PROFESSIONAL INDUSTRIAL SCADA / HMI
Our vision: „A customer has a complete access
to the technology, anywhere and anytime.“
mySCADA Technologies Product Guide 1www.myscada.org
mySCADA VALUES
QUALITY
Our aim is always assure the highest quality of our products.
We respond quickly and flexibly to the automation market
changes by applying many years of industrial automation SCADA
system experience to meet new requirements and challenges of
our clients. Product development always involves a close contact with
mySCADA users and an innovative approach. We have the utmost
confidence in high stability and quality of our products.
FAIR PRICING
We believe that innovative and advanced SCADA system at
an affordable price is not impossible to achieve. We deliver
the top quality at reasonable prices so that a wide range of
customers can afford no-compromise high quality mySCADA
products, from a small single client solution to large automa-
tion SCADA projects.
SERVICE & SUPPORT
We highly value the relationships with our clients. The
clients feedback and inquiries are treated with the
upmost importance by mySCADA support team. Our
engineers provide an exceptional and reachable technical
assistance and repair services for all mySCADA products.
Our goal is to achieve 100% client satisfaction.
OUR MARKET
We provide a full range of industrial SCADA/HMI (Human Machine Interface) software and hardware solutions that empower you to get a full control of your automation
systems and networks. Our current product range includes industrial automation SCADA/HMI applications for mobile and smart devices operated on iOS and Android,
myBOX range and myPRO range operated on Windows, OS X and Linux. The core of our system is myDESIGNER - the central all-in-one project development studio.
mySCADA Technologies Product Guide 2www.myscada.org
mySCADA FEATURES AND HIGHLIGHTS
SCALABILITY AND VERSATILITY
With mySCADA you can easily create HMI/SCADA projects of any size.
Thanks to its scalable architecture, mySCADA can be deployed from smaller
automated production lines up to redundant multi-user plant systems. As your
business grows, mySCADA grows with you. Using this standard and open
technology you can upgrade your system with additional or new technologies
and devices any time later in the future. You do not need to pay for additional
modules as the functionality of your system is always unlimited. You can easily
upscale your system as your requirements evolve.
EASY DEPLOYMENT
Save your time and money – create your project just once and download it
to any device you want with a single mouse click.
Simple, intuitive, user-friendly project development platform myDESIGNER is a software tool for system configuration and HMI project deployment that makes the core of mySCADA
System. All visualizations are drawn in vector graphics that is independent on screen resolutions. Therefore, you do not have to re-design your project to get a fully functional HMI on a
device of your choice regardless of the screen size.
FLEXIBILITY
Multiple, feature-rich HMI screens, built-in web server, web-based deployment, platform independ-
ent.
With mySCADA you can access your technology with a regular computer, smartphone, tablet or even
smart television without a functionality or speed limitation. You can quickly launch your system across
any number of clients without any installation at all. All you need is a modern web-browser. mySCADA
runs on Windows, Mac OS X, Linux, iOS, Android – you never have to worry about the operating system
you are using.
mySCADA Technologies Product Guide 3www.myscada.org
MODERN AND INNOVATIVE
While designing mySCADA we have been looking for the most innovative approach that would
combine the best SCADA functionality with latest IT technology and its standard protocols and
practices.
mySCADA is based on the latest industrial and IT open standards and is very powerful and straight forward
to use it - has built-in server side scripting, very smart and affordable licensing, works on all operating
systems and supports advanced data collecting. mySCADA is a modern system built by professionals who
have an ongoing expertise in the automation and IT industries.
INTEGRATED CONNECTIVITY
mySCADA integrates PLC communication drivers at the system level to provide a maximum communication speed and
efficiency.
You need not to pay for any extra software to communicate with your PLC or DCS controller and put a complicated system
configuration in risk. With built-in communication drivers mySCADA reaches top-speed performance while ensuring
absolute reliability, simplicity and high security. mySCADA integrates the communication drivers of all major PLC brands or
relies on the built in OPC UA driver.
SECURITY AND SCALABILITY
Industrial - grade security and reliability is ensured at all levels of mySCADA.
mySCADA provides options to configure user access management and user action tracking.
SSL secure web page access is on the same security level as common banking applications.
