2ALHR004ModuleUser'sManual



1. Features

‐ On‐chiplowpowermicrocontroller

‐ 128KBofIn‐systemprogrammableflash

‐ 8KBSRAM

‐ OnboardcrystalandPFAAntenna

2. Application

‐ Mobiledeviceaccessories(Android/iOS)

‐ Wirelessdatacommunication

‐ Remotesensors

3. Pindefinition



PinNo.DescriptionPinTypeFunctions

1BLE_RXDigitalI/OUARTRX

2BLE_TXDigitalI/OUARTTX

3WAKE_UPOutputDigitalI/O

4STATUSInputDigitalI/O

5GNDDigitalI/OGND

6V+DigitalI/OVDD

7BLE_ENDigitalI/OVDDEnable

4. Howtouse:

‐ BeforesendinganyUARTCommand,"WAKE_UP10"mustbedoneby

externalMCU.

‐ IftheCC2640moduleisconnectedtoSmartDevices(Android/iOS),thepin

STATUSwillbelogic"1"toinformexternalMCU.

‐ Beacon



1. SendCommand'D'/'P'tosendlivemeasureddatafromexternalthrough

Beacon.

2. Thisisdefaultmode,and2ALHR002modulesenddataonly.Cannot

receiveanydata.

‐ BLE



1. SendCommand'M'toswitchmodefromBeacontoBLE.

2. Afterthemodeswitchsuccessfully,theexternalMCUcanreceivedata

fromSmartphone.

‐ Receiver



1. SendCommand'A'/'B'toswitchmodefromBeacontoReceiver.

2. OnlyspecificBeacondatacanbereceived,andtheexternalMCUreceives

thedatafromUART

5. Protocol:

‐ UARTBaudRate:115200,8,N,1

‐ Commands

'D':SendMeasuredData

ExternalMCU2ALHR004Module

StarterLenOPBattery DataCKEnd

#D(0D0A)h

ExternalMCU2ALHR004Module

StarterLenOPIndiCKEnd

>D (0D0A)h



'P':SendProductInformation

ExternalMCU2ALHR004Module

StarterLenOPFPProd.S/NCal.DateCKEnd

#P(0D0A)h

ExternalMCU2ALHR004Module

StarterLenOPIndiCKEnd

>P (0D0A)h



'M':ModeSwitch

ExternalMCU2ALHR004Module

StarterLenOPS/NCKEnd

#M (0D0A)h

ExternalMCU2ALHR004Module

StarterLenOPIndiCKEnd

>M (0D0A)h



'A':ScanProductInformation

ExternalMCUVEABT001Module

StarterLenOPCKEnd

'#''A' (0D0A)h



ExternalMCUVEABT001Module

StarterLenOPSNAPOBattRSSICKEnd

'>''A'     (0D0A)h



'B':ScanMeasuredData

ExternalMCUVEABT001Module

StarterLenOPSNCKEnd

'#''B'  (0D0A)h

ExternalMCUVEABT001Module

StarterLenOPAPOBattDataRSSICKEnd

'>''B'     (0D0A)h


