Scatter file syntax.

L6258E: Entry point (<address>) lies in an overlaid Execution region.

This message indicates a problem with the scatter file.

See the following in the armlink User Guide:

Scatter file syntax.

L6259E: Reserved Word '<name>' cannot be used as a <type> region name.

<name> is a reserved word, so choose a different name for your region.

L6260E: Multiple load regions with the same name (<regionname>) are not allowed.

This message indicates a problem with the scatter file.

See the following in the armlink User Guide:

Scatter file syntax.

L6261E: Multiple execution regions with the same name (<regionname>) are not allowed.

This message indicates a problem with the scatter file.

See the following in the armlink User Guide:

Scatter file syntax.

L6263E: <addr> address of <regionname> cannot be addressed from <pi_or_abs> Region

Table in <regtabregionname>

The Region Table contains information used by the C-library initialization code to copy,

decompress, or create ZI. This error message is given when the scatter file specifies an image

structure that cannot be described by the Region Table.

The error message is most common when PI and non-PI load regions are mixed in the same

image.

L6265E: Non-PI Section <obj>(<sec>) cannot be assigned to PI Exec region <er>.

This might be caused by explicitly specifying the wrong Arm library on the linker command-

line. Either:

• Remove the explicit specification of the Arm library.

• Replace the library, for example, c_t.l, with the correct library.

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-61

Non-Confidential

L6266E: RWPI Section <obj>(<sec>) cannot be assigned to non-PI Exec region <er>.

A file compiled with --apcs=/rwpi is placed in an execution region that does not have the PI

attribute.

L6271E: Two or more mutually exclusive attributes specified for Load region <regname>

This message indicates a problem with the scatter file.

L6272E: Two or more mutually exclusive attributes specified for Execution region

This message indicates a problem with the scatter file.

L6273E: Section <objname>(<secname>) has mutually exclusive attributes (READONLY and

ZI)

This message indicates a problem with the object file.

L6275E: COMMON section <obj1>(<sec1>) does not define <sym> (defined in

<obj2>(<sec2>))

Given a set of COMMON sections with the same name, the linker selects one of them to be added to

the image and discards all others. The selected COMMON section must define all the symbols

defined by any rejected COMMON section, otherwise a symbol that was defined by a rejected

section would become undefined again. The linker generates an error if the selected copy does

not define a symbol that a rejected copy does. This error is normally caused by a compiler fault.

Contact your supplier.

L6276E: Address <addr> marked both as <s1>(from <sp1>(<obj1>) via <src1>) and

<s2>(from <sp2>(<obj2>) via <src2>).

The image cannot contain contradictory mapping symbols for a given address, because the

contents of each word in the image are uniquely typed as A32 ($a) or T32 ($t) code, DATA

($d), or NUMBER. It is not possible for a word to be both A32 code and DATA. This might

indicate a compiler fault. Contact your supplier.

L6277E: Unknown command '<cmd>'.

L6278E: Missing expected <str>.

L6279E: Ambiguous selectors found for <sym> ('<sel1>' and '<sel2>').

L6280E: Cannot rename <sym> using the given patterns.

See the following in the armlink User Guide:

RENAME steering file command.

L6281E: Cannot rename both <sym1> and <sym2> to <newname>.

See the following in the armlink User Guide:

RENAME steering file command.

L6282E: Cannot rename <sym> to <newname> as a global symbol of that name exists

(defined) in <obj>).

See the following in the armlink User Guide:

RENAME steering file command.

L6283E: Object <objname> contains illegal local reference to symbol <symbolname>.

An object cannot contain a reference to a local symbol, because local symbols are always

defined within the object itself.

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-62

Non-Confidential

L6285E: Non-relocatable Load region <lr_name> contains R-Type dynamic relocations.

First R-Type dynamic relocation found in <object>(<secname>) at offset 0x<offset>.

This error occurs where there is a PI reference between two separate segments, if the two

segments can be moved apart at runtime. When the linker sees that the two sections can be

moved apart at runtime it generates a relocation (an R-Type relocation) that can be resolved if

the sections are moved from their statically linked address. However the linker faults this

relocation (giving error L6285E) because PI regions must not have relocations with respect to

other sections as this invalidates the criteria for being position independent.

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-63

Non-Confidential

L6286E: Relocation #<rel_class>:<rel_number> in <objname>(<secname>) with respect to

{symname|%s}. Value(<val>) out of range(<range>) for (<rtype>)

This error typically occurs in the following situations:

• In handwritten assembly code, where there are not enough bits within the instruction opcode

to hold the offset to a symbol.

For example, the offset range is ±4095 for an A32 state LDR or STR instruction.

• When the linker is having difficulty placing veneers around a large code section in your

image.

When the linker places a veneer near a very large section it must decide whether to place the

veneer before or after the section. When the linker has placed the veneer it might have to

place more veneers, which could be placed between the original veneer and its target. This

would increase the distance between the veneer and its target.

The linker automatically allows for modest increases in distances between veneers and their

targets. However, a large number of veneers placed between the original veneer and its target

might result in the target moving out of range. If this occurs, the linker generates message

L6286E.

To work around this, you can move large code sections away from areas where the linker is

placing many veneers. This can be done either by placing large sections in their own regions

or by placing them first in the region they are located in using the +FIRST directive in the

scatter-loading description file.

For example:

LOAD 0x0A000000 0x1000000

{

ROM1 +0x0

{

*(+RO)

}

This can be changed to:

LOAD 0x0A000000 0x1000000

{

ROM1 +0x0

{

*(+RO)

}

ROM1A +0x0

{

large.o (+RO)

}

• When .ARM.exidx exception-handling index tables are placed in different execution regions,

or too far from exception handling code.

The .ARM.exidx exception-handling index tables must be located in a single execution

region. Also, the distance from these tables to the C++ code that uses C++ exception

handling must be within the range -0x40000000 to 0x3fffffff. Otherwise, the linker reports

the following error:

L6286: Value(0x9ff38980) out of range(-0x9ff38980) out of range(-0x40000000

- 0x3fffffff) for relocation #0 (R_ARM_PREL31), wrt symbol xxx in

XXXX.o(.ARM.exidx)

This behavior is specified in the Exception Handling ABI for the Arm® Architecture

(EHABI). The EHABI states that the R_ARM_PREL31 relocation, which .ARM.exidx uses,

does not use the highest bit (bit 31) for calculating the relocation.

The most likely cause of this is that C++ code that must access the .ARM.exidx sections, has

been split and placed into separate execution regions, outside of the valid range

(-0x40000000 to 0x3fffffff).

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-64

Non-Confidential

To resolve this error, if you have memory between the separated execution regions, place

the .ARM.exidx section there with the selector *(.ARM.exidx). For example:

LOAD_ROM 0x00000000

{

ER1 0x00000000 ; The distance from ER2 to ER1 is out of

{ ; range.

file1.o (+RO) ; From a C++ source.

* (+RO)

}

ERx 0x30000000

{

*(.ARM.exidx) ; ARM.exidx to ER1 and ER2 both in range.

}

ER2 0x60000000

{

file2.o (+RO) ; From a C++ source.

}

ER3 +0

{

* (+RW, +ZI)

}

Otherwise, try placing the code into an execution region close enough to the tables (within

the range of -0x40000000 to 0x3fffffff).

In other cases, make sure you have the latest patch installed from Downloads.

For more information, see the following:

What does "Error: L6286E: Value out of range for relocation" mean?

Exception Handling ABI for the Arm® Architecture.

L6287E: Illegal alignment constraint (<align>) specified for <objname>(<secname>).

An illegal alignment was specified for an ELF object.

L6291E: Cannot assign Fixed Execution Region <ername> Load Address:<addr>. Load

Address must be greater than or equal to next available Load Address:<load_addr>.

See the following in the armlink User Guide:

Execution region attributes.

L6292E: Ignoring unknown attribute '<attr>' specified for region <regname>.

This error message is specific to execution regions with the FIXED attribute. FIXED means make

the load address the same as the execution address. The linker can only do this if the execution

address is greater than or equal to the next available load address within the load region.

See the following in the armlink User Guide:

•Root execution regions and the FIXED attribute.

•Execution region attributes.

L6294E: <type> region <regionname> spans beyond 32 bit address space (base <base>,

size <size> bytes).

