BE365 FE575/FE595
Keypad
Locks
User Guide
PLEASE KEEP THIS GUIDE
You will need these codes to operate
your lock!
CONSERVE ESTA GUÍA
¡Necesitará estos códigos para operar
la cerradura!
VEUILLEZ CONSERVERCE GUIDE
Vous aurez besoin de ces codes pour
faire fonctionner la serrure!
Place Label Here
Poner la etiqueta aquí
Placer l’autocollant ici
Default Codes
Códigos de predeterminado
Codes du défaut
22
ENGLISH
Warranty
Lifetime Limited Mechanical and Finish Warranty and 3-Year Limited Electronics Warranty
Subject to the terms and conditions of the warranty, Schlage extends a lifetime limited mechanical and nish warranty and a three
-year limited electronics warranty to the original consumer user (“Original User”) of our Schlage brand product (“Product”) against
defects in material and workmanship, as long as the Original User occupies the residential premises upon which the Product was
originally installed. See answers.schlage.com for specic warranty details and limitations, or contact Schlage Customer Service at
(888) 805-9837 in the U.S., 800-997-4734 in Canada or 018005067866 in Mexico for assistance.
Keypad Locks
User’s Guide
Contents
Register your Product
Document your purchase and register your warranty at RegisterMySchlage.com
Warranty ............................................................ 2
Lock Parts .......................................................... 4
Keypad Deadbolt ............................................. 4
Keypad Lever ................................................... 5
Keypad Deadbolt ............................................... 6
Locking and Unlocking ...................................... 6
Changing the Battery ........................................ 6
Key Override ..................................................... 7
Lock Override .................................................... 7
Keypad Locks .................................................... 8
Locking and Unlocking ...................................... 8
Key Override ..................................................... 8
Changing the Battery ........................................ 9
Programming Guide ........................................ 10
Schlage Button Signals ................................... 10
Codes .............................................................. 10
Default Code Locations ................................... 10
Basic Controls ..................................................11
Enhanced Controls ......................................... 12
Record Your Codes ......................................... 13
User Codes ..................................................... 13
Troubleshooting .............................................. 14
Restore Factory Settings ................................ 15
33
ENGLISH
» PLEASE KEEP THIS GUIDE
This guide contains important information about your lock!
•Default User Codes and Programming Code are located on the sticker on the back of this guide! You
will need these if you ever need to reset your lock back to factory default settings!
•The sticker also contains your serial number, which may be needed for warranty and customer
service support.
•Instructions for adding and deleting User Codes, changing the lock behavior, troubleshooting,
customer service and more are explained in this guide!
» WHY DO I NEED KEYS IF THIS IS A KEYLESS LOCK?
Good question! In the event that the battery is dead, or no User Code is known, you can use the
key to gain access by employing the emergency key override.
Browse to answers.schlage.com and click on
Electronic Keypad Locks in the menu on the right
side for videos, troubleshooting, FAQ and more.
Questions about your
new keypad lock?
Please don’t return it to the store!
Let us help you rst!
Need Help?
For technical documents and
videos, visit answers.schlage.com
U.S.A.: 888-805-9837
Canada: 800-997-4734
Mexico: 018005067866
4
ENGLISH
Keypad Deadbolt
Model BE365
Inside
Thumbturn
Outside
Thumbturn
Keypad
Numbers
Cylinder
Door Exterior Door Interior
Schlage
Button
Bolt
Keypad
•Used to enter codes for programming and unlocking. See Programming Guide on page 10 and Locking
and Unlocking on page 6 for more information.
Outside Thumbturn
•Used to unlock the lock after a valid User Code has been entered, or to lock the lock after the Schlage
button has been pressed.
Cylinder
•Used only in emergency situations to unlock the lock. See Key Override on page 7.
Inside Thumbturn
•Used to lock or unlock the lock.
LOCK PARTS
5
ENGLISH
Keypad Lever
Models FE575 (Auto Lock) and FE595 (Flex Lock)
FE595
(Flex Lock)
FE575
(Auto Lock)
Thumbturn
Cylinder
Keypad
Numbers
Outside
Lever
Door Exterior Door Interior
Schlage
Button
Latch
Inside Lever
LOCK PARTS
Keypad
•Located on the outside of the lock.
