Introduction

3. For more detailed information, contact "General Inquiries" using the phone

number on the back of this manual.

・

FeliCa reader/writer function of FOMA terminal uses weak waves

requiring no licenses for radio stations.

・

It uses 13.56 MHz frequency band. When using other reader/writers in

your surroundings, keep FOMA terminal away sufficiently from them.

Before using the FeliCa reader/writer, confirm that there are no radio

stations using the same frequency band nearby.

・

Do not use a remodeled FOMA terminal. Using a remodeled terminal

violates the Radio Law.

FOMA terminal is certified according to technical standard conformance of

specified wireless equipment based on the Radio Law, and as a proof of it, the

"Technical Compliance Mark " is depicted on the engraved sticker of FOMA

terminal.

If you remodel FOMA terminal by removing its screws, your certification of

technical standard conformance becomes invalid.

Do not use FOMA terminal with its certification of technical standard conformance

invalid as it violates the Radio Law.

・

Be careful when you use FOMA terminal while driving a car etc.

Using a mobile phone while driving is subject to penal regulations.

If you inevitably receive a call, tell the caller that you will "call back" by handsfree,

then park in a safe place and call back.

・

Use the Bluetooth function only in Japan.

The Bluetooth function of the FOMA terminal is compliant with wireless standards

and is authorized for use only in Japan.

If you use this function overseas, you may be punished.

・

Use FeliCa reader/writer function only in Japan.

FeliCa reader/writer function of FOMA terminal conforms to Japanese radio

standards.

If you use this function overseas, you may be punished.

FeliCa reader/writer

CAUTION

F-01B_usugata_1kou_0729

Introduction

Waterproofness/Dustproofness

F-01Bis provided with the following waterproofness by firmly closing the

external connection jack cap, installing the back cover and locking the

cover.

・

IPX5 (Former JIS protection code 5)

・

IPX8

that is a higher standard than IPX7 (former JIS protection code

Also, F-01B is dustproof to IP5X (former JIS protection code 5)

if the

external connection jack cap is strictly closed as well as the back cover is

mounted and locked.

*1 Code IPX5 means that a phone keeps functioning after directly applying a jet

flow of 12.5 L/min. for at least 3 minutes from a distance of 2.5-3 m on a

rotating turntable.

*2 Code IPX7 means that a phone keeps functioning after it is slowly submerged

to depth of 1 m in static tap water at room temperature, left there for 30

minutes and then taken out.

*3 Code IPX8 means that it provides waterproofness of which exceeds of IPX7

standard.

*4 Code IP5X means that a device is protected against the ingress of dust specific

to dustproof test (25

m or smaller in diameter), so that the ingress will not

interfere with predefined operation and safety of the device.

F-01B provides the following waterproof performances of IPX8.

･

F-01B keeps functioning after it is slowly submerged to depth of 1.5 m in

static tap water at room temperature, left there for 30 minutes and then taken

out.

･

The mobile phone keeps shooting still images or moving pictures in 30

minutes in static tap water at room temperature.

✜

What you can do with waterproofness and

dustproofness of F-01B

・

You can talk or watch 1Seg programs without using an umbrella in the

rain (for rainfall of 20 mm or less per hour).

- When your hands or FOMA terminal are wet, avoid installing/removing the back

cover or opening/closing the external connection jack cap.

・

You can wash mud or dirt away.

- Do not apply water flow stronger than allowed (e.g., such water flow that gives

you pain when applied to your skin directly from a faucet or shower).

- Wash it using room-temperature tap water with your hand, with FOMA terminal

locked, the back cover installed and the external connection jack cap held in

position.

- Do not use any brush, sponge, soap, cleaning material, etc.

- After flushing away, wipe off water with a dry cloth, drain, and dry naturally.

・

You can touch the terminal with your hand that is wet with salt water

or seawater.

- Do not operate the terminal.

- If you touch the terminal with your wet hand, flush away immediately as

predefined.

・

You can also shoot still images and moving pictures in the pool depth

of 1.5 m.

- Do not perform other operations underwater than shooting still images and

moving pictures.

- If you put the terminal in water of swimming pool, be sure to have it within 30

minutes.

- If FOMA terminal gets wet with water from the swimming pool, wash it as

predefined.

・

You can use FOMA terminal in a bathroom.

- Do not put the terminal in the bathtub. Do not use the terminal in hot water.

Doing so may cause malfunction.

- Never put FOMA terminal in hot spring water or water containing soap,

detergent or bath powder.

To ensure waterproofness/dustproofness

To keep the FOMA terminal waterproof/dustproof, be sure to observe the

points below.

・

If FOMA terminal should get wet with salt water, sea water or soft drink, you can

flush away. However, do not let the terminal get wet with liquids other than tap

water at room temperature.

F-01B_usugata_1kou_0729

Introduction

・

Open/close the external connection jack cap as described below.

Place your finger at groove on the hinge side to open the cap.

Close with the tab for the back cover at the rear side of the cap fitted into the

concave of this terminal. Make sure that the cap is completely closed without

slack.

・

Install the back cover as described below.

Align 8 tabs of the back cover with concaves of FOMA terminal. While pressing the

back cover in the direction of

so that there is no gap between FOMA terminal

and back cover, slide the back cover in the direction of

to install, then slide the

back cover lever in the direction of

to lock.

