Flying Dragon Development LT-0331 LANTERN User Manual BR Manual CampRocker 1

Flying Dragon Development Ltd. LANTERN BR Manual CampRocker 1

Contents

User Manual 2

Fully charge the lantern using the supplied Micro-USB charging cable.
1. Connect the micro-USB charing cable into the lanterns charging port at the
back of the lantern, and the USB end of the micro-USB charging
cable into your home power outlet (DC5V power sources). Or use a
computer or other 5V/1A power source. Plug the USB charging cable into the
USB port.
2. Standard charging time is around 4.5 hours. (Depending on the life of the
battery, the charging time will vary). Be careful not to charge it for more
than 8 hours. Over charging will damage the battery.
NOTE: The charging time and the operation time may vary depending on the use environment.
Status indicator:
The battery power indicator light indicates how much
battery life remains for the mode in use.
Light ashing = Charging
All lights on = Fully charged 100% battery life
Three light on = Around 75% battery life
Two light on = Around 50% battery life
One light on = Low battery > Around 25% battery life
How To Charge
Trouble Shooting
The lantern speaker doesn’t work or it won’t pair
• Try moving your device closer.
• Is the lantern turned on and charged?
• Turn the Bluetooth o and then on to wake it.
• Is Bluetooth enabled on your device or computer?
• Try repeating the setup procedure in this guide or pair with a dierent
Bluetooth device.
• The speaker plays music from one device at a time. Unpair the device not
being used. (Refer to your device documentation for help.) Pair a new
device using the setup procedure.
• If pairing with a computer, specify the lantern speaker as the audio out
device on the computer.
Operation with audio function
To play audio from a Bluetooth device, you need to pair the device with the
lantern speaker.
1. On your Bluetooth device, turn on Bluetooth and scan for devices in its
Bluetooth menu.
2. Turn on the Bluetooth when powering up for the rst time, the lantern
speaker is discoverable for 2 minutes and is ready for pairing. A short
sound will indicate the Bluetooth is on.
3. The device code of this lantern “BRUNTON C-ROCKER” will appear on the
device list of your Bluetooth device, select the lantern. The Bluetooth status
will show on your Bluetooth menu after pairing is established. The lantern
speaker is ready to play music.
Note: If the Bluetooth turns o after ve minutes, it enters power saving mode. Slide the power
switch o and then turn on to wake the Bluetooth, and try pairing your device again. Repeat
step 3.
Note: The lantern speaker operates with a single pair devices mode. If you pair the speaker with
another device, the device least recently connected needs to be un-paired with the speaker rst.
Repeat steps 2 and 3 above
Remark: Connect audio cable (not included) directly to AUX audio plug to play music without
Bluetooth connection.
Operation with power bank function
1. Select the suitable USB charging cable (dierent devices require
dierent charging cables for charging).
2. Put the USB cable into lantern USB output port, then put the other
side of the cable into the charging device (mobile, tablet, etc.) The device
will then start charging.
3. When the lantern battery is discharged, it will stop charging.
Operation with light function
To turn the lantern ON, press the main button.
Adjust the light mode (High / Low / Red / O) by pressing the main button.
To turn the lantern OFF, press the main button once after Red light mode.
Operation Instruction
Status indicator :
2
3
Turn on Bluetooth
>
>
Bluetooth devices
SEARCHING
(Dierent devices require
dierent charging cables
for charging - Cable(s)
not included.)
Charging 100% battery life 75% battery life 50% battery life 25% battery life
100% battery life
75% battery life
50% battery life
25% battery life
Status
indicator
“Low, High, Red, O” light switch
1
Bluetooth devices
ON
Bluetooth devices
Select this
CONNECT
BRUNTON C-ROCKER
Bluetooth devices
PAIRED
09012015 V1
