Fujitsu Client Computing IOT008 Remote Monitoring Station User Manual Short Term Confidential
Fujitsu Limited Remote Monitoring Station Short Term Confidential
(Short-Term Confidential) User Manual
Remote Monitoring Station
Instruction Manual (detailed version)
How to Use This Manual
Pages 3 and 4 of this document contain the same information as the instruction manual “Usage Precautions”
sheet packaged with Remote Monitoring Station (“the product”). Pages in this section are not numbered.
If you require a printed copy of the instruction manual, please print pages 3 and 4 of this document on
B4 or larger sized paper.
Detailed information on the product’s functions is included from page 5 of this document. Please refer
to it when managing the system.
Content
■
Alarm Indication ................................................ 3
■
To users of this product ........................................ 3
■
Confirm included items prior to use ............................. 3
■
Ports and controls – main unit - ................................ 3
■ Power ON/OFF .................................................. 3
■
Installation of Remote Monitoring Station ....................... 3
■
Safety Notes .................................................... 4
■
Disposal ........................................................ 4
■
Additional Information .......................................... 4
■ Detailed information ........................................... 5
□ Function List ....................................................................................................... 5
□ Sound playback function.............................................................................................. 7
□ Limitations of each sensing ......................................................................................... 10
□ Main unit operation (Gateway Software Configuration Tool) ........................................................... 11
□ Main unit operation (Device Management Tool) ........................................................................ 12
□ Setting method when function is not used ............................................................................ 12
□ Product operation ( Button ) ........................................................................................ 13
□ LED list ........................................................................................................... 15
□ Connection of external devices ...................................................................................... 15
2
■
In this manual, various pictures are used to indicate alarm. These are signs to prevent
harms and
meaning are as
The following sign is used to show what one the content of harm and damage is.
The
Bluetooth
such marks by FUJITSU LIMITED is under license.
Google, Google logo, Google Play and Android
UBIQUITOUSWARE is a
All other trademarks specified here are
the property of their respective owners.
Copyright FUJITSU LIMITED 201
Please contact the source this product was obtained from
if you have any questions about using this product or if
■
This product’s functions and use may vary depending on how it was configured by the
source it was obtained
us).
Please ask for an explanation of this product’s functions and use when you receive
the product, or contact the source the product was obtained from for help.
*
This product is not meant to p
accidents, or damage caused through use of this product.
*
This product is not meant for specialized monitoring such as childcare, caregiving, or medical purposes.
We are not to be hel
for these applications.
■
Prior to using this product, confirm that the following items are included in the package. If anything is
please contact the source the product was obtained from. In addition to the included items listed on this sheet,
the package may also contain a sheet of instructions. Place
in safekeeping.
In addition, the attached articles of the stand for
■
□
□
□
Remote Monitoring Station
-
Alarm Indication
In this manual, various pictures are used to indicate alarm. These are signs to prevent
harms and
damages that
meaning are as
follows.
DANGER
WARNING
CAUTION
The following sign is used to show what one the content of harm and damage is.
The sign shown by
content of warning is shown in the sign and sideward of that.
The sign shown by
A concrete content of the prohibition is shown in the sign and sideward
of that.
The sign shown by
instruction is shown in the sign and sideward of that.
Bluetooth
®
word
mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of
such marks by FUJITSU LIMITED is under license.
Google, Google logo, Google Play and Android
UBIQUITOUSWARE is a
All other trademarks specified here are
the property of their respective owners.
Copyright FUJITSU LIMITED 201
Please contact the source this product was obtained from
if you have any questions about using this product or if
you
To users of this product
This product’s functions and use may vary depending on how it was configured by the
source it was obtained
us).
Please ask for an explanation of this product’s functions and use when you receive
the product, or contact the source the product was obtained from for help.
This product is not meant to p
accidents, or damage caused through use of this product.
This product is not meant for specialized monitoring such as childcare, caregiving, or medical purposes.
We are not to be hel
for these applications.
Confirm included items prior to use
Prior to using this product, confirm that the following items are included in the package. If anything is
please contact the source the product was obtained from. In addition to the included items listed on this sheet,
the package may also contain a sheet of instructions. Place
in safekeeping.
○
Remote Monitoring Station(main unit)
○
AC Adapter
○
Warranty Card
In addition, the attached articles of the stand for
○
Stand
■
Ports and controls
Front
Rear
Bottom
Screw hole
Consulting
Call Cancel Button
Pyroelectric sensor
Thermohygrometer sensor
BLE Pairing Button
WLAN Connect Button
Cable guide
Remote Monitoring Station
-
Precautions for use
Alarm Indication
In this manual, various pictures are used to indicate alarm. These are signs to prevent
damages that
might be added to you and other people. The display and the
follows.
DANGER
When this display is disregarded and wrong handling is done,
there is a high possibility that the person dies or sustains
severe injuries.
WARNING
When this
there is a possibility that the person dies or sustains severe
injuries.
CAUTION
When this display is disregarded and wrong handling is done,
there is a possibility that the person owes injury or the
property damage occurs.
The following sign is used to show what one the content of harm and damage is.
The sign shown by
content of warning is shown in the sign and sideward of that.
The sign shown by
A concrete content of the prohibition is shown in the sign and sideward
of that.
The sign shown by
instruction is shown in the sign and sideward of that.
mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of
such marks by FUJITSU LIMITED is under license.
Google, Google logo, Google Play and Android
trademark of FUJITSU LIMITED.
All other trademarks specified here are
the property of their respective owners.
Copyright FUJITSU LIMITED 201
6
To users of this product
Please contact the source this product was obtained from
if you have any questions about using this product or if
you
need help resolving any concerns.
More Information can be found on the Internet at:
http://www.fmworld.net/biz/uware/support/
To users of this product
This product’s functions and use may vary depending on how it was configured by the
source it was obtained
from (the business customer that purchased the product from
Please ask for an explanation of this product’s functions and use when you receive
the product, or contact the source the product was obtained from for help.
This product is not meant to p
accidents, or damage caused through use of this product.
This product is not meant for specialized monitoring such as childcare, caregiving, or medical purposes.
We are not to be hel
d responsible for incidents, accidents, or damage caused through use of this product
for these applications.
Confirm included items prior to use
Prior to using this product, confirm that the following items are included in the package. If anything is
please contact the source the product was obtained from. In addition to the included items listed on this sheet,
the package may also contain a sheet of instructions. Place
Remote Monitoring Station(main unit)
AC Adapter
Warranty Card
Confirm that all product serial numbers are entered on the warranty card.
In addition, the attached articles of the stand for
Stand
○Screw
○
Ports and controls
Screw hole
Consulting
Call Button
Camera LED
Call Cancel Button
Pyroelectric sensor
Thermohygrometer sensor
Mic
BLE Pairing Button
WLAN Connect Button
Cable guide
Remote Monitoring Station
Precautions for use
Alarm Indication
In this manual, various pictures are used to indicate alarm. These are signs to prevent
might be added to you and other people. The display and the
When this display is disregarded and wrong handling is done,
there is a high possibility that the person dies or sustains
severe injuries.
When this
display is disregarded and wrong handling is done,
there is a possibility that the person dies or sustains severe
injuries.
When this display is disregarded and wrong handling is done,
there is a possibility that the person owes injury or the
property damage occurs.
The following sign is used to show what one the content of harm and damage is.
The sign shown by
△
means prompts warning and attention. A concrete
content of warning is shown in the sign and sideward of that.
The sign shown by
means an act of not doing (prohibited activity).
A concrete content of the prohibition is shown in the sign and sideward
The sign shown by
●
means what you must do. A concrete content of the
instruction is shown in the sign and sideward of that.
mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of
such marks by FUJITSU LIMITED is under license.
Google, Google logo, Google Play and Android
is a trademark of Google Inc. or a registered trademark.
trademark of FUJITSU LIMITED.
All other trademarks specified here are
the property of their respective owners.
To users of this product
Please contact the source this product was obtained from
if you have any questions about using this product or if
need help resolving any concerns.
More Information can be found on the Internet at:
http://www.fmworld.net/biz/uware/support/
To users of this product
This product’s functions and use may vary depending on how it was configured by the
from (the business customer that purchased the product from
Please ask for an explanation of this product’s functions and use when you receive
the product, or contact the source the product was obtained from for help.
This product is not meant to p
revent entry or theft. We are not to be held responsible for incidents,
accidents, or damage caused through use of this product.
This product is not meant for specialized monitoring such as childcare, caregiving, or medical purposes.
d responsible for incidents, accidents, or damage caused through use of this product
Confirm included items prior to use
Prior to using this product, confirm that the following items are included in the package. If anything is
please contact the source the product was obtained from. In addition to the included items listed on this sheet,
the package may also contain a sheet of instructions. Place
Remote Monitoring Station(main unit)
Confirm that all product serial numbers are entered on the warranty card.
In addition, the attached articles of the stand for
○
Double-sided
Ports and controls
–
main unit
Remote Monitoring Station
Precautions for use
In this manual, various pictures are used to indicate alarm. These are signs to prevent
might be added to you and other people. The display and the
When this display is disregarded and wrong handling is done,
there is a high possibility that the person dies or sustains
severe injuries.
display is disregarded and wrong handling is done,
there is a possibility that the person dies or sustains severe
When this display is disregarded and wrong handling is done,
there is a possibility that the person owes injury or the
property damage occurs.
The following sign is used to show what one the content of harm and damage is.
means prompts warning and attention. A concrete
content of warning is shown in the sign and sideward of that.
means an act of not doing (prohibited activity).
A concrete content of the prohibition is shown in the sign and sideward
means what you must do. A concrete content of the
instruction is shown in the sign and sideward of that.
mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of
is a trademark of Google Inc. or a registered trademark.
trademark of FUJITSU LIMITED.
To users of this product
Please contact the source this product was obtained from
if you have any questions about using this product or if
need help resolving any concerns.
