Dongguan Taide BT026 Bluetooth Speaker User Manual

Dongguan Taide Industrial Co., Ltd. Bluetooth Speaker Users Manual

Contents

User Manual

Dear user,
Thank you very much for choosing BT026 Speaker. Please read this user manual carefully in
order to operate this device in the correct manner.
I. THINGS TO REMMEBER.
Please store and use this product at normal temperature;
DO NOT expose this product to rain or dampness
DO NOT toss this product and prevent it from falling and being damaged
DO NOT disassemble, repair and modify this product
As it is inbuilt with lithium battery, DO NOT place it in fire to avoid danger!
II. GENTLE REMINDER
1. To prolong the speaker‘s life span and for your wellbeing, please don't listen to music with max
volume for a long time to avoid hearing damage.
2. When something is wrong with the speaker, please immediately put it of, unplug the USB, to
prevent the speaker and other parts from getting damaged.
III. OVERVIEW
Function:
Power on or Power off
Handsfree icon
Bluetooth icon
AUX line in
DC 5V jack
Battery indicator icon
Bluetooth indicator icon
Aux indicator icon
Decrease volume or select last track
Increase volume or select next track
Play or Pause
Scene Lamp Switch
Increase Lightness
Decrease Lightness
IV. SPECIFICATIONS
Model: BT026
Bluetooth specification: Bluetooth V4.2
Transmission distance : ≦ 10M
USB charging voltage: DC 5V/500mA
Built-in battery: Lithium battery, 4000mAh
Output power: 6W x 2
Frequency response: 90Hz-20KHz
Sensitivity: 80db±2db
S/N ratio: ≥ 76dB
V. PACKING LIST
1. Speaker * 1
2. USB cable * 1
3. User manual * 1
VI. FUNCTION DESCRIPTION
BLUETOOTH OPERATION
1. Turn on the speaker. The blue indicator light will flash to detect Bluetooth enabled devices
near you. The blue indicator light will go out if no Bluetooth device is detected within 5
minutes.
2. Pair the speaker with the desired Bluetooth device.
3. Play/pause as desired by pressing.
AUX PLAYBACK OPERATION
1. Turn on the speaker.
2. Insert a 3.5mm audio cable into the aux jack on the back of the speaker, connecting to any
audio device such as mobile phones or computers with the other port.
3. press to enter mute mode and re-press to release the sound.
LAMP LIGHT OPERATION
1. Press to turn on the lamp light
2. Press to control the lightness.
CHARGING THE SPEAKER
The speaker has a built-in Lithium battery. The battery is rechargeable and provides approx 18
hours of continuous operation when fully charged.
Use the micro-USB cable to charge the speaker. The red indicator light will illuminate. The red
indicator light will go of when the speaker is fully charged.
VIII. COMPATIBILITY
Device equipped with BLUETOOTH 2.1 or higher version, such as the iPad, iPhone, iPod Touch
as well as a majority of "Smartphone” that support Bluetooth.
Bluetooth 2.1 including agreements as：A2DP, AVRCP, HFP.
VIII. TROUBLESHOOTING
PROBLEM
TROUBLESHOOTING
Failure in connection
and pairing
1. Inspect whether the speaker is in search mode or restart
the machine.
2. If many Bluetooth enabled devices are switched on then it
will cause difficulty in searching the device. So, please
switch off other Bluetooth equipments.
The sound is less or
distorted
1. Inspect the volume of the Bluetooth equipment and adjust
the volume.
2. The power of battery might be insufficient. Please charge
it.
Discontinuous music
See whether the effective connection distance of sound is
exceeded, or, whether there is obstacle between the speaker
and the Bluetooth equipment.
The indicator for
Bluetooth mode is not
on
1. It indicates that the power of the battery is not sufficient.
Please try again after charging it.
2. Restart the machine.
PHENOMENO
N
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment. This device complies with Part
15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
