outer & INNer prImary covers
12-2
ALUMINUM OUTER FOR BIG TWIN
Die cast chrome aluminum cover. This cover is
reinforced in all critical areas. Partially drilled 9th hole.
P5030 ‘71-84 FX & ‘84-88 Softail®
Repl. OEM 60507-77 & 60507-82A
ALUMINUM OUTER
Die cast chrome aluminum cover. This cover is reinforced in all critical
areas, and has a tab for floorboard mount in front of inspection cover.
P5040 ‘70-84 FL
Repl. OEM’s 60508-70 & 60508-82A
TIN CHROME OUTER FOR BIG TWIN
P5070 ‘36-64, with proper inner primary
Repl. OEM 60505-36
TIN CHROME OUTER
Electric start, ts stock inner, w/out bearing.
P5060 ‘70-84 Big Twin
TIN CHROME INNER
P5080 ‘70-E84 FL-FLH, ‘71-E84 FX
TIN CHROME INNER FOR BIG TWIN
P5010 Early ‘36-54 models
Repl. OEM 60620-36
P5020 55-64 models
Repl. OEM 60505-55
INNER PRIMARY COVERS FOR SOFTAIL®
P3007 ‘94-later OEM 60630-94
P3040 ‘95-later FXST models Repl. OEM 60630-94A
P3039 ‘89-93 FXST models Repl. OEM 60630-90
P3042 ‘71-84 FX models Repl. OEM 60421-79A
CHROME OUTER PRIMARY COVER
For Dyna & Softail® models with forward controls.
P3001 ‘99-up Softail®, 99-05 Dyna models OEM 60543-99
P3029 ‘95-later FXST models Repl. OEM 60543-95
P3028 ‘89-93 FXST models Repl. OEM 60543-89
12-3
prImary accessorIes
PRIMARY
NEEDLE BEARING
For outer primary, supports starter
shaft.Made in the USA.
E4430 ‘65-up Big Twin
electric start
Repl. OEM 9063
PRIMARY COVER FILLER CAP & CLUTCH HOLE CAP
Chrome plated steel caps have a 15/16” hex to facilitate installation
and removal with a standard wrench. Available for:
E4980 ‘85-90 XLH Primary Filler Cap & Clutch Adjusting Hole
Cap. 2 required per motor
E4979 ‘77-84 Sportster® Primary Filler Cap & Clutch Adjusting
Hole Cap. 2 required per motor
E4978 ‘71-76 Sportster® Clutch Adjusting Hole Cap
E4977 ‘71-76 Sportster® Filler Cap Breather
CHROME PRIMARY SAVER
This product helps to protect your
primary cover around those turns.
P5160 Fits all Big Twin
4 speed swingarms.
CHROME SIDE COVER
Bag of 100
F6141 Washers ¼” I.D., small O.D.
Repl. OEM 6099
WASHER AND SEAL
O3248 Late ‘84-present, 10 pack
Repl. OEM 31433-84
STARTER SHAFT BUSHING
P5002 Bushing OEM 33445-94
STARTER SHAFT BUSHING
P5003 Bushing OEM 33446-94
INNER BUSHING
P5001 Bushing OEM 33445-89
INNER PRIMARY WASHERS
P5159 Washers 5 pack
OEM 6016
CHROME INNER PRIMARY TRIM COVER
This quality die cast cover provides a much more precise t, and a classier three
dimensional look. Nicely formed edges give this cover a creamy, owing appearance
that enhances the entire primary area. Four mounting points insure secure, quiet
operation.
P3021 Trim cover
INNER PRIMARY MOUNTING KITS
Complete hardware kit properly mounts inner primary.
F4072 ‘00-up Softail® & ‘99-up Dyna Glide® & ‘01-up FLT
F4073 ‘86-00 FLT, FXR
F4051 ‘94-99 Softail® & ‘94-98 Dyna Glide®
F4049 ‘86-93 Softail® & ‘91-93 Dyna Glide®
F4074 ‘80-85 FL, FX
OIL TANK ALLEN
SCREW SETS
F4710 ‘77-up XL Oil Fill
& Clutch Adj. Allen
Plugs Set with wrench
derby covers
12-4
NESS-TECH® FLAMED
P5410 ‘70-up Big Twin.
3 hole Chrome
NESS-TECH® GROOVED
P4023 ‘70-Up Big Twin.
3 hole Chrome
JAYBRAKE
3 hole
P3255 ‘70-up Big Twin. Chrome.
P3254 ‘70-up Big Twin. Polished.
LEGENDS SPEED BALL
P5021 ‘70-up Big Twin.
3 hole Chrome
DERBY COVER WASHERS
F6177 Wet Clutch Derby Cover
Nylon 1/4 Washer 80”
Repl. OEM 31433-84
SKULL WITH FLAMES
BILLET DERBY COVER
P3036 ‘70-Up Big Twin
3 Hole Chrome
P3037 5 Hole Chrome
CHROME DERBY COVER
FOR TWIN CAM
P3038 ‘99-up 5 Hole Domed
SKULL DERBY COVER
P4035 ‘70-Up Big Twin
3 Hole Polished
P4036 5 Hole Polished
DERBY COVER
BUTTONHEAD ALLENS
BY GARDNER WESTCOTT
F6607 ‘99-up Twin Cam
NESS-TECH® RADIUS
P3209 5 hole Chrome
MILLENNIUM BALL MILLED
P3031 ‘70-up Big Twin.
3 hole Chrome
12-5
derby covers
CHROME PLAIN
P5270 ‘70-up Big Twin, 3 Hole
with out ring groove
Repl. OEM 25414-70
CHROME ANTIQUE STYLE
Early style derby cover for early tin primary
P5260 ‘36-64 Big Twin
Repl. OEM 60557-36
CHROME RAISED STYLE
This late style chrome steel derby cover is raised &
comes complete with gasket & mounting screws.
P5280 ‘70-up Big Twin 3 Hole
Repl.OEM 25141-70
CHROME RACER LOOK
P3010 ‘70-up Big Twin 3 Hole
CHROME ALLEN SCREW SIDE COVER SETS
All high quality polished chrome. All you need to complete the job. American made.
Cam and Primary Cover Sets Include: Transmission, chain clutch, and derby.
F4980 F4930 F6122
ALLEN SCREW SIDE COVER SETS SPORTSTER®
PART # APPLICATION FITMENT
F6122 CAM & PRIMARY ‘91-UP XL
F4200 CAM & PRIMARY ‘86-90 XL
F4210 CAM & PRIMARY ‘77-85 XL
F4220 CAM & PRIMARY ‘71-76 XL
F6141 SIDE COVER WASHERS, ¼
BAG OF 100 CHROMED
ALLEN SCREW SIDE COVER SETS BIG TWINS
PART # APPLICATION FITMENT
F4059 CAM PRIMARY TRANS 07-UP SOFTAILS
F4062 PRIMARY / DERBY 07-UP SFTL / FLT
F4067 CAM PRIMARY TRANS 07-UP FLT
F4026 CAM PRIMARY TRANS 2000-06 TWIN CAM
F4028 CAM PRIMARY TRANS ‘99-06 FXD
F4027 CAM PRIMARY TRANS ‘99-06 FLT TC
F4980 SIDE COVER SET 1991-98 DYNA GLIDE
F4160 CAM PRIMARY TRANS 87-99 SOFTAIL®
F4150 CAM PRIMARY TRANS ‘87-98 FLT & FXR
F4170 CAM PRIMARY TRANS ‘85-86 FLT & FXR
F4180 CAM PRIMARY TRANS - ‘80-84 FLT & FXR
F4190 CAM PRIMARY TRANS - ‘70-84 FX & FLH
F4930 CAM PRIMARY INSPECTION ‘65-69
F4940 CAM PRIMARY INSPECTION ‘36-64
F4135 TRANS MOUNT SET ‘89-99 SOFTAIL
F4175 TRANS TOP COVER KIT, ‘91-98 DYNA
F6141 1/4 SIDE COVER WASHERS
BAG OF 100 CHROMED
F5770 3/8
INspectIoN covers
12-6
PLAIN
P5220 Chrome
Repl. OEM 60572-78
A.R.T.
P3025 Dyna Glide®
Polished
CHROME EARLY STYLE
P5210 For Steel Primary
Repl. OEM 60573-36
RACER LOOK
P3012 ‘74-85 FX Chrome
RACER LOOK
P3011 Chrome
SKULL & FLAMES BILLET COVER
P3023 Chrome
NESS-TECH® FLAMED
P5411 Chrome NESS-TECH® LOUVERED & GROOVED
P5416 Louvered Chrome
P5418 Grooved Chrome
‘71-85 FX
P5230 With footpeg and
shift hole, Chrome.
Repl. OEM 60579-74
SKULL INSPECTION COVER
P4037 Polished
All inspection covers without shifter shaft hole t
‘86-up Softail®, Dyna Wide Glide® & ‘65-86 FL, FX 4 speed
NESS-TECH® RADIUS
P3211 Chrome
INspectIoN covers
12-7
NESS-TECH® GROOVED
P4021 ‘85-94 FXR models
Chrome with shifter
shaft hole not shown
P4022 FLT Chrome
RACER LOOK
P3014 ‘85-94 FXR models
Chrome
LEGENDS SPEEDBALL
P5025 FXR, FLT with forward control
Chrome
INSPECTION COVER
P3026 ‘85-94 FXR, polished
P3027 FLT models, polished
not shown
NESS-TECH® FLAMED
P5412 ‘85-94 FXR models
Chrome
prImary belt drIve systems
12-8
B5043
POLISHED ALUMINUM DOME SET
B5053 For 3” Evo electric start belt drives
8MM 3” ELECTRIC START BELT DRIVE SYSTEMS
The kit contains BDL’s race proven clutch pack, special aluminum pressure plate with springs and shoulder
bolts. Also includes one piece all aluminum, cast motor plate and starter housing. This plate locks engine and
transmission together. Polished moon pulley covers included on EVO belt drive. These models must use 1991
and later stock style starter, and some modifications will be necessary to install these complete kits.
