This Quick Start Guide gives you the basics to
start using your AXV5000SR. Please visit
www.axxeraaudio.com/support/manuals.php
to download a complete owner’s manual or call customer
service at 1-866-382-5476
(Monday-Friday, 9AM-5PM EST)
Wall Mount Radio
Button Operation
1 2 3 4 5 6
7
9
101218
11131415161723 19
2022
21
8
24
APP Control
The Axxera iPlug™ Smart App is the ultimate wireless remote control for your
AXV5000SR receiver. You can download the Axxera iPlug app from Apple
Appstore or Google Playstore and install it on your smartphone or tablet.
Step 1:
Cut a mounting hole referring
to the cutout diagram on
the right side
Step 2:
Put a cushion on the left
and right side of the unit
as shown on the right side
and slide the unit into the
mounting hole.
Step 3:
Connect wiring harness
and antenna and mount
the unit using screws
Snap trim ring into place
Mounting the Head Unit:
ISO mounting
FCC Compliance
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
Warning: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Axxera Electronics Corp.
Toll Free: 1-866-382-5476
Monday-Friday, 9AM-5PM
www.axxeraaudio.com
©2014 Dual Electronics Corp. All rights reserved.
The SD logo is a trademark of the SD Card Association.
iPhone, iPod, iPod classic, iPod nano, and iPod touch are trademarks of Apple Inc., registered in the U.S. and other countries.
“Made for iPod” and “Made for iPhone” mean that an electronic accessory has been designed to connect specifically to iPod or iPhone,
respectively, and has been certified by the developer to meet Apple performance standards. Apple is not responsible for the operation of
this device or its compliance with safety and regulatory standards. Please note that the use of this accessory with iPod or iPhone may affect
wireless performance.
The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Namsung is under license.
Pandora, the Pandora logo, and the Pandora trade dress are trademarks of Pandora Media, Inc., used with permission.
Other trademarks and trade names are those of their respective owners.
N SA 0 318 - V 01
Bluetooth® Operation*
Preparation Before using a Bluetooth device, it must be paired and
connected. Ensure that Bluetooth is activated on your
device before beginning the pairing process.
Pairing a New
Device
The head unit broadcasts the pairing signal constantly
when no devices are connected. Complete the pairing
sequence from your Bluetooth device. Refer to the
owner’s manual for your device for more details.
The device name is “AXV5000SR”
The Bluetooth passcode is "1234”
Note: If passcode "1234" does not pair your device to
the receiver, use passcode "0000".
Note: The head unit can be in any mode of operation
when pairing is performed.
Streaming Audio
Troubleshooting
•Press
ll
to skip to the next available audio track.
•Press
nn
to skip to the previous audio track.
•Press
l
/
II
to toggle between play and pause during
playback.
The head unit supports A2DP wireless streaming audio
from a Bluetooth mobile device directly to your head unit.
The following functions can be used to control the music:
General Operation
Power On/Off Press the button to turn the unit on. Press again to
turn unit off.
Volume Adjust volume using volume + and - Button.
Mute Press to silence the audio. Press again to resume
listening at the previously selected volume.
Auxiliary Inputs Insert a 3.5mm cable in the units front AUX port, or RCA
cables into the rear AUX-IN connectors.
Reset Press the RESET button to reset the unit back to the
factory settings if abnormal operation occurs. The reset
button is located behind the front panel.
Setting the Clock With the unit on, press and hold DISP until the clock
begins to flash, then release. Press Volume + and - to adjust
the clock. Press DISP button one more time, then the minute
begins to flash. Press Volue + and - to adjust the minute.
Press DISP again to save the selected time
Display Press DISP to toggle display between various displayed
information.
Audio / Menu Press and hold AUDIO/MENU to enter the menu.
Press AUDIO/MENU to select between menu (Auto Store,
Freq USA/EURO, DX/LOC, Stereo/Mono, Demo On/Off,
Programmable Volume, Sleep, Alarm, BT, Reset, and Beep)
and press Volume + and 1 to adjust options
Changing Modes Press MODE to select between AM/FM, Front Aux,
Rear Aux, USB and Bluetooth modes. Modes of operation
are indicated in the display.
AM/FM Tuner Operation
Seek Tuning
Manual Tuning
Band
Storing Presets
Recalling
Presets
Press TUNE
nn
or TUNE
ll
for more than one
second to seek to the next strong station.
Press TUNE
nn
or TUNE
ll
momentarily to move
radio frequency up or down one step at a time. Press and
hold to advance quickly.
Press BAND to select between FM1, FM2, FM3, AM1
and AM2 bands. Up to six presets can be programmed
for each band, enabling up to 18 FM stations and 12 AM
stations to be stored in memory.
Up to 18 FM and 12 AM stations can be stored. To store
a station, select the desired band and station. Press and
hold the desired preset button (1-6) for more than two
seconds. When stored, the preset number will appear in
the display.
Preset stations can be recalled any time by pressing the
corresponding preset button.
Speaker Zone Control Operation
Press the Zone “F” button to turn on/off the sound from this zone.
Speaker Front
Speaker Zone 1
Speaker Zone 2
Press the Zone “1” button to turn on/off the sound from this zone.
Press the Zone “2” button to turn on/off the sound from this zone.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
Mute/Dimmer
Mode
Disp
Preset #1/Repeat
Preset #2/Random
Preset #3/Intro scan
Preset #6/Folder Up
IR Remote Sensor
Preset #5/Folder Down
USB Slot
Aux Input
Preset #4/Play/Pause
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
23.
24.
Tune/Track Up
Tune/Track Down
Volume Up
Volume Down
Reset
Zone2 Speaker On/Off
Band/Esc
Zone1 Speaker On/Off
Search/Select
Front Speaker On/Off
Power
Audio/Menu
Wiring Diagram - Inputs/Outs
VIOLET
VIOLET/BLACK
BLUE
AMP REMOTE
ACC
GRAY
GRAY/BLACK
WHITE
WHITEVBLACK
LIGHTGGREEN
LIGHTGGREENVBLACK
ZONE1 SPEAKER R
ZONE1 SPEAKER L
ZONE2 SPEAKER R
ZONE2 SPEAKER L
ANT
Remote Control Operation
1 2 3
4
5
6
7
810
12
11
14
13
16
15
18
17
9
