ELITEGROUP COMPUTER SYSTEMS G610IABG Notebook with 11abg WLAN User Manual 610 E V1

Elitegroup Computer Systems Co., Ltd Notebook with 11abg WLAN 610 E V1

Contents

Manual Pt1

i
G610
i
Preface
Copyright 2005
All Rights Reserved.
The information in this document is subject to change without prior
notice in order to improve reliability, design and function and does not
represent a commitment on the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special,
incidental, or consequential damages arising out of the use or inability to
use the product or documentation, even if advised of the possibility of
such damages.
This document contains proprietary information protected by copyright.
All rights are reserved. No part of this manual may be reproduced by any
mechanical, electronic, or other means in any form without prior written
permission of the manufacturer.
Trademarks
AutoCAD and Autoshade are trademarks of Autodesk, Inc. IBM, OS/2,
and VGA are trademarks of International Business Machines Corp. Lotus,
1-2-3, and Symphony are trademarks of Lotus Development Corp.
Windows, Word, MS-DOS, and Microsoft are trademarks of Microsoft
Corp. VESA is a trademark of Video Electronics Standards Association.
Other product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of
their respective companies.
Limitation of Liability
While reasonable efforts have been made to ensure the accuracy of this
manual, the manufacturer and distributor assume no liability resulting
from errors or omissions in this manual, or from the use of the
information contained herein.
ii
Notices
Federal Communications Commission Radio Frequency
Interference Statement
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate
radio frequency energy and if not installed and used in accordance with
the instruction manual may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected
• Consult the dealer or an experienced radio TV technician for help
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate
this equipment.
IMPORTANT NOTE: FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated
with minimum distance 20cm between the radiator & your body. To
maintain compliance with FCC RF exposure compliance requirements,
please avoid direct contact to the transmitting antenna during transmitting.
If this device is going to be operated in 5.15 ~ 5.25GHz frequency range,
then it is restricted in indoor environment only.
This transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.
ECS declares that the G610 (FCC ID: SA6G610IABG) is limited in
2412~2462MHz by specified firmware controlled in the USA.
iii
EC DECLARATION OF CONFORMITY (EUROPE)
Hereby, Elitegroup, declares that this product is in compliance with the
essential requirements and other relevant provisions of Directive 1999/5/EC
as listed below
Article 3.1(a): EN 60950, EN50371
Article 3.1(b): EN 301 489-1, EN 301 489-17
Article 3.2: EN 300 328, EN 301 893
0976
Caution:
This equipment is intended to be used in all EU and EFTA countries. Outdoor
use may be restricted to certain frequencies and/or may require a license
for operation. Contact local Authority for procedure to follow. Note:
Combinations of power levels and antennas resulting in a radiated power
level of above 100 mW equivalent isotropic radiated power (EIRP) are
considered as not compliant with the above mentioned directive and are
not allowed for use within the European community and countries that have
adopted the European R&TTE directive 1999/5/EC.
List of national restrictions:
Bulgaria: General authorization required for outdoor use and public service.
France: Outdoor use limited to 10 mW e.i.r.p. within the band 2454-2483.5
MHz.
Italy: If used outside of own premises, general authorization is required .
Luxembourg: General authorization required for public service.
Rumania: On a secondary basis. Individual license required. T/R 22-06 not
implemented.
EUROPE – RESTRICTIONS FOR USE OF 5GHZ
FREQUENCIES IN EUROPEAN COMMUNITY COUNTRIES
Allowed
Frequency
Bands
Allowed Channel
Numbers Countries
5.15-5.25GHz
36, 40, 44, 48 Austria
5.15-5.35GHz
36, 40, 44, 48, 52,
56, 60, 64 Cyprus, Czech Republic, France,
Hungary, Slovakia
iv
5.15-5.35 &
5.470-
5.725GH z
36, 40, 44, 48, 52,
56, 60, 64, 100, 104,
108, 112, 116, 120,
124, 128, 132, 136,
140
Belgium, Bulgaria, Denmark,
Estonia, Finland, Germany,
Greece, Iceland, Ireland, Italy,
Latvia, Liechtenstein, Lithuania,
Luxembourg, Malta,
Netherlands, Norway, Poland,
Portugal, Slovenia, Spain,
Sweden, Switzerland, U.K.
• This device may not be operated outdoors when using the bands
5150-5350MHz (Channels 36, 40, 44, 48, 52, 56, 50, 64).
• In Italy the end-user must apply for a license from the national
spectrum authority to operate this device outdoors.
• To remain in conformance with European spectrum usage laws for
Wireless LAN operation, the above 5GHz channel limitations apply.
The user should check the current channel of operation. If operation
is occurring outside of the allowable frequencies as listed above, the
user must cease operating at that location and consult the local
technical support staff responsible for the wireless network.
• The 5GHz Turbo mode feature is not allowed for operation in any
European Community country
• This device must not be operated in ad-hoc mode using channels in
the 5GHz bands in the European Community. Ad-hoc mode provides
a direct communication between two client devices without a
Wireless LAN Access Point.
• This device must be used with Access Points that have employed and
activated a radar detection feature required for European
Community operation in the 5GHz bands. This device will operate
under the control of the Access Point in order to avoid operating on a
channel occupied by any radar system in the area. The presence of
nearby radar operation may result in temporary interruption in
communications of this device. The Access Point’s radar detection
feature will automatically restart operation on a channel free of radar.
You may consult with the local technical support staff responsible for
the wireless network to ensure the Access Point device(s) are properly
configured for European Community operation.
v
Notice:
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
Shielded interface cables and a non-shielded AC power cord must be used
in order to comply with emission limits.