B5043 ‘90-97 Softail®, Replacement Belt B5808
B5121 ‘90-97 Softail®, with oil lter plate Replacement Belt B5808
B5042 ‘85-89 Softail®, Replacement Belt B5808
B5044 ‘70-78 Shovelhead, with ratchet tranny lid, Replacement Belt B5810
Requires removal of OEM oil tank bracket and clearancing of the clutch release arm.
Use 1979 clutch arm OEM 37054-79.
BELT DRIVES LIMITED
TOP FUEL DRIVE
BDL’s monster all billet Top Fuel Street Drive is ready
for action. The 14mm by 85mm wide 3 3/8” belt is the same that the
Top Fuel racers use on the 600-plus horsepower machines. The newly
designed Kevlar clutch consists of varying spring pressure to accommodate any size
motor on the market. The hub is made from 7075 aluminum and then hard-anodized for superior strength.
B5058 is the complete drive with outboard bearing support. The outboard support plate is reversible. The
back side is channeled for another distinct look with the flat side which is polished.
B5058 ‘90-up Softail® 14mm Belt Drive. Complete Kit.
Includes oil lter mount and side guard.
B5059 ‘90-up Softail® 14mm Belt Drive with side guard.
Includes oil lter mount, side guard, plus a reversible outboard bearing support.
B5050 Replacement 3 3/8” Belt 85 tooth
8MM 3” ELECTRIC START
BELT DRIVE SYSTEMS
These complete belt drives come with a
outboard bearing support.
B5117 ‘90-up Softail®
B5118 ‘90-up Softail® plate comes
with oil filter mount
B5119 ‘90-01 Dyna
B5120 ‘02-up Dyna
B5808 Replacement Belt
12-9
prImary belt drIve systems
8MM PRIMARY BELT DRIVE SYSTEM FOR EVOLUTION®
BDL kits cover all ‘86-98 EVO rubber mount 5-speed & 5-speed Softail® models. Complete dry clutch (included)
utilizes BARNETT kevlar plates. The inner clutch hub comes with a 40mm double roll bearing as opposed to
the 35mm stock single. All this adds up to a cleaner, smoother power delivery system with less vibration, and
more horsepower to the rear wheel. Sealed primary bearing included.
B5005 ‘94-up 5-speed Softail® 45/68 (splined),
Replacement Belt B5112
B5004 ‘94-up rubber mount 5-speed 48/68 (splined),
Replacement Belt B5111
B5003 ‘90-93 EVO 5-speed Softail® 45/68 (splined),
Replacement Belt B5112
B5001 ‘90-93 EVO rubber mount 5-speed 48/68 (splined),
Replacement Belt B5111
B5002 ‘86-89 EVO 5-speed Softail® 47 teeth front, 45/68 (tapered),
Replacement Belt B5112
B5000 ‘86-90 EVO rubber mount 5-speed 48/68 (tapered),
Replacement Belt B5111
Replacement Parts
B5815 Rear Basket. Includes starter gear, dogs and bearing
NOTE: the drives listed below are high
performance drives, clearance to the inner
primary will be necessary due to the large
diameter of these high performance pulleys.
8MM 3” BELT DRIVE SYSTEMS FOR EVOLUTION®
These 3” Belt Drive Systems for EVO motors are for
racing applications and cover ‘84-up Softail® &
rubber mount models.
B5034 ‘91-up Softail®, splined, kick start, 47/72,
Replacement Belt B5808
B5036 ‘91-up rubber mount, splined, kick start, 48/72,
Replacement Belt B5809
B5033 ‘84-90 Softail®, tapered, kick start, 47/72,
Replacement Belt B5808
B5035 ‘84-90 rubber mount, tapered, kick start, 48/72,
Replacement Belt B5809
BELT DRIVES LIMITED
NEW RETRO FIT KIT
This new billet support plate can be retro fitted
to all BDL 3” open 8mm Softail® and Dyna belt
drives. This support plate keeps the engine and
trans shafts from flexing the plate which is a
must for all large engine wide tire applications.
The kit includes a polished custom billet support,
polished pulley covers, new pressure plate with
hardware. Some modifications must be made
for fitment.
B5116 All Softail® & Dyna retro t kit
12-10
replacemeNt parts for evolutIoN®
Insert & Special Nut
For Offset Front Pulley
B5826 ¼” B5830 1 ¼”
B5827 ½” B5831 1 ½”
B5828 ¾” B5832 1 ¾”
B5829 1” B5833 2” To order pulleys and insert/nut
together, ask your sales rep.
Letter Part# BDL# Description
B5817 47-EV-3E 3” front pulley, 47 tooth EVO Softail®
A C2396 72-3E 3” pulley clutch basket with gear, dogs, & bearing Sft, FXR, Dyna
B5057 SG-2PG Starter ring gear with pinion gear for all ‘94-up applications
B5028 SG-2 Starter ring gear for all ‘85-93 Big Twins
B5105 SG-1 Starter ring gear for all ‘65-84 Big Twins
B5089 48EV 1¾” splined front pulley, 48 tooth, rubber mount EVO 8mm
B5818 48EV-3 3” splined front pulley, 48 tooth, EVO
B B5088 45EV Front pulley 45 tooth Softail®
C B5085 EIBG-1 Inside belt guide for B5088
D B5086 EOBG-1 Outside belt guide for B5088
E B5375 FHN-2 Flat hex engine nut for splined shaft
F B5376 WA-2 Flat washer for splined engine nut shaft
B5373 FHN-1 Flat hex engine nut for tapered shaft
B5374 WA-1 Flat washer for tapered engine nut shaft
G B5815 EV-475 Rear basket, Softail®, FXR & Shovelhead 5 speed
H C2386 EVRD-1 Round dogs Softail®, FXR, & Shovelhead 5 speed. 12 pcs.
I B5081 EV-180 Splined hub for ‘90-up 3” open & closed drives
B5029 EV-170 Tapered hub for ‘86-89
J B5107 EPB-100 Primary Bearing ‘86-up EVO
K B5087 CC-244 C-clip hub bearing retainer
B5122 CC-158 C-clip for backside of hub
L B5104 EPS-100 Seal - inner clutch hub ‘86-up EVO
B5824 68S ‘91-up E/S splined 68 tooth rear pulley
M B5814 HNS-100 Hub nut with seal ‘90-up
B5823 68T ‘86-90 EVO-tapered 68 tooth rear pulley
B5079 72S-3 Rear basket hub & bearing 72 tooth splined ‘91-up Big Twin
B5080 72T-3 Rear basket hub & bearing 72 tooth tapered ‘84-90 Big Twin
N C2393 EPP-100 Pressure Plate
O C2399 CDAS-100 Clutch adjusting screw with jam nut
P B5026 ESB-100 Shoulder bolts, long, set of 6
Q B5103 ECS-100 Clutch springs, set of 6
C2394 EDP-200 Splined clutch steel plate for inner hub - sold each
C2389 ERDS-100 Steel clutch plate for round clutch dogs - sold each
C2390 EDP-100 Steel clutch plate for square clutch dogs - sold each
C2391 ECP-200 Clutch plate, kevlar - sold each - 4 needed
C2392 ECP-100 Clutch half plate, kevlar - sold each - 2 needed
R C2397 ERCP-100 Kevlar clutch ber plates - Set of 7
S C2398 ERCS-100 Clutch steel plates - Set of 7
C2918 CHDK-1 Clutch hub friction plate
B5083 CC-193 C-clip for motor plate bearing
C3609 BF-1 Clutch hub bearing kit
T B5027 TFBSB-100 Bearings for outboard support - pair
OFFSET FRONT PULLEY
B5084 3” - 47 tooth pulley for Softail®
B
C
D
E
F
A
T
N
P
Q
O
RS
G
I
J
L
H
K
M
12-11
B5032 ‘65-83 rear chain drive with 45/68
EVO style stacked clutch
Replacement Belt B5112
B5039 ‘79-83 rear chain drive with 48/68
5 speed with stacked clutch
Replacement Belt B5111
B5041 ‘79-84 rear belt drive with 45/68
4 speed with stacked clutch
Replacement Belt B5112
B5017 ‘37-54 1 ½” belt, 39/62 front tapered
Replacement Belt B5200
B5018 ‘55-64 1 ½” belt, 39/62 front splined
Replacement Belt B5200
B5019 ‘65-77 1 ½” belt, 40/62 front splined
Replacement Belt B5200
B5020 ‘78-84 1 ½” belt, 41/61 front splined
Replacement Belt B5200
11MM PRIMARY BELT DRIVE SYSTEM FOR KICKER OR ELECTRIC START
These American made belt drive kits include front & rear pulleys, washer and nut for front pulley and primary
idler/adjuster (on GS-up) use in conjunction with proper safety hardware.
