polyDFEv2.0

User Manual

Paula Tataru

October 3, 2018

polyDFE infers the distribution of ﬁtness eﬀects (DFE) of new mutations from polymorphism, and, if available,

can also incorporate divergence data obtained from an outgroup. The polymorphism data is provided as an

unfolded site frequency spectrum (SFS). Note that, in order to obtain an unfolded SFS, at least one outgroup

is needed. However, including the divergence data when inferring the DFE can lead to bias in the estimated

parameters (see Tataru et al. (2017) for further discussion).

Once the DFE is obtained, polyDFE also calculates α, the rate of adaptive molecular evolution, commonly

deﬁned as the proportion of ﬁxed adaptive mutations among all non-synonymous substitutions.

polyDFEv2.0 (Tataru and Bataillon,2018) can ﬁt jointly multiple datasets for which some parameters can

be set to be invariant (shared across the datasets). This enables model testing for parameter invariance, for

example, testing if diﬀerent datasets have the same DFE or not.

This code implements the program described in Tataru et al. (2017); Tataru and Bataillon (2018).

This manual is supplemented by a tutorial providing the full analysis of a dataset. Note that the tutorial has

been made using polyDFEv1.1 and the Rscripts have to be slightly adapted to work with polyDFEv2.0.

E[Pneut(1)] E[Pneut(2)] . . . E[Pneut(n

−

1)] E[Psel(1)] E[Psel(2)] . . . E[Psel(n

−

1)] E[Dsel]E[Dneut]

an r2. . . rn−1θ= 4NeµS= 4Nesrn

θaφ

rate of ancestral error nuisance parameters

distribution of

mutation rates

distribution of

ﬁtness eﬀects

divergence

parameter

...

Contents

1 Authors 3

2 License 3

3 Requirements 3

4 Installation 3

5 New in v2.0 3

6 Error reporting 3

7 Running polyDFE 4

7.1 Specifying the data ﬁle(s) ....................................... 4

7.2 Specifying the DFE and parameters of interest ........................... 5

7.3 Simulating data ............................................. 6

7.3.1 Examples ............................................ 6

7.4 Estimating the DFE and α...................................... 7

7.4.1 Controlling the optimization procedure ........................... 7

7.4.2 Excluding divergence data ................................... 11

7.4.3 Controlling the polyDFE output ................................ 11

7.4.4 Additional arguments ..................................... 11

7.4.5 What to do when the gradient / size is large ........................ 11

7.4.6 Examples ............................................ 12

8 Post-processing using R13

8.1 Parsing the output of polyDFE .................................... 13

8.2 Summarizing the DFE ......................................... 13

8.3 Calculating α.............................................. 14

8.4 Bootstrapping data ........................................... 14

8.5 Model testing .............................................. 14

8.6 Model averaging ............................................ 14

8.7 Creating init file .......................................... 15

8.8 Examples ................................................ 15

Index 15

1 Authors

polyDFE has been developed and implemented by Paula Tataru and Marco A.P. Franco.

2 License

polyDFE is open source, distributed under the GNU General Public License, version 3. See LICENSE.txt for

details.

3 Requirements

polyDFE is implemented in C and uses the GSL library. This should be downloaded from https://www.gnu.

org/software/gsl/ and compiled accordingly. polyDFE has been tested using GSL-1.16. Note that polyDFE

does not work with a newer version of GSL.

4 Installation

The simplest way to compile polyDFE is

1. cd to the directory containing the makefile and type

make all

to compile the code.

2. You can remove the program binaries and object ﬁles from the source code directory by typing

make clean

If the GSL library is not installed in the default directory, than the installation path needs to be speciﬁed in the

makefile by updating USR_INC and USR_LIB and uncommenting the lines at the top of the makefile:

############################################################

# for non-default GSL installation

############################################################

# USR_INC := -I<ROOT PATH TO GSL 1.16>/include/

# USR_LIB := -L<ROOT PATH TO GSL 1.16>/lib/

############################################################

polyDFEv2.0 is also distributed as pre-compiled binaries for Windows, Linux and macOS. When using Linux

and macOS, it might be necessary to change the access permissions to the binary in order to execute it. This

can be achieved by

chmod +x polyDFE-2.0-<os>

where polyDFE-2.0-<os> is the polyDFEv2.0 binary.

5 New in v2.0

polyDFEv2.0 enables model testing across diﬀerent data sets: often when inferring the DFE, the ﬁnal aim is to

test if the DFE diﬀers signiﬁcantly across diﬀerent areas of the genome or diﬀerent species. polyDFEv2.0 can

estimate parameters jointly over multiple data sets (see -d), where some parameters (for example, the DFE)

are shared across the data sets, while the rest of the parameters are estimated independently for each data set

(see -i,-r and -g). Additionally, polyDFEv2.0 implements a new optimization method (see -o).

postprocessing.R has also been updated to handle the new output format of polyDFEv2.0.

6 Error reporting

polyDFE has in-built checks which, if they fail, they stop the execution and print an error message. If this

or any other type of problematic behaviour is encountered, please report it directly on https://github.com/

paula-tataru/polyDFE or by sending an email to paula.tataru at gmail.com.

