Baby Looney Tu n e s
N u r s e ry Monitor & Crib Light
O w n e r ’s Guide
Thank you for purchasing the Safety 1s t Baby Looney Tunes Nursery Monitor & Crib
Light. This is a state-of-the-art system that combines some of the most unique feature s
that any baby monitor offers. We are confident that you will appreciate its many
highlights. As you will soon learn there are many more feature s . . .
The Baby’s Unit (Transmitter) has continuous transmission that clearly sends your
b a b y ’s sounds to the Pare n t ’s Unit. This gives you the ability to continue with your
daily activities throughout the house or yard and at the same time monitor your baby.
The Pare n t ’s Unit (Receiver) remains with you wherever you go to pick up the sounds
that are transmitted from the Baby’s Unit. It conveniently clips to your belt or easily
stands on a table.
Both units are completely portable or AC powered. The AC Adapter allows the
receiver and transmitter to be plugged into any standard electrical outlet for use with
your household electricity. For convenient use without an outlet, use a 9 volt battery
for the Pare n t ’s unit and 4 “D” cell alkaline batteries for the Baby’s unit (Batteries not
i n c l u d e d ) .
We are sure that you will find the Safety 1st Baby Looney Tunes Nursery Monitor &
Crib Light convenient and easy to use. To insure that you will benefit from all of the
g r eat features that our monitor offers, and to make sure that it is used pro p e r l y, we
u r ge you to:
1
C o n t e n t s B a t t e r y Require m e n t s
Safety Instru c t i o n s
P a re n t ’s Unit (Receiver)
B a b y ’s Unit (Tr a n s m i t t e r )
Crib Clamp Assembly
(2) A/C Adapters
(4) "D" size alkaline batteries
(1) 9-volt battery
(Batteries Not Included)
C A U T I O N
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT REMOVE COVER OR BACK.
NO SERVICEABLE PA R TS INSIDE.
REFER SERVICING TO SAFETY 1S T CONSUMER RELATIONS DEPA R TMENT (800)-723-3065
DO NOT EXPOSE THIS PRODUCT TO WATER OR MOISTURE.
l a u n d r y tub in a wet basement, or near a swimming pool, etc.
■V E N T I L AT I O N : The Nursery Monitor should not be situated on a bed, sofa, rug, or similar surface that may block the ventilation
openings, or placed in an enclosed installation, such as a book case or cabinet that may impede the flow of air through the ventilation
o p e n i n g s .
■H E AT: The Nursery Monitor should be situated away from heat sources such as radiators, heat registers, stoves, or other appliances
that produce heat.
■POWER SOURCE:The Nursery Monitor should be connected to a power supply only of the type described in these operating
i n s t ru c t i o n s .
■POWER CORD PROTECTION: The power supply cord should be routed so that it is not likely to be walked on or pinched by items
placed upon or against it. Pay particular attention to the cord at the plug, convenience receptacle, and at the point it exits from the
N u r s e r y Monitor.
■C L E A N I N G : Use a dry cotton cloth to keep the Nursery Monitor free of dust. Do Not Use Wa t e r.
■NON-USE PERIODS: The power cord of the Nursery Monitor should be unplugged from the outlet when unused for a long period of
time. Batteries should be removed from both units.
■OBJECT AND LIQUID ENTRY: Care should be taken so that objects do not fall onto, and liquids are not spilled into the enclosure
t h r ough the openings.
■DAMAGE REQUIRING SERV I C E : The Nursery Monitor should be serviced by qualified service personnel when:
A. The Power supply cord has been damaged; or
B. Objects have fallen or liquid has been spilled into the product; or
C. The Monitor has been exposed to rain; or
D. The Monitor does not appear to operate normally or exhibits a marked change in its perf o rmance; or
E. The Monitor has been dropped or the enclosure damaged.
THE USER SHOULD NOT ATTEMPT TO SERVICE OR REPAIR THE MONITOR. ALL SERVICING SHOULD BE REFERRED TO
SAFETY 1S T CONSUMER RELATIONS DEPA RT M E N T: (800) 723-3065
WALL MOUNTING: THE PARENT’S UNIT MAY BE MOUNTED ON THE WALL ONLY AS DESCRIBED IN THESE INSTRUCTIONS.
