SOUNDS SO CLEAR
NURSERY MONITOR
Product Number: 71580
•Adult assembly is required to install the battery (if used).
•For proper setup and use, please read these instructions
and keep for future reference.
•Includes one AC adaptor to power receiver (plugs into
standard household outlets –120V AC). Receiver also runs
on battery power (9V alkaline battery – not included).
•Includes one AC powered transmitter (plugs into standard
household outlets – 120V AC).
PROBLEMS AND SOLUTIONS
PROBLEMS SOLUTIONS
1Transmitter power off. Power indicator not lit.
2You hear static or buzzing because transmitter channel switch is not on
same channel as receiver.
3Transmitter power off. Power indicator not lit. Light switch that controls
power flow to wall outlet off.
4Transmitter power off. Power indicator not lit. AC power cord
plug-to-outlet not connected.
5Transmitter power off. Power indicator not lit. Power is off because
circuit breaker for baby’s room off.
6You hear static or buzzing and all
five bars lit on receiver.
1Turn transmitter power on. Power indicator lights.
2Make sure channel switches on both transmitter and receiver set to same channel.
3Make sure light switch that controls power flow to wall outlet is on.
4Check AC power cord plug-to-outlet connections.
5Make sure house fuses and circuit breakers are on.
6Check all five solutions above. Any one or more of these solutions should solve
the problem.
Helpful Hint: If, after checking all of these solutions, you believe that your transmitter
AC power cord or receiver AC adaptor is damaged, please call Fisher-Price®at
1-800-432-KIDS.
PROBLEM
You can hear conversations or
sounds from other homes. There is
signal interference due to other
nursery monitors on same channel
or cordless telephones.
SOLUTION
Change channel switches on both trans-
mitter and receiver to eliminate source
of interference.
Helpful Hints:
- Do not use more than one transmitter
and one receiver at same time in same
household.
- Always remember that you are using
public airwaves when using your moni-
tor. Conversations, even from rooms
near transmitter, may broadcast to other
nursery monitors, radios, cordless tele-
phones, or scanners outside your home.
To protect privacy of your home, always
turn transmitter off when not in use.
PROBLEM SOLUTION
Circuit Breaker
3
1
2
4
2
6
BUZZZZ
BUZZZZZ
BUZZZZZ
5
STATIC
STATIC
STATIC
2
“Ma, ma, ma.
Da, da, da…”
“Did you read
about…”
“Did you read
about…”
“Wah, Wah,
Wah…”
“Wah, Wah,
Wah…”
“Wah, Wah,
Wah…”
1
You hear static or buzzing because receiver is out
of range of transmitter.
Note: Range varies depending on surrounding
conditions such as noise levels, physical obstructions
and signal interference.
Move receiver closer to transmitter.
Helpful Hint:
- If you cannot hear your child and all five bars do not light, your
receiver battery is weak. Replace receiver battery with a fresh,
9V alkaline battery or use AC adaptor for power source.
TM
IMPORTANT!
• This product is not intended to be used as a medical monitor
and its use should not replace adult supervision.
• Test sound reception of receiver before first-time use and
whenever you change location of transmitter.
• To prevent entanglement:
- Never place transmitter in a crib or playpen. Keep transmitter
and receiver out of baby’s reach.
- Never use extension cords with transmitter or AC adaptor.
• Never use transmitter, receiver or AC adaptor near water
(ie.: bathtub, sink, laundry tub or wet basement, etc.).
• Always use transmitter, receiver and AC adaptor where there is
adequate ventilation. To prevent overheating, keep transmitter,
receiver and AC adaptor away from heat sources such as
radiators, heat registers, direct sunlight, stoves, amplifiers, or
other appliances which produce heat.
CAUTION
This product cannot replace
responsible adult supervision.
Place transmitter in room in
which you intend to use it. Slide
transmitter power switch to turn
power on. Turn on a radio.
Test transmitter transmission and receiver reception.
Place receiver in room in which
you intend to use it. Rotate
on/off/volume dial to turn power
on. Adjust receiver location.
Hint: If you turn receiver power on
before transmitter power, you will
hear a static noise and all five
bars in variable light display light.
Simply turn volume down and turn
transmitter power on.
If you experience interference
(buzzing or static, etc.) while
using one channel setting,
switch both units to other
channel. Selecting a channel is
usually a one time adjustment.
9V (6LR61)
SHOWN ACTUAL SIZE
• Locate battery compartment door on back of receiver.
• Loosen screw in battery compartment door.
• Open battery compartment door and snap terminals of a fresh,
9V alkaline battery into receiver connectors.
• Close battery compartment door. Tighten screw with Phillips screwdriver.
Do not over-tighten.
• Remove the battery during long periods of non-use. Always remove
an exhausted battery from the product. Battery leakage and corrosion
can damage the product. Dispose of the battery safely.