7 Running polyDFE

Running polyDFE with the argument -h will print out the usage (required and optional arguments):

$ ./polyDFE -h

./polyDFEv2.0

Usage: ./polyDFE -d data_file_1[:data_file_2:...:data_file_j]

[-m model(A, B, C, D) [K]] [-i init_file ID_1[:ID_2:...:ID_j]] [-t]

{-s m_neut L_neut m_sel L_sel n ||

[-o optim(bfgs, conj_pr, conj_fr, simplex)] [-k kind(s, j, s+j)]

[-r range_file ID_1[:ID_2:...:ID_j]] [-i init_file ID [-j]]

[-e] [-w] [-g grouping_file ID_1[:ID_2:...:ID_j]] [-p optim_file ID]

[-b [basinhop_file ID]] [-l min] [-v verbose(0, 1, frequency)]}

polyDFE runs in two modes: -s, used for simulating data under the hierarchical probabilistic model, and -o,

used for estimating the DFE and α. If neither -s or -o are given, then -o bfgs is used by default (see -o for

details). If both -s and -o are given, polyDFE will terminate with an error. Optional arguments are given

between [].

7.1 Specifying the data ﬁle(s)

Regardless of the mode polyDFE is ran in, the ﬁles containing the data have to be speciﬁed using the following

argument:

•-d data_file_1[:data_file_2:...:data_file_j]: path to one or multiple data ﬁles.

data_file_i, for 1 ≤i≤jis where polyDFE will write the simulated data, if -s is used, or will read the

input data, if -o is used.

The ﬁles can contain any number of empty lines and comment lines that start with #. Excluding these,

the structure is

1mneut msel n

2pneut (1) pneut (2) ... pneut (n-1) lneut dneut ld,neut

... ...

mneut +1 pneut (1) pneut (2) ... pneut (n-1) lneut dneut ld,neut

mneut +2 psel (1) psel (2) ... psel (n-1) lsel dsel ld,sel

... ...

mneut +msel +1 psel (1) psel (2) ... psel (n-1) lsel dsel ld,sel

where

◦mneut and msel are the number of fragments that are assumed to be evolving neutrally or under

selection, respectively;

◦nis the ingroup sample size (number of sequences / haplotypes);

◦pz(i) is the ith entry in the SFS within the fragment, for sites that are assumed to be evolving

neutrally, z= neut, or under selection, z= sel;

◦lzis the total number of sites within the fragment used for the SFS (number of successfully sequenced

sites within the ingroup) that are assumed to be evolving neutrally, z= neut, or under selection,

z= sel;

◦dzis the total number of ﬁxed mutations in the ingroup relative to the outgroup (divergence counts)

within the fragment, that are assumed to be evolving neutrally, z= neut, or under selection, z= sel;

◦ld,z is the total number of sites within the fragment used for the divergence counts (number of

successfully sequenced sites within the ingroup and outgroup) that are assumed to be evolving

neutrally, z= neut, or under selection, z= sel; for a given fragment, lzand ld,z could be diﬀerent if

certain sites are successfully sequenced in the ingroup, but not in the outgroup.

The divergence data (last two columns, dzand ld,z ) can be absent from the ﬁle. If it is absent, it should

be absent for all fragments.

polyDFE uses data divided into fragments in order to model variability in mutation rates, as described

in Tataru et al. (2017). If only one neutral and one selected fragments are provided, than variability in

mutation rates is not modelled.

The provided ﬁles input/example_1,input/example_2 and input/example_3 are examples of input

data.

7.2 Specifying the DFE and parameters of interest

Regardless of the mode polyDFE is ran in, the assumed DFE model has to be speciﬁed using the following

argument:

•-m model(A, B, C, D) [K]: assumed DFE model.

polyDFE assumes that the DFE φtakes one of four speciﬁc functional forms, encoded A, B, C, and D,

described below

◦A: the DFE is given by a reﬂected displaced Γ distribution, parameterized by ¯

S,band Smax, with

density

φA(S;¯

S, b, Smax) = fΓ(Smax −S;Smax −¯

S, b) if S≤Smax

0 otherwise

where ¯

Sis the mean of the DFE, bis the shape of the Γ distribution, Smax is the maximum value

that Scan take, and fΓ(x;m, b) is the density of the Γ distribution with mean mand shape b.

◦B: the DFE is given by a mixture of a Γ and discrete distributions, parameterized by Sd,b,pband

Sb, where

φB(S;Sd, b, pb, Sb) = 





(1 −pb)fΓ(−S;−Sd, b) if S≤0

pbif S=Sb

0 otherwise

where Sdis the mean of the DFE for S≤0, bis the shape of the Γ distribution, pbis the probability

that S > 0, and Sbis the shared selection coeﬃcient of all positively selected mutations, and

fΓ(x;m, b) is the density of the Γ distribution with mean mand shape b.

◦C: the DFE is given by a mixture of a Γ and Exponential distributions, parameterized by Sd,b,pb

and Sb, where

φC(S;Sd, b, pb, Sb) = (1 −pb)fΓ(−S;−Sd, b) if S≤0

pbfe(S;Sb) if S > 0

where Sdis the mean of the DFE for S≤0, bis the shape of the Γ distribution, pbis the probability

that S > 0, Sbis the mean of the DFE for S > 0, and fΓ(x;m, b) is the density of the Γ distribution

with mean mand shape b, while fe(x;m) is the density of the Exponential distribution with mean

◦D: the DFE is given as a discrete DFE, where the selection coeﬃcients can take one of Sidistinct

values, 1 ≤i≤K, where each value Sihas probability pi, with

i=0

pi= 1

The value of Kneeds to be provided in the command line for model D.