This equipment is to be used with power supply:
I/P: 100-240V AC, 50-60Hz, 1.5A
O/P: 19V DC, 4.74A, 90W
There is no internal power supply.
vi
Table of Content
Before you Start------------------------------------------------------------ 1
Conventions of This Manual......................................................................1
Safety Precautions .......................................................................................1
Wichtige Sicherheitshinweise....................................................................3
Things you must remember before working on your computer............6
Introduction ----------------------------------------------------------------- 9
Welcome to the Notebook PC ...................................................................9
Unpacking the Notebook............................................................................9
Getting to Know Your Computer..............................................................10
Getting Started ------------------------------------------------------------- 19
Connecting to a Power Source...................................................................19
Turning On Your Notebook Computer.....................................................20
Inserting and Removing the Battery Pack................................................21
Charging the Battery Pack.........................................................................22
Using the Notebook Computer----------------------------------------- 23
Adjusting the LCD Screen Display...........................................................23
The TouchPad..............................................................................................25
Data Storage and Retrieval ........................................................................26
PCMCIA Cards and Expansion Sockets ..................................................27
Power Saving Modes ..................................................................................27
Resetting the System...................................................................................30
Using the Windows .....................................................................................30
Desktop Operation -------------------------------------------------------- 35
Audio.............................................................................................................35
Connecting Peripheral Devices .................................................................36
Internet Connection------------------------------------------------------- 39
Using Both DHCP and Static IP for Connection to Internet.................42
Using Wireless LAN Network for Connection to Internet (Microsoft’s
Service Pack 2) (Optional).........................................................................44
Configuring and Maintaining your System------------------------- 45
Introduction..................................................................................................45
Microsoft Center Edition (MCE) (Option)--------------------------- 53
Windows XP Media Center Edition (MCE) ............................................53
MCE Application Sound Adjustment .......................................................54
Playing Live TV on an MCE .....................................................................56
vii
VGA Utilities----------------------------------------------------------------- 59
Intel Graphics...............................................................................................59
ATI Graphics................................................................................................67
Viewing Live Video (Option) -------------------------------------------- 75
Using the Remote Control..........................................................................76
WinDVR Mode ............................................................................................76
Application buttons in DVR mode............................................................78
Application buttons in DVD mode ...........................................................80
Application buttons in Music mode ..........................................................82
Video Conferencing (Option) ------------------------------------------- 83
Application...................................................................................................83
Troubleshooting------------------------------------------------------------ 89
Locating a Problem.....................................................................................89
Checking Cables and Connections............................................................89
The Power-On Self Test .............................................................................90
General Hardware Problems ......................................................................91
Contacting Your Dealer..............................................................................93
How do I Expand my Notebook --------------------------------------- 95
Upgrading your Memory............................................................................96
Easy to Upgrade HDD Module..................................................................97
Specification ---------------------------------------------------------------- 99
Detailed Notebook Specifications.............................................................99
viii
Canadian DOC Notice For Class B Computing Devices
This Class B digital apparatus meets all requirements of the Canadian
Interference - Causing Equipment Regulations.
Cet appareil numerique de la classe B repecte toutes les exigences du
Règlement sur le matèriel brouilleur du Canada.
Personal Inventory
This Notebook computer system is designed for years of productive and
pleasurable computing. Use this section to keep notes about details of
your purchase. Update this section when you add new options.
Date of Purchase:
Dealer’s Name:
Phone:
Address:
E-Mail Address:
WWW Site:
Serial Number:
CPU Type:
Hard Disk Capacity:
Memory Capacity:
Optional Equipment:
1
BEFORE YOU START
Conventions of This Manual
Use this manual will help you get the most from your notebook computer.
• If you are an experienced user of computers and/or
Microsoft’s Windows operating systems, you might find it
useful to read the Quick Start Guide that comes along with
your accessories.
• If you are a less experienced user, you should through the
manual carefully before using your system.
Whether or not you are an experienced user, you should consult on the
Troubleshooting Chapter if you encounter any problems with your
notebook.
Safety Precautions
This section is designed to assist you in identifying potentially unsafe
conditions while working with this product. Required safety features have
been installed in the computer to protect you from injury. However, you
should use good judgment to identify potential safety hazards:
1. Please read these safety instructions carefully.
2. Please keep this User's Manual for later reference.
3. Please disconnect this equipment from AC outlet before cleaning.
Don't use liquid or sprayed detergent for cleaning. Use moisture
sheet or cloth for cleaning.
4. For pluggable equipment, that the socket-outlet shall be installed
near the equipment and shall be easily accessible.
5. Please keep this equipment from humidity.
6. Lay this equipment on a reliable surface when installed. A drop or
fall could cause injury.
7. Make sure to use the right voltage for the power source when
connecting the equipment to the power outlet.
2
8. Place the power cord in such a way that people can not step on it.
Do not place anything on top of the power cord.
9. All cautions and warnings on the equipment should be noted.
10. If the equipment is not use for a long time, disconnect the equipment
from the main power outlet to avoid being damaged by transient
overvoltage.
11. Never pour any liquid into the opening, this could cause fire or
electrical shock.
12. Never open the equipment. For safety reason, the equipment should
only be opened by a qualified service personnel.
13. If on the following situations arises, get the equipment checked by a
service personnel:
a. The Power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d. The equipment has not worked well or you cannot get it work
according to the user's manual.
e. The equipment has dropped and damaged.
f. If the equipment has obvious sign of breakage.
14. Do not leave this equipment in an environment unconditioned,
storage temperature above 60°C (140°f), it may damage the
equipment.
15. The unit can be operated at an ambient temperature of max. 35°C.
16. The sound pressure level at the operators position according to IEC
704-1: 1982 is equal or less than 70 dB(A).
17. Power Cord Requirements
The power cord set used with the AC adaptor must meet the
requirements of the country where you use the AC adaptor, whether
it is 100-120 or 200-240 Vac. The following information explains
the requirements for power cord set selection.
Ø The cord set must be approved for the country in which it is
used.
Ø The appliance coupler must have a configuration for mating
with a CEE22/EN6032/IEC 320 appliance inlet.
A. For U.S. and Canada:
Ø The cord set must be UL Listed and CSA Certified.
Ø The minimum specifications for the flexible cord are No.
18 AWG.
B. For Japan:
3
Ø All components of the cord set must bear a “PSE” or “ T ”
mark and registration number in accordance with the
Japanese Dentori Law.
Ø The minimum specifications for the flexible cord are .75m
㎡ conductors.
C. For Other Countries:
Ø The cord set fittings must bear the certification mark of the
agency responsible for evaluation in a specific country.
Ø The flexible cord must be of a HAR (harmonized) type
H05VV-F.
Ø The cord set must have a current capacity of a least 2.5
Amperes and voltage rating of 125 or 250 Vac.
18. When using your telephone equipment, basic safety precautions
should always be followed to reduce the risk of fire, electric shock
and injury to persons. These precautions includes the following:
• Do not use this product near water, for example, near a
bathtub, washbowl, kitchen sink or laundry tub, in a wet
basement or near a swimming pool.
• Avoid using a telephone (other than a cordless type)
during an electrical storm. There may be a remote risk of
electric shock from lightning.
• Do not use the telephone to report a gas leak in the
vicinity of the leak.
• Use only the power cord indicated in this manual.
19. Do not use the AC adapter near open water or other liquids. Never
spill liquid into the AC adapter.
20. Laser Warning: Laser Class I Product Caution - Invisible laser
radiation when open avoid exposure to beam.