* Make sure that the back cover is completely closed without slack. Slide the

back cover in the direction of the arrow shown on the lever, and then make

sure the cover is securely locked before using.

・

Securely lock the back cover and firmly close the external connection jack cap.

Even a fine obstacle (one hair, one grain of sand, tiny fiber, etc.) put between

contact surfaces may allow water to enter.

・

Do not poke the microphone, earpiece or speaker with a swab or sharp object.

・

Do not let FOMA terminal fall. It may become scratched causing the waterproof/

dustproof performance to degrade.

・

The external connection jack cap and the rubber packing of the inner lid play an

important role for keeping waterproof/dustproof performance. Do not remove or

scratch it. Also, prevent dust from adhering to it.

Groove on the hinge side

Tab on the back

cover side

Back cover

Lever

F-01B_usugata_1kou_0729

Introduction

To keep the FOMA terminal waterproof/dustproof, replacement of parts is

required every 2 years regardless of whether FOMA terminal appears normal

or abnormal. DOCOMO replaces the parts as a chargeable service. Bring FOMA

terminal to a sales outlet such as a DOCOMO-specified repair office.

Important precautions

Do not perform actions shown in the illustrations below.

Observe the following precautions to use FOMA terminal properly.

・

Accessories and optional devices are not waterproof/dustproof. When watching

1Seg etc. with FOMA terminal installed in the desktop holder, do not use it in a

bath room, shower room, kitchen or lavatory even if it is not connected to the AC

adapter.

・

Do not apply water flow stronger than allowed (e.g., such water flow that gives

you pain when applied to your skin directly from a faucet or shower). F-01B

provides the following waterproof performances of IPX5. However, it causes

malfunction.

・

If FOMA terminal gets wet with salt water, seawater, water from the swimming

pool or soft drink, or with mud or soil, flush away immediately. When it dries out,

it becomes harder to get rid of, causing malfunction.

・

Do not use FOMA terminal before flushing mud or soil away. This damages FOMA

terminal.

・

Do not put FOMA terminal in hot water, use it in a sauna or apply hot airflow (from

a hair dryer etc.) to it.

・

Do not move in water or slam the terminal against the surface of water with FOMA

terminal opened.

・

If you put the terminal in tap water or in water of swimming pool, be sure to have

it within 30 minutes.

・

When you use the terminal in swimming pool, obey rules of the facility.

・

FOMA terminal does not float on water.

・

Do not leave water on FOMA terminal. May short-circuit the power jacks, or in a

cold region, water may freeze causing malfunction.

・

Do not leave water on the microphone, earpiece or speaker. Such water may

interfere with talking.

・

If the back cover is damaged, replace it. Water may enter inside from a damaged

section causing troubles such as electric shocks or corrosion of the battery.

・

If FOMA terminal gets wet with water or other liquids with the external connection

jack cap or back cover open, the liquid may get inside the terminal causing electric

shocks or malfunction. Stop using FOMA terminal, turn the power OFF, remove

the battery pack and contact a DOCOMO-specified repair office.

・

If rubber gasket on the external connection jack cap or inner lid is damaged or

deformed, replace it at DOCOMO-specified repair office.

DOCOMO does not guarantee actual operations under all states. Malfunctions

deemed to be caused by inappropriate operation by the customer are not

covered by the warranty.

Using Soap/Detergent/

Bath powder

Soaking in

ocean water

Washing by

laundry machine

Applying strong

water flow

Washing with

brush/sponge

Using in

hot spring

F-01B_usugata_1kou_0729

Introduction

Wash the terminal with tap water while holding the external connection

cap. Do not rub the terminal.

* After washing FOMA terminal, drain in the following steps, and dry naturally.

When FOMA terminal is wet, water may flow out after wiping it off; drain the water

in the following steps.

Wipe FOMA terminal surface with dry, clean cloth etc.

Shake FOMA terminal approximately 20 times, firmly holding its

hinge section, until there is no more water splattering.

Softly press dry, clean cloth etc., against FOMA terminal to wipe off

water remaining in the microphone, earpiece, speaker, keys or

hinges.

Washing FOMA terminal

Draining water when the FOMA terminal gets wet

Press here

To drain water off the speaker, shake

FOMA terminal with the speaker upward

F-01B_usugata_1kou_0729

Introduction

Remove the back cover and wipe off any drops of water around the

inner lid and the rear side of the back cover. Never open the inner lid.

After wiping off the water, install and lock the back cover.

Removing back cover

⇒P25

Wipe off water drained from FOMA terminal with dry, clean cloth etc.

･

Water, if any, remaining in FOMA terminal may ooze up after wiping off.

･

Do not wipe off water remaining in concaves directly with a cotton swab etc.

･

After wiping off water, dry naturally.

Check the following before and after charging.

・

Check that FOMA terminal is not wet. Never try to charge the battery pack when

FOMA terminal is wet.

・

Accessories and optional devices are not waterproof/dustproof.

・

When charging the battery when or after FOMA terminal is wet, adequately drain

it and wipe off water with a dry, clean cloth etc., before connecting a desktop

holder or opening the external connection jack cap.

・

When the external connection jack cap is opened for charging, close the cap firmly

after charging. It is recommended that the desktop holder be used for charging to

prevent water from seeping inside from the external connection jack.

・

Do not use the AC adapter or desktop holder in a bathroom, shower room, kitchen,

lavatory or other highly humid area. May cause fire or electric shock.