This error message relates to a problem with the scatter file.

L6295E: Relocation #<rel_class>:<rel_number> in <objname>(<secname>) with respect to

<symname> SBREL relocation requires image to be RWPI

L6296E: Definition of special symbol <sym1> is illegal as symbol <sym2> is absolute.

See L6188E.

L6300W: Common section <object1>(<section1>) is larger than its definition

<object2>(<section2>).

This might indicate a compiler fault. Contact your supplier.

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-65

Non-Confidential

L6301W: Could not find file <filename>: <reason>

The specified file was not found in the default directories.

L6302W: Ignoring multiple SHLNAME entry.

There can be only one SHLNAME entry in an edit file. Only the first such entry is accepted by the

linker. All subsequent SHLNAME entries are ignored.

L6304W: Duplicate input file <filename> ignored.

The specified filename occurred more than once in the list of input files.

L6305W: Image does not have an entry point. (Not specified or not set due to multiple

choices.)

The entry point for the ELF image was either not specified, or was not set because there was

more than one section with an entry point linked-in. You must use linker option --entry to

specify the single, unique entry, for example:

--entry 0x0

--entry <label>

The label form is typical for an embedded system.

L6306W: '<attr1>' section <objname>(<secname>) should not use the address of

'<attr2>' function <sym>.

See L6238E.

L6307W: Relocation #<rel_class>:<rel_num> in <objname>(<secname>) with respect to

<sym>. Branch to unaligned destination.

L6308W: Could not find any object matching <membername> in library <libraryname>.

The name of an object in a library is specified on the link-line, but the library does not contain

an object with that name.

L6309W: Library <libraryname> does not contain any members.

A library is specified on the linker command-line, but the library does not contain any members.

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-66

Non-Confidential

L6310W: Unable to find ARM libraries.

This is most often caused by incorrect arguments to --libpath.

Set the correct path with the --libpath linker option. The default path for a Windows

installation is:

install_directory\lib

Ensure this path does not include any of the following:

•\armlib

•\cpplib

• any trailing slashes (\) at the end. These are added by the linker automatically.

Use --verbose or --info libraries to display where the linker is attempting to locate the

libraries.

See the following in the armlink User Guide:

•--info=topic[,topic,...].

•--libpath=pathlist.

•--verbose.

See the following in the Compiler User Guide:

•Toolchain environment variables.

L6311W: Undefined symbol <symbol> (referred from <objname>).

See L6218E.

L6312W: Empty <type> region description for region <region>

L6313W: Using <oldname> as an section selector is obsolete. Please use <newname>

instead.

For example, use of IWV$$Code within the scatter file is obsolete. Replace IWV$$Code with

Veneer$$Code.

L6314W: No section matches pattern <module>(<section>).

For example:

No section matches pattern foo.*o(ZI).

This can be caused by any of the following:

• The file foo.o is mentioned in your scatter file, but it is not listed on the linker command

line. To resolve this, add foo.o to the link line.

• You are trying to place the ZI data of foo.o using a scatter file, but foo.o does not contain

any ZI data. To resolve this, remove the +ZI attribute from the foo.o line in your scatter file.

• You have used __attribute__((at(address))) in your source code to place code and data

at a specific address. You have also specified *(.ARM.__AT_address) in a scatter file, but

you have not specified the address as eight hexadecimal digits. For example, if you specify

__attribute__((at(0x10000))) in your source code, then you must specify the section

name as *(.ARM.__AT_0x00010000) in the scatter file.

See the following in the armlink User Guide:

•Methods of placing functions and data at specific addresses.

•Placement of sections at a specific address with __at.

L6315W: Ignoring multiple Build Attribute symbols in Object <objname>.

An object can contain at most one absolute BuildAttribute$$... symbol. Only the first such

symbol from the object symbol table is accepted by the linker. All subsequent ones are ignored.

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-67

Non-Confidential

L6316W: Ignoring multiple Build Attribute symbols in Object <objname> for section

<sec_no>

An object can contain at most one BuildAttribute$$... symbol applicable to a given section.

Only the first such symbol from the object symbol table is accepted by the linker. All

subsequent ones are ignored.

L6317W: <objname>(<secname>) should not use the address of '<attr1>' function <sym>

as the image contains '<attr2>' functions.

L6318W: <objname>(<secname>) contains branch to a non-code symbol <sym>.

This warning means that in the (usually assembler) file, there is a branch to a non-code symbol

(in another AREA) in the same file. This is most likely a branch to a label or address where there

is data, not code.

For example:

AREA foo, CODE

B bar

AREA bar, DATA

DCD 0

END

This results in the message:

init.o(foo) contains branch to a non-code symbol bar.

If the destination has no name:

BL 0x200 ; Branch with link to 0x200 bytes ahead of PC

the following message is displayed:

bootsys.o(BOOTSYS_IVT) contains branch to a non-code symbol <Anonymous Symbol>.

This warning can also appear when linking objects generated by GCC. GCC uses linker

relocations for references internal to each object. The targets of these relocations might not have

appropriate mapping symbols that permit the linker to determine whether the target is code or

data, so a warning is generated. By contrast, armcc resolves all such references at compile-time.

L6319W: Ignoring <cmd> command. Cannot find section <objname>(<secname>).

For example, when building a Linux application, you might have:

--keep *(.init_array)

on the linker command-line in your makefile, but this section might not be present when

building with no C++, in which case this warning is reported:

Ignoring --keep command. Cannot find section *(.init_array)

You can often ignore this warning, or suppress it with --diag_suppress 6319.

L6320W: Ignoring <cmd> command. Cannot find argument '<argname>'.

L6323W: Relocation #<rel_class>:<rel_number> in <objname>(<secname>) with respect to

<sym>. Multiple variants exist. Using the <type> variant to resolve ambiguity

L6324W: Ignoring <attr> attribute specified for Load region <regname>.

This attribute is applicable to execution regions only. If specified for a Load region, the linker

ignores it.

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-68

Non-Confidential

L6325W: Ignoring <attr> attribute for region <regname> which uses the +offset form of

base address.

This attribute is not applicable to regions using the +offset form of base address. If specified

for a region, which uses the +offset form, the linker ignores it.

A region that uses the +offset form of base address inherits the PI, RELOC, or OVERLAY

attributes from either:

• the previous region in the description

• the parent load region if it is the first execution region in the load region.

See the following in the armlink User Guide:

•Inheritance rules for load region address attributes.

•Inheritance rules for execution region address attributes.

•Inheritance rules for the RELOC address attribute.

L6326W: Ignoring ZEROPAD attribute for non-root execution region <ername>.

ZEROPAD only applies to root execution regions. A root region is a region whose execution

address is the same as its load address, and so does not require moving or copying at run-time.

See the following in the armlink User Guide:

Execution region attributes.

L6329W: Pattern <module>(<section>) only matches removed unused sections.

All sections matching this pattern have been removed from the image because they were

unused. For more information, use --info unused.

See the following in the armlink User Guide:

•Elimination of unused sections.

•--info=topic[,topic,...].

L6330W: Undefined symbol <symbol> (referred from <objname>). Unused section has been

removed.

This means that an unused section has had its base and limit symbols referenced. For more

information, use --info unused.

See the following in the armlink User Guide:

•Elimination of unused sections.

•--info=topic[,topic,...].

L6331W: No eligible global symbol matches pattern <pat>.

L6332W: Undefined symbol <sym1> (referred from <obj1>). Resolved to symbol <sym2>.

L6334W: Overalignment <overalignment> for region <regname> cannot be negative.

See the following in the armlink User Guide:

Overalignment of execution regions and input sections.

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-69

Non-Confidential

L6335W: ARM interworking code in <objname>(<secname>) may contain invalid tailcalls

to ARM non-interworking code.

The compiler is able to perform tailcall optimization for improved code size and performance.

However, there is a problematic sequence for Armv4T code in which a T32 interworking (IW)

function calls (by a veneer) an A32 IW function, which tailcalls an A32 non-interworking (~IW)

function. The return from the A32 non-IW function can pop the return address off the stack into

the PC instead of using the correct BX instruction. The linker can detect this situation and report

this warning.

T32 IW tailcalls to T32 non-IW do not occur because T32 tailcalls with B are so short ranged

that they can only be generated to functions in the same ELF section which must also be T32.