•Used to enter codes for programming and unlocking. See
Programming Guide on page 10 and Locking and
Unlocking on page 8 for more information.
Lever
•The inside lever can be rotated at any time to retract the
latch.
•The outside lever can be rotated at any time, but will only
retract the latch when the lock is unlocked.
Cylinder
•Located on the outside of the lock.
•Used only in emergency situations to unlock the lock. See Key Override on page 8.
Thumbturn
•FE595 ONLY: Used to put the lock in a locked or unlocked state.
66
ENGLISH
MODEL BE365
Locking and Unlocking
From the outside:
To Lock
1. Press the Schlage
button.*
2. Rotate the thumbturn
away from the hinges.
* If the Turn Lock feature is disabled, a valid User
Code must be entered to lock the door. See Enable
or Disable Lock & Leave on page 12.
To Unlock
» If lighting is low, press the Schlage button to
illuminate the keypad before beginning.
1. Enter a User Code
into the keypad.
2. Rotate the thumbturn
toward the hinges.
Changing the Battery
»Replace the batteries in your lock at the same time each year that you test and replace the batteries in
your smoke alarms. This will ensure continued reliable operation. Use a high-quality alkaline 9 volt battery
for replacement.
1. Remove the inside cover. 2. Replace the battery. 3. Re-tuck wires so they will
not be crimped. Replace the
cover.
Lithium Batteries?
Lithium batteries may have a longer life, but when they begin to fail, they fail quickly. We
don’t recommend them because they don’t give you a lot of time to change your batteries
before the lock is completely dead.
KEYPAD DEADBOLT
77
ENGLISH
Key Override
Key Override can be used to gain access when the battery is completely dead, when no valid User Code is
known or when Lock Override is engaged.
1. Insert the key into
the cylinder.
2. Rotate the key 90°
toward the hinges.
3. Push the key and
cylinder into the
thumbturn.
4. Rotate the
thumbturn 90°
toward the hinges.†
† Reverse steps to relock. Hold the thumbturn still while removing the key. See Changing the Battery on page
6 or Restore Factory Settings on page 15 for more information.
Lock Override
Lock Override can be used to completely disable the keypad. When engaged, a key must be used to unlock
the lock.
1. Remove the inside
cover.
2. Disconnect and
remove the battery.
3. Use a small athead
screwdriver to rotate
the lock override
slot to LOCKOUT.
4. Re-tuck wires so
they will not be
crimped. Replace
the cover.
Slot
KEYPAD DEADBOLT
88
ENGLISH
MODELS FE575— AUTO LOCK AND FE595— FLEX LOCK
Locking and Unlocking
Keypad locks are always locked from the outside, by default. Only the FE595 can be set to unlocked.
To Temporarily Unlock
» If lighting is low, press the Schlage button to
illuminate the keypad before beginning.
1. Enter a User Code
into the keypad.
2. Rotate the lever to
open the door. Door will
automatically re-lock.
To Set to Unlocked (FE595 Only)
1. Rotate the inside
thumbturn to the
vertical position.*
2. Rotate the thumbturn
back to the horizontal
position to re-lock.
* No User Code is required to open the door when the
lock is set to unlocked.
Key Override
Key Override can be used when the battery is completely dead, or when no valid User Code is known.
1. Insert key. 2. Rotate key 270° to unlock. 3. Rotate knob/lever to open door.*
* Rotate the key back to starting position to relock. The key cannot be removed from the cylinder while the lock is
unlocked. See Changing the Battery on page 9 or Restore Factory Settings on page 15 for more information.
KEYPAD LOCKS
What is the difference between the Auto Lock and the Flex Lock?
The Auto Lock (FE575) is always locked from the outside. The Flex Lock (FE595) is normally
locked from the outside, but can be set to unlocked by putting the thumbturn in the vertical
position.
99
ENGLISH
Changing the Battery
»Replace the batteries in your lock at the same time each year that you test and replace the batteries in
your smoke alarms. This will ensure continued reliable operation. Use a high-quality alkaline 9 volt battery
for replacement.
