Foshan Lanchiya Digital Technology 00M11201 WIRELESS BLUETOOTH SPEAKER User Manual
Foshan Lanchiya Digital Technology Co., Ltd. WIRELESS BLUETOOTH SPEAKER
User Manual
SPECIFICATIONS
Amplifier output power: left/right 1.5Wx2, subwoofer 3.5Wx1
Amplifier input sensitivity: ≤400m V
Amplifier SNR:≥ 70dB
Frequency response:70Hz~20KHz
Power voltage: AC100-240V, 50/60Hz
Battery: 7.4V 1800mHA
Battery time 10hours
Battery charging time: 4-6hours
Blue tooth range: 7-10M(23-33FT)
Bluetooth version: 3.0 2.4G Support A2DP
M1
56
9. Built-in battery : when using the built-in battery to play music, the unit will
manage the battery use automatically, when the power is low, the unit will
decrease the volume to ensure the sound quality and longer play time; when
the power is not enough to support normal play, the indicator will flash and
the unit will be switch to standby, please use the prope r power adapter to
charge the unit for normal use.
10.Charging:, please use the supplied power adapter to charging, the green
indicator on the back of the unit will be flashing during charging. When
the battery is fully-charged, the green indicator will stop flashing.
AMETHYSTM 1
6.Re-pairing: To touc h the PAIR button on the control panel for re-pairing,
meanwhile the indicator will flash, and there is voice prompt that the unit
is ready to be paired. Please follow step 3 to do pairing.
7.AUX input play: Switch the M1 on, touch the INPUT button on the control
panel, the indi cator will flash once, and the unit will be connected to the
AUX channel play. The music in mobiles, MP3, PC, etc can be played through
3.5mm a udio cable. Press input again will turn to bluetooth channel and
reconnect automatic.
PAIR
INPUT
8.DC5V Charging output: the unit provide standard USB port charging, with
DC5V 1A charging current, which can charge mobiles, MP3, etc through
USB cable.。
FLASH
1.The Bluetooth device can't find the speaker, the speaker may still connect
with last Blue tooth device or another device are searching and connecting
with speaker at same time. Now you need to operate as Step 3 to re-connect it.
2. If you hear intermittent sound or no sound from speaker after connection.
Please check if the distance from you and speaker are over 10M(33FT)
3.To avoid echo when using the speaker phone function, do not place your
phone near or in front of the M1 speaker.
4.For best results it is recommended that Bluetooth enabled music player that
supports Apple iPod, iPhone, Samsung players, and Window media players
be used. Other, third party supported media players may not support smooth
song change functions, which may cause sound distortion or interruption
between song tracks.
5.Please use power adaptor which provide from Lanchiya to avoid damage
your speaker.
6.Please connect and disconnect adaptor when the switch is in OFF position
7.if your mobile doesn't support mobile ring transfer, you can only hear the
M1 Built in ring voice “ incoming call”, when calling come in.
NOTE
*
AMETHYST INNOVATIONS CORPORATION
14731-J Franklin Avenue Tustin, CA. 92780
Phone: 714-731-2921
Website: www.amethystinnovationscorp.com
5. Speaker Phone operation: When the call comes in during playing music,
answer the call by touching the button 【PHONE】on the touching panel and
talk facing the top panel; or dial the receiver button on the mobile to use mobile
to answer the call. Press and hold on 【PHONE】for 2 seconds to hang up the
phone during calling.
PHONE
1
1.M1 machine 2.Power adapter 3.Audio cable 4 User manual.
PACKAGE CONTENTS
Brief Operation Introduction
PROPERTY RIGHTS INFORMATION:
The trademark amethyst lanchiya and all the developed products with this label
are registered patents,and belong to Foshan LANCHIYA digitai Technology Co.,Ltd.
Our company reservesall rights,and not a l low repr i nti n g.O t her conc e rne d
tradem arks a ll b e lo ng t o t he ir p r o p r ie t o r s .As to the c o n s t a n t upd ate and
development of the products,our company reserves the right to change and
rework our products without notice.