More Information can be found on the Internet at:
http://www.fmworld.net/biz/uware/support/
To users of this product
This product’s functions and use may vary depending on how it was configured by the
from (the business customer that purchased the product from
Please ask for an explanation of this product’s functions and use when you receive
the product, or contact the source the product was obtained from for help.
revent entry or theft. We are not to be held responsible for incidents,
accidents, or damage caused through use of this product.
This product is not meant for specialized monitoring such as childcare, caregiving, or medical purposes.
d responsible for incidents, accidents, or damage caused through use of this product
Confirm included items prior to use
Prior to using this product, confirm that the following items are included in the package. If anything is
please contact the source the product was obtained from. In addition to the included items listed on this sheet,
the package may also contain a sheet of instructions. Place
the included items along with the sheet of instructions
Remote Monitoring Station(main unit)
○
Precautions to use (this sheet)
○
Power cable
Confirm that all product serial numbers are entered on the warranty card.
In addition, the attached articles of the stand for
tape x2
○
main unit
Remote Monitoring Station
Precautions for use
In this manual, various pictures are used to indicate alarm. These are signs to prevent
might be added to you and other people. The display and the
When this display is disregarded and wrong handling is done,
there is a high possibility that the person dies or sustains
display is disregarded and wrong handling is done,
there is a possibility that the person dies or sustains severe
When this display is disregarded and wrong handling is done,
there is a possibility that the person owes injury or the
The following sign is used to show what one the content of harm and damage is.
means prompts warning and attention. A concrete
content of warning is shown in the sign and sideward of that.
means an act of not doing (prohibited activity).
A concrete content of the prohibition is shown in the sign and sideward
means what you must do. A concrete content of the
instruction is shown in the sign and sideward of that.
mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of
is a trademark of Google Inc. or a registered trademark.
To users of this product
Please contact the source this product was obtained from
if you have any questions about using this product or if
need help resolving any concerns.
More Information can be found on the Internet at:
http://www.fmworld.net/biz/uware/support/
This product’s functions and use may vary depending on how it was configured by the
from (the business customer that purchased the product from
Please ask for an explanation of this product’s functions and use when you receive
the product, or contact the source the product was obtained from for help.
revent entry or theft. We are not to be held responsible for incidents,
This product is not meant for specialized monitoring such as childcare, caregiving, or medical purposes.
d responsible for incidents, accidents, or damage caused through use of this product
Confirm included items prior to use
Prior to using this product, confirm that the following items are included in the package. If anything is
please contact the source the product was obtained from. In addition to the included items listed on this sheet,
the included items along with the sheet of instructions
Precautions to use (this sheet)
Power cable
Confirm that all product serial numbers are entered on the warranty card.
In addition, the attached articles of the stand for
RCB sold separately are as follows.
○
Adsorption tape x2
main unit
-
Note: only the model mounted camera
Remote Monitoring Station
Precautions for use
-
In this manual, various pictures are used to indicate alarm. These are signs to prevent
might be added to you and other people. The display and the
When this display is disregarded and wrong handling is done,
there is a high possibility that the person dies or sustains
display is disregarded and wrong handling is done,
there is a possibility that the person dies or sustains severe
When this display is disregarded and wrong handling is done,
there is a possibility that the person owes injury or the
The following sign is used to show what one the content of harm and damage is.
means prompts warning and attention. A concrete
content of warning is shown in the sign and sideward of that.
means an act of not doing (prohibited activity).
A concrete content of the prohibition is shown in the sign and sideward
means what you must do. A concrete content of the
instruction is shown in the sign and sideward of that.
mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of
is a trademark of Google Inc. or a registered trademark.
To users of this product
Please contact the source this product was obtained from
if you have any questions about using this product or if
need help resolving any concerns.
More Information can be found on the Internet at:
http://www.fmworld.net/biz/uware/support/
This product’s functions and use may vary depending on how it was configured by the
from (the business customer that purchased the product from
Please ask for an explanation of this product’s functions and use when you receive
the product, or contact the source the product was obtained from for help.
revent entry or theft. We are not to be held responsible for incidents,
This product is not meant for specialized monitoring such as childcare, caregiving, or medical purposes.
d responsible for incidents, accidents, or damage caused through use of this product
Prior to using this product, confirm that the following items are included in the package. If anything is
please contact the source the product was obtained from. In addition to the included items listed on this sheet,
the included items along with the sheet of instructions
Precautions to use (this sheet)
Confirm that all product serial numbers are entered on the warranty card.
RCB sold separately are as follows.
Adsorption tape x2
Screw hole for the
Emergency C
all Button
Power LED
Camera [Note]
Speaker
Status LED
Mic
BLE Pairing LED
Volume Button
Power Connector
Note: only the model mounted camera
WLAN Connect LED
In this manual, various pictures are used to indicate alarm. These are signs to prevent
might be added to you and other people. The display and the
When this display is disregarded and wrong handling is done,
there is a high possibility that the person dies or sustains
display is disregarded and wrong handling is done,
there is a possibility that the person dies or sustains severe
When this display is disregarded and wrong handling is done,
there is a possibility that the person owes injury or the
The following sign is used to show what one the content of harm and damage is.
means prompts warning and attention. A concrete
content of warning is shown in the sign and sideward of that.
means an act of not doing (prohibited activity).
A concrete content of the prohibition is shown in the sign and sideward
means what you must do. A concrete content of the
mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of
is a trademark of Google Inc. or a registered trademark.
Please contact the source this product was obtained from
if you have any questions about using this product or if
This product’s functions and use may vary depending on how it was configured by the
from (the business customer that purchased the product from
Please ask for an explanation of this product’s functions and use when you receive
the product, or contact the source the product was obtained from for help.
revent entry or theft. We are not to be held responsible for incidents,
This product is not meant for specialized monitoring such as childcare, caregiving, or medical purposes.
d responsible for incidents, accidents, or damage caused through use of this product
Prior to using this product, confirm that the following items are included in the package. If anything is
missing,
please contact the source the product was obtained from. In addition to the included items listed on this sheet,
the included items along with the sheet of instructions
Precautions to use (this sheet)
Confirm that all product serial numbers are entered on the warranty card.
RCB sold separately are as follows.
Screw hole for the
stand
all Button
Camera [Note]
BLE Pairing LED
Volume Button
Power Connector
Note: only the model mounted camera
WLAN Connect LED
In this manual, various pictures are used to indicate alarm. These are signs to prevent
might be added to you and other people. The display and the
High Safety Required Use
This Product is designed, developed and manufactured as contemplated for general use,
general office use, personal use, household use, and ordinary industrial use, but is not designed, developed and
manufactured as contemplated for use accompanying fatal risks or dangers that, unless extremely high safety is se
could lead directly to death, personal injury, severe physical damage or other loss (hereinafter “High Safety Required
Use”), including without limitation, nuclear reaction control in nuclear facility, aircraft flight control, air traffic
control, h
not use this Product without securing the sufficient safety
About
・
Wireless devices that use the 2.4 GHz band (as indicated above) make use of the entire bandwidth
and are unable to avoid using the bandwidth used by mobile identification equipment. FHSS is used
as the modulation method, and such devices may interfere with
・
In addition to commercial, scientific, and medical devices (such as microwaves), on
and designated low
other locations are also operated within the frequency band used by this product.
（
1
（
2
（
3
・
It is recommended that this product be used within a 10 m radius (the line
communicate with (the maximum
communication distance may vary depending on the usage environment, such as the structure/material of the building it
is being used in, obstacles, software, installation
where communication slows down or even becomes impossible.
・
If you will be using this product on an airplane, first contact the relevant airline company to confirm.
・
We are not to be held
communication.
Wireless LAN (WLAN)
・
The product uses the 2.4 GHz band. DS
interference distance is
All bandwidths can be used, and that bands of mobile unit identification devices can be avoided.
（
1
（
2
（
3
（
4
・
It is recommended that this product be used within a 25 m radius (unobstructed) from devices it will communicate with.
However, due to the nature of wireless LAN technology, the communication
environment, such as the structure/material of the building it is being used in, obstacles, software, installation
conditions, and radio wave conditions.
・
There may also be situations where communication slows down
・
In mixed IEEE 802.11g and IEEE 802.11b wireless LAN environments, IEEE 802.11g functions may not be available in order
to maintain compatibility with IEEE 802.11b standards. If IEEE 802.11g functions are required, keep IEEE 802
IEEE 802.11b networks separate, and leave at least five channels
This product’s functions and use may vary depending on how it was configured by the
from (the business customer that purchased the product from
Please ask for an explanation of this product’s functions and use when you receive
revent entry or theft. We are not to be held responsible for incidents,
This product is not meant for specialized monitoring such as childcare, caregiving, or medical purposes.
d responsible for incidents, accidents, or damage caused through use of this product
missing,
please contact the source the product was obtained from. In addition to the included items listed on this sheet,
the included items along with the sheet of instructions
■
□
Power ON
1.
2.
□
Power OFF
Remove the power
■
*
If you were provided with any installation instructions from the provider of this product, be sure
to follow them.
Install the Remote Monitoring Station according to
in. We recommend using the separately sold stand or wall attachment options to install
the R
emote
1/4th inch screws) can be installed using the screw
unit.
This section explains how to install the stand (sold separately).
For information on how to install the wall attachment, please refer to the manual
supplied with the wall attachment.
1.
2.
3.
stand
Cut side
High Safety Required Use
This Product is designed, developed and manufactured as contemplated for general use,
general office use, personal use, household use, and ordinary industrial use, but is not designed, developed and
manufactured as contemplated for use accompanying fatal risks or dangers that, unless extremely high safety is se
could lead directly to death, personal injury, severe physical damage or other loss (hereinafter “High Safety Required
Use”), including without limitation, nuclear reaction control in nuclear facility, aircraft flight control, air traffic
control, h
eavy transport logistics, medical life support system, missile launch control in weapon system. You shall
not use this Product without securing the sufficient safety
About
Bluetooth
Wireless devices that use the 2.4 GHz band (as indicated above) make use of the entire bandwidth
and are unable to avoid using the bandwidth used by mobile identification equipment. FHSS is used
as the modulation method, and such devices may interfere with
In addition to commercial, scientific, and medical devices (such as microwaves), on
and designated low
-
power radio stations (nonlicensed) for mobile identification used in factory produc
other locations are also operated within the frequency band used by this product.
