User manual

Product Overview

In order to make sure you get the best possible results from your

new Speaker Mojo II, please thoroughly read and carefully follow

all instructions in this User’s Manual or on the product. Keep this

User’s Manual in a convenient location for future reference.

Package Contents:

Speaker Mojo II x 1

Power cradle x 1

Power adapter x 1

Micro USB charging cable x 1

Aux cable x 1

User’s Manual x 1

If any of the above contents were missing or damaged, please

visit bemwireless.com/support/ to obtain a replacement.

Please do not return to Club, please call 855-839-8616 if you have

any questions or issues with the Speaker Mojo II.

Compatibility

All devices enabled with Bluetooth technology, including iPhones,

iPads, iPods, smartphones, laptops, tablets and more.

Also compatible with any device that has a standard 3.5mm

earphone jack such as MP3 players, PSP, mobile phones, etc.

Meet the Speaker Mojo II

Before learning about your Speaker Mojo II, take a moment to

look it over and familiarize yourself with its features.

IMPORTANT : S ELECT S PEAKER MODE PR IOR TO TURN ING ON S PEAKER (S)

L R

Product Interface

1. Microphone

2. Volume +

3. Volume –

4. Play / Pause /Speak-

erphone

5. Power Cradle

6. On/ Off switch

7. Bluetooth© indicator

8. Aux in

9. Micro USB power port

10. Power indicator

Power Cradle

11. USB port

12. Power Indicator

13. Charging switch

14. Micro USB power port

Stereo Function

15. Stereo (L, M, R) Switch

Speaker Mojo II

Important: Select Speaker mode prIor to turnIng on Speaker(S)

Charging Modes

1. Direct Speaker Charge

Connect the standard USB end of the

supplied USB cable to a USB power source

(PC, USB power adapter…etc.). Connect

the Micro USB jack to the USB charging

port on the Speaker Mojo II. It will take

about 2 hours to fully charge the Speaker

Mojo II alone.

Charging Indicator Light Modes

Power indicator on Speaker Mojo II

• Red LED: Speaker Mojo II is charging;

• No LED: Battery is fully charged

• Note: When the battery is low, you will hear a tone signaling

you to charge the unit soon

2. Power Cradle Charge

The Power cradle is a backup battery pack

for Speaker Mojo II and your Bluetooth

device. Connect the standard USB end of the

supplied USB cable to a USB power source

(PC, USB power adapter…etc.). Connect the

Micro USB jack to the USB charging port on

the power cradle. The charging indicator will

light up while charging. It will take about 3 hours to fully charge

the power cradle.

Important: Select Speaker mode prIor to turnIng on Speaker(S)

Indicator on power cradle

• Red LED : Charging, it will go off when it is fully charged;

• Blue LED : power output is on.

3. Wireless Conductive Charging via Power Cradle

Connect the standard USB end of the

supplied USB cable to a USB power

source (PC, USB power adapter…

etc.). Connect the Micro USB jack

to the USB charging port on the

power cradle. The charging indicator

will light up while charging. If you

put Speaker Mojo II onto the power

cradle, it will charge them both at the

same time whether you connect the power to the Speaker Mojo

II or power cradle. It will take about 5 hours for charging them at

the same time. Once both are fully charged, the battery life of the

Speaker Mojo II can be doubled. This can be done by turning on

the power cradle, placing the Speaker Mojo II on the cradle and

turning it on while playing music.

Please note, the Speaker Mojo II LED charging indicator will not

light up when the speaker is charging on the Power Cradle

Charging Modes (Cont.)

Important: Select Speaker mode prIor to turnIng on Speaker(S)

4. Charging Other USB Enabled Devices via Power Cradle

The included Power Cradle can

also be used to charge other USB

enabled devices. Simply follow the

steps listed in number 2 to charge

up the Power Cradle. You can now

take the power cradle with you on

the go to charge various other smart

devices via USB. You can do so by

connecting the standard USB end

of a USB cable to the USB port in the back of the Power Cradle.

Then plug the other end into your smart device.

Slide the power switch to “on” to turn it on and begin charging

other smart devices. The blue indicator light will light up to signify

the unit is on.Slide the power switch to “off” to turn off the power

cradle. The blue indicator light will go out and your smart devices

will no longer charge via USB.