The warning is pessimistic in that an object might contain invalid tailcalls, but the linker cannot

be sure because it only looks at the attributes of the objects, not at the contents of their sections.

To avoid the warning, either recompile your entire code base, including any user libraries, with

--apcs /interwork, or manually inspect the A32 IW function to check for tailcalls (that is,

where function calls are made using an ordinary branch B instruction), to check whether this is a

real problem. This warning can be suppressed with --diag_suppress L6335W.

L6337W: Common code sections <o1>(<s1>) and <o2>(<s2>) have incompatible floating-

point linkage

L6339W: Ignoring RELOC attribute for execution region <er_name>.

Execution regions cannot explicitly be given the RELOC attribute. They can only gain this

attribute by inheriting it from the parent load region or the previous execution region if using the

+offset form of addressing.

See the following in the armlink User Guide:

Execution region attributes.

L6340W: options first and last are ignored for link type of <linktype>

The --first and --last options are meaningless when creating a partially-linked object.

L6366E: <object> attributes<attr> are not compatible with the provided cpu and fpu

attributes<cli> <diff>.

L6367E: <object>(<section>) attributes<attr> are not compatible with the provided cpu

and fpu attributes<cli> <diff>

L6368E: <symbol> defined in <object>(<section>) attributes<attr> are not compatible

with the provided cpu and fpu attributes<cli> <diff>

L6369E: <symbol> defined in <object>(ABSOLUTE) are not compatible with the provided

cpu and fpu Attributes<cli> <diff>

L6370E: cpu <cpu> is not compatible with fpu <fpu>

See the following in the armlink User Guide:

•--cpu=name.

•--fpu=name.

L6371E: Adding attributes from cpu and fpu: <attrs>

L6372E: Image needs at least one load region.

L6373E: libattrs.map file not found in System Library directory <dir>. Library

selection may be impaired.

L6384E: No Load Execution Region of name <region> seen yet at line <line>.

This might be because you have used the current base address in a limit calculation in a scatter

file. For example:

ER_foo 0 ImageBase(ER_foo)

L6385W: Addition overflow on line <line>

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-70

Non-Confidential

L6386E: Exec Region Expressions can only be used in base address calculations on line

<line>

L6387E: Load Region Expressions can only be used in ScatterAssert expressions on line

<line>

See the following in the armlink User Guide:

ScatterAssert function and load address related functions.

L6388E: ScatterAssert expression <expr> failed on line <line>

See the following in the armlink User Guide:

ScatterAssert function and load address related functions.

L6389E: Load Region <name> on line <line> not yet complete, cannot use operations

that depend on length of region

L6390E: Conditional operator (expr) ? (expr) : (expr) on line <line> has no : (expr).

See the following in the armlink User Guide:

•About Expression evaluation in scatter files.

•Expression rules in scatter files.

L6404W: FILL value preferred to combination of EMPTY, ZEROPAD and PADVALUE for

Execution Region <name>.

See the following in the armlink User Guide:

Execution region attributes.

L6405W: No .ANY selector matches Section <name>(<objname>).

See the following in the armlink User Guide:

Placement of unassigned sections with the .ANY module selector.

L6406W: No space in execution regions with .ANY selector matching Section

<name>(<objname>).

This occurs if there is not sufficient space in the scatter file regions containing .ANY to place the

section listed. You must modify your scatter file to ensure there is sufficient space for the

section.

See the following in the armlink User Guide:

Placement of unassigned sections with the .ANY module selector.

L6407W: Sections of aggregate size 0x<size> bytes could not fit into .ANY

selector(s).

This warning identifies the total amount of image data that cannot be placed in any .ANY

selectors.

For example, .ANY(+ZI) is placed in an execution region that is too small for the amount of ZI

data:

ROM_LOAD 0x8000

{

ROM_EXEC 0x8000

{

.ANY(+RO,+RW)

}

RAM +0 0x{...} <<< region max length is too small

{

.ANY(+ZI)

}

See the following in the armlink User Guide:

Placement of unassigned sections with the .ANY module selector.

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-71

Non-Confidential

L6408W: Output is --fpic yet section <sec> from <obj> has no FPIC attribute.

L6409W: Output is --fpic yet object <obj> has no FPIC attribute.

L6410W: Symbol <sym> with non STV_DEFAULT visibility <vis> should be resolved

statically, cannot use definition in <lib>.

L6411W: No compatible library exists with a definition of startup symbol <name>.

L6412W: Disabling merging for section <sec> from object <obj>, non R_ARM_ABS32

relocation from section <srcsec> from object <srcobj>

L6413W: Disabling merging for section <sec> from object <obj>, Section contains

misaligned string(s).

L6414E: --ropi used without --rwpi or --rw-base.

This error relates to options that are unsupported in Arm Compiler 6.0.

L6415E: Could not find a unique set of libraries compatible with this image. Suggest

using the --cpu option to select a specific library.

See the following in the armlink User Guide:

--cpu=name.

L6416E: Relocation <type> at <relclass>:<idx> <objname>(<secname>) cannot be veneered

as it has an offset <offset> from its target.

L6417W: Relocation #<rel_class>:<rel_number> in <objname>(<secname>) is with respect

to a reserved tagging symbol(#<idx>).

L6418W: Tagging symbol <symname> defined in <objname>(<secname>) is not recognized.

L6419W: Undefined symbol <symbol> (referred from <objname>) imported.

L6420E: Ignoring <oepname>(<secname>:<secnum>) as it is not of a recognized type.

L6422U: PLT generation requires an architecture with ARM instruction support.

For the linker to generate a Procedure Linkage Table (PLT), you must be using a target that

supports the A32 instruction set. For example, the linker cannot generate a PLT for a Cortex‑M3

target.

L6423E: Within the same collection, section <secname> cannot have different sort

attributes.

L6424E: Within the same collection, section <secname1> and section <secname2> cannot

be separated into different execution regions.

L6425E: Within the same collection, section <secname> cannot have their section names

with different length.

L6426E: Within the same collection, section <secname> cannot have its name

duplicated.

L6427E: Cannot rename <sym> to <newname> as it has already been renamed to <name>).

L6429U: Attempt to set maximum number of open files to <val> failed with error code

<error>.

An attempt to increase the number of file handles armlink can keep open at any one time has

failed.

L6431W: Ignoring incompatible enum size attribute on Symbol <symbol> defined in

L6432W: Ignoring incompatible enum size attribute on Object <object>(<section>).

L6433W: Ignoring incompatible enum size attribute on object <object>.

L6434W: Ignoring incompatible wchar_t size attribute on Symbol <symbol> defined in

L6435W: Ignoring incompatible wchar_t size attribute on Section <object>(<section>).

L6436W: Ignoring incompatible wchar_t size attribute on object <object>.

L6437W: Relocation #<rel_class>:<idx> in <objname>(<secname>) with respect to

<armsym>. Branch relocation to untyped symol in object <armobjname>, target state

unknown.

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-72

Non-Confidential

L6438E: __AT section <objname>(<secname>) address <address> must be at least 4 byte

aligned.

L6439W: Multiply defined Global Symbol <sym> defined in <objname>(<secname>) rejected

in favour of Symbol defined in <selobj>(<selsec>).

L6440E: Unexpected failure in link-time code generation

L6441U: System call to get maximum number of open files failed <error>.

L6442U: Linker requires a minimum of <min> open files, current system limit is <max>

files.

L6443W: Data Compression for region <region> turned off. Region contains reference to

symbol <symname> which depends on a compressed address.

The linker requires the contents of a region to be fixed before it can be compressed and cannot

modify it after it has been compressed. Therefore a compressible region cannot refer to a

memory location that depends on the compression process.

L6444I: symbol visibility : <symname> set to <visibility>.

L6445I: symbol visibility : <symname> merged to <set_vis> from existing <old_vis> and

new <new_vis>.

L6447E: SHT_PREINIT_ARRAY sections are not permitted in shared objects.

L6448W: While processing <filename>: <message>

L6449E: While processing <filename>: <message>

L6450U: Cannot find library <libname>.

L6451E: <object> built permitting Thumb is forbidden in an ARM-only link.

L6452E: <object>(<section>) built permitting Thumb is forbidden in an ARM-only link.

L6453E: <symbol> defined in <object>(<section>) built permitting Thumb is forbidden

in an ARM-only link.