SAF E T Y IN S TR UC T IO NS :
To e n s u r e y o u r s a f e t y a n d e n j o y m e n t , r e a d a n d f o l l o w t h e s a f e t y
i n s t r u c t i o n s a n d u s e i n t h e d i r e c t e d m a n n e r. K ee p t hi s m an u a l f o r
f u t u r e r e f e r e n c e .
WARING: To pr e v e nt a n y f i re o r el e ctri c al hazards, do not remove
or dissemble any parts from this unit. Please ensure that you use a
qualified technician to service it.
• Do not expose the unit to rain, water or moisture
• Do not place liquid on or close to unit
• Do not place unit on or near an open fire such as candles or light
• Keep away from heat and dust
• Place unit on a stable and level platform
• Do not place any items on top of unit
• Do not use excessive force when pushing the unit buttons
• Do not attempt to pull the power cord from a distance to shut the power
Children and dispose in appointed place for battery
• Secure all cords and connections and do not use pinched or defective one
• Unplug the power cord if the unit is left unused for extended periods
• Clean with a damp cloth only
• Operating temperature 0ºC-55ºC (32ºF~131ºF)
( FT)
•
• Blue tooth device can't be found: probably, the Speaker has been connected by
other Blue tooth device. Press Pair button to search it again. If you still cannot
find the speaker, please Turn Off the speaker for 5second then turn it on.
• Blue tooth signal intermittently: the effective distance between speaker and
Device is 10M, the signal will be intermittent if the distance more than 10M 33 .
• If there are more than 1 Speaker are switch on, the Bluetooth device will find
more than 1 speaker, if you want to connect one of them please turn off the others
• If your Bluetooth device on searching and find many other Bluetooth device,
please wait for the searching finished and select Speaker to pair.
The unit with Lithium Battery in please don't burn,bite,Keep away from
234
1.Connection: Using built in battery or Plug M1 into an outlet using the include
AC adaptor then switch it On Please make sure the switch is on off position
when you plug M1 with AC adaptor.
4
2. Power-on Operation: After switching M1 on, the indicator on the front panel
is on, and Voice remind [Power ON] then the Bluetooth channel; then starts
to search the device that connected last time. If the searching is successful,
M1 will connect automatically with the device, and voices 『pair completed』
then the Vocie remind”DU DU Du” for connect ready. M1 will play the music
through the device. If the searching is failed, M1 will be in the status of Ready
to pair.
FRONT PANEL
1. LED indicator
2. Preview
3. Play/pause
4. Next
5. Volume+
6. Input
7. Microphone
8. Pair,
9. Handsfree phone
10.Volume-
11. Charging indicator
12. DC in
13. Switch
14. AUX,
15.Charging out port
(DC 5V 1A)
BACK PANEL
1
2
34
5
6
7
8
9
10
11
12
13
14
15
TOP PANEL
3.Connecting to the Bluetooth device : Search and connect 【AMETHYST M1】
with your Bluetooth device.. The Invoice remind “Pair completed”. Then you
can play music from your Bluetooth device.
AMETHYST M1
4. Music-playing operation: When M1 has successfully connected to the Bluetooth
device properly, you can control the music-playing of the mobiles through
touching the PRE,NEXT,PLAY/PAUSE button on the touching panel.
PREV,NEXT,PLAY/PAUSE
AMETHYST M1
NOTE: It may take 4-6 hours to fully
charge the battery.
ON
OFF
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.These limits are
designed toprovide reasonable prot ection against h a r mf ul interference
in a re s i d e ntial installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instr ucti o n s , may ca u s e h a r m f ul interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
in s ta l lat io n. I f t hi s equipmen t does ca u s e harmful interference to radio
or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Conne ct the equipment into an outlet on a circu it different from that to
which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
Caution: The user is cautioned that changes or modifications not expressly
appro ved by the party responsible for compl iance could void the user's
authority to operate the equipment.
This equ ipment complies with FCC’s RF radiation exposure limits set forth
for an uncon trolled environment. The antenna(s) used for this transmitt er
must be instal led and operated to provide a separation distance of at least
20 cm from all persons and must not be collocated or operating in conjunction
with a n y other an t enn a or t r ansmitter.Installers must ensure that 20cm
separation distance will be maintaine d between the device (excluding its
handset) and users.
3
21
COMPLIANCE WITH FCC REGULATIONS
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference
that may cause undesired operation.