1
）
Prior to using this product, confirm that there are no on
stations for mobile identification use being operated nearby.
2
）
If the use of this product causes radio interference with an on
identification, immediately stop the produc
below) to discuss ways to prevent interference (such as putting up partitions).
3
）
If the use of this product causes radio interference with a designated low
identification or if you have any other concerns, please contact the source this product was obtained from.
It is recommended that this product be used within a 10 m radius (the line
communicate with (the maximum
communication distance may vary depending on the usage environment, such as the structure/material of the building it
is being used in, obstacles, software, installation
where communication slows down or even becomes impossible.
If you will be using this product on an airplane, first contact the relevant airline company to confirm.
We are not to be held
communication.
Wireless LAN (WLAN)
The product uses the 2.4 GHz band. DS
interference distance is
All bandwidths can be used, and that bands of mobile unit identification devices can be avoided.
1
）
In the frequency band used by WLAN devices, in addition to home electric appliances such as a microwave oven
and industrial/scientific/m
in production lines of a factory, etc., specified low power radio
in operation.
2
）
Before using this device, confirm that in
low power radio stations or amateur radio stations are not in operation in your neighborhood
3
）
If this device generates harmful radio wave interference against in
of mobile objects, change the using frequency promptly or stop using wireless LAN function.
4
）
If the use of this product causes radio interference with a designated low
identification or if you have any othe
It is recommended that this product be used within a 25 m radius (unobstructed) from devices it will communicate with.
However, due to the nature of wireless LAN technology, the communication
environment, such as the structure/material of the building it is being used in, obstacles, software, installation
conditions, and radio wave conditions.
There may also be situations where communication slows down
In mixed IEEE 802.11g and IEEE 802.11b wireless LAN environments, IEEE 802.11g functions may not be available in order
to maintain compatibility with IEEE 802.11b standards. If IEEE 802.11g functions are required, keep IEEE 802
IEEE 802.11b networks separate, and leave at least five channels
Power ON/OFF
Power ON
Connect the
Connect the
P
and connects the power supply plug of the AC adapter to an
outlet.
Then power of R
power LED turns on green
Power OFF
Remove the power
Installation of Remote Monitoring Station
If you were provided with any installation instructions from the provider of this product, be sure
to follow them.
Install the Remote Monitoring Station according to
in. We recommend using the separately sold stand or wall attachment options to install
emote
M
onitoring
1/4th inch screws) can be installed using the screw
unit.
This section explains how to install the stand (sold separately).
For information on how to install the wall attachment, please refer to the manual
supplied with the wall attachment.
Set the power cable in the cable gu
Cable sticking out from bottom
Peel the paper from the
then stick the tape to the bottom surface of the stand.
Install the stand to the Remote Monitoring Station.
Use a
coin to tighten and loosen the screw.
Note 1: The thick tape is
is D
ouble
Note 2: Clean any dirt or dust from the bottom surface
of the stand prior to attaching the tape.
Cut side
High Safety Required Use
This Product is designed, developed and manufactured as contemplated for general use,
general office use, personal use, household use, and ordinary industrial use, but is not designed, developed and
manufactured as contemplated for use accompanying fatal risks or dangers that, unless extremely high safety is se
could lead directly to death, personal injury, severe physical damage or other loss (hereinafter “High Safety Required
Use”), including without limitation, nuclear reaction control in nuclear facility, aircraft flight control, air traffic
eavy transport logistics, medical life support system, missile launch control in weapon system. You shall
not use this Product without securing the sufficient safety
®
wireless technology
Wireless devices that use the 2.4 GHz band (as indicated above) make use of the entire bandwidth
and are unable to avoid using the bandwidth used by mobile identification equipment. FHSS is used
as the modulation method, and such devices may interfere with
In addition to commercial, scientific, and medical devices (such as microwaves), on
power radio stations (nonlicensed) for mobile identification used in factory produc
other locations are also operated within the frequency band used by this product.
Prior to using this product, confirm that there are no on
stations for mobile identification use being operated nearby.
If the use of this product causes radio interference with an on
identification, immediately stop the produc
below) to discuss ways to prevent interference (such as putting up partitions).
If the use of this product causes radio interference with a designated low
identification or if you have any other concerns, please contact the source this product was obtained from.
It is recommended that this product be used within a 10 m radius (the line
communicate with (the maximum
output for Class 2). However, due to the nature of Bluetooth® wireless technology, the
communication distance may vary depending on the usage environment, such as the structure/material of the building it
is being used in, obstacles, software, installation
where communication slows down or even becomes impossible.
If you will be using this product on an airplane, first contact the relevant airline company to confirm.
responsible for any data transmitted nor information leaked during Bluetooth® wireless technology
Wireless LAN (WLAN)
The product uses the 2.4 GHz band. DS
interference distance is
about 40 m or less.
All bandwidths can be used, and that bands of mobile unit identification devices can be avoided.
In the frequency band used by WLAN devices, in addition to home electric appliances such as a microwave oven
and industrial/scientific/m
edical devices, in
in production lines of a factory, etc., specified low power radio
Before using this device, confirm that in
low power radio stations or amateur radio stations are not in operation in your neighborhood
If this device generates harmful radio wave interference against in
of mobile objects, change the using frequency promptly or stop using wireless LAN function.
If the use of this product causes radio interference with a designated low
identification or if you have any othe
It is recommended that this product be used within a 25 m radius (unobstructed) from devices it will communicate with.
However, due to the nature of wireless LAN technology, the communication
environment, such as the structure/material of the building it is being used in, obstacles, software, installation
conditions, and radio wave conditions.
There may also be situations where communication slows down
In mixed IEEE 802.11g and IEEE 802.11b wireless LAN environments, IEEE 802.11g functions may not be available in order
to maintain compatibility with IEEE 802.11b standards. If IEEE 802.11g functions are required, keep IEEE 802
IEEE 802.11b networks separate, and leave at least five channels
Power ON/OFF
Power
cable to an AC adapter.
P
ower
cable to the DC
and connects the power supply plug of the AC adapter to an
Then power of R
emote
power LED turns on green
Remove the power
supply plug of the AC adapter from an outlet.
Installation of Remote Monitoring Station
If you were provided with any installation instructions from the provider of this product, be sure
Install the Remote Monitoring Station according to
in. We recommend using the separately sold stand or wall attachment options to install
onitoring
S
tation
1/4th inch screws) can be installed using the screw
This section explains how to install the stand (sold separately).
For information on how to install the wall attachment, please refer to the manual
supplied with the wall attachment.
Set the power cable in the cable gu
Cable sticking out from bottom
Peel the paper from the
then stick the tape to the bottom surface of the stand.
Install the stand to the Remote Monitoring Station.
coin to tighten and loosen the screw.
Line the screw holes up and fasten
them with a screw.
Note 1: The thick tape is
Adsorption
ouble
-sided tape.
Note 2: Clean any dirt or dust from the bottom surface
of the stand prior to attaching the tape.
This Product is designed, developed and manufactured as contemplated for general use,
general office use, personal use, household use, and ordinary industrial use, but is not designed, developed and
manufactured as contemplated for use accompanying fatal risks or dangers that, unless extremely high safety is se
could lead directly to death, personal injury, severe physical damage or other loss (hereinafter “High Safety Required
Use”), including without limitation, nuclear reaction control in nuclear facility, aircraft flight control, air traffic
eavy transport logistics, medical life support system, missile launch control in weapon system. You shall
not use this Product without securing the sufficient safety
wireless technology
Wireless devices that use the 2.4 GHz band (as indicated above) make use of the entire bandwidth
and are unable to avoid using the bandwidth used by mobile identification equipment. FHSS is used
as the modulation method, and such devices may interfere with
In addition to commercial, scientific, and medical devices (such as microwaves), on
power radio stations (nonlicensed) for mobile identification used in factory produc
other locations are also operated within the frequency band used by this product.
Prior to using this product, confirm that there are no on
stations for mobile identification use being operated nearby.
If the use of this product causes radio interference with an on
identification, immediately stop the produc
t from transmitting radio waves, and contact support (information
below) to discuss ways to prevent interference (such as putting up partitions).
If the use of this product causes radio interference with a designated low
identification or if you have any other concerns, please contact the source this product was obtained from.
It is recommended that this product be used within a 10 m radius (the line
output for Class 2). However, due to the nature of Bluetooth® wireless technology, the
communication distance may vary depending on the usage environment, such as the structure/material of the building it
is being used in, obstacles, software, installation
conditions, and radio wave conditions. There may also be situations
where communication slows down or even becomes impossible.
If you will be using this product on an airplane, first contact the relevant airline company to confirm.
responsible for any data transmitted nor information leaked during Bluetooth® wireless technology
The product uses the 2.4 GHz band. DS
-
SS and OFDM are used as the modulation schemes. The
about 40 m or less.
All bandwidths can be used, and that bands of mobile unit identification devices can be avoided.
In the frequency band used by WLAN devices, in addition to home electric appliances such as a microwave oven
edical devices, in
-
plant radio stations for identification of mobile objects used
in production lines of a factory, etc., specified low power radio
Before using this device, confirm that in
-
plant
low power radio stations or amateur radio stations are not in operation in your neighborhood
If this device generates harmful radio wave interference against in
of mobile objects, change the using frequency promptly or stop using wireless LAN function.
If the use of this product causes radio interference with a designated low
identification or if you have any othe
r concerns, please contact the provider of this product.
It is recommended that this product be used within a 25 m radius (unobstructed) from devices it will communicate with.