L6454E: <symbol> defined in <object>(ABSOLUTE) built permitting Thumb is forbidden in

an ARM-only link.

L6455E: Symbol <symbolname> has deprecated ARM/Thumb Synonym definitions (by

<object1> and <object2>).

L6459U: Could not create temporary file.

L6462E: Reference to <sym> from a shared library only matches a definition with

Hidden or Protected Visibility in Object <obj>.

L6463U: Input Objects contain <archtype> instructions but could not find valid target

for <archtype> architecture based on object attributes. Suggest using --cpu option to

select a specific cpu.

See the following in the armlink User Guide:

--cpu=name.

L6464E: Only one of --emit-relocs and --emit-debug-overlay-relocs can be selected.

See the following in the armlink User Guide:

•--emit_debug_overlay_relocs.

•--emit_relocs.

L6467W: Library reports remark: <msg>

L6468U: Only --pltgot=direct or --pltgot=none supported for --base_platform with

multiple Load Regions containing code.

See the following in the armlink User Guide:

•--base_platform.

•--pltgot=type.

L6469E: --base_platform does not support RELOC Load Regions containing non RELOC

Execution Regions. Please use +0 for the Base Address of Execution Region <ername> in

Load Region <lrname>.

See the following in the armlink User Guide:

•--base_platform.

•Inheritance rules for the RELOC address attribute.

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-73

Non-Confidential

L6470E: PLT section <secname> cannot be moved outside Load Region <lrname>.

L6471E: Branch Relocation <rel_class>:<idx> in section <secname> from object

<objname> refers to ARM Absolute <armsym> symbol from object <armobjname>, Suppress

error to treat as a Thumb address.

L6475W: IMPORT/EXPORT commands ignored when --override_visibility is not specified

The symbol you are trying to export, either with an EXPORT command in a steering file or with

the --undefined_and_export command-line option, is not exported because of low visibility.

See the following in the armlink User Guide:

•--override_visibility.

•--undefined_and_export=symbol.

•EXPORT.

L6616E: Cannot increase size of RegionTable <sec_name> from <obj_name>

L6617E: Cannot increase size of ZISectionTable <sec_name> from <obj_name>

L6629E: Unmatched parentheses expecting ) but found <character> at position <col> on

line <line>

This message indicates a parsing error in the scatter file.

L6630E: Invalid token start expected number or ( but found <character> at position

This message indicates a parsing error in the scatter file.

L6631E: Division by zero on line <line>

This message indicates an expression evaluation error in the scatter file.

L6632W: Subtraction underflow on line <line>

This message indicates an expression evaluation error in the scatter file.

L6634E: Pre-processor command in '<filename>'too long, maximum length of <max_size>

This message indicates a problem with pre-processing the scatter file.

L6635E: Could not open intermediate file '<filename>' produced by pre-processor:

This message indicates a problem with pre-processing the scatter file.

L6636E: Pre-processor step failed for '<filename>'

This message indicates a problem with pre-processing the scatter file.

L6637W: No input objects specified. At least one input object or library(object) must

be specified.

At least one input object or library(object) must be specified.

L6638U: Object <objname> has a link order dependency cycle, check sections with

SHF_LINK_ORDER

L6640E: PDTTable section not least static data address, least static data section is

Systems that implement shared libraries with RWPI use a process data table (PDT). It is created

at static link time by the linker and must be placed first in the data area of the image.

This message indicates that the scatter file does not permit placing the PDT first in the data area

of the image.

To avoid the message, adjust your scatter file so that the PDT is placed correctly. This message

can also be triggered if you accidentally build object files with --apcs=/rwpi.

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-74

Non-Confidential

L6642W: Unused virtual function elimination might not work correctly, because

<obj_name> has not been compiled with --vfe

L6643E: The virtual function elimination information in section <sectionname> refers

to the wrong section.

This message might indicate a compiler fault. Contact your supplier.

L6644E: Unexpectedly reached the end of the buffer when reading the virtual function

elimination information in section <oepname>(<sectionname>).

This message might indicate a compiler fault. Contact your supplier.

L6645E: The virtual function elimination information in section

<oepname>(<sectionname>) is incorrect: there should be a relocation at offset

<offset>.

This message might indicate a compiler fault. Contact your supplier.

L6646W: The virtual function elimination information in section

<oepname>(<sectionname>) contains garbage from offset <offset> onwards.

This message might indicate a compiler fault. Contact your supplier.

L6647E: The virtual function elimination information for

<vcall_objectname>(<vcall_sectionname>) incorrectly indicates that section

<curr_sectionname>(object <curr_objectname>), offset <offset> is a relocation (to a

virtual function or RTTI), but there is no relocation at that offset.

This message might indicate a compiler fault. Contact your supplier.

L6649E: EMPTY region <regname> must have a maximum size.

See the following in the armlink User Guide:

Execution region attributes.

L6650E: Object <objname> Group section <sectionidx> contains invalid symbol index

<symidx>.

L6651E: Section <secname> from object <objname> has SHF_GROUP flag but is not member

of any group.

L6652E: Cannot reverse Byte Order of Data Sections, input objects are <inputendian>

requested data byte order is <dataendian>.

L6654E: Rejected Local symbol <symname> referred to from a non group member

<objname>(<nongrpname>)

This message might indicate a compiler fault. Contact your supplier.

L6656E: Internal error: the vfe section list contains a non-vfe section called

<oepname>(<secname>).

This message might indicate a compiler fault. Contact your supplier.

L6664W: Relocation #<rel_class>:<rel_number> in <objname>(<secname>) is with respect

to a symbol(#<idx> before last Map Symbol #<last>).

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-75

Non-Confidential

L6665W: Neither Lib$$Request$$armlib Lib$$Request$$cpplib defined, not searching ARM

libraries.

The following code produces this warning:

AREA Block, CODE, READONLY

EXPORT func1

;IMPORT ||Lib$$Request$$armlib||

IMPORT printf

func1

LDR r0,=string

BL printf

BX lr

AREA BlockData, DATA

string DCB "mystring"

END

The linker has not been told to look in the libraries and so cannot find the symbol printf.

This also causes the following error:

L6218E: Undefined symbol printf (referred from L6665W.o).

If you do not want the libraries, then ignore this message. Otherwise, to fix both the error and

the warning uncomment the line:

IMPORT ||Lib$$Request$$armlib||

L6679W: Data in output ELF section #<sec> '<secname>' was not suitable for

compression (<data_size> bytes to <compressed_size> bytes).

L6682E: Merge Section <oepname>(<spname>) is a code section

L6683E: Merge Section <oepname>(<spname>) has an element size of zero

L6684E: Section <spname> from object <oepname> has SHF_STRINGS flag but not SHF_MERGE

flag

L6685E: Section <spname> from object <oepname> has a branch reloc <rel_idx> to a

SHF_MERGE section

L6688U: Relocation #<rel_class>:<rel_idx> in <oepname>(<spname>) references a

negative element

L6689U: Relocation #<rel_class>:<rel_idx> in <oepname>(<spname>). Destination is in

the middle of a multibyte character

L6690U: Merge Section <spname> from object <oepname> has no symbols

L6703W: Section <er> implicitly marked as non-compressible.

L6707E: Padding value not specified with PADVALUE attribute for execution region

<regionname>.

See the following in the armlink User Guide:

Execution region attributes.

L6708E: Could not process debug frame from <secname> from object <oepname>.

L6709E: Could not associate fde from <secname> from object <oepname>.

L6713W: Function at offset <offset> in <oepname>(<secname>) has no symbol.

L6714W: Exception index table section .ARM.exidx from object <oepname> has no data.

L6720U: Exception table <spname> from object <oepname> present in image, --

noexceptions specified.

See the following in the armlink User Guide:

--exceptions, --no_exceptions.

L6721E: Section #<secnum> '<secname>' in <oepname> is not recognized and cannot be

processed generically.

L6725W: Unused virtual function elimination might not work correctly, because there

are dynamic relocations.

L6728U: Link order dependency on invalid section number <to> from section number

<from>.

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-76

Non-Confidential

L6730W: Relocation #<rel_class>:<index> in <objname>(<secname>) with respect to

<name>. Symbol has ABI type <type>, legacy type <legacy_type>.

This warning relates to a change in linker behavior between RVCT 2.0 and 2.1.