21. Danger of explosion if battery is incorrectly replaced. Replace only
with the same or equivalent type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer's
instructions. Never remove the battery pack while the power is on as
this may result in data loss when the system loses power.
22. The input receptacle is used as the main disconnecting device.
Wichtige Sicherheitshinweise
1. Bitte lesen Sie diese Hinweis sorgfältig durch.
2. Heben Sie dirse Anleitung für den späteren Gebrauch auf.
3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen.
Versenden Sie Keine Flüssig- oder Aerosolreiniger. Am besten
4
eignet sich ein angefeuchtetes Tuch zur Reinigung.
4. Die Netzanschlußsteckdose soll nahe dem Gerät angebracht und
leicht zugänglich sein.
5. Das Gerät ist vor Feuchtigkeit zu schützen.
6. Bei der Aufstellung des Gerätes ist auf sicheren Stand zu achten.
Ein Kippen oder Fallen könnte Beschädigungen hervorrufen.
7. Beachten Sie beim Anschluß an das Stromnet die Anschlußwerte.
8. Verlegen Sie die Netzanschlußleitung so, daß niemand darüber fallen
kann. Es sollte auch nichts auf der Leitun abgestellt werden.
9. Alle Hinweise und Warnungen, die sich am Gerät befinden, sind zu
beachten.
10. Wird das Gerät üeinen längeren Zeitraum nicht benutzt, sollten Sie
es vom Stromnetz trennen. Somit wird im Falle einer Überspannung
eine Beschädigung vermieden.
11. Durch die Lüftungsöffnungen dürfen niemals Gegenstände oder
Flüssigkeien in das Gerät gelangen. Dies könne einen Brand bzw.
Elektrischen Schlag auslösen.
12. Öffnen Sie niemals das Gerät. Das Gerät darf aus Gründen der
elektrischen Sicherheit nur von authorisiertem Servicepersonal
geöffnet werden.
13. Wenn folgende Situationen auftreten ist das Gerät vom Stromnetz zu
trennen und von einer qualifizierten Servicestelle zu Überprüfung.:
a. Netzlabel oder Netzstecker sind beschädigt.
b. Flüssigkeit ist in das Gerät eingedrungen.
c. Das Gerät war Feuchtigkeit ausgesetzt.
d. Wenn das Gerät nicht der Bedienungsanleitung entsprechend
funktioniert oder Sie mit Hilfe dieser Anleitung keine
Verbesserung erzielen.
e. Das Gerät ist gefallen und/oder das Gehäuse ist beschädigt.
f. Wenn das Gerät deutliche Anzeichen eines Defektes aufweist.
14. VORSICHT: Explosiongsgetahr bei unsachgemäßen Austausch der
Batterie. Ersatz nur durch denselben oder einem vom Hersteller
empfohlenem ähnlichen Typ. Entsorgung gebrauchter Batterien
nach Angaben des Herstellers.
15. Dieses Schaltnetzteil kann bis zu einer Außentemperatur von
maximal 35ºC.
16. Die Ausgangswerte dürfen nicht die auf dem Label angegebenen
Werte überschreiten.
17. Anforderungen an das Stromkabel
Das Kabel-Set, das an das Netzteil angeschlossen wird, muss den
5
Anforderungen des Landes, in dem Sie das Netzteil einsetzen,
genügen, je nachdem, ob die Netzspannung 100-120 oder 200-240V
Wechselspannung beträgt.
Ø Das Kabel-Set muss für das Land, in dem es eingesetzt
wird, zugelassen sein.
Ø Der Gerätestecker des Kabels muss in eine CEE22/ EN603/
IEC 320 Buchse passen.
A. Für die USA und Kanada:
Ø Das Kabel-Set muss UL-gelistet und CSA zertifiziert sein.
Ø Die Minimalanforderungen für das Kabel entsprechen No.
18 AWG.
B. Für Japan:
Ø Alle Teile des Kabel-Sets müssen entsprechend dem
japanischen Dentori Law mit einem „PSE“ or „T”-Symbol
markiert sein
Ø Die Minimalanforderungen für das Kabel sind .75m ㎡
Leiter.
C. Für andere Länder:
Ø Die Zubehörteile des Kabel-Sets müssen das Prüfsiegel
derjenigen Stelle, die in dem jeweiligen Land für die
Sicherheitsprüfung zuständig ist, tragen.
Ø Das Kabel muss vom HAR (harmonisierten) Typ H05VV-F
sein.
Ø Das Kabel-Set muss eine Stromkapazität von mindestens
2,5 Ampere haben und Spannungen von 125 oder 250 V
Wechselstrom gestatten.
18. Bei der Benutzung Ihres Telefongerätes sollten Sie immer die
grundlegenden Sicherheitsmaßnahmen beachten, um das Risiko von
Feuer, Stromschlägen und Verletzungen zu minimieren. Zu beachten
sind u.a. folgende Punkte:
• Benutzen Sie das Gerät nicht in der Nähe von Wasser,
wie zum Beispiel Badewanne, Waschbecken, Spülbecken,
Waschbottich, in feuchten Kellerräumen oder in der Nähe
von Schwimmbecken.
• Benutzen Sie kein Telefon (ausgenommen schnurlose
Modelle) während eines Gewitters. Es besteht das
geringe Restrisiko eines Blitzschlages.
• Benutzen Sie das Telefon nicht um ein Gasleck zu
melden, falls es sich in der Nähe des Lecks befindet.
6
• Benutzen Sie nur solch ein Stromkabel, wie in dieser
Anleitung beschrieben.
19. Benutzen Sie das Netzteil nicht in unmittelbarer Nähe zu Wasser
oder anderen Flüssigkeiten. Gießen Sie nie Flüssigkeiten über das
Netzteil.
20. Achtung Laser: Laser Produkt der Klasse I. Achtung - Unsichtbarer
Laserstrahl, vermeiden Sie Kontakt mit dem Strahl bei offenem
Gehäuse.
21. Es besteht Explosionsgefahr, wenn der Akku nicht ordnungsgemäß
ersetzt wird. Ersetzen Sie den Akku nur durch einen Akku gleichen
oder äquivalenten Typs, der vom Hersteller empfohlen wird.
Entsorgen Sie Akkus entsprechend den Anweisungen des Herstellers.
Entfernen Sie den Akku auf keinen Fall bei eingeschaltetem
Notebook, da hierdurch Daten verloren gehen könnten.