However, due to the nature of wireless LAN technology, the communication
environment, such as the structure/material of the building it is being used in, obstacles, software, installation
conditions, and radio wave conditions.
There may also be situations where communication slows down
In mixed IEEE 802.11g and IEEE 802.11b wireless LAN environments, IEEE 802.11g functions may not be available in order
to maintain compatibility with IEEE 802.11b standards. If IEEE 802.11g functions are required, keep IEEE 802
IEEE 802.11b networks separate, and leave at least five channels
cable to an AC adapter.
cable to the DC
-
IN connector of the product
and connects the power supply plug of the AC adapter to an
emote
M
onitoring
power LED turns on green
in
a short time.
supply plug of the AC adapter from an outlet.
Installation of Remote Monitoring Station
If you were provided with any installation instructions from the provider of this product, be sure
Install the Remote Monitoring Station according to
in. We recommend using the separately sold stand or wall attachment options to install
tation
. Commercially sold tripods or other fixtures (that use
1/4th inch screws) can be installed using the screw
This section explains how to install the stand (sold separately).
For information on how to install the wall attachment, please refer to the manual
supplied with the wall attachment.
Set the power cable in the cable gu
Cable sticking out from bottom
Peel the paper from the
Adsorption
tape or the cut side of the
then stick the tape to the bottom surface of the stand.
Install the stand to the Remote Monitoring Station.
coin to tighten and loosen the screw.
Line the screw holes up and fasten
them with a screw.
Adsorption
tape
; the thin tape
Note 2: Clean any dirt or dust from the bottom surface
of the stand prior to attaching the tape.
This Product is designed, developed and manufactured as contemplated for general use,
general office use, personal use, household use, and ordinary industrial use, but is not designed, developed and
manufactured as contemplated for use accompanying fatal risks or dangers that, unless extremely high safety is se
could lead directly to death, personal injury, severe physical damage or other loss (hereinafter “High Safety Required
Use”), including without limitation, nuclear reaction control in nuclear facility, aircraft flight control, air traffic
eavy transport logistics, medical life support system, missile launch control in weapon system. You shall
not use this Product without securing the sufficient safety
required for the High Safety Required Use.
Wireless devices that use the 2.4 GHz band (as indicated above) make use of the entire bandwidth
and are unable to avoid using the bandwidth used by mobile identification equipment. FHSS is used
as the modulation method, and such devices may interfere with
other devices at a range of 10 m.
In addition to commercial, scientific, and medical devices (such as microwaves), on
power radio stations (nonlicensed) for mobile identification used in factory produc
other locations are also operated within the frequency band used by this product.
Prior to using this product, confirm that there are no on
-
premise
stations for mobile identification use being operated nearby.
If the use of this product causes radio interference with an on
t from transmitting radio waves, and contact support (information
below) to discuss ways to prevent interference (such as putting up partitions).
If the use of this product causes radio interference with a designated low
identification or if you have any other concerns, please contact the source this product was obtained from.
It is recommended that this product be used within a 10 m radius (the line
output for Class 2). However, due to the nature of Bluetooth® wireless technology, the
communication distance may vary depending on the usage environment, such as the structure/material of the building it
conditions, and radio wave conditions. There may also be situations
where communication slows down or even becomes impossible.
If you will be using this product on an airplane, first contact the relevant airline company to confirm.
responsible for any data transmitted nor information leaked during Bluetooth® wireless technology
SS and OFDM are used as the modulation schemes. The
All bandwidths can be used, and that bands of mobile unit identification devices can be avoided.
In the frequency band used by WLAN devices, in addition to home electric appliances such as a microwave oven
-
plant radio stations for identification of mobile objects used
in production lines of a factory, etc., specified low power radio
plant
radio stations for identification of mobile objects, specified
low power radio stations or amateur radio stations are not in operation in your neighborhood
If this device generates harmful radio wave interference against in
of mobile objects, change the using frequency promptly or stop using wireless LAN function.
If the use of this product causes radio interference with a designated low
r concerns, please contact the provider of this product.
It is recommended that this product be used within a 25 m radius (unobstructed) from devices it will communicate with.
However, due to the nature of wireless LAN technology, the communication
environment, such as the structure/material of the building it is being used in, obstacles, software, installation
There may also be situations where communication slows down
or even becomes impossible.
In mixed IEEE 802.11g and IEEE 802.11b wireless LAN environments, IEEE 802.11g functions may not be available in order
to maintain compatibility with IEEE 802.11b standards. If IEEE 802.11g functions are required, keep IEEE 802
IEEE 802.11b networks separate, and leave at least five channels
open between the channels used at each network.
cable to an AC adapter.
IN connector of the product
and connects the power supply plug of the AC adapter to an
onitoring
Station
turns on.
a short time.
supply plug of the AC adapter from an outlet.
Installation of Remote Monitoring Station
If you were provided with any installation instructions from the provider of this product, be sure
Install the Remote Monitoring Station according to
in. We recommend using the separately sold stand or wall attachment options to install
. Commercially sold tripods or other fixtures (that use
1/4th inch screws) can be installed using the screw
This section explains how to install the stand (sold separately).
For information on how to install the wall attachment, please refer to the manual
Set the power cable in the cable gu
ide.
Cable sticking out from back
tape or the cut side of the
then stick the tape to the bottom surface of the stand.
Install the stand to the Remote Monitoring Station.
coin to tighten and loosen the screw.
Line the screw holes up and fasten
them with a screw.
; the thin tape
Note 2: Clean any dirt or dust from the bottom surface
of the stand prior to attaching the tape.
This Product is designed, developed and manufactured as contemplated for general use,
general office use, personal use, household use, and ordinary industrial use, but is not designed, developed and
manufactured as contemplated for use accompanying fatal risks or dangers that, unless extremely high safety is se
could lead directly to death, personal injury, severe physical damage or other loss (hereinafter “High Safety Required
Use”), including without limitation, nuclear reaction control in nuclear facility, aircraft flight control, air traffic
eavy transport logistics, medical life support system, missile launch control in weapon system. You shall
required for the High Safety Required Use.
Wireless devices that use the 2.4 GHz band (as indicated above) make use of the entire bandwidth
and are unable to avoid using the bandwidth used by mobile identification equipment. FHSS is used
other devices at a range of 10 m.
In addition to commercial, scientific, and medical devices (such as microwaves), on
-
premise radio stations (licensed)
power radio stations (nonlicensed) for mobile identification used in factory produc
other locations are also operated within the frequency band used by this product.
premise
radio stations or designated low
If the use of this product causes radio interference with an on
-
premise radio station used for mobile
t from transmitting radio waves, and contact support (information
below) to discuss ways to prevent interference (such as putting up partitions).
If the use of this product causes radio interference with a designated low
-
power radio station used for mob
identification or if you have any other concerns, please contact the source this product was obtained from.
It is recommended that this product be used within a 10 m radius (the line
-of-
sight radius) from devices it will
output for Class 2). However, due to the nature of Bluetooth® wireless technology, the
communication distance may vary depending on the usage environment, such as the structure/material of the building it
conditions, and radio wave conditions. There may also be situations
If you will be using this product on an airplane, first contact the relevant airline company to confirm.
responsible for any data transmitted nor information leaked during Bluetooth® wireless technology
SS and OFDM are used as the modulation schemes. The
All bandwidths can be used, and that bands of mobile unit identification devices can be avoided.
In the frequency band used by WLAN devices, in addition to home electric appliances such as a microwave oven
plant radio stations for identification of mobile objects used
in production lines of a factory, etc., specified low power radio
stations
or amateur radio stations can be
radio stations for identification of mobile objects, specified
low power radio stations or amateur radio stations are not in operation in your neighborhood
If this device generates harmful radio wave interference against in
-
plant radio stations for ide
of mobile objects, change the using frequency promptly or stop using wireless LAN function.
If the use of this product causes radio interference with a designated low
-
power radio station used for mobile
r concerns, please contact the provider of this product.
It is recommended that this product be used within a 25 m radius (unobstructed) from devices it will communicate with.
However, due to the nature of wireless LAN technology, the communication
distance may vary depending on the usage
environment, such as the structure/material of the building it is being used in, obstacles, software, installation
or even becomes impossible.
In mixed IEEE 802.11g and IEEE 802.11b wireless LAN environments, IEEE 802.11g functions may not be available in order
to maintain compatibility with IEEE 802.11b standards. If IEEE 802.11g functions are required, keep IEEE 802
open between the channels used at each network.
IN connector of the product
and connects the power supply plug of the AC adapter to an
turns on.
A
supply plug of the AC adapter from an outlet.
Installation of Remote Monitoring Station
If you were provided with any installation instructions from the provider of this product, be sure
Install the Remote Monitoring Station according to
the environment it will be used
in. We recommend using the separately sold stand or wall attachment options to install
. Commercially sold tripods or other fixtures (that use
1/4th inch screws) can be installed using the screw
hole on the bottom of the main
This section explains how to install the stand (sold separately).
For information on how to install the wall attachment, please refer to the manual
Cable sticking out from back
tape or the cut side of the
then stick the tape to the bottom surface of the stand.
Install the stand to the Remote Monitoring Station.
Line the screw holes up and fasten
Do not install slanted.
AC Adapter
including without limitation,
general office use, personal use, household use, and ordinary industrial use, but is not designed, developed and
manufactured as contemplated for use accompanying fatal risks or dangers that, unless extremely high safety is se
could lead directly to death, personal injury, severe physical damage or other loss (hereinafter “High Safety Required
Use”), including without limitation, nuclear reaction control in nuclear facility, aircraft flight control, air traffic
eavy transport logistics, medical life support system, missile launch control in weapon system. You shall
required for the High Safety Required Use.