Multiple Virtual Private Networks (VPN) provides a trouble-free and secure connection of
your technology into the Internet.
mySCADA Technologies Product Guide 4www.myscada.org
POWERFUL CONNECTIVITY
Melsec - Q
Mitsubishi PLCs
OPC UA
OPC Unified Architecture Client Driver
EtherNet/IP
ControLogix, CompactLogix, MicroLogix, SLC 500, PLC 5, Omron PLCs,...
Modbus TCP (RTU)
ABB, Wago, Unitronics, Schneider PLCs,...
Siemens S7
Siemens S7-300, Siemens S7-400, Siemens S7-1200, Siemens LOGO!
Toyopuc
Toyota PLCs
mySCADA Technologies Product Guide 5www.myscada.org
mySCADA Technologies Product Guide 6www.myscada.org
13 - 20
myBOX
11 - 12
myPRO
9 - 10
myMOBILE
7 - 8
myDESIGNER
TABLE OF CONTENTS
GUI design in scalable vector graphics (SVG)
Support for background images (JPEG, GIF, PNG)
Ability to attach PDF-documents to the projects
Ability to attach MP3-sounds to the projects
Rich component library
Animations and effects based on tag values can
be added to any shape or objects
Simple to use
Free for personal and business use
myDESIGNER
Unified design tool for any platform
myDESIGNER is an integrated all-in-one project development software tool for configuration and project deployment and is the core of mySCADA system.
myDESIGNER is the HMI visualization platform, where users can build scalable, vector-based graphics that keep the crisp quality when zoomed in can be used without limitation for screens
with different resolutions. myDESIGNER is very intuitive, flexible and simple to use. You can quickly choose elements for your projects from the rich components library, set all kinds of
animations for graphical elements, stylize the colors, gradients and even create complex time effects in few simple steps. myDESIGNER is built with maximum user comfort in mind, to
make your work efficient and comfortable. myDESIGNER is available on windows, Mac OS X and Linux.
mySCADA Technologies Product Guide 7www.myscada.org
česlečeslečesle
česlečeslečesle
myDESIGNER
mySCADA Technologies Product Guide 8www.myscada.org
myDESIGNER
myMOBILE
myPRO
myBOX
myMOBILE
smart SCADA for smart devices
myMOBILE brings a whole new range of mobile control possibilities into industrial control and maintenance. Using the current mobile smart devices significantly reduces your
costs while following the latest technology trends. myMOBILE can either complement or replace your current operators panels, and can be used by the field operators for a
local or remote control. With the myDESIGNER all-in-one development platform it is really easy and quick to create your projects and start using the application even for less
experienced users.
The communication drivers are embedded, so all you need is you smart device, WiFi network or Internet connection and myMOBILE for iOS or Android Application. For remote connections,
myMOBILE operates through a secure VPN link to provide a maximum security for your technology.
Complete HMI PLC Interface System
Multi-touch and Zoom
Alarms, Trends, Charts
Remote Access
CONTROL YOUR FACTORY WITH TABLET OR SMART PHONE,
ANYTIME AND FROM ANYWHERE IN THE WORLD
mySCADA Technologies Product Guide 9www.myscada.org
myMOBILE
You can buy our products online
checkout our new webshop
CONNECT THE DECISION MAKERS
WITH THE REAL TIME DATA
OPERATORS
Stay in touch and be informed even when
traveling
Get alarm notification immediately even
on remote locations
MAINTENANCE
Extend your reach with remote access
and save the travel costs and time
Remote monitoring and diagnostics
MANAGEMENT
Visualize business data at all times from
anywhere
Get access to your production data
directly from your office
Use the production data to analyze and
improve your business performance
mySCADA Technologies Product Guide 10www.myscada.org
store.myscada.org
myPRO
Professional HMI/SCADA software package
Web-Based Access
Multi Platform
HMI/SCADA Software
Smart and Affordable Pricing for All Project Sizes
Alarms, Trends, Charts
Complex Reporting
Extremely Fast Response Rates due to Integrated
Architecture
FULL-FEATURED, YET SIMPLE, COST EFFECTIVE,
ROBUST SCADA/HMI SOLUTION OF YOUR AUTOMATION NEEDS
myPRO is a powerful software package featuring complete options for professional visualization, processing and analysis of real-time industrial processes. myPRO is an
advanced stand-alone HMI/SCADA solution that relies on the client/server architecture. myPRO has been designed with respect to the maximum user comfort. It is simple to
install, simple to use and simple to maintain.
mySCADA Technologies Product Guide 11www.myscada.org
myPRO
mySCADA Technologies Product Guide 12www.myscada.org
mySCADA is an optimized soft-
ware solution suitable to run on
Operators panels. You can use
Windows or Linux OS based
operators panels.