Speaker Selection (Mode)

Important: Before you go to turn on the Speaker Mojo II please

stop and read these instructions carefully.

The Speaker Mojo II can be played in a couple of different ways.

Mono mode will allow you to work with just one speaker or stereo

mode which allows you to pair up two speakers.

Charging Modes (Cont.)

Play Modes

Important: Select Speaker mode prIor to turnIng on Speaker(S)

Playing in Mono Mode: Make sure the

switch on the bottom of the speaker

is switched to “M” before turning on

the speaker

Playing in Stereo Mode: One

speaker must be switched to “L”

on the bottom and the other must

be switched to “R” before turning

them on.

Power on / Power off

Slide the power switch to “on” to

turn on the Speaker Mojo II. The

Bluetooth indicator will light up blue to signify the unit is on and

ready to be paired.

Slide the power switch to “off” to turn off the unit

and the Bluetooth indicator light will go out.

Play Modes (Cont.)

L R

Important: Select Speaker mode prIor to turnIng on Speaker(S)

Single Speaker

• Bluetooth mode: Play an audio

signal from the connected

Bluetooth device. Before turning

the Speaker Mojo II on, turn the

speaker over so that the bottom

of the speaker is facing up. Locate

the stereo switch (L,M,R) on the speaker and make sure that

it is set to the “M” or mono setting.

• Now turn on the Speaker Mojo II. Once the Speaker Mojo II

has entered Bluetooth mode, the Bluetooth icon will light

up blue and the tone conrming that the unit is currently in

Bluetooth pairing mode will sound.

• Go to the Bluetooth settings on your smart device to nd

the device named “Mojo II”. A tone will sound to conrm the

device has paired successfully. Next time the Speaker Mojo II

and connected device will pair automatically.

Please note: Mojo II will not show up as an available device

unless you have set the stereo switch to “M”. Your device

must be within 40 feet of the speaker while in bluetooth

mode.

• Direct Connection Mode (Aux In): To play music via direct

connection simply insert the included Aux cable into the Aux

in port on the back of the Speaker. Direct connection mode is

not supported in Stereo Mode.

Play Modes (Cont.)

L R

Important: Select Speaker mode prIor to turnIng on Speaker(S)

Play Modes (Cont.)

• Please Note: If an Aux cable is connected to the speaker it will

not play music from Bluetooth© connected devices.

Stereo Speaker Mode (Two Speakers)

• Bluetooth mode: The Speaker Mojo II has

the ability to be connected together with

another Speaker Mojo II to enter into stereo

speaker mode. To enter into stereo speaker

mode, begin by selecting either one of the

Speaker Mojo II speakers and slide the stereo

switch on the bottom of the speaker to “L”

which stands for left.

• Take the other speaker and slide the stereo

switch to “R” which stands for right. Now

turn on the speakers and they will auto pair

to each other within 10 seconds of being

turned on.

• Go to the Bluetooth settings on your smart

device to nd the device named “Mojo II”.

A tone will sound to conrm the device has

paired successfully. Next time the Speaker

Mojo II and connected device will pair

automatically.

L R

Important: Select Speaker mode prIor to turnIng on Speaker(S)

• Note: If you are in Stereo Mode and the “R-speaker”

disconnects due to being too far apart, the music playing on

the “L-speaker” will pause. In stereo mode the speakers can

be no more than 20 feet apart from each other.Once you are

back in the above range of operation for the two speakers,

they will reconnect by themselves automatically .When paired

successfully again, there will be indication sound signaling a

reconnection, and the two speakers will begin playing music

within 3 seconds.

• Direct Connection Mode (Aux In): Direct connection via

Aux In is not supported in Stereo Speaker mode. Please

refer to the “Direct Connection Mode” section on Page 8 for

information on how to connect to a single speaker.

Play Modes (Cont.)

Important: Select Speaker mode prIor to turnIng on Speaker(S)

Press the Play/Pause button to play or pause the music when

using a music player through your Bluetooth© connected device.

Pressing the + and - buttons will increase or decrease the volume

on the Speaker Mojo II. Please note that this will not affect the

volume levels on the connected device. When the volume level on

the speaker has reached capacity you will hear a tone. In stereo

mode either speaker can be used to control volume level and

play/pause.