・

Do not touch the AC adapter or desktop holder with wet hands. May cause electric

shock.

Around the inner lid

Rear side of the back cover

Charging

F-01B_usugata_1kou_0729

Basic Operation

Before Using

Attaching UIM (FOMA card)/battery pack

After turning power OFF, close FOMA terminal and hold it in your

hand so that you can properly attach the card/pack.

✜

Removing the Back Cover

Slide the back cover lever in the direction of

to unlock, and then

slide the cover in the direction of

by 2 mm with a thumb to remove

it. Pinch the tab of the inner cover and open the cover in the direction

until it stops.

✜

Installing UIM

Pull the tab with your nail and pull out the tray until it clicks. (

). Hold

UIM with the IC side down, align the beveled corner with the tray and

push into the tray until it stops (

✜

Installing battery pack

With the label side of the battery pack upward, align convex parts of

the battery pack with concave parts of FOMA terminal and slide the

battery pack in the direction of

, press the battery pack in the

direction of

to set it in, and then close the inner cover.

✜

Installing back cover

Place the 8 tabs of back cover to the notches, press back cover in the

direction of

to avoid forming any clearance between FOMA

terminal and back cover, then slide it in the direction of

to install it.

Finally, slide the lever in the direction of

to lock.

Point

･

The inner cover can be solidly closed for maintaining water-/dust-proof

performance. Opening the cover forcibly may injure your nails or fingers.

･

To prevent damage due to excessive force, the hinge of the inner cover

(the section where FOMA terminal makes contacts) is designed to be

removed. If it is detached, align metal pins on the inner cover with the

slots on FOMA terminal, and then press the cover until it clicks.

Tab

Lever Press here with your thumb

Back Cover

Corner cut

UIM

Tray

Tab

Convex Part

Concave Part

Battery Pack

Back cover

Lever

F-01B_usugata_1kou_0729

Basic Operation

Before Using

Charging

The battery pack does not have a full charge at time of purchase.

Use AC adapter for FOMA terminal to charge the battery before

using FOMA terminal.

Insert the AC adapter to the desktop holder, with

the arrow on the AC adapters connector upward.

Unfold the AC adapters power plug and insert it

into a 100V AC outlet.

With FOMA terminal closed, insert it into the

desktop holder.

* Check that the light turns on.

After charging is completed, remove FOMA

terminal from the desktop holder.

Open jack cap (

) of FOMA terminal, hold the

connector horizontally with the arrow side

upward and insert it to the jack. (

)

Unfold the power plug and insert it into a 100V

AC outlet.

When charging is over, pull out the power plug

from the outlet, and pull out from FOMA terminal

horizontally while pressing the release buttons

on both sides of the connector.

✜

Operations for charging

When charging starts, a charge start alert sounds. While charging, the

light turns on and the battery icons on the display and the sub-display

blink. When charging is over, a charge completion alert sounds.

Using desktop holder and AC adapter in

combination for charging

100V AC outlet

Light

Release button

Connector

Desktop holder

Insert at the back side

AC adapter

Power plug

Charging using AC adapter

100V AC outlet

Connector

Release button

External

connection

jack

Jack cap

Power plug

AC adapter

Light

F-01B_usugata_1kou_0729

Basic Operation

Before Using

Turning power ON - Initial Setting

Perform the following operations after turning the power ON for

the first time.

(2 sec. or more)

"Yes" or "No" on a confirmation

screen of enlarged menu setting

Set required items on Initial

setting screen

[Quit]

Always set Password and Request permit/

deny. If you exit without setting, Initial

setting screen reappears when the power

is turned ON the next time.

on a confirmation screen of software update

function

The stand-by display appears.

Point

Turning power off :

(2 sec. or more)

Changing the initial setting :

hgdg

･

If no operation is performed, the display light is turned off

automatically according to the settings in

【

Light time-out

】

【

Power saving mode

】

. The display light turns on again if there is

any operation or incoming call.

Information

Before Using

User information

Check your own phone number.

For details of checking/changing a mail address, refer to "Mobile

Phone User's Guide [i-mode] FOMA version".

User information

The screen shown to the right appears.

Point

Editing user information :

On User information edit screen,

Authenticate

Edit

Checking a phone number during a call :

F-01B_usugata_1kou_0729

Basic Operation

Screens

Viewing display

The current state can be checked by the

icon appearing on the screen. Below are

major icons.

✜

Top of the display

Battery level

Signal strength

Self mode ON

In data transfer mode

Connecting to i-mode

Infrared communication in operation

Bluetooth power ON

The total calls cost exceeds the limit

Bluetooth connection being

established

Communication using a handsfree

device in progress

Handsfree ON

Power saving mode activated

Positioning with GPS

Security lock ON

A phonebook entry or schedule has

secret attribute

High-pitched alarm ON

Unread Area Mail exists

Unread i-mode mail exists

Arrival i-concier information exists

Unreceived i-mode mail exists in the i-

mode Center

Displaying SSL/TLS page etc.