22. Der Netzeingabeanschluss dient als Hauptschalter des Geräts.
Things you must remember before working on your
computer
Let your computer acclimate itself
Your notebook can easily stand temperature extremes but it doesn’t like
rapid changes in temperature, like going from the cold outdoors to a
warm office. Rapid changes in temperature can cause water droplets to
condense inside your case, threatening to damage the electronic parts
inside.
After receiving your notebook when it’s hot or cold outside, try not to
power up the computer immediately, let the computer adjust to the room
temperature gradually at least for three to four hours.
If your system arrives in cold weather, do not apply power to
the computer or monitor until they have been allowed to come
to room temperature.
Heat, Cold, Humidity, and Glare
Find a suitable place for your computer that’s not too hot, too cold, too
dark, or too bright. Glare can make it hard to read the screen.
7
• Try to avoid the computer components from being destroyed
if it is over heated, so try to allow plenty of room for air to
circulate around the case.
• Do not block the ventilation opening.
• Do not place your computer in direct sunlight.
Suitable place to work
Your computer will run well wherever you’re comfortable but extremes
of temperature and humidity can be challenging to your system’s parts.
There are some things you can tolerate that the computer can’t – things
like static electricity, dust, water, steam and oil. In case you decide to pull
over for roadside computing, try to choose a clean, comfortable work area
for your system.
A lithium-ion battery pack will be available when you are traveling. If
you are running your system for the first time on battery power, remove
the battery from the package, install it into the system and recharge the
battery to fully prepare for service.
8
9
INTRODUCTION
Welcome to the Notebook PC
Congratulations on your purchase of the Notebook PC. Your Notebook
features the latest advances in portable computing technology. The
Notebook’s modular design provides maximum expandability without
compromising portability. The high-performance CPU and enhanced IDE
hard drive provides you with extra processing power for handling
complex graphics and running large programs.
A premium notebook designed for successful executives who demand the
very best and featuring ultimate power, ultimate wide screen display,
ultimate AV capabilities and ultimate connectivity. A Media solution is a
combination of Windows XP software augmented by InterVideo
WinCinema – including WinDVR for watching television, WinDVD for
viewing movies and WinRIP for playing music.
Unpacking the Notebook
The Notebook comes securely packaged in a sturdy cardboard shipping
carton. Upon receiving your Notebook, open the carton and carefully
remove the contents. If anything is missing or damaged, please contact
your Notebook dealer immediately. The shipping carton should contain
the following items:
• The Notebook computer
• An AC adapter
• An AC power cord
• Software Drivers CD
Do not throw the packaging materials away. You may need them later if
you have to ship the computer for repairs.
10
Because the Notebook computer is available in
different configurations, some of the features mentioned in
this manual might not be included on your computer or may
differ slightly.
Getting to Know Your Computer
Opening the LCD Panel
To avoid damage to the display panel:
1. Try not to slam the display upon closing it.
2. Try not to place any object on top when it is closed or open.
3. Be sure the system is turned off or in suspend mode before you
close the display panel.
With the LCD screen open, you will see several features important for
operating your Notebook computer. Each of these features is briefly
described below:
11
1. Light-To-Voltage Converter Module
This computer provides a Light-to-voltage converter
module which is a sensor directly proportional to the light
intensity of your surrounding working environment. This will
affect the backlight intensity (bright/dark) of your screen
display.
Controlling the backlight intensity manually
Use the hot-key combination of Fn+F7 and Fn+F8 respectively
to decrease/increase the brightness of your LCD display. The
Light-to-voltage converter module function will be terminated
immediately after you implement these two manual adjustments
of your computer backlight intensity.
12
Controlling the backlight intensity using the Light-To-
Voltage Converter Module
To control the backlight intensity of your notebook using this
function, shut down and start your computer to implement this
function as default value in determining the backlight intensity of
your surrounding working environment.
2. LCD Display
This LCD panel can only support up to a maximum opening of
130 degrees, please do not push it forcibly.
3. System Status Indicator Panel
CardReader access Hard Disk access
NumLock mode CapsLock mode
ScrollLock mode
4. Wireless LAN Switch Button
5. TV Button (Launch the WinDVR application)
6. DVD Button (Launch the WinDVD application)
7. Internet Explorer Button
8. Outlook Express Button
9. Power/Resume Button
10. Stereo Speakers
11. Keyboard
12. The Built-in Microphone
13
13. TouchPad
14. TouchPad Buttons
15. CMOS Camera (Option)
The Front Side
LED Indicators
1. Power On
This LED will light when the system is power on.
2. Suspend
This LED will light when the system is in suspend mode.
3. Battery Charge
This LED will light when the battery is in charging mode.
14
The Left Side
1. DC IN Connector
2. The CD-ROM/DVD-ROM or DVD CD-RW Combo
3. PCMCIA
4. CardReader
Be sure the face of the card must
be
facing down when inserting it to the
cardreader slot.
5. PCMCIA Eject Button
6. 1394 Port
15
The Right Side
1. Kensington Lock
2. Ventilation Opening
3. MCE Port
4. External CRT Port
5. S-Video Port
6. Modem Port
Always disconnect all telephone lines from the wall
outlet before servicing or disassembling this equipment. To
reduce the risk of fire use only No. 26 AWG or larger
telecommunication line cord.
16
7. LAN Port
When using a LAN, please use an EMI Shielding
Cable to minimize an inteference when transmitting.
8. USB Ports
9. Audio Line Out Jack
10. ExternalMicrophone Jack
The Rear
1. Cable TV Input
Before connecting the cable into the connector, be
sure to remove first the cover on the cable TV connector at
the rear of the computer with the aid of a screw driver. One
more thing that you need to be aware of is to know the video
standard being used in your country that you are viewing.
This system supports 3 video standard namely: NTSC, PAL
and SECAM. For detailed information on the proper
connection of the cable TV, please refer to Chapter 9 on
“Viewing Live Video”.
2. USB Ports
17
The Bottom Panel
1. Expansion Compartment
2. Hard Disk
This model offers you with a “Free-Fall Detection”
function and system alarm from excessive shock to decrease
errors from process variaton and environmental stress.
18
3. Optical Drive
4. CPU Compartment
5. Battery Release Latch
6. Battery Lock
7. Battery
19
GETTING STARTED
Connecting to a Power Source
Connecting the AC Adapter
A universal AC adapter is provided to supply your computer with power
and also charge the computer’s battery pack. The adapter’s AC input
voltage can range anywhere from 100 to 240 volts, covering the standard
voltages available in almost every country.
The power cord for the AC adapter requires a three-hole grounded AC
outlet. To connect the computer to an external power source:
1. Plug the AC adapter’s connector into the DC-IN connector at the left
side of the computer.