If -m is not given, model Cis used by default.

When simulating data (mode -s), the DFE and other additional parameters have to be speciﬁed using -i. This

can also optionally be used when inferring the parameters (mode -o). This way, the user can control which

parameters should be estimated and which should be kept ﬁxed to a given value, and can also provide the

initial values of the parameters used during the optimization. Note that if using -m D,-i is no longer optional,

as it contains the information about the selection coeﬃcients Si.

•-i init_file ID_1[:ID_2:...:ID_j]: path to a ﬁle containing the values of the DFE and other pa-

rameters, and one or multiple IDs.

init_file can contain any number of empty lines and comment lines that start with #. Excluding these,

the structure of each line is

id [0|1|2] an [0|1|2] cont [0|1|2] λ[0|1|2] ¯

θ[0|1|2] a <DFE parameters> [0|1|2] r2..rn

Each line starts with a positive numerical id. This is used such that multiple conﬁgurations of the

parameters can be stored in the same ﬁle. When running polyDFE, the desired line for initializing the

parameters is speciﬁed through the id by setting ID_i, for 1 ≤i≤j, to the right value.

The id is followed by the values of the parameters, in the order an,cont,λ,¯

θ,a, the DFE parameters

(see -m), and the ri, 2 ≤i≤n, parameters, where nis the ingroup sample size. The riparameters can

also be provided for i > n, but those values will be ignored. This is useful if the same line in init_file

is used for multiple data sets that have diﬀerent sample sizes.

All parameters are preceded by a ﬂag, which is either 0, 1 or 2. In the -s mode, the ﬂag is not used,

but this becomes important for the -o mode, where the ﬂag indicates if a parameter should be estimated

independently (ﬂag 0), should be kept ﬁxed to the value provided in init_file (ﬂag 1), or should be

estimated but shared across the multiple input data ﬁles (see -d). All riparameters share one ﬂag.

When running polyDFE jointly over multiple data ﬁles (see -d), either only one ID should be provided,

which is then used for all the data ﬁles, or a number j(the same as the number of input data ﬁles) of IDs

is required. In the latter case, ID_i will be used for data_file_i, for 1 ≤i≤j. If one parameter has

ﬂag 2 for some ID_i but ﬂag 0 for some other ID_l, than this parameter is estimated and shared over all

the data ﬁles.

When -m D is used, only the probabilities piare estimated, while the selection coeﬃcients Siare ﬁxed to

the given values.

For details of the meaning of each parameter, please see Tataru et al. (2017), noting that an is simply

referred to as .

The parameter cont is deprecated since v1.1 and is no longer used. For backward compatibility, it is still

present in the init_file.

The aparameter is directly linked to variability of mutation rates. If it is wished for mutation rates to

be assumed constant, than acan be ﬁxed to −1. If both mneut and msel provided in the input dataﬁle

(through argument -d) are equal to 1 (i.e. the data is not divided into fragments), then the mutation

variability is not estimated by default. When mutation variability is allowed, than the observed data

(counts) are assumed to follow a negative binomial distribution, otherwise they are assumed to follow a

Poisson distribution. See Tataru et al. (2017) for more details on mutation variability. Note that if the

variability in mutation rate is not of interest, then acan be ﬁxed to −1 without biasing the inference of

the remaining parameters.

The provided ﬁles input/init_model_A.txt,input/init_model_BandC.txt and input/init_model_D.txt

give examples of the structure of the init_file for the diﬀerent DFE models.

7.3 Simulating data

The simulation mode (-s) requires the following argument:

•-s m_neut L_neut m_sel L_sel n: simulate data.

When using -s, simulated data will be printed in data_file with mneut =m_neut,msel =m_sel,

lneut =ld

neut =L_neut and lsel =ld

sel =L_sel, for all simulated fragments. For details on mzand lz, with

z∈ {neut,sel}, see -d.

7.3.1 Examples

When simulating data, polyDFE throws a warning about overwriting the ﬁle and requires input from the user

to conﬁrm the action:

$ ./polyDFE -d input/example_1 -m A -s 500 2000 500 6000 20 -i input/init_model_A.txt 1

---- Running command

---- ./polyDFE -d input/example_1 -m A -s 500 2000 500 6000 20 -i input/init_model_A.txt 1

Warning: simulating data, input/example_1 will be overwritten.

Do you want to continue with simulation? (Y/N): Y

This is to ensure that no ﬁles containing data are overwritten by mistake.

The provided ﬁles input/example_1,input/example_2 and input/example_3 are obtained by calling

$ ./polyDFE -d input/example_1 -m A -s 500 2000 500 6000 20 -i input/init_model_A.txt 1

$ ./polyDFE -d input/example_2 -m C -s 50 20000 50 60000 20 -i input/init_model_BandC.txt 1

$ ./polyDFE -d input/example_3 -m D 5 -s 100 10000 100 30000 20 -i input/init_model_D.txt 1

The simulated data_file contains information at the beginning about the DFE model used for the simulation,

together with the values of all parameters.

7.4 Estimating the DFE and α

The estimation (optimization) mode (-o) allows for the estimation of DFE and α. For this, next to the

arguments described above, it allows for a series of optional arguments, which control the optimization, both

how the parameters are estimated, but also when a set of parameters found is considered to be optimal.

