Page 1 of 14
B2CH079AA
B2CH079AA Product Manual
ERM2 5 GHz WLAN Radio Module
Document Date: November 2007
Document Number : PM-B2CH079AA
Document Version Number : 2
Document Status: Release
© Copyright 2006 by BelAir Networks.
All rights reserved..
B2CH079AA Product Manual – ERM2, 5 GHz WLAN Radio Module
November 2007 Page 2 of 14
PM-B2CH079AA Version 2
B2CH079AA Product Manual – ERM2, 5 GHz WLAN Radio Module
November 2007 Page 3 of 14
PM-B2CH079AA Version 2
Contents
About this Document .................................................................... 3
Introduction .................................................................................... 4
Conditions of Use ........................................................................... 5
Module Installation and Service.................................................... 7
Final Product Requirements ......................................................... 8
Regulatory Statements................................................................ 11
About this Document
This document is a product manual for the B2CH079AA 5 GHz WLAN Radio
Module, including its limitations on use in any product marketed or offered for sale.
It is intended as a supplement to training and documentation by BelAir Networks
Inc. or its authorized agents.
B2CH079AA Product Manual – ERM2, 5 GHz WLAN Radio Module
November 2007 Page 4 of 14
PM-B2CH079AA Version 2
Introduction
The B2CH079AA (hereafter referred to as “the module”) is a 5 GHz radio module
compatible with the IEEE 802.11 standard for Wireless LAN operation. It is
designed to be interoperable with WLAN products which are based on Direct
Sequence Spread Spectrum (DSSS) radio technology.
The module contains a complete 802.11a radio and Medium Access Control (MAC)
protocol engine which allows implementation of an 802.11a module.
The module is not intended for stand-alone operation. It will only be marketed as a
complete product, in conjunction with a package, DC power supply and antenna
(hereafter referred to as “the product” or the “final product”).
Since the module has a BelAir networks proprietary digital interface, it cannot be
directly connected to any standard telecommunications or computer devices. It can
only be used with final products designed and authorized specifically for that
purpose.
B2CH079AA Product Manual – ERM2, 5 GHz WLAN Radio Module
November 2007 Page 5 of 14
PM-B2CH079AA Version 2
Conditions of Use
General Conditions of Use
This manual is intended to supplement training provided by BelAir Networks or
authorized parties. The module B2CH079AA is only intended for use in BelAir
Networks products and is not for sale to the general public as a stand-alone module.
Please read this entire document, including the Regulatory Statements section
before attempting to install or operate the module.
Warning: Any use of B2CH079AA in any manner which is not expressly
specified within this manual or specifically approved by BelAir Networks or its
authorized agents will void the user’s right to operate this module, and is expressly
forbidden by BelAir Networks. This includes any modification of the module,
installation of the module in a configuration or used with an antenna which is not
expressly listed in this document or approved by BelAir Networks.
List of Approved Final Products
The B2CH079AA module is only approved for use in the following BelAir Networks
products:
• BelAir200. See BelAir200 documentation for complete manufacturing instructions.
• BelAir100. See BelAir100 documentation for complete manufacturing instructions.
• BelAir50c. See BelAir50c documentation for complete manufacturing instructions.
Operation of the module within the products expressly listed above is required to
ensure compliance to all FCC and Industry Canada regulations. Any modification of
the module, or its use in any configuration not expressly listed above may void the
user’s right to operate this module.
Country of Use
B2CH079AA is certified with limited modular approval for use as an Intentional
Radiator in the United States as device: FCC ID: RAR20031001 and in Canada as
B2CH079AA Product Manual – ERM2, 5 GHz WLAN Radio Module
November 2007 Page 6 of 14
PM-B2CH079AA Version 2
IC: 4674A-20031001. Please read all regulatory statements at the end of this
document before any attempt to install or operate this module.
The module is only certified for operation in the United States and Canada. Before
attempting to install and operate this module in any other country, contact BelAir
Networks for approval.
Module Labeling
One or more labels are applied to the module during manufacture, including a label
which identifies the FCC and Industry Canada identification numbers. Do not
attempt to remove any labels from the module.
B2CH079AA Product Manual – ERM2, 5 GHz WLAN Radio Module
November 2007 Page 7 of 14
PM-B2CH079AA Version 2
Module Installation and Service
Installation into a Product
The module shall only be installed by a technician trained by BelAir Networks or its
authorized agents. It should only be installed into an approved product (see above)
following all manufacturing and service procedures for that product. The module
should only be installed into a final product in a manufacturing or service depot site.