Note

The following example produces a warning message only when --strict_relocations is

used, or when the input objects are from RVCT 2.0 or earlier.

Example:

AREA foo, CODE, READONLY

CODE32

ENTRY

KEEP

func proc

NOP

ENDP

DCD foo

END

In RVCT 2.0 and earlier, the linker determines whether interworking is needed based on the

content, which in this example is A32 code. In RVCT 2.1 and later, the linker follows the ABI,

which defines that it is the type of the symbol, in this example STT_SECTION (which is

interpreted as data), that determines whether interworking is applied.

The simplest solution is to move the data into a separate data area in the assembly source file.

Alternatively, you can use --diag_suppress 6730 to suppress this warning.

L6731W: Unused virtual function elimination might not work correctly, because the

section referred to from <secname> does not exist.

L6733W: <objname>(<secname>) contains offset relocation from <lr1name> to <lr2name>,

load regions must be rigidly relative.

L6738E: Relocation #<rel_class>:<relocnum> in <oepname>(<secname>) with respect to

<wrtsym> is a GOT-relative relocation, but _GLOBAL_OFFSET_TABLE_ is undefined.

Some GNU produced images can refer to the symbol named _GLOBAL_OFFSET_TABLE_. If there

are no GOT Slot generating relocations and the linker is unable to pick a suitable address for the

GOT base the linker issues this error message.

L6739E: Version '<vername>' has a dependency to undefined version '<depname>'.

L6740W: Symbol '<symname>' versioned '<vername>' defined in '<symverscr>' but not

found in any input object.

L6741E: Versioned symbol binding should be 'local:' or 'global:'.

L6742E: Symbol '<symname>' defined by '<oepname>'. Cannot not match to default

version symbol '<defversym>'

L6743E: Relocation #<rel_class>:<index> in <oepname>(<spname>) with respect to

<symname> that has an alternate def. Internal consistency check failed

L6744E: Relocation #<rel_class>:<index> <oepname>(<spname>) with respect to undefined

symbol <symname>. Internal consistency check:

L6745E: Target CPU <cpuname> does not Support ARM, <objname>(<secname>) contains ARM

code

L6747W: Raising target architecture from <oldversion> to <newversion>.

If the linker detects objects that specify the obsolete Armv3, it upgrades these to Armv4 to be

usable with Arm libraries.

L6748U: Missing dynamic array, symbol table or string table in file <oepname>.

L6751E: No such sorting algorithm <str> available.

L6753E: CallTree sorting needs Entry Point to lie within a CallTree Sort ER.

L6761E: Removing symbol <symname>.

L6762E: Cannot build '<type>' PLT entries when building a <imgtype>.

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-77

Non-Confidential

L6763W: '<optname>' cannot be used when building a shared object or DLL. Switching it

off

L6764E: Cannot create a PLT entry for target architecture 4T that calls Thumb symbol

L6765W: Shared object entry points must be ARM-state when linking architecture 4T

objects.

This can occur when linking with GNU C libraries. The GNU startup code crt1.o does not

have any build attributes for the entry point, so the linker cannot determine which execution

state (A32 or T32) the code runs in. Because the GNU C library startup code is A32 code, you

can safely ignore this warning, or you can suppress it by using --diag_suppress 6765.

L6766W: PLT entries for architecture 4T do not support incremental linking.

L6769E: Relocation #<rel_class>:<relocnum> in <oepname>(<secname>) with respect to

<wrtsym>. No GOTSLOTexists for symbol.

L6770E: The size and content of the dynamic array changed too late to be fixed.

L6771W: <oepname>(<secname>) contains one or more address-type relocations in RO

data. Making section RW to be dynamically relocated at run-time.

L6772W: IMPORT <symname> command ignored when building --sysv.

L6774W: <objname>(<secname>) has debug frame entries of a bad length.

L6775W: <objname>(<secname>) has FDEs which use CIEs which are not in this section.

L6776W: The debug frame in <objname>(<secname>) does not describe an executable

section.

L6777W: The debug frame in <objname>(<secname>) has <actual> relocations (expected

<expected>)

L6778W: The debug frame in <objname>(<secname>) uses 64-bit DWARF.

L6780W: <origvis> visibility removed from symbol '<symname>' through <impexp>.

L6781E: Value(<val>) Cannot be represented by partition number <part> for relocation

#<rel_class>:<rel_number> (<rtype>, wrt symbol <symname>) in <objname>(<secname>)

L6782W: Relocation #<rel_class>:<relnum> '<rtype>' in <oepname> may not access data

correctly alongside <pltgot_type> PLT entries

L6783E: Mapping symbol #<symnum> '<msym>' in <oepname>(<secnum>:<secname>) defined at

the end of, or beyond, the section size (symbol offset=0x<moffset>, section

size=0x<moffset>, section size=0x<secsize>)

This indicates that the address for a section points to a location at the end of or outside of the

ELF section. This can be caused by an empty inlined data section and indicates there might be a

problem with the object file. You can use --diag_warning 6783 to suppress this error.

L6784E: Symbol #<symnum> '<symname>' in <oepname>(<secnum>:<secname>) with value

<value> has size 0x<size> that extends to outside the section.

The linker encountered a symbol with a size that extends outside of its containing section. This

message is only a warning by default in the RVCT 2.2 build 503 and later toolchains. Use

--diag_warning 6784 to suppress this error.

L6785U: Symbol '<symname>' marked for import from '<libname>' already defined by

'<oepname>'

L6786W: Mapping symbol #<symnum> '<msym>' in <oepname>(<secnum>:<secname>) defined at

unaligned offset=0x<moffset>

L6787U: Region table handler '<handlername>' needed by entry for <regionname> was not

found.

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-78

Non-Confidential

L6788E: Scatter-loading of execution region <er1name> to [<base1>,<limit1>) will

cause the contents of execution region <er2name> at [<base2>,<limit2>) to be

corrupted at run-time.

This occurs when scatter-loading takes place and an execution region is put in a position where

it partially or wholly overwrites another execution region (which can be itself or another

region).

For example, the following code generates this error:

LOAD_ROM 0x0000 0x4000

{

EXEC1 0x4000 0x4000

{

* (+RW,+ZI)

}

EXEC2 0x0000 0x4000

{

* (+RO)

}

and reports:

Error: L6788E: Scatter-loading of execution region EXEC2 will cause the contents of

execution region EXEC2 to be corrupted at run-time.

This code does not generate the error:

LOAD_ROM 0x0000 0x4000

{

EXEC1 0x0000 0x4000

{

* (+RO)

}

EXEC2 0x4000 0x4000

{

* (+RW,+ZI)

}

See the following in the armlink User Guide:

Information about scatter files.

L6789U: Library <library> member <filename> : Endianness mismatch.

L6790E: Relocation #<rel_class>:<relnum> in <objname>(<secname>) with respect to

<symname>. May not IMPORT weak reference through GOT-generating relocation

L6791E: Unknown personality routine <pr> at 0x<offset> <oepname>(<secname>).

L6792E: Descriptor at offset 0x<offset> <oepname>(<secname>).

L6793E: Expecting Landing pad reference at offset 0x<offset> in cleanup descriptor

<oepname>(<secname>).

L6794E: Expecting Landing pad reference at offset 0x<offset> in catch descriptor

<oepname>(<secname>).

L6795E: Expecting RTTI reference at offset 0x<offset> in catch descriptor

<oepname>(<secname>).

L6796E: Descriptor at offset 0x<offset> <oepname>(<secname>) overruns end of section.

L6797E: Data at Offset 0x<offset> in exception table <oepname>(<secname>) overruns

end of section

L6798E: Expecting RTTI reference at offset 0x<offset> in Function Specification

descriptor <oepname>(<secname>).

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-79

Non-Confidential

L6799E: Expecting Landing Pad reference at offset 0x<offset> in Function

Specification descriptor <oepname>(<secname>).

A landing pad is code that cleans up after an exception has been raised. If the linker detects old-

format exception tables, it automatically converts them to the new format.

This message does not appear unless you are using a later version of the linker with an earlier

version of the compiler.

L6800W: Cannot convert generic model personality routine at 0x<offset>

<oepname>(<secname>).

A personality routine unwinds the exception handling stack. If the linker detects old-format

exception tables then it automatically converts them to the new format. This message indicates a

fault in the compiler. Contact your supplier.