7.4.1 Controlling the optimization procedure

One of the key issues in inferring the parameters is to ensure that the likelihood function is properly optimized

over the space of parameters. polyDFE implements multiple steps to ensure, as much as possible, that good

parameters are found. These can be customized by the user using the following arguments:

•-o (bfgs, conj_pr, conj_fr, simplex): optimization method to use for estimating the parameters.

polyDFE uses GSL to run a local optimization algorithm and ﬁnd estimates of the parameters. GSL

implements multiple optimization algorithms. Generally, optimization is more eﬃcient if it also uses the

derivative of the function to be optimized. Therefore, in polyDFE we have chosen to use three of the

algorithms oﬀered by GSL, which all rely on the function (in this case, the data likelihood) derivatives.

Additionally, polyDFE also implements one method that does not rely on the derivative:

◦bfgs: the Broyden-Fletcher-Goldfarb-Shanno (BFGS) algorithm.

◦conj_pr: the Polak-Ribiere conjugate gradient algorithm;

◦conj_fr: the Fletcher-Reeves conjugate gradient algorithm;

◦simplex: the the Simplex algorithm of Nelder and Mead.

For details on the diﬀerent optimization algorithms, please see the GSL manual. When -o is not given,

-o bfgs is used by default. polyDFE has been tested using the BFGS algorithm.

Note that the optimization of the parameters for model D(see -m for details) is more diﬃcult, due to

the fact that the probabilities piare constrained to sum to 1, while all of the above algorithms are

unconstrained.

•-p optim_file ID: path to a ﬁle containing parameters that control the optimization algorithm, and id.

optim_file can contain any number of empty lines and comment lines that start with #. Excluding

these, the structure of each line is

id abs step size tolerance max iterations

Each line starts with a positive numerical id. This is used such that multiple conﬁgurations for the

optimization algorithms can be stored in the same ﬁle. When running polyDFE, the desired line for

parameters that control the optimization is speciﬁed through the id by setting ID to the right value.

The optim_file is used to control the behavior of the optimization algorithms from GSL, speciﬁed using

-o:

◦abs: this the absolute tolerance value that the gradient or the minimizer-speciﬁc characteristic size

(for -o simplex) of the function to be optimized (here, the likelihood) is tested against. When

the gradient / size is smaller than this values, than GSL considers that it has successfully found an

optimum. If this value is too large, it will lead to an early termination of the algorithm. If the

value is too small, it might lead to a longer running time of the algorithm without, potentially, much

improvement on the function. However, it is always better to have an absolute tolerance value that

is too small than too large. If a set of values found is a true optimum, than the gradient / size should

be 0. Default value: 0.00001 and 0.01 for -o simplex.

◦step size: the GSL optimization algorithms use a line search and the step size determines the size of

the ﬁrst step performed in the search. Default value: 2.

◦tolerance: speciﬁes the accuracy of the line search, with the precise meaning depending on the

algorithm used. Default value: 0.1.

◦max iterations: the GSL optimization algorithms are iterative. If the number of performed iterations

reaches max iter, than the algorithm is stopped, regardless of the gradient / size. Default value:

2000 and 20000 for -o simplex.

For more details on the above, please consult the GSL manual.

The provided ﬁle input/params.optim is an example of an optim_file.

•-l min: limit running time to min.

To control the running time of polyDFE, one run of the optimization algorithm is stopped if it has used

more than min. By default, min is set to 300 (5h). Note that if min is set too low, there is a high chance

that the optimization algorithm will terminate without ﬁnding good optimal parameters. Setting min to

a negative number will allow the optimization algorithm to run until it ﬁnishes, without a limited running

time.

•-e: automatically estimate the initial value of the parameters.

The optimization algorithms require an initial value for the parameters to be optimized. This can either

be provided using -i if the user has a good idea for such values, or can, by using -e. If -e is used

without -i, then all the parameters (expect for cont, which, by default, is not estimated and set to 0)

will be automatically initialized and then optimized. When multiple data ﬁles are provided (see -d), all

parameters are shared (ﬂag 2, see -i) by default. However, if -i and -e are used together, the initial

value of the parameters is estimated automatically only for those parameters that are not ﬂagged with 1

and are consequently optimized.

The parameters ¯

θ,a,λand rican be estimated deterministically. The rest of the parameters are estimated

using a grid search approach. However, for the DFE model D, the probabilities piare set to be uniform

when -e is used.

If -i is not used, -e is used by default.

•-j: use jointly both the provided initial values and automatically estimated values of parameters.

When -j is used together with -i, then the optimization algorithm is ran twice, once where the initial

value of the parameters is the one given in the init_file, and a second time where the automatic

estimation from -e is used. At the end, the parameters that have the best likelihood, found from one of

the two runs, will be reported.

•-k kind(s, j, s+j): kind of likelihood optimization to use for estimating the parameters.

The likelihood computation is split in two parts: the neutral likelihood for the neutral SFS, which does

not require the DFE, and the selected likelihood for the selected SFS, which requires all the parameters,

including the DFE. Many DFE inference methods ﬁrst infer all the parameters but the DFE (to which we

refer as the neutral parameters) from the neutral SFS, and then conditional on those, they infer the DFE

from the selected SFS. By default, polyDFE infers all of the parameters jointly by using both the neutral

and selected SFS, which is computationally more costly as many parameters have to be optimized at the

same time. The kind of likelihood optimization can be controlled through -k:

◦s:polyDFE is ran in a single mode, where the neutral likelihood is ﬁrst optimized, followed by the

optimization of the selected likelihood;

◦j:polyDFE is ran in a joint mode, where the joint likelihood is optimized;

◦s+j:polyDFE is ran in a single + joint mode, where ﬁrst the single mode is used and the

parameters found are used as initial values in the following joint mode.