FE595
1. Remove the inside cover. 2. Replace the battery. 3. Replace the cover.
FE575
1. Remove the lock from the door. 2. Open the battery
compartment and replace
the battery.
3. Reinstall the lock on the door.
Lithium Batteries?
Lithium batteries may have a longer life, but when they begin to fail, they fail quickly. We
don’t recommend them because they don’t give you a lot of time to change your batteries
before the lock is completely dead.
KEYPAD LOCKS
10
ENGLISH
Schlage Button Signals
The color of the Schlage button indicates the status of the lock.
Orange
•the lock is in programming mode
Green
•a correct user code was entered
•the programming process is complete
Red
•an incorrect user code was entered
•there was an error in programming
•low batteries
•red blinking indicates critically low battery
Codes
Control of the lock is simply managed via a six-digit Programming Code and four-digit User Codes.
PROGRAMMING CODE
(Six Numbers)
•The lock comes preset with one unique default
Programming Code. It can be found on the
stickers, one on the back of the keypad assembly
and one on the front of this User Guide.
•Used to put the lock in programming mode.
•DOES NOT unlock the lock.
•The rst four numbers must be different from all of
the User Codes currently in the lock.
•If you forget the Programming Code, you can reset
the lock to factory settings, which restores the
default Programming Code. See Restore Factory
Settings on page 15.
USER CODES
(Four Numbers)
•The lock comes preset with two unique default
User Codes. They may be found on the stickers,
one on the back of the keypad assembly and one
on the front of this User Guide.
•Used to unlock the lock.
•These four numbers must be different from the rst
four numbers of the Programming Code.
•Up to 19 possible User Codes can be stored in the
lock at one time.
Default Code Locations
The Default User Codes and Programming Code are located in two places:
Back of the Keypad
» You must remove the Keypad from the door to see
this sticker.
Front of this User Guide
BE365 FE575/FE595
Keypad
Locks
User Guide
PLEASE KEEP THIS GUIDE
You will need these codes to operate
your lock!
CONSERVE ESTA GUÍA
¡Necesitará estos códigos para operar
la cerradura!
VEUILLEZ CONSERVERCE GUIDE
Vous aurez besoin de ces codes pour
faire fonctionner la serrure!
Place Label Here
Poner la etiqueta aquí
Placer l’autocollant ici
Default Codes
Códigos de predeterminado
Codes du défaut
Programming Code XXX XXX
User Code A XXXX
User Code B XXXX
S/N x-xxxxxxxx
Model XXXXX

Programming Code XXXXXX
User Code A XXXX
User Code B XXXX
S/N x-xxxxxxxx
Model XXXXX

Programming Code XXXXXX
User Code A XXXX
User Code B XXXX
S/N x-xxxxxxxx
Model XXXXX

Programming Code XXXXXX
User Code A XXXX
User Code B XXXX
S/N x-xxxxxxxx
Model XXXXX

PROGRAMMING GUIDE
1111
ENGLISH
Basic Controls
»Write your programming code here for easy access. Also see Record Your
Codes on page 13 for space to record User Codes.
PROGRAMMING CODE
ADDING USER CODES*
Enter
Programming Code
(six numbers)
Press Press Enter New
User Code
(four numbers)
Enter Same New
User Code
(four numbers)
Wait for
3 Orange Lights +
3 Beeps
Keypad
turns
blue
Wait for
3 Orange Lights +
3 Beeps
Wait for
3 Orange Lights +
3 Beeps
Success!
1 Green Light +
Long Beep
* These four numbers must be different from the rst four numbers of the Programming Code.
DELETING USER CODES
Enter
Programming Code
(six numbers)
Press Press Enter Unwanted
User Code
(four numbers)
Enter Same Unwanted
User Code
(four numbers)
Wait for
3 Orange Lights +
3 Beeps
Keypad
turns
blue
Wait for
3 Orange Lights +
3 Beeps
Wait for
3 Orange Lights +
3 Beeps
Success!
1 Green Light +
1 Long Beep
CHANGING THE PROGRAMMING CODE*
Enter
Programming Code
(six numbers)
Press Press Enter New
Programming Code
(six numbers)
Enter Same New
Programming Code
(six numbers)
Wait for
3 Orange Lights +
3 Beeps
Keypad
turns blue
Wait for
3 Orange Lights +
3 Beeps
Wait for
3 Orange Lights +
3 Beeps
Success!