Auto-send mail exists

Music&Video Channel program

obtaining reservation exists

During i-

ppli operation

ppli call exists

Alarm clock ON

Schedule reminder ON

Inside OFFICEED area

✜

Bottom of the display

Arrival information (missed call, recorded

message, voice mail service, unread

message, unread ToruCa, i-

ppli call)

Silent mode ON

Call alert volume OFF

Vibrator for voice call ON

In Public mode (Drive mode)

Record message ON

Keypad dial lock ON

GPS Request failed

Personal data lock ON

Music&Video Channel program

obtaining failure

Reading UIM

IC card lock ON

Available multi-cursor key

Performing 1Seg recording

reservation

ppli Auto start failed

microSD card installed during

Communication mode

Connected to external device using

USB cable

Pedometer/ACT monitor is set

Software update notice

Auto-update of latest pattern

definition failure

Ample

charge

Almost exhausted

(Charge the battery)

Strong Out of service area or where

radio waves do not reach

Weak

F-01B_usugata_1kou_0729

Basic Operation

Task Area

The icon indicating the function

(task) in progress appears in the

task area.

Guide Area and Key Operation

Operations that can be performed by

pressing

and

are displayed in the guide area.

To perform an operation in the guide

area, press the corresponding key.

The guide display for

and the functions assigned

are automatically switched

according to the tilt of FOMA

terminal.

Even when FOMA terminal is

closed, the icons and messages in

the sub-display provide a lot of

information.

When no operation is performed

for approximately 8 seconds, the sub-display light is turned off,

but it turns on again when you press either side key.

✜

Switching views

Each time you press

, the view switches in the order of Clock (Digital

⇒

Clock (Digital 2)

⇒

Analog. When "Use" is set to Set Pedometer/

Activity monitor, or "Yes"is set to Show ticker of i-Channel setting,

each time you press

, the view switches in the order of Activity

⇒

Channel ticker

⇒

Clock.

✜

Arrival Information

When a missed call, recorded message, unread message, unread

messageR/F, voice message of Voice Mail service or i-concier

information exists, pressing

with Clock displayed displays the

number of missed calls, and then pressing

scrolls reception date/

time and information about the senders.

✜

Call light and mail light

Call light ( ) blinks when an unchecked missed call exists, and Mail

light ( ) blinks when an unread message or unread SMS exists.

Task area

Guide area

Sub-display

･

The light turns on just by tilting FOMA handset.

【

Auto light on

】

Information

F-01B_usugata_1kou_0729

Basic Operation

Screens

Menu operation

On the stand-by display, press

and then perform the

functions from the menu. You can select a menu item with

shortcut operations, which use the keypad,

and

, or with

multi-cursor operation, which uses the multi-cursor key to move

the cursor.

〈Example〉

Selecting "Calculator"

Shortcut operations

me7e4

Multi-cursor key operations

Move the cursor to "

Accessory"

［

Select

］

Move the cursor to "

Calculator"

［

Select

］

Point

･

Even when a function is running, you can perform the same operation if

"MENU" is displayed on the guide area.

･

To return to the previous menu, press

. To return to the stand-by

display, press

･

On the stand-by display with Info/calendar layout, Shortcut icons set, or

with arrival information icon or i-concier information displayed, press

to change the display to Focus mode that allows you to quickly display the

related information.

You can switch among "Kisekae Menu", the design of which can be

changed using Kisekae Tool

（⇒P44）

, "Basic Menu", which has

the fixed menu numbers, and "Select Menu", to which menu items

can be saved freely.

A Kisekae menu matched with the color of FOMA terminal is set by

default.

Point

･

In some types of Kisekae menus, the menu structure is changed according

to usage frequency, or the number assigned to menu item (item number)

may not be applicable.

m 7 4

Switching menu screens

･

The menu that appears when

is pressed on the stand-by display

can be changed from Start start menu.

⇒P40

Information

F-01B_usugata_1kou_0729

Basic Operation

Screens

Using touch panel

You can use the display as touch panel. You can perform the same

operation by touch operation as on the screen to move the cursor

with key operation. The followings are major touch operations.

Types of touch operations

Touch

Touch the display lightly once and release the finger.

The operation becomes effective when you release

your finger from the display. This operation is mainly

for selecting menus, items, etc.

Double-touch

Touch the display lightly twice and release the finger.

The operation becomes effective when you release

your finger from the display. This operation is mainly

for zooming in/out or switching the display.

Slide

Keep touching the display, move your finger up,

down, right or left. This operation is for scrolling a

screen, rewinding/fast-forwarding a video, etc.

Slide

quickly

Touch the display lightly and flick your finger up,

down, right or left. This operation is for switching

pages or images, or moving to a different chapter or

tune, etc.

Example: SlideExample: Touch

Touch-specific operations

Perform touch-specific operation

to select a function from the

stand-by display. To display the

stand-by launcher (shown to the

lower right), touch other than the

stand-by touch button.

Guidance button

You can touch guidance buttons

to return to the previous screen

(

), exit a function (

), or

operate a function displayed in

the guide area (

F-01B_usugata_1kou_0729

Basic Operation

Menu buttons for touch

operation

Buttons that correspond to a

function are displayed.

Moving focus and selecting

menu/item

To select a menu or item, touch a

menu or item to select, move the

focus for touch operation, then

touch the menu or item again.

Link items or confirmation

screens

Directly touch an item.

Numeric value setting roller

When you select an

item to set numeric

values such as date

and time, you can

rotate the roller by

slide operation to set

it.

Menu button for touch operation

e.g. : Outgoing call screen e.g. : My document

Slide on the list

Touch an item

directly

Direction/Determination

button

When using i-mode browser in

Viewer style, you can operate

menus or items on the displayed

screen using the direction/

determination button.