By default, polyDFE uses -k j. Note that using -k s might lead to parameters that are not optimal.

•-r range_file ID_1[:ID_2:...:ID_j]: path to a ﬁle containing the allowed range of all parameters,

and one or multiple IDs.

range_file can contain any number of empty lines and comment lines that start with #. Excluding

these, the structure of each line is

id k min

an max

an min

cont max

cont λmin λmax ¯

θmin ¯

θmax amin amax <DFE parameters> rmin rmax

Each line starts with a positive numerical id. This is used such that multiple conﬁgurations of the

parameters can be stored in the same ﬁle. When running polyDFE, the desired line for the range of the

parameters is speciﬁed through the id by setting ID to the right value.

The id is followed by k, which controls the transformation of the parameters (see below) and the range

within each parameter should be estimated. Some parameters are intrinsically constrained (for example,

pbfor DFE models Band Cis, by construction, constrained to be between 0 and 1), while many param-

eters have to be positive (or negative, for example, Sdfor DFE models Band C). In order to treat all

parameters in the same way and to also allow the user to narrow the range in which the optimum pa-

rameters are searched, all parameters are then constrained to the range provided by the user through the

range_file. However, the optimization algorithms polyDFE uses (see -o for details) are unconstrained,

in that the parameters can take any value in the interval (−∞,+∞). In order to change the original

constrained optimization problem to an unconstrained one, polyDFE transforms the parameters from the

range provided by the user to the interval (−∞,+∞). For this, a generalized logistic function is used.

This function is parameterized by a growth rate (or steepness of curve) k, which controls the spread of

the transformation: the smaller the k, the more quicker the transformed values move from −∞ to +∞.

polyDFE has been tested with a value of k= 0.01. If the optimization algorithm cannot ﬁnd a good

solution (i.e. the gradient / size is small, see -p for details), the kparameter can be changed in the hope

of better performance.

Note that, in order for the optimization algorithm to successfully ﬁnd the optimum parameters (the

parameters that have the largest likelihood), the ranges should be large enough to ensure that they cover

the optimum values. If a parameter is inferred to be very close to one of the borders of its range, than

the range should be expanded.

If initial values of the parameters provided through -i or as calculated when -e is provided are not within

the ranges, the program will automatically update the ranges.

When part of the DFE is given by a Γ distribution (see -m), the parameter bcontrols its shape. If b

is very small and therefore the distribution is very leptokurtic, it is diﬃcult to calculate the likelihood

accurately, and it is thus recommended to keep the minimum range for bat least 0.01.

If ranges are not provided, than polyDFE sets automatic ranges that are very large.

The parameter cont is deprecated since v1.1 and is no longer used. For backward compatibility, it is still

present in the range_file.

When running polyDFE jointly over multiple data ﬁles (see -d), either only one ID should be provided,

which is then used for all the data ﬁles, or a number j(the same as the number of input data ﬁles) of

IDs is required. In the latter case, ID_i will be used for data_file_i, for 1 ≤i≤j.

The provided ﬁles input/range_model_A.txt,input/range_model_BandC.txt and

input/range_model_D.txt are examples of range_file.

•-g grouping_file ID_1[:ID_2:...:ID_j]: path to a ﬁle containing grouping information for the ri

parameters, and one or multiple IDs.

grouping_file can contain any number of empty lines and comment lines that start with #. Excluding

these, the structure of each line is

id G i1i2... iG

Each line starts with a positive numerical id. This is used such that multiple conﬁgurations of the grouping

can be stored in the same ﬁle. When running polyDFE, the desired line for the range of the parameters

is speciﬁed through the id by setting ID to the right value.

The grouping_file is used to provide information on grouping the riparameters. By default, each entry

1≤i < n in the SFS, and the divergence count, have one value of riassociated to it. If nis very large,

this leads to a lot of parameters that need to be estimated. One could expect that the distortion that is

incurred on the counts that are modeled using the riparameters could be similar for neighboring values

(for example, i−1, iand i+ 1). Then only one rvalue can be estimated for those counts that share a

similar distortion.

The grouping given in grouping_file will result in rvalues corresponding to the SFS entries as follows

(where one interval represents one range for the SFS entries):

r1r2r3. . . rG+1

[1] [2, i1] [i1+ 1, i2]. . . [iG, n0]

where n0is either n, if divergence data is used in the estimation (see -w for details), or n−1 otherwise.

For identiﬁability reasons, r1is always set to 1 and not estimated.

When running polyDFE jointly over multiple data ﬁles (see -d), either only one ID should be provided,

which is then used for all the data ﬁles, or a number j(the same as the number of input data ﬁles) of

IDs is required. In the latter case, ID_i will be used for data_file_i, for 1 ≤i≤j. Note that if the r

parameters are shared (ﬂag 2, see -i), than the grouping used has to be same for the data ﬁles.

The provided ﬁle input/params.grouping is an example of a grouping_file.

•-b [basinhop_file ID]: path to a ﬁle containing parameters that control the basin-hopping algorithm,

and id.

basinhop_file can contain any number of empty lines and comment lines that start with #. Excluding

these, the structure of each line is

id max same max iterations temperature step accept rate interval factor

Each line starts with a positive numerical id. This is used such that multiple conﬁgurations for the basin-

hopping algorithm can be stored in the same ﬁle. When running polyDFE, the desired line for the range

of the parameters is speciﬁed through the id by setting ID to the right value.

