Dongguan Hele Electronics J11 Bluetooth Headset User Manual J11 sw 066 000002
Dongguan Hele Electronics Co., Ltd. Bluetooth Headset J11 sw 066 000002
Users Manual
QCY-J11
QCY-J11
BLUETOOTH
a.m.
Turn on Bluetooth
Visibility
Device name
Visible to all Bluetooth devices nearby
Available Devices
Available Devices
User Manual
Overview How to Wear How to Connect How to Charge
Large EarGel
Note: we recommend that you try middle EarGel first as it fits
most people.
Gently push EarBud into
ear canal and adjust its
end towards your mouth
then shake your head to
check its stability.
Maiden pairing: once
powering on, earphone will
auto enter pairing mode
(LED blinks red and blue).
Non-maiden pairing: power
off the earphone then hold
MFB for 5s to enter
pairing mode.
Low battery will be warned by voice prompt.
(LED will be solid red when charging and turn to blue
once fully charged.)
Function
Multi-point Connectivity
Power-on
Hold MFB for 2s(LED will be blue for 1s).
1. Refer How to Connect to build connectivity with phone1
then power off Bluetooth earphone.
2. Hold MFB until LED blinks red and blue. On phone2, search
for QCY-J11 and tap to connect.
3. On phone1, search for QCY-J11 and tap to finish multi-point
connectivity.
Three-way Calling & Switch
Tap MFB to answer incoming call. If another call is coming in
sync, tap MFB to put the first call on hold while activate the
second call. Double tap MFB to switch between active call
and held call.
Basic Parameter
Model:J11
Bluetooth version:V4.1
Bluetooth profile:HFP,HSP,AVRCP,A2DP
Operation range: 10m(crow-fly distance with no obstacle)
Noise isolation: DSP
Standby time: approx. 70hr
Talk time: approx. 3hr
Charging time: approx. 1 or 2hr
Battery type: li-ion
Battery capacity:3.7V 55mAh
Input Parameter:5V 70mA
(All technical specifications shall be subject to practical
performance)
Operation
Voice Assistant
When standby, hold MFB for 1s to activate voice assistant
(like Siri).
Switch Audio Output
When calling, hold MFB for 1s to switch audio output between
earphone and cellphone.
Power-off
Hold MFB for 3s(LED will be red for 2s).
Answer/End Call
Tap MFB to answer incoming call and tap again to end it.
Ignore Call
Hold MFB for 1s to ignore incoming call.
Mute on/off
When calling, double tap MFB.
Pause/Play
When playing, tap MFB to pause and tap again to play.
On cellphone, search for
QCY-J11 and tap to connect
(Earphone will auto
reconnect to the last
device in connectivity
records, if any.)
Middle EarGel Small EarGel
EarWing
MFB
Hold
5
This form is made by SJ/T 11364 regulation.
O：means that hazardous substance content in the homogeneo
us materials of this part is within the limitsof GB/T 26572
regulation.
X ：means that hazardous substance content in, at least,one
certain homogeneous material of this part is beyond the
limits of GB/T 26572 regulation.
Hazardous substances and their contents in the item
（Pb） （Hg）
（Cd） （Cr(VI)）（PBB）（PBDE）
Hazardous Substances
Part Name
Main body
Battery
Ear tips
Accessories
Charging cable
Lifespan:
As the booklet states, the eco-lifespan of the item is 5 years
while using it in normal ways. During the period, no dangerous
material will be leaked. The item must be recycled by the local law.
Notes: Please arrange using time properly as your hearing may
be damaged by using the device for a long time.
Tips Warranty Card
Warranty Period
12 months after you purchase this item.(or you may
inquire your local shopper for more details.)
Free Service:
Supposing any defects caused by quality issues occur
within the warranty period, please take this warranty
card and purchase receipts to your distributor for free
repairing service.
1. Before using the headset, please read the manual
carefully and keep it for future references.
2. The headset need to be fully charged prior to first-time
use.
3. If the headset is left unused for over two weeks, please
recharge it periodically.
4. Please use the chargers made by qualified manufacturer.
5. If the headset cannot be found by your phone, please
check whether it is in pairing mode; if left unconnected for
a long while, the headset will exit pairing mode,please
re-enter the mode; if a procedure error of your phone
occurs, reboot it; if a procedure error of the headsetoccurs,
reboot or reset it.
Caveats
1. Never disassemble or modify your headset for any
reasons to avoid any damages and danger.
2. Do not store the headset in extreme temperatures (under
0℃ or over 45℃).
3. Avoid using the indicator close to the eyes of children or
animals.
4. Do not use this headset during a thunderstorm to avoid
irregular function and increased risk of electricshock.
5. Do not use harsh chemicals or strong detergents to
clean the headset.
6. Keep the headset dry.
Free repairing will not be accessed under following
circumstances：
1. Damages caused unauthorized disassembly.
2. Defects or physical damages caused by leaking or
dropping off.
3. Damages by act of God.Supposing your item is within
any damages or defects except the above circumstances,
please return to us or your distributor for free repairing.
Perform standard:Q/HL 2-2017
Manufacturer:
Dongguan Hele Electronics Co., Ltd.
Address: Dalingya Industrial Zone, Daojiao
Town, Dongguan City, Guangdong,
China.
Model Number:
Date of Purchasing:
User's Phone:
User's Name:
User's Address:
Shop's Name:
Shop's Address:
Comments:
55mm
80mm
FCC Statement
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including
interference that may cause undesired operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate the equipment.
FCC ID:RDR-J11
USB Charging Dock
EarGel
Mic
Skip Track Forward
When playing, double tap MFB.
Bluetooth Headset