WHEN USED WITH ADAPTERS, KEEP ALL PA R TS OF THIS MONITOR OUT OF REACH OF CHILDREN!
CAUTION: THIS MONITOR IS NOT INTENDED TO REPLACE PROPER ADULT SUPERVISION.
YOU SHOULD CHECK YOUR CHILD’S ACTIVITY AT REGULAR INTERVALS AS THIS MONITOR WILL NOT ALERT
PARENTS TO THE SILENT ACTIVITIES OF A CHILD.
F e a t u r es and Components
PARENT'S UNIT (RECEIVER)
1 Power/Channel Switch
2 Volume Dial
3 AC Adapter Jack
4B a t t e r y Compartment (9-volt)
5 Plastic Belt Clip
6S p e a k e r
7 Key Hole Slot for Wall Mounting
8 Flexible Antenna
9 Low Battery Indicator (Red)
1 0 Power On Indicator (Gre e n )
1 1 B a t t e r y Cover
1 2 (9-volt) Battery (not included)
1 3 B a t t e r y Contacts
F r ont view of Pare n t ’s Unit (Receiver) Rear view of Pare n t ’ s Unit (Receiver)
F e a t u r es and Components (continued)
BABY'S UNIT (TRANSMITTER)
1 Power On Indicator
2 Low Battery Indicator
3 Power/Channel Switch
4M i c ro p h o n e
5B a t t e r y Compartment (4 “D” Cell Alkaline)
6 AC Adapter Jack
7 Crib Light Button
8 Voice Activation Sensitivity Switch
9 Crib Clamp Assembly
1 0 Four “D” alkaline batteries, positive (+) to top (not included)
1 1 B a t t e r y Cover
12 A C Adapter Jack
12
A/C ADAPTER
The A/C Adapter is a low voltage power source that allows you to use your household electricity to run the Baby and Pare n t ’ s Unit when you
want to conserve battery life. It connects to the A/C Adapter Jack in the Pare n t ’s Unit and in the Baby’s Unit (when not in use on crib), and
plugs into any standard electrical outlet in your home.
Note: Do not place adapter under a window where a child might use it to step on and reach something that might be dangero u s .
CAUTION: These adapters were made with a specific design for Safety 1st Baby Looney Tunes Nursery Monitor & Crib Light. They cannot
be used with any other appliance. Never use a diff e r ent type of adapter with this monitor.
Operating Your Baby Looney Tunes Nursery Monitor & Crib Light
Follow these instructions to operate your Baby Looney Tunes Baby Looney Tunes Nursery Monitor & Crib Light. Reference the illustrations
p r ovided on page 1 & 2 for the location of all features described in these instructions.
B a b y ’s Unit:
For best results, attach the Baby’s Unit to the crib or place the Baby’s Unit on a dresser near the crib or bed.
Note: Baby’s Unit can only operate on battery power when attached to crib.
9
Installing the batteries in Baby’s Unit (transmitter):
R E Q U I R E D :
Phillips Scre w d r i v e r
4 "D" Size Alkaline Batteries
1. Remove screws from battery cover and remove cover.
2. Insert 4 "D" size alkaline batteries into the battery compartment by matching the (+) and (-) symbols. (Figure 1)
N O T E : The low battery indicator illuminates when the batteries need to be re p l a c e d .
3. Replace the battery cover and insert and tighten the scre w s .
Attaching Baby’s Unit to Crib:
R E Q U I R E D :
B a b y ’s Unit (transmitter)
Crib Clamp Assembly
1. Set the Baby’s unit to setting "A". If you experience static or noise interf e r ence, switch both
units to setting "B". Power On Indicator should be illuminated.
