Users Manual
DE-620
(RF CARD READER) Table of Contents
1. Specifications
2. Overview
User´s Manual
3. Product Contents
4. Installation
5. Operation
6. Dimension and Characteristic
7. Technical Su
pp
ort
DUALi INC.
Made in KOREA
pp
(Document Number : EP13-09-001)
1. Specifications 2. Overview
CPU ARM 32-bit Cortex-M3
1.1 DE-600S
Host
Communication
USB 2.0(1.1)
Compatible ISO 14443 Type-A (Include
- Support read / write the ISO14443 Type A
& B RF-Card, FeliCa card, Mifare Card
Protocol.
Card MIFARE) and Type-B, FeliCa
card, ISO 7816 Contact Card
and SIM Type
Read Range
Inside 4 cm
- Host Communication : USB
1.2 Caution
Read
Range
Inside
4
cm
Frequency 13.56MHz
Power USB Power (DC 5V), Max 250mA
- Do not expose to the hot temperature,
hot sunny, wet condition.
Consumption
Operating
Environment
-20ﾟC 〜 50ﾟC - Fragile on the shake, outside damage.
-
Sensitive to the installed environment
Size 68 ☓ 120 ☓ 28(mm)
Sensitive
to
the
installed
environment
,
do not expose in the iron metal around
the reader, it should cause the fatal
defection
3. Product Contents 4. Installation
USB CABLE
PC
READER - USB communication : Download USB
Driver from www.duali.com
- Provided communication protocol:
Length high + Length low + Command or
Response Code + Data
Sl kitt
-
S
amp
l
e wor
ki
ng
t
es
t
program
- Ask to the Service provider
( Program provider ) for more command
and function protocol
USB CABLE
and
function
protocol
5. Operation 6. Dimension and Characteristic
- You can test it with Duali test program
to read / write on the specific card.
5.1 Dimension
Power LEDUSB connector
- You can develop many different program
such as Access, time & attendance,
card issuing, PC security with the
r id d D li DLL d Pr t l
p
r
ov
id
e
d
D
ua
li
DLL
an
d
Pr
o
t
oco
l
.
- Functions.
120mm
* Mifare card Read/Write
* ISO 14443 A-Type Card Read/Write
* ISO 14443 B-Type Card Read/Write
* FeliCa card Read/Write
* ISO 7816 T=0 (Contact or SIM Type)
* Buzzer On/Off
* LED On/Off
68
mm
28
*
LED
On/Off
68
28
mm
Antenna
5 2 Characteristic
FCC (Federal Communications Commission)
This equipment has been tested and found to comply with the limits for a
5
.
2
Characteristic
- Operation Temperature : -20℃ 〜 50℃
- Input Volatge : DC 5V (USB)
This
equipment
has
been
tested
and
found
to
comply
with
the
limits
for
a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
- Card Reading Range : Inside 10 Cm
7. Technical Support
However,
there
is
no
guarantee
that
interference
will
not
occur
in
a
particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Address : Room 505 Samsung Technopark,
#471 Wonchen, Youngtong, Suwon,
Gyeonggi
443380, Korea.
- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
- Consult the dealer or an experienced radio/TV technical for help.
This device complies with Part 15 of the FCC`s Rules. Operation is subject
to the following two Conditions:
1Thi d i t h flit f d
Gyeonggi
443380,
Korea.
- URL : www.duali.com
1
.
Thi
s
d
ev
i
ce may no
t
cause
h
arm
f
u
l
i
n
t
er
f
erence, an
d
2. This device must accept ant interference received, including
interference that may cause undesirable operation.
Hereby, DUALi Inc. declares that this DE-620 is in compliance with the
essential requirements and other relevant provisions of directive 1999/5/EC
- Tel : +82-31-213-0074
WARNING:
This equipment may generate or use radio frequency energy.
.
Changes or modifications to this equipment may cause
harmful interference unless the modifications are expressly
approved in the instruction manual. The user could lose the
authority to operate this equipment if an unauthorized
change or modification is made.