By default, polyDFE runs the optimization algorithm once (or twice, see -j for details). However, the

optimization algorithms are local, in that they only ﬁnd an optimum that is in the neighborhood of the

initial values of the parameters. To look more thoroughly for a global optimum, polyDFE allows the

user to run the basin-hopping algorithm (Purisima and Scheraga,1987;Wales and Doye,1997;Wales

and Scheraga,1999). polyDFE contains a reimplementation of the basin-hopping algorithm found in the

Python library, scipy (Jones et al.,2001–;Wales and Doye,1997).

Basin-hopping attempts to ﬁnd the global optimum by iterating the following steps

1. perturbing randomly the current value of the parameters;

2. running the local optimization algorithm (as chosen through -o) using the new values as initial

values;

3. accepting or rejecting the found optimum based on the likelihood and temperature.

Basin-hopping has been shown to be very eﬃcient for a wide variety of problems in physics and chemistry.

Unfortunately, there is no way to determine if the true global optimum has actually been found, and

therefore it is left to the user to ensure that. The algorithm is controlled through

◦max same: If after max same iterations, the basin-hopping algorithm does not ﬁnd an improved set

of parameters, than the algorithm stops. Default value: 50.

◦max iterations: The basin-hopping algorithm is ran for a maximum number of iterations. Default

value: 500.

◦temperature: The temperature is used in the metropolis criterion when accepting or rejecting the

new values. For best results, the temperature should be comparable to the typical diﬀerence in

likelihood between local optima. Default value: 1.

◦step: The step controls how far away from the current value the perturbated value is. This is crucial

for the algorithm’s performance. Ideally, it should be comparable to the typical separation between

local optima of the likelihood. The algorithm implemented in polyDFE will automatically adjust the

step, but it make take many iterations to ﬁnd an optimal value. Default value: 50.

◦accept rate: The target accept rate (percentage of new values that are accepted in step 3) for when

adjusting the step. Default value: 0.5.

◦interval: Every interval iterations, the basin-hopping algorithm adjusts the step. Default value: 10.

◦factor: When the step is adjusted, it is done with this factor. Default value: 0.9.

-b can be used without basinhop_file ID. If only -b is given, then polyDFE runs basin-hopping with

the default parameter values given above.

The provided ﬁle input/params.basinhop is an example of a basinhop_file.

7.4.2 Excluding divergence data

By default polyDFE performs the inference using all available data, including divergence data if this is present

in the data ﬁle given through -d data file. Divergence data can be excluded from the analysis by using the

argument:

•-w: do not use divergence data.

When -w is used, then the DFE and other parameters are estimated without using divergence data, as

described in Tataru et al. (2017). If the divergence data is absent from the data_file,-w will be used

by default.

7.4.3 Controlling the polyDFE output

polyDFE prints to standard output information about what type of analysis it performs, status on the opti-

mization procedure and, when this is completed, the best likelihood, gradient / size and parameters found, the

expected SFS (and divergence, if -w was not used) and estimated α. The frequency of prints regarding the

optimization procedure are controlled through the argument:

•-v verbose(0, 1, frequency): verbose frequency.

By default, verbose is set to 0, and only the names of the parameters that are estimated, their initial and

ﬁnal values are printed. Otherwise, every verbose iterations of the optimization algorithm, information is

printed about the current value of the parameters, the corresponding likelihood, gradient / size and status

of the optimization. Apart from the possible status values that GSL uses, polyDFE uses the additional

values:

◦-3: local optimization is stuck in the same parameter values (it cannot further improve on the current

values).

◦-4: restarting the local optimization lead to the same parameter values.

◦-5: the local optimization is being restarted; sometimes, when the local optimization cannot further

improve on the current values, restarting the optimization can allow it to proceed further. If the

local optimization is stuck in the same values, restarting is done at most 3 consecutive times.

◦-6: the local optimization used at least min minutes given through -l, and has been stopped.

◦-7: the likelihood evaluation returned NAN and the local optimization is therefore stopped. This

can happen for certain values of the parameters, where the numerical integration over the DFE fails.

◦-8: a maximum number of likelihood evaluations has been reached, and the local optimization has

been stopped.

When running polyDFE on multiple data ﬁles (see -d), the names of the parameters are preceded by a ﬂag i

that indicates if this parameter is either shared (i= 0) or that it is estimated for data_file_i, with 1 ≤i≤j.

7.4.4 Additional arguments

•-t: the total running time of polyDFE will be measured and printed on the standard output at the end.

7.4.5 What to do when the gradient / size is large

If inferred parameters are at a true optimum, than the gradient / size of the corresponding likelihood should

be 0. If the gradient /size is large, this indicates that the optimization failed in ﬁnding good values for the

parameters. The run of polyDFE can be changed in multiple ways to try to address this problem:

•The optimization algorithm terminates with status 0 (see -v) if the gradient / size is smaller than the

absolute tolerance value, abs. If this is too large, the optimization algorithm might terminate prematurely.

The value can be changed using -p.

•The optimization algorithm is ran for a certain number of iterations. If this number is reached, polyDFE

prints the message ”reached maximum number of iterations allowed”. If this happens and the gradient /

size is still large, the number of iterations should be increased using -p.