Connection

Laptop / Notebook / PC

As the Bluetooth© versions for these types of devices varies

greatly, the connection methods will differ as well. If you

can not connect with the Speaker Mojo II using the previous

method instructed you may need to install a new version of the

Bluetooth© driver.

Please reference the instructions of device for details.

Audio Use

Follow the connection steps to pair a Bluetooth© device with

the Speaker Mojo II. At this point you can send any kind of audio

signal to your speaker (music, video, gaming, etc.). Just use your

device as normal and the audio will play through your Speaker

Mojo II.

Controls

Operation Details

Important: Select Speaker mode prIor to turnIng on Speaker(S)

Operation Details (cont.)

Speaker Phone

After pairing your mobile phone to Speaker Mojo II with

Bluetooth, the speaker phone function can be used.

• Making a call: Call will automatically transfer to the

speakerphone. If not, tap play/pause button;

• Answering a call: Tap play/pause button to answer the

incoming call;

• Ending a call : Tap play/pause button during the call to

end the call;

• Rejecting a call : Hold play/pause button to reject the

incoming call;

• Redial last number: Double tap play/pause button to redial

the last number when it is not in a call.

If you are using the speaker phone function in Stereo Speaker

Mode, please note that the call will come through the “L”

speaker. The volume and microphone functions will only work on

the “L” speaker.

Important: Select Speaker mode prIor to turnIng on Speaker(S)

Troubleshooting

Issue: Pairing is unsuccessfully after multiple attempts

Solution:

• Check if the Bluetooth indicator light is on. If the indicator

light is off, please press the power button to turn the unit

on. If the Bluetooth indicator light still doesn’t come on after

pressing the power button, please charge the unit.

• Check for other Bluetooth devices around the surroundings

that may interfere with searching and turn devices off.

• If pairing in single “Mono Mode” make sure the switch on the

bottom of the speaker is sitting on “M”.

• Power off and then power on the unit to restart the Bluetooth

Unplug any cables plugged into the AUX IN, restart all

devices and then attempt pairing again.

Issue: Pairing in Stereo Mode is unsuccessfully after multiple

attempts

Solution:

• First check to see that one speaker is switched to “L” on

the bottom, and the other is switched to “R”. Turn off the

speakers then turn them back on.

• Check to make sure that all cables are unplugged from the

AUX IN port.

• If you would like to enter into “Stereo Mode” from “Mono

Mode” you will need to turn off both speakers. Then select

one of the speakers to be the “L” speaker and one to be the

Important: Select Speaker mode prIor to turnIng on Speaker(S)

Maintenance

Please follow the instructions below for cleaning your

Speaker Mojo II

• Power off the unit and unplug the power adapter from

wall outlet

• Use a soft, dry, lint-free cloth and wipe gently

• Do not use alcohol, benzene, thinners or other chemical

detergents as these can cause the casing to be warped

or discolored

For questions, comments or to purchase more be¯m wireless

products go to bemwireless.com

“R” speaker by sliding the switch on the bottom of each

speaker.

• Be sure to make your mode selection (Mono or Stereo) while

the speakers are powered off. Then turn them on.

Issue: Interference or static during playback

Solution:

• Avoid using the device between concrete or other building

structures that may interfere with the signal.

• Please check if the battery level of the unit and the

For more troubleshooting help go to http://bemwireless.com

Troubleshooting (cont.)

Important: Select Speaker mode prIor to turnIng on Speaker(S)

More Info

For questions, comments or to purchase more be¯m wireless

products go to: bemwireless.com

You can also follow us at:

facebook.com/bemwireless

twitter.com/bemwirelessco

youtube.com/bemwireless

For information on your product’s warranty go to:

bemwireless.com/support

Storage

• Power off the Speaker Mojo II If the unit will not be used for

an extended period of time.

• Do not set the unit in a damp environment, high temperatures

or in direct sunlight.

Important: Select Speaker mode prIor to turnIng on Speaker(S)

FCC Radiation Exposure Statement

This equipment complies with FCC radiation exposure limits set forth for an

uncontrolled environment. This equipment should be installed and operated

with minimum distance 20cm between the radiator & your body.