Wireless devices that use the 2.4 GHz band (as indicated above) make use of the entire bandwidth
and are unable to avoid using the bandwidth used by mobile identification equipment. FHSS is used
other devices at a range of 10 m.
premise radio stations (licensed)
power radio stations (nonlicensed) for mobile identification used in factory produc
tion lines and
radio stations or designated low
premise radio station used for mobile
t from transmitting radio waves, and contact support (information
below) to discuss ways to prevent interference (such as putting up partitions).
power radio station used for mob
identification or if you have any other concerns, please contact the source this product was obtained from.
sight radius) from devices it will
output for Class 2). However, due to the nature of Bluetooth® wireless technology, the
communication distance may vary depending on the usage environment, such as the structure/material of the building it
conditions, and radio wave conditions. There may also be situations
If you will be using this product on an airplane, first contact the relevant airline company to confirm.
responsible for any data transmitted nor information leaked during Bluetooth® wireless technology
SS and OFDM are used as the modulation schemes. The
All bandwidths can be used, and that bands of mobile unit identification devices can be avoided.
In the frequency band used by WLAN devices, in addition to home electric appliances such as a microwave oven
plant radio stations for identification of mobile objects used
or amateur radio stations can be
radio stations for identification of mobile objects, specified
low power radio stations or amateur radio stations are not in operation in your neighborhood
.
plant radio stations for ide
of mobile objects, change the using frequency promptly or stop using wireless LAN function.
power radio station used for mobile
r concerns, please contact the provider of this product.
It is recommended that this product be used within a 25 m radius (unobstructed) from devices it will communicate with.
distance may vary depending on the usage
environment, such as the structure/material of the building it is being used in, obstacles, software, installation
or even becomes impossible.
In mixed IEEE 802.11g and IEEE 802.11b wireless LAN environments, IEEE 802.11g functions may not be available in order
to maintain compatibility with IEEE 802.11b standards. If IEEE 802.11g functions are required, keep IEEE 802
open between the channels used at each network.
supply plug of the AC adapter from an outlet.
Installation of Remote Monitoring Station
If you were provided with any installation instructions from the provider of this product, be sure
the environment it will be used
in. We recommend using the separately sold stand or wall attachment options to install
. Commercially sold tripods or other fixtures (that use
hole on the bottom of the main
This section explains how to install the stand (sold separately).
For information on how to install the wall attachment, please refer to the manual
Cable sticking out from back
tape or the cut side of the
Double-
sided tape, and
Do not install slanted.
AC Adapter
Power cable
Attach here
including without limitation,
general office use, personal use, household use, and ordinary industrial use, but is not designed, developed and
manufactured as contemplated for use accompanying fatal risks or dangers that, unless extremely high safety is se
cured,
could lead directly to death, personal injury, severe physical damage or other loss (hereinafter “High Safety Required
Use”), including without limitation, nuclear reaction control in nuclear facility, aircraft flight control, air traffic
eavy transport logistics, medical life support system, missile launch control in weapon system. You shall
required for the High Safety Required Use.
premise radio stations (licensed)
tion lines and
radio stations or designated low
-power radio
premise radio station used for mobile
t from transmitting radio waves, and contact support (information
power radio station used for mob
ile
identification or if you have any other concerns, please contact the source this product was obtained from.
sight radius) from devices it will
output for Class 2). However, due to the nature of Bluetooth® wireless technology, the
communication distance may vary depending on the usage environment, such as the structure/material of the building it
conditions, and radio wave conditions. There may also be situations
If you will be using this product on an airplane, first contact the relevant airline company to confirm.
responsible for any data transmitted nor information leaked during Bluetooth® wireless technology
In the frequency band used by WLAN devices, in addition to home electric appliances such as a microwave oven
plant radio stations for identification of mobile objects used
or amateur radio stations can be
radio stations for identification of mobile objects, specified
plant radio stations for ide
ntification
power radio station used for mobile
r concerns, please contact the provider of this product.
It is recommended that this product be used within a 25 m radius (unobstructed) from devices it will communicate with.
distance may vary depending on the usage
environment, such as the structure/material of the building it is being used in, obstacles, software, installation
In mixed IEEE 802.11g and IEEE 802.11b wireless LAN environments, IEEE 802.11g functions may not be available in order
to maintain compatibility with IEEE 802.11b standards. If IEEE 802.11g functions are required, keep IEEE 802
.11g and
open between the channels used at each network.
If you were provided with any installation instructions from the provider of this product, be sure
the environment it will be used
in. We recommend using the separately sold stand or wall attachment options to install
. Commercially sold tripods or other fixtures (that use
hole on the bottom of the main
For information on how to install the wall attachment, please refer to the manual
sided tape, and
Do not install slanted.
Power cable
Attach here
4.
Peel the film from the Adsorption tape (or paper from the non-cut side of the Double-sided
tape), attach it firmly to the adhesion surface, and then install the Remote Monitoring
Station.
Note the following during installation.
* Install on a flat surface with no irregularities.
* Remove any dirt, water, or oil from the installation location prior to installation.
* Do not attach double-sided tape to locations with weak surfaces such as wallpaper.
* When double-sided tape is removed it may leave a mark. If using a chemical such as an adhesive
remover to clean the surface, make sure that it will not cause any damage.
■ Safety Notes
This section includes important information in order to use this product safely and correctly. Be sure to read this
information prior to using this product, so that it can be used correctly, safely, and appropriately. Be sure to read
the manual carefully in order to use the product correctly.
Common notes for UBIQUITOUSWARE products
DANGER
Always be sure to turn this product off
prior to entering areas (such as gasoline
stands) with flammable gas (such as
propane gas or gasoline) or dust. Do not charge the
product in these areas.
Doing otherwise could cause the gas to ignite.
WARNING
Use indicated peripheral devices only.
Doing otherwise could cause heat buildup,
ignition, an explosion, a malfunction, or
leaking.
Do not subject the product to strong
forces, drop it, drive nails through it,
hammer it, or step on it.
Doing otherwise could cause ignition, damage, or
injury.
Do not place this product in fire, heat
it, or short the terminals.
Doing otherwise could cause smoke,
ignition, or an explosion.
If this product behaves abnormally (such
as heat buildup, emitting smoke or
strange odors/noises), immediately
remove it from your wrist and turn the power off.
If the product is connected to its AC adapter,
remove the power plug from the outlet.
Continuing to use this product when it is acting
abnormally could cause electrical shock or a fire.
If a liquid (such as water) or a foreign
substance (such as metal) enters this
product, immediately turn the product
off. If the product is connected to its AC adapter,
remove the power plug from the outlet.
Continuing to use it in this state could cause
electrical shock or a fire.
If this product is dropped or parts such
as its cover are damaged, immediately
turn the product off and repair it.
Continuing to use it in this state could cause
electrical shock or a fire.
If you hear thunder, do not touch this
product or its cables until there is no
danger of lighting striking.
Do not connect any cables as long as there is a danger
of lighting striking. If there is a danger of
lighting striking, turn this product off beforehand
and immediately remove the product from your wrist.
If the product is connected to its AC adapter, remove
the power plug from the outlet and then detach the
cables.
Doing otherwise could result in being shocked by
lightning or could cause a fire. The product could
also malfunction.
Never disassemble or modify this product
yourself.
Doing otherwise could result in injury,
electrical shock, or a fire.
When using this product, do not cover it
with a blanket or other covering, place
it near a heater, or place it on an
electric carpet.
Doing otherwise could trap heat inside the product,
causing a fire.
Do not use cleaning sprays (that include
flammable substances) to clean this
product.
Doing otherwise could result in a malfunction or
fire.
If this product is damaged and the main unit’s
internals are exposed due to dropping it or the like,
do not touch the exposed internals.
Doing otherwise could cause electrical shock or
Store the main unit and its accessories
outside the reach of infants.
Do not allow infants to chew or swallow the
main unit or its accessories.
If an infant should swallow the main unit
or its accessories, consult immediately
with a physician.
Use only included or specified AC adapters
or power cables with this product; do not
use the included AC adapter or power cable
with other products.
Doing otherwise could cause an electrical shock or
fire.
CAUTION
Do not wipe with benzine or paint
thinner.
Doing otherwise could cause paint
peeling, cracking, injury caused by damage, or a
fire.
If this product is dirty or wet, wipe it
clean with a dry cloth or the like.
If left dirty or wet the product could
deteriorate more quickly or its color could fade.
Do not place heavy objects on this
product.
Doing otherwise could cause damage or
injury.
Do not use or place this product in
locations that are subject to direct
sunlight or that are very hot (such as in
locked vehicles).
Doing otherwise could cause an electrical shock or
fire. It could also result in damage or a
malfunction.
AC Adapter, Power cable
WARNING
Use only at the specified power supply
voltage.
Failure to do so could cause ignition,
fire, heat buildup, or electrical shock.
Do not connect to devices that generate
square waves (uninterruptible power
supplies (UPS) or automobile AC power
supplies).
Doing otherwise may result in a fire.
Make sure that the power plug is firmly
inserted all the way into the outlet.
If the connection is not good it could
cause electrical shock, heat buildup, or ignition
that could result in a fire. Do not use any loose
outlets.
Insert the AC adapter power plug directly
and firmly into the outlet (100 V AC). Do
not use piggybacked electrical outlets.
Doing otherwise could cause electrical shock, burns,
or fire.
Hold the AC adapter or power cable straight
when inserting or removing them. Do not
apply unreasonable force.
Doing otherwise could cause fire, burns, injury, or
electrical shock.
When removing the AC adapter power plug
from the outlet, be sure to grab the AC
adapter. Do not pull the power cable.
Pulling the power cable could damage it, causing
electrical shock or fire.
Place the product near the outlet in an
accessible location where the power plug
can easily be reached.
Doing otherwise could make it impossible to remove
the power plug or could lead to danger.
injury due to the damaged part.
Store bags and the like used for the
packaging material outside the reach of
children.
Doing otherwise could result in suffocation if the
child puts the material in his or her mouth or covers
his or her head with it.
Do not insert or remove the power cable or
AC adapter if your hands are wet.
Doing otherwise could cause electrical
shock.
