Dongguan Newmen Electronics Technology MS146OR Mouse User Manual S CNL MS 146RF Quick User Guide EN
Dongguan Newmen Electronics Technology Co.,LTD Mouse S CNL MS 146RF Quick User Guide EN
manual
1
CONNECTLAND –MS-146OR Mouse – Guide
1. CONTENTS
The Connectland wireless optical mouse is included with the following accessories: a nano
USB 2.4GHz receiver, two LR03 AAA 1.5V batteries and a quick user’s guide.
Please contact immediately your vendor if one of them is missing.
2. INSTALLATION
a) Press battery cap button and open battery cap.
b) Insert two LR03 AAA 1.5V batteries (caution to the polarity).
c) Take out the nano USB receiver and replace the cap.
Switch on the mouse. Plug the nano receiver into your computer’s USB port.
System will recognize the new USB device and installed by itself. Then user will see “device
can be used », after successfully installed.
Battery cap button
2x Batteries AAA
compartment
ON/OFF
USB receiver 2.4GHz
compartment
PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn
2
CONNECTLAND –MS-146OR Mouse – Guide
3. SYSTEMS SUPPORTED
The wireless mouse is compliant with the following operating systems:
- Microsoft Windows 98SE/ME/2000/2003/XP/VISTA
(Insert Microsoft Windows CDROM if asked)
- IBM and PC compatible
4. KEY-PRESS INSTRUCTION
CPI adjustable instruction (Count Per Inch) :
The mouse has 2 sensitive modes: 800cpi and 1600cpi.
To activate normal use mode: 800cpi
Press the CPI button. CPI light indicator will flash on 4 times.
To activate sensitive use mode: 1600cpi
Press the CPI button again. CPI light indicator will flash on 8 times.
Back
CPI and battery
CPI/DPI adjustable
Scroll wheel
Right
Forward
Left button
PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn
Federal Communications Commission (FCC) Statement
You are cautioned that changes or modifications not expressly approved by the part
responsible for compliance could void the user’s authority to operate the equipment.
NOTE: This device has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this device does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1. This device may not cause interference and
2. This device must accept any interference received, including interference that may
cause undesired operation.