PANEL SOLUTION
myPRO is based on client/serv-
er architecture. Therefore it can
be deployed on any server
running Linux, Windows or Mac
OS X. You can have an unlimited
number of clients connected.
SERVER SOLUTION
Use myPRO directly on a opera-
tor's computer. myPRO package
is an advanced stand-alone
HMI/SCADA solution bringing
together a server and client for
trouble-free use on a single
computer.
DESKTOP SOLUTION
HMI Interface
Vector Graphics
Web Access
Multiple Simultaneous Users
Alarming
Data Logging
Remote Access
Reporting
Visual Programming
Server Side Scripting
Multiple PLC Protocols
myBOX
Complete and innovative package
THE FLEXIBILITY AND PERFORMANCE OF
THIS RELIABLE AND FAST COMPACT SYSTEM IS IMPRESSIVE...
myBOX provides innovative, and above all, fast and compact devices-myBOX Optimum, myBOX Logger and myBOX Extreme that integrate the most important HW and SW
elements of a reliable SCADA system into one small device. These compact devices embrace the functionality of industrial SCADA server, communication server, HMI visuali-
zation software (except for myBOX Logger), switch, router and 3G/LTE modem. Compact means all-in-one solution that has been designed for maximum flexibility and effec-
tiveness. myBOX devices can be easily and quickly deployed on the top of your existing technology network.
To be able to respond to an increasing pressure on production efficiency and manage the ongoing data flow, using a reliable and powerful SCADA system is essential. With myBOX
you easily turn your production data into useful information being delivered to competent users for better, more informed decision making.
mySCADA Technologies Product Guide 13www.myscada.org
CPU
Port 1 (Serial or Ethernet)
Port 2 (Serial or Ethernet)
Memory (SSD Drive)
Micro SD Card Slot
Power Supply Socket
Ethernet Port
SIM Card Compartment
GSM 3G/LTE, GPS
Ethernet (10/100 Mbit) or
Serial Port (2xRS232, 1xRS485) or
WiFi (802.11 b/g)
Ethernet (10/100 Mbit) or
Serial Port (2xRS232, 1xRS485)
Highest
performance
up to quad core 1.3
GHz CPU (ARM Cortex
A9 with ULP GeForce
GPU)
Memory for
huge data load
up to 1 GB RAM
up to 16 GB SSD
micro SD Card
Ethernet
interface
up to 3x10/100 Mbit
Ethernet, routing,
VPN, firewall
Serial-ports
up to 4xRS232 and
2xRS485 serial ports
Wi-Fi
802.11 b/g
AP mode
Client mode
3G/4G Modem
Integrated GPS
Functionality
dual SIM option on
request
mySCADA Technologies Product Guide 14www.myscada.org
myBOX
myBOX
myBOX LOGGER
Remote machinery diagnostics
myBOX Logger is a single-purpose industrial device for data logging with remote troubleshooting via a secure web server or integrated VPN server. Monitoring functions let you set and
generate alarm notifications for critical conditions by SMS and e-mail. You can access your production data through a comfortable web interface with one click export to MS Excel. Use
myREPORTS Application to plot and analyse the logged data to closely track your production efficiency and quality. myBOX Logger is easy to extend with user definable scripts and report-
ing options.
Siemens S7
PLC Protocol
S7-1200, S7-200, S7-300, LOGO! ...