L6801E: <objname>(<secname>) containing <secarmthumb> code cannot use the address of

'~IW (The user intended not all code should interwork)' <funarmthumb> function <sym>.

The linker can diagnose where a non-interworking (~IW) function has its address taken by code

in the other state. This error is disabled by default, but can be enabled by linking with --strict.

The error can be downgraded to a warning with --diag_warning 6801 and subsequently

suppressed completely if required with --diag_suppress 6801

Where code, for example, in a.c uses the address of a non-interworking function in t.c:

armclang -c -mcpu=cortex-a9 --target=arm-arm-none-eabi a.c

armclang -mthumb -c -mcpu=cortex-a9 --target=arm-arm-none-eabi t.c

armlink t.o a.o --strict

reports:

Error: L6801E: a.o(.text) containing ARM code cannot use the address of '~IW' Thumb

function foo.

L6802E: Relocation #<rel_class>:<idx> in <objname>(<secname>) with respect to

<armsym>. Thumb Branch to non-Thumb symbol in <armobjname>(<armsecname>).

L6803W: Relocation #<rel_class>:<idx> in <objname>(<secname>) with respect to

<armsym>. Thumb Branch is unlikely to reach target in<armobjname>(<armsym>).

L6804W: Legacy use of symbol type STT_TFUNC detected

L6805E: Relocation #<rel_class>:<idx> in <objname>(<secname>) with respect to

<armsym>. Branch to untyped Absolute symbol in <armobjname>, target state unknown

L6806W: Relocation #<rel_class>:<idx> in <objname>(<secname>) with respect to

<othersym>. Branch to untyped symbol in <otherobjname>(<othersecname>), ABI requires

external code symbols to be of type STT_FUNC.

L6807E: Relocation #<rel_class>:<idx> in <objname>(<secname>) with respect to

<othersym>. Branch to untyped symbol in same section. State change is required.

L6809W: Relocation <rel_class>:<idx> in <objname>(<secname>) is of deprecated type

<rtype>, please see ARMELF for ABI compliant alternative

L6810E: Relocation <rel_class>:<idx> in <objname>(<secname>) is of obsolete type

<rtype>

Relocation errors and warnings are most likely to occur if you are linking object files built with

previous versions of the Arm tools.

To show relocation errors and warnings, use the --strict_relocations switch. This option

enables you to ensure ABI compliance of objects. It is off by default, and deprecated and

obsolete relocations are handled silently by the linker.

See the following in the armlink User Guide:

--strict_relocations, --no_strict_relocations.

L6812U: Unknown symbol action type, please contact your supplier.

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-80

Non-Confidential

L6813U: Could not find Symbol <symname> to rename to <newname>.

See the following in the armlink User Guide:

RENAME steering file command.

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-81

Non-Confidential

L6815U: Out of memory. Allocation Size:<alloc_size> System Size:<system_size>.

This error is reported by Arm Compiler v4.1 and later. It provides information about the amount

of memory available and the amount of memory required to perform the link step.

This error occurs because the linker does not have enough memory to link your target object.

This is not common, but might be triggered for a number of reasons, such as:

• Linking very large objects or libraries together.

• Generating a large amount of debug information.

• Having very large regions defined in your scatter file.

In these cases, your workstation might run out of virtual memory.

This issue might also occur if you use the FIXED scatter-loading attribute. The FIXED attribute

forces an execution region to become a root region in ROM at a fixed address. The linker might

have to add padding bytes between the end of the previous execution region and the FIXED

region, to generate the ROM image. The linker might run out of memory if large amounts of

padding are added when the address of the FIXED region is far away from the end of the

execution region. The link step might succeed if the gap is reduced.

See the following in the armlink User Guide:

•Execution region attributes.

•Root execution regions and the FIXED attribute.

While the linker can generate images of almost any size, it requires a larger amount of memory

to run and finish the link. Try the following solutions to improve link-time performance, to

avoid the Out of memory error:

1. Shut down all non-essential applications and processes when you are linking.

For example, if you are running under Eclipse, try running your linker from the command-

line, or exiting and restarting Eclipse between builds.

2. Use the --no_debug linker option.

This command tells the linker to create the object without including any debug information.

See the following in the armlink User Guide:

--debug, --no_debug.

Note

It is not possible to perform source level debugging if you use this option.

3. Reduce debug information.

If you do not want to use the --no_debug option, there are other methods you can use to try

to reduce debug information.

You can also use the fromelf utility to strip debug information from objects and libraries

that you do not have to debug.

See the following in the fromelf User Guide:

--strip=option[,option,...].

4. Use partial linking.

You can use partial linking to split the link stage over a few smaller operations. Doing this

also stops duplication of the object files in memory in the final link.

See the following in the armlink User Guide:

--partial.

5. Increase memory support on Windows operating systems.

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-82

Non-Confidential

On some Windows operating systems it is possible to increase the virtual address space from

2GB (the default) to 3GB.

For more information, see the following Microsoft article:

Memory Support and Windows Operating Systems.

6. Use the --no_eager_load_debug linker option.

This option is available in RVCT 4.0 build 697 and later. It causes the linker to remove

debug section data from memory after object loading. This lowers the peak memory usage of

the linker at the expense of some linker performance, because much of the debug data has to

be loaded again when the final image is written.

See the following in the armlink User Guide:

--eager_load_debug, --no_eager_load_debug.

If you are still experiencing the same problem, raise a support case.

L6828E: Relocation #<rel_class>:<idx> in <objname>(<secname>) with respect to

<symname>, Branch source address <srcaddr> cannot reach next available pool at

[<pool_base>,<pool_limit>). Please use the --veneer_pool_size option to increase the

contingency.

The --veneer_inject_type=pool veneer generation model requires branches to veneers in the

pool to be able to reach the pool limit, which is the highest possible address a veneer can use. If

a branch is later found that cannot reach the pool limit, and armlink is able to fit all the veneers

in the pool into the lower pool limit, then armlink reduces the pool limit to accommodate the

branch. Error message L6828 is issued only if armlink is unable to lower the pool limit.

See the following in the armlink User Guide:

--veneer_inject_type=type.

L6898E: Relocation #<rel_class>:<idx> in <objname>(<secname>) with respect to

<armsym>. ARM branch to non-ARM/Thumb symbol in <armobjname>(<armsecname>).

L6899E: Existing SYMDEFS file '<filename> 'is read-only.

L6900E: Expected parentheses to specify priority between AND and OR operators.

L6901E: Expected symbol name.

L6902E: Expected a string.

L6903E: Cannot execute '<text>' in '<clause>' clause of script.

L6904E: Destination symbol of rename operation clashes with another rename.

L6905E: Source symbol of rename operation clashes with another rename.

L6906E: (This is the rename operation which it clashes with.)

L6907E: Expected an expression.

L6910E: Expected a phase name.

L6912W: Symbol <symname> defined at index <idx> in <oepname>(<secname>), has ABI

symbol type <symtype> which is inconsistent with mapping symbol type <maptype>.

L6913E: Expected execution region name.

L6914W: option <spurious> ignored when using --<memoption>.

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-83

Non-Confidential

L6915E: Library reports error: <msg>

The message is typically one of the following:

•Error: L6915E: Library reports error: scatter-load file declares no heap or stack

regions and __user_initial_stackheap is not defined.

Error: L6915E: Library reports error: The semihosting __user_initial_stackheap

cannot reliably set up a usable heap region if scatter loading is in use

It is most likely that you have not re-implemented __user_setup_stackheap() or you have

not defined ARM_LIB_STACK or ARM_LIB_HEAP regions in the respective scatter file.

Note

__user_setup_stackheap() supersedes the function __user_initial_stackheap(). Arm

recommends not using __user_initial_stackheap() if possible.

See the following in the Arm® C and C++ Libraries and Floating-Point Support User

Guide:

— __user_setup_stackheap().

— Legacy function __user_initial_stackheap().

See the following in the armlink User Guide:

Reserving an empty region.

•Error: L6915E: Library reports error: __use_no_semihosting was requested but

<function> was referenced.

Where <function> represents __user_initial_stackheap, _sys_exit, _sys_open,

_sys_tmpnam, _ttywrch, system, remove, rename, _sys_command_string, time, or

clock.

