Estone Technology TP36Q10 IRV 10.1 Touch Screen Control Panel User Manual manual
Estone Technology Inc. IRV 10.1 Touch Screen Control Panel manual
Users Manual
1. SHOWS THE BATTERY / FRESH WATER / BLACK W ATER 1 / BLACK WATER 2 / GREY
WATER 1 / GREY WATER 2 / GALLEY TANK STATUS
2. PANEL POWER (ON/OFF)
3. ENTRY LIGHT (ON/OFF)
4. PORCH LIGHTS (ON/OFF)
5. ELECTRIC WATER HEATER (ON/OFF)
6. ODS FLOOD (ON/OFF)
7. LP GAS WATER HEATER (ON/OFF)
8. WATER PUMP (ON/OFF)
9. TANK HEATER (ON/OFF)
10. STEP LIGHT (ON/OFF)
11. AISLE LIGHT (ON/OFF)
12. CONTROL SLIDE ROOM IN
13. CONTROL SLIDE ROOM 2 IN
14. CONTROL SLIDE ROOM 3 IN
15. CONTROL AWNING RETRACT
16. CONTROL AWNING 2 RETRACT
17. CONTROL SLIDE ROOM OUT
18. CONTROL SLIDE ROOM 2 OUT
19. CONTROL SLIDE ROOM 3 OUT
20. CONTROL AWNING EXTEND
21. CONTROL AWNING EXTEND
22. POWER ON/OFF
23. CONNECT TO THE CONTROLLER - RELAY BOX
24. MIN USB
SLID E
ROOM 2 OU T
SLID E
ROOM 3 OU T
AWNIN G
EXTE ND
AWNIN G 2
EXTE ND
SLID E
ROOM 2 IN
SLID E
ROOM 3 IN
AWNIN G
RETR AC T
AWNIN G 2
RETR AC T
LP GAS
WATER
HEATER
WATER
PUMP
TANK
HEATER
STEP
LIGH T
AIS LE
LIGH T
Galle y
tank
Grey
water 2
Grey
water 1
Black
water 1
Black
water 2
Fresh
water 1
Batte ry
SLID E
ROOM I N
SLID E
ROOM O UT
DSI FAULT
ENTRY
LIGH T
PORCH
LIGH TS
ELECTRIC
WATER
HEATER
ODS
FLOO D
1
2 3 4 5 6
7 8 9 10 11
12 13 14 15 16
17 18 19 20 21
22
MINI USB
RJ45 24
23
USER MANUAL Power On/Off
Press and hold (PANEL POWER) button to power on.
Press and hold (PANEL POWER) button to power off.
Restart PANEL
Press and hold POWER button to restart panel system .
Press the button (3-11) breifly to operate ON/OFF as below:
3. ENTRY LIGHT (ON/OFF)
4. PORCH LIGHTS (ON/OFF)
5. ELECTRIC WATER HEATER (ON/OFF)
6. ODS FLOOD (ON/OFF)
7. LP GAS WATER HEATER (ON/OFF)
8. WATER PUMP (ON/OFF)
9. TANK HEATER (ON/OFF)
10. STEP LIGHT (ON/OFF)
11. AISLE LIGHT (ON/OFF)
Press and hold the button (3-11) to control as below:
12. CONTROL SLIDE ROOM IN
13. CONTROL SLIDE ROOM 2 IN
14. CONTROL SLIDE ROOM 3 IN
15. CONTROL AWNING RETRACT
16. CONTROL AWNING 2 RETRACT
17. CONTROL SLIDE ROOM OUT
18. CONTROL SLIDE ROOM 2 OUT
19. CONTROL SLIDE ROOM 3 OUT
20. CONTROL AWNING EXTEND
21. CONTROL AWNING 2 EXTEND
Symbol level shows the Battery / Fresh water / Black water 1 / Black water 2 / Grey water 1 / Grey
water 2 / Gallery Tank status:
Galley
tank
Grey
water 2
Grey
water 1
Black
water 1
Black
water 2
Fresh
water 1
Battery
Warning: Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Warning:
The TP36Q10 has been tested for body-worn Specific Absorption Rate (SAR) compliance. The radio module has
been evaluated and found to be compliant to the requirements as set forth in CFR 47 Sections, 2.1093, and
15.247 (b) (4) addressing RF Exposure from radio frequency devices. This model meets the applicable
government requirements for exposure to radio frequency waves. The highest SAR level measured for this device
was 0.946 W/kg.
