Fleetwood Group VL4B Low Power RF and IR Module User Manual CERTIFICATE OF COMPLIANCE
Fleetwood Group Inc Low Power RF and IR Module CERTIFICATE OF COMPLIANCE
User Manual
Rhein Tech Laboratories, Inc.
Client:
Fleetwood Group, Inc.
360 Herndon Parkway
Model:
VL4B
Suite 1400
Standards:
FCC 15.231/IC RSS-210
Herndon, VA 20170
http://www.rheintech.com
FCC/IC ID:
FBRVL4B/1859A-VL4B
Report #:
2010155
Page 27 of 38
Appendix K : Manual
Please refer to the following pages.
USER MANUAL
VL4B Module
ii
Copyright 2007 Fleetwood Group, Inc., Electronics Division. All rights reserved. Licensed software products are
owned by Fleetwood Group, Inc. or its suppliers and are protected by United States copyright laws and international
treaty provisions.
Fleetwood Group, Inc. products are covered by U.S. and foreign patents, issued and pending. Information in this
publication supersedes that in all previously published material. Specifications and pricing are subject to change
without notice.
Printed in the U.S.A.
Fleetwood Group, Inc.
Electronics Division
11832 James St.
Holland, Michigan 49424
www.fleetwoodgroup.com
Sales: 1-800-257-6390
Technical Service: 1-888-GO-REPLY (467-3759)
Reply® is a registered trademark of Fleetwood Group, Inc.
Other trademarks contained herein are the property of their respective holders.
Revision History:
Rev Date Description
A 8/11/2010 Original
iii
Table of Contents
1.0 VL4B MODULE ................................................................................................................................................... 4
1.1 DESCRIPTION ....................................................................................................................................................... 4
1.2 BATTERY REPLACEMENT ..................................................................................................................................... 4
1.3 FCC AND IC ......................................................................................................................................................... 4
1.4 STANDARDS AND GUIDELINES ............................................................................................................................. 4
1.5 FCC/IC COMPLIANCE .......................................................................................................................................... 5
4
1.0 VL4B Module
1.1 Description
The VL4B Module is an infrared transmitting badge with a RF supervisory signal. The VL4B Module contains a
low power RF transmitter chip which is controlled by a micro processor. The frequency synthesizer for generation
of the RF output carrier is received from a low frequency external crystal. A crystal resonator chip runs the micro
processor device. When an RF transmission needs to be generated the data from the microprocessor is sent to the RF
chip. The modulation used by the radio frequency chip is on/off key at 433.92MHz. The RF antenna is a PCB
etched loop. The VL4B is powered by a three-volt battery.
Both infrared and RF signals are independent of each other. Both infrared and RF signals contain recognition code
to identify the badge, along with motion status, battery status, and switch information.
There are two ways that theVL4B Module can send RF transmission packets. The first is an automatic transmission
per FCC regulations section 15.231 part (a) paragraph three, which states that the periodic rate of transmission does
not exceed one transmission of not more than one second duration per hour of each transmitter. The second type of
RF transmission occurs when a button is pressed on the badge. The RF transmission packets cease operation when
the button is released.
1.2 Battery Replacement
The VL4B is powered from a 3V battery. The battery is replaceable. To replace battery, open the case, remove the
old battery, and replace with a new battery noting its polarity. The negative side of the battery should be facing the
PCB.
1.3 FCC and IC
VL4B Module
Responsible Party Pertaining to the Declaration of Conformity
Fleetwood Group, Inc.
11832 James Street
Holland, MI 49424
Attn: Product Service Coordinator
Phone: 888-467-3759
1.4 Standards and Guidelines
This device complies with the following USA/Canada Regulations:
The USA Federal Communications Commission (FCC) Rules and Regulations
Industry Canada Rules and Regulations
This device complies with the following national and international standards:
FCC Part 15B, 15.231e (10-01-09)
IC RSS-210 Issue 7
5
1.5 FCC/IC Compliance
This device complies with Part 15 of the FCC Rules and RSS-210 of the Industry Canada Rules. Operation is subject to
the following two conditions: (1) this device may not cause interference and (2) this device must accept any interference,
including interference that may cause undesired operation of the device. The user is cautioned that changes or
modifications to the device that are not approved by the manufacturer could void the user’s authority to operate the device.