Do not wrap the power cable tightly around
the AC adapter, or otherwise apply
pressure to the base.
Doing otherwise could expose or sever the core of the
power cable, causing electrical shock or fire.
When the AC adapter is connected to the
outlet, do not catch anything on it or
otherwise subject it to strong impact.
Doing otherwise could cause injury or a malfunction.
Do not drop the AC adapter or subject it
to strong impact. Doing otherwise could
damage the internal circuit board. Do not
use deformed, broken, or damaged AC adapters or power
cables.
Doing otherwise could cause a malfunction,
electrical shock, or fire.
Periodically remove the AC adapter or
power plug from the outlet, and use a soft
cloth to clean dust from the connecting
parts of the outlet, AC adapter, and power cable.
Using the product when these are dusty could cause
electrical shock, burns, or fire. Inspect and clean
the product once per year.
Always remove the AC adapter power plug
from the outlet during maintenance.
Doing otherwise could cause electrical
shock.
Never use in bathrooms or other highly
humid locations.
Doing otherwise could cause electrical
shock or a malfunction.
If the product will not be used for a long
period of time, remove the AC adapter
power plug from the outlet and disconnect
the AC adapter.
Doing otherwise could cause a fire.
Do not use damaged AC adapters, power
cables, or power plugs.
Doing otherwise could cause fire or
electrical shock.
Do not bring screwdrivers or other metal
objects near the AC adapter power plug.
Doing otherwise could cause fire or
electrical shock.
Do not damage, modify, heat, or pull the
power cable. Do not place heavy objects on
it, or bend or twist it unreasonably. Do not
use damaged cables.
Doing otherwise could cause electrical shock, a short
circuit, fire, or burns.
Radio components
WARNING
Precautions on WLAN and
Bluetooth
®
wireless technology
Turn wireless communication
functions off (for example, turn the product
off) in the following locations.
・Inside hospitals or in locations with
electronic medical devices
Be especially careful not to bring the
product into operating rooms, intensive
care units, CCUs (coronary care units), or
other similar locations.
・Locations where the use of wireless
communication functions is prohibited,
such as on airplanes
・Near automatic control devices such as
automatic doors or fire alarms
・Locations where you may come into close
contact with individuals who are wearing
implantable medical devices (such as
pacemakers) in the situation where you
cannot move freely, etc.
■ Disposal
CAUTION
For commercial customers who have purchased the product from us, refer to “Disposing
and Recycling ICT Products” on our webpage
(http://www.fujitsu.com/jp/about/environment/society/products/recycleinfo/). If this
product was obtained from another source, please contact that source.
■ Additional Information
□ Precautions for use
・This product uses wireless communication, and there may be cases where functions may not be used
as expected if there is cross talk or interference. We are not to be held responsible for incidents,
accidents, or damage caused through use of this product.
・If the status LED turns red, a sensor malfunction or communication error may have occurred. If this
occurs, please contact the source this product was obtained from.
・A smartphone (Android 4.4 or later) and special application are required to initialize this product.
・No personal information is stored in this product.
・This product cannot be used if it is not turned on.
・Place one hand on the Remote Monitoring Station to stabilize it when pressing buttons. Doing otherwise
could cause the adhesion side of the stand to come unstuck, making it impossible to press buttons.
・The wireless LAN IEEE 802.11b unit installed in the Remote Monitoring Station can use wireless
channels 1 through 13. Set the wireless LAN access point to use a channel within the range from
1 to 13. Please refer to your wireless access point manual for information on how to configure
it.
■
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This
must accept any interference received, including
operation.
Changes or modifications not expressly approved by the
could void the user’s
This transmitter must not be co
or transmitter.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to
reasonable protection against harmful interference in
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful inte
communications. However,
particular installation. If this equipment does cause
television reception, which can be determined by tu
user is encouraged to try to correct the interference by one or more of the following
measures:
—
Reorient or relocate the receiving antenna.
—
Increase the separation between the equipment and receiver.
—
Connect the equipment into an ou
receiver is connected.
—
Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment and meets
should be installed and operated keeping the
person’s body.
■
FCC CAUTION
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This
must accept any interference received, including
operation.
Changes or modifications not expressly approved by the
could void the user’s
This transmitter must not be co
or transmitter.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to
reasonable protection against harmful interference in
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful inte
communications. However,
particular installation. If this equipment does cause
television reception, which can be determined by tu
user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an ou
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment and meets
should be installed and operated keeping the
person’s body.
IC CAUTION
FCC CAUTION
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This
device may not cause harmful interference, and (2) this device
must accept any interference received, including
Changes or modifications not expressly approved by the
could void the user’s
authority to operate the equipment.
This transmitter must not be co
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to
part 15 of the FCC Rules. These limits are design
reasonable protection against harmful interference in
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful inte
communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
television reception, which can be determined by tu
user is encouraged to try to correct the interference by one or more of the following
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an ou
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment and meets
the FCC radio frequency (RF) Exposure Guidelines. This equipment
should be installed and operated keeping the
IC CAUTION
This device complies with part 15 of the FCC Rules. Operation is subject to the following
device may not cause harmful interference, and (2) this device
must accept any interference received, including
Changes or modifications not expressly approved by the
authority to operate the equipment.
This transmitter must not be co
-
located or operated in co
Note: This equipment has been tested and found to comply with the limits for a Class B
part 15 of the FCC Rules. These limits are design
reasonable protection against harmful interference in
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful inte
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
television reception, which can be determined by tu
user is encouraged to try to correct the interference by one or more of the following
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an ou
tlet on a circuit different from that to which the
Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
the FCC radio frequency (RF) Exposure Guidelines. This equipment
should be installed and operated keeping the
This device complies with part 15 of the FCC Rules. Operation is subject to the following
device may not cause harmful interference, and (2) this device
must accept any interference received, including
interference that
Changes or modifications not expressly approved by the
authority to operate the equipment.
located or operated in co
Note: This equipment has been tested and found to comply with the limits for a Class B
part 15 of the FCC Rules. These limits are design
reasonable protection against harmful interference in
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful inte
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
television reception, which can be determined by tu
user is encouraged to try to correct the interference by one or more of the following
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
tlet on a circuit different from that to which the
Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
the FCC radio frequency (RF) Exposure Guidelines. This equipment
should be installed and operated keeping the
radiator at least 20cm or more away from
This device complies with part 15 of the FCC Rules. Operation is subject to the following
device may not cause harmful interference, and (2) this device
interference that
Changes or modifications not expressly approved by the
party responsible for compliance
authority to operate the equipment.
located or operated in co
njunction with any other antenna
Note: This equipment has been tested and found to comply with the limits for a Class B
part 15 of the FCC Rules. These limits are design
reasonable protection against harmful interference in
a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful inte
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or
television reception, which can be determined by tu
rning the equip
user is encouraged to try to correct the interference by one or more of the following
Increase the separation between the equipment and receiver.
tlet on a circuit different from that to which the
Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
the FCC radio frequency (RF) Exposure Guidelines. This equipment
radiator at least 20cm or more away from
This device complies with part 15 of the FCC Rules. Operation is subject to the following
device may not cause harmful interference, and (2) this device
interference that
may cause undesired
party responsible for compliance
njunction with any other antenna
Note: This equipment has been tested and found to comply with the limits for a Class B
part 15 of the FCC Rules. These limits are design
a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful inte
rference to radio
there is no guarantee that interference will not occur in a
harmful interference to radio or
rning the equip
ment off and on,
user is encouraged to try to correct the interference by one or more of the following
tlet on a circuit different from that to which the
Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
the FCC radio frequency (RF) Exposure Guidelines. This equipment
radiator at least 20cm or more away from
This device complies with part 15 of the FCC Rules. Operation is subject to the following
device may not cause harmful interference, and (2) this device
may cause undesired
party responsible for compliance
njunction with any other antenna
Note: This equipment has been tested and found to comply with the limits for a Class B
part 15 of the FCC Rules. These limits are design
ed to provide
a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
rference to radio
there is no guarantee that interference will not occur in a
harmful interference to radio or
ment off and on,
the
user is encouraged to try to correct the interference by one or more of the following
tlet on a circuit different from that to which the
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
the FCC radio frequency (RF) Exposure Guidelines. This equipment
radiator at least 20cm or more away from
This device complies with part 15 of the FCC Rules. Operation is subject to the following
device may not cause harmful interference, and (2) this device
may cause undesired
party responsible for compliance
njunction with any other antenna
Note: This equipment has been tested and found to comply with the limits for a Class B
ed to provide
a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
rference to radio
there is no guarantee that interference will not occur in a
harmful interference to radio or
the
user is encouraged to try to correct the interference by one or more of the following
tlet on a circuit different from that to which the
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
the FCC radio frequency (RF) Exposure Guidelines. This equipment
radiator at least 20cm or more away from
5
■ Detailed information
□ Function List
In order to use this function, “UBIQUITOUSWARE Sensor Algorithm” (sold separately) is required.
・Product function
Function Specification Application Example
Sound detection Detects conversation and speech of the person. Safety confirmation
Trespassing prevention
Snoring detection Detects snore frequency/interval. Safety confirmation
Health monitoring
Disturbance
detection of
respiration
Detects the length of the long silence interval between snoring.
Health monitoring
Cough detection
Detects a high frequency of consecutive coughs.
Detected as positive if at least 10 sets of consecutive coughs (i.e.
20 coughs) are detected in an hour.
Safety confirmation
Health monitoring
TV sound detection Detects the sound spreading from TV. Safety confirmation
Sound pressure
measurement Measure the mean of the sound pressure per minute. Abnormal big sound
(Big sound detection)
Abnormal big sound
detection Notifies the event of big sound pressure as abnormality.
Abnormal big sound
(Big sound detection)
Trespassing prevention
Temperature and
humidity measurement
Measure the temperature / the humidity. Heat index measurement warning
The estimate of the
thermal environment
level
Estimates the thermal environment level on a scale of 1 to 5 from
the heat index that is based on heat and humidity information
measured by the thermo-hygro sensor.