FCC Statement

1. This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions:

• This device may not cause harmful interference.

• This device must accept any interference received,

including interference that may cause undesired

operation.

&KDQJHVRUPRGL´FDWLRQVQRWH[SUHVVO\DSSURYHGE\WKHSDUW\UHVSRQVLEOH

for compliance could void the user’s authority to operate the equipment.

NOTE: This equipment has been tested and found to comply with the limits for

a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a

residential installation.

This equipment generates uses and can radiate radio frequency energy and, if

not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to try

to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help

IMPORTANT: SELECT SPEAKER MODE PRIOR TO TURNING ON SPEAKER(S)

IMPORTANT : S ELECT S PEAKER MODE PR IOR TO TURN ING ON S PEAKER (S)

IC Caution.

- English:

This device complies with Industry Canada licence-exempt RSS standard(s).

Operation is subject to the following two conditions: (1) This device may not cause

interference, and (2) This device must accept any interference, including interference

that may cause undesired operation of the device.

This equipment should be installed and operated with a minumum distance of 20 cm

between the radiator and your body.

- French:

Le present appareil est conforme aux CNR d'Industrie Canada applicables aux appareils

radio exempts de licence. L'exploitation estautorisée aux deux conditions suivantes:

(1) l'appareil ne doit pas produire de brouillage, et

(2) l'utilisateur de l'appareildoit accepter tout brouillageradioélectrique subi, mêmesi le

brouillage est susceptible d'en compromettre le fonctionnement.

Cet équipement doit être installé et utilisé à une distance minimale de 20 cm entre le

radiateur et votre corps.

Product Name : Speaker Mojo II

Model Number : HL2750

Power Supply: 5V,1A

Output Power: 1.5W X 2

USB charging output: 5V,1A x 1

Working Range: Approximately 40ft, 12m

Working atmosphere: 0˚C-40˚C / 20%-90%RH

be¯m wireless

http://bemwireless.com/

be¯m wireless LLC.

1725 Kilkenny Ct.

Woodstock, IL. USA

Made in China

IMPORTANT : S ELECT S PEAKER MODE PR IOR TO TURN ING ON S PEAKER (S)

Safety Instructions

This product is specially designed based on the full attention to

safety; in order to make sure the accident-free operation, please

abide the guidelines listed below:

• Always position the unit on a stable and level

surface. Unstable surface can cause the unit to topple and

fall, resulting in possible damage or injury

• Do not drop, unpack, open, beat, curve, prink and

burn the unit

• Avoid using the unit nearby basins or sinks where

it may come in contact with water

• Do not place any ware with full water on the top

of the unit, such as vase, glass, pot, and please avoid placing candle on

the speaker surface as well

• Protect the using of the unit from any overheating devices (such as

radiator, heating installation, cooking stove or other heating devices

• Regardless of what reasons cause the unit damage, please ask for the

maintenance personnel to repair

• If you want to do the cleaning, please turn off the unit and unplug the

• Set the volume properly to prevent injury to the unit and your personal

health.

IMPORTANT : S ELECT S PEAKER MODE PR IOR TO TURN ING ON S PEAKER (S)

Safety Instructions (cont.)

Correct Disposal of this product. This marking indicates that this product

should not be disposed with other household wastes throughout the EU. To

prevent possible harm to the environment or human health from uncontrolled

waste disposal, recycle it responsibly to promote the sustainable reuse of

material resources. To return your used device, please use the return and

collection systems or contact the retailer where the product was purchased.

They can take this product for environmental safe recycling

WARNING:

• The battery (battery or batteries or battery pack) shall not be exposed to

•

the apparatus.

• CAUTION: Danger of explosion if battery is incorrectly replaced. Replace

only with the same or equivalent type.

IMPORTANT : S ELECT S PEAKER MODE PR IOR TO TURN ING ON S PEAKER (S)

be¯m wireless | 1725 Kilkenny Court | Woodstock IL 60098

TEL: 855-839-8616

E Core Technology HL2750 Speaker Mojo II User Manual

ECORE TECHNOLOGY COMPANY LIMITED Speaker Mojo II

User manual

Navigation menu

Namespaces

Views

Navigation