This error can appear when retargeting semihosting-using functions, to avoid any SVC or

BKPT instructions being linked-in from the C libraries.

Ensure that no semihosting-using functions are linked in from the C library by using:

#pragma import(__use_no_semihosting)

See the following in the Arm® C and C++ Libraries and Floating-Point Support User

Guide:

Using the libraries in a nonsemihosting environment.

If there are still semihosting-using functions being linked in, the linker reports this error.

To resolve this, you must provide your own implementations of these C library functions.

The emb_sw_dev directory contains examples of how to re-implement some of the more

common semihosting-using functions. See the file retarget.c.

See the following for more information on semihosting-using C library functions:

Arm® C and C++ Libraries and Floating-Point Support User Guide.

Note

The linker does not report any semihosting-using functions such as, for example,

__semihost(), in your own application code.

To identify which semihosting-using functions are still being linked-in from the C libraries:

1. Link with armlink --cpu=8-M --verbose --list err.txt

2. Search err.txt for occurrences of __I$use$semihosting

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-84

Non-Confidential

For example:

...

Loading member sys_exit.o from c_2.l.

reference : __I$use$semihosting

definition: _sys_exit

...

This shows that the semihosting-using function _sys_exit is linked-in from the C

library. To prevent this, you must provide your own implementation of this function.

•Error: L6915E: Library reports error:__use_no_heap was requested, but <reason>

was referenced

If <reason> represents malloc, free, __heapstats, or __heapvalid, the use of

__use_no_heap conflicts with these functions.

•Error: L6915E: Library reports error:__use_no_heap_region was requested, but

<reason> was referenced

If <reason> represents malloc, free, __heapstats, __heapvalid, or __argv_alloc, the

use of __use_no_heap_region conflicts with these functions.

L6916E: Relocation #<rel_class>:<idx> in <oepname>(<spname>). R_ARM_CALL for

conditional BL instruction).

L6917E: Relocation #<rel_class>:<idx> in <oepname>(<spname>). R_ARM_JUMP24 for BLX

instruction.

L6918W: Execution region <ername> placed at 0x<eraddr> needs padding to ensure

alignment <spalign> of <oepname>(<spname>).

L6922E: Section <objname>(<secname>) has mutually exclusive attributes (READONLY and

TLS)

L6923E: Relocation #<rel_class>:<idx> in <oepname>(<spname>) with respect to

<symname>. TLS relocation <type> to non-TLS symbol in <symobjname>(<symsecname>).

L6924E: Relocation #<rel_class>:<idx> in <oepname>(<spname>) with respect to

<symname>. Non-TLS relocation <type> to STT_TLS symbol in <symobjname>(<symsecname>).

L6925E: Ignoring <token> attribute for region <region>. MemAccess support has been

removed.

L6926E: Relocation #<rel_class>:<idx> in <oepname>(<spname>) has incorrect relocation

type <rtype> for instruction encoding 0x<bl>.

L6927E: Relocation #<rel_class>:<idx> in <oepname>(<spname>) has incorrect relocation

type <rtype> for instruction encoding 0x<bl1><bl2>.

L6932W: Library reports warning: <msg>

L6935E: Debug Group contents are not identical, <name> with signature sym <sig> from

objects (<new>) and (<old>)

L6936E: Multiple RESOLVE clauses in library script for symbol '<sym>'.

L6937E: Multiple definitions of library script function '<func>'.

L6939E: Missing alignment for region <regname>.

L6940E: Alignment <alignment> for region <regname> must be at least 4 and a power of

2 or MAX.

L6941W: chmod system call failed for file <filename> error <perr>

L6942E: Execution Region <ername> contains multiple <type>, sections:

L6966E: Alignment <alignment> for region <regname> cannot be negative.

L6967E: Entry point (<address>) points to a THUMB instruction but is not a valid

THUMB code pointer.

L6968E: Could not parse Linux Kernel version \"<kernel>\".

L6969W: Changing AT Section <name> type from RW to RO in <ername>.

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-85

Non-Confidential

L6971E: <objname>(<secname>) type <type> incompatible with <prevobj>(<prevname>) type

<prevtype> in er <ername>.

You might see this message when placing __at sections with a scatter file. For example, the

following code in main.c and the related scatter file gives this error:

int variable __attribute__((at(0x200000)));

LR1 0x0000 0x20000

{

ER1 0x0 0x2000

{

*(+RO)

}

ER2 0x8000 0x2000

{

main.o

}

RAM 0x200000 (0x1FF00-0x2000)

{

*(+RW, +ZI)

}

The variable has the type ZI, and the linker attempts to place it at address 0x200000. However,

this address is reserved for RW sections by the scatter file. This produces the error:

Error: L6971E: stdio_streams.o(.data) type RW incompatible with

main.o(.ARM.__AT_0x00200000) type ZI in er RAM.

To fix this, change the address in your source code, for example:

int variable __attribute__((at(0x210000)));

See the following in the armlink User Guide:

•Methods of placing functions and data at specific addresses.

•Placement of sections at a specific address with __at.

L6972E: <objname>(<secname>) with required base 0x<required> has been assigned base

address 0x<actual>.

L6973E: Error placing AT section at address 0x<addr> in overlay ER <ername>.

For example, you attempted to use __attribute__((at(address))) to place a section when

building a DLL or application with an overlay region. __attribute__((at(address)))

requires that you specify a fixed location in a scatter file with .ARM.__at_address. In this case,

you must also specify the --no_autoat linker option.

See the following in the armlink User Guide:

•Placement of sections at a specific address with __at.

•--autoat, --no_autoat.

L6974E: AT section <name> does not have a base address.

See the following in the armlink User Guide:

Placement of sections at a specific address with __at.

L6975E: <objname>(<secname>) cannot have a required base and SHF_MERGE.

L6976E: <objname>(<secname>) cannot have a required base and SHF_LINK_ORDER.

L6977E: <objname>(<secname>) cannot be part of a contiguous block of sections

L6978W: <objname>(<secname>) has a user defined section type and a required base

address.

L6979E: <objname>(<secname>) with required base address cannot be placed in Position

Independent ER <ername>.

L6980W: FIRST and LAST ignored for <objname>(<secname>) with required base address.

See the following in the armlink User Guide:

Section placement with the FIRST and LAST attributes.

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-86

Non-Confidential

L6981E: __AT incompatible with BPABI and SystemV Image types

See the following in the armlink User Guide:

Restrictions on placing __at sections.

L6982E: AT section <objname>(<spname>) with base <base> limit <limit> overlaps

address range with AT section <obj2name>(<sp2name>) with base <base2> limit <limit2>.

See the following in the armlink User Guide:

Placement of sections at a specific address with __at.

L6983E: AT section <objname>(<spname>) with required base address <base> out of range

for ER <ername> with base <erbase> and limit <erlimit>.

This can occur if you specify __attribute__((at(address))) in your

code, .ARM.__at_address in your scatter file, and --no_autoat option on the linker command

line. In this case, the address part of .ARM.__at_address must be specified as eight

hexadecimal digits. For example:

int x1 __attribute__((at(0x4000))); // defined in function.c

; scatter file

LR1 0x0

{

...

function.o(.ARM.__at_0x00004000)

...

}

See the following in the armlink User Guide:

•Placement of sections at a specific address with __at.

•--autoat, --no_autoat.

L6984E: AT section <objname>(<spname>) has required base address <base> which is not

aligned to section alignment <alignment>.

See the following in the armlink User Guide:

Placement of sections at a specific address with __at.

L6985E: Unable to automatically place AT section <objname>(<spname>) with required

base address <base>. Please manually place in the scatter file using the --no_autoat

option.

See the following in the armlink User Guide:

•Placement of sections at a specific address with __at.

•--autoat, --no_autoat.

3 Linker Errors and Warnings

3.2 List of the armlink error and warning messages

reserved.

3-87

Non-Confidential

Chapter 4

ELF Image Converter Errors and Warnings

Describes the error and warning messages for the ELF image converter, fromelf.

It contains the following section:

•4.1 List of the fromelf error and warning messages on page 4-89.

reserved.

4-88

Non-Confidential

4.1 List of the fromelf error and warning messages

Lists the error and warning messages that fromelf produces.

Note

License-related error messages can be found in the 1.1 List of the licensing error and warning messages

on page 1-9 section.

