User Manual
FCC Guidelines for WLANs Operating in the
5470-5725 MHz Band
STATEMENT OF COMPLIANCE
1/174 02-LZA 101 806 Uen C
Copyright
© Ericsson AB 2013. All rights reserved. No part of this document may be
reproduced in any form without the written permission of the copyright owner.
Disclaimer
The contents of this document are subject to revision without notice due to
continued progress in methodology, design and manufacturing. Ericsson shall
have no liability for any error or damage of any kind resulting from the use
of this document.
Trademark List
Wi-Fi®Wi-Fi®is a registered trademark of the Wi-Fi Alliance.
Wi-Fi Certified Logo
The Wi-Fi CERTIFIED logo is a registered trademark
of the Wi-Fi Alliance.
Ericsson Ericsson is the trademark or registered trademark of
Telefonaktiebolaget LM Ericsson. All other product or
service names mentioned in this manual are trademarks
of their respective companies.
1/174 02-LZA 101 806 Uen C | 2013-12-13
FCC Guidelines for WLANs Operating in the 5470-5725 MHz Band
1/174 02-LZA 101 806 Uen C | 2013-12-13
About this Document
1 About this Document
This section describes the scope and target groups for this document.
1.1 Scope
This document contains guidelines from the U.S. Federal Communications
Commission (FCC) specific to products operating in a particular band.
1.2 Target Group
The information in this document is intended for personnel performing hardware
installation.
1.3 Comments About the Documentation
Ericsson encourages you to provide feedback, comments or suggestions so
that we can improve the documentation to better meet your needs. With your
comments provide the following:
• Document title
• Document number and revision
• Page number or section number
Please send your comments to your local Ericsson Support.
1
1/174 02-LZA 101 806 Uen C | 2013-12-13
FCC Guidelines for WLANs Operating in the 5470-5725 MHz Band
2 FCC Guidelines
The FCC, FAA, National Telecommunications and Information Administration
(NTIA) and industry are working to resolve interference to Terminal Doppler
Weather Radar (TDWR) systems used near airports that has occurred from
some outdoor wireless systems operating in the 5470 MHz – 5725 MHz band.
To protect TDWR operations, installers and operators must ensure the following
guidelines are met:
• Devices must not transmit on channels which overlap the 5600 – 5650
MHz band.
• Devices intended for outdoor use are further restricted, as follows:
Devices must be professionally installed when operating in the 5470
– 5725 MHz band.
Any installation of either a master or a client device within 35 km of a
TDWR location must be separated by at least 30 MHz (center-to-center)
from the TDWR operating frequency as shown in Table 1.
If the device is installed within 35 km of multiple TDWRs, the device
must ensure that it avoids operation within 30 MHz for each of the
TDWRs. This requirement applies even if the master is outside the 35
km radius but communicates with outdoor clients which may be within
the 35 km radius of the TDWRs.
Additional mitigation techniques include not orienting the antennas in the main
beam of the weather radar and ensuring that the antenna is not positioned in
line-of-sight of the FAA TDWR.
A voluntary Wireless Internet Service Providers Association (WISPA)
sponsored database has been developed that allows operators and installers
to register the location information of the UNII devices operating outdoors
in the 5470 – 5725 MHz band within 35 km of any TDWR location (see
http://www.spectrumbridge.com/udia/home.aspx). This database may be used
by government agencies in order to expedite resolution of any interference to
TDWRs.
Ericsson strongly recommends that all operators and installers register in
this WISPA database the location information of the UNII devices operating
outdoors in the 5470 – 5725 MHz band within 35 km of any TDWR location.
Procedures on how to register the devices in the database with the appropriate
information regarding the location and operation of the device and installer
information can be found on the database.
21/174 02-LZA 101 806 Uen C | 2013-12-13
TDWR Location Information
3 TDWR Location Information
Table 1 shows TDWR information provided by NTIA. Use this
table as a quick reference. For the latest information, refer to
http://www.spectrumbridge.com/udia/home.aspx.