EtherNet/IP
Modbus serial IPCDAS, ADAM, RTUs,…
Melsec Binary Melsec-Q, E71 controller type, 3E packets
Fully Supported Including Hierarchy
OPC Unified Architecture Client Driver
OPC UA
Toyopuc
ControlLogix, CompactLogix, Micrologix 1200, Micrologix 1400,
Micrologix 1500, SLC 500, PLC 5, Omron PLCs
Wago, Schneider, Micrologix, RTUs, …Modbus TCP
Type
3G Module
Quad-band HSPA+/HSUPA/HSDPA/WCDMA
2100/1900/900/850 (MHz)
Quad-band GSM/GPRS/EDGE 850/900/1800/1900 (MHz)
Download / upload 21Mbps / 5.76Mbps
Cerfitications CE, FCC, RoHS, IC, GCF, PTCRB, CCC
LTE Module
Type LTE (FDD) B1/B2/B3/B5/B7/B8/B20
DC-HSPA+/HSPA+/HSPA/UMTS dual-band B1/B2/B5/B8
EDGE/ GPRS/ GSM quad-band 850/900/1800/1900 MHz
Download / upload 100Mbps / 50Mbps
Cerfitications CE, GCF, RoHS
Type
Wifi Module
802.11b/g
Access Point Mode Yes
Frequency 2.4 GHz WLAN
WEP, TKIP, and AES
CE, FCC, RoHS
HW Encryption
72.2 Mbps for 20 MHz channel,
150 Mbps for 40 MHz channel
Speed
Certifications
No. of simultaneously
connected clients
Max 7
I/O Port
SD Card Yes
Ethernet 10/100 Mbit up to 3 ports
RS485 up to 2 ports
HW Watchdog integrated
RS232 up to 4 ports
Networking
DHCP Client and Server
Interface Routing and bridging supported
Firewall Integrated
dynDNS Supported
Network Address Translation (NAT) Supported
Performance
Performance
High
CPU NVIDIA® TegraTM 2 ARM CortexTM-A9 Dual Core 2x1 GHz,
1MB Level 2 cache
Temperature
0° to 70° C, -40° to 85° C (IT Version), -20° to 70° C (IT 3G)
CE, FCC, RoHS
Highly recyclable, RoHS, Ultra low power consumption
Temperature Range
Certification
Ecology
Memory RAM 512MB DDR2 (32 Bit)
Storage 1GB Flash / 16 GB SSD
Power
Dimensions
Supply Voltage 12-48 VDC
Size 127 x 33 x 128 mm (W x H x D)
Type
GPS Standalone GPS, A-GPS, GPS Extra
Data format NMEA data
Security
VPN PPTP Client and Server
Cisco VPN Direct import of pcf files
IPSEC Full support
Open VPN Client and server
mySCADA Technologies Product Guide 15www.myscada.org
myBOX
2014 mySCADA Technologies Product Guide 16www.myscada.org
SAVE YOUR TIME AND MONEY ENGAGING
myBOX Logger FOR DIRECT 24/7 INTERNET ACCESS
TO YOUR REMOTE TECHNOLOGY.
myBOX Logger
LGR-NNNN
2x
4x
2x
1x
2x
1x
2x
4x
1x
2x
1x2x
2x
4x
1x
2x
1x2x
1x2x
1x2x
1x2x
LGR-ENNN
LGR-EENN
LGR-SNNN
LGR-SSNN
LGR-ESNN
LGR-NNGN
LGR-ENGN
LGR-EEGN
LGR-SNGN
LGR-SSGN
LGR-ESGN
LGR-NWNN
LGR-EWNN
LGR-SWNN
LGR-NWGN
LGR-EWGN
LGR-SWGN
LGR-NNLN
LGR-ENLN
LGR-EELN
LGR-SNLN
LGR-SSLN
LGR-ESLN
LGR-NWLN
LGR-EWLN
LGR-SWLN
Ordering Code
Integrated Ethernet Port
Second Ethernet Port
Third Ethernet Port
3G Modem
LTE Modem
WiFi Module
RS232
Serial Ports Card
RS485
-/
PRODUCT
LGR
P1
N - None
E - Ethernet
S - Serial ports
CUSTOM
N - None
I - Industrial*
2S - Double sim
O1
N - None
G - 3G Modem
L - LTE Modem
O2
N - None
M - Memory
16 Gbyte
P2
N - None
S - Serial ports
W - WiFi
N - None
E - Ethernet
*Industrial version covers the enhanced industrial temperature
range of -40º C to +85º C (available on requst)
mySCADA Technologies Product Guide 17www.myscada.org
myBOX
myBOX OPTIMUM
Boost the performance of your automation system
myBOX Optimum is an unique all-in-one industrial grade SCADA system, suitable for all kinds of small, mid-large and heavy industrial production branches, such as water and
waste control, automation, energy, oil and gas refining, transportation, telecommunications, food and beverage that can be easily added to your existing network.
