The ECW5410-O is an Wave 2 indoor 802.11a/b/g/n/ac dual-band, dual-radio enterprise indoor AP with a
4x4 MU-MIMO antenna configuration.
Through its Gigabit Ethernet port the 802.11ac dual-band wireless AP can connect to the backbone network.
The ECW5410-O supports 802.3at PoE, which enables the AP to be powered remotely by a PoE switch. An
AC power adapter option is also included for locations where PoE is not available.
Product Overview
ECW5410-O
802.11ac OCP Wireless Access Point
DATASHEET
Wireless 802.11ac Technology
Using 802.11ac MIMO (Multiple Input Multiple)
wireless technology, the AP supports three
and three receiving antennas that extend range and
increase the throughput by up to nine times that of
existing Wi-Fi.
Wave 2, MU-MIMO
Support 4 clients at the same time. Also, it supports
beamforming and channel bonding(80MHz160MHz)
Advanced Traffic Management
Support for up to sixteen Virtual Access Point (VAP)
interfaces per radio, which allows traffic to be separated
for different user groups within the same service area.
Each radio can support up to 100 wireless clients,
shared between all VAPs, whereby the clients associate
with each VAP in the same way as they would with
physically separate APs. This means that each VAP
can be configured with its own Service Set Identification
(SSID), security settings, VLAN assignments, and other
parameters, allowing the AP to serve a diverse range of
client needs from a single unit.
Dual-Band Access Point
Easy on your budget and simple to install, the AP uses
dynamic rate shifting to automatically match the best
connection speed, keeping users connected to the
network even while roaming.
Key Features and Benefits
Application Diagram
TEL: 886-3-5638888 FAX: 886-3-6686111
1, Creation Rd. III, Hsinchu Science Park, Taiwan 30077
sales_ec@edge-core.com
www.edge-core.com
ECW5410-O Product Specifications
Physical Features Network Management
Standards
Wireless Frequency
Antenna
Warranty
Features
One 10/100/1000BASE-T Gigabit Ethernet (RJ-45) port with
802.3at/af-compliant Power over Ethernet (PoE) support
One 10/100/1000BASE-T Gigabit Ethernet (RJ-45)
One console port(10/100/1000BASE-T) with an RJ-45 connector
One USB Port (optional)
One Reset Button
Five LEDs: Power, WLAN 2.4G, WLAN 5G, Eth1/PoE, Eth2
PoE 802.3at compliant
IEEE 802.11n 2.4 GHz and 5.0 GHz
IEEE 802.11ac/a 5.0 GHz
IEEE 802.11b/g, 2.4 GHz
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
IEEE 802.3af Power over Ethernet (PoE)
IEEE 802.11h Regulatory Domain Selection
IEEE 802.11i
Wi-Fi Multimedia (WMM)
Wireless Distribution System (WDS)
802.11g/n:
2.4 ~ 2.4835 GHz (US, Canada)
2.4 ~ 2.4835 GHz (ETSI, Japan)
802.11b:
2.4 ~ 2.4835 GHz (US, Canada)
2.4 ~ 2.4835 GHz (ETSI)
2.4 ~ 2.497 GHz (Japan)
802.11a/n/ac:
5.15 ~ 5.25 GHz (lower band) US/Canada, Europe, Japan
5.25 ~ 5.35 GHz (middle band) US/Canada, Europe, Japan
5.725 ~ 5.825 GHz (upper band) US/Canada
5.50 ~ 5.70 GHz Europe
5.47 ~ 5.725GHz
Telent
Web-based Management (HTTP and HTTPS)
SNMP management v1/v2c
Software download and upgrade by TFTP, HTTP
Configuration file backup and restore
System Information –AP status, station status, event logs
SNTP
Country selection
IPv4 and IPv6 dual stack support
Remote Management
UPNP
Upstream / Dwonstream Rate Limit
Type: PCB type
Gain: 4dBi in 2.4GHz, 5dBi in 5GHz
Please check www.edge-core.com for the warranty terms in
your country/region.
Wireless Features
VAP (Virtual Access Point) support with up to 16
SSIDs(2.4GHz: 8, 5GHz: 8)
Operation modes: AP Mode, Point-to-Point WDS, Point-to-
Multiple points WDS, WDS With AP
Transmit power adjustment
Dynamic Channel Selection for noisy environment
Auto-channel selection
Support Multi-cast
Security
WEP 64/128-bits
Wi-Fi Protected Access (WPA/WPA2)
WPA/WPA2 (PSK) over WDS
Secure SSH (Secure Sockets Shell), Telnet
SSID broadcast enable/disable
Regulatory Compliance
FCC Part 15 Subpart B
CE
Radio Signal Certification
FCC Part 15C 15.247, 15.207 (2.4GHz)
EN 300 328
EN 301 489-1
EN 301 489-17
Mechanical
Dimensions: 190.88x194.76x38mm
Weight: 0.623kg
Power
Input: 100 or 240 VAC, 50-60 Hz
Output: 12V 2A (or Ethernet PoE 802.3af/ at compatible)
Power Consumption: 17.4 W maximum
Environmental Specification
Temperature:
Standard Operating: 0°C to 50°C
Storage: -20°C to 70°C
Humidity: 10% to 95% (non-condensing)
For More Information
To find out more about Edge-Core Networks products and solutions, visit
www.edge-core.com
About Edge-Core Networks
Edge-Core Networks is in the business of providing innovative network
solutions. In the service provider network, in the data center or in the cloud,
Edge-Core Networks delivers the software and systems that transform the
way the world connects. Edge-Core Networks serves customers and partners
worldwide. Additional information can be found at www.edge-core.com.