B5010 ‘37-54 adj. trans. kick start, 31/47 front tapered ........................................... Replacement Belt B5061
B5011 ‘55-64 adj. trans. kick start, 31/47 front splined........................................... Replacement Belt B5061
B5012 ‘65-84 alum. primary, kick start with idler, 31/47 front splined ..................... Replacement Belt B5061
B5013 ‘65-84 alum. primary, electric start with idler, 31/47 front splined ................. Replacement Belt B5061
B5014 ‘79-84 rear, 5-speed electric start with idler, 31/47 front splined .................. Replacement Belt B5062
B5015 ‘65-78, 1 ½” belt, 41/61 teeth front
splined rear chain drive
Replacement Belt B5190
B5016 ‘79-84, 1 ½” belt, 41/61 teeth front
splined rear chain drive will not fit
5-speed transmission
Replacement Belt B5200
B5045 ‘79-84 rear belt drive 1 ½” belt,
41/61 FXSB, FXB
Replacement Belt B5200
REPLACEMENT PARTS
8MM CLOSED ELECTRIC
B5073 Rear pulley, 61 T
electric start
B5816 Rear pulley 68 T
B5819 Front pulley 45 T
splined
B5093 Front pulley 41 T
splined
11MM SYSTEM
B5074 Repl. 11mm rear pulley
kick start 47 T
B5075 Repl. 11mm rear pulley
electric start 47 T
B5091 Repl. 11mm front pulley
tapered 31 T
B5092 Repl. 11mm front pulley
splined 31 T
B5105 ‘65-84 Starter ring gear
electric start
8MM CLOSED KICK
B5072 ‘37-77 Rear pulley, 62 T
B5071 ‘78-84 Rear pulley, 61 T
B5094 ‘37-54 Front pulley, 39 T
tapered
B5095 ‘55-64 Front pulley, 39 T
splined
B5096 ‘65-77 Front pulley, 40 T
splined
B5093 ‘78-84 Front pulley, 41 T
splined
prImary belt drIve systems
8MM CLOSED PRIMARY KICK START
These belt drive kits include belt, front and rear pulleys, washer and nut for the front pulley. Use only in
conjunction with proper safety hardware.
8MM CLOSED PRIMARY ELECTRIC START
These 8mm belt drive kits include Kevlar belt, front & rear pulleys, washer & nut for the front pulley and
stacked clutch.
8MM CLOSED PRIMARY ELECTRIC START
Belt drive kits include belt, front & rear pulleys, washer & nut for the front pulley and outside guide where
necessary. For use in conjunction with proper safety hardware.
2” & 3” belt drIve systems
12-12
RETRO FIT CLUTCH FOR 3”
FOUR SPEED BELT DRIVES
This complete clutch package is designed to move the weight
in-board over the bearing to eliminate the gyro effect of the
stock or early style hub. This kit fits all 3” belt drive ‘36-83.
To be used with existing 3” front pulley and belt.
B5078 Retro t kit
8MM OPEN 2” KICK
B5076 ‘37-84 Rear pulley, 76 T 2”
B5097 ‘37-54 Front pulley, 47 T, tapered
B5098 ‘55-84 Front pulley, 47 T, splined
B5101 Front pulley nut & washer kit
8MM OPEN 3” KICK
B5077 ‘37-84 Rear pulley, 76 T 3”
B5099 ‘37-54 Front pulley, 47 T 3” tapered
B5100 ‘55-84 Front pulley, 47 T 3” splined
REPLACEMENT PARTS
Bearing kit included.
8MM OPEN PRIMARY KICK START 3” BELT
These belt drive kits include belt, front & rear pulleys,
washer & nut for the front pulley.
Note: 3” Belt Drive Kits are intended for
racing applications only.
B5023 ‘37-54, 47/76 front tapered
Replacement Belt B5810
B5024 ‘55-84, 47/76 front splined
Replacement Belt B5810
8MM OPEN PRIMARY KICK START 2” BELT
These belt drive kits include belt, front & rear pulleys, washer
& nut for the front pulley. Use in conjunction with proper
safety hardware.
B5021 ‘37-54 2” belt, 47/76 front tapered
Replacement Belt B5110
B5022 ‘55-84 2” belt, 47/76 front splined
Replacement Belt B5110
8MM OPEN PRIMARY KICK START
3” BELT WITH STACKED CLUTCH
B5040 ‘65-84 47/72 teeth splined with Evo style stacked clutch
Replacement Belt B5808
B5037 ‘37-54 47/76 teeth tapered with stacked clutch
Replacement Belt B5810
B5038 ‘55-84 47/76 teeth splined with stacked clutch
Replacement Belt B5810
12-13
REPLACEMENT FINAL DRIVE BELT
DAYCO PANTHER
14MM BELT
GATES 14MM
POLY BELT
APPLICATION
STOCK BELTS ARE 1 ½”
O.E.M. NUMBER
OF TEETH
B5803 B5800 ‘80-86 FXB, FXSB, FXWG, FLH 40003-79 126
B5804 ––––– CUSTOM APPLICATION 127
B5820 B5052 ‘91-UP SPORTSTER®40022-91 128
B5821 B5048 ‘93 SOFTAIL®40012-90 128
B5822 B5049 ‘95-UP SOFTAIL®40017-94 130
B5935 CUSTOM APPLICATION 1 1/8” 130
B5805 B5801 ‘86-92 & ‘94 SOFTAIL®40023-86V 132
B5936 CUSTOM APPLICATION 1 1/8” 132
B5811 B5051 ‘91-UP DYNA 40015-90 133
B5932 CUSTOM APPLICATION 1 1/8” 40015-00 133
B5931 CUSTOM APPLICATION 1 1/8” 40307-00 135
B5807 ––––– CUSTOM APPLICATION 135
B5806 B5802 ‘85-96 FLT ‘85-94 FXR 40001-85 136
B5937 CUSTOM APPLICATION 1 1/8” 136
B5933 ‘97-UP FLT, FLHT, FLHTR, FLHR 40024-97 139
B5934 00-UP FLT, FLHT 1 1/8” 139
PRIMARY BELT QUICK REFERENCE CHART
WIN PART# BELT NUMBER MM WIDTH NUMBER OF TEETH
B5930 38078 14MM 1 1/2” 78
B5050 BDL-14-85 14MM 3 3/8” 85
B5062 5S11 11MM 1 1/2” 92
B5060 30884 11MM 1 1/2” 96
B5061 1185 11MM 1 1/2” 99
B5370 37117-1 8MM 1 1/2” 117
B5420 9608M 1-1/2 FOR 45’S 8MM 1 1/2” 120
B5111 BDL-130 8MM 1 1/2” 130
B5190 30853-ST 8MM 1 1/2” 132
B5200 30853-BE BULLS EYE 8MM 1 1/2” 132
B5046 BDL-132-15/8 8MM 1 5/8” 132
B5030 BDL-132 8MM 1 3/4” 132
B5809 BDL-132-3 8MM 3” 132
B5112 BDL-138 8MM 1 1/2” 138
B5047 BDL-141-15/8 8MM 1 5/8” 141
B5031 BDL-141 8MM 1 3/4” 141
B5808 BDL-141-3 8MM 3” 141
B5180 BDL-37144-1 8MM 1 1/2” 144
B5110 BDL-37144-2 8MM 2” 144
B5810 BDL-37144-3 8MM 3” 144
replacemeNt belts
wIde & prImary chaIN drIve kIts
12-14
PRIMARY CHAIN DRIVES
Includes 25 tooth compensator
C1961 ‘90-up electric start this kit comes
with starter pinion gear for use on ‘94-up
C1962 ‘86-89 electric start
C1963 ‘70-83 electric start
DIAMOND PRIMARY CHAIN
C1960 ‘36-up Diamond Big Twin 4 speed, all
Softail® & Dyna Glide® 428-2-82 pitch
Repl. OEM 40007-36A
C1970 ‘57-up Diamond Sportster®, size 35-3-94 pitch
Repl. OEM 40005-57
C1980 ‘79-up Diamond all Big Twin 5 speed,
428-2-76 pitch.
Repl. OEM 40037-79
3” WIDE DRIVE KITS
Uses B5808 Belt on page 12-13
B5008 3” kit with ¾” offset
B5009 3” kit with 1.0” offset
PRIMARY SPACERS
B5070 ¼”
B5102 ½”
B5108 ¾”
B5109 1”
PRIMARY DRIVE KIT
This kit includes the primary chain, chain tensioner,
compensation sprocket and all necessary hardware.
P3041 ‘94-later Softail® & Dyna models.
OEM 40035-00
WIDE DRIVE KITS FOR 3” ELECTRIC START
Wide drive kits come with everything pictured, including offset front pulley and primary spacer.
STARTER PINION GEAR 9 TOOTH
Will t all Softail®, FXR & Dyna’s for use on BDL 3”
Belt Drives with 66 tooth ring gear. ‘90-06
P5004 9 tooth starter pinion gear
P5005 +1” 9 tooth starter pinion gear
3” WIDE DRIVE KITS
‘90-up Softail® only.
B5006 3” kit with ¼” offset
B5007 3” kit with ½” offset
B5113 1 ¼”
B5106 1 ½”
B5114 1 ¾”
B5115 2”
P5004 P5005
12-15
bIllet covers & chaIN teNsIoNers
CHAIN TENSIONER PARTS
PRIMARY IDLER BEARING KIT
This kit includes bearing and serrated plate which attaches
to the larger serrated plate found inside the inner primary.
This bearing assures correct belt tensioning by improving
the wrap of the belt teeth on both pulleys.
B5025 Idler Bearing Kit
P5130 Chain Tensioner
Repl. OEM 39990-65
P5131 Adjuster nut
P5132 Chain tensioner
replacement shoe
Repl. OEM 39976-65B
P5140 Chain Tensioner
Anchor Plate
Repl. OEM 39998-65
3” ELECTRIC START BILLET COVERS
These chrome billet covers fit our 3” Softail® and Dyna electric start kits
B5054 Billet cover 2 Dome
B5056 Billet cover No Dome
B5055 Billet cover 1 Dome
MOTOR PLATE & OIL FILTER KIT FOR SOFTAIL
BDL offers a motor plate for softails that will accommodate the
oil filter in the center of the plate, the side guard can still be used
without interference. Kit includes oil filter, fittings, oil line & clamps.
O3246 ‘90-up Motor plate and lter
B5082 Motor plate bearing all Big Twins
HYDRAULIC AUTOMATIC
CHAIN TENSIONER
This new automatic chain tensioner uses
the oil in the primary as its own reservoir.
