MULTI POINT LOCK TRIM
PRICE BOOK
Eecve February 1, 2021
Photo by: This Old House, Idea Home East Matunuck Project
EMTEK MULTI POINT LOCK TRIM FOR SWINGING DOORS
CHOOSE TRIMSETS FROM DOOR & LOCK CONFIGURATIONS, AVAILABLE IN BOTH KEYED AND NONKEYED FUNCTIONS
American Cylinder Hub Above/Below Handle,
3⁄” Center-to-Center
ref. G-U®
Euro Cylinder Hub Below Handle,
3⁄” Center-to-Center
ref. G-U®
PAGE
16
21
To determine your Multi Point Lock configuration:
1) Identify the manufacturer of your door and multi-point lock
2) Measure the center-to-center hole spacing between the lever and the cylinder
3) Check the lever position: is it above or below the cylinder?
4) Identify the type of cylinder used in the door: is it American or Euro Profile Cylinder?
> >
TABLE OF CONTENTS
(92mm)
3-5/8”
4-1/2"
4-1/2"
Door Manufacturers listed under each configuration are for reference only and are subject to change. Some
retrofitting may be necessary. Please carefully measure and identify your hardware using the diagrams and steps
listed below.
Large Multi Point Entry Set
Large Multi Point Entry Set
3-5/8”
4-1/2"
4-1/2"
(92mm) 3-5/8”
4-1/2"
4-1/2"
(92mm)
PAGE
Door Configuration #1
American Cylinder Hub Below Handle, 3⁄” Center-to-Center
ref. Atrium®, G-U®, KML by Andersen®, Andersen®,
Marvin Integrity®, Paddock Lockmaster™, Superior®
26
Door Configuration #2
American Cylinder Hub Above Handle, 3⁄” Center-to-Center
ref. BiltBest®, G-U®, Hurd® (Energy Saver), Andersen®
32
Door Configuration #3
American Cylinder Hub Above Handle, 4⁄” Center-to-Center
ref. Andersen®
38
TABLE OF CONTENTS
Door Configuration #4
American Cylinder Hub Above Handle, 3⁄” Center-to-Center
ref. Ashland®, G-U®, Caradco®, JELD-WEN®, Jeldwen® Custom
Collection (formerly Pozzi®), Marvin®, PGT®, Premium Collection
(formerly Norco®), Weathershield®
44
4
TABLE OF CONTENTS
Product Index
Order Form
Lifetime Limited Warranty
Door Configuration #6
American Cylinder Hub Below Handle, 3⁄” Center-to-Center
ref. Milgard®, Pella®
56
Door Configuration #7
American Cylinder Hub Above Handle, 6” Center-to-Center
ref. Trillenium® (formerly W&F Manufacturing)
62
72
74
75
Door Configuration #8
American Cylinder Hub Above Handle, 5¼” Center-to-Center
ref. Neuma Doors®
67
PAGE
Door Configuration #5
Euro Profile Cylinder Below Handle, 3⁄” Center-to-Center
ref. Crestline®, Hoppe®, Hurd®, KFV®, Kolbe & Kolbe®, Lincoln®,
Loewen®, Paddock Lockmaster™, Peachtree®, Semco®, Sierra
Pacific®, Signature®, Simpson®, Therma-Tru®, Vetter®, Willmar®,
Windsor®, Weathershield®
50
"
"
"
1⁄
5¼
8⁄
5
G-U® is a registered trademark of G-U Hardware, Inc. Paddock™ is a registered trademark of Yale® UK. Pella® is a registered
trademark of Pella Corporation. Sierra Pacific Windows® is a registered trademark of Sierra Pacific Industries. Superior® is a
registered trademark of Superior Engineered Products Corporation. Willmar® is a registered trademark of JELD-WEN of Canada Ltd.
Andersen® is a registered trademark of Andersen Corporation. Trillenium® is a registered trademark of Endura Products, Inc. Eagle®
is a registered trademark of Eagle Window and Door, Inc, BiltBest® is a registered trademark of BiltBest Windows and Patio Doors.
Ashland® is a registered trademark of Ashland Products, Inc. Caradco®, JELD-WEN, Norco® and Pozzi® are registered trademarks of
JELD-WEN Inc., Oregon, USA. Integrity® and Marvin® are registered trademarks of Marvin Windows and Doors. Milgard® is a
registered trademark of Milgard Windows, Inc. Therma-Tru® is a registered trademark of Therma-Tru Doors®. HOPPE® is a registered
trademark of HOPPE North America, Inc. Hurd® is a registered trademark of Hurd Millwork Company. Kolbe & Kolbe® is a registered
trademark of Kolbe & Kolbe Millwork Company, Inc. Lincoln® is a registered trademark of Lincoln Wood Products, Inc. Loewen® is
a registered trademark of Loewen Windows. PGT® is a registered trademark of PGT Industries. Peachtree® and Vetter® are
registered trademark of The Peachtree Companies, Inc. Semco® is a registered trademark of Semling-Menke Co. Inc. Weathershield®
is a registered trademark of Weathershield Mfg. Inc. KML by Andersen® is a registered trademark of KML by Andersen. Atrium® is
a registered trademark of Atrium. KFV® is a registered trademark of KFV. Simpson® is a registered trademark of Simpson.
Signature® is a registered trademark of Signature. Crestline® is a registered trademark of Crestline. Windsor® is a registered
trademark of Windsor. Neuma Doors® is a registered trademark of Nan Ya Plastics Corporation. With the exception of Paddock™,
none of the aforementioned companies are affiliated with Emtek Products, Inc.
Door Manufacturers listed under each configuration are for reference only and are subject to
change. Some retrofitting may be necessary. Please carefully measure and identify your hardware
using the diagrams and steps listed on pages 3, 4 and 5.
6