1 Green Light +
Long Beep
* The rst four numbers must be different from all of the User Codes currently in the lock.
»If you make a mistake
during programming,
press the Schlage
button repeatedly until
the keypad lights blue.
Then start over.
PROGRAMMING GUIDE
Want to see a video?
Browse to answers.schlage.com and search on “How to Program Keypad Lock” for a
video. Other videos and information are also available.
12
ENGLISH
Enhanced Controls
Schlage’s keypad locks were designed with added features that allow you to adapt the lock to your needs.
Additional features that you can choose to use include:
ENABLE VACATION MODE DISABLE VACATION MODE
Enter
Programming
Code
(six numbers)
Press Press
When enabled, no User
Codes will unlock the
door, preventing any
unauthorized attempts
of entry when no one is
home for a prolonged
period of time.
Enter
Programming Code
(six numbers)
Wait for
3 Orange Lights +
3 Beeps
Keypad
turns
blue
Success!
1 Green
Light +
1 Long Beep
Success!
1 Green Light + 1 Long
Beep
ENABLE OR DISABLE BEEPER
Enter
Programming Code
(six numbers)
Press Press
The beeper can be turned off if desired.
Beeps will still sound during programming.
» The beeper may not be audible to
everyone.
Wait for
3 Orange Lights + 3
Beeps
Keypad
turns
blue
Success!
1 Green Light + 1 Long
Beep
DELETE ALL USER CODES
Enter
Programming Code
(six numbers)
Press Press Enter
Programming Code
(six numbers)
Removes ALL User
Codes from the
lock.
Wait for
3 Orange Lights + 3
Beeps
Keypad
turns
blue
Wait for
3 Orange Lights + 3
Beeps
Success!
1 Green Light + 1 Long
Beep
ENABLE OR DISABLE LOCK & LEAVE
KEYPAD DEADBOLT (BE365) ONLY
Enter
Programming Code
(six numbers)
Press Press
Enabled by default. When enabled, the
deadbolt can be locked from the outside by
pressing the Schlage button and rotating
the thumbturn. When disabled, a User
Code must be entered before rotating the
thumbturn. Disabling this feature keeps an
unauthorized person from locking the door
from the outside.
Wait for
3 Orange Lights + 3
Beeps
Keypad
turns
blue
Success!
1 Green Light + 1 Long
Beep
13
ENGLISH
RECORD YOUR CODES
PROGRAMMING CODE
User Codes
»Up to 19 User Codes can be stored in the lock at one time.
NAME USER CODE
EXAMPLE: JOHN SMITH 1234
» KEYPAD WEAR
Consider changing your
codes on a periodic basis so
buttons wear evenly.
14
ENGLISH
Browse to answers.schlage.com and click on Electronic Keypad Locks in the menu on the right side for
videos, troubleshooting, FAQ and more.
Lock Issue Beeps* Lights Solution
KEYPAD DEADBOLT ONLY
I can unlock my deadbolt
by simply pushing the
Schlage button. I don’t
need a code.
1 High Green
Blinking
Your lock has been installed incorrectly and is not
secure. Repeat the installation process. Ensure the
cam and bolt positions are correct, as referenced in the
installation instructions. Browse to answers.schlage.
com and search on “Installing BE365” for a video.
After pushing
and rotating thumbturn,
the deadbolt does not
extend.
None None Lock and Leave feature is disabled. See Enable or
Disable Lock & Leave on page 12.
After entering my User
Code, the lock ashes
green, but I cannot
unlock the lock.
1 High Green
Blinking Lock Override is enabled and should be disabled. See
Lock Override on page 7.
Outside thumbturn does
not freely spin after
deadbolt is thrown.
None None
Lock is malfunctioning. Disable the keypad by enabling
Lock Override. See Lock Override on page 7. Call
Customer Service.
I forgot my Programming
Code. None None
Check the front of this guide or the back of the keypad
assembly for the default Programming Code.
If needed, restore lock to factory settings. See Restore
Factory Settings on page 15.