It has its own pump & operates like a
hydraulic lifter in the engine. Once you
install it there is no need to adjust the
primary chain again.
P5133 Hydraulic Automatic
Chain Tensioner
rear chaINs & prImary
12-16
110 112 120 DIAMOND CHAIN MASTER LINKS
C1730 C1740 C1741 STANDARD C1940
C1742 C1743 C1744 XDL DUROLUBE C1745
C1746 C1747 C1748 XLO O-RING C1749
SUPER LINKS HEAVY-DUTY CHAIN
PART # LENGTH PART # LENGTH
C1600 100 C1605 110
C1601 102 C1606 112
C1602 104 C1607 120
C1603 106 C1608 MASTER LINKS
C1604 108
HEAVY-DUTY
CHAIN BREAKER
Use on all 420 to 630 size chain.
T3521 Chain breaker
DIAMOND PRIMARY CHAIN
C1960 ‘36-up Diamond Big Twin 4 speed, all Softail® &
Dyna Glide® 428-2-82 pitch Repl. OEM 40007-36A
C1970 ‘57-up Diamond Spst size 35-3-94 pitch
Repl. OEM 40005-57vv
C1980 ‘79-up Diamond all Big Twin 5 speed
size 428-2-76 pitch Repl. OEM 40037-79
110 112 120 RK CHAIN MASTER LINKS
C1290 C1300 N/A HEAVY DUTY C1380
C1350 C1360 C1370 O-RING N/A
HEAVY DUTY CHAIN LUBE
All-purpose chain lube excellent for
street, touring & off-road applications.
Thick, tacky formula eliminates messy
fly off & stops chain rust.
C1009 6.8 oz. can sold each
C1060 6.8 oz. can 12/case
C1011 17.4 oz. can sold each
C1070 17.4 oz. can 6/case
12-17
balaNcer products
BALANCE MASTERS™ ACTIVE ENGINE BALANCING
Patented Active Balancing Technology is utilized to constantly adjust to changes in the
vehicle including engine and tire wear as well as speed changes. No wheel weights or
expensive close tolerance engine balancing are required. Just using a combination of
Balance Masters one on each wheel, one on the clutch and another on the crank or
compensator virtually eliminates vibration permanently with no need to ever balance
again! Your engine will last significantly longer, run smoother and produce additional
horsepower. Plus, vibration will no longer rattle your body parts, blur your mirrors or
cause parts to shake off.
BALANCERS FOR BIG TWIN
COMPENSATOR front CLUTCH rear
B5304 ‘91-up B5330 ‘98-up
B5303 ‘70-90 B5302 ‘90-97
B5305 ‘37-69 B5301 ‘84-89
B5308 straight sprocket no comp. B5300 3 & 5 finger hub ‘41-84
B5302
B5304
B5309
B5307
B5330
B5317
B5300 B5301
B5303
B5307
B5310
B5306
B5309
B5308
B5304
B5305
B5303
B5302
BALANCERS FOR SPORTSTER®
SPROCKET front CLUTCH rear
B5307 ‘91-up B5302 ‘91-up
B5306 ‘60-90 B5316 L‘84-90
B5315 ‘71-E84
BALANCERS FOR BELT DRIVES
FRONT PULLEY REAR PULLEY CLUTCH
B5309 fits 1 1/2 Primo B5331 Fits all BDL
B5310 Fits all BDL,
Primo 2” & 3” Primo Brute III
B5332 Fits Primo Brute III, Also
Rivera’s Pro-Clutch models
PC-1000, PC-1100 and PC-1200
BALANCER SET FOR BDL 1 3/4 EVO BELT DRIVE
B5321 Includes front & rear balancer
BALANCERS FOR WHEEL ASSEMBLY
B5317 Dual Flange Wheels ‘73-up
B5320 ‘78-83 Wheels
B5318 9 or 10 Spoke Cast Wheels
B5319 Star Hubs ‘36-72
sprockets, Nuts, & balaNcers
12-18
COMPENSATING SPROCKET
For Softail® ‘94-up
S4235 25 T Repl. OEM 40308-94
For Big Twins ‘70-85
S4214 23 T Repl. OEM 40282-70
S4215 24 T Repl. OEM 40275-70
SPLINED MOTOR SPROCKET
For Big Twins ‘55-84
S4210 22 T Repl. OEM 40209-55
S4211 23 T Repl. OEM 40210-55
S4212 24 T Repl. OEM 40211-55
S4213 25 T Repl. OEM 40212-55
TAPER MOTOR SPROCKET
For Big Twins ‘36-54
S4207 22 T Repl. OEM 40209-36
S4208 23 T Repl. OEM 40210-36
S4209 24 T Repl. OEM 40211-36
MOTOR SPROCKET
For Sportster®
S4232 ‘57-69 XL 34 T Repl. OEM 40288-58
S4233 ‘70-76 XL 34 T Repl. OEM 40235-70A
S4234 ‘77-91 XL 34 T Repl. OEM 40235-74
BALANCE MASTERS COMPENSATOR
These Gold & Silver Eagle compensators from Balance
Masters are the only compensators engineered to incorporate
Active Balancing Technology. They are also the lightest and
strongest compensators ever designed.
B5324 ‘91-up Big Twin Silver Eagle
B5323 ‘70-82 Big Twin Gold Eagle
MOTOR SPROCKET NUTS
BY COLONY
F6342 ‘30-54 Big Twins Original style
F6343 ‘55-up Big Twins Original style
F6344 ‘36-54 Big Twins Acorn style
F6345 ‘57-up Sportster® Acorn style
MOTOR SPROCKET
NUT BY PAUGHCO
E6515 ‘84-89, sold each
F6342 F6344
SLIDING CAM
S4265 ‘84-up
Repl. OEM 40299-83A
COMPENSATING SPROCKET KIT
These kits include compensating sprocket
nut, retainer and spring assembly,
sliding cam for compensating sprocket,
compensating sprocket and crankshaft
extension. 25 tooth.
S4206 ‘94 & later models
Repl. OEM 40308-94
SPROCKET SHAFT EXTENSIONS
For ‘91-up Softail & Dyna, ‘85-up FLT, ‘85-94 FXR
S4261 Stock length Repl. OEM 40266-85
S4258 ½” over stock
S4259 1” over stock
MOTOR SPROCKET NUTS
For ‘91-up
S4264 Stock length
Repl. OEM 40392-91
S4263 ½” over stock
S4262 1” over stock
SPROCKET COVER
Die cast polished aluminum
sprocket cover.
S4205 ‘81-90 Sportster®
Repl.OEM 34911-81
12-19
TAPER MOTOR SPROCKET
For Big Twins ‘36-54
S4207 22 T Repl. OEM 40209-36
S4208 23 T Repl. OEM 40210-36
S4209 24 T Repl. OEM 40211-36
TRANSMISSION SPROCKET NUT
Use on Big Twin ‘36-up 1 ½” - 24 thread
E3036 Sprocket nut
Repl. OEM 35211-91A
OFFSET SPROCKET KIT
For Softail® And FXR This offset sprocket converts
belt drive to chain drive. Kit includes offset sprocket
and spacer. Fits ‘86-up Softail®, ’85-94 FXR
S4224 24 T S4260 23 T
BDL TRANSMISSION
PULLEY FOR BELT DRIVE
These lightweight pulleys are about 1/3 the weight
of stock pulleys. This means extended life of the fifth gear bearing and
more horsepower to the rear wheel.
B5064 29 T Pulley B5067 32 T Pulley
B5065 30 T Pulley B5068 33 T Pulley
B5066 31 T Pulley B5069 34 T Pulley
traNsmIssIoN pulleys & sprockets
MEGA NUT
The JIMS® Mega Nut has a lock plate built in. The
Mega Nut can also be secured in several additional
places by an easy drilling and tapping operation.
T4668 ‘85-present Big Twin and XL, with belt
drive. Twin cam 88® and JIMS® 6
speed.
Repl. OEM 35211-91
T5038 32T Trans Sproket
Upgrade kit.
OEM 40210-85
TRANSMISSION SPROCKET FOR BIG TWIN
FL, FX ‘80-85
PART # TEETH REPL. OEM
S4218 22 T 33338-83 & 35203-80
S4219 23 T 33337-83 & 35212-80
S4220 24 T
FLT, FXR ‘80-84
S4221 22 T 33336-83
S4222 23 T 33333-79
S4223 24 T
FL, FX ‘36-79
S4216 22 T
S4217 23 T
S5010 24 T
S5020 25 T
TRANSMISSION SPROCKET FOR SPORTSTER®
L84-90
PART # TEETH REPL. OEM
S4229 21 T 35208-84
S4230 22 T
S4231 23 T 35205-84
L79-E84
S4227 22 T
S4228 23 T
S4253 21 T
‘52-E79
S4225 21 T 35205-52A
S4226 24 T
BIG TWIN SPORTSTER®
TRANSMISSION SPROCKETS
FOR BIG TWINS & SPORTSTER®
OFFSET MOTOR
SPROCKET
S4245 ½” 25 tooth
S4248 ¾” 25 tooth
S4256 1” 25 tooth
rear sprockets
12-20
FLAT REAR SPROCKETS FOR ‘82-85 XL
S4246 48T Chrome Repl. OEM 41470-82
DISHED REAR SPROCKETS FOR ‘82-85 FXR, FXRS
WITH CHAIN REAR DRIVE
S5090 48T Chrome
Repl. OEM 40954-81
S4255 51T Chrome
Repl. OEM 40954-83
DISHED REAR SPROCKETS
FOR ‘73-85 FL, FX
S4243 48T Chrome
S5060 49T Chrome
S5050 51T Chrome Repl. OEM 41470-78
DISHED REAR SPROCKETS FOR ‘79-81 XL
S4243 48T Chrome
S5060 49T Chrome
S5050 51T Chrome Repl. OEM 41470-73
FLAT REAR SPROCKETS FOR ‘86-92 XL
S4250 48T Chrome Repl. OEM 41470-86
S4251 49T Chrome
51T REAR BRAKE DRUM SPROCKETS
FOR ‘30-72 FL, FX, XL
Comes complete with rivets and dowel pins
S5080 ‘30-57 FL ‘57-78 XL Repl. OEM 41470-30
S4236 ‘62-66 FL Repl. OEM 41470-62
S4237 ‘67-72 FL/FX Repl. OEM 41470-67
Replacement rivet & dowel pin sets
S4239 ‘67-72 FL, FX
12-21
wheel, pulley & rotor desIgNs
3 SPOKE DOUBLE CUT #43 SPOKE BACK CUT #1 SOLID #7
15 SPOKE #9 5 STAR #10 BALLZAK #12
SPADE #13 RHINO #14 10 SPOKE #18
Please see the following pages for our huge selection of matching wheels, pulleys and rotors. This
great line of wheels, etc. are precision CNC machined made in the USA by people who take pride
in their workmanship and the quality that they produce. They come with a beautifully polished finish
complete with hub and a Timken bearing kit ready to bolt on.
