Dynabook UPA3844RD Nano receiver User Manual GMAA0015001T

Toshiba Corporation Nano receiver GMAA0015001T

User Manual

Nano Receiver Wireless Optical Mouse
Users Manual
English/Español
2 Nano Receiver Wireless Optical Mouse
Safety icons
Indicates an imminently hazardous situation which,
if not avoided, will result in death or serious injury.
Indicates a potentially hazardous situation which,
if not avoided, could result in death or serious injury.
Indicates a potentially hazardous situation which,
if not avoided, may result in minor or moderate injury.
Indicates a potentially hazardous situation which,
if not avoided, may result in property damage.
Provides important information.
This guide contains safety instructions that must be observed to
avoid potential hazards that could result in personal injuries,
damage to your equipment, or loss of data. These safety cautions
have been classified according to the seriousness of the risk, and
icons highlight these instructions as follows:
Nano Receiver Wireless Optical Mouse 3
Important Safety Instructions
To protect against risk of fire, bodily injury, electric shock or
damage to the equipment:
Do not immerse any part of this product in water or other
liquid.
Do not spray liquid on this product or allow excess liquid
to drip inside.
Do not use this product if it has sustained any type
of damage.
Disconnect this product before cleaning.
Regulatory Compliance
FCC Information
FCC notice "Declaration of Conformity Information"
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the
FCC rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interfer-
ence to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following
4 Nano Receiver Wireless Optical Mouse
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician
for help.
Changes or modifications made to this equipment, not
expressly approved by TOSHIBA or parties authorized by
TOSHIBA, could void the user’s authority to operate the
equipment.
FCC Conditions
This equipment has been tested and found to comply with Part
15 of the FCC Rules. Operation is subject to the following two
conditions:
This device may not cause harmful interference.
This device must accept any interference received,
including interference that may cause undesired operation.
Contact
Address :
:
TOSHIBA America Information Systems, Inc.
9740 Irvine Boulevard
Irvine, California 92618-1697
Telephone (949) 583-3000
Nano Receiver Wireless Optical Mouse 5
Following Information is Only for EU-Member States
Disposal of Products
Disposal of Batteries and/or Accumulators
Pb, Hg, Cd
The crossed out wheeled dust bin symbol indicates that
products must be collected and disposed of separately from
householdwaste. Integrated batteries and accumulators can be
disposed ofwith the product. They will be separated at the
recycling centres. The black bar indicates that the product was
placed on the market after August 13, 2005.
By participating in separate collection of products and batteries,
you will help to assure the proper disposal of products and
batteries and thus help to prevent potential negative
consequences for the environment and human health. For more
detailed information about the collection and recycling
programmes available in your country, please visit our website
(http://eu.computers.toshiba-europe.com) or contact your local
city office or the shop where you purchased the product.
The crossed out wheeled dust bin symbol indicates that
batteries and/or accumulators must be collected and disposed
ofseparately from household waste.
If the battery or accumulator contains more than the specified
values of lead (Pb), mercury (Hg), and/or cadmium (Cd)
definedin the Battery Directive (2006/66/EC), then the chemical
Pb, Hg, Cd symbols for lead (Pb), mercury (Hg) and/or
cadmium (Cd) will
appear below the crossed out wheeled dust bin symbol. By
participating in separate collection of batteries, you will helpto
assure the proper disposal of products and batteries and
thushelp to prevent potential negative consequences for the
environment and human health.
For more detailed information about the collection and
recycling programmes available in your country, please visit our
website (http://eu.computers.toshiba-europe.com) or contact
your local city office or the shop where you purchased the
product.
6 Nano Receiver Wireless Optical Mouse
Copyright Statement
Disclaimer
January 2009, Rev1.0
Trademarks
This guide is copyrighted by Toshiba Corporation with all
rights reserved. Under the copyright laws, this guide cannot be
reproduced in any form without the prior written permission
of Toshiba. No patent liability is assumed, however, with
respect to the use of the information contained herein.
