Fego Precision Co TP36RF315 Transmitter User Manual TP36 RF

Fego Precision Industrial Co Ltd Transmitter TP36 RF

Users Manual

Transmitter：TP36RF315
SPEC
Power：AAA battery*2
Distance：40 feet(air)
Frequency：RF 315 MHZ fixed frequency.
ID：65535 sets
Dim：DIP SW ON -> Light Dimmer，OFF -> Light On/Off。
FAN Function
OFF KEY：Fan off
HI KEY：Fan high speed
MED KEY：Fan medium speed
LO KEY：Fan low speed
LIGHT Function
LIGHT KEY：Light on/off or Dimmer。
Receiver：RL-142
Spec
Power：120V/60HZ
Frequency：RF 315MHZ.
FAN：Hi-Med-Lo 3 speeds.
LIGHT：Light On/Off or dim is controlled by Transmitter DIP SW.
FAN Function
HI：Fan runs in high speed and the receiver long beeps for 3 times.
Med：Fan runs in medium speed and the receiver long beeps for 2 times.
Low：Fan runs in low speed and the receiver long beeps for 1 times.
Off ：Fan stops running and the receiver beeps for 4 times.
LIGHT Function
Non-dim mode：Light runs only full On and Off. The receiver short beeps for one time. This
mode is only used for CFL bulb.
Dim Mode：Light can be dimmed. It dims from lightest to lowest back and forth. When the
light is the brightest or lowest, it short beeps for 2 times. This mode is not suitable for CFL
bulb.
FAN & LIGHT Memory Function
The Receiver would memorize the FAN speed and Bulb brightness. If in Dim mode, the
brightness of the bulb would be memorized in the receiver. When the AC power is turned off
for more than 2 seconds and then back to work, the FAN speed and bulb will recover.
Automatic Pairing
The receiver and transmitter pair each other automatically. By learning process, the receiver
memorize the transmitter code in build-in memory automatically.
Learning process: in one minute when the receiver first time gets powered, press and hold the
Off button on the transmitter for about 5 seconds. The receiver beeps for 4 times to complete
the learning process. The pairing is done and you can start to use it.
FCC ID : M8CTP36RF315
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
“Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.”
