PROPRIETARY
RF Module
User Guide
Doc Number: 930-00004-01
Proprietary Information
Revision History
DATE REVISION DESCRIPTION AUTHOR
8/04/2007 01 Initial release Steven Oliver
8/13/2007 02 FCC modifications John MacLean
Approvals
The information contained in this document is the sole property of FitSense Technology. Any
reproduction in part or whole without the written permission of FitSense Technology is
prohibited.
FitSense Technolog
y
RF MODULE DOC #: 930-00004-01 REVISION: 02
© 2006 FITSENSE TECHNOLOGY CONFIDENTIAL PAGE 2 OF 3
1 User Guide
1.1 Introduction:
The RF Module (RFM) enables any PC based product with a USB port to provide wireless
communication between FitSense Sensors.
1. Installation:
Installaton and Serviceing is only to be performed by a qualified
technician trained by FitLinxx in the installation of this module.
1. Locate the USB port on the Equipment.
2. Install the RF Module USB cable in to the USB port.
3. If USB connection is made internally to the PC the cables must be stripped back and soldered
onto the appropriate USB signal pins. This can only be performed by a FitSense qualified
technician!
RF MODULE DOC #: 930-00004-01 REVISION: 02
© 2006 FITSENSE TECHNOLOGY CONFIDENTIAL PAGE 3 OF 3
1.3 Operation:
The RF Module will transmit RF packets to FitSense Test Equipment called the Wirless Sensing Module.
When you run the program WSM.exe on the Personal Computer the RF Module is connected to, all the
LEDs on the WSM will light up showing the RF module is transitting and receiving.
1.4 Regulatory:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference and (2) this device must accept any
interference received, including interference that may cause undesired operations.
Changes or modifications not expressly approved by the party responsible for compliance
could void the users authority to operate the device.