2. Connect the power cord to the AC adapter and then to a wall outlet.
Do not use inferior extension cords as this may result in
damage to your Notebook. The Notebook comes with its own
AC adapter. Do not use a different adapter to power the
computer and other electrical devices.
20
Whenever possible, keep the AC adapter plugged into the Notebook and
an electrical outlet to recharge the battery.
Never turn off or reset your Notebook while the hard disk is in
use and the HDD status icon is lit; doing so can result in loss
or destruction of your data. Always wait at least 5 seconds
after turning off your Notebook before turning it back on;
turning the power on and off in rapid succession can damage
the Notebook’s electrical circuitry.
Turning On Your Notebook Computer
Turn on your Notebook by pressing the power button. Hold the button
down for a 1 or 2 second and release. The Power-On Self Test (POST)
runs automatically.
After the POST is completed, the computer reads the operating system
from the hard disk drive into computer memory (this is commonly
referred to as “booting” a computer). If your OS (Operating System such
as Windows XP etc) is installed, it should start automatically.
To turn the Notebook off, save your work and close all open applications,
click on Start, then select the “Turn off the computer”. A selection box
will be displayed and click on the “Turn Off” button to shut down your
computer.
When your computer hangs up, press the power
button for 4-6 seconds to shut down the computer.
Operating on Battery Power
Your computer comes with a rechargeable battery pack that lets you
operate the computer without an external power source. When the battery
pack is fully charged, you can operate the computer for approximately 2
hours under the following conditions:
• The battery pack initially has a full charge.
• No peripheral devices are installed.
• The disk/DVD-ROM drives run no more than 10% of the time.
Only use batteries that are approved by an
authorized dealer for this model only. All batteries are not the
21
same and therefore should not be treated as such. Using the
wrong battery could cause serious damage to your computer
and yourself through toxic emissions.
Inserting and Removing the Battery Pack
The battery pack should already be inserted in your Notebook computer
when you unpack it. If not inserted, follow these directions:
22
To remove the battery pack:
Charging the Battery Pack
The installed battery pack charges automatically any time the computer is
connected to the AC adapter and an external power source.
If this is your first time to use the battery, be sure to fully discharge the
battery and recharged until it is fully charged.
23
USING THE NOTEBOOK
COMPUTER
Adjusting the LCD Screen Display
The LCD screen display can be adjusted by the following key
combinations.
KEYS FUNCTIONS
[Fn] + [F7] Decreases the brightness level.
[Fn] + [F8] Increases the brightness level.
[Fn] + [F10]
Use this key combination to expand your video
screen or toggle to its original size.
[Fn] + [F12]
This key combination toggles the display between
the LCD, CRT, simultaneous LCD/CRT.
LCD Care
LCD screens are delicate devices that need careful handling. Please pay
attention to the following precautions:
• When you are not using the computer, keep the LCD screen
closed to protect it from dust.
• If you need to clean your LCD screen, use a soft tissue to
gently wipe the LCD surface.
• Do not put your fingers or sharp objects directly on the
surface and never spray cleaner directly onto the display.
• Do not press on, or store any objects on the cover when it is
closed. Doing so may cause the LCD to break.
External CRT Display
You can hook up an external monitor through the 15-pin CRT connector.
• LCD only
• CRT only
• Simultaneous display of the LCD screen and CRT monitor
24
You can switch between these display configurations by pressing the key
combination [Fn] + [F12]. For information on connecting an external
display, please refer to Chapter Four.
A Tour of the Notebook’s Keyboard
The Notebook’s keyboard uses a standard QWERTY layout with the
addition of special function keys and an embedded numeric keypad for
number intensive data entry. Your keyboard supports Windows by
incorporating the two Windows specific keys.
With the two Windows keys you will be able to access and take
advantage of many of the timesaving features of Windows software. The
function keys (F1-F12) on the top row of the keyboard, serve different
purposes and carry out different tasks depending on the application you
are running.
The cursor (arrow) keys (which are all located in the lower right corner of
your keyboard) and the [PgUp], [PgDn], [Home] and [End] keys (which
are located along the right edge of the keyboard) allow you to move the
active cursor of the computer to various locations on the screen or within
the document.
The embedded numeric keypad consists of 15 keys that make number
intensive input more convenient. Like the [Num Lock] key, these keys are
labeled in blue on the keycaps. Numeric assignments are located at the
upper right of each key.
When the numeric keypad is engaged, the NumLock icon will appear in
the System Window. The keypad is activated by pressing the [Fn] +
[NumLk] key. If an external keyboard is connected, pressing the
NumLock key on either the Notebook or external keyboard will
enable/disable NumLock of both keyboards in unison.
To disable the Notebook numeric keypad while keeping the keypad on an
external keyboard activated, use the [Fn] + [NumLk] hot key on the
Notebook keyboard.
The Notebook’s Hot Key Controls
KEYS FUNCTION(S)
Power
Button Press this button once to power on or enter
the suspend/resume mode.
Press this button for more than 4 seconds to
power off the system.
[Fn] + [F2] This key combination turns on/off the volume.
[Fn] + [F3] Decreases the speaker volume.
25
KEYS FUNCTION(S)
[Fn] + [F4] Increases the speaker volume.
[Fn] + [F5] Enable/disable Touch pad
[Fn] + [F7] Decreases the brightness level.
[Fn] + [F8] Increases the brightness level.
[Fn] + [F10] Use this key combination to expand your
video screen or reset to its original size.
[Fn] + [F12] This key combination toggles the display
between the LCD, CRT, simultaneous
LCD/CRT.
Launch Button
KEYS FUNCTION(S)
Wireless
Button Press this button to On/Off wireless function.
TV Button Press this button to open the TV function.
(Launch the InterVideo WinDVR application)
DVD Button Press this button to open the DVD player for
playing any DVD file (Launch the InterVideo
WinDVD application)
Internet
Button Open the Microsoft’s IE Internet Explorer
Email Button
Open the Microsoft’s Outlook
The TouchPad
The touchpad is a rectangular electronic panel located just below your
keyboard. You can use the static-sensitive panel of the touchpad and slit it
to move the cursor. You can use the buttons below the touchpad as left
and right mouse buttons.
26
TouchPad Precautions
The TouchPad is a pressure sensitive device. Please take note of the
following precautions.
• Make sure the TouchPad does not come into contact with dirt,
liquids or grease.
• Do not touch the TouchPad if your fingers are dirty.
• Do not rest heavy objects on the TouchPad or the TouchPad
buttons.
You can use the TouchPad with Microsoft Windows as well as non-
Windows applications.