2. Place Baby’s Unit in desired location on crib slats with Baby Looney Tunes characters facing
i n w a r d. Screw shaft should be resting on the crib rail. (Figure 2) (Do not translate text in re d )
3. Holding Baby’s Unit in place, insert crib clamp assembly into shaft (Figure 3)
4. Tu r n knob clockwise to tighten until secure. (Figure 3)
Using the Crib Light
Your Baby Looney Tunes Baby’s Unit (transmitter) includes a crib light feature that is activated
by the sounds of your baby and can also be activated manually.
1. Slide voice activation sensitivity switch to the desired sensitivity setting. Set to high sensitivity
when you want the crib light activated by quieter sounds or low sensitivity when you want
the crib light activated by louder sounds.
N O T E : The crib light will automatically shut off after five minutes.
2. To activate the crib light manually, press the manual crib light button. (Figure 4)
3. To shut off the crib light manually, press the manual crib light button. (Figure 4)
Installing the batteries in Pare n t ’s Unit ( Receiver):
1. Remove screw from battery cover on Pare n t ’s Unit and remove cover.
2. Insert a 9-volt battery into the battery compartment by snapping the battery contacts
into the corresponding connectors on the battery clip in the unit. (Figure 5)
N O T E : The low battery indicator illuminates when the batteries need to be re p l a c e d .
3. Replace the battery cover and insert and tighten the scre w.
Adjusting the Channels
1. Place the Pare n t ’s Unit at least 10 feet from the Baby’s Unit.
2. Plug the round end of the adapter into the Pare n t ’s Unit, then plug the adapter into an electrical outlet.
3. Set the Pare n t ’s Unit to setting "A". If you experience static or noise interf e r ence, switch both units to setting "B".
N O T E : C o n f i r m the Pare n t ’s Unit and Baby’s Unit are set to the same setting (A and A or B and B).
4. Adjust the volume so you can hear your baby at all times.
N O T E : The Pare n t ’s Unit may be mounted to a wall by using a screw (not included) to attach the unit using the keyhole located on the back
on the unit.
( F i g u r e 4)
( F i g u r e 5)
( F i g u r e 2) ( F i g u r e 3)
( F i g u r e 2) ( F i g u r e 3)
( F i g u r e 1)
Using the A/C Adapter
The A/C Adapters should be used whenever possible to increase the life of the batteries. However, if the Baby’s Unit is mounted to the crib
the A/C Adapter cannot be used.
Both units will automatically convert to A/C operation when used with the A/C Adapters. It is not necessary to remove batteries during A/C
operation. Both units will automatically switch back to battery power when disconnected from the adapter.
N O T E : If you experience a power failure, the Pare n t ’s Unit (Receiver) and Baby’s unit (transmitter) will not automatically switch to battery
p o w e r. You must disconnect the A/C Adapter from the Pare n t ’s Unit and Baby’s Unit (if not mounted to the crib).
Operating Tips
■Make sure that both units are on the same channel.
Even though you may hear your baby’s sounds, proper use of this system re q u i res that both units must be on the same channel. If the units
a r e on diff e r ent channels, the signals from the Baby’s Unit may still be strong enough to be picked up by the Pare n t ’s Unit, but there will be a
lot of static.
■When unit is not in use, remove AC Adapter and be sure the power dial is "Off " .
When you are not using the adapter, remove it from the unit and store it in a safe, dry place until you need it again. If the AC Adapter is
plugged into the unit but not being used in an electrical outlet, the adapter will prevent the battery operation of the unit.
■Use your re c e i v e r ’s AC Adapter when you will be in the same location for most of the day.
Use of the adapter provides maximum power to the unit and provides additional antenna length.
■When using the AC Adapter with household electricity, make sure the outlet has power.
Some electrical outlets are powered through a wall switch in the room. If the Baby’s Unit is plugged in and turned "On", the power indicator
light should be lit. If it is not, try turning the wall switch in the room "On".
