Dongguan Koppo Electronics BT592 Bluetooth headset User Manual

Dongguan Koppo Electronics Co.,Ltd Bluetooth headset

Contents

User Manual

Charge
Ｕｓｅｒ　Ｍａｎｕａｌ
ＢＴ－５９２
CONTROLS
CONTROLS AND FEATURES BLUETOOTH BLUETOOTHSPERKER&MIC
Pairing Indicator Light
Power/Pair/Play/Pause/
Volume+
DC Power Input
Line In
Microphone
Press to adjust the volume increase/Previous song Volume-
Press to adjust the volume decrease/Next song
Speaker Switch Key
Slide to switch from
headphone to speaker mode.
Please note:
The external speakers on
the headphone are not
waterproof.Do not use
in rainy or damp
weather conditions.
Press and hold to power the unit on.
Press and hold for 5+seconds to begin pairing;
Press and hold to Power the unit off
Press to play or pause the current track;
Pairing a Bluetooth Device for the First Time
1.With the unit off, press and hold the Power/Pair/Play/Pause button
for about 4s.The indicator will flash red and blue.When pairing,
remain within 3 feet of the unit.
2.Using the native controls on your bluetooth device,select the BT-592
in your bluetooth setting to pair. If your device requests a password,
enter the password 0000.
Refer to the user manual for your specific device for instructions on
pairing and connecting bluetooth devices.After initial pairing,the unit
will stay paired unless unpaired manually by the user or erased due
to reset of the device;
Remarks: If your device should become unpaired or you find it is
unable to connect,repeat the above steps;
SAFETY INFORMATION ACCESSORIES
Headphone speaker diameter:Φ40mm
Impedance:32Ω
S.P.L: 109dB±3dB
Rated power: 100mW
Frequency Response:20Hz-20KHz
Speaker diameter:Φ40mm
Impedance:4Ω
S.P.L: 81dB±3dB
Rated power:3W
Frequency Response: 160Hz～20KHz
Microphone Unit:Φ4*1.5mm
S.P.L:-42±3dB
LINE IN LED INDICATORS
Playing music wirelessly Using the audio input
Require a 3.5mm audio cable(included)
1.Connect a 3.5mm audio cable to the line in input on the unit and
the audio output on an audio device.
2.Use the native device controls on the connected device to play
your audio through the unit.
Note:The headphones do not have to be powered on to hear music
through the line in input.Do this to conserve battery power;
Using the Speaker phone
1.When a call is received, a ringtone will sound through the
speakers.
2.Press the power/pair/play/pause button t accept the call or accept
the call with the native controls on the connected device.
3.The incoming call received through the device will now be heard
through the headphones.
4.To end a call, press the power/pair/play/pause button or end the
call using the native controls on th connected device.
1.To play or pause a selected track,use the native controls on the
connected bluetooth device or press the power/pair/play/pause
button.
2.Audio played through the connected bluetooth device will now be
heard through the headphones;
Status
Power on
Power off
Charging
Fully charged
Pairing
Indicator
Flashing blue light
No light
Red light on
Blue light on
Flashing red
and blue light
FEATURES
Supports Bluetooth v3.0
Wireless range:33 feet
Supports profile A2DP,AVRCP,
HSP,HFP
Built-in microphone with noise
cancellation technology
Micro-USB port for battery recharge
3.5mm audio input
Adjustable headband
3.5mm audio cable
USB cable
User manual
INCLUDES
DC battery power:built-in 1000 mAH
Rechargeable lithiumion battery
Headphone battery time: up to 25+hours
Speaker battery time: up to 3 hours
blue
LED
Volume Control: Under the music or conversation mode:
(1)Volume +: Press and hold the volume + (3~5s), the volume will
increase gradually.
(2)Volume -: Press and hold the volume - (3~5s), the volume will
decrease gradually.
In the state of music mode, press the volume + shortly (1s), then will
go to previous song; press the volume - shortly (1s), then will go to
next song
11 1210
Connect the included USB Cable to the
USB Port of Computer or Adapter USB
Port.
Bluetooth headset
Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions
(1)this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation
FCC Statement