Data Storage and Retrieval
Data storage and retrieval are two of the most fundamental tasks you will
perform when working with your computer. The Notebook is equipped
with a hard disk drive (HDD).
The HDD is removable allowing for easy upgrades.
The DVD-ROM/Combo
Features of the DVD-ROM/Combo Module
The features of the DVD-ROM/Combo drive are listed below.
• The Audio Play feature allows you to play music CDs
• Front panel load/unload button
• Supports CD-DA, DVD-ROM mode 1 and mode 2, Multi-
Session Photo CD™, CD-I/Video CD (pcs.)
• Low power consumption
• 12.7mm height
Precautions for Handling DVD-ROM/Combo Discs
• Always hold the disc by the edges, avoid touching the
surface.
• Use a clean, dry, cloth to remove dust, smudges, or
fingerprints. Wipe from the center outward.
• Do not write or place objects on the surface of the disc.
• Store discs in a cool dry place not to damage the disc.
• Do not use benzene, thinners, or cleaners with detergent.
Only use DVD-ROM cleaning kits.
• Do not bend or drop the discs.
27
PCMCIA Cards and Expansion Sockets
The Notebook features one PCMCIA expansion socket design to interface
with one Type II card.
Inserting a PCMCIA Card
The computer will emit a medium tone followed by a high tone when a
PC card is inserted. When you eject a card, the computer will emit a high
tone followed by a medium tone. You can insert and remove a PC card
whether the computer is turned On or Off.
Follow these instructions to insert a PCMCIA card:
1. Hold the PCMCIA card with the arrow side up and the connector
side toward the socket.
2. Align the card connectors with the socket and carefully slide into the
socket until it locks into place.
The system will beep once to indicate that it has detected the PC card.
To remove a PC card push the eject button, the button will pop-out, push
the button again to eject the PCMCIA.
When inserting a Type II PC card, make sure the connector is inserted in
the socket. Before ejecting a PC card, ensure that it is not being accessed
by the System.
For example, if the message “Write protect error writing Drive x” is
displayed, the user has to change the write protect switch setting on the
memory card. To change the switch setting, (a) eject the card, (b) change
the switch setting, and (c) re-insert the card.
Always disconnect all telephone lines from the wall outlet before
servicing or disassembling this equipment. To reduce the risk of fire, use
only No. 26 AWG or larger telecommunication line cord.
Power Saving Modes
This section contains information on the Notebook’s power system,
including the AC Adapter, the battery system, recharging the battery, and
tips for conserving battery power.
The power system is comprised of two parts, the AC Adapter and the
battery system. The AC Adapter converts AC power from a wall outlet to
the DC power required by the computer.
The Battery Power System
A fully charged pack will provide approximately 2 hours of battery life
depending on your system configuration application it runs. Before using
the computer on battery power for the first time, check the battery status
icon on the Windows Toolbar to make sure the battery is fully charged.
28
See Battery Status later in this section for a description and explanation of
the Windows Battery icon.
Charging the battery takes about 4 hours to charge when the system is in
off state. If possible, always charge the battery completely.
Removing the Battery Pack
To remove the battery pack from its compartment, please refer to Chapter
Three, Inserting and Removing the Battery Pack.
Preparing the Battery Pack for Use
Before using the battery pack for the first time, the Smart Battery IC
within the battery pack should be calibrated in order to get accurate
reporting of remaining battery life status.
To calibrate the battery pack follows the instructions below:
1. Insert the battery into the battery compartment and turn on the
Notebook. If the battery is completely without power go to the next
step.
Otherwise, let the battery run down until the battery low-low
warning beeps are heard.
The system will automatically enter Suspend mode.
2. Turn the Notebook off. Connect the AC adapter and let the battery
fully recharge. When the battery charge indicator turns off, the
battery is fully charged.
3. Turn On the notebook, let the battery run down until the battery is in
low-low state and you hear a warning beeps. The system will
automatically enter the Suspend mode. You can now connect the AC
adapter.
4. The battery pack is now calibrated properly.
In general, using the battery until the low-low battery-warning indicator
appears and fully recharges the battery each time (full discharge/charge
cycle) will ensure the accurate reporting of the battery gauge status.
Automatic Battery Pack Charging Function
You can automatically charge the battery pack by using the AC Adapter.
The charge time is about 4 hours when the Notebook power is turned off.
The following table summarizes the charging modes:
Charge Mode
Charge Time
Fast 4 hours with the system off or in Suspend
mode. The temperature must be 25°C or
below room temperature.
29
Pre-Charge A pre-charge is supplied to the Li-Ion
battery pack.
Battery Status
Windows XP has an applet in the Control Panel that will display an icon
in the Windows taskbar indicating when the Notebook is running on
battery power or is attached to the AC adapter.
This applet also displays a meter that indicates how much charge is
remaining in the battery.
Battery Low Warning
When the pack initially reaches the “Battery Low” state approximately 7
~ 10 minutes of the usable battery life is left.
You will hear an audible beep signal every 1.5 seconds alerting you to the
“Battery Low” status. When the battery power reaches the “Battery Low
Low” status the beeping sound will accelerate.
Your battery now has 1 ~ 2 minutes of battery charge remaining. You
must save your data or connect AC power immediately; otherwise, you
may lose your data.
Sound Meaning
Continuous
beeping every
1.5 seconds
Battery Low: Indicates that there is 7 to10
minutes charge remaining.
Beeping
accelerates Battery Low Low: Indicates that there is 1
to 2 minutes of battery charge remaining.
Save your work and turn off the Notebook,
or connect the AC adapter.
When there is only one minute of battery charge remaining, the Notebook
will enter suspend mode or hibernate according to Windows setting. You
should connect AC power and resume to save your work.
Small Battery for the Real Time Clock
There is a small built-in battery pack that supplies power to the system in
order to maintain certain system information while the power is off. If the
Notebook is left without a power source for long period of time, this
battery will be exhausted and system information will be lost.
Danger of explosion if battery is incorrectly replaced. Replace only with
the same or equivalent type recommended by the manufacturer. Dispose
of used batteries according to the manufacturer's instructions.
Never remove the battery pack while the power is on as this may result in
data loss when the system loses power.
30
Battery Calibration
The purpose for this process is to provide a long battery life for your
system battery pack.
1. Turn on the computer, when the text appears, press [Del] or the
[Delete] key until the system enters the BIOS Setup screen, you may
now make the necessary changes.
2. Press the è arrow key until it reaches the “Exit” menu screen.
Again press the ê arrow key and select the “Battery Calibration”
item.