Channel switch panel/Volume

adjust panel/Slider

While playing 1Seg or a moving

picture, slide vertically or

horizontally to display a panel,

and then touch or slide.

Touch or slide the slider to adjust

a value.

Making a voice call

To make a voice call, press

on the stand-by touch display.

Answer a call

To answer a call, touch the

display while receiving a call to

display a button.

F-01B_usugata_1kou_0729

Basic Operation

Screens

使いかたガイド

(Guide)

Guide provides overviews and operations of functions , and

troubleshooting. (In Japanese only)

LifeKit

Guide

Select

a search method

(Contents) :

Search from a list of

functions.

索引

(Index) :

Search from a list of words

sorted according to Japanese syllabary.

フリーワード検索

(Free word search) :

Enter a keyword to search for.

ブックマーク

(Bookmark) :

Search from a

list of registered bookmarks.

困ったときには

(Troubleshooting) :

Search from lists of

troubles or error messages.

Point

･

On a description screen, select "

この機能を使う

(Use this function)" to

perform a function. Selecting a link item in "

関連機能

(related functions)",

or "

→コチラ

(See more)" displays a corresponding description screen.

･

You can also access Free word search from Quick search.

⇒P114

ޛ૶޿߆ߚࠟࠗ࠼)WKFGޜ

Information

You can notify your phone number (caller ID) to the other party's

terminal when making a voice call.

Settings & NW services

Services

Caller ID

notification

Activate/Deactivate

Inform

Select "

Not inform" if you do not want to inform.

Point

･

Caller ID is your important personal information. Carefully consider

whether you want to include caller ID information when making a call.

･

If an announcement of requesting caller ID is heard when making a call,

make a call again after setting your caller ID to "Inform".

Caller ID notification

(Default : Inform)

F-01B_usugata_1kou_0729

141

Others

Index

Specific absorption rate (SAR) of mobile phone

This model phone FOMA F-01B meets the MIC's

technical regulation

governing exposure to radio waves.

The technical regulation established permitted levels of radio frequency

energy, based on standards that were developed by independent scientific

organizations through periodic and thorough evaluation of scientific studies.

The regulation employs a unit of measurement known as the Specific

Absorption Rate, or SAR. The SAR limit is 2 watts/kilogram (W/kg)

averaged

over 10 grams of tissue. The limit includes a substantial safety margin designed

to assure the safety of all persons, regardless of age and health. The value of

the limit is equal to the international guidelines recommended by ICNIRP.

All phone models should be confirmed to comply with the regulation, before

they are available for sale to the public. The highest SAR value for this FOMA

F-01B is 0.641 W/kg. It was taken by the Telecom Engineering Center (TELEC).

The test for SAR was conducted according to the MIC testing procedure using

standard operating positions with the phone transmitting at its highest

permitted power level in all tested frequency bands. While there may be

differences between the SAR levels of various phones and at various positions,

they all meet the MIC's technical regulation. Although the SAR is determined at

the highest certified power level, the actual SAR of the phone during operation

can be well below the maximum value.

For further information about SAR, please see the websites below.

World Health Organization (WHO) :

http://www.who.int/peh-emf/

ICNIRP :

http://www.icnirp.de/

MIC :

http://www.tele.soumu.go.jp/e/sys/ele/body/ index.htm

TELEC :

http://www.telec.or.jp/ENG/Index_e.htm

NTT DOCOMO :

http://www.nttdocomo.co.jp/english/product/

FUJITSU LIMITED :

http://www.fmworld.net/product/phone/sar/

*1 Ministry of Internal Affairs and Communications.

*2 The technical regulation is provided in Article 14-2 of the

Ministry Ordinance Regulating Radio Equipment.

*3 International Commission on Non-Ionizing Radiation

Protection.

The product "F-01B" is declared to conform with the essential requirements of

European Union Directive 1999/5/EC Radio and Telecommunications Terminal

Equipment Directive 3.1(a), 3.1(b) and 3.2. The Declaration of Conformity can

be found at http://www.fmworld.net/product/phone/doc/.

This mobile phone complies with the EU requirements for exposure to radio

waves.

Your mobile phone is a radio transceiver, designed and manufactured not to

exceed the SAR* limits** for exposure to radio-frequency(RF) energy, which

SAR* value, when tested for compliance against the standard was 0.551W/Kg.

While there may be differences between the SAR* levels of various phones and

at various positions, they all meet*** the EU requirements for RF exposure.

* The exposure standard for mobile phones employs a unit of measurement

known as the Specific Absorption Rate, or SAR.

** The SAR limit for mobile phones used by the public is 2.0 watts/kilogram (W/

Kg) averaged over ten grams of tissue, recommended by The Council of the

European Union. The limit incorporates a substantial margin of safety to give

additional protection for the public and to account for any variations in

measurements.

*** Tests for SAR have been conducted using standard operation positions with

the phone transmitting at its highest certified power level in all tested

frequency bands. Although the SAR is determined at the highest certified

power level, the actual SAR level of the phone while operating can be well

below the maximum value. This is because the phone is designed to operate

at multiple power levels so as to use only the power required to reach the

Declaration of Conformity

F-01B_usugata_1kou_0729

142

Others

network. In general, the closer you are to a base station antenna, the lower the

power output.