Great designs! Great workmanship! Excellent quality which means big sales!
froNt wheels
12-22
FRONT WHEELS 2000-UP SOFTAIL®, ROAD KING®, FAT BOY®, HERITAGE, DEUCE, BIG TWINS & SPORTSTER®
POLISHED
SIZE
3 SPOKE
BACK CUT
#1
3 SPOKE
DOUBLE
CUT #4
15 SPOKE
#9
5 STAR
#10
BALLZAK
#12
SPADES
#13
RHINO
#14
10 SPOKE
#18
19 x 2.15
Dyna Narrow Glide®
XL Single Disc
W3403 W3420 W3437 W3454 W3471 W3488 W3506 W3523
21 x 2.15
Dyna Narrow Glide®
XL Single Disc
W3404 W3421 W3438 W3455 W3472 W3489 W3507 W3524
21 x 3.25
Dyna Narrow ® XL
Single Disc
W3405 W3422 W3439 W3456 W3473 W3490 W3508 W3525
19 x 2.15
Narrow Glide® Dual
Disc
W3406 W3423 W3440 W3457 W3474 W3491 W3509 W3526
21 x 2.15
Narrow Glide® Dual
Disc
W3407 W3424 W3441 W3458 W3475 W3492 W3510 W3527
21 x 3.25
Narrow Glide® Dual
Disc
W3408 W3425 W3442 W3459 W3476 W3493 W3511 W3528
16 x 3
Wide Glide® Single
Disc Left Side
W3409 W3426 W3443 W3460 W3477 W3494 W3512 W3529
18 x 3.50
Wide Glide® Single
Disc Left Side
W3410 W3427 W3444 W3461 W3478 W3495 W3513 W3530
21 x 2.15
Wide Glide® FXST/C
Duece Single Disc
Left Side
W3411 W3428 W3445 W3462 W3479 W3496 W3514 W3531
21 x 2.15
Stock Springer®
Single Disc
W3412 W3429 W3446 W3463 W3480 W3497 W3515 W3532
21 x 3.25
Wide Glide® Single
Disc Left Side
W3413 W3430 W3447 W3464 W3481 W3498 W3516 W3533
16 x 3
Wide Glide®
Road King®
Dresser Dual Disc
W3414 W3431 W3448 W3465 W3482 W3499 W3517 W3534
21 x 2.15
Wide Glide®
Road King®
Dresser Dual Disc
W3415 W3432 W3449 W3466 W3483 W3501 W3518 W3535
21 x 3.25
FLH Road King®
Dresser Dual Disc
W3416 W3433 W3450 W3467 W3484 W3502 W3519 W3536
16 x 3
Fat Boy® Heritage
Single Disc Left Side
W3417 W3434 W3451 W3468 W3485 W3503 W3520 W3537
18 x 3.50
Fat Boy® Heritage
Single Disc Left Side
W3418 W3435 W3452 W3469 W3486 W3504 W3521 W3538
21 x 3.25
Fat Boy® Heritage
Single Disc Left Side
W3419 W3436 W3453 W3470 W3487 W3505 W3522 W3539
#1 #4 #9 #10
#12 #13 #14 #18
All front wheels shown here
have matching rear wheels
on page 12-24.
All wheels front & rear can be
special ordered in chrome.
Chrome wheels are forged.
Ask your sales rep
for all the details.
12-23
froNt wheels
FRONT WHEELS ‘84-99 FXD Dyna Glide® SPORTSTER® & FXR Narrow Glide
POLISHED
SIZE
3 SPOKE
BACK CUT
#1
3 SPOKE
DOUBLE
CUT #4
15 SPOKE
#9
5 STAR
#10
BALLZAK
#12
SPADES
#13
RHINO
#14
10 SPOKE
#18
18 x 3.50
Single Disc Left Side W2871 W2875 W2879 W2887 W2895 W2904 W2912 W2920
18 x 3.50 Dual Disc W2872 W2876 W2880 W2888 W2896 W2905 W2913 W2921
19 x 2.15
Single Disc Left Side W2640 W2670 W2881 W2889 W2897 W2906 W2914 W2922
19 x 2.15 Dual Disc W2641 W2671 W2882 W2890 W2898 W2907 W2915 W2923
21 x 2.15
Single Disc Left Side W2642 W2672 W2883 W2891 W2899 W2908 W2916 W2924
21 x 2.15 Dual Disc W2643 W2673 W2884 W2892 W2901 W2909 W2917 W2925
21 x 3.25
Single Disc Left Side W2873 W2877 W2885 W2893 W2902 W2910 W2918 W2926
21 x 3.25 Dual Disc W2874 W2878 W2886 W2894 W2903 W2911 W2919 W2927
FRONT WHEELS ‘80-UP FXDWG Dyna Wide Glide® FXSTC Softail® Custom & FXWG
POLISHED
SIZE
3 SPOKE
BACK CUT
#1
3 SPOKE
DOUBLE
CUT #4
15 SPOKE
#9
5 STAR
#10
BALLZAK
#12
SPADES
#13
RHINO
#14
10 SPOKE
#18
18 x 3.50
Single Disc Left Side W2715 W2703 W2932 W2936 W2940 W2944 W2948 W2952
19 x 2.15
Single Disc Left Side W2928 W2930 W2933 W2937 W2941 W2945 W2949 W2953
21 x 2.15
Single Disc Left Side W2714 W2702 W2934 W2938 W2942 W2946 W2950 W2954
21 x 3.25
Single Disc Left Side W2929 W2931 W2935 W2939 W2943 W2947 W2951 W2955
FRONT WHEELS ‘86-UP FLSTC Heritage & FLSTF/N Fat Boy® & Nostalgia
POLISHED
SIZE
3 SPOKE
BACK CUT
#1
3 SPOKE
DOUBLE
CUT #4
15 SPOKE
#9
5 STAR
#10
BALLZAK
#12
SPADES
#13
RHINO
#14
10 SPOKE
#18
16 X 3
Single Disc Left Side W2716 W2704 W2956 W2958 W2960 W2962 W2964 W2966
18 x 3.50
Single Disc Left Side W2717 W2705 W2957 W2959 W2961 W2963 W2965 W2967
FRONT WHEELS ‘88-UP FXSTS Springer® Softail® & Bad Boy® except FLSTS (Softail® Springer® right side mount)
POLISHED
SIZE
3 SPOKE
BACK CUT
#1
3 SPOKE
DOUBLE
CUT #4
15 SPOKE
#9
5 STAR
#10
BALLZAK
#12
SPADES
#13
RHINO
#14
10 SPOKE
#18
21 x 2.15
Single Disc Left Side W2718 W2706 W2970 W2972 W2974 W2976 W2978 W2980
21 x 3.25
Single Disc Left Side W2968 W2969 W2971 W2973 W2975 W2977 W2979 W2981
FRONT WHEELS ‘87-UP ROAD KING®, FLHS, FLHT, FLT
POLISHED
SIZE
3 SPOKE
BACK CUT
#1
3 SPOKE
DOUBLE
CUT #4
15 SPOKE
#9
5 STAR
#10
BALLZAK
#12
SPADES
#13
RHINO
#14
10 SPOKE
#18
16 X 3 Dual Disc W2712 W2700 W2984 W2987 W2990 W2993 W2996 W2999
18 x 3.50 Dual Disc W2713 W2701 W2985 W2988 W2991 W2994 W2997 W3401
21 x 3.25 Dual Disc W2982 W2983 W2986 W2989 W2992 W2995 W2998 W3402
#18#14#13#12#10#9#4#1
All front wheels shown here have matching rear wheels on page 12-24.
All wheels can be special ordered in chrome. All chrome wheels are forged. Ask your sales rep for details.
REAR WHEELS ‘84-99 SOFTAIL®, ROAD KING®, DEUCE, BIG TWIN, SPORTSTER®
POLISHED
SIZE
3 SPOKE
BACK CUT
#1
3 SPOKE
DOUBLE
CUT #4
SOLID
#7
15 SPOKE
#9
5 STAR
#10
BALLZAK
#12
SPADES
#13
RHINO
#14
10 SPOKE
#18
16 x 3
Road King®,
Big Twin
FLHS, FLHT
W2639 W2669 W2689 W2766 W2773 W2780 W2787 W2794 W2802
16 x 3
Sportster® Belt Drive W2719 W2707 W2755 W2767 W2774 W2781 W2788 W2795 W2803
17 x 5.5
Softail® Big Twins W2760 W2762 W2764 W2768 W2775 W2782 W2789 W2796 W2804
18 x 3.5
Softail® Big Twins W2721 W2709 W2757 W2769 W2776 W2783 W2790 W2797 W2805
18 x 3.5
Sportster® Belt Drive W2720 W2708 W2756 W2770 W2777 W2784 W2791 W2798 W2806
18 x 5.5
Softail® Big Twins W2722 W2710 W2758 W2771 W2778 W2785 W2792 W2799 W2807
18 x 8.5
Softail® Big Twins W2761 W2763 W2765 W2772 W2779 W2786 W2793 W2801 W2808
Note: 17 x 5.5 & 18 x 5.5 rear wheel for Softail® Deuce accepts 180 tire only.
