BEL20000
BEL20000 Product Manual
2.4 GHz WLAN Radio Module
Document Date: September 2003
Document Number: PM20000-001
Document Version Number: 2
Document Status: Release
© Copyright 2003 by BelAir Networks.
All rights reserved..
BEL20000 Product Manual – 2.4 GHz WLAN Radio Module
September 2003 Page 2 of 12
PM20000-001 version 2
Contents
About this Document ............................................................. 2
Introduction............................................................................. 3
Conditions of Use.................................................................... 4
Module Installation and Service ............................................ 6
Final Product Requirements.................................................. 7
Regulatory Statements........................................................... 9
About this Document
This document is a product manual for the BEL20000 2.4 GHz WLAN Radio
Module, including its limitations on use in any product marketed or offered for
sale. It is intended as a supplement to training and documentation by BelAir
Networks Inc. or its authorized agents.
BEL20000 Product Manual – 2.4 GHz WLAN Radio Module
September 2003 Page 3 of 12
PM20000-001 version 2
Introduction
The BEL20000 (hereafter referred to as “the module”) is a 2.4 GHz radio
module compatible with the IEEE 802.11 standard for Wireless LAN
operation. It is designed to be interoperable with WLAN products which are
based on Direct Sequence Spread Spectrum (DSSS) radio technology.
The module contains a complete 802.11b radio and Medium Access Control
(MAC) protocol engine which allows implementation of an 802.11b access
point (AP).
The module is not intended for stand-alone operation. It will only be
marketed as a complete product, in conjunction with a package, DC power
supply and antenna (hereafter referred to as “the product” or the “final
product”).
Since the module has a BelAir networks proprietary digital interface, it cannot
be directly connected to any standard telecommunications or computer
devices. It can only be used with final products designed and authorized
specifically for that purpose.
BEL20000 Product Manual – 2.4 GHz WLAN Radio Module
September 2003 Page 4 of 12
PM20000-001 version 2
Conditions of Use
General Conditions of Use
This manual is intended to supplement training provided by BelAir Networks
or authorized parties. The module BEL20000 is only intended for use in BelAir
Networks products and is not for sale to the general public as a stand-alone
module.
Please read this entire document, including the Regulatory Statements section
before attempting to install or operate the module.
Warning: Any use of BEL20000 in any manner which is not expressly
specified within this manual or specifically approved by BelAir Networks or its
authorized agents will void the user’s right to operate this module, and is
expressly forbidden by BelAir Networks. This includes any modification of the
module, installation of the module in a configuration or used with an antenna
which is not expressly listed in this document or approved by BelAir
Networks.
List of Approved Final Products
The BEL20000 module is only approved for use in the following BelAir
Networks products:
• BA200. See BA200 documentation for complete manufacturing
instructions.
Operation of the module within the products expressly listed above is
required to ensure compliance to all FCC and Industry Canada regulations.
Any modification of the module, or its use in any configuration not expressly
listed above may void the user’s right to operate this module.
Country of Use
BEL20000 is certified with limited modular approval for use in the United
States as an Intentional Radiator as device: FCC ID: RAR20000001 and in
Canada as IC: 4674A-20000001. Please read all regulatory statements at the
end of this document before any attempt to install or operate this module.
BEL20000 Product Manual – 2.4 GHz WLAN Radio Module
September 2003 Page 5 of 12
PM20000-001 version 2
The module is only certified for operation in the United States and Canada.
Before attempting to install and operate this module in any other country,
contact BelAir Networks for approval.
Module Labeling
One or more labels are applied to the module during manufacture, including a
label which identifies the FCC and Industry Canada identification numbers. Do
not attempt to remove any labels from the module.
BEL20000 Product Manual – 2.4 GHz WLAN Radio Module
September 2003 Page 6 of 12
PM20000-001 version 2
Module Installation and Service
Installation into a Product
The module shall only be installed by a technician trained by BelAir Networks
or its authorized agents. It should only be installed into an approved product
(see above) following all manufacturing and service procedures for that
product. The module should only be installed into a final product in a
manufacturing or service depot site.
Caution: BEL20000 is an electro-static discharge (ESD) sensitive device. All
appropriate ESD measures must be taken when handling the module. Failure
to employ appropriate ESD protection may damage the module.
Module Service
The module is not intended as a field-serviceable unit. It contains no field-
replaceable or field-serviceable parts, or any external adjustable mechanisms.
The module should only be serviced in a manufacturing or service depot site
approved by BelAir Networks or its authorized agents.