Caution: B2CH079AA is an electro-static discharge (ESD) sensitive device. All
appropriate ESD measures must be taken when handling the module. Failure to
employ appropriate ESD protection may damage the module.
Module Service
The module is not intended as a field-serviceable unit. It contains no field-
replaceable or field-serviceable parts, or any external adjustable mechanisms. The
module should only be serviced in a manufacturing or service depot site approved
by BelAir Networks or its authorized agents.
B2CH079AA Product Manual – ERM2, 5 GHz WLAN Radio Module
November 2007 Page 8 of 14
PM-B2CH079AA Version 2
Final Product Requirements
The requirements below apply to any final product in which the B2CH079AA module is installed.
Antenna Usage and Module Transmit Power
B2CH079AA module shall only be used in conjunction with the following antenna
types as outlined in the table that follows:
Antenna Models and Maximum Allowable Power Setting
Frequency
Band
Channels Location Maximum Rated Transmit Power with Antenna Type
5.730 – 5.845 GHz 146 to 169 Indoor /
Outdoor
Antenna Gain Max Rated Transmit
Power
MaxRad MMO58004NF 4 dBi 20 dBm
MaxRad MMO58010NF
MTI MT-482003/N
10 dBi 20 dBm
BelAir BMA000210 10.5 dBi 20 dBm
BelAir BMA000203 15 dBi 20 dBm
H+S SPA 5600/9/23/0/V 23 dBi + 20 dBm (P2P)* else
13 dBm
MTI MT-486001 28 dBi + 20 dBm (P2P)* else
8 dBm
MTI MT-485028/N 22 dBi + 20 dBm (P2P)* else
14 dBm
MTI MT-485001 19 dBi 20 dBm (P2P)* else
17 dBm
MAXRAD
WISP4959018MBV 15 dBi 20 dBm (P2P)* else
21 dBm
Andrew P2F-52-NEA 30 dBi + 20 dBm (P2P)* else
6 dBm
In order to comply with the FCC and Industry Canada rules in the USA and Canada,
respectively, it is required to respect the maximum transmit power limits as follows
for each of the antenna types. +, * see notes following :
B2CH079AA Product Manual – ERM2, 5 GHz WLAN Radio Module
November 2007 Page 9 of 14
PM-B2CH079AA Version 2
* P2P indicates that the rated transmit power is only permissible for use in point-to-
point links. For point-to-multipoint or multipoint-to-multipoint links the power
must be reduced as shown.
+ These antennas require an external filter between the product and antenna, part
number BMA000281-A
Warning: Use of this module in conjunction with any antenna not expressly
listed above will void authority to install or operate this equipment.
Warning: Setting of module transmit power above the limits specified in the
above table for a particular combination of antenna type, frequency of operation,
and type of usage, will exceed FCC or Industry Canada limits and void authority to
install or operate this equipment.
Product Installation
Products which contain B2CH079AA-A shall only be installed by professional
installers trained by BelAir Networks or its authorized agents. In addition to normal
installation procedures and good installation practice, professional installers are
responsible to ensure that:
1. Only an approved antenna (see above) is connected to the module, and,
2. The antenna is mounted in such a manner and in such a location that access to the
antenna by the general population is minimized. Access to the antenna by the
general population should be limited to more than the minimum safety distance.
This distances are outlined according to product type and whether high gain
antennas are used:
B2CH079AA Product Manual – ERM2, 5 GHz WLAN Radio Module
November 2007 Page 10 of 14
PM-B2CH079AA Version 2
Minimum Safety Distances
Radios with ERM2 RAR20031001
Product Standard Antennas
RF boards : All valid
combinations ERM2 ARM3C PSM1,2 WRM1,2 ERM2 ARM3C PSM1,2 WRM1,2
BelAir50, BelAir
100,100T,100S
up to 19
dBi Any 10 dbi 15 dbi up to 30 dBi Any 25 dBi 25 dBi
Distance
BelAir 200 up to 19
dBi Any 10 dbi 15 dbi up to 30 dBi Any 25 dBi 25 dBi
Distance
ARM3C :RAR20000003 PSM1,2:RAR20004001, RAR20008001 WRM1,2 : RAR20006001, RAR20007001
High Gain Antennas
35 cm (13.8 in) 125 cm (49.2 in)
50 cm (19.7 in) 160 cm (63 in)
Adherence to these rules by the professional installer is mandatory. See full
installation procedures for the particular product for details.