©2010 by Toshiba Corporation. All rights reserved.
Information in this document is subject to change without
notice. The manufacturer does not make any representations or
warranties (implied or otherwise) regarding the accuracy and
completeness of this document and shall in no event be liable
for any loss of profit or any commercial damage, including but
not limited to special, incidental, consequential, or other
damage.
Microsoft, Windows, Windows XP, Windows Vista, and
Window 7 are either registered trademarks or trademarks of
Microsoft Corporation in the United States and/or other
countries.
Other trademarks or brand names mentioned herein are
trademarks or registered trademarks of their respective
companies.
7 Nano Receiver Wireless Optical Mouse
Introduction
Thank you for purchasing the Toshiba Nano Receiver Wireless
Optical Mouse!
Package Contents
Check to make sure you have all of the following items :
User's Manual (this booklet) and a standard limited
warranty booklet
Wireless Optical mouse with Nano receiver
Two AAA batteries
Quick Tour
The following figures show the components of the top and
bottom of the mouse
Scroll wheel
Right
Left
Battery
indicator light
button
button
cover
on/off
Nano
receiver
8 Nano Receiver Wireless Optical Mouse
System Requirements
Microsoft® Windows® 2000
Windows® XP
Windows Vista®
Windows 7
USB port
Setting up the Mouse
Installing the Batteries
1Remove the battery cover.
2Insert the batteries as shown into the battery compartment.
3Replace the battery cover.
1st2nd
AAA batteries
9 Nano Receiver Wireless Optical Mouse
Establishing a Connection between the Mouse and the Computer
1Press down firmly on the Nano receiver until it clicks and
partially pops out of the mouse.
2Remove the receiver from the mouse.
Nano receiver
3Plug the Nano receiver into an available USB port
on your computer.
10 Nano Receiver Wireless Optical Mouse
If the mouse is in Sleep mode, click button or moving
mouse to wake it up.
Status Indications
The indicator light on the top of the mouse provides information
about the current status of the mouse.
Troubleshooting
Indicator light status: Indicates:
Solid red (2 Seconds) Power on/Ready for connection
Problem Solution(s)
Mouse does not
work
Indicator light
flashes red
Make sure you have installed the mouse correctly.
Please see “Setting up the Mouse” on page 8.
Make sure the Nano receiver is plugged into an available
USB port on your computer.
Make sure the mouse has been detected properly by the
operating system. Refer to your computer documentation
for the correct port configuration.
Low battery warning. Replace the batteries as indicated
in the section “Setting up the Mouse” on page 8.
Replace both batteries at the same time. Do not mix old
and new batteries or different types of batteries.
Nano Receiver Wireless Optical Mouse 11
Specifications*
Model number PA3844 // PA3844D
Buttons Left, Right, Scroll wheel
Interface USB
Power requirements Operating: 2.7V/10 mA
Stand-by: 2.7V/0.6 mA
Sleeping: 2.7V/0.3 mA
Dimensions
(D x W x H)
97 x 58 x 35 mm
(3.8 x 2.3 x 1.4 inches)
Weight 65 g (2.3 ounces)
Wave length 625–646 nm
15 inches/sec
8 G
Acceleration
1200/1600 dpi
2.4 GHz (2.402–2.480 GHz)
0 dBm
3000 times/sec
Velocity
Acceleration
Optical sensor
Resolution
Frequency band
(Change DPI- Push Mid key +
Right Key 2 seconds)
RF output power
8 m (open space 10 m)
0%–90% (50 ± 2°C)
0–40°C (32–104°F)
RF distance
Operating humidity
Operating temperature
* Specifications are subject to change without further notice.
-20–60°C (-4–140°F)
Storage temperature
12 Bluetooth Wireless Laser Mouse
Federal Communication Commission Interference Statement
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Consult the dealer or an experienced radio/TV technician for help.
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate
this equipment.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. End users must follow the specific operating
instructions for satisfying RF exposure compliance.
This transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.
Low battery
Flashing red
LED will flash for 5 seconds when user wake up mouse every time.
DPI change
Push mid key and right button at the same time for two seconds then
DPI will change automatically.
2.4GWireless Optical Mouse / PA3844
Nano receiver / PA3844D
7
9
IndustryCanadastatement:
This device complies with RSS-210 of the Industry Canada Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
IMPORTANT NOTE:
Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth
for an uncontrolled environment. This equipment should be
installed and operated with minimum distance 20cmbetween the
radiator & your body.

Navigation menu