Q0105E: Load region #<segindex> extends beyond top of address space.

Q0106E: Out of Memory.

Q0107E: Failed writing output file '<filename>': <reason>

Q0108E: Could not create output file '<filename>': <reason>

Q0119E: No output file specified.

Q0120E: No input file specified.

Q0122E: Could not open file '<filename>': <reason>

If <reason> is Invalid argument, this might be because you have invalid characters on the

command line.

For example, on Windows you might have used the escape character \ when specifying a filter

with an archive file:

fromelf --elf --strip=all t.a$test*.o$ -o filtered/

On Windows, use:

fromelf --elf --strip=all t.a(test*.o) -o filtered/

See the following in the fromelf User Guide:

input_file.

Q0128E: File i/o failure.

This error can occur if you specify a directory for the --output command-line option, but you

did not terminate the directory with a path separator. For example, --output=my_elf_files/.

See the following in the fromelf User Guide:

--output=destination.

Q0129E: Not a 32 bit ELF file.

Q0130E: Not a 64 bit ELF file.

Q0131E: Invalid ELF identification number found.

This error is given if you attempt to use fromelf on a file which is not in ELF format, or which is

corrupted. Object (.o) files and executable (.axf) files are in ELF format.

Q0132E: Invalid ELF section index found <idx>.

Q0133E: Invalid ELF segment index found <idx>.

Q0134E: Invalid ELF string table index found <idx>.

Q0135E: Invalid ELF section entry size found.

Q0136E: ELF Header contains invalid file type.

Q0137E: ELF Header contains invalid machine name.

Q0138E: ELF Header contains invalid version number.

See Q0131E.

4 ELF Image Converter Errors and Warnings

4.1 List of the fromelf error and warning messages

reserved.

4-89

Non-Confidential

Q0147E: Failed to create Directory <dir>: <reason>

If <reason> is File exists, this might be because you have specified a directory that has the

same name as a file that already exists. For example, if a file called filtered already exists,

then the following command produces this error:

fromelf --elf --strip=all t.a(test*.o) -o filtered/

The path separator character / informs fromelf that filtered is a directory.

See the following in the fromelf User Guide:

--output=destination.

Q0171E: Invalid st_name index into string table <idx>.

See Q0131E.

Q0172E: Invalid index into symbol table <idx>.

See Q0131E.

Q0186E: This option requires debugging information to be present

The --fieldoffsets option requires the image to be built with dwarf debug tables.

Q0425W: Incorrectly formed virtual function elimination header in file

This might indicate a compiler fault. Contact your supplier.

Q0426E: Error reading vtable information from file

This might indicate a compiler fault. Contact your supplier.

Q0427E: Error getting string for symbol in a vtable

This might indicate a compiler fault. Contact your supplier.

Q0433E: Diagnostic style <style> not recognised

Q0440E: No relocation sections for <secname>

Q0447W: Unknown Diagnostic number (<num>)

Q0448W: Read past the end of the compressed data while decompressing section

'<secname>' #<secnum> in <file>

This might indicate an internal fault. Contact your supplier.

Q0449W: Write past the end of the uncompressed data buffer of size <bufsize> while

decompressing section '<secname>' #<secnum> in <file>

This might indicate an internal fault. Contact your supplier.

Q0450W: Section '<secname>' #<secnum> in file <file> uses a mixture of legacy and

current ABI relocation types.

Q0451W: Option '--strip symbols' used without '--strip debug' on an ELF file that has

debug information.

Q0452W: Option '--strip filesymbols' used without '--strip debug' on an ELF file that

has debug information.

Q0453W: Stripping path names from '<path1>' and '<path2>' produces a duplicate file

name '<filename>'.

Q0454E: In ELF file: <details>

4 ELF Image Converter Errors and Warnings

4.1 List of the fromelf error and warning messages

reserved.

4-90

Non-Confidential

Chapter 5

Librarian Errors and Warnings

Describes the error and warning messages for the Arm librarian, armar.

It contains the following section:

•5.1 List of the armar error and warning messages on page 5-92.

reserved.

5-91

Non-Confidential

5.1 List of the armar error and warning messages

Lists the error and warning messages that armar produces.

L6800U: Out of memory

L6825E: Reading archive '<archive>' : <reason>

L6826E: '<archive>' not in archive format

L6827E: '<archive>': malformed symbol table

L6828E : '<archive>': malformed string table

L6829E: '<archive>': malformed archive (at offset <offset>)

L6830E: Writing archive '<archive>' : <reason>

L6831E: '<member>' not present in archive '<archive>'

L6832E: Archive '<archive>' not found : <reason>

L6833E: File '<filename>' does not exist

L6835E: Reading file '<filename>' : <reason>

L6836E: '<filename>' already exists, so will not be extracted

L6838E: No archive specified

L6839E: One of the actions -[<actions>] must be specified

L6840E: Only one action option may be specified

L6841E: Position '<position>' not found

L6842E: Filename '<filename>' too long for file system

L6843E: Writing file '<filename>' : <reason>

L6874W: Minor variants of archive member '<member>' include no base variant

Minor variants of the same function exist within a library. Find the two equivalent objects and

remove one of them.

L6875W: Adding non-ELF object '<filename>' to archive '<name>'

5 Librarian Errors and Warnings

5.1 List of the armar error and warning messages

reserved.

5-92

Non-Confidential

Chapter 6

Other Errors and Warnings

Describes error and warning messages that might be displayed by any of the tools.

It contains the following sections:

•6.1 Internal faults and other unexpected failures on page 6-94.

•6.2 List of other error and warning messages on page 6-95.

reserved.

6-93

Non-Confidential

6.1 Internal faults and other unexpected failures

Internal faults indicate that the tool has failed an internal consistency check or has encountered some

unexpected input that it could not deal with. They might point to a potential issue in the tool itself.

For example:

Internal fault: [0x76fd03:600448]

contains:

• The message description (Internal fault).

• A six hex digit fault code for the error that occurred (0x76fd03).

• The version number (60 is Arm Compiler 6.0).

• The build number (0448 in this example).

If you see an internal fault, contact your supplier.

To facilitate the investigation, try to send only the single source file or function that is causing the error,

plus the command-line options used.

If the internal fault is caused by the assembler, and the source code contains pre-processor macros, it

might be necessary to use the compiler to preprocess the source before sending it to your supplier.

6 Other Errors and Warnings

6.1 Internal faults and other unexpected failures

reserved.

6-94

Non-Confidential

6.2 List of other error and warning messages

A list of the error and warning messages that any of the tools in the Arm Compiler toolchain produce.

Note

When the message is displayed, the X prefixing the message number is replaced by an appropriate letter

relating to the tool. For example, the code X3900U is displayed as L3900U by the linker when you have

specified an unrecognized option.

X3900U: Unrecognized option '<dashes><option>'.

<option> is not recognized by the tool. This could be because of a spelling error or the use of an

unsupported abbreviation of an option.

X3901U: Missing argument for option '<option>'.

X3902U: Recursive via file inclusion depth of <limit> reached in file '<file>'.

X3903U: Argument '<argument>' not permitted for option '<option>'.

Possible reasons include malformed integers or unknown arguments.

X3904U: Could not open via file '<file>'.

X3905U: Error when reading from via file '<file>'.

X3906U: Malformed via file '<file>'.

X3907U: Via file '<file>' command too long for buffer.

X3908U: Overflow: '<string>' will not fit in an integer.

X3910W: Old syntax, please use '<hyphens><option><separator><parameter>'.

X3912W: Option '<option>' is deprecated.

X3913W: Could not close via file '<file>'.

X3915W: Argument '<argument>' to option '<option>' is deprecated

X3916U: Unexpected argument for option '<dashes><option>'

X3917U: Concatenated options cannot have arguments: -<option> <arg>

X9905E: cannot use --apcs=/hardfp without floating point hardware

X9906E: cannot use --apcs=/hardfp with fpu <fpu_option>

X9907E: unable to select no floating point support

X9908E: --fpmode=none overrides --fpu choice

6 Other Errors and Warnings

6.2 List of other error and warning messages

reserved.

6-95

Non-Confidential

Arm® Compiler Errors And Warnings Reference Guide 100074 0610 00 En

Navigation menu

Versions of this User Manual:

Views

Navigation