Table 1 TDWR Locations
State City Longitude Latitude Frequency
Terrain
Elevation
(MSL) [ft]
Antenna
Height
Above
Terrain [ft]
AZ PHOENIX W 112 09 46 N 33 25 14 5610 MHz 1024 64
CO DENVER W 104 31 35 N 39 43 39 5615 MHz 5643 64
FL FT LAUDERDALE W 080 20 39 N 26 08 36 5645 MHz 7113
FL MIAMI W 080 29 28 N 25 45 27 5605 MHz 10 113
FL ORLANDO W 081 19 33 N 28 20 37 5640 MHz 72 97
FL TAMPA W 082 31 04 N 27 51 35 5620 MHz 14 80
FL WEST PALM BEACH W 080 16 23 N 26 41 17 5615 MHz 20 113
GA ATLANTA W 084 15 44 N 33 38 48 5615 MHz 962 113
IL MCCOOK W 087 51 31 N 41 47 50 5615 MHz 646 97
IL CRESTWOOD W 087 43 47 N 41 39 05 5645 MHz 663 113
IN INDIANAPOLIS W 086 26 08 N 39 38 14 5605 MHz 751 97
KS WICHITA W 097 26 13 N 37 30 26 5603 MHz 1270 80
KY COVINGTON
CINCINNATI
W 084 34 48 N 38 53 53 5610 MHz 942 97
KY LOUISVILLE W 085 36 38 N 38 02 45 5646 MHz 617 113
LA NEW ORLEANS W 090 24 11 N 30 01 18 5645 MHz 297
MA BOSTON W 070 56 01 N 42 09 30 5610 MHz 151 113
MD BRANDYWINE W 076 50 42 N 38 41 43 5635 MHz 233 113
MD BENFIELD W 076 37 48 N 39 05 23 5645 MHz 184 113
MD CLINTON W 076 57 43 N 38 45 32 5615 MHz 249 97
MI DETROIT W 083 30 54 N 42 06 40 5615 MHz 656 113
MN MINNEAPOLIS W 092 55 58 N 44 52 17 5610 MHz 1040 80
MO KANSAS CITY W 094 44 31 N 39 29 55 5605 MHz 1040 64
MO SAINT LOUIS W 090 29 21 N 38 48 20 5610 MHz 551 97
MS DESOTO COUNTY W 089 59 33 N 34 53 45 5610 MHz 371 113
NC CHARLOTTE W 080 53 06 N 35 20 14 5608 MHz 757 113
NC RALEIGH DURHAM W 078 41 50 N 36 00 07 5647 MHz 400 113
NJ WOODBRIDGE W 074 16 13 N 40 35 37 5620 MHz 19 113
NJ PENNSAUKEN W 075 04 12 N 39 56 57 5610 MHz 39 113
31/174 02-LZA 101 806 Uen C | 2013-12-13
FCC Guidelines for WLANs Operating in the 5470-5725 MHz Band
State City Longitude Latitude Frequency
Terrain
Elevation
(MSL) [ft]
Antenna
Height
Above
Terrain [ft]
NV LAS VEGAS W 115 00 26 N 36 08 37 5645 MHz 1995 64
NY FLOYD BENNETT
FIELD
W 073 52 49 N 40 35 20 5647 MHz 897
OH DAYTON W 084 07 23 N 40 01 19 5640 MHz 922 97
OH CLEVELAND W 082 00 28 N 41 17 23 5645 MHz 817 113
OH COLUMBUS W 082 42 55 N 40 00 20 5605 MHz 1037 113
OK AERO. CTR TDWR #1 W 097 37 31 N 35 24 19 5610 MHz 1285 80
OK AERO. CTR TDWR #2 W 097 37 43 N 35 23 34 5620 MHz 1293 97
OK TULSA W 095 49 34 N 36 04 14 5605 MHz 712 113
OK OKLAHOMA CITY W 097 30 36 N 35 16 34 5603 MHz 1195 64
PA HANOVER W 080 29 10 N 40 30 05 5615 MHz 1266 113
PR SAN JUAN W 066 10 46 N 18 28 26 5610 MHz 59 113
TN NASHVILLE W 086 39 42 N 35 58 47 5605 MHz 722 97
TX HOUSTON
INTERCONTL
W 095 34 01 N 30 03 54 5605 MHz 154 97
TX PEARLAND W 095 14 30 N 29 30 59 5645 MHz 36 80
TX DALLAS LOVE FIELD W 096 58 06 N 32 55 33 5608 MHz 541 80
TX LEWISVILLE DFW W 096 55 05 N 33 03 53 5640 MHz 554 31
UT SALT LAKE CITY W 111 55 47 N 40 58 02 5610 MHz 4219 80
VA LEESBURG W 077 31 46 N 39 05 02 5605 MHz 361 113
WI MILWAUKEE W 088 02 47 N 42 49 10 5603 MHz 820 113
41/174 02-LZA 101 806 Uen C | 2013-12-13