•The optimization algorithm has a time limit, after which it is stopped. In this case, polyDFE prints the

message ”reached maximum running time allowed”. If this happens and the gradient / size is still large,

the running time allowance should be increased using -l.

•If polyDFE was ran with -k s or -k s+j, setting -k j might lead to better estimates. See -k for details.

•If the inferred value of one of the parameters is very close to one of the borders of its range, than its range

should be consequently increased using -r.

•The optimization algorithm’s performance is highly dependent on the initial values of the parameters. To

investigate a wider range of initial values, the basin-hopping algorithm can be ran using -b.

•Diﬀerent optimization algorithms can lead to better parameters found. The optimization algorithm can

be changed using -o.

•The parameters are transformed from their range to (−∞,+∞) using a generalized logistic function which

depends on a parameter k. Choosing a diﬀerent value for kby using -r might lead to a better result.

•If the sample size nof the data is large, then a lot of parameters have to be estimated, which might

interfere with the optimization process. To reduce the number of parameters, the rparameters can be

grouped by using -g. However, an initial optimization is still needed to gain some information on how

the grouping of the rparameters should be done. Then automatic grouping can be calculated in Rusing

createInitLines.

7.4.6 Examples

Inferring a full DFE using model Cusing default arguments:

$ ./polyDFE -d input/example_2 > output/example_2_full_C

Inferring a full DFE using model C, while running the optimization algorithm twice, once initialized with

estimated parameters, and once with parameters speciﬁed from ﬁle:

$ ./polyDFE -d input/example_2 -i input/init_model_BandC.txt 1 -v 20 -j > output/example_2_init_C

Inferring a deleterious DFE using model C:

$ ./polyDFE -d input/example_2 -i input/init_model_BandC.txt 2 -v 100 > output/example_2_del

Inferring a full DFE using model Cwithout mutation variability:

$ ./polyDFE -d input/example_2 -i input/init_model_BandC.txt 3 > output/example_2_novar_C

Inferring a full DFE using model Cwithout nuisance rparameters, and using diﬀerent kinds of likelihood

optimization and parametrization of the optimziation algorithm:

$ ./polyDFE -d input/example_2 -i input/init_model_BandC.txt 4 -j > output/example_2_nonuis_C

$ ./polyDFE -d input/example_2 -i input/init_model_BandC.txt 4 -j -k s \

-p input/params.optim 4 > output/example_2_nonuis_s_C

$ ./polyDFE -d input/example_2 -i input/init_model_BandC.txt 4 -j -k s+j \

> output/example_2_nonuis_sj_C

The above examples illustrate that using -k s and -k s+j can give poor estimates. When the runs are

initialized with the values calculated automatically (see -j), -k s terminates with likelihood −3930.524,

while -k s+j terminates with likelihood −3928.647. The default run (-k j) ﬁnds a much better likelihood

of −3924.453. However, when the runs are initialized with the values used for simulating the data from

input/init_model_BandC.txt, all runs ﬁnd likelihoods that are approximately −3924.5. This indicates that

-k s and -k s+j should be used with caution, as they might lead to suboptimal estimates.

Inferring a full DFE using model Aand 10 basin-hopping iterations:

$ ./polyDFE -d input/example_2 -m A -i input/init_model_A.txt 1 -e \

-b input/params.basinhop 1 -v 200 > output/example_2_full_A

Inferring a full DFE using model C where this is shared or not across 2 data ﬁles:

$ ./polyDFE -d input/example_1:input/example_2 -i input/init_model_BandC.txt 1 -e \

-v 200 > output/example_1_2_indep

$ ./polyDFE -d input/example_1:input/example_2 -i input/init_model_BandC.txt 20 -e \

-v 200 > output/example_1_2_share

8 Post-processing using R

polyDFE is accompanied by a series for Rfunctions that allow

•parsing the output of polyDFE for easy manipulation in R

•summarizing the DFE estimated by polyDFE

•calculating αusing alternative deﬁnitions

•bootstrapping data

•performing model testing

•performing model averaging

•creating init_file containing the best found parameters

•creating grouping for the rparameters

8.1 Parsing the output of polyDFE

The function

parseOutput(filename)

allows the user to parse the output of polyDFE from multiple runs stored in filename. The function returns a

list with entries for each separate run of polyDFE found, containing

•the name of the input ﬁle used;

•the DFE model used;

•the best likelihood found and the corresponding gradient;

•the values of all parameters (including those that have been ﬁxed using the ﬂag 1 in init_file, see -i

for details);

•which parameters have been estimated;

•the value of n(the sample size of the data);

•expected SFS and, if relevant, divergence counts and misattributed polymorphism;

•estimates of α.

8.2 Summarizing the DFE

The function

getDiscretizedDFE(estimates, sRanges = c(-100, -10, -1, 0, 1, 10))

discretizes the DFE found in estimates, which is one entry from the list returned by parseOutput. The

discrete categories are given as a vector in sRanges.

8.3 Calculating α

The function

estimateAlpha(estimates, supLimit = 0, div = NULL, poly = TRUE)

calculates both αdiv (when div = NULL) and αdfe (when div is given) (Tataru et al.,2017), using the parameters

found in estimates, which is one entry from the list returned by parseOutput.

Galtier (2016) argues that mutations with positive selection coeﬃcients that are not higher than a certain

threshold should, eﬀectively, be treated as neutral mutations when calculating α(see also Tataru et al. (2017)).