Heat index measurement warning
Notice of the degree
of risk of the heat
stroke
If the
thermal environment level is high, the administrator is
notified and the terminal automatically plays an announcement
urging that measures be taken.
Heat index measurement warning
Detection of
human body motion
Uses a motion sensor to detect human
movement in order to determine
whether or not someone is in the vicinity.
Safety confirmation
Trespassing prevention
Camera The image photography of the still image is possible.
Safety confirmation
(As confirmation means of the
situation)
Abnormal big sound detection
(As confirmation means of the
situation)
Trespassing prevention
VoIP call originating
Notifies/Alerts to the administrator by only pushing the Emergency
Call or Consulting Call Button.
Emergency Call / talk
Consulting Call Button
VoIP call incoming Receives VoIP calls made by administrators. Emergency Call / talk
Consulting Call Button
Notification
transmission
Sends notification that the Emergency Call button or Consulting
Call
Button was pressed (must select VoIP call
transmission for each
button, and then make a call).
Emergency Call / talk
Consulting Call Button
Cancel
Pressing the Call Cancel Button cancels abnormality notificati
on.
If the Emergency Call Button or Consulting Call B
utton is pressed
accidentally, or
if an abnormality is erroneously detected, the user
can prevent the call from connecting or a photo from being taken.
Simultaneous
announcement of
the sound
Five audio files are stored in the terminal as means of communicating
with the user. Sounds can be played back at the direction of the
administrator.
It is possible to update audio files over the network.
Announcement
Trespassing
prevention mode
Turns on/off the trespassing prevention mode.
When the sound or motion sensor detected it in absence,
notifies
the trespassing event to a server and beeps alarm sound.
And takes a picture and uploads it to a server.
Trespassing prevention
Trespassing
prevention mode
wit
h the date and hour
designation
Controls On/OFF of the trespassing prevention mode by setting the
date and time.
Turns on the trespassing prevention mode automatically when it is
past the designated date and time,
*Please turn off the trespassing prevention mode befor
ehand when
turning on this mode.
Trespassing prevention
The firmware update
of the Remote
Monitoring Station
Downloads the firmware of the Remote Monitoring Station
from a
server and updates it. The firmware update
* Please see the FUJITSU IoT Solution UBIQUITOUSWARE General Catalog for actual examples of usage scenarios.
6
・Cooperation function with the vital sensing band
Function Specification Application Example
Bluetooth
out-of-range
notification
Detects when Vital
Sensing Band's Bluetooth connection drops, and
can notify the administrator that the user has moved away from the
Remote Monitoring Station.
Out-of-range notification
Transfer function of
the sensor data of the
vital sensing band
Collects sensor data via
Bluetooth from the vital sensing band and
uploads it to a server.
Firmware update
function of the vital
sensing band
Downloads the firmware of the vital sensing band from a server and
transmits data to it via Bluetooth.
The firmware update.
7
□ Sound playback function
・Customizing the audio file
The audio file played over the Remote Monitoring Station and each function sound can be customized over the network.
List of sounds that can be configured
No.
Type Length
Usage Playback Stop Volume
Priority
Default
announcement
message
1
Announcement
1
90sec
Information provision
announcement
Playback
request from
the service
provider
Stops after
repeating
twice
Set
volume
4 "There has been an
earthquake. Please
act calmly. Stay safe
and extinguish the
source of the fire.
Please check the TV
or radio for
information and stay
calm." (Assuming
there has been an
earthquake)
2
Announcement
2
90sec
Information provision
announcement
Playback
request from
the service
provider
Stops after
repeating
twice
Set
volume
4 "A heavy rain and
flood warning has
been issued. Please
check the weather
forecast for
updates." (Assuming
there is heavy rain
and flooding)
3
Announcement
3
90sec
Information provision
announcement
Playback
request from
the service
provider
Stops after
repeating
twice
Set
volume
4 "A disaster has
occurr
ed happened in
your residence area.
Please check
information on TV or
radio and act calmly.
"
(Assuming there has
been a disaster)
4
Announcement
4
90sec
Information provision
announcement
Playback
request from
the service
provider
Stops after
repeating
twice
Set
volume
4 "There has been a
disaster in your
region. Please
evacuate to the
specified evacuation
site." (Assuming
there has been a
disaster)
5
Announcement
5
90sec Information
provision
announcement
Playback
request from
the service
provider
Stops after
repeating
twice
Set
volume
4 "The earlier
announcement was
false alarm".
6
Announcement
prior to a
photo shoot
10sec Announcement sound
played prior to
shooting with the
camera according to
instructions from the
service provider
Playback
request from
the service
provider
Playback
completion
Set
volume
3
"It will take a photo
of you right after
this announcement.
Please press the
Call
Cancel Bu
tton if it's
unnecessary.
3.2.1"
7 Shutter
sound
1sec Camera sound when
shooting with the
camera
• After the
announcement
prior to a
photo shoot
is complete
• After the
service
provider
requests a
photo shoot
Playback
completion
Set
volume
3 Shutter sound
8 Volume
change sound
1sec Confirmation sound
played when a V
olume
Button (+)/(-) is
pressed
When a V
olume
Button
(+)/(-) is
pressed
Playback
completion
Set
volume
6 Volume change sound
8
No.
Type Length
Usage Playback Stop Volume
Priority
Default
announcement
message
9 Cancel sound
2sec Confirmation sound
played when the Call
Cancel Button is
pressed
When the
Call
Cancel
Button is
pressed
Playback
completion
Set
volume
1 "Your request has
been canceled."
10 Chimes sound
5sec Chime sound played
prior to playing an
information
announcements/thermal
environment level
announcement
Announcement
1-5 /
Prior to
thermal
environment
level
announcement
Playback
completion
Set
volume
--- Chimes sound
11 Thermal
environment
level
announcement
20sec Thermal environment
alert announcement
When a
thermal
environment
level of 4 or
5 is detected
* After
playing the
chime sound,
an alert
announcement
must be made.
Stops after
repeating
twice (can be
set to repeat
from 1 to 10
times)）
Set
volume
5 "You have a risk to
get heat stroke in
this room.
Please take some
water, make the
room
cooler etc.
to avoid
the risk. "
12 Alarm sound 5sec Alarm sound played
when an intrusion is
detected
After
sending a
photo when an
intrusion
was detected
• After
repeating for
10 minutes
• When the
trespass mode
is OFF
• When
abnormality
detection
status is OFF
Maximum
volume
(Level
5)
2 Alarm sound
13 Emergency
Call Button
15sec Announcement sound
played until a call is
received from the
center, after the
Emergency Call B
utton
is pressed
After
pressing the
Emergency
Call Button
* Repeats
until the
stop
condition
• When
incoming call
received from
the center was
automatically
answered
•
When cancel
is pressed
• When time
has passed (5
minutes)
Set
volume
2 "Emergency Call
Button has been ju
st
pressed.
It's connecting now
so please wait a
while. "
14 Received
call
announcement
20sec Announcement sound
played until a call is
received from the
center, after the
Consulting Call B
utton
is pressed
When there is
an incoming
call
・Playback
completion
・When the
Call
Cancel B
utton
is pressed
Set
volume
2 "Receiving a call.
Please hold on.
Please press the
Call
Cancel B
utton if it's
unnecessary. "
15 Consulting
announcement
10sec Announcement sound
played until a call is
received from the
center, after the
Consulting Call B
utton
is pressed
After
pressing the
Consulting
Call Button
* Repeats
until the
stop
condition is
reached
• When
incoming call
received from
the center was
automatically
answered
•
When cancel
is pressed
• When time
has passed (5
minutes)
Set
volume
2 "Consulting Call
B
utton has been just
pressed.
It's connecting now
so please hold on a
minute. "
16 Ring back
tone
5sec Outgoing call ring
back tone
When there is
an outgoing
call
• When the
center has
responded
•
When cancel
is pressed
• When an
outgoing call
failed
Set
volume
2 Ringing tone
9
* One with a small figure is reproduced by priority.
* It reproduces in the winning when the same priority reproduction demands are generated.
Sound data that can be played on this product is PCM format.
- sampling rate：16000Hz
- bit sample：16 bit
- number of channels：1ch(monaural)
- volume level：The largest level where a waveform clip is not generated is recommended.
Please edit the sound source by using the sound edit software to become the above-mentioned condition.
10
□ Limitations of each sensing
Mic
・May detect sounds from sources other than people. For example, sounds from dogs or cats may be detected as voices.
・If used with a window left open, sounds from outside may make it difficult to detect human voices, or the device
may react to human voices from outside.
・Detection performance
- It detects it when there is 5 dB or more sound pressure difference between a surrounding noise and the sound
to be detected.
- Detects audio when audio to detect is 65 dB or higher (for voices, coughs, and TV audio).
- Detects audio when audio to detect is 60 dB or higher (for snoring and disturbance of respiration).
- Detects audio when audio to detect is 95 dB or higher (for detecting loud noises).
- Detection area: Horizontal: approx. 180 degrees, Vertical: approx. 180 degrees Distance: approx. less than 5
m (in case of voice, cough and TV sound. In the case of snoring and disturbance of respiration, it is less than
50cm)
Motion sensor
・Sensor that detects moving objects with a temperature difference from the surroundings. Moving objects other than
people may therefore be detected as people. Some examples include animals, opening/closing doors, curtains moving
in the wind, air coming from air conditioners, steam rising from electric water heaters, and swiveling electric
heaters.
・Detection performance
- Detects objects with a +4°C difference in temperature from the surroundings (with a size of around 150 cm x 30 cm)
that have moved in a horizontal direction at a speed of around 1.0 m/s.
- Detection area: Horizontal : approx. 120 degrees, Vertical : approx. 90 degrees, Distance : approx. less than
8 m
Camera
・Performance
- Shooting range : Horizontal : approx. 70 degrees, Vertical : approx. 40 degrees
- Approx. 900 K pixels ( 1280ｘ720)
・Other
- Photographing in a dark place is not possible.