Specify if your axle is 3/4” or 1” on rear wheel 18 x 8.5. This size is for wide frame custom application.
18 x 4.25 #1824 & 18 x 10.5 #18216 sizes not listed here, as well as most other sizes listed above, are also available in forged aluminum.
Ask your salesperson for the details.
REAR WHEELS 2000-UP SOFTAIL®, DEUCE, BIG TWINS, & SPORTSTER®
POLISHED
SIZE
3 SPOKE
BACK CUT
#1
3 SPOKE
DOUBLE
CUT #4
SOLID
#7
15 SPOKE
#9
5 STAR
#10
BALLZAK
#12
SPADES
#13
RHINO
#14
10 SPOKE
#18
16 x 3
Softail® Big Twins W2809 W2816 W2823 W2830 W2837 W2844 W2851 W2858 W2865
16 x 3
Sportster® Belt Drive W2810 W2817 W2824 W2831 W2838 W2845 W2852 W2859 W2866
17 x 5.5
Softail® Big Twins W2811 W2818 W2825 W2832 W2839 W2846 W2853 W2860 W2867
18 x 3.5
Softail® Big Twins W2812 W2819 W2826 W2833 W2840 W2847 W2854 W2861 W2868
18 x 3.5
Sportster® W2813 W2820 W2827 W2834 W2841 W2848 W2855 W2862 W2869
18 x 5.5
Softail® Deuce W2814 W2821 W2828 W2835 W2842 W2849 W2856 W2863 W2870
18 x 8.5
Softail® Big Twins W2815 W2822 W2829 W2836 W2843 W2850 W2857 W2864 W2871
Note: 17 x 5.5 & 18 x 5.5 rear wheel for Softail® Deuce accepts 180 tire only.
Specify if your axle is 3/4” or 1” on rear wheel 18 x 8.5. This size is for wide frame custom application.
18 x 4.25 #1824 & 18 x 10.5 #18216 sizes not listed here, as well as most other sizes listed above, are also available in forged aluminum.
Ask your salesperson for the details.
rear wheels
#12 #13 #14 #18
#1 #4 #9 #10#7
All rear wheels shown here & below have matching front wheels on page 12-22 and 12-23.
All wheels can be special ordered in chrome. All chrome wheels are forged. Ask your sales rep for details.
12-24
REAR PULLEYS ‘84-99 SOFTAIL®, BIG TWIN FORGED PULLEYS
POLISHED
TEETH
3 SPOKE
BACK CUT
#1
3 SPOKE
DOUBLE
CUT #4
SOLID
#7
15 SPOKE
#9
5 STAR
#10
BALLZAK
#12
SPADES
#13
RHINO
#14
10 SPOKE
#18
65 Tooth 1 1/2” W2645 W2675 W2695 W2605 W2607 W2610 W2612 W2614 W2616
70 Tooth 1 1/2” W2646 W2676 W2696 W2606 W2608 W2611 W2613 W2615 W2617
REAR PULLEYS 2000-PRESENT SOFTAIL®, BIG TWIN FORGED PULLEYS
POLISHED
ADAPTER KITS
TEETH
3 SPOKE
BACK CUT
#1
3 SPOKE
DOUBLE
CUT #4
SOLID
#7
15 SPOKE
#9
5 STAR
#10
BALLZAK
#12
SPADES
#13
RHINO
#14
10 SPOKE
#18
65 Tooth 1 1/8”
With Adapter W2618 W2620 W2623 W2626 W2629 W2632 W2635 W2638 W2681
70 Tooth 1 1/8”
With Adapter W2711 W2621 W2624 W2627 W2630 W2633 W2636 W2679 W2682
70 Tooth 1 1/2”
Road King®
Road Glide®
Dresser
W2619 W2622 W2625 W2628 W2631 W2634 W2637 W2680 W2683
ROTORS ‘84-99 11.5” STAINLESS STEEL
POLISHED 3 SPOKE
BACK CUT
#1
3 SPOKE
DOUBLE
CUT #4
15 SPOKE
#9
5 STAR
#10
BALLZAK
#12
SPADES
#13
RHINO
#14
10 SPOKE
#18
Left Front W2647 W2677 W3001 W3004 W3007 W3010 W3013 W3016
Right Front W2648 W2678 W3002 W3005 W3008 W3011 W3014 W3017
Right Rear W2644 W2674 W3003 W3006 W3009 W3012 W3015 W3018
ROTORS 2000-PRESENT 11.5” STAINLESS STEEL
POLISHED 3 SPOKE
BACK CUT
#1
3 SPOKE
DOUBLE
CUT #4
15 SPOKE
#9
5 STAR
#10
BALLZAK
#12
SPADES
#13
RHINO
#14
10 SPOKE
#18
Left Front W3019 W3023 W3026 W3029 W3035 W3038 W3042 W3045
Right Front W3021 W3024 W3027 W3033 W3036 W3039 W3043 W3046
Right Rear W3022 W3025 W3028 W3034 W3037 W3041 W3044 W3047
pulleys & rotors
#1 #4 #7 #9
#10 #12 #13 #14
12-25
Matching pulleys
and rotors are
listed below. See
wheel or pulley
design for your
selected rotor as
most rotors are
not pictured. #9 #14
#18 #14
#9
All pulley’s listed here can be special ordered in chrome.
Clear Wheel
custom wheels
All wheels on pages 12-26 thru 12-31 are custom made to order. Matching
pulleys and rotors are available too. All wheels are Revolutionary 3D designed
except for clear wheels. A 50% deposit is required on any custom wheel order.
Call your rep for details on cost and ETA.
PATENT: D534,981
Meets and exceeds JASO requirements
for motorcycle wheels.
12-26
SIZES
26 X 3.5 18 X 14
24 X 4 18 X 10.5
23 X 4 18 X 8.5
21 X 9 18 X 5.5
21 X 3 18 X 4.25
21 X 2.15 18 X 3.5
20 X 10.5 17 X 12
The
Incredible
Clear
Wheel...
Yes, we said
CLEAR!
360˚ Brake
Optional for
clear wheel only.
custom wheels
12-27
custom wheels
12-28
Cypher Wheel
Big Homie
SIZES
26 X 3.5
24 X 4
23 X 4
21 X 9
21 X 3
21 X 2.15
20 X 10.5
18 X 14
18 X 10.5
18 X 8.5
18 X 4.25
18 X 3.5
17 X 12
SIZES
26 X 3.5 20 X 10.5
24 X 4 18 X 14
23 X 4 18 X 10.5
21 X 9 18 X 8.5
21 X 3 17 X 12
21 X 2.15 -
X-Wang
DS-3
custom wheels
DS-1
12-29
Don Juan
SIZES
26 X 3.5 18 X 14
24 X 4 18 X 10.5
23 X 4 18 X 8.5
21 X 9 18 X 5.5
21 X 3 18 X 4.25
21 X 2.15 18 X 3.5
20 X 10.5 17 X 12
custom wheels
Trippin’
Devil’s Slide
SIZES
26 X 3.5 18 X 14
24 X 4 18 X 10.5
23 X 4 18 X 8.5
21 X 9 18 X 5.5
21 X 3 18 X 4.25
21 X 2.15 18 X 3.5
20 X 10.5 17 X 12
12-30
Cutlass
custom wheels
S & M
12-31
SIZES
26 X 3.5 18 X 14
24 X 4 18 X 10.5
23 X 4 18 X 8.5
21 X 9 18 X 5.5
21 X 3 18 X 4.25
21 X 2.15 18 X 3.5
20 X 10.5 17 X 12
M1
SIZES
26 X 3.5 20 X 10.5
24 X 4 18 X 14
23 X 4 18 X 10.5
21 X 9 18 X 8.5
21 X 3 17 X 12
21 X 2.15 -
pulleys, froNt & rear wheels
12-32
DNA MOTORCYCLE PRODUCTS
All wheels are made in the USA & are
assembled using the highest grade
materials available. Such as: chrome billet
hubs, stainless steel spokes & nipples,
spun chrome steel rings & are tubeless.
DNA CHROME
SUPER
SPOKE PULLEY
Looks Great with spoke
& aluminum wheels.
PINGEL® REAR
SPROCKET SPACER
Spacer allows the installation
of wheels up to 142mm wide
on 2000-2003 H-D FLH models
without any other modifications.
POLISHED REAR PULLEYS & COVERS FROM BDL
B4414 Chrome Bolt Covers for Conventional Flat Pulleys
Step 1 Step 2 Step 3
5 SPOKE
B4411 65T
B4413 70T
9 SPOKE
B4410 70T
SWEPT
B4417 65T
B4419 70T
SOLID
B4420 65T
B4422 70T
W2601 70T 1 1/8
W2602 65T 1 1/8
W2603 70T 1 1/2
W2604 65T 1 1/2
60 SPOKE 80 SPOKE FRONT WHEEL
W3054 W3065 16 X 3.5 FLST ‘00-up
W3051 W3062 16 X 3.5 FLST ‘86-99
W3055 W3066 19 X 2.15 Narrow Glide® ‘00-up
W3052 W3063 19 X 2.15 Narrow Glide® ‘86-99
W3056 W3067 21 X 2.15 Wide Glide® ‘00-up
W3053 W3064 21 X 2.15 Wide Glide® ‘84-99
60 SPOKE 80 SPOKE REAR WHEEL ‘00-UP
W3057 W3068 16 X 3.5
W3059 16 X 6
W3058 W3069 18 X 4.25
W3060 W3071 18 X 5.5
W3061 W3072 18 X 8.5
60 SPOKE 80 SPOKE
BELT SPROCKET COVER
If your serious about building a
custom bike, you’ll need a belt
sprocket cover. This chrome cover
is machined from a solid hunk of
billet aluminum. Includes a polished
aluminum backing plate to hide the
sprocket & chrome countersunk
allen bolts.