Product Labeling
The following permanent label, or one containing equivalent information, must
be affixed in a conspicuous location on the exterior of every product
containing this module:
This device contains the following:
RAR20031001 IC: 4674A-20031001
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2)
This device must accept any interference received, including
interference that may cause undesired operation.
B2CH079AA Product Manual – ERM2, 5 GHz WLAN Radio Module
November 2007 Page 11 of 14
PM-B2CH079AA Version 2
Regulatory Statements
The following regulatory notes apply to the product which contains module
B2CH079AA. The following sections or equivalent information shall appear in the
user-manual of the final product.
Regulatory Information and Disclaimers
Installation and use of this device must be in strict accordance with the instructions
included in the user documentation provided with the product. Any changes or
modifications to this product not expressly approved by the party responsible for
compliance could void the user’s authority to operate this equipment.
The manufacturer is not responsible for any interference to radio or television
equipment caused by unauthorized modification of this device, or attachment of any
antennas or equipment other than those specified by the manufacturer. The
manufacturer or its authorized resellers or distributors will assume no liability for
any damage or violation of government regulations arising from failing to comply
with these guidelines.
Manufacturer’s FCC Conformity Statement
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions (1) this device may not cause
harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
FCC Interference Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
B2CH079AA Product Manual – ERM2, 5 GHz WLAN Radio Module
November 2007 Page 12 of 14
PM-B2CH079AA Version 2
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Manufacturer’s Industry Canada Conformity Statement
This device has been designed to operate with an antenna having a maximum gain of
30 dB. Antenna having a higher gain is strictly prohibited per regulations of Industry
Canada. The required antenna impedance is 50 ohms.
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including interference
that may cause undesired operation of the device.
To reduce potential radio interference to other users, the antenna type and its gain
should be so chosen that the equivalent isotropically radiated power (EIRP) is not
more than that required for successful communication.
This Class B Digital apparatus meets all the requirements of the Canadian
Interference-Causing Equipment Regulations.
RF Exposure Statement
This Wireless LAN radio device has been evaluated under FCC Bulletin OET 65C
and found to be compliant to the requirements set forth in CFR 47 Sections 2.1091,
2.1093, and 15.247 (b) (4) addressing RF exposure from radio frequency devices.
This device complies with FCC RF radiation exposure limits for an uncontrolled
environment. The radiated output power of this Wireless LAN device is below the
FCC radio frequency exposure limits. However, this device should still be installed
B2CH079AA Product Manual – ERM2, 5 GHz WLAN Radio Module
November 2007 Page 13 of 14
PM-B2CH079AA Version 2
and used in such a manner that the potential for human contact during normal
operation is minimized. In order to comply with RF exposure limits established in
the ANSI C95.1 standard, this equipment should be installed and operated at a
minimum distance between the radiator and a human body. This minimum distance
is:
Minimum Safety Distances
Radios with ERM2 RAR20031001
Product Standard Antennas
RF boards : All valid
combinations ERM2 ARM3C PSM1,2 WRM1,2 ERM2 ARM3C PSM1,2 WRM1,2
BelAir50, BelAir
100,100T,100S
up to 19
dBi Any 10 dbi 15 dbi up to 30 dBi Any 25 dBi 25 dBi
Distance
BelAir 200 up to 19
dBi Any 10 dbi 15 dbi up to 30 dBi Any 25 dBi 25 dBi
Distance
ARM3C :RAR20000003 PSM1,2:RAR20004001, RAR20008001 WRM1,2 : RAR20006001, RAR20007001
High Gain Antennas
35 cm (13.8 in) 125 cm (49.2 in)
50 cm (19.7 in) 160 cm (63 in)
B2CH079AA Product Manual – 2.4 GHz WLAN Radio Module
November 2007 Page 14 of 14
PM-B2CH079AA Version 2
BelAir Networks Inc.
603 March Road
Kanata, Ontario
Canada
K2K 2M5
613-254-7070
Sales
sales@belairnetworks.com
Support
support@belairnetworks.com
General Information
Info@belairnetworks.com