- After a photo is taken, it may take up to two minutes to upload it (depending on the communication environment
and server environment). Other functions such as the Emergency Call Button, Consulting Call Button, or receiving
calls cannot be used during this time.
- Zoom and photographing in a dark place are not possible.
- The camera and call functions cannot be used at the same time. If the Consulting Call/Emergency Call Buttons
are pressed or if a call comes in when the camera is taking a photo, the camera shooting will be canceled.
- When a VoIP call is received or made, or when waiting for a call after pressing the Consulting Call Button, the
shooting instruction will be discarded.
Thermo-hygro sensor
- It takes 30 minutes to start of measurement after power on.
Call Cancel Button
- Cannot use the Emergency Call, Consulting Call and Call Cancel Button for 2 seconds after pushing a button.
11
□ Main unit operation (Gateway Software Configuration Tool)
Operation items Overview Remarks
Setting of Remote Monitoring Station
Configure the Remote Monitoring
Station.
Please refer to the appendix in the User's
Guide (Gateway/Device Settings Version) for
settings.
Remote Monitoring Station diagnosis
Confirm operation of the Remote
Monitoring Station.
└
WLAN connection status
└
Server connection status
└
Pyroelectric sensor status
└
Trespassing prevention mode
└
Camera shooting
Edit/send whitelist Manage a Vital Sensing Unit
to connect
with a Remote Monitoring Station。
The server URL, login ID, and password will
need to be configured in the application.
Device settings
Configure a Vital Sensing Unit
connected with a Remote Monitoring
Station.
└
Device ID
└
Motion function operation settings
└
Vital algorithm function settings
└
Vibration settings
└
Pulse sensor parameter settings
※ For more details, refer to the "User's Guide (for Main Module) / (for Gateway and Device Setup)" attached to the
"UBIQUITOUSWARE Sensor Algorithm".
12
□ Main unit operation (Device Management Tool)
Operation items Overview
Device / Gateway / Remote Monitoring Station List
Display the list of Device / Gateway / Remote Monitoring
Station.
Checking Contents of
Device / Gateway / Remote Monitoring
Station
On clicking a device ID or a gateway ID or a station ID in the
"Device/Gateway/Remote Monitoring Station List," you can check
the data contents that are set for that ID.
(For single device / Gateway)
Batch Editing Devices / Gateways / Remote Monitoring Stations
Edit the value of set item of Device / Gateway / Remote
Monitoring Station at once.
(For multiple devices / Gateways)
Command History
Display the history of control command of
Device / Gateway /
Remote Monitoring Station.
(Display for each request number)
Detailed Information of Control Commands
Display the detailed information of control commands to the
Device / Gateway / Remote Monitoring Station.
(Display the result of
the process, etc. to each Device / Gateway
/ Remote Monitoring Station)
List of uploaded log files Display the list of uploaded log
files from the Device / Gateway
/ Remote Monitoring Station.
IoT Platform Setting Set the connection information to the platform.
Command Create New
■Getting Log
■Firmware Update
■Camera Shooting
■Mode Change
■Sound Data Download
■Sound Data Playback
■Alarm Release
■Remote Monitoring Station Reset
■Certificate Download
The following can be directed.
* The Device in this item refers to Vital Sensing Unit.
* The more information of this tool can be found in the (Sensor Algorithm User's Guide (for Main Module)（Device and Gate Way
Setting）).
□ Setting method when function is not used
Function Operation
All call functions(Incoming and
outgoing)
Do not configure the telephone number after configuring the setting when the C
onsulting
Call button is pressed and the setting when the Emergency Call Button is pressed to "call."
Call function by Consulting Call
Button
Do not configure the consulting report contact telephone number after configuring the
setting when the Consulting Call Button is pressed to "call."
Call function by Emergency Call
Button
Do not configure the emergency report contact telephone number after configuring the
setting when the Emergency Call Button pressed to "call."
Temperature and humidity
measurement Turn off the thermo-hygro sensor ON/OFF.
Trespassing prevention Turn off the Trespassing prevention mode OM/FF and the Trespassing prevention mode
with
the date and hour designation.
Safety confirmation Turn safety confirmation OFF in the sensor algorithm settings.
Out-of-range notification Turn out detection mode OFF.
Camera shooting
There is no setting to turn the function OFF.
To prevent the camera from taking photos, the administrator should not issue a shooting
instruction, or the trespassing prevention mode should be turned OFF. If the trespassing
prevention mode is ON it will automatically take photos.
To completely disable
the camera shooting function, use a Remote Monitoring Station (No
Camera).
13
□ Product operation ( Button )
・Normal button operation
Status Emergency
Call Button
Consulting
Call Button
Call Cancel
button
BLE Pairing
Button
WLAN Connect
Button
Volume
Button(+)
Volume
Button(-)
Short
push
Push
and
hold
Short
push
Push
and
hold
Short
push
Push
and
hold
Short
push
Push
and
hold
Short
push
Push
and
hold
Short
push
Push
and
hold
Short
push
Push
and
hold
During/Under
normal
operation
Emerge
ncy
call
-
VoIP
incomi
ng
- - - -
Blueto
oth
pairin
g with
smartp
hone
-
WLAN
connec
tion
Volume-
up
Volume
-up
Volume-
down
Volume
-down
During
emergency
report /
During
consulting
report /
During
announcement
- - - -
Cancel
( VoIP
call/
camera
photog
raphy
)
- - - - - Volume-
up
Volume
-up
Volume-
down
Volume
-down
During VoIP
call - - - - - - - - - - Volume-
up
Volume
-up
Volume-
down
Volume
-down
During
trespassing
prevention
mode
- - - - - - - - - - Volume-
up
Volume
-up
Volume-
down
Volume
-down
During
camera
photographin
g
Emerge
ncy
call
-
VoIP
incomi
ng
- - - - - - - Volume-
up
Volume
-up
Volume-
down
Volume
-down
During
firmware
update
Emerge
ncy
call
(*1)
-
Emerge
ncy
call
(*1)
- - - - - - - Volume-
up
Volume
-up
Volume-
down
Volume
-down
Out-of-servi
ce - - - - - - - - - - Volume-
up
Volume
-up
Volume-
down
Volume
-down
Configuring
product from
smartphone
over a
Bluetooth
connection
Emerge
ncy
call
test
-
VoIP
incomi
ng
test
- - - -
Blueto
oth
pairin
g with
smartp
hone
-
WLAN
connec
tion
Volume-
up
Volume
-up
Volume-
down
Volume
-down
During
Bluetooth
setting
Emerge
ncy
call
-
VoIP
incomi
ng
- - - - - -
WLAN
connec
tion
Volume-
up
Volume
-up
Volume-
down
Volume
-down
During WLAN
setting with
the WLAN
connection
button
- - - - - - -
Blueto
oth
pairin
g with
smartp
hone
- - Volume-
up
Volume
-up
Volume-
down
Volume
-down
* Five volume levels are available (level 1 to level 5). Pressing the Volume Buttons (+)/ (-) will increase or decrease the
volume step by step.
*1: Emergency call and VoIP incoming are possible only when the firmware data is downloaded. But the firmware download
is cancelled.
14
・Plural button operation
Status
WLAN Connect & BLE Pairing Button
Power-on with pushing both buttons at the same time
WLAN Connect & BLE Pairing Button
Short push Push and hold Short push
Push and hold
During/Under
normal operation
- Reset to factory default - Bluetooth pairing with the Vital S
ensing
Unit
During emergency
report / During
consulting report /
During
announcement
- - - -
During VoIP call
- - - -
During trespassing
prevention mode
- - - -
During camera
photographing
- - - -
During firmware
update
- - - -
Out-of-service
- - - -
Configuring
product from
smartphone over a
Bluetooth
connection
- - - Bluetooth pairing with the Vital S
ensing
Unit
During Bluetooth
setting
- - - -
During WLAN setting
with the WLAN
Connection Button
- - - Bluetooth pairing with the Vital S
ensing
Unit
15
□ LED list
LED Status of main unit Status of LED
Status LED
(Green and Red)
Calling
Green flashing
Emergency announcement
Dangerous Heat Disorder
announcement
Talking Green lights
Equipment abnormality occurs in
Red flashing
During a firmware update Green fast flashing
Power LED
(Green)
Power ON Lighting
Power OFF Turning lights off
Camera LED
(Green)
Camera use Lighting⇒20 seconds after off
Camera unused Turning lights off
WLAN Connect LED
(Green)
WLAN setting in Green flashing
WLAN setup complete Green lights⇒3 seconds after off
Network communication possible Green lights
BLE Pairing LED
(Green and Red)
Pairing in Green flashing
*Up to 30 seconds
Pairing establishment Green lights⇒3 seconds after off
Pairing failed Red flashing⇒3 seconds after off
* All LED is turned off when the power supply of the main unit is off.
* When the WLAN is cut in the out of the sphere etc. after the WLAN is connected, the WLAN Connect LED is turned off.
* The BLE Pairing LED does not light while connected it after the BLE pairing succeeds.
* The Status LED might seem flashing to orange if equipment abnormality occurred while the Status LED is lighting or flashing
to green.
* When the Status LED has flashed in red or orange, an equipment abnormality occurs. Please put the power supply of the main
unit again.
□ Connection of external devices
Capable of connecting external devices
UBIQUITOUSWARE Vital Sensing Unit
・The maximum number of connections to a single Remote Monitoring Station : 4
・Connection method : Select from the connection by the pairing and by the whitelist
Remote Monitoring Station
Instruction Manual (detailed version)
Published by FUJITSU LIMITED
Information on the product description meets the
design
specifications of Fujitsu and is provided for
comparison purposes.
Several factors may cause the actual results to
differ.
Technical data is subject to change without prior
notification. Fujitsu rejects any responsibility
with regard to technical or
editorial mistakes or
omissions.