myBOX Optimum comes with mySCADA software built-in the device, no additional programs or plugins are needed. Thanks to its robust nature, you can put the myBOX Optimum right
next to your PLC. Connecting with your PLC or DCS system is extremely simple due to the integrated communication drivers. Plug in the myBOX Optimum and instantly use the rich,
perfectly looking HMI to visualize your processes, turn on alarm notifications for critical events, enable remote connection to your technology with the help of integrated VPN services,
bridge your PLC network securely into the internet, use the advanced logging options with integrated reporting. Have instant access to your technology with no compromises.
I/O Port
SD Card Yes
Ethernet 10/100 Mbit up to 3 ports
RS485 up to 2 ports
HW Watchdog integrated
RS232 up to 4 ports
Networking
DHCP Client and Server
Interface Routing and bridging supported
Firewall Integrated
dynDNS Supported
Network Address Translation (NAT) Supported
Performance
Performance
High
CPU NVIDIA® TegraTM 2 ARM CortexTM-A9 Dual Core 2x1 GHz,
1MB Level 2 cache
Temperature
0° to 70° C, -40° to 85° C (IT Version), -20° to 70° C (IT 3G)
CE, FCC, RoHS
Highly recyclable, RoHS, Ultra low power consumption
Temperature Range
Certification
Ecology
Memory RAM 512MB DDR2 (32 Bit)
Storage 1GB Flash / 16 GB SSD
Power
Dimensions
Supply Voltage 12-48 VDC
Size 127 x 33 x 128 mm (W x H x D)
Security
VPN PPTP Client and Server
Cisco VPN Direct import of pcf files
IPSEC Full support
Open VPN Client and server
Siemens S7
PLC Protocol
S7-1200, S7-200, S7-300, LOGO! ...
EtherNet/IP
Modbus serial IPCDAS, ADAM, RTUs,…
Melsec Binary Melsec-Q, E71 controller type, 3E packets
Fully Supported Including Hierarchy
OPC Unified Architecture Client Driver
OPC UA
Toyopuc
ControlLogix, CompactLogix, Micrologix 1200, Micrologix 1400,
Micrologix 1500, SLC 500, PLC 5, Omron PLCs
Wago, Schneider, Micrologix, RTUs, …Modbus TCP
Type
3G Module
Quad-band HSPA+/HSUPA/HSDPA/WCDMA
2100/1900/900/850 (MHz)
Quad-band GSM/GPRS/EDGE 850/900/1800/1900 (MHz)
Download / upload 21Mbps / 5.76Mbps
Cerfitications CE, FCC, RoHS, IC, GCF, PTCRB, CCC
LTE Module
Type LTE (FDD) B1/B2/B3/B5/B7/B8/B20
DC-HSPA+/HSPA+/HSPA/UMTS dual-band B1/B2/B5/B8
EDGE/ GPRS/ GSM quad-band 850/900/1800/1900 MHz
Download / upload 100Mbps / 50Mbps
Cerfitications CE, GCF, RoHS
Type
Wifi Module
802.11b/g
Access Point Mode Yes
Frequency 2.4 GHz WLAN
WEP, TKIP, and AES
CE, FCC, RoHS
HW Encryption
72.2 Mbps for 20 MHz channel,
150 Mbps for 40 MHz channel
Speed
Certifications
No. of simultaneously
connected clients
Max 7
Type
GPS Standalone GPS, A-GPS, GPS Extra
Data format NMEA data
mySCADA Technologies Product Guide 18www.myscada.org
myBOX
myBOX Optimum
*Industrial version covers the enhanced industrial temperature
range of -40º C to +85º C (available on requst)
-/
PRODUCT
BOX