･

This device complies with part 15 of the FCC rules.

Operation is subject to the following two conditions :

this device may not cause harmful interference, and

this device must accept any interference received, including interference

that may cause undesired operation.

･

Changes or modifications made in or to the radio phone, not expressly

approved by the manufacturer, will void the user's authority to operate the

equipment.

This model phone meets the U.S. Government's requirements for exposure to

radio waves.

This model phone contains a radio transmitter and receiver. This model phone

is designed and manufactured not to exceed the emission limits for exposure

to radio frequency (RF) energy as set by the FCC of the U.S. Government. These

limits are part of comprehensive guidelines and establish permitted levels of RF

energy for the general population. The guidelines are based on standards that

were developed by independent scientific organizations through periodic and

thorough evaluation of scientific studies.

The exposure standard for wireless mobile phones employs a unit of

measurement known as the Specific Absorption Rate (SAR). The SAR limit set

by the FCC is 1.6 W/kg. Tests for SAR are conducted using standard operating

positions as accepted by the FCC with the phone transmitting at its highest

certified power level in all tested frequency bands. Although the SAR is

determined at the highest certified power level, the actual SAR level of the

phone while operating can be well below the maximum value. This is because

the phone is designed to operate at multiple power levels so as to use only the

power required to reach the network. In general, the closer you are to a wireless

base station antenna, the lower the power output level of the phone.

Before a phone model is available for sale to the public, it must be tested and

certified to prove to the FCC that it does not exceed the limit established by the

U.S. government-adopted requirement for safe exposure. The tests are

performed on position and locations (for example, at the ear and worn on the

body) as required by FCC for each model. The highest SAR value for this model

phone as reported to the FCC, when tested for use at the ear, is 0.462W/kg, and

when worn on the body, is 0.521W/kg. (Body-worn measurements differ

among phone models, depending upon available accessories and FCC

requirements).

While there may be differences between the SAR levels of various phones and

at various positions, they all meet the U.S. government requirements.

The FCC has granted an Equipment Authorization for this model phone with all

reported SAR levels evaluated as in compliance with the FCC RF exposure

guidelines. SAR information on this model phone is on file with the FCC and

can be found under the Equipment Authorization Search section at http://

www.fcc.gov/oet/ea/fccid/ (please search on FCC ID VQK-F01B).

Federal Communications Commission (FCC)

Notice

FCC RF Exposure Information

F-01B_usugata_1kou_0729

143

Others

For body worn operation, this phone has been tested and meets the FCC RF

exposure guidelines when used with an accessory designated for this product

or when used with an accessory that contains no metal and which positions the

handset at a minimum distance of 1.5 cm from the body.

* In the United States and Canada, the SAR limit for wireless mobile phones

used by the general public is 1.6 Watts/kg (W/kg), averaged over one gram

of tissue. SAR values may vary depending upon national reporting

requirements and the network band.

This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses and

can radiate radio frequency energy and, if not installed and used in accordance

with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not

occur in a particular installation.

If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the

following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

AIRCRAFT

Switch off your wireless device when boarding an aircraft or whenever you are

instructed to do so by airline staff. If your device offers flight mode or similar

feature consult airline staff as to whether it can be used on board.

DRIVING

Full attention should be given to driving at all times and local laws and

regulations restricting the use of wireless devices while driving must be

observed.

HOSPITALS

Mobile phones should be switched off wherever you are requested to do so in

hospitals, clinics or health care facilities. These requests are designed to

prevent possible interference with sensitive medical equipment.

PETROL STATIONS

Obey all posted signs with respect to the use of wireless devices or other radio

equipment in locations with flammable material and chemicals. Switch off your

wireless device whenever you are instructed to do so by authorized staff.

INTERFERENCE

Care must be taken when using the phone in close proximity to personal

medical devices, such as pacemakers and hearing aids.

Pacemakers

Pacemaker manufacturers recommend that a minimum separation of 15 cm be

maintained between a mobile phone and a pace maker to avoid potential

interference with the pacemaker. To achieve this use the phone on the opposite

ear to your pacemaker and does not carry it in a breast pocket.

Hearing Aids

Some digital wireless phones may interfere with some hearing aids. In the

event of such interference, you may want to consult your hearing aid

manufacturer to discuss alternatives.

For other Medical Devices :

Please consult your physician and the device manufacturer to determine if

operation of your phone may interfere with the operation of your medical

device.

Important Safety Information

F-01B_usugata_1kou_0729

144

Others

Index

Export Administration Regulations

This product and its accessories may be under coverage of the Export

Administration Regulations of Japan ("Foreign Exchange and Foreign

Trade Control Laws" and the related laws and regulations). And, they

are also under coverage of Export Administration Regulations of the

U.S. When exporting and reexporting this product and its

accessories, take necessary procedures on your responsibility and

expense. For details, contact Ministry of Economy, Trade and

Industry of Japan or US Department of Commerce.

Index

Intellectual Property Right

Except for the case protected by copyright laws such as personal use, use of

FOMA terminal to reproduce, alter, or publicly transmit recorded pictures or

sounds, or copyrighted text, images, music or software downloaded from

websites without the copyright holder's authorization is prohibited.

Note that taking photos or recordings at some demonstrations, performances

or exhibitions may be prohibited even when only for personal use.

