Indoor Photo Detector
ES700IPD
Detect and view events as they happen
11
Lifestyle
Product Specifications
The perfect combination of motion detection and image capture
functionality. It features:
•A compact, indoor detector and photo verification device
•Once armed, the ES700IPD captures a photo images upon PIR
detection
•Can be also triggered by a user request
•Compressed stream of photos are sent via RF to the control unit,
and from there to a designated recipient (security service
provider, email account, etc.)
•Full-color JPEG photos sent through the network to monitoring
service or user email
•Walk through mode when combined with a Magnet Switch
•Wireless and battery-operated for easy, maintenance-free
installation
“Plug-&-Play” state-of-the-art Wireless security system:
•User-friendly
•Utilizes cutting-edge technology
•Bidirectional RF wireless communication
•Battery operated
•Easy to install
•Nonintrusive, state-of-the-art design
COMMUNICATION:
•Bi-directional: End-to-End Bi-Directional ESI protocol
•Advanced radio supervision algorithm
•Up to 700 meters RF range (open air)
•Modulation and Frequency: BFSK , 868.3 MHz for Europe or 916.5 MHz for USA
•Encoding: 32-bit ID, over 4 billion combinations
SECURITY:
•Unique electronic serial number
•Tamper alarm when tilted
IMAGE CAPTURE:
•Captured full-color JPEG photos (up to 5 frames/second)
•Selectable Quality & Resolution: from 320x240 to640x480
•Illumination (for image capture in darkness/low-light): Super-bright white LED
CAMERA:
•VGA (640 x 480) pixel color CMOS camera
•Shooting Angle (diagonal): 67°
•Shooting Range: 10m / 32.8 ft. at daylight
POWER:
•Uses 3 standard AA Alkaline batteries,
•Battery life of 3 years
•DC-jack for an optional external power supply
ADDITIONAL INFORMATION:
•Detection Type: Passive Infrared
•Insect Immunity: Sealed Optics
•Pet Immune option
SIZE and WEIGHT:
•Dimensions: 123x60x60 mm / 4.9x2.4x2.4 In. (LxWxD)
•Weight: 160 gr. / 0.35 lb. (batteries: 50 gr. / 0.11 lb.)
ENVIRONMENT:
•Operating Ambient Temperature range: -10°C ~ 55°C / 14°F ~ 131°F
•Humidity: up to 95%, non condensing
CERTIFICATION:
•CE: CE mark, EMC/EMI according to ETSI EN 301 489-4, ETSI EN 301 489-1, EN
50130-4:1996, EU Directive 1999/5/EC for R&TTE
•Radio: ETSI EN 300 220-3, ETSI EN 300 220-1, CEPT/ERC Recommendation 70-
03, EN 50131-5-3:2005 + A1:2008
•Safety: EN/IEC60950-1, TUV : UL 60950-1
•Security & Alarm systems: EN 50131-1:2006 + A1:2009 Class-II Grade-2, EN
50131-2-2:2008 Class-II Grade-2, EN50131-6:2008 Type-C
•Reliability (Mech. & Environmental conditions): EN 50130-5:1999 &IEC 60068
Certifications and approvals:
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications to this equipment not expressly approved by the party responsible for
compliance (Essence Security International Ltd.) could void the user’s authority to operate the
equipment.
WARNING! To comply with FCC RF exposure compliance requirements, the device should be located at
a distance of at least 20 cm from all persons during normal operation. The antennas used for this
product must not be co-located or operated in conjunction with any other antenna or transmitter.
This device complies with FCC Rules Part 15. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation
