Dongguan Koppo Electronics BT592 Bluetooth Headset User Manual

Dongguan Koppo Electronics CO.,Ltd Bluetooth Headset Users Manual

Contents

Users Manual

1
User Manual
■product name：Headset+ outer ring music Bluetooth headset
■apperance：
■As picture show：
1， LED indicator of lightoutside speaker。 2，on-off of outside speaker。 3，bluetooth LED indicator
light。 4， bluetooth power switch button 。 5，previous/VOL（+）。 6，Next/VOL（-）。 7，MICRO
USB socket。 8，Φ40mm 4Ohm 3W speaker。 9，earphone socket。 10，MIC
1
2
3
4
5
6
7
8
9
10
00
8
2
■Basic specification
Product size：200*190*80mm
Net weight：225g
Working voltage：3.7 V；
Low batter indicator voltage：3.2 V；
Play time： 30hours for headphone；3 hours for speaker
Charging voltage：DC 5 V；
Charge interface：MICRO USB
Charging time： 2hours；
Charging current：500mA
Audio input interface：yes
Automatic shutdown time when no connection：5 minutes
■opreating instruction
Turn on：Long press the multifunction button until blue LED on
Power off : long press the multifunction button until red LED on;
Pairing：：In pairing mode automatically
Volume adjustment：Long press VOL（+）turn up the volume；Long press VOL(-）turn down the volume
Previous /Next: In the state of music mode, press the volume-up button shortly to the previous song
and press the volume-down button shortly to the next song.
Pause/Play : In the state of music mode, click the power button to pause the music and click again to
play continuously.
Answering/ending call：press the multifunction button shortly
Rejecting call：Long press the multifuntion button for 2s to reject the phone call
Redial the last call： Double click the multifunction button, the headphone will dial last phone number
remotely and automatically;
Voice dialing：No
Speaker turn on：switch speaker to ON till the LED indicator light as blue
Speaker turn off:switch speaker to OFF till LED indicator light off,
■LED Indicator
Low battery：red light flash
Charging：The red light and when finished,the light off
Bluetooth connected：blue light glitter slowly.
Bluetooth have not connected：bluetooth glitter quickly
Paring-------Red and Blue LED glitters in turn
3
■bluetooth
chip：VIMI 9621SF
version：Bluetooth 3.0
Paring name：BT-592
Profile:A2DP，AVRCP，HSP，HFP
RF carrier frequency：2402MHz-2480MHz
Receiver distance：360°/ 10m；
■speaker 1
Speaker diameter：40mm；
Impedance： 32Ω
Rated power：100mW
Frequency Response：150Hz～20KHz；
Sensitivity：98dB±3dB；
■speaker 2
Speaker diameter：40mm；
Impedance： 4Ω
Rated power：3W
Frequency Response：100Hz～20KHz；
Sensitivity：95dB±3dB；
■MIC
MIC sheet：Φ4*1.5mm
Sensitivity：-42±3dB
■Battery
Battery sheet ：3.7V 1000mAh lithium-ion battery
Battery size：6.0（thick）*34（wide）*50（length）
■Environment condition
Working temperature： -5～45℃
Storage temperature：-40～70℃
Federal Communications Commission (FCC) Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generate, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate this equipment.
RF exposure warning
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment.
The equipment must not be co-located or operating in conjunction with any other antenna or
transmitter.
