RoamAbout R2 Wireless Access Platform
802.11a/b/g Radio Card
Quick Installation Guide
This document provides the RoamAbout R2 Wireless Access Platform 802.11a/b/g radio card
installation information, Radio Certification and Regulatory information.
Wireless LAN and Your Health
Wireless LAN products are radio devices that emit radio frequency electromagnetic energy. The
level of energy emitted by a Wireless LAN device is much less than the electromagnetic energy
emitted by devices like mobiles phones.
Because Wireless LAN products operate within the guidelines found in radio frequency safety
standards and recommendations, Enterasys believes this product is safe for use by consumers.
These standards and recommendations reflect the consensus of the scientific community and
result from deliberations of panels and committees of scientists who continually review and
interpret the extensive research literature.
Important Safety Instructions
When using this product, always follow the basic safety precautions to reduce the risk of fire,
electric shock and injury to persons, including the following:
1. Always install the products as described in the documentation that is included with your
product.
2. Do not use the product near water, for example, near a bath tub, wash bowl, kitchen sink or
laundry tub, in a wet basement or near a swimming pool.
3. Avoid using this product during an electrical storm. There may be a remote risk of electric
shock from lightning.
4. Do not use this product to report a gas leak in the vicinity of the leak.
Caution: Changes or modifications made to this device which are not expressly approved by the
party responsible for compliance could void the user’s authority to operate the equipment.
P/N 9034079-01
![](/img.php?id=473927&img=bg2.png)
2 of 6
Regulatory Information
You must install and use this device in strict accordance with the manufacturer’s instruction as
described in the user documentation that is included with your product.
Before you follow the instructions or use of this product, carefully read the contents of this
document for device-specific constraints or rules that may apply in the country where you want to
use this product. The user must always ensure that country and/or channel selection of Peer-to-
Peer groups or Base Station Networks match the regulations of the country of operation.
In some situations or environments, the use of wireless devices may be restricted by the proprietor
of the building or responsible representatives of the organization. These situations may for
example include:
• Using the wireless equipment on board of airplanes, or
• In any other environment where the risk of interference to other device or service is perceived
or identified as harmful.
If you are uncertain of the policy that applies to the use of wireless equipment in a specific
organization or environment (e.g.airplane), you are encouraged to ask for authorization to use this
device prior to turning on the equipment.
The manufacturer is not responsible for any radio or television interference caused by
unauthorized modification of the device, or the substitution or attachment of connecting cables
and equipment other than specified by the manufacturer. The correction of interference caused by
such unauthorized modification, substitution or attachment will be the responsibility of the user.
The manufacturer and its authorized resellers or distributors are not liable for any damaged or
violation of government regulations that may arise from failing to comply with these guidelines.
Canada - Industry Canada (IC)
This Class B digital apparatus meets all requirements of the Canadian Interference-Causing
Equipment Regulations.
cet appareil de la class B respecte toutes les exigences du Reglement sur le matereil brouiller du
Canada.
USA - Federal Communications Commission (FCC)
This device complies with Part 15 of FCC Rules. Operation of the device is subject to the following
two conditions (1) This device may not cause harmful interference, and (2) this device must accept
any interference that may caused undesired operation.
Exposure to Radio Frequency Radiation
Caution: To comply with the FCC RF exposure compliance requirements, the following antenna
installation and device operating configurations must be satisfied:
For integral and external antenna configurations:
The operation distance between the antenna and any other person’s body (including hands, wrists,
feet and ankles) must be at least 20cm (8 inches).
![](/img.php?id=473927&img=bg3.png)
3 of 6
Federal Communications Commission Notice
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generated, uses, and can radiate radio frequency energy. If not installed and used
in accordance with the instructions, it may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a residential installation.
If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encourage to try and correct the
interference by one or more of following measures:
• Reorient or relocate the receiving antenna.
• Increase the distance between the equipment and the receiver.
• Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
• If you have a problem with your wireless equipment, such as interference from your
equipment to a Mobile Object Identification System (RF-ID), contact your authorized reseller
or manufacture.
Radio Approval
Use the following table to determine whether you are allowed to use your wireless device in the
countries listed below. You can find the radio transmitter number of your device on the
identification label of your wireless device.
For the latest version of this document, check the web site at:
www.enterasys.com/products/wireless
Country Enterasys Part Number Approval Number
USA RBTBH-R2W FCC ID: QXO-RBTBHR2W
Canada RBTBH-R2W IC: 4138-RBTBHR2W
![](/img.php?id=473927&img=bg4.png)
4 of 6
Channel Information
802.11a
US/Canada: 12 non-overlapping channels (5.15 ~ 5.35 GHz, 5.725 ~ 5.825 GHz)
Channel Frequencies and Channel Numbers for Operating in the US are listed in the following
table.
* 5.15 - 5.25 GHz is for indoor use only
802.11b/g
US/Canada: 11 (1 ~ 11)
Frequency Band Channel Number Center Frequencies
U-NII lower band
5.15 - 5.25 GHz*
36
40
44
48
5.180 GHz
5.200 GHz
5.220 GHz
5.240 GHz
U-NII middle band
5.25 - 5.35 GHz
52
56
60
64
5.260 GHz
5.280 GHz
5.300 GHz
5.320 GHz
U-NII upper band
5.725 - 5.825 GHz
149
153
157
161
5.745 GHz
5.765 GHz
5.785 GHz
5.805 GHz
![](/img.php?id=473927&img=bg5.png)
5 of 6
Radio Card Installation
Refer to the RoamAbout R2 Wireless Platform Hardware Installation Guide to install the RoamAbout
R2.
1. Refer to the Regulatory and FCC requirements located in this document before you install the
card into the RoamAbout R2.
2. Ensure that the power to the RoamAbout R2 is off.
3. To install the Radio Card, perform the following steps:
a. Position the card as shown below.
b. Carefully insert the card.
c. Press down firmly to seat the card. The following figure shows the radio card inserted
into the RoamAbout R2.
4. Refer to the RoamAbout R2 Wireless Platform Hardware Installation Guide for cabling and startup
information.
Radio Card
![](/img.php?id=473927&img=bg6.png)
6 of 6
Enterasys Networks reserves the right to make changes in specifications and other information contained in
this document and its web site without prior notice. The reader should in all cases consult Enterasys
Networks to determine whether any such changes have been made.
The hardware, firmware, or software described in this document is subject to change without notice.
IN NO EVENT SHALL ENTERASYS NETWORKS BE LIABLE FOR ANY INCIDENTAL, INDIRECT,
SPECIAL, OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING BUT NOT LIMITED TO LOST
PROFITS) ARISING OUT OF OR RELATED TO THIS DOCUMENT, WEB SITE, OR THE INFORMATION
CONTAINED IN THEM, EVEN IF ENTERASYS NETWORKS HAS BEEN ADVISED OF, KNEW OF, OR
SHOULD HAVE KNOWN OF, THE POSSIBILITY OF SUCH DAMAGES.
Enterasys Networks, Inc.
50 Minuteman Road
Andover, MA 01810
© 2004 Enterasys Networks, Inc. All rights reserved.
Part Number: 9034079-01 September 2004
ENTERASYS, ENTERASYS NETWORKS, ROAMABOUT, and any logos associated therewith, are
trademarks or registered trademarks of Enterasys Networks, Inc. in the United States and other countries.
All other product names mentioned in this manual may be trademarks or registered trademarks of their
respective companies.