P1
N - None
E - Ethernet
S - Serial ports
CUSTOM
N - None
I - Industrial*
2S - Double sim
O1
N - None
G - 3G Modem
L - LTE Modem
O2
N - None
M - Memory
16 Gbyte
P2
N - None
S - Serial ports
W - WiFi
N - None
E - Ethernet
myBOX OPTIMUM
Technology
Network
Operators PC
Supervision
Network
WEB Client
LAN 2
WAN
4G/LTE Backup
Engineering
station
myMOBILE
Siemens S7
Modbus
EtherNet/IP
LAN 1
SCADA functions NETWORKING functions
advanced HMI interface
multiple PLC protocols
simultaneous Client Access
complex alarm system
trends, reports and data analysis
secure user access and control
visual programming
server side scripts
integrated secure web server
advanced routing options
multiple types of VPN tunnels,
(Cisco, PPTP, IPSEC, Open VPN)
remote access and control
remote PLC programming
optional integrated 3G/4G
modem with GPS functionality
BOX-NNNN
2x
4x
2x
1x
2x
1x
2x
4x
1x
2x
1x2x
2x
4x
1x
2x
1x2x
1x2x
1x2x
1x2x
BOX-ENNN
BOX-EENN
BOX-SNNN
BOX-SSNN
BOX-ESNN
BOX-NNGN
BOX-ENGN
BOX-EEGN
BOX-SNGN
BOX-SSGN
BOX-ESGN
BOX-NWNN
BOX-EWNN
BOX-SWNN
BOX-NWGN
BOX-EWGN
BOX-SWGN
BOX-NNLN
BOX-ENLN
BOX-EELN
BOX-SNLN
BOX-SSLN
BOX-ESLN
BOX-NWLN
BOX-EWLN
BOX-SWLN
Ordering Code
Integrated Ethernet Port
Second Ethernet Port
Third Ethernet Port
3G Modem
LTE Modem
WiFi Module
RS232
Serial Ports Card
RS485
mySCADA Technologies Product Guide 19www.myscada.org
myBOX
myBOX EXTREME
Rebuilt for performance and speed
When designing myBOX Extreme, we took an approach that centered around the highest possible performance for professional industrial use – it is equipped with Quad (4x) Core 1.4 GHz
CPU, 1 GB DDR3 (32 Bit) RAM and 16 GB Industrial Flash memory storage. myBOX Extreme is a complete SCADA package that integrates networking and advanced security functions. It is
capable of managing huge data volumes and high memory storage requirements without decreasing the real-time speed and the response time. myBOX Extreme is ideal for the most
demanding projects from all kinds of industries.
I/O Port
SD Card Yes
Ethernet 10/100 Mbit up to 3 ports
RS485 up to 2 ports
HW Watchdog integrated
RS232 up to 4 ports
Networking
DHCP Client and Server
Interface Routing and bridging supported
Firewall Integrated
dynDNS Supported
Network Address Translation (NAT) Supported
Performance
Performance
Ultra
CPU NVIDIA® TegraTM 3 ARM CortexTM-A9 Quad Core 4x 1.4 GHz,
1MB Level 2 cache
Temperature
0° to 70° C, -40° to 85° C (IT Version), -20° to 70° C (IT 3G)
CE, FCC, RoHS
Highly recyclable, RoHS, Ultra low power consumption
Temperature Range
Certification
Ecology
Memory RAM 1 GB DDR3 (32 Bit)
Storage 16 GB Flash
Power
Dimensions
Supply Voltage 12-48 VDC
Size 127 x 33 x 128 mm (W x H x D)
Security
VPN PPTP Client and Server
Cisco VPN Direct import of pcf files
IPSEC Full support
Open VPN Client and Server
Siemens S7
PLC Protocol
S7-1200, S7-200, S7-300, LOGO! ...
