D103602X012 May 2012
Field Communicator Menu Tree
www.Fisher.com
FIELDVUE™ DLC3020f Digital Level Controller
FIELDVUE and Fisher are marks owned by one of the companies in the Emerson Process
Management business unit of Emerson Electric Co. Emerson, Emerson Process
Management, and the Emerson logo are trademarks and service marks of Emerson
Electric Co.
© 2012 Fisher Controls International LLC. All rights reserved.
Home
Overview
Configure
Service Tools
(on back side)
Advanced
Process Fluids (Interface only)
Upper Fluid
Lower Fluid
Change Process Fluid
Temperature Compensation
Density Tables
Calibration/Setup Log
Methods
View
Restore
Save Current
Rename
Delete Device
Variable Configuration
Sensor Units
Sensor Parameters
Torque Tube
Sensor Hardware Information
Configure
Instrument Setup
Manual Setup
Alert Setup
(on back side)
Calibrate
(on back side)
Overview
Check Status
Primary Purpose Variables
Shortcuts
Check Status
Device Status:
Good
Failed
Maintenance or
Advisory
Mode Status:
In Service or
Not in Service
Variable Configuration
Type of Measurement
Primary Value Range High
Primary Value Range Low
Primary Value Offset
Primary Value Range Units
Calibration In Use
Name
Date
Calibration Method
Calibrator
Calibration/Setup Logs
Calibration in Use
Calibration/Setup Log Methods
Menu Tree applies to
Device Revision DD RevisionFirmware Revision
1 1.0 0x03
Hardware Revision
1.0
475 Field
Communicator
Shortcuts
Device Information
Calibration/Setup Logs
Device Information
Device Overview
Version Information
Manufacturing Information
Device Overview
Instrument Model Number
Instrument Serial Number
Version Information
Device Revision
Firmware Revision
Hardware Revision
Major Sensor Revision
Minor Sensor Revision
DD Information
Manual Setup
Mode
Device
Process Fluid (Level only)
Process Fluids (Interface only)
Instrument Display
Snap Acting Control
Options
(continued on back side)
Sensor Hardware Information
Model Type
End Connection Style
End Connection Type
Body Material
Pressure Rating
Mechanical Sensor Serial Number
Displacer Size
Displacer Material
Displacer Rating
G Dimension
Torque Tube Material
Torque Tube Wall
Heat Insulator
Manufacturing Information
Lever Assembly ID
Communication Module ID
Sensor Module ID
Shop Order Number
Terminal Box Date Code
Sensor Units
Unit System
Length Units
Volume Units
Weight Units
Temperature Units
Torque Rate Units
Fluid Density Units
Sensor Parameters
Displacer Length
Displacer Volume
Displacer Weight
Driver Rod Length
Instrument Mount Position
Torque Tube
Torque Tube Material
Compensated Torque Rate
Torque Tube Table
Torque Tube Table
Temperature 1
Gain 1
Temperature 2
Gain 2
...
...
...
...
Temperature 10
Gain 10
Process Fluid (Level only)
Process Fluid
Change Process Fluid
Temperature Compensation
Density Table
Density Table
Temperature 1
Density 1
Temperature 2
Density 2
...
...
...
...
Temperature 10
Density 10
Temperature Compensation
Temperature Input
Temperature For Compensation
(Visible if Temperature
Input = None only)
Upper Fluid
Fluid Name
Density in Use
Lower Fluid
Fluid Name
Density in Use
Temperature Compensation
Temperature Input
Temperature For Compensation
(Visible if Temperature
Input = None only)
Process Fluid
Fluid Name
Density in Use
Upper Fluid Density Table
Lower Fluid Density Table
Temperature 1
Density 1
Temperature 2
Density 2
...
...
Temperature 10
Density 10
Manual Setup
Overview
DLC3020f Digital Level Controller
DLC3020f Digital Level Controller
Italics text = Method
Density Tables
Upper Fluid Density Table
Lower Fluid Density Table
www.Fisher.com
For the telephone number of the Emerson Process
Management sales office nearest you, contact:
In North America
Fisher Controls International LLC
1 (641) 754‐3011
In Latin America
Fisher Controls International LLC
1 (314) 746‐9900
In Asia Pacific
Emerson Process Management
Asia Pacific Private Ltd.