Avoid taking pictures of others with FOMA terminal without their consent or

disclosing recorded pictures of others without their consent to general public

through Internet websites etc., because they may infringe on portrait rights.

Company and product names mentioned in this manual are trademarks or

registered trademarks of their respective holders.

･

"FOMA", "mova", "i-motion", "i-mode", "i-

ppli", "i-motion mail", "i-shot",

"DoPa", "mopera", "mopera U", "WORLD CALL", "WORLD WING", "Chaku-

motion", "Deco-mail", "visualnet", "V-live", "i-area", "Chara-den", "i-

ppliDX",

"i-Channel", "Dual Network", "FirstPass", "Security Scan", "Public mode",

"ToruCa", "iD", "2in1", "DCMX", "OFFICEED", "IMCS", "Chokkan Game",

"docomo PRIME series" and logos of "FOMA", "i-mode", "i-

ppli",

"Music&Video Channel", "DCMX", "iD" and "HIGH-SPEED" are trademarks or

registered trademarks of NTT DOCOMO.

･

Microsoft

, Windows

, Windows Vista

, Windows Media

and

PowerPoint

are trademarks or registered trademarks of "Microsoft

Corporation" in the US and other countries.

･

Microsoft Excel and Microsoft Word are product names of Microsoft

Corporation in the U.S.A. In this manual, they may be described as Excel and

Word.

･

"Multitask" is a registered trademark of NEC Corporation.

･

"Catch Phone (Call Waiting Service)" is a registered trademark of Nippon

Telegraph and Telephone Corporation.

･

Free Dial logo mark is a registered trademark of NTT Communications

Corporation.

Copyrights and portrait rights

Trademarks

F-01B_usugata_1kou_0729

145

Others

･

Java and all Java-related trademarks and logos are trademarks or registered

trademarks of Sun Microsystems, Inc. in the US and other countries.

･

This product contains NetFront Browser, NetFront Sync

Client of ACCESS CO., LTD.

ACCESS and NetFront are trademarks or registered trademarks of ACCESS

CO., LTD. in Japan, US and other countries.

･

reserved.

JBlend and JBlend-related trademarks are trademarks or registered

trademarks of Aplix Corporation in Japan and other countries.

･

This product contains Adobe

Flash

Lite

and Adobe Reader

Mobile

technology of Adobe Systems Incorporated.

Adobe Flash Lite Copyright

2003-2009 Adobe Systems Incorporated. All

rights reserved.

Adobe Reader Mobile Copyright

1993-2009 Adobe Systems Incorporated.

Adobe, Adobe Reader, Flash and Flash Lite are either registered trademarks

or trademarks of Adobe Systems Incorporated in the United States and/or

other countries.

･

QR code is a registered trademark of Denso Wave Inc.

･

microSDHC Logo is a trademark.

･

FeliCa is a registered trademark of Sony

Corporation.

･

"CROSS YOU" is a trademark of Sony Corporation.

･

is a registered trademark of FeliCa Networks, Inc.

･

Word, Excel and PowerPoint file display technologies

are powered by Picsel Technologies.

Picsel, Picsel File Viewer and the Picsel cube logo are trademarks or

registered trademarks of Picsel Technologies.

･

McAfee

is registered trademarks or trademarks of McAfee, Inc. and/or its

affiliates in the US and/or other countries.

･

G-GUIDE, G-GUIDE MOBILE and their logos are registered

trademarks in Japan of U.S. Gemstar-TV Guide International, Inc.

and/or its affiliates.

･

QuickTime is a registered trademark of Apple Inc. in the US and other

countries.

･

ATOK + APOT of Justsystem Corporation is installed in this product as

Japanese character conversion function.

"ATOK" "APOT (Advanced Prediction Optimization Technology)" are

registered trademarks of Justsystem Corporation.

･

is a trademark or registered trademark of Nuance

Communications, Inc. in US and of Nuance corporations in other

countries.

･

This equipment is provided with the software licensed by Symbian Software

Ltd. or the licensor”1998-2009. and Symbian OS are trademarks of

Symbian Ltd. or the licensor.

･

"Privacy mode" is a registered trademark of FUJITSU LIMITED.

･

Bluetooth

and its logo are registered trademarks of Bluetooth SIG, Inc., and

NTT DOCOMO uses them under license. Other trademarks and names inhere

to their respective owners.

･

Napster is a registered trademark of Napster, LLC. and/or its affiliates in the

US and/or other countries.

･

Manufactured under license from Dolby Laboratories. Dolby and the double-

D symbol are trademarks of Dolby Laboratories.

･

FrameSolid is the registered trademark of Morpho, Inc. in Japan and other

countries.

･

The automatic guiding technology utilized is TrackSolid, a product of

Morpho, Inc. TrackSolid is a trademark of Morpho, Inc.

･

Google is registered trademark of Google Inc.

･

ズーキーパー

(Zookeeper) is a trademark or registered trademark of

KITERETSU Inc.

･

日英版しゃべって翻訳

for F (J-E Speech Translation for F)" is trademark of

ATR-Trek.

･

Other company and product names mentioned in this manual are

trademarks or registered trademarks of their respective holders.

･

The abbreviations of operating systems (Japanese versions) below are used

in this manual.

- Windows Vista stands for Windows Vista

(Home Basic, Home Premium,

Business, Enterprise and Ultimate).