EtherNet/IP
Modbus serial IPCDAS, ADAM, RTUs,…
Melsec Binary Melsec-Q, E71 controller type, 3E packets
Fully Supported Including Hierarchy
OPC Unified Architecture Client Driver
OPC UA
Toyopuc
ControlLogix, CompactLogix, Micrologix 1200, Micrologix 1400,
Micrologix 1500, SLC 500, PLC 5, Omron PLCs
Wago, Schneider, Micrologix, RTUs, …Modbus TCP
Type
3G Module
Quad-band HSPA+/HSUPA/HSDPA/WCDMA
2100/1900/900/850 (MHz)
Quad-band GSM/GPRS/EDGE 850/900/1800/1900 (MHz)
Download / upload 21Mbps / 5.76Mbps
Cerfitications CE, FCC, RoHS, IC, GCF, PTCRB, CCC
LTE Module
Type LTE (FDD) B1/B2/B3/B5/B7/B8/B20
DC-HSPA+/HSPA+/HSPA/UMTS dual-band B1/B2/B5/B8
EDGE/ GPRS/ GSM quad-band 850/900/1800/1900 MHz
Download / upload 100Mbps / 50Mbps
Cerfitications CE, GCF, RoHS
Type
Wifi Module
802.11b/g
Access Point Mode Yes
Frequency 2.4 GHz WLAN
WEP, TKIP, and AES
CE, FCC, RoHS
HW Encryption
72.2 Mbps for 20 MHz channel,
150 Mbps for 40 MHz channel
Speed
Certifications
No. of simultaneously
connected clients
Max 7
Type
GPS Standalone GPS, A-GPS, GPS Extra
Data format NMEA data
mySCADA Technologies Product Guide 20www.myscada.org
myBOX
myBOX Extreme
BEX-NNNM
2x
4x
2x
1x
2x
1x
2x
4x
1x
2x
1x2x
2x
4x
1x
2x
1x2x
1x2x
1x2x
1x2x
BEX-ENNM
BEX-EENM
BEX-SNNM
BEX-SSNM
BEX-ESNM
BEX-NNGM
BEX-ENGM
BEX-EEGM
BEX-SNGM
BEX-SSGM
BEX-ESGM
BEX-NWNM
BEX-EWNM
BEX-SWNM
BEX-NWGM
BEX-EWGM
BEX-SWGM
BEX-NNLM
BEX-ENLM
BEX-EELM
BEX-SNLM
BEX-SSLM
BEX-ESLM
BEX-NWLM
BEX-EWLM
BEX-SWLM
Ordering Code
Integrated Ethernet Port
Second Ethernet Port
Third Ethernet Port
3G Modem
LTE Modem
WiFi Module
Memory Module 16GB
RS232
Serial Ports Card
RS485
SCADA functions NETWORKING functions
advanced HMI interface
multiple PLC protocols
simultaneous Client Access
complex alarm system
data logging (periodic and event driven)
trends, reports and data analysis
secure user access and control
visual programming
server side scripts
integrated secure web server
advanced routing options
multiple types of VPN tunnels,
(Cisco, PPTP, IPSEC, Open VPN)
remote access and control
remote PLC programming
optional integrated 3G/4G
modem with GPS functionality
-/
PRODUCT
BEX
P1
N - None
E - Ethernet
S - Serial ports
CUSTOM
N - None
I - Industrial*
2S - Double sim
O1
N - None
G - 3G Modem
L - LTE Modem
M - Memory
16GB
P2
N - None
S - Serial ports
W - WiFi
N - None
E - Ethernet
*Industrial version covers the enhanced industrial temperature
range of -40º C to +85º C (available on requst)
myBOX EXTREME
Technology
Network
Operators PC
Supervision
Network
WEB Client
LAN 2
WAN
3G Backup
Engineering
station
myMOBILE
Siemens S7
Modbus
EtherNet/IP
LAN 1
mySCADA Technologies is an independent Czech company focused fully on the development and production of
industrial SCADA/HMI systems. Our engineers have many years of experience in industrial automation and
know-how of the technological processes control. We introduce highly innovative, scalable process
visualization products and solutions built on open-architecture that offer high-performance
functions for modern and effective monitoring of automation processes. All our products are
developed and manufactured exclusively in Europe.
OUR TEAM
mySCADA development team puts an incredible energy and enthusiasm into developing and testing our
products. Our engineers and technicians focus on the future trends and the latest technologies to ensure
mySCADA is always one step ahead of our competitors. We provide regular updates and new system
functionalities to guarantee a maximum efficiency of your mySCADA system.
mySCADA Technologies Product Guide 21www.myscada.org
ABOUT mySCADA TECHNOLOGIES
myMOBILE myPRO myBOX myHOME
WHO WE ARE
mySCADA Technologies Product Guide 22www.myscada.org
INNOVATIVE, FAST, PERFECTLY DESIGNED,
EXTREMELY POWERFUL… mySCADA
www.myscada.org
+420 224 904 121
Evropska 11
160 00 Prague, Czech Republic
info@myscada.org store.myscada.org

Navigation menu