This threshold can be controlled here by setting supLimit.

When used, div should contain divergence data, which can be read using the function

parseDivergenceData(filename)

where filename is the same data ﬁle used for running polyDFE, see -d for details.

As described in Tataru et al. (2017), divergence data can contain misatributed polymorphism. This is the

default behavior, but the correction can be turned oﬀ by setting poly = FALSE.

8.4 Bootstrapping data

The function

bootstrapData(inputfile, outputfile = NULL, rep = 1)

creates bootstrap data from the data found in inputfile, which is the same data ﬁle used for running polyDFE,

see -d for details. The output is written to ﬁles with names <outputfile>_i for 1 ≤i≤rep. By default,

outputfile = NULL, and the function writes to <inputfile>_i instead.

8.5 Model testing

The function

compareModels(est1, est2 = NULL, nested = NULL)

compares the models found in est1 and est2 by calculating the AIC and, where relevant, the LRT.

Both est1 and est2 can either be lists returned by parseOutput, or ﬁle names, as for parseOutput. If these

contain more then one run of polyDFE, then run ifrom est1 is compared to run ifrom est2.

The function can automatically detect if models are nested for calculating the LRT, however nestedness can be

enforced by setting nested = TRUE.

The function returns a list containing two entries

•AIC is a matrix containing the number of estimated parameters, the log likelihood and AIC for est1 in

columns 1 – 3 and for est2 in columns 4 – 6, for all runs of polyDFE found in each row;

•LRT is a matrix containing the degrees of freedom in column 1, the likelihood of est1 in column 2, the

likelihood of est2 in column 3 and the p-value from the LRT test in column 4, for all runs of polyDFE

found in each row.

If est2 = NULL, only the AIC is calculated for est1.

8.6 Model averaging

The function

getAICweights(estimates)

calculates AIC weights (Posada and Buckley,2004) for the runs of polyDFE found in estimates, a list as

returned by parseOutput. The weights can the be used to calculate model avearge for a parameter of interest,

such as any DFE parameter, or a discretized DFE (see getDiscretizedDFE)), α, or any other calculable

quantities.

8.7 Creating init file

The function

createInitLines(estimates, outputfile, startingID = 1,

fix = c("eps_cont"), share = "all", groupingDiff = NA)

writes the values of the parameters found in estimates, a list as returned by parseOutput, or a ﬁle name,

as for parseOutput. For each run of polyDFE, a new line is appended to <outputfile>_init containing the

values of the best parameters found in the format described previously (see -i for details).

The IDs for each line are consecutive and start at startingID.

The parameters given in fix are ﬂagged with 1, the ones in share are ﬂagged with 2, while the rest of the

parameters are ﬂagged with 0. If fix = "all", than all parameters are ﬂagged with 1, and, similarly, if

share = "all", than all parameters are ﬂagged with 2.

Grouping of rparameters (see -g for details) can be calculated automatically by setting groupingDiff. If the

diﬀerence between riand ri+1 is smaller than groupingDiff, than they are placed in the same group. The

grouping information is appended to <outputfile>_grouping, with ID matching to the ID in <outputfile>_init.

8.8 Examples

The accompanying ﬁle example.R shows how to post-process the polyDFE output ﬁles generated in 7.4.6.

Index

polyDFE arguments

-b,10

-d,4

-e,8

-g,9

-h,4

-i,5

-j,8

-l,8

-m,5

-o,7

-p,7

-r,9

-s,6

-t,11

-v,11

-w,11

Rpostprocessing functions

bootstrapData, 14

compareModels, 14

createInitLines, 15

estimateAlpha, 14

getAICweights, 14

getDiscretizedDFE, 13

parseDivergenceData, 14

parseOutput, 13

References

N. Galtier. Adaptive protein evolution in animals and the eﬀective population size hypothesis. PLoS genetics, 12(1),

2016.

E. Jones, T. Oliphant, P. Peterson, et al. SciPy: Open source scientiﬁc tools for Python, 2001–. URL http://www.

scipy.org/. [Online; accessed 2016-09-21].

D. Posada and T. R. Buckley. Model selection and model averaging in phylogenetics: advantages of akaike information

criterion and bayesian approaches over likelihood ratio tests. Systematic biology, 53(5):793–808, 2004.

E. O. Purisima and H. A. Scheraga. An approach to the multiple-minima problem in protein folding by relaxing

dimensionality: Tests on enkephalin. Journal of Molecular Biology, 196(3):697–709, 1987.

P. Tataru and T. Bataillon. polyDFEv2.0: Testing for invariance of the distribution of ﬁtness eﬀects within and across

species. bioRxiv, 2018. doi: https://doi.org/10.1101/363887.

P. Tataru, M. Mollion, S. Gl´emin, and T. Bataillon. Inference of distribution of ﬁtness eﬀects and proportion of adaptive

substitutions from polymorphism data. Genetics, 207(3):1103–1119, 2017.

D. J. Wales and J. P. Doye. Global optimization by basin-hopping and the lowest energy structures of Lennard-Jones

clusters containing up to 110 atoms. The Journal of Physical Chemistry A, 101(28):5111–5116, 1997.

D. J. Wales and H. A. Scheraga. Global optimization of clusters, crystals, and biomolecules. Science, 285(5432):

1368–1372, 1999.

Manual

Navigation menu

Versions of this User Manual:

Views

Navigation