I need to delete a User
Code that I don’t remember. None None
Delete all User Codes. Then add all needed User
Codes back into the lock. See Programming Guide
on page 10.
User Code does not unlock
lock.
2 Red User Code entered is not a valid User Code.
1 High,
1 Low
Green
then
Red
Vacation Mode is enabled. See Disable Vacation
Mode on page 12.
does not light when
numbers are pressed. None None
Too many incorrect User Codes have been entered.
Wait 30 seconds and try again.
If keypad does not respond after 30 seconds, then
replace battery. See Changing the Battery on page
6 for Keypad Deadbolt or Changing the Battery
on page 9 for Keypad Lock.
There is a delay before
unlock after a valid User
Code is entered.
High/
Low,
then 1
Red
then
Green
Battery is low and should be replaced. See Changing
the Battery on page 6 for Keypad Deadbolt or
Changing the Battery on page 9 for Keypad Lock.
blinking red but no
codes have been entered. None
Quick
Red
Blinking
Battery is dead and MUST be replaced. See Changing
the Battery on page 6 for Keypad Deadbolt or
Changing the Battery on page 9 for Keypad Lock.
TROUBLESHOOTING
15
ENGLISH
Lock Issue Beeps* Lights Solution
Cannot add a new User
Code.
High/
Low Red
19 User Codes already exist. Delete a User Code
before adding a new one. See Deleting User Codes
on page 11.
2 Red
Second User Code entered did not match rst User
Code entered. See Adding User Codes* on page
11.
The User Code matches the rst four digits of the
existing Programming Code.
Cannot delete a User Code. 2 Red Second User Code entered did not match rst User
Code entered.
Cannot change
Programming Code. 2 Red
Second Programming Code entered did not match
rst Programming Code entered. See Changing the
Programming Code* on page 11.
First four digits of new Programming Code match an
existing User Code.
Cannot delete all User
Codes. 2 Red Programming Code entered second time is incorrect.
Lock will not stay in
programming mode. 2 Red
Any key other than was pressed immediately
after programming mode was entered.
An incorrect entry was made during the programming
process.
* Number of beeps if beeper is turned on.
Restore Factory Settings
If you lose or forget your Programming Code, you can
restore the factory settings, which will restore the default
Programming code.
1. Disconnect the battery.
2. Press and release the Schlage button.
3. The following steps must occur within 10 seconds:
a. Reconnect the battery. The Schlage button will
light green for one second.
b. Then, press and hold the Schlage button until it
lights green and the lock beeps.
4. Try entering one of the default User Codes. If it does
not unlock the lock, start over at step 2.
Once you’ve done this, you can change the programming code to a personalized number. See Changing the
Programming Code* on page 11.
WARNING
Locate the default Programming and User
Codes on the front of this guide or the back
of the Keypad Assembly before beginning!
Default Programming and User Codes will be
restored. All existing User Codes and current
Programming Code will be erased.
CUSTOMER SERVICE CANNOT RETRIEVE
LOST DEFAULT CODES! DO NOT RESTORE
FACTORY SETTINGS UNLESS YOU CAN
LOCATE THE DEFAULT CODES.
TROUBLESHOOTING
BE365 FE575/FE595
Cerraduras
con teclado
Guía del usuario
CONSERVE ESTA GUÍA
»

24508517
If you have questions about any part
of installation or programming, don’t
return the Keypad Lock to the store.
Our Schlage Customer Service
representatives are ready to help.
Toll-free: 888-805-9837
answers.schlage.com
Si tiene dudas acerca de
cualquier parte de la instalación
o programación, no devuelva
la cerradura con teclado a la
tienda. Nuestros representantes
del Departamento de Servicio de
Asistencia al Cliente de Schlage
están listos para ayudarlo.
Línea gratuita: 888-805-9837
answers.schlage.com
Si vous avez des questions à
propos d’une partie de l’installation
ou de la programmation, ne
retournez pas la serrure à clavier
numérique au magasin. Les
représentants du service à la
clientèle de Schlage sont à votre
service.
Sans frais : 888-805-9837
answers.schlage.com
© Allegion 2014
Printed in U.S.A.
24508517 Rev. 07/14-b

Navigation menu