• Never short circuit the battery terminals.
• A non-rechargeable battery is not to be recharged.
• Only a battery of the same or equivalent type as recommended in
the “Receiver Battery Installation” instructions is to be used.
• If a removable rechargeable battery is used, it is only to be charged
under adult supervision.
• A rechargeable battery is to be removed from the product before it
is charged.
• If you use a battery charger, it should be examined regularly for
damage to the cord, plug, enclosure and other parts. Do not use a
damaged battery charger until it has been properly repaired.
IMPORTANT! Test sound reception of this monitor before
first time use and whenever you change location of
transmitter (see this page).
1Set transmitter channel switch to same channel as receiver.
2Place transmitter in same room with child. Point microphone
directly toward crib or play area.
3Plug AC power cord into wall outlet.
4Slide transmitter on/off switch to turn power on. Power
indicator lights.
5Place receiver where you will see or hear it.
6Unwrap and fully extend AC adaptor cord for best reception. Insert
AC adaptor jack into receiver socket and plug into wall outlet.
Note: To use a 9V alkaline battery for power source, refer to
“Receiver Battery Installation” instructions on this page.
7Rotate receiver on/off/volume dial to turn power on. Power
indicator lights. Rotate on/off/volume dial to adjust volume.
Battery Compartment Door
2
3
“Peek-a-boo…”
4
1
Occasionally a consumer may experience a problem with one of our
products. If this should happen, please call us, toll-free, rather than
return this product to the store. Usually we can solve the problem on
the telephone or by sending you replacement parts. Please call
Fisher-Price®Consumer Affairs, toll-free at 1-800-432-KIDS, 8 AM - 5 PM
EST Monday through Friday. Hearing-impaired consumers using TTY/TDD
equipment, please call 1-800-382-7470. Or, write to: Fisher-Price®
Consumer Affairs, 636 Girard Avenue, East Aurora, New York 14052.
Excess dirt in transmitter microphone will hamper transmission
of sound. Clean outer surface of transmitter and receiver with
a cloth lightly dampened with a mild cleaning solution.
Never immerse transmitter, receiver or AC adaptor.
Note: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equip-
ment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interfer-
ence to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Consult the dealer or an experienced radio/TV technician
for help.
Sounds So ClearTM Nursery Monitor
Model Number: 71580
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
Sounds So ClearTM Nursery Monitor
Consumer Affairs Department
636 Girard Avenue
East Aurora, New York 14052
Any modification of the transmitter or receiver will violate FCC
compliance and can void the user’s authority to operate the
equipment.
Fisher-Price, Inc., 636 Girard Avenue, East Aurora, New York
14052 warrants that the
Sounds So ClearTM Nursery Monitor
is free
from all defects in material and workmanship when used under
normal conditions for a period of one (1) year from the date
of purchase.
Should the product fail to perform properly, we will repair or
replaceit at our option, free of charge. Purchaser is responsible
for shipping the product to Consumer Affairs at the address indi-
cated above and for all associated freight and insurance cost.
Fisher-Price, Inc., will bear the cost of shipping the repaired or
replaced item to you. This warranty is void if the owner repairs
or modifies the product. This warranty excludes any liability
other than that expressly stated above including but not limited
to any incidental or consequential damages.
SOME STATES DO ALLOW THE EXCLUSION OR LIMITATION OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE
LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU
MAY ALSO HAVE OTHER RIGHTS WHICH MAY VARY FROM STATE
TO STATE.
The electronic components in transmitter, receiver and AC
adaptor are not designed for consumer repair. Evidence of
any attempt of consumer repair will void this warranty.
If you have any questions about this product:
In Canada, call 1-800-567-7724, or write to: Mattel Canada Inc., 6155 Freemont Blvd.,
Mississauga, Ontario L5R 3W2.
In Great Britain, telephone 01628 500303.
In Australia, Mattel Australia Pty. Ltd., 658 Church Street, Locked Bag #870, Richmond,
Victoria 3121 Australia. Consumer Advisory Service 1-800-800-812 (valid only in Australia).
Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, New York 14052, U.S.A.
©1999 Mattel, Inc. All Rights Reserved.
® and ™ designate U.S. trademarks of Mattel, Inc.
Printed in Hong Kong 715780pr-0920
7
1
5
6
“Peek-a-boo…”
RECEIVER BATTERY
INSTALLATION
TESTING SOUND
RECEPTION
BATTERY TIPS
FCC NOTE
(UNITED STATES ONLY)
ONE (1) YEAR
LIMITED WARRANTY
SETUP AND USE CARE
CONSUMER
INFORMATION
Notes:
• Variable light display lights when sound is received by receiver.
• If all five bars in variable light display light:
- Receiver power is on and transmitter power is off.
- Receiver is too far away from transmitter.
- Receiver and transmitter are not on same channel.
- Loud sounds are transmitting.