Checklist for Problem Solving
Power indicator light not working
Static or interf e r ence in the signal
t r a n s m i s s i o n
P a re n t ’s Unit is making loud noises
P a re n t ’s Unit is picking up noises
f r om outside your home
Weak sound coming from unit
Crib light does activate or activates
too much
Power is not getting to the unit
B a b y ’s and Pare n t ’s Units may be set on
d i ff e rent channels
Appliances with loud fans near units may
be blocking transmission
Unit may be under fluorescent lights
Local interf e r ence from electrical or radio
f r equency appliance near your location
Units are too close together
Neighbors may have a baby monitor or
c o r dless phone
Batteries may be weak
Units may be too far away from each other
Sensitivity may need to be adjusted
Make sure wall outlet is working. May
possibly need to be turned on by a switch.
Make sure both units are on the same
channel (A or B)
Tu r n off the appliances that may be
causing interf e re n c e
Reduce the distance between the two
units or turn off lights
Switch channel setting on both Pare n t ’s
and Baby’s Units
P a re n t ’s Unit needs to be at least 10 feet
(3meters) away from the Baby’s Unit
Change both units to the alternate channel
(A or B)
Check batteries, replace if necessary
Move the units closer to each other
Adjust sensitivity switch
P R O B L E M POSSIBLE CAUSE S O L U T I O N
IF YOU ARE STILL HAVING PROBLEMS, PLEASE CALL TOLL FREE FOR HELP! (800) 723-3065.
ONE (1) YEAR LIMITED WA R R A N T Y
Safety 1s t , Inc. warrants to the original owner of this product that the Nursery Monitor is free from defects in materials and workmanship for a period of one
1) year from the date of the original purchase. If this monitor fails to function when used as directed under normal conditions, within the one (1) year
period, Safety 1s t will either repair or replace the product at our option, free of charge, when it is re t u r ned complete and in its original packaging, pre p a i d
postage, and insured to Safety 1s t Consumer Relations Department, 210 Boylston Street, Chestnut Hill, MA 02467. Product must be accompanied by a pro o f
of purchase, either a bill of sale, receipted invoice, or other proof that the Monitor is within the warranty period. Safety 1s t will bear the cost of repairing or
replacing the product and shipping it back to you.
This warranty does not apply to a Nursery Monitor that has been damaged as a result of improper maintenance, accidents, improper voltage supply or other
misuse. The warranty is also void if owner repairs or modifies the product in any way. Safety 1s t is not liable for any incidental or consequential damages
with re g a r d to this product. The warranty also excludes any liability other than what is stated above. No other warranties are given.
LEGAL RIGHTS VA RY FROM STATE TO STATE. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION
OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS MAY NOT APPLY TO YOU.
I M P O RTANT NOTE: ONLY USE THE ADAPTERS SUPPLIED FOR THIS NURSERY MONITOR.
USE OF OTHER ADAPTERS WILL VOID THIS WA R R A N T Y.
IMPORTANT!
Please do not return this product to the store!
Your questions and comments are important to us!
Thank you for purchasing this quality product from Safety 1s t . We are confident you will be pleased with its many feature s
and perf o r mance. If you are having any problems assembling, installing, or using this product, please call us. We will be very
happy to answer any questions that you may have. Many times there is a simple solution to any problem that may occur.
Talking to us directly will be convenient and save you time.
f you have questions or comments, please call our toll free Consumer Relations number: (800)723-3065.
We guarantee all of our Safety 1st products. If you are not completely satisfied, please re t u r n with proof of purchase to:
Safety 1st, Inc., 210 Boylston St. Chestnut Hill, Massachusetts 02467 USA
Safety 1st Canada Inc., 804 Rue Deslauriers, Ville St. Laurent, Quebec H4N 1X1 Canada
Safety 1st Europe Ltd., Isopad House, Shenley Road, Borehamwood, Herts, WD61TE Great Britain
Made in CHINA to Safety 1st quality specifications. ©1998 Safety 1st
1 1 / 9 8
6
Call our Consumer Re l a tions De p a rt m e n t to l l - f r ee at (800) 723-3065
9:00 am to 5:00 pm (EST) Mo n d ay - Fri d ay.
We will gladly answer any and all of your questions about this prod u ct.