B4308 70T Sprocket cover
NESS REAR
PULLEY SPACER
Converts 1-1/8” width
2000-up pulley to
99-earlier wheel. Allows
use of 170 width tires on
1999 & earlier application. B4415
B4312
12-33
froNt wheels
SINGLE & DUAL DISC WHEEL ASSEMBLIES
These chrome assemblies are designed for ‘78-up single and
dual disc models.
W3090 19” Single & Dual Disc ‘84-up FX, FXR, XL,
Dyna Narrow Glide® Repl. OEM 43312-84
W3100 21” Single & Dual Disc ‘84-up FX, FXR, XL,
Dyna Narrow Glide®
W3190 19” Dual Disc wheel ‘78-E84 FX, XL
Repl. OEM 43341-78
W3200 21” Dual Disc wheel ‘78-E84 FX, XL
W3160 16” Single Disc wheel ‘84-99 FXST, FXWG & FXDWG
STAR HUB WHEEL ASSEMBLIES
A full selection of beautifully chromed wheels
& spokes. Bearing preloads are factory set.
Laced & Trued in America.
W3110 16” Big Twin ‘36-66 front or rear
Repl. OEM 40981-40
DUAL FLANGE WHEEL ASSEMBLIES
These wheels are laced & trued in the U.S.A. Comes
complete with hub bearing kit installed. Available with
5/16” flange holes to fit ‘73-83 FXWG, FXR/T front or
with 7/16” flange holes for ‘73-83 FL, FLH front.
W3030 19” front, 5/16” WM 2
W3040 21” front, 5/16” WM 2
Repl. OEM 43664-80B
W3031 19”, 7/16
W3032 21”, 7/16
CHROME 80-SPOKE FROM AMERICAN
WIRE WHEEL
Composition billet hub and steel rim with 80 gauge 190 steel
spokes. This DOT approved show chrome wheel features a rim of
1010 cold rolled steel. Complete with Hub, bearings, spacers and
seals. Fits ‘86-up Big Twins and ‘79-up Sportster®.
R3066 16” x 3.5” complete front assembly, single disc.
SINGLE FLANGE WHEELS FOR BIG TWINS
This assembly features beautiful chrome components.
Each wheel comes complete with a 21” rim laced to a
chrome hub assembly with bearings, seals and internal
components.
W3140 21” ‘84-99 FXST except Springer®, ‘84-86 FXWG
W3150 21” 5/16”, ‘73-83 FX, FXE 80, FXWG
rear wheels & bearINgs
12-34
CHROME DUAL FLANGE REAR
This wheel assembly comes complete with chrome spokes
laced to chrome hubs and rims. The hubs come with thick
spoke flanges and rotor flanges held to .001” runout. This
is a very versatile assembly and as such will accept any
stock sprocket-rotor configuration.
W3050 16” x 3” fits ‘73-83 FL, FLH, FXWG, ‘73-83 FX
Repl. OEM 40968-73
CHROME WHEEL FOR SPORTSTER®
This wheel assembly comes complete with chrome
spokes laced to chrome rims and hubs.
Each kit also includes bearings, spacers and seals.
W3170 16”x 3” fits XLH, XLCH ‘55-78
Repl. OEM 40989-70
WHEEL BEARINGS
B3904 ‘63-78 XL Rear Wheel, ‘54-72 XL & ‘71-72
FX Front Wheel Repl.OEM 9008
B3905 Same As Above, Shielded Repl.OEM 9009
B3906 ‘54-72 Sportster® Rear Wheel double row
Repl. OEM 9010
H3030 ‘73-up Big Twin Front & Rear Wheel, ‘73-up
Sportster® Front Wheel, ‘79-up Sportster®
Rear Wheel includes Races. Sold in pairs
Repl. OEM 9052
B3925 Timken wheel bearing & race.
‘73-99 Big Twin Front & Rear Wheel,
‘73-up Sportster® Front Wheel
‘79-up Sportster® Rear Wheel
Sold each. Repl. OEM 9052
WHEEL BEARINGS
B3903 Pre-99 Sealed wheel bearing ¾” dia
B3909 2000-up Sealed wheel bearing 1” dia
12-35
wheel accessorIes
BALANCE MASTERS™
FOR WHEELS
See page 12-17 for our complete
line & stop vibration problems.
B5317 ‘73-up Wheels, dual ange
B5318 Wheels, 9 spoke cast
B5319 ‘36-72 Wheels, star hub
B5320 ‘78-83 FX Wheels
OINKER VALVE STEM CAPS
J1214 Pewter
J1215 Gold
WILD ONE SKULL VALVE STEM CAPS
W3080 Chrome valve stem caps
WHEEL SEALS
PART# DESCRIPTION
S4080 Rubber Oil Seal Repl. OEM 47519-83A
Cast or spoked front and rear wheels on most models from ‘83-99
S4100 Steel Oil Seal Repl. OEM 47519-72
Cast rear and spoked or cast front wheels on FX (except FXWG),
FXR, and XL from ‘73-86
Cast front and rear wheels on FL from ‘73-79
Cast rear wheel (sprocket side only) on FLT, FLHT from ‘80-83
Also ts the swingarm on 4-speed FX Big Twin disc brake models
from ‘73-86
S4090 Rubber Oil Seal Repl. OEM 47519-58
Spoked rear wheel on FL, FX and FXR from ‘79-83
Spoked front wheel on FL, & FXWG from ‘80-83
Cast front or rear wheels on FL ‘80-84
Cast front or rear (brake side only) on FLT and FLHT from ‘82-84
Also ts the swingarm on all Big Twin drum brake models from ‘58-72
spokes & rIms
12-36
FRONT SPOKES FROM WIN
Each complete spoke kit consists of 40 spokes and nipples.
Available in chrome or highly polished stainless steel.
SPOKE WRENCH
Heavy Duty spoke wrench
for spoke nipple sizes 1-6
T4660
CHROME WHEEL WEIGHTS
10 pack
W3265 ¼oz.
W3266 ½ oz.
W3267 ¾ oz.
W3268 1.0 oz.
NYLON RIM SAVERS
Protect your alloy rims from getting scratched
by tire levers or tools while changing tires.
Sold in pairs.
W3275 Rim Savers
RIM STRIPS
R3304 1 ¼” for 16” rear rims
with side valve inner tube
R3305 1 ¼” for 16” rear rims
with center valve inner tube
R3306 1” for 19” rims with center valve inner tube
R3307 1” for 21” rims with center valve inner tube
W3269 ¼ stick-on silver 36 pk
CHROME STAINLESS RIM
SIZE
RIM
TYPE
SPOKE
LENGTH
SPOKE
BEND
NIPPLE
SIZE APPLICATION
S4318 15” Drop Center 6 ¼” 1 size Std. ‘36-up KH, XL
S3080 S4319 16” Drop Center 6 ¾” 1 size Std. FX, FL Rear
S4315 S4320 19” Drop Center 8 ¼” 1 size Std. ‘36-84 FL
S4316 S4321 21” Drop Center 9 ¼” 1 size Std. ‘81-up FXWG
S3030 18” Custom 8 ¼” 1 size Std. ‘84-up FXST
S3040 S4322 19” Custom 8 ¾” 1 size Std. Front
S3050 S4323 21” Custom 9 ¾” 1 Size Extend
ALUMINUM FRONT DISC BRAKE
S3010 19” Custom 8 ¾” 2 size Extend ‘73-up XL, FX
S3020 21” Custom 9 ¾” 2 size Extend
S4317 19” Drop Center 8 ¼” 2 size Extend
ALUMINUM FRONT BRAKE DRUM
S4327 S4324 19” Drop Center 5 58 2 size Std. ‘64-72 XL, FX
S3060 S4325 19” Custom 6” 2 size Std.
S3070 S4326 21” Custom 6 ¾” 2 size Std.
CHROME DROP CENTER FRONT RIMS
40-hole steel rims.
R3020 19” WM-1 1.60 width
R3040 19” WM-2 1.85 width
R3030 21” WM-2 1.85 width
R3031 21” WM-2 2.15 width
R3032 21” WM-2 2.15 width Excel rim
CHROME DROP CENTER REAR RIMS
40-hole steel rim.
R3050 16” x 3” Repl. OEM 43085-81
R3061 16” x 3.5”
STICK-ON
WHEEL WEIGHTS
LEAD WHEEL WEIGHTS
10 pack
W3262 ¾ oz.
W3263 1.0 oz.
W3264 1½ oz.
12-37
wheel hubs
CHROME FRONT DUAL DISK WHEEL HUB
Complete with all internal components.
H3070 ‘77-83 FX, FXR & XL with dual disc
Narrow Glide® front end
Repl. OEM 43600-78
H3110 ‘84-up Dyna Glide®, FX, FXR & XL models except FXLR
with single or dual disc Narrow Glide® front ends
Repl. OEM 43619-84
CHROME FRONT SINGLE DISK HUB ASSEMBLIES
Complete chrome single flange hubs with bearings,
seals and all internal components.
H3349 ‘84-up FLST/C, FLSTN front 5/16” ange holes
Repl. OEM 43053-86
H3347 ‘84-86 FXWG models & ‘84-up FXSTC & ‘93-up
FXDWG except Springer®, also custom applications
on single disc FX & XL models with wide fork conversions
Repl. OEM 43672-84
CHROME DUAL FLANGE HUB ASSEMBLIES
Complete chrome hub assembly with all internal components.
