Dongguan Taide BT041 Bluetooth Speaker User Manual
Dongguan Taide Industrial Co., Ltd. Bluetooth Speaker
user manual
Voyage Bluetooth® Speaker
Instruction Manual
Back Cover Front Cover page 02 page 03
page 04 page 05 page 06 page 07
BLUETOOTH OPERATION
1. Please ensure that the Bluetooth function has been turned
on in the settings of your Bluetooth enabled device.
2. Turn the speaker on, the indicator light will flash to detect
Bluetooth enabled devices near you and will enter pairing
mode. The indicator light will go off if no Bluetooth devices
3. “GEMLINE SPKR” will appear on the Bluetooth device list,
are detected within 5 minutes.
select “GEMLINE SPKR” to establish pairing. If instructed
to enter a PIN code, please enter ‘0000’.
4. When you want to play audio from another Bluetooth device,
disconnect the speaker from the original device and follow
steps 1-3 to re-pair the speaker with a new Bluetooth
enabled device.
CHARGING THE SPEAKER
1. When the battery is low, please charge via the included
Mini USB cable. The charging time is approximately 1
hour and provides up to 2 hours of continuous operation.
2. The LED indicator light will be red during charging and will
turn off once it is fully charged.
AUX PLAYBACK OPERATION
1. Turn on the speaker.
2. Connect the speaker to a smartphone, audio device, or laptop
3. The volume, play/pause, and next/previous song button can
only be adjusted on the device that is connected through
the 3.5mm AUX cable (AUX Cable not included).
GENERAL FUNCTIONSSPECIFICATION
.
Bluetooth Specifications：Bluetooth® V4.0
Transmission distance: up to 10 m (This may vary based on
environmental factors or the type of Bluetooth® device being
used)
Built-in battery: Lithium Battery 300mAh
USB Recharge voltage: DC 5V
Output power: 3W
Frequency Response: 90Hz-20Khz
Sensitivity: 80db±2db
Product dimensions: 2” x 2” x 2”
PACKING
• Bluetooth® Speaker with strap
• Mini USB Charging Cable
• User Manual
WARNING
1. Do not disassemble, repair, or modify the speaker.
2. Do not place product in or near fire to avoid danger, as it
uses a lithium battery.
3. Avoid storage at extreme temperatures, this can shorten the
battery life and may affect the speaker.
4. Keep the speaker dry and do not store the speaker in damp
areas to avoid damage to the speaker.
5. Avoid dropping the speaker as it may damage the speaker.
KIND REMINDER
1. To prolong the speaker’s life span and to avoid hearing
damage, please do not listen to music under high volume for
long periods of time.
2. When an error occurs with the speaker, please turn off the
speaker and restart it to troubleshoot.
3. When the speaker’s power is low, the Bluetooth range may
be affected. Please charge the speaker to avoid disruptions
during use.
Unable to pair the
speaker with a
mobile device
1. Inspect whether the speaker is searching
for a Bluetooth enabled device to connect
to. If not, restart the headphones.
2. Difficulty in searching and connecting to
a desired device can be affected if multiple
devices are equipped, turned on, and in
range for Bluetooth connectivity. Please
turn off or disable the Bluetooth function on
the other devices.
3. The power of the battery is insufficient,
please recharge the speaker.
1. Inspect the distance between the speaker
and the Bluetooth enabled device, it may
exceed the Bluetooth transmission range.
2. Inspect if there is an obstacle between
the speaker and the Bluetooth enabled
device.
3. The power of the battery is insufficient,
please recharge the speaker.
Strap
Bottom View
Volume Control
PreviousTrack/Next Track
Play/Pause Button
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment. This device complies with Part
15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
This device complies with Industry Canada licence-exempt RSS
standard(s). Operation is subject to the following two conditions:
(1)this device may not cause interference, and(2) this device must
accept any interference, includinginterference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada
applicables auxappareils radio exempts de licence. L'exploitation
est autorisée aux deux conditions suivantes :(1) l'appareil ne doit
pas produire de brouillage, et(2) l'utilisateur de l'appareil doit
accepter tout brouillage radioélectrique subi, même si le brouillage
est susceptible d'en compromettre lefonctionnement.