Press the [Enter] key and disconnect the AC adapter then press the
[Y] key until you hear continuous battery low-low warning beeping
sounds. The system will be fully discharge and shutdown completely.
3. Connect the AC adapter and let the battery fully recharge. The
“Battery Charge LED” which is located at the left side of the
notebook will light indicating it is in charging status.
4. When the battery charge LED turns off will indicate the system is
fully charged.
5. Repeat step 1 to 4 once again.
6. The battery is now fully calibrated.
Resetting the System
After installing a software application package, you may be prompted to
reset the system to load the changed operating environment. To reset the
system, or “reboot,” press the [Ctrl] + [Alt] + [Delete] keys
simultaneously. This is known as “warm boot.” This key combination
acts as “software” reset switch when you encounter hardware or software
problems, which lock up the Notebook.
If this key combination does not shut down the Notebook, you can reset
the Notebook by using the Notebook’s power button. Should the
Notebook lock up for some reason, pressing this button powers the
Notebook off.
Adjusting the Brightness
To adjust the brightness on the LCD screen, press and hold down the [Fn]
key in the lower left hand corner of the keyboard and press the [F7] key
to reduce the brightness or [F8] to increase the brightness.
Using the Windows
Help Windows
For Windows XP help, click Start èHelp and Support icon will open
the dialog box.
31
Desktop
Desktop may vary differently on the software installed in your notebook
with different or additional shortcuts.
Recycle Bin
Used for storing deleted files in case you want to recover and save it in
your system. The files will only be deleted from the Recycle Bin
permanently only if you empty it by right clicking your mouse and select
the “Empty Recycle Bin”.
32
Start Button
Allows easy access to all Windows
programs.
The Start menu allows you
to adapt and show the
programs used most
frequently. If you wish to
keep an item, right click the
item and click Pin to Start
menu.
Log Off will enable the
current user to log off and
allows a new user to log on.
Turn Off Computer allows
you to shut down, restart,
and Stand by modes for
power saving purposes.
Taskbar
When you open a program, its icon is displayed at the taskbar for you to
conveniently move between programs by clicking the relevant button.
To add or remove toolbars from the taskbar: right click an empty spot on
the taskbar, select Toolbars è choose the toolbar you want to add.
Notification
The icons that appear here are for quick access to some programs and
computer functions that you frequently used. For you to see the hidden
icons, simply click the icon.
To prevent Windows XP from hiding icons:
From an empty spot on the Taskbar, right click your mouse and select
the Properties, remove the checked mark on the Hide inactive icons.
33
Control Panel
It is in this area that you can change how Windows looks and works.
Click Start è Control Panel dialog box. There are two interfaces –
Classic View or Category View.
34
35
DESKTOP OPERATION
This chapter discusses those functions of your notebook that are typical of
desktop systems.
Audio
The Multimedia Sound System
The Notebook’s built-in audio capabilities allow you to take advantage of
a wide range of education and entertainment multimedia software. The
Notebook is equipped with internal stereo speakers, a microphone, and
input audio ports for external audio units.
An external microphone can be connected to the microphone jack.
External speakers or headphones can be connected to the Notebook’s
audio-out jack. External audio devices can be connected to the Line in
jack.
Audio Volume Control
The Notebook is equipped with hot-key volume controls: Pressing the [Fn]
+ [F3] hot-key combination decreases the audio output volume; press the
[Fn] + [F4] hot-key combination increases the audio output volume.
Audio Software
Your notebook comes equipped with an integrated sound system capable
of providing you with quality audio sound through the built-in speakers or
through external speakers connected via the system ports.
Sound Recording
Your system allows you to record sounds and store them as files using the
microphone via the microphone jack on the rear of the notebook
computer. Check the Windows Help and Support Center in Windows for
information on using the various elements in sound recording.
36
For a high-quality sound, click on the "Volume Control" at the
lower right end of your screen. From the Volume Control
windows, click on the "Advanced" tab, click and select the
"Microphone Boost" item.
Playing Sound Files
Your notebook can play audio files stored in MIDI, WAVE or MP3 file
format. Check the Help and Support Center in Windows for information
on the functions of the Media Player.
External Speakers and Microphone
The sound system is capable in providing high-quality sound to external
speakers and receiving and processing sounds from an external
microphone or external sound source.
Connecting Peripheral Devices
To expand your computing capabilities, you can add a variety of external
devices to your computer.
37
38
Page intentionally left blank
39
INTERNET CONNECTION
There are numerous ways to connect to the Internet. This may vary from
the user’s working environment as well as system specifications.
• Using a modem and a telephone line
• Using a wired LAN
• Using a wireless LAN (Optional)
Using a modem for Connection to Internet
• Use a telephone line to connect to the modem port of your
computer. Do not use a digital telephone line.
• Please apply to an Internet Service Provider (ISP) for
Internet service in order for you to connect the modem to the
Internet and use e-mail.
For more detail on the Network key, please refer to your local
ISP provider and follow the procedures describe in the “ISP
Installation Guide” to proceed with the installation.
Using a wired LAN for Connection to Internet
For you connect to the Internet, a wired LAN environment normally uses
the company’s LAN or a broadband modem.
1. Use the network (LAN) cable to connect to the LAN port of the
system.
2. Select on “My Network Places” and click on the “View Network
Connection” in the “Control Panel” window.
3. In the “Network Tasks” window, use your mouse pointer to click on
the “Local Area Connection”.
40
4. Select “Properties” from the popup menu that appears
5. In the “This connection uses the following items” field, select
“Internet Protocol (TCP/IP), and click “Properties”.
41
6. Enter the system’s IP and DNS server addresses on the General tab
of the “Internet Protocol (TCP/IP) Properties” window. If DHCP is
used, click “Obtain an IP address automatically” and “Obtain DNS
server address automatically” on the General tab.
42
7. After all the all the information are correctly entered in the “Internet
Protocol (TCP/IP) Properties” window, click “OK” to finish.
Using Both DHCP and Static IP for Connection to Internet
When you are alternatively using networks with either DHCP or static IP
addressing, you can use alternative settings that enable simultaneous
configurations of DHCP and static IP to use both of the network connects
without reconfiguring.
1. Follow the steps mentioned when you are using wired LAN
connection from 1 to 7.
2. Click on the “User configured” and enter the appropriate values in
the “Alternate Configuration” tab.