(65) 6777‐8211
In Europe
Emerson Process Management Ltd.
+44 1634 895800
For equipment service or support needs, contact
your local Emerson Process Management sales office
Manual Setup (continued)
Mode
Device
Process Fluid (Level)
Process Fluids (Interface)
Instrument Display
Snap Acting Control
Options
Instrument Display
Display Option
Device Display Primary Value Units
Decimal Places
Display Primary Value Offset
Scroll Message Control
Scroll Message Control
Primary Value Bad
Primary Value Uncertain
Failed Alert
Maintenance Alert
Advisory Alert
Configure
Instrument Setup
Manual Setup
Alert Setup
Calibrate
Snap Acting Control
Primary Value
Primary Value Percent
Snap Acting Control
Snap Units
DI1 Trip Point Settings
DI2 Trip Point Settings
DI1 Trip Point Settings
DI1 Action
DI1 Trip Point
DI1 Deadband
DI1 Readback
DI2 Trip Point Settings
DI2 Action
DI2 Trip Point
DI2 Deadband
DI2 Readback
Options
Resource Block Tag
Transducer Block Tag
Write Lock
Confirm Time
Communication Timeout
Function Block Available
Features Selected
Write Alarm
Block Alarm
Alert Key
Resource Block Tag
Tag Description
Strategy
Transducer Block Tag
Tag Description
Strategy
Write Lock
Write Lock
Write Priority
Communication Timeout
Shed Remote Cascade
Shed Remote Out
Function Block Available
CasIn to Transducer Block
Features Selected
Reports
Fault State
Write Lock
Reannunciation
Write Alarm
Disc Alarm Disabled
Write Alarm Alarm State
Write Alarm Unacknowledged
Block Alarm
Block Alarm Disabled
Block Alarm Alarm State
Block Alarm Unacknowledged Configure
Instrument Setup
Manual Setup
Alert Setup
Calibrate
Alert Setup
Rapid Rate Limit (length/sec)
Clear Rate Limit Alert
PlantWeb Alert Enable
PlantWeb Alert Reporting
PlantWeb Alert Enable
Failed Enable
Maintenance Enable
Advisory Enable
PlantWeb Alert Reporting
Failed Suppress
Maintenance Suppress
Advisory Suppress
Configure
Instrument Setup
Manual Setup
Alert Setup
Calibrate
Calibrate
Calibration in Use
Full Calibration (Bench)
Full Calibration (Field)
Expert User Calibration
Calibration in Use
Name
Date
Calibration Method
Calibrator
Expert User Calibration
Bench Calibration
Field Calibration
Trim Current Calibration
Bench Calibration
Weight
Min/Max
Two Point
Field Calibration
Simple Zero/Span
Min/Max
Two Point
Two Point Time Delay
Trim Current Calibration
Zero Trim
Gain Trim
Default Gain
Home
Overview
Configure
Service Tools
Advanced
Service Tools
Mode
Alerts
Variables
Maintenance
Simulate
Maintenance
Calibration/Setup Logs
Restart Options
LCD Test
Variables
Type of Measurement
Primary Value
Upper Fluid (Interface only)
Lower Fluid (interface only)
Process Fluid (Level only)
Compensated Torque Rate
Temperature Compensation
Run Time Extremes
Primary Value
Primary Value
Primary Value Percent
Lower Fluid (Interface only)
Fluid Name
Density in Use
Process Fluid (Level only)
Fluid Name
Density in Use
Upper Fluid (Interface only)
Fluid Name
Density in Use
Run Time Extremes
Run Time
Time Since Reset
Instrument Temperature
Maximum Recorded Temperature
Minimum Recorded Temperature
Time Over Upper Temperature Limit
Time Under Lower Temperature Limit
Temperature Integral (deg-days)
Calibration/Setup Logs
Calibration In Use
Calibration/Setup Log Methods
Calibration In Use
Name
Date
Calibration Method
Calibrator
Calibration/Setup Log
Methods
View
Restore
Save Current
Rename
Delete
LCD Test
Enable/Disable LCD Test
Device Display Test
Display Primary Value
Display Primary Value Percent
Simulate
Simulate Alert Conditions
Simulate Active Alerts
Simulate Active Alerts
Failed Active
Maintenance Active
Advisory Active
Service Tools
Calibrate
Alert Setup
Manual Setup
(continued)