H3348 ‘86-up FXST/S, FXR, FLSTC, ‘93-95 FLSTN and ‘86-up XL
rear 3/8” rotor hole and 7/16” pulley hole
Repl. OEM 40976-86
H3080 ‘73-83 FL, FLH front & rear, ‘73-83 FX,FXWG
rear 7/16” hole Repl. OEM 43540-73
H3342 ‘73-83 FXWG, FXRT front wheel hub with 5/16” ange holes
Repl. OEM 43663-80A
CHROME DUAL FLANGE EXTRA WIDE REAR HUB
7/8” offset, 7/16” hole on sprocket side, 3/8” on brake side
and accepts up to 5” rim
H3081 ‘84-99 Big Twin, XL
hub covers
12-38
SUPER MOON HUB COVER
These chrome steel mini-hubcaps take an old idea and
give it a new clean look. Easy to install and made in the
U.S.A.
H3812 ‘84-95 FXWG/DWG, FXST/S/C
H3813 ‘86-up all Heritage
CONE COVER
For the ultimate machine look in hubcaps, Win has
the answer. American Made.
H3814 ‘84-up FXWG/DWG, FXST/S/C
H3815 ‘86-up all Heritage
90° FRONT HUB COVER
These American made chrome hub covers are for the
area between the brake rotor flange or the belt pulley
flange and the spoke area of the wheel hub. Includes
hold-down plates.
H3816 ‘87-91 FXSTS
H3817 ‘92-up FXSTS
H3818 ‘86-up FLSTC
H3819 ‘84-up FXWG/DWG, FXST/C/S
H3821 ‘90-up Front for Fat Boy®
90° REAR HUB COVERS FOR SOFTAIL®
These chrome brake covers include special rotor and pulley
hold-down plates and are easy to install. They are available
for rear application on ‘87-92 Softail® models. Made in the
U.S.A.
H3820 ‘86-up FXDWG, 5-speed Softail®
rear hubs with laced wheels
H3822 ‘90-up Rear for Fat Boy®
GROOVED CONE HUB COVER
American made by Wild 1 & beautifully chromed.
H3823 ‘87-up FXSTS/C
BABY MOON HUB COVER
A chrome classic. Front hub cover for laced wheels.
Made in the U.S.A
H3810 ‘84-95 FXWG/DWG, FXST/S/C
H3811 ‘86-up all Heritage
CHROME FRONT AXLES
These chrome front axles are sold without hardware, which is available separately.
All hardware kits include any spacers, sleeves, nuts, washers & cotter pins in respect to
their OEM application. All measurements on the chart listed below are from the base of
the head to the end of the axle.
Hardware Only Axle Only Length Repl. Axle OEM Front Application
A4009 A4015 9 5/8 43872-36 ‘36-48 EL/FL/UL
A4010 A4016 8 7/8 43875-48 ‘49-66 EL/FL
A4010 A4017 9 1/8 43875-67 ‘67-71 FL
A4011 A4018 10 3/16 43875-73 ‘73-80 FL, ‘80-83 FXWG
A4012 A4019 10 11/16” 43346-83
‘81-84 FL, ‘84-99 FXST/C
‘84-86 FXWG, ‘83-99 all
FLH models
A4013 A4020 6 1/8 43871-52 ‘52-72 K/XL/FX
A4014 A4021 8” 43871-73 ‘73-77 XL/FX
A4014 A4022 8” 43883-77 ‘77-83 XL/FX/ FXR
A4014 A4023 8” 43883-84 ‘84-87 XL/FX/FXR
CHROME REAR AXLES
These chrome rear axles are sold without hardware, which is available separately. All
hardware kits include any spacers, sleeves, nuts, washers & cotter pins in respect to
their OEM application. All measurements on the chart listed below are from the base of
the head to the end of the axle.
Hardware Only Axle Only Length Repl. Axle OEM Rear Application
A4032 A4040 10 11/16 41552-36 ‘36-57 EL/FL/UL
A4033 A4041 11” 41552-58A ‘58-66 FL
A4034 A4042 11” 41552-67 ‘67-72 FL/FX
A4035 A4043 12 1/8 41552-73 ‘73-85 FL/FX
A4036 A4044 12 5/16 41580-79 ‘80-86 FL/FX Belt Drive
A4037 A4045 10 3/8 41551-52 ‘52-78 K/XL
A4038 A4046 11 5/16 41563-77A ‘79-up XL
A4039 A4047 12 ½” 41110-79A ‘82-99 FXR & FLH,
‘86-99 Softails®
A4058 A4049 13” 41114-90 ‘91-up Dyna
12-39
axles, Nuts & caps
Length
Length
axles, Nuts & caps
12-40
AXLE & BULLET STYLE NUT ASSEMBLIES
These American made polished stainless steel fasteners are
part of a stunning Bullet Style fastener line.
See hardware section for complete line.
F6405 Front axle & S/S nut assembly for FXSTS Springer®
F6406 Rear axle & S/S spacer/washer set for Softail®
Nut bottoms
BULLET STYLE FRONT AXLE NUT
COVER & SPACER SET
These American made polished stainless steel
fasteners are part of a stunning Bullet Style fastener line.
See hardware section for complete line.
F6404 All Softail® models except Springer®
CHROME FRONT AXLE CAPS
A3175 ‘73-up Big Twin
12-41
axle covers
SKULL AXLE NUT COVERS
The ultimate bad ass accessories, these chrome nut
covers come complete with diamond cut eyes to glue in the
sockets. For matching accessories see Wild One Products
in index.
A3070 ‘88-up Springer®
A3071 ‘84-99 Wide Glide® Front
A3072 Fits all rear with 15/16” nuts
CHROME FRONT AXLE NUT COVERS
These chrome nut covers fit a variety of applications:
A4048 ‘72-84 FL, ‘80-up FLT, 80-86 FXWG,
‘84-up Softail®, ‘88-up FXR.
CHROME REAR AXLE CAPS FOR SOFTAIL®
The perfect way to hide those ugly axle nuts
on your ‘86-up FLST or FXST.
A4050 Softail® axle caps, pair
axle Nuts
12-42
CHROME FRONT AXLE NUT KIT
A quality hardware kit offered by Colony to make the older
Harley® look better and stay together longer. Kits contain one
each; axle nut, sleeve nut and cotter pin or two castle nuts and
two cotter pins depending on application.
F6334 ‘30-71 Big Twins
CHROME REAR AXLE ACORN KIT
When installed, these chrome plated 1 1/4” hex acorn
nuts will add a clean, finished look to any Harley® with
welded nut rear axle.
F6331 Acorn nut
CHROME REAR AXLE NUT & WASHER KIT
Chrome plated heavy duty machined steel washers
prevent distortion of square swingarms.
F6337 ‘73-up Big Twins & ‘79-up XL
CHROME REAR AXLE NUT AND LOCK KIT
Quality reproduction rear axle kit contains axle nut, sleeve nut,
sleeve collar and axle lockwasher. All parts are made to original
Harley® specifications.
F6332 ‘30-72 Big Twins
CHROME FRONT AXLE NUT & WASHER KIT
Chrome plated machined steel washer, hex nut, and stainless steel
lockwasher fits Wide Glide®, FX, Sportster®.
F6335 ‘73-up FX, Sportster®
F6336 ‘72-up Wide Glide®
12-43
axle adJusters
CHROME SWINGARM END COVER AND NUT KIT
These nicely chrome plated end covers and nuts will replace the original
Harley® part used on FX, FL, FXR & XL.
F6338 ‘73-up Big Twins & ‘79-up XL’s
CUSTOM AXLE ADJUSTERS
Super custom look to fit stock swingarms.
Sold in pairs.
A3049 ‘82-92 FXR
CHROME REAR CHAIN AXLE ADJUSTERS
Chrome plated, Made in America by Colony. ‘86-up FXST. Sold Each
F6392 ‘86-92 FXST
Repl. OEM 47579-86.
F6395 ‘93-99 FXST
Repl. OEM 47579-93
CHROME SWINGARM END CAP ADJUSTERS
These swingarm end cap adjusters feature die-cast
construction and chrome finish. Sold in pairs.
F2224 ‘73-86 4-speed Big Twins, ‘79-up XL models
Repl. OEM’s 47554-73, 41532-89
CHROME LATE AXLE ADJUSTERS
Includes washer, lock nut & rear fork end cover.
Sold in pairs.
W3210 ‘73-up Big Twins except ‘87-up Softail®,
‘79-up XL
Repl. OEM 41530-84
axle adJusters
12-44
ALLEN SCREW WHEEL ADJUSTER SETS
BY GARDNER-WESTCOTT
F4810 Thru-72 Big Twins Wheel Adjustment Bolts Rear
F4820 ‘87-92 FXST & FLST Softail® Wheel Adjustment Bolts Rear
F4039 ‘93-up all Softail® models Wheel Adjustment Bolts Rear
CHROME AXLE ADJUSTER
SPACERS FOR SOFTAIL®
F2900 ‘86-89 Spacers
Repl. OEM 47577-86
CHROME REAR WHEEL ADJUSTER
Featuring square swingarms and die cast construction.
Helps prevent swingarm tube damage from over
tightening axles. Sold in pairs.
F2223 ‘82-94 FXR
Repl. OEM 41570-77
CHROME REAR AXLE ADJUSTERS
Double nuts. Sold in pairs.
W3231 ‘00-up Softail®
Repl. OEM 47577-00 & 7783 nuts
W3230 ‘54-78 KH, XL, XLH, XLCH
Repl. OEM 39985-52
REAR AXLE ADJUSTING SCREW
Chrome plated custom 3/8-16 adjusting screw & locknuts.
F4041 2000-up Softail®
Repl. OEM 47579-00

Navigation menu