43
3. When you have completed the entire configuration, click “OK”.
44
Using Wireless LAN Network for Connection to Internet
(Microsoft’s Service Pack 2) (Optional)
45
CONFIGURING AND MAINTAINING
YOUR SYSTEM
Introduction
The BIOS (Basic Input and Output System) Setup program is a menu
driven utility that enables you to make changes to the system
configuration and tailor your system to reflect installed hardware or alter
system performance. When the Notebook is turned back on, the system is
configured with the values stored in CMOS. With easy-to-use menus, you
can configure such items as:
• Hard drives and peripherals
• Boot up Drive Sequence
• Password protection
• Power Management Features
The settings made in the BIOS Setup program intimately affect how the
Notebook performs.
Navigating through BIOS Setup
The Setup program has been designed to make it as easy to use as
possible. If you accidentally make a setting and don’t know which one to
switch back to, the Setup program has a hot key that allows you to return
to the previous value.
Accessing the BIOS Setup Program
To access the BIOS Setup program, press the DEL key after the
Notebook has run through its POST.
Item Specific Help
On the right side of the Setup screen is an area labeled Item Specific Help.
This area will list navigation key shortcuts and information that is specific
for the item that you are currently editing.
46
The Menu Bar
The top of the screen has a menu bar with the following selections:
• Main - Use this menu to make changes to the basic system
configuration.
• Advanced - Use this menu to enable and make changes to
the advanced features available on your system.
• Security - Use this menu to set a password. The password
allows boot up and controls access to the BIOS setup menu.
• Boot - Use this menu to configure the default system device
used to locate and load the Operating System and for
booting up the Notebook.
• Exit - Use this menu to exit the current menu or specify how
to exit the Setup program.
To access the menu bar items, press the right or left arrow key on the
keyboard until the desired item is highlighted.
The Legend Bar
At the bottom of the Setup screen you will notice a legend bar. The keys
in the legend bar allow you to navigate through the various setup menus.
The following table lists the keys found in the legend bar with their
corresponding alternates and functions.
Legend Key
Alternate
Key Function
F1 Displays the General Help
window. It can be enabled from
anywhere in the BIOS.
Esc Jumps to the Exit menu or returns
to the Main menu from a
submenu.
← Selects the menu item to the left.
→ Selects the menu item to the
right.
↑ or ↓ arrow keys Moves the cursor up and down
between fields.
Tab Enter Moves the cursor to the next
position available in the field.
Shift + Tab Moves the cursor to previous
position available in the field.
47
Legend Key
Alternate
Key Function
Minus key (-)
Scrolls backward through the
values for the highlighted field.
Plus key (+) Scrolls forward through the values
for the highlighted field.
Home PgUp Moves the cursor to the field at
the top of the wi ndow.
End PgDn Moves the cursor to the field at
the bottom of the window.
F9 Sets the parameters for the
current menu to their default
values.
F10 Save and Exit.
Enter Will select a sub menu or show a
range of options for a field.
Launching Submenus
Note that a right pointer symbol þ appears to the left of certain fields.
This pointer indicates that a submenu can be launched from this field. A
submenu contains additional options for a field parameter. To call up a
submenu, simply move the cursor to highlight the field and press the
[Enter] key. Use the [Esc] key to return to the Main menu.
General Help
In addition to the Item Specific Help window, the BIOS Setup program
also provides a General Help screen can be called up from any menu by
simply pressing [F1].
To exit the help window, press the [Enter] or the [Esc] key.
Save Changes and Exit the Setup Program
Refer to the Exit menu section of this chapter for detailed information on
saving changes and exiting the setup program.
48
The Main Menu
When the Setup program is accessed, the following screen appears:
49
The Advanced Menu
Selecting Advanced from the menu bar displays the advanced menu:
If your system support InterVideo application, select the
“InterVideo” item from the “Shortcut Key Working With”
selection menu.
If your system supports the WinXP MCE application, select
the “WinXP MCE” item from the “Shortcut Key Working With”
selection menu.
If your system supports the CyberLink application, select the
“CyberLink” item from the “Shortcut Key Working With”
selection menu. (Optional)
50
The Security Menu
The Notebook’s advanced system of security allows you to set a
password to prevent unauthorized access to system resources, data, and
the BIOS Setup Program.
51
The Boot Menu
The Boot menu allows the user to specify the order in which the
Notebook is to check for a device to boot the system. You can also
configure the way that the system will boot up. To make changes, select
Boot from the menu bar.
The following screen appears:
Use the up and down arrows to select the boot device. Then press either
the plus key [+] to move the device up the list or the minus key [-] to
move the device down the list.
52
The Exit Menu
Once you have made all of your selections from the various menus in the
Setup program, you should save your changes and exit Setup. Select Exit
from the menu bar to display the following menu:
53
MICROSOFT CENTER EDITION
(MCE) (OPTION)
Windows XP Media Center Edition (MCE)
The Windows MCE is a complete software for home PC operating system
for you to enjoy entertainment choices together in one place easily
accessible from anywhere in the room. This will benefits the consumers
to enjoy Media Center experience in their own living room.
For more information on the function of the MCE, please refer
to the Microsoft’s Windows XP MCE user’s guide that goes
along with your software package.
54
Please be advice that when you received your computer, the
MCE port at the right side.
MCE Application Sound Adjustment
This notice only applies to those systems that only support MCE
application when you are using the Windows volume adjustment function.
From your Windows, click on the lower left corner of the screen the
speaker icon and open the Volume Control Properties Window.
If you are using MCE’s “My TV” application
• Use your mouse right button to click on the “Volume” icon
and select the “Open Volume Control” item.
• The “Volume Control” display window is displayed on your
screen.
• Click on the “Options” tab and select the “Properties” item.
55
• From the “Properties” display window, enable the “Aux” item
and click “OK”.
• The “Aux” is now added on the “Volume Control” window.
• Enable the “Mute” tab on the “Aux” item and close the
window.
If you are using InterVideo’s WinDVR application
The procedures are almost the same as those mentioned above from steps
1 to 5 to adjust the volume control. On step 6, disable the “Mute” tab on
the “Aux” item and close the window.
56
Playing Live TV on an MCE
When playing Live TV under the MCE environment please note these
important instructions.
• If when you click on “Live TV” button on your MCE
application window you get the following error message:
• You will need to install the “WinDVD” software from the
WinCinema utility driver on your support CD. After insert the
support CD into your optical disk drive, the system will
automatically run the autorun application.
• Click on the “Application” tab to display the “Multi Menu”
window.
57
• Select “InterVideo WinCinema XP MCE” from the pull-down
menu, then click the “Setup” button.
• From the “Setup” window, choose the desired software or
press the “Select All” button.
• Follow the Wizard’s on-screen instructions to complete the
installation.
• Restart the system.
58
Page intentionally left blank

Navigation menu