BEL20000 Product Manual – 2.4 GHz WLAN Radio Module
September 2003 Page 7 of 12
PM20000-001 version 2
Final Product Requirements
The requirements below apply to any final product in which the BEL20000
module is installed.
Antenna Usage
BEL20000 module shall only be used in conjunction with the following antenna
types:
• BelAir Networks model: BEL10012, 8 dBi directional diversity antenna,
beamwidth 65 degrees.
Warning: Use of this module in conjunction with any antenna not
expressly listed above will void authority to install or operate this equipment.
Product Installation
Products which contain BEL20000 shall only be installed by professional
installers trained by BelAir Networks or its authorized agents. In addition to
normal installation procedures and good installation practice, professional
installers are responsible to ensure that:
1. Only an approved antenna (see above) is connected to the module, and,
2. The antenna is mounted in such a manner and in such a location that
access to the antenna by the general population is minimized. Access to
the antenna by the general population should be limited to greater than 20
cm (8 inches) during normal operation.
Adherence to these rules by the professional installer is mandatory. See full
installation procedures for the particular product for details.
Product Labeling
The following permanent label, or one containing equivalent information, must
be affixed in a conspicuous location on the exterior of every product
containing this module:
BEL20000 Product Manual – 2.4 GHz WLAN Radio Module
September 2003 Page 8 of 12
PM20000-001 version 2
This device contains the following:
FCC ID: RAR20000001 IC: 4674A-20000001
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2)
This device must accept any interference received, including
interference that may cause undesired operation.
BEL20000 Product Manual – 2.4 GHz WLAN Radio Module
September 2003 Page 9 of 12
PM20000-001 version 2
Regulatory Statements
The following regulatory notes apply to the product which contains module
BEL20000. The following sections or equivalent information shall appear in the
user-manual of the final product.
Regulatory Information and Disclaimers
Installation and use of this device must be in strict accordance with the
instructions included in the user documentation provided with the product.
Any changes or modifications to this product not expressly approved by the
party responsible for compliance could void the user’s authority to operate
this equipment.
The manufacturer is not responsible for any interference to radio or television
equipment caused by unauthorized modification of this device, or attachment
of any antennas or equipment other than those specified by the manufacturer.
The manufacturer or its authorized resellers or distributors will assume no
liability for any damage or violation of government regulations arising from
failing to comply with these guidelines.
Manufacturer’s FCC Conformity Statement
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions (1) this device may not
cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
FCC Interference Statement
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
BEL20000 Product Manual – 2.4 GHz WLAN Radio Module
September 2003 Page 10 of 12
PM20000-001 version 2
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Manufacturer’s Industry Canada Conformity Statement
This device has been designed to operate with an antenna having a maximum
gain of 8.5 dB. Antenna having a higher gain is strictly prohibited per
regulations of Industry Canada. The required antenna impedance is 50 ohms.
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
To reduce potential radio interference to other users, the antenna type and its
gain should be so chosen that the equivalent isotropically radiated power
(EIRP) is not more than that required for successful communication.
This Class B Digital apparatus meets all the requirements of the Canadian
Interference-Causing Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les exigences du
Réglement sur le matériel brouilleur du Canada.
RF Exposure Statement
This Wireless LAN radio device has been evaluated under FCC Bulletin OET
65C and found to be compliant to the requirements set forth in CFR 47
Sections 2.1091, 2.1093, and 15.247 (b) (4) addressing RF exposure from radio
frequency devices.
BEL20000 Product Manual – 2.4 GHz WLAN Radio Module
September 2003 Page 11 of 12
PM20000-001 version 2
This device complies with FCC RF radiation exposure limits for an
uncontrolled environment. The radiated output power of this Wireless LAN
device is below the FCC radio frequency exposure limits. However, this
device should still be installed and used in such a manner that the potential for
human contact during normal operation is minimized. In order to comply with
RF exposure limits established in the ANSI C95.1 standard, this equipment
should be installed and operated at a minimum distance of 20 centimeters (8
inches) between the radiator and a human body.
BEL20000 Product Manual – 2.4 GHz WLAN Radio Module
September 2003 Page 12 of 12
PM20000-001 version 2
BelAir Networks U.S. East
11921 Freedom Drive
Suite 550
Reston, VA
USA
20190
703-736-8306
BelAir Networks U.S. West
1902 Wright Place
Suite 200
Carlsbad, CA
USA
92008
760-918-5544
BelAir Networks Inc.
603 March Road
Kanata, Ontario
Canada
K2K 2M5
613-254-7070
Sales
sales@belairnetworks.com
Support
support@belairnetworks.com
General Information
Info@belairnetworks.com

Navigation menu
