Etiger Digital Technology ES-RC1 Remote Control User Manual
Shanghai Etiger Digital Technology Co., Ltd. Remote Control Users Manual
Users Manual
EN Box Content
1 x Remote Control
1 x User Manual
Home Mode
Arm
Panic
Disarm
LED indicator
Before Using for the First Time
Register the remote control in the alarm system
Switch to Connection Mode on the control panel. Then press any key on
the remote control. The control panel beeps once: the remote control is
registered. If you hear two beeps, the remote control has already been
connected.
www.etiger.com
ES-RC1
Remote Control
Usage
Key Operation Function
Arm Arms the security system
Disarm Disarms the security system
Home
Mode
Arms all the sensors but the ones in
zone A. Sensors in zone A will not
trigger the alarm (Home Mode).
Panic
Triggers the alarm regardless the status
of the alarm system. The control panel
dials the stored phone numbers.
+ Arm
(in Mute mode) Arms the system silently
+
Disarm
(in Mute mode) Disarms the system silently
Specications
Power Supply:
DC 3V (CR2025 button battery x1)
Operation current:
≤7 mA
Transmission distance:
≤ 80 m (in open area)
Radio-frequency:
315MHz (±75KHz)
Housing material:
ABS plastic
Operating conditions:
Temperature: -10°C ~ +55°C
Relative Humidity: ≤80%
(non-condensing)
Dimensions:
57 x 31 x 11 mm
LED indications
Blinks once
Sends transmitting signal
Low light
Low battery, replace the battery immediately
Standards
This product bears the selective sorting symbol for waste electrical
and electronic equipment (WEEE). This means that this product must
be handled pursuant to European Directive 2002/96/EC in order to be
recycled or dismantled to minimize its impact on the environment. For
further information, please contact your local or regional authorities.
Electronic products not included in the selective sorting process are
potentially dangerous for the environment and human health due to
the presence of hazardous substances.
In compliance with European laws.
This product was designed and manufactured in compliance with
Directive 2002/95/EC of the European Parliament and of the Council on
the restriction of use of certain hazardous substances in electrical and
electronic equipment (RoHS Directive - RoHS) and is deemed to comply
with the maximum concentration values set by the European Technical
Adaptation Committee (TAC).
Manufactured in China.
Images, illustrations and text are non-contractual. ETIGER and the ETIGER logo are
registered trademarks and the property of ETIGER.
Copyright © 2014 ETIGER. All rights reserved.
ETIGER EUROPE
Rue de la Loi, 25, 7100 La Louvière, Belgique
service@etiger.com
This user manual is available in other languages at
www.etiger.com/eu/support
ES-RC1-UM-ENFR20140725-2.1-W
FCC Information and Copyright
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
15.19 Labelling requirements.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1)This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