F-01B_usugata_1kou_0729

146

Others

- Windows XP indicates the Microsoft

Windows

XP Professional

operating system or Microsoft

Windows

XP Home Edition operating

system.

- Windows 2000 indicates the Microsoft

Windows

2000 Professional

operating system.

･

FeliCa is a contactless IC card technology developed by Sony Corporation.

･

This product contains a module developed by the Independent JPEG Group.

･

The image interpolation technology utilized is FrameSolid, a product of

Morpho, Inc.

･

This product is equipped with the technologies of GestureTek, Inc.

･

学研モバイル国語辞典

(Gakken Mobile JpnDic)", "

学研モバイル和英辞典

(Gakken Mobile JE Dic)", "

学研モバイル英和辞典

(Gakken Mobile EJ Dic)", "

今

日は何の日

(Today's trivia)" and "

今日の歴史

(Today in history)" are

copyrighted by GAKKEN CO., LTD.

･

This product is licensed based on MPEG-4 Visual Patent Portfolio License.

The use of MPEG-4 Video Codec function is allowed for personal and

nonprofit use only in the cases below.

- Recording moving pictures and i-motion that conform to MPEG-4 Visual

Standard (hereinafter referred to as MPEG-4 Video)

- Playing MPEG-4 Videos recorded personally by consumers not engaged in

profit activities

- Playing MPEG-4 Video supplied from the provider licensed from MPEG-LA

For further utilizing such as promotion, in-house use or profit-making

business, please contact MPEG LA, LLC in U.S.

･

Content owners use Windows Media digital rights management technology

(WMDRM) to protect their intellectual property, including copyrights. This

device uses WMDRM software to access WMDRM-protected content. If the

WMDRM software fails to protect the content, content owners may ask

Microsoft to revoke the software's ability to use WMDRM to play or copy

protected content. Revocation does not affect unprotected content. When

downloading licenses for protected content, you agree that Microsoft may

include a "Revocation List" with the licenses. Content owners may require

you to upgrade WMDRM to access their content. If you decline an upgrade,

you cannot access a content that requires the upgrade.

Others

2009.X (1st Edition)

●

If you lose your FOMA terminal or have it stolen, immediately take the steps necessary for suspending the use of the FOMA terminal.

●

If the FOMA terminal you purchased is damaged, bring your FOMA terminal to a repair counter specified by DOCOMO after returning to Japan.

* Unavailable from land-line phones, etc.

Repairs

■

From DOCOMO mobile phones

(In Japanese only)

■

From land-line phones

(In Japanese only)

0120-800-000

(toll free)

(No prefix)

151

(toll free)

●

Please confirm the phone number before you dial.

●

For Applications or Repairs and After-Sales Service, please contact the above-mentioned information center or the docomo shop etc. near you on the NTT DOCOMO website or the i-mode site.

NTT DOCOMO website http://www.nttdocomo.co.jp/english/ i-mode site iMenu⇒お客様サポート (user support)⇒ドコモショップ (docomo Shop) * In Japanese only

* Service available in: English, Portuguese, Chinese, Spanish, Korean.

* Available from mobile phones and PHSs.

General Inquiries <docomo Information Center>

0120-005-250 (toll free)

* You are charged a call fee to Japan when calling from a land-line phone, etc.

※If you use F-01B, you should dial the number ＋81-3-5366-3114 (to enter '＋',

press and hold the '0' key for at least one second).

* You are charged a call fee to Japan when calling from a land-line phone, etc.

※If you use F-01B, you should dial the number ＋81-3-6718-1414 (to enter '＋',

press and hold the '0' key for at least one second).

Failures encountered overseas

Loss or theft of FOMA terminal or payment of cumulative cost overseas

(available 24 hours a day)

■

From DOCOMO mobile phones

(available 24 hours a day)

■

From DOCOMO mobile phones

International call access code for

the country you stay (table 1)

■

From land-line phones <Universal number>

You might be charged a domestic call fee according to the call rate for the country you stay.

※See page

XXX

for international call access codes for major countries (table 1)

and international prefix numbers for the universal number (table 2).

International prefix number for

the universal number (table 2)

■

From land-line phones <Universal number>

-81-3-5366-3114* (toll free) International call access code for

the country you stay (table 1) -81-3-6718-1414* (toll free)

-800-0120-0151*

You might be charged a domestic call fee according to the call rate for the country you stay.

※See page

XXX

for international call access codes for major countries (table 1)

and international prefix numbers for the universal number (table 2).

International prefix number for

the universal number (table 2) -800-5931-8600*

To prevent damage to the

environment, bring used

battery packs to a docomo

service counter, a docomo

agent or a recycle center.

This manual is printed

using an ink based on

soy bean oil.

Don't forget your mobile phone ･･･ or your manners!

When using your mobile phone in a public place, don't forget to

show common courtesy and consideration for others around you.

■

From DOCOMO mobile phones

(In Japanese only)

■

From land-line phones

(In Japanese only)

0120-800-000

(toll free)

(No prefix)

113

(toll free)

* Unavailable from land-line phones, etc.

* Available from mobile phones and PHSs.

Fujitsu F01B Fujitsu F-01B Cellular Phone User Manual F 01B E H1 eps

Fujitsu Limited Fujitsu F-01B Cellular Phone F 01B E H1 eps

Contents

manual part 3

Navigation menu

Namespaces

Views

Navigation
